PowerPoint to accompany

Technology of Machine Tools 6th Edition

Krar • Gill • Smid

Milling Machines Section 12

Copyright © The McGraw-Hill Companies, Inc. Permission required for reproduction or display.

59-2

Milling Machines • Used to produce one or more machined surfaces accurately on workpiece – One or more rotary milling cutters

• Workpiece held on work table or holding device and brought into with cutter • Vertical milling machine most common • Horizontal milling machine handles operations normally performed by other tools




The Vertical Milling Machine Unit 59 Copyright © The McGraw-Hill Companies, Inc. Permission required for reproduction or display.

59-4

Objectives • List four main uses of a vertical milling machine • Describe how angular surfaces can be machined • List three types of vertical milling machines • State the purposes of the main parts of a knee and column machine

59-5

Vertical Milling Machine • Developed in 1860's • Combines vertical spindle of drill press with longitudinal and traverse movements of milling machine • Milling process may be vertical, horizontal, angular, or helical • Can be used for milling, drilling, boring, and reaming • Can machine in one, two, or three planes – X, Y, Z

59-6

Variety of Operations • • • • •

• Gear cutting Face milling • Drilling End milling • Boring Keyway cutting • Jig boring Dovetail cutting T-slot and circular Many facing operations slot cutting done with fly cutter (cost reduction).

59-7

Ram-Type Vertical Milling Machine

59-8

Parts of Ram-Type Vertical Mill • Base made of ribbed cast iron – May contain coolant reservoir

• Column often cast with base – Machined face provides ways for vertical movement of knee – Upper part machines to receive turret where overarm mounted

59-9

Parts of Ram-Type Vertical Mill • Overarm round and may be adjusted toward or away from column • Head attached to end of ram – Made to swivel head in one plane – Universal-type machines allow swivel in 2 planes

• Motor mounted on top of head – provides drive to spindle through V-belts




Cutting Speed, Feed, and Depth of Cut Unit 60


60-11

Objectives • Select cutting speeds and calculate the r/min for various cutters and materials • Select and calculate the proper feeds for various cutters and materials • Follow the correct procedure for taking roughing and finishing cuts

60-12

Factors Affecting the Efficiency of a Milling Operation • Cutting speed – Too slow, time wasted – Too fast, time lost in replacing/regrinding cutters

• Feed – Too slow, time wasted and cutter chatter – Too fast, cutter teeth can be broken

• Depth of cut – Several shallow cuts wastes time

60-13

Cutting Speed • Speed, in surface feet per minute (sf/min) or meters per minute (m/min) at which metal may be machined efficiently • Work machined in a lathe, speed in specific number of revolutions per min (r/min) depending on its diameter to achieve proper cutting speed • In milling machine, cutter revolves r/min depending on diameter for cutting speed

60-14

Important Factors in Determining Cutting Speed • • • • • •

Type of work material Cutter material Diameter of cutter Surface finish required Depth of cut taken Rigidity of machine and work setup

60-15

Milling Machine Cutting Speeds High-Speed Steel Cutter Material

ft/min

Alloy steel 40–70

m/min ft/min 12–20

Aluminum 500–1000 150–300 Bronze Cast iron

65–120 50–80

Carbide Cutter 150–250

m 45–75

1000–2000 300–60

20–35 200–400 15–25

125–200

60–120 40–60

Free m steel

100–150

30–45 400–600

120–18

Machine steel

70–100

21–30 150–250

45–75

Stainless steel

30–80

Tool steel

60–70

10–25 18–20

100–300

125–200

3

40–60

60-16

Inch Calculations • For optimum use from cutter, proper speed must be determined • Diameter of cutter affects this speed Calculate speed required to revolve a 3-in. diameter high-speed steel milling cutter for cutting machine steel (90 sf/min). simplify formula CS ( ft ) 90 12 xCS 4 xCS r / min     circumfere nce(in.) 3 x3.1416 3 x3.1416 D

4 x90 360 r / min    120 3 3

60-17

Cutting Speed Rules for Best Results 1. For longer cutter life, use lower CS in recommended range 2. Know hardness of material to be machined 3. When starting, use lower range of CS and gradually increase to higher range 4. Reduce feed instead of increase cutter speed for fine finish 5. Use of coolant will generally produce better finish and lengthen life of cutter

