HP ProLiant MicroServer Gen8 Maintenance and Service Guide

Abstract This document is for an experienced service technician. It is helpful if you are qualified in the servicing of computer equipment and trained in recognizing hazards in products with hazardous energy levels and are familiar with weight and stability precautions.

Part Number: 718901-001 June 2013 Edition: 1

© Copyright 2013 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein. Microsoft® and Windows® are U.S. ed trademarks of Microsoft Corporation. Intel®, Celeron®, and Pentium® are trademarks of Intel Corporation in the U.S. and other countries.

Contents Customer self repair ...................................................................................................................... 5 Parts only warranty service ............................................................................................................................ 5

Illustrated parts catalog ............................................................................................................... 15 Mechanical components ............................................................................................................................. 15 System components .................................................................................................................................... 18

Removal and replacement procedures ........................................................................................... 21 Required tools ............................................................................................................................................ 21 Safety considerations .................................................................................................................................. 21 Preventing electrostatic discharge ...................................................................................................... 21 Symbols on equipment ...................................................................................................................... 21 Server warnings and cautions............................................................................................................ 22 Preparation procedures ............................................................................................................................... 22 Power down the server ..................................................................................................................... 23 Open the front bezel ........................................................................................................................ 24 Remove the front bezel ..................................................................................................................... 25 Remove the chassis cover .................................................................................................................. 26 Install the chassis cover ..................................................................................................................... 27 Remove the system board assembly.................................................................................................... 28 Install the system board assembly....................................................................................................... 30 Drive carrier .............................................................................................................................................. 30 LFF non-hot-plug drive ................................................................................................................................. 31 Optical drive blank .................................................................................................................................... 33 Optical drive ............................................................................................................................................. 33 Flash-backed write cache procedures ........................................................................................................... 34 FBWC module ................................................................................................................................. 34 Capacitor pack ................................................................................................................................ 35 Recovering data from the flash-backed write cache .............................................................................. 37 Front I/O module assembly ......................................................................................................................... 37 Ambient temperature sensor cable ............................................................................................................... 40 LFF non-hot-plug drive cage bracket ............................................................................................................. 41 System fan ................................................................................................................................................. 45 Integrated power supply ............................................................................................................................. 46 Expansion board ........................................................................................................................................ 47 DIMMs ...................................................................................................................................................... 48 General DIMM slot population guidelines ........................................................................................... 48 Removing a DIMM ........................................................................................................................... 49 Heatsink .................................................................................................................................................... 49 Processor................................................................................................................................................... 51 System board ............................................................................................................................................ 53 System battery ........................................................................................................................................... 60 HP Trusted Platform Module......................................................................................................................... 61

Troubleshooting .......................................................................................................................... 62 Troubleshooting resources ........................................................................................................................... 62

Diagnostic tools .......................................................................................................................... 63

Contents

3

HP product QuickSpecs .............................................................................................................................. 63 HP Insight Diagnostics ................................................................................................................................ 63 HP Insight Diagnostics survey functionality .......................................................................................... 63 HP Insight Remote software ............................................................................................................. 63 HP ROM-Based Setup Utility ........................................................................................................................ 64 Integrated Management Log ........................................................................................................................ 64 USB and functionality ...................................................................................................................... 65 USB .................................................................................................................................... 65 Internal USB functionality .................................................................................................................. 65 External USB functionality ................................................................................................................. 65 Automatic Server Recovery .......................................................................................................................... 65

Component identification ............................................................................................................. 66 Front components .............................................................................................................................. 66 Front LEDs and buttons ....................................................................................................................... 67 Rear components .............................................................................................................................. 68 Rear LEDs and buttons ....................................................................................................................... 69 System board components .......................................................................................................................... 69 DIMM slot locations .......................................................................................................................... 71 System maintenance switch ............................................................................................................... 71 NMI functionality ............................................................................................................................. 72 Drive numbering ........................................................................................................................................ 72 FBWC module LED definitions ..................................................................................................................... 73 Fan location .............................................................................................................................................. 74 T-10/T-15 Torx screwdriver ......................................................................................................................... 74

Cabling ..................................................................................................................................... 75 Cabling overview ....................................................................................................................................... 75 Four-bay LFF non-hot-plug drive cage cabling ................................................................................................ 75 Capacitor pack cabling .............................................................................................................................. 76 Optical drive cabling.................................................................................................................................. 77 Front I/O assembly cabling......................................................................................................................... 77 Ambient temperature sensor cabling ............................................................................................................ 78 System fan cabling ..................................................................................................................................... 78 Power supply cabling ................................................................................................................................. 79

Specifications ............................................................................................................................. 80 Environmental specifications ........................................................................................................................ 80 Server specifications ................................................................................................................................... 80 Power supply specifications ......................................................................................................................... 80 HP 150 W Integrated Power Supply .................................................................................................. 80

Acronyms and abbreviations ........................................................................................................ 82 Documentation ............................................................................................................. 84 Index ......................................................................................................................................... 85

Contents

4

Customer self repair HP products are designed with many Customer Self Repair (CSR) parts to minimize repair time and allow for greater flexibility in performing defective parts replacement. If during the diagnosis period HP (or HP service providers or service partners) identifies that the repair can be accomplished by the use of a CSR part, HP will ship that part directly to you for replacement. There are two categories of CSR parts:

•

Mandatory—Parts for which customer self repair is mandatory. If you request HP to replace these parts, you will be charged for the travel and labor costs of this service.

•

Optional—Parts for which customer self repair is optional. These parts are also designed for customer self repair. If, however, you require that HP replace them for you, there may or may not be additional charges, depending on the type of warranty service designated for your product.

NOTE: Some HP parts are not designed for customer self repair. In order to satisfy the customer warranty, HP requires that an authorized service provider replace the part. These parts are identified as "No" in the Illustrated Parts Catalog. Based on availability and where geography permits, CSR parts will be shipped for next business day delivery. Same day or four-hour delivery may be offered at an additional charge where geography permits. If assistance is required, you can call the HP Technical Center and a technician will help you over the telephone. HP specifies in the materials shipped with a replacement CSR part whether a defective part must be returned to HP. In cases where it is required to return the defective part to HP, you must ship the defective part back to HP within a defined period of time, normally five (5) business days. The defective part must be returned with the associated documentation in the provided shipping material. Failure to return the defective part may result in HP billing you for the replacement. With a customer self repair, HP will pay all shipping and part return costs and determine the courier/carrier to be used. For more information about HP's Customer Self Repair program, your local service provider. For the North American program, refer to the HP website (http://www.hp.com/go/selfrepair).

Parts only warranty service Your HP Limited Warranty may include a parts only warranty service. Under the of parts only warranty service, HP will provide replacement parts free of charge. For parts only warranty service, CSR part replacement is mandatory. If you request HP to replace these parts, you will be charged for the travel and labor costs of this service.

Réparation par le client (CSR) Les produits HP comportent de nombreuses pièces CSR (Customer Self Repair = réparation par le client) afin de minimiser les délais de réparation et faciliter le remplacement des pièces défectueuses. Si pendant la période de diagnostic, HP (ou ses partenaires ou mainteneurs agréés) détermine que la réparation peut être effectuée à l'aide d'une pièce CSR, HP vous l'envoie directement. Il existe deux catégories de pièces CSR:

Customer self repair 5

Obligatoire - Pièces pour lesquelles la réparation par le client est obligatoire. Si vous demandez à HP de remplacer ces pièces, les coûts de déplacement et main d'œuvre du service vous seront facturés. Facultatif - Pièces pour lesquelles la réparation par le client est facultative. Ces pièces sont également conçues pour permettre au client d'effectuer lui-même la réparation. Toutefois, si vous demandez à HP de remplacer ces pièces, l'intervention peut ou non vous être facturée, selon le type de garantie applicable à votre produit. REMARQUE: Certaines pièces HP ne sont pas conçues pour permettre au client d'effectuer lui-même la réparation. Pour que la garantie puisse s'appliquer, HP exige que le remplacement de la pièce soit effectué par un Mainteneur Agréé. Ces pièces sont identifiées par la mention "Non" dans le Catalogue illustré. Les pièces CSR sont livrées le jour ouvré suivant, dans la limite des stocks disponibles et selon votre situation géographique. Si votre situation géographique le permet et que vous demandez une livraison le jour même ou dans les 4 heures, celle-ci vous sera facturée. Pour bénéficier d'une assistance téléphonique, appelez le Centre d'assistance technique HP. Dans les documents envoyés avec la pièce de rechange CSR, HP précise s'il est nécessaire de lui retourner la pièce défectueuse. Si c'est le cas, vous devez le faire dans le délai indiqué, généralement cinq (5) jours ouvrés. La pièce et sa documentation doivent être retournées dans l'emballage fourni. Si vous ne retournez pas la pièce défectueuse, HP se réserve le droit de vous facturer les coûts de remplacement. Dans le cas d'une pièce CSR, HP e l'ensemble des frais d'expédition et de retour, et détermine la société de courses ou le transporteur à utiliser. Pour plus d'informations sur le programme CSR de HP, ez votre Mainteneur Agrée local. Pour plus d'informations sur ce programme en Amérique du Nord, consultez le site Web HP (http://www.hp.com/go/selfrepair).

Service de garantie "pièces seules" Votre garantie limitée HP peut inclure un service de garantie "pièces seules". Dans ce cas, les pièces de rechange fournies par HP ne sont pas facturées. Dans le cadre de ce service, la réparation des pièces CSR par le client est obligatoire. Si vous demandez à HP de remplacer ces pièces, les coûts de déplacement et main d'œuvre du service vous seront facturés.

Riparazione da parte del cliente Per abbreviare i tempi di riparazione e garantire una maggiore flessibilità nella sostituzione di parti difettose, i prodotti HP sono realizzati con numerosi componenti che possono essere riparati direttamente dal cliente (CSR, Customer Self Repair). Se in fase di diagnostica HP (o un centro di servizi o di assistenza HP) identifica il guasto come riparabile mediante un ricambio CSR, HP lo spedirà direttamente al cliente per la sostituzione. Vi sono due categorie di parti CSR: Obbligatorie – Parti che devono essere necessariamente riparate dal cliente. Se il cliente ne affida la riparazione ad HP, deve sostenere le spese di spedizione e di manodopera per il servizio. Opzionali – Parti la cui riparazione da parte del cliente è facoltativa. Si tratta comunque di componenti progettati per questo scopo. Se tuttavia il cliente ne richiede la sostituzione ad HP, potrebbe dover sostenere spese addizionali a seconda del tipo di garanzia previsto per il prodotto. NOTA: alcuni componenti HP non sono progettati per la riparazione da parte del cliente. Per rispettare la garanzia, HP richiede che queste parti siano sostituite da un centro di assistenza autorizzato. Tali parti sono identificate da un "No" nel Catalogo illustrato dei componenti.

