[JOHN DEERE PARTS CATALOG] 1
Pricing – Freight – Returns PRICES ARE SUBJECT TO CHANGE WITHOUT NOTICE Payment:
We accept Visa, MasterCard, Discover and American Express. UPS fee for COD shipments is $10.00. This does not include the shipping charges.
Freight policy:
Effective January 1, 2010 Order values of $2,750.00 or more (new parts only for JD & Yanmar) will be freight PREPAID, Eastern & Central time zones. Pacific and Western time zones are PREPAID on order values of $3,750.00 or more. The title of the product, and inherent risk of loss, will transfer to the customer upon shipment from our warehouse. Claims for product damages or lost in transit are the responsibility of the buyer and should be filed with the carrier immediately. All returns must be authorized by Fredricks Importing, Inc. and must be in good condition. Used or installed parts will not be accepted. Parts must be returned within 30 days of purchase and be PREPAID. Returned goods subject to 25% handling charge. Returns including cores must be totally assembled. Disassembled items will not be accepted. Cores must be in condition to be rebuilt. Electrical parts are not returnable.
Returned goods:
NOTE: OEM part numbers are used for identification and reference only.
2
PARTS for JOHN DEERE Headlights and Bulbs LB-4155
Head light bulb 850, 950, 1050, 1250, 1450, 1650 Repl. CH11439
LB-4262
Head light bulb 650, 750 Repl. CH15208
HL-4201
Head light assembly 650, 750 Repl. CH18025
HL-4145
Head light assembly 850, 950, 1050 1250, 1450, 1650 Repl. CH11323
Turn Signal Switch TSS-4080
Turn signal switch 670, 770 Repl. M805412
TSS-4080
Turn signal switch 850, 950, 1050 Will repl. M800365 by removing bullet type wire connecters & replace with ring, hook or spade terminals
Fender lights FL-4150
Fender light, two bolt mount, 1-3/4” center, amber lens
FL-4440
Fender light, post mount, amber lens (approx. 2-1/4” dia.)
FL-6012
Fender light, post mount, amber lens (approx. 3-1/4” dia.)
ALTERNATOR AL-1215
Alternator, 12V – 15 Amp, 650, 750
Repl. MIA10312 (old # CH15587) AL-1235
Alternator, 12V – Fits: 850, 950, 1050, 1250, 1450 Repl: TY6647, CH10493
3
Voltage Regulator VR-550
Voltage regulator, 6-plug 850, 950, 1050, 1250, 1450, 1650 Repl. CH12806
VR-522
Voltage regulator, 6-plug 650, 750 Repl. M802471 (old # CH15589)
VR-150
Voltage regulator – 20 amp 670, 770, 870, 970, 1070; F915 Commercial Mower; 322, 330, 332 Garden Tractors Repl. AM101406
Ignition Switch IS-52110
Ignition switch 650, 750, 850, 950, 1050 Repl. CH11696
IK-5216
Ignition (double cut flat steel) KEY only for IS-52110 Repl. CH12206
Indicator Lamp Assembly ILA-4151
Indicator lamp assembly 850, 950, 1050 Repl. CH11893
Hour Meter Cable HMC-4167
Hour meter cable 655, 755 Repl. AM875587 Approx. 48” long
HMC-4275
Hour meter cable 650, 670, 750, 770, 850, 855, 950, 955, 1050 Repl. CH12241 (old # AM875588) Approx. 54-1/2” long
Dash Board DBP-8595
Dash board early 850 & early 950 Repl. AM878226 (old # CH12257)
DBP-1050
Dash board with fuel gauge opening 850, 950, 1050 Repl. CH19206
4
Model
Part # Standard
Replaces Standard
Part # .010
Replaces .25 under
Part # .030 .75 under
CH15398 AM876251 CH15399 AM876252
MB-152A MB-355A MB-555A RB-55A
CH17660 AM876249 CH17661 AM876250
MB-152C MB-355C MB-555C RB-55C
MB-152 MB-255 MB-355 MB-555 RB-55
CH15398 AM876257 AM876251 CH15399 AM876252
MB-152A MB-255A MB-355A MB-555A RB-55A
CH17660 AM876258 AM876249 CH17661 AM876250
MB-152C MB-255C MB-355C MB-555C RB-55C
MB-516 MB-315 MB-215 MB-516 RB-16
CH10338 AM875925 AM875926 CH10338 AM875927
