8100 SERIES
THINK...MERCER FIRST®
MERCER VALVE
MERCER VALVE CO., INC. ® “AUTO SEAT TECHNOLOGY”®
MERCER VALVE COMPANY, INC.® “Auto Seat Technology”®
8100 SERIES SAFETY RELIEF VALVES
8100 Series Product Overview The Mercer Valve 8100 Series Pressure Relief Valve is “State of the Art” in soft seat, high flow rate, pressure relieving devices. The 8100 Series spring operated valve was the first pressure relief valve to incorporate Mercer Valve’s patented “Auto Seat Technology”® into its design. Our “Auto Seat Technology“® incorporates a fully guided disk and low rate spring to ensure an accurate and repeatable set pressure. The low rated, guided spring will reduce stresses on the spring, giving you a consistent, repeatable set pressure, which will continually out last the competition. The soft seated 8100 Series has a field-proven lip seal design, which allows for a tighter seal up to set pressure. This tight seal reduces leaks and limits product loss. Our non-rising stem allows us to produce a valve with a shorter bonnet, which will be lighter and fit in tighter confined spaces. The 8100 Series is manufactured in accordance with the requirements of ASME Boiler and Pressure Vessel Code, Section VIII, Division 1 for Air/Gas. The 8100 Series is well suited for compressors, separators, transmission, gathering lines, and other production processes.
8100 Series Features • Designed with “Auto Seat Technology”®. • Consistent Set Pressures allowing repeatable uses without repair 2 or resetting. • Open, Close, Seat and SealTM. • Fully guided disk keeps the disk properly aligned, opening and closing, helping to reseat the valve. • Mechanical Stop prevents wear on parts and controls valve lift. • Low rated and fully guided spring allows for more consistent set pressures from pop to pop. • Pop Action relief allows valve to go to full lift at set pressure. Helps with DOT regulated applications. • Built in accordance with the requirements of ASME Boiler and Pressure Vessel Code. Sec. VIII Div 1. • Non-rising stems allowing valves to be installed in small areas.
2
www.mercervalve.net · 1.800.833.6402
MERCER VALVE COMPANY, INC.® “Auto Seat Technology”®
8100 SERIES SAFETY RELIEF VALVES
8100 Series Specifications
Basic Valve Size
1/2” Orifice
3/4” Orifice
Inlet Sizes Available
3/4” NPT 1” NPT
1 1/2” NPT 2” NPT
Outlet Sizes Available
1” NPT
2” NPT
Inlet and Outlet Connection Types Available
Male NPT x Female NPT Female NPT x Female NPT
Orifice Diameter
.520 in.
.775 in.
Orifice Area
.212 in2
.472 in2
Equivalent API Letter
E
G
Pressure Ranges
15 to 2400 psi
15 to 2000 psi
Standard Temperature Range
-20ºF to 400ºF
-20ºF to 400ºF
ASME “Slope” (Gas)
3.10
7.21
Equivalent Flow Coefficient (Gas)
.798
.833
Approximate Weight
4.5 lbs.
10.0 lbs.
NOTE: Mercer Valve reserves the right to change product designs and specifications without notice.
www.mercervalve.net · 1.800.833.6402
3
MERCER VALVE COMPANY, INC.® “Auto Seat Technology”®
8100 SERIES SAFETY RELIEF VALVES
8100 Series Parts and Materials
2
8100 Series 1/2” Orifice ITEM NO
PART NAME
STANDARD MATERIALS
1
INLET BASE
CARBON STEEL
2
BASE SEAL
SOFT STEEL
3
NOZZLE O-RING
FLUOROCARBON (FKM)
4
NOZZLE SUBASSEMBLY
STAINLESS STEEL WITH SOFT SEAT
5
DISK SUBASSEMBLY
STAINLESS STEEL
6
BODY SUBASSEMBLY
CARBON STEEL
7
SET SPRING
STAINLESS STEEL
8
ADJUSTMENT SCREW
STAINLESS STEEL
9
ADJUSTMENT BUSHING
CARBON STEEL
10
CENTER BUSHING
CARBON STEEL
11
ADJUSTMENT SCREW O-RING
BUNA N
12
CENTER BUSHING O-RING
BUNA N
13
WASHER
CARBON STEEL
14
LOCKNUT
CARBON STEEL
15
CLOSED CAP
ALUMINUM
NOTE: Mercer Valve reserves the right to change product designs and specifications without notice.