Customer self repair 6

In base alla disponibilità e alla località geografica, le parti CSR vengono spedite con consegna entro il giorno lavorativo seguente. La consegna nel giorno stesso o entro quattro ore è offerta con un supplemento di costo solo in alcune zone. In caso di necessità si può richiedere l'assistenza telefonica di un addetto del centro di o tecnico HP. Nel materiale fornito con una parte di ricambio CSR, HP specifica se il cliente deve restituire dei componenti. Qualora sia richiesta la resa ad HP del componente difettoso, lo si deve spedire ad HP entro un determinato periodo di tempo, generalmente cinque (5) giorni lavorativi. Il componente difettoso deve essere restituito con la documentazione associata nell'imballo di spedizione fornito. La mancata restituzione del componente può comportare la fatturazione del ricambio da parte di HP. Nel caso di riparazione da parte del cliente, HP sostiene tutte le spese di spedizione e resa e sceglie il corriere/vettore da utilizzare. Per ulteriori informazioni sul programma CSR di HP contattare il centro di assistenza di zona. Per il programma in Nord America fare riferimento al sito Web HP (http://www.hp.com/go/selfrepair).

Servizio di garanzia per i soli componenti La garanzia limitata HP può includere un servizio di garanzia per i soli componenti. Nei termini di garanzia del servizio per i soli componenti, HP fornirà gratuitamente le parti di ricambio. Per il servizio di garanzia per i soli componenti è obbligatoria la formula CSR che prevede la riparazione da parte del cliente. Se il cliente invece richiede la sostituzione ad HP, dovrà sostenere le spese di spedizione e di manodopera per il servizio.

Customer Self Repair HP Produkte enthalten viele CSR-Teile (Customer Self Repair), um Reparaturzeiten zu minimieren und höhere Flexibilität beim Austausch defekter Bauteile zu ermöglichen. Wenn HP (oder ein HP Servicepartner) bei der Diagnose feststellt, dass das Produkt mithilfe eines CSR-Teils repariert werden kann, sendet Ihnen HP dieses Bauteil zum Austausch direkt zu. CSR-Teile werden in zwei Kategorien unterteilt: Zwingend – Teile, für die das Customer Self Repair-Verfahren zwingend vorgegeben ist. Wenn Sie den Austausch dieser Teile von HP vornehmen lassen, werden Ihnen die Anfahrt- und Arbeitskosten für diesen Service berechnet. Optional – Teile, für die das Customer Self Repair-Verfahren optional ist. Diese Teile sind auch für Customer Self Repair ausgelegt. Wenn Sie jedoch den Austausch dieser Teile von HP vornehmen lassen möchten, können bei diesem Service je nach den für Ihr Produkt vorgesehenen Garantiebedingungen zusätzliche Kosten anfallen. HINWEIS: Einige Teile sind nicht für Customer Self Repair ausgelegt. Um den Garantieanspruch des Kunden zu erfüllen, muss das Teil von einem HP Servicepartner ersetzt werden. Im illustrierten Teilekatalog sind diese Teile mit „No“ bzw. „Nein“ gekennzeichnet. CSR-Teile werden abhängig von der Verfügbarkeit und vom Lieferziel am folgenden Geschäftstag geliefert. Für bestimmte Standorte ist eine Lieferung am selben Tag oder innerhalb von vier Stunden gegen einen Aufpreis verfügbar. Wenn Sie Hilfe benötigen, können Sie das HP technische Center anrufen und sich von einem Mitarbeiter per Telefon helfen lassen. Den Materialien, die mit einem CSR-Ersatzteil geliefert werden, können Sie entnehmen, ob das defekte Teil an HP zurückgeschickt werden muss. Wenn es erforderlich ist, das defekte Teil an HP zurückzuschicken, müssen Sie dies innerhalb eines vorgegebenen Zeitraums tun, in der Regel innerhalb von fünf (5) Geschäftstagen. Das defekte Teil muss mit der zugehörigen Dokumentation in der Verpackung zurückgeschickt werden, die im Lieferumfang enthalten ist. Wenn Sie das

Customer self repair 7

defekte Teil nicht zurückschicken, kann HP Ihnen das Ersatzteil in Rechnung stellen. Im Falle von Customer Self Repair kommt HP für alle Kosten für die Lieferung und Rücksendung auf und bestimmt den Kurier-/Frachtdienst. Weitere Informationen über das HP Customer Self Repair Programm erhalten Sie von Ihrem Servicepartner vor Ort. Informationen über das CSR-Programm in Nordamerika finden Sie auf der HP Website unter (http://www.hp.com/go/selfrepair).

Parts-only Warranty Service (Garantieservice ausschließlich für Teile) Ihre HP Garantie umfasst möglicherweise einen Parts-only Warranty Service (Garantieservice ausschließlich für Teile). Gemäß den Bestimmungen des Parts-only Warranty Service stellt HP Ersatzteile kostenlos zur Verfügung. Für den Parts-only Warranty Service ist das CSR-Verfahren zwingend vorgegeben. Wenn Sie den Austausch dieser Teile von HP vornehmen lassen, werden Ihnen die Anfahrt- und Arbeitskosten für diesen Service berechnet.

Reparaciones del propio cliente Los productos de HP incluyen muchos componentes que el propio puede reemplazar (Customer Self Repair, CSR) para minimizar el tiempo de reparación y ofrecer una mayor flexibilidad a la hora de realizar sustituciones de componentes defectuosos. Si, durante la fase de diagnóstico, HP (o los proveedores o socios de servicio de HP) identifica que una reparación puede llevarse a cabo mediante el uso de un componente CSR, HP le enviará dicho componente directamente para que realice su sustitución. Los componentes CSR se clasifican en dos categorías:

•

Obligatorio: componentes para los que la reparación por parte del es obligatoria. Si solicita a HP que realice la sustitución de estos componentes, tendrá que hacerse cargo de los gastos de desplazamiento y de mano de obra de dicho servicio.

•

Opcional: componentes para los que la reparación por parte del es opcional. Estos componentes también están diseñados para que puedan ser reparados por el . Sin embargo, si precisa que HP realice su sustitución, puede o no conllevar costes adicionales, dependiendo del tipo de servicio de garantía correspondiente al producto.

NOTA: Algunos componentes no están diseñados para que puedan ser reparados por el . Para que el haga valer su garantía, HP pone como condición que un proveedor de servicios autorizado realice la sustitución de estos componentes. Dichos componentes se identifican con la palabra "No" en el catálogo ilustrado de componentes. Según la disponibilidad y la situación geográfica, los componentes CSR se enviarán para que lleguen a su destino al siguiente día laborable. Si la situación geográfica lo permite, se puede solicitar la entrega en el mismo día o en cuatro horas con un coste adicional. Si precisa asistencia técnica, puede llamar al Centro de asistencia técnica de HP y recibirá ayuda telefónica por parte de un técnico. Con el envío de materiales para la sustitución de componentes CSR, HP especificará si los componentes defectuosos deberán devolverse a HP. En aquellos casos en los que sea necesario devolver algún componente a HP, deberá hacerlo en el periodo de tiempo especificado, normalmente cinco días laborables. Los componentes defectuosos deberán devolverse con toda la documentación relacionada y con el embalaje de envío. Si no Customer self repair 8

enviara el componente defectuoso requerido, HP podrá cobrarle por el de sustitución. En el caso de todas sustituciones que lleve a cabo el cliente, HP se hará cargo de todos los gastos de envío y devolución de componentes y escogerá la empresa de transporte que se utilice para dicho servicio. Para obtener más información acerca del programa de Reparaciones del propio cliente de HP, póngase en o con su proveedor de servicios local. Si está interesado en el programa para Norteamérica, visite la página web de HP siguiente (http://www.hp.com/go/selfrepair).

Servicio de garantía exclusivo de componentes La garantía limitada de HP puede que incluya un servicio de garantía exclusivo de componentes. Según las condiciones de este servicio exclusivo de componentes, HP le facilitará los componentes de repuesto sin cargo adicional alguno. Para este servicio de garantía exclusivo de componentes, es obligatoria la sustitución de componentes por parte del (CSR). Si solicita a HP que realice la sustitución de estos componentes, tendrá que hacerse cargo de los gastos de desplazamiento y de mano de obra de dicho servicio.

Customer Self Repair Veel onderdelen in HP producten zijn door de klant zelf te repareren, waardoor de reparatieduur tot een minimum beperkt kan blijven en de flexibiliteit in het vervangen van defecte onderdelen groter is. Deze onderdelen worden CSR-onderdelen (Customer Self Repair) genoemd. Als HP (of een HP Service Partner) bij de diagnose vaststelt dat de reparatie kan worden uitgevoerd met een CSR-onderdeel, verzendt HP dat onderdeel rechtstreeks naar u, zodat u het defecte onderdeel daarmee kunt vervangen. Er zijn twee categorieën CSR-onderdelen: Verplicht: Onderdelen waarvoor reparatie door de klant verplicht is. Als u HP verzoekt deze onderdelen voor u te vervangen, worden u voor deze service reiskosten en arbeidsloon in rekening gebracht. Optioneel: Onderdelen waarvoor reparatie door de klant optioneel is. Ook deze onderdelen zijn ontworpen voor reparatie door de klant. Als u echter HP verzoekt deze onderdelen voor u te vervangen, kunnen daarvoor extra kosten in rekening worden gebracht, afhankelijk van het type garantieservice voor het product. OPMERKING: Sommige HP onderdelen zijn niet ontwikkeld voor reparatie door de klant. In verband met de garantievoorwaarden moet het onderdeel door een geautoriseerde Service Partner worden vervangen. Deze onderdelen worden in de geïllustreerde onderdelencatalogus aangemerkt met "Nee". Afhankelijk van de leverbaarheid en de locatie worden CSR-onderdelen verzonden voor levering op de eerstvolgende werkdag. Levering op dezelfde dag of binnen vier uur kan tegen meerkosten worden aangeboden, indien dit mogelijk is gezien de locatie. Indien assistentie gewenst is, belt u een HP Service Partner om via de telefoon technische ondersteuning te ontvangen. HP vermeldt in de documentatie bij het vervangende CSR-onderdeel of het defecte onderdeel aan HP moet worden geretourneerd. Als het defecte onderdeel aan HP moet worden teruggezonden, moet u het defecte onderdeel binnen een bepaalde periode, gewoonlijk vijf (5) werkdagen, retourneren aan HP. Het defecte onderdeel moet met de bijbehorende documentatie worden geretourneerd in het meegeleverde verpakkingsmateriaal. Als u het defecte onderdeel niet terugzendt, kan HP u voor het vervangende onderdeel kosten in rekening brengen. Bij reparatie door de klant betaalt HP alle verzendkosten voor het vervangende en geretourneerde onderdeel en kiest HP zelf welke koerier/transportonderneming hiervoor wordt gebruikt.

Customer self repair 9

Neem op met een Service Partner voor meer informatie over het Customer Self Repair programma van HP. Informatie over Service Partners vindt u op de HP website (http://www.hp.com/go/selfrepair).

Garantieservice "Parts Only" Het is mogelijk dat de HP garantie alleen de garantieservice "Parts Only" omvat. Volgens de bepalingen van de Parts Only garantieservice zal HP kosteloos vervangende onderdelen ter beschikking stellen. Voor de Parts Only garantieservice is vervanging door CSR-onderdelen verplicht. Als u HP verzoekt deze onderdelen voor u te vervangen, worden u voor deze service reiskosten en arbeidsloon in rekening gebracht.