60-18

Milling Machine Feed • Defined as distance in inches (or mm) per minute that work moves into cutter – Independent of spindle speed

• Feed: rate work moves into revolving cutter – Measured in in/min or mm/min

• Milling feed: determined by multiplying chip size (chip per tooth) desired, number of teeth in cutter, and r/min of cutter • Chip, or feed, per tooth (T or (FPT): amount of material that should be removed by each tooth of the cutter

60-19

Factors in Feed Rate 1. 2. 3. 4. 5. 6. 7.

Depth and width of cut Design or type of cutter Sharpness of cutter Workpiece material Strength and uniformity of workpiece Type of finish and accuracy required Power and rigidity of machine, holding device and tooling setup

60-20

Recommended Feed Per Tooth (High-speed Cutters) Sample Table Face Helical See Table 60.2 in Text Mills Mills Material

in.

mm

Alloy steel

.006

0.15 .005

Aluminum

.022

0.55

Slotting and Side Mills in. mm in. 0.12 .004 0.1

.018 0.45 .013 0.33

Brass and bronze (medium) Table.014 0.35 .011 0.28 .008 shows feed per tooth for roughing cuts –0.2 Cast iron for finishing cut, the feed per tooth would be reduced or even 1/3 of value (medium) .013to1/2 0.33 .010 0.25 shown .007 0.18

60-21

Ideal Rate of Feed • Work advances into cutter, each successive tooth advances into work equal amount – Produces chips of equal thickness • Feed per tooth

Feed = no. of cutter teeth x feed/tooth x cutter r/min Feed (in./min) = N x T x r/min

60-22

Examples: Feed Calculations Inch Calculations Find the feed in inches per minute using a 3.5 in. diameter, 12 tooth helical cutter to cut machine steel (CS80) First, calculate proper r/min for cutter: 4 xCS 4 x80 r / min    91 D 3.5 Feed(in/min) = N x T x r/min =12 x .010 x 91 = 10.9 or 11 in/min

60-23

Direction of Feed: Conventional • Most common method is to feed work against rotation direction of cutter

60-24

Direction of Feed: Climbing • When cutter and workpiece going in same direction • Cutting machine equipped with backlash eliminator • Can increase cutter life up to 50%

60-25

Advantages of Climb Milling • Increased tool life (up to 50%) – Chips pile up behind or to left of cutter

• Less costly fixtures required – Forces workpiece down so simpler holding devices required

• Improved surface finishes – Chips less likely to be carried into workpiece

60-26

Advantages of Climb Milling • Less edge breakout – Thickness of chip tends to get smaller as nears edge of workpiece, less chance of breaking

• Easier chip removal – Chips fall behind cutter

• Lower power requirements – Cutter with higher rake angle can be used so approximately 20% less power required

60-27

Disadvantages of Climb Milling • Method cannot be used unless machine has backlash eliminator and table gibs tightened • Cannot be used for machining castings or hot-rolled steel – Hard outer scale will damage cutter

60-28

Depth of Cut • Roughing cuts should be deep – Feed heavy as the work and machine will permit – May be taken with helical cutters having fewer teeth

• Finishing cuts should be light with finer feed – Depth of cut at least .015 in. – Feed should be reduced rather than cutter speeded up




End Mills Unit 61


61-30

Objectives • Name two types of material of which end mills are made and state their application • Describe the purpose of two-flute and multiple-flute end mills • Know the purpose of climb and conventional milling

61-31

End Mills • Greatly improved since days of carbon-steel cutting tools • High-speed steel (HSS) cutting tools maintain very important place in metalcutting industry • Variables influencing cutter decision – Part shape, work material, wear resistance of tool, red hardness, machine condition

61-32

High-Speed End Mills • Relatively inexpensive, easy to get and do jobs quite well • Capable of machining with close tolerances • Single most versatile rotary tools used on conventional and CNC machines • If need harder tool, frequent solution is cobalt end mill – Less expensive than carbide, long tool life

61-33

Carbide End Mills • Carbide properties vs. HSS tool materials – Higher hardness – Greater rigidity – Can withstand higher cutting temperatures

