Foreword The main objective of these tutorials is to give you a kick start using SolidWorks. The approach to write this tutorial is based on what is the most important knowledge you should know and what is commonly tool used. You will learn step by step by working on it. These tutorials will teach you the basic skills of using Solidworks in your daily design works. Even this tutorials didn’t have full explanations of tools that Solidworks have but don’t worry you will master it along the way, as I did. If you have any questions about these tutorials, drop your mail to [email protected]
Solidworks 2010 Tutorials: Beginner http://www.solidworkstutorials.com ©2010 solidworkstutorials.com , All rights reserved. This publication is copyright under the solidworkstutorials.com All rights reserved. Apart from any fair dealing for the purpose of private study, research, criticism, or review, as permitted under the Copyright Designs and Patents Act 1988, no part may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, electrical, chemical, mechanical, photocopying, recording or otherwise, without the prior permission of the copyright owners. Unlicensed multiple copying of this publication is illegal. Inquiries should be addressed to: [email protected] If this guide is distributed with software that includes an end- agreement, this guide, as well as the software described in it, is furnished under license and may be used or copied only in accordance with the of such license. Except as permitted by any such license, no part of this guide may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, recording, or otherwise, without the prior written permission of solidworkstutorials.com. Please note that the content in this guide is protected under copyright law even if it is not distributed with software that includes an end- license agreement. The content of this guide is furnished for informational use only, is subject to change without notice, and should not be construed as a commitment by solidworkstutorials.com. Solidworkstutorials.com assumes no responsibility or liability for any errors or inaccuracies that may appear in the informational content contained in this guide. Please that existing artwork or images that you may want to include in your project may be protected under copyright law. The unauthorized incorporation of such material into your new work could be a violation of the rights of the copyright owner. Please be sure to obtain any permission required from the copyright owner. Any references to company names in sample templates are for demonstration purposes only and are not intended to refer to any actual organization. The publishers are not responsible for any statement made in this publication. Data, discussion, and conclusions developed by the Author are for information only and are not intended for use without independent substantiating investigation on the part of the potential s. Opinions expressed are those of the Author and are not necessarily those of the Institution of Mechanical Engineers or its publishers.
i
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Solidworks Tutorials: Beginner Table of contents
www.solidworkstutorials.com
Table of contents Beginner Part 1: My First Solid … … … … 1 The big picture how SolidWorks works, it starts with a simple editable sketch. From this sketch a feature build the solid. From this solid it produces drawing... Beginner Part 2: Sketching … … … Sketch is the base of your part, it’s a good practice to master sketching in SolidWorks...
… 10
Beginner Part 3: Turning Parts … … … … 23 Some parts such as pins and shafts can be manufacture by turning process on lathe machine, we can create turning part by revolving it sketch on it axis... Beginner Part 4: Hole Wizard … … … … 30 Hole Wizard is used for creating predefined and standard holes such as counter bore hole, counter sunk hole, screw clearance hole and many more... Beginner Part 5: Pattern … … … … 40 Pattern (or some called array) is used to repeat features in linear arrangement or circular arrangement. It’s good to know how to optimize these tool, it help you make your part faster and easier... Beginner Part 6: Assembly Parts … … … 60 Assembly is a part of design process, it show how all designed parts work together as a single unit... Beginner Part 7: Detailing Drawing … … … 80 Once solid parts created we need to transfer it to engineering drawing so the others can understand your parts…
Solidworks Tutorials: Beginner Table of contents
ii
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 1: My First Solid
www.solidworkstutorials.com
Beginner Part 1: My First Solid The big picture how SolidWorks works, it starts with a simple editable sketch. From this sketch a feature build the solid. From this solid it produces drawing... Let’s begin your first solid...
1.
Click New
2.
Click Front Plane, insert sketch on plane by click Sketch.
In this tutorial you will make this 3. bracket, start from sketch and build features.
4.
Beginner Part 1: My First Solid
Click Sketch
, click Part
, OK.
, click
Corner Rectangular . Start first point at origin and click another point at top right side.
Click Smart Dimension , click top edge set dimension to 3in and click right edge set dimension to 2in.
1
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 1: My First Solid
www.solidworkstutorials.com
5.
Beginner Part 1: My First Solid
To build features, click Extruded Boss/Base
, set D1 to
0.10in
.
and
2
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 1: My First Solid
www.solidworkstutorials.com 6.
Click on front face of the part, click Normal To.
7.
Click Circle
, sketch circle on face
.
Click Smart Dimension , click circle edge and set diameter to 0.6in. For circle positioning click circle edge and vertical part edge set to 0.5in. Click circle edge again and click horizontal part edge set to 0.5in.
Beginner Part 1: My First Solid
3
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 1: My First Solid
www.solidworkstutorials.com
8.
Click Extruded Cut
All
Beginner Part 1: My First Solid
, change Direction 1 to Through
and
.
4
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 1: My First Solid
www.solidworkstutorials.com 9.
Click on front face and select Sketch
. Select Corner Rectangular top right edge to center.
10. Click Smart Dimension dimension to 2in and 1in.
Beginner Part 1: My First Solid
sketch rectangular from
, set rectangular
5
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 1: My First Solid
www.solidworkstutorials.com
Click Extruded Cut
and select Through All
and
.
11. Click on front face and select Sketch
. Click Corner Rectangular and sketch rectangular start form bottom left edge to right edge.
Beginner Part 1: My First Solid
6
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 1: My First Solid
www.solidworkstutorials.com
Click Smart Dimension and set rectangular height to 0.1in.
12. Click Extruded Boss/Base
Style and select Isometric.
Beginner Part 1: My First Solid
set Direction 1 to 0.5in
and
. Click Display
7
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 1: My First Solid
www.solidworkstutorials.com
13. Click Fillet
, check Full preview
add fillet to all edges
Beginner Part 1: My First Solid
8
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 1: My First Solid
www.solidworkstutorials.com
and
.
14. Save it?
the part as Bracket and you’re done! Simple isn’t
Go to table of contents Go to beginning of chapter tutorial Go to www.solidworkstutorials.com
Beginner Part 1: My First Solid
9
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 2: Sketching
www.solidworkstutorials.com
Beginner Part 2: Sketching Sketch is the base of your part, it’s a good practice to master sketching in SolidWorks...
1.
Click New
2.
Click Front Plane, insert sketch on plane by click Sketch.
3.
Click Sketch
, click Part
, OK.
In this tutorial you will make this box, start from sketch and build features. You’ll learn how to use sketch tools to build this part.
, click
Corner Rectangular . Start first point at origin and click another point at top right side.
4.
Beginner Part 2: Sketching
Click Smart Dimension , click top edge set dimension to 2in and click right edge set dimension to 2in.
10
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 2: Sketching
www.solidworkstutorials.com 5.
To build features, click Features>Extruded Boss/Base
, set D1 to 0.50in
and
Beginner Part 2: Sketching
.
11
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 2: Sketching
Beginner Part 2: Sketching
www.solidworkstutorials.com 6.
Click on front face of the part, click Normal To.
7.
Click on front face and click Sketch.
12
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 2: Sketching
www.solidworkstutorials.com
8.
Click Offset Entities
, set to 0.1in and check
Reverse box
9.
Beginner Part 2: Sketching
Click Extruded Cut
and
.
, change D1 to 0.4in.
13
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 2: Sketching
www.solidworkstutorials.com 10. Click on side face, click Sketch.
11. While pressing Ctrl key select inner left and right edge.
Click
Convert Entities
.
12. Select Centerline from line menu , sketch a centerline midpoint to midpoint of both converted
Beginner Part 2: Sketching
14
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 2: Sketching
www.solidworkstutorials.com
edges. 13. Click sketched centerline
and click Offset Entities.
Beginner Part 2: Sketching
15
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 2: Sketching
www.solidworkstutorials.com
Set Parameter, D to 0.3in check Bi-directional and
.
14. Now click Trim Entities to remove excess line, before make any cut make sure under option Trim to
closest is selected. Trim extra line as below sketch. Answers Yes if notification appear.
