Pro-weld Stud Welding Catalog h3f17

STUD WELDING EQUIPMENT & ACCESSORIES CATALOG

WWW.PROWELDINTERNATIONAL.COM 129 COMMERCE DR LAGRANGE, OH. 44050 PHONE: (440)-355-6064 FAX: (440)-355-6474

07/01/02

CD WELDING SYSTEMS PART # CD-212 B COLLET SYSTEM WELDER L.D. CD HANDGUN GROUND CABLE, #4X15’

100-0112 200-0015 300-0100 125-0100

CD-212 TAPER BASE SYSTEM WELDER TAPER BASE GUN GROUND CABLE, #4X15’

100-0113 200-0015 300-0101 125-0100

CD-212 GAP GUN SYSTEM WELDER GAP GUN “Y” GROUND CABLE, #2X8’

100-0114 200-0019 300-0700 125-0108

CD-212P B COLLET SYSTEM WELDER L.D. CD HANDGUN GROUND CABLE, #4X15’

100-0117 200-0025 300-0100 125-0100

CD-212P TAPER BASE SYSTEM WELDER TAPER BASE GUN GROUND CABLE, #4X15’

100-0118 200-0025 300-0101 125-0100

CD-312 B COLLET SYSTEM WELDER L.D. CD HANDGUN GROUND CABLE, #4X15’

100-0108 200-0012 300-0100 125-0100

CD-312 TAPER BASE SYSTEM WELDER TAPER BASE GUN GROUND CABLE, #4X15’

100-0109 200-0012 300-0101 125-0100

CD-312 GAP GUN SYSTEM WELDER GAP GUN “Y” GROUND CABLE, #2X8’

100-0115 200-0020 300-0700 125-0108

LIST PRICE CALL FOR YOUR LOCAL DISTRIBUTOR

ALL PRICES SHOWN ARE FOR 110 VAC, 60 HZ SYSTEMS

ALL PRICES ARE F.O.B. FACTORY ALL PRICES SUBJECT TO CHANGE WITHOUT NOTICE PAGE

1

07/01/02

CD WELDING SYSTEMS PART # CD-512 B COLLET SYSTEM WELDER H.D. CD HANDGUN GROUND CABLE, #2X15’(2 REQUIRED)

100-0110 200-0013 300-0200 125-0101

CD-512 TAPER BASE SYSTEM WELDER H.D. TAPER BASE GUN GROUND CABLE, #2X15’(2 REQUIRED)

100-0111 200-0013 300-0201 125-0101

CD-512 GAP GUN SYSTEM WELDER GAP GUN GROUND CABLE, #2X15’(2 REQUIRED)

100-0116 200-0021 300-0700 125-0101

LIST PRICE

ALL PRICES SHOWN ARE FOR 110 VAC, 60 HZ SYSTEMS 110/220 VAC 50/60 HZ SYSTEMS ADD $300.00 TO LIST PRICE ON (CD-312 AND CD-512 ONLY)

SPECIAL WELDING GUNS, UNITS, AND CABLES PART # BANTAM A-58 (ARC WELDING GUN) BANTAM C-2 (CD WELDING GUN #2X16’) BANTAM C-2 (CD WELDING GUN #2X25’) SLIM LINE CD WELDING GUN

LIST PRICE

300-0303 300-0300 300-0301 300-0400

TABLE TOP CD UNIT (WITHOUT WELDER OR FIXTURES)

ALL PRICES ARE F.O.B. FACTORY ALL PRICES SUBJECT TO CHANGE WITHOUT NOTICE

PAGE 2

07/01/02

ARC WELDING SYSTEMS PART # ARC-656 STANDARD SYSTEM WELDER L.D. GUN (25’ LEADS) GROUND 15’ X #2

100-0215 200-0027 300-0802 125-0101

ARC-656 SYSTEM WITH DAMPENER WELDER L.D. GUN (25’ LEADS) W/DAMPENER GROUND 15’ X #2

100-0216 200-0027 300-0803 125-0101

ARC-656 GAS SYSTEM WELDER L.D. SET-LIFT GUN (25’ LEADS) (without gasfoot and gas hose) “Y” GROUND #2 X 15’ GAS FOOT PIECE 25’ GAS HOSE

100-0217 200-0028 300-0804

LIST PRICE

125-0109 BG-3 119-0012

OPTIONAL GAS REGULATOR REGULATOR HOSE 10FT W/FITTINGS

119-0014 119-0015

ARC-800 STANDARD SYSTEM WELDER L.D. ARC GUN GROUND CABLE, 1/OX25’ COMBO CABLE, 1/OX50’

100-0211 200-0026 300-0800 125-0102 125-1000

ARC-800 SYSTEM WITH DAMPENER WELDER L.D. ARC GUN WITH DAMPENER GROUND CABLE, 1/OX25’ COMBO CABLE, 1/OX50’

100-0212 200-0026 300-0801 125-0102 125-1000

ARC-800 PRICE SHOWN IS FOR 208/230/460VAC 60 HZ SINGLE PHASE

ALL PRICES ARE F.O.B. FACTORY ALL PRICES SUBJECT TO CHANGE WITHOUT NOTICE

PAGE

3

07/01/02

ARC WELDING SYSTEMS PART #

LIST PRICE

ARC-1200 L.D SYSTEM WELDER L.D. ARC GUN GROUND CABLE, 1/OX25’ COMBO CABLE, 1/OX50’

100-0208 200-0018 300-0800 125-0102 125-1000

ARC-1200 L.D.SYSTEM WITH DAMPENER WELDER L.D. ARC GUN WITH DAMPENER GROUND CABLE, 1/OX25’ COMBO CABLE, 1/OX50’

100-0209 200-0018 300-0801 125-0102 125-1000

ARC-1200 SYSTEM W/ M.D. GUN WELDER M.D. ARC GUN GROUND CABLE, 1/OX25’ COMBO CABLE, 1/OX50’ 220/380/415 VAC 50 HZ SYSTEMS

100-0213 200-0018 300-0805 125-0102 125-1000 ADD $700.00 TO LIST PRICE

ARC-1850 M.D. GUN SYSTEM WELDER M.D. ARC GUN GROUND CABLE, 1/OX25’ COMBO CABLE, 1/OX50’

100-0214 200-0022 300-0805 125-0103 125-1001

ARC-1850 SINGLE GUN SYSTEM WELDER H.D. ARC GUN GROUND CABLE, 4/OX25’ COMBO CABLE, 4/OX50’

100-0210S 200-0022 300-0900 125-0104 125-1002

ARC-1850 DUAL GUN SYSTEM WELDER H.D. ARC GUN (2 REQUIRED) GROUND CABLE, 4/OX25’ (2 REQUIRED) COMBO CABLE, 4/OX50’ (2 REQUIRED) 220/380/415 VAC 50 HZ SYSTEMS

