Maya Installation Licensing Guide 611p3l

. Clear the check box if you do not want to create a shortcut to the program.

■

Product Install Path - Specify the drive and location where you want to install Maya.

8 Click another product tab to configure another product, or click Next and then Configuration Complete to return to the Begin Installation page. Click Install. NOTE To retain a copy of your configuration settings, click Copy to Clipboard.

Installing and Running the Product | 15

9 On the Installation Complete page, note the directory path where you can find and read the installation log. 10 Click Finish. You have successfully installed Maya. You are now ready to your product and start using the program. To the product, start Maya and follow the on-screen instructions. See also and Activate Maya on page 27.

Install Maya on Mac OS X By default, Maya is installed in the following directory: /Applications/Autodesk/maya2011/. To install Maya on Mac OS X 1 Do one of the following to launch the installer: ■

■

If you are installing from a DVD, insert the DVD into your drive, then double-click the Maya DVD icon that appears on your desktop. Navigate to the Maya/MacOSX folder on the DVD drive. If you are installing from a package, double-click the Maya .dmg.

2 In the Finder window that opens, double-click the Install Maya 2011 program. The Autodesk Product Configuration wizard starts. 3 In the License Agreement window, do the following: ■

Select your Country or Region from the drop-down list.

■

Select I ACCEPT to accept the and conditions.

■

Click Next.

If you do not accept the and want to stop the installation, select I REJECT and click Close. 4 In the Choose components window, select the components you want to install and click Next. For example, this window lets you select from the following components: ■

Maya 2011

16 | Chapter 2 Maya Installation

■

Maya 2011 Documentation

■

Composite

■

Backburner

■

MatchMover

5 In the Maya 2011 License Configuration window, do the following: ■

Enter your 11-digit serial number.

■

Enter your Product key.

■

Select your License type: Standalone or Network. If you select the Standalone license type, obtain your stand-alone license later by following the steps in and Activate Maya. If you select the Network license type, enter your license server name in the Server name field that appears. your network to find your license server name.

■

Click Next.

An Installing Maya 2011 window displays with a progress indicator bar. 6 In the Installing Maya 2011 window, that the components you want have finished installing, then click Done.

Install Maya on Linux This section provides detailed information on installing Maya on Linux. By default, Maya is installed in the following directory: /usr/autodesk/maya2011-x64.

Install Maya on Linux using the Installation wizard To install Maya on Linux 1 Do one of the following to start the Maya install: ■

If you are installing from a DVD, insert the DVD into your drive.

■

If you are installing from a package, extract the Maya packages from the compressed file.


2 Open a shell as a super and navigate to the directory where you extracted the packages. 3 Type./setup and press Enter. This starts the Autodesk Product Configuration wizard. 4 In the License Agreement window, do the following: ■

Select your Country or Region from the drop-down list.

■

Select I ACCEPT to accept the and conditions.

■

Click Next.

If you do not accept the and want to stop the installation, select I REJECT and click Close. 5 In the Choose components window, select the components you want to install and click Next. This window lets you select from components including: ■

Autodesk Maya 2011

■

Autodesk Maya 2011 Documentation

■

MatchMover

■

Composite

■

Autodesk Backburner

6 In the Maya 2011 License Configuration window, do the following: ■

Enter your 11-digit serial number.

■

Enter your Product key.

■

Select your License type: Standalone or Network. If you select the Standalone license type, obtain your stand-alone license later by following the steps in and Activate Maya. If you select the Network license type, enter your license server name in the Server name field that appears. your network to find your license server name. (If you are setting up a license server, see the Network Licensing Guide on page 79.)

■

Click Next.

An Installing Maya 2011 window displays with a progress indicator bar.


7 In the Installing Maya 2011 window, that the components you want have finished installing, then click Done.

Install Maya on Linux using the rpm utility With the rpm command line utility, you can use either the -i flag or the -ivh flag to install the programs. The -ivh flag provides you with more information during the installation. To install Maya on Linux using the rpm utility 1 Open a shell as a super . 2 Do one of the following: ■

Insert the Maya DVD into your drive and mount the DVD drive. For example, type: mount -r /dev/dvd /mnt/dvd.

■

Extract the Maya packages from the compressed file, then change to the directory where you extracted the Maya packages.

3 Use the ls command to list the packages. The packages you see will be similar to the following, where # indicates the specific package numbers. Package name

Description

Required

Maya2011_0_64-2011.0#.x86_64.rpm

Maya for Linux

Yes

Maya2011_0-docs_en_US_642011-#.x86_64.rpm

Maya 2011 documentation

No

adlmapps-1.3.#.x86_64.rpm

Autodesk licensing

Yes

adlmflexnetclient1.3.#.x86_64.rpm

Autodesk standalone licensing

Only for standalone licensing (Not required if you use network licensing)

adlmflexnetserver1.3.#.x86_64.rpm

License server tools (for network licensing)

No


Package name

Description

Required

AutodeskToxik2011-2011.0#.x86_64.rpm

Composite

No

backburner.sw.base-2011#.i386.rpm

Autodesk Backburner

No

backburner_webmonitor.sw.base-2011-#.i386.rpm

Autodesk Backburner web monitor

No

autodesk.backburner.monitor2011-#.i386.rpm

Autodesk Backburner monitor

No

MatchMover2011_0_642011.0-#.x86_64.rpm

MatchMover

No

4 To install the required software, enter the following command: rpm -ivh Maya2011_0_64-2011.0-#.x86_64.rpm adlmapps1.3.#.x86_64.rpm adlmflexnetclient-1.3.#.x86_64.rpm

where # indicates the specific package numbers. NOTE If you have a previously installed version of AdLM and Maya for Linux, uninstall that version before installing this version. To what version you have, execute the following command: rpm -qa | egrep 'adlm|Maya'. Maya 2011 adds the required libXm.so.3 library to the Maya lib directory as part of its standard install, so installing the openMotif runtime rpm is not required. 5 Look for a file named libGL.so in the /usr/lib/ or /usr/X11R6/lib directory to that OpenGL is installed. 6 (Optional) To install the documentation package, type the following where # is the specific package number: rpm -ivh Maya2011_0_64-docs_en_US-2011.0-#.x86_64.rpm

The files are installed in the following directory: /usr/autodesk/maya2011-x64

7 Run the following command to set whether you are using a network or a stand-alone license:


/usr/autodesk/maya2011-x64/bin/licensechooser /usr/autodesk/maya2011-x64/ unlimited

where you specify standalone or network for . This updates the license.env file (used by the Autodesk licensing software) with your license type information. 8 Add /opt/Autodesk/Adlm/R1/lib64/to LD_LIBRARY_PATH to set your shared libraries for this session. For example, you can run the following command in a BASH shell: export LD_LIBRARY_PATH=/opt/Autodesk/Adlm/R1/lib64/

9 Run the following commands to Maya with the Autodesk licensing software, where <productKey1> and <productKey2> are your product keys, and <serialNum> is your serial number.: ■

(Stand-alone licensing) /usr/autodesk/maya2011-x64/bin/adlmreg -i S <productKey1> <productKey2> 2011.0.0.F <serialNum> /var/opt/Autodesk/Adlm/Maya2011/MayaConfig.pit

■

(Network licensing) /usr/autodesk/maya2011-x64/bin/adlmreg -i N <productKey1> <productKey2> 2011.0.0.F <serialNum> /var/opt/Autodesk/Adlm/Maya2011/MayaConfig.pit

NOTE If you purchased Maya alone and received only one product key, you can enter the same product key for both <productKey1> and <productKey2>. For example: /usr/autodesk/maya2011-x64/bin/adlmreg -i S 657C1 657C1 2011.0.0.F 000-00000000 /var/opt/Autodesk/Adlm/Maya2011/MayaConfig.pit

This step updates the product information .pit file, which you can copy to other machines that have the same configuration if you are installing many instances of Maya. These commands return a Registration succeeded message, and you can now run Maya using your stand-alone or network license.


Additional Linux Notes This section provides information for configuring Maya to run on Linux, describes differences between Maya for Linux and other versions of Maya, and provides other information specific to using Maya on the Linux operating system. For complete information on limitations and possible workarounds, also refer to the Maya 2011 Release Notes.

Compiling plug-ins and standalone programs To compile plug-ins and standalone applications for Maya 2011 on Linux, use the released gcc 4.1.2 compiler. Maya has been compiled with this compiler under RHEL 5.1 WS. In addition, Maya uses some component libraries that may already exist on your system (for example, Qt, Python, OpenAL, Intel TBB, MKL, Cg). These libraries are installed in the /lib directory under your Maya installation directory, and should not interfere with the normal operation of your Linux system. In some cases, your system may include newer versions of these libraries, which may or may not be compatible with Maya. IMPORTANT Maya requires its own versions of the Qt libraries to run properly. For more information, see the API Guide.

Installing additional required packages and fonts On Linux, especially on Fedora systems, not all system libraries required to run Maya are included in the default installation of the operating system. You can use rpm to find and install any additional system-dependent library packages and get the required runtime libraries. For RHEL and Fedora, you can use the yum program to install the rpm packages. For example, to install some of the following dependent libraries, you can execute the following commands: ■

yum install mesa-libGLw

■

yum install libXp

■

yum install gamin audiofile audiofile-devel e2fsprogs-libs

Dependent OpenGL libraries (vendor Nvidia/AMD supplied) ■

libGL.so from Nvidia/AMD 3rd party library


■

libGLw.so.1 from mesa-libGLw

Dependent X Windows libraries ■

libXp.so.6 from package libXp

■

libXmu.so.6 from package libXmu

■

libXpm.so.4 from package libXp

■

libXt.so.6 from package libXt

■

libXi.so.6 from package libXi

■

libXext.so.6 from package libXext

■

libX11.so.6 from package libX11

■

libXinerama.so.1 from package libinerama

■

libXau.so.6 from package libXau

■

libxcb.so.1 from package libxcb

Dependent System libraries ■

libfam.so.0 from package gamin

■

libaudiofile.so.0 from package audiofile

■

libaudiofile.so from package audiofile-devel

■

libuuid.so.1 from package e2fsprogs-libs

■

ibpthread.so.0

■

llibc.so.6

■

libdl.so.2

■

libz.so.1

■

librt.so.1

■

libSM.so.6

■

libICE.so.6

■

libutil.so.1

■

libssl.so.6


■

libcrypto.so.6

IMPORTANT Note the following additional information on libssl.so.6 and libcrypto.so.6. libssl.so.6 and libcrypto.so.6 are versions of the OpenSSL library that ships with RHEL 5.1. These are new dependencies for Maya 2011. Many Linux distributions do not include this version of the library, and Maya does not re-distribute this file with its installation package. For OpenSSL and Maya, it is generally sufficient to create a symbolic link for the currently installed system libraries to the same name with the so.6 version. As root, create the symlinks in the Maya lib directory to isolate them from the rest of your system. If the installer does not detect a libssl.so.6 library, it should attempt the following. su cd /usr/autodesk/maya2011/lib ln –s /usr/lib64/libssl.so.8 libssl.so.6 ln –s /usr/lib64/libcrypto.so.8 libssl.so.6

Dependent applications ■

tcsh This is a command language interpreter application. Run the command yum install tcsh to install.

Dependent 32-bit Backburner monitor libraries ■

php

■

elfutils-libelf

■

glibc

■

libgcc

■

libstdc++

■

httpd To ensure that you install the required 32-bit version of these libraries, run the following commands to install: (Fedora 11) yum install httpd php

elfutils-libelf.i586


glibc.i686 libstdc++.i586

(Red Hat Enterprise Linux WS 5.4) yum install httpd php

elfutils-libelf.i386

glibc.i686 libstdc++.i386

Fonts Maya also uses some fonts that may not be installed by default. Execute the following to install these fonts: yum install liberation-mono-fonts liberation-fonts-common liberation-sans-fonts liberation-serif-fonts

Differences in operation When installed on a Linux system, Maya works in much the same way as when installed on Windows.

Uned Maya features Some of the features in the Windows versions are not currently ed. These include output to AVI or SGI movie formats. Please refer to the Maya 2011 Release Notes for more information.

Linux desktop configuration To use Maya on Linux, certain default keyboard and mouse bindings must be changed from the factory settings. These default bindings prevent commands from being received by Maya, such as the ones that let you tumble or pan a view in a . Different Linux window managers have different key bindings and different procedures for setting them. Linux systems are highly customizable, and many combinations of Linux system components are possible for use with Maya—more than can be described (or tested) by Autodesk. The following instructions give the procedures necessary for changing the most common configurations.

KDE and Gnome desktop configuration For Maya to work properly with KDE and Gnome, some modifications should be made to the mouse control. The default bindings of the Alt key and mouse buttons do not work well with Maya. Maya 2011 adds to use the Meta (Windows) key to act as the Alt key for tumbling. If you want to use the Alt+mouse buttons for scene tumbling, ensure the bindings do not conflict.


Different versions of KDE and Gnome may have different methods of selecting the key bindings. See the KDE and Gnome documentation for instructions if the following steps don’t work for your particular window manager. KDE under Red Hat 1 Open the KDE Control Center. 2 Select Desktop and then select Window Behavior. 3 Do one of the following: ■

(Red Hat Enterprise Linux WS 5.4) Open the Actions tab.

■

(Fedora 11) Open the Window Actions tab.

4 In the following section: ■

(Red Hat Enterprise Linux WS 5.4) Inner Window, Titlebar & Frame

■

(Fedora 11) Interactive Inner Window, Inner Window, Titlebar & Frame

For modifier key Meta, set all mouse action combinations to Nothing. 5 Click Apply and close the Control Center. Gnome under Red Hat 1 Open the Gnome . 2 Do one of the following: ■

(Red Hat Enterprise Linux WS 5.4) Select Applications, then Preferences and then select Windows.

■

(Fedora 11) Select System, then Preferences and then select Windows.

3 In the Window Preferences dialog box, set the “To move a window...” key to Super. (Setting either Control or Alt here can cause problems when using Maya.) 4 Click Close.

Installing Multiple or Bundled Products Some Autodesk packages are comprised of multiple products or are part of multi-product bundles.


In the installation wizard, for packages containing multiple products, you can choose which products and languages you want to install. During the install process, you are informed whether a copy of the software is already installed. You are also warned if your system does not meet the minimum system requirements for the product. Each product name is displayed on its own tabbed ; you can configure them individually. If you purchased a package that is a multi-product bundle, such as an educational or institutional package, you may have a package that includes several Autodesk products. For these bundled packages, an Installer disc contains information for all the products in the package. The Installer disc helps you install all of the products. This includes a Ree which describes issues general to the bundle or suite. NOTE If you are installing Maya as part of a suite, it is recommended that you refer to both the suite install guide and this install guide.

and Activate Maya The first time you start Maya, the Product License Activation wizard is displayed. You can either activate Maya at that time, or Try Maya and activate it later. Until you and enter a valid activation code for Maya, you are operating the program in trial mode and the Product License Activation wizard is displayed for 30 days from the first time that you run the program. If after 30 days of running Maya in trial mode you have not ed and provided a valid activation code, your only option is to and activate Maya. You will not be able to run in trial mode after the 30 days expires. Once you and activate Maya, the Product License Activation wizard is no longer displayed. The fastest and most reliable way to and activate your product is by using the Internet. Simply enter your registration information and send it to Autodesk over the Internet. Once you submit your information, registration and activation occur quickly. To and activate Maya 1 Click the Start menu ➤ Programs or All Programs ➤ Autodesk ➤ <Maya> ➤ <Maya>. 2 In the Maya Product License Activation wizard, select Activate, and then click Next. This starts the activation process.


3 Click and Activate (Get an Activation Code). 4 Click Next and follow the on-screen instructions. If you do not have Internet access, or if you want to use another method of registration, you can and activate Maya in one of the following ways: Email Create an email message with your registration information and send it to Autodesk. Fax or Post/Mail Enter your registration information, and fax or mail the information to Autodesk.

Launch Maya Assuming that you followed all of the previous steps outlined in this installation section, you can launch Maya and start taking advantage of its new and updated features. For more detailed information about the new features, learning videos, online Help, or Maya services and , see the Welcome screen after you launch the product. You can start Maya in the following ways: ■

Desktop shortcut icon. When you install Maya, an Maya shortcut icon is placed on your desktop unless you cleared that option during installation. Double-click the Maya shortcut icon to start the program.

■

Start menu. On the Start menu, click Programs or All Programs ➤ Autodesk ➤ <Maya> ➤ <Maya>.

■

Location where Maya is installed. If you have istrative permissions, you can run Maya in the location where you installed it. If you are a limited-rights , you must run Maya from the Start menu or from the desktop shortcut icon. If you want to create a custom shortcut, make sure that the Start In directory for the shortcut points to a directory where you have write permissions.

Uninstall Maya The following sections describe how to uninstall Maya 2011. NOTE If you uninstall Maya 2011, Composite and MatchMover will be disabled.


Uninstall Maya on Windows When you uninstall Maya, all components are removed. This means that even if you've previously added or removed components, or if you've reinstalled or repaired Maya, the uninstall removes all Maya installation files from your system. There are two ways to uninstall Maya on Windows. To uninstall Maya using the Uninstall utility 1 From the Start menu, select Programs > Autodesk > Autodesk Maya 2011 > Uninstall Maya. 2 Follow the instructions in the window that appears. To uninstall Maya using the Windows uninstall utility 1 Open the Control and do one of the following: ■

(Windows XP) Launch the Add or Remove Programs window.

■

(Windows 7 and Windows Vista) Select Programs or Programs and Features.

2 In the list of programs that appears, select Maya 2011 and click Uninstall or Remove. 3 Follow the instructions in the window that appears.

Uninstall Maya on Mac OS X To uninstall Maya on Mac OS X 1 Navigate to the Maya directory (by default, /Applications/Autodesk/maya2011/). 2 Drag the maya2011 application to the trash. 3 Open a Terminal window and execute the following commands, where <productKey> is your product key.: adlmreg –u S <productKey> 2011.0.0.F adlmreg –u N <productKey> 2011.0.0.F


This ensures that product information is properly removed from the ProductInformation.pit file.

Uninstall Maya on Linux To uninstall Maya on Linux you can use the rpm utility. To uninstall Maya using rpm 1 Open a shell as a super . 2 Add /opt/Autodesk/Adlm/R1/lib64/ to LD_LIBRARY_PATH to set your shared libraries for this session. For example, by running the following command: export LD_LIBRARY_PATH=/opt/Autodesk/Adlm/R1/lib64/

3 Run both of the following commands, where <productKey> is your product key: /usr/autodesk/maya2011-x64/bin/adlmreg -u S <productKey> 2011.0.0.F /usr/autodesk/maya2011-x64/bin/adlmreg -u N <productKey> 2011.0.0.F

4 List the installed package names by entering: rpm -qa |egrep 'adlm|Maya'

5 Identify each package name you want to uninstall. For example, the Maya-2011-# package (where # is the package number). 6 Uninstall each package using the following command: rpm -e

PackageName

Network istration and Deployment Preparing a Deployment To prepare for a deployment, you should take the time to review the following requirements and options.