MB-516A MB-315A MB-215A MB-516A RB-16A
CH17665 AM875931 AM875932 CH17665 AM875933
MB-516C MB-315C MB-215C MB-516C RB-16C
MB-525 MB-225 MB-325 MB-425 RB-45
CH20066 AM875929 AM875928 CH20067 AM875930
MB-525A MB-225A MB-325A MB-425A RB-45A
CH17673 AM875936 AM875935 CH17675 AM875937
MB-525C MB-225C MB-325C MB-425C RB-45C
MB-9150A RB-9150A
AM875374 AM875395
MB-9150C RB-9150C
650 Front main MB-152 Center main - flanged MB-355 Rear main MB-555 Rod bearing RB-55 750 Front main 2nd main 3rd main - flanged Rear main Rod bearing 850 Front main 2nd main 3rd main - flanged Rear main Rod bearing 950 / 1050 Front main 2nd main 3rd main - flanged Rear main Rod bearing
770 / 790 / 870 / 955 / 970 / 1070 / 3320 / 3520 / 4300 / 4310 / 4500 / 4600 / 4700 Main bearing MB-9150 AM875371 Rod bearing - JD3203 RB-9150 AM875392
TB-150
Thrust bearing set (2 pieces) 770, 790 w/3TNE84, 870, 955, 970, 1070, 3120, 3203, 3320, 3520, 4300, 4310, 4500, 4600, 4700 Repl. AM875373 & MIA880555 NOTE: Order 2 for one engine
5
PILOT BUSHINGS PB-4450
Pilot bushing 650, 670, 750, 770, 790, 850, 950 Repl. CH10408
Connecting Rod w/ piston pin bushing CR-215
Connecting rod w/ bushing 850 Repl. CH10682
CR-375
Connecting rod w/ bushing 650, 750 Repl. CH15609
CR-384
Connecting rod w/ bushing 950, 1050 Repl. CH10683
CR-9150
Connecting rod w/ bushing 770, 870, 955, 970, 1070, 4500, 4600, 4700 Repl. AM875391
Piston Pin Bushing PPB-4060
Piston pin bushing 650, 750 Repl. M808605 (old # CH15482)
PPB-4160
Piston pin bushing 850 Repl. CH10357
PPB-4450
Piston pin bushing 950, 1050 Repl. M806859
PPB-9100
Piston pin bushing 770, 870, 955, 970, 1070, 4300, 4500, 4600, 4700 Repl. M801256
Crankshaft CS-380
Crankshaft w/keys 850 Repl. CH10659
CS-384
Crankshaft w/keys 950, 1050 Repl. CH20055
6
CS-3154
FRONT CRANKSHAFT SEALS Front crank seal 850, 950, 1050 Repl. CH10390
CS-1450
Front crank seal 650, 750 Repl. CH15390
CS-9795
Front crank seal 770, 790, 855, 870, 955, 970, 990, 1070, 4200, 4300, 4310, 4400, 4410, 4500, 4510, 4600, 4610, 4700, 4710 Repl. M800988
CS-1250
REAR CRANKSHAFT SEALS Rear crank seal 950, 1050 Repl. CH10191
CS-1551
Rear crank seal 650, 750 Repl. CH15402
CS-4085
Rear crank seal 655, 670, 755, JD 2210, 2305, 2320, 4100 Repl. M801941 (old # M87809)
CS-4160
Rear crank seal 850 Repl. CH10340
CS-9120
Rear crank seal 770, 790, 870, 955, 970, 990, 1070, 2520, 3120, 3203, 3320, 3520, 3720, 4200, 4300, 4310, 4400, 4410, 4500, 4510, 4600, 4610, 4700, 4710 Repl. M805278
WS-80
Wet sleeve w/o’rings 850 Repl. CH13597
OR-1300
O’ring for WS-80 Repl. CH10327
WS-90
Wet sleeve w/o’rings 950 Repl. CH13598
OR-1000
O’ring for WS-90 Repl. CH16109
7
EP-1567 RS-520
Piston w/ pin & clips 650, 750 Repl. CH15479 (80mm) Ring set – STD. 650, 750 Repl. CH15608 (80mm)
EP-1567A RS-520A
0.25mm OS piston w/ pin & clips 650, 750 Repl. CH15622 0.25mm OS ring set 650, 750 Repl. CH15621
EP-1567B RS-520B
0.50mm OS piston w/ pin & clips 650, 750 0.50mm OS ring set 650 750
EP-4160 RS-300
Piston w/ pin & clips 850 Repl. CH10355 (80mm) Ring set 850 Repl. CH12046
EP-4763 RS-763
Piston w/ pin & clips 950 Repl. CH11803 (90mm) Ring set 950 Repl. CH12053
RS-350
Ring set, STD 870, 1070 Repl. AM877273 (84mm)
RS-350A
Ring set, 0.25 mm OS 870, 1070 Repl. AM877294
RS-350B
Ring set, 0.50 mm OS 870, 1070 Repl. AM878245
RS-351
Ring set, STD 770, 970 Repl. AM875390 (82mm)
RS-351A
Ring set, 0.25 mm OS 770, 970 Repl. AM875394
RS-351B
Ring set, 0.50 mm OS 770, 970 Repl. AM878243
FOR JD 1050 Must purchase EP-4763 piston and RS-763 ring set together as our ring set does NOT have the keystone type top ring.