100-0210D 200-0023 300-0900 125-0104 125-1002 ADD $800.00 TO LIST PRICE

ALL PRICES ARE F.O.B. FACTORY ALL PRICES SUBJECT TO CHANGE WITHOUT NOTICE

PAGE 4

07/01/02

ARC WELDING SYSTEMS PART #

LIST PRICE

ARC-3000 SINGLE GUN SYSTEM WELDER H.D. ARC GUN GROUND CABLE, 4/OX25’ COMBO CABLE, 4/OX50’

100-0207S 200-0016 300-0900 125-0110 125-1002

ARC-3000 DUAL GUN SYSTEM WELDER H.D. ARC GUN (2 REQUIRED) GROUND CABLE, 4/OX25’ (2 REQUIRED) COMBO CABLE, 4/OX50’ (2 REQUIRED) 380/415/440 VAC 50 HZ SYSTEM

100-0207D 200-0017 300-0900 125-0110 125-1002 ADD $1200.00 TO LIST PRICE

ARC 1200/1850/3000 PRICE SHOWN IS FOR 230/460/575VAC 60 HZ THREE PHASE.

ALL PRICES ARE F.O.B. FACTORY ALL PRICES SUBJECT TO CHANGE WITHOUT NOTICE

PAGE

5

FERRULE GRIPS CLOSED FERRULE GRIP (1” LONG) BRASS STUD SIZE 3/16 1/4 5/16 3/8 7/16 1/2 5/8 3/4 7/8 1” 1/8-5/8”

FOOT SIZE SMALL SMALL SMALL SMALL SMALL SMALL MEDIUM MEDIUM LARGE LARGE MEDIUM

GRIP DIA.(D) .305 .380 .445 .505 .585 .650 .785 1.030 1.203 1.406 .930

PART NO. GN-019 GN-025 GN-031 GN-037 GN-043 GN-050 GN-062 GN-075 GN-087 GN-100 037-157

PRICE D

SPLIT FERRULE GRIP (1” LONG) BRASS STUD SIZE 3/16 1/4 5/16 3/8 7/16 1/2 5/8 3/4 7/8 1”

FOOT SIZE SMALL SMALL SMALL SMALL SMALL SMALL MEDIUM MEDIUM LARGE LARGE

GRIP DIA.(D) .305 .380 .445 .505 .585 .650 .785 1.030 1.203 1.406

PART NO. GC-019 GC-025 GC-031 GC-037 GC-043 GC-050 GC-062 GC-075 GC-087 GC-100

PRICE D

LONG SPLIT FERRULE GRIP (2” LONG) BRASS STUD SIZE 1/4 5/16 3/8 7/16 1/2 5/8 3/4

FOOT SIZE SMALL SMALL SMALL SMALL SMALL MEDIUM MEDIUM

GRIP DIA.(D) .380 .445 .505 .585 .650 .785 1.030

PART NO. GD-025 GD-031 GD-037 GD-043 GD-050 GD-062 GD-075

PRICE D

***ADD $1.00 FOR COPPER GRIPS***

PAGE

6

CHUCKS

ADJUSTABLE CHUCKS STUD DIA. 2MM (.079) #2 12 GA & #4 1/8 & #5 10 GA & #6 4MM (.155) #8 #10 & 5MM (.196) 6MM (.236) .215 .330 1/4 5/16 8MM 3/8 10MM (.390) 7/16 12MM (.472) 1/2 14MM (.551) 9/16 5/8 16MM .680 18MM (.708) 3/4 7/8 20MM 1”

PART NO. CN-002M CN-008 CN-010 CN-012 CN-013 CN-004M CN-015 CN-018 CN-006M CN-021 CN-033 CN-025 CN-031 CN-008M CN-037 CN-010M CN-043 CN-012M CN-050 CN-014M CN-056 CN-062 CN-016M CN-068 CN-018M CN-075 CN-087 CN-020M CN-100

PRICE

2-1/2”

2-1/2”

3”

*** ADD $12.00 FOR BERYLLIUM CHUCKS — ONLY AVAILABLE IN SIZES UP TO 1/2” SPECIAL DIAMETER NON-STANDARD 1/2” AND UNDER

PAGE 7

LONG AND RECTANGULAR CHUCKS

3-7/8” LONG ADJUSTABLE CHUCKS STUD SIZE #6 #8 #10 & 5MM 6 MM 1/4 5/16 8MM .330 3/8 10MM 7/16 12MM 1/2 9/16 5/8 3/4

PART NO. CM-013 CM-015 CM-018 CM-006M CM-025 CM-031 CM-008M CM-033 CM-037 CM-010M CM-043 CM-012M CM-050 CM-056 CM-062 CM-075

PRICE

3-7/8”

SIZES CM-025 AND UNDER ARE BERYLLIUM

4-3/4” EXTRA LONG ADJUSTABLE CHUCKS STUD SIZE #6 #8 #10 1/4 5/16 3/8 7/16 1/2 5/8 3/4

PART NO. CL-013 CL-015 CL-018 CL-025 CL-031 CL-037 CL-043 CL-050 CL-062 CL-075

PRICE

4-3/4”

SIZES CL-025 AND UNDER ARE BERYLLIUM

RECTANGULAR CHUCKS STUD SIZE 1/8 X 1/4 1/8 X 3/8 1/8 X 5/8 1/8 X 7/8 1/8 X 1” 1/4 X 3/4

PART NO. CR-CA CR-CB CR-CC CR-CH CR-CE CR-CF

PRICE

3”

PAGE

8

HEADED STUD CHUCKS 3/8 DIA. HEADED ANCHOR CHUCK (3/4” DIA. HEAD) PART NO. CH-037 CH-037-1 CH-037-2 CH-037-3 SCREWS

DESCRIPTION COMPLETE ASSY. SLEEVE ONLY BASE ONLY STOP SCREW 10-32 X 3/8

PRICE

1/2 DIA. HEADED ANCHOR CHUCK (1” DIA. HEAD) PART NO. CH-050 CH-050-1 CH-050-2 CH-050-3 SCREWS

DESCRIPTION COMPLETE ASSY. SLEEVE ONLY BASE ONLY STOP SCREW 10-32 X 3/8

PRICE

3-1/2”

5/8 & 3/4 DIA. HEADED ANCHOR CHUCK (1-1/4” DIA. HEAD) PART NO. CH-075 CH-075-1 CH-075-2 CH-075-3 SCREWS

DESCRIPTION COMPLETE ASSY. SLEEVE ONLY BASE ONLY STOP SCREW 10-32 X 1/2

PRICE

7/8 DIA. HEADED ANCHOR CHUCK (1-3/8” DIA. HEAD) PART NO. CH-087 CH-087-1 CH-087-2 CH-075-3 SCREWS

DESCRIPTION COMPLETE ASSY. SLEEVE ONLY BASE ONLY STOP SCREW 10-32 X 1/2

PRICE

3-1/4”