15. Click View Orientation>Isometric.
16. Click Features>Extruded Boss/Base , for Direction 1, click Reverse Direction (green box) and set D1 to 0.1in.
Beginner Part 2: Sketching
16
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 2: Sketching
www.solidworkstutorials.com
and
Beginner Part 2: Sketching
.
17
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 2: Sketching
www.solidworkstutorials.com 17. Click on front face and click Normal To.
18. Click on front face and click Sketch.
Beginner Part 2: Sketching
18
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 2: Sketching
www.solidworkstutorials.com
19. Click Circle,
sketch circle at left edge.
20. Click Smart Dimension, below sketch.
21. Click on sketched circle,
Copy Entities.
Beginner Part 2: Sketching
dimension sketch as
click
Set delta x
19
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 2: Sketching
www.solidworkstutorials.com
to 0.3in
and
.
22. Click Centerline, sketch centerline across front face and make sure it starts at midpoint left edge and midpoint right edge and
.
23. While press Ctrl key, select both sketched circle and click Mirror Entities , on Mirror Option click Mirror about: box, and select centerline
Beginner Part 2: Sketching
20
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 2: Sketching
www.solidworkstutorials.com
and 24. Click Extruded Cut,
and set D1 to 0.1in
25. Click View Orientation>Back,
Beginner Part 2: Sketching
.
and
.
21
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 2: Sketching
www.solidworkstutorials.com and click on back face and click Sketch.
26. Click Sketch>Circle,
sketch circle at lower left edge.
Click Smart
Dimension sketch below.
and dimension sketched circle as
and
Beginner Part 2: Sketching
.
22
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 2: Sketching
www.solidworkstutorials.com
27. Click on sketched circle,
and click
Linear Sketch Pattern and on Direction 1 set D1 to 1.2in and on Direction 2, change # to 2 and set D2 to 1.2in and
Beginner Part 2: Sketching
.
23
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 2: Sketching
www.solidworkstutorials.com
28. Click Features>Extruded Cut,
and set direction to
Through All Click View Orientation>Isometric.
29. Save it?
and
.
the part as Sketch and you’re done! Simple isn’t
Go to table of contents Go to beginning of chapter tutorial Go to www.solidworkstutorials.com
Beginner Part 2: Sketching
24
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 3: Turning Part
www.solidworkstutorials.com
Beginner Part 3: Turning Part Some parts such as pins and shafts can be manufacture by turning process on lathe machine, we can create turning part by revolving it sketch on it axis...
In this tutorial you will make this pin, start from sketch and build solid body by revolve it sketch on axis. You’ll learn how to use revolved boss/base and revolved cut to build this part.
1.
Click New,
click Part,
OK.
2.
Click Front Plane, insert sketch on plane by click Sketch.
3.
Click on Line, sketch a closed loop start at origin, sketch as sketch below end back at origin.
and
4.
Click Smart Dimension sketch below.
and 5.
Beginner Part 3: Turning Part
and dimension sketch as
.
Click Features>Revolved Boss/Base, and click on bottom line as it axis.
25
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 3: Turning Part
www.solidworkstutorials.com
and
6.
Beginner Part 3: Turning Part
.
Click View Orientation>Front and click Front Plane and click Sketch.
26
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 3: Turning Part
www.solidworkstutorials.com
7.
Click Corner Rectangle, and sketch rectangle overlap on solid body as sketched below.
and
.
8.
Click Smart Dimension sketched below.
9.
To view solid body axis, click View>Temporary Axes.
and dimension sketch as
10. To make second undercut, click Features>Revolved Cut and select temporary axes as it axis
Beginner Part 3: Turning Part
27
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 3: Turning Part
www.solidworkstutorials.com
and
Beginner Part 3: Turning Part
.
28
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 3: Turning Part
www.solidworkstutorials.com 11. To hide temporary axes, click View>Temporary Axes.
12. Save
the part and you’re done! Simple isn’t it?
Go to table of contents Go to beginning of chapter tutorial Go to www.solidworkstutorials.com
Beginner Part 3: Turning Part
29
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 4: Hole Wizard
www.solidworkstutorials.com
Beginner Part 4: Hole Wizard Hole Wizard is used for creating predefined and standard holes such as counter bore hole, counter sunk hole, screw clearance hole and many more...
In this tutorial you will add counterbore, countersink and tap holes to this plate by using Hole Wizard tools.
1.
Click New,
2.
Click Top Plane, insert sketch on plane by click Sketch.
3.
Click on Corner Rectangle, origin.
and
4.
Beginner Part 4: Hole Wizard
OK.
sketch a rectangle start at
.
Click Smart Dimension sketch below.
and 5.
click Part,
and dimension sketch as
.
Click Features>Extruded Boss/Base, set D1 to 1in
on Direction 1
30
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 4: Hole Wizard
www.solidworkstutorials.com
6.
7.
Beginner Part 4: Hole Wizard
and . Click on top face and click Normal To.
Click Features>Hole Wizard on Hole Type, select Counterbore, Standard to Ansi Inch, Type to Socket Head Cap Screw, Size to #10, Fit to Normal and End Condition to Through All.
31
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 4: Hole Wizard
www.solidworkstutorials.com
For positions placement for this counterbore hole, click on Positions tab. more positions at each edge.
Beginner Part 4: Hole Wizard
Now click three
32
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 4: Hole Wizard
www.solidworkstutorials.com
8.
Click on Smart Dimensions, click on center point of counterbore hole and click left edge, set dimension to 0.5in.
Continue dimensioning as sketched below.
9.
and . For adding countersink at center, click on top face and click on Hole Wizard
Beginner Part 4: Hole Wizard
.
33
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 4: Hole Wizard
www.solidworkstutorials.com
On Hole Type, select Countersink, Standard to Ansi Inch, Type to Flat Head Screw (100), Size to #10, Fit to Normal and End Condition to Through All. 10. For positions placement for this countersink holes, click on Positions tab. more positions at center.
Beginner Part 4: Hole Wizard
Now click three
34
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 4: Hole Wizard
www.solidworkstutorials.com
11. Click on Smart Dimensions, click on center point of countersink hole and click left edge, set dimension to 2.5in.
Continue dimensioning as sketched below.
and . 12. For adding center tap hole, click on top face at center and click Hole Wizard.
Beginner Part 4: Hole Wizard
35
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 4: Hole Wizard
www.solidworkstutorials.com
On Hole Type, select Tap, Standard to Ansi Inch, Type to Tapped hole, Size to 1/2-13, End Condition to Through All. 13. For positions placement for this tap hole, click on Positions tab. There is another style to positions hole wizard is define it position by sketch, let try it.
Click on Centerline, Sketch a horizontal line start at midpoint of left edge to midpoint left
Beginner Part 4: Hole Wizard
36
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 4: Hole Wizard
www.solidworkstutorials.com edge. Press Esc to end sketch centerline.
14. Click and drag tap center to midpoint of centerline.
and . 15. Click View Orientation>Isometric. Done.
Beginner Part 4: Hole Wizard
37
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 4: Hole Wizard
www.solidworkstutorials.com
16. Save
the part as Plate1 and you’re done! Simple isn’t it?
Go to table of contents Go to beginning of chapter tutorial Go to www.solidworkstutorials.com
Beginner Part 4: Hole Wizard
38
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 5: Pattern
www.solidworkstutorials.com
Beginner Part 5: Pattern Pattern (or some called array) is used to repeat features in linear arrangement or circular arrangement. It’s good to know how to optimize these tool, it help you make your part faster and easier...
1. In this tutorial you will add multiple 2. features as linear pattern and circular pattern using pattern tools.
3.
Click New,
Click on Corner Rectangle, origin.
Beginner Part 5: Pattern
sketch a rectangle start at
.
Click Smart Dimension sketch below.
and 5.
OK.
Click Top Plane, insert sketch on plane by click Sketch.
and
4.
click Part,
and dimension sketch as
.
Click Features>Extruded Boss/Base, set D1 to 1in
on Direction 1
39
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 5: Pattern
Beginner Part 5: Pattern
www.solidworkstutorials.com
6.
and . Click on top face and click Normal To.