IMPORTANT While some of the concepts and procedures in the following sections may prove useful as guidelines for network s using Mac OS X and Linux, only the Windows version of the Maya installer includes a deployment wizard. Also note that most images and examples in this section are based on AutoCAD.

System requirements for istrative image Before you begin installing the program on a network, make sure that your servers and client workstations meet the minimum recommended hardware and software requirements for a deployment. For complete system requirements, see www.autodesk.com/qual-charts. The program will automatically detect if the Windows operating system is the 32- or 64-bit version when installing Maya. The appropriate version of Maya will be installed. The 32-bit version of Maya cannot be installed on a 64-bit version of Windows vice-versa.

Choose an installation type When you set up your deployment, you need to choose the type of installation to deploy. In the Deployment wizard, you specify one of the following installation types:

Stand-Alone installation (Stand-Alone option) Choose this type of installation for stand-alone installations where a single serial number and product key are used for a single seat. Like a multi-seat stand-alone installation, you do not use the Network License Manager to manage product licensing, but installation, registration, and activation occurs on each workstation.

Multi-Seat Stand-Alone installation (Stand-Alone option) Choose this type of installation for stand-alone installations where a single serial number and product key are used for multiple seats. Multi-seat stand-alone installations do not rely upon the Network License Manager to manage product licenses; however, you can still use the Deployment wizard to create istrative images and deployments. Registration and activation is more automated for multi-seat stand-alone installations. After the first activation using the multi-seat stand-alone serial number and product key,

Preparing a Deployment | 31

activation occurs automatically for all workstations based on this deployment, as long as your systems are connected to the Internet.

Network License installation With this type of installation, you install the program to workstations with the files and registry entries that allow the program to communicate with the Network License Manager. You also define the configuration of the Network License Manager so that the licenses can be accessed. Workstations running the program based on a network installation do not require individual activation. Licensing of this program is managed by at least one license server.The main advantage is that you can install Maya on more systems than the number of licenses you have purchased (for example, purchasing 25 licenses but installing on 40 workstations). At any one time, Maya runs on the maximum number of systems for which you have licenses. This means you get a true floating license.

Create a Network Share Once you have fully prepared for creating a deployment, you are ready to set up and distribute Maya by creating a network share location (folder). A network share is an installation folder that you make available to s' computers on a network. You point s to this location to install the program. NOTE You must have Full Control permissions set for your shared folder when you are creating your deployment images. Read permissions are necessary to access the network share and istrative permissions on the workstation where the program is deployed. To create a network share folder 1 On your network server’s desktop, create a folder named Deployments. 2 Right-click the Deployments folder and click Share and Security (or Sharing). 3 In the Properties dialog box, Sharing tab, select Share This Folder. 4 Specify a Share Name, such as Deployments, if necessary. 5 Click the Permissions button. In the Permissions dialog box enter your group or names, and make sure Full Control is selected. Click OK.


In Vista, right-click the Deployments folder and then click Share. In the File Sharing dialog box type in or browse to the name of the group or you want to share the folder with. Click Add, and then click Share. 6 For each product you plan to install, create a subfolder in the Deployments folder. Name each folder with the pertinent product name.

(Windows) Setting Up and Creating a Deployment The deployment process provides you with numerous options for creating, and customizing your deployments, so you should set aside ample time to complete the process in one sitting. To be successful, it is recommended that you review the following checklist and information before you begin. The deployment process is initiated from the installation wizard’s Create Deployments selection. Once a deployment is created, s then access the deployment to install products to their computers.

Prepare for a Network Deployment Complete the following preliminary tasks before creating a network deployment. Deployment Checklist Review the system requirements. Confirm your network, servers, and client workstations meet the system requirements. Understand the type of license you have purchased. For a network license deployment, you should also be familiar with the type of license server model you want to use, and the license server name(s). Install and activate any tools and utilities.

Locate your product serial number and product key. These are located on the outside of the product packaging, or in the Autodesk Upgrade and Licensing Information email message. Determine how you intend to personalize the program(s) during registration. Using consistent registration data is very important.

(Windows) Setting Up and Creating a Deployment | 33

Deployment Checklist Identify the location, and create a shared folder where deployments will reside for each program you plan to deploy. Close all other programs and disable anti-virus software.

Decide which language to use for each of your deployment packages. NOTE Languages can be included only during the creation of the deployment, not during modification. Determine whether your deployment plan involves using imaging software to distribute your program(s) to client workstations. Determine whether to create log files that contain deployment and installation data, and whether to run silent mode. NOTE When the program is installed from a deployment using silent mode, s’ systems automatically reboot without warning when the installation is complete. Determine an installation type (Typical or Custom).

Determine your preferences—including whether to display the Welcome Screen, whether to require Internet Explorer, the default publishing format, and whether to create a desktop shortcut. Set up access to online resources, such as Subscription Center, Help, Customer Error Reporting.

Your Deployment Choices Enter and Product Information The and Product Information page is used to personalize the program for your environment. The information you enter is permanently retained with the product and is displayed in the Help menu on all workstations. Because you can't change this information later without uninstalling, take care when entering the information.


You must also enter the product serial number and product key in order to run the product. The serial number and product key are located on the outside of the product packaging, or in the Autodesk Upgrade and Licensing Information email. The serial number must contain a three-digit prefix followed by an eight-digit number. The product key consists of five characters.

Creating Log Files From the General Deployment Settings dialog, you can setup two types of log files with which you can monitor information about deployments and installations. ■

Create network log The network log file keeps a record of all workstations that run the deployment. On the General Deployment Settings page, you choose whether or not to create a network log file. The log lists the name, workstation name, and the status of the installation. Refer to this file for status information and details about problems that s encountered during installation (for example, low disc space or inadequate permissions). The network log is named with the same name you chose for your deployment. You can specify where the log file is created by entering either a valid UNC (universal naming convention) path or hard-coded path on your network, for example \\MyComputer\Autodesk\ . s should use their actual computer name in place of MyComputer. NOTE The folder where the network log resides must be a shared folder where s who install the program have Change permissions. Otherwise, successes or failures for installations cannot be written to the log file.


■

Create client log The client log contains detailed installation information for each workstation. This information may be useful in diagnosing installation problems. The client log is located in the %Temp% directory of each client workstation.

What Is Silent Mode? When silent mode is active and a initiates the deployment, the installation proceeds without any explicit input. s cannot change any of your installation settings. No dialog boxes are presented that require interaction from the .

WARNING When the product is installed from a deployment using silent mode, s’ systems will reboot automatically and without warning when the installation is complete.

Create a Default Deployment If you do not plan to customize your deployment, you can create a default deployment. The following procedure illustrates how quickly you can set up a default deployment using the deployment wizard. This procedure illustrates a single-server network deployment using a Typical installation with no customizations. For information about customizing product configurations in a deployment, see Create a Custom Deployment.


To create a deployment using default settings 1 Start the Maya Installation wizard. 2 On the initial page, select a language for the deployment instructions. Click Create Deployments. 3 On the Begin Deployment page, specify the following: ■

istrative Image Field. Enter or locate the path to the shared network location where you want to create and store your istrative image. s install the program from this location. NOTE For information on how to create a network share, see Create a Network Share on page 32.

■

Deployment Name Field. Enter the new deployment's name. This name is used for the shortcut from which s will install the product.

■

This is to be a: Select either 32-bit or 64-bit for your target operating system.

Click Next. 4 On the Select the Products to Include in the Deployment page, select the products, and language to include in your deployment. Click Next. 5 Review the Autodesk software license agreement. Click I Accept, and then click Next. 6 On the and Product Information page, enter your information, serial number, and product key. Click Next. WARNING After you click Next, you cannot change the information entered on the this page unless you uninstall the product. 7 On the General Deployment Settings page specify whether to ■

Create a network log file. Specify the log file’s location by entering either a valid UNC (universal naming convention) path or a hard-coded path on your network. NOTE The folder that contains the network log file must be a shared folder for which s who install the program have Change permissions. Otherwise, successes or failures for installations cannot be written to the log file.


■

Create a client log file.

■

Run the installation in silent mode to prevent s from changing installation settings.

For more information on log files, see Creating Log Files on page 35. For more information on silent mode, see What Is Silent Mode? on page 36. Click Next. 8 On the Create Deployment page, click Create Deployment. Click Yes to continue creating the deployment using the default configuration. An istrative image is created in your shared folder using the deployment options listed in Current Settings. To retain a copy of your deployment settings, click Copy to Clipboard. 9 On the Deployment Complete page, click Finish.

Modify a Deployment (Optional) After a deployment is created, it may be necessary to modify the deployment for some client workstations. You can apply a patch or include various custom files that are not part of the base istrative image. You can also perform modifications such as changing the installation directory from drive C to drive D. To modify a deployment 1 Open the shared network folder where you originally chose to place your product deployment. 2 In the Tools folder, double-click the Create & Modify a Deployment shortcut. The deployment wizard is redisplayed. 3 Click through the deployment pages and make the necessary changes. 4 Click Create Deployment.

Point s to the istrative Image When you are done creating the deployment, s can install the program using the shortcut located with the istrative image. The shortcut name


matches the deployment name that you specified in the deployment wizard. Notify s of the location of the istrative image, instruct them to double-click the shortcut, and provide any other necessary instructions.

Distributing an Autodesk Program You can choose from several methods of distributing an Autodesk program. Network sharing is the default method. ■

Network Share. s launch the program with the shortcut icon that you created with the deployment wizard. The program is installed on s' local computers, and a product icon appears on their desktop. NOTE s must have Read permissions to access the network share and istrative permissions on the workstation where this program is installed.

■

Scripting. See Use Scripts to Deploy the Program on page 39.

■

Group Policy Objects (GPOs). See Use Group Policies to Run a Deployment.

Use Scripts to Deploy the Program A script executes a command or a set of commands. Scripts are similar to batch files but are more flexible. Installation scripts are most useful for stand-alone installation of programs on computers that are connected to a network. Scripts are also useful for installing service packs, extensions, and object enablers on a network. You create a script by using a text editor such as Notepad and then saving it in ASCII format in a file with the file extension .vbs. The script consists of one or more commands, as well as command switches that specify options, and flags that modify the options. An installation script also contains path names. An installation script points to the location of the product's setup.exe file. You must point to the setup.exe file on your product disc. For example: Autodesk product CDROM1\setup.exe

Distributing an Autodesk Program | 39

In order for Maya to run properly, the following software and prerequisites must be installed and met on the computer where the program is being installed: ■

Microsoft Internet Explorer version 6.0 Service Pack 1 or later (You can Microsoft Internet Explorer from the Microsoft website by visiting www.microsoft.com)

■

Microsoft Scripting Engine The sample scripts in this section are based on Microsoft Scripting Engine 5.6, which works with both VBScripts and JavaScript. If you don't have the scripting engine installed, you can it for free from the Microsoft website at www.msdn.microsoft.com/scripting. Sample scripts and Help files are also available there for .

■

istrative permissions

A Sample Installation Script The sample script in this section installs the program in a typical configuration. To make it easy to copy this sample script and substitute your own information, the same names are used throughout for variable items. The log file name is based on the product being installed. You can either use the log file name in the script or change it to something else. Serial number prefix: 123 Serial number: 12345678 First name: My First Name Last name: My Last Name Organization: Organization A sample script for a silent installation of this program uses the syntax shown in this section.

Scripted installation for AutoCAD LT ' Scripted installation for AutoCAD LT 2011 option explicit '


' Create variables dim shell dim productType dim strADSKFirstName dim strADSKLastName dim strADSKOrganization dim strADSKSNPrefix dim strADSKSNNumber dim strADSKProdKey dim strADSKPath dim strSourcePath '

' Script initialization Set shell = CreateObject("WScript.Shell") productType = "ACADLT" '

' Name and Organization information strADSKFirstName = "My First Name" strADSKLastName = "My Last Name" strADSKOrganization = "Organization" ' ' Serial Number information strADSKSNPrefix = "123" strADSKSNNumber = "12345678" strADSKProdKey="ABCDE" '

Use Scripts to Deploy the Program | 41

' Source to install from (e.g. D: is assumed to be Install Media) strSourcePath = "D:\" ' ' Destination to install to strADSKPath = Shell.ExpandEnvironmentStrings("%ProgramFiles%") "\Autodesk\" + "AutoCAD LT 2011" strADSKPath = strADSKPath + "\" RunStandaloneInstall() ' End of Script Wscript.quit() function RunStandaloneInstall() dim retString '

+

retString = """" & strSourcePath & "\setup.exe" & """" & "/w /t /qb " retString = retString & " /c " & productType & ": " retString = retString & "INSTALLDIR=" & """" & strADSKPath & """" & " " retString = retString & "ACADSERIALPREFIX=" & strADSKSNPrefix & " " retString = retString & "ACADSERIALNUMBER=" & strADSKSNNumber & " " retString = retString & "ADLM_PRODKEY=" & strADSKProdKey & " " retString = retString & "ACADFIRSTNAME=" & """" & strADSKFirstName & """" & " " retString = retString & "ACADLASTNAME=" & """" & strADSKLastName & """" & " " retString = retString & "ACADORGANIZATION=" & """" & strADSKOrgan ization & """" & " " retString = retString & "InstallLevel=5 " shell.run retString,2,1 end function

Use Switches and Flags in Scripts The following table lists all of the switches and flags that are relevant to installation.


NOTE You must set the installation switch to INSTALLDIR=. If this is not done, programs that run outside Maya (such as the License Transfer utility) are not installed. Switches in Installation Scripts Switch

Description

INSTALLDIR=

Specifies the location to install the product.

ACADSERIALPREFIX=

Specifies the numbers that precede the hyphen in the serial number.

ACADSERIALNUMBER=

Specifies the serial number.

INSTALLLEVEL=

Specifies the type of installation: 3=Typical

ACADFIRSTNAME=

Specifies the first name personalization.

ACADLASTNAME=

Specifies the last name personalization.

ACADORGANIZATION=

Specifies the company name.

ADLM_PRODKEY=

Specifies the product key (found on the same label as the serial number).

Interface Flags Flag

Description

q

Designates that the installation is performed in silent mode.

Run Scripts After creating a script, you move it to a server or use a mapped drive letter or a UNC (universal naming convention) path. If you place it on a server for s to run, create a share on the server, and then add s to the share with the rights they need. Because all that s need to do is run the script, provide read-only access to the share directory. Next (on the same server or on a different server), create a directory for each product you want to install. Choose a location for this directory that won't be changed so that you can point to the MSI files in your scripts. Copy the

Use Scripts to Deploy the Program | 43

product disc(s) to that directory. You may also want to create directories for service packs, extensions, and your own customization tools. You can use any of the following methods to run an installation script: ■

Run the script manually at each individual workstation. To run the installation, paste the script into the Run dialog box or run it from the Windows command prompt.

■

Send an email with the UNC path to each who should run the script. To run the script, the follows your instructions.

■

Email the script to each with instructions for use.

■

Set up the script so that it runs on .

Use Group Policies to Run a Deployment With group policies, you can and install a program by asg a deployment to computers. A deployment that is assigned to a computer can be used by any of that computer. Generally, you would assign the deployment to a computer that is used by a large number of s. NOTE Autodesk products are designed to be installed on a computer so that any who logs on to the computer can run the software. If you assign a deployment to a specific rather than a computer, you may encounter problems when a second specified tries to install or uninstall a copy of the program. The following outlines the advantages and disadvantages of using group policies. Advantages ■

Works well with deployment functionality.

■

Allows you to add custom files through the deployment wizard.

■

Allows deployment to workstations.

Disadvantages ■

Prohibits the ing of command-line parameters to an MSI executable. You must use scripts instead.


■

Prohibits customization of application settings, other than what is set while creating a deployment.

There are three main steps to distributing this program through group policies. ■

Create an application distribution share point. The application distribution share point is created using the deployment wizard. See Create a Default Deployment on page 36 or Create a Custom Deployment to create a deployment.

■

Assign the deployment to a computer. See Use Group Policies to Assign a Deployment to Computers.

■

the installation. Confirm that the program has been correctly installed. See a Group Policy Deployment on page 49.

Use Group Policies to Assign a Deployment to Computers Perform the following procedures from a Windows XP workstation or a Windows 2000 or 2003 server that has Group Policy Management Console installed, and has access to the Active Directory server. NOTE For more information about Group Policy Management, see http://technet.microsoft.com/en-us/windowsserver/grouppolicy. To assign a deployment to a computer 1 Start the Group Policy Management Console (gpmc.msc). 2 Right-click the organizational unit where you want to create the group policy object. Then select Create and Link a GPO Here and name the Group Policy. 3 Edit the policy. 4 In the Group Policy Object Editor dialog box, under Software Settings, right-click Software Installation, and click New ➤ Package. 5 In the Open dialog box, navigate to the istrative image’s location that you specified in the deployment wizard. Navigate to Image\<processor type>\<product name folder>. The processor type is

Use Group Policies to Run a Deployment | 45

either x86 or x64, depending on the processor type for which you created your deployment. Examples For x86 deployments: \\server123\Deployment\Image\x86\acad For x64 deployments: \\server123\Deployment\Image\x64\acad

6 Select the Windows Installer Packages file called acad-<deployment name>-for-GPO.msi. Click Open. If the deployment was called “Maya 2011 32 bit,” then the deployment’s the MSI file would be acad-Maya 2011 32 bit-for-GPO.msi.

7 In the Deploy Software dialog box, select Advanced and click OK.


8 In the Properties dialog box, Modifications tab, click Add.

9 In the Open dialog box, select the Transform Package file called acad-<deployment name>.mst). Click Open. 10 In the Properties dialog box, Modifications tab, click Add. 11 In the Open dialog box, navigate to <deployment location>\Tools and select the Transform Package file called gpo.mst.

Use Group Policies to Run a Deployment | 47

After clicking Open, the Properties dialog should look like the following:

12 Click OK to complete the package.


The group policy object is now assigned to all computers that are of the organizational unit for which the group policy object has been created. The next time a computer in the organizational unit is restarted, the program will be installed and will be available for all s of the computer. See a Group Policy Deployment on page 49 to confirm that the group policy has been created correctly.

a Group Policy Deployment To that this deployment has been correctly assigned to a computer, restart a computer that is in the organizational unit for which the group policy was created. The program installation begins before the prompt is displayed. The operating system displays group policy messages, including a message indicating the installation of any managed software. After logging in, double-click the program icon on the desktop to complete the installation and start the program. NOTE If problems arise, an entry is logged in the system's Event Viewer under Applications.

