Contents Electrophoresis overview

4

Select precast gel

Protein gel electrophoresis is a simple way to separate proteins prior to downstream detection or analysis, and is a critical step in most workflows that isolate, identify, and characterize proteins. We offer a complete array of products to rapid, reliable protein electrophoresis for a variety of applications, whether it is the first or last step in your workflow. Our portfolio of high-quality protein electrophoresis products unites gels, stains, molecular weight markers, running buffers, and blotting products for your experiments.

8 10

Gel selection guide Gels

Prepare samples and select buffers Sample prep kits 26 Buffers and reagents 28 Buffers and reagents selection guide 29

Select the standard Protein ladders 34 Protein standards selection guide 36

Choose the electrophoresis chamber system and power supply Electrophoresis chamber systems 50 Electrophoresis chamber system selection guide 51 Power supplies 58

Run the gel Gel run conditions 59 Troubleshooting tips 60

Stain the gel Protein stains 62 Protein stains selection guides 63, 67, 69, 70 Electrophoretic staining technology 71

Post stain Transfer and detection 74

Appendix Protocol quick reference 76 Ordering information 81

For a complete listing of all available products and more, visit thermofisher.com/separate

For ordering information refer to page XX. For quick reference on the protocol please refer to page XX.

Precast protein gels

Sample preparation and electrophoresis buffers

Protein standards

Electrophoresis chamber systems and power supplies

Electrophoresis run conditions

Protein gel stains

3

4

Select precast gel


Select the standard


Run the gel

Stain the gel

Post stain

Electrophoresis matrix Electrophoresis is defined as the Two types of matrices are commonly used in transport of charged molecules electrophoresis—polyacrylamide and agarose. The matrices act as porous media and behave like a molecular sieve. through a solvent by an electric Separation of molecules is dependent upon the gel pore size of the matrix used. Agarose has a large pore size and is ideal field. Electrophoresis is a simple, for separating macromolecules such as nucleic acids and protein complexes. Polyacrylamide has a smaller pore size and is ideal for rapid, and sensitive analytical separating most proteins and smaller nucleic acids. tool for separating proteins and Polyacrylamide gel electrophoresis nucleic acids. Any charged ion or (PAGE) molecule will migrate when placed Polyacrylamide gels are generated by the polymerization of acrylamide monomers. These monomers are crosslinked into in an electric field. Most biological long chains by the addition of bifunctional compounds such as (bis), which react with the free molecules carry a net charge at any N,N,-methylenebisacrylamide functional groups of the chain termini. The concentration of acrylamide and bisacrylamide determines the pore size of the gel. pH other than at their isoelectric The higher the acrylamide concentration, the smaller the pore size, resulting in resolution of lower molecular weight molecules and point and will migrate at a rate vice versa. proportional to their charge density. PAGE allows one to separate proteins for different applications

The mobility of a biological molecule through an electric field will depend on the following factors:

based on: • The acrylamide matrix • Buffer systems

Electrophoresis conditions

Linear vs. gradient gels

The separation of molecules is dependent on the electrophoresis conditions. Electrophoresis can be performed under the following conditions:

Gels that have a single acrylamide percentage are referred to as linear gels, and those with a range are referred to as gradient gels. The advantage of using a gradient gel is that it allows the separation of a broader range of proteins than a linear gel.

Continuous vs. discontinuous gels Researchers occasionally refer to gels as continuous or discontinuous. A continuous gel is a gel that has been formed from a single acrylamide solution in the entire gel cassette. A discontinuous gel is formed from two acrylamide solutions, a small, low-percentage stacking gel where the protein wells reside, and a larger portion of gel that separates the proteins. In the traditional Tris-glycine protein gel system, the proteins are stacked in the stacking gel between the highly mobile leading chloride ions (in the gel buffer) and the slower, trailing glycine ions (in the running buffer). The reason for using the stacking gel is to improve the resolution of the bands in the gel. These stacked protein bands undergo sieving once they reach the separating gel.

Mini vs. midi protein gels Commercial gels are available in two size formats, minigels and midigels. Both gels have similar run lengths, but midigels are wider than minigels, allowing midigels to have more wells or larger wells. The additional wells in the midigels permit more samples or large sample volumes to be loaded onto one gel.

Denaturing conditions Electrophoresis is performed under denaturing conditions using an anionic detergent such as sodium dodecylsulfate (SDS). SDS denatures and unfolds the protein by wrapping around the hydrophobic portions. SDS binds at a ratio of ~1.4 g SDS per gram of protein. The resultant SDS-protein complexes are highly negatively charged and are resolved in the gel based on their size.