Reparo feito pelo cliente Os produtos da HP são projetados com muitas peças para reparo feito pelo cliente (CSR) de modo a minimizar o tempo de reparo e permitir maior flexibilidade na substituição de peças com defeito. Se, durante o período de diagnóstico, a HP (ou fornecedores/parceiros de serviço da HP) concluir que o reparo pode ser efetuado pelo uso de uma peça CSR, a peça de reposição será enviada diretamente ao cliente. Existem duas categorias de peças CSR: Obrigatória – Peças cujo reparo feito pelo cliente é obrigatório. Se desejar que a HP substitua essas peças, serão cobradas as despesas de transporte e mão-de-obra do serviço. Opcional – Peças cujo reparo feito pelo cliente é opcional. Essas peças também são projetadas para o reparo feito pelo cliente. No entanto, se desejar que a HP as substitua, pode haver ou não a cobrança de taxa adicional, dependendo do tipo de serviço de garantia destinado ao produto. OBSERVAÇÃO: Algumas peças da HP não são projetadas para o reparo feito pelo cliente. A fim de cumprir a garantia do cliente, a HP exige que um técnico autorizado substitua a peça. Essas peças estão identificadas com a marca "No" (Não), no catálogo de peças ilustrado. Conforme a disponibilidade e o local geográfico, as peças CSR serão enviadas no primeiro dia útil após o pedido. Onde as condições geográficas permitirem, a entrega no mesmo dia ou em quatro horas pode ser feita mediante uma taxa adicional. Se precisar de auxílio, entre em contato com o Centro de e técnico da HP para que um técnico o ajude por telefone. A HP especifica nos materiais fornecidos com a peça CSR de reposição se a peça com defeito deve ser devolvida à HP. Nos casos em que isso for necessário, é preciso enviar a peça com defeito à HP dentro do período determinado, normalmente cinco (5) dias úteis. A peça com defeito deve ser enviada com a documentação correspondente no material de transporte fornecido. Caso não o faça, a HP poderá cobrar a reposição. Para as peças de reparo feito pelo cliente, a HP paga todas as despesas de transporte e de devolução da peça e determina a transportadora/serviço postal a ser utilizado. Para obter mais informações sobre o programa de reparo feito pelo cliente da HP, entre em contato com o fornecedor de serviços local. Para o programa norte-americano, visite o site da HP (http://www.hp.com/go/selfrepair).

Serviço de garantia apenas para peças A garantia limitada da HP pode incluir um serviço de garantia apenas para peças. Segundo os termos do serviço de garantia apenas para peças, a HP fornece as peças de reposição sem cobrar nenhuma taxa.

Customer self repair 10

No caso desse serviço, a substituição de peças CSR é obrigatória. Se desejar que a HP substitua essas peças, serão cobradas as despesas de transporte e mão-de-obra do serviço.

Customer self repair 11

Customer self repair 12

Customer self repair 13

Customer self repair 14

Illustrated parts catalog Mechanical components

Item

Description

Spare part number

Customer self repair (on page 5)

1

Chassis cover

724494-001

Mandatory1

2

Optical drive blank

724499-001

Mandatory1

3

LFF non-hot-plug drive carrier*

691585-001

Mandatory1

4

Front bezel assembly

724490-001

Mandatory1

5

System board tray

724500-001

Mandatory1

6

Heatsink

724501-001

Optional2

* When no drive is installed in the non-hot-plug drive carrier, it serves as a blank for a non-hot-plug drive configuration. Mandatory—Parts for which customer self repair is mandatory. If you request HP to replace these parts, you will be charged for the travel and labor costs of this service.

1

Illustrated parts catalog

15

Optional—Parts for which customer self repair is optional. These parts are also designed for customer self repair. If, however, you require that HP replace them for you, there may or may not be additional charges, depending on the type of warranty service designated for your product. 3 No—Some HP parts are not designed for customer self repair. In order to satisfy the customer warranty, HP requires that an authorized service provider replace the part. These parts are identified as "No" in the Illustrated Parts Catalog. 2

Mandatory: Obligatoire—Pièces pour lesquelles la réparation par le client est obligatoire. Si vous demandez à HP de remplacer ces pièces, les coûts de déplacement et main d'œuvre du service vous seront facturés. 2 Optional: Facultatif—Pièces pour lesquelles la réparation par le client est facultative. Ces pièces sont également conçues pour permettre au client d'effectuer lui-même la réparation. Toutefois, si vous demandez à HP de remplacer ces pièces, l'intervention peut ou non vous être facturée, selon le type de garantie applicable à votre produit. 3 No: Non—Certaines pièces HP ne sont pas conçues pour permettre au client d'effectuer lui-même la réparation. Pour que la garantie puisse s'appliquer, HP exige que le remplacement de la pièce soit effectué par un Mainteneur Agréé. Ces pièces sont identifiées par la mention “Non” dans le Catalogue illustré. 1

Mandatory: Obbligatorie—Parti che devono essere necessariamente riparate dal cliente. Se il cliente ne affida la riparazione ad HP, deve sostenere le spese di spedizione e di manodopera per il servizio. 2 Optional: Opzionali—Parti la cui riparazione da parte del cliente è facoltativa. Si tratta comunque di componenti progettati per questo scopo. Se tuttavia il cliente ne richiede la sostituzione ad HP, potrebbe dover sostenere spese addizionali a seconda del tipo di garanzia previsto per il prodotto. 3 No: Non CSR—Alcuni componenti HP non sono progettati per la riparazione da parte del cliente. Per rispettare la garanzia, HP richiede che queste parti siano sostituite da un centro di assistenza autorizzato. Tali parti sono identificate da un “No” nel Catalogo illustrato dei componenti. 1

Mandatory: Zwingend—Teile, die im Rahmen des Customer Self Repair Programms ersetzt werden müssen. Wenn Sie diese Teile von HP ersetzen lassen, werden Ihnen die Versand- und Arbeitskosten für diesen Service berechnet. 2 Optional: Optional—Teile, für die das Customer Self Repair-Verfahren optional ist. Diese Teile sind auch für Customer Self Repair ausgelegt. Wenn Sie jedoch den Austausch dieser Teile von HP vornehmen lassen möchten, können bei diesem Service je nach den für Ihr Produkt vorgesehenen Garantiebedingungen zusätzliche Kosten anfallen. 3 No: Kein—Einige Teile sind nicht für Customer Self Repair ausgelegt. Um den Garantieanspruch des Kunden zu erfüllen, muss das Teil von einem HP Servicepartner ersetzt werden. Im illustrierten Teilekatalog sind diese Teile mit „No“ bzw. „Nein“ gekennzeichnet. 1

Mandatory: Obligatorio—componentes para los que la reparación por parte del es obligatoria. Si solicita a HP que realice la sustitución de estos componentes, tendrá que hacerse cargo de los gastos de desplazamiento y de mano de obra de dicho servicio. 2 Optional: Opcional— componentes para los que la reparación por parte del es opcional. Estos componentes también están diseñados para que puedan ser reparados por el . Sin embargo, si precisa que HP realice su sustitución, puede o no conllevar costes adicionales, dependiendo del tipo de servicio de garantía correspondiente al producto. 3 No: No—Algunos componentes no están diseñados para que puedan ser reparados por el . Para que el haga valer su garantía, HP pone como condición que un proveedor de servicios autorizado realice la sustitución de estos componentes. Dichos componentes se identifican con la palabra “No” en el catálogo ilustrado de componentes. 1

Mandatory: Verplicht—Onderdelen waarvoor Customer Self Repair verplicht is. Als u HP verzoekt deze onderdelen te vervangen, komen de reiskosten en het arbeidsloon voor uw rekening. 2 Optional: Optioneel—Onderdelen waarvoor reparatie door de klant optioneel is. Ook deze onderdelen zijn ontworpen voor reparatie door de klant. Als u echter HP verzoekt deze onderdelen voor u te vervangen, kunnen daarvoor extra kosten in rekening worden gebracht, afhankelijk van het type garantieservice voor het product. 3 No: Nee—Sommige HP onderdelen zijn niet ontwikkeld voor reparatie door de klant. In verband met de garantievoorwaarden moet het onderdeel door een geautoriseerde Service Partner worden vervangen. Deze onderdelen worden in de geïllustreerde onderdelencatalogus aangemerkt met "Nee". 1

Mandatory: Obrigatória—Peças cujo reparo feito pelo cliente é obrigatório. Se desejar que a HP substitua essas peças, serão cobradas as despesas de transporte e mão-de-obra do serviço.

1

Illustrated parts catalog

16

Optional: Opcional—Peças cujo reparo feito pelo cliente é opcional. Essas peças também são projetadas para o reparo feito pelo cliente. No entanto, se desejar que a HP as substitua, pode haver ou não a cobrança de taxa adicional, dependendo do tipo de serviço de garantia destinado ao produto. 3 No: Nenhuma—Algumas peças da HP não são projetadas para o reparo feito pelo cliente. A fim de cumprir a garantia do cliente, a HP exige que um técnico autorizado substitua a peça. Essas peças estão identificadas com a marca “No” (Não), no catálogo de peças ilustrado. 2

Illustrated parts catalog

17

System components

Item

Description

Spare part number

Customer self repair (on page 5)

7

LFF non-hot-plug drive bracket assembly

724493-001

Mandatory1

8

Capacitor pack

671353-001

Mandatory1

9

Front I/O module assembly

724492-001

No3

10

SATA DVD-RW optical drive (9.5 mm, 0.37 in)

724498-001

Mandatory1

11

LFF non-hot-plug 6G SATA drives (8.89 cm, 3.5 in)

—

—

a) 500 GB drive

659571-001

Mandatory1

b) 1 TB drive*

659569-001

Mandatory1

c) 2 TB drive*

659570-001

Mandatory1

d) 3 TB drive*

628183-001

Mandatory1

12

HP 150 W Integrated Power Supply

724496-001

Mandatory1

13

System battery, 3.3-V lithium

234556-001

Mandatory1

14

System board

724495-001

Mandatory1

15

Processor (include alcohol pad and thermal compound)

—

— Optional2

16

a) 2.30-GHz Intel Celeron G1610T processor, 2C, 2 MB, 730232-001 35 W b) 2.50-GHz Intel Pentium G2020T processor, 2C, 3 MB, 731127-001 35 W* DIMMs — a) 2 GB, single-rank x8 PC3-12800E-11

684033-001

Mandatory1

b) 2 GB, single-rank x8 PC3L-10600E-9*

664694-001

Mandatory1

Optional2 —

Illustrated parts catalog

18

Item

Description

Spare part number

Customer self repair (on page 5)

c) 4 GB, dual-rank x8 PC3-12800E-11*

684034-001

Mandatory1

d) 4 GB, dual-rank x8 PC3L-10600E-9*

664695-001

Mandatory1

e) 8 GB, dual-rank x8 PC3-12800E-11*

684035-001

Mandatory1

f) 8 GB, dual-rank x8 PC3L-10600E-9*

664696-001

Mandatory1

17

System fan

724491-001

Mandatory1

18

Ambient temperature sensor cable*

725205-001

No3

* Not shown Mandatory—Parts for which customer self repair is mandatory. If you request HP to replace these parts, you will be charged for the travel and labor costs of this service. 2 Optional—Parts for which customer self repair is optional. These parts are also designed for customer self repair. If, however, you require that HP replace them for you, there may or may not be additional charges, depending on the type of warranty service designated for your product. 3 No—Some HP parts are not designed for customer self repair. In order to satisfy the customer warranty, HP requires that an authorized service provider replace the part. These parts are identified as "No" in the Illustrated Parts Catalog. 1