Distribute the Product Using Imaging Software The following information is provided for those who use imaging software, such as Norton Ghost, to create a master image to distribute Autodesk products. Once created, the master image is then replicated to other computers throughout your facility. NOTE Autodesk does not recommend or the distribution of Maya using imaging software. However, if you plan to use this method of distribution, please review the following instructions carefully. Care needs to be taken since the use of imaging software can result in the following situations: ■

Conflicts with the product licensing

■

Incomplete installations and problems with activation

Distribute the Product Using Imaging Software | 49

NOTE If you are experiencing licensing instability in a SATA RAID environment, using imaging software to distribute Autodesk products can cause product activation problems, such as “Activation code limit exceeded” when you attempt to activate.

Use a Master Image to Distribute Multi-Seat Stand-Alone Products to Multiple Systems You can distribute the product using a master image for a multi-seat stand-alone product. NOTE When using Norton Ghost, you must use the -ib switch to include the boot sector in your master image. Consult your imaging software for more details on including the boot sector as part of the master image. Master images should not be created if you’ve previously run Autodesk products on the master computer. Cleaning the system may be necessary. To distribute a multi-seat stand-alone product to multiple computers using a master image 1 Create a network deployment for a multi-seat stand-alone product. For more information, see Create a Custom Deployment. 2 Install Maya from the deployment onto the master computer. 3 Do one of the following on the master computer: ■

Create a master image, including the boot sector. Test the product on a machine other than the master computer before distributing the product. Launch the product on the other machine, and and activate it. s have a 30-day grace period to and activate the product on their machines.

■

Launch and customize the product as necessary. Create a master image and distribute it to s. If s’ computers are connected to the Internet, the product is automatically activated. s whose computers are not connected to the Internet have a 7-day grace period to and activate the product.

4 Apply the master image to the target computers.


Restore the Master Image The following procedure assumes that you have saved a copy of each workstation’s AdLM folder (and Product Licenses folder, if present) to either another workstation or a disc before you reformat the workstation. To restore a product using a master image 1 Exit the application. Do not run the application again until after you have completed this procedure. 2 In Windows Explorer, copy the AdLM folder from the appropriate path shown below to a location other than the disc that will be restored. C:\Documents and Settings\All s\Application Data\FLEXnet 3 Reformat the workstation and restore the master image. NOTE Do not perform a low-level format of the hard drive. 4 Copy the AdLM folder that you created in step 2 to its original workstation and location on that workstation. NOTE When you restore the disc image, any files that were altered are put back in their original state and ready to use again. The license files are preserved, and no reactivation of products is necessary.

Clean a Master System and Restore the Operating System If you have already run Maya on the master computer, the master computer should be properly cleaned first. To clean a master computer and restore the operating system 1 Clean the hard drive, including the boot sector. For example, if you use Norton’s GDISK utility, use the following command: gdisk 1 /diskwipe Where 1 is the hard disk that is being wiped. NOTE If you use a utility other than Norton Ghost, make sure that it cleans the boot sector; otherwise, you will not be able to activate Autodesk products.

Distribute the Product Using Imaging Software | 51

2 Create a new partition and use the restore disc or product disc to install the operating system.

Install mental ray for Maya satellite Overview of mental ray (satellite) mental ray for Maya s a different form of network rendering: mental ray satellite rendering. The new network rendering capability, based on mental ray satellite technology, allows you to install a version of mental ray (satellite) on any networked computer. This special version of mental ray resides on that machine and waits for rendering tasks from Maya. It supplements the mental ray rendering capabilities in Maya with the additional rendering power provided by the networked computers’ Us. A mental ray distributed rendering can speed up all of the following tasks: ■

interactive rendering (through the Maya interface)

■

IPR rendering with mental ray for Maya

■

interactive batch rendering (a batch render started by Maya)

■

command-line rendering

The rendering process is typically initiated from the master machine (the machine running Maya or where the command-line render starts from). The slave machines (satellite rendering computers) process rendering tasks they receive over the network from the master and send back results. The master machine handles task distribution, load balancing, and the collection of received rendering tasks which make up the rendered image. For more information about mental ray satellite, including how to set up the rayhosts file to get and receive data from Maya, see the Maya Help. In the Maya Help, navigate to Guide > Rendering and Render Setup > Rendering > mental ray for Maya rendering > Network rendering using mental ray for Maya. Setting up the rayhosts file is required for mental ray for Maya satellite rendering to work.


Slave machine installation The special version of mental ray standalone with satellite rendering technology must be installed on all slave machines. The satellite-enabled versions of mental ray for Windows, Mac OS X, and Linux are included with this release of Maya on the Maya DVD. (Windows) To install mental ray standalone with satellite licensing 1 On each slave machine, begin the installation process by inserting the Maya DVD, opening the mental ray satellite folder and the platform-specific Windows folder, and double-clicking the mental ray standalone installer. The installer appears. 2 Follow the installation steps. During the installation, you can click Custom to change the installation directory. The default installation directory is: C:\Program Files\Autodesk\mrsat3.8.1-maya2011

(Mac OS X) To install mental ray standalone with satellite licensing 1 On each slave machine, begin the installation process by inserting the Maya DVD, opening the mental ray satellite folder and double-clicking the mental ray standalone installer. 2 Follow the installation steps. During the installation, you can change the installation directory. The default installation directory is: /Applications/Autodesk/mrsat3.8.1-maya2011

(Linux) To install mental ray standalone with satellite licensing using rpm 1 as root. 2 On each slave machine, begin the installation process by inserting the Maya DVD. 3 Mount the DVD drive, if necessary. For example, type: mount -r /dev/dvd /mnt/dvd

4 Open the mental ray satellite directory, go to the Linux directory, and enter the following command (where # is the specific package number):

Slave machine installation | 53

rpm –ivh mentalraySatellite3.8.1_maya2011-3.8-#.x86_64.rpm

NOTE 64-bit Windows releases of mental ray for Maya satellite use the same port and service name as the 32-bit version. You will run into problems if you install both the 32-bit and the 64-bit versions on a 64-bit system. There is only one service entry/xinetd config, so installing a 64-bit package after the 32-bit (or the other way around) leaves only the last installed version working.

Slave machine additional setup Once this version of mental ray is installed and running, a service on the machine (the Ray Sat server) waits for rendering tasks from mental ray for Maya on the master machine. The satellite-enabled version of mental ray does not require its own licensing; it is activated through Maya’s licensing. On the slave machine, the Ray Sat server (service name: mental ray Satellite 3.8.1 for Maya 2011) must be running. To that it is running on Windows, follow this procedure. To that Ray Sat server is running (Windows) 1 Open a Windows command prompt. 2 Navigate to the bin directory of the mental ray satellite standalone. By default this is C:\Program Files\Autodesk\mrsat3.8.1-maya2011\bin\. 3 Type the following: raysat2011server /query

A message should be returned that the RaySat2011 Server service is running. If you do not get this message, make sure that RaySat2011 Server has been installed as a service, and start it from the Services Control (Settings > Control > istrative Options > Services) or type the following: raysat2011server /start

Slave machine port setup On the slave machine, port number 7411 is set by default. This works well in the majority of cases and you won’t need to change the port number.


If you want to change the port number that mental ray satellite uses to a value other than 7411, you must edit the services file. The port value would be determined by your network (a free T/IP port). To change the port number (Windows, Linux) 1 Edit the services file with a text editor. The services file is located at: ■

(Windows XP) C:\Windows\system32\drivers\etc\services

■

(Linux) /etc/services

2 Change the number in the following line (here, 7411) to the desired port number: mi-raysat2011 7411/t

To change the port number (Mac OS X 10.4, Tiger) 1 as super (sudo -s). 2 Open the file /etc/services using your preferred text editor. 3 Edit the line: mi-raysat2011 7411/t. 4 Save the file. 5 From the Finder menu, select Go > Applications and then double-click the Utilities folder. 6 Double-click the NetInfo Manager icon. 7 Under the Services directory of the NetInfo database, find and select the appropriate service (mental ray Satellite 3.8.1 for Maya 2011). 8 Click the lock icon at the bottom of the and then enter your name and . This allows you to unlock the NetInfo database and make changes. 9 Select the port field and change its value to the desired port number. 10 Click the lock icon again when you’re done. 11 From the Finder menu, select Domain > Save Changes to commit your changes to the NetInfo database. 12 Reboot your machine.

Slave machine port setup | 55

To change the port number (Mac OS X 10.5, Leopard) 1 as super (sudo -s). 2 Open the file /etc/services using your preferred text editor. 3 Edit the line: mi-raysat2011 7411/t. 4 Save the file. 5 Open a Terminal window and do the following: sudo /usr/bin/dscl . -change /Services/mi-raysat2011port <cur rentportnumber>

For example: sudo /usr/bin/dscl . -change /Services/mi-raysat2011 port 7109 7411

NOTE To determine the port you’re currently using, in a Terminal window, type: /bin/dscl . -read /Services/mi-raysat2011 6 Reboot your machine.

Licensing of satellite rendering For standalone licenses, the use of mental ray for Maya with satellite can only be initiated from the specified host for which your received your Maya key. The workstation can distribute mental ray for Maya rendering to up to eight slave Us. For networked licenses, use of the functionality is slightly more flexible. For networked license setups, the license running Maya and the license running mental ray for Maya can be logged out separately, allowing certain rendering tasks to be initiated remotely. There are two possible cases when using mental ray for Maya with networked licenses: ■

(Interactive) With Maya running interactively on a workstation, initiate a mental ray for Maya render (either a single frame in the Render View, Batch render or command line render) on the workstation. The networked mental ray for Maya portion of your license is logged out. This allows the mental ray satellite slaves indicated in your rayhost file to participate in the render.


■

(Offline) If you launch a command line mental ray for Maya render, the computer you launched the command from then becomes the master machine for mental ray for Maya satellite rendering. NOTE If you have launched Maya but have not yet rendered with mental ray for Maya since the start of your interactive session, no mental ray for Maya line item from your networked license is checked out. You may therefore start a command line mental ray for Maya render from another host. This checks out the mental ray for Maya portion of the license, making it unavailable for any other workstation, including the workstation of the who launched Maya.

For more details on mental ray rendering, see the Rendering sections of the Maya Help, as well as the mental ray reference included with the Maya Help.

Installation Troubleshooting This section provides solutions to installation issues and answers to commonly asked questions that may arise while installing your product(s). Additional troubleshooting information and is also available at http://autodesk.com/servicesand

General Installation Issues This section outlines common issues and their solutions that may arise while performing a general install of your product(s).

How can I check my graphics card driver to see if it needs to be updated? It is recommended that you and update your graphics card driver to optimize your program. Use the following procedure to identify your current graphics card driver. To identify your graphics card driver 1 On the Start menu (Windows), click Settings ➤ Control . 2 Click the Display icon to access the Display Properties.

Installation Troubleshooting | 57

In Vista, click Settings ➤ Control ➤ Personalization ➤ Display Settings. 3 Open the Settings tab and click the Advanced button. 4 Click the Adapter tab to check the adapter type. 5 Click the Properties button and open the Driver tab to check driver version and see if newer drivers are available. TIP Many newer graphic cards offer tabbed pages where you can learn more precise information about your specific graphic card. If specific tab pages are present, refer to them instead of the Adapter tab.

What is the text editor used for? The text editor you designate during installation is used for editing text files such as PGP and CUS dictionary files while you are running your product.

What is the difference between a stand-alone license and a network license? Stand-alone licensed products are ed and activated to an individual workstation. While the software can be installed on multiple systems in your facility, the license only allows one system to be operational. If you need to run more systems, you need to purchase more stand-alone licensed products, or consider converting to network licenses. Network licensed products rely on the Network License Manager to keep track of software licenses. The software can be installed and run on multiple systems, up to the maximum number of licenses you’ve purchased. The Network License Manager “checks out” licenses until they are all in use. No further systems can run the program until a license is “checked in.” If you need to run more systems, you can purchase additional licenses for the Network License Manager to maintain.


What is the benefit of using a network licensed version of the software? Network licensed products are recommended for large drafting/design facilities, classrooms, and lab environments. The main advantage is that you can install products on more systems than the number of licenses you have purchased (for example, purchasing 25 licenses but installing on 40 workstations). At any one time, products will run on the maximum number of systems for which you have licenses. This means you get a true floating license. If software needs to be run on more systems, additional licenses can be purchased.

How do I access my documentation? Documentation is available on the product media or as a web-based Help file. The complete Help system is installed during the product installation process. During the installation process, you can access specific installation and licensing documentation by clicking the Read the Documentation or Documentation links in the wizards.

What is SAMreport-Lite? SAMreport-Lite is a report generator that helps you monitor the usage of applications that use FLEXnet. SAMreport-Lite complements FLEXnet by providing a graphical interface (GUI) from which to run usage reports. SAMreport-Lite can help you make better decisions about your software assets. For more information, see the SAMreport-Lite ’s Guide.

Deployment Issues This section outlines common issues and their solutions with regards to software deployments.

Is there a checklist I can refer to when performing a deployment? Maya Installation contains a checklist that describes preliminary actions of the deployment process. See Prepare for a Network Deployment on page 33.

Deployment Issues | 59

Where should deployments be located? Shared folders are required for both network license and multi-seat stand-alone methods of installation. The shared folder (network share) is created before you run the installation wizard and is where product deployments are stored. Shared folders are required for multi-seat stand-alone methods of installation. The shared folder (network share) is created before you run the installation wizard and is where product deployments are stored. It is recommended that you name the network share folder Deployments on the desktop of the system where you want deployments stored. You can then add subfolders inside the shared Deployments folder that clearly convey the names of products you plan to deploy. For example, any subfolders that are placed inside a shared folder are automatically shared. TIP You must have Full Control permissions set for your shared folder when you are creating your deployment images. Read permissions are necessary to access the network share and istrative permissions on the workstation where the program is deployed.

What are RSS feeds and how do they benefit my installation? An RSS feed is a live link you initiate by subscribing to someone’s website. Once subscribed, the primary benefit is a constantly updating stream of content that is delivered to your system in the form of summarized articles, forum threads, blog posts, and so on. RSS stands for Rich Site Summary (or Really Simple Syndication).

Networking Issues This section outlines common issues and their solutions with regards to performing a network installation or configuring your network license server(s).

Where do I find my server name? When installing a network licensed product, you must specify the name of the server that will run the Network License Manager. If you don’t know the server name, you can quickly find it by opening a Windows command prompt on the system that will be the Network License Manager. At the prompt, enter ipconfig /all and note the Host Name entry.


What is an istrative image (MSI) file? An istrative image is a collection of shared file resources created during the deployment process and is used by deployments to install the program to networked workstations. Service packs (patches) can be applied to an istrative image when you create the deployment. A .msi file is a Microsoft Installer file.

What is the impact of selecting all products for the istrative image, and can I add products later? If you elect to include all products in your deployment, the istrative image will be larger. You should select all products only when you create multiple deployments from this image and prefer not to use the installation disc. If there are products you rarely or never use, and you do not expect to create additional deployments, you should only select a subset of products. You can still create a deployment at a later date, and include additional products, but you need to create a new istrative image. You need the installation disc to do so.

Uninstall and Maintenance Issues This section outlines common issues and their solutions with regards to adding and removing features, reinstalling or repairing your installation, and uninstalling products.

When should I reinstall the product instead of a repair? You should reinstall your product if you accidentally delete or alter files that are required by the program. Missing or altered files adversely affect the performance of your product and cause error messages when you try to execute a command or find a file. If an attempt to repair an installation fails, reinstalling is the next best option.

Uninstall and Maintenance Issues | 61

Do I need my original disc(s) to reinstall my product? When performing a reinstall of the product, you are prompted to load your original disc(s). Installation data is cached locally on your drive and that data is reused when reinstalling.

When I uninstall my software, what files are left on my system? If you uninstall the product, some files remain on your system such as files you created or edited (drawings or custom menus). Your license file also stays on your workstation when you uninstall your product. If you reinstall on the same workstation, the license information remains valid and you do not have to reactivate the product.


Glossary of Installation

3

activate Part of the Autodesk software registration process, it allows you to run a product in compliance with the product's end- license agreement. Active Directory A directory service from Microsoft that is part of Windows 2000 and Windows 2003 Server that manages the identities and relationships that make up network environments. istrative image A collection of shared file resources created by the deployment wizard and used by deployments to install the program to network workstations. advertising A pull technology that notifies s of an updated software product that is available for installation. s typically double-click a shortcut (or do a similar operation) to complete the installation of the d product. deploy The process of installing an Autodesk product to one or more computers on a network. deployment A link to a unique MST (Microsoft Transform) file that serves as a basis for an installation. Using the deployment wizard, s can create multiple deployments that result in different types of installations for s. directory service A network service that identifies all resources on a network and makes them accessible to s and applications. Resources include email addresses, computers, and peripheral devices such as printers. Ideally, the directory service should make the physical network topology and protocols transparent so that a on a network can access any resource without knowing where or how it is physically connected. Virtually all directory services are based on the X.500 ITU standard. group policy Microsoft server technology that provides a way to do push installations and advertising-based installations using standard Microsoft 2000 Server istration components. installation image A deployment that consists of an MSI file, any associated transforms, additional -specified custom files, and profile and registry settings.

63

language pack A set of installed files that enable the to work in the application in the language specified by the Language Pack. language family A set of languages (core product, plus language packs) that are distributed together, typically based on a geographic grouping. License Transfer utility Allows you to use an Autodesk product on more than one computer without purchasing a separate license for each computer. MSI Microsoft installer that s a variety of parameters that can be scripted. MSP Microsoft patch file (see patch). MST Microsoft transform file. Modifies the components installed by the MSI file. For example, the deployment wizard creates an MST file with the settings that you specify. The deployment created by the deployment wizard uses the MST file in conjunction with the MSI file and MSIEXEC to install the program on local workstations. multi-seat stand-alone installation A type of installation where multiple stand-alone seats of the program are installed using a single serial number. network license installation A type of installation where you install the program to workstations with the files and registry entries that allow the program to communicate with the Network License Manager. partial profile A profile that contains partial registry information corresponding to a subset of the options available from the Files tab of the Options dialog box. patch A software update to an application. power A with rights to access and write to the Program Files folder and the HKEY_Local_Machine folder of the registry. pull technology An installation technology that requires interaction to complete the installation. push technology An installation technology that installs files to a remote desktop without any interaction. scripting The process of using scripting languages such as VB Script to facilitate the deployment of software packages. service pack Autodesk terminology for an application patch. silent mode An installation that proceeds without any explicit input. No dialog boxes are presented that require interaction from the .