7.
Click on top face and click Sketch.
40
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 5: Pattern
www.solidworkstutorials.com
Click on Circle
and sketch a circle on top face and
8.
Click on Smart Dimension sketched circle as sketch below.
9.
Click Features>Extruded Cut
Through All.
.
and dimension
on Direction 1 set to
and
.
10. Click Features>Hole Wizard on Hole Type, select Counterbore, Standard to Ansi Inch, Type to Socket Head Cap Screw, Size to #10, Fit to Normal and End Condition to Through All.
Beginner Part 5: Pattern
41
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 5: Pattern
www.solidworkstutorials.com
For positions placement for this counterbore hole, click on Positions tab. at lower left edge.
Beginner Part 5: Pattern
Click one point
42
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 5: Pattern
www.solidworkstutorials.com
11. Click on Smart Dimension sketched circle as sketch below.
and
and dimension
.
12. To pattern this counterbore hole, click on CBORE for #10 Socket Head Cap Screw1
and click Linear Pattern. Direction 1 pattern.
Beginner Part 5: Pattern
Click on bottom edge as
43
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 5: Pattern
www.solidworkstutorials.com
Set D1 to 2.5in and pattern # to 3. Click on highlighted arrow to switch it directions.
13. Click on left edge as Direction 2 pattern.
Set D2 to 3.4in and number of pattern # to 2. You can click
Beginner Part 5: Pattern
44
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 5: Pattern
www.solidworkstutorials.com on arrow to switch it directions.
and
.
14. Click on top face and click Sketch.
Click on Circle,
Beginner Part 5: Pattern
sketch a circle with center to open hole.
45
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 5: Pattern
www.solidworkstutorials.com
Click Smart Dimension, 1.5in.
set circle diameter to
15. Click Line, sketch a vertical line crossing sketch circle at 12 o’clock to 6 o’clock.
Press Esc key to end Line. Exit sketch. 16. Click on Hole Wizard, on Hole Type click on Tap, Standard: Ansi Inch, Type: Tapped Hole, Hole Specifications Size:1/4-20, End Condition Through All.
Beginner Part 5: Pattern
46
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 5: Pattern
www.solidworkstutorials.com
For positions placement for this tap hole, click on Positions tab. o’clock last sketched circle.
Beginner Part 5: Pattern
Click one point at 12
47
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 5: Pattern
www.solidworkstutorials.com
and
.
17. To hide guide sketch, click Sketch4 and click Hide.
18. To pattern tap hole, click on 1/4-20 Tapped Hole1
and click Circular Pattern.
Change view to isometric by click on View Orientation>Isometric
Click on open inner hole face as it’s pattern axis, set instances # to 6 and
Beginner Part 5: Pattern
.
48
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 5: Pattern
www.solidworkstutorials.com
19. Save
the part as Block and you’re done! Simple isn’t it?
Go to table of contents Go to beginning of chapter tutorial Go to www.solidworkstutorials.com
Beginner Part 5: Pattern
49
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com
Beginner Part 6: Assembly Parts Assembly is a part of design process, it show how all designed parts work together as a single unit. ...
1.
Click New,
click Part,
OK.
2.
Click Front Plane, insert sketch on plane by click Sketch.
3.
Click on Corner Rectangle, origin.
In this tutorial you will create this toy horse by assembly parts to one unit assembly.
and
4.
5.
Beginner Part 6: Assembly Parts
.
Click Smart Dimension sketch below.
and
sketch a rectangle start at
and dimension sketch as
.
Click Features>Extruded Boss/Base, set D1 to 4in
on Direction 1
50
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com
6.
Beginner Part 6: Assembly Parts
and . Click on right face and click Normal To.
51
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com 7.
Click on right face again and click Sketch.
Click on Circle
and sketch 4 circle at each corner. Click
on Smart Dimension sketched below.
8.
Click on Features>Extruded Cut
Through All on View OrientationIsometric.
Beginner Part 6: Assembly Parts
and dimension sketch as
and set Direction 1 to
and
. Click
52
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com
9.
Click on top face and click Normal To.
Click on top face again and click Sketch.
Beginner Part 6: Assembly Parts
53
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com
Click on Corner Rectangle top and bottom.
Click on Smart Dimension rectangles as sketched below.
Beginner Part 6: Assembly Parts
and sketch 2 rectangles at
and dimension these
54
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com
10. Click on Features>Extruded Cut 1.0in
and set Direction 1 to
and . Click on View Orientation>Isometric.
Beginner Part 6: Assembly Parts
55
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com
11. Save
the part as Body.
12. Click New,
click Part,
OK.
13. Click Right Plane, insert sketch on plane by click Sketch.
14. Click on Corner Rectangle, origin.
and
Beginner Part 6: Assembly Parts
sketch a rectangle start at
.
56
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com
15. Click Smart Dimension sketch below.
and dimension sketch as
16. Click Centerline and sketch vertical centerline through top edge midpoint to bottom midpoint. Press Esc to end centerline.
Beginner Part 6: Assembly Parts
57
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com
17. Click on Circle,
sketch 3 circles onto centerline and
using Smart Dimension sketched below.
dimension sketch as
18. Click Features>Extruded Boss/Base, set D1 to 0.25in
and
on Direction 1
. Click on View
Orientation>Isometric.
Beginner Part 6: Assembly Parts
58
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com
19. To change part color, right click on Part2>Appearance>Appearance
On Color select Shiny and pick white color.
and 20. Save
the part as Leg.
21. Click New,
Beginner Part 6: Assembly Parts
.
click Part,
OK.
59
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com 22. Click Right Plane, insert sketch on plane by click Sketch.
23. Click on Circle,
Dimension
and sketch a circle. Click Smart
dimension this circle to 0.25in.
24. Click Features>Extruded Boss/Base, set D1 to 0.25in
and
on Direction 1
.
25. Click on right face and click Normal To.
Click on this face again and click Sketch.
Beginner Part 6: Assembly Parts
60
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com
26. Click on Circle,
Dimension
and sketch a circle. Click Smart
dimension this circle to 1.5in.
27. Click Features>Extruded Boss/Base, set D1 to 0.25in
and
on Direction 1
.
28. To change part color, right click on Part3>Appearance>Appearance
Beginner Part 6: Assembly Parts
61
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com
On Color select Standard and pick red color.
and
29. Save
.
the part as Wheel.
30. Click New,
click Part,
OK.
31. Click Right Plane, insert sketch on plane by click Sketch.
Beginner Part 6: Assembly Parts
62
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com
32. Click on Line,
and sketch a horse head.
33. Click on Smart Dimension as sketched below.
and dimension sketch
34. Click Features>Extruded Boss/Base, set D1 to 0.5in
and 35. To change part color, right click on Part4>Appearance>Appearance
Beginner Part 6: Assembly Parts
on Direction 1
.
63
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com
On Color select Shiny and pick white color.
and
36. Save
the part as Head.
37. Click New,
Beginner Part 6: Assembly Parts
.
click Part,
OK.
64
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com 38. Click Right Plane, insert sketch on plane by click Sketch.
39. Click on Line,
and sketch a horse tail.
40. Click on Smart Dimension as sketched below.
Beginner Part 6: Assembly Parts
and dimension sketch
65
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com
41. Click Features>Extruded Boss/Base, set D1 to 0.5in
and 42. To change part color, right click on Part5>Appearance>Appearance
on Direction 1
.
On Color select Shiny and pick white color.
Beginner Part 6: Assembly Parts
66
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com
and
43. Save
.
the part as Tail.
Let’s begin assembly all this parts.
44. Click New, click Assembly, OK. 45. To add part in assembly, Click Browse…
Beginner Part 6: Assembly Parts
67
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com Select Body.sldprt and click Open. Click on workspace.
46. To add leg part, click Insert Components Browse…
Beginner Part 6: Assembly Parts
, click
68
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com Select Leg.sldprt and click Open. Click on workspace.
