Rexnord and Link-Belt Roller Chains

Section Index Description

Page

A – Introduction Introduction

A-2

B – Drive Chains Standard Roller Chains

B-1

SU and H Series Chains

B-4

Double Pitch Drive Chains

B-6

Extra Clearance Chains

B-6

Corrosion Resistant Chains

B-7

O-Ring Chains

B-8

C – Drive Engineering Engineering Recommendations

C-1

Specifications, Dimensions and Ratings

C-9

Lubrication

C-45

Drive Installation

C-47

D – Conveyor Chains Conveyor Chains Introduction

D-1

Standard Roller Chains and Attachments

D-2

Double Pitch Roller Chains and Attachments

D-4

Redi-Lube Chain

D-8

Hollow Pin Chain

D-10

Side Bow Chain

D-14

Block Chain

D-15

E – Conveyor Engineering Engineering Recommendations

E-1

Selection Procedure

E-4

Layouts and Formulas

E-6

Selection Example

E-8

Lubrication

E-9

Sprocket Data

E-10

F – British Standard Standard Roller Chain

F-1

RC for Heavy Drives and Lifting Applications

F-4

RC with Straight Link Plates

F-4

RC with Thermoplastic Bearings

F-5

Hollow Pin

F-6

Side Bow

F-7

Double Pitch Roller Chain

F-8

G – General Products and Information Specifications

G-1

Sprocket Reference Data

G-2

Chain and Parts Packaging

G-3

Chain Parts Standards

G-4

Chain Repair Tools

G-5

H – Technical Data Technical Data

H-1

Chain Index

H-3

A

Link-Belt and Rexnord Roller Chains Drives

Standard roller chain is broadly used in power transmission applications ranging from general industrial applications to demanding oil field service to operation in such specialized areas as food processing and heavy construction equipment.

Standard roller chain/single strand

Single and multiple standard roller chains, available in many sizes, meet most drive requirements. Specifications are shown on pages B-1 through B-3. Double-pitch drive chains frequently prove the economical choice for slower speed drives on relatively long centers. For details, see page B-6. Modifications of these chains, developed for special operating conditions, are described below.

Standard roller chain/multiple strand

Corrosion resistance—Standard roller chain made of stainless steel provides excellent performance in applications requiring high resistance to corrosive attack. See page B-7.

Shock resistance - Link-Belt SU and Rexnord Heavy "H" series roller chain provides additional capacity to withstand intermittent shock loading. Features include improved fatigue resistance, thicker sidebars, and heat-treated pins. See page B-4.

Side bow roller chain1 - Extra clearance chain with ability to flex and twist. Ideal for use on curved conveyors or to transmit power under misaligned sprocket conditions. Available in 3/8” to 1” single pitch. See page D-15.

Hollow pin chain1 - The versatile conveyor chain. Constructed with special pin links which have hollow pins assembled in the pin plates. This unique design allows easy insertion of cross rods or attachments to preassembled chain at desired spacings. Attachments can be repositioned without removing chain from conveyor. It is available in single and double-pitch with or without Carrier Rollers. Full line of standard attachments available. See page D-11. 1

Double-pitch drive chain

Extra clearance - Trans-Flex® chain is designed for severe duty applications, such as in transit mixers, crawler drives, and other uses requiring delivery of full power despite recurrent sprocket misalignment. See page B-6.

ULTR-O-LIFETM O-ring roller chain1 - Uses square cross sectional O-rings to seal in special lube while sealing out dirt, moisture and other contaminants. Available in 5/8” thru 1 1/4” pitch single pitch series. Runs on standard ANSI sprockets. See page B-8.

Block chain1 - Used in light load, low speed conveyors. Consisting of block links (solid or laminated) and link plates ed by pins, all block chains are 1” pitch and vary in width of block from 3/16” to 1/2”. See page D-16.

REDI-LUBETM chain1 - Selflubricating, heavy walled, oilimpregnated, sintered steel bushings replace bushing and roller of standard ANSI chain. Available in single and double-pitch. Full range of standard attachments also available. See page D-9.

Conveyors

Restricted lubrication

Standard and double-pitch conveyor chains are available with a selection of attachments to accommodate slats, angles, rollers, crossroads, and other conveying devices. See pages D-3 through D-8.

Double-pitch roller chain with largediameter rollers combines smooth, quiet operation and long life. This modification proves particularly useful in applications requiring minimum lubrication or where conditions make lubrication difficult. See page D-6.

Available only in Link-Belt Brand

A-2 (7010)

Dimensions and other engineering data are subject to change. Certified specifications of ordered product furnished upon request.

B

Link-Belt and Rexnord Drive Chains Standard roller chains

T T

G G

E E D D

PITCH PITCH

C C F F

B B

A A

Single Strand Chain Number

Chain pitch, inches

Fig. 6453 Fig. 6453

Average Ultimate strength, pounds

Min. ANSI UTS, pounds

Dimensions, inches

Weight per foot, pounds

A

B

C

D

Page references

E

F

G

HP ratings

T

Sprocket data

25 ∆

.250

940

781

.08

.15

.19

.090

.130

.13

.20

.23

.03

C- 9

C-10

35 ∆

.375

2,100

1,758

.22

.24

.31

.141

.200

.19

.31

.35

.05

C-11

C-12

40 ∆

.500

3,700

3,125

.39

.32

.38

.156

.313

.31

.41

.47

.06

C-13

C-14

41 ∆

.500

2,000

1,500

.27

.27

.32

.141

.306

.25

.32

.38

.05

C-15

C-16

50 ∆

.625

6,100

4,882

.70

.41

.48

.200

.400

.38

.52

.59

.08

C-17

C-18

60

.750

8,500

7,030

1.02

.50

.60

.234

.469

.50

.60

.71

.09

C-19

C-20

80

1.000

14,500

12,500

1.67

.63

.74

.312

.625

.63

.75

.91

.13

C-21

C-22

100

1.250

26,000

19,530

2.72

.76

.89

.375

.750

.75

.97

1.13

.16

C-23

C-24

120

1.500

36,500

28,125

3.72

.96

1.13

.438

.875

1.00

1.13

1.38

.19

C-25

C-26

140

1.750

48,500

38,280

4.69

1.02

1.21

.500

1.000

1.00

1.31

1.56

.22

C-27

C-28

160

2.000

68,000

50,000

6.12

1.23

1.41

.563

1.125

1.25

1.56

1.81

.25

C-29

C-30

180

2.250

86,000

63,280

9.06

1.39

1.56

.688

1.406

1.41

1.85

2.14

.28

C-31

C-32

200

2.500

100,000

78,125

10.9

1.54

1.89

.781

1.563

1.50

1.94

2.31

.31

C-33

C-34

240

3.000

152,200

112,500

16.4

1.85

2.20

.938

1.875

1.88

2.44

2.81

.38

C-35

C-36

G G

K K

T T

E E

PITCH PITCH

D D C C F F

Chain Number

Chain pitch, inches




B B

A A

Double Strand

Dimensions, inches A

B

C

D

E

F

Fig. 6445 Fig. 6445

Page references

G

K

T

HP Sprocket ratings data

35-2 ∆

.375

4,200

3,516

.42

.45

.50

.141

.200 s

.19

.31

.35

.399

.05

C-11

C-12

40-2 ∆

.500

7,400

6,250

.79

.60

.67

.156

.313

.31

.41

.47

.566

.06

C-13

C-14

50-2 ∆

.625

12,200

9,764

1.39

.76

.83

.200

.400

.38

.52

.59

.713

.08

C-17

C-18

60-2

.750

17,000

14,060

2.00

.95

1.05

.234

.469

.50

.60

.71

.897

.09

C-19

C-20

80-2

1.000

29,000

25,000

3.31

1.21

1.30

.312

.625

.63

.75

.91

1.153

.13

C-21

C-22

100-2

1.250

52,000

39,060

5.19

1.46

1.59

.375

.750

.75

.97

1.13

1.408

.16

C-23

C-24

120-2

1.500

73,000

56,250

7.38

1.84

2.02

.438

.875

1.00

1.13

1.38

1.789

.19

C-25

C-26

140-2

1.750

97,000

76,560

9.25

1.98

2.17

.500

1.000

1.00

1.31

1.56

1.924

.22

C-27

C-28

160-2

2.000

136,000

100,000

12.5

2.38

2.56

.563

1.125

1.25

1.56

1.81

2.305

.25

C-29

C-30

180-2

2.250

172,000

126,560

17.6

2.69

2.86

.688

1.406

1.41

1.85

2.14

2.592

.28

C-31

C-32

200-2

2.500

200,000

156,250

21.0

2.96

3.31

.781

1.563

1.50

1.94

2.31

2.817

.31

C-33

C-34

240-2

3.000

304,400

225,000

32.2

3.58

3.93

.938

1.875

1.88

2.44

2.81

3.458

.38

C-35

C-36

∆ Available only in riveted construction. All other sizes may be furnished cottered or riveted. s Bushing diameter. Chain is rollerless. Dimensions and other engineering data are subject to change. Certified specifications of ordered product furnished upon request.

(7010) B-1

B G

K

K

T

E

PITCH

D

C F

B

A

Triple Strand Chain Number

Chain pitch, inches

Fig. 6446





B

C

D

E

Page references

F

G

K

T


35-3

.375

6,300

5,274

.62

.63

.70

.141

.200 s

.19

.31

.35

.399

.05

C-11

C-12

40-3 ∆

.500

11,100

9,375

1.18

.89

.95

.156

.313

.31

.41

.47

.566

.06

C-13

C-14

50-3 ∆

.625

18,300

14,646

2.09

1.12

1.19

.200

.400

.38

.52

.59

.713

.08

C-17

C-18

60-3

.750

25,500

21,090

3.00

1.40

1.50

.234

.469

.50

.60

.71

.897

.09

C-19

C-20

80-3

1.000

43,500

37,500

4.97

1.78

1.87

.312

.625

.63

.75

.91

1.153

.13

C-21

C-22

100-3

1.250

78,000

58,590

7.67

2.16

2.29

.375

.750

.75

.97

1.13

1.408

.16

C-23

C-24

120-3

1.500

109,500

84,375

11.0

2.74

2.91

.438

.875

1.00

1.13

1.38

1.789

.19

C-25

C-26

140-3

1.750

145,500

114,840

13.8

2.94

3.13

.500

1.000

1.00

1.31

1.56

1.924

.22

C-27

C-28

160-3

2.000

204,000

150,000

18.6

3.52

3.71

.563

1.125

1.25

1.56

1.81

2.305

.25

C-29

C-30

180-3

2.250

258,000

189,840

26.9

3.98

4.15

.688

1.406

1.41

1.85

2.14

2.592

.28

C-31

C-32

200-3

2.500

300,000

234,375

31.5

4.38

4.73

.781

1.563

1.50

1.94

2.31

2.817

.31

C-33

C-34

240-3

3.000

456,600

337,500

49.4

5.31

5.75

.938

1.875

1.88

2.44

2.81

3.458

.38

C-35

C-36

G

K

K

K

T

E

PITCH

D C F

B

A

Quadruple Strand Chain Number

Chain pitch, inches


Fig. 6447




B

C

D

E

F

Page references G

K

T


35-4 ∆

.375

8,400

7,032

.82

.78

.91

.141

.200 s

.19

.31

.35

.399

.05

C-11

C-12

40-4 ∆

.500

14,800

12,500

1.57

1.17

1.23

.156

.313

.31

.41

.47

.566

.06

C-13

C-14

50-4 ∆

.625

24,400

19,528

2.76

1.48

1.54

.200

.400

.38

.52

.59

.713

.08

C-17

C-18

60-4

.750

34,000

28,120

3.83

1.84

1.95

.234

.469

.50

.60

.71

.897

.09

C-19

C-20

80-4

1.000

58,000

50,000

6.76

2.35

2.44

.312

.625

.63

.75

.91

1.153

.13

C-21

C-22

100-4

1.250

104,000

78,120

10.1

2.86

2.99

.375

.750

.75

.97

1.13

1.408

.16

C-23

C-24

120-4

1.500

146,000

112,500

14.7

3.63

3.81

.438

.875

1.00

1.13

1.38

1.789

.19

C-25

C-26

140-4

1.750

194,000

153,120

18.4

3.90

4.09

.500

1.000

1.00

1.31

1.56

1.924

.22

C-27

C-28

160-4

2.000

272,000

200,000

24.8

4.67

4.86

.563

1.125

1.25

1.56

1.81

2.305

.25

C-29

C-30

180-4

2.250

344,000

253,120

35.8

5.28

5.45

.688

1.406

1.41

1.85

2.14

2.592

.28

C-31

C-32

200-4

2.500

400,000

312,500

43.2

5.80

6.14

.781

1.563

1.50

1.94

2.31

2.817

.31

C-33

C-34

240-4

3.000

608,800

450,000

65.7

7.04

7.38

.938

1.875

1.88

2.44

2.81

3.458

.38

C-35

C-36

∆ Available only in riveted construction. All other sizes may be furnished cottered or riveted. s Bushing diameter. Chain is rollerless.

B-2 (7010)


B

Link-Belt and Rexnord Drive Chains Standard roller chains

G

K

K

K

K

T

E

PITCH

D

C F

B

A

Quintuple Strand Chain Number

Chain pitch, inches

Fig. 6448



Dimensions, inches


A

B

C

D

E

Page references

F

G

K

T


35-5 ∆

.375

10,500

8,790

1.06

1.03

1.11

.141

.200 s

.19

.31

.35

.399

.05

C-11

C-12

40-5 ∆

.500

18,500

15,625

1.97

1.45

1.52

.156

.313

.31

.41

.47

.566

.06

C-13

C-14

50-5 ∆

.625

30,500

24,410

3.15

1.84

1.90

.200

.400

.38

.52

.59

.713

.08

C-17

C-18

60-5

.750

42,500

35,150

5.02

2.30

2.40

.234

.469

.50

.60

.71

.897

.09

C-19

C-20

80-5

1.000

72,500

62,500

8.21

2.92

3.03

.313

.625

.63

.75

.91

1.153

.13

C-21

C-22

100-5

1.250

130,000

97,650

12.7

3.56

3.69

.375

.750

.75

.97

1.13

1.408

.16

C-23

C-24

120-5

1.500

182,500

140,625

18.4

4.52

4.70

.438

.875

1.00

1.13

1.38

1.789

.19

C-25

C-26

140-5

1.750

242,500

191,400

22.9

4.86

5.05

.500

1.000

1.00

1.31

1.56

1.924

.22

C-27

C-28

160-5

2.000

340,000

250,000

31.9

5.82

6.00

.563

1.125

1.25

1.56

1.81

2.305

.25

C-29

C-30

180-5

2.250

430,000

316,400

44.7

6.57

6.74

.688

1.406

1.41

1.85

2.14

2.592

.28

C-31

C-32

200-5

2.500

500,000

390,625

53.9

7.22

7.56

.781

1.563

1.50

1.94

2.31

2.817

.31

C-33

C-34

240-5

3.000

761,000

562,500

82.0

8.76

9.11

.938

1.875

1.88

2.44

2.81

3.458

.38

C-35

C-36

G

K

K

K

K

K

T

E

PITCH

D

C F

B

A Fig. 6449

Sextuple Strand Chain Number

Chain pitch, inches





B

C

D

E

F

Page references G

K

T


35-6 ∆

.375

12,600

10,548

1.27

1.23

1.31

.141

.200 s

.19

.31

.35

.399

.05

C-11

C-12

40-6 ∆

.500

22,200

18,750

2.36

1.73

1.80

.156

.313

.31

.41

.47

.566

.06

C-13

C-14

50-6 ∆

.625

36,600

29,292

3.77

2.19

2.25

.200

.400

.38

.52

.59

.713

.08

C-17

C-18

60-6

.750

51,000

42,180

6.02

2.75

2.85

.234

.469

.50

.60

.71

.897

.09

C-19

C-20

80-6

1.000

87,000

75,000

9.84

3.50

3.61

.313

.625

.63

.75

.91

1.153

.13

C-21

C-22

100-6

1.250

156,000

117,180

15.2

4.26

4.39

.375

.750

.75

.97

1.13

1.408

.16

C-23

C-24

120-6

1.500

219,000

168,750

22.0

5.42

5.59

.438

.875

1.00

1.13

1.38

1.789

.19

C-25

C-26

140-6

1.750

291,000

229,680

27.4

5.82

6.01

.500

1.000

1.00

1.31

1.56

1.924

.22

C-27

C-28

160-6

2.000

408,000

300,000

38.3

6.97

7.15

.563

1.125

1.25

1.56

1.81

2.305

.25

C-29

C-30

180-6

2.250

516,000

379,680

53.6

7.87

8.04

.688

1.406

1.41

1.85

2.14

2.592

.28

C-31

C-32

200-6

2.500

600,000

468,750

64.6

8.64

8.98

.781

1.563

1.50

1.94

2.31

2.817

.31

C-33

C-34

240-6

3.000

913,200

675,000

98.4

10.50

10.84

.938

1.875

1.88

2.44

2.81

3.458

.38

C-35

C-36

∆ Available only in riveted construction. All other sizes may be furnished cottered or riveted. s Bushing diameter. Chain is rollerless. Minimum order quantities may be required in some parts. Dimensions and other engineering data are subject to change. Certified specifications of ordered product furnished upon request.

(7010) B-3

B

SU (Super Ultimate) and H (Heavy) Series Chains Link-Belt SU and Rexnord H series chains differ from standard roller chains in sidebar thickness and in pin material and heat treatment. The combination of increased sidebar thickness and high hardness alloy through hardened pins results in greater average ultimate tensile strength ratings for the SU and H series chains. The SU and H chains are capable of withstanding higher operating and intermittent shock loading without reduction of pin-bushing wear life. Multiple width SU and H series chains are available. SU and H series single strand roller chains operate on standard series roller chain sprockets. However, multiple strand heavy series chains require sprockets with rows of teeth with wider spacing to accommodate the thicker chain sidebars. See page B-5. T

G

E

PITCH

D

C F

B

A Fig. 6453

SU series Average Chain pitch, Ultimate inches strength, Rexnord pounds

Chain Number Link-Belt

t bearing area, square inches


A

B

C

D

E

F

G

T

Sprocket data

Page references

Dimensions, inches

60H ∆

60H∆

.750

8,500

.176

1.23

.56

.65

.234

.469

.50

.60

.69

.13

C-20

80SU

80H

1.000

17,500

.295

1.95

.69

.81

.313

.625

.63

.75

.91

.16

C-22

100SU

100H

1.250

29,000

.427

2.84

.83

.95

.375

.750

.75

.97

1.13

.19

C-24

120SU

120H

1.500

41,000

.636

4.14

1.02

1.19

.438

.875

1.00

1.13

1.38

.22

C-26

140SU

140H

1.750

56,000

.759

5.17

1.08

1.27

.500

1.000

1.00

1.31

1.56

.25

C-28

160SU

160H

2.000

70,000

1.028

6.92

1.29

1.47

.563

1.125

1.16

1.56

1.81

.28

C-30

180SU

180H

2.250

95,000

1.413

9.54

1.45

1.62

.688

1.406

1.41

1.85

2.14

.31

C-32

264 n

64S

2.500

135,000

2.023

12.45

1.674

2.018

.875

1.562

1.50

2.05

2.38

.38

C-34

∆ Case hardened pin. 60 n Replaces 250S and runs on 200 sprockets. Have dimensions certified for installation purposes.

B-4 (7010)


B

Sprocket Tooth Profile - Heavy Series Roller Chain Single strand heavy series roller chain can be used with ANSI standard series roller chain sprockets of corresponding pitch. However, multiple strand heavy series roller chain cannot be used with the standard series sprockets, b ecause of the extra thickness of link plates on the heavy series. Sprockets for multiple strand heavy series roller chain must be made to order.

Single Strand Dimensions, inches

B

Chain No.

Pitch

B

E

F

R

60H

.750

0.459

0.375

0.272

0.796

80SU

1.000

0.575

0.500

0.325

1.062

F

1.250

0.692

0.625

0.380

1.327

1.500

0.924

0.750

0.549

1.593

140SU

1.750

0.924

0.875

0.487

1.858

160SU

2.000

1.156

1.000

0.656

2.124

180SU

2.250

1.301

1.125

0.740

2.392

264

2.500

1.389

1.250

0.764

2.654

PITCH DIA.

100SU 120SU

E

R

SINGLE

Double Strand Dimensions, inches Chain No.

Pitch

A

B

D

E

F

G

60H-2

.750

1.471

0.444

0.583

0.375

0.257

1.027

80SU-2

1.000

1.839

0.556

0.727

0.500

0.306

1.283

100SU-2

1.250

2.210

0.670

0.870

0.625

0.358

1.540

120SU-2

1.500

2.820

0.894

1.032

0.750

0.519

1.926

140SU-2

1.750

2.949

0.894

1.161

0.875

0.457

2.055

160SU-2

2.000

3.555

1.119

1.317

1.000

0.619

2.436

180SU-2

2.250

4.248

1.259

1.730

1.125

0.700

2.989

264-2

2.500

4.426

1.344

1.738

1.250

0.719

3.082

B

A D G F E

DOUBLE

Triple Strand Dimensions, inches Chain No.

Pitch

A

B

D

E

F

G

60H-3

.750

2.498

0.444

0.583

0.375

0.257

1.027

80SU-3

1.750

3.122

0.556

0.727

0.500

0.306

1.283

100SU-3

1.250

3.750

0.670

0.870

0.625

0.358

1.540

120SU-3

1.500

4.746

0.894

1.032

0.750

0.519

1.926

140SU-3

1.750

5.004

0.894

1.161

0.875

0.457

2.055

160SU-3

2.000

5.991

1.119

1.317

1.000

0.619

2.436

180SU-3

2.250

7.237

1.259

1.730

1.125

0.700

2.989

264-3

2.500

7.508

1.344

1.738

1.250

0.719

3.082

B

D G

A G

F

E

TRIPLE

Quadruple Strand Dimensions, inches Chain No.

Pitch

A

B

D

E

F

G

60H-4

.750

3.499

0.418

0.609

0.375

0.231

1.027

80SU-4

1.000

4.375

0.526

0.757

0.500

0.276

1.283

100SU-4

1.250

5.253

0.633

0.907

0.625

0.321

1.540

120SU-4

1.500

6.626

0.848

1.078

0.750

0.473

1.926 2.055

140SU-4

1.750

7.013

0.848

1.207

0.875

0.411

160SU-4

2.000

8.371

1.063

1.373

1.000

0.563

2.436

180SU-4

2.250

10.170

1.203

1.786

1.125

0.640

2.989

264-4

2.500

10.524

1.278

1.804

1.250

0.653

3.082

B

QUADRUPLE

D G

A G

G

F

E


(7010) B-5

B

Link-Belt and Rexnord Drive Chains Double-pitch drive chains

CHAIN PITCH

Double-pitch drive chains are dimensionally identical to standard roller chains of the same strength, except for pitch length, which is “doubled”. With only one-half the number of pins, bushings , and rollers, double-pitch chains are lighter and more economical than standard roller chains and are ideal for slow and moderate speed applications, particularly when shaft centers are relatively long. Sprockets for double-pitch drive chains are normally furnished with two times the number of teeth required to the chain. As illustrated at right, the relationship between chain pitch and roller diameter results in adequate space for a second set of teeth, which substantially increases sprocket life.

A

C

D

E

B T PITCH

PITCH

F

G Fig. 7031

Average Chain Chain pitch, Ultimate Number inches strength, pounds



A

B

C

D

E

F

G

T

Dimensions, inches

Page references HP ratings Sprocket data

2040 ∆

1.000

3,900

.068

.28

.32

.38

.156

.313

.31

.39

.45

.06

C-37

C-38

2050 ∆

1.250

6,300

.108

.41

.41

.48

.200

.400

.38

.48

.55

.08

C-39

C-40

2060

1.500

8,500

.162

.65

.50

.60

.234

.469

.50

.60

.71

.09

C-41

C-42

2060 H

1.500

8,500

.176

.79

.56

.64

.234

.469

.50

.60

.71

.13

C-41

C-42

2080

2.000

16,000

.275

1.10

.63

.74

.313

.625

.63

.75

.91

.13

C-43

C-44

∆ Available only in riveted construction. All other sizes may be furnished cottered or riveted.

Extra Clearance Chains

T A

Trans-Flex straight-sidebar, extra-clearance roller chain is specially designed for severe service on transit mixers and on crawler drives for shovels and cranes. Trans-Flex roller chain permits twist of 8° and sidebend of 4" per 4-foot length. It delivers full power despite recurrent sprocket misalignment. Trans-Flex chain operates on standard roller chain sprockets. ®

B

D

E

C

PITCH G

F

Fig. 8618C

Average Chain Chain pitch, Ultimate Number inches strength, pounds



A

B

C

D

E

F

G

T

Dimensions, inches


140TF

1.750

48,500

.726

5.13

1.02

1.21

.500

1.000

1.00

1.43

1.56

.22

C-27

160TF

2.000

68,000

.991

6.70

1.23

1.41

.563

1.125

1.25

1.64

1.81

.25

C-29

C-30

160SU TF

2.000

70,000s

1.028

7.40

1.29

1.47

.563

1.125

1.25

1.64

1.81

.28

C-31

C-32

Cottered chains standard. Riveted construction can be furnished. Horsepower ratings for flex-t chains are 75% of the values shown in the rating tables. s Higher strength due to thru-hardened pins and side bars of heavier section.

B-6 (7010)


C-28

B

Link-Belt and Rexnord Drive Chains Corrosion resistant chains

Stainless Steel Chains: Stainless steel chain sideplates are manufactured from AISI Type 300 chrome nickel stainless steel, with pins, bushings and rollers manufactured from AISI Type 400 stainless steel providing a balanced combination of wear, corrosion and heat resistance adequate for most operating conditions.

Plated Chains: Standard carbon steel chain, assembled from parts individually plated with nickel, zinc or chrome, can be furnished to provide improved corrosion and/or wear characteristics compared to a standard, unprotected carbon steel chain. Assembled carbon steel chains should not be plated because component failure may occur.

Where increased corrosion, wear and/or heat resistance is required, chains may be custom designed and manufactured with components made from other grades of stainless steel compatible with the specific operating conditions.

Sprockets: Standard carbon steel sprockets may be suitable for many applications; however, sprockets can be made from a variety of corrosion-resistant materials to suit application conditions. They are manufactured to the same applicable standards and dimensions as sprockets for standard precision roller chains.

G

T

E

PITCH

D

C F

A

B

Fig. 6453

Stainless Steel Average Chain Chain pitch, Ultimate Number inches strength, pounds



A

B

C

D

E

F

G

T

Dimensions, inches


25 SS ∆

.250

650

.017

.10

.15

.19

.091

.130 s

.13

.20

.23

.03

C-09

C-10

35 SS ∆

.375

1,550

.041

.22

.24

.27

.141

.200 s

.19

.31

.34

.05

C-11

C-12

40 SS ∆

.500

2,800

.068

.40

.32

.38

.156

.313

.31

.41

.45

.06

C-13

C-14

41 SS ∆

.500

1,550

.049

.27

.27

.32

.141

.306

.25

.32

.38

.05

C-15

C-16

50 SS ∆

.625

5,000

.108

.66

.41

.48

.200

.400

.38

.52

.59

.08

C-17

C-18

60 SS

.750

7,000

.162

1.03

.50

.60

.234

.469

.50

.60

.71

.09

C-19

C-20

80 SN

1.000

12,000

.275

1.70

.63

.74

.313

.625

.63

.75

.91

.13

C-21

C-22

100 SN

1.250

18,750

.401

2.82

.76

.89

.375

.750

.75

.97

1.13

.16

C-23

C-24

∆ Available only in riveted construction. All other sizes may be furnished cottered or riveted. s Bushing diameter, chain is rollerless. Horsepower ratings for stainless steel chains, when lubricated and operated at normal temperatures, are 25% of the values shown in the rating tables. See Table 3, page C-7. Carbon Steel sprockets. Sprockets made from corrosion-resistant materials can be furnished on order.


(7010) B-7

B

Link-Belt ULTR-O-LIFE O-Ring Chain Link-Belt ULTR-O-LIFE™ O-ring chain is built for applications where relubrication is nearly impossible or where contaminants are excessive resulting in frequent and costly maintenance. Construction: Link-Belt O-ring chain uses O-rings to seal in special lubricants protecting the pin/bushing area virtually eliminating the need for relubrication. The O-rings seal out dirt, moisture and other contaminants offering the ultimate protection against accelerated wear. Advantages: Link-Belt O-ring chain is easily maintained lasting three to ten times longer than standard series roller chains. Productivity and overall chain economy is dramatically increased while life-cycle costs are decreased. O-ring chains provide greater wear resistance, superior toughness and better operating performance in addition to enhancing equipment maintainability.

H

A C

W

D

B T

E

Dimensions, inches Chain Number

Roller Bushing Pitch

Width

Diam.

W

D

Conn.End Riv. End to to Overall Center Line Center Line A

B

Overall Width

Link Height

Plate Thickness

Pin Diameter

Minimum Ultimate Strength

Aver. Wt. Per Foot

C

H

T

E

Lbs.

Lbs.

50-OR

0.625

0.38

0.40

0.47

0.55

0.94

0.59

0.08

0.20

4,882

0.71

60-OR

0.750

0.50

0.47

0.56

0.66

1.13

0.70

0.09

0.23

7,030

1.07

80-OR

1.000

0.63

0.63

0.72

0.81

1.44

0.95

0.13

0.31

12,500

1.8

100-OR

1.250

0.75

0.75

0.86

0.98

1.70

1.16

0.16

0.38

19,530

2.0

B-8 (7010)


C

Drive Engineering

Engineering recommendations Several drive selections can usually be made for a given application. Consideration of life expectancy, space, speed, cost and similar factors often suggest the better selection. Use the following recommendations as a guide when selecting roller chain drives. Horsepower ratings The horsepower ratings listed on pages C-9 to C-35 apply directly to lubricated, single strand, standard and heavy series roller chains. Multiple strand chains are selected from the same rating tables by applying the factors in Table 2, page C-7. Stainless steel chain and other variations of standard roller chain are also selected from the rating tables by applying the appropriate material or design variation factor from Table 3, page C-7. Chain pitch Use the smallest pitch chain that will handle the horsepower and load requirements. Single strand chains satisfy most requirements and are usually more economical. Use small pitch multiple strand chains for high speed drives or when quietness is desirable. This permits a larger number of teeth in the driver sprocket and results in smoother drive operation.

Chordal action The rise and fall of each pitch of chain as it engages a sprocket is termed chordal action and causes repeated chain speed variations. As illustrated by chart A, chordal action and speed variation decrease as the number of teeth in the small sprocket is increased. Chordal action becomes negligible when 25 or more teeth are used and results in smoother drive operation. Quietness Speed and horsepower usually determine chain pitch. When quietness is essential, select a smaller pitch, wider chain and a driver sprocket with at least 25 teeth. Number of teeth for large sprockets The number of teeth in the large sprocket has an appreciable effect on the amount of t wear (or pitch elongation) that can be accommodated by the chain before it tends to jump or ride over the teeth. This is illustrated by Chart B. Generally, a roller chain has reached its useful wear life when the elongation per pitch is in the range of 2% to 3% of pitch. As show in the chart, this would result in a maximum of 65-100 teeth for the large sprocket. This suggested maximum can be exceeded by making a more conservative chain selection.

Number of teeth for small sprockets The recommended minimum number of teeth for the small sprocket varies with operating conditions. The recommended minimums are:

When space limits the diameter of the large sprocket, it may be necessary to select a smaller pitch, multiple strand chain to provide a sufficient number of teeth for the small sprocket.

Very slow speed drives........... 12 teeth Slow speed drives................... 17 teeth Moderate speed drives........... 21 teeth High speed drives................... 25 teeth

Drive ratio The drive ratio is determined by the speeds of the driving and driven shafts. Properly engineered, drives with ratios up to 10:1 will perform satisfactorily. However, doublereduction drives with smaller ratios have better operating characteristics and are often more economical than a large ratio, single-reduction drive.

Hardened teeth It is good practice to harden sprockets with 25 teeth or less when applied to:

Very low speed, heavily loaded drives High speed drives Large ratio drives Abrasive or corrosive conditions

For additional information, consult Rexnord. Chart A : Variations in chain speed due to chordal action Chart A Variations action Chart in A : chain Variationsspeed in chain due speed to duechordal to chordal action = PITCH OF SPROCKET WHEEL Chart A : Variations inRchain speedRADIUS due to chordal action 180° r ==RPITCH X COS R RADIUS OF SPROCKET WHEEL T

13 12

V2 - V1 X 100 V2

12 11

11 10

PERCENT SPEED VARIATION = 2= PERCENT SPEED VARIATION

PERCENT SPEED VARIATION =

10 9 8 7 6 5 4 3 2 1 0

r

12 11

0

R 180° T

10 9 9 8 8 7 7 6 6 5 5 4 3 4 2 3

A

r 180° T

R

r R r 180° R

V1=2πrN 12T

180° T

V1=2πrN 12 V1=2πrN 12

MAXIMUM MAXIMUM CHAIN SPEED A CHAIN SPEED MAXIMUM CHAIN SPEED A r R V2=2πRN V2=2πRN 12 180° r R12 V2=2πRN T 12 180° T

7:1 RATIO (TWO DRIVES)

Fig. 6460

Fig. 6460 Fig. 6460

elongation elongation and number of teeth in and largenumber sprocketof teeth in large sprocket

6 5 4 3 2

CHORDAL RISECHORDAL AND RISE AND1 FALL OF CHAINFALL = R - rOF CHAIN = R - r

CHORDAL RISE AND FALL OF CHAIN = R -0r 0 0 5 110 15 20 25 30 35 40 45 0NUMBER 5 OF 10TEETH 15 IN20 25 30 35 40 45 SPROCKET 0 NUMBER OF TEETH IN SPROCKET 0 5 10 15 20 25 30 35 40 45 NUMBER OF TEETH IN SPROCKET 1 2

7:1 RATIO (TWO DRIVES) 7:1 RATIO (TWO DRIVES)

Chart B Variations in useful based Chart B : Variations in useful chain chain lifelife based on pitchon pitch elongation and numberof of teeth in large sprocket elongation and number teeth in large sprocket Chart B : Variations in useful chain life based on pitch Chart B : Variations in useful chain life based on pitch CHAIN WEAR PERPER PITCH IN %INOF CHAIN WEAR PITCH % PITCH OF PITCH

14 13

13

V - VV12 - V1 X 100 X 100 V 2 V2

14

7:1 RATIO

R = PITCH RADIUS OF SPROCKET WHEEL 180° T OF TEETH r 180° == RNUMBER X COS T r = R X COS N T= RPM MINIMUM T = NUMBER OF TEETH T = NUMBER OF TEETH CHAIN SPEED N = RPM A N = RPM MINIMUM MINIMUM CHAIN A SPEED CHAIN SPEED A

CHAIN WEAR PER PITCH IN % OF PITCH

14

7:1 RATIO 7:1 RATIO

ELONGATION PER PITCH IN % OF PITCH =

200 T 200 T

6

ELONGATION PER PITCH IN % OF PITCH = PITCH ELONGATION PER PITCH IN% INCHES = 2 =X P ELONGATION PER IN OF PITCH T

6

ELONGATION PER PITCH INCHES = T IN INCHES P =INCHAIN PITCH ELONGATION PER PITCH IN INCHES = 2TX P P = CHAIN PITCH IN INCHES T = NUMBER OF TEETH IN LARGE SPROCKET P = CHAIN PITCH IN INCHES T = NUMBER OF TEETH IN LARGE SPROCKET

200

T

2 XP

5

5

T = NUMBER OF TEETH IN LARGE SPROCKET

4

4 3 3 2 2 1 1

10 20 30 400 50 60 70 80 90 100 110 120 130 140 150 160 170

0

10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170

0

LARGE SPROCKET 10 20 30NUMBER 40 50 OF 60 TEETH 70 80IN90 100 110 120 130 140 150 160 170

NUMBER OF TEETH IN LARGE SPROCKET 0

NUMBER OF TEETH IN LARGE SPROCKET

Fig. 7314


Fig. 7314

Fig. 7314

(7010) C-1

C Select relatively large diameter sprockets for 1:1 and 2:1 ratio drives, especially if required to operate on horizontal centers. This will assure adequate distance between the two spans of chain and prevent them from striking as wear accumulates. This is particularly important for drives on long, fixed centers with the slack chain span on top.

Typical drive arrangements using chain tighteners are shown in the preferred drive arrangements below. Offset links may be used to adjust chain length when other means are not available. Single-pitch offset links and twopitch offset assemblies can be supplied. Offset assemblies are recommended for high speed or heavily loaded drives. Chain tension should be carefully maintained when the following operating conditions exist:

Fig. 6459 Fig. 6459

RECOMMENDED RECOMMENDED

NOT RECOMMENDED NOT RECOMMENDED

Fig. 6459

Fig. 6459 NOT RECOMMENDED SmallRECOMMENDED pitch, multiple strand chains generally more RECOMMENDED NOTare RECOMMENDED Fig. 6459 RECOMMENDED NOT economical for large ratio drives onRECOMMENDED minimum centers. Large pitch, single strand chains are usually most economical for small ratio drives on long centers.

Chain length When possible use a chain length with an even number of pitches to eliminate the need for an offset link

Center distance Sprocket centers must be more than 1/2 the sum of the sprocket outside diameters to avoid tooth interference.

Fixed centers When sprocket centers cannot be adjusted, make a conservative drive selection by using a larger service factor than indicated. Also, provide good lubrication.

A suggested minimum center distance would equal the diameter of the large sprocket plus half the diameter of the small sprocket. Drives so proportioned also assure the minimum suggested chain wrap of 120° on the small sprocket. 120° +

120° + 120° 120° ++ 120° +

Low speed drives Ratings are not shown in the horsepower tables for extremely low speeds. For operation at these speeds, select drives on a chain strength basis. The ratio of ultimate chain strength to working load should be at least 6:1.

D

d

d Ddd + d

Drives that operate at varying speeds such as power takeoff drives from a torque converter, from an engine with a multispeed gear transmission, or from a constant horsepower, variable speed electric motor, should be selected on a chain strength basis. The ratio of ultimate strength to maximum peak load should not be less than 6:1. The selection should be checked against the horsepower table for sufficient rating at the normal operating speed.

D D6461 Fig.D D

d 2

d

D+ 2 dd D D ++ 22 d D+ 2

Fig. 6461 Fig. Fig.6461 6461

Fig. 6461 Chain tension To obtain maximum chain life, make provisions to maintain proper chain tension. Make an initial adjustment after approximately the first 100 hours of operation to remove slack caused by initial elongation. Thereafter, the frequency of periodic adjustments is governed by operating conditions.

Drives operating from variable speed, variable horsepower electric motors should be selected to meet the maximum load requirements. In selecting the chain pitch, consideration must be given to the range of speeds involved.

Fig. 6457

Preferred drive arrangements The drive arrangements illustrated below are desirable for optimum life of the drive. The preferred direction of rotation is indicated for each arrangement, although arrangements A, B and C will operate C satisfactorily in either direction.B

Fig. 6457 Fig. Fig.6457 6457 Fig. 6457

The simplest method of adjusting chain tension is to provide for movement of one shaft. This method is commonly used for drives operating from electric motors or internal combustion engines since they can be mounted on adjustable baseplates or slide rails.

A

A AA A

For fixed center drives, chain tension may be maintained by an automatic or manually adjusted chain tightener. Manually operated chain tighteners must be frequently checked for proper adjustment. The idler sprocket should have a minimum of 17 teeth and should be located adjacent to the driving sprocket so that at least 3 teeth are in full engagement with the non-load-carrying span of chain. AN T

Fixed centers Vertical or near vertical centers Shock or pulsating loads Reversals in direction of rotation

C-2 (7010)

Fig. 6458

F

F FF F

G

U If possible, provide enough adjustment of the chain tightener TA to permit removal of two pitches of chain.

AN SPAANN UT SSPPN TAUUTSTPA A A TTUT TA MOVEMENT MOVEMENT MOVEMENT MOVEMENT

C CC C

D

SP

MOVEMENT

B BB B

E

Fig. 6455

G G G G

D DD D

E EE E Fig. 6455 Fig.6455 6455 Fig.

Fig. 6458 Fig.6458 6458 Fig. Fig. 6458


Fig. 6455

C

Drive Engineering Other arrangements These arrangements are not generally recommended but they will give satisfactory service if carefully attended and chain tension is accurately maintained.

Fig. 6456

Operating conditions The service factors listed in Table 1 page C-7 are for normal operating conditions. Increase these service factors to compensate for any of the following conditions:

Heavy starting loads Frequent starts and stops Lubrication inferior to method recommended Short or fixed centers Vertical centers, particularly if the small sprocket is in the low position Two or more driven shafts Periodic load variation in a single revolution Reversals of drive rotation Inertia strains Large ratios

Lubrication Adequate lubrication is necessary for optimum drive life. A general guide to the recommended method of lubrication is indicated in the horsepower rating tables. These recommendations are based primarily on chain speed. For complete lubrication data, refer to pages C-45 and C-46. Useful formulas Formulas for calculating horsepower, torque, chain speed, working load and similar values are given on page H-1.

Drive selection procedure Although horsepower and speed are the prime considerations for selecting a drive, the following information is also necessary:

Source of power Horsepower to be transmitted Size and speed of driving shaft Driven equipment Size and speed of driven shaft Approximate center distance between shafts Relative position of shafts Space limitations

With this information the selection procedure is as follows: Establish the service factor Select a service factor from Table 1, page C-7, to compensate for the loads imposed on the chain by the type of input power and the type of equipment to be driven. If the exact driven equipment is not listed, use the factor for equipment with similar operting characteristics. Increase the service factor, if necessary, in accordance with the instructions under “Operating Conditions” above.

Establish the material or design variation factor When a variation of standard roller chain is being selected (such as stainless steel chain for corrosion resistance), refer to Table 3 on page C-7 and determine the appropriate variation factor. This factor compensates for either the design or material difference so that a selection can be made from the standard roller chain rating table. Calculate the equivalent horsepower Multiply the horsepower to be transmitted by the service factor (and by the variation factor, if applicable). This product is the equivalent horsepower or the value on which the chain selection is based. Select a trial chain Standard roller chains are most commonly used and are selected from Chart C, page C-5. Single strand chains satisfy most drive requirements; however, multiple strand chains are often required for high speed drives, where space limits sprocket diameters, or where horsepower requirements exceed the capacity of single strand chains. Double-pitch chains are often used for slow speed, comparatively low horsepower drives on long centers. Use Chart D, page C-6, to make a trial chain selection. To make a tentative chain selection, project a horizontal line from the horsepower scale and a vertical line from the speed scale based on the equivalent horsepower and the RPM of the small sprocket. The area in which the two lines intersect indicates the probable chain requirement. It is often desirable to evaluate selections based on the next smaller or next larger chain size, especially if the point of intersection is near the border of an area.

Determine the number of teeth for the small sprocket The ratings in the horsepower tables apply to single strand chains.

If a single strand standard roller chain or a double-pitch roller chain has been tentatively selected, refer directly to the horsepower rating table for the trial chain (see pages C-9 to C-43). In the column corresponding to the RPM of the small sprocket, find the rating nearest to the equivalent horsepower. Follow this line horizontally to the left to find the number of teeth required for the small sprocket. If a single multiple strand trial chain has been selected, the required rating per strand must be determined in order to use the rating tables. The required table rating per strand is calculated by dividing the equivalent horsepower by the appropriate multiple strand factor from Table 2, page C-7. Now, refer to the horsepower rating table for the trial chain. In the column corresponding to the RPM of the small sprocket, find the rating nearest to the required rating per strand just calculated. Follow this line horizontally to the left to find the number of teeth for the small sprocket. Check the small sprocket Check the bore capacity of the sprocket selected, making sure it will accommodate the driving shaft. If the initial selection does not have adequate bore capacity, use a sprocket with larger number of teeth, or select a drive using the next larger pitch of chain. Determine the drive ratio Divide the speed of the faster turning shaft by the speed of the slower turning shaft.


(7010) C-3

C Determine the number of teeth for the large sprocket Multiply the drive ration by the number of teeth in the small sprocket. If the drive is to operate in a restricted location, check the sprocket radii against the space limitation. Radial clearance required for each sprocket is equal to one-half the sum of its pitch diameter and the chain pitch. Encased drives require an additional 3" radial clearance. If sufficient space is not available, consider a smaller pitch, multiple strand drive. Calculate exact center distance and chain length Formulas for these calculations are on page C-8. Lubrication The methods of lubrication shown in the horsepower rating tables are based primarily on chain speed; however, the relative position of driving and driven shafts often influence the method of lubrication. Recommendations and complete lubrication information are given on pages C-45 and C-46.

Drive selection example Problem Select a roller chain drive for the following conditions:

Source of power Horsepower to be transmitted Size of driving shaft Speed of driving shaft Driven equipment Size of driven shaft Speed of driven shaft Approximate center distance Relative position of shafts Space limitations

Gearmotor 10 HP 2.438" diameter 100 RPM Bucket elevator uniformly fed 2.938" diameter 42 RPM 24.00" On same horizontal plane None

Check the small sprocket As shown in the rating table, the maximum bore of a 17-tooth No. 100 sprocket is larger than the 2.438" bore required; therefore, the selection is satisfactory. Stock sprockets are readily available and are often more economical. Drive ratio The drive ratio equals:

100 RPM = 2.38 to 1 42 RPM

Number of teeth in large sprocket The number of teeth in the large sprocket equals: 2.38 x 17 = 40.4 teeth. Use a 40-tooth sprocket. Center distance and chain length Using the formula on page C-8, calculate the chain length as follows: 15.932-6.803 A= = .19000 2 x 24 From Table 4, page C-8, select the next higher listed value of .19081 for A. Corresponding factors for B, C and D are 1.9633, .4389, and .5611, respectively. The chain length in pitches equals: 1.9633 x 24 + (.4389 x 17) + (.5611 x 40) x 1.25 = 67.601 1.25 Use 68 pitches, which is the nearest even number. Calculate the exact center distance, using 68 pitches: 68 - (.4389 x 17) – (.5611 x 40) x 1.25 E= = 24.254" 1.9633 Lubrication The No. 100 rating table specifies Type B bath or disc lubrication. For lubrication and bathing details, see pages C-45 to C-46.

Solution

The drive selected for this application consists of:

Service factor The service factor listed in Table 1 on page C-7 for a uniformly fed bucket elevator driven by a gearmotor is 1.0.

17-tooth No. 100 driving sprocket 40-tooth No. 100 driven sprocket 68 pitches of No. 100 roller chain for 24.254” shaft centers, and an oil-retaining casing for oil bath lubrication.

Material or design variation factor Since the listed conditions do not indicate the need for a variation in chain material or design, select a standard roller chain. Therefore, a variation factor does not apply. Equivalent horsepower The equivalent horsepower equals: 10 x 1.0 = 10 HP Trial Chain From Chart C, page C-5, note that the intersection of the 100 RPM vertical line and the 10 HP horizontal line falls in the area for No. 100 chain. Thus, the trial chain is No. 100 single strand. Small sprocket In the No. 100 rating table, page C-23, the 100 RPM column lists 10.3 horsepower which corresponds closely to the equivalent horsepower of 10 required for this application. This rating is for single strand chain when used with a 17-tooth sprocket.

C-4 (7010)


C

Drive Engineering Chart Chart C Trail selection of standard roller chains


(7010) C-5

C

Chart D Trial selection of double-pitch roller chains

C-6 (7010)


C

Drive Engineering Table 1 Service factors Driven equipment

Service factors Input power Internal combustion engine with hydraulic drive

Internal combustion engine with mechanical drive

Electric motor or turbine

Agitators, liquid stock

1.0

1.0

1.2

Beaters

1.2

1.3

1.4

Blowers, centrifugal

1.0

1.0

1.2

Boat propellers

1.4

1.5

1.7

Compressors centrifugal

1.2

1.3

1.4

reciprocating, 3 or more cylinders

1.2

1.3

1.4

reciprocating, singular, 2 cylinders

1.4

1.5

1.7

Conveyors uniformly loaded or fed

1.0

1.0

1.2

not uniformly loaded or fed

1.2

1.3

1.4

reciprocating

1.4

1.5

1.7

Cookers, cereal

1.0

1.0

1.2

Crushers

1.4

1.5

1.7

Elevators, bucket uniformly loaded or fed

1.0

1.0

1.2

not uniformly loaded or fed

1.2

1.3

1.4

Fans, centrifugal

1.0

1.0

1.2

Feeders rotary table

1.0

1.0

1.2

apron, belt, screw, rotary vane

1.2

1.3

1.4

reciprocating

1.4

1.5

1.7

Generators

1.0

1.0

1.2

Grinders

1.2

1.3

1.4

Hoists

1.2

1.3

1.4

Kettles, brew

1.0

1.0

1.2

Kilns and dryers, rotary

1.2

1.3

1.4

Lineshafts light or normal service

1.0

1.0

1.2

heavy service

1.2

1.3

1.4

Machinery uniform load, nonreversing

1.0

1.0

1.2

moderate pulsating load, nonreversing

1.2

1.3

1.4

severe impact or variable load, reversing

1.4

1.5

1.7

Mills ball, pebble and tube

1.2

1.3

1.4

hammer, rolling

1.4

1.5

1.7

Pumps centrifugal

1.0

1.0

1.2

reciprocating, 3 or more cylinders

1.2

1.3

1.4

Screens, rotary, uniformly fed Uniform load Basis for service factors:

1.2

1.3

1.4

1.0

1.0

1.2

Moderate shock load

1.2

1.3

1.4

Heavy shock load

1.4

1.5

1.7

Table 2 Multiple strand factors Number of strands

Multiple strand factor

2

1.7

3

2.5

4

3.3

5

4.1

6

5.0

7 or more

Consult Rexnord

Table 3 Material or design variation factors Type of chain

Variation factor

Speed limitations

Trans-Flex®

1.00

-

Stainless steel

4.00*

Limit to slower operating speeds.

* Assuming good lubrication; otherwise, make a conservative selection by using a larger factor, or consult Rexnord.