64 | Chapter 3 Glossary of Installation

Autodesk Licensing Guide

65

66

Stand-Alone Licensing Guide

4

Stand-alone Licensing A stand-alone license allows you to run an Autodesk® product on a single workstation.

Introduction Stand-alone licensing allows you to use your Autodesk product in trial mode for a given number of days from the first time you launch the product. The number of days that a trial mode is active differs between Autodesk products. You can activate your license at any time before the trial period expires. When you activate your product, you receive an activation code. If you activate online, your activation code is automatically retrieved from Autodesk and the product starts. Activations are also available through email, fax, phone, or the Autodesk website. NOTE If you are installing and using an Autodesk product on both operating systems of a dual-boot operating system, you must obtain a separate activation code for each operating system. The license file stays on your workstation when you uninstall your product. If you reinstall your Autodesk product on the same workstation, the license information is still valid. You do not have to reactivate the product.

67

Multi-Seat Stand-Alone License A multi-seat stand-alone license allows you to install, , and activate an Autodesk product on several workstations using a single serial number. Multi-seat licenses can be purchased through your Authorized Autodesk Reseller. The Create Deployment feature in the provided installer simplifies deployment by creating a server image that you can access to install the software on your workstation. The software activates automatically when it is started for the first time and if an Internet connection is available. NOTE To avoid activation failures, it is recommended that you use the provided installer to create the deployment server image. For more information about multi-seat stand-alone install, see your product’s installation documentation.

Activate Your Product You can activate your Autodesk product either on startup or while you are running the product. If you cannot activate online, offline activation is available.

Manage your Stand-Alone License Check Product Information You can view detailed information about your Autodesk product and your product license (such as the license usage type and the license behavior), and then save this information as a text file.

License usage types NOTE All license types are available as stand-alone and network except for the Student Portfolio license, which is available as stand-alone only. Commercial A license for a product that was purchased commercially. Not for Resale A license for a product that is not sold commercially.

68 | Chapter 4 Stand-Alone Licensing Guide

Educational (EDU)/Institution A license designed specifically for educational institutions. Student Portfolio A license for students who are using an Autodesk product as part of their curriculum.

License behaviors Trial A license that allows individuals to try the product in trial mode for a specified number of days. The trial period starts the first time you launch your product. When the trial period expires, the product must be ed and activated to continue use. Permanent Allows permanent use of an Autodesk product. Term Extendable Allows access to an Autodesk product for a limited time. The term can be extended at any time. Term Non-Extendable Allows access to an Autodesk product for a limited time. The term cannot be extended.

View Product Information To view product information 1 Launch Maya. 2 Select Help > About Maya from the main menu bar. 3 In the About Autodesk Maya window, click Product License Information. 4 In the Product License Information dialog box that appears, view details about your product and the product license. NOTE Only basic license borrowing for Maya is ed through the Borrow License button in this dialog box. For more information, see Borrow a Maya license with sub-features on page 121. 5 In the Product License Information dialog box, click Close.

Save License Information as a Text File You can save your product license information as a text file.

View Product Information | 69

To save license information as a text file 1 Launch Maya. 2 Select Help > About Maya from the main menu bar. 3 In the About Autodesk Maya window, click Product License Information. 4 In the Product License Information dialog box, click Save As. 5 In the Save As dialog box, name the file, choose a location where you want to save the file, and then click Save. 6 In the Product License Information dialog box, click Close.

Update Your Serial Number If you installed your product with the trial serial number (000-00000000), you can update that trial serial number with a valid serial number. Your valid serial number is located on the outside of the product packaging or in the Autodesk Upgrade and Licensing Information email you received if you ed your product. NOTE If you have lost your serial number, the Autodesk Business Center (ABC) at 800-538-6401 for assistance. When you and activate your product, you are asked for the product serial number, which is automatically entered upon completion of the activation process. If you have a multi-product bundle of software that uses a single serial number, only the first product you and activate displays the updated serial number. For other products to display the serial number, you must update it from the Help menu. NOTE For the updated serial number to display, you must be logged into the system with rights. To update your serial number 1 Launch Maya. 2 Select Help > About Maya from the main menu bar. 3 In the About Autodesk Maya dialog box that appears, click Product License Information.


4 In the Product License Information dialog box, click Update. 5 In the Update the Serial Number dialog box, enter your product serial number. The serial number is located on the outside of the product packaging or in the Autodesk Upgrade and Licensing Information email you received if you ed your product. NOTE If you have lost your serial number, the Autodesk Business Center (ABC) at 800-538-6401 for assistance. 6 Click OK. You can now see the updated serial number.

Transfer your Stand-alone License About the License Transfer Utility The License Transfer Utility transfers a product license online from one computer to another, and ensures that the product works only on the computer that contains the license. The License Transfer Utility is a custom stand-alone installation option. During installation, a shortcut is created. A shortcut is installed once per product, per workstation. You may want to transfer a license to a computer temporarily (if you want to use an Autodesk product on your laptop, for example) or permanently (if the computer where you originally activated your Autodesk product is being replaced). You can leave the license on the secondary computer indefinitely, or you can move the license between computers as needed. License transfers rely on the product’s serial number. Before an Autodesk product can be exported, it must be activated with the serial number and product key. During license import, a previously activated and exported license is imported to a product or product suite installed with the same serial number. The activation is transferred to the import computer, completing the license transfer. NOTE The number of concurrent exports you can have, is equal to the number of seats you own. For example, if you own one seat you can have one export in progress at a time. You cannot complete another export until the one in progress has been imported. Similarly, if you have five seats, you can have up to five concurrent exports in progress at one time.

Transfer your Stand-alone License | 71

NOTE When you upgrade your Autodesk product (non-subscription), you can no longer perform online license transfers of the previous license. NOTE Although the License Transfer Utility allows you to transfer your product license between computers, your license agreement may not allow the installation of an Autodesk product on more than one computer. Read your license agreement to find out whether your product license permits the use of the License Transfer Utility. To transfer a license you must have an Internet connection, have an Autodesk product installed on both computers, and perform an online export and import of the license.

Install the Autodesk Product Before you can use the License Transfer Utility to transfer licenses, you must have an Autodesk product installed on all computers involved in the transfer.

To install the Autodesk product 1 Install and activate the Autodesk product on a computer. See your product's installation instructions for complete details. 2 Install the Autodesk product on any other computer that will be using the License Transfer Utility. You do not have to or activate the product on this computer. See your product's installation instructions for complete details.

Export a License A license is exported when the License Transfer Utility moves a product license from a computer to the online Autodesk server. The license can be exported as public or private. Exporting a license as public means that you are not reserving the license and anyone using the same serial number and their own ID and can import that license. Exporting a license as private means that you are reserving that license for yourself and the license can only be imported with the same serial number, your ID, and your . NOTE An Internet connection is required to export a license.


To export a license 1 On the computer where you want to export the license, do the following: ■

(Windows XP/Windows 7/Windows Vista) Click Start ➤ All Programs ➤ Autodesk ➤ [Autodesk Product] ➤ License Transfer Utility.

■

(Mac OS X) Navigate to /Applications/Autodesk/maya2011/Licensing/ and double-click the License Transfer Utility application.

■

(Linux) Open a shell and run the following command, where <productKey> is your product key: /opt/Autodesk/Adlm/R1/bin/LTU <productKey> 2011.0.0.F -d "SA"

The License Transfer Utility displays the Autodesk product name and serial number. 2 In the License Transfer Utility, click Sign In. 3 On the page, enter your Autodesk ID and and click . 4 On the License Export page, confirm the export information. 5 If you want to make the license available as a public import, click Make the license available as a public import. 6 Click Export. 7 On the License Export Confirmation page, click Finish.

Import a License A license is imported when the License Transfer Utility moves a previously exported product license from the online Autodesk server to a computer. When you have exported a product license from a computer, you complete the license transfer process by importing that license onto a computer. A license is imported when the License Transfer Utility creates an active license on a computer, allowing your Autodesk product to run on this computer. When you use the License Transfer Utility to import a license to a computer, you are not activating the product on the computer; you are simply transferring your activation to this machine. NOTE An Internet connection is required to import a license.

Import a License | 73

To import a license 1 On the computer where you want to import the license, do the following: ■


■


■


The License Transfer Utility displays the Autodesk product name and serial number. 2 In the License Transfer Utility, click Sign In. 3 On the page, enter your Autodesk ID and and click . 4 On the License Import Confirmation page, click Finish. The license is now imported to the computer and you can run your Autodesk product on this computer. If you want to transfer the license to another computer, repeat the export and import procedures.

To import a license to replace a trial license 1 On the computer where you want to import the license, do the following: ■


■


■


The License Transfer Utility displays the Update the Serial Number and Product Key options. 2 Enter the serial number and product key to update your Autodesk product and click Update. The License Transfer Utility displays the updated serial number.


3 In the License Transfer Utility, click Sign In. 4 On the page, enter your Autodesk ID and and click . 5 On the License Import Confirmation page, click Finish. The license is now imported to the computer and you can run your Autodesk product on this computer. If you want to transfer the license to another computer, repeat the export and import procedures.

Troubleshoot a Stand-alone License Error Hardware Changes If you replace or reconfigure hardware on the computer where your Autodesk product license resides, the stand-alone license might fail. You will not be able to use your product. To prevent damage to your product license, use the License Transfer Utility to export your license file. After you make the hardware change, you can import the license file back. For instructions ing the License Transfer Utility, see Transfer Your Stand-Alone License. NOTE If you get a license error when you change your hardware, you may have to reactivate your license. See Activate Your Product on page 68.

Reinstalling an Operating System If you reinstall your operating system on the computer where your Autodesk license resides, the license might fail. You will not be able to use your product. To resolve a license error in this case, you must reactivate your product. See Activate Your Product on page 68.

To prevent a license error when you reinstall an operating system NOTE If using Norton Ghost Boot Record.

™

or another image utility, do not include the Master

Troubleshoot a Stand-alone License Error | 75

1 Locate one of the following folders and make a backup copy: ■

(Windows XP) C:\Documents And Settings\All s\Application Data\FLEXnet

■

(Windows 7/Windows Vista) C:\ProgramData\FLEXnet

2 Reinstall the operating system and reinstall the Autodesk product. 3 Paste the license folder to the same location from which you originally copied the folder in step 1. You can now run your Autodesk product.

Changing the System Date and Time Your product license allows for time changes to the system clock within two days of the current time. If you set your system clock back more than two days, the next time you start your product, you will receive a message that gives you the option of correcting the system clock. If you do not correct the system clock, you receive a license error.

To prevent a license error due to a change in system date and time ■

Make sure that your computer's system date and time are accurate when you install and activate your Autodesk product.

Distributing Software Image to Multiple Computers You can use the Deployment Wizard’s Stand-alone option to create a software installation image on your server. You can distribute this image by making it available on your computer network. During creation of this image, you are prompted for registration information, which is stored with the image and deployed to all installations. Additionally, you can manually distribute the software using the installation CD that comes with your Autodesk product. However, if your computers do not have an Internet connection, make sure the registration data for each computer matches exactly. Inconsistent registration data can cause activation failures.


To prevent a license error when distributing software image to multiple computers ■

The distribution of applications using “ghosting” is not recommended, and can result in incomplete installations and activation problems.

Stand-alone Licensing FAQs How do I switch my license from stand-alone to network or network to stand-alone? If you have purchased stand-alone and network licenses and you want to switch which license Maya is using, there are two main methods to change the license type. ■

■

Uninstall and re-install Maya, changing the type of license you specify during the install. Edit the MAYA_LICENSE_METHOD environment variable in your license.env file.

If you have added the MAYA_LICENSE_METHOD variable to your system environment variables or to a Maya.env file, you must also update the license type in those locations.

To edit the MAYA_LICENSE_METHOD environment variable 1 Locate the license.env file in the following location: ■

(Windows) C:\Program Files\Autodesk\Maya2011\bin

■

(Linux) /usr/autodesk/maya2011-x64/bin

■

(Mac OS X) In the Maya installation directory (by default /Applications/Autodesk/maya2011/), right-click the Maya application and select Show Package Contents. Locate the license.env file in the

Contents directory. 2 Edit the MAYA_LICENSE_METHOD variable to indicate the type of license you want, for example: MAYA_LICENSE_METHOD=standalone

to set Maya to use a stand-alone license, or

Stand-alone Licensing FAQs | 77

MAYA_LICENSE_METHOD=network

to set Maya to use a network license. If you are switching from a stand-alone to a network license, continue with the following steps to set your license server name. 3 Navigate to the following directory to locate and open the LIATH.LIC file. ■

(Windows) C:\Program Files\Autodesk\Maya2011

■

(Mac OS X and Linux) /var/flexlm/

4 Edit the line SERVER <servername> where <servername> is your license server name. If you do not find the LIATH.LIC file in this location, you can create a license file by saving a text file with the extension .lic, and including the following lines: SERVER <servername> 0 USE_SERVER

IMPORTANT If you have added the MAYA_LICENSE_METHOD variable to your system environment variables or to a Maya.env file, you must also update the license type in those locations. To locate the Maya.env file ■ ■

(Windows) C:\Documents and Settings\\My Documents\maya (Mac OS X) /s/name/Library/Preferences/Autodesk/maya/version

■

(Linux) /home/<>/maya


Network Licensing Guide

5

Network Licensing A network license lets you run an Autodesk product on a network. Network licenses can be purchased through your Authorized Autodesk Reseller. Setting up network licenses for an Autodesk product requires careful planning and execution. This section gives you instructions about how to set up a network licensed environment, and assumes that you are familiar with the terminology and processes required to set up an Autodesk product to run on a network.

Plan Your Network Licensing This section contains information that you need to know before you set up a network license server. The section includes information about ed license server models, license operation and availability, network license file definitions and parameters, license file examples, license types and behaviors, and the license server heartbeat signal.

System Requirements for the Network License Manager System Requirements for the Network License Manager (Windows) Make sure that your network license server meets the minimum recommended requirements. See the following tables for hardware and software requirements.

79

NOTE The Network License Manager s Ethernet network configurations only. Hardware and software requirements for the network license server (Windows) Hardware/Software

Requirement

Operating System

Windows® 7® 32-bit Windows 7 64-bit ■

Windows 7 Starter (32-bit)

■

Windows 7 Home Basic (32-bit)

■

Windows 7 Home

■

Windows 7 Professional

■

Windows 7 Ultimate

■

Windows 7 Enterprise

Windows Vista 32-bit SP2 or later Windows Vista 64-bit SP2 or later ■

Windows Vista Enterprise

■

Windows Vista Business

■

Windows Vista Ultimate

■

Windows Vista Home and Basic (32-bit)

■

Windows Vista Home (64-bit)

Windows XP 32-bit SP2 or later Windows XP 64-bit SP2 or later ■

Windows XP Home

■

Windows XP Professional

Windows Server 32-bit SP1 or later Windows Server 64-bit SP1 or later ■

Windows 2008 Server R2

■

Windows 2008 Server

■

Windows 2003 Server R2

■

Windows 2003 Server

80 | Chapter 5 Network Licensing Guide

Hardware and software requirements for the network license server (Windows) Hardware/Software

Requirement

Computer/processor

Intel® Pentium® III or higher 450 Mhz (minimum)

Network interface card

Compatible with existing Ethernet network infrastructure NOTE The Network License Manager s multiple network interface cards, but at least one must be an Ethernet card.

Communication protocol

T/IP NOTE The Network License Manager uses T packet types.

Browsers

Internet Explorer® 6 Internet Explorer 7 Internet Explorer 8

FLEXnet

11.7.0.0

Virtual Machine (Windows) Hardware

Virtualizer

Virtual OS

Intel PC 64

Windows 2008 or Windows 2003R2 servers running on VM-

Vista 64-bit, Vista 32-bit, Windows XP 32-bit, Windows 7 32-bit (Home , Professional, Ultimate, and Enterprise), Windows 7 64-bit, Windows Server 32-bit, Windows Server 64-bit

ware® ESX3.5 Update 3 (License Manager Only)

System Requirements for the Network License Manager (Mac OS X) Make sure that your network license server meets the minimum recommended requirements. See the following tables for hardware and software requirements.

System Requirements for the Network License Manager | 81

NOTE The Network License Manager s Ethernet network configurations only. Hardware and software requirements for the network license server (Mac OS X) Hardware/Software

Requirement

Operating system

Mac OS® X version 10.6 and later

Computer/processor

Intel Mac


Compatible with existing Ethernet network infrastructure NOTE The Network License Manager s multiple network interface cards, but at least one must be an Ethernet card.


T/IP NOTE The Network License Manager uses T packet types

Browsers

Safari 4.0

FLEXnet

11.7.0.0

System Requirements for the Network License Manager (Linux) Make sure that your network license server meets the minimum recommended requirements. See the following tables for hardware and software requirements. NOTE The Network License Manager s Ethernet network configurations only. Hardware and software requirements for the network license server (Linux) Hardware/Software Operating system

Requirement Linux® 64-bit Red Hat® Enterprise Linux 5.0 WS (U4)

Computer/processor

Intel Pentium 3 or higher 450 Mhz (minimum)


Compatible with existing Ethernet network infrastructure


Hardware and software requirements for the network license server (Linux) Hardware/Software

Requirement NOTE The Network License Manager s multiple network interface cards, but at least one must be an Ethernet card.


T/IP NOTE The Network License Manager uses T packet types

FLEXnet

11.7.0.0

Plan Your License Server Configuration You must decide which license server model to use for managing your Autodesk product licenses on a server. Autodesk s the following network license server models: ■

Single license server model

■

Distributed license server model

■

Redundant license server model

Single License Server Model In the single license server model, the Network License Manager is installed on a single server, so license management and activity is restricted to this server. A single license file represents the total number of licenses available on the server. Advantages of the Single License Server Model ■

Because all license management takes place on a single server, you have just one point of istration and one point of failure.

■

Of the three license server models, this configuration requires the least amount of maintenance.

Plan Your License Server Configuration | 83

Disadvantage of the Single License Server Model ■

If the single license server fails, the Autodesk product cannot run until the server is back online.

Distributed License Server Model In the distributed license server model, licenses are distributed across more than one server. A unique license file is required for each server. To create a distributed license server, you must run the Network License Manager on each server that is part of the distributed server pool. Advantages of the Distributed License Server Model ■

Servers can be distributed across a wide area network (WAN); they do not need to exist on the same subnet.

■

If one server in the distributed server pool fails, the licenses on the remaining servers are still available.

■

If you need to replace a server in the distributed server pool, you do not need to rebuild the entire pool.

■

Server replacement is easier than in a redundant server pool, where you must reactivate the entire pool.

Disadvantage of the Distributed License Server Model ■

If a server in the distributed server pool fails, the licenses on that server are unavailable.