47. To add wheel part, click Insert Components click Browse…
Beginner Part 6: Assembly Parts
,
69
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com Select Wheel.sldprt and click Open. Click on workspace.
48. Each of this part need to be mate together, click Mate click on body right face
and turn the assembly around (click wheel button and turn model) click on leg inner face.
Beginner Part 6: Assembly Parts
70
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com
Coincident mate already pre selected, click 49. Turn the assembly back to previous view.
Beginner Part 6: Assembly Parts
.
71
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com 50. Click on inner hole face on body and inner hole of leg.
The Concentric mate already pre selected, click this step for bottom hole.
. Repeat
and . 51. Turn the assembly the other way.
Beginner Part 6: Assembly Parts
72
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com 52. Click on wheel shaft face and inner leg hole.
Concentric mate already pre selected, click 53. Click on inner wheel face
.
turn the assembly to left side and click on outer leg face.
Coincident mate already pre selected, click . 54. Repeat step 46 – 53 for other set of legs and wheels.
55. To add head part, click Insert Components click Browse…
Beginner Part 6: Assembly Parts
,
73
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com
Select Head.sldprt and click Open. Click on workspace. To
add tail part, click Insert Components Browse…
, click
Select Tail.sldprt and click Open. Click on workspace.
Beginner Part 6: Assembly Parts
74
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com
56. Click Mate
, click on tail face,
turn assembly the other way, and click on back face cut.
Coincident mate already pre selected, click 57. Click on side face of body cut,
.
turn assembly to left and click on side face of tail,
Beginner Part 6: Assembly Parts
75
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com
Coincident mate already pre selected, click 58. Click on top edge of tail,
.
turn assembly to view top body and click on top face of the body.
Coincident mate already pre selected, click . 59. Turn the model to facing front of the body, click on side face of inner cut,
Beginner Part 6: Assembly Parts
76
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com
turn the assembly to left and click on head side face.
Coincident mate already pre selected, click 60. Click on inner cut face of the body,
.
turn the assembly around and click on back head face.
Beginner Part 6: Assembly Parts
77
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com
Coincident mate already pre selected, click . 61. Turn the assembly to view front side, click on head lower edge,
and click on body bottom inner cut.
Coincident mate already pre selected, click
Beginner Part 6: Assembly Parts
.
78
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com 62. Click View Orientation>Isometric
and you’re done!
63. Save isn’t it?
the assembly as Horse and you’re done! Simple
Go to table of contents Go to beginning of chapter tutorial Go to www.solidworkstutorials.com
Beginner Part 6: Assembly Parts
79
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 7: Detailing Drawing
www.solidworkstutorials.com
Beginner Part 7: Detailing Drawing Once solid parts created we need to transfer it to engineering drawing so the others can understand your parts…
1.
Click New,
click Drawing,
OK.
2.
On Sheet Format/Size select A – Landscape and OK.
3.
Click Browse...
In this tutorial you create drawing for this part.
locate you Block.sldprt (Part from Beginner Part 5: Pattern tutorials)
Beginner Part 7: Detailing Drawing
70
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 7: Detailing Drawing
4.
Beginner Part 7: Detailing Drawing
www.solidworkstutorials.com
Click Open. For Orientation select Top and for Display Style select Hidden Lines Visible,
71
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 7: Detailing Drawing 5.
www.solidworkstutorials.com Click on sheet to add this view,
click again on left side to add side view of the part,
click once more to upper right of sheet to view it’s 3D view.
Beginner Part 7: Detailing Drawing
72
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 7: Detailing Drawing
6.
7.
Beginner Part 7: Detailing Drawing
www.solidworkstutorials.com
Click . Repositions part 3D view to upper right corner of the sheet by dragging it to this location.
There is no centerline for holes in side view, let’s add this centerline, click on side view,
73
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 7: Detailing Drawing
www.solidworkstutorials.com
Click on Annotation tab,
click on Centerline,
centerline automatically added to side view, click
8.
Beginner Part 7: Detailing Drawing
Click Smart Dimension and pull dimension to bottom.
.
and click on bottom edge
74
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 7: Detailing Drawing
9.
www.solidworkstutorials.com
Zoom in, click on center hole edge,
click on counter bore hole edge
and pull dimension to bottom side.
Beginner Part 7: Detailing Drawing
75
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 7: Detailing Drawing
www.solidworkstutorials.com
10. Click on center hole edge,
click on counter bore hole edge
Beginner Part 7: Detailing Drawing
76
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 7: Detailing Drawing
www.solidworkstutorials.com
and pull dimension to bottom side.
11. Repeat step 10 and continue dimension for the third counter bore hole.
Beginner Part 7: Detailing Drawing
77
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 7: Detailing Drawing
www.solidworkstutorials.com
Beginner Part 7: Detailing Drawing
78
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 7: Detailing Drawing
www.solidworkstutorials.com
12. Click on center hole edge,
click on left edge
and pull dimension to bottom side.
Beginner Part 7: Detailing Drawing
79
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 7: Detailing Drawing
www.solidworkstutorials.com
13. Repeat step 12 for right edge.
Beginner Part 7: Detailing Drawing
80
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 7: Detailing Drawing
www.solidworkstutorials.com
14. Click on center hole edge and pull out it’s diameter dimension.
Beginner Part 7: Detailing Drawing
81
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 7: Detailing Drawing
www.solidworkstutorials.com
15. Click on thread diameter and pull out its radius dimension.
Beginner Part 7: Detailing Drawing
82
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 7: Detailing Drawing
www.solidworkstutorials.com
16. Click on center hole edge,
click on counterbore hole edge
and pull it’s dimension to left side.
Beginner Part 7: Detailing Drawing
83
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 7: Detailing Drawing
www.solidworkstutorials.com
17. Click on center hole edge,
click on bottom edge
and pull it’s dimension to left side.
Beginner Part 7: Detailing Drawing
84
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 7: Detailing Drawing
www.solidworkstutorials.com
18. Repeat steps 16 and 17 for top counterbore and top edge.
19. Click
to end Smart Dimension. Click on Annotation tab,
click on Hole Callout.
Click on counterbore hole
and pull out its hole callout to right side.
Beginner Part 7: Detailing Drawing
85
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 7: Detailing Drawing
www.solidworkstutorials.com
20. Click on thread
and pull out its hole callout to right side.
Click
Beginner Part 7: Detailing Drawing
to end hole callout annotation.
86
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 7: Detailing Drawing
www.solidworkstutorials.com
21. Click on Sketch tab,
Click on Centerline, sketch a centerline thru center of Block. Point (hover your cursor) to midpoint of left edge (don’t click),
move you cursor to left side,
now click on sheet and click again on right side.
Press Esc to end centerline.
Beginner Part 7: Detailing Drawing
87
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 7: Detailing Drawing
www.solidworkstutorials.com
22. Click on centerline,
click on View Layout tab,
click on Section View, check Flip Direction
on section Line option,
and click on sheet for this section view.
Beginner Part 7: Detailing Drawing
88
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 7: Detailing Drawing
www.solidworkstutorials.com
23. You can customize each view how it’s appear on drawing by changing it’s display style. Click on Section A-A view,
on Display Style click on Hidden Line Removed.
Click
Beginner Part 7: Detailing Drawing
. Your section view now changed.
89
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 7: Detailing Drawing
www.solidworkstutorials.com
24. Click on 3D view,
on Display Style click on Shaded With Edges.
To change it’s scale, under Scale click on Use custom scale, set to 1:3
and
Beginner Part 7: Detailing Drawing
.