1” DIA. HEADED ANCHOR CHUCK (1-5/8 DIA. HEAD) PART NO. CH-100 CH-100-1 CH-100-2 CH-075-3 SCREWS

PAGE 9

DESCRIPTION COMPLETE ASSY. SLEEVE ONLY BASE ONLY STOP SCREW 10-32 X 1/2

PRICE

SPECIAL CHUCKS LEGS Y ANCHOR CHUCKS

ANCHOR SIZE 3/16 1/4 5/16

BENT STUD CHUCK

PART NO. CY-018 CY-025 CY-031

PRICE

ARC STUD WELDING LEGS

STUD DIA. 3/8 3/8 1/2 1/2 5/8 5/8 3/4 3/4

BEND 90 deg 45 deg 90 deg 45 deg 90 deg 45 deg 90 deg 45 deg

PART NO. CB-037-90 CB-037-45 CB-050-90 CB-050-45 CB-062-90 CB-062-45 CB-075-90 CB-075-45

PRICE

MALE CHUCKS

L

LENGTH DIA. 7” 5/16 9” 5/16 14” 5/16 18” 5/16 7” 3/8 9” 3/8 14” 3/8 18” 3/8 24” 3/8 27” 3/8 32” 3/8 36” 3/8 48” 3/8 5/16 LEG WASHER 5/16 LEG SCREW 3/8 LEG WASHER 3/8 LEG SCREW

PART NO. L-03107 L-03109 L-03114 L-03118 L-03707 L-03709 L-03714 L-03718 L-03724 L-03727 L-03732 L-03736 L-03748 L-031-1 L-031-2 L-037-1 L-037-2

PRICE 2-1/2”

HOLE SIZE 8/32 10-24 10-32 1/4-20 5/16-18 3/8-16 1/2-13 5/8-11 3/4-10 1/4 3/8 1/2 5/8

PART NO. CX-008-32 CX-010-24 CX-010-32 CX-025-20 CX-031-18 CX-037-16 CX-050-13 CX-062-11 CX-075-10 CX-025 CX-037 CX-050 CX-062

PRICE

PAGE

10

WELD THRU DECK ACCESSORIES WELD THRU DECK FERRULE HOLDER WELD THRU DECK FOOT ASSEMBLY

PART NO. B-0021 B-0021-1 B-0021-2 B-0021-3

DESCRIPTION FOOT ASSY. FOOT ONLY EXTENSION BAR 1/4-20 X 1 SCREWS

PRICE

REFACTORY FERRULE FOOT PLATE

PART NO. B-0060-1 B-0060-2 B-0060-3 B-0060-4 B-0060-5

DESCRIPTION 3/4 WTD/7/8 FLAT 3/4 FLAT 5/8 FLAT 1” FLAT 1/2 FLAT

PRICE

HEAVY DUTY FERRULE GRIP

DIA.

PART NO. QY-025-1 QY-025-2 QY-025-3

PAGE 11

NECK DIA. .810 .930 1.030

PRICE

PART NO. GH-050 GH-062 GH-075 GH-087 GH-100

STUD DIA. 1/2 5/8 3/4 7/8 1

PRICE

CLOSED FEET

B-1N

B-2N

B-6N/B-7N

B-3N

B-4N/B-5N

028-833

STANDARD CLOSED FEET

GUN TYPE

STUD SIZE

PART NO.

PRO-WELD INT. NELSON NS-20 NELSON NS-30 PRO-WELD INT. NELSON NS-20 NELSON NS-30 PRO-WELD INT. NELSON NS-20 BANTAM A-58 BANTAM A-58 PRO-WELD INT.

1/8-1/2 1/8-1/2 1/8-1/2 5/8-3/4 5/8-3/4 5/8-3/4 7/8-1” 7/8-1” 1/8-1/2 5/8-3/4 1/8-3/8

B-1N B-1N B-6N B-2N B-2N B-7N B-3N B-3N B-4N B-5N 028-833

PRICE

PAGE

12

SPLIT FEET

B-1C

B-3C

B-2C

B-6C/B-7C

B-4C/B5C

B-4CR/B-5CR

STANDARD SPLIT FEET

PAGE 13

GUN TYPE

STUD SIZE

PART NO.

PRO-WELD INT. NELSON NS-20 NELSON NS-30 PRO-WELD INT. NELSON NS-20 NELSON NS-30 PRO-WELD INT. NELSON NS-20 BANTAM A-58 BANTAM A-58 BANTAM C-2 BANTAM C-2

1/8-1/2 1/8-1/2 1/8-1/2 5/8-3/4 5/8-3/4 5/8-3/4 7/8-1” 7/8-1” 1/8-1/2 5/8-3/4 1/8-1/2 5/8-3/4

B-1C B-1C B-6C B-2C B-2C B-7C B-3C B-3C B-4C B-5C B-4CR (RECESSED) B-5CR (RECESSED)

PRICE

SPECIAL FEET AND FERRULE PLATES

SPLIT BI-POD FEET STUD SIZE 1/8-1/2 5/8-3/4 7/8-1”

PART NO. BP-1C BP-2C BP-3C

PRICE

CLOSED BI-POD FEET STUD SIZE 1/8-1/2 5/8-3/4 7/8-1”

PART NO. BP-1N BP-2N BP-3N

PRICE

**NOTE: PLEASE SPECIFY GUN TYPE**

TWIN LEG FERRULE FOOT PLATE STUD SIZE 1/4 5/16 3/8 1/2 5/8 3/4 7/8 1”

PART NO. QN-025 QN-031 QN-037 QN-050 QN-062 QN-075 QN-087 QN-100

PRICE

**NOTE: PLEASE SPECIFY GUN TYPE**

SINGLE LEG FERRULE FOOT PLATE STUD SIZE 1/4 3/8 1/2 5/8 3/4 7/8

PART NO. QM-025 QM-037 QM-050 QM-062 QM-075 QM-087

PRICE

PAGE

14

SPECIAL ACCESSORIES FERRULE TUBING STUD SIZE #8 #10 1/4 5/16 3/8 7/16 1/2 5/8 3/4

PART NO. MP-015 MP-018 MP-025 MP-031 MP-037 MP-043 MP-050 MP-062 MP-075

I.D. .291 .305 .380 .445 .505 .585 .650 .785 1.030

O.D. .360 .375 .500 .562 .625 .687 .750 .906 1.156

L 36” 36” 36” 36” 36” 36” 36” 36” 36”

I.D. .360 .375 .500 .562 .625 .687 .750 .906

O.D. .875 .875 .875 .875 .875 .875 .875 1.156

PRICE

PRICE

O.D.