4
www.mercervalve.net · 1.800.833.6402
MERCER VALVE COMPANY, INC.® “Auto Seat Technology”®
8100 SERIES SAFETY RELIEF VALVES
8100 Series 3/4” Orifice ITEM NO
PART NAME
STANDARD MATERIALS
1
INLET BASE
CARBON STEEL
2
BASE SEAL
SOFT STEEL
3
NOZZLE O-RING
FLUOROCARBON (FKM)
4
NOZZLE SUBASSEMBLY
STAINLESS STEEL WITH SOFT SEAT
5
DISK SUBASSEMBLY
STAINLESS STEEL
6
BODY SUBASSEMBLY
CARBON STEEL
7
SET SPRING
STAINLESS STEEL
8
ADJUSTMENT SCREW
STAINLESS STEEL
9
ADJUSTMENT BUSHING
CARBON STEEL
10
CENTER BUSHING
CARBON STEEL
11
CENTER BUSHING O-RING
BUNA N
12
CENTERNUT
CARBON STEEL
13
ADJUSTMENT SCREW O-RING
BUNA N
14
LOCKNUT
CARBON STEEL
15
CLOSED CAP
ALUMINUM
NOTE: Mercer Valve reserves the right to change product designs and specifications without notice.
www.mercervalve.net · 1.800.833.6402
5
MERCER VALVE COMPANY, INC.® “Auto Seat Technology”®
8100 SERIES SAFETY RELIEF VALVES
8100 Series Threaded Dimensions and Weights Inlet and Outlet Code
Inlet and Outlet Size
Orifice Available
Pressure Limit (psi)
Dimensions “A” x “B” x “C” (in ±1/16)
Approx. Weight (lbs)
11
3/4” FNPT x 1” FNPT
1/2”
15 - 2400
2-1/4 x 1-7/8 x 7-1/16
4.5
12
3/4” MNPT x 1” FNPT
1/2”
15 - 2400
3-1/4 x 1-7/8 x 8
4.5
16
1” FNPT x 1” FNPT
1/2”
15 - 2400
3-1/4 x 1-7/8 x 8
5.5
17
1” MNPT x 1” FNPT
1/2”
15 - 2400
3-1/4 x 1-7/8 x 8
4.5
33
1 1/2” FNPT x 2” FNPT
3/4”
15 - 2000
4-5/8 x 2-3/8 x 10-5/16
13
34
1 1/2” MNPT x 2” FNPT
3/4”
15 - 2000
4-7/16 x 2-3/8 x 10-1/16
12
42
2” FNPT x 2” FNPT
3/4”
15 - 2000
4-5/8 x 2-3/8 x 10-5/16
12
43
2” MNPT x 2” FNPT
3/4”
15 - 2000
4-7/16 x 2-3/8 x 10-1/16
12
2
NOTE: Mercer Valve reserves the right to change product designs and specifications without notice.
6
www.mercervalve.net · 1.800.833.6402
MERCER VALVE COMPANY, INC.® “Auto Seat Technology”®
8100 SERIES SAFETY RELIEF VALVES
8100 Series Exploded View ITEM NO
PART NAME
1
CAP
2
LOCKNUT
3
BODY SUBASSEMBLY
4
ADJUSTMENT SCREW O-RING
5
ADJUSTMENT BUSHING
6
ADJUSTMENT SCREW
7
SET SPRING
8
DISK SUBASSEMBLY
9
NOZZLE SUBASSEMBLY
10
NOZZLE O-RING
11
BASE SEAL
12
INLET BASE
NOTE: Mercer Valve reserves the right to change product designs and specifications without notice.
