Shimano 105 5700 Rear Derailleur Installation Manual e312c

SHIMANO 105 Rear Derailleur (10-speed) Silver Version (Short Cage/Long Cage)

7

8 9 10 11

SHIMANO CODE NO.

DESCRIPTION

Y5XH98010 Y55625080 Y5XH98020 Y5XH98030 Y5X998020 Y5UC14000 Y5VG14000 Y5VG15000 Y5XH98130 Y5XH98140 Y5XH98150 Y5XH98160 Y5XH98120 Y5XH08000 Y5VG09300 Y5V598140

B-Axle Assembly B-Tension Adjusting Screw (M4 x 13.5) Cable Fixing Bolt (M5 x 8.5) & Plate Cable Adjusting Bolt Unit Stroke Adjusting Screws (M4 x 11.5) & Plate P-Seal Ring P-Tension Spring (SS-type) P-Tension Spring (GS-type) Outer Plate & Plate Stopper Pin (Silver/SS-type) for RD-5700-A-S-SS Outer Plate & Plate Stopper Pin (Black/SS-type) for RD-5700-A-L-SS Outer Plate & Plate Stopper Pin (Silver/GS-type) for RD-5700-A-S-GS Outer Plate & Plate Stopper Pin (Black/GS-type) for RD-5700-A-L-GS Tension & Guide Pulley Set Inner Plate (SS-type) Inner Plate (GS-type) Pulley Bolt 12.5mm (2 pcs.)

A: Same parts. B: Parts are usable, but differ in materials, appearance, finish, size, etc. Absence of mark indicates non-interchangeability.

Specifications are subject to change without notice.

RD

RD ITEM NO. 1 2 3 4 5 6

- 57 00

Black Version (Short Cage/Long Cage)

- 67 00

RD-5700-A-S (SS/GS) RD-5700-A-L (SS/GS)

INTERCHANGEABILITY B A A A

A A A A A A A A

A A A

A A Apr.-2011-3285

© Shimano Inc. A

SI-5XN0A-001-00

General Safety Information

In order to realize the best performance, we recommend that the following combination be used. 105

Series

WARNING “Maintenance interval depends on the usage and riding circumstances. Clean regularly the chain with an appropriate chaincleaner. Never use alkali based or acid based solvents such as rust cleaners. If those solvent be used chain might break and cause serious injury.”

• In order to obtain good gear shifting performance, the CN-7901 / 6701 / 5701 / 4601 has a forward side and a reverse side, and the sides are marked so that the CN-7901 / 6701 / 5701 / 4601 will face the correct way when installed. The proper design performance will be obtained when the CN7901 / 6701 / 5701 / 4601 is installed so that it faces the correct way. If it is installed so that it faces the opposite way, the chain may come off and the bicycle may fall over and serious injury may occur as a result. • Use the reinforced connecting pin only for connecting the narrow type of chain. • If connecting pins other than Reinforced reinforced connecting pins are Chain Chain tool connecting pin used, or if a reinforced connecting pin or tool which is 10-speed super narrow with groove (3) TL-CN32 not suitable for the type of chain chain such as TL-CN23 is used, sufficient connection CN-7901 / 6701 / 5701 / TL-CN27 force may not be obtained, 4601 / 7801 / 6600 / 5600 with groove (2) which could cause the chain to break or fall off. • Make sure that the connecting pin is aligned with the outer link surface from the side that the pin is inserted. It should feel smooth and flush when you run your finger over it. The pin will protrude slightly on the backside after the break off pin is removed. • If it is necessary to adjust the length of the chain due to a change in Reinforced Connecting Pin the number of sprocket teeth, make the cut at some other place than the place where the chain has been ed using a reinforced connecting pin. The chain will be damaged if it is cut at a place where it has been ed with a reinforced connecting pin. Link Pin Link Pin • Check that the tension of the chain is correct and that the chain is not damaged. If the tension is too weak or the chain is damaged, the chain should be replaced. If this is not done, the chain may break and cause serious injury. • Obtain and read the service instructions carefully prior to installing the parts. Loose, worn or damaged parts may cause the bicycle to fall over and serious injury may occur as a result. We strongly recommend only using genuine Shimano replacement parts. • Obtain and read the service instructions carefully prior to installing the parts. If adjustments are not carried out correctly, the chain may come off and this may cause you to fall off the bicycle which could result in serious injury. • Read these Technical Service Instructions carefully, and keep them in a safe place for later reference.

TIAGRA

Double Triple Double Triple ST-5700 ST-5703 ST-4600 ST-4603

Shifting lever

10

Gears

For a 28T or more sprocket (SS type only) Add 2 links (with the chain on both the largest sprocket and the largest chainring)

10

Largest sprocket

Largest chainring

Chain

Operate the shifting lever several times to move the chain to the 2nd sprocket. Then, while pressing the lever just enough to take up the play in the lever, turn the crank arm. Play 2

3

+2 links

OT-SP41

Outer casing Rear derailleur

RD-5700-A

Type

SS

Freehub Cassette sprocket

RD-4600 SS

GS

GS

FH-5700

FH-4600

CS-5700

CS-4600

CN-5701 CN-5600 CN-4601 CN-5600

Chain

SM-SP17

Bottom bracket cable guide

SM-SP17

Stroke adjustment and cable securing 1. Top adjustment

Outer line of smallest sprocket

Turn the top adjustment screw to adjust so that the guide pulley is below the outer line of the smallest sprocket when looking from the rear.