(7010) C-7

C Chain length and center distance computations A center distance equal to the diameter of the large sprocket plus one-half the diameter of the small sprocket is the suggested minimum for average applications. An even number of pitches is desirable. However, if an odd number of pitches is required, offset links are provided. These symbols are used for the following formulas: e = desired sprocket centers in inches E = exact sprocket centers in inches g = pitch diameter of small sprocket in inches

G = pitch diameter of large sprocket in inches N = actual length of chain in pitches P = chain pitch in inches t = number of teeth in small sprocket T = number of teeth in large sprocket

The number of pitches in the chain equals the sum of the pitches between sprockets and the pitches around the sprockets, or Number of pitches =

To determine the sprocket centers and chain length of a given drive, calculate factor A using the formula: A=

Be +Ct+DT P

The chain length should equal an even number of pitches so that the chain will couple without the use of an offset link. Therefore, select an even whole number nearest to the calculated number of pitches. Using this value as N, the exact sprocket centers is found by the following formula:

G-g 2e

Refer to Table 4 and select factors B, C and D corresponding to value A or the next higher value.

E=

(N - C t - D T) P B

Table 4 Factors for sprocket centers and chain length A

B

C

D

A

B

C

D

A

B

C

D

A

B

C

D

.00000 .00436 .00873 .01309 .01745 .02181 .02618 .03054 .03490 .03926 .04362 .04798 .05234 .05669 .06105 .06540 .06976 .07411 .07846 .08281 .08716 .09150 .09585 .10019 .10453 .10887 .11320 .11754 .12187 .12620 .13053 .13485 .13917 .14349 .14781 .15212 .15643 .16074 .16505 .16935 .17365 .17794 .18224 .18652 .19081 .19509

2.0000 2.0000 1.9999 1.9998 1.9997 1.9995 1.9993 1.9991 1.9988 1.9985 1.9981 1.9977 1.9973 1.9968 1.9963 1.9957 1.9951 1.9945 1.9938 1.9931 1.9924 1.9916 1.9908 1.9899 1.9890 1.9881 1.9871 1.9861 1.9851 1.9840 1.9829 1.9817 1.9805 1.9793 1.9780 1.9767 1.9754 1.9740 1.9726 1.9711 1.9696 1.9681 1.9665 1.9649 1.9633 1.9616

.5000 .4986 .4972 .4958 .4944 .4931 .4917 .4903 .4889 .4875 .4861 .4847 .4833 .4819 .4806 .4792 .4778 .4764 .4750 .4736 .4722 .4708 .4694 .4681 .4667 .4653 .4639 .4625 .4611 .4597 .4583 .4569 .4556 .4542 .4528 .4514 .4500 .4486 .4472 .4458 .4444 .4431 .4417 .4403 .4389 .4375

.5000 .5014 .5028 .5042 .5056 .5069 .5083 .5097 .5111 .5125 .5139 .5153 .5167 .5181 .5194 .5208 .5222 .5236 .5250 .5264 .5278 .5292 .5306 .5319 .5333 .5347 .5361 .5375 .5389 .5403 .5417 .5431 .5444 .5458 .5472 .5486 .5500 .5514 .5528 .5542 .5556 .5569 .5583 .5597 .5611 .5625

.19937 .20364 .20791 .21218 .21644 .22070 .22495 .22920 .23345 .23769 .24192 .24615 .25038 .25460 .25882 .26303 .26724 .27144 .27564 .27983 .28402 .28820 .29237 .29654 .30071 .30486 .30902 .31316 .31730 .32144 .32557 .32969 .33381 .33792 .34202 .34612 .35021 .35429 .35837 .36244 .36650 .37056 .37461 .37865 .38268 .38671

1.9598 1.9581 1.9563 1.9545 1.9526 1.9507 1.9487 1.9468 1.9447 1.9427 1.9406 1.9385 1.9363 1.9341 1.9319 1.9296 1.9273 1.9249 1.9225 1.9201 1.9176 1.9151 1.9126 1.9100 1.9074 1.9048 1.9021 1.8994 1.8966 1.8939 1.8910 1.8882 1.8853 1.8824 1.8794 1.8764 1.8733 1.8703 1.8672 1.8640 1.8608 1.8576 1.8544 1.8511 1.8478 1.8444

.4361 .4347 .4333 .4319 .4306 .4292 .4278 .4264 .4250 .4236 .4222 .4208 .4194 .4181 .4167 .4153 .4139 .4125 .4111 .4097 .4083 .4069 .4056 .4042 .4028 .4014 .4000 .3986 .3972 .3958 .3944 .3931 .3917 .3903 .3889 .3875 .3861 .3847 .3833 .3819 .3806 .3792 .3778 .3764 .3750 .3736

.5639 .5653 .5667 .5681 .5694 .5708 .5722 .5736 .5750 .5764 .5778 .5792 .5806 .5819 .5833 .5847 .5861 .5875 .5889 .5903 .5917 .5875 .5944 .5958 .5972 .5986 .6000 .6014 .6028 .6042 .6056 .6069 .6083 .6097 .6111 .6125 .6139 .6153 .6167 .6181 .6194 .6208 .6222 .6236 .6250 .6264

.39073 .39474 .39875 .40275 .40674 .41072 .41469 .41866 .42262 .42657 .43051 .43445 .43837 .44229 .44620 .45010 .45399 .45787 .46175 .46561 .46947 .47332 .47716 .48099 .48481 .48862 .49242 .49622 .50000 .50377 .50754 .51129 .51504 .51877 .52250 .52621 .52992 .53361 .53730 .54097 .54464 .54829 .55194 .55557 .55919 .56280

1.8410 1.8376 1.8341 1.8306 1.8271 1.8235 1.8199 1.8163 1.8126 1.8089 1.8052 1.8014 1.7976 1.7937 1.7899 1.7860 1.7820 1.7780 1.7740 1.7700 1.7659 1.7618 1.7576 1.7535 1.7492 1.7450 1.7407 1.7364 1.7321 1.7277 1.7233 1.7188 1.7143 1.7098 1.7053 1.7007 1.6961 1.6915 1.6868 1.6821 1.6773 1.6726 1.6678 1.6629 1.6581 1.6532

.3722 .3708 .3694 .3681 .3667 .3653 .3639 .3625 .3611 .3597 .3583 .3569 .3556 .3542 .3528 .3514 .3500 .3486 .3472 .3458 .3444 .3431 .3417 .3403 .3389 .3375 .3361 .3347 .333 .3319 .3306 .3292 .3278 .3264 .3250 .3236 .3222 .3208 .3194 .3181 .3167 .3153 .3139 .3125 .3111 .3097

.6278 .6292 .6306 .6319 .6333 .6347 .6361 .6375 .6389 .6403 .6417 .6431 .6444 .6458 .6472 .6486 .6500 .6514 .6528 .6542 .6556 .6569 .6583 .6597 .6611 .6625 .6639 .6653 .6667 .6681 .6694 .6708 .6722 .6736 .6750 .6764 .6778 .6792 .6806 .6819 .6833 .6847 .6861 .6875 .6889 .6903

.56641 .57000 .57358 .57715 .58070 .58425 .58779 .59131 .59482 .59832 .60182 .60529 .60876 .61222 .61566 .61909 .62251 .62592 .62932 .63271 .63608 .63944 .64279 .64612 .64945 .65276 .65606 .65935 .66262 .66588 .66913 .67237 .67559 .67880 .68200 .68518 .68835 .69151 .69466 .69779 .70091 .70401 .70711

1.6483 1.6433 1.6383 1.6333 1.6282 1.6231 1.6180 1.6129 1.6077 1.6025 1.5973 1.5920 1.5867 1.5814 1.5760 1.5706 1.5652 1.5598 1.5543 1.5488 1.5432 1.5377 1.5321 1.5265 1.5208 1.5151 1.5094 1.5037 1.4979 1.4921 1.4863 1.4804 1.4746 1.4686 1.4627 1.4567 1.4507 1.4447 1.4387 1.4326 1.4265 1.4204 1.4142

.3083 .3069 .3056 .3042 .3028 .3014 .3000 .2986 .2972 .2958 .2944 .22931 .2917 .2903 .2889 .2875 .2861 .2847 .2833 .2819 .2806 .2792 .2778 .2764 .2750 .2736 .2722 .2708 .2694 .2681 .2667 .2653 .2639 .2625 .2611 .2597 .2583 .2569 .2556 .2542 .2528 .2514 .2500

.6917 .6931 .6944 .6958 .6972 .6986 .7000 .7014 .7028 .7042 .7056 .7069 .7083 .7097 .7111 .7125 .7139 .7153 .7167 .7181 .7194 .7208 .7222 .7236 .7250 .7264 .7278 .7292 .7306 .7319 .7333 .7347 .7361 .7375 .7389 .7403 .7417 .7431 .7444 .7458 .7472 .7486 .7500

C-8 (7010)


C

Drive Engineering

No. 25 chain .250" pitch G

T

E

PITCH

D

C F

A

Fig. 6453

B

Specifications and dimensions Dimensions, inches

Chain Number


t bearing area sq. in.


A

B

C

D

E

F

G

T

25

940

.017

.08

.15

.19

.090

.130 ∆

.13

.20

.23

.03

Available only in riveted construction. All other sizes may be furnished cottered or riveted. ∆ Bushing Diameter. Chain is rollerless.

Ratings Number of Maximum teeth, bore in small inches sprocket 100

500

900

Horsepower for single strand chain s RPM of small sprocket 1200 1800 2500 3000 3500 4000 4500 5000 5500 6000 6500 7000 7500 8000 8500 9000 10000

11

.313

0.05

0.23

0.39

0.50

0.73

0.98

1.15

1.32

1.38

1.16

0.99

0.86

0.75

0.67

0.60

0.54

0.49

0.45

0.41

0.35

12

.375

0.06

0.25

0.43

0.55

0.80

1.07

1.26

1.45

1.57

1.32

1.12

0.97

0.86

0.76

0.68

0.61

0.56

0.51

0.47

0.40

13

.438

0.06

0.27

0.47

0.60

0.87

1.17

1.38

1.58

1.77

1.49

1.27

1.10

0.96

0.86

0.77

0.69

0.63

0.57

0.53

0.45

14

.563

0.07

0.30

0.50

0.65

0.94

1.27

1.49

1.71

1.93

1.66

1.42

1.23

1.08

0.96

0.86

0.77

0.70

0.64

0.59

0.50

15

.563

0.08

0.32

0.54

0.70

1.01

1.36

1.61

1.85

2.08

1.84

1.57

1.36

1.20

1.06

0.95

0.86

0.78

0.71

0.65

0.56

16

.563

0.08

0.34

0.58

0.76

1.09

1.46

1.72

1.98

2.23

2.03

1.73

1.50

1.32

1.17

1.05

0.94

0.86

0.78

0.72

0.61

17

.625

0.09

0.37

0.62

0.81

1.16

1.56

1.84

2.11

2.38

2.22

1.90

1.64

1.44

1.28

1.14

1.03

0.94

0.86

0.79

0.67

18

.750

0.09

0.39

0.66

0.86

1.24

1.66

1.96

2.25

2.53

2.42

2.07

1.79

1.57

1.39

1.25

1.12

1.02

0.93

0.86

0.73

19

.813

0.10

0.41

0.70

0.91

1.31

1.76

2.07

2.38

2.69

2.62

2.24

1.94

1.70

1.51

1.35

1.22

1.11

1.01

0.93

0.79

20

.875

0.10

0.44

0.74

0.96

1.38

1.86

2.19

2.52

2.84

2.83

2.42

2.10

1.84

1.63

1.46

1.32

1.20

1.09

1.00

0.86

21

.875

0.11

0.46

0.78

1.01

1.46

1.96

2.31

2.66

2.99

3.05

2.60

2.26

1.98

1.76

1.57

1.42

1.29

1.17

1.08

0.92

22

.938

0.11

0.48

0.82

1.07

1.53

2.06

2.43

2.79

3.15

3.27

2.79

2.42

2.12

1.88

1.69

1.52

1.38

1.26

1.16

0.99

23

1.000

0.12

0.51

0.86

1.12

1.61

2.16

2.55

2.93

3.30

3.50

2.98

2.59

2.27

2.01

1.80

1.62

1.47

1.35

1.24

1.06

24

1.063

0.13

0.53

0.90

1.17

1.69

2.27

2.67

3.07

3.46

3.73

3.18

2.76

2.42

2.15

1.92

1.73

1.57

1.44

1.32

1.12

25

1.188

0.13

0.56

0.94

1.22

1.76

2.37

2.79

3.21

3.61

3.96

3.38

2.93

2.57

2.28

2.04

1.84

1.67

1.53

1.40

1.20

28

1.250

0.15

0.63

1.07

1.38

1.99

2.68

3.15

3.62

4.09

4.54

4.01

3.47

3.05

2.70

2.42

2.18

1.98

1.81

1.66

1.42

30

1.313

0.16

0.68

1.15

1.49

2.15

2.88

3.40

3.90

4.40

4.89

4.45

3.85

3.38

3.00

2.68

2.42

2.20

2.01

1.84

1.57

32

1.500

0.17

0.73

1.23

1.60

2.30

3.09

3.64

4.18

4.72

5.25

4.90

4.25

3.73

3.30

2.96

2.67

2.42

2.21

2.03

1.73

35

1.688

0.19

0.80

1.36

1.76

2.53

3.41

4.01

4.61

5.20

5.78

5.60

4.86

4.26

3.78

3.38

3.05

2.77

2.53

2.32

1.98

40

1.875

0.22

0.92

1.57

2.03

2.93

3.93

4.64

5.32

6.00

6.68

6.85

5.93

5.21

4.62

4.13

3.73

3.38

3.09

2.83

2.42

Lubrication type n

A

B

C

s Ratings are based on a service factor of 1. For a complete list of service factors, refer to Table 1, page C-7. The ratings listed above apply directly to lubricated, single strand, standard roller chains. To select chains that vary in design or material from standard roller chain, use the factors in Table 3, page C-7. n Type A: Manual or drip (Maximum chain speed 500 FPM)] Type B: Bath or disc (Maximum chain speed 3500 FPM) Type C: Forced (pump)


(7010) C-9

C

No. 25 sprockets .250" pitch

Dimensions Number of teeth

Pitch diameter, inches

Root diameter, inches

Outside diameter, inches ∆

Maximum hub and groove diameter, inches

8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45

.653 .731 .809 .887 .966 1.045 1.124 1.203 1.282 1.361 1.440 1.519 1.598 1.678 1.757 1.836 1.915 1.995 2.074 2.154 2.233 2.312 2.392 2.471 2.551 2.630 2.710 2.789 2.869 2.948 3.028 3.107 3.187 3.266 3.346 3.425 3.505 3.584

.523 .601 .679 .757 .836 .915 .994 1.073 1.152 1.231 1.310 1.389 1.468 1.548 1.627 1.706 1.785 1.865 1.944 2.024 2.103 2.182 2.262 2.341 2.421 2.500 2.580 2.659 2.739 2.818 2.898 2.977 3.057 3.136 3.216 3.295 3.375 3.454

.754 .837 .919 1.002 1.083 1.167 1.246 1.326 1.407 1.487 1.568 1.648 1.729 1.809 1.889 1.969 2.049 2.129 2.209 2.289 2.389 2.449 2.529 2.609 2.688 2.768 2.848 2.928 3.008 3.087 3.167 3.247 3.327 3.406 3.486 3.566 3.646 3.725

.31 .41 .48 .56 .64 .73 .81 .89 .97 1.06 1.13 1.22 1.30 1.38 1.45 1.53 1.61 1.69 1.77 1.86 1.94 2.02 2.09 2.19 2.25 2.34 2.41 2.48 2.58 2.66 2.73 2.81 2.89 2.97 3.05 3.13 3.20 3.30

Hub length thru bore Sprocket type

B

Maximum bore with standard keyseat, inches s .250 .250 .250 .313 .375 .438 .563 .563 .563 .625 .750 .813 .875 .875 .938 1.000 1.063 1.188 1.250 1.250 1.250 1.250 1.313 1.375 1.500 1.563 1.625 1.688 1.750 1.750 1.813 1.813 1.875 1.938 2.000 2.125 2.188 2.250

S max., inches

Number of teeth




.125 .125 .125 .156 .219 .219 .313 .328 .344 .375 .469 .500 .531 .563 .594 .625 .656 .719 .734 .750 .766 .781 .813 .844 .938 .969 1.000 1.031 1.063 1.094 1.156 1.172 1.188 1.219 1.250 1.313 1.344 1.375

46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83

3.664 3.743 3.823 3.902 3.982 4.061 4.141 4.220 4.300 4.379 4.459 4.538 4.618 4.697 4.777 4.857 4.936 5.016 5.095 5.175 5.254 5.334 5.413 5.493 5.572 5.652 5.732 5.811 5.891 5.970 6.050 6.129 6.209 6.288 6.368 6.448 6.527 6.607

3.805 3.885 3.964 4.044 4.124 4.203 4.283 4.363 4.442 4.522 4.602 4.681 4.761 4.841 4.920 4.727 4.806 4.886 4.965 5.045 5.124 5.204 5.283 5.363 5.442 5.522 5.602 5.681 5.761 5.840 5.920 5.999 6.079 6.158 6.238 6.318 6.397 6.477

3.534 3.613 3.693 3.772 3.852 3.931 4.011 4.090 4.170 4.249 4.329 4.408 4.488 4.567 4.647 5.000 5.080 5.159 5.239 5.319 5.398 5.478 5.558 5.637 5.717 5.796 5.876 5.956 6.035 6.115 6.195 6.274 6.354 6.433 6.513 6.593 6.672 6.752

Number of teeth 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108 109 110 111 112 113 114 115 116 117 118 119 120


Outside Root diameter, diameter, inches inches ∆

6.686 6.556 6.766 6.636 6.845 6.715 6.925 6.795 7.004 6.874 7.084 6.954 7.164 7.034 7.243 7.113 7.323 7.193 7.402 7.272 7.482 7.352 7.561 7.431 7.641 7.511 7.720 7.590 7.800 7.670 7.880 7.750 7.959 7.829 8.039 7.882 8.118 7.962 8.198 8.042 8.277 8.121 8.357 8.201 8.437 8.280 8.516 8.360 8.596 8.439 8.675 8.519 8.755 8.599 8.834 8.678 8.914 8.758 8.994 8.837 9.073 8.917 9.153 8.996 9.232 9.076 9.312 9.156 9.391 9.235 9.471 9.315 9.550 9.394 Larger sizes available

Tooth dimensions

Number of teeth

Length thru bore, inches

8 to 19

.50

20 to 35

.63

36 to 73

.75

74 to 100

.88

T = .110” + .000”, –.007”

Recommended standard bore tolerances, keyseat dimensions, eccentricity tolerances, and similar data, page G-2. ∆ Non-functional dimension that may vary with the type of cutter used. s Based on maximum hub diameter.

C-10 (7010)


6.832 6.911 6.991 7.070 7.150 7.230 7.309 7.389 7.468 7.548 7.628 7.707 7.787 7.866 7.946 8.026 8.105 8.185 8.264 8.344 8.424 8.503 8.583 8.662 8.742 8.822 8.901 8.981 9.060 9.140 9.220 9.299 9.379 9.458 9.538 9.618 9.697

C

Drive Engineering


T

PITCH

K

E

E

D

D

C

K

K

T

C Fig. 6447

F

A

B

A

B

Fig. 6453

Specifications and dimensions Chain Number

Chain width, number of strands


t bearing area sq. in.



B

C

D

E

F

G

K

T

35

Single

2,100

.041

.22

.24

.31

.141

.200 ∆

.19

.31

.35

.399

.05

35-2

Double

4,200

.082

.42

.45

.50

.141

.200 ∆

.19

.31

.35

.399

.05

35-3

Triple

6,450

.123

.62

.63

.70

.141

.200 ∆

.19

.31

.35

.399

.05

35-4

Quadruple

8,600

.164

.82

.78

.91

.141

.200 ∆

.19

.31

.35

.399

.05

35-5

Quintuple

10,750

.205

1.06

1.03

1.11

.141

.200 ∆

.19

.31

.35

.399

.05

35-6

Sextuple

12,900

.246

1.27

1.23

1.31

.141

.200 ∆

.19

.31

.35

.399

.05

Available only in riveted construction. ∆ Bushing Diameter. Chain is rollerless.

Ratings Number of Maximum teeth, bore in small inches sprocket 100

Horsepower for single strand chain s RPM of small sprocket 1200 1800 2500 3000 3500 4000 4500 5000 5500 6000 6500 7000 7500 8000 8500 9000 10000

500

900

11

.563

0.18

0.77

1.31

1.70

2.45

3.30

2.94

2.33

1.91

1.60

1.37

1.18

1.04

0.92

0.82

0.74

0.67

0.62

0.57

0.48

12

.625

0.20

0.85

1.44

1.87

2.70

3.62

3.35

2.66

2.17

1.82

1.56

1.35

1.18

1.05

0.94

0.85

0.77

0.70

0.64

0.55

13

.688

0.22

0.93

1.57

2.04

2.94

3.95

3.77

3.00

2.45

2.05

1.75

1.52

1.33

1.18

1.06

0.95

0.87

0.79

0.73

0.62

14

.813

0.24

1.01

1.71

2.21

3.18

4.28

4.22

3.35

2.74

2.30

1.96

1.70

1.49

1.32

1.18

1.07

0.97

0.88

0.81

0.69

15

.875

0.25

1.08

1.84

2.38

3.43

4.61

4.68

3.71

3.04

2.55

2.17

1.88

1.65

1.47

1.31

1.18

1.07

0.98

0.90

0.77

16

.938

0.27

1.16

1.97

2.55

3.68

4.94

5.15

4.09

3.35

2.81

2.40

2.08

1.82

1.62

1.45

1.30

1.18

1.08

0.99

0.85

17

1.063

0.29

1.24

2.10

2.73

3.93

5.28

5.64

4.48

3.67

3.07

2.62

2.27

2.00

1.77

1.58

1.43

1.30

1.18

1.09

0.93

18

1.188

0.31

1.32

2.24

2.90

4.18

5.61

6.15

4.88

3.99

3.35

2.86

2.48

2.17

1.93

1.73

1.56

1.41

1.29

1.18

1.01

19

1.250

0.33

1.40

2.37

3.07

4.43

5.95

6.67

5.29

4.33

3.63

3.10

2.69

2.36

2.09

1.87

1.69

1.53

1.40

1.28

1.10

20

1.313

0.35

1.48

2.51

3.25

4.68

6.29

7.20

5.72

4.68

3.92

3.35

2.90

2.55

2.26

2.02

1.82

1.65

1.51

1.39

1.18

21

1.438

0.37

1.56

2.64

3.42

4.93

6.63

7.75

6.15

5.03

4.22

3.60

3.12

2.74

2.43

2.17

1.96

1.78

1.62

1.49

1.27

22

1.563

0.38

1.64

2.78

3.60

5.19

6.97

8.21

6.59

5.40

4.52

3.86

3.35

2.94

2.61

2.33

2.10

1.91

1.74

1.60

1.37

23

1.688

0.40

1.72

2.92

3.78

5.44

7.31

8.62

7.05

5.77

4.83

4.13

3.58

3.14

2.79

2.49

2.25

2.04

1.86

1.71

1.46

24

1.750

0.42

1.80

3.05

3.96

5.70

7.66

9.02

7.51

6.15

5.15

4.40

3.81

3.35

2.97

2.66

2.40

2.17

1.99

1.82

1.56

25

1.813

0.44

1.88

3.19

4.13

5.95

8.00

9.43

7.99

6.54

5.48

4.68

4.05

3.56

3.16

2.82

2.55

2.31

2.11

1.94

1.65

28

2.125

0.50

2.12

3.61

4.67

6.73

9.05

10.7

9.47

7.75

6.49

5.55

4.81

4.22

3.74

3.35

3.02

2.74

2.50

2.30

1.96

30

2.281

0.54

2.29

3.89

5.03

7.25

9.74

11.5

10.5

8.59

7.20

6.15

5.33

4.68

4.15

3.71

3.35

3.04

2.77

2.55

2.17

32

2.500

0.58

2.45

4.17

5.40

7.77

10.4

12.3

11.6

9.47

7.93

6.77

5.87

5.15

4.57

4.09

3.69

3.35

3.06

2.81

0

35

2.781

0.64

2.70

4.59

5.95

8.56

11.5

13.6

13.2

10.8

9.08

7.75

6.72

5.90

5.23

4.68

4.22

3.83

3.50

3.21

0

40

3.250

0.73

3.12

5.30

6.87

9.89

13.3

15.7

16.2

13.2

11.1

9.47

8.21

7.20

6.39

5.72

5.15

4.68

0

-

-

Lubrication type n

A

B

s Ratings are based on a service factor of 1. For a complete list of service factors, refer to Table 1, page C-7. The ratings listed above apply directly to lubricated, single strand, standard roller chains. For multiple strand chains, apply the factors shown in the table at right. To select chains that vary in design or material from standard roller chain, use the factors in Table 3, page C-7. n Type A: Manual or drip (Maximum chain speed 370 FPM) Type B: Bath or disc (Maximum chain speed 2800 FPM) Type C: Forced (pump)

C

Multiple strand factors Number of strands


2

1.7

3

2.5

4

3.3

5

4.1

6

5.0

7 or more

Consult Rexnord


(7010) C-11

C







8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45

.980 1.096 1.214 1.331 1.449 1.567 1.685 1.804 1.922 2.041 2.159 2.278 2.397 2.516 2.635 2.754 2.873 2.992 3.111 3.230 3.349 3.468 3.588 3.707 3.826 3.945 4.064 4.183 4.303 4.422 4.541 4.660 4.780 4.899 5.018 5.137 5.257 5.376

.780 .896 1.014 1.131 1.249 1.367 1.485 1.604 1.722 1.841 1.959 2.078 2.197 2.316 2.435 2.554 2.673 2.792 2.911 3.030 3.149 3.268 3.388 3.507 3.626 3.745 3.864 3.983 4.103 4.222 4.341 4.460 4.580 4.699 4.818 4.937 5.507 5.176

1.130 1.255 1.379 1.502 1.625 1.746 1.868 1.989 2.110 2.231 2.352 2.472 2.593 2.713 2.833 2.953 3.074 3.194 3.314 3.434 3.553 3.673 3.793 3.913 4.032 4.152 4.272 4.392 4.511 4.631 4.751 4.870 4.990 5.109 5.229 5.349 5.468 5.588

.50 .63 .75 .86 .98 1.11 1.23 1.36 1.47 1.59 1.72 1.84 1.95 2.08 2.20 2.31 2.44 2.56 2.67 2.80 2.92 3.03 3.16 3.28 3.39 3.52 3.64 3.75 3.88 4.00 4.11 4.23 4.36 4.47 4.59 4.72 4.83 4.95

Maximum bore with standard keyseat, inches s .250 .375 .500 .563 .625 .688 .813 .875 .938 1.063 1.188 1.250 1.313 1.438 1.563 1.688 1.750 1.813 1.938 2.000 2.125 2.250 2.281 2.375 2.500 2.625 2.750 2.781 2.875 3.000 3.125 3.188 3.250 3.281 3.375 3.438 3.500 3.625

S max., inches .125 .250 .313 .344 .406 .438 .500 .531 .594 .656 .719 .750 .813 .906 .969 1.031 1.094 1.156 1.219 1.250 1.313 1.375 1.438 1.500 1.563 1.625 1.688 1.750 1.813 1.875 1.938 1.969 2.000 2.063 2.125 2.156 2.188 2.250

Number of teeth



46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83

5.495 5.614 5.734 5.853 5.972 6.091 6.211 6.330 6.449 6.569 6.688 6.807 6.927 7.046 7.165 7.284 7.404 7.523 7.642 7.762 7.881 8.000 8.120 8.239 8.358 8.478 8.597 8.716 8.836 8.955 9.074 9.194 9.313 9.432 9.552 9.671 9.790 9.910

5.295 5.414 5.534 5.653 5.772 5.891 6.011 6.130 6.249 6.369 6.488 6.607 6.727 6.846 6.965 7.084 7.204 7.323 7.442 7.562 7.681 7.800 7.920 8.039 8.158 8.278 8.397 8.516 8.636 8.755 8.874 8.994 9.113 9.232 9.352 9.471 9.590 9.710

Hub length thru bore, inches Sprocket Number of Type Teeth 8 to 19 B

C

1 .75

5.708 5.827 5.946 6.066 6.186 6.305 6.425 6.544 6.664 6.783 6.903 7.022 7.142 7.261 7.381 7.500 7.619 7.739 7.858 7.978 8.097 8.217 8.336 8.456 8.575 8.695 8.814 8.934 9.053 9.172 9.291 9.411 9.531 9.650 9.770 9.889 10.008 10.128

Number of teeth 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108 109 110 111 112 113 114 115 116 117 118 119 120




10.247 10.367 10.486 10.606 10.725 10.844 10.964 11.083 11.203 11.322 11.441 11.561 11.680 11.800 11.919 12.038 12.158 12.277 12.397 12.519 12.635 12.755 12.874 12.994 13.113 13.232 13.352 13.471 13.590 13.710 13.829 13.949 14.068 14.187 14.307 14.426 14.546

Tooth dimensions, inches

Chain Width, Number of Strands 2 3 4 5 1.25


1.75

2.13

2.63

6 3.13

Dimension

1

T

.168

Chain Width, Number of Strands 2 3 4 5

6

.162

.162

.149

.149

.149

20 to 44

.88

1.38

1.88

2.25

2.75

3.25

L

-

.560

.958

1.343

1.741

2.139

45 to 102

1.00

1.50

2.00

2.38

2.88

3.38

K

-

.399

.399

.399

.399

.399

103 to 120

1.25

1.75

2.25

2.63

3.13

3.63

41 to 80

1.75

2.00

2.25

2.50

2.75

3.00

81 to 120

2.00

2.25

2.50

2.75

3.00

3.25

Machined sprockets ......... +.000”, –.008” Tolerances for T and L

Hot rolled steel plate sprockets or unfinished forgings ....... +.000”, –.027”

Recommended standard bore tolerances, keyseat dimensions, eccentricity tolerances and similar data, page G-2. ∆ Non-functional dimension that may vary with the type of cutter used. s Based on maximum hub diameter.

C-12 (7010)


C

Drive engineering


T

PITCH

K

E

E

D

D

C

K

K

T

C Fig. 6447

F

A

B

A

B

Fig. 6453


Chain Width, Number of Strands

Average ultimate strength, pounds

40 40-2 40-3 40-4 40-5 40-6

Single Double Triple Quadruple Quintuple Sextuple

3,700 7,400 11,100 14,800 18,500 22,200

t Weight bearing per foot, area, pounds sq. in. .068 .136 .204 .272 .340 .408

.39 .79 1.18 1.57 1.97 2.36


B

C

D

E

F

G

K

T

.32 .60 .89 1.17 1.45 1.73

.38 .67 .95 1.23 1.52 1.80

.156 .156 .156 .156 .156 .156

.313 .313 .313 .313 .313 .313

.31 .31 .31 .31 .31 .31

.41 .41 .41 .41 .41 .41

.47 .47 .47 .47 .47 .47

.566 .566 .566 .566 .566 .566

.06 .06 .06 .06 .06 .06

Available only in riveted construction.

Ratings Number of Maximum teeth, bore in small inches sprocket 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 28 30 32 35 40

.750 .844 1.000 1.188 1.250 1.375 1.500 1.625 1.750 1.875 2.063 2.188 2.250 2.250 2.281 2.625 2.750 3.000 3.563 3.781

Lubrication type n

50

100

200

300

400

500

Horsepower for single strand chain s RPM of small sprocket 700 1000 1200 1400 1600 1800 2400 3000 3500 4000 5000 6000 7000 8000

0.23 0.25 0.28 0.30 0.32 0.35 0.37 0.39 0.42 0.44 0.46 0.49 0.51 0.54 0.56 0.63 0.68 0.73 0.81 0.93

0.43 0.47 0.52 0.56 0.60 0.65 0.69 0.73 0.78 0.82 0.87 0.91 0.96 1.00 1.05 1.18 1.27 1.36 1.50 1.74

0.80 0.88 0.96 1.04 1.12 1.20 1.29 1.37 1.45 1.53 1.62 1.70 1.78 1.87 1.95 2.20 2.38 2.55 2.81 3.24

1.16 1.27 1.39 1.50 1.62 1.74 1.85 1.97 2.09 2.21 2.33 2.45 2.57 2.69 2.81 3.18 3.42 3.67 4.04 4.67

1.50 1.65 1.80 1.95 2.10 2.25 2.40 2.55 2.71 2.86 3.02 3.17 3.33 3.48 3.64 4.11 4.43 4.75 5.24 6.05

1.83 2.01 2.20 2.38 2.56 2.75 2.93 3.12 3.31 3.50 3.69 3.88 4.07 4.26 4.45 5.03 5.42 5.81 6.40 7.39

2.48 2.73 2.97 3.22 3.47 3.72 3.97 4.22 4.48 4.73 4.99 5.25 5.51 5.76 6.02 6.81 7.33 7.86 8.66 10.0

A

3.42 3.76 4.10 4.44 4.78 5.13 5.48 5.82 6.17 6.53 6.88 7.23 7.59 7.95 8.30 9.39 10.1 10.8 11.9 13.8

4.03 4.43 4.83 5.23 5.64 6.04 6.45 6.86 2.27 7.69 8.11 8.52 8.94 9.36 9.78 11.1 11.9 12.8 14.1 16.3

4.63 5.09 5.55 6.01 6.47 6.94 7.41 7.88 8.36 8.83 9.31 9.79 10.3 10.8 11.2 12.7 13.7 14.7 16.2 18.7

5.22 5.74 6.26 6.78 7.30 7.83 8.36 8.89 9.42 9.96 10.5 11.0 11.6 12.1 12.7 14.3 15.4 16.5 18.2 21.1

4.66 5.31 5.99 6.70 7.43 8.18 8.96 9.76 10.5 11.1 11.7 12.3 12.9 13.5 14.1 15.9 17.2 18.4 20.3 23.4

B

s Ratings are based on a service factor of 1. For a complete list of service factors. Refer to Table 1, page C-7. The ratings listed above apply directly to lubricated, single strand, standard roller chains. For multiple strand chains, apply the factors shown in the table at right. To select chains that vary in design or material from standard roller chain, use the factors in Table 3, page C-7. n Type A: Manual or drip (Maximum chain speed 300 FPM) Type B: Bath or disc (Maximum chain speed 2300 FPM) Type C: Forced (pump)

3.03 3.45 3.89 4.35 4.82 5.31 5.82 6.34 6.88 7.43 7.99 8.57 9.16 9.76 10.4 12.3 13.6 15.0 17.2 21.0

2.17 2.47 2.79 3.11 3.45 3.80 4.17 4.54 4.92 5.31 5.72 6.13 6.55 6.99 7.43 8.80 9.76 10.8 12.3 15.0

1.72 1.96 2.21 2.47 2.74 3.02 3.31 3.60 3.91 4.22 4.54 4.87 5.20 5.54 5.89 6.99 7.75 8.54 9.76 11.9

1.41 1.60 1.81 2.02 2.24 2.47 2.71 2.95 3.20 3.45 3.71 3.98 4.26 4.54 4.82 5.72 6.34 6.99 7.99 9.76

1.01 1.15 1.29 1.45 1.60 1.77 1.94 2.11 2.29 2.47 2.66 2.85 3.05 3.25 3.45 4.09 4.54 5.00 5.72 6.99

0.77 0.87 0.98 1.10 1.22 1.34 1.47 1.60 1.74 1.88 2.02 2.17 2.32 2.47 2.63 3.11 3.45 0 0 0

0.61 0.69 0.78 0.87 0.97 1.07 1.17 1.27 1.38 1.49 1.60 1.72 1.84 1.96 0 0 0 -

0.50 0.57 0.64 0.71 0.79 0.87 0.96 0 0 0 0 0 0 0 -

C Number of strands


2

1.7

3

2.5

4

3.3

5

4.1

6

5.0

7 or more

Consult Rexnord


(7010) C-13

C







8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45

1.307 1.462 1.618 1.775 1.932 2.089 2.247 2.405 2.563 2.721 2.879 3.038 3.196 3.355 3.513 3.672 3.831 3.989 4.148 4.307 4.466 4.625 4.783 4.942 5.101 5.260 5.419 5.578 5.737 5.896 6.055 6.214 6.373 6.532 6.691 6.850 7.009 7.168

.995 1.150 1.306 1.463 1.620 1.777 1.935 2.093 2.251 2.409 2.567 2.726 2.884 3.043 3.201 3.360 3.519 3.677 3.836 3.995 4.154 4.313 4.471 4.630 4.789 4.948 5.107 5.266 5.425 5.584 5.743 5.902 6.061 6.220 6.379 6.538 6.697 6.856

1.507 1.674 1.839 2.003 2.166 2.329 2.491 2.653 2.814 2.975 3.136 3.297 3.457 3.618 3.778 3.938 4.098 4.258 4.418 4.578 4.738 4.898 5.057 5.217 5.377 5.536 5.696 5.856 6.015 6.175 6.334 6.494 6.653 6.813 6.972 7.132 7.291 7.451

.67 .84 1.00 1.17 1.33 1.50 1.66 1.81 1.98 2.14 2.30 2.45 2.63 2.78 2.94 3.09 3.27 3.42 3.58 3.73 3.91 4.06 4.22 4.38 4.55 4.70 4.86 5.02 5.17 5.34 5.50 5.66 5.81 5.97 6.14 6.30 6.45 6.61

Maximum bore with standard keyseat, inches s .375 .500 .625 .750 .844 1.000 1.188 1.250 1.375 1.500 1.625 1.750 1.875 2.063 2.188 2.250 2.250 2.281 2.313 2.375 2.625 2.750 2.750 2.813 3.000 3.375 3.438 3.563 3.625 3.688 3.750 3.750 3.781 3.813 4.000 4.250 4.500 4.750

S max., inches

Number of teeth




.188 .313 .406 .469 .516 .625 .719 .750 .844 .938 1.000 1.063 1.188 1.281 1.344 1.375 1.406 1.438 1.469 1.500 1.625 1.688 1.750 1.781 1.875 2.125 2.156 2.219 2.250 2.281 2.313 2.344 2.375 2.406 2.500 2.625 2.750 2.875

46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83

7.327 7.486 7.645 7.804 7.963 8.122 8.281 8.440 8.599 8.758 8.917 9.076 9.236 9.395 9.554 9.713 9.872 10.031 10.190 10.349 10.508 10.667 10.826 10.986 11.145 11.304 11.463 11.622 11.781 11.940 12.099 12.258 12.417 12.577 12.736 12.895 13.054 13.213

7.015 7.174 7.333 7.492 7.651 7.810 7.969 8.128 8.287 8.446 8.605 8.764 8.924 9.083 9.242 9.401 9.560 9.719 9.878 10.037 10.196 10.355 10.514 10.674 10.833 10.992 11.151 11.310 11.469 11.628 11.787 11.946 12.105 12.265 12.424 12.583 12.742 12.901

7.609 7.769 7.927 8.088 8.247 8.407 8.566 8.725 8.885 9.044 9.203 9.363 9.522 9.681 9.841 10.000 10.159 10.318 10.478 10.637 10.796 10.956 11.115 11.274 11.434 11.593 11.752 11.911 12.071 12.230 12.389 12.548 12.708 12.867 13.026 13.185 13.345 13.504

Hub length thru bore, inches Sprocket Number of Type Teeth 8 to 19

1 .88

84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108 109 110 111 112 113 114 115 116 117 118 119 120




13.663 13.822 13.982 14.141 14.300 14.459 14.618 14.777 14.937 15.096 15.255 15.414 15.573 15.733 15.892 16.051 16.210 16.370 16.529 16.688 16.847 17.006 17.166 17.324 17.483 17.643 17.803 17.961 18.120 18.280 18.439 18.598 18.757 18.917 19.076 19.235 19.394



Number of teeth

2.13

2.75

3.38

6 4.00

Dimension

1

T

.168


6

.162

.162

.149

.149

.149

20 to 46

1.00

1.63

2.25

2.88

3.50

4.13

L

-

.560

.958

1.343

1.741

2.139

47 to 76

1.13

1.75

2.38

3.00

3.63

4.25

K

-

.399

.399

.399

.399

.399

77 to 90

1.25

2.00

2.63

3.25

3.88

4.50

91 to 120

1.38

2.25

2.88

3.50

4.13

4.75

30 to 60

1.75

2.13

2.50

3.25

3.63

4.00

B

C

61 to 82

2.00

2.38

2.75

3.50

3.88

4.25

83 to 120

2.25

2.63

3.00

3.75

4.13

4.50




C-14 (7010)


C

Drive Engineering


G

PITCH

PITCH

T

T

E

E

D

D

C F

C

AF

B

A

B

Fig. 6453

Fig. 6453



t bearing area, sq. in.


A

B

C

D

E

F

G

T

41

2,000

.049

.27

.27

.32

.141

.306

.25

.32

.38

.05

Dimensions, inches



.875 .969 1.125 1.250 1.313 1.438 1.563 1.688 1.813 1.875 2.063 2.188 2.250 2.250 2.313 2.625 2.813 3.125 3.563 3.875

Lubrication type n

50

100

200

300

400

500


0.13 0.14 0.15 0.16 0.18 0.19 0.20 0.22 0.23 0.24 0.26 0.27 0.28 0.29 0.31 0.35 0.38 0.40 0.44 0.51

0.24 0.26 0.28 0.31 0.33 0.36 0.38 0.40 0.43 0.45 0.48 0.50 0.53 0.55 0.57 0.65 0.70 0.75 0.83 0.96

0.44 0.49 0.53 0.57 0.62 0.66 0.71 0.75 0.80 0.84 0.89 0.93 0.98 1.03 1.07 1.21 1.31 1.40 1.54 1.78

0.64 0.70 0.76 0.83 0.89 0.95 1.02 1.08 1.15 1.21 1.28 1.35 1.41 1.48 1.55 1.75 1.88 2.02 2.22 2.57

0.82 0.91 0.99 1.07 1.15 1.24 1.32 1.40 1.49 1.57 1.66 1.74 1.83 1.92 2.00 2.26 2.44 2.61 2.88 3.33

1.01 1.11 1.21 1.31 1.41 1.51 1.61 1.72 1.82 1.92 2.03 2.13 2.24 2.34 2.45 2.77 2.98 3.20 3.52 4.07

1.37 1.50 1.63 1.77 1.91 2.05 2.18 2.32 2.46 2.60 2.74 2.89 3.03 3.17 3.31 3.74 4.03 4.33 4.76 5.50

A

1.88 2.07 2.25 2.44 2.63 2.82 3.01 3.20 3.40 3.59 3.78 3.98 4.17 4.37 4.57 5.16 5.56 5.96 6.57 7.59

1.71 1.95 2.20 2.46 2.73 3.01 3.29 3.59 3.89 4.20 4.46 4.69 4.92 5.15 5.38 6.08 6.55 7.03 7.74 8.94

1.36 1.55 1.75 1.95 2.17 2.39 2.61 2.85 3.09 3.33 3.59 3.85 4.11 4.38 4.66 5.52 6.13 6.75 7.72 9.43

1.11 1.27 1.43 1.60 1.77 1.95 2.14 2.33 2.53 2.73 2.94 3.15 3.37 3.59 3.81 4.52 5.01 5.52 6.32 7.72

0.93 1.06 1.20 1.34 1.49 1.64 1.79 1.95 2.12 2.29 2.46 2.64 2.82 3.01 3.20 3.79 4.20 4.63 5.29 6.47

0.61 0.69 0.78 0.87 0.96 1.06 1.16 1.27 1.38 1.49 1.60 1.71 1.83 1.95 2.08 2.46 2.73 3.01 3.44 4.20

B

0.43 0.49 0.56 0.62 0.69 0.76 0.83 0.91 0.98 1.06 1.14 1.23 1.31 1.40 1.49 1.76 1.95 2.15 2.46 3.01

0.34 0.39 0.44 0.49 0.55 0.60 0.66 0.72 0.78 0.84 0.91 0.97 1.04 1.11 1.18 1.40 1.55 1.71 1.95 2.39

0.28 0.32 0.36 0.40 0.45 0.49 0.54 0.59 0.64 0.69 0.74 0.80 0.85 0.91 0.96 1.14 1.27 1.40 1.60 1.95

0.20 0.23 0.26 0.29 0.32 0.35 0.39 0.42 0.46 0.49 0.53 0.57 0.61 0.65 0.69 0.82 0.91 1.00 1.14 1.40

0.15 0.17 0.20 0.22 0.24 0.27 0.29 0.32 0.35 0.38 0.40 0.43 0.46 0.49 0.53 0.62 0.69 0 0 0

0.12 0.14 0.16 0.17 0.19 0.21 0.23 0.25 0.28 0.30 0.32 0.34 0.37 0.39 0 0 0 -

0.10 0.11 0.13 0.14 0.16 0.17 0.19 0 0 0 0 0 0 0 -

C

s Ratings are based on a service factor of 1. For a complete list of service factors, refer to Table 1, page C-7. The ratings listed above apply directly to lubricated, single strand, standard roller chains. To select chains that vary in design or material from standard roller chain, use the factors in Table 3, page C-7. n Type A: Manual or drip (Maximum chain speed 300 FPM) Type B: Bath or disc (Maximum chain speed 2300 FPM) Type C: Forced (pump)


(7010) C-15

C







8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45

1.307 1.462 1.618 1.775 1.932 2.089 2.247 2.405 2.563 2.721 2.879 3.038 3.196 3.355 3.513 3.672 3.831 3.989 4.148 4.307 4.466 4.625 4.783 4.942 5.101 5.260 5.419 5.578 5.737 5.896 6.055 6.214 6.373 6.532 6.691 6.850 7.009 7.168

1.001 1.156 1.312 1.469 1.626 1.783 1.941 2.099 2.257 2.415 2.573 2.732 2.890 3.049 3.207 3.366 3.525 3.683 3.842 4.001 4.160 4.319 4.477 4.636 4.795 4.954 5.113 5.272 5.431 5.590 5.749 5.908 6.067 6.226 6.385 6.544 6.703 6.862

1.507 1.674 1.839 2.003 2.166 2.329 2.491 2.653 2.814 2.975 3.136 3.297 3.457 3.618 3.778 3.938 4.098 4.258 4.418 4.578 4.738 4.898 5.057 5.217 5.377 5.536 5.696 4.856 6.015 6.175 6.334 6.494 6.653 6.813 6.972 7.132 7.291 7.451

.77 .94 1.09 1.27 1.42 1.59 1.75 1.91 2.08 2.23 2.39 2.55 2.72 2.88 3.03 3.19 3.36 3.52 3.67 3.83 4.00 4.16 4.31 4.47 4.64 4.80 4.95 5.11 5.27 5.44 5.59 5.75 5.91 6.06 6.23 6.39 6.55 6.70

Maximum bore with standard keyseat, inches s .500 .625 .750 .875 .969 1.125 1.250 1.313 1.438 1.563 1.688 1.813 1.875 2.063 2.188 2.250 2.250 2.313 2.375 2.563 2.625 2.750 2.813 2.938 3.125 3.375 3.438 3.563 3.625 3.750 3.750 3.781 3.875 4.000 4.250 4.375 4.625 4.875

S max., inches

Number of teeth




.313 .406 .469 .531 .609 .688 .750 .813 .906 .969 1.031 1.156 1.188 1.281 1.344 1.375 1.438 1.469 1.500 1.594 1.625 1.750 1.781 1.844 1.938 2.125 2.156 2.219 2.250 2.313 2.344 2.375 2.438 2.500 2.625 2.688 2.750 2.938

46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83

7.327 7.486 7.645 7.804 7.963 8.122 8.281 8.440 8.599 8.758 8.917 9.076 9.236 9.395 9.554 9.713 9.872 10.031 10.190 10.349 10.508 10.667 10.826 10.986 11.145 11.304 11.463 11.622 11.781 11.940 12.099 12.258 12.417 12.577 12.736 12.895 13.054 13.213

7.021 7.180 7.339 7.498 7.657 7.816 7.975 8.134 8.293 8.452 8.611 8.770 8.930 9.089 9.248 9.407 9.566 9.725 9.884 10.043 10.202 10.361 10.520 10.680 10.839 10.998 11.157 11.316 11.475 11.634 11.793 11.952 12.111 12.271 12.430 12.589 12.748 12.907

7.609 7.769 7.927 8.088 8.247 8.407 8.566 8.725 8.885 9.044 9.203 9.363 9.522 9.681 9.841 10.000 10.159 10.318 10.478 10.637 10.796 10.956 11.115 11.274 11.434 11.593 11.752 11.911 12.071 12.230 12.389 12.548 12.708 12.867 13.026 13.185 13.345 13.504

Hub length thru bore, inches Sprocket Number of Type Teeth

B

8 to 19 20 to 46 47 to 76 77 to 90 91 to 120

Hub length, inches .88 1.00 1.13 1.25 1.38

Number of teeth 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108 109 110 111 112 113 114 115 116 117 118 119 120





Sprocket Type

Number of Teeth

Hub length, inches

C

30 to 60 61 to 82 83 to 120

1.75 2.00 2.25

T = .227” + .000”, –.009” for machined sprockets. T = .227” + .000”, –.032” for hot rolled steel plate sprockets or unfinished forgings.