Redundant License Server Model In the redundant license server model, you use three servers to authenticate a single license file. One server acts as the master, while the other two provide backup if the master server fails. With this configuration, licenses continue to be monitored and issued as long as at least two servers are still functional. The license file on all three servers is the same. You must install the Network License Manager on each server. In the redundant license server model, all servers must reside on the same subnet and have consistent network communications. (Slow, erratic, or dial-up connections are not ed.)


Advantage of the Redundant License Server Model ■

If one of the three servers fails, all licenses that are managed in the server pool are still available.

Disadvantages of the Redundant License Server Model ■

If more than one server fails, no licenses are available.

■

All three servers must reside on the same subnet and have reliable network communications. The redundant server pool does not provide network fault tolerance.

■

If one of the three servers is replaced, the complete redundant server pool must be rebuilt.

■

If your Autodesk product s license borrowing and licenses are borrowed from a redundant license server pool, you must restart the license server after you stop the Network License Manager.

Learn About Your License In this section, you learn about license operation and availability, the license file, license types and behaviors, and the heartbeat signal.

License Operation and Availability When you start an Autodesk product, the product determines the server from which it should try to obtain a license. The product then requests a license through the T/IP network protocol to the license server. If the number of available licenses has not been exceeded on the license server, the Network License Manager assigns a license to the workstation. A product session then starts on the workstation, and the number of available licenses on the license server is reduced by one. Likewise, when you exit a product, the Network License Manager frees a license for another . If you run multiple sessions of an Autodesk product on an individual workstation, only one license is used. When the last session is closed, the license is freed.

Learn About Your License | 85

The following three processes manage the distribution and availability of licenses: ■

License manager daemon (lmgrd.exe). Handles the original with the application, and then es the connection to the vendor daemon. The lmgrd.exe daemon is used to communicate with the vendor daemon only; lmgrd.exe does not authenticate or dispense licenses, but rather es requests to the vendor daemon. By using this approach, a single lmgrd.exe daemon can be used by multiple software vendors to provide license authentication. The lmgrd.exe daemon starts and restarts the vendor daemons as needed.

■

Autodesk vendor daemon (adskflex.exe). Tracks the licenses that are checked out and the workstations that are using them. Each software vendor has a unique vendor daemon to manage vendor-specific licensing. As its name implies, the adskflex.exe vendor daemon is specific to Autodesk products.

■

License file. A text file that has vendor-specific license information.

You can run only one Autodesk vendor daemon (adskflex.exe) on your license server. This means that if you plan to serve licenses for multiple Autodesk products that were purchased individually (not as part of a suite or bundle) you must combine the license file contents for the products into one license file. For example, if you plan to serve Maya licenses from a machine that is already serving 3ds max licenses, you must append the contents of your Maya license file to the 3ds max license file. See Example of a License File for Combined Autodesk Product Versions on page 91 for more information. TIP You can use the following commands to query the status of your license server and determine how many licenses you have in total, how many are in use, and to that your license server is up and running: ■

■

(Windows) lmutil lmstat -a -c (where is your license file name) (Mac OS X) /usr/local/flexnetserver/lmutil lmstat -a -c /var/flexlm/maya.lic

■

(Linux) /opt/flexnetserver/lmutil lmstat -a -c /var/flexlm/maya.lic


License Files The network license file you receive from Autodesk contains licensing information required for a network installation. You obtain license file data when you your Autodesk product. The license file contains information about network server nodes and vendor daemons. It also contains an encrypted digital signature that is created when Autodesk generates the file. The license file is located on your license server in the location that you specify when you save the license file from the Once Web page, or using the license information that Autodesk emails to you. NOTE If you are already running a network license server for a separate Autodesk product, such as 3ds max, you must append the contents of your Maya license file to the contents of the license file for the other Autodesk product. See Example of a License File for Combined Autodesk Product Versions on page 91. The following table defines each license file parameter. Definitions of license file parameters Line

Parameter

Definition

Example

SERVER

Host Name

Host name of the server where the Network License Manager resides

LABSERVER

Host ID

Ethernet address of the server where the Network License Manager resides

03D054C0149B

USE_SERVER

[None]

VENDOR

Vendor Daemon

Name of the server-side Autodesk vendor daemon

adskflex.exe

Port Number

Network port number reserved and assigned for use only by Autodesk products running the Autodesk vendor daemon

port=2080

Name

Name of feature code group

SERIES_1

Version

Internal version number reference

1.000

PACKAGE


Definitions of license file parameters Line

Parameter

Definition

Example

COMPONENTS

List of feature codes ed in the package

COMPONENTS= "526000REVIT_9_OF\ 51200ACD_2007_OF\ 513001INVBUN_11_OF"

OPTIONS

INCREMENT

OPTIONS=SUITE

SUPERSEDE

Replacement for any existing Increment line of the same feature code from any license files on the same license server that have a date earlier than the defined Issue Date

SUPERSEDE

SIGN

Encrypted signature used to authenticate the attributes of the license file

SIGN=0 SIGN2=0

Feature Code

Product ed by the license file

51200ACD_2007_0F

Expiration Date

Amount of time the licenses are available

permanent

Number of Licenses

Number of licenses ed by the license file

25

VENDOR_STRING

License usage type and license behavior of the product that is ed by the license file

COMMERCIAL

BORROW

Definition of the license borrowing period for the licenses defined under the same increment line. In this example, the maximum period that licenses can be borrowed is 4320 hours (180 days), unless otherwise noted (for example, BORROW=2880 means that licenses can be borrowed for a maximum of 2880 hours, or 120 days).

BORROW=4320


Definitions of license file parameters Line

Parameter

Definition

Example

License borrowing is disabled when this parameter is absent in the license file. DUP_GROUP

Definition of multiple license requests when the same and same host share the same license

DUP_GROUP=UH

ISSUED

Date that the license file was generated by Autodesk

15-jul-2006

Serial Number

Serial number of the Autodesk product

123-12345678

SIGN

Encrypted signature used to authenticate the attributes of the license file

SIGN=6E88EFA8D44C

License File Examples Example of a License File Not Specific to a Product Here is an example of the contents of a license file and the parameters associated with each line: SERVER ServerName HostID USE_SERVER VENDOR adskflex port=portnumber INCREMENT feature_code Adskflex Version ExpDate NumberofLicenses \ VENDOR_STRING=UsageType:Behavior BORROW=4320 SUPERSEDE \ DUP_GROUP=DupGrp ISSUED=IssueDate SN=SerialNumber SIGN= \


Example of a License File for a Single or Distributed Server Here is an example of a completed license file for a single or distributed license server model: SERVER XXHP0528 0019bbd68993 USE_SERVER VENDOR adskflex port=2080 INCREMENT 57600ACD_2009_0F adskflex 1.000 permanent 5 \ VENDOR_STRING=commercial:permanent BORROW=4320 SUPERSEDE \ DUP_GROUP=UH ISSUED=09-Jan-2008 SN=123-12345678 SIGN="1393 \ E368 816E D417 C1CD 7DBD 7B90 1354 D6F0 48FE EBB8 9C84 C3AF \ 7D79 BEE1 0181 0655 76FF 996C B707 14B5 D4DE A3FE 0B2D 2D36 \ 057C A579 7866 26BF 44E2" SIGN2="1280 943B 53A7 9B93 E00B D967 \ D821 BD37 BE6D B78A F074 B223 88AA 242C DD0A 1292 D56F 4108 \ 62CD FA35 E365 0736 A011 7833 8B35 7BFF DAD8 34A8 452F 2EB4"

Example of a License File for a Redundant Server Here is an example of a completed license file for a redundant license server model: SERVER CCN12378042 001cc4874b03 27005 SERVER XXHP0528 0019bbd68993 27005 SERVER CCN12378043 001cc4874b10 27005 USE_SERVER VENDOR adskflex port=2080 INCREMENT 57600ACD_2009_0F adskflex 1.000 permanent 5 \ VENDOR_STRING=commercial:permanent BORROW=4320 SUPERSEDE \ DUP_GROUP=UH ISSUED=10-Jan-2008 SN=123-12345678 SIGN="11C4 \ CA79 07FC 7AD0 409A 6E04 6E98 D76C 197C 0416 076C B211 1CDD \ D0AB 698B 16BF 7A0E D4F8 1CFE 2985 644F 64CD CECE 0DDB 5951 \ 3262 7C31 13A8 F08F 55B2" SIGN2="19A6 FDA3 2ED5 5301 8675 7B81 \ 1B0E 451B 19F1 1A99 C8E9 CBA6 8CB3 6AC3 8B38 1519 13F2 2373 \ 82AE 55E5 1A25 4952 4458 F3A2 6F28 D25D 1DC0 E066 209B 0953"

NOTE The redundant server model requires the addition of a port number (the default is 27005) for each server.


Example of a License File for Combined Autodesk Product Versions You can combine a license file for different releases of the same Autodesk product or for different Autodesk products, and run all products from one license server. For example, you can combine a license file for AutoCAD 2009 ® with license files for Autodesk Maya 2009 and AutoCAD Map. If your license server distributes licenses for multiple Autodesk products that were purchased individually (not part of a suite or bundle), you must combine the network license information from all products into one license file. In this example, the content from a license file for AutoCAD 2008 has been appended to an AutoCAD 2009 license file: SERVER XXHP0528 0019bbd68993 USE_SERVER VENDOR adskflex port=2080 INCREMENT 57600ACD_2009_0F adskflex 1.000 permanent 5 \ VENDOR_STRING=commercial:permanent BORROW=4320 SUPERSEDE \ DUP_GROUP=UH ISSUED=09-Jan-2008 SN=123-12345678 SIGN="1393 \ E368 816E D417 C1CD 7DBD 7B90 1354 D6F0 48FE EBB8 9C84 C3AF \ 7D79 BEE1 0181 0655 76FF 996C B707 14B5 D4DE A3FE 0B2D 2D36 \ 057C A579 7866 26BF 44E2" SIGN2="1280 943B 53A7 9B93 E00B D967 \ D821 BD37 BE6D B78A F074 B223 88AA 242C DD0A 1292 D56F 4108 \ 62CD FA35 E365 0736 A011 7833 8B35 7BFF DAD8 34A8 452F 2EB4" INCREMENT 54600ACD_2008_0F adskflex 1.000 permanent 3 \ VENDOR_STRING=commercial:permanent BORROW=4320 SUPERSEDE \ DUP_GROUP=UH ISSUED=09-Jan-2008 SN=123-12345678 SIGN="1E6E \ 4B61 5712 4766 92A0 6782 9EF4 3F47 56A1 1F38 6DE8 C0C7 90AC \ 7289 152E 0EA2 CC0D 3F10 577A 0489 CEB6 10D5 FBCC B552 0C9D \ 5966 91A6 59F0 2788 FACE" SIGN2="1DDF 3B9D 3392 71D5 AB08 7E05 \ 8497 111E 092F 0E54 8DC2 2BED 17C2 2CC1 981B 0EC2 BC15 8F00 \ C79A ABFD 2136 BABA 2EDF E941 EA53 32C6 597F F805 5A8A 599A"


For example, the section of license information you need to append from one file into the other is similar to the following: INCREMENT 54600ACD_2008_0F adskflex 1.000 permanent 3 \ VENDOR_STRING=commercial:permanent BORROW=4320 SUPERSEDE \ DUP_GROUP=UH ISSUED=09-Jan-2008 SN=123-12345678 SIGN="1E6E \ 4B61 5712 4766 92A0 6782 9EF4 3F47 56A1 1F38 6DE8 C0C7 90AC \ 7289 152E 0EA2 CC0D 3F10 577A 0489 CEB6 10D5 FBCC B552 0C9D \ 5966 91A6 59F0 2788 FACE" SIGN2="1DDF 3B9D 3392 71D5 AB08 7E05 \ 8497 111E 092F 0E54 8DC2 2BED 17C2 2CC1 981B 0EC2 BC15 8F00 \ C79A ABFD 2136 BABA 2EDF E941 EA53 32C6 597F F805 5A8A 599A"

Package License File Examples Autodesk offers a package license file option, which allows you use of a set of products that are packaged and sold together. The package license file contains a set number of licenses for four different versions of your software. Running an instance of any one of the versions uses one license in the package. Packaged license files prior versioning for subscription s. Package license files operate under the following guidelines: ■

Package license files come with the current version of the software and three previous versions of the same product.

■

License files may be combined with license files for different products. For more information about combining license files, see Example of a Package License File for Combined Autodesk Product Versions on page 95.

■

Package license files cannot be combined with non-package license files for product versions contained in the package. For example, you cannot combine a Autodesk Product 2009 package license file with a regular license file for Autodesk Product 2008, 2007, or 2006.

■

Both the PACKAGE and INCREMENT sections of the license are required for licensing to work properly. When you combine license files, be sure to include both of these sections.

■

License borrowing, option files, and licensing cascading work the same for package licenses as they do for regular license files.

■

A new license file will supersede an older license file.

The following sections provide package license file examples for single, distributed, and redundant license servers, and combined Autodesk product versions.


Example of a Package License File for a Single or Distributed Server Here is an example of a completed license file for a single or distributed license server model: SERVER Server1 1a34567c90d2 USE_SERVER VENDOR adskflex port=2080 PACKAGE SERIES_1 adskflex 1.000 COMPONENTS="54700REVIT_2009_0F \ 54600ACD_2009_0F 51300INVBUN_11_0F" OPTIONS=SUITE SUPERSEDE \ ISSUED=09-Jan-2008 SIGN="1707 9EAC CBCB 2405 692E 4A89 \ AA26 30CC 2AC2 D6B3 A61B AB5E 492E 3EBD 0B48 4E75 193A DA82" \ FC45 C009 E360 944A 14BA E99C 9B24 5A1B 4A44 083A BE5F 3827 \ SIGN2="004A FC90 AB47 3F6B 59BC 0E6D 6681 6971 A76A BA52 98E2 \ 5671 26B3 0E78 791B 109F 0591 7DC3 F09F 4D8D 4FB7 E341 4A03 \ CD68 1D77 27F8 8555 9CF7 DEDD 9380" INCREMENT SERIES_1 adskflex 1.000 permanent 100 \ VENDOR_STRING=commercial:permanent BORROW=4320 DUP_GROUP=UH \ SUITE_DUP_GROUP=UHV SN=123-12345678 SIGN="1707 9EAC CBCB \ 692E 4A89 FC45 C009 E360 944A 14BA E99C 9B24 5A1B 4A44 BE5F \ 3827 AA26 30CC 2AC2 D6B3 A61B AB5E 492E 3EBD 0B48 DA82" \ SIGN2="004A FC90 AB47 3F6B 59BC 0E6D 6681 6971 A76A BA52 \ 5671 26B3 0E78 791B 109F 0591 7DC3 F09F 4D8D 4FB7 E341 4A03 \ CD68 1D77 27F8 8555 9CF7 DEDD 9380"


Example of a Package License File for a Redundant Server Here is an example of a completed license file for a redundant license server model: SERVER 1a34567c90d2 27005 SERVER 2a34567c90d2 27005 SERVER 3a34567c90d2 27005 USE_SERVER VENDOR adskflex port=2080 PACKAGE 64300ACD_F adskflex 1.000 COMPONENTS="57600ACD_2009_0F \ 54600ACD_2008_0F 51200ACD_2007_0F 48800ACD_2006_0F" \ OPTIONS=SUITE SUPERSEDE ISSUED=27-May-2008 SIGN="1092 05D8 \ A206 276B 2C84 EFAD ACA5 C54B 68A4 653E C61F 31DE C8CE B532 \ CFBB 0006 5388 347B FDD6 A3F4 B361 7FD4 CDE4 4AAC 0D11 B0EF \ 4B44 BFD6 3426 97DD" SIGN2="0670 B01A D060 0069 FF25 F1CD D06B \ 314E E7C9 3552 5FFA 4AC7 28A7 C897 F56A 19BB FB1C 754E 6704 \ DEEA AC4E F859 2E9B 64B6 0DD0 9CCE 9556 269F EAC0 2326" INCREMENT 64300ACD_F adskflex 1.000 permanent 50 \ VENDOR_STRING=commercial:permanent BORROW=4320 SUPERSEDE \ DUP_GROUP=UH SUITE_DUP_GROUP=UHV ISSUED=27-May-2008 \ SN=399-99999999 SIGN="1B5B 8D70 4CAD 32E5 9CA2 82E0 5C47 291C \ 35AB 9B9C 5B3E 5067 F61B 4139 1B32 0716 1FD3 5105 A991 B78E \ 9D1E 63AB BC23 0D1E B70C 2A05 E1C1 F605 ABB1 2EA8" SIGN2="01D6 \ 31F5 2951 4500 E5C8 058F 7490 9789 9EF4 CBED DA27 5F06 6780 \ 9033 2018 0C3B E1E0 3580 E60E C2BB B4AB 8D6A 4245 3059 8CA6 \ 2EFE DFAE 027F 2ABE 3F2B"


Example of a Package License File for Combined Autodesk Product Versions Here is an example of a completed license file for combined Autodesk product versions:


SERVER servername 123456789111 USE_SERVER VENDOR adskflex port=2080 PACKAGE 64300ACD_F adskflex 1.000 COMPONENTS="57600ACD_2009_0F \ 54600ACD_2008_0F 51200ACD_2007_0F 48800ACD_2006_0F" \ OPTIONS=SUITE SUPERSEDE ISSUED=25-Jun-2008 SIGN="03EF DE18 \ 8046 0124 4EA4 6953 F82D 3169 7C24 D0DE E58E 8168 FFA3 D891 \ B43B 08D8 7E7F C6ED CBCC FE2A BB0A 4566 C2AE F1C1 D373 8348 \ E6E3 884A E398 1C78" SIGN2="07AC D696 8844 D19F AB00 8B75 53A3 \ 2F76 91DF AED0 3231 1506 0E6B ADC6 C3B8 1797 93B5 9756 8C0F \ 8811 56E6 B2BA 0523 FE2E 82B7 1628 076F 173B F37C 7240" INCREMENT 64300ACD_F adskflex 1.000 permanent 2 \ VENDOR_STRING=commercial:permanent BORROW=4320 SUPERSEDE \ DUP_GROUP=UH SUITE_DUP_GROUP=UHV ISSUED=25-Jun-2008 \ SN=399-99999999 SIGN="1CCB E88D B819 8604 06FA 9AEE 42F1 CBEA \ 37B9 3CFA A0A8 697F 9CB1 8354 6256 05ED 69D4 D2FF D512 6A2E \ D5DD B722 EF5B 3172 BA95 4625 F8D3 DD24 BB39 6A58" SIGN2="0DFF \ FA6F C378 20E0 2622 BE52 B434 F99F 2681 2B93 64F2 CE0C 7F4A \ 7024 B3D1 051A 6920 72BD DE35 8920 E6A1 C8D6 AF23 7BE7 CC91 \ 6916 70B1 9E80 AB07 1644" PACKAGE 64800INVPRO_F adskflex 1.000 \ COMPONENTS="59600INVPRO_2009_0F \ 55300INVPRO_2008_0F 51400INVPRO_11_0F 49000INVPRO_10_0F" \ OPTIONS=SUITE SUPERSEDE ISSUED=25-Jun-2008 SIGN="1306 5990 \ F8A1 56FB 1D8A 9DA7 D6AE 8E9E F6EC 2862 367A 36E2 C5FB E6E1 \ 4AAA 0128 8C2D 95FD 09B2 ABA1 6F98 A0A3 70DE 3220 6835 7E51 \ 3849 9D81 8BDC 9DC1" SIGN2="0021 AA08 F2E7 8AEB 5345 341A 7E42 \ 3001 B8C5 DFC2 6EB8 87C5 C04A AE43 A10F 1DA1 EF8A F0FA 10F5 \ AC81 1E22 789F A18D 650F 6BBB 563A BDA5 DD1C 82EC 27F6" INCREMENT 64800INVPRO_F adskflex 1.000 permanent 2 \ VENDOR_STRING=commercial:permanent BORROW=4320 SUPERSEDE \ DUP_GROUP=UH SUITE_DUP_GROUP=UHV ISSUED=25-Jun-2008 \ SN=399-99999966 SIGN="0BE4 51F4 570C DC48 5E66 F952 629E EDF0 \ 019C 6FF7 0509 1FF0 D4FB 3B16 1981 073F 31EC A241 8CB3 8782 \ E655 00C6 E097 D5EF B0D8 67D3 199D 699D 2E09 B16F" SIGN2="1254 \ 3E37 0CE4 F42D B7CD 858C 92FC A963 5274 770F 9354 FE29 E117 \ 205D C632 0C4E AEC0 7501 9D9E FFEB D84D F154 16A1 E120 339A \


FDBF 3F07 4477 B8B3 5DA4"

License Types and Behaviors Autodesk s dynamic product usage and license behaviors. This means that you can purchase a specific type of behavior with a specific license and change that license at a later date without having to uninstall and reinstall the Autodesk product. NOTE All license types are available as stand-alone and network except for the Student Portfolio license, which is available as stand-alone only. License types include the following: ■

Commercial. A license for a product that was purchased commercially.