www.mercervalve.net · 1.800.833.6402
7
MERCER VALVE COMPANY, INC.® “Auto Seat Technology”®
8100 SERIES SAFETY RELIEF VALVES
8100 Series Capacity Chart Set Pressure (psi)
8
AIR CAPACITY AT 60ºF AND STD ATMOSPHERIC CONDITIONS SCFM
1/2” Orifice MSCFH MMSCFD
SCFM
3/4” Orifice MSCFH MMSCFD
15
101
6.08
0.15
236
14.15
0.34
20
117
7.01
0.17
272
16.31
0.39
25
132
7.94
0.19
308
18.47
0.44
30
148
8.87
0.21
344
20.64
0.50
50
216
12.96
0.31
503
30.15
0.72
75
301
18.08
0.43
701
42.05
1.01
100
387
23.19
0.56
899
53.95
1.29
125
472
28.31
0.68
1097
65.84
1.58
150
557
33.42
1296
77.74
1.87
200
728
43.65
0.80 2 1.05
1692
101.53
2.44
300
1069
64.11
1.54
2485
149.12
3.58
400
1410
84.57
2.03
3278
196.70
4.72
500
1751
105.03
2.52
4071
244.29
5.86
600
2092
125.49
3.01
4865
291.88
7.01
700
2433
145.95
3.50
5658
339.46
8.15
800
2774
166.41
3.99
6451
387.05
9.29
900
3115
186.87
4.48
7244
434.63
10.43
1000
3456
207.33
4.98
8037
482.22
11.57
1100
3797
227.79
5.47
8830
529.81
12.72
1250
4308
258.48
6.20
10020
601.18
14.43
1500
5161
319.63
7.43
12002
720.15
17.28
2000
6866
411.93
9.89
15968
958.08
22.99
2400
8230
493.77
11.85
www.mercervalve.net · 1.800.833.6402
MERCER VALVE COMPANY, INC.® “Auto Seat Technology”®
8100 SERIES SAFETY RELIEF VALVES
0.6 SG NATURAL GAS CAPACITY AT 60ºF AND STD ATMOSPHERIC CONDITIONS Set Pressure 1/2” Orifice 3/4” Orifice (psi) SCFM MSCFH MMSCFD SCFM MSCFH MMSCFD 15
126
7.59
0.18
294
17.65
0.42
20
146
8.75
0.21
339
20.35
0.49
25
165
9.91
0.24
384
23.04
0.55
30
184
11.07
0.27
429
25.74
0.62
50
270
16.17
0.39
627
37.61
0.90
75
376
22.55
0.54
874
52.45
1.26
100
482
28.93
0.69
1122
67.30
1.62
125
589
35.32
0.85
1369
82.14
1.97
150
695
41.70
1.00
1616
96.98
2.33
200
908
54.46
1.31
2111
126.66
3.04
300
1333
79.98
1.92
3100
186.02
4.46
400
1758
105.50
2.53
4090
245.38
5.89
500
2184
131.03
3.14
5079
304.75
7.31
600
2609
156.55
3.76
6068
364.11
8.74
700
3035
182.07
4.37
7058
423.47
10.16
800
3460
207.60
4.98
8047
482.83
11.59
900
3885
233.12
5.59
9037
542.20
13.01
1000
4311
258.64
6.21
10026
601.56
14.44
1100
4736
284.17
6.82
11015
660.92
15.86
1250
5374
322.45
7.74
12499
749.96
18.00
1500
6438
386.26
9.27
14973
898.37
21.56
2000
8565
513.88
12.33
19920
1195.18
28.68
2400
10266
615.97
14.78
www.mercervalve.net · 1.800.833.6402
9
MERCER VALVE COMPANY, INC.® “Auto Seat Technology”®
8100 SERIES SAFETY RELIEF VALVES
8100 Series Product Numbering System 81
-
17
1
5
1
VALVE SERIES 81 – 8100 Series INLET & OUTLET COMBINATION 11 – 3/4”
FNPT x 1” FNPT
12 – 3/4”
MNPT x 1” FNPT*
16 – 1”
FNPT x 1” FNPT
17 – 1”
MNPT x 1” FNPT*
33 – 1 1/2” FNPT x 2” FNPT 34 – 1 1/2” MNPT x 2” FNPT * 42 – 2”
FNPT x 2” FNPT
43 – 2”
MNPT x 2” FNPT*
2
ORIFICE SIZE 1
– 1/2”
DIAMETER*
2
– 3/4”
DIAMETER*
INLET BASE & BODY MATERIAL 5 – CARBON STEEL/WCB CARBON STEEL* 6 – 316 STNLS STL/WCB CARBON STEEL CAP TYPE 1 – CLOSED CAP* 2 – OPEN LIFT LEVER 3 – CLOSED LIFT LEVER NOTE: Mercer Valve reserves the right to change product designs and specifications without notice.