Specifications

Lever (A)

When shifting to 3rd

When no sound at all is heard

Tighten the outer casing adjustment barrel until the chain returns to the 2nd sprocket. (clockwise)

Loosen the outer casing adjustment barrel until the chain touches the 3rd sprocket and makes noise. (counter clockwise)

Top adjustment screw Guide pulley

SS

GS

34 teeth or less

39 teeth or less

30 T

30 T

Type Total capacity Largest sprocket

11 T

11 T

16 teeth or less

22 teeth or less

Smallest sprocket Front chainwheel tooth difference

* When using with junior models, use the CS-6600. * The number of teeth on the smallest sprocket for SS-specification rear derailleurs is 15T. * The number of teeth on the smallest sprocket for GS-specification rear derailleurs is 14T. * If using a 52-39-30T front chainwheel, the largest rear sprocket should be 28T.

2. Connection and securing of the cable Connect the cable to the rear derailleur and, after taking up the initial slack in the cable, re-secure to the rear derailleur as shown in the illustration.

Pull

Tightening torque: 6 - 7 N·m {52 - 60 in. lbs.}

Note: Be sure that the cable is securely in the groove.

Installation of the rear derailleur

Outer casing adjustment barrel

When installing, be careful that deformation is not caused by the B-tension adjustment screw coming into with the dropout tab.

Groove Dropout tab

3. Low adjustment Turn the low adjustment screw so that the guide pulley moves to a position directly in line with the largest sprocket.

Largest sprocket

Bracket spindle tightening torque: 8 - 10 N·m {70 - 86 in. lbs.}

Outer casing adjustment barrel

Best setting

5 mm Allen key

Note

• If gear shifting operations cannot be carried out smoothly, clean the derailleur and lubricate all moving parts. • If the amount of looseness in the links is so great that adjustment is not possible, you should replace the derailleur. • You should periodically clean the derailleur and lubricate all moving parts (mechanism and pulleys). • If gear shifting adjustment cannot be carried out, check the degree of parallelism at the rear end of the bicycle. Also check if the cable is lubricated and if the outer casing is too long or too short. • If you hear abnormal noise as a result of looseness in a pulley, you should replace the pulley. • You should periodically wash the sprockets in a neutral detergent and then lubricate them again. In addition, cleaning the chain with neutral detergent and lubricating it can be a effective way of extending the useful life of the sprockets and the chain. • If the chain keeps coming off the sprockets during use, replace the sprockets and the chain. • For smooth operation, use the specified outer casing and the bottom bracket cable guide. • Grease the inner cable and the inside of the outer casing before use to ensure that they slide properly. • Use a frame with internal cable routing is strongly discouraged as it has tendencies to impair the SIS shifting function due to its high cable resistance. • The tension pulley has an arrow on it to indicate the direction of rotation. Install the tension pulley so that the arrow is pointing clockwise when looking at the outer side of the derailleur. • Parts are not guaranteed against natural wear or deterioration resulting from normal use. • For maximum performance we highly recommend Shimano lubricants and maintenance products. • For any questions regarding methods of installation, adjustment, maintenance or operation, please a professional bicycle dealer.

5. SIS Adjustment

B-tension adjustment screw

Guide pulley Low adjustment screw

Chain length

4. How to use the B-tension adjustment screw

Note:

In order to obtain good gear shifting performance, the CN7901 / 6701 / 5701 / 4601 has a forward side and a reverse side, and the sides are marked so that the CN-7901 / 6701 / 5701 / 4601 will face the correct way when installed.

Mount the chain on the smallest chainring and the largest sprocket, and turn the crank arm backward. Then turn the Btension adjustment screw to adjust the guide pulley as close to the sprocket as possible but not so close that it touches. Next, set the chain to the smallest sprocket and repeat the above to make sure that the pulley does not touch the sprocket. Largest sprocket Smallest sprocket

The best setting is when the shifting lever is operated just enough to take up the play and the chain touches the 3rd sprocket and makes noise. * Return the lever to its original position (the position where the lever is at the 2nd sprocket setting and it has been released) and then turn the crank arm clockwise. If the chain is touching the 3rd sprocket and making noise, turn the outer casing adjustment barrel clockwise slightly to tighten it until the noise stops and the chain runs smoothly. Operate lever to change gears, and check that no noise occurs in any of the gear positions. For the best SIS performance, periodically lubricate all power-transmission parts.

■ Replacing the rear derailleur

Forward (outer side) 3 mm Allen key

The side with the mark shown in the illustration is the forward side (outer side).

Reverse (inner side)

SI-5XN0A-001

Smallest sprocket

Technical Service Instructions

Rear derailleur

Largest chainring

● In case of a triple front chainwheel

Guide pulley / Tension pulley Tightening torque : 2.5 - 5.0 N·m {22 - 44 in. lbs.}

Chain

Guide pulley Tension pulley

B-tension adjustment screw

90°

Right angle to the ground

Not OK

OK

One Holland, Irvine, California 92618, U.S.A. Phone: +1-949-951-5003

Industrieweg 24, 8071 CT Nunspeet, The Netherlands Phone: +31-341-272222

3-77 Oimatsu-cho, Sakai-ku, Sakai-shi, Osaka 590-8577, Japan

* Service Instructions in further languages are available at : http://techdocs.shimano.com Please note: specifications are subject to change for improvement without notice. (English) © Jan. 2011 by Shimano Inc. XBC SZK Printed in Japan.
