XenCenter loads all valid plugins found in subdirectories of the Plugins directory when it starts:  

The plugin name ( ) must be the same as the directory in which it is placed. The resource DLL and the XML configuration file must follow these naming conventions: .resources.dll .xlugin.xml

For example, if your organization is called Citrix and you write a plugin called Example which runs a batch file called do_something.bat, the following files must be in place (assuming a default XenCenter installation): C:\Program Files\Citrix\XenCenter\Plugins\Citrix\Example\Example.resources.dll C:\Program Files\Citrix\XenCenter\Plugins\Citrix\Example\example.xlugin.xml C:\Program Files\Citrix\XenCenter\Plugins\Citrix\Example\do_something.bat

5

XML Configuration File In your plugin XML configuration file you define which menu items and tab items you would like to appear in XenCenter. These are referred to as features, and you can customize each one using the XML attributes described in this specification. Example: A sample XML configuration file <XenCenterPlugin xmlns="http://www.citrix.com/XenCenter/Plugins/schema" version="1" plugin_version="1.0.0.0"> <MenuItem name="Hello World" menu="vm" contextmenu="none" serialized="obj" icon="Plugins\Citrix\HelloWorld\icon.png" search="dd7fbce2-b0d4-4c61-9707-e4b0f718673e" description="The worlds most friendly plugin, it loves to say hello"> <Shell filename="Plugins\Citrix\HelloWorld\HelloWorld.exe" /> <Search uuid="dd7fbce2-b0d4-4c61-9707-e4b0f718673e" name="HelloSearch" major_version="2" minor_version="0" show_expanded="yes"> <EnumPropertyQuery property="power_state" equals="no" query="Running" />

6

If your configuration file is invalid, XenCenter logs an error and the plugin is ignored. You can enable, disable and view errors with your plugin configuration file in the XenCenter plugins dialog. Note: Errors will only be shown in the dialog your configuration file XML can be parsed. If your plugin is not listed in the dialog use the XenCenter log file to debug your XML.

XML Configuration File: Basic Structure The XML elements in a configuration file have the following structure:

<XenCenterPlugin>

<Search>

<MethodList>

XenSearchXML...

<MenuItem>

<Shell> or or <XenServerPowerShell>

<MenuItem>

The XenCenterPlugin XML element is declared as follows: <XenCenterPlugin xmlns="http://www.citrix.com/XenCenter/Plugins/schema" version="1"> ...

With the following XML attributes: Important: The ‘version’ attribute is required; your plugin will not load unless it is set.

7

<MenuItem>

Key

Value

Description

 1

The XenCenter plugin version this plugin was written for. Currently only version 1 is in use.

label

 [string]

description

 [string]

copyright

 [string]

link

 [string]

Used in XenCenter as a friendly replacement for the plugin name as dictated by the directory structure. A short description of this plugin to show in XenCenter. A copyright notice for this plugin to show in XenCenter A URL web resource for the plugin to show in XenCenter

version

Optional/ Required Required

Default

Optional

-

Optional

-

Optional

-

Optional

-

-

XML Configuration File: XenSearch You can include XenSearch definitions in your plugin configuration file for features to reference. They can use these searches to tell XenCenter when they wish to be enabled or shown. Example: A MenuItem feature is using a XenSearch definition to restrict itself to shut down VMs <XenCenterPlugin xmlns="http://www.citrix.com/XenCenter/Plugins/schema" version="1"> <MenuItem name="hello-menu-item" menu="vm" serialized="none" search="dd7fbce2-b0d4-4c61-9707-e4b0f718673e"> <Shell filename="Plugins\Citrix\HelloWorld\HelloWorld.bat" /> <Search uuid="dd7fbce2-b0d4-4c61-9707-e4b0f718673e" name="NotRunning" major_version="2" minor_version="0" show_expanded="yes">

8

<EnumPropertyQuery property="power_state" equals="no" query="Running" />

The best way to get a XenSearch definition into your plugin configuration file is to construct it in XenCenter, export it to a local file and copy it into your configuration file.

