PLANMECA OY

Features Technical Specifications 7.5.2008

1/(3)

PLANMECA PROLINE XC DIGITAL PANORAMIC X-RAY UNIT

Main features

EH: ProlineXC_digital_specs_1.doc

•

Easy to use

•

Easy and fast patient positioning with 3 positioning laser lights, patient facing the , fully motorized patient positioning system

•

Small size and light weight stand, total weight 108 kg

•

Rotating diameter 83 cm

•

Available as wall-mounted or free-standing

•

Low dose, constant potential, microprocessor controlled generator with very high operating frequency 80 kHz.

•

Mains voltage fluctuations automatically compensated

•

Automatic cooling control

•

Self-sensing microprocessor controls

•

Intuitive graphic control (GUI) with clear texts, symbols and images, colour TFT screen with touch •

Technical factors and selected programs displayed on screen

•

Pre-programmable exposure settings

•

Help codes

•

Automatic compensation for the cervical vertebrae shadow

•

Optimised image geometry and constant magnification •

Adjustable focal layer, 9 different (3 sizes x 3 forms)

•

Exposure programs:

•

Standard panoramic program

•

Vertical segmenting (5 segments)

PLANMECA OY

Features Technical Specifications 7.5.2008

•

2/(3)

•

Paediatric mode (low dose, reduced exposure area for small patients)

•

Automatic double TMJ program (open and closed view on the same film)

•

Sinus program

Options: •

True Profile TMJ program

•

XC Proline Digital Cephalostat

Dimax3 sensor system •

One single sensor for both panoramic and cephalometric imaging or two fixed sensors.

•

Easy and fast change between imaging modalities

•

Versatile panoramic and cephalometric imaging programs

•

Fully automatic and software controlled soft tissue filter, automatic alignment for cephalometry, horizontal scanning

•

Very small and adjustable pixel size, high-resolution imaging, minimised movement unsharpness

•

Very low radiation dose

•

Fast data link of image transfer

•

Radiation hardened long life sensor

•

AGC Automatic Gain Control

•

PCI or Ethernet connection to computer

•

Versatile and easy-to-use Dimaxis software, DICOM compatible

•

Wide range of image processing and enhancement tools

•

Upgradeable to all existing Planmeca panoramic x-rays

Proline Digital Cephalostat (optional) •

factory installed or retrofitted

•

Steady and stable construction.

•

Automatic alignment of radiation source,

•

Functionally designed and easy-to use head positioner, swivelling nasal , low absorption carbon fibre ear posts.

•

Magnification scale appears on the image

•

No mechanical soft tissue filter, soft tissue filtering in imaging software.

Technical specifications X-ray unit X-ray tube

D-052 SB

Focal spot size SID Total filtration Anode voltage Maximum ripple Anode current Magnification of exposures

0,5 x 0,5 mm (IEC 336) 480 mm (19'') 2.5 mm Al 60 - 80 kV ± 1 kV 4 -12 mA DC 1.2(constant) panoramic 1.13 cephalostat 100 V, 117 V, 220 V, 240 V, 50 / 60 Hz ±10 % (automatic)

Line voltage Regulation EH: ProlineXC_digital_specs_1.doc

PLANMECA OY

Features Technical Specifications 7.5.2008

Line current Chin rest level Ceph ear post level Colour

8 / 16 A 99 – 171 cm (10 cm column extension available) 102 – 167 cm RAL 9016 (white)

Technical specifications Dimax3 digital sensor system CCD pixel size Image pixel size CCD active surface Resolution Image field Data transmission Interface File size (uncompressed)

Pixel matrix Soft tissue filter Scan time

EH: ProlineXC_digital_specs_1.doc

3/(3)

33 µm 66/99/130 µm (selectable) 9 x 136 mm, panoramic 9 x 270 mm, cephalometric max. 9 lp/mm, pan 5,0 – 3,8 lp/mm, ceph 14 x 30 cm, panoramic 22.6 x 18/27 cm, cephalometric 10 MB/s PCI or Ethernet Panoramic: 4420 kB normal resolution 8770 kB enhanced resolution 17500 kB high resolution 1032 x 2144 pixels, normal resolution 1376 x 2858 pixels, enhanced resolution 2064 x 4288 pixels, high resolution software operated 2.5 – 18 s, pan 17 - 23 s, ceph