Mandatory: Obligatoire—Pièces pour lesquelles la réparation par le client est obligatoire. Si vous demandez à HP de remplacer ces pièces, les coûts de déplacement et main d'œuvre du service vous seront facturés. 2 Optional: Facultatif—Pièces pour lesquelles la réparation par le client est facultative. Ces pièces sont également conçues pour permettre au client d'effectuer lui-même la réparation. Toutefois, si vous demandez à HP de remplacer ces pièces, l'intervention peut ou non vous être facturée, selon le type de garantie applicable à votre produit. 3 No: Non—Certaines pièces HP ne sont pas conçues pour permettre au client d'effectuer lui-même la réparation. Pour que la garantie puisse s'appliquer, HP exige que le remplacement de la pièce soit effectué par un Mainteneur Agréé. Ces pièces sont identifiées par la mention “Non” dans le Catalogue illustré. 1

Mandatory: Obbligatorie—Parti che devono essere necessariamente riparate dal cliente. Se il cliente ne affida la riparazione ad HP, deve sostenere le spese di spedizione e di manodopera per il servizio. 2 Optional: Opzionali—Parti la cui riparazione da parte del cliente è facoltativa. Si tratta comunque di componenti progettati per questo scopo. Se tuttavia il cliente ne richiede la sostituzione ad HP, potrebbe dover sostenere spese addizionali a seconda del tipo di garanzia previsto per il prodotto. 3 No: Non CSR—Alcuni componenti HP non sono progettati per la riparazione da parte del cliente. Per rispettare la garanzia, HP richiede che queste parti siano sostituite da un centro di assistenza autorizzato. Tali parti sono identificate da un “No” nel Catalogo illustrato dei componenti. 1

Mandatory: Zwingend—Teile, die im Rahmen des Customer Self Repair Programms ersetzt werden müssen. Wenn Sie diese Teile von HP ersetzen lassen, werden Ihnen die Versand- und Arbeitskosten für diesen Service berechnet. 2 Optional: Optional—Teile, für die das Customer Self Repair-Verfahren optional ist. Diese Teile sind auch für Customer Self Repair ausgelegt. Wenn Sie jedoch den Austausch dieser Teile von HP vornehmen lassen möchten, können bei diesem Service je nach den für Ihr Produkt vorgesehenen Garantiebedingungen zusätzliche Kosten anfallen. 3 No: Kein—Einige Teile sind nicht für Customer Self Repair ausgelegt. Um den Garantieanspruch des Kunden zu erfüllen, muss das Teil von einem HP Servicepartner ersetzt werden. Im illustrierten Teilekatalog sind diese Teile mit „No“ bzw. „Nein“ gekennzeichnet. 1

Mandatory: Obligatorio—componentes para los que la reparación por parte del es obligatoria. Si solicita a HP que realice la sustitución de estos componentes, tendrá que hacerse cargo de los gastos de desplazamiento y de mano de obra de dicho servicio. 2 Optional: Opcional— componentes para los que la reparación por parte del es opcional. Estos componentes también están diseñados para que puedan ser reparados por el . Sin embargo, si precisa que HP realice su sustitución, puede o no conllevar costes adicionales, dependiendo del tipo de servicio de garantía correspondiente al producto. 1

Illustrated parts catalog

19

No: No—Algunos componentes no están diseñados para que puedan ser reparados por el . Para que el haga valer su garantía, HP pone como condición que un proveedor de servicios autorizado realice la sustitución de estos componentes. Dichos componentes se identifican con la palabra “No” en el catálogo ilustrado de componentes. 3

Mandatory: Verplicht—Onderdelen waarvoor Customer Self Repair verplicht is. Als u HP verzoekt deze onderdelen te vervangen, komen de reiskosten en het arbeidsloon voor uw rekening. 2 Optional: Optioneel—Onderdelen waarvoor reparatie door de klant optioneel is. Ook deze onderdelen zijn ontworpen voor reparatie door de klant. Als u echter HP verzoekt deze onderdelen voor u te vervangen, kunnen daarvoor extra kosten in rekening worden gebracht, afhankelijk van het type garantieservice voor het product. 3 No: Nee—Sommige HP onderdelen zijn niet ontwikkeld voor reparatie door de klant. In verband met de garantievoorwaarden moet het onderdeel door een geautoriseerde Service Partner worden vervangen. Deze onderdelen worden in de geïllustreerde onderdelencatalogus aangemerkt met "Nee". 1

Mandatory: Obrigatória—Peças cujo reparo feito pelo cliente é obrigatório. Se desejar que a HP substitua essas peças, serão cobradas as despesas de transporte e mão-de-obra do serviço. 2 Optional: Opcional—Peças cujo reparo feito pelo cliente é opcional. Essas peças também são projetadas para o reparo feito pelo cliente. No entanto, se desejar que a HP as substitua, pode haver ou não a cobrança de taxa adicional, dependendo do tipo de serviço de garantia destinado ao produto. 3 No: Nenhuma—Algumas peças da HP não são projetadas para o reparo feito pelo cliente. A fim de cumprir a garantia do cliente, a HP exige que um técnico autorizado substitua a peça. Essas peças estão identificadas com a marca “No” (Não), no catálogo de peças ilustrado. 1

Illustrated parts catalog

20

Removal and replacement procedures Required tools You need the following items for some procedures:

•

T-10/T-15 Torx screwdriver (on page 74)

•

HP Insight Diagnostics (on page 63)

Safety considerations Before performing service procedures, review all the safety information.

Preventing electrostatic discharge To prevent damaging the system, be aware of the precautions you need to follow when setting up the system or handling parts. A discharge of static electricity from a finger or other conductor may damage system boards or other static-sensitive devices. This type of damage may reduce the life expectancy of the device. To prevent electrostatic damage:

•

Avoid hand by transporting and storing products in static-safe containers.

•

Keep electrostatic-sensitive parts in their containers until they arrive at static-free workstations.

•

Place parts on a grounded surface before removing them from their containers.

•

Avoid touching pins, leads, or circuitry.

•

Always be properly grounded when touching a static-sensitive component or assembly.

Symbols on equipment The following symbols may be placed on equipment to indicate the presence of potentially hazardous conditions. This symbol indicates the presence of hazardous energy circuits or electric shock hazards. Refer all servicing to qualified personnel. WARNING: To reduce the risk of injury from electric shock hazards, do not open this enclosure. Refer all maintenance, upgrades, and servicing to qualified personnel. This symbol indicates the presence of electric shock hazards. The area contains no or field serviceable parts. Do not open for any reason. WARNING: To reduce the risk of injury from electric shock hazards, do not open this enclosure.

Removal and replacement procedures

21

This symbol on an RJ-45 receptacle indicates a network interface connection. WARNING: To reduce the risk of electric shock, fire, or damage to the equipment, do not plug telephone or telecommunications connectors into this receptacle. This symbol indicates the presence of a hot surface or hot component. If this surface is ed, the potential for injury exists. WARNING: To reduce the risk of injury from a hot component, allow the surface to cool before touching. This symbol indicates that the component exceeds the recommended weight for one individual to handle safely. WARNING: To reduce the risk of personal injury or damage to the equipment, observe local occupational health and safety requirements and guidelines for manual material handling. These symbols, on power supplies or systems, indicate that the equipment is supplied by multiple sources of power. WARNING: To reduce the risk of injury from electric shock, remove all power cords to completely disconnect power from the system.

Server warnings and cautions WARNING: To reduce the risk of personal injury from hot surfaces, allow the drives and the internal system components to cool before touching them. WARNING: To reduce the risk of personal injury, electric shock, or damage to the equipment, remove the power cord to remove power from the server. The front Power On/Standby button does not completely shut off system power. Portions of the power supply and some internal circuitry remain active until AC power is removed. CAUTION: Protect the server from power fluctuations and temporary interruptions with a regulating uninterruptible power supply. This device protects the hardware from damage caused by power surges and voltage spikes and keeps the system in operation during a power failure. CAUTION: Do not operate the server for long periods with the chassis cover open or removed. Operating the server in this manner results in improper airflow and improper cooling that might lead to thermal damage. CAUTION: When installing hardware or performing maintenance procedures requiring access to internal components, HP recommends that you first back up all server data to avoid loss.

Preparation procedures To access some components and perform certain service procedures, perform one or more of the following procedures:

•

Power down the server (on page 23). Before removing a non-hot-plug component from the server, you must power down the server.

•

Open the front bezel (on page 24).

Removal and replacement procedures

22

•

Remove the front bezel (on page 25).

•

Remove the chassis cover (on page 26).

•

Remove the system board assembly (on page 28).

Power down the server Before powering down the server for any upgrade or maintenance procedures, perform a backup of critical server data and programs. WARNING: To reduce the risk of personal injury, electric shock, or damage to the equipment, remove the power cord to remove power from the server. The front Power On/Standby button does not completely shut off system power. Portions of the power supply and some internal circuitry remain active until AC power is removed. IMPORTANT: When the server is in standby mode, auxiliary power is still being provided to the system. To power down the server, use one of the following methods:

•

Press and release the Power On/Standby button. This method initiates a controlled shutdown of applications and the OS before the server enters standby mode.

•

Press and hold the Power On/Standby button for more than 4 seconds to force the server to enter standby mode. This method forces the server to enter standby mode without properly exiting applications and the OS. If an application stops responding, you can use this method to force a shutdown.

•

Use a virtual power button selection through iLO. This method initiates a controlled remote shutdown of applications and the OS before the server enters standby mode.

Before proceeding, the server is in standby mode by observing that the system power LED is amber.

Removal and replacement procedures

23

Open the front bezel If the front bezel is not secured from inside the chassis, open the bezel.

If the front bezel is secured from inside the chassis, do the following (Perform steps 1 to 3 only if the server is turned on.): 1.

Power down the server (on page 23).

2.

Disconnect the power cord from the AC source.

3.

Disconnect the power cord from the server.

4.

Remove the chassis cover (on page 26).

5.

Slide the release tab upward to unlock the front bezel from the chassis.

Removal and replacement procedures

24

6.

Open the front bezel.

Remove the front bezel If the front bezel is not secured from inside the chassis, open the front bezel, and then release the hinges from the front .

If the front bezel is secured from inside the chassis, do the following (Perform steps 1 to 3 only if the server is turned on.): 1.

Power down the server (on page 23).

2.

Disconnect the power cord from the AC source.

3.

Disconnect the power cord from the server.

4.

Remove the chassis cover (on page 26).

Removal and replacement procedures

25

5.

Slide the release tab upward to unlock the front bezel from the chassis.

6.

Open the front bezel.

7.

Release the bezel hinges from the front .

Remove the chassis cover 1.

Power down the server (on page 23).

2.

Disconnect the power cord from the AC source.

3.

Disconnect the power cord from the server.

4.

Disconnect all peripheral cables from the server.

5.

If a Kensington security cable is installed, disconnect it from the rear . See the security cable documentation for instructions.

6.

Loosen the rear thumbscrews that secure the chassis cover.