L

I.D.

FERRULE TUBE BUSHING STUD SIZE #8 #10 1/4 5/16 3/8 7/16 1/2 5/8

PART NO. MB-015 MB-018 MB-025 MB-031 MB-037 MB-043 MB-050 MB-062

1/2” O.D.

I.D.

GAS ADAPTOR FEET FOR ALUMINUM WELDING SPECIFY GUN TYPE WHEN ORDERING

PART NO. BG-1 PRICE: USE WITH FERRULE NELSON #751-929-999

PART NO. BG-2 PRICE: USE WITHOUT FERRULE NELSON P/N #751-022-000 FOOT ONLY BG-2-1 SPARK SHIELD ONLY BG-2-2 VALVE ASSY. BG-2-3

PAGE 15

PART NO. BG-3 PRICE: USE W/ARC-656 GAS UNIT FOOT ONLY SPARK SHIELD ONLY HOSE CONNECTOR GAS HOSE (not shown)

BG-3-1 BG-3-2 119-0010 119-0012

CAPACITOR DISCHARGE ACCESSORIES “B” COLLETS STUD DIA 3 MM 14 GA 12 GA & #4 1/8 GA & #5 10 GA & #6 4 MM #8 #10 5 MM 6 MM .215 1/4 5/16 8 MM 3/8 10 MM

PART NO. CDB-003M CDB-008 CDB-010 CDB-012 CDB-013 CDB-004M CDB-015 CDB-018 CDB-005M CDB-006M CDB-021 CDB-025 CDB-031 CDB-008M CDB-037 CDB-010M

PRICE

3/8 DIA 1-3/8

“B” COLLETS AGM STYLE STUD DIA. 14 GA 12 GA #6 #8 #10 1/4

PART NO. CDB-008A CDB-010A CDB-013A CDB-015A CDB-018A CDB-025A

PRICE

PART NO. CDBS-013 CDBS-004M CDBS-015 CDBS-018 CDBS-005M CDBS-006M CDBS-025 CDBS-031

PRICE

3/8 DIA. 1-3/16

SOYER COLLETS STUD DIA. #6 4 MM #8 #10 5 MM 6 MM 1/4 5/16

.390

1.781

PAGE

16

CAPACITOR DISCHARGE ACCESSORIES

ONE PIECE /MAGNETIC CHUCK PART NO. 039-613

PRICE

MAGNETIC CHUCK PART NO. 035-301 017-633 029-615 039-609 039-610 SCREW

DESCRIPTION COMPLETE ASSY MAGNET ONLY CONDUCTOR PLATE INSUL. TUBE INSUL. DISC 10-32 X 7/8

PRICE

“B” COLLETS PROTECTOR STUD SIZE 14 GA X 12 GA 10 GA BODY ONLY 12 GA INSERT 10 GA INSERT

PART NO. 028-837 028-838 028-836 028-834 028-835

PRICE

“B” STOP STUD LENGTH 1/4 3/8 1/2 5/8 3/4 7/8 1” 1-1/8 1-1/4 1-3/8 (BUTTON STOP) UNIVERSAL

PAGE 17

STOP LENGTH 1-1/4 1-1/8 1” 7/8 3/4 5/8 1/2 3/8 1/4 1/8

PART NO. 033-781 033-782 033-783 033-784 033-785 033-775 033-776 033-777 033-778 033-779 033-780

PRICE SHORT BUTTON STOP

UNIVERSAL “B” STOP

CAPACITOR DISCHARGE ACCESSORIES COLLETS INSERTS FOR WELD STUDS COLLETS INSERTS FOR WELD PINS

1/4 DIA 1-3/4”

STUD DIA. X DEPTH #4 X 1/4 #4 X 3/8 #4 X 1/2 #4 X 1” #6X 1/4 #6 X 3/8 #6 X 1/2 #6 X 5/8 #6 X 3/4 #6X 1” 10GA X 1/2 10GA X 3/4 10GA X 1 #8X 1/4 #8 X 3/8 #8 X 1/2 #8 X 5/8 #8 X 3/4 #8X 1” #10 X 1/4 #10 X 3/8 #10 X 1/2 #10 X 5/8 #10 X 3/4 #10X 1” 1/4 X 1/4 1/4 X 3/8 1/4 X 1/2 1/4 X 5/8 1/4 X 3/4 1/4 X 1” 5/16 X 3/8 5/16 X 1/2 5/16 X 5/8 5/16 X 3/4 5/16 X 1” 3/8 X 1/2 3/8 X 3/4 3/8 X 1”

PART NO. CI-010-025 CI-010-037 CI-010-050 CI-010-100 CI-013-025 CI-013-037 CI-013-050 CI-013-062 CI-013-075 CI-013-100 CI-014-050 CI-014-075 CI-014-100 CI-015-025 CI-015-037 CI-015-050 CI-015-062 CI-015-075 CI-015-100 CI-018-025 CI-018-037 CI-018-050 CI-018-062 CI-018-075 CI-018-100 CI-025-025 CI-025-037 CI-025-050 CI-025-062 CI-025-075 CI-025-100 CI-031-037 CI-031-050 CI-031-062 CI-031-075 CI-031-100 CI-037-050 CI-037-075 CI-037-100

PRICE

STUD DIA. X DEPTH 12GA X 1/2 12GA X 3/4 12GA X 1” 10GA X 1/2 10GA X 3/4 10GA X 1”

PART NO. CIP-010-050 CIP-010-075 CIP-010-100 CIP-014-050 CIP-014-075 CIP-014-100

PRICE

STANDARD SPARK SHIELD

STUD RANGE 14 GA – #6 #8 – 3/8

PART NO. 033-764 033-765

PRICE

VENTED SPARK SHIELD

STUD RANGE 14 GA – 10 GA #6 – 3/8

PART NO. 033-769 033-769L

PRICE

TEMPLATE TUBE ADAPTOR

TEMPLATE I.D. 1” DIA. 1-1/4” DIA.

PART NO. 039-839 039-840

PRICE

PAGE

18

NELSON & KSM COLLETS NELSON STYLE COLLETS

3/8”DIA.