90
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 7: Detailing Drawing
www.solidworkstutorials.com
25. Save it?
the drawing as Block and you’re done! Simple isn’t
Go to table of contents Go to beginning of chapter tutorial Go to www.solidworkstutorials.com
Beginner Part 7: Detailing Drawing
91
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Foreword The main objective of these tutorials is to give you a kick start using SolidWorks. The approach to write this tutorial is based on what is the most important knowledge you should know and what is commonly tool used. You will learn step by step by working on it. These tutorials will teach you the basic skills of using Solidworks in your daily design works. Even this tutorials didn’t have full explanations of tools that Solidworks have but don’t worry you will master it along the way, as I did. If you have any questions about these tutorials, drop your mail to [email protected]
Solidworks 2010 Tutorials: Beginner http://www.solidworkstutorials.com ©2010 solidworkstutorials.com , All rights reserved. This publication is copyright under the solidworkstutorials.com All rights reserved. Apart from any fair dealing for the purpose of private study, research, criticism, or review, as permitted under the Copyright Designs and Patents Act 1988, no part may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, electrical, chemical, mechanical, photocopying, recording or otherwise, without the prior permission of the copyright owners. Unlicensed multiple copying of this publication is illegal. Inquiries should be addressed to: [email protected] If this guide is distributed with software that includes an end- agreement, this guide, as well as the software described in it, is furnished under license and may be used or copied only in accordance with the of such license. Except as permitted by any such license, no part of this guide may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, recording, or otherwise, without the prior written permission of solidworkstutorials.com. Please note that the content in this guide is protected under copyright law even if it is not distributed with software that includes an end- license agreement. The content of this guide is furnished for informational use only, is subject to change without notice, and should not be construed as a commitment by solidworkstutorials.com. Solidworkstutorials.com assumes no responsibility or liability for any errors or inaccuracies that may appear in the informational content contained in this guide. Please that existing artwork or images that you may want to include in your project may be protected under copyright law. The unauthorized incorporation of such material into your new work could be a violation of the rights of the copyright owner. Please be sure to obtain any permission required from the copyright owner. Any references to company names in sample templates are for demonstration purposes only and are not intended to refer to any actual organization. The publishers are not responsible for any statement made in this publication. Data, discussion, and conclusions developed by the Author are for information only and are not intended for use without independent substantiating investigation on the part of the potential s. Opinions expressed are those of the Author and are not necessarily those of the Institution of Mechanical Engineers or its publishers.
i
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Solidworks Tutorials: Beginner Table of contents
www.solidworkstutorials.com
Table of contents Beginner Part 1: My First Solid … … … … 1 The big picture how SolidWorks works, it starts with a simple editable sketch. From this sketch a feature build the solid. From this solid it produces drawing... Beginner Part 2: Sketching … … … Sketch is the base of your part, it’s a good practice to master sketching in SolidWorks...
… 10
Beginner Part 3: Turning Parts … … … … 23 Some parts such as pins and shafts can be manufacture by turning process on lathe machine, we can create turning part by revolving it sketch on it axis... Beginner Part 4: Hole Wizard … … … … 30 Hole Wizard is used for creating predefined and standard holes such as counter bore hole, counter sunk hole, screw clearance hole and many more... Beginner Part 5: Pattern … … … … 40 Pattern (or some called array) is used to repeat features in linear arrangement or circular arrangement. It’s good to know how to optimize these tool, it help you make your part faster and easier... Beginner Part 6: Assembly Parts … … … 60 Assembly is a part of design process, it show how all designed parts work together as a single unit... Beginner Part 7: Detailing Drawing … … … 80 Once solid parts created we need to transfer it to engineering drawing so the others can understand your parts…
Solidworks Tutorials: Beginner Table of contents
ii
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 1: My First Solid
www.solidworkstutorials.com
Beginner Part 1: My First Solid The big picture how SolidWorks works, it starts with a simple editable sketch. From this sketch a feature build the solid. From this solid it produces drawing... Let’s begin your first solid...
1.
Click New
2.
Click Front Plane, insert sketch on plane by click Sketch.
In this tutorial you will make this 3. bracket, start from sketch and build features.
4.
Beginner Part 1: My First Solid
Click Sketch
, click Part
, OK.
, click
Corner Rectangular . Start first point at origin and click another point at top right side.
Click Smart Dimension , click top edge set dimension to 3in and click right edge set dimension to 2in.
1
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 1: My First Solid
www.solidworkstutorials.com
5.
Beginner Part 1: My First Solid
To build features, click Extruded Boss/Base
, set D1 to
0.10in
.
and
2
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 1: My First Solid
www.solidworkstutorials.com 6.
Click on front face of the part, click Normal To.
7.
Click Circle
, sketch circle on face
.
Click Smart Dimension , click circle edge and set diameter to 0.6in. For circle positioning click circle edge and vertical part edge set to 0.5in. Click circle edge again and click horizontal part edge set to 0.5in.
Beginner Part 1: My First Solid
3
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 1: My First Solid
www.solidworkstutorials.com
8.
Click Extruded Cut
All
Beginner Part 1: My First Solid
, change Direction 1 to Through
and
.
4
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 1: My First Solid
www.solidworkstutorials.com 9.
Click on front face and select Sketch
. Select Corner Rectangular top right edge to center.
10. Click Smart Dimension dimension to 2in and 1in.
Beginner Part 1: My First Solid
sketch rectangular from
, set rectangular
5
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 1: My First Solid
www.solidworkstutorials.com
Click Extruded Cut
and select Through All
and
.
11. Click on front face and select Sketch
. Click Corner Rectangular and sketch rectangular start form bottom left edge to right edge.
Beginner Part 1: My First Solid
6
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 1: My First Solid
www.solidworkstutorials.com
Click Smart Dimension and set rectangular height to 0.1in.
12. Click Extruded Boss/Base
Style and select Isometric.
Beginner Part 1: My First Solid
set Direction 1 to 0.5in
and
. Click Display
7
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 1: My First Solid
www.solidworkstutorials.com
13. Click Fillet
, check Full preview
add fillet to all edges
Beginner Part 1: My First Solid
8
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 1: My First Solid
www.solidworkstutorials.com
and
.
14. Save it?
the part as Bracket and you’re done! Simple isn’t
Go to table of contents Go to beginning of chapter tutorial Go to www.solidworkstutorials.com
Beginner Part 1: My First Solid
9
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 2: Sketching
www.solidworkstutorials.com
Beginner Part 2: Sketching Sketch is the base of your part, it’s a good practice to master sketching in SolidWorks...
1.
Click New
2.
Click Front Plane, insert sketch on plane by click Sketch.
3.
Click Sketch
, click Part
, OK.
In this tutorial you will make this box, start from sketch and build features. You’ll learn how to use sketch tools to build this part.
, click
Corner Rectangular . Start first point at origin and click another point at top right side.
4.
Beginner Part 2: Sketching
Click Smart Dimension , click top edge set dimension to 2in and click right edge set dimension to 2in.
10
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 2: Sketching
www.solidworkstutorials.com 5.
To build features, click Features>Extruded Boss/Base
, set D1 to 0.50in
and
Beginner Part 2: Sketching
.
11
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 2: Sketching
Beginner Part 2: Sketching
www.solidworkstutorials.com 6.
Click on front face of the part, click Normal To.
7.
Click on front face and click Sketch.
12
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 2: Sketching
www.solidworkstutorials.com
8.
Click Offset Entities
, set to 0.1in and check
Reverse box
9.
Beginner Part 2: Sketching
Click Extruded Cut
and
.
, change D1 to 0.4in.
13
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 2: Sketching
www.solidworkstutorials.com 10. Click on side face, click Sketch.
11. While pressing Ctrl key select inner left and right edge.
Click
Convert Entities
.
12. Select Centerline from line menu , sketch a centerline midpoint to midpoint of both converted
Beginner Part 2: Sketching
14
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 2: Sketching
www.solidworkstutorials.com
edges. 13. Click sketched centerline
and click Offset Entities.
Beginner Part 2: Sketching
15
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 2: Sketching
www.solidworkstutorials.com
Set Parameter, D to 0.3in check Bi-directional and
.
14. Now click Trim Entities to remove excess line, before make any cut make sure under option Trim to
closest is selected. Trim extra line as below sketch. Answers Yes if notification appear.
15. Click View Orientation>Isometric.
16. Click Features>Extruded Boss/Base , for Direction 1, click Reverse Direction (green box) and set D1 to 0.1in.
Beginner Part 2: Sketching
16
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 2: Sketching
www.solidworkstutorials.com
and
Beginner Part 2: Sketching
.