Removal and replacement procedures

26

7.

Slide the chassis cover toward the rear , and then lift it to remove it from the chassis.

Install the chassis cover 1.

Align the installation markers on the chassis cover with those located on the front edge of the chassis, and then slide the chassis cover back onto the server.

2.

Tighten the rear thumbscrews to secure the chassis cover in place.

3.

Connect the peripheral devices to the server.

4.

If a Kensington security cable was removed, connect it to the rear . See the security cable documentation for instructions.

5.

Connect the server to the network. Do one of the following:

6.

o

Connect the Ethernet cable.

o

Connect the server to the switch.

Connect the power cord to the server.

Removal and replacement procedures

27

7.

Power up the server.

Remove the system board assembly 1.

Power down the server (on page 23).

2.

Disconnect the power cord from the AC source.

3.

Disconnect the power cord from the server.

4.

Remove the chassis cover (on page 26).

5.

It is recommended that you take a picture of the current system board cable connections for reference during server reassembly.

6.

If the drive cage is connected to a storage controller board, disconnect the Mini-SAS cable from the board.

7.

Disconnect all cables connected to the system board. o

24-pin system board power supply cable

o

SATA cable (only if an optical drive is installed)

o

Mini-SAS cable (only if the drive cage is connected to the system board)

o

Front I/O cable (pulling up the blue loop to disconnect the cable)

o

Fan cable

o

Ambient temperature sensor cable (pulling up the brown loop to disconnect the cable)

In the following illustration of the system board, the gray connectors correspond to the system board cables that you must disconnect.

Removal and replacement procedures

28

8.

Press the system board tray latch.

9.

Slide the system board assembly completely out of the chassis.

Removal and replacement procedures

29

Install the system board assembly 1.

Slide the system board assembly into the chassis.

2.

Connect all cables disconnected from the system board and/or expansion board.

Drive carrier CAUTION: To prevent improper cooling and thermal damage, do not operate the server unless all bays are populated with either a component or a blank. To remove the component: 1.

Open the front bezel (on page 24).

2.

Remove the drive carrier.

To replace the component, slide the component into the bay until it clicks.

Removal and replacement procedures

30

LFF non-hot-plug drive CAUTION: To prevent improper cooling and thermal damage, do not operate the server unless all bays are populated with either a component or a blank. To remove the component: 1.

Back up all server data on the drive.

2.

Power down the server (on page 23).

3.

If the front bezel is not secured from inside the chassis, open the bezel.

4.

If the front bezel is secured from inside the chassis, do the following: a. Disconnect the power cord from the AC source. b. Disconnect the power cord from the server. c.

Remove the chassis cover (on page 26).

d. Open the front bezel.

Removal and replacement procedures

31

e. Release the bezel hinges from the front .

5.

Remove the drive.

6.

Remove the drive from the carrier.

To replace the component, reverse the removal procedure.

Removal and replacement procedures

32

Optical drive blank To remove the component: 1.

Power down the server (on page 23).

2.

Disconnect the power cord from the AC source.

3.

Disconnect the power cord from the server.

4.

Remove the chassis cover (on page 26).

5.

Press the optical drive blank release latches, and then pull the blank out of the drive bay.

To replace the component, reverse the removal procedure.

Optical drive CAUTION: To prevent improper cooling and thermal damage, do not operate the server unless all bays are populated with either a component or a blank. To remove the component: 1.

Power down the server (on page 23).

2.

Disconnect the power cord from the AC source.

3.

Disconnect the power cord from the server.

4.

Remove the chassis cover (on page 26).

5.

Disconnect the optical drive cable from the drive.

Removal and replacement procedures

33

6.

Press the optical drive release lever, and then push the drive out of the bay.

To replace the component, reverse the removal procedure.

Flash-backed write cache procedures The following types of procedures are provided for the FBWC option:

•

•

Removal and replacement of failed components: o

Removing the cache module ("FBWC module" on page 34)

o

Removing the capacitor pack ("Capacitor pack" on page 35)

Recovery of cached data from a failed server ("Recovering data from the flash-backed write cache" on page 37) CAUTION: Do not detach the cable that connects the battery pack or capacitor pack to the cache module. Detaching the cable causes all data in the cache module to be lost.

FBWC module CAUTION: The cache module connector does not use the industry-standard DDR3 mini-DIMMs. Do not use the controller with cache modules designed for other controller models, because the controller can malfunction and you can lose data. Also, do not transfer this cache module to an uned controller model, because you can lose data. CAUTION: In systems that use external data storage, be sure that the server is the first unit to be powered down and the last to be powered back up. Taking this precaution ensures that the system does not erroneously mark the drives as failed when the server is powered up. To remove the component: 1.

Power down the server (on page 23).

2.

Disconnect the power cord from the AC source.

3.

Disconnect the power cord from the server.

Removal and replacement procedures

34

4.

Remove the chassis cover (on page 26). CAUTION: When connecting or disconnecting the capacitor pack cable, the connectors on the cache module and cable are susceptible to damage. Avoid excessive force and use caution to avoid damage to these connectors.

5.

Disconnect the capacitor pack cable from the cache module.

6.

Remove the cache module.

To replace the component, reverse the removal procedure.

Capacitor pack CAUTION: In systems that use external data storage, be sure that the server is the first unit to be powered down and the last to be powered back up. Taking this precaution ensures that the system does not erroneously mark the drives as failed when the server is powered up. To remove the component: 1.

Power down the server (on page 23).

Removal and replacement procedures

35

2.

Disconnect the power cord from the AC source.

3.

Disconnect the power cord from the server.

4.

Remove the chassis cover (on page 26).

5.

If the existing cache module is connected to a capacitor pack, observe the FBWC module LEDs: o

If a backup is in progress, wait for the backup to complete.

o

If the backup is complete, or if the cache has failed, remove the controller from the server, and then continue with the next step.

6.

Disconnect the capacitor pack cable from the cache module.

7.

Open the capacitor pack holder.

8.

Remove the capacitor pack.

To replace the component, reverse the removal procedure.

Removal and replacement procedures

36

Recovering data from the flash-backed write cache If the server fails, use the following procedure to recover data temporarily stored in the FBWC. CAUTION: Before starting this procedure, read the information about protecting against electrostatic discharge ("Preventing electrostatic discharge" on page 21). 1.

Perform one of the following: o

Set up a recovery server using an identical server model. Do not install any internal drives or FBWC in this server. (HP recommends this option.)

o

Find a server that has enough empty drive bays to accommodate all the drives from the failed server and that meets all the other requirements for drive and array migration.

2.

Power down the failed server ("Power down the server" on page 23).

3.

Transfer the drives from the failed server to the recovery server.

4.

Perform one of the following:

5.

o

If the array controller has failed, remove the cache module and capacitor pack from the failed array controller, and install the cache module and capacitor pack on an identical array controller model in the recovery server.

o

If the server has failed, remove the controller, cache module, and capacitor pack from the failed server, and install the controller, cache module, and capacitor pack in the recovery server.

Power up the recovery server. If there was data in the cache at the time of the controller or server failure, a 1792 POST message appears, stating that valid data was flushed from the cache. This data is now stored on the drives in the recovery server. You can now transfer the drives (and controller, if one is used) to another server. If the drives are migrated to different drive positions or there are volumes present in the recovery server, a 1724 POST message appears, stating that logical drive configuration has been updated automatically.

Front I/O module assembly To remove the component: 1.

Power down the server (on page 23).

2.

Disconnect the power cord from the AC source.

3.

Disconnect the power cord from the server.

4.

Remove the front bezel (on page 25).

5.

Remove the chassis cover (on page 26).

6.

If installed, remove the optical drive ("Optical drive" on page 33).

7.

If installed, remove the expansion board ("Expansion board" on page 47).

8.

Remove the front cover: a. Remove the front cover screws. b. Starting from the bottom side and moving upward, release the rear side latches from their metal

tabs.

Removal and replacement procedures

37

c.

9.

To detach the cover from the chassis, push the latches toward the front.

Remove the power button/LED module: a. Release the module cable from the top chassis clips. b. Remove the module bracket screw. c.

Remove the module bracket.

Removal and replacement procedures

38

d. Press the two module latches together, and then pull the module from the chassis.

10.

Remove the front USB module: a. Remove the USB module screw. b. Pull the USB module out of the chassis.

11.

Remove the front I/O module assembly: a. Pull the blue loop to disconnect the front I/O module cable from the system board. b. Release the cable from the two chassis cable clips located on the underside of the drive cage.

Removal and replacement procedures

39

c.

Release the cable from the left-side cable clip.

d. Pull the module cable out through the top chassis opening. e. Pull the entire assembly out of the front USB module chassis opening.

To replace the component, reverse the removal procedure.

Ambient temperature sensor cable To remove the component: 1.

Power down the server (on page 23).

2.

Disconnect the power cord from the AC source.

3.

Disconnect the power cord from the server.

4.

Remove the front bezel (on page 25).

5.

Remove the chassis cover (on page 26).

Removal and replacement procedures

40

6.

Remove the ambient temperature sensor cable: a. Open the left-side chassis cable clip. b. If more working room is required, disconnect the following cables from the system board:

— System board power cable — Optical drive SATA cable — Mini-SAS cable c.

Pull the brown loop to disconnect the sensor cable from the system board.

d. Detach the cable end with the rubber stopper from the chassis.

e. Remove the rubber stopper from the sensor cable.

To replace the component, reverse the removal procedure.

LFF non-hot-plug drive cage bracket To remove the component: 1.

Power down the server (on page 23).

2.

Disconnect the power cord from the AC source.

Removal and replacement procedures

41

3.

Disconnect the power cord from the server.

4.

Open the front bezel (on page 24).

5.

Remove all drives ("LFF non-hot-plug drive" on page 31) and drive carriers ("Drive carrier" on page 30).

6.

If the chassis cover was not removed in step 4, remove it ("Remove the chassis cover" on page 26).

7.

Open the left and right side chassis cable clips to allow the drive cable removal.

8.

o

Right side cable clip

o

Left side cable clip

Disconnect the drive power cable: a. If installed, remove the optical drive ("Optical drive" on page 33). b. Pull the drive power cable out from the top chassis opening.

Removal and replacement procedures

42

c.

Disconnect the drive power cable from the PSU 4-pin drive power connector.

d. Pull the drive power cable out from the right side chassis opening.

9.

Release the Mini-SAS cable from the chassis:

Removal and replacement procedures

43

a. Disconnect the Mini-SAS cable from the system board or from a storage controller.

b. Pull the Mini-SAS cable out from the left side chassis opening toward the right side one until the

cable is released from the chassis.

10.

Remove the non-hot-plug drive cage bracket: a. Remove the bracket screws. b. To release the bracket from the chassis tabs, pull it up and move it backward.

Removal and replacement procedures

44

c.

Pull the bracket out of the chassis.

To replace the component, reverse the removal procedure.

System fan To remove the component: 1.

Power down the server (on page 23).

2.

Disconnect the power cord from the AC source.

3.

Disconnect the power cord from the server.

4.

Remove the chassis cover (on page 26).

5.

Disconnect the fan cable.

6.

Remove the screws securing the system fan, and then remove the fan.

To replace the component, reverse the removal procedure.