8
Head Gasket HG-650
Head gasket 650 (2T80UJ eng) Repl. MIU10631 (old # M802217)
HG-655
Head gasket 655 Repl. M800004 (old # M801790)
HG-567
Head gasket 750 Repl. M802218 (old # CH15372)
HG-755
Head gasket 670, 755 Repl. M807297 (old # M87853 & M805694)
HG-156
Head gasket 770 Repl. M805831
HG-150
Head gasket 850 Repl. MIU800109 (old # CH10115)
HG-865
Head gasket 855, 856 Repl. M805845
HG-157
Head gasket 870, 955 Repl. M805837 (old # M804333)
HG-950
Head gasket 950, 1050 thru engine SN 089472 Repl. M808712
HG-970
Head gasket 970 Repl. M805849 (old # M801187)
HG-1070
Head gasket 1070 Repl. M805850 (old # M804334)
Valve Cover Gasket VCG-650
Valve cover gasket 650 Repl. CH15429
VCG-1550
Valve cover gasket 750 Repl. CH15431
VCG-1150
Valve cover gasket 850 Repl. CH10129
VCG-1250
Valve cover gasket 950, 1050 Repl. CH13884
VCG-9150
Valve cover gasket 790, 870, 955, 4300 Repl. M801741
VCG-9550
Valve cover gasket 970, 1070, 4500, 4600, 4700 Repl. M801230
9
Front Cover Gasket FCG-4450
Front cover gasket 850, 950, 1050 Repl. CH12819
FCG-1450
Front cover gasket 650, 750 Repl. CH15386
Main Bearing Housing Gasket MBHG-4160 Main brg housing gasket 850 Repl. CH10339 MBHG-4460 Main brg housing gasket 950, 1050 Repl. CH10445 MBHG-9150 Main brg housing gasket 770, 855, 856, 870, 955, 970, 1070 Repl. M801204 OR-1350
Main brg housing O-ring 650, 750 Repl. CH15404
10
Oil Pan Gaskets OPG-1150
Oil pan gasket 850 Repl. M811637 & CH12820
OPG-1250
Oil pan gasket 950, 1050 Repl. M811638 & CH12821
OPG-1575
Oil pan gasket 750 Repl. M806944 (old # CH15376)
OPG-650
Oil pan gasket 650 Repl. M810522 (old # CH15375)
OPG-1730
Oil pan gasket (UPPER) 955, 970, 1070 (4)
OPG-9550
Oil pan gasket (LOWER) 955, 970, 1070 (5)
Oil Pumps OP-1423
Oil pump 850, 950, 1050 Repl. CH20064
OPG-3202
Oil pump gasket for OP-1423 applications Repl. CH10414
OP-9350
Oil pump 650, 750 Repl. CH15617
OPG-1450
Gasket for OP-9350 oil pump Repl. CH15492
OP-9553
Oil pump: Compact Utility Tractors 3036E, 3038E, 3520, 3720, 4105 Repl. RG60604
OPG-9150
Gasket for OP-9553 Repl. M801005
Oil Pressure Sending Switch OP-39450
Oil pressure sending switch 650, 750 Repl. CH15500
Oil Filter OF-4085
Oil filter, spin-on – 3.75” tall 650, 750, 850, 855, 856, 950, 1050 Repl. M801002
Air Filters AF-2276
Air filter w/fin125 & 170 Skid Steer Loaders Repl. AH19847; 850, 950, 1050 & Excavators 25, 30, 50 Repl. CH12767
AF-6270
Air filter w/fin 650, 655, 750, 756 Repl. CH15451
11
Valve Train Parts IV-1218
Valve, intake 850 Repl. CH10055
EV-1218
Valve, exhaust 850 Repl. CH10056
IV-1422
Intake valve 1050 before SN 11,000 Repl. CH15724
EV-1422
Exhaust valve 1050 Repl. CH15725
IV-4600
Valve, intake 950 Repl. CH10094
EV-4600
Valve, exhaust 950 Repl. CH10095
IV-9100
Valve, intake 770, 870, 955, 970, 1070, 4300, 4500 4600 Repl. M801220