Nondenaturing (native) conditions Electrophoresis is performed under nondenaturing (native) conditions using buffer systems that maintain the native protein conformation, subunit interaction, and biological activity. During native electrophoresis, proteins are separated based on their charge to mass ratios.

Reducing conditions Electrophoresis is performed under reducing conditions using reducing agents such as dithiothreitol (DTT), β-mercaptoethanol (β-ME) or tris(2-carboxyethyl)phosphine (TCEP). The reducing agents completely unfold the denatured proteins into their subunits by cleaving the disulfide bonds between cysteine residues.

Buffer systems

• Electrophoresis conditions

Electrophoresis is performed using continuous or discontinuous buffer systems. A continuous buffer system utilizes only one buffer in the gel and running buffer. A discontinuous buffer system utilizes a different gel buffer and running buffer1. This system may also use two gel layers of different pore sizes and different buffer composition (the stacking and separating gel). Electrophoresis using a discontinuous buffer system results in concentration of the sample and higher resolution.

• Field strength • Net charge on the molecule • Size and shape of the molecule • Ionic strength

Did you know? Arne Tiselius won the Nobel Prize in Chemistry for electrophoretic analysis of serum proteins in 1948.

Reference

• Properties of the matrix through which the molecules migrate (e.g., viscosity, pore size)

The acrylamide matrix

1. Ornstein L (1964) Disc electrophoresis. 1. Background and theory. Ann N Y Acad Sci 121:321-349.

Mini Gel Tank



Protein standards



Protein gel stains

5

6

Select precast gel

Comparison of discontinuous buffer systems SDS-PAGE utilizes a discontinuous buffer system to concentrate or “stack” samples into a very sharp zone in the stacking gel at the beginning of the run. In a discontinuous buffer system, the primary anion in the gel is different (or discontinuous) from the primary anion in the running buffer. Both the Invitrogen™ NuPAGE™ systems (Bis-Tris and Tris-acetate gels) and the Laemmli (Tris-glycine) system are examples of discontinuous buffer systems and work in a similar fashion. However, the NuPAGE system operates at a lower pH as a result of the proprietary ions that are in the system. In a Tris-glycine system (Figure 1), three ions are primarily involved: •C hloride (–), supplied by the gel buffer, serves as the leading ion because it has the highest attraction to the anode relative to other anions in the system. • Glycine (–), the primary anion provided by the running buffer, serves as the trailing ion, because it is only partially negatively charged and remains behind the more highly charged chloride ions in a charged environment. • Tris base (+), is a common ion present in both the gel and the running buffers. During electrophoresis, the gel and buffer ions in the Tris-glycine system form an operating pH of 9.5 in the separating region of the gel. In the case of the Bis-Tris system (Figure 2), three ions are primarily involved: • Chloride (–) supplied by the gel buffer, serves as the fast-moving leading ion. • MES or MOPS (–) (depending on the running buffer choice) serves as the trailing ion. ∙ MES: 2-(N-morpholino) ethane sulfonic acid ∙ MOPS: 3-(N-morpholino) propane sulfonic acid • Bis-Tris (+) acts as the common ion present in the gel while Tris (+) is provided by the running buffer.

With the Tris-acetate system (Figure 3), three ions are primarily involved: • Acetate (–), the leading ion from the gel buffer • Tricine (–), the trailing ion from the running buffer • Tris (+), the common ion (in both gel and running buffer) This system also operates at a significantly lower pH than the Trisglycine system, resulting in less gel-induced protein modifications. The diagrams below (Figures 1, 2, and 3) summarize the migration differences in the stacking gel of each system.


Select the standard


Run the gel

Stain the gel

Post stain

7

Select precast gel High-performance precast protein gels If you are doing standard one-dimensional protein electrophoresis, we have a broad range of solutions to fit your research needs. Our selection of precast gels consists of several different chemistries, well formats, and gel sizes, so you can get the protein separation you need for accurate downstream results. Bolt Bis-Tris Plus gel.