■

Not for Resale. A license for a product that is not sold commercially. Not for Resale products are for evaluation or demonstration purposes only and may not be used for commercial or production use.

■

Educational (EDU)/Institution. A license designed specifically for educational institutions.

■

Student Portfolio. A license for students who are using an Autodesk product as part of their curriculum.

License behaviors are as follows: ■

Permanent. Enables permanent use of an Autodesk product.

■

Term Extendable. Enables access to an Autodesk product for a limited time. The term can be extended at any time.

■

Term Non-Extendable. Enables an Autodesk product for a limited time. The term cannot be extended.

Heartbeat Signal When an Autodesk product is running, it communicates with the license server at regular intervals using a communication method known as the “heartbeat” signal. If the heartbeat signal is lost, the server tries to reconnect. If the server cannot reconnect, the receives a license error.


If the product stops working because it has lost a connection to the server, you must shut down the product, and then restart it. If the problem causing the original loss of the heartbeat signal is resolved and there are available licenses on the server, the program can be restarted.

Network License Manager Install the Network License Manager The Network License Manager is used to configure and manage license servers. It includes the lmgrd, adskflex, and lmutil tools that you need to set up your license server. (Windows) When creating a deployment, the Installation wizard prompts you for information about the license manager, such as license server model and server name. If an earlier version of the Network License Manager is already installed on the computer, you should upgrade by installing the Autodesk Network License Manager into the folder where the older version was located.

Install the Network License Manager (Windows) You can install the Network License Manager before or after you use the Installation wizard. The order in which you install the network applications does not matter, as long as you install everything you need and you provide consistent license server information across the network applications.

To install your Network License Manager 1 In the Autodesk Installation wizard, click Install Tools and Utilities. 2 On the Select the Products to Install page, select Autodesk Network License Manager and click Next. 3 Review the Autodesk software license agreement for your country or region. You must accept this agreement to proceed with the installation. Choose your country or region, click I Accept, and then click Next. NOTE If you do not agree to the of the license and want to terminate the installation, click Cancel.


4 On the Begin Installation page, review your product selection and the current settings. If you do not want to change anything, click Install. If you want to change the install type or installation path, click Configure. 5 On the Select the Installation Location page, accept the default installation path (C:\Program Files\Autodesk Network License Manager) or Browse to specify a different path. If you enter a path that does not exist, a new folder is created using the name and location you provide. Click Next. WARNING Do not install the Network License Manager on a remote drive. When you install the Network License Manager files, you must provide a path to a local drive. You must specify the drive letter; the universal naming convention (UNC) is not permitted. 6 On the Configuration Complete page, click Configuration Complete to return to the confirmation page. 7 On the Begin Installation page, click Install. 8 When the Installation Complete page displays, click Finish.

Install the Network License Manager (Mac OS X) To install the Network License Manager 1 Navigate to the NetworkLicenseManager folder on your Maya DVD, or in the package you ed. 2 Do one of the following: ■

(DVD) Double-click the Network License Manager package icon.

■

() Double-click the Network License Manager .dmg, then double-click the Network License Manager package icon.

The Install Autodesk NLM wizard appears. 3 Click Continue to begin the installation, then follow the instructions in the installer to install the Network License Manager tools. 4 Click Close when you see the Install Succeeded message. By default, the Network License Manager tools are installed in the following directory: /usr/local/flexnetserver. In addition, scripts to help set up your license server are installed in the following directory: /Library/StartUpItems/adsknlm.

Install the Network License Manager | 99

Install the Network License Manager (Linux) To install the Network License Manager 1 Open a shell as a super . 2 Navigate to the NetworkLicenseManager directory on your Maya DVD, or extract the Network License Manager package from the compressed file that you ed. 3 To install the Network License Manager, enter the following command: rpm -ivh adlmflexnetserver-#.rpm

where # is the package number.

Obtain a License Through autodesk.com You can and activate your network license by going to https://once.autodesk.com and following the on-screen instructions.

Obtain the Server Host Name and Host ID Manually Autodesk uses the server host name, host ID, and product serial number to generate a license file. To obtain the information manually, you can use the command prompt or you can run the lmtools.exe utility. If you use lmtools.exe, do not run it on a remote workstation.

To obtain the host name and ID using the Windows command prompt 1 Do one of the following: ■

(Windows XP) Click Start > Programs > Accessories > Command Prompt.

■

(Windows Vista) Click Start > All Programs > Accessories > Command Prompt.

2 In the Windows command prompt, enter the following command, then press Enter: ipconfig /all

3 Locate the Host Name line, and write down the host name.


4 Locate the Physical Address line. Write down the physical address without the dashes. This is your twelve-character host ID. NOTE If your server has more than one network adapter, select the one that corresponds to a physical network adapter. To determine which adapters are physical: in the Windows command prompt, enter ipconfig /all, and then view the Description field above each physical address. If there is more than one physical network adapter, it does not matter which one you use. Devices such as VPN adapters, PPP adapters, and modems are not valid. 5 Close the Windows command prompt.

To obtain the host name and ID using lmtools.exe You should be logged in with rights when working with the LMTOOLS utility. 1 Click Start ➤ All Programs ➤ Autodesk ➤ Network License Manager ➤ LMTOOLS Utility. 2 In the LMTOOLS program, click the Systems Settings tab. 3 On the Systems Settings tab, locate the Computer/Hostname box. Copy the host name and paste the information into a text editor. 4 Locate the Ethernet Address box. The Ethernet address is the host ID. It consists of twelve characters. Write down the information. If your Ethernet address is more than twelve characters, write down the first twelve characters only. NOTE If your server has more than one Ethernet adapter, select one that corresponds to a physical network adapter. 5 Close lmtools.exe.

To obtain the host name and ID using the Mac OS X or Linux terminal window 1 Launch a Terminal window. 2 Go to the directory where lmutil is installed. 3 Retrieve the host name by entering the following in Terminal: <prompt>./lmutil lmhostid -hostname

The host name is displayed.

Obtain the Server Host Name and Host ID Manually | 101

4 Retrieve the host ID by entering the following in Terminal: <prompt>./lmutil lmhostid

The twelve-character host ID is displayed. 5 Close the Terminal Window.

Configure a License Server Configure a License Server (Windows) You configure a license server so that you can manage your Autodesk product licenses. Configure the license server with the lmtools.exe utility.

To configure your license server You should be logged in with rights when working with the LMTOOLS utility. 1 Click Start ➤ All Programs ➤ Autodesk ➤ Network License Manager ➤ LMTOOLS Utility. 2 In the LMTOOLS program, on the Service/License File tab, make sure the Configure Using Services option is active. 3 Click the Config Services tab. 4 In the Service Name list, select the service name you want to use to manage licenses. ®

By default, the service name is Flexlm Service 1. If FLEXnet is managing other software on your computer in addition to Autodesk, you can change the service name to avoid confusion. For example, you can rename Flexlm Service 1 to Autodesk Server1. NOTE If you have more than one software vendor using FLEXnet for license management, the Service Name list contains more than one option. Make sure that only one Autodesk service is listed. 5 In the Path to Lmgrd.exe File field, enter the path to the Network License Manager daemon (lmgrd.exe), or click Browse to locate the file. By default, this daemon is installed in the C:\Program Files\Autodesk Network License Manager folder.


6 In the Path to the License File box, enter the path to your license file, or click Browse to locate the file. This is the path to the license file obtained through autodesk.com or the location where you placed the license file if you obtained it offline. 7 In the Path to the Debug Log File box, enter a path to create a debug log, or click Browse to locate an existing log file. It is recommended that you save to the C:\Program Files\Autodesk Network License Manager folder. The log file must have a .log file extension. For new log files, you must enter the .log extension manually. 8 To run lmgrd.exe as a service, select Use Services. 9 To start lmgrd.exe automatically when the system starts, select Start Server at Power Up. 10 Click Save Service to save the new configuration under the service name you selected in step 4. Click Yes when prompted if you would like to save the settings to the service. 11 Click the Start/Stop/Reread tab and do one of the following: ■

If a service has not yet been defined for Autodesk, click Start Server to start the license server.

■

If a service for Autodesk is already defined and running, click ReRead License File to refresh the Network License Manager with any changes made to the license file or Options file.

The license server starts running and is ready to respond to client requests. 12 Close lmtools.exe. NOTE Before performing any system maintenance on your license server, see Stop and Restart the License Server on page 109.

Configure a License Server (Mac OS X) You configure a license server so that you can manage the Maya licenses you received using the Autodesk Once Web page. You configure the license server using the LMTOOLS utility.

Configure a License Server | 103

Before configuring your license server, ensure that: ■

You have installed the Network License Manager, which contains the following files: lmgrd, adskflex, and lmutil. For Mac OS X, this installer also includes important scripts that help you set up your license server. (See Install the Network License Manager (Mac OS X) on page 99.)

■

You have received the network license file from Autodesk that contains the product licenses; for example, productlicense.lic. (See Obtain a License Through autodesk.com on page 100.)

To configure automatic start-up of your license server 1 Locate your network license file and rename it adsk_server.lic. 2 Copy adsk_server.lic to the following directory: /var/flexlm/ NOTE Create this directory if it does not already exist. 3 Reboot your computer. 4 Use the Console to that lmgrd and adskflex start up successfully.

Configure a License Server (Linux) You configure a license server so that you can manage your Autodesk product licenses.

To configure automatic start-up of your license server Before configuring your license server for Linux, ensure that the following steps have been completed: ■

You have installed the Autodesk Network License Manager which contains the following files: lmgrd, adskflex, and lmutil.

■

You have received the network license file from Autodesk that contains the product licenses; for example, productlicense.lic. 1 Extract the FLEXnet IPv4 server files into the following directory: /home/< id>/flexlm11.7. NOTE Replace < id> with your id, not a root id.


2 Copy the .lic file into the flexlm11.7 directory created in Step 1. 3 Open a terminal window in root mode. 4 Go to the directory /etc/. 5 Locate the rc.local file. 6 Edit the rc.local file and start lmgrd by entering the following commands in the terminal window: NOTE Replace acad.lic with your license file name. 7 /bin/su < id> -c ‘echo starting lmgrd>\ /home/< id>/flexlm11.7/boot.log’ /usr/bin/nohup/bin/su < id> -c ‘umask 022;\ /home/< id>/flexlm11.7/lmgrd -c\ /home/< id>/flexlm11.7/acad.lic >> \ /home/< id>/flexlm11.7/boot.log ‘ /bin/su < id> -c ‘echo sleep 5 >> \ /home/< id>/flexlm11.7/boot.log ‘ /bin/sleep 5 /bin/su < id> -c ‘echo lmdiag >>\ /home/< id>/flexlm11.7/boot.log ‘ /bin/su < id> -c ‘/home/< id>/flexlm11.7/lmutil lmdiag -n -c\ /home/< id>/flexlm11.7/acad.lic >> \ /home/< id>/flexlm11.7/boot.log ‘ /bin/su < id> -c ‘echo exiting >>\ /home/< id>/flexlm11.7/boot.log ‘

8 Save the edited rc.local file. 9 Reboot your machine and that the lmgrd and adskflex have started by doing one of the following: ■

During the reboot, look for the message that the license server has started.

■

Check the boot.log file created in /home/< id>/flexlm11.7/ to see if lmgrd and adskflex have started.

Configure a License Server | 105

NOTE Before performing any system maintenance on your license server, see Stop and Restart the License Server on page 109.

Install SAMreport-Lite (Optional) SAMreport-Lite is a reporting tool that helps you track network license usage. With SAMreport-Lite technology from Acresso™ Software, you can monitor client usage for Autodesk network licensed products. To learn more about installing and using SAMreport-Lite, see the SAMreport-Lite ’s Guide.

Uninstall the Network License Manager You can uninstall the Network License Manager from the license server. When you uninstall the Network License Manager, licenses are no longer available to your s. NOTE You must manually delete files that you created for use with the Network License Manager (such as log files, license files, and the Options file). They are not automatically deleted when you uninstall.

Uninstall the Network License Manager (Windows) To uninstall the Network License Manager 1 Click Start ➤ All Programs ➤ Autodesk ➤ Network License Manager ➤ LMTOOLS Utility. 2 In the LMTOOLS program, click the Start/Stop/Reread tab. 3 On the Start/Stop/Reread tab, click Stop Server. 4 Close lmtools.exe. 5 In the Windows Control , do one of the following: ■

(Windows XP) Double-click Add/Remove Programs.

■

(Windows 7/Windows Vista) Double-click Programs and Features.


Do one of the following: ■

(Windows XP) In the Add/Remove Programs window, click Autodesk Network License Manager. Click Remove.

■

(Windows 7/Windows Vista) In the Programs and Features window, click Autodesk Network License Manager. Click Remove.

6 If prompted, restart your computer.

Uninstall the Network License Manager (Mac OS X) To uninstall the Network License Manager 1 Delete the following directories: ■

/usr/local/flexnetserver/

■

/Library/StartUpItems/adsknlm

This removes the main license server tools as well as the configuration scripts that help you set up your license server. 2 Reboot your machine.

Uninstall the Network License Manager (Linux) To uninstall the Network License Manager 1 Open a shell as a super . 2 Execute the following command to the package number of the Network License Manager that you installed: rpm -qa |grep adlm

3 Execute the following command to uninstall the Network License Manager package: rpm -e adlmflexnetserver-#.rpm

where # is the package number. 4 If you edited your rc.local file to configure your license server (for example to start lmgrd), remove those commands from the rc.local file. (See also Configure a License Server (Linux) on page 104.)

Uninstall the Network License Manager | 107

Network License Tools Autodesk Network licensing tools include FLEXnet configuration tools, license borrowing, and SAMreport-Lite. Each tool is described in the sections that follow. This section also includes information for updating FLEXnet and installing and configuring the Autodesk Network License Manager on a network.

FLEXnet Configuration Tools The Network License Manager uses FLEXnet® license management technology from Acresso Software. FLEXnet provides istrative tools that help to simplify management of network licenses. You can use FLEXnet tools to monitor network license status, reset licenses lost to a system failure, troubleshoot license servers, and update existing license files on the fly. For specific information ing FLEXnet configuration tools, you can find the Licenseistration.pdf document in the following directory: ■

(Windows) C:\Program Files\Autodesk Network License Manager\Docs\Flex\Licenseistration.pdf

■

(Mac OS X) /usr/local/flexnetserver/Licenseistration.pdf

■

(Linux) /opt/flexnetserver/Licenseistration.pdf

Utilities for License Server Management FLEXnet provides two utilities for managing the license server. These tools are located in the C:\Program Files\Autodesk Network License Manager folder. ®

lmtools.exe Provides a Microsoft Windows graphical interface for managing the license server. lmutil.exe Provides a set of command line options for managing the license server. You can use lmtools.exe or lmutil.exe to perform the following server management tasks: ■

Start, stop, and restart the server.

■

Configure, update, and reread the license file.


■

Diagnose system or license problems.

■

View server status, including active license status.

Stop and Restart the License Server Before you can perform any system maintenance on your license server, you must stop the license server. When you have completed maintenance, you can restart the license server.

To stop the license server (Windows) You should be logged in with rights when working with the LMTOOLS utility. 1 Click Start ➤ All Programs ➤ Autodesk ➤ Network License Manager ➤ LMTOOLS Utility. 2 In the LMTOOLS program, on the Service/License File tab, select the Configure Using Services option. 3 Select the service name for the license server you want to stop manually. 4 Click the Start/Stop/Reread tab. 5 On the Start/Stop/Reread tab, click Stop Server. 6 Close lmtools.exe.

To restart the license server (Windows) You should be logged in with rights when working with the LMTOOLS utility. 1 Click Start ➤ All Programs ➤ Autodesk ➤ Network License Manager ➤ LMTOOLS Utility. 2 In the LMTOOLS program, on the Service/License File tab, select the Configure Using Services option. 3 Select the service name for the license server you want to start manually. 4 Click the Start/Stop/Reread tab. 5 On the Start/Stop/Reread tab, click Start Server to restart the license server.

FLEXnet Configuration Tools | 109

To stop the license server (Mac OS X) Enter the following in Terminal: sudo /sbin/SystemStarter stop adsknlm

To restart the license server (Mac OS X) Enter the following in Terminal: sudo /sbin/SystemStarter restart adsknlm

To stop the license server (Linux) Enter the following in Terminal: ./lmutil lmdown -q -force

To restart the license server (Linux) Enter the following in Terminal: ./lmgrd -c acad.lic -l debug.log

NOTE Replace acad.lic with your license file name and debug.log with your log file name.