C-16 (7010)

13.663 13.822 13.982 14.141 14.300 14.459 14.618 14.777 14.937 15.096 15.255 15.414 15.573 15.733 15.892 16.051 16.210 16.370 16.529 16.688 16.847 17.006 17.166 17.324 17.483 17.643 17.803 17.961 18.120 18.280 18.439 18.598 18.757 18.917 19.076 19.235 19.394


C

Drive Engineering


T

PITCH

K

E

E

D

D

C

K

K

T

C Fig. 6447

F

A

B

A

B

Fig. 6453





Dimensions, inches


A

B

C

D

E

F

G

K

T

50

Single

6,100

.108

.70

.41

.48

.200

.400

.38

.52

.59

.713

.08

50-2

Double

12,000

.216

1.39

.76

.83

.200

.400

.38

.52

.59

.713

.08

50-3

Triple

18,300

.324

2.09

1.12

1.19

.200

.400

.38

.52

.59

.713

.08

50-4

Quadruple

24,400

.432

2.76

1.48

1.54

.200

.400

.38

.52

.59

.713

.08

50-5

Quintuple

30,500

.540

3.15

1.84

1.90

.200

.400

.38

.52

.59

.713

.08

50-6

Sextuple

36,600

.648

3.77

2.19

2.25

.200

.400

.38

.52

.59

.713

.08



.969 1.125 1.313 1.438 1.625 1.750 1.875 2.063 2.250 2.375 2.563 2.688 2.813 2.875 2.906 3.250 3.563 3.750 4.125 5.125

Lubrication type n

50

100

300

500

900

Horsepower for single strand chain s RPM of small sprocket 1000 1200 1400 1600 1800 2100 2400 2700 3000 3500 4000 4500 5000 5500 6000

0.45 0.49 0.54 0.58 0.63 0.67 0.72 0.76 0.81 0.86 0.90 0.95 1.00 1.04 1.09 1.23 1.33 1.42 1.57 1.81

0.84 0.92 1.00 1.09 1.17 1.26 1.34 1.43 1.51 1.60 1.69 1.77 1.86 1.95 2.03 2.30 2.48 2.66 2.93 3.38

2.25 2.47 2.70 2.92 3.15 3.38 3.61 3.83 4.07 4.30 4.53 4.76 5.00 5.23 5.47 6.18 6.66 7.14 7.86 9.08

3.57 3.92 4.27 4.63 4.99 5.35 5.71 6.07 6.44 6.80 7.17 7.54 7.91 8.29 8.66 9.79 10.5 11.3 12.5 14.4

6.06 6.65 7.25 7.86 8.47 9.08 9.69 10.3 10.9 11.5 12.2 12.8 13.4 14.1 14.7 16.6 17.9 19.2 21.1 24.4

6.66 7.31 7.97 8.64 9.31 9.98 10.7 11.3 12.0 12.7 13.4 14.1 14.8 15.5 16.2 18.3 19.7 21.1 23.2 26.8

A

7.85 8.62 9.40 10.2 11.0 11.8 12.6 13.4 14.2 15.0 15.8 16.6 17.4 18.2 19.0 21.5 23.2 24.9 27.4 31.6

8.13 9.26 10.4 11.7 12.6 13.5 14.4 15.3 16.3 17.2 18.1 19.1 20.0 20.9 21.9 24.7 26.6 28.6 31.5 36.3

6.65 7.58 8.55 9.55 10.6 11.7 12.8 13.9 15.3 16.3 17.6 18.8 20.1 21.4 22.8 27.0 30.0 32.2 35.5 41.0

5.58 6.35 7.16 8.01 8.88 9.78 10.7 11.7 12.7 13.7 14.7 15.8 16.9 18.0 19.1 22.6 25.1 27.7 31.6 38.7

4.42 5.04 5.69 6.35 7.05 7.76 8.50 9.26 10.0 10.8 11.7 12.5 13.4 14.3 15.2 18.0 19.9 22.0 25.1 30.7

3.62 4.13 4.65 5.20 5.77 6.35 6.96 7.58 8.22 8.88 9.55 10.2 11.0 11.7 12.4 14.7 16.3 18.0 20.6 25.1

B

s Ratings are based on a service factor of 1. For a complete list of service factors, refer to Table 1, page C-7. The ratings listed above apply directly to lubricated, single strand, standard roller chains. For multiple strand chains, apply the factors shown in the table at right. To select chains that vary in design or material from standard roller chain, use the factors in Table 3, page C-7. n Type A: Manual or drip (Maximum chain speed 250 FPM) Type B: Bath or disc (Maximum chain speed 2000 FPM) Type C: Forced (pump)

3.04 3.46 3.90 4.36 4.83 5.32 5.83 6.35 6.89 7.44 8.01 8.59 9.18 9.78 10.4 12.3 13.7 15.1 17.2 21.0

2.59 2.95 3.33 3.72 4.13 4.55 4.98 5.42 5.88 6.35 6.84 7.33 7.84 8.35 8.88 10.5 11.7 12.9 14.7 18.0

2.06 2.34 2.64 2.95 3.27 3.61 3.95 4.30 4.67 5.04 5.42 5.82 6.22 6.63 7.05 8.35 9.26 10.2 11.7 14.3

1.68 1.92 2.16 2.42 2.68 2.95 3.23 3.52 3.82 4.13 4.44 4.76 5.09 5.42 5.77 6.84 7.58 8.35 9.55 0

1.41 1.61 1.81 2.03 2.25 2.47 2.71 2.95 3.20 3.46 3.72 3.99 4.27 4.55 4.83 5.73 0 0 0 -

1.20 21.37 1.55 1.73 1.92 2.11 2.31 2.52 2.73 2.95 3.18 3.41 0 0 0 0 -

1.04 1.19 1.34 1.50 1.66 1.83 2.01 0 0 0 0 0 -

0.92 1.04 0 0 0 0 0 -

C Number of strands


2

1.7

3

2.5

4

3.3

5

4.1

6

5.0

7 or more

Consult Rexnord


(7010) C-17

C







8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45

1.633 1.827 2.023 2.219 2.415 2.612 2.809 3.006 3.204 3.401 3.599 3.797 3.995 4.194 4.392 4.590 4.788 4.987 5.185 5.384 5.582 5.781 5.979 6.178 6.376 6.575 6.774 6.972 7.171 7.370 7.569 7.767 7.966 8.165 8.363 8.562 8.761 8.960

1.233 1.427 1.623 1.819 2.015 2.212 2.409 2.606 2.804 3.001 3.199 3.397 3.595 3.794 3.992 4.190 4.388 4.587 4.785 4.984 5.182 5.381 5.579 5.778 5.976 6.175 6.374 6.572 6.771 6.970 7.169 7.367 7.566 7.765 7.963 8.162 8.361 8.560

1.884 2.092 2.299 2.504 2.708 2.911 3.114 3.316 3.517 3.719 3.919 4.121 4.321 4.522 4.722 4.922 5.123 5.323 5.523 5.723 5.922 6.122 6.321 6.521 6.721 6.920 7.120 7.319 7.519 7.718 7.918 8.117 8.316 8.516 8.715 8.914 9.114 9.313

.84 1.06 1.27 1.47 1.67 1.88 2.08 2.28 2.48 2.69 2.89 3.08 3.28 3.48 3.69 3.89 4.08 4.28 4.48 4.69 4.89 5.08 5.28 5.48 5.69 5.89 6.08 6.28 6.48 6.69 6.88 7.08 7.28 7.48 7.67 7.88 8.08 8.28

Maximum bore with standard keyseat, inches s .563 .688 .875 .969 1.125 1.313 1.438 1.625 1.750 1.875 2.063 2.250 2.375 2.563 2.688 2.813 2.875 2.906 2.938 3.125 3.250 3.313 3.563 3.719 3.750 3.781 3.875 4.125 4.313 4.375 4.500 4.750 5.125 5.250 5.500 5.750 5.875 6.125

S max., inches

Number of teeth




.344 .438 .531 .609 .688 .813 .906 1.000 1.063 1.188 1.281 1.375 1.500 1.594 1.656 1.719 1.781 1.813 1.875 1.938 2.000 2.094 2.219 2.313 2.344 2.375 2.438 2.500 2.625 2.688 2.750 3.000 3.125 3.250 3.375 3.625 3.688 3.750

46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83

9.159 9.357 9.556 9.755 9.954 10.153 10.351 10.550 10.749 10.948 11.147 11.346 11.544 11.743 11.942 12.141 12.340 12.539 12.738 12.936 13.135 13.334 13.533 13.732 13.931 14.130 14.329 14.527 14.726 14.925 15.124 15.323 15.522 15.721 15.920 16.118 16.317 16.516

8.759 8.957 9.156 9.355 9.554 9.753 9.951 10.150 10.349 10.548 10.747 10.946 11.144 11.343 11.542 11.741 11.940 12.139 12.338 12.536 12.735 12.934 13.133 13.332 13.531 13.730 13.929 14.127 14.326 14.525 14.724 14.923 15.122 15.321` 15.520 15.718 15.917 16.116

9.512 9.711 9.911 10.110 10.309 10.508 10.708 10.907 11.106 11.305 11.504 11.703 11.903 12.102 12.301 12.500 12.699 12.898 13.097 13.296 13.496 13.694 13.894 14.093 14.292 14.491 14.690 14.889 15.088 15.287 15.486 15.685 15.884 16.083 16.283 16.481 16.681 16.879


1 1.00

84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108 109 110 111 112 113 114 115 116 117 118 119 120




2.50

3.25

4.00

6 4.75

Dimension T

1


6

3.43

.332

.332

.311

.311

.311

20 to 39

1.13

1.88

2.63

3.38

4.13

4.88

L

-

1.045

1.758

2.450

3.163

3.876

40 to 61

1.38

2.13

2.88

3.63

4.38

5.13

K

-

.713

.713

.713

.713

.713

62 to 90

1.63

2.38

3.13

3.88

4.63

5.38

91 to 120

1.88

2.63

3.38

4.13

4.88

5.63

26 to 48

2.00

2.50

3.00

3.75

4.25

4.75

B

49 to 60

2.25

2.75

3.25

4.00

4.50

5.00

61 to 80

2.50

3.00

3.50

4.25

4.75

5.25

81 to 120

2.75

3.25

3.75

4.50

5.00

5.50

C

C-18 (7010)

17.079 17.278 17.476 17.676 17.874 18.074 18.273 18.471 18.671 18.869 19.069 19.268 19.466 19.666 19.864 20.064 20.263 20.463 20.661 20.860 21.059 21.258 21.457 21.656 21.855 22.054 22.253 22.452 22.651 22.850 23.049 23.248 23.447 23.646 23.845 24.038 24.243



Number of teeth





C

Drive Engineering


T

PITCH

K

E

E

D

D

C

K

K

T

C Fig. 6447

F

A

B

A

B

Fig. 6453







B

C

D

E

F

G

K

T

60

Single

8,500

.162

1.02

.50

.60

.234

.469

.50

.60

.71

.897

.09

60-2

Double

17,000

.324

2.00

.95

1.05

.234

.469

.50

.60

.71

.897

.09

60-3

Triple

25,500

.486

3.00

1.40

1.50

.234

.469

.50

.60

.71

.897

.09

60-4

Quadruple

34,000

.648

3.83

1.84

1.95

.234

.469

.50

.60

.71

.897

.09

60-5

Quintuple

42,500

.810

5.02

2.30

2.40

.234

.469

.50

.60

.71

.897

.09

60-6

Sextuple

51,000

.972

6.02

2.69

2.85

.234

.469

.50

.60

.71

.897

.09

Available in riveted or cottered construction.


1.250 1.344 1.500 1.750 1.938 2.125 2.313 2.500 2.688 2.813 3.063 3.250 3.438 3.625 3.750 4.188 4.500 4.750 5.500 6.250

Lubrication type n

25

50

100

200

300

500


0.41 0.45 0.50 0.54 0.58 0.62 0.66 0.70 0.75 0.79 0.83 0.87 0.92 0.96 1.00 1.13 1.22 1.31 1.44 1.67

0.77 0.85 0.92 1.00 1.08 1.16 1.24 1.31 1.39 1.47 1.55 1.63 1.71 1.79 1.87 2.12 2.28 2.45 2.69 3.11

1.44 1.58 1.73 1.87 2.01 2.16 2.31 2.45 2.60 2.75 2.90 3.05 3.19 3.35 3.50 3.95 4.26 4.56 5.03 5.81

2.69 2.95 3.22 3.49 3.76 4.03 4.30 4.58 4.85 5.13 5.40 5.68 5.96 6.24 6.52 7.37 7.94 8.52 9.38 10.8

3.87 4.25 4.64 5.02 5.41 5.80 6.20 6.59 6.99 7.38 7.78 8.19 8.59 8.99 9.40 10.6 11.4 12.3 13.5 15.6

6.13 6.74 7.34 7.96 8.57 9.19 9.81 10.4 11.1 11.7 12.3 13.0 13.6 14.2 14.9 16.8 18.1 19.4 21.4 24.7

8.30 9.12 9.94 10.8 11.6 12.4 13.3 14.1 15.0 15.8 16.7 17.5 18.4 19.3 20.1 22.8 24.5 26.3 29.0 33.5

A

10.4 11.4 12.5 13.5 14.5 15.6 16.7 17.7 18.8 19.8 20.9 22.0 23.1 24.2 25.3 28.5 30.8 33.0 36.3 42.0

11.4 12.6 13.7 14.8 16.0 17.1 18.3 19.5 20.6 21.8 23.0 24.2 25.4 26.6 27.8 31.4 33.8 36.3 39.9 46.1

12.5 13.7 14.9 16.2 17.4 18.7 19.9 21.2 22.5 23.8 25.1 26.4 27.7 29.0 30.3 34.2 36.8 39.5 43.5 50.3

11.9 13.5 15.2 17.0 18.8 20.2 21.6 22.9 24.3 25.7 27.1 28.5 29.9 31.3 32.7 37.0 39.8 42.7 47.1 54.4

9.4 10.7 12.1 13.5 15.0 16.5 18.1 19.7 21.4 23.1 24.8 26.6 28.4 30.3 32.2 38.2 42.4 46.7 53.4 62.5

B

s Ratings are based on a service factor of 1. For a complete list of service factors, refer to Table 1, page C-7. The ratings listed above apply directly to lubricated, single strand, standard and heavy series roller chains. For multiple strand chains, apply the factors shown in the table at right. To select chains that vary in design or material from standard roller chain, use the factors in Table 3, page C-7. n Type A: Manual or drip (Maximum chain speed 220 FPM) Type B: Bath or disc (Maximum chain speed 1800 FPM) Type C: Forced (pump)

7.70 8.77 9.89 11.1 12.3 13.5 14.8 16.1 17.5 18.9 20.3 21.8 23.3 24.8 26.4 31.3 34.7 38.2 43.7 53.4

6.45 7.35 8.29 9.26 10.3 11.3 12.4 13.5 14.6 15.8 17.0 18.2 19.5 20.8 22.1 26.2 29.1 32.0 36.6 44.7

5.51 6.28 7.08 7.91 8.77 9.66 10.6 11.5 12.5 13.5 14.5 15.6 16.7 17.8 18.9 22.4 24.8 27.3 31.3 38.2

3.94 4.49 5.06 5.66 6.28 6.91 7.57 8.25 8.95 9.66 10.4 11.1 11.9 12.7 13.5 16.0 17.8 19.6 22.4 27.3

3.00 3.42 3.85 4.31 4.77 5.26 5.76 6.28 6.81 7.35 7.91 8.48 9.07 9.66 10.3 12.2 13.5 14.9 17.0 0

2.38 2.71 3.06 3.42 3.79 4.17 4.57 4.98 5.40 5.83 6.28 6.73 7.19 7.67 8.15 0 0 0 0 -

1.95 2.22 2.50 2.80 3.10 3.42 3.74 4.08 4.42 0 0 0 0 0 0 -

1.63 1.86 0 0 0 0 0 0 0 -

C



2

1.7

3

2.5

4

3.3

5

4.1

6

5.0

7 or more

Consult Rexnord


(7010) C-19

C







8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45

1.960 2.193 2.427 2.662 2.898 3.134 3.371 3.607 3.844 4.082 4.319 4.557 4.794 5.032 5.270 5.508 5.746 5.984 6.222 6.460 6.699 6.937 7.175 7.413 7.652 7.890 8.129 8.367 8.605 8.844 9.082 9.321 9.559 9.798 10.036 10.275 10.513 10.752

1.491 1.724 1.958 2.193 2.429 2.665 2.902 3.139 3.376 3.613 3.850 4.088 4.326 4.563 4.801 5.039 5.277 5.515 5.753 5.992 6.230 6.468 6.706 6.945 7.183 7.421 7.660 7.898 8.137 8.375 8.613 8.852 9.090 9.329 9.567 9.806 10.044 10.283

2.261 2.510 2.759 3.005 3.249 3.493 3.737 3.979 4.220 4.463 4.703 4.945 5.186 5.426 5.666 5.906 6.147 6.387 6.627 6.867 7.106 7.346 7.586 7.826 8.065 8.304 8.544 8.783 9.023 9.262 9.501 9.740 9.980 10.219 10.458 10.697 10.937 11.176

1.03 1.28 1.52 1.77 2.02 2.25 2.50 2.75 2.98 3.22 3.47 3.70 3.95 4.19 4.44 4.67 4.91 5.16 5.39 5.63 5.88 6.11 6.34 6.59 6.83 7.06 7.31 7.55 7.78 8.03 8.27 8.50 8.75 8.98 9.22 9.47 9.70 9.94

Maximum bore with standard keyseat, inches s .625 .875 1.000 1.250 1.344 1.500 1.750 1.938 2.125 2.313 2.500 2.688 2.813 3.063 3.250 3.438 3.625 3.750 3.875 4.000 4.188 4.375 4.500 4.563 4.750 5.125 5.375 5.500 5.625 5.875 6.000 6.125 6.250 6.375 6.500 6.875 7.125 7.375

S max., inches

Number of teeth




.406 .531 .625 .750 .828 .938 1.063 1.219 1.313 1.469 1.563 1.656 1.719 1.906 2.000 2.156 2.250 2.313 2.438 2.500 2.594 2.688 2.750 2.906 3.000 3.188 3.313 3.375 3.563 3.688 3.750 3.813 3.875 3.938 4.000 4.188 4.313 4.438

46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83

10.990 11.229 11.467 11.706 11.945 12.183 12.422 12.660 12.899 13.137 13.376 13.615 13.853 14.092 14.331 14.569 14.808 15.046 15.285 15.524 15.762 16.001 16.240 16.478 16.717 16.956 17.194 17.433 17.671 17.910 18.149 18.387 18.626 18.865 19.103 19.342 19.581 19.819

10.522 10.760 10.999 11.237 11.476 11.714 11.953 12.192 12.430 12.669 12.907 13.146 13.385 13.623 13.862 14.100 14.339 14.577 14.816 15.055 15.293 15.532 15.771 16.009 16.248 16.487 16.725 16.964 17.203 17.441 17.680 17.918 18.157 18.396 18.635 18.873 19.112 19.350

11.414 11.654 11.893 12.132 12.371 12.610 12.849 13.088 13.327 13.566 13.805 14.044 14.283 14.522 14.761 15.000 15.239 15.478 15.716 15.956 16.195 16.433 16.673 16.911 17.150 17.389 17.628 17.867 18.106 18.344 18.584 18.822 19.061 19.300 19.539 19.778 20.017 20.255


1 1.25

84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108 109 110 111 112 113 114 115 116 117 118 119 120




20.495 20.733 20.972 21.211 21.449 21.689 21.927 22.166 22.405 22.643 22.883 23.121 23.360 23.599 23.837 24.077 24.315 24.554 24.793 25.032 25.271 25.509 25.748 25.987 26.226 26.465 26.704 26.942 27.181 27.420 27.659 27.898 28.136 28.375 28.614 28.853 29.091



Number of teeth

3.00

4.00

4.88

6 5.75

Dimension

1


6

T

.459

.444

.444

.418

.418

.418

31 to 50

1.50

2.38

3.25

4.25

5.13

6.00

L

-

1.342

2.240

3.112

4.010

4.908

51 to 83

1.75

2.63

3.50

4.50

5.38

6.25

K

-

.897

.897

.897

.897

.897

84 to 120

2.00

2.88

3.75

4.75

5.63

6.50

20 to 40

2.25

2.75

3.75

4.75

5.50

6.25

41 to 80

2.50

3.00

3.75

4.75

5.50

6.25

81 to 120

3.00

3.50

4.00

5.00

5.75

6.50

B

C




C-20 (7010)


C

Drive Engineering

No. 80 chain 1.000" pitch G

T

PITCH

K

E

E

D

D

C

K

K

T

C Fig. 6447

F

A

B

A

B

Fig. 6453







B

C

D

E

F

G

K

T

80

Single

14,500

.275

1.67

.63

.74

.313

.625

.63

.75

.91

1.153

.13

80-2

Double

29,000

.550

3.31

1.21

1.30

.313

.625

.63

.75

.91

1.153

.13

80-3

Triple

43,500

.825

4.97

1.78

1.87

.313

.625

.63

.75

.91

1.153

.13

80-4

Quadruple

58,000

1.100

6.76

2.35

2.44

.313

.625

.63

.75

.91

1.153

.13

80-5

Quintuple

72,500

1.375

8.21

2.92

3.03

.313

.625

.63

.75

.91

1.153

.13

80-6

Sextuple

87,000

1.650

9.84

3.50

3.61

.313

.625

.63

.75

.91

1.153

.13



1.625 1.750 2.000 2.250 2.563 2.875 3.125 3.375 3.688 3.813 4.125 4.438 4.625 4.688 4.750 5.375 5.750 6.313 7.750 9.375

Lubrication type n

25

50

100

200

300

400


0.97 1.06 1.16 1.25 1.35 1.45 1.55 1.64 1.74 1.84 1.94 2.04 2.14 2.24 2.34 2.65 2.85 3.06 3.37 3.89

1.80 1.98 2.16 2.34 2.52 2.70 2.88 3.07 3.25 3.44 3.62 3.81 4.00 4.19 4.37 4.94 5.33 5.71 6.29 7.27

3.36 3.69 4.03 4.36 4.70 5.04 5.38 5.72 6.07 6.41 6.76 7.11 7.46 7.81 8.16 9.23 9.94 10.7 11.7 13.6

6.28 6.89 7.52 8.14 8.77 9.41 10.0 10.7 11.3 12.0 12.6 13.3 13.9 14.6 15.2 17.2 18.5 19.9 21.9 25.3

9.04 9.93 10.8 11.7 12.6 13.5 14.5 15.4 16.3 17.2 18.2 19.1 20.1 21.0 21.9 24.8 26.7 28.6 31.6 36.4

11.7 12.9 14.0 15.2 16.4 17.6 18.7 19.9 21.1 22.3 23.5 24.8 26.0 27.2 28.4 32.1 34.6 37.1 40.9 47.2

14.3 15.7 17.1 18.6 20.0 21.5 22.9 24.4 25.8 27.3 28.8 30.3 31.8 33.2 34.7 39.3 42.3 45.4 50.0 57.7

A

19.4 23.0 21.3 26.2 23.2 29.1 25.1 31.5 27.1 34.0 29.0 36.4 31.0 38.9 33.0 41.4 35.0 43.8 37.0 46.3 39.0 48.9 41.0 51.4 43.0 53.9 45.0 56.4 47.0 59.0 53.2 66.7 57.3 71.8 61.4 77.0 67.6 84.8 78.1 99.01

19.6 22.3 25.2 28.2 31.2 34.4 37.7 41.1 44.5 48.1 51.7 55.5 59.3 62.0 64.8 73.3 78.9 84.6 93.3 108

14.9 17.0 19.2 21.4 23.8 26.2 28.7 31.2 33.9 36.6 39.4 42.2 45.1 48.1 51.1 60.6 67.2 74.0 84.7 103

11.8 13.5 15.2 17.0 18.9 20.8 22.7 24.8 26.9 29.0 31.2 33.5 35.8 38.2 40.6 48.1 53.3 58.7 67.2 82.1

B

The dotted line indicates the point at which pin and bushing galling is likely to begin. When the desired selection falls within the shaded area, consult Rexnord for guidance. s Ratings are based on a service factor of 1. For a complete list of service factors, refer to Table 1, page C-7. The ratings listed above apply directly to lubricated, single strand, standard and heavy series roller chains. For multiple strand chains, apply the factors shown in the table at right. To select chains that vary in design or material from standard roller chain, use the factors in Table 3, page C-7. n Type A: Manual or drip (Maximum chain speed 170 FPM) Type B: Bath or disc (Maximum chain speed 1500 FPM) Type C: Forced (pump)

9.69 11.0 12.5 13.9 15.4 17.0 18.6 20.3 22.0 23.8 25.6 27.4 29.3 31.2 33.2 39.4 43.6 48.1 55.0 67.2

8.12 9.25 10.4 11.7 12.9 14.2 15.6 17.0 18.4 19.9 21.4 23.0 24.6 26.2 27.8 33.0 36.6 40.3 46.1 56.3

6.93 7.90 8.91 9.96 11.0 12.2 13.3 14.5 15.7 17.0 18.3 19.6 21.0 22.3 23.8 28.2 31.2 34.4 39.4 48.1

6.01 6.85 7.72 8.63 9.57 10.5 11.5 12.6 13.6 14.7 15.9 17.0 18.2 19.4 20.6 24.4 27.1 29.8 34.1 20.0

5.27 6.01 6.78 7.57 8.40 9.25 10.1 11.0 12.0 12.9 13.9 14.9 15.9 17.0 18.1 21.4 23.8 26.2 0 0

4.42 5.04 5.68 6.35 7.04 7.76 8.49 9.25 10.0 10.8 11.7 12.5 13.4 14.2 15.1 0 0 0 -

3.77 4.30 4.85 5.42 6.01 6.62 7.25 7.90 8.57 0 0 0 0 0 0 -

1.70 0 0 0 0 0 0 0 0 -

C



2

1.7

3

2.5

4

3.3

5

4.1

6

5.0

7 or more

Consult Rexnord


(7010) C-21

C

No. 80 sprockets 1.000" pitch






8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45

2.613 2.924 3.236 3.549 3.864 4.179 4.494 4.810 5.126 5.442 5.759 6.076 6.393 6.710 7.027 7.344 7.661 7.979 8.296 8.614 8.932 9.249 9.567 9.885 10.202 10.520 10.838 11.156 11.474 11.792 12.110 12.428 12.746 13.064 13.382 13.700 14.018 14.336

1.988 2.299 2.611 2.924 3.239 3.554 3.869 4.185 4.501 4.817 5.134 5.451 5.768 6.085 6.402 6.719 7.035 7.354 7.671 7.989 8.307 8.624 8.942 9.260 9.577 9.895 10.213 10.531 10.849 11.167 11.485 11.803 12.121 12.439 12.757 13.075 13.393 13.711

3.014 3.347 3.678 4.006 4.332 4.657 4.982 5.305 5.627 5.950 6.271 6.593 6.914 7.235 7.555 7.875 8.196 8.516 8.836 9.156 9.475 9.795 10.114 10.434 10.753 11.072 11.392 11.711 12.030 12.349 12.668 12.987 13.306 13.625 13.944 14.263 14.582 14.901

1.38 1.72 2.05 2.38 2.70 3.02 3.34 3.67 3.98 4.31 4.54 4.95 5.28 5.59 5.92 6.23 6.56 6.88 7.20 7.52 7.84 8.16 8.48 8.80 9.11 9.44 9.75 10.08 10.39 10.72 11.03 11.34 11.67 11.98 12.31 12.63 12.94 13.27

Maximum bore with standard keyseat, inches s .875 1.188 1.313 1.625 1.750 2.000 2.250 2.563 2.875 3.125 3.375 3.688 3.813 4.125 4.438 4.625 4.688 4.750 5.063 5.125 5.375 5.625 5.750 6.000 6.313 7.000 7.563 7.750 8.063 8.250 8.500 9.125 9.375 9.500 9.625 9.750 9.813 9.875

S max., inches

Number of teeth




.563 .719 .813 1.000 1.063 1.250 1.375 1.594 1.813 1.938 2.125 2.281 2.344 2.563 2.719 2.813 2.938 3.000 3.156 3.188 3.313 3.563 3.625 3.750 3.906 4.250 4.656 4.750 4.906 5.000 5.125 5.438 5.563 5.625 5.688 5.750 5.906 5.938

46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83

14.654 14.972 15.290 15.608 15.926 16.244 16.562 16.880 17.198 17.517 17.836 18.153 18.471 18.789 19.107 19.426 19.744 20.062 20.380 20.698 21.016 21.335 21.653 21.971 22.289 22.607 22.926 23.244 23.562 23.880 24.198 24.517 24.835 25.153 25.471 25.790 26.108 26.426

14.029 14.347 14.665 14.983 15.301 15.619 15.937 16.255 16.573 16.892 17.210 17.528 17.846 18.164 18.482 18.800 19.119 19.347 19.755 20.073 20.391 20.710 21.028 21.346 21.664 21.982 22.301 22.619 22.937 23.255 23.573 23.892 24.210 24.528 24.846 25.165 25.483 25.801

15.219 15.538 15.857 16.176 16.495 16.813 17.132 17.451 17.769 18.088 18.406 18.725 19.044 19.363 19.681 20.000 20.318 20.637 20.955 21.274 21.593 21.911 22.230 22.548 22.867 23.185 23.504 23.822 24.141 24.459 24.778 25.096 25.415 25.733 26.052 26.370 26.689 27.007


B

C

1 1.38

3.63

4.75

5.88

6 7.00



27.326 27.644 27.962 28.281 28.599 28.918 29.236 29.554 29.873 30.191 30.510 30.828 31.146 31.465 31.783 32.102 32.420 32.739 33.057 33.376 33.694 34.012 34.331 34.649 34.968 35.286 35.605 35.923 36.241 36.560 36.878 37.197 37.515 37.833 38.152 38.470 38.788

Dimension

1


T

.575

.557

6

.557

.526

.526

.526

16 to 24

1.63

2.75

3.88

5.00

6.13

7.25

L

-

1.709

2.861

3.982

5.134

6.286

25 to 37

1.88

3.00

4.13

5.25

6.38

7.50

K

-

1.153

1.153

1.153

1.153

1.153

38 to 60

2.13

3.25

4.38

5.50

6.63

7.75

61 to 88

2.38

3.50

4.63

5.75

6.88

8.00

89 to 120

2.63

3.75

4.88

6.00

7.13

8.25

18 to 36

2.50

3.25

4.50

5.75

6.50

7.25

37 to 64

3.00

3.75

4.50

5.75

6.50

7.25

65 to 80

3.25

4.00

4.75

6.00

6.75

7.50

81 to 120

3.50

4.25

5.00

6.25

7.00

7.75

C-22 (7010)

84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108 109 110 111 112 113 114 115 116 117 118 119 120




Number of teeth





C

Drive Engineering


T

PITCH

K

E

E

D

D

C

K

K

T

C Fig. 6447

F

A

B

A

B

Fig. 6453







B

C

D

E

F

G

K

T

100

Single

26,000

.401

2.72

.76

.89

.375

.750

.75

.97

1.13

1.408

.16

100-2

Double

52,000

.802

5.19

1.46

1.59

.375

.750

.75

.97

1.13

1.408

.16

100-3

Triple

78,000

1.203

7.67

2.16

2.29

.375

.750

.75

.97

1.13

1.408

.16

100-4

Quadruple

104,000

1.604

10.1

2.86

2.99

.375

.750

.75

.97

1.13

1.408

.16

100-5

Quintuple

130.000

2.005

12.7

3.56

3.69

.375

.750

.75

.97

1.13

1.408

.16

100-6

Sextuple

156,000

2.406

15.2

4.26

4.39

.375

.750

.75

.97

1.13

1.408

.16

Available in riveted and cottered construction.


2.000 2.250 2.500 2.813 3.250 3.500 3.813 4.188 4.563 4.875 5.250 5.625 5.813 6.000 6.125 7.000 7.625 8.250 9.125 -

Lubrication type n

25

50

100

200

1.85 2.03 2.22 2.40 2.59 2.77 2.96 3.15 3.34 3.53 3.72 3.91 4.10 4.30 4.49 5.07 5.47 5.86 6.46 7.46

3.45 3.79 4.13 4.48 4.83 5.17 5.52 5.88 6.23 6.58 6.94 7.30 7.66 8.02 8.38 9.47 10.2 10.9 12.0 13.9

6.44 7.08 7.72 8.36 9.01 9.66 10.3 11.0 11.6 12.3 13.0 13.6 14.3 15.0 15.6 17.7 19.0 20.4 22.5 26.0

12.0 17.3 22.4 13.2 19.0 24.6 14.4 20.7 26.9 15.6 22.5 29.1 16.8 24.2 31.4 18.0 26.0 33.6 19.2 27.7 35.9 20.5 29.5 38.2 21.7 31.2 40.5 22.9 33.0 42.8 24.2 34.8 45.1 25.4 36.6 47.4 26.7 38.4 49.8 27.9 40.2 52.1 29.2 42.0 54.4 33.0 47.5 61.5 35.5 51.2 66.3 38.1 54.91 71.1 42.0 60.4 78.3 48.5 69.8 90.4

A

300

400

Horsepower for single strand chain s RPM of small sprocket 500 600 700 800 900 1000 1200 1400 1600 1800 2000 2200 2400 2600 27.4 30.1 32.8 35.6 38.3 41.1 43.9 46.7 49.5 52.3 55.1 58.0 60.8 63.7 66.6 75.2 81.0 86.9 95.7 111

32.3 35.5 38.7 41.9 45.2 48.4 51.7 55.0 58.3 61.6 65.0 68.3 71.7 75.0 78.4 88.6 95.5 102 113 130

37.1 40.8 44.5 48.2 51.9 55.6 59.4 62.3 67.0 70.8 74.6 78.5 82.3 86.2 90.1 102 110 118 130 150

32.8 37.3 42.1 47.0 52.2 57.5 63.0 68.6 74.4 79.8 84.2 88.5 92.8 97.2 102 115 124 133 146 169

27.5 31.3 35.3 39.4 43.7 48.2 52.8 57.5 62.3 67.3 72.4 77.7 83.0 88.5 94.1 112 124 136 156 188

23.4 26.7 30.1 33.7 37.3 41.1 45.0 49.1 53.2 57.5 61.8 66.3 70.9 75.6 80.3 95.2 106 116 133 163

B


17.8 20.3 22.9 25.6 28.4 31.3 34.3 37.3 40.5 43.7 47.0 50.4 53.9 57.5 61.1 72.4 80.3 88.5 101 124

14.2 16.1 18.2 20.3 22.5 24.8 27.2 29.6 32.1 34.7 37.3 40.0 42.8 45.6 48.5 57.5 63.7 70.2 80.3 98.1

11.6 13.2 14.9 16.6 18.4 20.3 22.3 24.2 26.3 28.4 30.6 32.8 35.0 37.3 39.7 47.0 52.2 57.5 65.8 80.3

9.71 11.1 12.5 13.9 15.5 17.0 18.7 20.3 22.0 23.8 25.6 27.5 29.4 31.3 33.3 39.4 43.7 45.2 55.1 0

8.29 9.45 10.6 11.9 13.2 14.5 15.9 17.4 18.8 20.3 21.9 23.4 25.1 26.7 28.4 33.7 10.0 0 0 -

7.19 8.19 9.23 10.3 11.4 12.6 13.8 15.0 16.3 17.6 19.0 20.3 7.74 0 0 0 0 -

6.31 7.19 8.10 9.05 10.0 11.1 0.79 0 0 0 0 0 0 -

1.29 0 0 0 0 0 0 -

C



2

1.7

3

2.5

4

3.3

5

4.1

6

5.0

7 or more

Consult Rexnord


(7010) C-23

C







8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45

3.266 3.655 4.045 4.437 4.830 5.223 5.617 6.012 6.407 6.803 7.198 7.595 7.991 8.387 8.783 9.180 9.577 9.973 10.370 10.767 11.164 11.561 11.958 12.356 12.753 13.150 13.547 13.945 14.342 14.740 15.137 15.534 15.932 16.329 16.727 17.124 17.522 17.920

2.516 7.905 3.295 3.687 4.080 4.473 4.867 5.262 5.657 6.053 6.448 6.845 7.241 7.637 8.033 8.430 8.827 9.223 9.620 10.017 10.414 10.811 11.208 11.606 12.003 12.400 12.797 12.195 13.592 13.990 14.387 14.784 15.182 15.579 15.977 16.374 16.772 17.170

3.768 4.184 4.598 5.008 5.415 5.821 6.228 6.631 7.034 7.438 7.839 8.241 8.643 9.044 9.444 9.844 10.245 10.645 11.045 11.445 11.844 12.244 12.643 13.043 13.441 13.840 14.240 14.639 15.038 15.436 15.835 16.234 16.633 17.031 17.430 17.829 18.228 18.626

1.73 2.14 2.56 2.97 3.38 3.78 4.19 4.59 5.00 5.41 5.80 6.20 6.61 7.00 7.41 7.81 8.20 8.61 9.02 9.41 9.81 10.20 10.61 11.00 11.41 11.80 12.20 12.61 13.00 13.41 13.80 14.20 14.59 15.00 15.39 15.80 16.19 16.59

Maximum bore with standard keyseat, inches s 1.188 1.375 1.625 2.000 2.250 2.500 2.813 3.250 3.500 3.813 4.188 4.563 4.875 5.250 5.625 5.813 6.000 6.125 6.188 6.375 7.000 7.250 7.625 7.750 8.250 8.375 9.000 9.125 -

S max., inches

Number of teeth




.719 .844 1.000 1.250 1.375 1.563 1.719 2.000 2.188 2.344 2.594 2.781 3.063 3.250 3.438 3.656 3.750 3.813 3.844 4.063 4.250 4.375 4.563 4.750 5.000 5.063 5.375 5.438 -

46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83

18.317 18.715 19.122 19.510 19.908 20.305 20.703 21.100 21.498 21.896 22.293 22.691 23.089 23.486 23.884 24.282 24.680 25.077 25.475 25.873 26.271 26.668 27.066 27.464 27.862 28.259 28.657 29.055 29.453 29.850 30.248 30.646 31.044 31.441 31.839 32.237 32.635 33.033

17.567 17.965 18.362 18.760 19.168 19.555 19.953 20.350 20.748 21.146 21.543 21.941 22.339 22.736 23.134 25.532 23.930 24.327 24.725 25.123 25.521 25.918 26.316 26.714 27.112 27.509 27.907 28.305 28.703 29.100 29.498 29.896 30.294 30.691 31.089 31.487 31.885 32.283

19.024 19.423 19.821 20.220 20.619 21.016 21.415 21.814 22.211 22.610 23.008 23.406 23.805 24.204 24.601 25.000 25.398 25.796 26.194 26.592 26.991 27.389 27.788 28.185 25.584 28.981 29.380 29.778 30.176 30.574 30.973 31.370 31.769 32.166 32.565 32.963 33.361 33.759

B

C

8 to 13 14 to 18 19 to 38 39 to 53 54 to 68 69 to 88 89 to 120 15 to 26 27 to 40 41 to 60 61 to 72 73 to 80 81 to 100 101 to 120

C-24 (7010)

1 1.50 1.75 2.00 2.25 2.50 2.75 3.00 3.00 3.25 3.50 3.75 4.00 4.25 4.50

Chain Width, Number of Strands 2 3 4 5 2.88 3.13 3.38 3.63 3.88 4.13 4.38 4.25 4.25 4.50 4.75 5.00 5.25 5.50

84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108 109 110 111 112 113 114 115 116 117 118 119 120



33.430 32.680 33.828 33.078 34.226 33.476 34.624 33.874 35.021 34.271 35.419 34.669 35.817 35.067 36.215 35.465 36.612 35.862 37.010 36.260 37.408 36.658 37.806 37.056 38.203 37.453 38.601 37.851 38.999 38.249 39.397 38.647 39.795 39.045 40.193 39.443 40.591 39.841 40.989 40.239 41.386 40.636 41.784 41.034 42.182 41.432 42.580 41.820 42.978 42.228 43.376 42.626 43.774 43.024 44.171 43.421 44.569 43.819 44.967 44.217 45.365 44.615 45.763 45.013 46.161 45.411 46.559 45.809 46.957 46.027 47.354 46.604 47.752 47.002 Larger sizes available.

34.158 34.555 34.953 35.351 35.749 36.148 36.545 36.943 37.341 37.739 38.138 38.535 38.933 39.331 39.729 40.128 40.525 40.924 41.321 41.720 42.118 42.515 42.914 43.311 43.710 44.108 44.506 44.904 45.301 45.700 46.098 46.496 46.894 47.291 47.690 48.088 48.485



Number of teeth

4.25 4.50 4.75 5.00 5.25 5.50 5.75 5.25 5.25 5.25 5.50 5.75 6.00 6.25

5.75 6.00 6.25 6.50 6.75 7.00 7.25 6.25 6.25 6.25 6.50 6.75 7.00 7.25

7.13 7.38 7.63 7.88 8.13 8.38 8.63 7.25 7.25 7.25 7.50 7.75 8.00 8.25

6 8.50 8.75 9.00 9.25 9.50 9.75 10.00 8.25 8.25 8.25 8.50 8.75 9.00 9.25

Dimension

1


T

.692

.669

L

-

K

-

6

.669

.633

.633

.633

2.077

3.485

4.857

6.265

7.673

1.408

1.408

1.408

1.408

1.408





C

Drive Engineering


T

PITCH

K

E

E

D

D

C

K

K

T

C Fig. 6447

F

A

B

A

B

Fig. 6453





Dimensions, inches


A

B

C

D

E

F

G

K

T

120

Single

36,500

.606

3.72

.96

1.13

.438

.875

1.00

1.13

1.38

1.789

.19

120-2

Double

73,000

1.212

7.38

1.84

2.02

.438

.875

1.00

1.13

1.38

1.789

.19

120-3

Triple

109,500

1.818

11.0

2.74

2.91

.438

.875

1.00

1.13

1.38

1.789

.19

120-4

Quadruple

146,000

2.424

14.7

3.63

3.81

.438

.875

1.00

1.13

1.38

1.789

.19

120-5

Quintuple

182,500

3.030

18.4

4.52

4.70

.438

.875

1.00

1.13

1.38

1.789

.19

120-6

Sextuple

219,000

3.636

22.0

5.42

5.59

.438

.875

1.00

1.13

1.38

1.789

.19



2.438 2.750 3.188 3.625 4.000 4.438 4.688 5.188 5.563 5.938 6.375 6.500 6.688 7.000 7.250 8.375 9.250 10.000 -

Lubrication type n

Horsepower for single strand chain s RPM of small sprocket 10

25

50

100

200

300

400

500

600

700

800

900

1000 1100 1200 1300 1400

1600

1800

2000

1.37 1.50 1.64 1.78 1.91 2.05 2.19 2.33 2.47 2.61 2.75 2.90 3.04 3.18 3.32 3.76 4.05 4.34 4.78 5.52

3.12 3.43 3.74 4.05 4.37 4.68 5.00 5.32 5.64 5.96 6.28 6.60 6.93 7.25 7.58 8.57 9.23 9.90 10.9 12.6

5.83 6.40 6.98 7.56 8.15 8.74 9.33 9.92 10.5 11.1 11.7 12.3 12.9 13.5 14.1 16.0 17.2 18.5 20.3 23.5

10.9 11.9 13.0 14.1 15.2 16.3 17.4 18.5 19.6 20.7 21.9 23.0 24.1 25.3 26.4 29.8 32.1 34.5 38.0 43.9

20.3 22.3 24.3 26.3 28.4 30.4 32.5 34.6 36.6 38.7 40.8 42.9 45.0 47.1 49.3 55.7 60.0 64.3 70.9 81.8

29.2 32.1 35.0 37.9 40.9 43.8 46.8 49.8 52.8 55.8 58.8 61.8 64.9 67.9 71.0 80.2 86.4 92.6 102 118

37.9 41.6 45.4 49.1 53.0 56.8 60.6 64.5 68.4 72.2 76.2 80.1 84.0 88.0 91.9 104 112 120 132 153

46.3 50.9 55.5 60.1 64.7 69.4 74.1 78.8 83.6 88.3 93.1 97.9 103 108 112 127 137 147 162 187

54.6 59.9 65.3 70.8 76.3 81.8 87.3 92.9 98.5 104 110 115 121 127 132 150 161 173 190 220

46.3 52.8 59.5 66.5 73.8 81.3 89.0 97.0 105 114 122 131 139 146 152 172 185 199 219 253

37.9 43.2 48.7 54.4 60.4 66.5 72.8 79.4 86.1 92.9 100 107 115 122 130 154 171 188 215 263

31.8 36.2 40.8 45.6 50.6 55.7 61.0 66.5 72.1 77.9 83.8 89.9 96.1 102 109 129 143 158 180 220

27.1 30.9 34.9 39.0 43.2 47.6 52.1 56.8 61.6 66.5 71.6 76.7 82.0 87.4 92.9 110 122 135 154 188

13.4 15.3 17.2 19.2 21.3 23.5 25.8 28.1 30.4 32.9 35.4 37.9 40.5 43.2 45.9 54.4 42.4 0 0 0

11.2 12.8 14.4 16.1 17.9 19.7 21.6 23.5 25.5 27.5 29.6 16.6 0 0 0 0 0 -

9.59 10.9 12.3 8.94 0 0 0 0 0 0 0 0 -

A

B


23.5 26.8 30.2 33.8 37.4 41.2 45.2 49.2 53.4 57.6 62.0 66.5 71.1 75.8 80.6 95.5 106 117 133 163

20.6 23.5 26.5 29.6 32.9 36.2 39.6 43.2 46.8 50.6 54.4 58.4 62.4 66.5 70.7 83.8 92.9 102 117 143

18.3 20.9 23.5 26.3 29.1 32.1 35.2 38.3 41.5 44.9 48.3 51.8 55.3 59.0 62.7 74.3 82.4 90.8 104 127

16.4 18.7 21.0 23.5 26.1 28.7 31.5 34.3 37.2 40.1 43.2 46.3 49.5 52.8 56.1 66.5 73.8 81.3 92.9 59.5

C



2

1.7

3

2.5

4

3.3

5

4.1

6

5.0

7 or more

Consult Rexnord


(7010) C-25

C







8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38

3.920 4.386 4.854 5.324 5.796 6.268 6.741 7.215 7.689 8.163 8.638 9.113 9.589 10.064 10.540 11.016 11.492 11.968 12.444 12.921 13.397 13.874 14.350 14.827 15.303 15.780 16.257 16.734 17.211 17.687 18.164

3.045 3.511 3.979 4.449 4.921 5.393 5.866 6.340 6.814 7.288 7.763 8.238 8.714 9.189 9.665 10.141 10.617 11.093 11.569 12.046 12.522 12.999 13.475 13.952 14.428 14.905 15.382 15.859 16.336 16.812 17.289

4.521 5.021 5.517 6.009 6.498 6.986 7.473 7.958 8.441 8.925 9.407 9.890 10.371 10.853 11.333 11.813 12.294 12.774 13.254 13.734 14.212 14.693 15.171 15.651 16.130 16.608 17.088 17.567 18.045 18.524 19.002

2.08 2.58 3.08 3.58 4.06 4.55 5.03 5.52 6.00 6.48 6.97 7.45 7.94 8.42 8.89 9.38 9.86 10.34 10.81 11.30 11.78 12.25 12.73 13.22 13.69 14.17 14.66 15.13 15.61 16.09 16.56

Maximum bore with standard keyseat, inches s 1.313 1.625 2.063 2.438 2.750 3.188 3.625 4.000 4.438 4.688 5.188 5.563 5.938 6.375 6.500 6.688 7.000 7.250 7.625 8.000 8.375 8.750 9.250 9.750 10.000 -

S max., inches

Number of teeth




Number of teeth

.813 1.000 1.281 1.531 1.688 1.969 2.250 2.500 2.719 2.844 3.219 3.406 3.719 3.938 4.000 4.094 4.250 4.375 4.688 4.875 4.938 5.250 5.500 5.750 6.000 -

39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69

18.641 19.118 19.595 20.072 20.549 21.026 21.503 21.980 22.458 22.935 23.412 23.889 24.366 24.843 25.320 25.798 26.275 26.752 27.229 27.707 28.184 28.661 29.138 29.616 30.093 30.570 31.047 31.525 32.002 32.479 32.957

17.766 18.243 18.720 19.197 19.674 20.151 20.628 21.105 21.583 22.060 22.537 23.014 23.491 23.968 24.445 24.923 25.400 25.877 26.354 26.832 27.309 27.786 28.263 28.741 29.218 29.695 30.172 30.650 31.127 31.604 32.082

19.481 19.959 20.438 20.916 21.395 21.873 22.352 22.829 23.307 23.786 24.264 24.743 25.220 25.698 26.177 26.654 27.132 27.609 38.088 28.566 29.045 29.522 30.000 30.477 30.956 31.433 31.911 32.390 32.867 33.345 33.822

70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100


B

C

8 to 12 13 to 16 17 to 34 35 to 52 53 to 73 74 to 100 14 to 21 22 to 27 28 to 36 37 to 46 47 to 60 61 to 72 73 to 80 81 to 94 95 to 100

1 2.00 2.25 2.50 2.75 3.00 3.25 3.50 3.50 3.50 3.75 4.00 4.25 4.50 5.00 5.50


33.434 32.559 33.911 33.036 34.388 33.513 34.866 33.991 35.343 34.468 35.820 34.945 36.298 35.423 36.766 35.900 37.252 36.377 37.730 36.855 38.207 37.332 38.684 37.809 39.162 38.287 39.639 38.764 40.116 39.241 40.594 39.719 41.071 40.196 41.548 40.673 42.026 41.151 42.503 41.628 42.981 42.106 43.458 42.583 43.935 43.060 44.412 43.537 44.889 44.014 45.367 44.492 45.844 44.969 46.321 45.446 46.799 45.924 47.277 46.402 47.754 46.879 Larger sizes available.