XML Configuration File: Shared RBAC Method List Important: Shared method list definitions were first added in version 5.6 Feature Pack 1. To configure RBAC for your plugin in version 5.6 you will need to define the list of required methods on each feature command individually. See ‘Commands and RBAC’ for more information. When the is connected to a server running Role Based Access Control your plugin may not have permission to execute all the XenServer API calls you need. A method list can be defined for each command to warn XenCenter which API calls will be needed before the plugin is even executed. See ‘Commands and RBAC’ for more information. By defining a shared RBAC method list as a child of your XenCenterPlugin node you can have multiple commands share the same common list of methods: <XenCenterPlugin xmlns="http://www.citrix.com/XenCenter/Plugins/schema" version="1"> <MenuItem name="hello-menu-item" menu="vm" serialized="none"> <Shell filename="Plugins\Citrix\HelloWorld\HelloWorld.bat" required_method_list=”methodList1” /> <MenuItem name="hello-menu-item"

9

menu="file" serialized="none"> <Shell filename="Plugins\Citrix\HelloWorld\HelloWorld.bat" required_method_list=”methodList1” /> <MethodList name="methodList1"> host.reboot, vm.start

This is purely for convenience and is equivalent to defining the method list on each command separately. When both required_method_list and required_methods are set on a command, required_methods is taken by preference. For syntax and further information see ‘Commands and RBAC’.

10

Features Each XenCenter Plugin can define multiple features to extend the functionality of XenCenter for specific tasks. These features are the new menu items and tab pages you are adding to XenCenter.

Feature

MenuItem Feature

TabPage Feature

GroupMenuItem Feature

GroupMenuItem features are available to help organize your MenuItem features, but rely on MenuItem features to provide any functionality.

Features: XML Attributes All of the features mentioned above share some common optional and required attributes that allow you to customize their appearance and functionality. Important: The ‘name’ attribute is required for all features, your plugin will not load unless it is set Key

Value

name

 [string]

label

 [string]

search

 [string]

description tooltip

 [string]  [string]

icon

 [string]

Description The name for this feature. If label is not set, this name will be used for display purposes in XenCenter. It is also used for logging. Used as a ‘name’ replacement for facing display purposes in XenCenter. The uuid of a XenSearch defined in your configuration file. It will be used for setting enablement and visibility of this feature. A short description of this feature. Any text you wish to display a tooltip for this feature. A relative path from your XenCenter install directory to an

11


Default

Optional

-

Optional

-

Optional Optional

-

Optional

-

-

icon image for this feature. It will be displayed at size 16x16.

Example: A configuration file with a MenuItem feature using some of the common feature XML attributes <XenCenterPlugin xmlns="http://www.citrix.com/XenCenter/Plugins/schema" version="1"> <MenuItem name="Hello Exe World" menu="file" serialized="obj" icon="Plugins\Citrix\HelloWorld\icon.png" tooltip="Says hello to the whole world" label="Hello" search="dd7fbce2-b0d4-4c61-9707-e4b0f718673e" description="The worlds most friendly plugin, it loves to say hello"> <Shell filename="Plugins\Citrix\HelloWorld\HelloWorld.exe" /> <Search uuid="dd7fbce2-b0d4-4c61-9707-e4b0f718673e" name="HelloSearch" major_version="2" minor_version="0" show_expanded="yes"> <EnumPropertyQuery property="power_state" equals="no" query="Running" />

12

Features: MenuItem and GroupMenuItem Plugin authors can use MenuItem and GroupMenuItem features to add menu items in XenCenter. GroupMenuItems collect your menu items under sub menus and MenuItems launch your plugin commands. Figure: An example hierarchy of menu items that launch various plugin commands

<MenuItem>

<MenuItem>

<Shell>

HelloWorld.ps1

 

<MenuItem>

<Shell>

HelloWorld.exe

HelloWorld.bat

Each GroupMenuItem can have multiple MenuItem children Each MenuItem has exactly one child command which runs a target executable or script.