• Can run at higher speeds and feeds – Increasing production rates – Providing long tool life

• High-performance tool material

61-34

Common Machining Operations Performed with HSS, cobalt, solid carbide, or indexable insert type end mill • Open and closed pockets • Facing operations for small areas • Counterboring and spotfacing

• Peripheral end milling • Milling of slots and keyways • Channel groves, face grooves and recesses • Chamfering


61-35

End Mill Forms • Ground into required shapes – Flat bottom end mill (most common) • Used for all operations requiring flat bottom and sharp corner between wall and bottom

– End mill with full radium (ball nose end mill) • Used for 3D machining of various surfaces

– End mill with corner radium (bull nose end mill) • Used for either 3D work or for flat surfaces that require corner radius between wall and bottom


61-36

Three common types and the relationship of the radius to the tool diameter.

61-37

Common Types of End Mills • Two-Flute End Mill – Have large, open flutes that provide excellent chip flow – Recommended for general-purpose milling – Always select shortest end mill possible for job to obtain maximum tool rigidity – Can have different length lips on end • Mill slots, keyways, plunge cut and drill shallow holes

61-38

Common Types of End Mills • Three-Flute End Mill – – – –

With end teeth Used to plunge into workpiece Used to mill slots, pockets and keyways Minimize chatter and better chip removal

• Roughing End Mill – Designed to provide best performance while machining broad range of materials – Allows deeper cuts at faster feed rates

61-39

Direction of Cut: Climb • Cutter rotation and table feed going in same direction • Vertical milling: cutter tendency to pull work into cutting flutes • Horizontal milling: cutter pushes work against table • Maximum thickness of chip occurs at beginning of cut and exits when thin – Result – chip absorbs heat generated Copyright © The McGraw-Hill Companies, Inc. Permission required for reproduction or display.

61-40

Direction of Cut: Conventional • When cutter rotation and table feed are moving in opposite directions – Has tendency to pull or lift workpiece up from table

• Important that work be held securely

61-41

Direction of Cut

61-42

Milling Cutter Failure • Excessive heat – One of main causes of total cutting edge failure – Caused by cutting edges rubbing on workpiece and chips sliding along faces of teeth – Ever-expanding cycle – Minimized by correct speeds, feeds, and coolant

• Abrasion – Wearing-away action caused by metallurgy of workpiece – dulls cutting edges and cause "wear lands"

61-43

Chipping or Crumbling of Cutting Edges • Small fractures occur and small areas of cutting edges chip out when cutting forces impose greater load on cutting edges – Material left uncut imposes greater cutting load – Condition progressive • Once started will lead to total cutter failure

• Dull edges increase friction, heat, and horsepower requirements

61-44

Clogging • Some workpiece materials have "gummy" composition – Chips long, stringy and compressible

• Chips clog or jam into flute area • Minimize by reducing depth or width of cut, reducing FPT, using tools with fewer teeth, creating more chip space and coolant – Coolant applied under pressure to flush out flute area

61-45

Work Hardening of Workpiece • Can cause milling cutter failure • Result of action of cutting edges deforming or compressing surface of workpiece, causing change in work material structure that increases its hardness • Important to use sharp tools at generous power feeds and use coolant • Causes glaze – break by vapor honing or abrading surface with coarse emery cloth




Vertical Mill Operations Unit 62


62-47

Objectives • Align the vertical head and vise to within ±.001 in. (0.02 mm) • Insert and remove end mills from spring collets • Accurately machine a block square and parallel • Drill holes to an accurate location

62-48

Vertical Milling Machine • Versatile and easy setup • Performs wide variety of operations – – – –

End milling, face milling Keyway and dovetail cutting T-slot and circular slot cutting Gear cutting, drilling, boring, reaming

• Cutting tools used relatively small so cost lower

62-49

Aligning the Vertical head • Head must be square to table (90º) Procedure to check spindle alignment 1. Mount dial indicator on suitable rod, bent at 90º and held in spindle 2. Position indicator over front Y axis of table 3. Carefully lower spindle until indicator button touches table and dial indicator s no more than ¼ revolution; set bezel to zero; Lock spindle in place

