Milling machine From Wikipedia, the free encyclopedia
A milling machine is a machine tool used for the complex shaping of metal and other solid materials. Its basic form is that of a rotating cutter or endmill which rotates about the spindle axis (similar to a drill), and a movable table to which the workpiece is affixed. That is to say the cutting tool generally remains stationary (except for its rotation) while the workpiece moves to accomplish the cutting action. Milling machines may be operated manually or under computer numerical control (see CNC). Milling machines can perform a vast number of complex operations, such as slot cutting, planing, drilling, rebating, routing, etc.
Endmills for a milling machine.
Cutting fluid is often pumped to the cutting site to cool and lubricate the cut, and to sluice away the resulting swarf.
Contents 1 Types of milling machines 1.1 Milling machine variants 2 Computer numerical control 2.1 Milling machine tooling 3 See also
Types of milling machines There are two main types of mill: the vertical mill and the horizontal mill. In the vertical mill the spindle axis is vertically oriented. Milling cutters are held in the spindle and rotate on its axis. The spindle can generally be extended (or the table can be raised/lowered, giving the same effect), allowing plunge cuts and drilling. There are two subcategories of vertical mills: the bedmill and the turret mill. Turret mills, like the ubiquitous Bridgeport, are generally smaller than bedmills, and are considered by some to be more versatile. In a turret mill the spindle remains stationary during cutting operations and the table is moved both perpendicular to and parallel to the spindle axis to accomplish cutting. In the bedmill, however, the table moves only perpendicular to the spindle's axis, while the spindle itself moves parallel to its own axis. Also of note is a lighter machine, called a mill-drill. It is quite popular with hobbyists, due to its small size and lower price. These are frequently of lower quality than other types of machines, however. A horizontal mill has the same sort of x–y table, but the cutters are mounted on a horizontal arbor across the table. A majority of horizontal mills also feature a +15/-15 degree rotary table that allows milling at shallow angles. While endmills and the other types of tools available to a vertical mill may be used in a horizontal mill, their real advantage lies in arbormounted cutters, called side and face mills, which have a cross section rather like a circular saw, but are generally wider and smaller in diameter. Because the cutters have good from the arbor, quite heavy cuts can be taken, enabling rapid material removal rates. These are used to mill grooves and slots. Plain mills are used to shape flat surfaces. Several cutters may be ganged together on the arbor to mill a complex shape of slots and planes. Special cutters can also cut grooves, bevels, radii, or indeed any section desired. These specialty cutters tend to be expensive. Simplex mills have one spindle, and duplex mills have two. It is also easier to cut gears on a horizontal mill. A more complex form of the milling machine is the Universal milling machine, in which the rotating cutter can be oriented
http://en.wikipedia.org/wiki/Milling_machine
7/3/2007
Milling machine - Wikipedia, the free encyclopedia
Page 2 of 8
vertically or horizontally, increasing the flexibility of the machine tool. The table of the universal machine can be swiveled through a small angle (up to about 15 degrees), enabling the axis of the spindle to coincide with the axis of a helix to be milled with the use of a gear driven indexing attachment.
Milling machine variants Box or column mills are very basic hobbyist bench-mounted milling machines that feature a head riding up and down on a column or box way. Turret or Vertical ram mills are more commonly referred to as bridgeport-type milling machines. The spindle can be aligned in many different positions for a very versatile, if somewhat less rigid machine. C-Frame mills are larger, industrial production mills. They feature a knee and fixed spindle head that is only mobile vertically. They are typically much more powerful than a turret mill, featuring a separate hydraulic motor for integral hydraulic power feeds in all directions, and a twenty to fifty horsepower motor. Backlash eliminators are almost standard equipment. They use large NMTB 40 or 50 tooling. The tables on C-frame mills are usually 18" by 68" or larger, to allow multiple parts to be machined at the same time. Knee mill refers to any milling machine that has a vertically adjustable table. Bed mill refers to any milling machine where the spindle is on a pendant that moves up and down to move the cutter into the work. These are generally more rigid than a knee mill. Jig borers are vertical mills that are built to bore holes, and very light slot or face milling. They are typically bed mills with a long spindle throw. The beds are more accurate, and the handwheels are graduated down to .0001" for precise hole placement. Horizontal boring mills are large, accurate bed horizontal mills that incorporate many features from various machine tools. They are predominantly used to create large manufacturing jigs, or to modify large, high precision parts. They have a spindle stroke of several (usually between four and six) feet, and many are equipped with a tailstock to perform very long boring operations without losing accuracy as the bore increases in depth. A typical bed would have X and Y travel, and be between three and four feet square with a rotary table or a larger rectangle without said table. The pendant usually has between four and eight feet in vertical movement. Some mills have a large (30" or more) intergal facing head. Right angle rotary tables and vertical milling attachments are available to further increase productivity. Floor mills have a row of rotary tables, and a horizontal pendant spindle mounted on a set of tracks that runs parallel to the table row. These mills have predominantly been converted to CNC, but some can still be found (if one can even find a used machine available) under manual control. The spindle carriage moves to each individual table, performs the machining operations, and moves to the next table while the previous table is being set up for the next operation. Unlike any other kind of mill, floor mills have floor units that are entirely movable. A crane will drop massive rotary tables , X-Y tables , and the like into position for machining, allowing the largest and most complex custom milling operations to take place.