17
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 2: Sketching
www.solidworkstutorials.com 17. Click on front face and click Normal To.
18. Click on front face and click Sketch.
Beginner Part 2: Sketching
18
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 2: Sketching
www.solidworkstutorials.com
19. Click Circle,
sketch circle at left edge.
20. Click Smart Dimension, below sketch.
21. Click on sketched circle,
Copy Entities.
Beginner Part 2: Sketching
dimension sketch as
click
Set delta x
19
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 2: Sketching
www.solidworkstutorials.com
to 0.3in
and
.
22. Click Centerline, sketch centerline across front face and make sure it starts at midpoint left edge and midpoint right edge and
.
23. While press Ctrl key, select both sketched circle and click Mirror Entities , on Mirror Option click Mirror about: box, and select centerline
Beginner Part 2: Sketching
20
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 2: Sketching
www.solidworkstutorials.com
and 24. Click Extruded Cut,
and set D1 to 0.1in
25. Click View Orientation>Back,
Beginner Part 2: Sketching
.
and
.
21
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 2: Sketching
www.solidworkstutorials.com and click on back face and click Sketch.
26. Click Sketch>Circle,
sketch circle at lower left edge.
Click Smart
Dimension sketch below.
and dimension sketched circle as
and
Beginner Part 2: Sketching
.
22
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 2: Sketching
www.solidworkstutorials.com
27. Click on sketched circle,
and click
Linear Sketch Pattern and on Direction 1 set D1 to 1.2in and on Direction 2, change # to 2 and set D2 to 1.2in and
Beginner Part 2: Sketching
.
23
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 2: Sketching
www.solidworkstutorials.com
28. Click Features>Extruded Cut,
and set direction to
Through All Click View Orientation>Isometric.
29. Save it?
and
.
the part as Sketch and you’re done! Simple isn’t
Go to table of contents Go to beginning of chapter tutorial Go to www.solidworkstutorials.com
Beginner Part 2: Sketching
24
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 3: Turning Part
www.solidworkstutorials.com
Beginner Part 3: Turning Part Some parts such as pins and shafts can be manufacture by turning process on lathe machine, we can create turning part by revolving it sketch on it axis...
In this tutorial you will make this pin, start from sketch and build solid body by revolve it sketch on axis. You’ll learn how to use revolved boss/base and revolved cut to build this part.
1.
Click New,
click Part,
OK.
2.
Click Front Plane, insert sketch on plane by click Sketch.
3.
Click on Line, sketch a closed loop start at origin, sketch as sketch below end back at origin.
and
4.
Click Smart Dimension sketch below.
and 5.
Beginner Part 3: Turning Part
and dimension sketch as
.
Click Features>Revolved Boss/Base, and click on bottom line as it axis.
25
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 3: Turning Part
www.solidworkstutorials.com
and
6.
Beginner Part 3: Turning Part
.
Click View Orientation>Front and click Front Plane and click Sketch.
26
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 3: Turning Part
www.solidworkstutorials.com
7.
Click Corner Rectangle, and sketch rectangle overlap on solid body as sketched below.
and
.
8.
Click Smart Dimension sketched below.
9.
To view solid body axis, click View>Temporary Axes.
and dimension sketch as
10. To make second undercut, click Features>Revolved Cut and select temporary axes as it axis
Beginner Part 3: Turning Part
27
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 3: Turning Part
www.solidworkstutorials.com
and
Beginner Part 3: Turning Part
.
28
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 3: Turning Part
www.solidworkstutorials.com 11. To hide temporary axes, click View>Temporary Axes.
12. Save
the part and you’re done! Simple isn’t it?
Go to table of contents Go to beginning of chapter tutorial Go to www.solidworkstutorials.com
Beginner Part 3: Turning Part
29
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 4: Hole Wizard
www.solidworkstutorials.com
Beginner Part 4: Hole Wizard Hole Wizard is used for creating predefined and standard holes such as counter bore hole, counter sunk hole, screw clearance hole and many more...
In this tutorial you will add counterbore, countersink and tap holes to this plate by using Hole Wizard tools.
1.
Click New,
2.
Click Top Plane, insert sketch on plane by click Sketch.
3.
Click on Corner Rectangle, origin.
and
4.
Beginner Part 4: Hole Wizard
OK.
sketch a rectangle start at
.
Click Smart Dimension sketch below.
and 5.
click Part,
and dimension sketch as
.
Click Features>Extruded Boss/Base, set D1 to 1in
on Direction 1
30
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 4: Hole Wizard
www.solidworkstutorials.com
6.
7.
Beginner Part 4: Hole Wizard
and . Click on top face and click Normal To.
Click Features>Hole Wizard on Hole Type, select Counterbore, Standard to Ansi Inch, Type to Socket Head Cap Screw, Size to #10, Fit to Normal and End Condition to Through All.
31
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 4: Hole Wizard
www.solidworkstutorials.com
For positions placement for this counterbore hole, click on Positions tab. more positions at each edge.
Beginner Part 4: Hole Wizard
Now click three
32
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 4: Hole Wizard
www.solidworkstutorials.com
8.
Click on Smart Dimensions, click on center point of counterbore hole and click left edge, set dimension to 0.5in.
Continue dimensioning as sketched below.
9.
and . For adding countersink at center, click on top face and click on Hole Wizard
Beginner Part 4: Hole Wizard
.
33
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 4: Hole Wizard
www.solidworkstutorials.com
On Hole Type, select Countersink, Standard to Ansi Inch, Type to Flat Head Screw (100), Size to #10, Fit to Normal and End Condition to Through All. 10. For positions placement for this countersink holes, click on Positions tab. more positions at center.
Beginner Part 4: Hole Wizard
Now click three
34
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 4: Hole Wizard
www.solidworkstutorials.com
11. Click on Smart Dimensions, click on center point of countersink hole and click left edge, set dimension to 2.5in.
Continue dimensioning as sketched below.
and . 12. For adding center tap hole, click on top face at center and click Hole Wizard.
Beginner Part 4: Hole Wizard
35
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 4: Hole Wizard
www.solidworkstutorials.com
On Hole Type, select Tap, Standard to Ansi Inch, Type to Tapped hole, Size to 1/2-13, End Condition to Through All. 13. For positions placement for this tap hole, click on Positions tab. There is another style to positions hole wizard is define it position by sketch, let try it.
Click on Centerline, Sketch a horizontal line start at midpoint of left edge to midpoint left
Beginner Part 4: Hole Wizard
36
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 4: Hole Wizard
www.solidworkstutorials.com edge. Press Esc to end sketch centerline.
14. Click and drag tap center to midpoint of centerline.
and . 15. Click View Orientation>Isometric. Done.
Beginner Part 4: Hole Wizard
37
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 4: Hole Wizard
www.solidworkstutorials.com
16. Save
the part as Plate1 and you’re done! Simple isn’t it?
Go to table of contents Go to beginning of chapter tutorial Go to www.solidworkstutorials.com
Beginner Part 4: Hole Wizard
38
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 5: Pattern
www.solidworkstutorials.com
Beginner Part 5: Pattern Pattern (or some called array) is used to repeat features in linear arrangement or circular arrangement. It’s good to know how to optimize these tool, it help you make your part faster and easier...
1. In this tutorial you will add multiple 2. features as linear pattern and circular pattern using pattern tools.
3.
Click New,
Click on Corner Rectangle, origin.
Beginner Part 5: Pattern
sketch a rectangle start at
.
Click Smart Dimension sketch below.
and 5.
OK.
Click Top Plane, insert sketch on plane by click Sketch.
and
4.
click Part,
and dimension sketch as
.
Click Features>Extruded Boss/Base, set D1 to 1in
on Direction 1
39
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 5: Pattern
Beginner Part 5: Pattern
www.solidworkstutorials.com
6.
and . Click on top face and click Normal To.
7.
Click on top face and click Sketch.
40
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 5: Pattern
www.solidworkstutorials.com
Click on Circle
and sketch a circle on top face and
8.