2-3/8”

STUD SIZE #6 #8 #10 1/4 5/16 4 MM 6 MM 12 GA

PART NO. CDBN-013 CDBN-015 CDBN-018 CDBN-025 CDBN-031 CDBN-004M CDBN-006M CDBN-010

NELSON # 500-001-356 500-001-357 500-001-366 500-001-359 500-001-360 500-001-361 500-001-362 500-001-363

PRICE

NELSON ADJ. STOPS FOR ABOVE

STUD LENGTH 1/4 TO 5/8 3/4 TO 1-1/8 1-1/4 TO 1-5/8 1-3/4 TO 2-1/8 INSULATOR ONLY

PART NO. 500-017-017 500-017-018 500-017-019 500-017-020 500-017-025

PRICE

KSM / ERICO AIR COLLET 7/16

1-1/2”

BOTTOM LOAD STUD DIA PART NO. #4 (.112) 016-412 #6 (.138) 016-415 #8 (.164) 016-416 #10 (.189) 004-684 1/4 (.250) 016-418

RAM FEED .PRICE

STUD DIA PART NO. #4 (.112) 025-016 #6 (.138) 025-017 #8 (.164) 025-018 #10 (.189) 025-019 1/4 (.250) 025-020

NON-STOCK ITEM / ALLOW 2 WEEKS FOR DELIVERY PAGE 19

.PRICE

ADAPTORS

B-CI ADAPTOR

K-B ADAPTORS 1/4-20

3/8 DIA 1/4 DIA

3/8 DIA

L

1-3/4

PART NO. 044-082 7/8 LONG 033-746 1-9/16 LONG

PRICE PART NO. 039-464

B-N ADAPTOR

PRICE

K-N ADAPTORS 1/4-20 ARC TAPER

ARC TAPER

1-7/8

2-3/8

PART NO. 039-468

PRICE

PART NO. 033-750

PRICE

ADAPTORS MISCELLANEOUS ADAPTORS ARC TAPER

PART NO. MT-0008

DESCRIPTION TEMPLATE TUBE 1/4-1/2 ARC STUDS

MT-0012

TEMPLATE TUBE 5/8-3/4 ARC STUDS

033-505L

L-TEC CHUCK ADAPTOR

033-749

K-CI ADAPTORS

751-458-049

NS-30 CHUCK ADAPTORS

I.D.

PRICE

L

PART NO. 044-083 N-B 044-084 N-CI

I.D. 3/8 ID 1/4 ID

PRICE

THREADED TAPERED ADAPTORS

PART NO. MT-0003

PRICE

PAGE

20

WELD CABLE CONNECTORS

HEAVY DUTY HI TEMP CONNECTOR

PART NO. 107-0006 107-0006-1 107-0006-2

DESCRIPTION 4/O (M) HI TEMP 4/O (M) SLEEVE 4/O BRASS ONLY

107-0007-MF HI TEMP PIN COPPER WRAP SET SCREW 1/2-20 X 1/2

PRICE

PART NO. 107-0007 107-0007-1 107-0007-2

DESCRIPTION 4/O (F) HI TEMP 4/O (F) SLEEVE 4/O BRASS ONLY

(FITS (M) OR (F) )

LIGHT DUTY CONNECTOR

PART NO. 107-0010 107-0011 107-0012

PAGE 21

DESCRIPTION 1/O (M) FIBER SHELL 1/O (F) FIBER SHELL #4 (M) FIBER SHELL

PRICE

PRICE

CONTROL CABLE CONNECTORS

CONTROL CABLE CONNECTOR

PART NO. 107-0014 107-0015 107-0001

DESCRIPTION MALE 4 POLE CONNECTOR FEMALE 4 POLE CONNECTOR MOUNT CONNECTOR

PRICE

HUBBELL STYLE CONNECTOR

NELSON 2-WIRE (M)

PART NO. 107-0016 107-0017 107-0018 107-0019 107-0020 107-0030 107-0032 107-0031

MOUNT

PROWELD HUBBELL (M)

DESCRIPTION NELSON 2-WIRE (M) NELSON 2-WIRE (F) NELSON 2-WIRE ( MOUNT) (M) RUBBER COVER (F) RUBBER COVER PROWELD HUBBELL (M) PROWELD HUBBELL (F) PROWELD HUBBELL ( MOUNT)

PRICE

PAGE

22

MOUNT CAMLOK CONNECTORS

PART NO. 107-0003 107-0002

DESCRIPTION MALE MOUNT FEMALE MOUNT

PRICE

WELD CABLE LUGS

PART NO. 123-0003 123-0001 123-0006 123-0002 123-0008 123-0009 123-0013 123-0010

DESCRIPTION #4 W/#10 HOLE #1 W/#10 HOLE #1 W/1/4 HOLE #1 W/3/8 HOLE 1/O W/3/8 HOLE 1/O W/1/2/ HOLE 4/O W/3/8 HOLE 4/O W/1/2/ HOLE

PRICE

ACCESSORIES

PART NO. 102-0041 102-0042 PAGE 23

DESCRIPTION ALLEN WRENCH SET CHUCK EJECTOR KEY

PRICE

LIGHT DUTY CD WELDING GUN PART # 300-0100

ITEM DESCRIPTION 1 2

3 4 5 6 7 8 9 10 11 12

PART NO.

REAR CAP MAIN SPRING SILVER BLACK SPRING RED SPRING COPPER SPRING SHAFT BEARING GUN SHAFT

033-384 001-800 001-801 001-802 033-387 033-610 033-799

8-32 X 3/4 CAP SCREW

033-016

TRIGGER SPRING

033-382 049-995 033-383 033-404 033-381 036-496 033-662-25

10-32 X 3/16 SET SCREW

CABLE CLAMP TRIGGER SWITCH TRIGGER BUTTON SHAFT BLOCK #4 WELD CABLE ASSY (25FT)

LIST

ITEM 13 14 15 16 17 18 19 20 21 22 23

DESCRIPTION

PART NO.

CONTROL CABLE 25’ STRAIN RELIEF BOOT GUN BODY ASSY SHAFT BELLOWS BOOT RETAINING RING FACE PLATE ASSY SHAFT BOOT SNAP RING WELD PIGTAIL ASSY

033-658-25 001-181 033-881 033-445 033-447 033-665 033-446 033-608 018-375 016-876 033-757 033-757 028-833

10-32 X 3/4 PAN HEAD SCREW 10-32 X 1/2 PAN HEAD SCREW

5/16 X 7” LEG ASSY 5/16 X 12” LEG ASSY FOOTPIECE MED. CLOSED

LIST

PAGE 24

PRECISION LIGHT DUTY CD WELDING GUN PART # 300-0102

ITEM DESCRIPTION 1 2 3 4 5 6 7 8 9 10 11 12

PAGE 25

REAR CAP MOLDED BUSHING BEARING ASSEMBLY SHAFT TUBE #8-32 X 3/4” HEAD CAP SCREW

TRIGGER SPRING #10-32 X 3/16” HEAD STE SCREW

WELD PIGTAIL TRIGGER SWITCH TRIGGER BUTTON MOLDED

SHAFT BLOCK WELD CABLES 25’ #4

PART NO. 036-473SW 033-467SW 033-610SW 033-799 033-016 033-382 049-995 033-608

033-404 033-381SW 036-496SW 033-662-25

LIST

ITEM 13 14 15 16 17 18 19 20 21 22 23 24

DESCRIPTION CONTROL CABLE 25’

PART NO.