Example: A configuration file detailing the MenuItems and GroupMenuItems shown in the figure above <XenCenterPlugin xmlns="http://www.citrix.com/XenCenter/Plugins/schema" version="1"> <MenuItem name="Hello Powershell World" menu="file" serialized="obj">

13

/> <MenuItem name="Hello Batch World" menu="file" serialized="obj"> <Shell filename="Plugins\Citrix\HelloWorld\HelloWorld.bat" /> <MenuItem name="Hello Exe World" menu="file" serialized="obj"> <Shell filename="Plugins\Citrix\HelloWorld\HelloWorld.exe" />

MenuItems which are children of a GroupMenuItem appear as a sub menu under their group. The MenuItem validation logic still requires that the ‘menu’ attribute is set for these sub MenuItems, however their location is dictated by the menu attribute on the parent GroupMenuItem.

Features: MenuItem XML Attributes Important: The inherited feature attribute ‘name’ is required and your plugin will not load unless it is set Important: Each MenuItem feature must contain exactly one child node describing a XenCenter plugin command, your plugin will not load unless this is satisfied

14

Key -

menu

serialized

contextmenu

Value

Description

Optional/ Required -

Default

 -

[All attributes inherited from feature]

           

file view pool server vm storage templates tools window help obj global

The XenCenter menu you would like this to appear under.

Required

-

Optional

-

      

none pool server vm storage template folder

If set to obj, the menu item will disable itself if it’s command is already running against the selected object. If set to global only one instance of it’s command will be allowed to run at a time regardless of what is selected. An additional context menu you would like this menu item to appear under.

Optional

[value for menu]

-

Unless you set ‘none’ the item will already be present on the context menu that relates to the ‘menu’ attribute (if such a context menu exists).

Features: GroupMenuItem XML Attributes Important: The inherited feature attribute ‘name’ is required and your plugin will not load unless it is set Note: Each GroupMenuItem feature can contain as many MenuItem child nodes as you would like

15

Key -

menu

contextmenu

Value

Description


Default

 -


                

The main XenCenter menu you would like this to appear under.

Required

-

An additional context menu you would like this menu item to appear under.

Optional

[value for menu]

file view pool server vm storage templates tools window help none pool server vm storage template folder

-

Unless you set ‘none’ the item will already be present on the context menu that relates to the ‘menu’ attribute (if such a context menu exists).

Features: TabPage Tab page features load a URL to display as an extra tab inside XenCenter. In this way they can be used to allow access to web management consoles or to add additional interface features into XenCenter. Note: All local HTML and JavaScript examples in this section are using the modified JQuery libraries for RPC calls through XenCenter as well as the vanilla JQuery base library v1.3.2

16

Features: TabPage XML Attributes Important: The inherited feature attribute ‘name’ is required and your plugin will not load unless it is set Important: The ‘url’ attribute is required and your plugin will not load unless it is set Key

Value

Description


Default

 -


 [string]

The local or remote URL where the HTML page to load can be found.

Required

-

context-menu

 true  false

Optional

false

xencenter-only

 true  false

Optional

false

relative

 true  false

Whether you would like the context menu for this html page to be enabled. If set, this tabpage will appear when the XenCenter node is selected in the resource list and nowhere else. If set, the ‘url’ attribute will be interpreted as relative to the XenCenter

Optional

false

-

url

17

-

help-link

credentials

 [string]

 true  false

install directory. The URL to launch in a separate browser when the requests for help on the tab page. Indicates that the webpage is using scripting and wishes to use XenCenter’s session credentials to interact with the server. This sets window.external.Session Uuid and window.external.Session Url for scripting access.

Optional

-

Optional

false

Optional

false

WARNING: BY EXPOSING THESE VARIABLES YOU ARE ALLOWING EXTERNAL WEBPAGES ACCESS TO YOUR XENSERVER

console

 true  false

Indicates that this tab page is meant to replace the standard XenCenter console.