Click on Smart Dimension sketched circle as sketch below.
9.
Click Features>Extruded Cut
Through All.
.
and dimension
on Direction 1 set to
and
.
10. Click Features>Hole Wizard on Hole Type, select Counterbore, Standard to Ansi Inch, Type to Socket Head Cap Screw, Size to #10, Fit to Normal and End Condition to Through All.
Beginner Part 5: Pattern
41
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 5: Pattern
www.solidworkstutorials.com
For positions placement for this counterbore hole, click on Positions tab. at lower left edge.
Beginner Part 5: Pattern
Click one point
42
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 5: Pattern
www.solidworkstutorials.com
11. Click on Smart Dimension sketched circle as sketch below.
and
and dimension
.
12. To pattern this counterbore hole, click on CBORE for #10 Socket Head Cap Screw1
and click Linear Pattern. Direction 1 pattern.
Beginner Part 5: Pattern
Click on bottom edge as
43
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 5: Pattern
www.solidworkstutorials.com
Set D1 to 2.5in and pattern # to 3. Click on highlighted arrow to switch it directions.
13. Click on left edge as Direction 2 pattern.
Set D2 to 3.4in and number of pattern # to 2. You can click
Beginner Part 5: Pattern
44
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 5: Pattern
www.solidworkstutorials.com on arrow to switch it directions.
and
.
14. Click on top face and click Sketch.
Click on Circle,
Beginner Part 5: Pattern
sketch a circle with center to open hole.
45
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 5: Pattern
www.solidworkstutorials.com
Click Smart Dimension, 1.5in.
set circle diameter to
15. Click Line, sketch a vertical line crossing sketch circle at 12 o’clock to 6 o’clock.
Press Esc key to end Line. Exit sketch. 16. Click on Hole Wizard, on Hole Type click on Tap, Standard: Ansi Inch, Type: Tapped Hole, Hole Specifications Size:1/4-20, End Condition Through All.
Beginner Part 5: Pattern
46
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 5: Pattern
www.solidworkstutorials.com
For positions placement for this tap hole, click on Positions tab. o’clock last sketched circle.
Beginner Part 5: Pattern
Click one point at 12
47
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 5: Pattern
www.solidworkstutorials.com
and
.
17. To hide guide sketch, click Sketch4 and click Hide.
18. To pattern tap hole, click on 1/4-20 Tapped Hole1
and click Circular Pattern.
Change view to isometric by click on View Orientation>Isometric
Click on open inner hole face as it’s pattern axis, set instances # to 6 and
Beginner Part 5: Pattern
.
48
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 5: Pattern
www.solidworkstutorials.com
19. Save
the part as Block and you’re done! Simple isn’t it?
Go to table of contents Go to beginning of chapter tutorial Go to www.solidworkstutorials.com
Beginner Part 5: Pattern
49
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com
Beginner Part 6: Assembly Parts Assembly is a part of design process, it show how all designed parts work together as a single unit. ...
1.
Click New,
click Part,
OK.
2.
Click Front Plane, insert sketch on plane by click Sketch.
3.
Click on Corner Rectangle, origin.
In this tutorial you will create this toy horse by assembly parts to one unit assembly.
and
4.
5.
Beginner Part 6: Assembly Parts
.
Click Smart Dimension sketch below.
and
sketch a rectangle start at
and dimension sketch as
.
Click Features>Extruded Boss/Base, set D1 to 4in
on Direction 1
50
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com
6.
Beginner Part 6: Assembly Parts
and . Click on right face and click Normal To.
51
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com 7.
Click on right face again and click Sketch.
Click on Circle
and sketch 4 circle at each corner. Click
on Smart Dimension sketched below.
8.
Click on Features>Extruded Cut
Through All on View OrientationIsometric.
Beginner Part 6: Assembly Parts
and dimension sketch as
and set Direction 1 to
and
. Click
52
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com
9.
Click on top face and click Normal To.
Click on top face again and click Sketch.
Beginner Part 6: Assembly Parts
53
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com
Click on Corner Rectangle top and bottom.
Click on Smart Dimension rectangles as sketched below.
Beginner Part 6: Assembly Parts
and sketch 2 rectangles at
and dimension these
54
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com
10. Click on Features>Extruded Cut 1.0in
and set Direction 1 to
and . Click on View Orientation>Isometric.
Beginner Part 6: Assembly Parts
55
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com
11. Save
the part as Body.
12. Click New,
click Part,
OK.
13. Click Right Plane, insert sketch on plane by click Sketch.
14. Click on Corner Rectangle, origin.
and
Beginner Part 6: Assembly Parts
sketch a rectangle start at
.
56
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com
15. Click Smart Dimension sketch below.
and dimension sketch as
16. Click Centerline and sketch vertical centerline through top edge midpoint to bottom midpoint. Press Esc to end centerline.
Beginner Part 6: Assembly Parts
57
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com
17. Click on Circle,
sketch 3 circles onto centerline and
using Smart Dimension sketched below.
dimension sketch as
18. Click Features>Extruded Boss/Base, set D1 to 0.25in
and
on Direction 1
. Click on View
Orientation>Isometric.
Beginner Part 6: Assembly Parts
58
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com
19. To change part color, right click on Part2>Appearance>Appearance
On Color select Shiny and pick white color.
and 20. Save
the part as Leg.
21. Click New,
Beginner Part 6: Assembly Parts
.
click Part,
OK.
59
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com 22. Click Right Plane, insert sketch on plane by click Sketch.
23. Click on Circle,
Dimension
and sketch a circle. Click Smart
dimension this circle to 0.25in.
24. Click Features>Extruded Boss/Base, set D1 to 0.25in
and
on Direction 1
.
25. Click on right face and click Normal To.
Click on this face again and click Sketch.
Beginner Part 6: Assembly Parts
60
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com
26. Click on Circle,
Dimension
and sketch a circle. Click Smart
dimension this circle to 1.5in.
27. Click Features>Extruded Boss/Base, set D1 to 0.25in
and
on Direction 1
.
28. To change part color, right click on Part3>Appearance>Appearance
Beginner Part 6: Assembly Parts
61
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com
On Color select Standard and pick red color.
and
29. Save
.
the part as Wheel.
30. Click New,
click Part,
OK.
31. Click Right Plane, insert sketch on plane by click Sketch.
Beginner Part 6: Assembly Parts
62
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com
32. Click on Line,
and sketch a horse head.
33. Click on Smart Dimension as sketched below.
and dimension sketch
34. Click Features>Extruded Boss/Base, set D1 to 0.5in
and 35. To change part color, right click on Part4>Appearance>Appearance
Beginner Part 6: Assembly Parts
on Direction 1
.
63
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com
On Color select Shiny and pick white color.
and
36. Save
the part as Head.
37. Click New,
Beginner Part 6: Assembly Parts
.
click Part,
OK.
64
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com 38. Click Right Plane, insert sketch on plane by click Sketch.
39. Click on Line,
and sketch a horse tail.
40. Click on Smart Dimension as sketched below.
Beginner Part 6: Assembly Parts
and dimension sketch
65
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com
41. Click Features>Extruded Boss/Base, set D1 to 0.5in
and 42. To change part color, right click on Part5>Appearance>Appearance
on Direction 1
.
On Color select Shiny and pick white color.
Beginner Part 6: Assembly Parts
66
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com
and
43. Save
.
the part as Tail.
Let’s begin assembly all this parts.
44. Click New, click Assembly, OK. 45. To add part in assembly, Click Browse…
Beginner Part 6: Assembly Parts
67
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com Select Body.sldprt and click Open. Click on workspace.
46. To add leg part, click Insert Components Browse…
Beginner Part 6: Assembly Parts
, click
68
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com Select Leg.sldprt and click Open. Click on workspace.
47. To add wheel part, click Insert Components click Browse…
Beginner Part 6: Assembly Parts
,
69
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com Select Wheel.sldprt and click Open. Click on workspace.
48. Each of this part need to be mate together, click Mate click on body right face
and turn the assembly around (click wheel button and turn model) click on leg inner face.