10
www.mercervalve.net · 1.800.833.6402
MERCER VALVE COMPANY, INC.® “Auto Seat Technology”®
8100 SERIES SAFETY RELIEF VALVES
V
06
G1
1 2 – DIGIT “SPECIAL” CODE (IF APPLICABLE ASSIGNED BY MERCER) O-RING MATERIAL 1 – STANDARD O-RINGS* (FLUOROCARBON (FKM) & BUNA-N) TRIM CODES G1 – GAS SERVICE (15-1225: 1/2” ORIFICE, 15-520: 3/4” ORIFICE)* G2 – GAS SERVICE (1226-2400: 1/2” ORIFICE, 521-2000: 3/4” ORIFICE)* N1 – SOUR GAS SERVICE (15-1225: 1/2” ORIFICE, 15-520: 3/4” ORIFICE)* N2 – SOUR GAS SERVICE (1226-2400: 1/2” ORIFICE, 521-2000: 3/4” ORIFICE)*
SPRING CODE* (ASSIGNED BY MERCER) SEAT MATERIAL V – FLUOROCARBON (FKM) 90 DURO* T – 15% GLASS FILLED PTFE * B – BUNA-N * = STANDARD MATERIALS
P – VIRGIN PEEK*
Consult Factory for Additional Information
www.mercervalve.net · 1.800.833.6402
11
CORPORATE HEADQUARTERS 9609 NW 4th STREET OKLAHOMA CITY, OK 73127 1-800-833-6402 PHONE: (405) 495-6533, FAX: (405) 495-8728 [email protected] Please visit our website to learn about our branch locations!
WWW.MERCERVALVE.NET Mercer Valve Company, Inc.® manufactures pressure relief valves for uses with many different products. Your choice of a valve requires that you, as buyer, determine the valve material is compatible with the intended use of the valve. You are responsible to insure that the correct pressure relief valve is installed for your application and your order of a valve confirms the material compatibility choices.
MVC-81-2
Revision Date 04/18
Supersedes 10/15
THINK...MERCER FIRST®
MERCER VALVE
MERCER VALVE CO., INC. ® “AUTO SEAT TECHNOLOGY”®
MERCER VALVE COMPANY, INC.® “Auto Seat Technology”®
8100 SERIES SAFETY RELIEF VALVES
8100 Series Product Overview The Mercer Valve 8100 Series Pressure Relief Valve is “State of the Art” in soft seat, high flow rate, pressure relieving devices. The 8100 Series spring operated valve was the first pressure relief valve to incorporate Mercer Valve’s patented “Auto Seat Technology”® into its design. Our “Auto Seat Technology“® incorporates a fully guided disk and low rate spring to ensure an accurate and repeatable set pressure. The low rated, guided spring will reduce stresses on the spring, giving you a consistent, repeatable set pressure, which will continually out last the competition. The soft seated 8100 Series has a field-proven lip seal design, which allows for a tighter seal up to set pressure. This tight seal reduces leaks and limits product loss. Our non-rising stem allows us to produce a valve with a shorter bonnet, which will be lighter and fit in tighter confined spaces. The 8100 Series is manufactured in accordance with the requirements of ASME Boiler and Pressure Vessel Code, Section VIII, Division 1 for Air/Gas. The 8100 Series is well suited for compressors, separators, transmission, gathering lines, and other production processes.
8100 Series Features • Designed with “Auto Seat Technology”®. • Consistent Set Pressures allowing repeatable uses without repair 2 or resetting. • Open, Close, Seat and SealTM. • Fully guided disk keeps the disk properly aligned, opening and closing, helping to reseat the valve. • Mechanical Stop prevents wear on parts and controls valve lift. • Low rated and fully guided spring allows for more consistent set pressures from pop to pop. • Pop Action relief allows valve to go to full lift at set pressure. Helps with DOT regulated applications. • Built in accordance with the requirements of ASME Boiler and Pressure Vessel Code. Sec. VIII Div 1. • Non-rising stems allowing valves to be installed in small areas.
2
www.mercervalve.net · 1.800.833.6402
MERCER VALVE COMPANY, INC.® “Auto Seat Technology”®
8100 SERIES SAFETY RELIEF VALVES
8100 Series Specifications
Basic Valve Size
1/2” Orifice
3/4” Orifice
Inlet Sizes Available
3/4” NPT 1” NPT
1 1/2” NPT 2” NPT
Outlet Sizes Available
1” NPT
2” NPT
Inlet and Outlet Connection Types Available
Male NPT x Female NPT Female NPT x Female NPT
Orifice Diameter
.520 in.