Features: TabPage Javascript API – Introduction Using some modified JQuery libraries to XML-RPC calls through XenCenter it is possible for your tab page to communicate with XenServer using JavaScript. XenCenter provides a scripting object which contains the following public variables:    

SessionUuid SessionUrl SelectedObjectType SelectedObjectRef

These can be accessed through the window.external object in JavaScript and used to make XenServerAPI calls: // Retrieves the other config map for the currently selected XenCenter object and es it on to the callback function function GetOtherConfig(Callback) { var tmprpc;

18

function GetCurrentOtherConfig() { var toExec = "tmprpc." + window.external.SelectedObjectType + ".get_other_config(Callback, window.external.SessionUuid, window.external.SelectedObjectRef);"; eval(toExec); } tmprpc= new $.rpc( "xml", GetCurrentOtherConfig, null, [window.external.SelectedObjectType + ".get_other_config"] ); }

In this example we create an RPC object using 4 parameters: 1. Notifying that the RPC call is carrying XML (as opposed to JSON) 2. The function to execute (GetCurrentOtherConfig) which fires off an API call - the modified JQuery library packages up the API call as an XML-RPC request and hands it to XenCenter. Notice that the function name for the callback is ed as an additional first parameter to the API call. 3. We don’t specify a version number for the XML (null) which is interpreted as 1.0. 4. We a description of the API call we want to make inside GetCurrentOtherConfig so the appropriate objects are created for the function to access.

Features: TabPage Javascript API – Required Functions Important: It is required that you define a RefreshPage function in your JavaScript. XenCenter will call this function every time it reloads the HTML page or adjusts the variables on the scripting object. Your code should be structured so that the RefreshPage function can easily tear down and rebuild the state of the page: $(document).ready(RefreshPage);

function RefreshPage() { // hide the error div and show the main content div $("#content").css({"display" : ""}); $("#errorContent").css({"display" : "none"}); $("#errorMessage").html(""); RefreshMessagesAndStatus(); RefreshDescription(); RefreshTags(); }

19

Setting the function to be called at $(document).ready() ensures there are no race conditions between XenCenter signaling that the page should refresh and the page itself being ready to receive these requests.

Features: TabPage Javascript API – Receiving XenCenter Callbacks When you make an RPC object and get XenCenter to through an API call to XenServer you specify a callback function. When the XML-RPC request returns from XenServer the callback function is invoked by XenCenter, ing in a JSON object which contains the result as a parameter. Look at RefreshDescription below: // The result object of any xmlrpc call to the server contains: // - a result field which indicates whether it was succesfull or not, // - a value field containing any returned data in json // - an error description field containing any error information // This function checks for success, displays any relevant errors, and returns a json object that corresponds to the value field function CheckResult(Result) { var myResult=Result.result; if(myResult.Status=="Failure") { var message=myResult.ErrorDescription[0]; for(var i=1; i<myResult.ErrorDescription.length; i++) { message+=","+myResult.ErrorDescription[i]; } $("#content").css({"display" : "none"}); $("#errorContent").css({"display" : ""}); $("#errorMessage").html(message); return; } if (myResult.Value == "") { return; } myResult = eval("("+myResult.Value+")"); return myResult; } // DESCRIPTION UPDATE SECTION // This pair of methods chain to retrieve the description field from the server and display it. There is no writing to the description field on the server. function RefreshDescription() { var tmprpc; function RetrieveDescription() {

20

var toExec = "tmprpc." + window.external.SelectedObjectType + ".get_name_description(ShowDescription, window.external.SessionUuid, window.external.SelectedObjectRef);"; eval(toExec); } tmprpc= new $.rpc( "xml", RetrieveDescription, null, [window.external.SelectedObjectType + ".get_name_description"]) }

function ShowDescription(DescriptionResult) { var result = CheckResult(DescriptionResult); if (result == null) { $("#descriptionText").html("None"); return; } $("#descriptionText").html(result); }

Features: TabPage Replacement Consoles This feature allows you to specify that your tab page feature should replace the standard console tab page in XenCenter. It is often used when a VM has its own web interface and the standard console tab page does not need to be seen. To activate this feature, add the attribute console=”True” to the TabPageFeature tag in your configuration file. If the web page you have specified in your tab page feature cannot be reached by XenCenter, then the standard console tab page will be returned and your tab page feature will be hidden. If the tab page feature can be reached later on, it will be automatically restored, and the standard console tab page hidden.