62-50

4. Carefully rotate spindle 180º by hand until button bears on opposite side of table; Compare readings 5. If differences, loosen locking nuts on swivel mounting and adjust head until indicator s approximately ½ difference between two readings; Tighten locking nuts 6. Recheck accuracy of alignment 7. Rotate vertical mill spindle 90º and set dial indicator as in step 3

62-51

8. Rotate machine spindle 180º, check reading at other end of table 9. If two readings do not coincide, repeat step 5 until readings are same 10. Tighten locking nuts on swivel mount 11. Recheck readings and adjust if necessary

62-52

Aligning the Vise • When vise aligned on vertical milling machine, dial indicator may be attached to quill or head by clamps or magnetic base • Same method of alignment followed as outlined for aligning vise on horizontal milling machine

62-53

Collets • Hold end mills, cutting tools and accessories in machine spindle • Spring collet – Pulled into spindle by draw-bar that closes on cutter shank – Driven by means of friction between collet and cutter

• Solid collet • More rigid • Pulled into spindle by draw-bar • Driven by setscrews that bear against flats of cutter shank Copyright © The McGraw-Hill Companies, Inc. Permission required for reproduction or display.

62-54

To Mount a Cutter in a Spring Collet 1. Shut off electric power to machine 2. Place proper cutter, collet, and wrench on piece of masonite, wood, or soft plastic on table Copyright © The McGraw-Hill Companies, Inc. Permission required for reproduction or display.

62-55

3. 4. 5. 6. 7. 8. 9. 10.

Clean taper in machine spindle Place draw-bar into hole in spindle top Clean taper and keyway on collet Insert collet into spindle bottom, press up, and turn until keyway aligns with key in spindle Hold collet up with one hand and with other, thread draw-bar clockwise into collet Hold cutting tool with cloth and insert it into collet for full length of shank Tighten draw-bar into collet (clockwise) by hand Hold spindle brake lever and tighten draw-bar tightly as possible with wrench

62-56

Procedure to Remove Cutter from a Collet •

Operation for removing cutting tools similar to mounting, but in reverse order 1. Shut off electric power to machine 2. Place piece of masonite, wood, or soft plastic on machine table to hold necessary tools 3. Pull on spindle brake lever to lock spindle, loosen draw-bar with wrench (counterclockwise)

62-57

4. Loosen draw-bar, by hand, only about three full turns 5. Hold cutter with cloth 6. With soft-faced hammer, strike down sharply on head of draw-bar to break taper between collet and spindle 7. Remove cutter from collet 8. Clean cutter and replace it in its proper storage place where it will not be damaged by other tools

62-58

Machining a Block Square and Parallel •

Important that each side be machined in definite order Machining Side 1 1. Clean vise thoroughly and remove all burrs from workpiece, vise and parallels 2. Set work on parallels in center of vise with largest surface (side 1) facing up

59-59

62-60

Procedure to Machine an Angular Surface 1. Lay out angular surface 2. Clean vise 3. Align vise with direction of feed •

Utmost importance

4. Mount work on parallels in the vise Copyright © The McGraw-Hill Companies, Inc. Permission required for reproduction or display.

62-61

5. Swivel vertical head to required angle 6. Tighten quill clamp 7. Start machine and raise table until cutter touches work •

Raise table until cut desired depth

8. Take trial cut for about .50 in. 9. Check angle with protractor 10. If angle correct, continue cut 11. Machine to required depth, taking several cuts if necessary

62-62

3. With center drill spot each hole to be tapped to slightly larger than tap diameter 4. Drill hole to correct tap drill size for size of tap to be used 5. Mount stub center in drill chuck


62-63

Slots and Keyseats •

May be cut in shafts more easily on vertical milling machine, using a two- or three-fluted end mill Procedure for Cutting 1. Layout position of keyseat on shaft, and scribe reference lines on end of shaft Copyright © The McGraw-Hill Companies, Inc. Permission required for reproduction or display.