Update FLEXnet from a Previous Version This release of Autodesk products and later require FLEXnet version 11.7.0.0 or later. If you are currently using a version of FLEXnet that is earlier than 11.7.0.0, you need to version 11.7.0.0 or later. NOTE If the server where you plan to install the Autodesk Network License Manager has FLEXnet installed for another product, make sure that the version of lmgrd.exe is the most current version. To determine what version of FLEXnet is installed, you need to the version of the following files: Windows ■

lmgrd.exe

■

lmtools.exe

■

lmutil.exe


■

adskflex.exe

Mac OS X or Linux ■

lmgrd

■

lmutil

■

adskflex

To the version of lmutil.exe, lmtools.exe, or adskflex.exe (Windows) You should be logged in with rights when working with the LMTOOLS utility. 1 Click Start ➤ All Programs ➤ Autodesk ➤ Network License Manager ➤ LMTOOLS Utility. 2 In lmtools.exe, click the Utilities tab. 3 On the Utilities tab, enter the location of the file, or click the Browse button to locate the file and click Open. The file location should look something like this: C:\Program Files\Autodesk Network License Manager\lmutil.exe 4 On the Utilities tab, click Find Version. The version number of the file you selected is displayed. If necessary, use the following procedure to update your version of FLEXnet.

To the version of lmutil, lmgrd, or adskflex (Mac OS X or Linux) You should be logged in with the same ID you used when installing the FLEXnet files, for example, /s/<id>/adsknlm (Mac OS X) or /home/<id>/adsknlm (Linux). Enter the following commands in the terminal window/prompt: <prompt>./lmutil -v <prompt>./lmgrd -v <prompt>./adskflex -v

The output of each command will look similar to this example: Copyright © 1989-2007 Macrovision Europe Ltd. And/or Macrovision Corporation. All Rights reserved. lmutil v11.5.0.0 build 56285 i86_mac10


To update FLEXnet (Windows) You should be logged in with rights when working with the LMTOOLS utility. 1 Back up your license files. 2 Click Start ➤ All Programs ➤ Autodesk ➤ Network License Manager ➤ LMTOOLS Utility. 3 In the LMTOOLS program, click the Start/Stop/Reread tab. 4 On the Start/Stop/Reread tab, click Stop Server. 5 Close lmtools.exe. 6 Note the location where the Network License Manager is installed and then uninstall the Network License Manager. For details about uninstalling the Network License Manager, see Uninstall the Network License Manager. 7 Install the Network License Manager. For details about installing the Network License Manager to the same location as the previous version, see Install the Network License Manager. 8 Do one of the following: ■

(Windows XP) Click Start ➤ Programs ➤ Autodesk ➤ Network License Manager ➤ LMTOOLS.

■

(Windows Vista) Double-click the LMTOOLS icon on the desktop.

9 In the LMTOOLS program, click the Start/Stop/Reread tab. 10 On the Start/Stop/Reread tab, click Start Server. 11 Close lmtools.exe.

To update FLEXnet (Mac OS X) You should be logged in with the same ID you used when installing the FLEXnet files, for example, /s/<id>/adsknlm. The logged in ID should be in the sudoers list to execute some of the following commands. 1 Back up your license files. 2 Stop the Autodesk Network License Manager service by entering the following in Terminal: sudo /sbin/SystemStarter stop adsknlm


3 Note the location where the Network License Manager is installed and then uninstall the Network License Manager by entering the standard Mac OS X commands, for example, rm. 4 Install the Network License Manager. Copy the new version of the FLEXnet network license manager files (lmgrd, adskflex, and lmutil) to the location recommended when you configured your license server, for example, /s/< id>/adsknlm. 5 Start the Autodesk Network License Manager service by entering the following in Terminal: sudo /sbin/SystemStarter start adsknlm

NOTE Version 11.7.0.0 of the FLEXnet license manager that ships with Autodesk products is backwards compatible and will ister licenses for the Autodesk 2008-, 2007-, 2006-, 2005-, 2004-, and 2002-based products.

To update FLEXnet (Linux) You should be logged in with the same ID you used when installing the FLEXnet files, for example, /home/<id>/adsknlm. The logged in ID should be in the sudoers list to execute some of the following commands. 1 Back up your license files. 2 Stop the Autodesk Network License Manager service by entering the following in Terminal: ./lmutil lmdown -q -force

3 Note the location where the Network License Manager is installed and then uninstall the Network License Manager by entering the standard Linux commands, for example, rm. 4 Install the Network License Manager. Copy the new version of the FLEXnet network license manager files (lmgrd, adskflex, and lmutil) to the location recommended when you configured your license server, for example, /home/< id>/adsknlm. 5 Start the Autodesk Network License Manager service by entering the following in Terminal: ./lmgrd -c acad.lic -l debug.log

NOTE Replace acad.lic and debug.log with your license file name and log file name.


NOTE Version 11.7.0.0 of the FLEXnet license manager that ships with Autodesk products is backwards compatible and will ister licenses for the Autodesk 2008-, 2007-, 2006-, 2005-, 2004-, and 2002-based products.

Set Up and Use an Options File With an Options file, you set configuration options for managing licenses on each license server that you set up. An Options file sets parameters that the license file reads and the lmgrd program executes. If you want to have the same license behavior on some or all of your license servers, you must save the same Options file to each of those license servers. If you want to specify different license behavior on different license servers, you must create an Options file for each license behavior. You must save each Options file to the server where you want specific license behavior. NOTE For Options file changes to take effect on a license server, you must save the Options file, and then use lmtools.exe to reread the license file. Use the Options file to set parameters for the following server-related features: Report log file A compressed, encrypted file is created that generates accurate usage reports on license activity for use by SAMreport-Lite. See Create a Report Log on page 116. License borrowing If your Autodesk product s the license borrowing feature, you can allow s to borrow an Autodesk product license from a network license server so that they can use the product without being connected to the license server. A license can be borrowed for a limited time. See Configure License Borrowing with the Options File on page 116. License timeout With license timeout, you can set a timeout period on your license server for one Autodesk product at a time. When set, license timeout returns a license to the license server when a connection with the workstation is lost, or if a license is checked out but the Autodesk product is idle on a workstation for longer than the timeout period you define. See Set Up License Timeout on page 117. License timeoutall With license timeoutall, you can set a timeout period on your license server that applies to all Autodesk products installed on your computer. When set, license timeout returns a license to the license server when a connection with the workstation is lost, or if a license is checked out but the Autodesk product is idle on a workstation for longer than the timeout period you define. See Set Up License Timeout on page 117.


Here is an example of the contents of an Options file: REPORTLOG=c:\test\report.rl BORROW_LOWWATER Autodesk_f1 3 TIMEOUT Autodesk_f1 7200

You can also set up advanced license parameters, such as reserving a license, restricting license usage, or defining groups of s. To learn more about setting advanced Options file parameters, see the FLEXnet documentation in the C:\Program Files\Autodesk Network License Manager\Licenseistration.pdf file.

Create an Options file You should be logged in with rights when working with the LMTOOLS utility.

To create an options file 1 Open a text editor, enter the parameters you want, and then save the document as a file named adskflex.opt to the same location where you saved the license file. NOTE Make sure you save the file with the extension .opt. The default extension .txt is not recognized by the Network License Manager. 2 Do one of the following: ■

(Windows) Click Start ➤ All Programs ➤ Autodesk ➤ Network License Manager ➤ LMTOOLS Utility.

■

(Mac OS X) Launch a Terminal window, navigate to the Autodesk Network License Manager folder, and enter the following: ./lmutil lmreread -c @hostname-all

Close the Terminal window. 3 In the LMTOOLS program, on the Start/Stop/Reread tab. 4 On the Start/Stop/Reread tab, click ReRead License File. 5 Close lmtools.exe.


Create a Report the Options file, you can create a report log file that is used with SAMreport-Lite.

To create a report log 1 In a text editor, open the Options file, adskflex.opt. 2 In the Options file, enter the following syntax on its own line (with REPORTLOG entered in uppercase, as shown): REPORTLOG [+]report_log_path For example (Windows), the syntax REPORTLOG +"c:\My Documents\report.rl" means that a report log named report.rl is located in the folder c:\My Documents. For example (Mac OS X or Linux), the syntax REPORTLOG +"/s/< id>/NLM/report.rl" means that a report log named report.rl is located in the folder /s/< id>/NLM. NOTE Path names that contain spaces must be enclosed in quotation marks. In the REPORTLOG syntax, “[+]” means that entries to the log file you create are appended rather than replaced each time the Network License Manager is restarted. (It is recommended that you use this option so that you retain a history of log entries.)

Configure License Borrowing with the Options File If your Autodesk product s the license borrowing feature, you can use the Options file to configure license borrowing options. For example, you can define the maximum number of licenses that cannot be borrowed from your network at any one time. In addition, you can define which s can borrow an Autodesk product license. Licenses are borrowed per , not per machine. NOTE If your Autodesk product s license borrowing, and licenses are borrowed from a redundant license server pool, you must restart the license server after you stop the Network License Manager. At the end of a borrow period, the borrowed license is automatically disabled on the 's computer and becomes available again on the license server. s can also return a license before a borrow period has ended.


To set license borrowing parameters 1 In the Options file, enter the following syntax on its own line (with BORROW_LOWWATER entered in uppercase, as shown): BORROW_LOWWATER feature_code n In the BORROW syntax, “feature_code” is the name of the product in the license file, and “n” is the number of licenses that cannot be borrowed. For example, the syntax BORROW_LOWWATER Autodesk_f1 3 means that for the product Autodesk_f1, three licenses cannot be borrowed from the license server. 2 Enter the following syntax on the next line (with MAX_BORROW_HOURS entered in uppercase, as shown): MAX_BORROW_HOURS feature_code n In this syntax, “n” is the number of hours that a license can be borrowed. For example, the syntax MAX_BORROW_HOURS Autodesk_f1 360 means that for product Autodesk_f1, licenses can be borrowed for 360 hours, or 15 days. NOTE Licenses are borrowed in increments of 24 hours only. Any number that is more than a 24-hour increment is not used. For example, the number 365 would be rounded down to 360 hours, or 15 days.

For more information about setting up the license borrowing feature, see the FLEXnet documentation in the C:\Program Files\Autodesk Network License Manager folder. NOTE To borrow a license in an Autodesk product, click Help menu ➤ About ➤ Product Information. Alternatively, enter borrowlicense on the product command line. Help for this feature is available in the Borrow a License for [Autodesk Product] window and in C:\Program Files\[Autodesk Product]\Help\adsk_brw.chm.

Set Up License Timeout License timeout is set in the Options file to determine how long a product session can be idle before the license is reclaimed by the license server. When you set this flag in the Options file, a 's license is reclaimed by the license server if the product is idle on a workstation for more than the timeout period you define.


If a 's license is lost because of the idle timeout, the product attempts to claim a new license once the uses the product again. If no license is available, the can save work before the product shuts down. You can set individual license timeouts for each Autodesk product on your computer by using the TIMEOUT parameter or you can set one license timeout for all Autodesk products on your computer by using the TIMEOUTALL parameter.

To set license timeout parameters ■

For individual Autodesk products: In the Options file, enter the following syntax on its own line (with TIMEOUT entered in uppercase, as shown): TIMEOUT feature_code n In the TIMEOUT syntax, “feature_code” is the name of the product (referred to in the INCREMENT line in the license file), and “n” is the number of seconds before an inactive license is reclaimed by the license server. For example, the syntax TIMEOUT Autodesk_f1 7200 means that for the product Autodesk_f1, the license timeout period is set for 7200 seconds, or two hours.

■

For all Autodesk products: In the Options file, enter the following syntax on its own line (with TIMEOUTALL entered in uppercase, as shown): TIMEOUTALL n In the TIMEOUTALL syntax, “n” is the number of seconds before an inactive license is reclaimed by the license server. For example, the syntax TIMEOUTALL 7200 means that for all Autodesk products, the license timeout period is set for 7200 seconds, or two hours.

For more information ing the license timeout feature, see the FLEXnet documentation in the C:\Program Files\Autodesk Network License Manager folder.

License Borrowing If you are running a network-licensed version of the program, you can borrow a license from a license server to use the program for a specified time when your computer is not connected to the network.


Overview If you are using a network-licensed version of your Autodesk product and your network s the license borrowing feature, you can borrow a product license from your network license server to use the program when your computer is not connected to the network. Your license is automatically returned to the license server at the end of the day on the return date you set when you borrowed the license. You can also return a license early. NOTE There is a limit to the number of licenses available for borrowing. If you try to borrow a license and are notified that no licenses are available, all network licenses may already be borrowed by other s. If you are unable to borrow a license, see your network for help. If you have a stand-alone version of the program, you cannot borrow a license. You can, however, use the License Transfer Utility to transfer your license from one computer to another. To check your license type, select Help > About Maya from the main menu bar and click Product License Information to open the dialog box.

Important notes on borrowing Maya licenses Borrowing a Maya license using the general Autodesk license borrowing procedure does not borrow licenses for specialized nodes such as mental ray batch render nodes or fluid simulation nodes. If you are borrowing a Maya license and plan to use mental ray or fluid simulation while you have a borrowed license, use the Maya-specific license borrowing steps. See Borrow a Maya license with sub-features on page 121.

Borrow a License You can run the program when your computer is not connected to the network until your license-borrowing period ends. If you don't the date that a license expires, you can check the date by selecting Help > About Maya and clicking Product License Information. This opens the Product License Information dialog box. When the license-borrowing period expires, the borrowed license is automatically returned to the license server. Once your computer is reconnected to the network, you can run the program from the network or borrow a license again.

License Borrowing | 119

Interaction with Other License-Borrowing Tools Using the license borrowing feature in the program is the recommended way to borrow a license; however, some third-party borrowing tools may also be available to you. These tools are not ed or compatible with the license borrowing feature in the program. Other third-party or legacy license-borrowing tools that may be available to you are the Autodesk License Borrowing utility (shipped with Autodesk products) and the borrowing feature in lmtools.exe, a component of the Autodesk Network License Manager. If another license-borrowing tool is active when you attempt to use the license borrowing feature, you should proceed as follows to borrow a license for the program: ■

If you run the Autodesk License Borrowing utility that shipped with your Autodesk product and then turn on the borrowing flag for the Adskflex option or the All option, a license can be borrowed when you start the program. However, you cannot return a license until you exit and then restart the program.

■

If borrowing is set in lmtools.exe for all products, you can either (a) use the other tool to borrow licenses for the program or (b) stop the borrowing process in lmtools.exe and then use the license borrowing feature in the program.

■

If borrowing is set in lmtools.exe for non-Autodesk products only, you must stop the borrowing process in lmtools.exe. You can then use the license borrowing feature to borrow licenses for your Autodesk product. If you do not stop the borrowing process in lmtools.exe, the license borrowing feature will not function.

To borrow a license using the Help menu 1 Select Help > About Maya. 2 In the About Maya window, click Product License Information. 3 In the Product License Information window, click Borrow License. 4 In the Borrow a License window, on the calendar, click the date when you want to return the license. This date must be within the valid date range set by your network . The valid date range is displayed in this window. 5 Click Borrow License. 6 In the License Borrowed message, click OK.


The license is borrowed, and you can now use the program while your computer is disconnected from the network.

Borrow a License window Using the license borrowing feature, you can borrow a license from your network license server, and then use the license when your computer is disconnected from the license server; for example, when you are traveling for work. The Borrow a License window has the following options: Calendar Sets the date when you plan to return a borrowed license. The return date must be within the range specified by your network . Borrow a License Borrows the license from the network license server based on the return date that you specified. Cancel Cancels the borrowing action; no license is borrowed.

Borrow a Maya license with sub-features If you are planning to borrow a license and you need to use the mental ray batch render nodes or fluid simulation while you have the license borrowed, use the following steps to borrow a license.

Borrow a Maya license To borrow a Maya license (Windows) NOTE The LMTOOLS utility is packaged with the Network License Manager. If you do not have the LMTOOLS utility installed, you can install it as part of the the Network License Manager. See Install the Network License Manager on page 98. 1 Open the LMTOOLS utility by selecting Start > Programs > Autodesk > Common Utilities > FlexLM License Utilities. 2 In the LMTOOLS utility, switch to the Borrowing tab. 3 In the Vendor Name field, enter adskflex. 4 Enter the Return Date and the Return Time, then click Set Borrow Expiration.


5 Launch Maya. This borrows a Maya license from the server. 6 Use any sub-features of Maya (such as fluid simulation, mental ray rendering, or the mental ray local batch render) while you are still connected to your license server. This automatically borrows a license for those sub-features. After you have used the sub-feature(s) while connected to your license server, you can then use the sub-features later when you are not connected. To borrow a Maya license (Mac OS X or Linux) 1 Open a shell (Linux) or Terminal (Mac OS X) window. 2 Execute the following command: lmutil lmborrow adskflex enddate [time]

where enddate is the date you will return the license, formatted as follows: dd-mmm-yyyy. The time argument is optional, but is specified in 24-hour format (hh:mm). For example: lmutil lmborrow adskflex 14-oct-2010 [14:00] borrows a license until October 14, 2010 at 2:00 pm. 3 Launch Maya. This borrows a Maya license from the server. 4 Use any sub-features of Maya (such as fluid simulation, mental ray rendering, or the mental ray local batch render) while you are still connected to your license server. This automatically borrows a license for those sub-features. After you have used the sub-feature(s) while connected to your license server, you can then use the sub-features later when you are not connected.