Removal and replacement procedures

45

Integrated power supply WARNING: To reduce the risk of personal injury from hot surfaces, allow the power supply or power supply blank to cool before touching it. To remove the component: 1.

Power down the server (on page 23).

2.

Disconnect the power cord from the AC source.

3.

Disconnect the power cord from the server.

4.

Remove the chassis cover (on page 26).

5.

If installed, remove the optical drive ("Optical drive" on page 33).

6.

Disconnect all power supply cables: a. Disconnect the PSU P1 cable from the system board, and then release it from the left-side chassis

cable clip. b. If installed, remove the optical drive ("Optical drive" on page 33). c.

Disconnect the PSU P3 cable from the 4-pin optical drive power cable.

d. Disconnect the PSU P2 cable from the 4-pin drive power cable.

7.

Remove the power supply. a. Remove the three screws from the rear side of the power supply. b. Remove the one screw from the front side of the power supply.

Removal and replacement procedures

46

c.

Remove the power supply.

To replace the component, reverse the removal procedure.

Expansion board To remove the component: 1.

Power down the server (on page 23).

2.

Disconnect the power cord from the AC source.

3.

Disconnect the power cord from the server.

4.

Remove the chassis cover (on page 26).

5.

Disconnect all cables connected to the expansion board.

6.

To open the expansion slot cover retainer latch, press it.

7.

If the expansion board is secured with a screw, remove the screw.

Removal and replacement procedures

47

8.

Remove the expansion board.

To replace the component, reverse the removal procedure.

DIMMs General DIMM slot population guidelines •

The server s a maximum of 16 GB memory using two 8 GB single-rank or dual-rank UDIMMs.

•

The server s up to 1600 MT/s ECC UDIMMs.

•

LV DIMMs operate at 1.35 V instead of the 1.5 V for standard DDR3 DIMMs. LV DIMMs can be installed in this server, but the system does not recognize the reduced power consumption feature. It will be treated as a standard DDR3 DIMM.

•

Memory speed depends on the type of processor and the number of DIMMs installed in the server. Installed DIMMs can operate at either 1600 MT/s or 1333 MT/s. For more information, see the technical specification of the installed processor.

•

When installing DIMMs, populate the 1-A DIMM slot first and, then the 2-B slot.

•

For DIMM spare replacement, install the DIMMs per slot number as instructed by the system software.

•

Use only HP qualified DIMMs.

•

The server does not :

•

o

RDIMMs

o

Non-ECC UDIMMs

The minimum DIMM requirement to make this server bootable is a DIMM in either DIMM slot.

For detailed memory configuration rules and guidelines, use the Online DDR3 Memory Configuration Tool on the HP website (http://www.hp.com/go/ddr3memory-configurator).

Removal and replacement procedures

48

Removing a DIMM 1.

Power down the server (on page 23).

2.

Disconnect the power cord from the AC source.

3.

Disconnect the power cord from the server.

4.

Remove the chassis cover (on page 26).

5.

Open the DIMM slot latches.

6.

Remove the DIMM.

To replace the component, reverse the removal procedure.

Heatsink To remove the component: 1.

Power down the server (on page 23).

2.

Disconnect the power cord from the AC source.

3.

Disconnect the power cord from the server.

4.

Remove the chassis cover (on page 26).

5.

Remove the system board assembly (on page 28). WARNING: To reduce the risk of personal injury from hot surfaces, allow the heatsink to cool before touching it. CAUTION: Heatsink retaining screws should be tightened or loosened in diagonally opposite pairs (in an "X" pattern). Do not overtighten the screws as this can damage the board, connectors, or screws. Use the wrench supplied with the system to reduce the possibility of overtightening the screws.

6.

Remove the heatsink: a. Loosen one pair of diagonally opposite screws halfway, and then loosen the other pair of screws.

Removal and replacement procedures

49

b. Completely loosen all screws in the same sequence. c.

Remove the heatsink from the processor backplate.

To replace the component: 1.

Clean the old thermal grease from the processor with the alcohol swab. Allow the alcohol to evaporate before continuing.

2.

Remove the thermal interface protective cover from the heatsink.

CAUTION: Heatsink retaining screws should be tightened or loosened in diagonally opposite pairs (in an "X" pattern). Do not overtighten the screws as this can damage the board, connectors, or screws. Use the wrench supplied with the system to reduce the possibility of overtightening the screws. 3.

Install the heatsink: a. Position the heatsink on the processor backplate. b. Tighten one pair of diagonally opposite screws halfway, and then tighten the other pair of screws.

Removal and replacement procedures

50

c.

Finish the installation by completely tightening the screws in the same sequence.

4.

Install the system board assembly (on page 30).

5.

Install the chassis cover (on page 27).

6.

Connect the power cord to the server.

7.

Connect the power cord to the AC power source.

8.

Press the Power On/Standby button. The server exits standby mode and applies full power to the system. The system power LED changes from amber to green.

Processor WARNING: To reduce the risk of personal injury from hot surfaces, allow the drives and the internal system components to cool before touching them. CAUTION: To avoid damage to the processor and system board, only authorized personnel should attempt to replace or install the processor in this server. IMPORTANT: If installing a processor with a faster speed, update the system ROM before installing the processor. To remove the component: 1.

Power down the server (on page 23).

2.

Disconnect the power cord from the AC source.

3.

Disconnect the power cord from the server.

4.

Remove the chassis cover (on page 26).

5.

Remove the system board assembly (on page 28).

6.

Remove the heatsink ("Heatsink" on page 49). CAUTION: To avoid damage to the processor, do not touch the bottom of the processor, especially the area.

Removal and replacement procedures

51

CAUTION: The pins on the processor socket are very fragile. Any damage to them may require replacing the system board. 7.

Open the processor locking lever, and then open the processor retaining bracket.

8.

Grasp the processor by the edges, and then lift it out of the socket.

To replace the component: CAUTION: Failure to completely open the processor locking lever prevents the processor from seating during installation, leading to hardware damage. CAUTION: THE PINS ON THE SYSTEM BOARD ARE VERY FRAGILE AND EASILY DAMAGED. To avoid damage to the system board: • Do not touch the processor socket s. • Do not tilt or slide the processor when lowering the processor into the socket. 1.

Install the processor. Use the notches on both sides of the processor to properly align it into the socket.

CAUTION: Be sure to close the processor socket retaining bracket before closing the processor locking lever. The lever should close without resistance. Forcing the lever closed can damage the processor and socket, requiring system board replacement.

Removal and replacement procedures

52

2.

Close the processor retaining bracket, and then secure the processor locking lever.

3.

Clean the old thermal grease from the heatsink with the alcohol swab. Allow the alcohol to evaporate before continuing.

4.

Apply all the grease to the top of the processor in the following pattern to ensure even distribution.

5.

Install the heatsink ("Heatsink" on page 49).

6.

Install the system board assembly (on page 30).

7.

Install the chassis cover (on page 27).

8.

Connect each power cord to the server.

9.

Connect each power cord to the power source.

10.

Press the Power On/Standby button. The server exits standby mode and applies full power to the system. The system power LED changes from amber to green.

System board CAUTION: To avoid ESD damage, when removing electrostatic-sensitive components from the failed system board, place the components on a static-dissipating work surface or inside separate antistatic bags.

Removal and replacement procedures

53

To remove the system board: 1.

Power down the server (on page 23).

2.

Disconnect the power cord from the AC source.

3.

Disconnect the power cord from the server.

4.

Remove the chassis cover (on page 26).

5.

Remove the system board assembly. WARNING: To reduce the risk of personal injury from hot surfaces, allow the heatsink to cool before touching it. CAUTION: Heatsink retaining screws should be tightened or loosened in diagonally opposite pairs (in an "X" pattern). Do not overtighten the screws as this can damage the board, connectors, or screws. Use the wrench supplied with the system to reduce the possibility of overtightening the screws.

6.

Remove the heatsink: a. Loosen one pair of diagonally opposite screws halfway, and then loosen the other pair of screws. b. Completely loosen all screws in the same sequence. c.

Remove the heatsink from the processor backplate.

CAUTION: To avoid damage to the processor, do not touch the bottom of the processor, especially the area. 7.

Open the processor locking lever, and then open the processor retaining bracket.

Removal and replacement procedures

54

8.

Grasp the processor by the edges, and then lift it out of the socket.

9.

Remove all DIMMs ("Removing a DIMM" on page 49).

10.

If installed, remove the expansion board ("Expansion board" on page 47).

11.

Remove the failed system board.

Removal and replacement procedures

55

To replace the system board: 1.

Install the system board.

CAUTION: Failure to completely open the processor locking lever prevents the processor from seating during installation, leading to hardware damage. CAUTION: To avoid damage to the processor, do not touch the bottom of the processor, especially the area. 2.

Open the processor locking lever, and then open the processor retaining bracket.

Removal and replacement procedures

56

3.

Remove the processor socket cover.

CAUTION: THE PINS ON THE SYSTEM BOARD ARE VERY FRAGILE AND EASILY DAMAGED. To avoid damage to the system board: • Do not touch the processor socket s. • Do not tilt or slide the processor when lowering the processor into the socket. 4.

Install the processor. Use the notches on both sides of the processor to properly align it into the socket.

CAUTION: Be sure to close the processor socket retaining bracket before closing the processor locking lever. The lever should close without resistance. Forcing the lever closed can damage the processor and socket, requiring system board replacement.

Removal and replacement procedures

57

5.

Close the processor retaining bracket, and then secure the processor locking lever.

6.

Clean the old thermal grease from the heatsink and the top of the processor with the alcohol swab. Allow the alcohol to evaporate before continuing.

7.

Apply all the grease to the top of the processor in the following pattern to ensure even distribution.

CAUTION: Heatsink retaining screws should be tightened or loosened in diagonally opposite pairs (in an "X" pattern). Do not overtighten the screws as this can damage the board, connectors, or screws. Use the wrench supplied with the system to reduce the possibility of overtightening the screws. 8.

Install the heatsink: a. Position the heatsink on the processor backplate. b. Tighten one pair of diagonally opposite screws halfway, and then tighten the other pair of screws.

Removal and replacement procedures

58

c.

Finish the installation by completely tightening the screws in the same sequence.

CAUTION: When returning a damaged system board to HP, always install all processor socket covers to prevent damage to the processor sockets and system board. 9.

Install the processor socket cover on the failed system board.

10.

Install the system board assembly (on page 30).

11.

Install the DIMMs.

12.

If removed, install the expansion board.

13.

Install the chassis cover (on page 27).

14.

Connect the power cord to the server.

15.

Connect the power cord to the AC power source.

16.

Press the Power On/Standby button. The server exits standby mode and applies full power to the system. The system power LED changes from amber to green.

After you replace the system board, you must re-enter the server serial number and the product ID. 1.

During the server startup sequence, press the F9 key to access RBSU.

Removal and replacement procedures

59

2.

Select the Advanced Options menu.

3.

Select Service Options.

4.

Select Serial Number. The following warning appears: Warning: The serial number should ONLY be modified by qualified service personnel. This value should always match the serial number located on the chassis.

5.

Press the Enter key to clear the warning.

6.

Enter the serial number and press the Enter key.

7.

Select Product ID. The following warning appears: Warning: The Product ID should ONLY be modified by qualified service personnel. This value should always match the Product ID located on the chassis.

