Simplify your thermal efficiency calculation Standard chats and spreadsheet help S. Patel Syncrude Canada Ltd, Alberta, Canada Most process engineers recognize the value of furnace efficiency calculation, yet many are intimidated by the idea of performing them. The thermal efficiency calculation is important for evaluating its furnace performance. Engineers can no longer hope to be succesfull in evaluating furnace operation without a garsp of fundamentals of and thei applications to solving furnace problems. Focusing on fundamentals of furnace calculation provides a framework for engineer routinely wants to perform efficiency calculation, a spreadsheet program is necerssary. This article can help develop it. A pevious article shows how to calculate the thermal efficiency using flue gas analysis. The method described in this article considers fuel gas analysis and stack temperature to calculate the thermal efficiency. The procedure uses standard chart for excess air and enthalpy of the flue gas components to simplify the calculations. The difference between the simplified and the correct one is smaller, and its impact on the final calculation is negligible. The method described is intended for fired heaters burning only gaseous only. By understanding the procedure described, engineers will able to calculate the following : -

Lower heating value (LHV) or fuel heat combustion Combustion air and flue gas flowrates. Flue gas composition (both wet and dry basis) Funace thermal efficiency

Efficiency. The net thermal efficiency is equal to the total heat absorbed divided by the total heat input. The heat absorbed is equal to the total heat input minus the total heat losses from the system. The net thermal efficiency for the arrangements shown in Fig.1 can be determined by following equation :

Therefore,

Where,

e= Net thermal efficiency, % LHV =Heat input or lower heating value of the fuel, Btu/lb of fuel Ha = Heat input in the form of sensible heat of air, Btu/lb of fuel Qs = Calculated stack heat losses, Btu/lb of fuel

Qr = Assumed radiation heat loss, Btu/lb of fuel Heat input. Total heat input is the sum of the fuel LHV and sensible heat of air and fuel. LHV/lb of fuel is calculated using fuel gas analysis and the net heating value of fuel components. The heat of combustion is calculated by multiplying the weight fraction of fuel components by its net heating value. The total heat of combustion is then divided by the total fuel weight to obtain the LHV. Ha and Hf are estimated using the following equation :

Where : air = Spesific heat of air fuel=Spesific heat of fuel Tt=Combustion air temperature Tf=Fuel temperature Td= datum temperature (60oF) Heat Losses. Total heat losses are the sum of stack and radiation heat losses. The stack heat losses, Qs/lb of fuel, are determined from a summation of the enthalpy of the flue gas components at the stack temperature, Te. Fig. 2 is used to estimate the enthalpy of flue gas component/lb of fuel. One of the key steps in estimating the heat losses is to calculated the flue gas components produced/lb of fuel : Flue gas= Fuel + Combustion Air So, the first step in calculating the heat losses is to determine how much combustion air/lb of fuel is required. Estimating the theoritical or stoichiometric moles of oxygen required to complete the combustion will help to calculate the combustion air. The theoritical moles of oxygen required for combustion are calculated using the combustion reaction shown in table 1. For example, one mole of H2 requires 0,5 moles of oxygen. So, if H2 is one of the fuel components, the volume fractionation of H2 is multiplied 0,5 to calculate the moles of oxygen required by H2. The moles of oxygen required bu other fuel components are calculated similarly. Once the total theoritical moles of oxygen are calculated, its very easy to calculated the moles of combustion air. Air is 21% oxygen by volume. So Theoritical moles of combustion air = moles of oxygen x 100/21

The total theoritical moles of air are then corrected for excess air to get the actual moles of combustion air required. , Actual moles of air = theoritical moles of air + excess air Based on percent oxygen content in the flue gas (generally, an oxygen analyzer reading is used here), excess air can be estimared using fig.3. this chart can be used for natural and refinery fuel gases. After correcting the theoritical moles of combustion air with excess air, the combustion air/lb of fuel is calculated by multiplying the moles of combustion air by 29 (MW of air) and then dividing by the total fuel weight. Once the quantity of combustion air is determined the next step is calculate flue gas components produced/lb of fuel. The flue gas components are mainly CO2, H2O, SO2, O2 and N2. Hence, Moles of flue gas components = CO2 (moles of CO2 formed during combustion + moles of CO2 available as a fuel) +H2O ( moles of H2O formed during combustion + moles of H2O available as a fuel) + SO2 (moles of SO2 formed during combustion + moles of SO2 available as a fuel) + O2 (moles of oxygen supplied – moles of oxygen used during the combustion) + N2 (moles of N2 available from air + moles of N2 available as a fuel)