5.50 5.75 5.88 6.13 6.38 6.63 5.25 5.50 5.75 6.00 6.25 6.50 6.75 7.25 7.75

7.38 7.63 7.75 8.00 8.25 8.50 6.25 6.50 6.75 7.00 7.25 7.50 7.75 8.25 8.75

9.13 9.38 9.50 9.75 10.00 10.25 ... ... ... 8.00 8.25 8.50 8.75 9.25 9.75

6 10.88 11.13 11.25 11.50 11.75 12.00 ... ... ... ... 9.25 9.50 9.75 10.25 10.75

Dimension T

1


.924

.894

.894

.848

L

-

K

-

2.683

4.472

1.789

1.789

.848

6.215

8.004

9.793

1.789

1.789

1.789


6

.848



C-26 (7010)

34.301 34.778 35.256 35.733 36.212 36.689 37.167 37.644 38.123 38.600 39.078 39.555 40.034 40.511 40.989 41.466 41.943 42.422 42.899 43.377 43.854 44.331 44.810 45.287 45.765 46.242 46.719 47.198 47.657 48.153 48.630


Chain Width, Number of Strands 2 3 4 5 3.75 4.00 4.13 4.38 4.63 4.88 4.75 4.75 4.75 4.75 5.00 5.25 5.50 6.00 6.50



C

Drive Engineering


T

PITCH

K

E

E

D

D

C

K

K

T

C Fig. 6447

F

A

B

A

B

Fig. 6453







B

C

D

E

F

G

K

T

140

Single

48,500

.726

4.69

1.02

1.21

.500

1.000

1.00

1.31

1.56

1.924

.22

140-2

Double

97,000

1.452

9.25

1.98

2.17

.500

1.000

1.00

1.31

1.56

1.924

.22

140-3

Triple

145,500

2.178

13.8

2.94

3.13

.500

1.000

1.00

1.31

1.56

1.924

.22

140-4

Quadruple

194,000

2.904

18.4

3.90

4.09

.500

1.000

1.00

1.31

1.56

1.924

.22

140-5

Quintuple

242,500

3.630

22.9

4.86

5.05

.500

1.000

1.00

1.31

1.56

1.924

.22

140-6

Sextuple

291,000

4.356

27.4

5.82

6.01

.500

1.000

1.00

1.31

1.56

1.924

.22



2.750 3.125 3.625 4.063 4.688 5.063 5.625 5.938 6.250 6.688 7.125 7.438 8.125 8.625 8.813 10.000 -

Lubrication type n

10

25

50

100

150

200

Horsepower for single strand chain s RPM of small sprocket 250 300 350 400 450 500 550 600

2.12 2.33 2.54 2.75 2.96 3.18 3.39 3.61 3.82 4.04 4.26 4.48 4.70 4.92 5.14 5.81 6.26 6.71 7.40 8.54

4.83 5.31 5.79 6.27 6.76 7.24 7.73 8.23 8.72 9.22 9.72 10.2 10.7 11.2 11.7 13.3 14.3 15.3 16.9 19.5

9.02 9.91 10.8 11.7 12.6 13.5 14.4 15.4 16.3 17.2 18.1 19.1 20.0 20.9 21.9 24.7 26.7 28.6 31.5 36.4

16.8 18.5 20.2 21.8 23.5 25.2 26.9 28.6 30.4 32.1 33.8 35.6 37.3 39.1 40.8 46.2 49.7 53.3 58.7 67.9

24.2 26.6 29.0 31.5 33.9 36.3 38.8 41.3 43.7 46.2 48.7 51.3 53.8 56.3 58.8 66.5 71.6 76.8 84.6 97.7

31.4 34.5 37.6 40.8 43.9 47.1 50.3 53.5 56.7 59.9 63.1 66.4 69.7 72.9 76.2 86.2 92.8 99.5 110 127

38.4 42.2 46.0 49.8 53.7 57.5 61.4 65.3 69.3 73.2 77.2 81.2 85.2 89.2 93.2 105 113 122 134 155

A

45.2 49.7 54.2 58.7 63.2 67.8 72.4 77.0 81.6 86.3 91.0 95.6 100 105 110 124 134 143 158 182

52.0 57.1 62.2 67.4 72.7 77.9 83.2 88.5 93.8 99.1 104 110 115 121 126 143 154 165 181 210

58.6 64.4 70.2 76.0 81.9 87.8 93.8 99.8 106 112 118 124 130 136 142 161 173 186 205 236

65.2 71.6 78.0 84.5 91.1 97.7 104 111 118 124 131 138 145 151 158 179 193 206 227 263

71.6 78.7 85.8 93.0 100 107 115 122 129 137 144 151 159 166 174 197 212 227 250 289

B


75.2 85.7 93.5 101 109 117 125 133 141 149 157 165 173 181 189 214 231 247 272 315

66.0 75.2 84.8 94.8 105 116 127 138 150 161 170 178 187 196 205 232 249 267 295 340

700

800

1000 1200 1400 1600

52.4 59.7 67.3 75.2 83.4 91.9 101 110 119 128 138 148 158 169 180 213 236 260 297 363

42.9 48.9 55.1 61.6 68.3 75.2 82.4 89.8 97.4 105 113 121 130 138 147 174 193 213 243 297

30.7 35.0 39.4 44.1 48.9 53.8 59.0 64.2 69.7 75.2 80.9 86.8 92.8 98.9 105 125 138 152 174 213

23.3 26.6 30.0 33.5 37.2 41.0 44.9 48.9 53.0 57.2 61.6 66.0 70.6 75.2 80.0 94.8 105 116 130 0

18.5 21.1 23.8 26.6 29.5 32.5 35.6 38.8 42.1 45.4 48.9 52.4 56.0 59.7 63.5 0 0 0 0 -

15.2 17.3 19.5 21.8 0 0 0 0 0 0 0 0 0 0 0 -

C



2

1.7

3

2.5

4

3.3

5

4.1

6

5.0

7 or more

Consult Rexnord


(7010) C-27

C







8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38

3.920 4.386 4.854 5.324 5.796 6.268 6.741 7.215 7.689 8.163 8.638 9.113 9.589 10.064 10.540 11.016 11.492 11.968 12.444 12.921 13.397 13.874 14.350 14.827 15.303 15.780 16.257 16.734 17.211 17.687 18.164

3.045 3.511 3.979 4.449 4.921 5.393 5.866 6.340 6.814 7.288 7.763 8.238 8.714 9.189 9.665 10.141 10.617 11.093 11.569 12.046 12.522 12.999 13.475 13.952 14.428 14.905 15.382 15.859 16.336 16.812 17.289

4.521 5.021 5.517 6.009 6.498 6.986 7.473 7.958 8.441 8.925 9.407 9.890 10.371 10.853 11.333 11.813 12.294 12.774 13.254 13.734 14.212 14.693 15.171 15.651 16.130 16.608 17.088 17.567 18.045 18.524 19.002

2.08 2.58 3.08 3.58 4.06 4.55 5.03 5.52 6.00 6.48 6.97 7.45 7.94 8.42 8.89 9.38 9.86 10.34 10.81 11.30 11.78 12.25 12.73 13.22 13.69 14.17 14.66 15.13 15.61 16.09 16.56

Maximum bore with standard keyseat, inches s 1.313 1.625 2.063 2.438 2.750 3.188 3.625 4.000 4.438 4.688 5.188 5.563 5.938 6.375 6.500 6.688 7.000 7.250 7.625 8.000 8.375 8.750 9.250 9.750 10.000 -

S max., inches

Number of teeth




Number of teeth

.813 1.000 1.281 1.531 1.688 1.969 2.250 2.500 2.719 2.844 3.219 3.406 3.719 3.938 4.000 4.094 4.250 4.375 4.688 4.875 4.938 5.250 5.500 5.750 6.000 -

39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69

18.641 19.118 19.595 20.072 20.549 21.026 21.503 21.980 22.458 22.935 23.412 23.889 24.366 24.843 25.320 25.798 26.275 26.752 27.229 27.707 28.184 28.661 29.138 29.616 30.093 30.570 31.047 31.525 32.002 32.479 32.957

17.766 18.243 18.720 19.197 19.674 20.151 20.628 21.105 21.583 22.060 22.537 23.014 23.491 23.968 24.445 24.923 25.400 25.877 26.354 26.832 27.309 27.786 28.263 28.741 29.218 29.695 30.172 30.650 31.127 31.604 32.082

19.481 19.959 20.438 20.916 21.395 21.873 22.352 22.829 23.307 23.786 24.264 24.743 25.220 25.698 26.177 26.654 27.132 27.609 38.088 28.566 29.045 29.522 30.000 30.477 30.956 31.433 31.911 32.390 32.867 33.345 33.822

70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100

Hub length thru bore, inches Sprocket Type

B

C

Number of Teeth 8 to 12 13 to 16 17 to 34 35 to 52 53 to 73 74 to 100 14 to 21 22 to 27 28 to 36 37 to 46 47 to 60 61 to 72 73 to 80 81 to 94 95 to 100

2 3.75 4.00 4.13 4.38 4.63 4.88 4.75 4.75 4.75 4.75 5.00 5.25 5.50 6.00 6.50



3 5.50 5.75 5.88 6.13 6.38 6.63 5.25 5.50 5.75 6.00 6.25 6.50 6.75 7.25 7.75

4 7.38 7.63 7.75 8.00 8.25 8.50 6.25 6.50 6.75 7.00 7.25 7.50 7.75 8.25 8.75

5 9.13 9.38 9.50 9.75 10.00 10.25 8.00 8.25 8.50 8.75 9.25 9.75

6 10.88 11.13 11.25 11.50 11.75 12.00 9.25 9.50 9.75 10.25 10.75

Dimension

Chain Width, Number of Strands 1

2

3

4

5

6

T

.924

.894

.894

.848

.848

.848

L

-

2.683

4.472

6.215

8.004

9.793

K

-

1.789

1.789

1.789

1.789

1.789




C-28 (7010)

34.301 34.778 35.256 35.733 36.212 36.689 37.167 37.644 38.123 38.600 39.078 39.555 40.034 40.511 40.989 41.466 41.943 42.422 42.899 43.377 43.854 44.331 44.810 45.287 45.765 46.242 46.719 47.198 47.657 48.153 48.630


Chain Width, Number of Strands 1 2.00 2.25 2.50 2.75 3.00 3.25 3.50 3.50 3.50 3.75 4.00 4.25 4.50 5.00 5.50



C

Drive Engineering


T

PITCH

K

E

E

D

D

C

K

K

T

C Fig. 6447

F

A

B

A

B

Fig. 6453





Dimensions, inches


A

B

C

D

E

F

G

K

T

160

Single

68,000

.991

6.12

1.23

1.41

.563

1.125

1.25

1.56

1.81

2.305

.25

160-2

Double

136,000

1.982

12.5

2.38

2.56

.563

1.125

1.25

1.56

1.81

2.305

.25

160-3

Triple

204,000

2.973

18.6

3.52

3.71

.563

1.125

1.25

1.56

1.81

2.305

.25

160-4

Quadruple

272,000

3.964

24.8

4.67

4.86

.563

1.125

1.25

1.56

1.81

2.305

.25

160-5

Quintuple

340,000

4.955

31.9

5.82

6.00

.563

1.125

1.25

1.56

1.81

2.305

.25

160-6

Sextuple

408,000

5.946

38.3

6.97

7.15

.563

1.125

1.25

1.56

1.81

2.305

.25



3.250 3.500 4.000 4.563 5.000 5.625 6.313 6.500 7.063 7.250 7.750 8.125 8.750 9.625 -

Lubrication type n


25

50

100

150

200

250

300

350

400

450

500

550

600

700

800

900

1000

1100

1200

3.07 3.38 3.68 3.99 4.30 4.61 4.92 5.23 5.55 5.86 6.18 6.50 6.82 7.14 7.46 8.43 9.08 9.74 10.7 12.4

7.01 7.70 8.40 9.10 9.80 10.5 11.2 11.9 12.7 13.4 14.1 14.8 15.6 16.3 17.0 19.2 20.7 22.2 24.5 28.3

13.1 14.4 15.7 17.0 18.3 19.6 20.9 22.3 23.6 25.0 26.3 27.7 29.0 30.4 31.8 35.9 38.7 41.5 45.7 52.8

24.4 26.8 29.2 31.7 34.1 36.6 39.1 41.6 44.1 46.6 49.1 51.6 54.2 56.7 59.3 67.0 72.2 77.4 85.2 98.5

35.2 38.6 42.1 45.6 49.2 52.7 56.3 59.9 63.5 67.1 70.7 74.4 78.0 81.7 85.4 96.5 104 111 123 142

45.6 50.1 54.6 59.1 63.7 68.3 72.9 77.6 82.2 86.9 91.6 96.3 101 106 111 125 135 144 159 184

55.7 61.2 66.7 72.3 77.9 83.5 89.1 94.8 101 106 112 118 124 129 135 153 165 176 194 225

65.6 72.1 78.6 85.2 91.7 98.4 105 112 118 125 132 139 146 152 159 180 194 208 229 265

75.4 82.8 90.3 97.8 105 113 121 128 136 144 152 159 167 175 183 207 223 239 263 304

85.0 93.4 102 110 119 127 136 145 153 162 171 180 189 197 206 233 251 269 297 343

94.5 104 113 123 132 142 151 161 171 180 190 200 210 220 229 259 279 300 330 381

96.6 110 124 135 145 156 166 177 188 198 209 220 231 241 252 285 307 329 363 419

83.7 95.4 108 120 133 147 161 175 190 205 221 237 251 263 275 311 336 359 395 457

73.5 83.7 94.4 105 117 129 141 154 167 180 194 208 222 237 252 298 331 365 417 494

58.3 66.4 74.9 83.7 92.8 102 112 122 132 143 154 165 176 188 200 237 263 289 331 404

47.7 54.4 61.3 68.5 76.0 83.7 91.7 99.9 108 117 126 135 144 154 164 194 215 237 271 331

40.0 45.6 51.4 57.4 63.7 70.2 76.8 83.7 90.8 98.1 105 113 121 129 137 162 180 198 227 257

34.1 38.9 43.9 49.0 54.4 59.9 65.6 71.5 77.5 83.7 90.1 96.6 103 110 117 139 154 169 180 0

29.6 33.7 38.0 42.5 47.1 51.9 56.9 62.0 67.2 72.6 78.1 83.7 89.5 95.4 101 120 0 0 0 -

26.0 29.6 33.4 37.3 41.4 45.6 49.9 54.4 59.0 63.7 68.5 0 0 0 0 0 -

A

B


C



2

1.7

3

2.5

4

3.3

5

4.1

6

5.0

7 or more

Consult Rexnord


(7010) C-29

C







8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38

5.226 5.848 6.472 7.099 7.727 8.357 8.988 9.620 10.252 10.885 11.518 12.151 12.785 13.419 14.053 14.688 15.323 15.958 16.593 17.228 17.863 18.498 19.134 19.769 20.405 21.040 21.676 22.312 22.947 23.583 24.219

4.101 4.723 5.347 5.974 6.602 7.232 7.863 8.495 9.127 9.760 10.393 11.026 11.660 12.294 12.928 13.563 14.198 14.833 15.468 16.103 16.738 17.373 18.009 18.644 19.280 19.915 20.551 21.187 21.822 22.458 23.094

6.028 6.694 7.356 8.012 8.664 9.314 9.964 10.610 11.254 11.900 12.542 13.186 13.828 14.470 15.110 15.750 16.392 17.032 17.672 18.312 18.950 19.590 20.228 20.868 21.506 22.144 22.784 23.422 24.060 24.698 25.336

2.80 3.45 4.13 4.78 5.42 6.08 6.72 7.38 8.02 8.66 9.31 9.95 10.59 11.23 11.88 12.52 13.16 13.80 14.44 15.08 15.72 16.36 17.00 17.63 18.27 18.91 19.55 20.19 20.83 21.47 22.09

Maximum bore with standard keyseat, inches s 1.750 2.250 2.750 3.250 3.500 4.000 4.563 5.000 5.625 6.313 6.500 7.063 7.250 7.750 8.188 8.750 9.625 -

S max., inches

Number of teeth




Number of teeth

1.063 1.375 1.688 2.000 2.188 2.500 2.781 3.125 3.438 3.906 4.000 4.281 4.375 4.750 4.938 5.250 5.688 -

39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69

24.855 25.491 26.127 26.763 27.399 28.035 28.671 29.307 29.943 30.580 31.216 31.852 32.488 33.124 33.761 34.397 35.033 35.669 36.306 36.942 37.578 38.215 38.851 39.487 40.124 40.760 41.396 42.033 42.669 43.306 43.942

23.730 24.366 25.002 25.638 26.274 26.910 27.546 28.182 28.818 29.455 30.091 30.727 31.363 31.999 32.636 33.272 33.908 34.544 35.181 35.817 36.453 37.090 37.726 38.362 38.999 39.635 40.271 40.908 41.544 42.181 42.817

25.974 26.612 27.250 27.888 28.526 29.164 29.802 30.438 31.076 31.714 32.352 32.990 33.626 34.264 34.902 35.538 36.176 36.812 37.450 38.088 38.726 39.362 40.000 40.636 41.274 41.910 42.548 43.186 43.822 44.460 45.096

70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100


B

C

8 to 12 13 to 15 16 to 25 26 to 35 36 to 51 52 to 79 80 to 100 19 to 27 28 to 37 38 to 46 47 to 70 71 to 81 82 to 100

1 2.25 2.50 2.75 3.00 3.25 3.50 3.75 4.00 4.25 4.50 5.00 5.50 6.00



6.88 7.13 7.38 7.63 7.88 8.13 8.38 7.00 7.25 7.50 8.00 8.50 9.00

9.13 9.38 9.63 9.88 10.13 10.38 10.63 8.25 8.50 8.75 9.25 9.75 10.25

11.38 11.63 11.88 12.13 12.38 12.63 12.88 10.25 10.75 11.25 11.75

6 13.63 13.88 14.13 14.38 14.63 14.88 15.13 11.75 12.25 12.75 13.25

Dimension

1


6

T

1.156

1.119

1.119

1.063

1.063

1.063

L

-

3.424

5.729

7.978

10.283

12.588

K

-

2.305

2.305

2.305

2.305

2.305




C-30 (7010)

45.734 46.370 47.008 47.644 48.282 48.918 49.556 50.192 50.830 51.466 52.104 52.740 53.378 54.014 54.652 55.288 55.924 56.562 57.198 57.836 58.472 59.110 59.750 60.380 61.020 61.660 62.290 62.930 63.570 64.200 64.840


Chain Width, Number of Strands 2 3 4 5 4.50 4.75 5.00 5.25 5.50 5.75 6.00 5.75 5.75 6.00 6.50 7.00 7.50



C

Drive Engineering


T

PITCH

K

E

E

D

D

C

K

K

T

C Fig. 6447

F

A

B

A

B

Fig. 6453







B

C

D

E

F

G

K

T

180

Single

86,000

1.364

9.06

1.39

1.56

.688

1.406

1.41

1.85

2.14

2.592

.28

180-2

Double

172,000

2.728

17.6

2.69

2.86

.688

1.406

1.41

1.85

2.14

2.592

.28

180-3

Triple

258,000

4.092

26.9

3.98

4.15

.688

1.406

1.41

1.85

2.14

2.592

.28

180-4

Quadruple

344,000

5.456

35.8

5.28

5.45

.688

1.406

1.41

1.85

2.14

2.592

.28

180-5

Quintuple

430,000

6.820

44.7

6.57

6.74

.688

1.406

1.41

1.85

2.14

2.592

.28

180-6

Sextuple

516,000

8.184

53.6

7.87

8.04

.688

1.406

1.41

1.85

2.14

2.592

.28



3.375 4.000 4.500 5.375 5.875 6.250 6.688 7.375 7.750 8.250 9.313 -

Lubrication type n

10

25

50

100

150

200

Horsepower for single strand chain s RPM of small sprocket 250 300 350 400 450 500 550 600

4.24 4.66 5.08 5.51 5.93 6.36 6.79 7.22 7.66 8.10 8.53 8.97 9.41 9.86 10.3 11.6 12.5 13.4 14.8 17.1

9.68 10.6 11.6 12.6 13.5 14.5 15.5 16.5 17.5 18.5 19.5 20.5 21.5 22.5 23.5 26.6 28.6 30.7 33.8 39.0

18.1 19.8 21.6 23.4 25.3 27.1 28.9 30.8 32.6 34.5 36.3 38.2 40.1 42.0 43.9 49.6 53.4 57.2 63.1 72.9

33.7 37.0 40.4 43.7 47.1 50.5 54.0 57.4 60.8 64.3 67.8 71.3 74.8 78.3 81.8 92.5 99.6 107 118 136

48.6 53.4 58.2 63.0 67.9 72.8 77.7 82.7 87.6 92.6 97.6 103 108 113 118 133 144 154 170 196

62.9 69.1 75.4 81.6 88.0 94.3 101 107 114 120 126 133 140 146 153 173 186 199 220 254

76.9 84.5 92.1 99.8 108 115 123 131 139 147 155 163 171 179 187 211 227 244 268 310

A

B

90.6 99.6 109 118 127 136 145 154 164 173 182 192 201 210 220 249 268 287 316 365

104 114 125 135 146 156 167 177 188 199 209 220 231 242 253 286 308 330 363 420

117 129 141 152 164 176 188 200 212 224 236 248 260 273 285 322 347 372 410 473

124 142 156 169 182 196 209 222 236 249 262 276 290 303 317 358 386 414 458 526

106 121 136 152 169 186 204 222 241 260 280 300 318 333 348 394 424 455 501 579

92.0 105 118 132 146 161 177 193 209 226 243 260 278 296 315 374 414 456 522 575

650

700

800

900

1000 1100

71.6 81.6 92.0 103 114 126 138 150 163 176 189 203 216 231 245 291 322 355 406 465

64.1 73.0 82.3 92.0 102 112 123 134 145 157 169 181 194 206 220 260 289 318 364 398

52.4 59.7 67.4 75.3 83.5 92.0 101 110 119 129 138 148 159 169 180 213 236 260 291 244

46.9 50.1 56.5 63.1 70.0 77.1 84.4 92.0 99.8 108 116 124 133 142 151 178 198 0 0 0

37.5 42.8 48.2 53.9 59.7 65.8 72.1 78.5 85.2 92.0 99.0 0 0 0 0 0 0 -

32.5 37.1 0 0 0 0 0 0 0 0 0 -

C


80.7 92.0 104 116 129 142 155 169 183 198 213 228 244 260 277 328 364 401 458 524



2

1.7

3

2.5

4

3.3

5

4.1

6

5.0

7 or more

Consult Rexnord


(7010) C-31

C







8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38

5.879 6.579 7.281 7.986 8.693 9.402 10.112 10.822 11.533 12.245 12.957 13.670 14.383 15.096 15.810 16.524 17.238 17.952 18.666 19.381 20.096 20.810 21.525 22.240 22.955 23.670 24.385 25.101 25.816 26.531 27.246

4.473 5.173 5.875 6.580 7.287 7.996 8.706 9.416 10.127 10.839 11.551 12.264 12.977 13.690 14.404 15.118 15.832 16.546 17.260 17.975 18.690 19.404 20.119 20.834 21.549 22.264 22.979 23.695 24.410 25.125 25.840

6.782 7.533 8.276 9.014 9.747 10.478 11.207 11.934 12.661 13.385 14.110 14.834 15.557 16.279 16.999 17.721 18.441 19.161 19.881 20.601 21.319 22.039 22.757 23.477 24.194 24.914 25.632 26.350 27.068 27.785 28.503

3.14 3.89 4.64 5.38 6.11 6.84 7.58 8.30 9.03 9.75 10.47 11.20 11.92 12.64 13.36 14.08 14.80 15.52 16.25 16.97 17.69 18.41 19.13 19.84 20.56 21.28 22.00 22.72 23.44 24.16 24.86

Maximum bore with standard keyseat, inches s 2.000 2.250 2.875 3.375 4.000 4.500 5.375 5.875 6.250 6.688 7.375 7.750 8.250 9.313 -

S max., inches

Number of teeth




Number of teeth

1.250 1.375 1.813 2.125 2.500 2.750 3.313 3.688 3.875 4.094 4.438 4.750 5.000 5.531 -

39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69

27.962 28.677 29.393 30.108 30.824 31.539 32.255 32.971 33.686 34.402 35.118 35.834 36.549 37.265 37.981 38.696 39.412 40.128 40.844 41.560 42.276 42.991 43.707 44.423 45.139 45.855 46.571 47.287 48.003 48.719 49.435

26.556 27.271 27.987 28.702 29.418 30.133 30.849 31.565 32.280 32.996 33.712 34.428 35.143 35.859 36.575 37.290 38.006 38.722 39.438 40.154 40.870 41.585 42.301 43.017 43.733 44.449 45.165 45.881 46.597 47.313 48.029

29.221 29.939 30.656 31.374 32.092 32.810 33.527 24.243 34.961 35.678 36.396 37.114 37.829 38.547 39.265 39.980 40.698 41.416 42.131 42.849 43.567 44.282 45.000 45.716 46.433 47.151 47.867 48.584 49.300 50.018 50.733

70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100


B

1 2.50

7.50

10.00

12.50

6 15.00

11 to 13

2.75

5.25

7.75

10.25

12.75

15.25

14 to 17

3.00

5.50

8.00

10.50

13.00

15.50

18 to 23

3.25

5.75

8.25

10.75

13.25

15.75

24 to 34

3.50

6.00

8.50

11.00

13.50

16.00

35 to 52

4.00

6.50

9.00

11.50

14.00

16.50

53 to 72

4.50

7.00

9.50

12.00

14.50

17.00

73 to 90

5.00

7.50

10.00

12.50

15.00

17.50

91 to 100

5.50

8.00

10.50

13.00

15.50

18.00

C



24 to 34

4.50

6.25

7.75

9.50

-

-

35 to 52

5.00

6.75

8.25

10.00

11.75

13.50

53 to 72

5.50

7.25

8.75

10.50

12.25

14.00

73 to 90

6.25

8.00

9.50

11.25

13.00

14.75

91 to 100

7.00

8.75

10.25

12.00

13.75

15.50

Dimension

1


6

T

1.301

1.259

1.259

1.198

1.198

1.198

L

-

3.851

6.443

8.974

11.566

14.158

K

-

2.592

2.592

2.592

2.592

2.592




C-32 (7010)

51.451 52.166 52.884 53.600 54.317 55.033 55.751 56.466 57.184 57.899 58.617 59.333 60.050 60.766 61.484 62.199 62.915 63.632 64.348 65.066 65.781 66.499 67.214 67.932 68.648 69.363 70.081 70.796 71.514 72.230 72.947





C

Drive Engineering


T

PITCH

K

E

E

D

D

C

K

K

T

C Fig. 6447

F

A

B

A

B

Fig. 6453





Dimensions, inches


A

B

C

D

E

F

G

K

T

2002

Single

100,000

1.681

10.9

1.54

1.89

.781

1.563

1.50

1.94

2.31

2.817

.31

200-2

Double

200,000

3.362

21.0

2.96

3.31

.781

1.563

1.50

1.94

2.31

2.817

.31

200-3

Triple

300,000

5.043

31.5

4.38

4.73

.781

1.563

1.50

1.94

2.31

2.817

.31

200-4

Quadruple

400,000

6.724

43.2

5.80

6.14

.781

1.563

1.50

1.94

2.31

2.817

.31

200-5

Quintuple

500,000

8.405

53.9

7.22

7.56

.781

1.563

1.50

1.94

2.31

2.817

.31

200-6

Sextuple

600,000

10.086

64.6

8.64

8.98

.781

1.563

1.50

1.94

2.31

2.817

.31


Ratings Number of Maximum teeth, bore in small inches sprocket 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26

2.625 3.125 3.750 4.625 5.250 5.875 6.125 6.688 7.688 8.375 9.125 9.750 -

Lubrication type n

10

15

20

30

40

50

4.54 5.08 5.64 6.19 6.75 7.31 7.88 8.45 9.02 9.59 10.2 10.7 11.3 11.9 12.5 13.1 13.7 14.3

6.54 7.32 8.12 8.92 9.72 10.5 11.3 12.2 13.0 13.8 14.6 15.5 16.3 17.2 18.0 18.9 19.7 20.6

8.47 9.49 10.5 11.6 12.6 13.6 14.7 15.8 16.8 17.9 19.0 20.1 21.1 22.2 23.3 24.4 25.5 26.6

12.2 13.7 15.1 16.6 18.1 19.7 21.2 22.7 24.2 25.8 27.3 28.9 30.5 32.0 33.6 35.2 36.8 38.4

15.8 17.7 19.6 21.6 23.5 25.5 27.4 29.4 31.4 33.4 35.4 37.4 39.5 41.5 43.5 45.6 47.6 49.7

19.3 21.6 24.0 26.4 28.7 31.1 33.5 36.0 38.4 40.8 43.3 45.8 48.2 50.7 53.2 55.7 58.2 60.7

A

Horsepower for single strand chain s RPM of small sprocket 70 100 150 200 250 300 350 400 26.1 29.3 32.5 35.7 38.9 42.1 45.4 48.7 52.0 55.3 58.6 61.9 65.3 68.7 72.0 75.4 78.8 82.2

36.0 40.4 44.8 49.2 53.6 58.1 62.6 67.1 71.6 76.2 80.8 85.4 90.0 94.6 99.3 104 109 113

51.9 58.2 64.5 70.8 77.2 83.7 90.1 96.6 103 110 116 123 130 136 143 150 156 163

67.3 75.4 83.5 91.8 100 108 117 125 134 142 151 159 168 177 185 194 203 212

82.2 92.1 102 112 122 132 143 153 163 174 184 195 205 216 226 237 248 259

96.9 109 120 132 144 156 168 180 193 205 217 229 242 254 267 279 292 305

B


111 125 138 152 166 179 193 207 221 235 249 264 278 292 307 321 335 350

119 140 156 171 187 202 218 234 249 265 281 297 313 330 346 362 378 395

450

500

550

600

650

700

100 117 135 154 174 194 215 237 260 283 307 331 348 366 384 402 421 439

85.4 100 115 132 148 166 184 203 222 242 262 283 305 327 349 372 396 420

74.1 86.7 100 114 129 144 159 176 192 209 227 245 264 283 303 323 343 364

65.0 76.1 87.8 100 113 126 140 154 169 184 199 0 0 0 0 0 0 0

57.6 67.5 77.9 0 0 0 0 0 0 0 0 -

0 0 0 -

C



2

1.7

3

2.5

4

3.3

5

4.1

6

5.0

7 or more

Consult Rexnord


(7010) C-33

C







8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38

6.532 7.310 8.090 8.872 9.660 10.447 11.235 12.025 12.815 13.605 14.397 15.190 15.982 16.775 17.567 18.360 19.152 19.947 20.740 21.535 22.330 23.122 23.917 24.712 25.505 26.300 27.095 27.890 28.685 29.480 30.275

4.970 5.748 6.528 7.310 8.098 8.885 9.673 10.463 11.253 12.043 12.835 13.628 14.420 15.213 16.005 16.798 17.590 18.385 19.178 19.973 20.768 21.560 22.355 23.150 23.943 24.738 25.533 26.328 27.123 27.918 28.713

7.535 8.368 9.195 10.015 10.830 11.643 12.455 13.263 14.068 14.875 15.678 16.483 17.285 18.088 18.888 19.688 20.490 21.290 22.090 22.890 23.688 24.488 25.285 26.085 26.883 27.680 28.480 29.278 30.075 30.873 31.670

3.50 4.33 5.16 5.98 6.80 7.61 8.42 9.22 10.03 10.84 11.64 12.44 13.25 14.05 14.84 15.66 16.45 17.25 18.05 18.86 19.59 20.45 21.25 22.05 22.84 23.64 24.44 25.23 26.03 26.84 27.64

Maximum bore with standard keyseat, inches s 2.250 2.625 3.125 3.750 4.625 5.250 5.875 6.125 6.688 7.688 8.375 9.125 9.750 -

S max., inches

Number of teeth




Number of teeth

1.375 1.625 1.938 2.313 2.813 3.250 3.688 3.828 4.094 4.719 5.063 5.438 5.750 -

39 40 41 42 43 44 45 46 46 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 75 66 67 68 69

31.070 31.865 32.660 33.455 34.250 35.045 35.840 36.635 37.430 38.225 39.020 39.815 40.610 41.405 42.200 42.995 43.792 44.587 45.382 46.177 46.972 47.767 48.565 49.360 50.155 50.950 51.745 52.540 53.337 54.132 54.927

29.508 30.303 31.098 31.893 32.688 33.483 34.278 35.073 35.868 36.663 37.458 38.253 39.048 39.843 40.638 41.433 42.230 43.025 43.820 44.615 45.410 46.205 47.003 47.798 48.593 49.388 50.183 50.978 51.775 52.570 53.365

32.468 33.265 34.063 34.860 35.658 36.455 37.253 38.048 38.845 39.643 40.440 41.238 42.033 42.830 43.628 44.423 45.220 46.015 46.813 47.610 48.408 49.203 50.000 50.795 51.593 52.388 53.185 53.983 54.778 55.575 56.370

70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100

B

C

8 to 11 12 to 22 23 to 36 37 to 47 48 to 60 61 to 78 79 to 100 16 to 22 23 to 35 36 to 50 51 to 64 65 to 75 76 to 82 83 to 100

1 3.00 3.50 4.00 4.50 5.00 5.50 6.00 4.50 5.00 5.50 6.00 6.50 7.00 7.50

Chain Width, Number of Strands 2 3 4 5 5.75 6.25 6.75 7.25 7.75 8.25 8.75 6.25 6.75 7.25 7.75 8.25 8.75 9.25



8.75 9.25 9.75 10.25 10.75 11.25 11.75 8.00 8.50 9.00 9.50 10.00 10.50 11.00

11.50 12.00 12.50 13.00 13.50 14.00 14.50 9.75 10.25 10.75 11.25 11.75 12.25 12.75

14.25 14.75 15.25 15.75 16.25 16.75 17.25 12.00 12.50 13.00 13.50 14.00 14.50

6 17.00 17.50 18.00 18.50 19.00 19.50 20.00 13.75 14.25 14.75 15.25 15.75 16.25

Dimension


1

6

T

1.389

1.344

1.344

1.278

1.278

1.278

L

-

4.161

6.978

9.729

12.546

15.363

K

-

2.817

2.817

2.817

2.817

2.817




C-34 (7010)

57.168 57.963 58.760 59.555 60.353 61.148 61.945 62.740 63.538 64.333 65.130 65.925 66.723 67.518 68.315 69.110 69.905 70.703 71.498 72.295 73.090 73.890 74.680 75.480 76.280 77.070 77.870 78.660 79.460 80.260 81.050





C

Drive Engineering


T

PITCH

K

E

E

D

D

C

K

K

T

C Fig. 6447

F

A

B

A

B

Fig. 6453





Dimensions, inches


A

B

C

D

E

F

G

K

T

240

Single

152,200

2.488

16.4

1.85

2.20

.938

1.875

1.88

2.44

2.81

3.458

.38

240-2

Double

304,400

4.976

32.2

3.58

3.93

.938

1.875

1.88

2.44

2.81

3.458

.38

240-3

Triple

456,600

7.464

49.4

5.31

5.75

.938

1.875

1.88

2.44

2.81

3.458

.38

240-4

Quadruple

608,800

9.952

65.7

7.04

7.38

.938

1.875

1.88

2.44

2.81

3.458

.38

240-5

Quintuple

761,000

10.440

82.0

8.76

9.11

.938

1.875

1.88

2.44

2.81

3.458

.38

240-6

Sextuple

913,200

14.928

98.4

10.50

10.84

.938

1.875

1.88

2.44

2.81

3.458

.38


Ratings Number of Maximum teeth, bore in small inches sprocket 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26

3.250 4.000 4.500 5.500 6.250 7.875 8.813 9.688 -

Lubrication type n


10

15

20

25

30

40

50

60

80

100

125

150

175

200

250

300

350

400

450

3.92 4.39 4.86 5.34 5.83 6.31 6.80 7.29 7.78 8.28 8.78 9.28 9.78 10.3 10.8 11.3 11.8 12.3

7.31 8.19 9.08 9.97 10.9 11.8 12.7 13.6 14.5 15.4 16.4 17.3 18.2 19.2 20.1 21.1 22.0 23.0

10.5 11.8 13.1 14.4 15.7 17.0 18.3 19.6 20.9 22.3 23.6 24.9 26.3 27.6 29.0 30.4 31.7 33.1

13.6 15.3 16.9 18.6 20.3 22.0 23.7 25.4 27.1 28.8 30.6 32.3 34.1 35.8 37.6 39.3 41.1 42.9

16.7 18.7 20.7 22.7 24.8 26.9 28.9 31.0 33.1 35.2 37.4 39.5 41.6 43.8 45.9 48.1 50.3 52.4

19.6 22.0 24.4 26.8 29.2 31.7 34.1 36.6 39.0 41.5 44.0 46.5 49.0 51.6 54.1 56.7 59.2 61.8

25.4 28.5 31.6 34.7 37.9 41.0 44.2 47.4 50.6 53.8 57.0 60.3 63.5 66.8 70.1 73.4 76.7 80.0

31.1 34.9 38.6 42.4 46.3 50.1 54.0 57.9 61.8 65.8 69.7 73.7 77.7 81.7 85.7 89.7 93.8 97.8

36.7 41.1 45.5 50.0 54.5 59.1 63.6 68.2 72.9 77.5 82.2 86.8 91.5 96.2 101 106 110 115

47.5 53.2 59.0 64.8 70.6 76.5 82.4 88.4 94.4 100 106 112 119 125 131 137 143 149

58.1 65.0 72.1 79.2 86.4 93.6 101 108 115 123 130 138 145 152 160 167 175 183

71.0 79.5 88.1 96.8 106 114 123 132 141 150 159 168 177 186 195 205 214 223

83.6 93.7 104 114 124 135 145 156 166 177 187 198 209 220 230 241 252 263

96.1 108 119 131 143 155 167 179 191 203 215 228 240 252 265 277 290 302

108 121 135 148 161 175 188 202 215 229 243 257 270 284 298 312 327 341

132 148 164 181 197 213 230 247 263 280 297 314 331 348 365 382 399 416

156 175 194 213 232 251 271 290 310 330 350 370 390 410 430 450 470 491

169 198 223 245 267 289 311 334 356 379 402 423 439 454 469 483 496 509

138 162 187 213 240 268 297 328 359 377 393 407 421 435 448 0 0 0

116 136 156 0 0 0 0 0 0 0 0 0 0 0 0 -

A

B


C



2

1.7

3

2.5

4

3.3

5

4.1

6

5.0

7 or more

Consult Rexnord


(7010) C-35

C







8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38

7.893 8.771 9.708 10.649 11.591 12.536 13.482 14.492 15.377 16.327 17.276 18.227 19.177 20.129 21.080 22.032 22.984 23.936 24.889 25.841 26.794 27.747 28.700 29.654 30.607 31.560 32.514 33.467 34.421 35.375 36.329

5.964 6.896 7.833 8.774 9.716 10.661 11.607 12.554 13.502 14.452 15.401 16.352 17.302 18.254 19.205 20.157 21.109 22.061 23.014 23.966 24.919 25.872 26.825 27.779 28.732 29.685 30.639 31.592 32.546 33.500 34.454

9.042 10.044 11.034 12.018 12.996 13.971 14.943 15.912 16.881 17.847 18.813 19.779 20.742 21.705 22.665 23.628 24.588 25.548 26.508 27.468 28.425 29.385 30.342 31.302 32.259 33.129 34.176 35.133 36.090 37.047 38.004

4.20 5.20 6.20 7.19 8.16 9.14 10.11 11.08 12.05 13.02 13.98 14.94 15.91 16.88 17.83 18.80 19.75 20.70 21.67 22.63 23.59 24.55 25.50 26.47 27.42 28.38 29.34 30.30 31.25 32.22 33.17

Maximum bore with standard keyseat, inches s 2.983 3.250 4.000 4.500 5.500 6.250 7.875 8.813 9.688 -

S max., inches

Number of teeth




Number of teeth

1.844 2.000 2.500 2.750 3.375 3.875 4.688 5.281 5.719 -

39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69

37.283 38.237 39.191 40.145 41.099 42.053 43.007 43.961 44.915 45.869 46.824 47.778 48.732 49.687 50.641 51.595 52.550 53.504 54.458 55.413 56.368 57.322 58.277 59.231 60.185 61.140 62.095 63.049 64.004 64.958 65.913

35.408 36.362 37.316 38.270 39.224 40.178 41.132 42.086 43.040 43.994 44.949 45.903 45.857 47.812 48.766 49.720 50.675 51.629 52.583 53.538 54.493 55.447 56.402 57.356 58.310 59.265 60.220 61.174 62.192 63.083 64.038

38.961 39.918 40.875 41.832 42.789 43.746 44.703 45.657 46.614 47.571 48.528 49.485 50.439 51.396 52.353 53.307 54.264 55.221 56.175 57.132 58.089 59.043 60.000 60.954 61.911 62.868 63.822 64.779 65.733 66.690 67.644

70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100


B

C

7 to 10 11 to 15 16 to 22 23 to 31 32 to 38 39 to 52 53 to 65 66 to 82 83 to 100 23 to 31 32 to 38 39 to 52 53 to 65 66 to 82 83 to 100

1 3.25 4.00 4.50 5.00 5.50 6.00 6.50 7.00 7.50 6.25 7.00 7.75 8.50 9.00 9.75



10.25 11.00 11.50 12.00 12.50 13.00 13.50 14.00 14.50 10.50 11.25 12.00 12.75 13.25 14.00

13.75 14.50 15.00 15.50 16.00 16.50 17.00 17.50 18.00 12.75 13.50 14.25 15.00 15.50 16.25

17.25 18.00 18.50 19.00 19.50 20.00 20.50 21.00 21.50 15.00 15.75 16.50 17.25 17.75 18.50

6 20.75 21.50 22.00 22.50 23.00 23.50 24.00 24.50 25.00 17.25 18.00 18.75 19.50 20.00 20.75

Dimension

1


6

T

1.738

1.682

1.682

1.601

1.601

1.601

L

-

5.139

8.596

11.972

15.429

18.886

K

-

3.458

3.458

3.458

3.458

3.458




C-36 (7010)

68.601 69.555 70.512 71.466 72.423 73.377 74.334 75.288 76.245 77.199 78.156 79.110 80.067 80.021 81.978 82.932 83.886 84.843 85.797 86.754 87.708 88.665 89.619 90.576 91.530 92.484 93.441 94.395 95.352 96.306 97.263


Chain Width, Number of Strands 2 3 4 5 6.75 7.50 8.00 8.50 9.00 9.50 10.00 10.50 11.00 8.50 9.25 10.00 10.75 11.25 12.00



C

Drive Engineering

No. 2040 chain 1.000" pitch A

C

D

E

B T PITCH

PITCH

F

Fig. 7031





A

B

C

D

E

F

G

T

2040

3700

.068

.28

.32

.41

.156

.313

.31

39

.47

.06

Dimensions, inches

Available only in riveted or cottered construction.

Ratings Number of teeth, in small sprocket

Maximum bore inches

11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 30 35 40

2.188 2.250 2.281 2.625 2.750 3.000 3.438 3.625 3.750 3.781 4.000 4.500 -

Lubrication type n

25

50

100

150

200

Horsepower for single strand chain s RPM of small sprocket 250 300 400 500 600 700 800

.202 .233 .243 .263 .283 .303 .322 .342 .361 .380 .399 .419 .437 .456 .475 .568 .657 .748

.379 .419 .458 .497 .535 .572 .611 .648 .687 .720 .758 .794 .829 .866 .902 1.076 1.247 1.413

.687 .766 .842 .914 .989 1.06 1.13 1.20 1.27 1.34 1.41 1.48 1.54 1.60 1.67 1.99 2.30 2.60

.958 1.07 1.18 1.28 1.39 1.49 1.59 1.70 1.80 1.90 1.99 2.08 2.18 2.27 2.36 2.81 3.24 3.65

1.19 1.34 1.48 1.63 1.76 1.89 2.02 2.15 2.28 2.40 2.52 2.64 2.76 2.88 3.00 3.56 4.09 4.59

1.41 1.58 1.76 1.93 2.09 2.25 2.41 2.57 2.72 2.87 3.01 3.15 3.30 3.44 3.58 4.24 4.86 5.44

1

1.59 1.81 2.00 2.20 2.40 2.59 2.77 2.94 3.14 3.29 3.47 3.63 3.79 3.96 4.11 4.86 5.56 6.22

1.89 2.16 2.44 2.67 2.93 3.17 3.41 3.63 3.86 4.07 4.27 4.48 4.68 4.87 5.07 5.95 6.81 7.57

2.14 2.46 2.79 3.09 3.38 3.67 3.95 4.21 4.49 4.72 4.97 5.20 5.42 5.67 5.90 6.93 7.86 8.67

2

2.32 2.71 3.08 3.44 3.77 4.09 4.41 4.71 5.02 5.29 5.57 5.83 6.09 6.35 6.60 7.76 8.71 9.60

2.88 3.31 3.70 4.08 4.44 4.80 5.13 5.48 5.76 6.07 6.37 6.64 6.92 7.19 8.40 9.42 10.31

3.58 3.91 4.32 4.73 5.10 5.48 5.85 6.17 6.50 6.81 7.11 7.40 7.73 8.90 9.99 10.86

900

1000

1100

1200

1300

4.10 4.52 4.96 5.38 5.76 6.17 6.50 6.86 7.18 7.49 7.80 8.10 9.38 10.43 11.23

-

5.72 6.15 6.61 6.98 7.35 7.71 8.04 8.37 8.67 9.95 10.93 11.61

6.70 7.13 7.50 7.87 8.21 8.54 8.84 10.09 10.97 -

8.30 8.63 8.94 10.15 -

4.67 5.13 5.57 5.97 6.41 6.77 7.13 7.48 7.80 8.12 8.42 9.72 10.72 11.49

3

s Ratings based on service factor of 1. For complete listing service factors, refer to Table 1, page C-7. n Type 1: Manual drip (4 to 10 drops per minute), or splash. Type 2: Rapid drip (20 drops per minute minute minimum); splash, or disc. Type 3: Disc or forced.


(7010) C-37

Sprockets

Sprockets are usually furnished with twice the required number of teeth, virtually doubling sprocket life. Sprockets with only the required number of teeth can also be furnished.

No. 2040 sprockets 1.000" pitch T

OUTSIDE DIAMETER

PIITCH DIAMETER

S

ROOT DIAMETER

T

CHAIN PITCH

C

CHAIN PITCH

T

LENGTH THRU BORE

MAXIMUM HUB DIAMETER

CHAIN PITCH

Fig. 6446 Fig. 6450

MAXIMUM BORE

Type A

Number of teeth l





6 61/2 7 71/2 8 81/2 9 91/2 10 101/2 11 111/2 12 121/2 13 131/2 14 141/2 15 151/2 16 161/2 17 171/2 18 181/2 19 191/2 20 201/2 21 211/2 22 221/2 23

2.000 2.152 2.305 2.458 2.613 2.768 2.924 3.080 3.236 3.392 3.549 3.706 3.864 4.021 4.179 4.336 4.494 4.652 4.810 4.968 5.126 5.284 5.442 5.600 5.759 5.917 6.076 6.233 6.392 6.551 6.710 6.868 7.027 7.185 7.344

1.688 1.840 1.993 2.146 2.301 2.456 2.612 2.768 2.924 3.080 3.237 3.394 3.552 3.709 3.867 4.024 4.182 4.340 4.498 4.656 4.814 4.972 5.130 5.288 5.447 5.605 5.764 5.921 6.081 6.239 6.398 6.556 6.715 6.873 7.032

2.166 2.318 2.491 2.644 2.811 2.968 3.136 3.292 3.457 3.613 3.777 3.934 4.098 4.255 4.419 4.576 4.738 4.896 5.057 5.215 5.377 5.535 5.696 5.854 6.015 6.173 6.334 6.491 6.654 6.812 6.972 7.130 7.292 7.450 7.610

1.19 1.38 1.55 1.70 1.88 2.05 2.20 2.38 2.55 2.70 2.88 3.03 3.19 3.36 3.52 3.69 3.84 4.00 4.17 4.33 4.48 4.66 4.81 4.97 5.14 5.30 5.45 5.61 5.78 5.94 6.09 6.27 6.42 6.58 6.73

Maximum bore with standard keyseat, inches s .750 .844 1.000 1.188 1.250 1.375 1.438 1.688 1.813 1.938 2.188 2.250 2.250 2.281 2.281 2.375 2.625 2.688 2.750 2.813 3.000 3.375 3.438 3.563 3.625 3.688 3.750 3.750 3.781 3.813 4.000 4.250 4.500 4.750 -

B

6 to 91/2 10 to 23 231/2 to 38 39 to 45 46 to 80

.88 1.0 1.1 1.2 1.38

Fig. 8382

Type C

S max., inches

Number of teeth l




Number of teeth l

.469 .516 .625 .719 .750 .844 .969 1.031 1.125 1.219 1.344 1.375 1.406 1.438 1.469 1.500 1.625 1.656 1.750 1.781 1.875 2.125 2.156 2.219 2.250 2.281 2.313 2.344 2.375 2.406 2.500 2.625 2.750 2.875 -

231/2 24 241/2 25 251/2 26 261/2 27 271/2 28 281/2 29 291/2 30 301/2 31 311/2 32 321/2 33 331/2 34 35 36 37 38 39 40 41 42 43 44 45 46 47

7.502 7.661 7.820 7.979 8.137 8.296 8.455 8.614 8.772 8.931 9.090 9.249 9.408 9.567 9.725 9.885 10.043 10.202 10.361 10.520 10.679 10.838 11.156 11.474 11.792 12.110 12.428 12.746 13.064 13.382 13.700 14.018 14.336 14.654 14.972

7.190 7.349 7.508 7.667 7.825 7.984 8.143 8.302 8.460 8.620 8.778 8.937 9.096 9.255 9.413 9.573 9.731 9.890 10.049 10.208 10.367 10.526 10.844 11.162 11.480 11.798 12.116 12.434 12.752 13.070 13.388 13.706 14.024 14.342 14.660

7.768 7.928 8.087 8.248 8.406 8.566 8.725 8.885 9.043 9.204 9.362 9.521 9.680 9.841 9.999 10.160 10.318 10.478 10.637 10.796 10.955 11.12 11.43 11.75 12.07 12.39 12.71 13.03 13.35 13.66 13.98 14.30 14.62 14.94 15.26

48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80

Hub length thru bore, inches Of Hub length, Sprocket Number effective thru bore, Type teeth inches

Type B



15.290 14.978 15.608 15.296 15.926 15.614 16.244 15.932 16.562 16.250 16.880 16.568 17.198 16.886 17.516 17.205 17.835 17.523 18.153 17.841 18.471 18.159 18.789 18.477 19.107 18.795 19.426 19.114 19.744 19.432 20.062 19.750 20.380 20.068 20.698 20.386 21.016 20.704 21.335 21.023 21.653 21.341 21.971 21.659 22.289 21.977 22.607 22.295 22.926 22.614 23.244 22.932 23.562 23.250 23.880 23.568 24.198 23.886 24.517 24.205 24.835 24.523 25.153 24.841 25.471 25.159 Larger sizes available.


Sprocket Type

C

Number Of Hub length, effective thru bore, teeth inches 15 to 30 301/2 to 41 42 to 60 61 to 80

T = .284” + .000”, – .009” for machined sprockets. T = .284” + .000”, – .035” for hot rolled steel plate sprockets or unfinished forgings.

1.75 2.00 2.25 2.50

Recommended standard bore tolerances, keyseat dimensions, eccentricity tolerances, and similar data, page G-2. l “Effective” describes the number of teeth that engage the chain rollers during each revolution of the sprocket. See Fig. 8382 above. The effective number is used to calculate chain speed. Sprockets are normally furnished with twice the effective number listed. When the actual number of teeth is 24 or more, sprockets for No. 40 roller chain may be used. See page C-13 for sprocket data. ∆ Non-functional dimension that may vary with the type of cutter used. s Based on maximum hub diameter.