033-658SW 033-465SW SHAFT BOOT 033-445 SHAFT BOOT RETAINING RING 033-447 FACEPLATE 033-665 SHAFT PLUG 033-468 INSERT-REAR CAP SPACER 033-469 MAIN SPRING SILVER 001-800 SHAFT BOOT SNAP RING 033-446 #10-32 X 3/4” SCREW 018-375 7” X 5/16 STD. ADJ. LEG 033-757 FOOTPIECE MED. CLOSED 028-833 GUN BODY (2 PCS MACHINED)

LIST

PRECISION HEAVY DUTY CD WELDING GUN PART # 300-0202

ITEM DESCRIPTION 1 2 3 4 5 6 7 8 9 10 11 12

REAR CAP MOLDED BUSHING BEARING ASSEMBLY SHAFT TUBE #8-32 X 3/4” HEAD CAP SCREW

TRIGGER SPRING #10-32 X 3/16” HEAD STE SCREW

HEAVY DUTY PIGTAIL TRIGGER SWITCH TRIGGER BUTTON MOLDED

SHAFT BLOCK WELD CABLES 25’ #2

PART NO. 036-473SW 033-467SW 033-610SW 033-799 033-016 033-382 049-995 033-608SW

033-404 033-381SW 037-129SW 033-662-25H

LIST

ITEM 13 14 15 16 17 18 19 20 21 22 23 24

DESCRIPTION

PART NO.

LIST

CONTROL CABLE 25’

033-658SW 033-465SW SHAFT BOOT 033-445 SHAFT BOOT RETAINING RING 033-447 FACEPLATE 033-665 SHAFT PLUG 033-468 INSERT-REAR CAP SPACER 033-469 MAIN SPRING BLACK 001-801 SHAFT BOOT SNAP RING 033-446 #10-32 X 3/4” SCREW 018-375 7” X 5/16 STD. ADJ. LEG 033-757 FOOTPIECE MED. CLOSED 028-833 GUN BODY (2 PCS MACHINED)

PAGE 26

SLIM-LINE CD WELDING GUN PART # 300-0400

ITEM DESCRIPTION 1 2 3 4 5 6 7 8 9 10 11 12

PAGE 27

GUN BODY GUN SHAFT MAIN SPRING SPACER NYLON SLUG SWITCH PLATE SWITCH ASSY END CAP 10-32 X 1” SCREW CONTROL CABLE ASSY

WELD CABLE ASSY 10-32 X 3/8 SET SCREW (2)

PART NO. 033-457 033-458 033-464 048-312 048-314 048-313 031-196 033-463 015-680 036-900 033-663 034-477

LIST

C-2 BANTAM CD WELDING GUN PART # 300-0301

ITEM DESCRIPTION 1 2 3 4 5 7 8 9 9A 9B 10 11

BELLOWS RETAINER BELLOWS

PART NO. 001-816 003-499

10-24 X 1/2 SOCKET CAP SCREW FACE PLATE ASSY (TWIN LEG)

5/16-18 X 1-3/4 SET SCREW SPINDLE ASSY (TAPERED CHUCK)

GUN BODY MAIN SPRING SILVER MAIN SPRING BLACK MAIN SPRING RED SPRING PLUG BACK CAP

003-500 016-405 015-805 016-383 001-800

001-801 001-802 022-357 015-803

LIST

ITEM 12 13 14 15 16 17 18 19 20 21 22 23

DESCRIPTION

PART NO.

LIST

10-24 X 3/4 SOCKET CAP SCREW

HANDLE COVER WELD CABLE ASSY (25FT) CONTROL CABLE ASSY (25FT)

HANDLE POST NUT TRIGGER SWITCH

016-384 015-793-25 015-809-25 002-906 015-807

5-40 X 5/8 PAN HEAD SCREW

TRIGGER BUTTON

006-586

5/16-24 X 5/16 SET SCREW

FACE PLATE BUSHING 003-501 INTERNAL WELD CABLE 602-056B CABLE MOUNTING LUG 029-039

PAGE 28

A-58 BANTAM LIGHT DUTY ARC WELDING GUN PART # 300-0303

ITEM DESCRIPTION 1 2 3 4 5 6 7 8 9 10 11 12 13

PAGE 29

BELLOWS RETAINER BELLOWS

PART NO. 001-816 003-499

10-24 X 1/2 SOCKET CAP SCREW

FACE PLATE ASSY 5/16-18 X 1-3/4 SET SCREW

SPINDLE ASSY GUN BODY LIFTING ASSY SPLIT WASHER SOLENOID SPRING SOLENOID BACK CAP 10-24 X 3/4 SOCKET SET SCREW

003-500 016-405 015-792 016-383 015-791

001-332 001-337 015-797 015-803

LIST

ITEM 14 15 16 17 18 19 20 21 22 23 25 26

DESCRIPTION

PART NO.

HANDLE COVER

016-384 015-793 015-809 002-480 002-906 015-807

WELD CABLE ASSY (10FT) CONTROL CABLE ASSY (10FT)

WIRE NUTS HANDLE POST NUT TRIGGER SWITCH 5-40 X 5/8 PAN HEAD SCREW 5/16-24 X 5/16 SET SCREW

TRIGGER BUTTON FACE PLATE BUSHING SPACER 6-32 X 1/2 SOCKET CAP SCREW

006-586 003-501 023-356

LIST

LIGHT DUTY ARC WELDING GUN PART # 300-0500

**** PARTS AVAILABLE ONLY **** ITEM DESCRIPTION 1 2 3

6 7 8 9 10 11 12 14 15 16 17 18 19 20 21

GUN BODY ASSY HANDLE COVER REAR CAP COIL ASSY REAR COIL YOKE LIFT ADJ. SCREW ARMATURE ASSY ARMATURE SPRING LIFTING RING LIFTING RING SPRING LIFTING RING STOP MAIN SPRING LIFTING ROD CHUCK ADAPTOR CONNECTOR STUD EXTENSION SHAFT WELD CABLE ASSY CONTROL CABLE ASSY STRAIN RELIEF TRIGGER BUTTON TRIGGER SPRING

PART NO. 034-868 033-513 033-493 044-021 033-720 033-510 043-889

LIST

ITEM 22 22B 22C 23 24 25

PART NO.

