Uromac Lacertis Loko Series 726ux

LACERTIS LOKO series

ROAD-RAIL SHUNTER • Shunting capacity up to 2000 t • 360º swivelling cockpit for exceptional visibility • Articulated chassis for easy tracking-on on manoeuvre • Low operating and maintenance costs • Radio remote control system for one-man operation • Track gauge from 1000 to 1676 mm

LACERTIS LOKO series

Rail guidance system

Safety & Comfort

• Track gauge from 1000 to 1676 mm. • Automatic pressure compensation. • High pulling/towing capacity in both directions.

• 360º swivelling cockpit • Exceptional visibility in both directions • Increased security for the operator and other personnel around the machine • Dead man’s handle • Emergency stop

Articulated chassis

• Tracking-on on manoeuvre on narrow space. • High stability on track even on reduced radius curves • Continuous stabilization on the track • Permanent on four wheels with the rail.

Options

• Radio remote control system for one-man operation • Snow plough/brush • Generator • Crane • Pneumatic and electrical tools on demand • Special bodybuilding

Coupling options

• Mechanical drawbar • Automatic coupler • UIC hook • RK 900 • SA33 and AAR coupler • Others on demand.

Powertrain

• Engine: Deutz / Caterpillar according to latest emissions standard. • Linde hydraulics

LACERTIS LOKO SERIES LOKO 10

LOKO 12

LOKO 14

LOKO 18

Engine

75 kW 100 HP

90 kW 120 HP

129 kW 173 HP

129 kW 173 HP

Weight

10 t

12 t

14 t

18 t

Maximum Tractive effort

45 kN

55 kN

75 kN

100KN

Shunting capacity

700 t

1150 t

1500 t

2000 t

Air capacity for wagon brake system

300 l

600 l

600 l

800 l

Capacity of fuel tank

150 l

150 l

250 l

400 l

No

Yes

Yes

Yes

1

1

1/2

1/2

180º rotating seat No. of seats

For more complete information on Uromac products visit us on the web at www.uromac.com or your local distributor for more information. © 2018 Uromac Systems S.A. (SPAIN) All rights reserved. Materials and specifications are subject to change without notice. Featured machines in photos may include additional equipment.