8.

Enter the product ID and press the Enter key.

9.

Press the Esc key to close the menu.

10.

Press the Esc key to exit RBSU.

11.

Press the F10 key to confirm exiting RBSU. The server automatically reboots.

System battery If the server no longer automatically displays the correct date and time, then replace the battery that provides power to the real-time clock. Under normal use, battery life is 5 to 10 years. WARNING: The computer contains an internal lithium manganese dioxide, a vanadium pentoxide, or an alkaline battery pack. A risk of fire and burns exists if the battery pack is not properly handled. To reduce the risk of personal injury: • • • •

Do not attempt to recharge the battery. Do not expose the battery to temperatures higher than 60°C (140°F). Do not disassemble, crush, puncture, short external s, or dispose of in fire or water. Replace only with the spare designated for this product.

To remove the component: 1.

Power down the server (on page 23).

2.

Disconnect the power cord from the AC source.

3.

Disconnect the power cord from the server.

4.

Remove the chassis cover (on page 26).

5.

If installed, remove the expansion board ("Expansion board" on page 47).

6.

Locate the battery on the system board ("System board components" on page 69).

Removal and replacement procedures

60

7.

Remove the battery.

IMPORTANT: Replacing the system board battery resets the system ROM to its default configuration. After replacing the battery, reconfigure the system through RBSU. To replace the component, reverse the removal procedure. For more information about battery replacement or proper disposal, an authorized reseller or an authorized service provider.

HP Trusted Platform Module The TPM is not a customer-removable part. CAUTION: Any attempt to remove an installed TPM from the system board breaks or disfigures the TPM security rivet. Upon locating a broken or disfigured rivet on an installed TPM, s should consider the system compromised and take appropriate measures to ensure the integrity of the system data. If you suspect a TPM board failure, leave the TPM installed and remove the system board ("Remove the system board assembly" on page 28). an HP authorized service provider for a replacement system board and TPM board.

Removal and replacement procedures

61

Troubleshooting Troubleshooting resources The HP ProLiant Gen8 Troubleshooting Guide, Volume I: Troubleshooting provides procedures for resolving common problems and comprehensive courses of action for fault isolation and identification, issue resolution, and software maintenance on ProLiant servers and server blades. To view the guide, select a language:

•

English (http://www.hp.com//ProLiant_TSG_v1_en)

•

French (http://www.hp.com//ProLiant_TSG_v1_fr)

•

Spanish (http://www.hp.com//ProLiant_TSG_v1_sp)

•

German (http://www.hp.com//ProLiant_TSG_v1_gr)

•

Japanese (http://www.hp.com//ProLiant_TSG_v1_jp)

•

Simplified Chinese (http://www.hp.com//ProLiant_TSG_v1_sc)

The HP ProLiant Gen8 Troubleshooting Guide, Volume II: Error Messages provides a list of error messages and information to assist with interpreting and resolving error messages on ProLiant servers and server blades. To view the guide, select a language:

•

English (http://www.hp.com//ProLiant_EMG_v1_en)

•

French (http://www.hp.com//ProLiant_EMG_v1_fr)

•

Spanish (http://www.hp.com//ProLiant_EMG_v1_sp)

•

German (http://www.hp.com//ProLiant_EMG_v1_gr)

•

Japanese (http://www.hp.com//ProLiant_EMG_v1_jp)

•

Simplified Chinese (http://www.hp.com//ProLiant_EMG_v1_sc)

Troubleshooting

62

Diagnostic tools HP product QuickSpecs For more information about product features, specifications, options, configurations, and compatibility, see the product QuickSpecs on the HP Product Bulletin website (http://www.hp.com/go/productbulletin).

HP Insight Diagnostics HP Insight Diagnostics is a proactive server management tool, available in both offline and online versions, that provides diagnostics and troubleshooting capabilities to assist IT s who server installations, troubleshoot problems, and perform repair validation. HP Insight Diagnostics Offline Edition performs various in-depth system and component testing while the OS is not running. To run this utility, boot the server using Intelligent Provisioning. HP Insight Diagnostics Online Edition is a web-based application that captures system configuration and other related data needed for effective server management. Available in Microsoft Windows and Linux versions, the utility helps to ensure proper system operation. For more information or to the utility, see the HP website (http://www.hp.com/servers/diags). HP Insight Diagnostics Online Edition is also available in the SPP. For more information, see the HP website (http://www.hp.com/go/spp/).

HP Insight Diagnostics survey functionality HP Insight Diagnostics (on page 63) provides survey functionality that gathers critical hardware and software information on ProLiant servers. This functionality s operating systems that are ed by the server. For operating systems ed by the server, see the HP website (http://www.hp.com/go/os). If a significant change occurs between data-gathering intervals, the survey function marks the previous information and overwrites the survey data files to reflect the latest changes in the configuration. Survey functionality is installed with every Intelligent Provisioning-assisted HP Insight Diagnostics installation, or it can be installed through the SPP.

HP Insight Remote software HP strongly recommends that you install HP Insight Remote software to complete the installation or upgrade of your product and to enable enhanced delivery of your HP Warranty, HP Care Pack Service, or HP contractual agreement. HP Insight Remote supplements your monitoring continuously to ensure maximum system availability by providing intelligent event diagnosis, and automatic, secure submission of hardware event notifications to HP, which will initiate a fast and accurate resolution, based on your product’s service level. Notifications may be sent to your authorized HP Channel Partner for onsite service, if configured and available in your country.

Diagnostic tools

63

The HP Insight Remote software extends the HP enterprise remote portfolio for customers with small and medium size IT environments. The software is available in two variants:

•

HP Insight Remote 7.x software is optimized to up to 500 managed systems and can be installed on a Windows ProLiant hosting device or a Windows ESXi Virtual Machine. It can be integrated easily to work with a ed version of HP Systems Insight Manager. HP Insight Remote 7.x provides anytime, anywhere personalized access to your IT environment through HP Insight Online, and is also the recommended version for HP Proactive Care Service.

•

HP Insight Remote Advanced s medium-sized to large environments with up to 3,500 devices. It can be installed on a Windows ProLiant hosting device or a Windows ESXi Virtual Machine and requires HP Systems Insight Manager. Optionally, customers using HP Operations Manager or SAP Solution Manager to manage their environment can integrate these platforms easily to create a single view. This software is also optimized to deliver Mission Critical Services through additional features.

For more information about the Insight Remote Advanced software, see the HP website (http://www.hp.com/go/insightremote). The HP Insight Remote Release Notes detail the prerequisites, ed hardware, and associated operating systems. The release notes are available on the HP website (http://www.hp.com/go/insightremote/docs). HP Insight Remote is included as part of HP Warranty, HP Care Pack Service, or HP contractual agreement.

HP ROM-Based Setup Utility RBSU is a configuration utility embedded in HP ProLiant servers that performs a wide range of configuration activities that can include the following:

•

Configuring system devices and installed options

•

Enabling and disabling system features

•

Displaying system information

•

Selecting the primary boot controller

•

Configuring memory options

•

Language selection

For more information on RBSU, see the HP ROM-Based Setup Utility Guide on the Documentation CD or the HP website (http://www.hp.com//rbsu).

Integrated Management Log The IML records hundreds of events and stores them in an easy-to-view form. The IML timestamps each event with 1-minute granularity. You can view recorded events in the IML in several ways, including the following:

•

From within HP SIM

•

From within operating system-specific IML viewers

•

o

For Windows: IML Viewer

o

For Linux: IML Viewer Application

From within the iLO interface

Diagnostic tools

64

•

From within HP Insight Diagnostics (on page 63)

USB and functionality USB HP provides standard USB 2.0 , standard USB 3.0 , and legacy USB . Standard is provided by the OS through the appropriate USB device drivers. Before the OS loads, HP provides for USB 2.0 devices through legacy USB , which is enabled by default in the system ROM. USB 3.0 ports are not functional before the OS loads. The native OS provides USB 3.0 through appropriate xHCI drivers. Legacy USB provides USB functionality in environments where USB is not available normally. Specifically, HP provides legacy USB functionality for the following:

•

POST

•

RBSU

•

Diagnostics

•

DOS

•

Operating environments which do not provide native USB

Internal USB functionality An internal USB connector is available for use with security key devices and USB drive keys. This solution provides for use of a permanent USB key installed in the internal connector, avoiding physical access to secure data.

External USB functionality HP provides external USB to enable local connection of USB devices for server istration, configuration, and diagnostic procedures. For additional security, external USB functionality can be disabled through RBSU.

Automatic Server Recovery ASR is a feature that causes the system to restart when a catastrophic operating system error occurs, such as a blue screen, ABEND (does not apply to HP ProLiant DL980 Servers), or panic. A system fail-safe timer, the ASR timer, starts when the System Management driver, also known as the Health Driver, is loaded. When the operating system is functioning properly, the system periodically resets the timer. However, when the operating system fails, the timer expires and restarts the server. ASR increases server availability by restarting the server within a specified time after a system hang. At the same time, the HP SIM console notifies you by sending a message to a designated pager number that ASR has restarted the system. You can disable ASR from the System Management Homepage or through RBSU.

Diagnostic tools

65

Component identification Front components

Item

Description

1

USB 2.0 connectors

2

Optical drive (optional)

3

Drive bays (inside)

4

Front bezel

Component identification

66

Front LEDs and buttons

Item

Description

Status

1

Power On/Standby button and system power LED

Solid green = System on Flashing green (1 Hz/cycle per sec) = Performing power on sequence Solid amber = System in standby Off = No power present*

2

NIC status LED

Solid green = Link to network Flashing green (1 Hz/cycle per sec) = Network active Off = No network activity

3

Drive status LED

Solid green = System on Flashing green = Drive activity Off = System in standby or no power present

4

Health LED

Solid blue = Normal Flashing amber = System degraded Flashing red (1 Hz/cycle per sec) = System critical Fast-flashing red (4 Hz/cycles per sec) = Power fault**

* Facility power is not present, power cord is not attached, no power supplies are installed, power supply failure has occurred, or the power button cable is disconnected. ** To identify components in a degraded or critical state, see the iLO/BIOS logs and the server troubleshooting guide.

Component identification

67

Rear components

Item

Description

1

Kensington security slot

2

Power supply

3

Serial number/iLO information tag*

4

Power cord connector

5

Dedicated iLO connector

6

Video connector

7

USB 3.0 connectors

8

USB 2.0 connectors

9

NIC connector 2

10

NIC connector 1/shared iLO connector

11

System fan

* The serial number/iLO information tag shows the server serial number and the default iLO information. The same information is printed on separate labels located on the rear .

Component identification

68

Rear LEDs and buttons

Item

Description

Status

1

NIC link LED

Solid green = Link exists Off = No link exists

2

NIC status LED

Solid green = Link to network Flashing green (1 Hz/cycle per sec) = Network active Off = No network activity

System board components

Component identification

69

Item

Description

1

Fan connector

2

DIMM slots

3

Front I/O connector

4

Processor socket

5

TPM connector

6

System battery

7

Mini-SAS connector

8

Optical drive SATA connector

9

Ambient temperature sensor connector

10

24-pin system board power connector

11

Internal USB 2.0 connector

12

microSD card slot

13

NMI header

14

PCIe2 x16 (8, 4, 1) slot

15

System maintenance switch

Component identification

70

DIMM slot locations DIMM slots are numbered sequentially (1 through 4) for the processor. The ed AMP modes use the letter assignments for population guidelines.