Stop borrowing a Maya license Stopping license borrowing is different from returning a license. You can stop borrowing licenses if you have already checked out all of the licenses you want, but you still plan to use sub-features while you are connected to the network server and do not want to borrow those licenses. For example, you can borrow a Maya license and a mental ray subfeature license, then stop borrowing so that when you use fluid simulation (and


automatically use a subfeature license for fluid simulation), you do not borrow the fluid simulation license from the server. In this situation, after you stop borrowing, your Maya and mental ray licenses are still borrowed until the return date that you set, but the fluid simulation license you used stays on the server. To stop borrowing a Maya license (Windows) 1 Open the LMTOOLS utility by selecting Start > Programs > Autodesk > Common Utilities > FlexLM License Utilities. 2 In the LMTOOLS utility, switch to the Borrowing tab. 3 Click Don’t Borrow Anymore Today. To stop borrowing a Maya license (Mac OS X or Linux) 1 Open a shell (Linux) or Terminal (Mac OS X) window. 2 Execute the following command: lmutil lmborrow -clear

Return a Maya license and sub-feature licenses Your network license is automatically returned to the network license server at the end of the return date you set when you borrowed the license. You can also return a license earlier than the date you originally selected, as long as your computer is connected to the network license server when you attempt to return the borrowed license. Returning a license means that you are returning a license to the network server so that someone else can use or borrow it. Once a borrowed license is returned, you can borrow a license again as long as your computer is connected to the network license server and a license is available on the server. If you use fluid simulation, mental ray rendering, or the mental ray local batch render features while you have a Maya license borrowed from your license server, you have automatically borrowed a sub-feature license. The following steps include information on properly returning the licenses for those sub-features. The following table lists the feature codes that you will need if you use these sub-features. Feature or Sub-feature

Feature license code

Maya

85537MAYA_2011_0F

Fluid simulation

85537MAYAMFS_2011_0F


Feature or Sub-feature

Feature license code

mental ray interactive

85537MAYAMMR_2011_0F

mental ray local batch render nodes

85537MAYAMMR1_2011_0F 85537MAYAMMR2_2011_0F 85537MAYAMMR3_2011_0F 85537MAYAMMR4_2011_0F 85537MAYAMMR5_2011_0F

To return a license early (Windows) 1 Open the LMTOOLS utility by selecting Start > Programs > Autodesk > Common Utilities > FlexLM License Utilities. 2 In the LMTOOLS utility, switch to the Borrowing tab. 3 Click List Currently Borrowed Features, and note any sub-features that are listed in the bottom pane of the Borrowing tab. For example, if you have used fluid simulation, the sub-feature code 85537MAYAMFS_2011_0F is listed. 4 (Optional) If you are returning sub-feature licenses, copy the sub-feature code and paste it into the Feature Name field. 5 Click Return Borrowed Licenses Early. 6 Repeat steps 4 and 5 for all sub-features you have borrowed. To return a license early (Mac OS X or Linux) On the same computer where you borrowed the license, do the following: 1 Open a shell (Linux) or Terminal (Mac OS X) window. 2 Execute the following command to determine if you have borrowed any sub-feature licenses: lmutil lmborrow -status The command returns the feature codes for any sub-feature licenses you have checked out. For example, if you have used mental ray rendering, the feature code 85537MAYAMMR_2011_0F displays. 3 Execute the following command: lmutil lmborrow -return where specifies the code of the feature or subfeature for which you are returning a license.


Return a license Your network license is automatically returned to the network license server on the day that the license expires. You can also return a license earlier than the date you originally selected, as long as your computer is connected to the network license server when you attempt to return the borrowed license. Once a borrowed license is returned, you can borrow a license again as long as your computer is connected to the network license server and a license is available on the server. To return a borrowed license early 1 Select Help > About Maya, then click Product License Information. 2 In the Product License Information window, click Return License, then click Yes. Your license is returned to the network license server. After you return the borrowed license, you can borrow a license again immediately as long as a license for that product is available on the network. To check the license return date 1 Select Help > About Maya, then click Product License Information. 2 In the Product License Information window, under License Expiration Date, view the license return date.

Network Licensing FAQs What is the difference between a stand-alone license and a network license? Stand-alone licensed products are ed and activated to an individual workstation. While the software can be installed on multiple systems in your facility, the license only allows one system to be operational. If you need to run more systems, you need to purchase more stand-alone licensed products, or consider converting to network licenses. Network licensed products rely on the Network License Manager to keep track of software licenses. The software can be installed and run on multiple systems,

Network Licensing FAQs | 125

up to the maximum number of licenses you’ve purchased. The Network License Manager “checks out” licenses until they are all in use. No further systems can run the program until a license is “checked in.” If you need to run more systems, you can purchase additional licenses for the Network License Manager to maintain.

What is the benefit of using a network licensed version of the software? Network licensed products are recommended for large drafting/design facilities, classrooms, and lab environments. The main advantage is that you can install products on more systems than the number of licenses you have purchased (for example, purchasing 25 licenses but installing on 40 workstations). At any one time, products will run on the maximum number of systems for which you have licenses. This means you get a true floating license. If software needs to be run on more systems, additional licenses can be purchased. Registration and activation occurs only once and the licenses are maintained on your network license server.

How do I switch my license from stand-alone to network or network to stand-alone? If you have purchased stand-alone and network licenses and you want to switch which license Maya is using, there are two main methods to change the license type. ■

■

Uninstall and re-install Maya, changing the type of license you specify during the install. Edit the MAYA_LICENSE_METHOD environment variable in your license.env file.

If you have added the MAYA_LICENSE_METHOD variable to your system environment variables or to a Maya.env file, you must also update the license type in those locations.

To edit the MAYA_LICENSE_METHOD environment variable 1 Locate the license.env file in the following location: ■

(Windows) C:\Program Files\Autodesk\Maya2011\bin


■ ■

(Linux) /usr/autodesk/maya2011-x64/bin (Mac OS X) In the Maya installation directory (by default /Applications/Autodesk/maya2011/), right-click the Maya application and select Show Package Contents. Locate the license.env file in the

Contents directory. 2 Edit the MAYA_LICENSE_METHOD variable to indicate the type of license you want, for example: MAYA_LICENSE_METHOD=standalone

to set Maya to use a stand-alone license, or MAYA_LICENSE_METHOD=network

to set Maya to use a network license. If you are switching from a stand-alone to a network license, continue with the following steps to set your license server name. 3 Navigate to the following directory to locate and open the LIATH.LIC file. ■


■



IMPORTANT If you have added the MAYA_LICENSE_METHOD variable to your system environment variables or to a Maya.env file, you must also update the license type in those locations. To locate the Maya.env file ■ ■

(Windows) C:\Documents and Settings\\My Documents\maya (Mac OS X) /s/name/Library/Preferences/Autodesk/maya/version

How do I switch my license from stand-alone to network or network to stand-alone? | 127

■

(Linux) /home/<>/maya

How do I change the license server information I entered during the installation? To change the license server information you entered 1 Navigate to the following directory to locate and open the LIATH.LIC file. ■


■



What is Internet Explorer used for? After installing your product, you can operate in trial mode for a given number of days. Whenever you launch the program, you are prompted to activate the software. When you choose to activate the software, Internet Explorer makes this process much faster. Once you entered your registration data and submit it to Autodesk, an activation code is returned and you are not prompted again during startup.

Where can I find more information on troubleshooting network licensing? If you experience difficulty with installation or licensing, visit http://autodesk.com/servicesand for additional FAQ information, as well as an in-depth Knowledge Base that you can search for solutions to common installation and licensing issues and error messages.


Glossary of Licensing

6

ADSKFLEX_LICENSE_FILE In a distributed license server configuration, the environment variable used to point a workstation to the distributed license servers. adskflex.exe The Autodesk vendor daemon used with the FLEXnet license technology. This daemon keeps track of the Autodesk licenses that are checked out and the workstations that are using the licenses. borrowed license A license that allows you to use an Autodesk product for a limited period of time without having to buy a separate license or have network access to the license server. daemon A program that runs continuously in the background of a computer. The daemon handles requests from the computer and then forwards the requests to other programs or processes. The Network License Manager uses two daemons: the vendor daemon (adskflex.exe) and the license manager daemon (lmgrd.exe). debug log file A file used with FLEXnet to log connection activity (such as license failure or starting and stopping) between the Network License Manager and the workstation. deployment The files and folders created on a server and used by workstations to install Autodesk programs. distributed server A license server configuration option in which several servers are used to manage license distribution. Each distributed license server has a unique license file and a fixed number of licenses. If one distributed license server fails, the other servers are still able to distribute their licenses. Ethernet address See host ID. feature code A license file parameter that represents the product that is ed by that license file.

129

FLEXnet The Acresso Software license management technology implemented in the Autodesk family of products. heartbeat signal The communication signal between the Network License Manager and the workstation to that the workstation is accessible and has an active Autodesk product session running. host ID The unique hardware address of a network adapter. Also known as Ethernet address or physical address. host name The T/IP name associated with a computer. FLEXnet technology uses the host name as a parameter; the host name must be distinguished from the NetBIOS (server) name. idle A state of inactivity in your product that prompts a network license server to reclaim a license. Inactivity is due to no mouse or keyboard activity and no commands, LISP expressions, menu macros, or scripts in progress for the period of time that is defined in the Options file. See also license timeout. JRE (Java Runtime Environment) A program that is required to run Java programs. This program must be installed with SAMreport-Lite. license file A file used with FLEXnet that controls the number of available seats. This file must be in ASCII plain text format. license server A server that contains the Network License Manager. license timeout A feature that allows you to set up a timeout period on your license server to automatically return an idle license to the server so that it is available for use again. liath.lic In both single and redundant server configurations, the file used to point the workstation to the FLEXnet license server. Liath.lic is located in the root installation folder. lmgrd.exe The license manager daemon. This daemon handles the original with the program, and then es the connection to the vendor daemon, adskflex.exe. lmtools.exe A graphical interface utility used to ister the FLEXnet license technology. (Lmutil.exe is the command line version of this utility.) lmutil.exe A command line utility used to ister the FLEXnet license technology. (Lmtools.exe is the graphical interface version of this utility.) master daemon See lmgrd.exe. network license installation A type of installation that requires you to install and run the Network License Manager from a network server. You must install and configure the Network License Manager before clients can run the Autodesk product.

130 | Chapter 6 Glossary of Licensing

Network License Manager The technology used by Autodesk for network license management. Options file The file used by FLEXnet to control license manager parameters, such as reserving licenses and creating report logs used with SAMreport-Lite. physical address See host ID. redundant server A license server configuration option in which three servers are used to ister licenses. The redundant servers share a license file and a pool of licenses. The redundant server pool remains functional as long as two of the three servers are running and communicating with each other. report log file A file used with FLEXnet and SAMreport-Lite. This log file provides information about network license usage. The Options file creates the report log. SAMreport-Lite A version of Acresso Software's SAMreport tool. SAMreport-Lite is included on the Autodesk product discs. vendor daemon See adskflex.exe. workstation A desktop computer used by an individual on a network.

| 131

132

Index A

bundled products

activating programs 27, 68, 73 activation code 67 istrative images defined 61 shortcuts to 38 permission requirements stand-alone installation 10 Adskflex option 120 adskflex.exe (Autodesk vendor daemon) 86, 110 advertising deployments 44 anti-virus software 11 applications anti-virus software 11 closing during installation 11 uninstalling 29, 61 asg deployments 44–45 Autodesk Backburner installing 3, 12 Autodesk License Borrowing utility 120 Autodesk Network License Manager 120 Autodesk products activating 68 borrowing network licenses for 119 License Transfer utility 71 reinstalling 75 using off network 119 Autodesk vendor daemon 110

C

B borrowing licenses about 118–119 configuring 116 reconnecting and borrowing again 119, 125 returning licenses 125 borrowing Maya licenses 121 browsers 9

26

cleaning hard drives 51 client log files 36 client workstations asg deployments 44–45 imaging software deployments 49 repairing installations 51 ing deployments 49 Commercial licenses 68, 97 computers 9 licenses for 71 configuration desktop 25 configuring license borrowing 116 license servers 102, 104, 114 Maya license borrowing 121 copying licenses 71, 75

D daemons license manager daemons vendor daemons 86 versions of 110 data loss 11 dates system dates 76 default deployments 36 Deployment wizard 36, 76 deployments asg 44–45 Deployment wizard 36 distributing 45, 49 group policies 44 imaging software 49

86

133 | Index

issues 59 methods 39 modifying 38 preparing for 30 scripts 39 ing installation 49 desktop configuration 25 distributed license server model about 84 license file example 90 distributing deployments 45, 49 software installation images

H

76

E

F 27

G glossary 64, 131 group policies advantages and disadvantages advertising deployments 44 distributing deployments 45 ing deployments 49

134 | Index

9

79, 81–

I

early returns of licenses 125 Educational (EDU)/Institution licenses 69, 97 email registration 27 Ethernet address 100 exporting licenses about 71 transfer files 72

faxing registration information files uninstalling 29 flags 42 FLEXnet tools about 108 Options file 114–116 updating 110

hard disks cleaning 51 system requirements 9 hardware installation requirements license errors and 75 hardware requirements Network License Manager 82 heartbeat signals 97 host IDs 100 host names 100

44

imaging software deployments 49 importing licenses about 71 transfer files 73 Imtools.exe 120 install Autodesk Backburner 3, 12 MatchMover 3, 12 Maya on Linux (Quick Steps) 7 Maya on Linux (Step by Step) 17 Maya on Mac OS X (Quick Steps) 6 Maya on Windows (Quick Start) 4 Toxik 3, 12 install directory Linux 8, 17 Mac OS X 7 installation advertising deployments 44 group policies 44 imaging software 49 Installation wizard 12 License Transfer utility 72 multiple or bundled products 26 network deployment 33 Network License Manager 98 networking issues 60 overview 3 preparing for 9 registration and activation 27

reinstalling 61 repairing damaged installations 51, 61 SAMreport-Lite 106 scripts 39 serial numbers 10 software deployments 33, 59 stand-alone installation 12 starting 28 switches and flags 42 system requirements 9 troubleshooting 57 uninstalling 29, 61 ing deployments 49 workflow 3 Installation wizard 12 Internet program registration and activation 27 Internet Explorer (Microsoft) 9

K KDE 25 key bindings configuring

25

L languages selecting during installation 11 license borrowing about 118–119 borrowing licenses 118–119 configuring 116 returning licenses 125 third-party licensing tools 120 license borrowing for Maya 121 license files about 87 combined products 91 package examples 92 license manager daemon 86, 110 license servers borrowing licenses 118–119 configuring 102, 104, 114

heartbeat signals 97 host IDs and host names 100 limited number of licenses 119 management utilities 108 models 83 returning licenses 125 stopping and restarting 109 third-party licensing tools 120 types of 83 license timeout 117 License Transfer utility about 71 installing 72 transferring licenses 71 licenses about 85 active 71 asg 85 availability 85 behaviors (term limits) 97, 114 copying 75 exporting 72 FLEXnet tools 108 glossary 131 importing 73 license files 87 license servers 102, 104 license timeout 117 license types 58 moving between computers 75 single- 67 transferring 71, 73 types of 97 limits on number of licenses 119 Linux compiling plug-ins and applications 22 configuring license servers 104 install Maya 7 install Maya (Step by Step) 17 Network License Manager 82 Linux install 7 packages 19 rpm 19 lmgrd.exe (license manager daemon) 86, 110

Index | 135

lmtools.exe utility 100, 102, 108, 110 lmutil.exe utility 108, 110 log files creating 35 report log files 116

M Mac OS X install Maya 6 Network License Manager 81 mailing registration information 27 maintenance issues 61 master images 49, 51 master machine 52 master systems 51 MatchMover installing 3, 12 memory (RAM) system requirements 9 mental ray satellite rendering 52 Microsoft Installer files (MSI) 61 Microsoft Internet Explorer 9 Microsoft Windows configuring license servers 102 Network License Manager 79 Microsoft Windows operating systems 9 monitors 9 MSI files 61 multi-product bundles 26 multi-seat stand-alone installations 50

planning 79 tools and utilities 108 types of 97 Network License Manager asg licenses 85 glossary 131 installing 98 license server models 83 uninstalling 106 upgrading 98 network license servers borrowing licenses 118–119 limited number of licenses 119 returning licenses 125 third-party licensing tools 120 network log files 35 network shares creating 32 deploying products with 39 locations 60 Norton Ghost 49 Not for Resale licenses 68, 97

O operating systems reinstalling 75 restoring 51 system requirements 9 Options file (FLEXnet tools) 114–116 OS X Network License Manager 81

N

P

network istration group policies 44 network installations deployment 33 group policies 44 issues 60 scripting 39 network license installations license behaviors 114 license borrowing 116 license timeout 117

package license files 92–95 Permanent licenses 69, 97 permanent transfers of licenses 71 permission requirements stand-alone installation 10 physical address 100 pointing devices system requirements 9 port number changing 55 private licenses 72

136 | Index

processors 9 Product Activation wizard product information 34 viewing 69 product keys 10, 27 public licenses 72

27, 67

Q Quick Start Linux install 7 Mac OS X install Windows install

6 4

R RAM system requirements 9 ray sat server 54 reactivating programs 75 redundant license server model about 84 license file example 90 package license files 94 ing programs 27, 68 reinstalling operating systems 75 removing uninstalling programs 29, 61 repairing damaged installations 51, 61 report log files 116 restoring damaged installations 51, 61 operating systems 51 returning borrowed licenses 119, 125 RSS feeds 60 running scripts 43

S SAMreport-Lite installing 106 SATA RAID environments

50

satellite rendering changing port number 55 master 52 mental ray 52 ray sat server 54 slave 52 slave machine installation 53 scripts creating 39 deploying program with 39 flags and 42 running 43 sample scripts 40 switches and 42 system requirements 40 serial number updating 70 serial numbers stand-alone installation 10 servers 60 host IDs and host names 100 license servers 102, 104 stopping and restarting 109 service packs 9 shortcuts istrative images 38 silent mode 36, 40 single license server model about 83 license file example 90 package license files 93 single- licenses 67 slave machine 52 software deployments 59 software installation requirements 9 software requirements Network License Manager 79, 81– 82 stand-alone installations imaging software and 50 process 12 program registration and activation 27 scripting 39 stand-alone licenses 67 Student Portfolio licenses 69, 97

Index | 137

system dates 76 system requirements Maya 9, 31 Network License Manager 79, 81– 82 scripts 39 stand-alone installations 9 system times 76

T T/IP names 100 temporary transfers of licenses 71 Term Extendable licenses 69, 97 Term Non-Extendable licenses 69, 97 text editors 58 third-party licensing tools 120 time system time 76 timeouts 117 Toxik installing 3, 12 transfer files exporting 72 importing 73 transferring licenses 71 Trial licenses 69 trial mode 27 troubleshooting installation 57

U uninstall 28 uninstall Maya Linux 30

138 | Index

Mac OS X 29 uninstalling Network License Manager 106 uninstalling programs 29, 61 uned Maya features 25 updating FLEXnet tools 110 upgrading Network License Manager 98 information 34

V VBS files (installation script) 39 vendor daemons 86, 110 ing group policy deployments video cards 9, 57 video monitors 9 virus software 11

49

W web browsers 9 Windows configuring license servers 102 install Maya (Quick Start) 4 Network License Manager 79 Windows operating systems system requirements 9 workstations asg deployments 44–45 imaging software deployments 49 repairing installations 51 restoring master systems 51 ing deployments 49

Maya Installation Licensing Guide 611p3l

Overview 1s532p

More details 6h715l

Related Documents 2w1qw

Maya Installation Licensing Guide 611p3l

Aveva Licensing System Installation Guide 3l3bk

3ds Max 2011 Installation Licensing Guide 1i2y3l

Ansys - Installation And Licensing Documentation 3q6u2r

Synthesis 10 Installation And Licensing 2h2k2c

Ansys Inc. Licensing Guide 686f6z
