NELSON STUD WELDING SPECIFICATION: CFL Fully Threaded Studs

CFL

Nelson CFL studs are recommended for fastening applications where threads are needed for the full fastener length. CFL studs a re available in thread diameters of 1/4"-20 through 1”-8. Nelson fully threaded studs have a short length of pitch diameter weld base. Most of this length is melted off during the stud welding process so that usable thread extends down to the top of the weld flash on installed studs. For similar function studs, see CFP Small Diameter Threaded studs, CJL Reduced Base studs, L Partially Threaded studs, HBA Aluminum Full Base Diameter Threaded studs, HBL Full Base Diameter Threaded studs, Banding Cable Hangers, CrimpLok™ Cable Hangers, and Watertight nuts.

When ordering, specify Type, Diameter, Before Weld Length, Material, Quantity, and Part Number Example: CFL 3/8-16 x 2-1/4”; Mild Steel; 10,000 pieces; #101017193 Thread Minimum Burn Weld Base Weld Base Stud Diameter Length Size Off Length C A

Weld Flash Size E

F

Required Standard Accessories

Flash Clearance

Ferrule

Grip

Chuck

Foot

1/4-20

0.780

0.125

0.215

0.142

0.359

0.109

0.437

100101067

501001007

500001007

502001137

5/16-18

0.780

0.125

0.275

0.142

0.437

0.109

0.500

100101024

501001006

500001009

502001137 502001137

3/8-16

0.812

0.125

0.330

0.190

0.500

0.125

0.562

100101025

501001007

500001011

7/16-14

0.812

0.125

0.389

0.205

0.562

0.125

0.625

100101026

501001008

500001012

502001137

1/2-13

0.875

0.125

0.448

0.221

0.625

0.156

0.680

100101027

501001009

500001014

502001137

9/16-12

1.062

0.187

0.503

0.221

0.750

0.156

0.813

100101011

501001011

500001015

502001138

5/8-11

1.000

0.187

0.562

0.284

0.781

0.187

0.843

100101028

501001011

500001016

502001138

3/4-10

1.250

0.187

0.680

0.346

0.937

0.250

1.031

100101029

501001014

500001018

502001002

7/8-9

1.500

0.187

0.798

0.377

1.125

0.312

1.250

100101140

501001015

500001019

502001003

1-8

1.500

0.250

0.913

0.500

1.375

0.375

1.437

100101045

501001016

500001085

502001003

Stud lengths shorter than those shown above can be supplied in sizes 1/4"-20 through 1/2"-13 by using special low profile ceramic ferrules. All low profile ferrules, except the 1/4”-20 ferrule, were designed for use with full diameter weld base studs. For this reason, the weld flash size and flash clearance are increased. The minimum length, weld flash clearance, recommended deviance, ferrules, and ferrule grip numbers are shown below. Thread Size

Minimum Stud Length

E

F

Ferrule

Grip

Chuck

Foot

1/4-20

0.640

0.359

0.109

0.437

100101077

501001005

500001007

502001137

5/16-18

0.640

0.437

0.109

0.500

100101030

501001007

500001009

502001137

Weld Flash Size

Flash Clearance

Required Standard Accessories For Short Studs

3/8-16

0.687

0.500

0.125

0.593

100101031

501001008

500001011

502001137

7/16-14

0.687

0.593

0.140

0.656

100101032

501001009

500001012

502001137

1/2-13

0.750

0.687

0.156

0.750

100101033

501001001

500001014

502001138

MATERIALS: Studs are available in Low Carbon Mild Steel and Stainless Steel. For specific grade information, physical and chemical properties, conforming standards, and information on stud plating and heat treating, please see General Material Specifications. THREADS: Standard CFL studs are available with up to 3” of thread length in UNC-2A coarse thread. Other thread pitch series, and thread lengths greater than 3” are available as special order. FLUX: All Nelson partially threaded CFL studs have a solid flux load. Visit our website www.NelsonStudWelding.com for a list of our standard stock products. Nelson Stud Welding, Inc. 7900 West Ridge Road Elyria, Ohio 44035

PH 1-800-NEL-WELD 1-800-635-9353

E-mail: [email protected]

1/04