.775 in.
Orifice Area
.212 in2
.472 in2
Equivalent API Letter
E
G
Pressure Ranges
15 to 2400 psi
15 to 2000 psi
Standard Temperature Range
-20ºF to 400ºF
-20ºF to 400ºF
ASME “Slope” (Gas)
3.10
7.21
Equivalent Flow Coefficient (Gas)
.798
.833
Approximate Weight
4.5 lbs.
10.0 lbs.
NOTE: Mercer Valve reserves the right to change product designs and specifications without notice.
www.mercervalve.net · 1.800.833.6402
3
MERCER VALVE COMPANY, INC.® “Auto Seat Technology”®
8100 SERIES SAFETY RELIEF VALVES
8100 Series Parts and Materials
2
8100 Series 1/2” Orifice ITEM NO
PART NAME
STANDARD MATERIALS
1
INLET BASE
CARBON STEEL
2
BASE SEAL
SOFT STEEL
3
NOZZLE O-RING
FLUOROCARBON (FKM)
4
NOZZLE SUBASSEMBLY
STAINLESS STEEL WITH SOFT SEAT
5
DISK SUBASSEMBLY
STAINLESS STEEL
6
BODY SUBASSEMBLY
CARBON STEEL
7
SET SPRING
STAINLESS STEEL
8
ADJUSTMENT SCREW
STAINLESS STEEL
9
ADJUSTMENT BUSHING
CARBON STEEL
10
CENTER BUSHING
CARBON STEEL
11
ADJUSTMENT SCREW O-RING
BUNA N
12
CENTER BUSHING O-RING
BUNA N
13
WASHER
CARBON STEEL
14
LOCKNUT
CARBON STEEL
15
CLOSED CAP
ALUMINUM
NOTE: Mercer Valve reserves the right to change product designs and specifications without notice.
4
www.mercervalve.net · 1.800.833.6402
MERCER VALVE COMPANY, INC.® “Auto Seat Technology”®
8100 SERIES SAFETY RELIEF VALVES
8100 Series 3/4” Orifice ITEM NO
PART NAME
STANDARD MATERIALS
1
INLET BASE
CARBON STEEL
2
BASE SEAL
SOFT STEEL
3
NOZZLE O-RING
FLUOROCARBON (FKM)
4
NOZZLE SUBASSEMBLY
STAINLESS STEEL WITH SOFT SEAT
5
DISK SUBASSEMBLY
STAINLESS STEEL
6
BODY SUBASSEMBLY
CARBON STEEL
7
SET SPRING
STAINLESS STEEL
8
ADJUSTMENT SCREW
STAINLESS STEEL
9
ADJUSTMENT BUSHING
CARBON STEEL
10
CENTER BUSHING
CARBON STEEL
11
CENTER BUSHING O-RING
BUNA N
12
CENTERNUT
CARBON STEEL
13
ADJUSTMENT SCREW O-RING
BUNA N
14
LOCKNUT
CARBON STEEL
15
CLOSED CAP
ALUMINUM
NOTE: Mercer Valve reserves the right to change product designs and specifications without notice.
www.mercervalve.net · 1.800.833.6402
5
MERCER VALVE COMPANY, INC.® “Auto Seat Technology”®
8100 SERIES SAFETY RELIEF VALVES
8100 Series Threaded Dimensions and Weights Inlet and Outlet Code
Inlet and Outlet Size
Orifice Available
Pressure Limit (psi)
Dimensions “A” x “B” x “C” (in ±1/16)
Approx. Weight (lbs)
11
3/4” FNPT x 1” FNPT
1/2”
15 - 2400
2-1/4 x 1-7/8 x 7-1/16
4.5
12
3/4” MNPT x 1” FNPT
1/2”
15 - 2400
3-1/4 x 1-7/8 x 8
4.5
16
1” FNPT x 1” FNPT
1/2”
15 - 2400
3-1/4 x 1-7/8 x 8
5.5
17
1” MNPT x 1” FNPT
1/2”
15 - 2400
3-1/4 x 1-7/8 x 8
4.5
33
1 1/2” FNPT x 2” FNPT
3/4”
15 - 2000
4-5/8 x 2-3/8 x 10-5/16
13
34
1 1/2” MNPT x 2” FNPT
3/4”
15 - 2000
4-7/16 x 2-3/8 x 10-1/16
12
42
2” FNPT x 2” FNPT
3/4”
15 - 2000
4-5/8 x 2-3/8 x 10-5/16
12
43
2” MNPT x 2” FNPT
3/4”
15 - 2000
4-7/16 x 2-3/8 x 10-1/16
12
2
NOTE: Mercer Valve reserves the right to change product designs and specifications without notice.