EV-9100
Valve, exhaust 770, 870, 970, 1070, 4300, 4400, 4500, 4600 Repl. M811796 (old # M801221)
IG-1180
Guide, intake 650, 750; Intake & Exhaust 855, 856, 4200, 4300, 4400 Repl. CH16041
EG-1181
Guide, exhaust 650, 750 Repl. CH16042
IG-4160
Guide, intake 850 Repl. CH16043
EG-4160
Guide, exhaust 850 Repl. CH16044
IG-4450
Guide, intake 770, 790, 870, 950, 955, 970, 1050, 1070, 4300, 4500, 4600, 4700 Repl. M801227 (old # CH16045)
EG-4450
Guide, exhaust 950, 1050 Repl. CH19595 (old # CH16046) 770, 790, 870, 955, 970, 1070, 4300, 4500, 4600, 4700 Repl. M801228
VS-4460
Valve stem seal, intake & exhaust 950, 1050; Intake only 770, 790, 870, 955, 970, 1070, 4300, 4500, 4600, 4700 Repl. CH10450
VS-1400
Valve stem seal, exhaust 770, 790, 870, 970, 1070, 4300, 4500, 4600, 4700 Repl. T110650
VS-4160
Valve stem seal, intake & exhaust 650, 670, 750, 755, 756, 850, 855, 856, 2210, 4200, 4300, 4400 Repl. CH10346 (old # CH15432)
VS-4211
Valve spring 850 Repl. CH10086
VS-4060
Valve spring 650, 750 Repl. CH15417
VS-4511
Valve spring 950, 1050 Repl. CH10093
VS-9795
Valve spring 770, 790, 870, 955, 970, 1070, 4300, 4500, 4600, 4700 Repl. M801222
12
Water Pumps WP-2000
Water pump 850, 950, 1050 Repl. CH12859
WPG-2000
Gasket water pump to back plate 850, 950 1050 Repl. CH10490
WPG-4450
Gasket, back plate to head 850, 950, 1050 Repl. CH10420
WP-4201
Water pump 650, 750 Repl. CH15502
WPG-1450
Gasket, water pump to back plate 650, 750 Repl. CH15506
WPG-4441
Gasket, back plate to head 650, 750 Repl. CH15508
WPP-4235
Water pump pulley 850, 950, 1050 Repl. CH10491
WP-9107
Water Pump, 770, 790, 870, 970, 990, 1070 Repl: AM881340, M805843, M876341
Radiator Cooling Fan CF-4474
Fan 650 Repl. CH15515; 655, 670, 750 Repl. CH16048
Thermostat HT-9350
Thermostat 650, 670, 750, 755, 850, 950, 1050 Repl. CH15536
TG-9350
Gasket, thermostat 650, 670, 750, 755, 850, 950, 1050 Repl. M805702 (old # CH16026)
13
Temperature sending switch TS-44901
Temp sending switch for tractors w/warning light 650, 655, 750, 755, 850, 855, 950, 955, 1050 Repl. CH15516
FB-35
Fan belt 650, 750 Repl. CH18206
FB-36
Fan belt 850 before SN 007760 Repl. CH10154
FB-39
Fan belt 850 SN 007761 & up Repl. CH14022
FB-37
Fan belt 950 before SN 010859 Repl. CH10367
FB-40
Fan belt 950 SN 010860 & up, 1050 Repl. CH12865; 870, 970, 1070 Repl. M808685 (old # M802627)
FB-38
Fan belt 855, 856 Repl. M805441
FB-40
Fan belt 770, 870, 970, 1070 Repl. M808685 (old # M802627)
Fan Belts
14
Radiator Hoses RH-4902
Lower radiator hose 650, 750 Repl. CH15529
RH-4903
By hose 650, 750 Repl. CH15530
RH-4761
Upper radiator hose 650, 750 Repl. CH15528
RH-9150
Lower radiator hose 770, 790 Repl. M802634
RH-1150
By hose 850 -007760 Repl. CH10159
RH-4460
Upper radiator hose 850 sn 007761Repl. CH13960 (old # CH14029)