FRONT CAP ASSY FRONT SEAL FRONT BEARING TRIGGER SWITCH TRIGGER PIN EXT. BAR ASSY EXTENSION BAR

039-051 033-492 033-491 033-377 037-175 033-477 033-471

LIST

8-32 X 1/2 CAP SCREW

033-502

033-501 033-503 033-500 033-504 034-870 033-505 033-506 033-507 036-904 036-897 036-897-1 033-514 033-509

DESCRIPTION

26 27 28 29 30 32 34 35 36 37 38 39

CABLE CLAMP END CAP NUT 5/16-18 X 3/8 SCREW #10-32 X 3/8 SCREW #10-32 X 7/8 SCREW 8-32 X 5/8 PAN HEAD SCREW

WIRE NUT 3/8 X 9” LEG SMALL SPLIT FOOT LEG WASHER 1/4-20 X 1-1/4” SCREW

WELD CABLE BOOT BELLOWS

033-486 033-481 037-557 037-563 037-530 037-521 042-790 L-03709 B-1C L-037-1 L-037-2 036-904-1 033-512 PAGE 30

HEAVY DUTY ARC WELDING GUN PART # 300-0600

**** PARTS AVAILABLE ONLY **** ITEM DESCRIPTION 1 2 3 4 4A 4B 4C 5 5A 5B 5C 5D 5E 6 7 8 9 10 11 12 13 14 15 16 PAGE 31

PART NO.

CHUCK ADAPTOR CONNECTOR STUD BELLOWS FRONT CAP ASSY FRONT SEAL FRONT BEARING DAMPENING VALVE SHAFT EXT. ASSY

033-505 033-506 033-512 039-052 033-488 033-491 033-489

SHAFT RETAINING RING

033-495 033-496 033-497 033-498 033-499 033-494 034-870 033-504 033-503 033-502 044-021 033-720 033-493 037-521 037-563 037-557

EXPANDER BACKING RING PISTON CUP SEAL EXTENSION SHAFT FRONT CAP INSERT LIFTING ROD ASSY MAIN SPRING LIFTING RING SPRING ARMATURE SPRING COIL ASSY REAR COIL YOKE REAR CAP 8-32 X 5/8 PAN HEAD SCREW 10-32 X 3/8 SET SCREW 5-16-18 X 3/8 SET SCREW

033-618

LIST

ITEM 18 20 21 22 23 24 25 26 28 29

DESCRIPTION

PART NO.

LIFT ADJ. SCREW ARMATURE ASSY LIFTING RING LIFTING RING STOP WIRE NUT HANDLE COVER

033-510 043-889 033-501 033-500 042-790 033-513 037-530 036-897 036-897-1 044-059 033-477 033-471 033-486

10-32 X 7/8 SCREW CONTROL CABLE ASSY

STRAIN RELIEF BOOT WELD CABLE ASSY EXT. BAR ASSY EXTENSION BAR CABLE CLAMP 8-32 X 1/2 CAP SCREW

31 32 33 34 35 36 37 38 39 40

TRIGGER SWITCH TRIGGER SPRING

033-377 033-509 TRIGGER PIN 3/32 X 5/8 037-175 TRIGGER BUTTON 033-514 END CAP NUTS 033-482 LEG ASSY 3/8 X 14” L-03714 MEDIUM SPLIT FOOT B-2C LEG WASHERS L-037-1 LEG SCREW 1/4-20 X 1-1/4 L-037-2 PLUNGE DAMP. ASSY 033-619

LIST

HEAVY DUTY ARC WELDING GUN PART # 300-0601

**** PARTS AVAILABLE ONLY **** ITEM DESCRIPTION 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18

CHUCK ADAPTOR CONNECTOR STUD SHAFT EXTENSION BELLOWS END CAP NUTS FRONT BEARING FRONT CAP ASSY FRONT SEAL DAMPER HOUSING O-RING SPRING RETURN DAMPER

LIFTING ROD ASSY MAIN SPRING LIFT STOP HOUSING LIFTING RING MOVEABLE CORE CORE SPRING TRIGGER BUTTON TRIGGER SPRING

PART NO. 033-505 033-506 033-507 301-0018 033-482 033-491 301-0002 033-488 301-0020 102-0115 301-0021 301-0003A 301-0017 301-0019 301-0014 301-0013 301-0012 033-514 033-509

LIST

ITEM 19 20 21 22 23 24 25 26 27 28 29 30 31

DESCRIPTION

PART NO.

5/16 X 3/8 SET SCREW

037-557 033-486 044-059 044-059-1 033-471 033-477 033-377 036-897 036-897-1 037-530 033-513 301-0001 301-0009 105-0024 102-0117 301-0016 115-0010 301-0008 033-493 037-521

CABLE CLAMP WELD CABLE ASSY WELD CABLE BOOT EXT. BAR EXT.BAR ASSY TRIGGER SWITCH CONTROL CABLE ASSY STRAIN RELIEF BOOT 10-32 X 7/8 OVAL HEAD SCREW

HANDLE COVER GUN BODY COIL YOKE BEARING GUN COIL WAVE WASHER REAR COIL YOKE 8-32 X 1/4 SET SCREW

32 33 34

ADJUSTABLE CORE REAR CAP 8/32 X 5/8 PAN HEAD SCREW

LIST

PAGE 32

LIGHT DUTY ARC WELDING GUN PART # 300-0800

ITEM DESCRIPTION 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16

PAGE 33

CHUCK ADAPTER BELLOW NUT, END CAP FRONT CAP, L.D. BEARING LIFTING ROD ASM. SPRING, MAIN SCREW , #8-32 X 3/8 WASHER LIFT STOP HOUSING LIFTING RING MOVEABLE CORE SPRING, CORE GUN BODY COIL YOKE BEARING COIL, GUN

PART NO. 302-0026 302-0014 033-481 302-0004 033-491 302-0012 302-0017 115-0011

302-0025 301-0019 301-0014 301-0013 301-0012 302-0001 301-0009 105-0024

LIST

ITEM 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31

DESCRIPTION

PART NO.

WAVE WASHER YOKE, REAR COIL ADJUSTABLE CORE REAR CAP SCREW, #8-32 X 3/4 PAN HD TRIGGER BUTTON SNAP RING SPRING, TRIGGER TRIGGER SWITCH ASM

102-0117 301-0016 301-0008 033-493 037-521 302-0013 302-0023 302-0016 302-0010 115-0009 302-0009 037-557 115-0010 302-0028 302-0029

SCREW, #10-32 X 1/2 OVAL

HANDLE COVER SCREW, 5/16-18 X 3/8 SET SCREW, #8-32 X 1/4 SET

CONTROL CABLE ASM WELD CABLE ASM

LIST

LIGHT DUTY ARC WELDING GUN PART # 300-0801

ITEM 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17

DESCRIPTION

PART NO.