6
www.mercervalve.net · 1.800.833.6402
MERCER VALVE COMPANY, INC.® “Auto Seat Technology”®
8100 SERIES SAFETY RELIEF VALVES
8100 Series Exploded View ITEM NO
PART NAME
1
CAP
2
LOCKNUT
3
BODY SUBASSEMBLY
4
ADJUSTMENT SCREW O-RING
5
ADJUSTMENT BUSHING
6
ADJUSTMENT SCREW
7
SET SPRING
8
DISK SUBASSEMBLY
9
NOZZLE SUBASSEMBLY
10
NOZZLE O-RING
11
BASE SEAL
12
INLET BASE
NOTE: Mercer Valve reserves the right to change product designs and specifications without notice.
www.mercervalve.net · 1.800.833.6402
7
MERCER VALVE COMPANY, INC.® “Auto Seat Technology”®
8100 SERIES SAFETY RELIEF VALVES
8100 Series Capacity Chart Set Pressure (psi)
8
AIR CAPACITY AT 60ºF AND STD ATMOSPHERIC CONDITIONS SCFM
1/2” Orifice MSCFH MMSCFD
SCFM
3/4” Orifice MSCFH MMSCFD
15
101
6.08
0.15
236
14.15
0.34
20
117
7.01
0.17
272
16.31
0.39
25
132
7.94
0.19
308
18.47
0.44
30
148
8.87
0.21
344
20.64
0.50
50
216
12.96
0.31
503
30.15
0.72
75
301
18.08
0.43
701
42.05
1.01
100
387
23.19
0.56
899
53.95
1.29
125
472
28.31
0.68
1097
65.84
1.58
150
557
33.42
1296
77.74
1.87
200
728
43.65
0.80 2 1.05
1692
101.53
2.44
300
1069
64.11
1.54
2485
149.12
3.58
400
1410
84.57
2.03
3278
196.70
4.72
500
1751
105.03
2.52
4071
244.29
5.86
600
2092
125.49
3.01
4865
291.88
7.01
700
2433
145.95
3.50
5658
339.46
8.15
800
2774
166.41
3.99
6451
387.05
9.29
900
3115
186.87
4.48
7244
434.63
10.43
1000
3456
207.33
4.98
8037
482.22
11.57
1100
3797
227.79
5.47
8830
529.81
12.72
1250
4308
258.48
6.20
10020
601.18
14.43
1500
5161
319.63
7.43
12002
720.15
17.28
2000
6866
411.93
9.89
15968
958.08
22.99
2400
8230
493.77
11.85
www.mercervalve.net · 1.800.833.6402
MERCER VALVE COMPANY, INC.® “Auto Seat Technology”®
8100 SERIES SAFETY RELIEF VALVES
0.6 SG NATURAL GAS CAPACITY AT 60ºF AND STD ATMOSPHERIC CONDITIONS Set Pressure 1/2” Orifice 3/4” Orifice (psi) SCFM MSCFH MMSCFD SCFM MSCFH MMSCFD 15
126
7.59
0.18
294
17.65
0.42
20
146
8.75
0.21
339
20.35
0.49
25
165
9.91
0.24
384
23.04
0.55
30
184
11.07
0.27
429
25.74
0.62
50
270
16.17
0.39
627
37.61
0.90
75
376
22.55
0.54
874
52.45
1.26
100
482
28.93
0.69
1122
67.30
1.62
125
589
35.32
0.85
1369
82.14
1.97
150
695
41.70
1.00
1616
96.98
2.33
200
908
54.46
1.31
2111
126.66
3.04
300
1333
79.98
1.92
3100
186.02
4.46
400
1758
105.50
2.53
4090
245.38
5.89
500
2184
131.03
3.14
5079
304.75
7.31
600
2609
156.55
3.76
6068
364.11
8.74
700
3035
182.07
4.37
7058
423.47
10.16
800
3460
207.60
4.98
8047
482.83
11.59
900
3885
233.12
5.59
9037
542.20
13.01
1000
4311
258.64
6.21
10026
601.56
14.44
1100
4736
284.17
6.82
11015
660.92
15.86
1250
5374
322.45
7.74
12499
749.96
18.00
1500
6438
386.26
9.27
14973
898.37
21.56
2000
8565
513.88
12.33
19920
1195.18
28.68
2400
10266
615.97
14.78
www.mercervalve.net · 1.800.833.6402
9