RH-336
Upper radiator hose 850 -007760 Repl. CH11773
RH-4761
Lower radiator hose 850 Repl. CH14030
RH-1254
Lower radiator hose 950 –010859 Repl CH10310
RH-3810
Lower radiator hose 950 SN 010860-020000 Repl. CH14034
RH-1250
By hose 950 –010859 Repl. CH10270
RH-1252
By hose 950 sn 010860 & up, 1050 Repl. CH13628
RH-4460
Upper radiator hose 950 sn 010860 - 020000 Repl. CH13960 (old # CH14033); sn 020001 & up Repl. CH19298
RH-4460
Upper radiator hose1050 Repl. CH13960 (old # CH14029)
RH-1252
By hose1050 Repl. CH13628
OFT-4450
Round over-flow tank w/cap 850, 870, 950, 970, 990 -590000 sn, 1050, 1070 Repl. CH12866; 670, 770 Repl CH15518
RA-4450
Radiator 850 Repl. CH19293 (old # CH14024)
Radiator Drain Cock Assembly RD-1250
Drain cock (3 way) assembly 850, 950, 1050 Repl. CH10272
15
16
Manifolds, Muffler & Gaskets EM-1158
Exhaust Manifold 850 Repl. CH12069
MG-150
Manifold to head gasket, 850 Repl. CH10142 (3 required)
MG-1250
Manifold to head gasket, 950, 1050 Repl. CH10224 (3 required)
EM-1258
Exhaust Manifold 950 Repl. CH12068
MA-250
Muffler with elbow, mounting flange and pipe 650, 750, 850, 950, 1050 Repl. M802472
WC-3
Weather cap for 1-3/4” pipe Fits MA-250
MG-1450
Muffler to manifold gasket 650, 750, 850, 950, 1050 Repl. CH10403 & CH15915 755, 855 SN-009184 Repl. M805706
MG-1550
Gasket, manifold to head 750 Repl. M806016 (old # CH15458)
MG-9150
Gasket, manifold to head 870, 955, 970, 1070, 3320, 3520 Repl. M801746
GLOW PLUG GP-778
Glow plug 670, Compact Utility Models: 2210 Repl. AT110814 THERMOSTART PLUG
TE-4450
Thermostart plug 850, 900HC, 950, 1050 Repl. CH14079; (1) 650, 750 Repl. CH15593
TE-766
Adaptor for TE-4450 Repl. CH10459 (2) THERMOSTART TANK
HT-1750
Thermostart tank assembly 650, 750, 850, 950, 1050 Repl. CH11796
17
Injector pump IP-390
Injection Pump 850 / 950 / 1050 Repl. CH10679
IP-375
Injection Pump 750
IP-200
Injection Pump 650
Injector parts IA-4060
Injector assembly 650, 750 Repl. CH15620 (1)
IA-4160
Injector assembly 850 Repl. CH12411
IA-4770
Injector assembly 950, 1050 Repl. CH10685 (1)
IN-4770
Injector nozzle 650, 750, 850, 950, 1050 Repl. CH10499 (marked YDN-4SK1 6F)
IW-3854
Fuel Injection Valve Insulator 650, 750, 850, (1) 950, 1050 Repl. CH10072
GW-1550
Chamber gasket 650, 750 Repl. CH15436 (2)
GW-3288
Chamber gasket 850 Repl. CH10062
GW-4900
Chamber gasket 950, 1050 Repl. CH10099
IC-1550
Injector chamber, rear 650, 750 Repl. CH15434 (3)
IC-1400
Injector chamber, front 650, 750 Repl. CH15435 (4)
IC-1141
Injector chamber, rear 950, 1050 Repl. CH11763 (3)
IC-4450
Injector chamber, front 950 Repl. CH16008
IC-4400
Inj. chamber, rear 850 Repl. CH10092
(3)
IC-4160
Inj. chamber, front 850 Repl. CH14169
(4)
(1)
(2) (2)
(4)
18
Fuel System Parts TC-5504
