CALCULO DE CARGABILIDAD EN   TRANSFORMADORES DE MEDIDA

Fecha:  Setiembre 2013

Página: 1 de 10

  Descripción:

Rev. B

S.E.EL HIERRO Y LÍNEA DE TRANSMISIÓN 220 kV

SHOUGANG HIERRO PERÚ S.A.A.

PROYECTO: AMPLIACIÓN DE OPERACIONES MINA Y PLANTA DE BENEFICIO CONTRATO DE EPC Nº 14: “SE EL HIERRO, LÍNEA DE TRANSMISIÓN 220 kV” CALCULO DE CARGABILIDAD EN TRANSFORMADORES DE MEDIDA

Documento No.: 992481-6700-D-E-MC-0012

B

11/09/13

APROBACIÓN

ABB

SHP

SHP

A

02/09/13

APROBACIÓN

ABB

ABB

ABB

Rev.

Fecha

Emitido Para

Por

Revisado

Aprobado

CALCULO DE CARGABILIDAD EN   TRANSFORMADORES DE MEDIDA    Descripción:

992481‐6700‐D‐E‐MC‐0012

Rev. B

Fecha:  Setiembre 2013

Página: 2 de 10

S.E.EL HIERRO Y LÍNEA DE TRANSMISIÓN 220 kV

ÍNDICE 1

INTRODUCCIÓN .................................................................................................................... 3  1.1  1.2  1.3

OBJETIVO ............................................................................................................................................................. 3  ALCANCES ............................................................................................................................................................ 3  NORMAS APLICABLES ........................................................................................................................................ 3

2

CARACTERISTICAS GEOGRAFICAS ................................................................................. 3

3

CARACTERÍSTICAS DEL SISTEMA ELÉCTRICO .............................................................. 3

4

SELECCIÓN DE TRANSFORMADORES DE CORRIENTE ................................................. 4  4.1  4.2  4.3  4.4

5

CORRIENTE DEL PRIMARIO DEL TRANSFORMADOR .................................................................................... 4  CORRIENTE DEL SECUNDARIO DEL TRANSFORMADOR ............................................................................. 5  CARGABILIDAD DE LOS TRANSFORMADORES DE CORRIENTE ................................................................. 5  CARACTERÍSTICAS DE LOS TRANSFORMADORES DE CORRIENTE .......................................................... 6

SELECCIÓN DE TRANSFORMADORES DE TENSIÓN ...................................................... 6  5.1  5.2  5.3

RELACIÓN DE TRANSFORMACIÓN ................................................................................................................... 6  CARGABILIDAD DE LOS TRANSFORMADORES DE TENSIÓN....................................................................... 6  CARACTERÍSTICAS DE LOS TRANSFORMADORES DE TENSIÓN ............................................................... 7

6

CONCLUCIONES................................................................................................................... 7

7

ANEXOS

...................................................................................... 7

CALCULO DE CARGABILIDAD EN   TRANSFORMADORES DE MEDIDA

992481‐6700‐D‐E‐MC‐0012

Fecha:  Setiembre 2013

Página: 3 de 10

  Descripción:

Rev. B

S.E.EL HIERRO Y LÍNEA DE TRANSMISIÓN 220 kV

CALCULO DE CARGABILIDAD EN TRANSFORMADORES DE MEDIDA

1 INTRODUCCIÓN 1.1

OBJETIVO

El desarrollo de este documento tiene como objetivo, determinar las características de los transformadores de corriente y tensión para la subestación El Hierro en 220 kV. 1.2

ALCANCES

El alcance del presente informe comprende:  Desarrollo de la memoria de cálculo  Anexos de los cálculos 1.3

NORMAS APLICABLES

Para establecer las características de los equipos de medición de la subestación, se empleará la norma IEC 185 “Current Transformer”. 2 CARACTERISTICAS GEOGRAFICAS La S.E. El Hierro se encuentra ubicada en el asiento minero Marcona - Shougang (Mina - San Nicolás), Provincia de Nazca, Departamento de Ica. El área del Proyecto está comprendida al interior de la zona de influencia de la Nueva Planta Beneficio. Las características climatológicas y geográficas en el área del proyecto, son las siguientes:  Altura : 114 msnm  Temperatura Mínima : 5 °C  Temperatura Máxima : 40 ° C  Contaminación Ambiental : Muy severa carácter salino  Humedad relativa media : 50%/90% 3 CARACTERÍSTICAS DEL SISTEMA ELÉCTRICO Las características del sistema eléctrico son las siguientes: Cuadro Nº: 1 Características del Sistema Tensión Nominal Frecuencia asignada Puesta a tierra Número de fases

220kV 60 Sólido 3

Tensión asignada del equipos (kV)

245

Tensión de operación del sistema (kV)

220

992481‐6700‐D‐E‐MC‐0012

CALCULO DE CARGABILIDAD EN   TRANSFORMADORES DE MEDIDA

Fecha:  Setiembre 2013

Página: 4 de 10

  Descripción:

Rev. B

S.E.EL HIERRO Y LÍNEA DE TRANSMISIÓN 220 kV

Tensión Nominal

220kV

Tensión asignada soportada al impulso tipo rayo (kV)

1050

Corriente de cortocircuito prevista en el sistema (kA)

11,5 kA

Distancia de fuga mínima, (mm/kV fase tierra): Identificación de fases

55 R, S y T

4 SELECCIÓN DE TRANSFORMADORES DE CORRIENTE 4.1

CORRIENTE DEL PRIMARIO DEL TRANSFORMADOR

El procedimiento empleado para la selección de la corriente del primario del transformador de potencia es el siguiente:  Cálculo de la corriente de carga por el Transformador de Corriente (I1). La selección de la corriente de carga del Transformador de corriente de las celdas de salida y llegada de Línea se calcula con el flujo de carga máxima que pasará por dicho transformador de corriente.  La fórmula empleada para el cálculo de la corriente es la siguiente: I1= S/(√3xV) Donde: S: Potencia Total de consumo V: Tensión de operación del Sistema

 

Para Validar la corriente calculada y que el transformador de corriente no se sature ante eventos de cortocircuito, se calcula la corriente máxima por el devanado del primario La fórmula empleada para el cálculo de la corriente es el siguiente: I2= Icc/(N) Donde: I2: Corriente máxima a soportar por el TC sin saturarse N: Es el número de veces la corriente nominal previsto para el error del TC de protección; para nuestro caso es 5p20; entonces N=20.

Cuadro Nº: 2 Corrientes de Cortocircuito de Diseño Subestación El Hierro

2014 2015 2016 2025

Corriente Máxima en 220 kV 4.887 4.998 5.62 8.5 Considerando un incremento de la corriente de cortocircuito del 50%, por el crecimiento del sistema, se tiene 1.5x5.62=8.43 kA; considerándose 8,5 kA y que corresponde a la proyección a 11 años del sistema. De ambas corrientes determinadas I1 y I2 se selecciona el mayor valor normalizado para corriente en el primario del transformador de corriente. En el cuadro siguiente se presenta el resumen de las corrientes calculadas y seleccionadas:

992481‐6700‐D‐E‐MC‐0012

CALCULO DE CARGABILIDAD EN   TRANSFORMADORES DE MEDIDA

Fecha:  Setiembre 2013

Página: 5 de 10

  Descripción:

Rev. B

S.E.EL HIERRO Y LÍNEA DE TRANSMISIÓN 220 kV

Cuadro Nº: 3 Selección del Primario del Transformador de Corriente Tensión

Corriente de Saturación

Corriente de Carga

I primario

(kV)

I2

I1

Calculada Seleccionada

Descripción

   Bahía Salida

220

Icc (kA)

(A)

MVA

(A)

(A)

(A)

8,50

425

264

694

694

1200-600

La potencia máxima a transmitir en la bahía de salida de llegada de la SE Marcona, corresponde a la potencia de los dos transformadores de potencia de 220/22,9kV los cuales son de 132MVA cada uno, haciendo un total de 264MVA y en 220kV, 694A, esta vendría a ser la corriente de carga en la condiciones de máxima carga. Por otro lado la corriente de cortocircuito al año 2016 es de 5.62kA, con un incremento del 50%, sería 8,50kA, y esto nos da una corriente de 425A. 4.2

CORRIENTE DEL SECUNDARIO DEL TRANSFORMADOR

La norma IEC 185 “Current Transformer” estandariza las intensidades nominales en el secundario a valores de 1 y 5 A. La corriente en el secundario de los transformadores se ha elegido 1 A, pues permite menores valores de potencias en los transformadores de medida. 4.3

CARGABILIDAD DE LOS TRANSFORMADORES DE CORRIENTE

La cargabilidad de los núcleos de los transformadores de corriente se obtiene sumando los consumos totales que se originan desde el borne del transformador hasta el relé o medidor, tales como; consumo de los relés, consumo del cable de conexión. La potencia en estado normal de consumo del transformador de corriente se calcula conforme a la siguiente ecuación:

P  ( Rr  2 xRc xL ) xI S2 VA. Simplificando:

Burdentotal  BurdenRr  2 xBurdenRc VA. Dónde: Burden total: Potencia Total de consumo por la impedancia equivalente en bornes del TC. Rr: Resistencia del Relé de protección o equipo de medida. Rc: Resistencia del cable, ohm/m; se considera un cable N2XSY 4x4 mm² L: Longitud del cable desde el transformador de corriente hasta el gabinete, en metros. Is : Corriente que circula en el devanado secundario (1 A )

En el cuadro siguiente se presenta el burden total de los Transformadores de corriente y la cargabilidad del Transformador. Cuadro N° 3 Cargabilidad de los Transformadores de Corriente Descripción Bahía Llegada

Tensión (kV) 220

Longitud Cable "L" (m) 60.00

ohm/m 0.0050

Rc Rr ohm (total) Burden (VA) Burden (VA) 0.2970 0.2970 15.00

Burden Total 15.59

Corrte. Pot-Traf Secd. Is (A) VA 1.00 30

Cargab. 51.98%

Notas: El valor de Rr se tomó considerando el IED de mayor carga (ver anexo 7.0). Los IEDs considerados son los siguientes: - Relé de protección REC 670 (tanto principal como respaldo). - Medidor de energía ION 7650.