Beginner Part 6: Assembly Parts
70
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com
Coincident mate already pre selected, click 49. Turn the assembly back to previous view.
Beginner Part 6: Assembly Parts
.
71
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com 50. Click on inner hole face on body and inner hole of leg.
The Concentric mate already pre selected, click this step for bottom hole.
. Repeat
and . 51. Turn the assembly the other way.
Beginner Part 6: Assembly Parts
72
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com 52. Click on wheel shaft face and inner leg hole.
Concentric mate already pre selected, click 53. Click on inner wheel face
.
turn the assembly to left side and click on outer leg face.
Coincident mate already pre selected, click . 54. Repeat step 46 – 53 for other set of legs and wheels.
55. To add head part, click Insert Components click Browse…
Beginner Part 6: Assembly Parts
,
73
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com
Select Head.sldprt and click Open. Click on workspace. To
add tail part, click Insert Components Browse…
, click
Select Tail.sldprt and click Open. Click on workspace.
Beginner Part 6: Assembly Parts
74
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com
56. Click Mate
, click on tail face,
turn assembly the other way, and click on back face cut.
Coincident mate already pre selected, click 57. Click on side face of body cut,
.
turn assembly to left and click on side face of tail,
Beginner Part 6: Assembly Parts
75
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com
Coincident mate already pre selected, click 58. Click on top edge of tail,
.
turn assembly to view top body and click on top face of the body.
Coincident mate already pre selected, click . 59. Turn the model to facing front of the body, click on side face of inner cut,
Beginner Part 6: Assembly Parts
76
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com
turn the assembly to left and click on head side face.
Coincident mate already pre selected, click 60. Click on inner cut face of the body,
.
turn the assembly around and click on back head face.
Beginner Part 6: Assembly Parts
77
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com
Coincident mate already pre selected, click . 61. Turn the assembly to view front side, click on head lower edge,
and click on body bottom inner cut.
Coincident mate already pre selected, click
Beginner Part 6: Assembly Parts
.
78
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 6: Assembly Parts
www.solidworkstutorials.com 62. Click View Orientation>Isometric
and you’re done!
63. Save isn’t it?
the assembly as Horse and you’re done! Simple
Go to table of contents Go to beginning of chapter tutorial Go to www.solidworkstutorials.com
Beginner Part 6: Assembly Parts
79
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 7: Detailing Drawing
www.solidworkstutorials.com
Beginner Part 7: Detailing Drawing Once solid parts created we need to transfer it to engineering drawing so the others can understand your parts…
1.
Click New,
click Drawing,
OK.
2.
On Sheet Format/Size select A – Landscape and OK.
3.
Click Browse...
In this tutorial you create drawing for this part.
locate you Block.sldprt (Part from Beginner Part 5: Pattern tutorials)
Beginner Part 7: Detailing Drawing
70
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 7: Detailing Drawing
4.
Beginner Part 7: Detailing Drawing
www.solidworkstutorials.com
Click Open. For Orientation select Top and for Display Style select Hidden Lines Visible,
71
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 7: Detailing Drawing 5.
www.solidworkstutorials.com Click on sheet to add this view,
click again on left side to add side view of the part,
click once more to upper right of sheet to view it’s 3D view.
Beginner Part 7: Detailing Drawing
72
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 7: Detailing Drawing
6.
7.
Beginner Part 7: Detailing Drawing
www.solidworkstutorials.com
Click . Repositions part 3D view to upper right corner of the sheet by dragging it to this location.
There is no centerline for holes in side view, let’s add this centerline, click on side view,
73
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 7: Detailing Drawing
www.solidworkstutorials.com
Click on Annotation tab,
click on Centerline,
centerline automatically added to side view, click
8.
Beginner Part 7: Detailing Drawing
Click Smart Dimension and pull dimension to bottom.
.
and click on bottom edge
74
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 7: Detailing Drawing
9.
www.solidworkstutorials.com
Zoom in, click on center hole edge,
click on counter bore hole edge
and pull dimension to bottom side.
Beginner Part 7: Detailing Drawing
75
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 7: Detailing Drawing
www.solidworkstutorials.com
10. Click on center hole edge,
click on counter bore hole edge
Beginner Part 7: Detailing Drawing
76
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 7: Detailing Drawing
www.solidworkstutorials.com
and pull dimension to bottom side.
11. Repeat step 10 and continue dimension for the third counter bore hole.
Beginner Part 7: Detailing Drawing
77
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 7: Detailing Drawing
www.solidworkstutorials.com
Beginner Part 7: Detailing Drawing
78
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 7: Detailing Drawing
www.solidworkstutorials.com
12. Click on center hole edge,
click on left edge
and pull dimension to bottom side.
Beginner Part 7: Detailing Drawing
79
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 7: Detailing Drawing
www.solidworkstutorials.com
13. Repeat step 12 for right edge.
Beginner Part 7: Detailing Drawing
80
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 7: Detailing Drawing
www.solidworkstutorials.com
14. Click on center hole edge and pull out it’s diameter dimension.
Beginner Part 7: Detailing Drawing
81
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 7: Detailing Drawing
www.solidworkstutorials.com
15. Click on thread diameter and pull out its radius dimension.
Beginner Part 7: Detailing Drawing
82
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 7: Detailing Drawing
www.solidworkstutorials.com
16. Click on center hole edge,
click on counterbore hole edge
and pull it’s dimension to left side.
Beginner Part 7: Detailing Drawing
83
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 7: Detailing Drawing
www.solidworkstutorials.com
17. Click on center hole edge,
click on bottom edge
and pull it’s dimension to left side.
Beginner Part 7: Detailing Drawing
84
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 7: Detailing Drawing
www.solidworkstutorials.com
18. Repeat steps 16 and 17 for top counterbore and top edge.
19. Click
to end Smart Dimension. Click on Annotation tab,
click on Hole Callout.
Click on counterbore hole
and pull out its hole callout to right side.
Beginner Part 7: Detailing Drawing
85
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 7: Detailing Drawing
www.solidworkstutorials.com
20. Click on thread
and pull out its hole callout to right side.
Click
Beginner Part 7: Detailing Drawing
to end hole callout annotation.
86
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 7: Detailing Drawing
www.solidworkstutorials.com
21. Click on Sketch tab,
Click on Centerline, sketch a centerline thru center of Block. Point (hover your cursor) to midpoint of left edge (don’t click),
move you cursor to left side,
now click on sheet and click again on right side.
Press Esc to end centerline.
Beginner Part 7: Detailing Drawing
87
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 7: Detailing Drawing
www.solidworkstutorials.com
22. Click on centerline,
click on View Layout tab,
click on Section View, check Flip Direction
on section Line option,
and click on sheet for this section view.
Beginner Part 7: Detailing Drawing
88
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 7: Detailing Drawing
www.solidworkstutorials.com
23. You can customize each view how it’s appear on drawing by changing it’s display style. Click on Section A-A view,
on Display Style click on Hidden Line Removed.
Click
Beginner Part 7: Detailing Drawing
. Your section view now changed.
89
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 7: Detailing Drawing
www.solidworkstutorials.com
24. Click on 3D view,
on Display Style click on Shaded With Edges.
To change it’s scale, under Scale click on Use custom scale, set to 1:3
and
Beginner Part 7: Detailing Drawing
.
90
Buyer: muhammad rodhy ([email protected]) Transaction ID: 1XA19981EN783182K
Beginner Part 7: Detailing Drawing
www.solidworkstutorials.com
25. Save it?
the drawing as Block and you’re done! Simple isn’t
Go to table of contents Go to beginning of chapter tutorial Go to www.solidworkstutorials.com
Beginner Part 7: Detailing Drawing
91
Related Documents 2w1qw
Solidworks Tutorial For Beginner q5u4w
November 2019 99
Xaml Tutorial For Beginner 4c684e
November 2019 58
Tutorial Solidworks 3z545b
December 2020 0
Solidworks Simulation Tutorial 4iz1w
December 2019 120
Solidworks Sheet Metal Tutorial 2f5h2v
November 2019 121