C-38 (7010)

15.57 15.89 16.21 16.53 16.85 17.17 17.48 17.80 18.12 18.44 18.76 19.08 19.39 19.71 20.03 20.35 20.67 20.99 21.30 21.62 21.94 22.26 22.58 22.90 23.21 23.53 23.85 24.17 24.49 24.81 25.13 25.45 25.77


C

Drive Engineering

No. 2050 chain 1.250" pitch A

C

D

E

B T PITCH

PITCH

F

Fig. 7031





A

B

C

D

E

F

G

T

2050

6100

.108

.41

.41

.48

.200

.400

.38

.48

.59

.08

Dimensions, inches



Maximum bore inches

25

50

100

150

200

250

300

350

400

450

500

550

600

700

800

900

11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 30 35 40

2.625 2.875 2.938 3.250 3.563 3.750 3.875 4.313 4.500 5.125 5.500 5.875 -

.385 .428 .467 .506 .544 .582 .620 .658 .696 .732 .769 .806 .842 .879 .914 1.092 1.267 1.44

.72 .80 .87 .95 1.02 1.09 1.16 1.23 1.31 1.38 1.45 1.52 1.58 1.65 1.72 2.06 2.38 2.70

1.29 1.44 1.59 1.73 1.87 2.00 2.14 2.27 2.41 2.54 2.66 2.79 2.91 3.05 3.17 3.77 4.35 4.91

1.78 1.99 2.20 2.41 2.61 2.81 2.99 3.19 3.39 3.56 3.75 3.92 4.09 4.27 4.45 5.28 6.07 6.82

2.19 2.48 2.74 3.01 3.27 3.52 3.77 4.01 4.25 4.48 4.70 4.92 5.16 5.37 5.59 6.63 7.59 8.51

2.56 2.90 3.23 3.55 3.86 4.16 4.46 4.75 5.05 5.32 5.59 5.86 6.12 6.38 6.62 7.84 8.96 10.00

2.85 3.26 3.65 4.02 4.39 4.74 5.09 5.41 5.76 6.07 6.38 6.69 6.98 7.28 7.58 8.93 10.18 11.33

3.12 3.58 4.03 4.45 4.88 5.26 5.66 6.03 6.42 6.75 7.10 7.45 7.78 8.10 8.42 9.92 11.27 12.51

3.33 3.86 4.36 4.84 5.31 5.73 6.17 6.58 7.00 7.38 7.77 8.14 8.50 8.85 9.20 10.82 12.26 13.57

3.53 4.10 4.66 5.17 5.68 6.16 6.63 7.09 7.55 7.95 8.37 8.76 9.15 9.54 9.91 11.62 13.14 14.49

4.31 4.91 5.48 6.02 6.55 7.05 7.54 8.04 8.46 8.90 9.33 9.74 10.16 10.55 12.35 13.92 15.28

5.11 5.73 6.31 6.87 7.42 7.94 8.46 8.92 9.39 9.84 10.27 10.70 11.12 12.99 14.59 15.95

5.30 5.96 6.57 7.19 7.75 8.31 8.87 9.35 9.84 10.31 10.76 11.21 11.64 13.57 15.17 16.57

6.94 7.61 8.24 8.84 9.42 9.97 10.50 11.01 11.50 11.97 12.42 14.39 16.00 17.29

8.62 9.28 9.90 10.49 11.06 11.59 12.10 12.59 13.05 15.06 16.62 17.78

11.44 12.00 12.52 13.03 13.50 15.48 16.94 -

Lubrication type n

Horsepower for single strand chain s RPM of small sprocket

1

2

3

s Ratings are based on a service factor of 1. For a complete list of service factors, refer to Table 1, page C-7. n Type 1: Manual drip (4 to 10 drops per minute), or splash. Type 2: Rapid drip (20 drops per minute minute minimum); splash, or disc. Type 3: Disc or forced.


(7010) C-39

C

Sprockets


No. 2050 sprockets 1.250" pitch T

OUTSIDE DIAMETER

ROOT DIAMETER

CHAIN PITCH

S

PIITCH DIAMETER

T

CHAIN PITCH

T

LENGTH THRU BORE


CHAIN PITCH

Fig. 6446 Fig. 6450

MAXIMUM BORE

Type A

Number of teeth l





6 61/2 7 71/2 8 81/2 9 91/2 10 101/2 11 111/2 12 121/2 13 131/2 14 141/2 15 151/2 16 161/2 17 171/2 18 181/2 19 191/2 20 201/2 21 211/2 22 221/2 23

2.500 2.690 2.881 3.073 3.266 3.460 3.655 3.850 4.045 4.241 4.437 4.633 4.830 5.026 5.223 5.420 5.617 5.815 6.012 6.210 6.407 6.605 6.803 7.001 7.198 7.396 7.595 7.792 7.991 8.189 8.387 8.585 8.783 8.982 9.180

2.100 2.290 2.481 2.673 2.866 3.060 3.255 3.450 3.645 3.841 4.037 4.233 4.430 4.626 4.823 5.020 5.217 5.415 5.612 5.810 6.007 6.205 6.403 6.601 6.798 6.996 7.195 7.392 7.591 7.789 7.987 8.185 8.383 8.582 8.780

2.708 2.898 3.112 3.305 3.517 3.711 3.920 4.115 4.321 4.517 4.722 4.918 5.123 5.319 5.522 5.719 5.921 6.119 6.321 6.519 6.720 6.918 7.121 7.319 7.519 7.717 7.918 8.115 8.317 8.515 8.715 8.913 9.113 9.312 9.512

1.50 1.72 1.94 2.14 2.36 2.56 2.77 2.98 3.19 3.39 3.59 3.80 4.00 4.20 4.41 4.61 4.81 5.02 5.22 5.42 5.63 5.83 6.03 6.22 6.42 6.63 6.83 7.03 7.23 7.44 7.63 7.83 8.03 8.23 8.44

Maximum bore with standard keyseat, inches s .969 1.125 1.375 1.438 1.625 1.813 1.938 2.125 2.313 2.438 2.625 2.750 2.875 2.906 2.934 3.125 3.250 3.313 3.563 3.719 3.750 3.781 3.875 4.125 4.313 4.375 4.500 4.750 5.125 5.250 5.500 5.750 5.875 6.125 -

6 to 91/2

B

Type C

Fig. 8382

S max., inches

Number of teeth l




Number of teeth l


.609 .688 .844 .906 1.000 1.094 1.219 1.313 1.438 1.531 1.625 1.688 1.781 1.813 1.875 1.934 2.000 2.094 2.219 2.313 2.313 2.375 2.438 2.500 2.625 2.688 2.750 3.000 3.125 3.250 3.375 3.625 3.688 3.750 -

231/2 24 241/2 25 251/2 26 261/2 27 271/2 28 281/2 29 291/2 30 301/2 31 311/2 32 321/2 33 331/2 34 35 36 37 38 39 40 41 42 43 44 45 46 47

9.378 9.577 9.775 9.973 10.172 10.370 10.569 10.767 10.966 11.164 11.362 11.561 11.760 11.958 12.157 12.356 12.554 12.753 12.952 13.150 13.349 13.547 13.945 14.342 14.740 15.137 15.534 15.932 16.329 16.727 17.124 17.522 17.920 18.317 18.715

8.978 9.177 9.375 9.573 9.772 9.970 10.169 10.367 10.566 10.764 10.962 11.161 11.360 11.558 11.757 11.956 12.154 12.353 12.552 12.750 12.949 13.147 13.545 13.942 14.340 14.737 15.134 15.532 15.929 16.327 16.724 17.122 17.520 17.917 18.315

9.710 9.911 10.111 10.308 10.507 10.707 10.906 11.105 11.304 11.504 11.702 11.902 12.101 12.300 12.499 12.699 12.897 13.098 13.297 13.495 13.691 13.893 14.290 14.790 15.090 15.490 15.880 16.28 16.68 17.08 17.48 17.88 18.27 18.67 19.07

48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80

19.112 19.510 19.908 20.305 20.703 21.100 21.498 21.896 22.293 22.691 23.089 23.486 23.884 24.282 24.680 25.077 25.475 25.873 27.464 26.668 27.066 27.464 27.862 28.259 28.657 29.055 29.453 29.850 30.248 30.646 31.044 31.441 31.839


Type B

Outside Root diameter, diameter, inches inches ∆ 18.712 19.110 19.508 19.905 20.303 20.700 21.098 21.496 21.893 22.291 22.689 23.086 23.484 23.882 24.280 24.677 25.075 25.473 25.871 26.268 26.666 27.064 27.462 27.859 28.257 28.655 29.053 29.450 29.848 30.246 30.644 31.041 31.439

Larger sizes available.


Sprocket Type

Number Of Hub length, effective thru bore, teeth inches

1.00

13 to 24

2.00

10 to 191/2

1.13

241/2 to 30

2.25

20 to 301/2

1.38

301/2 to 40

2.50

31 to 45

1.63

41 to 60

2.75

46 to 80

1.88

61 to 72

3.00

73 to 80

3.25

C

T = .343” + .000”, – .010” for machined sprockets. T = .343” + .000”, – .036” for hot rolled steel plate sprockets or unfinished forgings.


C-40 (7010)

19.47 19.87 20.36 20.66 21.06 21.46 21.86 22.25 22.65 23.05 23.45 23.85 24.24 24.64 25.04 25.44 25.84 26.23 26.63 27.03 27.43 27.82 28.22 28.62 29.02 29.42 29.81 30.21 30.61 31.01 31.41 31.81 32.21


C

Drive Engineering

No. 2060 and 2060H 1.500" pitch A

C

D

E

B T PITCH

PITCH

F

Fig. 7031

Specifications and dimensions Average ultimate strength, pounds



A

B

C

D

E

F

G

T

2060

8,500

.162

.65

.50

.59

.234

.469

.50

.60

.69

.09

2060H

8,500

.162

.79

.59

.65

.234

.469

.50

.60

.69

.13

Chain Number

Dimensions, inches



Maximum bore inches

11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 30 35 40

3.125 3.563 3.813 4.125 4.500 4.688 5.250 5.563 5.938 6.188 6.438 7.000 -

Lubrication type n s n

25

50

75

100

125

.66 .73 .79 .86 .92 .99 1.05 1.12 1.18 1.25 1.31 1.37 1.44 1.50 1.56 1.86 2.16 2.45

1.21 1.34 1.48 1.60 1.72 1.85 1.97 2.10 2.23 2.34 2.46 2.58 2.69 2.80 2.92 3.48 4.03 4.55

1.70 1.90 2.09 2.27 2.45 2.64 2.82 2.99 3.17 3.34 3.51 3.67 3.83 4.00 4.17 4.96 5.73 6.46

2.15 2.41 2.65 2.90 3.14 3.36 3.59 3.82 4.05 4.26 4.49 4.70 4.90 5.11 5.32 6.32 7.29 8.20

2.54 2.85 3.15 3.45 3.74 4.01 4.28 4.56 4.83 5.09 5.36 5.62 5.86 6.11 6.36 7.55 8.67 9.70

Horsepower for single strand chain s RPM of small sprocket 150 200 250 300 350 400 450 2.93 3.30 3.65 4.00 4.34 4.66 4.98 5.31 5.62 5.93 6.24 6.54 6.83 7.12 7.41 8.78 10.06 11.31

1

3.58 4.05 4.52 4.97 5.39 5.82 6.22 6.63 7.03 7.41 7.80 8.16 8.53 8.90 9.27 10.94 12.52 13.99

4.12 4.70 5.27 5.79 6.32 6.82 7.32 7.82 8.29 8.74 9.19 9.62 10.06 10.47 10.89 12.76 14.67 16.33

4.56 5.24 5.91 6.54 7.14 7.73 8.29 8.85 9.42 9.92 10.43 10.93 11.42 11.90 12.37 14.55 16.54 18.35

4.93 5.71 6.46 7.17 7.86 8.52 9.14 9.78 10.41 10.97 11.55 12.08 12.62 13.16 13.67 16.05 18.17 20.08

6.08 6.92 7.72 8.48 9.21 9.91 10.60 11.29 11.91 12.52 13.13 13.71 14.28 14.84 17.38 19.61 21.57

7.32 8.18 9.01 9.80 10.56 11.31 12.08 12.74 13.40 14.04 14.67 15.27 15.86 18.54 20.80 22.84

500

550

600

650

700

8.58 9.48 10.34 11.14 11.96 12.76 13.46 14.14 14.84 15.49 16.14 16.76 19.53 21.88 23.86

10.77 11.64 12.50 13.35 14.08 14.83 15.55 16.22 16.89 17.53 20.38 22.73 24.64

12.06 12.97 13.87 14.64 15.42 16.15 16.87 17.56 18.21 21.11 23.40 25.42

14.30 15.10 15.90 16.67 17.38 18.11 18.79 21.70 23.99 -

17.83 18.57 19.24 22.16 -

2

3

Ratings are based on a service factor of 1. For a complete list of service factors, refer to Table 1, page C-7. Type1: Manual drip (4 to 10 drops per minute), or splash. Type 2: Rapid drip (20 drops per minute minimum); splash, or disc. Type 3: Disc or forced.


(7010) C-41

Sprockets


No. 2060, 2060H, sprockets 1.500" pitch T

OUTSIDE DIAMETER

ROOT DIAMETER

S

PIITCH DIAMETER

T

CHAIN PITCH

C

LENGTH THRU BORE

CHAIN PITCH

T


CHAIN PITCH

Fig. 6446 Fig. 6450

MAXIMUM BORE

Type A

Number of teeth l





6 61/2 7 71/2 8 81/2 9 91/2 10 101/2 11 111/2 12 121/2 13 131/2 14 141/2 15 151/2 16 161/2 17 171/2 18 181/2 19 191/2 20 201/2 21 211/2 22 221/2 23

3.000 3.228 3.457 3.688 3.920 4.152 4.386 4.620 4.854 5.089 5.324 5.560 5.796 6.032 6.268 6.504 6.741 6.978 7.215 7.452 7.689 7.926 8.163 8.401 8.638 8.875 9.113 9.350 9.589 9.826 10.064 10.302 10.540 10.778 11.016

2.531 2.759 2.988 3.219 3.451 3.683 3.917 4.151 4.385 4.620 4.855 5.091 5.327 5.563 5.799 6.035 6.272 6.509 6.746 6.983 7.220 7.457 7.694 7.932 8.169 8.406 8.644 8.881 9.120 9.357 9.595 9.833 10.071 10.309 10.547

3.249 3.477 3.735 3.964 4.221 4.453 4.704 4.938 5.185 5.420 5.666 5.902 6.147 6.383 6.627 6.863 7.106 7.343 7.587 7.824 8.066 8.303 8.543 8.781 9.023 9.260 9.501 9.738 9.980 10.217 10.458 10696 10.936 11.174 11.415

1.81 2.08 2.33 2.58 2.83 3.08 3.33 3.58 3.83 4.08 4.33 4.56 4.81 5.06 5.30 5.55 5.78 6.03 6.27 6.52 6.75 7.00 7.23 7.48 7.72 7.97 8.20 8.44 8.69 8.92 9.17 9.41 9.64 9.89 10.13

Maximum bore with standard keyseat, inches s 1.250 1.344 1.563 1.750 1.935 2.188 2.313 2.500 2.750 2.938 3.125 3.375 3.563 3.688 3.813 4.000 4.125 4.250 4.500 4.563 4.688 5.000 5.250 5.500 5.563 5.750 5.938 6.063 6.188 6.313 6.438 6.750 7.000 7.188 -

B

6 to 15 151/2 to 25 251/2 to 41 42 to 60 61 to 80

1.25 1.50 1.75 2.00 2.25

Fig. 8382

Type C

S max., inches

Number of teeth l




Number of teeth l


.750 .828 .969 1.063 1.219 1.375 1.469 1.563 1.688 1.813 1.934 2.094 2.219 2.281 2.375 2.500 2.563 2.625 2.750 2.906 2.969 3.125 3.250 3.6375 3.469 3.625 3.719 3.781 3.844 3.906 3.969 4.125 4.250 4.344 -

231/2 24 241/2 25 251/2 26 261/2 27 271/2 28 281/2 29 291/2 30 301/2 31 311/2 32 321/2 33 331/2 34 35 36 37 38 39 40 41 42 43 44 45 46 47

11.254 11.492 11.730 11.968 12.206 12.444 12.682 12.921 13.159 13.397 13.635 13.874 14.112 14.350 14.588 14.827 15.065 15.303 15.542 15.780 16.018 16.257 16.734 17.211 17.687 18.164 18.641 19.118 19.595 20.072 20.549 21.026 21.503 21.980 22.458

10.785 11.023 11.261 11.499 11.737 11.975 12.213 12.452 12.690 13.928 13.166 13.405 13.643 13.881 14.119 14.358 14.596 14.834 15.073 15.311 15.549 15.788 16.265 16.742 17.218 17.695 18.172 18.649 19.126 19.603 20.080 20.557 21.034 21.511 21.989

11.653 11.896 12.131 12.371 12.609 12.849 13.087 13.328 13.566 13.805 14.043 14.238 14.521 14.761 14.999 15.239 15.477 15.716 15.955 16.194 16.432 16.672 17.150 17.630 18.110 18.580 19.060 19.540 20.020 20.490 20.970 21.450 21.930 22.410 22.880

48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80

22.935 28.412 23.889 24.366 24.843 25.320 25.798 26.275 26.752 27.229 27.707 28.184 28.661 29.138 29.616 30.093 30.570 31.047 31.525 32.002 32.479 32.957 33.434 33.611 34.388 34.866 35.343 35.820 36.298 36.775 37.252 37.730 38.207


Type B




Sprocket Type

C

Number Of Hub length, effective thru bore, teeth inches 10 to 20 201/2 to 40 41 to 60 61 to 80

T = .459" + .000”, –.010” for machined sprockets. T = .459” + .000”, –.036” for hot rolled steel plate sprockets or unfinished forgings.

2.25 2.50 3.00 3.25


C-42 (7010)

23.36 23.84 24.32 24.79 25.27 25.75 26.23 26.70 27.18 27.66 28.14 28.61 29.09 29.57 30.05 30.53 31.00 31.48 31.96 32.43 32.91 33.39 33.87 34.34 34.82 35.30 35.78 36.25 36.73 37.21 37.69 38.17 38.65


C

Drive Engineering

No. 2080 chain 2.000" pitch

A

C

D

E

B T PITCH

PITCH

F

Fig. 7031





A

B

C

D

E

F

G

T

2080

14,500

.275

1.10

.66

.74

.312

.625

.63

.75

.88

.13

Dimensions, inches



Maximum bore inches

11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 30 35 40

4.250 4.625 4.938 5.250 5.688 6.188 7.375 7.938 8.438 9.313 9.563 9.813 -

Lubrication type n

10

20

30

40

50

.66 .72 .79 .85 .91 .98 1.04 1.11 1.17 1.23 1.29 1.36 1.42 1.48 1.54 1.84 2.14 2.43

1.24 1.37 1.49 1.62 1.74 1.87 1.99 2.11 2.23 2.35 2.47 2.58 2.70 2.82 2.93 3.50 4.07 4.61

1.78 1.96 2.15 2.33 2.52 2.70 2.88 3.05 3.23 3.40 3.57 3.74 3.90 4.05 4.20 5.02 5.82 6.60

2.26 5.52 2.77 3.01 3.25 3.48 3.71 3.94 4.17 4.40 4.62 4.84 5.06 5.27 5.48 6.54 7.56 8.55

2.76 3.08 3.36 3.66 3.95 4.24 4.52 4.80 5.09 5.36 5.62 5.90 6.16 6.43 6.69 7.96 9.19 10.38

Horsepower for single strand chain s RPM of small sprocket 60 70 80 90 100 150 200 3.20 3.56 3.91 4.26 4.60 4.94 5.28 5.61 5.94 6.26 6.58 6.89 7.20 7.51 7.81 9.29 10.71 12.09

3.60 4.03 4.44 4.85 5.25 5.64 6.02 6.40 6.77 7.13 7.49 7.84 8.19 8.54 8.89 10.59 12.21 13.76

3.99 4.48 4.95 5.42 5.86 6.29 6.72 7.14 7.56 7.98 8.39 8.79 9.18 9.56 9.94 11.74 13.48 15.17

4.38 4.92 5.45 5.96 6.45 6.93 7.40 7.87 8.33 8.78 9.23 9.67 10.10 10.53 10.95 12.97 14.92 16.80

4.78 5.36 5.93 6.49 7.03 7.56 8.09 8.60 9.10 9.60 10.09 10.57 11.05 11.52 11.98 14.23 16.35 18.36

1

6.36 7.20 8.02 8.82 9.60 10.36 11.10 11.82 12.52 13.20 13.87 14.53 15.18 15.82 16.45 19.46 22.26 24.88

7.60 8.68 9.73 10.75 11.74 12.70 13.63 14.53 15.40 16.25 17.08 17.90 18.71 19.51 20.30 23.91 27.23 30.28

250

300

350

400

450

9.82 11.08 12.29 13.46 14.59 15.69 16.76 17.80 18.81 19.79 20.74 21.66 22.55 23.42 27.52 31.21 34.52

13.60 14.94 16.24 17.50 18.72 19.90 21.04 22.14 23.20 24.23 25.23 26.20 30.70 34.65 28.09

17.65 19.04 20.38 21.67 22.91 24.11 25.27 26.40 27.50 28.57 33.56 37.57 40.96

21.77 23.18 24.52 25.80 27.03 28.22 29.38 30.52 35.52 39.66 43.07

-

2

30.98 32.16 37.26 -

3

s Ratings are based on a service factor of 1. For a complete list of service factors, refer to Table 1, page C-7. n Type1: Manual drip (4 to 10 drops per minute), or splash. Type 2: Rapid drip (20 drops per minute minimum); splash, or disc. Type 3: Disc or forced.


(7010) C-43

Sprockets


2080 sprockets 2.000" pitch T

OUTSIDE DIAMETER

ROOT DIAMETER

S

PIITCH DIAMETER

T

CHAIN PITCH

C

LENGTH THRU BORE

CHAIN PITCH

T


CHAIN PITCH

Fig. 6446 Fig. 6450

MAXIMUM BORE

Type A

Number of teeth l





6 61/2 7 71/2 8 81/2 9 91/2 10 101/2 11 111/2 12 121/2 13 131/2 14 141/2 15 151/2 16 161/2 17 171/2 18 181/2 19 191/2 20 201/2 21 211/2 22 221/2 23

4.000 4.304 4.610 4.917 5.226 5.536 5.848 6.160 6.472 6.785 7.099 7.413 7.727 8.042 8.357 8.672 8.988 9.304 9.620 9.936 10.252 10.568 10.885 11.201 11.518 11.834 12.151 12.467 12.785 13.102 13.419 13.736 14.053 14.371 14.688

3.375 3.679 3.985 4.292 4.601 4.911 5.223 5.535 5.847 6.160 6.474 6.788 7.102 7.417 7.732 8.047 8.363 8.679 8.995 9.311 9.627 9.943 10.260 10.576 10.893 11.209 11.526 11.842 12.160 12.477 12.794 13.111 13.428 13.746 14.063

4.332 4.636 4.982 5.289 5.627 5.937 6.271 6.583 6.914 7.227 7.556 7.870 8.195 8.510 8.835 9.150 9.476 9.792 10.115 10.431 10.753 11.069 11.392 11.708 12.030 12.346 12.668 12.984 13.306 13.623 13.944 14.261 14.581 14.899 15.219

2.42 2.78 3.11 3.45 3.80 4.13 4.45 4.80 5.13 5.45 5.78 6.09 6.42 6.75 7.08 7.41 7.72 8.05 8.38 8.69 9.02 9.34 9.66 9.98 10.31 10.63 10.95 11.27 11.59 11.91 12.23 12.55 12.88 13.19 13.52

Maximum bore with standard keyseat, inches s 1.625 1.750 2.063 2.250 2.688 3.000 3.250 3.500 3.750 3.938 4.250 4.500 4.625 4.688 4.938 5.063 5.250 5.500 5.688 5.875 6.188 6.813 7.375 7.688 7.938 8.188 8.438 8.875 9.313 9.438 9.563 9.688 9.813 9.875 -

Sprocket Type

Hub length, thru bore, inches

B

6 to 71/2 8 to 12 121/2 to 181/2 19 to 30 301/2 to 44 45 to 72 73 to 80

1.38 1.63 1.88 2.13 2.38 2.63 2.75

Sprocket Type

Number of teeth l




Number of teeth l


1.000 1.063 1.281 1.375 1.688 1.875 2.031 2.188 2.313 2.438 2.625 2.750 2.875 2.969 3.094 3.156 3.250 3.438 3.594 3.688 3.844 4.156 4.500 4.719 4.844 4.969 5.094 5.313 5.531 5.594 5.656 5.719 5.875 5.938 -

231/2 24 241/2 25 251/2 26 261/2 27 271/2 28 281/2 29 291/2 30 301/2 31 311/2 32 321/2 33 331/2 34 35 36 37 38 39 40 41 42 43 44 45 46 47

15.005 15.323 15.640 15.958 16.275 16.593 16.910 17.228 17.545 17.863 18.180 18.498 18.816 19.134 19.451 19.769 20.087 20.405 20.723 21.040 21.358 21.676 22.312 22.947 23.583 24.219 24.855 25.491 26.127 26.763 27.399 28.035 28.671 29.307 29.943

14.380 14.698 15.015 15.333 15.650 15.968 16.285 16.603 16.920 17.238 17.555 17.873 18.191 18.509 18.826 19.144 19.462 19.780 20.098 20.415 20.733 21.051 21.687 22.322 22.958 23.594 24.230 24.866 25.502 26.138 26.774 27.410 28.046 28.682 29.318

15.536 15.858 16.175 16.495 16.812 17.133 17.450 17.770 18.087 18.406 18.723 19.044 19.362 19.681 19.998 20.318 20.636 20.956 21.274 21.592 21.910 22.230 22.870 23.500 24.140 24.780 25.410 26.050 26.690 27.330 27.960 28.600 29.240 29.870 30.510

48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80

30.580 31.216 31.852 32.488 33.124 33.761 34.397 35.033 3.669 36.306 36.942 37.578 38.215 38.851 39.487 40.124 40.760 41.396 42.033 42.669 43.306 43.942 44.578 45.215 45.851 46.488 47.124 47.760 48.397 49.033 49.670 50.306 50.943

C

Number Of Hub length, effective thru bore, teeth inches 9 to 18 181/2 to 32 321/2 to 40 41 to 60 61 to 72 73 to 80

Fig. 8382

Type C

S max., inches

Hub length thru bore, inches Number Of effective teeth

Type B



Tooth dimensions, inches T = .575" + .000”, –.012” for machined sprockets. T = .575” + .000”, –.040” for hot rolled steel plate sprockets or unfinished forgings.

2.50 3.00 3.25 3.50 4.00 4.25


C-44 (7010)

31.25 31.78 32.42 33.06 33.69 34.33 34.97 35.61 36.24 36.88 37.52 38.15 38.79 39.43 40.06 40.70 41.34 41.97 42.61 43.24 43.88 44.52 45.16 45.79 46.43 47.07 47.70 48.34 48.98 49.61 50.25 50.89 51.53


C

Drive Engineering Lubrication

Generally, chains should be lubricated to achieve and maintain high operating efficiency and provide long service life. Factors such as operating conditions, chain size, type of service, and method of lubrication influence the life of chain. Many low-speed drives perform successfully with little lubrication, but where operating conditions permit, longer chain life will result from adequate lubrication.

Selection of the Lubricant Drives operating at room temperatures should be lubricated with an S.A.E. 30 mineral oil. For operation at high or low temperature extremes, oils with higher or lower viscosity numbers should be used, such as those listed below. Temperature of atmosphere surrounding drive, degrees Fahrenheit

S.A.E. viscosity number

The primary purpose of chain lubrication –20 to 40 20 is to provide a clean film of oil at all load40 to 100 30 carrying points where relative motion 100 to 120 40 occurs. To effectively lubricate the 120 to 140 50 chain ts, oil must be delivered to the spaces indicated in Figure 7913. The oil should be directed to the inside of the Petroleum oils should not be used lower span of chain INSIDE so thatTHE it will not be to lubricate drive chains operating ROLLER thrown off by centrifugal force before it in temperatures above 300°F (149° penetrates the chain t. BETWEEN THE SIDEUnder certain operating Celsius). BARS TOconditions, THE PIN chains operating in high temperature atmospheres can be INSIDE THE ROLLER effectively lubricated with colloidal BETWEEN THE SIDE graphite dispersed in a suitable volatile BARS TO THE PIN INSIDE THE ROLLER carrier. These solutions penetrate the chain ts and, upon evaporation of the BETWEEN THE SIDE leave a thin deposit of graphite carrier, Fig. 7913 BARS TO THE PIN on the chain t surfaces. This type of ROLLER CHAIN lubricant may be applied by drip-feed or wick-feed oil cups. Consult a lubricant Fig. 7913 manufacturer for recommendations ROLLER CHAIN when chains are required to operate at Factory Prelubrication temperatures between 300°F and 700°F (149° and 371°C). Laboratory tests and actual experienceFig. 7913 ROLLER CHAIN show that chain t friction is greatest Suggested Methods during the run-in period, the span of of Lubrication time between drive start-up and the point at which the lubrication system Several methods for lubricating chain begins to function effectively. To drives have been developed, each minimize t friction during this critical fitting a particular range of operating period of operation, Rexnord roller conditions. Horsepower, chain speed, chains are factory prelubricated. and the relative position of shafts are primary considerations. The various Laboratory tests show that methods suggested and their range of prelubrication reduces t wear application are described below. during the critical run-in period by approximately 50%. The result is longer Manual or drip lubrication may be operating life for the chain. used for open running drives (those enclosed by a safety guard) which Subsequent maintenance of a clean operate in a non-abrasive atmosphere. oil film between all bearing surfaces These methods should be confined is equally important for high operating to low horsepower drives operating at efficiency. low chain speeds. The lubricant may be applied to the clearances between sidebars with a brush, oil can, or dripcup oiler.

Drip-cups are usually mounted on a pipe with drilled holes spaced to distribute oil between the sidebars in the lower span of chain. About 4 to 10 drops per minute are sufficient to lubricate very slow speed drives, while a minimum of 20 drops per minute is recommended for higher speeds. The relative position of shafts is not a factor when these methods of lubrication are used. Bath lubrication is the simplest automatic method of lubricating encased chain drives and is highly satisfactory for low or moderate speeds. The chain dips into an oil reservoir to a depth of about one-half inch, forcing the lubricant into the chain ts. Only a short length of chain should run through the oil, preferably only that portion on the bottom of the lower sprocket. The relative shaft positions illustrated below are recommended when oil bath lubrication is used:

Fig. 6579

OIL LEVEL Fig. 6579

OIL LEVEL

Fig. 6579

OIL LEVEL

OIL LEVEL Fig. 5243

OIL LEVEL Fig. 5243

Fig. 5245

OIL LEVEL

OIL LEVEL OILFig. LEVEL 5243

Fig. 5245


Fig. 5245

(7010) C-45 OIL LEVEL

C Disc lubrication is very effective for moderately high-speed drives and is frequently used when the drive arrangement is not suitable for oil bath lubrication.

Forced lubrication is recommended for large horsepower drives, heavily loaded drives, high speed drives, or where oil bath or oil disc lubrication cannot be used.

OIL LEVEL

Fig. 4245 Fig. 4454

An oil disc mounted on the lower sprocket dips about one-half inch into an oil reservoir. The oil is thrown off the disc by centrifugal force, automatically lubricating the chain which is kept above the oil level. This method of lubrication is ineffective at high speeds as well as at very low speeds. Oil disc lubrication is applicable to the relative shaft positions illustrated below:

OIL LEVEL

Fig. 5248

Small ratio with horizontal Small ratio with horizontal centers centers

An oil pump is provided to supply a continuous spray of oil to the inside of the lower span of chain. The circulation of the lubricant aids in the dissipation of heat and results in a well-lubricated, cooler operating drive. The pump is usually direct-connected to a fractional horsepower motor as illustrated in Figure 4245. A chain driven pump, operating from either the driving or driven shaft may be used where electric power is not available. Pumps of about one-gallonper-minute capacity are adequate for most drives under 200 hp. The relative position of shafts is not a factor when forced lubrication is used.

Chain Casings Oil-retaining casings are an integral part of the lubricating system when the oil bath, disc, or forced methods of lubrication are used. OIL LEVEL Fig. 5247

As a safety feature, guard-type casings are required for drives lubricated by the manual or drip-cup methods.

Large ratio with small sprocket low Large ratio with small sprocket low

C-46 (7010)


C

Drive Engineering Drive Installation

Accurate alignment, proper chain tension, good lubrication, and periodic inspection are required to obtain maximum chain and sprocket life. For safe installation of chain and sprockets, careful attention should be given to the following instructions. Caution: Shut off all power to the equipment so that it cannot be started accidentally during these installation steps. Failure to do so can result in serious personal injury. Shaft alignment Mount the sprockets on their respective shafts. As illustrated in Photo 33635, align the shafts horizontally with a machinist’s level, and adjust the shafts for parallel alignment with a vernier, caliper, or feeler bar. The distance between shafts on both sides of the sprockets must be equal. When shafts have been accurately aligned, the motor, bearings, etc., should be bolted securely in place so that alignment will be maintained during operation.

33635

Aligning shafts

Sprocket alignment Sprockets must be in axial alignment for correct chain and sprocket tooth engagement. Apply a straight edge, or heavy cord to the machined sprocket surfaces as shown in Photo 33636. When a shaft is subject to end flat, the sprocket should be aligned for the normal running position. Tighten set screws in sprocket hubs to guard against lateral movement and to hold key in position. Chain installation Inspect chain to make sure it is free from dirt or grit before it is installed. Fit the chain around both sprockets bringing the free ends together on one sprocket as shown in Photo 33637. Insert connecting link and secure in place.

33636

Aligning sprockets

Note: Due to their flexibility, chains can be somewhat difficult to handle. When installing the chain, pick it up by the end links to avoid the possibility of pinching fingers or hands. Failure to do so may result in personal injury. Chain tension Adjust drive centers for proper chain tension, as outlined below. Normally, horizontal and inclined drives should be installed with an initial sag equal to approximately 2% of sprocket centers. Vertical center drives, and those subject to shock loading, reversal of rotation, or dynamic braking, should be operated with both spans of chain almost taught. Periodic inspection of such drives should be made to avoid operation with excessive slack and to maintain proper chain tension. To determine the amount of sag, pull one side of the chain taught allowing all the excess chain to accumulate in the opposite span. As illustrated in Photo 33638, place a straight edge over the slack span and, pulling the chain down at the center, measure the amount of sag. If necessary, adjust drive centers for proper sag that will result in correct chain tension.

33637

Inserting connecting link

Sag in inches based on 2% of sprocket centers Shaft centers, inches

20

30

40

50

60

70

80

90

100

125

150

Sag, Inches

.50

.63

.88

1.00

1.25

1.50

1.63

1.88

2.00

2.50

3.00 33638

Caution: To avoid serious personal injury, the drive should be enclosed in a casing or safety guard. Consult Rexnord for casing installation procedures. If the drive is not enclosed, clear the area of tools and other installation equipment before reconnecting the power.

Determining chain sag


(7010) C-47

C

NOTES

C-48 (7010)


D

Link-Belt and Rexnord Chains for Conveyor Applications

A broad selection of Link-Belt and Rexnord chains and attachments designed specifically for a wide range of conveying applications are available. Attachment designs accommodate slats, angles, rollers, crossroads and many other conveying devices.

Standard Roller Chain

Redi-LubeTM Chain1

Standard Roller chains, with suitable attachments, are the most widely used products for applications requiring compactness or extra-smooth operation. Their capabilities include uses where the conveyor operates as an integral part of the machine. See pages B-1 through B-3.

Self-lubricating, heavy walled, oilimpregnated, sintered steel bushings replace bushing and roller of standard ANSI chain. Available in single and double-pitch. Full range of standard attachments also available. See page D-9.

Block Chain1

Side Bow Roller Chain

Used in light load, low speed conveyors. Consisting of block links (solid or laminated) and link plates ed by pins, all Block chains are 1" pitch and vary in width of block from 3/16" to 1/2". See page D-16.

Extra clearance chain with ability to flex and twist. Ideal for use on curved conveyors or to transmit power under misaligned sprocket conditions. Available in 3/8" to 1" single pitch. See page D-15.

Double-Pitch Conveyor Chain

Hollow Pin Chain1

Lower in cost than standard roller chains, Double-Pitch Conveyor chains are generally recommeded for applications with relatively long shaft centers. Available variations include large diameter rollers and a hollow pin design. See pages D-3 through D-8.

The truly versatile conveyor chain. Constructed with special pin links which have hollow pins assembled in the pin plates. This unique design allows easy insertion of cross rods or attachments to preassembled chain at desired spacings. Attachments can be repositioned without removing chain from conveyor. It is available in single and double-pitch with or without Carrier Rollers. Full line of standard attachments available. See page D-11.

1

Available only in Link-Belt brand.


(7010) D-1

D

Conveyor Chains

Standard Roller Chains

G

T

G

For conveyor applications, Standard Roller chains find their widest use where compactness or extra-smooth operation is a paramount requirement.

T

E

PITCH E

PITCH

The feature of compactness is of particular advantage on applications where the conveyor is an integral part of a machine. Smooth operation may be achieved with standard roller chains because sprockets, with sufficient teeth to avoid chordal disturbance, are relatively small in diameter. In addition, precision construction provides accurate timing where this is an essential requirement.

D

D

C C

F F

A

A

B

B

Fig. 6453

Double-Pitch chains and attachments for long conveyors are listed on pages D-6 through D-7.

Fig. 6453

Chain Number

Chain pitch, inches




A

B

C

D

35∆

.375

2,100

.041

.22

.24

.27

.141

40∆

.500

3,700

.068

.39

.32

.38

.156

Dimensions, inches G

Sprocket data, pages

E

F

T

.200s

.19

.31

.35

.05

C-11

.313

.31

.41

.47

.06

C-13 C-17

50∆

.625

6,100

.108

.70

.41

.48

.200

.400

.38

.51

.59

.08

60

.750

8,500

.162

1.02

.50

.60

.234

.469

.50

.60

.71

.09

C-19

80

1.000

14,500

.275

1.67

.63

.74

.313

.625

.63

.75

.91

.13

C-21 C-23

100

1.250

26,000

.401

2.72

.76

.89

.375

.750

.75

.97

1.13

.16

120

1.500

36,500

.606

3.72

.96

1.13

.438

.875

1.00

1.13

1.38

.19

C-25

140

1.750

48,500

.726

4.69

1.02

1.21

.500

1.000

1.00

1.31

1.56

.22

C-27

160

2.000

68,000

.991

6.12

1.23

1.41

.563

1.125

1.25

1.56

1.81

.25

C-29

Standard Roller Chain Attachments P P

A

B A

B

A A

F F

HOLES-D

HOLES-D

F

T

E E

F

P

P

H

H

A A

HOLES-D

HOLES-D

T

E

G

T

E

H

T

P

P

H

G

G

G Fig. 4379

A1A1

A1 and K1 attachments

Fig. 4380

K1 K1

Fig. 4379

A1

Fig. 4380

K1 Dimensions, inches

Chain Number

Chain pitch, inches

A

B

D

E

F

G

H

P

T

35∆ 40∆ 50∆ 60 80 100 120 140 160

.375 .500 .625 .750 1.000 1.250 1.500 1.750 2.000

.38 .50 .63 .75 1.00 1.25 1.50 1.75 2.00

.27 .38 .48 .60 .74 .89 1.13 1.21 1.41

.11 .14 .20 .20 .27 .33 .39 .45 .52

.31 .38 .50 .63 .75 1.00 1.13 1.38 1.50

.13 .17 .31 .34 .41 .45 .55 .48 .67

.25 .31 .41 .47 .63 .78 .91 1.13 1.25

.19 .25 .31 .38 .50 .63 .75 .88 1.00

.13 .17 .31 .34 .41 .45 .55 .48 .67

.05 .06 .08 .09 .13 .16 .19 .22 .25

∆ Available only in riveted construction. All other sizes may be furnished cottered or riveted. s Bushing diameter. Chain is rollerless.

D-2 (7010)


D

Standard Roller Chain Attachments T

T T

T

T

E

T P H

E

T

HOLES-D F

HOLES-D

A

P

H

A

F

T A

Fig. 4382

B

B

Fig. 4382

A Fig. 4381

B

M1

M35

Fig. 4381

B

M1

M35

M35 and M1 attachments Dimensions, inches

Chain Number

Chain pitch, inches

A

B

D

E

F

G

H

P

T

35∆ 40∆ 50∆ 60 80 100 120 140 160

.375 .500 .625 .750 1.000 1.250 1.500 1.750 2.000

.38 .50 .63 .72 .97 1.25 1.44 1.75 2.00

.27 .38 .48 .60 .74 .89 1.13 1.21 1.41

.11 .14 .20 .20 .27 .33 .39 .45 .52

.31 .38 .56 .63 .75 1.00 1.13 1.38 1.50

.21 .19 .34 .44 .53 .58 .69 .72 .88

.19 .25 .31 .38 .50 .63 .75 .88 1.00

.21 .25 .37 .44 .41 .42 .50 .50 .61

.05 .06 .08 .09 .13 .16 .19 .22 .25

.05 .06 .08 .09 .13 .16 .19 .22 .25

C

C K

C

C

C K

C

K

A K

K

K

B

A

Fig. C-216 Fig. 4391

B

D1 and D100 Fig. 4391

Fig. C-216

D1 andD100 D100 D1 and

D3

D3 D3

D1, D3 and D100 attachments Dimensions, inches

Chain Number

Chain pitch, inches

A

B

C

35∆

.375

.24

.27

40∆

.500

.32

50∆

.625

60

D1s

K D3

D100†

.141

.38

.38

.44

.38

.156

.38

.38

.59

.40

.48

.200

.47

.47

.77

.750

.50

.60

.234

.56

.56

.94

80

1.000

.63

.74

.313

.75

.75

1.20

100

1.250

.76

.89

.375

.94

.94

1.47

120

1.500

.96

1.13

.438

1.13

1.13

1.84

140

1.750

1.02

1.21

.500

1.31

1.31

1.98

160

2.000

1.23

1.41

.563

1.50

1.50

2.38

∆ Available only in riveted construction. All other sizes may be furnished cottered or riveted. s Conforms to ANSI Standard B29.1 and will be furnished unless otherwise specified. † Formerly furnished as D1 attachment.


(7010) D-3

D

Conveyor Chains

Double Pitch Roller Chains Double-Pitch Conveyor chains are lower in cost than standard roller chains and are ideally suited for conveyor applications, particularly when shaft centers are relatively long. Double-Pitch conveyor chains have straight side-bars of equal height and can be furnished with standard diameter or large diameter rollers.

CHAIN PITCH

Standard diameter rollers are for applications where the chain slides along the conveyor path. The straight, equal height sidebars provide ample sliding surfaces to resist wear.

Fig. 6553A

Chains with rollers larger in diameter than the height of the sidebars are used where rolling action along the conveyor path is desired. Large Delrin rollers can be furnished for applications that require minimum or no lubrication. CHAIN PITCH

Sprockets Sprockets for Double-Pitch Conveyor chains with standard diameter rollers are normally furnished with two times the number of teeth required. As illustrated in Fig. 6553-A, the relationship between chain pitch and roller diameter results in adequate space for a second set of teeth which substantially increases sprocket life. When the total number of teeth in the sprocket is 24 or more, stock sprockets for standard roller chains of one-half the conveyor chain pitch may be used. Sprockets for conveyor chains with large diameter rollers can only be furnished with the required number of teeth as illustrated in Fig. 6553-B.

A

C

Fig. 6553B

A

D

C

D

E

E

B

B

T

T PITCH

PITCH

PITCH

F

F

G

Standard Diameter Steel Rollers

PITCH G

Fig. 5074

Fig. 5074

Carbon Steel Chain Number

Chain pitch, inches




A

B

C

D

E

F

G

T


C 2040∆

1.000

3,700

.068

.32

.32

.38

.156

.313

.31

.47

.47

.06

E-10

C 2050∆

1.250

6,100

.108

.51

.41

.48

.200

.400

.38

.59

.59

.08

E-12

C 2060H

1.500

8,500

.176

1.05

.56

65

.234

.469

.50

.68

.68

.13

E-14

C 2080H

2.000

12,500

.295

1.67

.69

.81

.313

.625

.63

.91

.91

.16

E-16

C 2100H

2.500

26,000

.427

2.55

.83

.95

.375

.750

.75

1.13

1.13

.19

E-18

C 2120H

3.000

36,500

.636

3.57

1.02

1.19

.438

.875

1.00

1.38

1.38

.22

E-20

C 2160H

4.000

68,000

1.014

6.18

1.30

1.48

.562

1.125

1.25

1.87

1.87

.28

E-22

Dimensions, inches

Stainless Steel Chain Number

Chain pitch, inches





B

C

D

E

F

G

T


C 2040 SS∆

1.000

3,000

.068

.32

.32

.38

.156

.313

.31

.45

.45

.06

E-10

C 2050 SS∆

1.250

5,000

.108

.51

.41

.48

.200

.400

.38

.55

.55

.08

E-12

C 2060H SS

1.500

6,800

.176

1.05

.56

65

.234

.469

.50

.71

.71

.13

E-14

C 2080H SN

2.000

12,000

.295

1.67

.69

.81

.313

.625

.63

.91

.91

.16

E-16

C 2100H SN

2.500

18,750

.427

2.55

.83

.95

.375

.750

.75

1.13

1.13

.19

E-18

C 2120H SN

3.000

27,000

.636

3.57

1.02

1.19

.438

.875

1.00

1.38

1.38

.22

E-20

C 2160H SN

4.000

47,000

1.014

6.18

1.30

1.48

.562

1.125

1.25

1.87

1.87

.28

E-22

∆ Available only in riveted construction. All other sizes may be furnished cottered or riveted.

D-4 (7010)


D

Large Diameter Steel Or Delrin Rollers A

C

D

E

B T PITCH

PITCH

F

G

Fig. 4383

Carbon Steel Chain Number

Chain pitch, inches




A

B

C

D

E

F

G

T

C 2042∆

1.000

3,700

.068

.56

.32

.38

.156

.625

.31

.47

.47

.06

E-11

C 2052∆

1.250

6,100

.108

.83

.41

.48

.200

.750

.38

.59

.59

.08

E-13

C 2062H

1.500

8,500

.176

1.55

.56

65

.234

.875

.50

.68

.68

.13

E-15

C 2082H

2.000

12,500

.295

2.35

.69

.81

.313

1.125

.63

.91

.91

.16

E-17

C 2102H

2.500

26,000

.427

3.85

.83

.95

.375

1.563

.75

1.13

1.13

.19

E-19

C 2122H

3.000

36,500

.636

6.22

1.02

1.19

.438

1.750

1.00

1.38

1.38

.22

E-21

C 2162H

4.000

68,000

1.014

9.34

1.30

1.48

.562

2.250

1.25

1.87

1.87

.28

E-23

Dimensions, inches


Stainless Steel Chain Number

Chain pitch, inches





B

C

D

E

F

G

T


C 2042 SS∆

1.000

3,000

.068

.56

.32

.38

.156

.625

.31

.47

.47

.06

E-11

C 2052 SS∆

1.250

5,000

.108

.83

.41

.48

.200

.750

.38

.59

.59

.08

E-13

C 2062H SS

1.500

6,800

.176

1.55

.56

65

.234

.875

.50

.68

.68

.13

E-15

C 2082H SN

2.000

12,000

.295

2.35

.69

.81

.313

1.125

.63

.91

.91

.16

E-17

C 2102H SN

2.500

18,750

.427

3.85

.83

.95

.375

1.563

.75

1.13

1.13

.19

E-19

C 2122H SN

3.000

27,000

.636

6.22

1.02

1.19

.438

1.750

1.00

1.38

1.38

.22

E-21

C 2162H SN

4.000

47,000

1.014

9.34

1.30

1.48

.562

2.250

1.25

1.87

1.87

.28

E-23

∆ Available only in riveted construction. All other sizes may be furnished cottered or riveted. When ordering chains and attachments with large Delrin rollers, add the suffix “DR” to the chain number listed above.


(7010) D-5

D

Conveyor Chains

Double Pitch Chain Attachments

F P

P HOLES-D HOLES-D

H

B

B

A

A

P

P

F

H

E

T

E

F

HOLES-D HOLES-D

H

G

A

A

A

P

E

F

T

E

T

G

G

Fig.Fig. 4385 4385

G

Fig.Fig. 4387 4387

A1 A1

K1 K1

A1

A1 and K1 attachments Chain Number

A

F

H

T

F

P

K1 Dimensions, inches

Chain pitch, inches

A

B

D

E

F

G

H

P

T

Standard Rollers

Large Rollers

C 2040∆

C 2042∆

1.000

.50

.38

.14

.75

.25

.36

.50

.22

.06

C 2050∆

C 2052∆

1.250

.63

.48

.20

.94

.34

.44

.63

.26

.08

C 2060H

C 2062H

1.500

.84

.65

.20

1.13

.50

.58

.75

.37

.13

C 2080H

C 2082H

2.000

1.09

.81

.27

1.50

.48

.75

1.00

.30

.16

C 2100H

C 2102H

2.500

1.31

.95

.33

1.88

.67

.92

1.25

.44

.19

C 2120H

C 2122H

3.000

1.56

1.19

.39

2.25

.83

1.09

1.50

.55

.22

C 2160H

C 2162H

4.000

2.06

1.48

.52

3.00

.72

1.44

2.00

.70

.28

F

F P

P

H

HM

M

E

E

B

A

A

P

P HOLES-D HOLES-D

B

T

HOLES-D HOLES-D

H

T

G

HM

M

E

E

G

A

A

A

P

P F

F

A

F

F T

T

G

Fig. 4386 Fig. 4386

G

Fig. 4388 Fig. 4388

A2 A2

K2 K2

A2 and K2 attachments Chain Number

Dimensions, inches

Chain pitch, inches

A

B

D

Standard Rollers

Large Rollers

C 2040∆

C 2042∆

1.000

.50

.38

C 2050∆

C 2052∆

1.250

.63

.48

C 2060H

C 2062H

1.500

.84

C 2080H

C 2082H

2.000

C 2100H

C 2102H

C 2120H C 2160H

E

F

G

H

R

P

T

.14

.75

.25

.36

.31

.38

.22

.06

.20

1.00

.34

.44

.39

.47

.26

.08

.65

.20

1.13

.50

.58

.47

.56

.37

.13

1.09

.81

.27

1.50

.48

.75

.63

.75

.31

.16

2.500

1.31

.95

.33

1.88

.67

.92

.78

.94

.47

.19

C 2122H

3.000

1.56

1.19

.39

2.25

.77

1.09

.94

1.13

.59

.22

C 2162H

4.000

2.06

1.48

.52

3.00

.72

1.44

1.25

1.50

.70

.28

For stainless steel chains and attachments, Rexnord. ∆ Available only in riveted construction. All other sizes may be furnished cottered or riveted. When ordering chains and attachments with large Delrin rollers, add the suffix “DR” to the chain number listed above.