CHUCK ADAPTER BELLOW NUT, END CAP FRONT CAP, BEARING LIFTING ROD ASM. SPRING, MAIN SCREW , #8-32 X 3/8 DAMPER STOP LIFT STOP HOUSING LIFTING RING MOVEABLE CORE SPRING, CORE GUN BODY COIL YOKE BEARING COIL, GUN WAVE WASHER

302-0026 302-0014 033-481 302-0003 033-491 302-0012 302-0017 115-0011

302-0021 301-0019 301-0014 301-0013 301-0012 302-0001 301-0009 105-0024 102-0117

LIST

ITEM 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33

DESCRIPTION

PART NO.

LIST

YOKE, REAR COIL ADJUSTABLE CORE REAR CAP SCREW, #8-32 X 3/4 PAN HD TRIGGER BUTTON SNAP RING SPRING, TRIGGER TRIGGER SWITCH ASM

301-0016 301-0008 033-493 037-521 302-0013 302-0023 302-0016 302-0010 SCREW, #10-32 X 1/2 OVAL 115-0009 HANDLE COVER 302-0009 SCREW, 5/16-18 X 3/8 SET 037-557 SCREW, #8-32 X 1/4 SET 115-0010 CONTROL CABLE ASM 302-0028 WELD CABLE ASM 302-0029 DAMPER COVER 302-0011 DAMPER 302-0007

PAGE 34

LIGHT DUTY SET LIFT ARC WELDING GUN PART # 300-0804

ITEM 1 2 3 4 5 6 7 8 9 10 11 12 13 14

PAGE 35

DESCRIPTION

PART NO.

CHUCK ADAPTOR BELLOWS NUT, END CAP BEARING FRONT CAP, L.D. LIFTING ROD ASM. SPRING, MAIN LIFT STOP HOUSING

302-0026 302-0014 033-481 033-491 302-0004 302-0034 302-0017

SCREW 5/16-18 X 3/8 SET

037-557 302-0001 301-0009 105-0024 102-0117 301-0016

GUN BODY COIL YOKE BEARING COIL, GUN WAVE WASHER YOKE, REAR COIL

301-0019

LIST

ITEM 15 16 17 18 19 20 21 22 23 24 25 26 27 28

DESCRIPTION

PART NO.

115-0010 302-0033 033-493 SCREW, #8-32 X 3/4 PAN HD 037-521 SCREW, #8-32 x 3/8 115-0011 WASHER 302-0025 TRIGGER BUTTON 302-0013 SPRING, TRIGGER 302-0016 SNAP RING 302-0023 TRIGGER SWITCH ASM 302-0010 HANDLE COVER 302-0009 SCREW, #10-32 X 1/2 OVAL 115-0009 CONTROL CABLE ASSY 25’ 302-0027 WELD CABLE ASSY 25’ 302-0032 SCREW, #8-32 X 1/4 SET

ADJUSTABLE CORE REAR CAP

LIST

MEDIUM DUTY ARC WELDING GUN PART # 300-0805

ITEM 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20

DESCRIPTION CHUCK ADAPTOR CONNECTOR STUD BELLOWS SHAFT EXT. FRONT CAP NYLON BEARING. LIFTING ROD SPRING ,MAIN DAMPER COVER DAMPER NUT, END CAP DAMPER STOP

PART NO.

033-505 033-506 301-0018 302-0036 302-0003 033-491 302-0012 302-0017 302-0011 302-0007 033-481 302-0021 SCREW, #8-32 X 3/8 FSCS 115-0011 LIFT HOUSING 301-0019 LIFTING RING 301-0014 MOVEABLE CORE 301-0013 SPRING , CORE 301-0012 GUN BODY 302-0001 COIL YOKE BEARING 301-0009 GUN COIL 105-0024

LIST

ITEM 21 22 23 24 25 26 27 28 29 30 31 32 33 34 34A 34B 34C 35 36 37

DESCRIPTION

PART NO.

LIST

WAVE WASHER REAR COIL YOKE

102-0117 301-0016 SCREW, #8-32 X 1/4 SET 115-0010 LIFT ADJ. SCREW 301-0008 REAR CAP 033-493 SCREW, #8-32 X 3/4 PAN HD. 037-521 HANDLE COVER 302-0009HD SCREW, #10-32 X 1/2 OVAL HD 115-0009 SCREW, 5/16-18 X 3/8 SET 037-557 SPRING, TRIGGER 302-0016 SNAP RING 302-0023 TRIGGER BUTTON 302-0013 TRIGGER SWITCH ASSY 302-0010 CABLE GUIDE ASSY 303-0009 SCREW, #10-32 X .625 SHCS 115-0012 CLAMP, CABLE GUIDE 303-0009-2 , CABLE GUIDE 303-0009-1 CONTROL CABLE ASSY 302-0028 WELD CABLE ASSY 036-904 WELD CABLE BOOT 036-904-1 CONTROL CABLE BOOT 036-897-1 PAGE 36

HEAVY DUTY ARC WELDING GUN PART # 300-0900

ITEM 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20

PAGE 37

DESCRIPTION CHUCK ADAPTOR CONNECTOR STUD BELLOWS SHAFT EXT. BEARING FRONT CAP . LIFTING ROD SPRING, MAIN LIFT STOP HOUSING LIFTING RING MOVEABLE CORE SPRING, CORE NUT, END CAP

PART NO.

033-505 033-506 301-0018 033-507 033-491 303-0003 303-0006 301-0017 301-0019 301-0014 301-0013 301-0012 033-482 DAMPER ADJUST KNOB 303-0005 DAMPER COVER 303-0007 DAMPER SPRING RETURN 301-0021 GUN BODY 302-0001 COIL YOKE BEARING 301-0009 COIL, GUN 105-0024 WAVE WASHER 102-0117

LIST

ITEM 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 35A 35B 35C 36

DESCRIPTION REAR COIL YOKE LIFT ADJ. SCREW REAR CAP

PART NO.

301-0016 301-0008 033-493 SCREW,#8-32 X 3/4 PAN HD. 037-521 TRIGGER BUTTON 302-0013 SNAP RING 302-0023 TRIGGER SPRING 302-0016 HANDLE COVER 302-0009HD TRIGGER SWITCH 302-0010 SCREW, #10-32 X 1/2 OVAL HD 115-0009 SCREW, #8-32 X 1/4 SET 115-0010 SCREW, 5/16-18 X 3/8 SET 037-557 WELD CABLE ASSY 044-059 CONTROL CABLE ASSY 302-0028 CABLE GUIDE ASSY 303-0009 SCREW, #10-32 X .625 SHCS 115-0012 CLAMP, CABLE GUIDE 303-0009-2 , CABLE GUIDE 303-0009-1 WELD CABLE BOOT 044-059-1 CONTROL CABLE BOOT 036-897-1

LIST

MANUFACTURED BY

PRO

WELD

MADE IN THE U.S.A.