System maintenance switch Position

Default

Function

S1

Off

Off = iLO security is enabled. On = iLO security is disabled.

S2

Off

Off = System configuration can be changed. On = System configuration is locked.

S3

Off

Reserved

S4

Off

Reserved

S5

Off

Off = Power-on is enabled. On = Power-on is disabled.

S6

Off

Off = No function On = ROM reads system configuration as invalid.

S7

—

Reserved

S8

—

Reserved

S9

—

Reserved

S10

—

Reserved

S11

—

Reserved

S12

—

Reserved

To access redundant ROM, set S1, S5, and S6 to on. When the system maintenance switch position 6 is set to the On position, the system is prepared to erase all system configuration settings from both CMOS and NVRAM.

Component identification

71

CAUTION: Clearing CMOS and/or NVRAM deletes configuration information. Be sure to properly configure the server or data loss could occur.

NMI functionality An NMI crash dump creates a crash dump log before resetting a system which is not responding. Crash dump log analysis is an essential part of diagnosing reliability problems, such as failures of operating systems, device drivers, and applications. Many crashes freeze a system, and the only available action for s is to restart the system. Resetting the system erases any information which could problem analysis, but the NMI feature preserves that information by performing a memory dump before a system reset. To force the system to invoke the NMI handler and generate a crash dump log, do one of the following:

•

Use the iLO Virtual NMI feature.

•

Short the NMI header ("System board components" on page 69).

For more information, see the HP website (http://h20000.www2.hp.com/bc/docs//Manual/c00797875/c00797875.pdf).

Drive numbering The server s four LFF non-hot-plug SATA drives.

Component identification

72

FBWC module LED definitions The FBWC module has three single-color LEDs (one amber and two green). The LEDs are duplicated on the reverse side of the cache module to facilitate status viewing.

1 - Amber

2 - Green

3 - Green

Interpretation

Off

Off

Off

The cache module is not powered.

Off

Flashing 0.5 Hz

Flashing 0.5 Hz

The cache microcontroller is executing from within its boot loader and receiving new flash code from the host controller.

Off

Flashing 1 Hz

Flashing 1 Hz

The cache module is powering up, and the capacitor pack is charging.

Off

Off

Flashing 1 Hz

The cache module is idle, and the capacitor pack is charging.

Off

Off

On

The cache module is idle, and the capacitor pack is charged.

Off

On

On

The cache module is idle, the capacitor pack is charged, and the cache contains data that has not yet been written to the drives.

Off

Flashing 1 Hz

Off

A backup is in progress.

Off

On

Off

The current backup is complete with no errors.

Flashing 1 Hz

Flashing 1 Hz

Off

The current backup failed, and data has been lost.

Flashing 1 Hz

Flashing 1 Hz

On

A power error occurred during the previous or current boot. Data may be corrupt.

Flashing 1 Hz

On

Off

An overtemperature condition exists.

Flashing 2 Hz

Flashing 2 Hz

Off

The capacitor pack is not attached.

Flashing 2 Hz

Flashing 2 Hz

On

The capacitor has been charging for 10 minutes, but has not reached sufficient charge to perform a full backup.

On

On

Off

The current backup is complete, but power fluctuations occurred during the backup.

On

On

On

The cache module microcontroller has failed.

Component identification

73

Fan location The server has one system fan located at the rear of the server.

T-10/T-15 Torx screwdriver The server includes a T-10/T-15 Torx screwdriver located on the front . Use this screwdriver to loosen screws during hardware configuration procedures.

Component identification

74

Cabling Cabling overview This section provides guidelines that help you make informed decisions about cabling the server and hardware options to optimize performance. For information on cabling peripheral components, refer to the white paper on high-density deployment at the HP website (http://www.hp.com/products/servers/platforms). CAUTION: When routing cables, always be sure that the cables are not in a position where they can be pinched or crimped.

Four-bay LFF non-hot-plug drive cage cabling •

Mini-SAS cable connected to the system board

Item

Description

1

4-pin power cable (connected to the PSU P2 cable)

2

Mini-SAS cable

Cabling

75

•

Mini-SAS cable connected to controller board

Item

Description

1

4-pin power cable (connected to the PSU P2 cable)

2

Mini-SAS cable

Capacitor pack cabling

Cabling

76

Optical drive cabling

Item

Description

1

4-pin power connector (connected to the PSU P3 cable) of the optical drive SATA Y-cable

2

Common end of the optical drive SATA Y-cable

3

SATA connector of the optical drive SATA Y-cable

Front I/O assembly cabling

Cabling

77

Ambient temperature sensor cabling

System fan cabling

Cabling

78

Power supply cabling

Item

PSU cable marker

Description

1

P3

4-pin optical drive power cable

2

P2

4-pin drive power cable

3

P1

24-pin system board power cable

Cabling

79

Specifications Environmental specifications Specification

Value

Temperature range* Operating

10°C to 35°C (50°F to 95°F)

Nonoperating

-30°C to 60°C (-22°F to 140°F)

Relative humidity (noncondensing) Operating, maximum wet bulb 10% to 90% temperature of 28°C (82.4°F) Nonoperating, maximum wet 5% to 95% bulb temperature of 38.7°C (101.7°F)

* All temperature ratings shown are for sea level. An altitude derating of 1°C per 304.8 m (1.8°F per 1,000 ft) to 3048 m (10,000 ft) is applicable. No direct sunlight allowed.

Server specifications Specification

Server

Height

23.25 cm (9.15 in)

Depth

24.50 cm (9.65 in)

Width

23.00 cm (9.06 in)

Weight, minimum (one drive, power supply, and processor installed)

7.40 kg (16.31 lb)

Weight, maximum (all drives, power supply, and processor installed)

9.80 kg (21.60 lb)

Power supply specifications The server s one HP 150 W Integrated Power Supply. CAUTION: Check the system and power supply input ratings before powering up the server.

HP 150 W Integrated Power Supply Specification

Value

Input requirements

—

Specifications

80

Rated input voltage

100 V AC to 240 V AC

Rated input frequency

47 Hz to 63 Hz

Rated input current

3.5 A

Rated input power

150 W

Efficiency (minimum)

70%

Power supply output

—

Rated steady-state power

150 W

Maximum peak power

200 W

Rated output power

150 W

Specifications

81

Acronyms and abbreviations ABEND abnormal end

AMP Advanced Memory Protection

ASR Automatic Server Recovery

CSR Customer Self Repair

DDR3 double data rate-3

FBWC flash-backed write cache

HP SIM HP Systems Insight Manager

iLO Integrated Lights-Out

IML Integrated Management Log

LFF large form factor

LV DIMM low-voltage DIMM

NMI nonmaskable interrupt

Acronyms and abbreviations

82

NVRAM nonvolatile memory

PCIe Peripheral Component Interconnect Express

POST Power-On Self Test

PSU power supply unit

RBSU ROM-Based Setup Utility

RDIMM ed dual in-line memory module

SAS serial attached SCSI

SATA serial ATA

SD Secure Digital

SPP HP Service Pack for ProLiant

TPM Trusted Platform Module

UDIMM uned dual in-line memory module

USB universal serial bus

Acronyms and abbreviations

83

Documentation HP is committed to providing documentation that meets your needs. To help us improve the documentation, send any errors, suggestions, or comments to Documentation (mailto:[email protected]). Include the document title and part number, version number, or the URL when submitting your .

Documentation 84

Index A ambient temperature sensor cable 40 ambient temperature sensor, cabling 78 Automatic Server Recovery (ASR) 65

B bezel, opening 24 bezel, removing 25

C cabling, drive cage 75 cabling, FBWC 76 cabling, front I/O 77 cabling, internal power 79 cabling, optical drive 77 cache module 34, 73 capacitor pack 35 capacitor pack cabling 76 chassis cover, installing 27 chassis cover, removing 26 clearing NVRAM 71 CMOS 71 components, front 66 components, mechanical 15 components, rear 68 components, system board 69 crash dump analysis 72 customer self repair (CSR) 5

D data recovery 37 diagnostic tools 63, 65 dimensions and weight 80 DIMM population guidelines 48 DIMM slot locations 71 DIMMs, low-voltage 48, 49 documentation 84 drive cabling 75 drive carrier 30 drive LEDs 67 drive numbering 72

drive, removing 30 drives, determining status of 67

E electrostatic discharge 21 environmental specifications 80 error messages 62 expansion board 47 external USB functionality 65

F fan cabling 78 fan location 74 FBWC module 34 FBWC module LEDs 73 flash-backed write cache procedures 34, 37 front bezel 24 front I/O assembly 37 front I/O cabling 77 front buttons 67 front components 66 front LEDs 67

H health driver 65 health LED 67 heatsink 49 HP Insight Diagnostics 63 HP Insight Diagnostics survey functionality 63 HP Insight Remote software 63 HP Systems Insight Manager (SIM) 63, 64 humidity 80

I illustrated parts catalog 15 iLO connector 68 Integrated Lights-Out (iLO) 64 Integrated Management Log (IML) 64 integrated power supply 46 internal USB connector 69 internal USB functionality 65

Index 85

K

Q

Kensington security slot 68

QuickSpecs 63

L

R

LED, system power 67 LEDs, drive 67 LEDs, FBWC module 73 LEDs, front 67 LEDs, NIC 67, 69 LEDs, rear 69 low-voltage DIMMs 48

rear buttons 69 rear components 68 rear LEDs 69 recovering the data from the cache 37 re-entering the server serial number 53 removal and replacement procedures 21 replacement procedures 21 required tools 21 requirements, environmental 80 ROM legacy USB 65 ROM-Based Setup Utility (RBSU) 64

M mechanical components 15 mechanical specifications 80 memory dump 72 memory module population guidelines 48 microSD card slot 69

N NIC connectors 68 NMI functionality 72 NMI header 69, 72 non-hot-plug drive cage bracket 41 non-hot-plug drives, removing 30

O operating system crash 72 operating systems ed 63 optical drive 33 optical drive blank 32 optical drive cabling 77

P part numbers 15 POST error messages 62 power down procedure 23 power supply 46 power supply cabling 79 power supply specifications 80 powering down 23 power-on 71 preparation procedures 22 processor option 18, 51 processor socket cover 51

S safety considerations 21 SATA drives 15, 18 serial number 68 serial number/iLO information tag 68 server warnings and cautions 22 spare part numbers 15 specifications, environmental 80 specifications, power supply 80 specifications, server 80 static electricity 21 symbols on equipment 21 system battery 60 system board 18, 53 system board assembly 15 system board assembly, installing 30 system board assembly, removing 28 system board components 69 system board replacement 53 system components 18, 66 system configuration settings 71 system fan 45, 74 system fan cabling 78 system maintenance switch 71

T T-10/T-15 Torx screwdriver 74 temperature requirements 80 TPM connector 69 troubleshooting resources 62 Trusted Platform Module (TPM) 61

Index 86

U USB connectors 69 USB 65 utilities 63

V video connector 69

W warnings 22 weight 80

Index 87