D-6 (7010)


D E E

H H

P P

F F

T T

T T

HOLES-D HOLES-D

T T

T T

A A

B B

B B

Fig. 4390 Fig. 4390

Fig. 4389 Fig. 4389

M1 M1 M1

M35

M35 M35 M35 and M1 attachments Chain Number

Dimensions, inches

Chain pitch, inches

A

B

D

Standard Rollers

Large Rollers

C 2040∆

C 2042∆

1.000

.44

.38

C 2050∆

C 2052∆

1.250

.56

.48

C 2060H

C 2062H

1.500

.69

C 2080H

C 2082H

2.000

C 2100H

C 2102H

C 2120H C 2160H

E

F

H

P

T

.20

.75

.37

.50

.37

.06

.27

1.00

.42

.63

.42

.08

.65

.33

1.13

.61

.75

.61

.13

.88

.81

.39

1.50

.70

1.00

.70

.16

2.500

1.13

.95

.52

1.88

.88

1.25

.88

.19

C 2122H

3.000

1.31

1.19

.58

2.25

1.06

1.50

1.06

.22

C 2162H

4.000

1.75

1.48

.75

3.00

1.08

2.00

1.08

.28

C C

C C K K

C C K K

K K

A A B B

Fig. 4392 Fig. 4392

Fig. C-217 Fig. C-217

D3 D3 D3

D1 and D100 D1 and D1 and D100D100

D1, D3 and D100 attachments Chain Number

Dimensions, inches

Chain pitch, inches

A

B

C

D1s

D3

D100†

Standard Rollers

Large Rollers

C 2040∆

C 2042∆

1.000

.32

.38

.156

.38

.38

.59

C 2050∆

C 2052∆

1.250

.40

.48

.200

.47

.47

.77

C 2060H

C 2062H

1.500

.56

.65

.234

.56

.56

.81

C 2080H

C 2082H

2.000

.69

.81

.313

.75

.75

1.08

C 2100H

C 2102H

2.500

.83

.95

.375

.94

.94

1.33

C 2120H

C 2122H

3.000

1.02

1.19

.438

1.13

1.13

1.72

C 2160H

C 2162H

4.000

1.30

1.48

.562

1.50

1.50

2.52

For stainless steel chains and attachments, Rexnord. ∆ Available only in riveted construction. All other sizes may be furnished cottered or riveted. When ordering chains and attachments with large Delrin rollers, add the suffix “DR” to the chain number listed above. † Formerly furnished as D1 attachment. s Conforms to ANSI Standard B29.1 and will be furnished unless otherwise specified.


(7010) D-7

D

Conveyor Chains Link-Belt Redi-Lube Chain

Link-Belt Redi-Lube™ chain is built for service comparable to that of ANSI roller chain and is interchangeable with the ANSI chain. However, Redi-Lube chain is self-lubricating. Like the ANSI chain, Redi-Lube is made in standard, single and multiple widths and DoublePitch; the latter in two series—drive and conveyor.

Standard Group

Construction Heavy-walled, oil-impregnated, sintered-steel bushings replace the conventional rollers and bushings of ANSI roller chain. Controlled interference fits between the bushings and link plates prevent tight chain ts, caused by the link plates backing off the bushings. Advantages Redi-Lube chain, being self-lubricating, assures long wear life when lubrication is not possible or practical. This advantage in Redi-Lube chain only applies to chain speed ranges shown in the “Speed Range” table on following page.

A

A

B

B

D

E

E

T

W

D

PITCH

T

W

Maximum operating temperature for Redi-Lube chain is 200°F. Built-in clearances and self-lubrication guard against corrosion and abrasion. Although these destructive elements cannot be entirely overcome, the constant presence of a lubricating film in the pinbushing area minimizes their effect.

PITCH

PITCH

PITCH C

C

TYPE SCCLK TYPE CTCLKCTP

COTTER TYPE SLC

COTTER TYPE LC

COTTER TYPE DC

Attachments A, K, M and D Type Attachments are available for the pin links only for Redi-Lube chain. Dimensionally these pin link attachments are the same as those for corresponding ANSI single pitch chains thru 3/4" pitch and Double-Pitch Conveyor series chains thru 11/2" pitch.

OFFSET LINK OFFSET TYPE OLKCTP

CONN. LINK CONN. LINK PIN LINK PIN LINK PIN LINK PIN LINK SPRING CLIP COTTER SOLID LONG LONG SINGLE SPLIT RIVETED CONN. LINK TYPECONN. LINK COTTER PIN LINK COTTER PIN LINK COTTER PIN LINK PIN LINK TYPE SCCLK CTCLKCTP TYPE RIV TYPE SLCLONG TYPE LCSINGLE TYPE DC SPRING CLIP COTTER SOLID LONG SPLIT RIVETED

LINK TYPE OLKCTP

TYPE RIV

Sprockets Single-Pitch Redi-Lube chain uses Standard Roller chain sprockets. Double-Pitch Redi-Lube chain uses Double-Pitch sprockets.

Double-Pitch Group—Drive Series

A

W C

D

E

B

A

B

D

E

PITCH

PITCH

W C

T

PITCH

T

PITCH

H

CONNECTING LINK SPRING CLIP TYPE SCCLK

CONNECTING LINK COTTER TYPE CTCLKCTP

CONNECTING LINK

CONNECTING LINK CTCLKCTP

Single Pitch Drive Series

Double Pitch Drive Series

Pitch

45LJ 55LJ 65LJ 65HLJ 85LJ 85HLJ 105LJ

2045LJ 2055LJ 2065LJ 2065HLJ -

0.500 1.000 0.625 1.250 0.750 1.500 0.750 1.500 1.000 1.000 1.250

D-8 (7010)

OFFSET LINK TYPE OLKCTP

PIN LINK RIVETED TYPE RIV

SPRING CLIP COTTER Dimensions, TYPE SCCLK Strengths and TYPEWeights

Chain Number

H



Dimensions, Inches

Riv. Conn. Bushing End to End to Center Center Width Diam. Line Line

Overall Width C

Average Minimum Average Type Type of Pin Ultimate Ultimate Weight Std. of Pin Connecting Diam. Strength, Strength, Per Foot, Link Link Height ThickLbs. Lbs. Lbs. ness Link Plate

W

D

A

B

Riv.

Cot.

H

T

E

0.31 0.31 0.38 0.38 0.50 0.50 0.50 0.50 0.63 0.63 0.75

0.31 0.31 0.40 0.40 0.47 0.47 0.47 0.47 0.63 0.63 0.75

0.33 0.33 .041 .041 0.50 0.50 0.58 0.59 0.66 0.72 0.80

0.41 0.41 0.48 0.48 0.59 0.59 0.67 0.66 0.75 0.81 0.92

0.66 0.66 0.81 0.81 1.00 1.00 1.11 1.13 1.31 1.44 1.58

0.73 0.73 0.89 0.89 1.09 1.09 1.25 1.25 1.41 1.53 1.72

0.47 0.47 0.59 0.59 0.70 0.69 0.69 0.69 0.95 0.95 1.19

0.06 0.06 0.08 0.08 0.09 0.09 0.13 0.13 0.13 0.16 0.16

0.16 0.16 0.20 0.20 0.23 0.23 0.23 0.23 0.31 0.31 0.38

2,650 2,650 5,200 5,200 7,800 7,800 8,500 8,500 13,000 14,000 20,000

2,500 2,500 4,130 4,130 5,980 5,980 7,080 7,080 11,000 12,000 17,000

0.39 0.32 0.65 0.42 0.99 0.61 1.09 0.97 1.8 2.1 2.7

Riv. Riv. Riv. Riv. Riv. Riv. Riv. Riv. SLC SLC SLC


SCCLK SCCLK SCCLK SCCLK SCCLK SCCLK SCCLK SCCLK DC DC DC

D

Conveyor Chains Carrier Roller Group Redi-Lube Chain Speed Ranges Speed Range FPM

40L

0-2000

50L

0-1500

60L

0-1000

60HL

0-1000

80L

0-750

80HL

0-750

With Carrier Rollers

Without Carrier Rollers

A

Chain Number

100L

0-250

1, 11/4, 11/2 - inch double-pitch

0-500

2-inch double-pitch

0-350

E

D

W C

B T

A

PITCH

PITCH

E

D W C

B T

PITCH



PITCH

PIN LINK DOUBLE COTTER TYPE DC

CONNECTING LIN COTTER TYPE CTCLKCTP

PIN LINK LONG SINGLE COTTER TYPE LC


NOTE: EXCEPT FOR CARRIER ROLLER, DRAWING ALSO APPLIES TO ROLLERLESS TYPE

Dimensions, Strengths and Weights Chain Number Without Carrier Rollers

Dimensions, Inches

With Carrier Rollers

C2045LJ C2042LJ C2055LJ C2052LJ C2065LJ C2065HLJ C2062HLJ C2085HLJ C2082HLJ 85HLJ 105LJ -

Bushing or Roller

Pitch

1.000 1.000 1.250 1.250 1.500 1.500 1.500 2.000 2.000 1.000 1.250

Riv. Conn. End to End to Center Center Width Diam. Line Line

Overall Width C

Average Minimum Average Pin Ultimate Ultimate Weight Std. Type Type of Diam. Strength, Strength, Per Foot, of Pin Connecting Height ThickLink Link ness Lbs. Lbs. Lbs. Link Plate

W

D

A

B

Riv.

Conn. Link

H

T

E

0.31 0.31 0.38 0.38 0.50 0.50 0.50 0.63 0.63 0.63 0.75

0.31 0.63 0.40 0.75 0.47 0.47 0.88 0.63 1.13 0.63 0.75

0.33 0.33 0.41 0.41 0.50 0.59 0.59 0.72 0.72 0.72 0.80

0.41 0.41 0.48 0.48 0.59 0.66 0.66 0.81 0.81 0.81 0.92

0.66 0.66 0.81 0.81 1.00 1.13 1.13 1.44 1.44 1.44 1.58

0.73 0.73 0.89 0.89 1.09 1.25 1.25 1.53 1.53 1.53 1.72

0.47 0.47 0.59 0.59 0.69 0.69 0.69 0.95 0.95 0.95 1.19

0.06 0.06 0.08 0.08 0.09 0.13 0.13 0.16 0.16 0.16 0.16

0.16 0.16 0.20 0.20 0.23 0.23 0.23 0.31 0.31 0.31 0.38

3,000 3,000 5,200 5,200 7,000 8,500 8,500 12,500 12,500 14,000 20,000

2,500 2,500 4,130 4,130 5,980 7,080 7,080 12,000 12,000 12,000 17,000


0.33 0.56 0.56 0.87 0.61 0.97 1.45 2.10 2.60 2.1 2.7

Riv. Riv. Riv. Riv. Riv. Riv. Riv. DC DC SLC SLC

SCCLK SCCLK SCCLK SCCLK SCCLK SCCLK SCCLK DC DC DC DC

(7010) D-9

D

Conveyor Chains Hollow Pin Chain

Link-Belt Hollow Pin chain is identical to ANSI Standard Roller Chain in pitch, roller width, and roller diameter. It is quality designed for long wear life in conveyor applications. The “hollow pin” feature provides unlimited conveyor design versatility. Link-Belt Hollow Pin chain is available in single pitch series or DoublePitch series. The Double-Pitch series is furnished either rollerless or with large-diameter carrier rollers constructed of steel or Delrin. Advantages: Attachments or crossrods can be inserted at any desired spacing, which provides great design versatility. Changes can be made without removing the chain from the conveyor.

Single Pitch Carrier Roller Type

A

E

D

Ease of assembly of attachments or crossrods reduces assembly costs and maintenance time. There is less down-time in the event of a conveyor jam-up.

W

B

Standard ANSI sprockets can be used except on large-diameter carrier roller chain.

T

PITCH

The type of connecting link used for all Hollow Pin chain is retaining ring (RR).

I.D. H CONN LINK RETAINING RING TYPE RRCLK HOLLOW

Sprockets: Single pitch Hollow Pin chain uses standard stock sprockets. Double-Pitch Hollow Pin chain uses Double-Pitch sprockets.

PIN LINK

Attachments: Since the connecting link for the Hollow Pin chain is in itself a wider assembly than the standard Hollow Pin chain, the connecting link will not accept an attachment.

Double Pitch Carrier Roller Type A

E

D

W C

B T

A

PITCH

PITCH

E

D W C

B T

PITCH



PITCH

PIN LINK DOUBLE COTTER TYPE DC

CONNECTING LIN COTTER TYPE CTCLKCTP

PIN LINK LONG SINGLE COTTER TYPE LC


EXCEPT FOR CARRIER ROLLER, DRAWING Dimensions, Strengths andNOTE: Weights ALSO APPLIES TO ROLLERLESS TYPE

Chain Number Single Pitch

Carrier Roller Double Pitch

45HP 55HP 65HP 85HP -

C2045HP C2055HP C2065HP C2085HP -

C2042HP C2052HP C2062HP C2082HP

D-10 (7010)

Riv. Conn. End to End to Width Diam. Center Center Line Line Bushing

Rollerless Double Pitch

Pitch

0.500 1.000 1.000 0.625 1.250 1.250 0.750 1.500 1.500 1.000 2.000 2.000

Overall Width C

W

D

A

B

Riv.

Ret Ring

0.31 0.31 0.31 0.38 0.38 0.38 0.50 0.50 0.50 0.63 0.63 0.63

0.31 0.31 0.63 0.40 0.40 0.75 0.47 0.47 0.88 0.63 0.63 1.13

0.33 0.33 0.33 0.41 0.41 0.41 0.50 0.50 0.50 0.61 0.67 0.67

0.38 0.38 0.38 0.44 0.44 0.44 0.55 0.55 0.55 0.70 0.77 0.77

0.66 0.66 0.66 0.80 0.80 0.80 0.98 0.98 0.98 1.22 1.34 1.34

0.69 0.69 0.69 0.84 0.84 0.84 1.03 1.03 1.03 1.32 1.44 1.44

Link Plate Pin Diameter Average Minimum Average ThickOut Inside Ultimate Ultimate Weight Height ness Diam. Diam. Strength, Strength, Per Foot, Lbs. Lbs. Lbs. H T E Min. 0.47 0.47 0.47 0.59 0.59 0.59 0.69 0.69 0.69 0.94 0.94 0.94

0.06 0.06 0.06 0.08 0.08 0.08 0.09 0.09 0.09 0.13 0.16 0.16

0.22 0.22 0.22 0.28 0.28 0.28 0.33 0.33 0.33 0.44 0.44 0.44

0.16 0.16 0.16 0.20 0.20 0.20 0.24 0.24 0.24 0.31 0.31 0.31

2,500 2,500 2,500 4,400 4,400 4,400 6,000 6,000 6,000 12,000 12,000 12,000

1,750 1,750 1,750 2,540 2,540 2,540 5,100 5,100 5,100 11,750 11,750 11,750


0.38 0.31 0.54 0.63 0.51 0.84 0.88 0.75 1.20 1.60 1.50 2.25

D

Hollow Pin Chain Attachments Standard attachments are separate, complete links having long pins which are inserted thru the hollow pins of the chain. All standard attachments will fit chains with or without large diameter carrier rollers. It is recommended that all attachments be inserted in the pin link position of the chain. Hollow Pin chain provides great versatility in conveyor design. Various types of attachments may be stocked for use on the same chain. Chain may be purchased in any desired length and assembled into a conveyor using loose attachments, adaptors, and/or cross rods in any desired spacing or arrangement. Attachments or cross rods may be inserted into any link in the chain without chain disassembly. Changes in attachments and in attachment spacing can be quickly accomplished while the chain remains on its sprockets. The attachments and the uses pictured on this page, while not standard, are typical of the versatility provided for by the unique features of Hollow Pin chain.

Wire mesh conveyor, using cross rods assembled to parallel strands of Hollow Pin Chain.

Note: Attachment applications on this page are examples of typical uses and should not be construed as being supplied by Rexnord.

Rod conveyor made by assembling cross rods with parallel strands of Hollow Pin Chain.

Vertical pins assembled in Hollow Pin Chain for locating and conveying.

Pivoting pusher attachment assembled into Hollow Pin Chain (special).


(7010) D-11

D

For Single Pitch Chain

Dimensions and Weights CC J

A-1 Connecting Link Attachments K

Chain Number

N M

T L Z

A-1 BENT LUG AND ONE HOLE, ONE SIDE

JJ KK

CC

L Z

J

K

L

M

N

T

Z

0.021

45HP

0.500

0.61

0.78

0.31

0.38

0.14

0.06

0.89

0.23

0.625

0.75

1.19

0.41

0.56

0.20

0.08

1.09

0.30

0.045

65HP

0.750

0.84

1.25

0.47

0.63

0.20

0.09

1.33

0.34

0.074

CC

Z

Ave. Wgt. per Attach., Lbs. 0.024

K-1 Connecting Link Attachments

N T

Pitch

55HP

Chain Number M

CC

Ave. Wgt. per Attach., Lbs.

Dimensions, Inches

Dimensions, Inches Pitch

JJ

KK

L

M

N

T

45HP

0.500

1.22

1.56

0.31

0.38

0.14

0.06

0.89

0.23

55HP

0.625

1.50

2.13

0.41

0.56

0.20

0.08

1.09

0.30

0.054

65HP

0.750

1.75

2.50

0.47

0.63

0.20

0.09

1.33

0.34

0.086

K-1 BENT LUGS AND ONE HOLE , BOTH SIDES M S

T

M-1 and M-35 Connecting Link Attachments

N

Ave. Wgt. per Attach., Lbs. Lug Lug One Both Side Sides

Dimensions, Inches Chain Number

R Z M-1 STRAIGHT LUGS, BOTH SIDES

CC

M-35 STRAIGT LUG, ONE SIDE

Pitch

M

S

T

CC

Z

R

N

45HP

0.500

0.38

0.69

0.06

0.89

0.23

0.50

0.14

0.021

55HP

0.625

0.56

0.94

0.06

0.89

0.30

0.63

0.20

0.045

0.024 0.054

65HP

0.750

0.63

1.06

0.08

1.09

0.34

0.72

0.20

0.074

0.086

D-1 and D-3 Connecting Link Attachments

CC K U

T E


Dimensions, Inches Chain Number

Pitch

E

K

T

CC

U

Z

D-1

D-3

Z

45HP

0.500

0.16

0.78

0.06

0.89

0.38

0.23

0.020

0.023

55HP

0.625

0.20

1.19

0.06

0.89

0.47

0.30

0.040

0.045

D-1 ONE EXTENDED PIN IN A PIN LINK

65HP

0.750

0.23

1.25

0.08

1.09

0.56

0.34

0.068

0.075

D-3 TWO EXTENDED PINS IN A PIN LINK

D-12 (7010)

If specific dimensions are required, or if flatness, alignment, or other dimensional requirements of attachments are critical, please Rexnord.


D

For Double Pitch Chain Dimensions and Weights A-1 and A-2 Connecting Link Attachments

Pitch

J

K

L

M

N

T

CC

G (A-2)

Z

ZZ


C2045HP

1.000

0.61

0.84

0.36

0.75

0.14

0.06

0.89

0.38

0.23

-

0.036

C2042HP

1.000

0.61

0.84

0.36

0.75

0.14

0.06

0.89

0.38

0.23

0.31

0.036

Chain Number

Dimensions, Inches

C2055HP

1.250

0.75

1.06

0.44

1.00

0.81

0.08

1.09

0.47

0.30

-

0.075

C2052HP

1.250

0.75

1.06

0.44

1.00

0.81

0.08

1.09

0.47

0.30

0.38

0.075

C2065HP

1.500

0.94

1.31

0.58

1.13

0.81

0.13

1.39

0.56

0.34

-

0.154

C2062HP

1.500

0.94

1.31

0.58

1.13

0.81

0.13

1.39

0.56

0.34

0.44

0.154

J

CC

K N

N M

T

G

L ZZ Z

A-1 BENT LUG, ONE HOLE, ONE SIDE A-2 BENT LUG TWO HOLES, ONE SIDE

K-1 and K-2 Connecting Link Attachments

JJ KK

CC

Chain Number C2045HP

Z

ZZ


0.23

-

0.042


JJ

KK

L

M

N

T

CC

G (K-2)

1.000

1.22

1.69

0.36

0.75

0.14

0.06

0.89

0.38

C2042HP

1.000

1.22

1.69

0.36

0.75

0.14

0.06

0.89

0.38

0.23

0.31

0.042

C2055HP

1.250

1.50

2.13

0.44

1.00

0.81

0.08

1.09

0.47

0.30

-

0.090

C2052HP

1.250

1.50

2.13

0.44

1.00

0.81

0.08

1.09

0.47

0.30

0.38

0.090

C2065HP

1.500

1.88

2.63

0.58

1.13

0.81

0.13

1.39

0.56

0.34

-

0.184

C2062HP

1.500

1.88

2.63

0.58

1.13

0.81

0.13

1.39

0.56

0.34

0.44

0.184

N

N M

T

G

L ZZ Z

K-1 BENT LUG, ONE HOLE, BOTH SIDES K-2 BENT LUG TWO HOLES, BOTH SIDES

M

T

G N

S

M-Type Connecting Link Attachments Chain Number

M

S

T

CC

Z

ZZ -

One Hole R N

R

Two Holes G N

1.000 0.75 0.77 0.06 0.89 0.23

0.44 0.20 0.53 0.38 0.14

0.035

0.042

C2042HP

1.000 0.75 0.77 0.06 0.89 0.23 0.31 0.44 0.20 0.53 0.38 0.14

0.035

0.042

C2055HP

1.250 1.00 0.97 0.08 1.09 0.30

0.56 0.25 0.63 0.47 0.20

0.075

0.090

C2052HP

1.250 1.00 0.97 0.08 1.09 0.30 0.38 0.56 0.25 0.63 0.47 0.20

0.075

0.090

C2065HP

1.500 1.13 1.20 0.13 1.39 0.34

0.69 0.33 0.75 0.56 0.20

0.154

0.184

C2062HP

1.500 1.13 1.20 0.13 1.39 0.34 0.44 0.69 0.33 0.75 0.56 0.20

0.154

0.184

-

CC

Ave. Wgt. per Attach., Lbs. Lug Lug One Both Side Sides

C2045HP

-

M-35 STRAIGHT LUG, ONE HOLE, ONE SIDE M-35-2 STRAIGHT LUG TWO HOLES, ONE SIDE M

E

K

T

CC

N

R

ZZ Z

M-1 STRAIGHT LUG, ONE HOLE, BOTH SIDES

CC

M-2 STRAIGHT LUG TWO HOLES, BOTH SIDES



T

G N

S

D-1 and D-3 Connecting Link Attachments Chain Number

R

ZZ Z


N

U

Z

ZZ

D-1

CC

D-3

C2045HP

1.000

0.16

0.77

0.06

0.89

0.38

0.23

-

0.034

0.037

C2042HP

1.000

0.16

0.77

0.06

0.89

0.38

0.23

0.31

0.034

0.037

C2055HP

1.250

0.20

0.95

0.08

1.09

0.47

0.30

-

0.066

0.071

C2052HP

1.250

0.20

0.95

0.08

1.09

0.47

0.30

0.38

0.066

0.071

C2065HP

1.500

0.23

1.17

0.13

1.39

0.56

0.34

-

0.133

0.140

C2062HP

1.500

0.23

1.17

0.13

1.39

0.56

0.34

0.44

0.133

0.140

T

U

K

E

ZZ Z

D-1 ONE EXTENDED PIN IN A PIN LINK D-3 TWO EXTENDED PINS IN A PIN LINK

If specific dimensions are required, or if flatness, alignment, or other dimensional requirements of attachments are critical, please Rexnord.


(7010) D-13

D

Conveyor Chains Side Bow Roller Chain

Side Bow Roller chain is an extra-clearance chain with the ability to permit side flexing and twisting. It is made of the same high-quality materials and specifications, and undergoes the same manufacturing processes and precision finishing, as ANSI standard roller chain. This chain is constructed of standard ANSI roller links combined with special pin links designed to allow greater clearance between the pins and bushings and between the roller link and pin-link plates. Compensation of the pin-link pitch results in uniform chain pitch throughout.

A

E

D

B T

C

W

Sprockets For most applications, stock standard ANSI cut tooth sprockets or existing sprockets may be used. For special applications, sprockets may be made-to-order. Side Bow Roller chain is designed for curved conveyor application on bottling, packaging, canning, and conveying machinery. Some typical applications for this chain are:

PITCH PITCH

1. To operate a live-roll conveyor on a power curve. 2. To carry materials around a curve by use of attachments or slats. 3. To transmit power where abnormal chain twist may be encountered.

H CONN. LINK CONN. LINK COTTER SPRING CLIP TYPE CTCLKCTP TYPE SCCLK


The use of Side Bow chain for this type of service results in substantial savings in chain replacement costs, in down time, and in maintenance costs. Attachments Roller-link attachments are same as ANSI standard. Pinlink attachments are made-to-order. Selection of this chain not included in the selection procedure of this catalog. For assistance in selection Rexnord.

R

Dimensions, Strengths and Weights Dimensions, Inches Rollers

Riv. End to Center Line

Cot. End to Center Line

Average Weight Per Foot, Lbs.

Type of Pin Link

Type of Connecting Link

0.125

0.20

Riv

CTCLKCTP

0.06

0.136

0.38

Riv

CTCLKCTP

0.59

0.08

0.172

0.66

Riv

SCCLK

1.02

0.70

0.09

0.200

0.95

Riv

CTCLKCTP

1.34

0.95

0.13

0.283

1.61

Riv

CTCLKCTP

Link Plate

Overall Width Ric.

Pin Diam.

Chain Number

Pitch

Width W

D

A

B

C

H

T

E

35TF

0.375

0.19

0.20

0.27

0.34

0.48

0.36

0.05

40TF

0.500

0.31

0.31

0.36

0.44

0.64

0.47

50TF

0.625

0.38

0.40

0.45

0.55

0.81

60TF

0.750

0.50

0.47

0.55

0.63

80TF

1.000

0.63

0.63

0.67

0.75

Diam.

Height

Thickness

Recommended Maximum Working Load (Pounds)

Chain Number

Pitch

Maximum Working Load For Side Bow Conditions (Pounds)

R

Maximum Twist Per Foot of Center Distance* (Degrees)

0-100

Minimum Radius, Inches

Chain Speed – Feet Per Minute 100-200

200-300

Average Ultimate Strgth., Lbs.

Minimum Ultimate Strgth., Lbs.

35TF

.375

10

80

125

75

45

1,800

1,700

40TF

.500

14

50

250

150

90

2,400

2,200

50TF

.625

16

40

450

240

145

4,600

3,550

60TF

.750

20

30

600

360

220

6,100

4,930

80TF

1.000

28

20

1,000

600

360

11,000

9,200

* Because this condition results in abnormal wear and strain on the chain parts, substantial reduction of normal service life must be expected.

Available Attachments

D-14 (7010)

Chain Number

Roller Link

Chain Number

Roller Link

35TF 40TF 50TF

A1, K1, M1, M35 A1, K1, M1, M35 A1, K1, M1, M35

60TF 80TF

A1, K1, M1, M35 A1, K1, M1, M35


D

Conveyor Chains Block Chain Link-Belt Block chain is precision-finished chain consisting of alternate block links and link plates, ed by pins. Solid blocks are made of sintered metal. Laminated blocks are made of laminated steel plates. All chain is 1-inch pitch, with block links varying from 3/16 - inch to 1/2 - inch in width. Pitch is measured between centers of alternate pins in a taut chain, instead of between centers of adjacent pins. This chain is used in light-load, low-speed conveyors. Its broad surface can be dragged along a guide to reduce the catenary load on sprockets. Block chain length tolerance is –0 to +1/16" per foot. Note: Non-corrosive and heat-resistant block chain - Stainless steel chains can be furnished on a made-to-order basis with laminated blocks only in riveted construction with cottered type connecting links.

LAMINATED A

Pitch Solid

Laminated

W

Pin Head Pin End to Ctr. to Ctr. Line Line A

B

A

E

T

WC

B PITCH

0.325” SPRING CLIP TYPE SCCLK

Overall Width C Riv.

WC

SOLID

Dimensions, inches Block Width

T

0.325”

Sprockets All Block Chain sprockets are made to order.

Chain Number

E

B

SCCLK

Link Plate Thickness

Pin. Diam.

T

E

RIVETED TYPE RIV

Recom. Max. Working Load, Lbs Chain Speed FPM

Average Weight Per Foot Lbs

0-100 101-200 201-300

B‑502

L‑502

1.000

0.19

0.19

0.25

0.38

0.44

0.06

0.17

200

182

143

0.3

B‑503

L‑503

1.000

0.25

0.22

0.28

0.44

0.50

0.06

0.17

230

209

164

0.3

B‑504

L‑504

1.000

0.31

0.28

0.33

0.56

0.61

0.08

0.19

230

209

164

0.4

B‑505

L‑505

1.000

0.38

0.31

0.36

0.63

0.67

0.08

0.19

300

273

214

0.4

B‑506

L‑506

1.000

0.50

0.38

0.42

0.75

0.80

0.08

0.19

300

273

214

0.5

-

L505SS

1.000

0.38

0.31

0.39

0.61

CTCLK

0.08

0.19

300

273

214

0.4


(7010) D-15

D

NOTES

D-16 (7010)


E

Conveyor Engineering Engineering Recommendations In keeping with modern machinery design, roller chains are widely used for conveyor service because of their appearance, availability, durability, and performance. Precision manufacturing assures long, dependable operation and economical service, while compactness and light weight result in minimum space and power requirements. Standard Roller chains used for conveyor and elevator service are the same as those used for power transmission drives. The Double Pitch Conveyor chains are similar to the drive chain series, differing principally in sidebar style. Compared to power transmission applications, chains for conveyor service operate at relatively slow speeds on longer centers and are not exposed to heavy sprocket impact from high velocity, or to the high frequency of t articulation. Consequently, different methods are used in selecting chains for conveyors than for power transmission service. The procedure for selecting conveyor chains is outlined on page E-4. Use the following recommendations as a guide when selecting roller chains for conveyors. Chain types Three general types of roller chains are used for conveyor applications: Standard Roller chains with suitable attachments are usually applied where sprocket diameters are restricted and smoothness of operation is essential. Most sizes are readily available in stainless steel for corrosive conditions. Double Pitch Conveyor chains are more economical than Standard Roller chains and are available with either standard diameter or large diameter rollers. Chains with standard diameter rollers are furnished for vertical conveyors or for applications where the chain slides on the edge of the sidebars. Chains with large diameter rollers are recommended when it is advantageous to reduce the power required to operate the conveyor. Flat-top chains in numerous styles are available for transporting containers of all types, small parts, packages, and countless other items through various processing operations. Top-plates attached to the chain form the carrying surface. Chain pitch Although conveyor chains are usually selected on the basis of ultimate strength, it is often necessary to consider chain pitch. Chain pitch may govern, or be governed by, the size of the carrier or the attachment spacing. Consider short pitch Standard Roller chains, 35 through 80, for short conveyors or where smooth operation is required. For a given sprocket diameter, smaller pitch chains permit a large number of sprocket teeth; hence, less chain speed variation. See Chart A, page E-2. For longer conveyors, consider Double Pitch Roller chains. Larger pitch standard roller chains, numbers 100 through 160, are used for more heavily loaded conveyors. For long conveyors with heavy loading, consider Steel Engineering chains. Consult Rexnord for specifications.

Multiple strand conveyors When two or more strands of chains must operate abreast, strands are matched for uniform length and attachment location. Each 10-foot length is tagged to indicate the proper sequence of assembly. Sprockets should be keyseated in line with respect to a tooth or tooth space to assure an equal distribution of the load in all strands of chain. 1

1

8

8

2

2

Fig C-166

It is not necessary to couple the strands in numerical sequence unless more than one type of attachment is used in variable spacing. Operating temperature Roller chains may be operated in moderately elevated temperature zones, as in baking and enameling ovens. The working factors listed in the table on page E-4 may be used when the chain temperature is below 350° F. Consult Rexnord Industrial Chain for operation at temperature above 350° F. Refer to page E-9 for information regarding lubrication at elevated temperatures. Chain t bearing area Chain t bearing area is the pin diameter multiplied by the bushing length. Although this value is not directly used in the chain selection procedure, it can serve as an indicator of comparative wear life between two chains. For this reason, bearing area values are shown in the conveyor chain specification tables, pages D-3 to D-6. Catenary tension and chain sag The formulas applying to the conveyor layouts on pages E-6 and E-7 do not consider catenary tension since most roller chain conveyors are designed to the return span of chain. However, for short conveyors, it is not uncommon or undesirable to permit the return run to hang free. Longer conveyors are sometimes designed so that the major portion of the return run is ed, thus allowing the catenary tension in the uned section of chain to act as a takeup. When the return run of chain on a long conveyor is uned, calculate the catenary tension due to chain weight and add it to the chain pull so that the selection will be based on the total working load. Catenary tension should not exceed the chain pull and must be considered when calculating bearing loads and necessary shaft diameters, but is not a factor in determining the required horsepower to operate the conveyor.

(7010) E-1

Conveyor Engineering Engineering Recommendations

It is often desirable to determine the amount of sag to be expected in the uned slack span of a conveyor chain so that required clearances can be established. Table 5 below lists the approximate sag for various center distances. Use the following formulas to calculate chain sag and catenary tension, where: E=Excess chain, inches, or arc AB minus straight line AB U=Uned horizontal length of catenary, inches

Sprockets with at least 15 teeth are recommended; however, where greater operating smoothness is required, use sprockets with 21 or more teeth. Chart A illustrates the relationship between chordal action and the number of teeth in sprockets. Driving power The driving power is usually applied to the head, or discharge, end of the conveyor. This arrangement is recommended so that only the carrying run of the conveyor chain is under maximum tension. R = PITCH RADIUS OF SPROCKET WHEEL 180°

= R X COS Chart A Variations inr chain speedT due to chordal action

W=Weight of conveyor components (chain, slats, flights, etc.) per conveyor foot

13 14

Pc=Catenary tension, pounds WZ

+

UNED CATENARY LENGTH U UNED CATENARY LENGTH U

A

Fig. C-158

B SAG Z

A

SAG Z

DRIVEN SPROCKET DRIVEN SPROCKET

Fig. C-158

B UNED CATENARY LENGTH U UNED CATENARY LENGTH U DRIVER SPROCKET DRIVER SPROCKET

A

B A

10 11

X

96Z 12

11 12

V2

WU2

100 X100

12 13

B

SAG Z

T

10 9

V2

Z = √.375 UE

V - V1V2 - V1

Pc =

RT==PITCH RADIUS OF SPROCKET WHEEL NUMBER OF TEETH 180° rN= =RRPM X COS T MINIMUM T = NUMBER OF TEETH CHAIN SPEED A N = RPM MINIMUM CHAIN SPEED r A R V1=2πrN 12 r 180° R V1=2πrN T 12 180°

14

Z=Sag, inches

PERCENT SPEED VARIATION = =2 PERCENT SPEED VARIATION

E

SAG Z

Sprockets Sprockets for conveyor and elevator applications are usually the same diameter at both the head and foot ends. Use sprockets with as many teeth as practical to achieve smooth operation and minimize chain and sprocket wear.

MAXIMUM CHAIN SPEED MAXIMUM CHAIN SPEED

98

A

87 76

r

65

V1=2πrN 12 V1=2πrN 12

R r180°

T 180° T

5 4 4 3 3 2 2 1 1 0 0 0 0

A R

CHORDAL RISE AND FALL OFRISE CHAIN =R-r CHORDAL AND FALL OF CHAIN = R - r 5 5

10 15 20 25 30 35 40 45 10NUMBER 15 20 25 30 35 40 45 OF TEETH IN SPROCKET NUMBER OF TEETH IN SPROCKET Fig. 5059

Table 5 Chain sag–equal size sprockets–horizontal centers Sprocket Center in inches 10 20 30 40 50 60 70 80 90 100 125 150 175 200

E-2 (7010)

/16

1

.484 .685 .839 .968 1.08 1.19 1.28 1.37 1.45 1.53 1.71 1.88 2.03 2.71

/8

1

.684 .968 1.19 1.37 1.53 1.68 1.81 1.94 2.04 2.17 2.42 2.65 2.86 3.06

3

/8

1.19 1.68 2.06 2.38 2.65 2.91 3.14 3.35 3.56 3.75 4.19 4.60 4.96 5.31

1

/2

1.37 1.94 2.38 2.74 3.06 3.35 3.63 3.87 4.11 4.33 4.84 5.30 5.73 6.12

/4

3

1.68 2.37 2.90 3.35 3.75 4.10 4.44 4.74 5.03 5.30 5.93 6.49 7.02 7.50

Approximate sag in inches Excess chain in inches 1 11/2 1.94 2.74 3.35 3.87 4.33 4.74 5.12 5.48 5.81 6.12 6.85 7.50 8.10 8.66

2.37 3.35 4.11 4.74 5.30 5.81 6.27 6.71 7.11 7.50 8.39 9.19 9.92 10.6

2

21/2

3

31/2

4

2.74 3.84 4.74 5.48 6.12 6.71 7.25 7.75 8.21 8.66 9.68 10.6 11.4 12.2

3.06 4.33 5.30 6.12 6.85 7.50 8.10 8.66 9.19 9.68 11.1 11.9 12.8 13.7

3.35 4.74 5.81 6.70 7.50 8.20 8.87 9.49 10.1 10.6 11.9 13.0 14.0 15.0

3.62 5.12 6.27 7.25 8.10 8.87 9.58 10.2 10.9 11.4 12.8 14.0 15.2 16.2

3.87 5.47 6.71 7.75 8.66 9.49 10.2 11.0 11.6 12.2 13.7 15.0 16.2 17.3

E

Takeups Locate takeups at the foot, or loading, end of the conveyor whenever practical. Screw takeups are ordinarily used but where fixed tension is required, such as on long conveyors subject to wide temperature variations, spring, gravity, or catenary takeups are recommended. Takeups should have sufficient travel to permit removal of 2 pitches of chain.

When operating in a clean atmosphere, lubricate the chain with a neutral grade of straight mineral oil that is fluid enough to penetrate the chain t. When operating in an abrasive atmosphere lubricate the chain with a neutral petroleum jelly or a soft grease which, when heated, becomes sufficiently fluid to penetrate into the chain t, but at operating temperature is solid enough to hinder the entrance of abrasive materials. When operating at elevated temperatures lubricate the chain with colloidal graphite dispersed in a suitable carrier.

Fig. 7970 Fig. 7970 Fig.Fig. 7970 7970 Fig. 7970

Fig. 7970

Fig. 7970

Screw takeup Used where periodic manual adjustments are sufficient.

Fig. 7970

Complete data on lubrication methods and recommendations are on page E-9. Typical arrangements The three arrangements illustrated are most commonly used to attach slats, pans, crossrods, and similar carriers to conveyor chains. Although the illustrations show the chains rolling on large diameter rollers, the same arrangements may be used for chains with standard diameter rollers where the chains slide on the edges of the sidebars.

Fig. 4706

Fig. 7971 Fig. 7971

Fig. 7971

Fig. 7971

Fig. 7971 Gravity takeup Fig.Fig. 7971 7971 Fig. 7971 Used where constant adjustment is desirable to compensate for chain wear.

Fig. 4706

Fig. 4706 Fig. 4706 Fig. 4706 Fig.Fig. 4706 4706 Fig. 4706

Arrangement 1 illustrates the use of A attachments to which the carriers are fastened. This arrangement permits rolling on both the carrying and return runs.

Fig. 7972

Fig. 7972

Fig. 7972

Fig. 4705

Fig. 7972

Fig. 7972 Fig.Fig. 7972 7972 Fig. 7972

Spring takeup Especially useful for shock loading conditions. Due to limited travel of the spring, manual adjustments are also necessary. Fig. 7973

Fig. 7973

Fig. 7973

Fig. 7973

Fig. 4705

Fig. 4705

4705 Fig. 4705 Fig.Fig. 4705 Fig.Fig. 4705 4705

Arrangement 2 illustrates a conveyor chain with K attachments. This arrangement gives greater chain stability to wide conveyors but permits rolling on only the carrying run. Slide rails the carrier and chain on the return run. Fig. 5075

Fig. 7973

Fig. 7973 Fig.Fig. 7973 7973

Catenary takeup Useful in long conveyors where the catenary can follow the drive sprocket, thereby relieving chain tension throughout the rest of the conveyor. The catenary provides “automatic” tensioning of the chain. Lubrication Conveyor chains must be properly lubricated to give long, trouble-free service.

Fig. 5075 Fig. Fig.5075 5075 Fig. 5075 Fig.Fig. 5075 5075

Fig. 5075

Arrangement 3 shows the recommended method of attaching crossrods to a conveyor chain. Tubular crossrods riveted to the extended chain pin, or D attachment, allow some flexibility in chain alignment and may prevent overloading of one strand. (7010) E-3

E

Conveyor Engineering Selection Procedure

Either standard or Double Pitch Roller chains, with suitable attachments, are most often used for conveying applications. Numerous attachments are available to accommodate slats, crossrods, and other commonly used conveying devices. The procedure for selecting the roller chains listed in Table 6 follows.

Roller chain selection procedure Preliminary information Although chain pull and speed are the prime considerations in selecting a roller chain for conveyor service, the following information is also required. Type of conveyor Conveyor speed, feet per minute (FPM) Approximate center distance between shafts, feet Approximate diameter and bore of sprockets, inches Weight of material to be conveyed, per conveyor foot Kind of material to be conveyed Weight of carriers (slats, pans), per conveyor foot Size and spacing of carriers Type of attachment

With this information, the selection procedure is as follows: Select the layout Refer to pages E-6 and E-7 and select the appropriate conveyor layout. Calculate the approximate conveyor pull Calculate the approximate conveyor pull from the formula accompanying the layout. Since a chain has not yet been selected, value W will include the weight of slats, pans, or other carriers, and an approximate chain weight of 2 pounds per foot for each strand. Also, assume a takeup tension of 40 pounds for each strand of chain. Establish the working factor Select a working factor based on the operating speed of the conveyor. The factors listed below apply to evenly loaded, well lubricated chains operating in a clean, non-abrasive atmosphere, and in a normal temperature environment. Increase the listed factors to compensate for any deviation from the operating conditions specified above. Chain speed, feet per minute

Working factor

Chain speed, feet per Carbon† Stainless s minute steel chain steel chain

Working factor Carbon† Stainless s steel chain steel chain

Up to 50

7

28

150 to 200

12

48

50 to 100

8

32

200 to 250

14

56

00 to 150

10

40

250 to 300

16

64

† Assumes good lubrication. s Assumes minimum lubrication.

Table 6 Ultimate strengths and weights Chain Number Type of chain

Standard Roller chain

DoublePitch Conveyor chain

E-4 (7010)

Standard diameter rollers 35 40 50 60 80 100 120 140 160 C 2040 C 2050 C 2060H C 2080H C 2100H C 2120H C 2160H

Large diameter rollers Steel

Delrin

C 2042 C 2052 C 2062H C 2082H C 2102H C 2122H C 2162H

C 2042 DR C 2052 DR C 2062H DR C 2082H DR C 2102H DR C 2122H DR C 2162H DR

Chain pitch, inches 3.75 .500 .625 .750 1.000 1.250 1.500 1.750 2.000 1.000 1.250 1.500 2.000 2.500 3.000 4.000



Carbon steel chain

Stainless steel chain

Standard diameter rollers

2,100 3,700 6,100 8,500 14,500 26,000 34,500 48,500 68,000 3,700 6,100 8,500 12,500 29,000 41,500 70,000

1,550 2,800 5,000 7,000 12,000 18,750 3,000 5,000 6,800 12,000 18,750 27,000 47,000

.22 .39 .70 1.02 1.67 2.72 3.72 4.69 6.12 .32 .51 1.05 1.67 2.55 3.57 6.18

Large diameter rollers Steel

Delrin

.56 .83 1.55 2.35 3.85 6.22 9.34

.33 .65 1.04 1.63 2.43 3.47 5.60

E

Roller chain selection procedure (cont.) Determine the minimum conveyor strength required Multiply the working factor by the approximate conveyor pull. The product is the minimum ultimate conveyor strength required. Determine the minimum chain strength required Divide the minimum conveyor strength by the number of strands carrying the load. When the conveyor is designed to use two or more parallel strands of chain the required chain strength should reflect the distribution of load on each strand. If equal load distribution is assured, base the required chain strength for double strand conveyors on 1/2 the minimum conveyor strength requirement, 1 /3 for triple strand, etc. If the strands are not evenly loaded, divide the calculated minimum conveyor requirement by the number of strands that will normally handle the imposed load. For example, the chain selected for a four-strand conveyor may have to be based on two or three strands taking the full load at times, due to its distribution on the conveyor. Select the conveyor chain Refer to Table 6 on page E-4 and select a chain with an ultimate strength slightly greater than the minimum requirement just calculated.

Chain length should equal an even number of pitches. Using the nearest even number of pitches as value N, calculate the exact sprocket centers from the formula: C = N – T × P 2 where C = exact sprocket centers, inches N = nearest even number of pitches P = chain pitch, inches T = number of teeth per sprocket When the number of teeth in the head and foot sprockets is unequal, chain length and exact sprocket centers are calculated from the formula on page C-8. Chain sag The amount of sag in the slack span of chain is calculated from the formula on page E-2. Lubrication It is usually advisable to lubricate conveyor chains. See page E-9 for methods and recommendations. Calculate the conveyor horsepower requirement To calculate the horsepower required to operate the conveyor, use the formula in the appropriate conveyor layout, pages E-6 and E-7.

The size of slats or pans, or the required spacing of attachments govern chain pitch. Make sure that the chain selected meets both pitch and strength requirements. Check the chain selection Refer to the formula previously used and compute the actual chain pull, considering chain weight (Table 6 on page E-4) and takeup tension now that a chain has been selected. Multiply the actual chain pull by the working factor to determine the minimum ultimate strength requirement. Check the result against the ultimate strength of the chain selected. If equal to or greater than the minimum requirement, the chain selection is satisfactory. Determine the number of teeth in the sprockets Use sprocket pitch diameters listed for drive series Double Pitch chains (pages E-10 through E-23) for determining the number of teeth in the desired sprocket for use with conveyor series extended pitch chains. If possible, use sprockets with 15 teeth or more. Smoothness of conveyor chain operation is dependent upon adequate teeth in the driving sprockets, as illustrated in Chart A, page E-2. Calculate chain length and sprocket centers When the number of teeth in the sprockets is equal, calculate chain length from the formula: chain length, in pitches = T + 2c P where c = center distance between shafts, inches P = chain pitch, inches T = number of teeth per sprocket

(7010) E-5

E

Conveyor Engineering Layouts and Formulas

Layouts and formulas The layouts on this page and page E-7 represent the most common conveyor arrangements. For layouts not shown, consult Rexnord. If the conveyor design involves both a horizontal and an inclined section, the total conveyor pull (PCV) is determined by calculating separate conveyor pulls for each section, using the formulas in Layouts A & B, and adding them together. The symbols used in the formulas and layouts are: F = Friction factor, Tables 7 and 8 HP = Horsepower at head shaft L = Length of conveyor or elevator centers, feet M = Weight of material carried per foot of conveyor or elevator, pounds P = Chain pitch, inches PB = Pull due to digging material from elevator boot, pounds PC = Conveyor pull due to catenary tension, pounds (See page E-2 for formula.) PL = Conveyor or elevator pull on loaded run, pounds PO = Conveyor pull from other sources, pounds PR = Conveyor pull on return run, pounds PT = Total calculated chain pull per strand, pounds PCV = Total calculated conveyor pull, pounds PEL = Total calculated elevator pull, pounds PTU = Conveyor take-up pull, pounds R = Vertical rise of elevator or inclined portion of conveyor, feet S = Chain speed, feet per minute T = Number of teeth in drive sprocket W = Weight of chain and conveying member (slats, buckets, etc.), pounds per foot of conveyor Y = Horizontal length of inclined portion of conveyor or elevator, feet

Coefficients of friction The factors in Tables 7 and 8 refer to roller chains operating on smooth, flat, clean tracks at normal operating temperatures. The factors should be increased when tracks cannot be kept clean. The coefficients of sliding friction in Table 7 apply when the conveyed load is carried by the edges of the chain sidebars or by the top plates of flat-top roller chains. The coefficients of rolling friction in Table 8 apply when the conveyed load is carried by double-pitch conveyor chains with large diameter rollers. Chains with standard diameter rollers are not recommended for rolling conveyors since the rollers may not always turn due to the small ratio between outside and inside diameters.

E-6 (7010)

Chain rolling or sliding and material carried Layout A L

TAKE-UP

DRIVE

TRAVEL

PCV

TRACK TRACK

Fig. 5068

Fig. 5068

The total conveyor pull is the sum of the following: Pull on loaded run PL = (W + M)LF Pull on return run PR = WLF Take-up pull ∆ PTU or PU Pull to operate tail sprocket PR × .1 Pull from other factors PO Total conveyor pull PCV Calculate the total chain pull per strand (PT) by dividing PCV by the number of strands taking the load. ∆ Usually, the takeup pull is known. If not, use 0.3% of the chain’s ultimate strength as a reasonable estimate. Horsepower required to operate the conveyor HP = (PCV – PTU or PC ) × 1.2 × S 33,000

Table 7 Coefficient of sliding friction

(Conveyed load carried by chain sidebars or top plates)

Non-lubricated steel track

Lubricated steel track

33

.24

Table 8 Coefficient of rolling frictions

(Conveyed load carried by large diameter rollers)

Chain number C 2042 C 2052 C 2062H C 2082H C 2102H C 2122H

Chain pitch, inches 1.000 1.250 1.500 2.000 2.500 3.000

Non-lubricated chain .17 .16 .16 .15 .14 .14

Chain speed, feet per minute .12 .11 .11 .10 .09 .09

s When calculating the approximate chain pull, use a trial rolling friction factor of .17 for non-lubricated chains or .12 for lubricated chains. n These factors should be used only when an adequate oil film will be maintained between rollers and bushings. Otherwise, use the factors for non-lubricated chain.

E

Chain rolling or sliding and material carried Layout B

Vertical elevator with material carried DRIVE PCV

Layout C PEL

DRIVE

L VEL TRA

CK

TRA

R

Y

Fig. 5069

TRAVEL

CK TRA

TAKE-UP

R

The total conveyor pull (PCV) is the sum of the following: Pull on loaded run: to move load = (W + M)YF PL = (W + M)YF + (W + M)R to lift load = (W + M)R Pull on return run N PR = WYF Take-up pull ∆ PTU or PC Pull to operate tail sprocket PR × .1 Pull from other factors PO Calculate the total chain pull per strand (PT) by dividing PCV by the number of strands taking the load. M

Disregard when

R Y

is greater than factor F.