Example of portical machine tool
Portical mills It has the spindle mounted in a T structure where 2 or 3 combined travels can be made depending if the work table is static or cross moved; The choice for one type or other in this case depends mostly on the part to be machined i.e. on its weight. Therefore the "ap" or "stepdown" needed on the average work done, should be considered, to watch for the torque on the moving axis;
Computer numerical control Most CNC milling machines or machining centers are computer controlled vertical mills with the ability to move the spindle vertically along the Z-axis. This extra degree of
http://en.wikipedia.org/wiki/Milling_machine
7/3/2007
Milling machine - Wikipedia, the free encyclopedia
Page 3 of 8
freedom permits their use in engraving applications, and also allows to create 2.5D surfaces such as relief sculptures. When combined with the use of conical tools or a ball nose cutter, it also significantly improves milling precision without impacting speed, providing a cost-efficient alternative to most flat-surface hand-engraving work.
Example of thin wall milling
CNC machines can exist in virtually any of the forms of manual machinery, like horizontal mills. The most advanced CNC milling-machines, the 5-axis machines, add two more axes in addition to the three normal axes (XYZ). Horizontal milling machines also have a C or Q axis, allowing the horizontally mounted workpiece to be rotated, essentially allowing asymmetric and eccentric turning. The fifth axis(B-Axis) controls the tilt of the tool itself. When all of these axes are used in conjunction with each other, extremely complicated geometries, even organic geometries such as a human head can be made with relative ease with these machines. But the skill to program such geometries is beyond that of most humans. Therefore, 5-axis milling machines are practically always programmed with CAM.
Five-axis Deckel Maho machining center
With the declining price of computers, free operating systems such as Linux, and open source CNC software, the entry price of CNC machines has plummeted. For example, Sherline, Prazi, and others make desktop CNC milling machines that are affordable by hobbyists.
Milling machine tooling There is some degree of standardization of the tooling used with CNC Milling Machines and to a much lesser degree with manual milling machines. CNC Milling machines will nearly always use SK (or ISO), CAT, BT or HSK tooling. CAT tooling, sometimes called VFlange Tooling, is the oldest variation and is probably still the most common. CAT tooling was invented by Caterpillar Inc. of Peoria, Illinois in order to standardize the tooling used on their machinery. CAT tooling comes in a range of sizes designated as CAT-30, CAT-40, CAT-50, etc. The number refers to the NMTB Taper size of the tool. An improvement on CAT Tooling is BT Tooling, which looks very similar and can easily be confused with CAT tooling. Like CAT Tooling, BT Tooling comes in a range of sizes and uses the same NMTB body taper. However, BT tooling is symmetrical about the spindle axis, which CAT tooling is not. This gives BT tooling greater stability and balance at high speeds. One other subtle difference between these two toolholders is the thread used to hold the pull stud. CAT Tooling is all Imperial thread and BT Tooling is all Metric thread. Note that this affects the pull stud only, it does not affect the tool that they can hold, both types of tooling are sold to accept both Imperial and metric sized tools.
CAT-40 Toolholder
SK and HSK tooling, sometimes called "Hollow Shank Tooling", is much more
http://en.wikipedia.org/wiki/Milling_machine
7/3/2007
Milling machine - Wikipedia, the free encyclopedia
Page 4 of 8
common in Europe where it was invented than it is in the United States. It is claimed that HSK tooling is even better than BT Tooling at high speeds. The holding mechanism for HSK tooling is placed within the (hollow) body of the tool and, as spindle speed increases, it expands, gripping the tool more tightly with increasing spindle speed. There is no pull stud with this type of tooling. The situation is quite different for manual milling machines — there is little standardization. Newer and larger manual machines usually use NMTB tooling. This tooling is somewhat similar to CAT tooling but requires a drawbar within the milling machine. Furthermore, there are a number of variations with NMTB tooling that make interchangeability troublesome. Two other tool holding systems for manual machines are worthy of note: They are the R8 collet and the Morse Taper #2 collet. Bridgeport Machines of Bridgeport Connecticut so dominated the milling machine market for such a long time that their machine "The Bridgeport" is virtually synonymous with "Manual milling machine." The bulk of the machines that Bridgeport made from about 1965 onward used an R8 collet system. Prior to that, the bulk of the machines used a Morse Taper #2 collet system.
Boring head on Morse Taper Shank
As an historical footnote: Bridgeport is now owned by Hardinge Brothers of Elmira, New York.
See also Metalworking Machining
Metalworking: Electrical discharge machining | Electro chemical machining | Endmill | Engraving | Hobbing machine | Lathe | Machine tool | Machining | Milling cutter | Milling machine | Planer | Pantograph | Shaper
Milling and machining:
Metalworking topics:
Casting | CNC | Cutting tools | Drilling and threading | Fabrication | Finishing | Grinding | Jewellery | Lathe (tool) | Machining | Machine tooling | Measuring | Metalworking | Hand tools | Metallurgy | Milling | Occupations | Press tools | Smithing | Terminology | Welding
Retrieved from "http://en.wikipedia.org/wiki/Milling_machine" Category: Machine tools
This page was last modified 12:34, 14 June 2007. All text is available under the of the GNU Free Documentation License. (See Copyrights for details.) Wikipedia® is a ed trademark of the Wikimedia Foundation, Inc., a USed 501(c)(3) tax-deductible nonprofit charity.