21

Commands In your configuration file, each MenuItem feature should have a single command as a child. They detail which executable or script to run when the clicks the MenuItem. In this version of the XenCenter plugin specification there are three types of command:   

Shell PowerShell XenServerPowerShell

Powershell and XenServerPowerShell are extensions of Shell and inherit all the properties of Shell. However they both have additional features which make it easier to run powershell scripts, for example XenServerPowerShell commands automatically load the XenServer PowerShell Snapin before executing.

Shell

PowerShell

XenServerPowerShell

Commands: Parameter Sets A parameter set is a collection of 4 parameters that are used to describe which items are selected in the XenCenter resource list when your command is executed. While each command has it’s own way of receiving parameters from XenCenter, the parameters will always be the same. They are delivered in sets of four which describe the selection in the XenCenter resource list:

22

url

sessionRef

class

objUuid

Two of the parameters are used to allow communication to the relevant server:  

The url parameter indicates the address of the applicable standalone server or pool master The sessionRef parameter is the session opaque ref that can be used to communicate with this server

Two of the parameters are used to describe which specific object is selected:  

The class parameter is used to show the class of the object which is selected in the resource list The objUuid parameter is the uuid of this selected object

Example: If you were to select both the local SR from a standalone server (Server A) and the pool node from a separate pool (Pool B), you would end up 2 parameter sets being ed into your plugin:

https://servera:443/

OpaqueRef:19969d9e-794f0eb0-2522-950c5ac35d31

SR

1b45aa8f-0c32-4c5d-e7b78add8007d04d

https://masterofpoolb:433/

OpaqueRef:c473046d9836-48ab-85a311c5a7c9ca51

Pool

a5d3bd5c-4b32-83a0-37ecd86cb40b4a28

In general you will receive one parameter set per object selected in the tree view, with two exceptions.  

Selecting a folder will give add a parameter set per object in the folder, not the folder itself Selected the XenCenter node will add a parameter set for each stand alone server or pool that is connected, with the class and objUuid parameters marked with the keyword ‘blank’

In this way, if the XenCenter node is selected you will be ed the necessary information to perform actions on any of the connected servers. However, selecting this node provides no contextual information about what the wishes to target, so the ‘blank’ keyword is used for the parameters which would identify specifically what is selected.

23

Example: If you were connected to Server A and Pool B from the previous example, and you selected both the XenCenter node and the local storage on Server A you would get the following parameter sets:



blank

blank

https://masterofpoolb:433/

OpaqueRef:c473046d-983648ab-85a3-11c5a7c9ca51

blank

blank



SR

1b45aa8f-0c32-4c5d-e7b78add8007d04d

Commands: Shell Shell commands are the most generic command type and launch executables, batch files and other files which have a ed windows extension. <XenCenterPlugin xmlns="http://www.citrix.com/XenCenter/Plugins/schema" version="1" plugin_version="1.0.0.0"> <MenuItem name="hello-menu-item" menu="file" serialized="obj"> <Shell filename="Plugins\Citrix\HelloWorld\HelloWorld.bat" window="true" log_output="true" dispose_time="0" param="{$type}" />

24

Commands: Shell Parameters For Shell commands the parameter sets are ed through as command line parameters to the batch file or executable. Any additional parameters supplied using the ‘param’ xml attribute (see below) will be first in the list of parameters, followed by sets of four command line parameters representing each parameter set.

Commands: Shell XML Attributes Note: The filename attribute is required and your plugin will not load unless it is set Key

Value

filename

 [string]

window

 True  False

log_output

 True  false

param

 [string]

dispose_time

 [float]

required_met hods

 [string]1

Description The file that you wish to execute, for example an executable or a windows batch file. This is a relative path from your XenCenter install directory. Whether to start the process in a window or run it in the background. Redirects the Standard Output and Standard Error streams of the plugin process to the XenCenter log file. A comma separated string of extra parameters to to the process. You can a parameter with spaces by encasing it in XML escaped quotes (") The grace period XenCenter should give the plugin after it has requested it to cancel. After this period, XenCenter assumes the plugin has hung and warns the . A comma separated string of api calls the plugin wishes to run. XenCenter blocks the plugin launch and warns

25


Default -

Accepts Placeholders True

Optional

true

-

Optional

false

-

Optional

-

True

Optional

20.0

-

Optional

-

False

 [string]

required_met hod_list

the when these requirements are not met due to a role restriction under RBAC. The name of a list of methods called out in the MethodList node (child of XenCenterPlugin). If required_methods is set, this is ignored.