∆ Usually, the takeup pull is known. If not, use 0.3% of the chain’s ultimate strength as a reasonable estimate.

Horsepower required to operate the conveyor HP = (PCV - PTU or PC) × 1.2 × S 33,000

Fig. 5073

TAKE-UP

The total elevator pull (PEL) is the sum of the following: Pull on loaded run Take-up pull Digging pull Pull to operate tail sprocket

PL = (W + M)R PTU PB = M × s PTU × .1

Calculate the total chain pull per strand (PT) by dividing PEL by the number of chain strands used in the elevator. ∆ Usually, the takeup pull is known. If not, use 0.3% of the chain’s ultimate strength as a reasonable estimate. s For material with small lumps, multiply M by the sprocket diameter. For fine or fluffy materials, multiply M by the sprocket radius.

Horsepower required to operate the elevator HP = PEL – (PTU + WR) × 1.2 × S 33,000

(7010) E-7

E

Conveyor Engineering

Selection Example

This example illustrates the method of selecting a conveyor chain solely on the basis of ultimate chain strength. Attachment spacing, appearance, or other factors may make it desirable to use a larger, higher strength chain than the minimum indicated by the conveyor pull formula and working factor. Problem Select a conveyor chain for the following application: Type of conveyor ��Double-strand horizontal slat conveyor, evenly loaded, with chain rolling and material carried. Chain lubricated and ed on carrying and return runs. Conveyor speed. . . . . . . . . . 200 FPM Approx. center distance between shafts . . . . . . . . . 60 feet Approx. sprocket diameters . . . . . . . . . . . . . 8.250" Sprocket bores. . . . . . . . . . . 1.938" Weight of material. . . . . . . . . 70 pounds per conveyor foot Kind of material ��35 pound cans, 10" diameter, spaced 2" apart, 2 cans per conveyor foot. Weight of slats ��5 pounds per conveyor foot Size and spacing of slats ��Will be designed in relation to pitch of chain selected. Solution Select the layout Layout A on page E-6 illustrates a horizontal conveyor with chain rolling and material carried. Calculate the approximate conveyor pull As indicated in the selection procedure, certain assumed values are used in the layout formula at this point. Chain weight = 2 lbs. per foot per strand Take-up tension = 40 lbs. per strand Rolling friction factor = .12 Using these values, the approximate conveyor pull is the sum of the following: Pull on loaded run PL = (W + M)LF = (5 + 4 + 70)60 × .12 =569 Pull on return run PR = WLF = 9 × 60 × .12 = 65 Takeup pull PTU = 40 x 2 = 80 Pull to operate tail sprocket PR × .1 = 65 × .1 = 7 Total conveyor pull PCV =721 Establish the working factor The working factor listed on page E-4 for a chain speed of 200 feet per minute is 14.

E-8 (7010)

Determine the minimum conveyor strength required The minimum requirement is: 721 x 14 = 10,094 pounds Determine the minimum chain strength required Since this is a double-strand conveyor, with each strand evenly loaded, the minimum chain strength per strand is 10,094 ÷ 2 or 5,047 pounds ultimate strength. Select the chain Since a rolling chain is desired, refer to Table 6 and tentatively select C 2052 chain which has large diameter rollers and an average ultimate strength of 6100 pounds. Check the chain selection From Layout A, compute the actual conveyor pull, using the weight of C 2052 chain shown in Table 6. Since the actual takeup pull is not known, use .3% of the ultimate strength of C 2052 chain for each strand. Also use the rolling friction factor for C 2052 shown in Table 8. The actual conveyor pull is the sum of the following: = 506# PL = [5 + (2 x .83) + 70] 60 × .11 PR = [5 + (2 x .83)] 60 × .11 = 44# PTU = .003 × 2 × 6100 = 37# PR × .1 = 44 × .1 = 4# Total conveyor pull (PCV) = 591# Minimum conveyor strength = 591 × 14 = 8274# Minimum chain strength per strand = 8274÷ 2 = 4137# The selection of C 2052 chain with an ultimate strength of 6100 pounds is satisfactory. Determine the number of teeth in the sprockets Refer to the listing for 2050 sprockets on page E-12. Note that a 19-tooth sprocket has a pitch diameter of 7.595" which is slightly less than the appropriate outside diameter of 8.250" desired, and that they will readily accommodate the 1.938" bore requirement. If a distance of 8.240" between the carrying and return runs is satisfactory, use 19-tooth sprockets. Calculate the chain length and sprocket chains Since the number of teeth in the sprockets are equal, the chain length from the formula on page E-5 is: 2(60 × 12) 19 + = 1171 pitches. Use 1172. 1.25 Exact sprocket centers, based on 1172 pitches, are: 1172 - 19 C = × 1.25 = 720.625", or 60' .625" 2 Lubrication Refer to page E-9 for recommendations. Calculate the horsepower requirement Use the formula accompanying Layout A to determine the horsepower requirement of the conveyor drive. HP = (591 - 37) × 1.2 × 200 = 4.03 33,000

E

Lubrication

Lubrication The primary purpose of chain lubrication is to provide a clean film of oil at all load carrying points where relative motion occurs. This is particularly important during the initial break-in period when the wear characteristics of the chain are being established. Consequently, most chains are pre-lubricated at the factory unless otherwise specified. To be effective, subsequent lubrication must be directed to the bearing surfaces as shown in Figure C-147.

Between the sidebars to the pin-bushing bearing surface Inside the roller

Elevated temperatures Petroleum oils should not be used to lubricate conveyor or elevator chains operating in temperatures exceeding 300°F (149°C). Under certain conditions, chains operating in high-temperature atmospheres can be effectively lubricated with colloidal graphite dispersed in a suitable volatile carrier. The solution penetrates the chain ts and, upon evaporation of the carrier, leaves a thin deposit of graphite on the chain t surfaces. The lubricant may be applied by drip-feed cups, provided agitation is used. Consult a lubricant manufacturer for recommendations when chains are required to operate at elevated temperatures. Corrosion The effect of unusual corrosion conditions can sometimes be reduced with special lubricants. Consult a lubricant manufacturer for a material that is not soluble in the corrosive element.

Roller chains all types

Fig. C-147

As a general rule, lubrication of conveyor and elevator chains is necessary to obtain adequate chain life. However, there may be some applications where little or no lubrication is permissible. Meat packing and food processing plants are typical examples where contamination of the conveyed material must be avoided. Likewise, the presence of lubricant in a very dusty or abrasive environment could be a deterrent to long chain life. In these cases, lubrication decisions must often be based on actual experience.

Selection of the lubricant Conveyor and elevator chains operating at room temperature should generally be lubricated with a straight mineral oil of S.A.E. viscosity number 30. Lower or higher ambient temperatures require oils with lower or higher viscosity numbers, respectively. The following operating conditions require special lubricants:

High loads When chain ts are subject to high unit bearing loads, use an “ EP” oil. This type of lubricant has an extreme pressure additive that helps maintain a cushioning film of oil between t components.

Methods of lubrication It is difficult and generally impractical to provide protective housings for chains applied to conveyors and elevators. They are usually operated in the open and exposed to the material being conveyed. Therefore, applying a lubricant is difficult under some operating conditions. Various methods are used to lubricate conveyor and elevator chains. The nature of the surrounding atmosphere is the principal consideration in selecting the best method to use. Clean atmosphere Chains operating in a relatively clean atmosphere can be lubricated manually or by a semiautomatic method using drip cups. The lubricant may be applied manually with a brush or spout-type oil can to the spaces shown in Figure C-147.

With the semi-automatic method, dripcups are usually mounted on a pipe with drilled holes spaced to distribute oil between the sidebars in the lower span of chain. About 4 to 10 drops per minute are usually sufficient to lubricate slowspeed conveyors. It will take about one hour to drop one ounce of oil at the rate of 10 drops per minute. Atmosphere laden with lint or nonabrasive dust Where large volumes of lint or non-abrasive dust are present, a brush or wiper can be used to clean the chain and apply the lubricant. Otherwise, the lint or dust will clog the chain t clearances and prevent the oil from penetrating into the ts. This type of lubrication can be made to operate automatically. Abrasive atmosphere If abrasives come in with the chain, lubrication becomes more difficult. When lubricants are applied externally, abrasive particles tend to adhere to the chain surfaces and act as a lapping or grinding compound. Under extreme conditions, it is sometimes advisable to avoid chain lubrication. Chains operating in an abrasive atmosphere can often be lubricated with a neutral petroleum jelly such as petrolatum, or with various other nonfluid lubricants such as greases with or without molybdenum disulfide or colloidal graphite additives. When properly heated, these lubricants are sufficiently fluid to penetrate the chain ts, but at normal temperatures are solid enough to hinder the entrance of abrasive materials. To lubricate a chain with petroleum jelly or non-fluid greases, heat the lubricant until fluid. Immerse the chain and allow it to soak until air bubbles cease to rise, thus indicating that the lubricant has penetrated the chain ts. Allow the chain to remain submerged until the lubricant is partially solidified to prevent the lubricant from draining out of the ts when the chain is removed. Before relubricating, thoroughly clean chain to remove all dirt and abrasives.

(7010) E-9

Sprockets


C 2040 sprockets 1.000" pitch

PIITCH DIAMETER

T

OUTSIDE DIAMETER

S

ROOT DIAMETER

T

CHAIN PITCH

E

CHAIN PITCH

T

LENGTH THRU BORE


CHAIN PITCH

Fig. 6446 Fig. 6450

MAXIMUM BORE

Number of effective teeth

Type A

Pitch dia., inches

Root dia., inches

Outside dia., inches ∆

Maximum hub diameter, inches

2.000 2.152 2.305 2.458 2.613 2.768 2.924 3.080 3.236 3.392 3.549 3.706 3.864 4.021 4.179 4.336 4.494 4.652 4.810 4.968 5.126 5.284 5.442 5.600 5.759 5.917 6.076 6.233 6.392 6.551 6.710 6.868 7.027 7.185 7.344

1.688 1.840 1.993 2.146 2.301 2.456 2.612 2.768 2.924 3.080 3.237 3.394 3.552 3.709 3.867 4.024 4.182 4.340 4.498 4.656 4.814 4.972 5.130 5.288 5.447 5.605 5.764 5.921 6.081 6.239 6.398 6.556 6.715 6.873 7.032

2.166 2.318 2.491 2.644 2.811 2.968 3.136 3.292 3.457 3.613 3.777 3.934 4.098 4.255 4.419 4.576 4.738 4.896 5.057 5.215 5.377 5.535 5.696 5.854 6.015 6.173 6.334 6.491 6.654 6.812 6.972 7.130 7.292 7.450 7.610

1.19 1.38 1.55 1.70 1.88 2.05 2.20 2.38 2.58 2.70 2.88 3.03 3.19 3.36 3.52 3.69 3.84 4.00 4.17 4.33 4.48 4.66 4.81 4.97 5.14 5.30 5.45 5.61 5.78 5.94 6.09 6.27 6.42 6.58 6.73

h

6 61/2 7 71/2 8 81/2 9 91/2 10 101/2 11 111/2 12 121/2 13 131/2 14 141/2 15 151/2 16 161/2 17 171/2 18 181/2 19 191/2 20 201/2 21 211/2 22 221/2 23

Maximum bore with standard keyseat, inches s .750 .844 1.000 1.188 1.250 1.375 1.438 1.688 1.813 1.938 2.188 2.250 2.250 2.281 2.281 2.375 2.625 2.688 2.750 2.813 3.000 3.375 3.438 3.563 3.625 3.688 3.750 3.750 3.781 3.813 4.000 4.250 4.500 4.750 -

S max., inches


.469 .516 .625 .719 .750 .844 .969 1.031 1.125 1.219 1.344 1.375 1.406 1.438 1.469 1.500 1.625 1.656 1.750 1.781 1.875 2.125 2.156 2.219 2.250 2.281 2.313 2.344 2.375 2.406 2.500 2.625 2.750 2.875 -

231/2 24 241/2 25 251/2 26 261/2 27 271/2 28 281/2 29 291/2 30 301/2 31 311/2 32 321/2 33 331/2 34 35 36 37 38 39 40 41 42 43 44 45 46 47

Sprocket Type


B

6 to 91/2 10 to 23 231/2 to 38 39 to 45 46 to 80

.88 1.00 1.13 1.25 1.38

Fig. 8382

Type C

Pitch dia., inches

Root dia., inches



7.502 7.661 7.820 7.979 8.137 8.296 8.455 8.614 8.772 8.931 9.090 9.249 9.408 9.567 9.725 9.885 10.043 10.202 10.361 10.520 10.679 10.838 11.156 11.474 11.792 12.110 12.428 12.746 13.064 13.382 13.700 14.018 14.336 14.654 14.972

7.190 7.349 7.508 7.667 7.825 7.984 8.143 8.302 8.460 8.620 8.778 8.937 9.096 9.255 9.413 9.573 9.731 9.890 10.049 10.208 10.367 10.526 10.844 11.162 11.480 11.798 12.116 12.434 12.752 13.070 13.388 13.706 14.024 14.342 14.660

7.768 7.928 8.087 8.248 8.406 8.566 8.725 8.885 9.043 9.204 9.362 9.521 9.680 9.841 9.999 10.160 10.318 10.478 10.637 10.796 10.955 11.12 11.43 11.75 12.07 12.39 12.71 13.03 13.35 13.66 13.98 14.30 14.62 14.94 15.26

48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80

h

Hub length thru bore Number of effective teeth

Type B

Pitch dia., inches

Root dia., inches

h

15.290 14.978 15.608 15.296 15.926 15.614 16.244 15.932 16.562 16.250 16.880 16.568 17.198 16.886 17.516 17.205 17.835 17.523 18.153 17.841 18.471 18.159 18.789 18.477 19.107 18.795 19.426 19.114 19.744 19.432 20.062 19.750 20.380 20.068 20.698 20.386 21.016 20.704 21.335 21.023 21.653 21.341 21.971 21.659 22.289 21.977 22.607 22.295 22.926 22.614 23.244 22.932 23.562 23.250 23.880 23.568 24.198 23.886 24.517 24.205 24.835 24.523 25.153 24.841 25.471 25.159 Larger sizes available. Consult Rexnord.

Outside dia., inches ∆ 15.57 15.89 16.21 16.53 16.85 17.17 17.48 17.80 18.12 18.44 18.76 19.08 19.39 19.71 20.03 20.35 20.67 20.99 21.30 21.62 21.94 22.26 22.58 22.90 23.21 23.53 23.85 24.17 24.49 24.81 25.13 25.45 25.77

Tooth dimensions Sprocket Type

C



15 to 30 301/2 to 41 42 to 60 61 to 80

1.75 2.00 2.25 2.50

T = .284" + .000", –.009" for machined sprockets. T = .284" + .000", –.035" for hot rolled plate sprockets or unfinished forgings.

Recommended standard bore tolerances, keyseat dimensions, eccentricity tolerances, and similar data, page G-2. h “Effective” describes the number of teeth that engage the chain rollers during each revolution of the sprocket. See Fig. 8382 above. The effective number is used to calculate chain speed. Sprockets are normally furnished with twice the effective number listed. When the actual number of teeth is 24 or more, sprockets for No.40 roller chain may be used. See page C-13 for sprocket data. ∆ Non-functional dimension that may vary with the type of cutter used. s Based on maximum hub diameter.

E-10 (7010)


Sprockets for large diameter roller chains can be furnished only with the actual number of teeth required.

T

OUTSIDE DIAMETER

ROOT DIAMETER

CHAIN PITCH

S

PIITCH DIAMETER

T

LENGTH THRU BORE

CHAIN PITCH

T


CHAIN PITCH

Fig. 6446 Fig. 6450

MAXIMUM BORE

Type A

Type B

Number of teeth




Maximum hub diameter, inches s

Maximum bore with standard keyseat, inches

S max., inches

Number of teeth

6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23

2.000 2.305 2.613 2.924 3.236 3.549 3.864 4.179 4.494 4.810 5.126 5.442 5.759 6.076 6.393 6.710 7.027 7.344

1.375 1.680 1.988 2.299 2.611 2.924 3.239 3.554 3.869 4.185 4.501 4.817 5.134 5.451 5.768 6.085 6.402 6.719

2.330 2.680 3.010 3.350 3.680 4.010 4.330 4.660 4.980 5.310 5.630 5.950 6.270 6.590 6.910 7.240 7.560 7.880

1.19 1.55 1.88 2.20 2.55 2.88 3.19 3.52 3.84 4.17 4.48 4.81 5.14 5.45 5.78 6.09 -

.750 1.000 1.250 1.438 1.813 2.188 2.250 2.281 2.625 2.750 3.000 3.438 3.625 3.750 3.781 4.000 -

.469 .625 .750 .969 1.125 1.344 1.406 1.469 1.625 1.750 1.875 2.156 2.250 2.313 2.375 2.500 -

24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40

Hub length thru bore Sprocket Type


B

6 to 9 10 to 23 24 to 38 39 to 40



7.661 7.036 7.979 7.354 8.296 7.671 8.614 7.989 8.932 8.307 9.249 8.624 9.567 8.942 9.885 9.260 10.202 9.577 10.520 9.895 10.838 10.213 11.156 10.531 11.474 10.849 11.792 11.167 12.110 11.485 12.428 11.803 12.746 12.121 Larger sizes available.

Outside diameter, inches ∆ 8.200 8.520 8.840 9.160 9.480 9.800 10.110 10.430 10.750 11.070 11.390 11.710 12.030 12.350 12.670 12.990 13.310

Tooth dimensions

Hub length, thru bore, Sprocket Type inches .88 1.00 1.13 1.25

Fig. 8382

Type C

C



15 to 30 31 to 40

1.75 2.00


Standard bore tolerances, keyseat dimensions, eccentricity tolerances, and similar data, page G-2. ∆ Non-functional dimension that may vary with the type of cutter used. s Based on maximum hub diameter.

(7010) E-11

E

Sprockets

Sprockets are usually furnished with twice the required number of teeth, virtually doubling sprocket life. Sprockets with only the required number of teeth, can also be furnished.

C 2050 sprockets 1.250" pitch T

OUTSIDE DIAMETER

ROOT DIAMETER

S

PIITCH DIAMETER

T

CHAIN PITCH

E

LENGTH THRU BORE

CHAIN PITCH

T


CHAIN PITCH

Fig. 6446 Fig. 6450

MAXIMUM BORE


Pitch dia., inches

Root dia., inches



2.500 2.690 2.881 3.073 3.266 3.460 3.655 3.850 4.045 4.241 4.437 4.633 4.830 5.026 5.223 5.420 5.617 5.815 6.012 6.210 6.407 6.605 6.803 7.001 7.198 7.396 7.595 7.792 7.991 8.189 8.387 8.585 8.783 8.982 9.180

2.100 2.290 2.481 2.673 2.866 3.060 3.255 3.450 3.645 3.841 4.037 4.233 4.430 4.626 4.823 5.020 5.217 5.415 5.612 5.810 6.007 6.205 6.403 6.601 6.798 6.996 7.195 7.392 7.591 7.789 7.987 8.185 8.383 8.582 8.780

2.708 2.898 3.112 3.305 3.517 3.711 3.920 4.115 4.321 4.517 4.722 4.918 5.123 5.319 5.522 5.719 5.921 6.119 6.321 6.519 6.720 6.918 7.121 7.319 7.519 7.717 7.918 8.115 8.317 8.515 8.715 8.913 9.113 9.312 9.512

1.50 1.72 1.94 2.14 2.36 2.56 2.77 2.98 3.19 3.39 3.59 3.80 4.00 4.20 4.41 4.61 4.81 5.02 5.22 5.42 5.63 5.83 6.03 6.22 6.42 6.63 6.83 7.03 7.23 7.44 7.63 7.83 8.03 8.23 8.44

h

6 61/2 7 71/2 8 81/2 9 91/2 10 101/2 11 111/2 12 121/2 13 131/2 14 141/2 15 151/2 16 161/2 17 171/2 18 181/2 19 191/2 20 201/2 21 211/2 22 221/2 23

Type A Maximum bore with standard keyseat, inches s .969 1.125 1.375 1.438 1.625 1.813 1.938 2.125 2.313 2.438 2.625 2.750 2.875 2.906 2.934 3.125 3.250 3.313 3.563 3.719 3.750 3.781 3.875 4.125 4.313 4.375 4.500 4.750 5.125 5.250 5.500 5.750 5.875 6.125 -

S max., inches


.609 .688 .844 .906 1.000 1.094 1.219 1.313 1.438 1.531 1.625 1.688 1.781 1.813 1.875 1.934 2.000 2.094 2.219 2.313 2.313 2.375 2.438 2.500 2.625 2.688 2.750 3.000 3.125 3.250 3.375 3.625 6.688 3.750 -

231/2 24 241/2 25 251/2 26 261/2 27 271/2 28 281/2 29 291/2 30 301/2 31 311/2 32 321/2 33 331/2 34 35 36 37 38 39 40 41 42 43 44 45 46 47



B

6 to 91/2 10 to 191/2 20 to 301/2 31 to 45 46 to 80 73 to 80

1.00 1.13 1.38 1.63 1.88 3.25

Fig. 8382

Type C

Pitch dia., inches

Root dia., inches



9.378 9.577 9.775 9.973 10.172 10.370 10.569 10.767 10.966 11.164 11.362 11.561 11.760 11.958 12.157 12.356 12.554 12.753 12.952 13.150 13.349 13.547 13.945 14.342 14.740 15.137 15.534 15.932 16.329 16.727 17.124 17.522 17.920 18.317 18.715

8.978 9.177 9.375 9.573 9.772 9.970 10.169 10.367 10.566 10.764 10.962 11.161 11.360 11.558 11.757 11.956 12.154 12.353 12.552 12.750 12.949 13.147 13.545 13.942 14.340 14.737 15.134 15.532 15.929 16.327 16.724 17.122 17.520 17.917 18.315

9.710 9.911 10.111 10.308 10.507 10.707 10.906 11.105 11.304 11.504 11.702 11.902 12.101 12.300 12.499 12.699 12.897 13.098 13.297 13.495 13.691 13.893 14.290 14.790 15.090 15.490 15.880 16.28 16.68 17.08 17.48 17.88 18.27 18.67 19.07

48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80

h


Type B

Pitch dia., inches

Root dia., inches


19.112 19.510 19.908 20.305 20.703 21.100 21.498 21.896 22.293 22.961 23.089 23.486 23.884 24.282 24.680 25.077 25.475 25.873 26.271 26.668 27.066 27.464 27.862 28.259 28.657 29.055 29.453 29.850 30.248 30.646 31.044 31.441 31.839

18.712 19.110 19.508 19.905 20.303 20.700 21.098 21.496 21.893 22.291 22.689 23.086 23.484 23.882 24.280 24.677 25.075 25.473 25.871 26.268 26.666 27.064 27.462 27.859 28.257 28.655 29.053 29.450 29.848 30.246 30.644 31.041 31.439

19.47 19.87 20.36 20.66 21.06 21.46 21.86 22.25 22.65 23.05 23.45 23.85 24.24 24.64 25.04 25.44 25.84 26.23 26.63 27.03 27.43 27.82 28.22 28.62 29.02 29.42 29.81 30.21 30.61 31.01 31.41 31.81 32.21

h



C



13 to 24 241/2 to 30 301/2 to 40 41 to 60 61 to 72

2.00 2.25 2.50 2.75 3.00


Recommended standard bore tolerances, keyseat dimensions, eccentricity tolerances, and similar data, page G-2. h “Effective” describes the number of teeth that engage the chain rollers during each revolution of the sprocket. See Fig. 8382 above. The effective number is used to calculate chain speed. Sprockets are normally furnished with twice the effective number listed. When the actual number of teeth is 24 or more, sprockets for No. 50 roller chain may be used. See page C-17 for sprocket data. ∆ Non-functional dimension that may vary with the type of cutter used. s Based on maximum hub diameter.

E-12 (7010)



T

OUTSIDE DIAMETER

ROOT DIAMETER

CHAIN PITCH

S

PIITCH DIAMETER

T

CHAIN PITCH

T

LENGTH THRU BORE


CHAIN PITCH

Fig. 6446 Fig. 6450

MAXIMUM BORE

Type A

Number of teeth





6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23

2.500 2.881 3.266 3.655 4.045 4.437 4.830 5.223 5.617 6.012 6.407 6.803 7.198 7.595 7.991 8.387 8.783 9.180

1.750 2.131 2.516 2.905 3.295 3.687 4.080 4.473 4.867 5.262 5.657 6.053 6.448 6.845 7.241 7.637 8.033 8.430

2.920 3.350 3.770 4.180 4.600 5.010 5.420 5.820 6.230 6.630 7.030 7.440 7.840 8.240 8.640 9.040 9.440 9.840

1.50 1.94 2.36 2.77 3.19 3.59 4.00 4.41 4.81 5.22 5.63 6.03 6.42 6.83 7.23 7.63 -

Type B Maximum bore with standard keyseat, inches s .969 1.375 1.625 1.938 2.313 2.625 2.875 2.938 3.250 3.563 3.750 3.875 4.313 4.500 5.125 5.500 -


B

Number of teeth

Fig. 8382

Type C

S max., inches

Number of teeth

.609 .844 1.000 1.219 1.438 1.625 1.781 1.875 2.000 2.219 2.313 2.438 2.625 2.750 3.125 3.375 -

24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40





Tooth dimensions


Sprocket Type

Number of teeth


6 to 9

1.00

13 to 24

2.00

10 to 19

1.13

25 to 30

2.25

20 to 30

1.38

31 to 40

2.50

31 to 40

1.63

C



(7010) E-13

E

Sprockets


C 2060H, FT 2060 1.500" pitch T

PIITCH DIAMETER

OUTSIDE DIAMETER

S

ROOT DIAMETER

T

CHAIN PITCH

E

LENGTH THRU BORE

CHAIN PITCH

T


CHAIN PITCH

Fig. 6446 Fig. 6450

MAXIMUM BORE


Pitch dia., inches

Root dia., inches



3.000 3.228 3.457 3.688 3.920 4.152 4.386 4.620 4.854 5.089 5.324 5.560 5.796 6.032 6.268 6.504 6.741 6.978 7.215 7.452 7.689 7.926 8.163 8.401 8.638 8.875 9.113 9.350 9.589 9.826 10.064 10.302 10.540 10.778 11.016

2.531 2.759 2.988 3.219 3.451 3.683 3.917 4.151 4.385 4.620 4.855 5.091 5.327 5.563 5.799 6.035 6.272 6.509 6.746 6.983 7.220 7.457 7.694 7.932 8.169 8.406 8.644 8.881 9.120 9.357 9.595 9.833 10.071 10.309 10.547

3.249 3.477 3.735 3.964 4.221 4.453 4.704 4.938 5.185 5.420 5.666 5.902 6.147 6.383 6.627 6.863 7.106 7.343 7.587 7.824 8.066 8.303 8.543 8.781 9.023 9.260 9.501 9.738 9.980 10.217 10.458 10.696 10.936 11.174 11.415

1.81 2.08 2.33 2.58 2.83 3.08 3.33 3.58 3.83 4.08 4.33 4.56 4.81 5.06 5.30 5.55 5.78 6.03 6.27 6.52 6.75 7.00 7.23 7.48 7.72 7.97 8.20 8.44 8.69 8.92 9.17 9.41 9.64 9.89 10.13

h

6 61/2 7 71/2 8 81/2 9 91/2 10 101/2 11 111/2 12 121/2 13 131/2 14 141/2 15 151/2 16 161/2 17 171/2 18 181/2 19 191/2 20 201/2 21 211/2 22 221/2 23

Type A Maximum bore with standard keyseat, inches s 1.250 1.344 1.563 1.750 1.938 2.188 2.313 2.500 2.750 2.938 3.125 3.375 3.563 3.688 3.813 4.000 4.125 4.250 4.500 4.563 4.688 5.000 5.250 5.500 5.563 5.750 5.938 6.063 6.188 6.313 6.438 6.750 7.000 7.188 -

S max., inches


.750 .828 .969 1.063 1.219 1.375 1.469 1.563 1.688 1.813 1.934 2.094 2.219 2.281 2.375 2.500 2.563 2.625 2.750 2.906 2.969 3.125 3.250 3.375 3.469 3.625 3.719 3.781 3.844 3.906 3.969 4.125 4.250 4.344 -

231/2 24 241/2 25 251/2 26 261/2 27 271/2 28 281/2 29 291/2 30 301/2 31 311/2 32 321/2 33 331/2 34 35 36 37 38 39 40 41 42 43 44 45 46 47



B

6 to 15 151/2 to 25 251/2 to 41 42 to 60 61 to 80

1.25 1.50 1.75 2.00 2.25

Fig. 8382

Type C

Pitch dia., inches

Root dia., inches



11.254 11.492 11.730 11.968 12.206 12.444 12.682 12.921 13.159 13.397 13.635 13.874 14.112 14.350 14.588 14.827 15.065 15.303 15.542 15.780 16.018 16.257 16.734 17.211 17.687 18.164 18.641 19.118 19.595 20.072 20.549 21.026 21.503 21.980 22.458

10.785 11.023 11.261 11.499 11.737 11.975 12.213 12.452 12.690 13.928 13.166 13.405 13.643 13.881 14.119 14.358 14.596 14.834 15.073 15.311 15.549 15.788 16.265 16.742 17.218 17.695 18.172 18.649 19.126 19.603 20.080 20.557 21.034 21.511 21.989

11.653 11.893 12.131 12.371 12.609 12.849 13.087 13.328 13.566 13.805 14.043 14.238 14.521 14.761 14.999 15.239 15.477 15.716 15.955 16.194 16.432 16.672 17.150 17.630 18.110 18.580 19.060 19.540 20.020 20.490 20.970 21.450 21.930 22.41 22.88

48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80

h

Pitch dia., inches

Root dia., inches


22.935 23.412 23.889 24.366 24.843 25.320 25.798 26.275 26.752 27.229 27.707 28.184 28.661 29.138 29.616 30.093 30.570 31.047 31.525 32.002 32.479 32.957 33.434 33.911 34.388 34.866 35.343 35.820 36.298 36.775 37.252 37.730 38.207

22.466 22.943 23.420 23.897 24.374 24.851 25.329 25.806 26.283 26.760 27.238 27.715 28.192 29.669 29.147 29.624 30.010 30.578 31.056 31.533 32.010 32.488 32.965 33.451 33.919 34.397 34.874 35.351 35.829 36.306 36.783 37.261 37.738

23.36 23.84 24.32 24.79 25.27 25.75 26.23 26.70 27.18 27.66 28.14 28.61 29.09 29.57 30.05 30.53 31.00 31.48 31.96 32.43 32.91 33.39 33.87 34.34 34.82 35.30 35.78 36.25 36.73 37.21 37.69 38.17 38.65

h


Tooth dimensions


Type B

Sprocket Type

C



10 to 20 201/2 to 40 41 to 60 61 to 80

2.25 2.50 3.00 3.25

T = .459" + .000", –.011" for machined sprockets. T = .459" + .000", –.036" for hot rolled steel plate sprockets or unfinished forgings.


E-14 (7010)



T

OUTSIDE DIAMETER

PIITCH DIAMETER

CHAIN PITCH

S

ROOT DIAMETER

T

CHAIN PITCH

T

LENGTH THRU BORE


CHAIN PITCH

Fig. 6446 Fig. 6450

MAXIMUM BORE

Type A

Number of teeth





6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23

3.000 3.457 3.920 4.386 4.854 5.324 5.796 6.268 6.741 7.215 7.689 8.163 8.638 9.113 9.589 10.064 10.540 11.016

2.125 2.582 3.045 3.511 3.979 4.449 4.921 5.393 5.866 6.340 6.814 7.288 7.763 8.238 8.714 9.189 9.665 10.141

3.500 4.020 4.520 5.020 5.520 6.010 6.500 6.990 7.470 7.960 8.440 8.920 9.410 9.890 10.370 10.850 11.330 11.810

1.81 2.33 2.83 3.33 3.83 4.33 4.81 5.30 5.78 6.27 6.75 7.23 7.72 8.20 8.69 9.17 -

Type B Maximum bore with standard keyseat, inches s 1.250 1.563 1.934 2.313 2.750 3.125 3.563 3.813 4.125 4.500 4.688 5.250 5.563 5.938 6.188 6.438 -

Hub length thru bore

Type C

S max., inches

Number of teeth

.750 .969 1.219 1.469 1.688 1.938 2.219 2.375 2.563 2.750 2.969 3.250 3.469 3.719 3.844 3.969 -

24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40


Fig. 8382




Tooth dimensions

Sprocket Type

Number of teeth


Sprocket Type

Number of teeth


B

6 to 15 16 to 25 26 to 40

1.25 1.50 1.75

C

10 to 20 21 to 40

2.25 2.50

T = .459" + .000", –.011" for machined sprockets. T = .459" + .000", –.036" for hot rolled steel plate sprockets or unfinished forgings.


(7010) E-15

E

Sprockets


C 2080H sprockets 2.000" pitch T

OUTSIDE DIAMETER

ROOT DIAMETER

S

PIITCH DIAMETER

T

CHAIN PITCH

E

CHAIN PITCH

T

LENGTH THRU BORE


CHAIN PITCH

Fig. 6446 Fig. 6450

MAXIMUM BORE


Pitch dia., inches

Root dia., inches



4.000 4.304 4.610 4.917 5.226 5.536 5.848 6.160 6.472 6.785 7.099 7.413 7.727 8.042 8.357 8.672 8.988 9.304 9.620 9.936 10.252 10.568 10.885 11.201 11.518 11.834 12.151 12.467 12.785 13.102 13.419 13.736 14.053 14.371 14.688

3.375 3.679 3.985 4.292 4.601 4.911 5.223 5.535 5.847 6.160 6.474 6.788 7.102 7.417 7.732 8.047 8.363 8.679 8.995 9.311 9.627 9.943 10.260 10.576 10.893 11.209 11.526 11.842 12.160 12.477 12.794 13.111 13.428 13.746 14.063

4.332 4.636 4.982 5.289 5.627 5.937 6.271 6.583 6.914 7.227 7.556 7.870 8.195 8.510 8.835 9.150 9.476 9.792 10.115 10.431 10.753 11.069 11.392 11.708 12.030 12.346 12.668 12.984 13.306 13.623 13.944 14.261 14.581 14.899 15.219

2.42 2.78 3.11 3.45 3.80 4.13 4.45 4.80 5.13 5.45 5.78 6.09 6.42 6.75 7.08 7.41 7.72 8.05 8.35 8.69 9.02 9.34 9.66 9.98 10.31 10.63 10.95 11.27 11.59 11.91 12.23 12.55 12.88 13.19 13.52

h

6 61/2 7 71/2 8 81/2 9 91/2 10 101/2 11 111/2 12 121/2 13 131/2 14 141/2 15 151/2 16 161/2 17 171/2 18 181/2 19 191/2 20 201/2 21 211/2 22 221/2 23

Type A Maximum bore with standard keyseat, inches s 1.625 1.750 2.063 2.250 2.688 3.000 3.250 3.500 3.750 3.938 4.250 4.500 4.625 4.688 4.938 5.063 5.250 5.500 5.688 5.875 6.188 6.813 7.375 7.688 7.938 8.188 8.438 8.875 9.313 9.438 9.563 9.688 9.813 9.875 -

S max., inches


1.000 1.063 1.281 1.375 1.688 1.875 2.031 2.188 2.313 2.438 2.625 2.750 2.875 2.969 3.094 3.156 3.250 3.438 3.594 3.688 3.844 4.156 4.500 4.719 4.844 4.969 5.094 5.313 5.531 5.594 5.656 5.719 5.875 5.938 -

231/2 24 241/2 25 251/2 26 261/2 27 271/2 28 281/2 29 291/2 30 301/2 31 311/2 32 321/2 33 331/2 34 35 36 37 38 39 40 41 42 43 44 45 46 47



B

6 to 71/2 8 to 12 121/2 to 181/2 19 to 30 301/2 to 44 45 to 72 73 to 80

1.38 1.63 1.88 2.13 2.38 2.63 2.75

Fig. 8382

Type C

Pitch dia., inches

Root dia., inches



15.005 15.323 15.640 15.958 16.275 16.593 16.910 17.228 17.545 17.863 18.180 18.498 18.816 19.134 19.451 19.769 20.087 20.405 20.723 21.040 21.358 21.676 22.312 22.947 23.583 24.219 24.855 25.491 26.127 26.763 27.399 28.035 28.671 29.307 29.943

14.380 14.698 15.015 15.333 15.650 15.968 16.285 16.603 16.920 17.238 17.555 17.873 18.191 18.509 18.826 19.144 19.462 19.780 20.098 20.415 20.733 21.051 21.687 22.322 22.958 23.594 24.230 24.866 25.502 26.138 26.774 27.410 28.046 28.682 29.318

15.536 15.858 16.175 16.495 16.812 17.133 17.450 17.770 18.087 18.406 18.723 19.044 19.362 19.681 19.998 20.318 20.636 20.956 21.274 21.592 24.910 22.230 22.870 23.500 24.140 24.780 25.410 26.050 26.690 27.330 27.960 28.600 29.240 29.870 30.510

48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80

h


Type B

Pitch dia., inches

Root dia., inches


30.580 31.216 31.852 32.488 33.124 33.761 34.397 35.033 35.669 36.306 36.942 37.578 38.215 38.851 39.487 40.124 40.760 41.396 42.033 42.669 43.306 43.942 44.578 45.215 45.851 46.488 47.124 47.760 48.397 49.033 49.670 50.306 50.943

29.955 30.591 31.227 31.863 32.499 33.136 33.772 34.408 35.044 35.681 36.317 39.953 37.590 38.226 38.862 39.499 40.135 40.771 41.408 42.044 42.681 43.371 43.953 44.590 45.226 45.863 46.499 47.135 47.772 48.408 49.045 49.681 50.318

31.25 31.78 32.42 33.06 33.69 34.33 34.97 35.61 36.24 36.88 37.52 38.15 38.79 39.43 40.06 40.70 41.34 41.97 42.61 43.24 43.88 44.52 45.16 45.79 46.43 47.07 47.70 48.34 48.98 49.61 50.25 50.89 51.53

h



C



9 to 18 181/2 to 32 321/2 to 40 41 to 60 61 to 72 73 to 80

2.50 3.00 3.25 3.50 4.00 4.25



E-16 (7010)


Sprockets for large diameter roller chains can be furnished only with the actual number of teeth required. T

PIITCH DIAMETER

OUTSIDE DIAMETER

CHAIN PITCH

S

ROOT DIAMETER

T

CHAIN PITCH

T

LENGTH THRU BORE


CHAIN PITCH

Fig. 6446 Fig. 6450

MAXIMUM BORE

Type A

Number of teeth





6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23

4.000 4.610 5.226 5.848 6.472 7.099 7.727 8.357 8.988 9.620 10.252 10.885 11.518 12.151 12.785 13.419 14.053 14.688

2.875 3.485 4.101 4.723 5.347 5.974 6.602 7.232 7.863 8.495 9.127 9.760 10.393 11.026 11.660 12.294 12.928 13.563

4.660 5.350 6.030 6.700 7.360 8.010 8.660 9.320 9.960 10.610 11.260 11.900 12.540 13.190 13.830 14.470 15.110 15.750

2.42 3.11 3.80 4.45 5.13 5.78 6.42 7.08 7.72 8.38 9.02 9.66 10.31 10.95 11.59 12.23 -

Type B Maximum bore with standard keyseat, inches s 1.625 2.063 2.688 3.250 3.750 4.250 4.625 4.938 5.250 5.688 6.188 7.375 7.938 8.438 9.313 9.563 -


Number of teeth


B

6 to 7 8 to 12 13 to 18 19 to 30 31 to 40

1.38 1.63 1.88 2.13 2.38

Fig. 8382

Type C

S max., inches

Number of teeth

1.000 1.281 1.688 2.031 2.313 2.625 2.875 3.094 3.250 3.594 3.844 4.500 4.844 5.094 5.531 5.656 -

24 25 26 27 28. 29 30 31 32 33 34 35 36 37 38 39 40






Number of teeth


C

9 to 18 19 to 32 33 to 40

2.50 3.00 3.25



(7010) E-17

E

Sprockets are usually furnished with twice the required number of teeth, virtually doubling sprocket life. Sprockets with only the required number of teeth, can also be furnished.

Sprockets


OUTSIDE DIAMETER

PIITCH DIAMETER

S

ROOT DIAMETER

T

CHAIN PITCH

E

CHAIN PITCH

T

LENGTH THRU BORE


CHAIN PITCH

Fig. 6446 Fig. 6450

MAXIMUM BORE


Type A

Pitch dia., inches

Root dia., inches



5.000 5.380 5.762 6.146 6.523 6.920 7.130 7.700 8.090 8.481 8.872 9.266 9.660 10.053 10.447 10.840 11.235 11.630 12.025 12.420 12.815 13.210 13.605 14.001 14.397 14.793 15.190 15.584 15.982 16.378 16.775 17.170

4.250 4.630 5.012 5.396 5.782 6.170 6.560 6.950 7.340 7.731 8.122 8.516 8.910 9.303 9.697 10.090 10.485 10.880 11.275 11.670 12.065 12.460 12.855 13.251 13.647 14.043 14.440 14.834 15.232 15.628 16.025 16.420

5.415 5.795 6.227 6.611 7.034 7.422 7.839 8.229 8.642 9.033 9.442 9.836 10.245 10.638 11.045 11.438 11.845 12.240 12.644 13.039 13.442 13.837 14.239 14.635 15.038 15.434 15.836 16.230 16.633 17.029 17.431 17.826

3.11 3.55 3.97 4.39 4.81 5.23 5.64 6.06 6.47 6.88 7.27 7.70 8.05 8.52 8.83 9.33 9.63 10.13 10.41 10.94 11.20 11.75 12.00 12.55 12.78 13.36 13.58 14.16 14.38 14.97 15.16 -

h

6 61/2 7 71/2 8 81/2 9 91/2 10 101/2 11 111/2 12 121/2 13 131/2 14 141/2 15 151/2 16 161/2 17 171/2 18 181/2 19 191/2 20 201/2 21 211/2

Type B Maximum bore with standard keyseat, inches s 2.063 2.375 2.625 3.000 3.375 3.688 4.000 4.438 4.750 5.125 5.500 5.750 5.875 6.063 6.188 6.313 6.750 7.188 7.438 7.750 8.000 8.375 8.750 9.063 -



B

6 to 61/2 7 to 9 91/2 to 19 191/2 to 261/2 27 to 34 35 to 40

Hub length, thru bore, inches 1.50 1.75 2.00 2.25 2.50 2.75

S max., inches

Fig. 8382

Type C Number of effective teeth

Pitch dia., inches

Root dia., inches


17.567 17.964 18.360 18.756 19.152 19.550 19.947 20.344 20.740 21.138 21.535 21.931 22.330 22.725 23.122 23.520 23.917 24.314 24.712 25.109 25.505 25.904 26.300 27.095 27.890 28.685 29.480 30.275 31.070 31.865

16.817 17.214 17.610 18.006 18.402 18.800 19.197 19.594 19.990 20.388 20.785 21.181 21.580 21.975 22.372 22.770 23.167 23.564 23.962 24.359 24.755 25.154 25.550 26.345 27.140 27.935 28.730 29.525 30.320 31.115

18.228 18.625 19.024 19.420 19.820 20.218 20.619 21.016 21.415 21.813 22.212 22.608 23.010 23.405 23.805 24.203 24.602 24.999 25.399 25.796 26.194 26.593 26.991 27.788 28.580 29.380 30.180 30.970 31.770 32.570

h

1.281 1.469 1.625 1.844 2.094 2.281 2.469 2.719 3.000 3.188 3.375 3.625 3.688 3.781 3.844 4.000 4.156 4.344 4.469 4.750 4.875 5.063 5.219 5.406 -

22 221/2 23 231/2 24 241/2 25 251/2 26 261/2 27 271/2 28 281/2 29 291/2 30 301/2 31 311/2 32 321/2 33 34 35 36 37 38 39 40



C

Number of effective teeth 71/2 to 13 131/2 to 20 201/2 to 30 301/2 to 36 37 to 40



3.00 3.25 3.50 3.75 4.00

Standard bore tolerances, keyseat dimensions, eccentricity tolerances, and similar data, page G-2. h “Effective” describes the number of teeth that engage the chain rollers during each revolution of the sprocket. See Fig. 8382 above. The effective number is used to calculate chain speed. Sprockets are normally furnished with twice the effective number listed. When the actual number of teeth is 24 or more, sprockets for No. 100 roller chain may be used. See page C-23. ∆ Non-functional dimension that may vary with the type of cutter used. s Based on maximum hub diameter.

E-18 (7010)

C 2102H sprockets 2.500" pitch


T

OUTSIDE DIAMETER

ROOT DIAMETER

CHAIN PITCH

S

PIITCH DIAMETER

T

CHAIN PITCH

T

LENGTH THRU BORE


CHAIN PITCH

Fig. 6446 Fig. 6450

MAXIMUM BORE

Type A

Number of teeth





6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23

5.000 5.762 6.532 7.310 8.090 8.872 9.660 10.447 11.235 12.025 12.815 13.605 14.397 15.190 15.982 16.775 17.567 18.360

3.438 4.200 4.970 5.748 6.528 7.310 8.098 8.885 9.673 10.463 11.253 12.043 12.835 13.628 14.420 15.213 16.005 16.798

5.830 6.690 7.540 8.370 9.300 10.020 10.830 11.640 12.460 13.260 14.070 14.870 15.680 16.480 17.290 18.090 18.890 19.690

3.11 3.97 4.81 5.64 6.47 7.27 8.05 8.83 9.63 10.41 11.20 12.00 12.78 13.58 14.38 15.16 -

Type B Maximum bore with standard keyseat, inches s 2.063 2.625 3.375 4.000 4.750 5.500 5.875 6.188 6.750 7.138 8.000 8.750 -


Number of teeth


B

6 7 to 9 10 to 19 20 to 26 27 to 34 35 to 40

1.50 1.75 2.00 .25 2.50 2.75

Type C

S max., inches

Number of teeth

1.281 1.625 2.094 2.469 3.000 3.375 3.688 3.844 4.156 4.469 4.875 5.219 -

24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40


Fig. 8382





C

Number of teeth


8 to 13 14 to 20 21 to 30 31 to 36 37 to 40

3.00 3.25 3.50 3.75 4.00



(7010) E-19

E

Sprockets



OUTSIDE DIAMETER

ROOT DIAMETER

S

PIITCH DIAMETER

T

CHAIN PITCH

E

LENGTH THRU BORE

CHAIN PITCH

T


CHAIN PITCH

Fig. 6446 Fig. 6450

MAXIMUM BORE


Type A

Pitch dia., inches

Root dia., inches



6.000 6.456 6.915 7.376 7.839 8.304 8.772 9.240 9.708 10.178 10.649 11.120 11.591 12.063 12.536 13.008 13.482 13.956 14.430 14.904 15.378 15.852 16.328 16.802 17.277 17.751 18.227 18.701 19.178 19.653 20.129 20.604

5.125 5.581 6.040 6.501 6.964 7.429 7.897 8.365 8.833 9.303 9.774 10.245 10.716 11.188 11.661 12.133 12.607 13.081 13.555 14.029 14.503 14.977 15.453 15.927 16.402 16.876 17.352 17.826 18.303 18.778 19.254 19.729

6.498 6.954 7.473 7.934 8.440 8.905 9.407 9.875 10.370 10.840 11.333 11.804 12.293 12.765 13.254 13.726 14.213 14.687 15.172 15.646 16.130 16.604 17.089 17.563 18.046 18.520 19.003 19.477 19.958 20.434 20.916 21.391

3.66 4.19 4.69 5.20 5.70 6.20 6.70 7.20 7.70 8.19 8.69 9.17 9.66 10.14 10.64 11.13 11.61 12.09 12.58 13.06 13.58 14.03 14.52 15.00 15.48 15.95 16.44 16.92 17.41 17.89 18.36 -

h

6 61/2 7 71/2 8 81/2 9 91/2 10 101/2 11 111/2 12 121/2 13 131/2 14 141/2 15 151/2 16 161/2 17 171/2 18 181/2 19 191/2 20 201/2 21 211/2

Maximum bore with standard keyseat, inches s 2.438 2.875 3.188 3.750 4.188 4.563 4.938 5.375 5.750 6.125 6.438 6.625 6.875 7.125 7.500 7.875 8.250 8.625 9.125 9.625 9.938 -



B

6 61/2 to 8 81/2 to 17 171/2 to 26 261/2 to 36 37 to 40

2.00 2.25 2.50 2.75 3.00 3.25

S max., inches

Fig. 8382

Type C Number of effective teeth

Pitch dia., inches

Root dia., inches


21.080 21.557 22.032 22.508 22.985 23.460 23.937 24.413 24.890 25.365 25.842 26.318 26.795 27.270 27.747 28.224 28.701 29.177 29.654 30.131 30.608 31.085 31.560 32.514 33.468 34.421 35.375 36.329 37.283 38.237

20.205 20.682 21.157 21.633 22.110 22.585 23.062 23.538 24.015 24.490 24.967 25.443 25.920 26.395 26.872 27.349 27.826 28.302 28.779 29.256 29.733 30.210 30.685 31.639 32.593 33.546 34.500 35.454 36.408 37.362

21.872 22.369 22.829 23.3058 23.787 24.262 24.743 25.219 25.700 26.175 26.654 27.130 27.611 28.086 28.565 29.042 29.523 29.999 30.478 30.955 31.435 31.912 32.389 33.345 34.300 35.260 36.210 37.170 38.120 39.080

h

1.531 1.781 1.969 2.344 2.594 2.781 3.031 3.313 3.563 3.813 3.969 4.125 4.188 4.313 4.563 4.813 4.906 5.125 5.438 5.688 5.938 -

22 221/2 23 231/2 24 241/2 25 251/2 26 261/2 27 271/2 28 281/2 29 291/2 30 301/2 31 311/2 32 321/2 33 34 35 36 37 38 39 40

Consult Rexnord.

Tooth dimensions


Type B

Sprocket Type

C



7 to 18 181/2 to 23 231/2 to 30 301/2 to 36 37 to 40

3.50 3.75 4.00 4.25 4.50


Standard bore tolerances, keyseat dimensions, eccentricity tolerances, and similar data, page G-2. h “Effective” describes the number of teeth that engage the chain rollers during each revolution of the sprocket. See Fig. 8382 above. The effective number is used to calculate chain speed. Sprockets are normally furnished with twice the effective number listed. When the actual number of teeth is 24 or more, sprockets for No. 120 roller chain may be used. See page C-25 for sprocket data. ∆ Non-functional dimension that may vary with the type of cutter used. s Based on maximum hub diameter.

