Introduction This chapter explains how to use the Service Tests, Utilities and Calibration. Each part is shown step by step in order that it is displayed on the Front . If the Test, Utility or Calibration should fail and display a system error, we explain where to go in the Service Manual to either troubleshoot the error of fix it directly. NOTE: If possible, always perform the related Service Test on a component that you are about to replace, to confirm it has failed.

Diagnostics - Self Test Whenever the Printer is switched ON, it automatically performs a series of internal self tests and mechanical initialization sequences. If any of the parts fail during this test, a system error will display and you should consult “System Error Codes and Warnings - Explanation” on page 92.

Phone Some of the tests, utilities and calibrations are simple to perform and there are parts of this chapter that a Call Agent can use to fix the printer over the phone by asking the customer to perform some of the procedures shown here. These procedures have a telephone icon in the corner of the page.

Tests, Utilities & Calibrations

that the Key combination for the Customer to Enter the Service Tests and Utilities is different from the one that the Customer Engineer will use.

Service Tests Entering the Diagnostic Service Tests Menu 1.

Make sure the printer is switched OFF from the power switch on the front of the printer and NOT from the power switch on the back of the printer.

2.

For Call Agents who will request the to Perform certain troubleshooting action, hold the Down arrow key and the Cancel key down and switch the printer ON using the front power switch. Wait until you hear one beep (usually after 5 seconds) before releasing ALL three keys.

ON PH

ES

RT PO P U

Switch Printer ON

Hold Cancel key

138 Chapter 4 Service Tests, Utilities & Calibrations

Hold DOWN key

3.

For On-Site Engineers, hold the Up arrow key and the Cancel key down and switch the printer ON using the front power switch. Wait until you hear one beep (usually after 5 seconds) before releasing ALL three keys.

ON

-

AI R REP E SIT

Hold UP key

Switch Printer ON

Hold Cancel key

4.

Once inside the Service Tests Menu use the Arrow keys to scroll through the “Service Tests” selections. Press the OK key to select the highlighted option. Press OK to confirm selection

NOTE: The diagnostic tests work in a special Mode which does NOT require the full Initialization of the Printer. Therefore it is important that once you have finished with the tests, you MUST power OFF the Printer and Power ON again before trying to print.

1. Interface Menu 1.1 Front Description The Front diagnostic test checks the following components and processes.

•

Front to formatter communication test

•

Front key test

•

Front beeper test

•

Front display test (pixels)

Procedure 1. Go to Diagnostic test>1. Interface Menu>1.1 Front , and press OK.

2.

The printer checks that the Front is able to communicate correctly with the Formatter. The printer tests Front communication and displays the hardware and firmware versions on the Front .

Service Tests

139

Tests, Utilities & Calibrations

Use UP and DOWN keys to select