Optional

-

False

Added in version 5.6 Feature Pack 1. 1 See the section on RBAC protection for more details

Commands: PowerShell Powershell commands specifically target powershell scripts and have several enhancements over a basic Shell command to help you access the various parameters XenCenter wishes to to your plugin. <XenCenterPlugin xmlns="http://www.citrix.com/XenCenter/Plugins/schema" version="1" plugin_version="1.0.0.0"> <MenuItem name="hello-menu-item" menu="file" serialized="obj"

26

Commands: PowerShell Object Information Array Information regarding the target items selected in the XenCenter resource list are stored in a powershell variable for easy access by your script. Inside the $objInfoArray variable you will find an array of hashmaps, each representing a parameter set. Use the following keys to access the parameters in each hashmap:    

‘url’ ‘sessionRef’ ‘class’ ‘objUuid’

[reflection.assembly]::loadwithpartialname('system.windows.forms') foreach ($objInfo in $objInfoArray) { $outputString = "url={0}, sessionRef={1}, objName={2}, objUuid={3}" -f $objInfo["url"], $objInfo["uuid"], $objInfo["class"], $objInfo["objUuid"] [system.Windows.Forms.MessageBox]::show("Hello from {0}!" -f $outputString) }

Commands: PowerShell Extra Parameter Array Any additional parameters you define using the ‘param’ XML attribute inherited from Shell are stored in the $ParamArray variable as a simple array. [reflection.assembly]::loadwithpartialname('system.windows.forms') foreach ($param in $ParamArray) { [system.Windows.Forms.MessageBox]::show("Hello from {0}!" -f $param) }

Commands: PowerShell XML Attributes Note: The filename attribute inherited from Shell is required and your plugin will not load unless it is set to point to a powershell script Key

Value

-

-

debug

 true  false

Description [All attributes inherited from Shell]

Enables debugging output that traps and details any uncaught exceptions. It is highly recommended you set window=true if debug is

27


Default -

Accepts Placeholders -

Optional

false

-

enabled.

function

 [string]

Executes the provided string as powershell code after the main script has finished executing.

Optional

-

True

Commands: XenServerPowerShell In addition to the features provided by the PowerShell Command, the XenServerPowerShell Command loads the XenServerPowershellSnapIn before executing your target powershell script. <XenCenterPlugin xmlns="http://www.citrix.com/XenCenter/Plugins/schema" version="1" plugin_version="1.0.0.0"> <MenuItem name="hello-menu-item" menu="file" serialized="obj" <XenServerPowerShell filename="Plugins\Citrix\HelloWorld\HelloWorld.ps1" debug="true" window="true" log_output="true" dispose_time="0" param="{$type}" function="Write-Output {$type}; read-host '[Press Enter to Exit]'" />

Commands: XenServerPowerShell Initialization Details To see precisely what set up is done to prepare your powershell environment for communicating with XenServer, see the Initialize-Environment script in your XenServerPSSnapin install directory. In brief, when your target script begins executing:  

All the XenServer cmdlet aliases will be initialized The global session variable will be initialized to store your session information

28

Commands: XenServerPowerShell Parameters The parameter sets and additional parameters can be accessed through the $objInfoArray and the $ParamArray variables as detailed in the previous PowerShell Command section.