Learn more at thermofisher.com/proteingels GLYCINE (Trailing Ion)

PROTEIN/SDS COMPLEX (Stacked Proteins)

CHLORIDE (Leading Ion)

PROGRESSION OF RUN

Figure 1. The Tris-glycine gel system. • Gel buffer ions are Tris and chloride (pH 8.7) • Running buffer ions are Tris, glycine, and SDS (pH 8.3) • Gel operating pH is 9.5

Common Ion is Tris, present in the gel and running buffers

MES or MOPS (Trailing Ion)


CHLORIDE (Leading Ion)

Figure 2. The Bis-Tris gel system. • Gel buffer ions are Bis-Tris and chloride (pH 6.4) • Running buffer ions are Tris, MES or MOPS, and SDS (pH 7.3) • Gel operating pH is 7.0

Precast gels Popular gel chemistries

Specialty gels

• NuPAGE Bis-Tris gels

• Novex Tricine gels

• NuPAGE Tris-Acetate gels

• NativePAGE gels

• Bolt Bis-Tris Plus gels

• Novex IEF gels

• Novex Tris-Glycine gels

• Novex Zymogram gels • E-PAGE gels

Did you know? Over 45 years ago, Ulrich K. Laemmli first published SDS-PAGE as a method for cleavage analysis of structural proteins in bacteriophage T4.

PROGRESSION OF RUN Common Ion is Bis-tris, present in the gel

Casting your own gels? TRICINE (Trailing Ion)


ACETATE (Leading Ion)

Figure 3. The Tris-acetate gel system. • Gel buffer ions are Tris and acetate (pH 7.0) • Running buffer Ions are Tris, tricine, and SDS (pH 8.3) • Gel operating pH is 8.1

We offer preassembled empty cassettes, buffers, and reagents.

 Learn more at thermofisher.com/gelcastingaccessories

PROGRESSION OF RUN Common Ion is Tris, present in the gel and running buffer

The combination of a lower-pH gel buffer (pH 6.4) and running buffer (pH 7.3–7.7) leads to a significantly lower operating pH (pH 7.0) during electrophoresis, resulting in better sample integrity and gel stability.



Protein standards



Protein gel stains

8


Select precast gel

Select the standard

Gel selection guide

Choose the electrophoresis chamber system and power supply chamber system and power supply

Run the gel

Stain the gel

Find the right gel for your research needs based on molecular weight, downstream applications, and throughput requirements.

Molecular weight Low molecular weight proteins and peptides (>2.5 kDa)

High molecular weight proteins (<500 kDa)

Novex Tricine gels

NuPAGE Tris-Acetate gels

High-sensitivity western blotting

Broad-range molecular weight separation

Low throughput

Medium or high throughput

Application

E-PAGE 48-well or 96-well gels

Downstream applications requiring high protein integrity (e.g., mass spectrometry)

Large sample volume for high detection sensitivity

Bolt Bis-Tris Plus gels

NuPAGE Bis-Tris gels






A

The most widely used gel system for separating a broad range of proteins by SDS-PAGE is the Laemmli system, which uses Tris-glycine gels comprising a stacking gel component that helps focus the proteins into sharp bands at the beginning of the electrophoretic run and the resolving gel component that separates the proteins based on size. This classic system uses a discontinuous buffer system where the pH and ionic strength of the buffer used for running the gel (Tris, pH 8.3) is different from the buffers used in the stacking gel (Tris, pH 6.8) and resolving gel (Tris, pH 8.8). The highly alkaline operating pH of the Laemmli system may cause band distortion, loss of resolution, or artifact bands. The major causes of poor band resolution with the Laemmli system are:

Novex Tris-Glycine gels

• Hydrolysis of polyacrylamide at the high pH of the resolving gel, resulting in a short shelf life of 8 weeks • Chemical alterations such as deamination and alkylation of proteins due to the high pH of the resolving gel

Native separation

Molecular weight 1st dimension 2nd dimension

Isoelectric point

NativePAGE gels

Novex Tris-Glycine gels with native buffers

Novex IEF gels

ZOOM™ IPG strips

NuPAGE Bis-Tris gels, 2D well

Novex Tris-Glycine gels, 2D well

Novex Tris-Glycine gels, 2D well

Novex Tris-Glycine ZOOM™ gels, IPG well

NuPAGE Bis-Tris gels, 2D well

NuPAGE Bis-Tris ZOOM gels, IPG well

 Find the right mini gel using our interactive gel selection tool at thermofisher.com/minigelselection

For ordering information refer to pages 81–87.

Protease activity Novex Zymogram gels (casein, blue casein, or gelatin substrates)

9

Choose the right gel chemistry for your research needs Bis-Tris chemistry vs. Tris-glycine chemistry

Denaturing separation

Coomassie dye or silver staining