Según la norma IEC 185 para asegurar la precisión de los transformadores el burden debe de estar entre el 25 % y el 100 % del burden total, validándose que el transformador opera correctamente.

992481‐6700‐D‐E‐MC‐0012

CALCULO DE CARGABILIDAD EN   TRANSFORMADORES DE MEDIDA

Fecha:  Setiembre 2013

Página: 6 de 10

  Descripción:

4.4

Rev. B

S.E.EL HIERRO Y LÍNEA DE TRANSMISIÓN 220 kV

CARACTERÍSTICAS DE LOS TRANSFORMADORES DE CORRIENTE

En el cuadro siguiente se presenta las características de los transformadores de corriente: Cuadro N° 4 Características de los Transformadores de Corriente

Descripción Bahía Llegada

Tensión (kV) 220

Relación de Transformación

Potencia

Clase

(VA)

Medición

Protección

1200-600/1-1-1-1

4x30 VA

1xCl 0,2

3x5P20

5 SELECCIÓN DE TRANSFORMADORES DE TENSIÓN 5.1

RELACIÓN DE TRANSFORMACIÓN

La relación de transformación de los transformadores de tensión es seleccionada con la tensión nominal del sistema y las tensiones normalizadas de los equipos, para nuestro caso es 115V. Cuadro N° 5 Relación de Transformación de los Transformadores de Tensión

5.2

Descripción

Tensión (kV)

Bahía Llegada

220

Relación de Transformación

CARGABILIDAD DE LOS TRANSFORMADORES DE TENSIÓN

La cargabilidad de los núcleos de los transformadores de tensión se obtiene sumando los consumos totales que se originan desde el borne del transformador hasta el relé o medidor, tales como; consumo de los relés, consumo del cable de conexión. La potencia en estado normal de consumo del transformador se calcula conforme la siguiente ecuación:

P

Vs 2 VA. ( Rr  2 xRc xL)

Simplificando:

Burdentotal  BurdenRr  2 xBurdenRc VA. Dónde: Burden total: Potencia Total de consumo por la impedancia equivalente en bornes del TT Rr: Resistencia del Relé de protección Rc: Resistencia del cable, ohm/m; se considera un cable N2XSY 4x4 mm² L: Longitud del cable desde el transformador de tensión hasta el gabinete, en metros. Vs : Tensión en el devanado secundario 115/√3

992481‐6700‐D‐E‐MC‐0012

CALCULO DE CARGABILIDAD EN   TRANSFORMADORES DE MEDIDA

Fecha:  Setiembre 2013

Página: 7 de 10

  Descripción:

Rev. B

S.E.EL HIERRO Y LÍNEA DE TRANSMISIÓN 220 kV

En el cuadro siguiente se presenta el burden total de los Transformadores de tensión y la cargabilidad del Transformador: Cuadro N° 6 Cargabilidad de los Transformadores de Tensión Descripción Bahía Llegada

Tensión (kV) 220

Longitud Cable "L" (m) 60.00

ohm/m 0.0050

Rc Rr ohm (total) Burden (VA) Burden (VA) 0.2970 0.0672 15.00

Burden Total 15.13

Tension Secd. (V) 66.40

Pot-Traf VA 30

Cargab. 50.45%

Notas: El valor de Rr se tomó considerando el IED de mayor carga (ver anexo 7.0). Los IEDs considerados son los siguientes: - Relé de protección REC 670 (tanto principal como respaldo). - Medidor de energía ION 7650.

Según la norma IEC 186 para asegurar la precisión de los transformadores el burden debe de estar entre el 25 % y el 100 % del burden total. 5.3

CARACTERÍSTICAS DE LOS TRANSFORMADORES DE TENSIÓN

En el cuadro siguiente se presenta el resumen de características de los transformadores de tensión del proyecto: Cuadro N° 7 Características de los Transformadores de Tensión Descripción Bahía Llegada

Tensión (kV) 220

Relación de Transformación

Potencia

Clase

(VA)

Medición Protección

2x50 VA

1xCl 0,2

1x3P

6 CONCLUCIONES De lo visto anteriormente los transformadores de medición cumplen con los requerimientos de carga que se colocarán en sus bornes (relés y medidor multifunción)

7 ANEXOS 7.1 7.2 7.3

Cuadro resumen Medidor multifunción ION 7650 IED controlador REC670