Commands: XenServerPowerShell XML Attributes Important: The filename attribute inherited from Shell is required and your plugin will not load unless it is set to point to a powershell script Key -

debug

Value

Description

 -

[All attributes inherited from Shell]

 true  false

Enables debugging output that traps and details any uncaught exceptions. It is highly recommended you set window=true Executes the provided string as powershell code after the main script has finished executing. Not Implemented (CA-40580) Not Implemented (CA-40580)

function

 [string]

version_min

 [string]

version_max

 [string]

29


Default -

Accepts Placeholders -

Optional

false

-

Optional

-

True

-

-

-

-

-

-

Commands: Preparing for RBAC By defining the methods that it will require in your configuration file a command can be prepared for the situation when XenCenter is connected to a server which is using Role Based Access Control. If the does not have permission to execute an API call on a server due to RBAC, then the call will fail with an RBAC_PERMISSION_DENIED exception. You can handle these exceptions from within the plugin (examine the ErrorDescription field on the response for details) or you can ask XenCenter to ensure that the can execute all possible commands you might need before the plugin is run: <XenCenterPlugin xmlns="http://www.citrix.com/XenCenter/Plugins/schema" version="1" plugin_version="1.0.0.0"> <MenuItem name="Hello Exe World" menu="file" serialized="obj" description="The worlds most friendly plugin, it loves to say hello"> <Shell filename="Plugins\Citrix\HelloWorld\HelloWorld.exe" required_methods="host.reboot, vm.start" />

The required_methods attribute accepts a comma separated list of API calls in the format: object.method. If the is operating on an RBAC enabled server, XenCenter will check that they can execute all of these API calls on their current role. If they can’t, the plugin is not launched and an error displayed:

30

Commands: Preparing for RBAC - Key White Lists Important: Key white lists were first exposed for plugin use in version 5.6 Feature Pack 1 You will be unable to use the white list for modifying map keys in version 5.6

Important: These white lists apply to advanced XenCenter keys. You should only modify them if you know what you are doing. In general, when operating under RBAC your role restricts you to modifying the other-config map on objects which are directly relevant to your role. For example a VM can modify the other-config map on a VM, but it cannot modify the other-config map on a server. Some specific keys have been white listed to all roles above read-only to allow XenCenter to set some advanced keys on other-config maps that would otherwise be inaccessible to the ’s role: Target object VDI SR network host VM pool VDI SR Network host VM pool pool task task network

Key XenCenter.CustomFields.*

folder

EMPTY_FOLDERS XenCenterUUID applies_to XenCenterCreateInProgress

You can enter these checks into your method list with the following syntax: <MethodList name="methodList1"> pool.set_other_config/key:folder, pool.set_other_config/key:XenCenter.CustomFields.*

31

Commands: Placeholders By leaving placeholders in your strings, XenCenter can call different functions, URLs or provide different parameters based on what object is selected in the resource list. When an XML attribute is marked as being able to accept placeholders you can leave wildcards for XenCenter to fill in based on the properties of the object that is selected in the resource list. Placeholder {$type} {$label} {$uuid}

Description The type of the selected object, e.g., VM, Network The label of the selected object The UUID of the selected object, or the full pathname of a folder

{$description}

The description of the selected object

{$tags}

Comma-separated list of the tags of the selected object

{$host}

The host name

{$pool}

The pool name

{$networks}

Comma-separated list of the names of the networks attached to the object

{$storage}

Comma-separated list of the names of the storage attached to the object

{$disks}

Comma-separated list of the types of the storage attached to the object

{$memory} {$os_name} {$power_state} {$virtualisation_status}

The host memory, in bytes The name of the operating system that a VM is running The VM power state, e.g. Halted, Running The state of the pure virtualization drivers installed on a VM

{$start_time}

Date and time that the VM was started

32

{$ha_restart_priority} {$size} {$ip_address}

The HA restart priority of the VM The size in bytes of the attached disks Comma-separated list of IP addresses associated with the selected object

{$uptime}

Uptime of the object, in a form such as '2 days, 1 hour, 26 minutes'

{$ha_enabled} {$shared}

true if HA is enabled, false otherwise Applicable to storage, true if storage is shared, false otherwise

{$vm} {$folder} {$folders}

Comma-separated list of VM names The immediate parent folder of the selected object Comma-separated list of all the ancestor folders of the selected object