MERCER VALVE COMPANY, INC.® “Auto Seat Technology”®
8100 SERIES SAFETY RELIEF VALVES
8100 Series Product Numbering System 81
-
17
1
5
1
VALVE SERIES 81 – 8100 Series INLET & OUTLET COMBINATION 11 – 3/4”
FNPT x 1” FNPT
12 – 3/4”
MNPT x 1” FNPT*
16 – 1”
FNPT x 1” FNPT
17 – 1”
MNPT x 1” FNPT*
33 – 1 1/2” FNPT x 2” FNPT 34 – 1 1/2” MNPT x 2” FNPT * 42 – 2”
FNPT x 2” FNPT
43 – 2”
MNPT x 2” FNPT*
2
ORIFICE SIZE 1
– 1/2”
DIAMETER*
2
– 3/4”
DIAMETER*
INLET BASE & BODY MATERIAL 5 – CARBON STEEL/WCB CARBON STEEL* 6 – 316 STNLS STL/WCB CARBON STEEL CAP TYPE 1 – CLOSED CAP* 2 – OPEN LIFT LEVER 3 – CLOSED LIFT LEVER NOTE: Mercer Valve reserves the right to change product designs and specifications without notice.
10
www.mercervalve.net · 1.800.833.6402
MERCER VALVE COMPANY, INC.® “Auto Seat Technology”®
8100 SERIES SAFETY RELIEF VALVES
V
06
G1
1 2 – DIGIT “SPECIAL” CODE (IF APPLICABLE ASSIGNED BY MERCER) O-RING MATERIAL 1 – STANDARD O-RINGS* (FLUOROCARBON (FKM) & BUNA-N) TRIM CODES G1 – GAS SERVICE (15-1225: 1/2” ORIFICE, 15-520: 3/4” ORIFICE)* G2 – GAS SERVICE (1226-2400: 1/2” ORIFICE, 521-2000: 3/4” ORIFICE)* N1 – SOUR GAS SERVICE (15-1225: 1/2” ORIFICE, 15-520: 3/4” ORIFICE)* N2 – SOUR GAS SERVICE (1226-2400: 1/2” ORIFICE, 521-2000: 3/4” ORIFICE)*
SPRING CODE* (ASSIGNED BY MERCER) SEAT MATERIAL V – FLUOROCARBON (FKM) 90 DURO* T – 15% GLASS FILLED PTFE * B – BUNA-N * = STANDARD MATERIALS
P – VIRGIN PEEK*
Consult Factory for Additional Information
www.mercervalve.net · 1.800.833.6402
11
CORPORATE HEADQUARTERS 9609 NW 4th STREET OKLAHOMA CITY, OK 73127 1-800-833-6402 PHONE: (405) 495-6533, FAX: (405) 495-8728 [email protected] Please visit our website to learn about our branch locations!
WWW.MERCERVALVE.NET Mercer Valve Company, Inc.® manufactures pressure relief valves for uses with many different products. Your choice of a valve requires that you, as buyer, determine the valve material is compatible with the intended use of the valve. You are responsible to insure that the correct pressure relief valve is installed for your application and your order of a valve confirms the material compatibility choices.
MVC-81-2
Revision Date 04/18
Supersedes 10/15
Related Documents 2w1qw
Mercer Valve 8100 1i55p
December 2019 74
Mercer Spring Operated Relief Valve Sizing V4.99 2z5r35
December 2019 46
Mercer Pilot Operated Relief Valve Sizing V5.1 3m5n1b
December 2019 57
Armorseal 8100 6q4d9
August 2021 0
8100-9 5a4v2r
November 2022 0
Mercer Talentsim 5p4h4c
December 2019 37More Documents from "yaneth" 172i1j
Ensayo Teoria Del Conocimiento 285k54
September 2021 0
Guia De Estudio De Quimica.docx d224w
April 2020 28
Tarea 3 - Mkt el Lanzamiento Zico 5f6y15
November 2020 0
504uu
May 2021 0
Mercer Valve 8100 1i55p
December 2019 74