62-64

6. Lower table until cutter clears workpiece 7. Move table over amount equal to half diameter of shaft plus half diameter of cutter plus thickness of paper


62-65

Woodruff Keys • Used when keying shafts and mating parts • Woodruff keyseats can be cut more quickly than square keyseats – Semicircular in shape and can be purchased in standard sizes designated by E numbers


62-66

Woodruff Keyseat Cutters • Have shank diameters of ½ in. for cutters up to 1 ½ in. in diameter • Cutters over 2 in. in diameter mounted on arbor • Size stamped on shank • Last two digits indicate nominal diameter in eighths of inch • Preceding numbers nominal width of cutter in thirty-seconds of an inch Copyright © The McGraw-Hill Companies, Inc. Permission required for reproduction or display.




Horizontal Milling Machines and Accessories Unit 64


64-68

Objectives • Recognize and explain the purposes of four milling machines • Know the purposes of the main operational parts of a horizontal and a vertical milling machine • Recognize and state the purposes of four milling machine accessories and attachments

64-69

Classification of Horizontal Milling Machines 1. Manufacturing-type •

Cutter height is controlled by vertical movement of headstock

2. Special-type •

Designed for specific milling operations

3. Knee-and-column-type •

Relationship between cutter height and work controlled by vertical movement of table

64-70

Plain Manufacturing Type Milling Machine


64-71

Cross section of a Cincinnati Machine Backlash Eliminator


64-72

Arbors, Collets, and Adapters


64-73

Vises Universal Vise Plain Vise

Swivel Base Vise Copyright © The McGraw-Hill Companies, Inc. Permission required for reproduction or display.

64-74

Fixturing Systems

Easy-to-adjust Stop Copyright © The McGraw-Hill Companies, Inc. Permission required for reproduction or display.

Quick-change self-locking system

64-75

Indexing, or Dividing, Head • Permits cutting of bolt heads, gear teeth, ratchets • Revolve work as required to cut helical gears and flutes in drills, reamers, and other tools – When connected to lead screw of milling machine




Milling Cutters Unit 65


65-77

Objectives • Identify and state the purposes of six standard milling cutters • Identify and state the purposes of four special-purpose cutters • Use high-speed steel and carbide cutters for proper applications

65-78

Plain Milling Cutters • Most widely used • Cylinder of high-speed steel with teeth cut on periphery • Used to produce flat surface • Several types – – – –

Light-duty Light-duty helical Heavy-duty High-helix


65-79

Light-Duty Plain Milling Cutter • Less than ¾ in. wide, straight teeth • Used for light milling operations • Those over ¾ in have helix angle of 25º – Too many teeth to permit chip clearance


65-80

Heavy-Duty Plain Milling Cutters • Have fewer teeth than light-duty type – Provide for better chip clearance

• Helix angle varies up to 45º – Produces smoother surface because of shearing action and reduced chatter

• Less power required


65-81

High-Helix Plain Milling Cutters • Have helix angles from 45º to over 60º • Suited to milling of wide and intermittent surfaces on contour and profile milling • Usually mounted on milling machine arbor – Sometimes shank-mounted with pilot on end and used for milling elongated slots Copyright © The McGraw-Hill Companies, Inc. Permission required for reproduction or display.

65-82

Standard Shank-Type Helical Milling Cutters • Called arbor-type cutters • Used for – Milling forms from solid metal – Removing inner sections from solids

• Inserted through previously drilled hole and ed at outer end with type A arbor


65-83

Side Milling Cutters • Comparatively narrow cylindrical milling cutters with teeth on each side and on periphery • Used for cutting slots and Straight for face and straddle milling operations • Free cutting action at high Staggered speeds and feeds • Suited for milling deep, narrow slots Copyright © The McGraw-Hill Companies, Inc. Permission required for reproduction or display.

65-84

Half-Side Milling Cutters • Used when only one side of cutter required • Also make with interlocking faces so two cutter may be placed side by side for slot milling • Have considerable rake – Able to take heavy cuts


65-85

Face Milling Cutters • Generally over 6 in. in diameter – Have inserted teeth made of high-speed steel held in place by wedging device

• Most cutting action occurs at beveled corners and periphery of cutter • Makes roughing and finishing cuts in one Copyright © The McGraw-Hill Companies, Inc. Permission required for reproduction or display.