If the has selected more than one target for the plugin (by multiselect or by selecting a folder) then it is not possible for XenCenter to know which object to use for the placeholder context. It is possible that in the future the placeholder logic will be extended to allow the plugin author to indicate which placeholders should be filled with which objects in a multi target scenario. Currently in a multi target scenario all placeholders will be substituted with the keyword ‘multi_target’, so it will at least be possible to detect this situation. Additionally, if there has been an error filling in a particular placeholder then the keywork ‘null’ will be substituted in to indicate this. One example of where you would see this is if the XenCenter node was selected, which has no object properties to fill in. Example: A community group adds their HTML help guides into a XenCenter tab based on which object is selected <XenCenterPlugin xmlns="http://www.citrix.com/XenCenter/Plugins/schema" version="1" plugin_version="1.0.0.0">

33

Resources and Internationalization In the text below, is the value of the Plugin name attributes and <entry_name> is the value of the MenuItem/TabPage name attributes. The following resources will be read from :       

.description – Shown in the plugins dialog. .copyright – Vendor copyright statement. Shown in the plugins dialog. .link – Link to vendor's webpage. Shown in the plugins dialog. <entry_name>.label – The menu entry label. <entry_name>.description – Shown in the plugins dialog. <entry_name>.icon – The icon to use in the menu entry. Should be a 16x16 PNG. May be omitted. <entry_name>.tooltip – The tooltip to use when the menu entry is disabled. May be omitted.

To create the resources file:   

•Create a RESX file containing the appropriate strings (this can be done in any project in Visual Studio (eg console project) Open up Visual Studio cmd prompt and navigate to the resx's directory Run resgen.exe .resx. ResGen is found in C:\Program



Files\Microsoft Visual Studio 8\SDK\bin\... Run al.exe /t:lib /embed: .resources /culture:0x007F / out: .resources.dll for the

 

invariant culture. Al is found in C:\Windows\Microsoft.Net\v2.{whatever version}\... If you wish to add any more cultures replace '0x007F' with the appropriate two letter culture string (eg 'ja' for Japanese) Place the invariant culture .resources.dll into the folder (with .xlugin.xml etc)



Other cultures should be as follows: \<culture>\ .resources.dll where <culture> is the two-letter ISO culture name

Unless stated otherwise, all of these entries are mandatory. If any are missing, then the problem will be logged, and the menu option will be disabled.

34

Deploying Each plugin is installed into: <XenCenter_install_dir>\Plugins\ \ . Notes:     



Plugins should expect to be read-only at runtime. By default <XenCenter_install_dir> is C:\Program Files\Citrix\XenCenter. is the name of the organization or individual authoring the plugin. is the name of the plugin. The author’s installation directory (<XenCenter_install_dir>\Plugins\ ) is known in this specification as . <XenCenter_install_dir> can be looked up in the registry. If XenCenter was installed as "just me" the location of the XenCenter install directory can be found at HKEY_CURRENT_\SOFTWARE\Citrix\XenCenter\InstallDir. If XenCenter was installed for all s this key is under HKEY_LOCAL_MACHINE.

In \ there should be:   

A plugin declaration file, named .xlugin.xml. A satellite assembly for resources, named .resources.dll. Anything else that the plugin needs for its proper functions.

Other than as specified in this document, XenCenter ignores the contents of . Plugin authors are free to install whatever content they need within their own . You may, for example, wish to have libraries or graphics that are shared between all their plugins, in which case (or a shared subdirectory of it) would be a good place for these. The same freedom applies to \ ; material in there that isn’t recognized by XenCenter will be ignored. The <XenCenter_install_dir>\Plugins directory is scanned when XenCenter starts and plugins that are found will be loaded. The directory can be re-scanned by restarting XenCenter or by pressing the Re-Scan Plugin Directory button on the XenCenter plugins dialog. Any subdirectory that does not contain .xlugin.xml will be silently ignored.

35

Xc Plugins 6z441k

Overview 1s532p

More details 6h715l

Related Documents 2w1qw

Xc Plugins 6z441k

Plugins 2l2v5h

Plugins 2l2v5h

Serial Plugins up6a

Plugins Sketchup 732j6v

Curviloft Plugins 621k5a

More Documents from "Puppaz Ebet" 3l3940

Xc Plugins 6z441k

Rab Konstruksi - Hspk 2016 2n3h8