E-20 (7010)



T

PIITCH DIAMETER

OUTSIDE DIAMETER

CHAIN PITCH

S

ROOT DIAMETER

T

LENGTH THRU BORE

CHAIN PITCH

T


CHAIN PITCH

Fig. 6446 Fig. 6450

MAXIMUM BORE

Type A

Type B

Number of teeth





6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23

6.000 6.915 7.839 8.772 9.708 10.649 11.591 12.536 13.482 14.430 15.378 16.328 17.277 18.227 19.178 20.129 21.080 22.032

4.250 5.164 6.089 7.022 7.958 8.899 9.841 10.786 11.732 12.680 13.628 14.578 15.527 16.477 17.428 18.379 19.330 20.282

7.000 8.030 9.040 10.042 11.033 12.017 12.996 13.971 14.945 15.914 16.883 17.849 18.815 19.778 20.742 21.705 22.665 23.627

3.66 4.69 5.70 6.70 7.70 8.69 9.66 10.64 11.61 12.58 13.58 14.52 15.48 16.44 17.41 18.36 -

Maximum bore with standard keyseat, inches s 2.438 3.188 4.188 4.938 5.750 6.438 6.875 7.500 8.250 9.125 9.938 -


Number of teeth


B

6 7 to 8 9 to 17 18 to 26 27 to 36 37 to 40

2.00 2.25 2.50 2.75 3.00 3.25

Type C

S max., inches

Number of teeth

1.531 1.969 2.594 3.031 3.563 3.969 4.188 4.563 4.906 5.438 5.938 -

24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40

Fig. 8382






C

Number of teeth


7 to 18 19 to 23 24 to 30 31 to 36 37 to 40

3.50 3.75 4.00 4.25 4.50



(7010) E-21

E

Sprockets



OUTSIDE DIAMETER

ROOT DIAMETER

S

PIITCH DIAMETER

T

CHAIN PITCH

E

LENGTH THRU BORE

CHAIN PITCH

T


CHAIN PITCH

Fig. 6446 Fig. 6450

MAXIMUM BORE


Type A

Pitch dia., inches

Root dia., inches



8.000 8.608 9.220 9.834 10.452 11.072 11.696 12.320 12.944 13.570 14.198 14.826 15.454 16.084 16.714 17.344 17.976 18.608 19.240 19.872 20.504 21.136 21.770 22.402 23.039 23.668 24.302 29.934

6.875 7.483 8.095 8.709 9.327 9.947 10.571 11.195 11.819 12.445 13.073 13.701 14.329 14.959 15.589 16.219 16.851 17.483 18.115 18.747 19.379 20.011 20.645 21.277 21.941 22.543 23.177 23.809

8.664 9.272 9.963 10.577 11.252 11.874 12.543 13.167 13.827 14.453 15.110 15.738 16.391 17.021 17.671 18.305 18.951 19.583 20.229 20.861 21.507 22.139 22.784 23.416 24.061 24.693 25.336 25.968

4.891 5.578 6.266 6.953 7.625 8.281 8.953 9.609 10.266 10.938 11.578 12.234 12.891 13.547 14.155 14.844 15.484 16.141 16.781 17.422 18.078 18.719 19.359 20.000 20.650 21.297 21.938 22.578

h

6 61/2 7 71/2 8 81/2 9 91/2 10 101/2 11 111/2 12 121/2 13 131/2 14 141/2 15 151/2 16 161/2 17 171/2 18 181/2 19 191/2

Type B Maximum bore with standard keyseat, inches s 3.438 3.750 4.250 4.938 5.500 6.125 6.313 6.875 7.188 7.750 8.250 8.625 9.125 9.938 -




B

6 61/2 to 71/2 8 to 121/2 13 to 171/2 18 to 251/2 26 to 34

2.25 2.50 2.75 3.00 3.25 3.50

Type C

S max., inches


Fig. 8382

Pitch dia., inches

Root dia., inches

h

2.156 2.344 2.625 3.031 3.375 3.813 3.969 4.188 4.344 4.750 4.906 5.125 5.438 5.938 -

20 201/2 21 211/2 22 221/2 23 231/2 24 241/2 25 251/2 26 261/2 27 271/2 28 281/2 29 291/2 30 301/2 31 311/2 32 321/2 33 331/2 34

25.570 24.445 26.204 25.079 26.839 25.713 27.472 26.347 28.106 26.981 28.742 27.617 29.376 28.251 30.010 28.885 30.646 29.521 31.280 30.155 31.916 30.791 32.550 31.425 33.186 32.061 33.820 32.695 34.456 33.331 35.090 33.965 36.360 35.235 36.360 35.235 36.996 36.871 37.632 36.507 38.268 37.143 38.902 37.777 39.538 38.413 40.174 39.049 40.810 39.685 41.446 40.321 42.080 40.955 42.716 41.591 43.352 42.227 Larger sizes available.

Outside dia., inches ∆ 26.613 27.247 27.889 28.523 29.163 29.799 30.439 31.037 61.715 32.349 32.990 33.624 34.264 34.898 35.539 36.173 37.448 37.448 38.088 38.724 39.363 39.997 40.637 41.273 41.941 42.547 43.185 43.821 44.460


C



6 to 131/2 14 to 181/2 19 to 23 231/2 to 24

4.00 4.25 4.50 5.00

T = 1.156" + .000", –.019" for machined sprockets. T=1 .156" + .000", –.062" for hot rolled plate sprockets or unfinished forgings.


E-22 (7010)


Sprockets for large diameter roller chains can also be furnished only with the actual number of teeth required.

T

OUTSIDE DIAMETER

PIITCH DIAMETER

CHAIN PITCH

S

ROOT DIAMETER

T

LENGTH THRU BORE

CHAIN PITCH

T


CHAIN PITCH

Fig. 6446 Fig. 6450

MAXIMUM BORE

Type A

Type B

h





6 7 8 9 10 11 12 13 14 15 16 17 18 19

8.000 9.220 10.452 11.696 12.944 14.198 15.454 16.714 17.976 19.240 20.504 21.770 23.036 24.302

5.750 6.970 8.202 9.446 10.694 11.948 13.204 14.464 15.726 16.990 18.254 19.520 20.786 22.053

9.33 10.71 12.06 13.39 14.71 16.02 17.33 18.63 19.93 21.22 22.51 23.80 25.08 26.37

4.891 6.266 7.625 8.953 10.266 11.578 12.891 14.188 15.484 16.781 18.078 19.359 20.650 21.938

Number of teeth

Maximum bore with standard keyseat, inches s 3.438 4.250 5.500 6.313 7.188 8.250 9.125 -


Number of teeth


B

6 7 8 to 12 13 to 17 18 to 25 26 to 34

2.25 2.50 2.75 3.00 3.25 3.50

Fig. 8382

Type C

S max., inches

Number of teeth

2.156 2.625 3.375 3.969 4.344 4.906 5.438 -

20 21 22 23 24 25 26 27 28 29 30 31 32 33 34

h



25.570 23.320 26.838 24.588 28.106 25.856 29.376 27.126 30.646 28.396 31.916 29.666 33.186 30.936 34.456 32.206 35.726 33.476 36.996 34.746 38.268 36.018 39.538 37.288 40.810 38.560 42.080 39.830 43.352 41.102 Larger sizes available.

Outside diameter, inches ∆ 27.66 28.94 30.22 31.50 32.78 34.06 35.34 36.62 37.90 39.18 40.46 41.74 43.01 44.29 45.57


C

Number of teeth


6 to 13 14 to 18 19 to 23 24 to 24

4.00 4.25 4.50 5.00

T = 1.156" + .000", –.019" for machined sprockets. T=1 .156" + .000", –.062" for hot rolled plate sprockets or unfinished forgings.


(7010) E-23

E

E

NOTES

E-24 (7010)

Link-Belt and Rexnord British Standard Roller Chain Single Strand (DIN 8187/ISO 606) T

G

E

PITCH

D

C F

A

B

Fig. 6453

Pitch ISO No.

Bearing Area

Required Ultimate Strength min

Weight

Dimensions, Millimeters

inch

mm

cm2

N

Lb/ft

A max mm

B max mm

C max mm

D max mm

E min mm

G max mm

T min mm

04

0.236

6.0

0.08

3,000

0.08

7.4

10.3

1.85

4.0

2.8

5.0

4.1

05 B - 1

0.315

8.0

0.11

5,000

0.12

8.6

11.7

2.31

5.0

3.0

7.1

4.77

06 B - 1

0.375

9.525

0.28

9,000

0.28

13.5

16.8

3.28

6.35

5.72

8.3

8.53

081

0.50

12.7

0.21

8,200

0.19

10.2

11.7

3.66

7.75

3.3

9.9

5.80

083

0.50

12.7

0.32

12,000

0.28

12.9

14.4

4.09

7.75

4.88

10.3

7.9

084

0.50

12.7

0.326

16,000

0.40

14.8

16.3

4.09

7.75

4.88

11.1

8.8

085

0.50

12.7

0.32

6,800

0.26

14.0

16.0

3.58

7.77

6.38

9.9

9.07

08 B - 1

0.50

12.7

0.50

18,000

0.47

17.0

19.0

4.45

8.51

7.75

11.6

11.3

10 B - 1

0.625

15.875

0.67

22,400

0.60

19.6

22.0

5.08

10.16

9.65

14.6

13.28

12 B - 1

0.75

19.05

0.89

29,000

0.77

22.7

25.1

5.72

12.07

11.68

15.9

15.62

16 B - 1

1.00

25.4

2.1

60,000

1.75

36.1

42.4

8.28

15.88

17.02

20.5

25.4

20 B - 1

1.25

31.75

2.96

95,000

2.49

40.4

47.6

10.19

19.05

19.56

25.7

29.0

24 B - 1

1.50

38.1

5.54

160,000

4.64

53.8

60.6

14.63

25.4

25.4

33.0

37.9

28 B - 1

1.75

44.45

7.39

200,000

5.78

63.3

72.8

15.90

27.94

3.99

37.0

46.5

32 B - 1

2.00

50.8

8.1

250,000

6.38

65.1

73.6

17.81

29.21

30.8

41.2

45.5

40 B - 1

2.50

63.5

12.75

355,000

10.15

78.9

91.3

22.89

39.37

38.1

51.5

55.7

48 B - 1

3.00

76.2

20.61

560,000

16.46

98.5

124.0

29.24

48.26

45.72

63.5

70.5

56 B - 1

3.50

88.9

27.90

850,000

24.53

114.7

140.0

34.32

53.98

53.34

77.0

81.3

Dimensions subject to change. Certified dimensions of ordered material furnished on request. Minimum order quantities may be required on some parts. Other sizes available upon request.

(7010) F-1

F

F

Double Strand (DIN 8187/ISO 606) G

K

T

E

PITCH

D C F

B

A

Fig. 6445

Pitch ISO No.

06 B - 2 08 B - 2 10 B - 2 12 B - 2 16 B - 2 20 B - 2 24 B - 2 28 B - 2 32 B - 2 40 B - 2 48 B - 2 56 B - 2

Bearing Area


Weight


inch

mm

cm2

N

Lb/ft

A max mm

B max mm

C max mm

D max mm

E min mm

G max mm

K mm

T min mm

0.375 0.50 0.625 0.75 1.00 1.25 1.50 1.75 2.00 2.50 3.00 3.50

9.525 12.7 15.875 19.05 25.4 31.75 38.1 44.45 50.8 63.5 76.2 88.9

0.56 1.01 1.34 1.79 4.21 5.91 11.09 14.79 16.21 25.5 41.23 55.8

16,900 32,000 44,500 57,800 106,000 170,000 280,000 360,000 450,000 630,000 1,000,000 1,600,000

0.52 0.94 1.21 1.55 3.56 4.87 9.24 11.63 12.63 20.09 32.66 48.72

23.8 31.0 36.2 42.2 68.0 76.9 102.2 122.8 123.6 151.2 189.7 221.3

27.1 33.0 38.6 44.4 74.0 83.6 112.7 132.7 132.4 163.8 215.2 246.5

3.28 4.45 5.08 5.72 8.28 10.19 14.63 15.90 17.81 22.89 29.24 34.32

6.35 8.51 10.16 12.07 15.88 1905 25.4 27.94 29.21 39.37 48.26 53.98

5.72 7.75 9.65 11.68 17.02 19.56 25.4 30.99 30.8 38.1 45.72 53.34

8.2 11.6 14.6 15.9 20.5 25.7 33.0 37.0 41.2 51.5 63.5 77.0

10.24 13.92 16.59 19.46 31.88 36.45 48.36 59.56 58.55 72.29 91.21 106.6

8.53 11.3 13.28 15.62 25.4 29.0 37.9 46.5 45.5 55.7 70.5 81.3

K

T

Triple Strand (DIN 8187/ISO 606)

G

K

E

PITCH

D

C F

Pitch ISO No.

06 B - 3 08 B - 3 10 B - 3 12 B - 3 16 B - 3 20 B - 3 24 B - 3 28 B - 3 32 B - 3 40 B - 3 48 B - 3 56 B - 3

F-2 (7010)

Bearing Area


Weight

B

A

Fig. 6446


inch

mm

cm2

N

Lb/ft

A max mm

B max mm

C max mm

D max mm

E min mm

G max mm

K mm

T min mm

0.375 0.5 0.625 0.75 1 1.25 1.5 1.75 2 2.5 3 3.5

9.525 12.7 15.875 19.05 25.4 31.75 38.1 44.45 50.8 63.5 76.2 88.9

0.84 1.51 2.02 2.68 6.31 8.87 16.63 22.18 24.31 38.25 61.84 83.71

24,900 47,500 66,700 86,700 160,000 250,000 425,000 530,000 670,000 950,000 1,500,000 2,240,000

0.79 1.41 1.75 2.28 5.24 7.29 13.78 17.3 18.78 30.1 48.72 73.24

34 44.9 52.8 61.7 99.9 113.4 150.5 182.3 182.2 223.5 281 328

37.3 47.2 55.6 65.2 107.2 121.2 160.4 192.2 181 236.1 306.5 353.2

3.28 4.45 5.08 5.72 8.28 10.19 14.63 15.9 17.81 22.89 29.24 34.32

6.35 8.51 10.16 12.07 15.88 1905 25.4 27.94 29.21 39.37 48.26 53.98

5.72 7.75 9.65 11.68 17.02 19.56 25.4 30.99 30.8 38.1 45.72 53.34

8.3 11.6 14.6 15.9 20.5 25.7 33 37 41.2 51.5 63.5 77

10.24 13.92 16.59 19.46 31.88 36.45 48.36 59.56 58.55 72.29 91.21 106.6

8.53 11.3 13.28 15.62 25.4 29 37.9 46.5 45.5 55.7 70.5 81.3


G

K

K

K

T

F

Metric Standard T

G

E

PITCH

D

C F

A

B

Fig. 6453

Pitch ISO No.

Re 217 Re 317 Re 425 Re 480 Re 487 He 488 Re 514 Re 516 Re 519 Rz 519 Re 525 Re 626

Bearing Area


Weight


inch

mm

cm2

N

Lb/ft

A max mm

B max mm

C max mm

D max mm

E min mm

G max mm

K mm

T min mm

0.5 0.625 0.75 0.75 0.787 0.787 1 1 1 1 1 1.18

12.7 15.875 19.05 19.05 20 20 25.4 25.4 25.4 25.4 25.4 30

0.44 0.51 1.12 1.05 1.35 1.8 1.33 1.74 2.29 4.58 1.33 2.1

18,000 23,600 33,500 40,000 35,500 35,500 45,000 63,000 80,000 160,000 45,000 63,000

0.45 0.54 1.05 0.97 1.34 1.34 1.17 1.61 2.12 4.2 1.07 1.57

15.4 16 27 25 32.1 32.5 27.3 30.8 36 67.8 27.4 35.5

18.9 20 31.8 29.5 35.9 37.3 33.1 37.6 39.8 72 32.5 41.9

4.45 5.08 5.72 6.1 6 8 7 8.28 9 9 7 8.28

8.51 10.16 12.07 12.07 12 12.01 14 15.88 15.88 15.88 12.7 15.88

6.4 6.48 13.5 11.68 16 16 12.7 12.71 17.02 17.02 12.7 17.02

11.6 14.7 16.8 16.8 19 19 19.7 20.6 24.1 24.1 20.8 20.5

31.88 -

9.93 10.08 19.4 17.23 22.5 22.5 19.07 21.07 25.4 25.4 19.07 25.4


(7010) F-3

F

Roller Chains for Heavy Drives and Lifting Applications T

G

E

PITCH

CHAIN PITCH

D

C F

B

A

Fig. 6553A

Fig. 6453

Pitch ISO No. inch

mm

Bearing Area


Weight

cm2

N

Lb/ft

Dimensions, Millimeters CHAIN PITCH

A max mm

B max mm

C max mm

D max mm

E min mm

G max mm

T min mm 25.7

KRV 12

1

25.4

2.61

117,500

2.96

40.1

-

10.19

19.5

12.7

24

R 38 SH

1.5

38.1

5.85

235,000

5.24

56.7

-

14.63

25.4

25.4

37.2

40

R 44 SH

1.75

44.45

7.39

270,000

6.59

66.3

-

15.9

27.94

30.99

40.8

46.5

Fig. 6553B

British Standard with Straight Link Plates C

D

B

PITCH

E T A

PITCH G

Fig. 5074b

Pitch ISO No.

06 B - 1 GL 06 B - 2 GL 8 B - 1 GL 10 B - 1 GL 10 B - 2 GL 12 B - 1 GL 12 B - 2 GL 16 B - 1 GL 16 B - 2 GL 20 B - 1 GL 24 B - 1 GL 32 B - 1 GL

F-4 (7010)

Bearing Area


Weight


inch

mm

cm2

N

Lb/ft

A max mm

B max mm

C max mm

D max mm

E min mm

G max mm

K mm

T min mm

0.375 0.375 0.5 0.625 0.625 0.75 0.75 1 1 1.25 1.5 2

9.525 9.525 12.7 15.875 15.875 19.05 19.05 25.4 25.4 31.75 38.1 50.8

0.28 0.56 0.5 0.67 1.34 0.89 1.79 2.1 4.21 2.96 5.54 7.1

9,000 16,000 18,000 22,400 44,500 29,000 57,800 60,000 106,000 95,000 160,000 250,000

0.28 0.52 0.5 0.67 1.28 0.89 1.75 1.92 3.9 2.69 5.04 6.99

12.8 23.1 17 18.9 35.5 22.3 41.7 35.4 37.4 40.4 53.8 65.1

15.8 26 19 22 38.6 25.1 44.4 42.4 74 47.6 60.6 73.6

3.28 3.28 4.45 5.08 5.08 5.72 5.72 8.28 8.28 10.19 14.63 17.81

6.35 6.35 8.51 10.16 10.16 12.07 12.07 15.88 15.88 19.05 25.4 29.21

5.72 5.72 7.75 9.65 9.65 11.68 11.68 17.02 17.02 19.56 25.4 30.8

8.1 8.1 12 13.9 13.9 15.9 15.9 20.3 20.3 25.8 33 41.2

10.24 16.59 19.46 31.88 -

8.53 8.53 11.3 13.28 13.28 15.62 15.62 25.4 25.4 29 37.9 45.5


Link-Belt and Rexnord British Standard Roller Chain with Thermoplastic Bearings Single Strand T

G

E

PITCH

D

C F

B

A Fig. 6453

Pitch ISO No.

08 B - 1 KL 10 B - 1 KL 12 B - 1 KL 16 B - 1 KL

Bearing Area


Weight


inch

mm

cm2

N

Lb/ft

A max mm

B max mm

C max mm

D max mm

E min mm

G max mm

K mm

T min mm

0.5 0.625 0.75 1

12.7 15.875 1905 25.4

0.5 0.67 0.89 2.1

14,000 19,000 25,000 53,000

0.46 0.6 0.77 1.75

16.7 18.9 22.3 35.4

20.3 23.2 25 41.9

4.45 5.08 5.72 8.28

8.51 10.16 12.07 15.88

7.75 9.65 11.68 17.02

11.6 14.7 15.9 20.6

-

11.3 13.28 15.62 25.45

Bearing Area


Weight

Double Strand Pitch ISO No.

08 B - 2 KL 10 B - 2 KL 12 B - 2 KL 16 B - 2 KL


inch

mm

cm2

N

Lb/ft

A max mm

B max mm

C max mm

D max mm

E min mm

G max mm

K mm

T min mm

0.5 0.625 0.75 1

12.7 15.875 1905 25.4

1.01 1.34 1.79 4.21

28,000 38,000 50,000 106,000

0.86 1.16 1.53 3.43

30.6 35.5 41.7 67.4

34.3 40 45.5 73.9

4.45 5.08 5.72 8.28

8.51 10.16 12.07 15.88

7.75 9.65 11.68 17.02

11.6 14.7 15.9 20.6

13.62 16.59 19.46 31.88

11.3 13.28 15.62 25.45


(7010) F-5

F

F

Hollow Pin Chains A

E

D

W

B T

PITCH I.D.

H CONN LINK RETAINING RING TYPE RRCLK HOLLOW

PIN LINK

Single Strand Main Dimensions acc. to European and American Standard Pitch ISO No.

Bearing Area


Weight

Rivet Width

Overall Width

Bushing Diameter

Pin Diameter

Link Plate Transverse Height

Inner Width

Bushing Width W min mm

inch

mm

cm2

N

Lb/ft

A max mm

C max mm

D max mm

E max mm

I.D. mm

H max mm

K min mm

T min mm

10 B - 1 HB

0.625

15.875

1.14

17,000

0.54

19.3

21.1

10.16

5.94

4

14.7

-

13.9

9.65

12 B - 1 HB

0.75

19.05

1.06

21,000

0.74

22.4

24

12.07

6.5

4

15.9

-

16.3

11.68

Inner Width

Bushing Width W min mm

Double Strand Main Dimensions acc. to European and American Standard Pitch ISO No.

Bearing Area


Weight

Rivet Width

Overall Width

Bushing Diameter

Pin Diameter

Link Plate Transverse Height

inch

mm

cm2

N

Lb/ft

A max mm

C max mm

D max mm

E max mm

I.D. mm

H max mm

K min mm

T min mm

10 B - 2 HB

0.625

15.875

2.08

33,500

1.08

37.3

39

10.16

5.94

4

14.7

17.08

13.9

9.65

12 B - 2 HB

0.75

19.05

2.12

42,500

1.48

43

45

12.07

6.5

4

15.9

20.6

16.3

11.68

F-6 (7010)


F

Side Bow Side Bow Roller Chains, Main Dimensions acc. to European Standard (DIN 8188) A

E

D

B T

W

C

PITCH PITCH

H CONN. LINK CONN. LINK COTTER SPRING CLIP TYPE CTCLKCTP TYPE SCCLK


R

Pitch ISO No. inch

mm


Weight

Pin Width

Overall Width

Roller Diameter

Pin Diameter

Link Plate Height

Radius

Inner Width

Roller Width

N

Lb/ft

A max mm

C max mm

D max mm

E max mm

H max mm

R min

T min mm

W min mm 7.75

08 B - 1 SB

0.5

12.7

11,200

0.48

17.1

18.3

8.51

4.45

11.8

315

11.3

10 B - 1 SB

0.625

15.875

15,000

0.062

19.4

20.6

10.16

5.08

14.7

400

13.28

9.65

12 B - 1 SB

0.75

19.05

20,000

0.81

22.5

23.7

12.07

5.72

15.9

500

15.61

11.68

Connecting links and offset are also available for all the chains.


(7010) F-7

F

Double-Pitch Roller Chains A E

B

W C

D

PITCH

T

PITCH

H


CONNECTING LINK COTTER TYPE CTCLKCTP



British Standard Pitch ISO No. inch

mm

Bearing Area


Weight

Rivet Width

Overall Width

Bushing Diameter

Pin Diameter

Link Plate Height

Inner Width

Bushing Width

cm2

N

Lb/ft

A max mm

B max mm

D max mm

E max mm

H max mm

T min mm

W min mm 7.75

208 B

1

25.4

0.5

18,000

0.3

16.7

19

8.51

4.45

11.5

11.3

210 B

1.25

31.75

0.67

22,400

0.4

18.9

21.9

10.16

5.08

14.5

13.28

9.65

212 B

1.5

38.1

0.89

29,000

0.5

22.3

24.7

12.07

5.72

15.9

15.62

11.68

216 B

2

50.8

2.1

60,000

1.15

35.4

38.5

15.88

8.28

21.4

25.4

17.02

F-8 (7010)


G

Sprockets

General Specifications The standard sprockets used with Rexnord chains, both physical and dimensional, are based on sound engineering principles. They reflect the practical experience gained from applying drives over the last century.

Material and hardness Sprocket materials and tooth hardness along with accurate machining, are as important to drive life as proper chain selection or adequate lubrication. Material and hardness have a strong influence on the rate of tooth wear and, therefore, the maintenance of optimum chain and sprocket interaction. The severity and frequency of tooth loading, environment, and similar operating conditions form the basis for material selection. For example, the small sprocket is usually made of higher carbon, more wear-resistant steel because its teeth the chain more often than those on the large sprocket. The frequency of is in direct proportion to the speeds of the driving and driven shafts. With these and other operating conditions in mind, the following standards have been established.

Recommended Sprocket Materials are indicated in the table below. Material and tooth hardness recommendations are based on chain speed, number of teeth, and operating conditions. When drives are designed for short-term operation, it may be desirable to specify a lower hardness than indicated in the table.

Chain speed FPM

Number of teeth

Recommended material and hardness Normal operating conditions s

Severe operating conditions n

25 or less

Medium carbon steel with an approximate hardness of 170 Brinell

Medium carbon steel with teeth hardened to 35C Rockwell minimum

26 or more

Medium carbon steel with an approximate hardness of 170 Brinell; or cast iron with a minimum hardness of 183 Brinell

Medium carbon steel with teeth hardened to 35C Rockwell minimum; or Alloy cast iron

25 or less



26 or more

Medium carbon steel with an approximate hardness of 170 Brinell; or cast iron with a minimum hardness of 183 Brinell

Medium carbon steel with teeth hardened to 35C Rockwell minimum; or Alloy cast iron

Up to 600

Over 600

s Operating conditions are considered normal when drives are enclosed and adequately lubricated, or when open drives operated in a clean atmosphere with ample lubrication. n Operating conditions are considered severe when drives are subject to frequent heavy overloads, shock or pulsating loads, inadequate lubrication, or when open running drives operate in an abrasive or corrosive atmosphere.

(7010) G-1

G

Sprocket Reference Data Bore tolerances

Maximum face run-out tolerances

Bores will be furnished within the standard tolerances listed below, unless otherwise specified.

Root diameter of sprocket, inches

Bore diameter, inches

Tolerance, inches

Maximum bore length, inches*

Up to and including 1" 11/16" to 2" 21/16" to 3" Over 31/16"

+.001 –.000 +.002 –.000 +.003 –.000 +.004 –.000

4 6 7 8

Maximum face run-out total indicator reading, inches Fully machined sprockets

Up to 10.000

.010

10.001 to 40.000

.001 per inch of root dia.

40.001 or more

.040

Sprockets with unfinished faces (forged or hot-rolled steel plate) .003 × root diameter (.020 minimum, .090 maximum)

*Applies to tolerances listed. For greater bore lengths, consult Rexnord.

Standard keyseat and setscrew sizes Diameter of Shaft

Setscrew

/8 × 1/16

10 – 24

/2 – 9/16

1

/8 – 7/8

3

1

5 15

Keyway Width × Depth

Diameter of Shaft

Keyway Width × Depth

Maximum pitch line eccentricity tolerances Commercial sprockets will be furnished within the eccentricity tolerances tabled below.

Setscrew

2 5/16 – 23/4

5

/16 × 3/32

1

/4

2 13/16 – 31/4

3

/4 × /8

5

/16

3 /16 – 3 /4

7

/8 × /16

3

/16 × 5/32

5

/16

313/16 – 41/2

1 × 1/2

3

3

/8

49/16 – 51/2

11/4 × 5/8

3

/4

Up to 4.000

.006

/2 *

5 9/16 – 61/2

11/2 × 3/4

3

/4

4.001 to 6.000

.008

6.001 to 10.000

.010

10.001 to 26.000

.001 per inch of root dia.

26.001 or more

.026

/16 – 1 /4 1

1

1

15/16 – 13/8

5

17/16 – 13/4

3

113/16 – 21/4

1

/8 × 3/16 /2 × 1/4

1

5

3

/8 × 5/16

5

/4 × 3/8

5

/8*

/8*

7


/4 /4

* Hub size may require smaller setscrews in some cases.

Maximum face run-out total indicator reading, inches Fully machined sprockets

Sprockets with unfinished faces (forged or hot-rolled steel plate)

.003 × root diameter (.020 minimum, .090 maximum)

Standard keyseat tolerances Sprockets for high speed drives or other applications requiring a minimum amount of pitch line eccentricity can be furnished within the following tolerances at a reasonable extra cost.

Keyseats will be furnished within these standard tolerances, unless otherwise specified. Bore diameter, inches

Tolerance, inches

Width of keyseat Depth of straight keyseat Depth of taper keyseat

+.002 – .000 +.010 – .000 +.000 – .010


Maximum eccentricity total indicator reading,inches

Up to 4.000 4.001 to 8.000 8.001 to 30.000

+.002 – .000 +.010 – .000 +.000 – .010

Negative tolerance on root diameters* Number of teeth

Chain Number 25

35

40

41

50

60

80

100

120

140

160

180

200

240

Up to 15

.004

.004

.004

.004

.005

.005

.006

.007

.007

.008

.009

.010

.010

.012

16 to 24

.004

004

.005

.005

.005

.006

.007

.008

.009

.010

.011

.012

.013

.015

25 to 35

.004

.004

.005

.005

.006

.007

.008

.009

.010

.012

.013

.014

.015

.018

36 to 48

.005

.005

.006

.006

.007

.008

.009

.010

.012

.013

.015

.016

.018

.021

49 to 63

.005

.005

.006

.006

.008

.009

.010

.012

.013

.015

.017

.018

.020

.024

64 to 80

.005

.006

.007

.007

.009

.010

.011

.013

.015

.017

.019

.012

.023

.027

81 to 99

.005

.006

.007

.007

.009

.010

.012

.014

.016

.019

.021

.023

.025

.030

100 to 120

.006

.006

.008

.008

.009

.011

.013

.016

.018

.020

.023

.025

.028

.033

121 to 143

.006

.007

.008

.008

.010

.012

.014

.017

.019

.022

.025

.028

.030

.036

144 and up

.006

.007

.009

.009

.011

.013

.015

.018

.021

.024

.027

.030

.033

.039

* No plus tolerances

G-2 (7010)

G

Chain and parts packaging Roller chains, chain parts, and sprockets are packaged for protection against damage and for convenience in handling and storing. Products remain factory-fresh, ready for immediate use. Packages are individually labeled with a complete description of contents, in order to simplify receiving and warehousing operations. Chain parts

Chain

Chain 10' coiled and boxed

Chain 50' and 100' reeled and cartoned

10' lengths are packaged in unique double-walled boxes, telescoping boxes, or slotted cartons, depending on size and weight. Each container is designed for excellent stacking strength and for protection against dust and/or dirt penetration.

50' and 100' lengths are wound on expendable reels and sealed in protective cartons. Carton flaps have an opening in the center to make reel center holes accessible for lifting with a rod or hook.

Connecting, roller, and offset links for all standard and Double Pitch chains are individually sealed in air and moisturetight plastic bags for maximum protection against dirt and rust. Parts for the more popular chain sizes are boxed in convenient quantities for ease of ordering and storage. See table on following page for sizes available and quantity per box.

Weight, pounds

Chain number

Weight, pounds

Chain number

Weight, pounds

Chain number

Weight, pounds

Chain number

50'

100'

25 25SS

.9 .9

60H 60SS

12.6 10.6

35 35-2 35-3 35-4 35SS

2.3 4.6 6.9 8.9 2.3

80 80-2 80-3 80-4 80SU 80SN

17.6 34.4 50.9 67.8 20.1 17.6

160 160-2 160-3 160SU 160TF 160SU-TF

63.9 131.5 192.0 70.6 67.0 73.1

180

93.0

40 40-2 40-3 40-4 40SS

4.2 8.4 12.5 16.5 4.2

100 100-2 100-3 100-4 100SU

26.6 52.4 79.8 104.8 30.2

200 200-2 200-3

108.2 210.3 315.3

240 264

163.6 122.0

25 35 40 41 50 60 60H 80 2040 C 2040 2050 C 2050 2060 C 2060H C 2080H

13.8 23.2 15.5 38.1 58.2 68.7 95.2 15.6s 24.0s 58.8s 89.8s

10.3 25.4 44.0 29.8 78.5 116.0 137.0 180.0s 30.0s 39.8s 47.0s 57.0s 67.5 111.3s -

41 41SS

2.8 2.8

50 50-2 50-3 50-4 50SS

7.2 14.3 21.5 28.7 7.2

120 120-2 120-3 120-4 120SU

38.6 78.2 116.0 151.5 42.4

2040 C 2040 C 2040SS

3.1 3.5 3.5

10.6 20.9 31.1 41.0

47.2 95.8 136.9 51.2 49.8

4.4 5.4 5.4

60 60-2 60-3 60-4

140 140-2 140-3 140SU 140TF

2050 C 2050 C 2050SS 2060 C 2060 C 2060H C 2060H-SS

6.9 8.4 10.9 10.9

Connecting links furnished with riveted chain One connecting link for each 10 feet of chain is furnished in all packages of riveted chain to replace the loss of a pin link each time the strand is cut.

(7010) G-3

G

Chain part standards Attachments

Slip-fit connecting links

Offset links

Spring clip type is standard for all single and multiple strand standard roller chains from .250" to .750" pitch.

Offset links are standard for all single and multiple strand Standard Roller chains except .250" pitch, and for all Double Pitch chains.

Cotter type is standard for all single strand Standard Roller chains from 1.000" to 2.000" pitch, and for all Double Pitch chains.

All standard and double pitch attachments listed in this book are individually packaged in plastic bags.

Offset assemblies Offset assemblies are standard for .250" pitch Standard Roller chain and are furnished on request for all other Standard Roller chains.

Press-fit connecting links Cotter type is standard for all single strand Standard Roller chains of 2.250" pitch and larger, and for all multiple strand Standard Roller chains of .750" pitch and larger.

Chain number 25 35 40 41 50 60 80 100 120 140 160 35-2 40-2 50-2 60-2 80-2 2040 2050 2060 2060H 2080 C 2040 C 2050 C 2060 C 2060H C 2080H C 2100H C 2120H

Slip-fit connecting links Spring clip type Cotter type Quantity Weight, Quantity Weight, per box pounds per box pounds 25 25 25 25 25 25 10 25 25 25 25 25 25 25 25 25 -

s Two-pitch offset assembly.

G-4 (7010)

.3 .4 .6 .5 1.1 1.7 1.6 .9 1.0 1.9 .8 1.3 2.1 .9 1.4 3.5 -

25 10 10 10 10 5 25 25 25 25 10 25 25 25 25 10 5 5

1.7 1.6 2.7 4.2 6.3 4.9 .8 1.3 2.1 2.5 1.9 .9 1.4 2.8 3.4 3.0 2.8 4.4

Roller links Roller links, Standard Roller chain components, can be furnished individually. For multiple strand chains, one roller link is required for each strand.

Press-fit connecting links, cotter type

Roller links

Offset links

Quantity per box

Weight, pounds

Quantity per box

Weight, pounds

20 10 -

2.4 2.5 -

25 25 25 25 25 25 10 10 10 10 5

.2 .4 .7 .5 1.2 2.0 1.9 3.3 5.7 8.1 6.4

Double strand chains use two standard roller links per pitch 25 25 25 25 10 25 25 25 25 10 5 5

.8 1.4 2.9 2.9 2.4 .9 1.6 2.8 3.4 3.1 2.9 4.7

Quantity per box 25 s 25 25 25 25 25 10 10 10 10 5 25 25 25 20 10 25 25 25 25 10 25 25 25 25 10 5 5

Weight, pounds .3 .4 .5 .5 1.2 2.0 1.8 3.3 5.5 7.8 6.2 .6 1.1 2.1 2.9 3.2 .7 1.4 2.4 2.9 2.3 .9 1.6 1.9 3.4 3.0 2.8 4.6

G

Chain Repair Tools Chain Breakers Chain Breakers are quality tools with forged jaws. The "push-out'' pins are of tempered alloy steel. They simplify the disassembly of roller chain and are available in two sizes.

Overall length.......................................................................6 inches Overall width.........................................................................3 inches Weight..................................................................................11 oz. For disassembly of: Single pitch chains Nos. 25 through 60 (1/4-, 3/8-, 1/2-, 5/8-, and 3/4-inch pitch) Double-Pitch chains, 1- and 11/4-inch pitch. Note: Breakers cannot be used with Carrier Roller Chain.

WARNING To avoid personal injury or property damage, persons connecting or disconnecting chain, and other personnel in the vicinity, must: • Always lock out equipment power switches before removing or installing chains. • Always use safety glasses to protect eyes. Wear protective clothing, gloves and safety shoes. • the chain to prevent uncontrolled movement of the chain and parts.

• Maintain tools in proper condition and assure their proper use. Use of pressing equipment is recommended. • Not attempt to connect or disconnect chain unless chain construction is clearly known and understood. • Use only subassemblies, as opposed to individual component parts, built by the chain manufacturer for assembling chain strands. • Not use any sections of damaged chains because they may have been overloaded and yielded.

(7010) G-5

G

NOTES

G-6 (7010)

H

Technical Data Formulas for engineering calculations The following formulas cover the basic calculations used in chain drive and chain conveyor engineering. For convenience, the formulas are expressed in both English and metric units of measure. In the International System of Units (S.I. system), which is the official scientific metric standard, power is expressed in watts and both weight and force are expressed in newtons. Nevertheless, English horsepower and kilograms are more commonly used today to express these values. For this reason, the chain ratings shown in this catalog are given in English horsepower, or pound-feet/second. English-metric conversion factors, however, are tabled on page H-2 so that English values can be translated to S.I. metric units.

Convenient engineering formulas Desired calculation Power

Formula

Formula

Metric units

English units H=

LS LTPN QN KN = = = 33,000 396,000 63,025 5252 Q=

Torque K=

Working Load

L=

63,025H = N 5252H N

Chain Sag and Catenary Pull

Symbols used in formulas D = Sprocket pitch diameter F = Factor of safety H = Power K = Torque L = Working load N = Sprocket speed P = Chain pitch Q = Torque R = Sprocket pitch radius S = Chain speed T = Number of sprocket teeth U = Ultimate chain strength W = Power

Q=

LR 12

33,000H 396,000H Q = = S TPN R

L=

=

LTPN QN = 60,000 9.549

9.549W N

1000Q R

60W S

=

LR 1000

=

=

60,000W TPN

S (exact) =

TPN 12

S (exact) =

TPN 1000

S (approx.) =

3.14ND 12

S (approx.) =

3.14ND 1000

N (exact) =

12S TP

N (exact) =

1000S TP

N (approx.) =

12S 3.14D

N (approx.) =

1000S 3.14D

Sprocket Speed

Factor of Safety

LS 60

LR

=

Chain Speed

Sprocket Pitch Diameter

W=

P

D= sin F=

( )

sin

U L

F=

See page E-1.

English units Inches - Horsepower Pound-feet Pounds Revolutions per minute Inches Pound-inches Inches Feet per minute - Pounds -

P

D=

180° T

( ) 180° T

U L

See page E-1.

Metric units Millimeters Newton-meters Newtons Revolutions per minute Millimeters Newton-meters Millimeters Meters per minute Newtons Watts (Nm per second)

(7010) H-1

H

English-metric conversions factors Multiply the base unit by the factor shown to obtain the desired conversion. Base unit

Factor

inch

in

millimeter

mm

25.4 .03937

Conversion millimeter

mm

inch

in

foot

ft

.3048

meter

m

meter

m

3.281

foot

ft

pound

lb

4.448

newton

N

newton

N

.225

pound

lb

pound

lb

.454

kilogram

kg

kilogram

kg

2.205

pound

lb

kilogram

kg

9.807

newton

N

newton

N

.102

kilogram

kg

pounds per foot

lb/ft

1.488

kilograms per meter

kg/m

kilograms per meter

kg/m

.672

pounds per foot

lb/ft

pound-feet

lb-ft

1.356

newton-meter

Nm

newton-meter

Nm

.737

pound-feet

lb-ft

pound-feet

lb-ft

.1384

kilogram-meter

kg-m

kilogram-meter

kg m

7.234

pound-feet

lb-ft

horsepower (English)

hp

745.7

watt

W

watt

W

.00134

horsepower

hp

Decimal equivalents of fractions Decimal equivalent, inches 2-place

3-place

2-place

3-place

/64

.39

.391

25

/32

.41

.406

13

/64

.42

.422

27

/16

.44

.438

7

/64

.45

.453

29

.02

.016

1

.03

.031

1

.05

.047

3

.06

.063

1

.08

.078

5

.09

.094

3

.11

.109

7

.13

.125

1

Fraction, inches /64

.70

.703

45

/32

.72

.719

23

/64

.73

.734

47

/64

/16

.75

.750

3

/4

/64

.77

.766

49

.47

.469

15

.48

.484

31

/8

.50

.500

1

.141

9

.156

5

.17

.172

11

.19

.188

3

.20

.203

13

.22

.219

7

.23

.234

15

.25

.250

1

.27

.266

17

.28

.281

9

.30

.297

19

.31

.313

5

.33

.328

21

.34

.344

11

.36

.359

22

/64

.38

.375

3

/8

/64

.78

.781

25

/64

.80

.797

51

/2

.81

.813

13

/64

.83

.828

53

/32

.84

.844

27

/64

.86

.859

55

/16

.88

.875

7

/64

.89

.891

57

/32

.91

.906

29

/64

.92

.922

59

/8

.94

.938

15

/64

.95

.953

61

/32

.97

.969

31

/64

.98

.984

63

/16

1.00

1.000

/64

.52

.516

33

.53

.531

17

/64

.55

.547

35

/16

.56

.563

9

/64

.58

.578

37

/32

.59

.594

19

/64

.61

.609

39

/4

.63

.625

5

/64

.64

.641

41

/32

.66

.656

21

/64

.67

.672

43

/16

.69

.688

11

/32

/64

/32

/32

/32

/64

Fraction, inches

3-place

/32

.14

Decimal equivalent, inches 2-place

/64

.16

H-2 (7010)

Decimal equivalent, inches

Fraction, inches

/32 /64

/16 /64

/32

/64 /8 /64

/32

/64 /16

/64 /32

/64

1

H

Chain and Sprocket Index Chain Number

25 25SS 35 35-2 35-3 35-4 35-5 35-6 35 SB 35 SS 40 40-2 40-3 40-4 40-5 40-6 40 L 40 SB 40 SS 41 41 SS 45 50 50-2 50-3 50-4 50-5 50-6 50 L 50 OR 50 SB 50 SS 55 60 60-2 60-3 60-4 60-5 60-6 60 EC 60 H 60 HL 60 L 60 OR 60 SB 60 SS 65 80 80-2 80-3 80-4 80-5 80-6 80 HL 80 L 80 OR 80 SB 80 SN 80 SU 85 100 100-2 100-3 100-4

Page references Chain

B-1 B-6 B-1, D-3, G-3 B-1 B-2 B-2 B-3 B-3 D-15 B-6 B-1, D-3 B-1 B-2 B-2 B-3 B-4 D-9 D-15 B-6 B-1 B-6 G-3 B-1, D-3 B-1 B-2 B-3 B-3 B-3 D-9 B-7 D-15 B-6 G-3 B-1, D-3 B-1 B-2 B-2 B-3 B-3 D-22 B-4 D-9 D-9 B-7 D-15 B-6 G-3 B-1, D-3 B-1 B-2 B-2 B-3 B-3 D-9 D-9 B-7 D-15 B-6 B-4 G-3 B-1, D-3 B-1 B-2 B-2

Sprocket data

C-10 C-10 C-12 C-12 C-12 C-12 C-12 C-12 C-12 C-12 C-14 C-14 C-14 C-14 C-14 C-14 C-14 C-14 C-14 C-16 C-16 * C-18 C-18 C-18 C-18 C-18 C-18 C-18 C-18 C-18 C-18 * C-20 C-20 C-20 C-20 C-20 C-20 C-20 B-4 C-20 C-20 C-20 C-20 C-20 * C-22 C-22 C-22 C-22 C-22 C-22 C-22 C-22 C-22 C-22 C-22 B-4 * C-24 C-24 C-24 C-24

Page references

Chain Number

Chain

100-5 100-6 100 L 100 OR 100 SN 100 SU 105 120 120-2 120-3 120-4 120-5 120-6 120 SU 125 140 140-2 140-3 140-4 140-5 140-6 140 SU 140 TF 145 160 160-2 160-3 160-4 160-5 160-6 160 SU 160 TF 160 SUTF 165 180 180-2 180-3 180-4 180-5 180-6 180 SU 185 200 200-2 200-3 200-4 200-5 200-6 205 240 240-2 240-3 240-4 240-5 240-6 245 264 B 502 B 503 B 504 B 505 B 506 1048 C 2048

B-3 B-3 D-9 B-7 B-6 B-4 G-3 B-1, D-3 B-1 B-2 B-2 B-3 B-3 B-4 G-3 B-1, D-3 B-1 B-2 B-2 B-3 B-3 B-4 B-5 G-3 B-1, D-3 B-1 B-2 B-2 B-3 B-3 B-4 B-5 B-5 G-3 B-1 B-1 B-2 B-2 B-3 B-3 B-4 G-3 B-1 B-1 B-2 B-2 B-3 B-3 G-3 B-1 B-1 B-2 B-2 B-3 B-3 G-3 B-4 D-15 D-15 D-15 D-15 D-15 D-11 D-11

Sprocket data

C-24 C-24 C-24 C-24 C-24 B-4 * C-26 C-26 C-26 C-26 C-26 C-26 B-4 * C-28 C-28 C-28 C-28 C-28 C-28 B-4 C-28 * C-30 C-30 C-30 C-30 C-30 C-30 B-4 C-30 B-4 * C-32 C-32 C-32 C-32 C-32 C-32 B-4 * C-34 C-34 C-34 C-34 C-34 C-34 * C-36 C-36 C-36 C-36 C-36 C-36 * B-4 * * * * * C-14 E-10

Chain Number

C 2049 1058 C 2058 C 2059 1068 C 2068 C 2069 1088 C 2088 H C 2089 H 2040 2040 L C 2040 C 2040 L C 2040 SS C 2042 C 2042 L C 2042 SS 2050 2050 L C 2050 C 2050 L C 2050 SS C 2052 C 2052 L C 2052 SS 2060 2060 L 2060 H 2060 HL C 2060 H C 2060 HL C 2060 HSS C 2060 L C 2062 H C 2062 HL C 2062 HSS 2080 C 2080 H C 2080 HL C 2080 HSN C 2082 H C 2082 HL C 2082 HSN C 2100 H C 2100 HSN C 2102 H C 2102 HSN C 2120 H C 2120 HSN C 2122 H C 2122 HSN C 2160 H C 2160 HSN C 2162 H C 2162 HSN L 502 L 503 L 504 L 505 L 505 SS L 506

Page references Chain

D-11 D-11 D-11 D-11 D-11 D-11 D-11 D-11 D-11 D-11 B-5 D-9 D-5 D-10 D-5 D-6 D-10 D-6 B-5 D-9 D-5 D-10 D-5 D-5 D-10 D-6 B-5 D-9 B-5 D-9 D-5 D-10 D-5 D-10 D-6 D-10 D-6 B-5 D-5 D-10 D-5 D-6 D-10 D-6 D-5 D-5 D-6 D-6 D-5 D-5 D-6 D-6 D-5 D-5 D-6 D-6 D-16 D-16 D-16 D-16 D-16 D-16

Sprocket data

E-11 C-18 E-12 E-13 C-20 E-14 E-15 C-22 E-16 E-17 C-38 C-38 E-10 E-10 E-10 E-11 E-11 E-11 C-40 C-40 E-12 E-12 E-12 E-12 E-12 E-13 C-42 C-42 C-42 C-42 E-14 E-14 E-14 C-42 E-15 E-15 E-15 C-44 E-16 E-16 E-16 E-17 E-17 E-17 E-18 E-18 E-19 E-19 E-20 E-20 E-21 E-21 E-22 E-22 E-23 E-23 * * * * * *

* Not Applicable

(7010) H-3

H

NOTES

H-4 (7010)

866-REXNORD/866-739-6673 (Within the U.S.) 414-643-2366 (Outside the U.S.) www.rexnord.com

Why Choose Rexnord? When it comes to providing highly engineered products that improve productivity and efficiency for industrial applications worldwide, Rexnord is the most reliable in the industry. Commitment to customer satisfaction and superior value extend across every business function. Delivering Lowest Total Cost of Ownership The highest quality products are designed to help prevent equipment downtime and increase productivity and dependable operation.

Valuable Expertise An extensive product offering is accompanied by global sales specialists, customer service and maintenance teams, available anytime. Solutions to Enhance Ease of Doing Business Commitment to operational excellence ensures the right products at the right place at the right time.

Rexnord Company Overview Rexnord is a growth-oriented, multi-platform industrial company with leading market shares and highly trusted brands that serve a diverse array of global end markets. Process & Motion Control The Rexnord Process & Motion Control platform designs, manufactures, markets and services specified, highly engineered mechanical components used within complex systems where our customers’ reliability requirements and the cost of failure or downtime are extremely high. Water Management The Rexnord Water Management platform designs, procures, manufactures and markets products that provide and enhance water quality, safety, flow control and conservation.

©2015 Rexnord

7010 08/15

7010 Rexnord And Link Belt Roller Chains Catalog P 5e5z6z

Overview 1s532p

More details 6h715l

Related Documents 2w1qw

7010 Rexnord And Link Belt Roller Chains Catalog P 5e5z6z

Roller Chain Link Belt 3p645

Link-belt Rex Bearings Catalog 661y4v

Tsubaki Conveyor Chains Catalog 4v6b6w

Link Belt Service Manual 5v3s36

Catalogo Chumaceras Link Belt 3v5z2s

More Documents from "Marcelo" 4g661w

504uu

Cuestionario De Fluidos I 474m12

7010 Rexnord And Link Belt Roller Chains Catalog P 5e5z6z

504uu

Subaru Cajas De Cambios Cvt 58g44

504uu