65-86

Shell End Mills • Face milling cutters under 6 in. • Solid, multiple-tooth cutters with teeth on face and periphery • Held on stub arbor – May be threaded or use key in shank to drive cutter Copyright © The McGraw-Hill Companies, Inc. Permission required for reproduction or display.

65-87

Angular Cutters • Single-angle – Teeth on angular surface – May or may not have teeth on flat – 45º or 60º

• Double-angle – Two intersecting angular surfaces with cutting teeth on both – Equal angles on both side of line at right angle to axis Copyright © The McGraw-Hill Companies, Inc. Permission required for reproduction or display.

65-88

Types of Formed Cutters

Concave Copyright © The McGraw-Hill Companies, Inc. Permission required for reproduction or display.

Convex

Gear Tooth

65-89

Metal-Slitting Saws


65-90

T-Slot Cutter • Used to cut wide horizontal groove at bottom of T-slot – After narrow vertical groove machined with end mill or side milling cutter

• Consists of small side milling cutter with teeth on both sides and integral shank for mounting


65-91

Dovetail Cutter • Similar to single-angle milling cutter with integral shank • Used to form sides of dovetail after tongue or groove machined • Obtained with 45º, 50º, 55º, or 60º angles


65-92

Woodruff Keyseat Cutter • Similar in design to plain and side milling cutters – Small (up to 2 in) solid shank, straight teeth – Large mounted on arbor with staggered teeth

• Used for milling semicylindrical keyseats in shafts • Designated by number system Copyright © The McGraw-Hill Companies, Inc. Permission required for reproduction or display.




Milling Machine Setups Unit 66


66-94

Objectives • Mount and remove a milling machine arbor • Mount and remove a milling cutter • Align the milling machine table and vise

66-95

Milling Machine Safety 1. Be sure work and cutter are mounted securely before taking cut 2. Always wear safety glasses 3. When mounting or removing milling cutters, always hold them with cloth to avoid being cut 4. When setting up work, move table as far as possible from cutter to avoid cutting your hands

66-96

5. Be sure cutter and machine parts clear work 6. Never attempt to mount, measure, or adjust work until cutter completely stopped 7. Keep hands, brushes, and rags away from revolving milling cutter at all times 8. Do not use an excessively heavy cut or feed •

Cause cutter to break and fly apart

66-97

9. Always use brush, not rag, to remove cuttings after cutter has stopped revolving 10. Never reach over or near revolving cutter •

Keep hands at least 12 in from revolving cutter

11. Keep floor around machine free from chips, oil, and cutting fluid

66-98

Milling Machine Setups 1. Check if machine surface and accessory free from dirt and chips prior to mounting 2. Do not place tools, cutters, or parts on milling machine table 3. Use keys on all but slitting saws when mounting cutters

66-99

4. Check that arbor spacers and bushings clean and free from burrs 5. When tightening arbor nut, take care to only hand tighten •

Hammer or wrench will strip threads and bend or damage accessory or part

6. When mounting work in vise, tighten vise securely by hand and tap into place with lead or soft-faced hammer




The Indexing, or Dividing, Head Unit 68 Copyright © The McGraw-Hill Companies, Inc. Permission required for reproduction or display.

68-101

Objectives • Calculate and mill flats by simple and direct indexing • Calculate the indexing necessary with a wide-range divider • Calculate the indexing necessary for angular and differential indexing

68-102

Indexing (Dividing) Head • One of most important attachments for milling machine • Used to divide circumference of workpiece into equally spaced divisions when milling gears, splines, squares and hexagons • Also used to rotate workpiece at predetermined ratio to table feed rate

68-103

Index Head Parts • Headstock with index plates • Headstock change gears • Quadrant


• Universal chuck • Footstock • Center rest

68-104

G – gear housing

D - crank A – large index plate B - crank

C – small index plate


Milling-machine-ppt.ppt 1k6u2v

Overview 1s532p

More details 6h715l

More Documents from "Ravichandran G" 5x541n

Tech Forging Process 295m36

Theory Of Metal Cutting 2.ppt 641m5a

Gasoline-direct-injection.ppt 9314l

Energy Resources Ks3 4p2624

Conduction-convection-radiation-powerpoint.ppt 494y5o

Drilling-machine.ppt 1j2a1d