Fuel tank cap (Metal) 1050 Repl. AM875877
TC-155
Fuel tank cap (Plastic) 850, 950, 1050 Repl. CH20242 (old # CH17086)
FT-32
Fuel tank 1050 Repl. CH13281
P-4060
Fuel bleeder plug Repl. CH10319
PG-3418
Gasket for P-4060 Repl. CH10558 (10)
FB-1
Fuel bowl 650, 670, 750, 870, 970, 990, (2) 1070 Repl. CH15552
OR-4321
O-ring for FB-1 fuel bowl Repl. CH10060 (3)
FF-3262
Fuel filter, 2.717” tall, 650, 670, 750, 4115 (1) Repl. CH15553
FF-3263
Fuel filter, 3.49” tall, 655, 755, 770, 850, (1) 855, 950, 1050, 4210, 4310, 4400 Repl. M801101
(5)
(Old # CH10479) FF-3507
Fuel filter, 3.50” tall, 1.969” OD 870, 955, (1) 970, 1070 Repl. T111383
FB-9155
Fuel bowl 870, 955, 970, 1070 (2) Repl. T111383
OR-650
O-ring for FB-9155 fuel bowl Repl. CH17154
TV-4200
Taper valve for fuel shutoff 650, 750, 770, (6) 850, 870, 950, 970, 1050, 1070 Repl. CH12734
H-5534
Fuel shutoff handle 650, 750, 850, 950, (7) 1050, 1250, 1450, 1650 Repl. CH12735
TVS-553
Taper valve spring 850, 870, 950, 970, 1050, 1070 Repl. CH10082
OR-240
O’ring for H-5534 handle Repl. CH10571 (4)
FBH-552
Fuel bowl head 850, 950, 1050 (12)
(3)
(9)
Repl. CH12792 FBR-250
Fuel bowl retainer ring 650, 655, 670, 750, 755, 770, 850, 855, (14) 870, 950, 970, 990, 1050, 1070, 1250, 1450, 1650, 4115 Repl. CH10106
19
FBR-556
Fuel bowl retainer ring for FB-9155 fuel bowl (14) Repl. T111382
20
Steering Parts
SW-150
Steering wheel 650, 750 Repl. M119181
SC-2500
Steering shaft 850, 950 (A) Repl. CH11175 (bearings not included)
SB-4145
Steering shaft bearing 850, 870, 950, (B) 970, 1050 Repl. CH11171
SC-1550
Steering shaft 650, 750 Repl. CH14731 (A) (bearings not included)
WK-519
Strg shaft woodruff key 650, 750 Repl. 26M4226
SB-750
Steering shaft bearing 650, 670, 750, (B) 770, 790 Repl. CH14732
SCB-4740
Steering column bushing 850, 950 Repl. CH11456 (2)
SCG-42
Steering column grommet 650, 750, 850, 950, (5) 1050 Repl. CH13854
SSS-4310
Steering sector shaft 650, 750 Repl. AM119584 (Old # CH14733)
26x38x7TC
Seal, steering sector shaft 650, 670, 750, 770 Repl. CH14736
SCB-1511
Lower housing 650, 750 Repl. CH14730
SC-1515
Strg box side cover 650, 750 Repl. CH14735 (10)
SBS-4080
Seal, steering housing 850 (-16000 sn), (5) 950 (-20000 sn) Repl. CH10813
(8)
21
JB-1500
Fitting, Power steering banjo bolt 1050 Repl. CH16844 (1)
PG-3414
Copper packing for JB-1500 Repl. CH11548 (2)
TIE ROD ENDS
DC-4730
Dust cover, ball t, common to most models Repl. CH11448
TR-1812
Tie rod end LH thread for right side 655, 670, 755, (B) 770, 850, 855, 955 Repl. AM878082
TR-1813
Tie rod end RH thread for left side 655, 670, 755, 770, 850, 855, 955 Repl. AM878081
TR-4150
Tie rod end (long) 650, 750 Repl. AM875955 (C)
TR-8290
Tie rod end (short) 650, 750 Repl. AM878080 (A) (Old # CH14551 & AM875953)
(A)
22
FRONT WHEELS FW-4100
Rim, 3 x 12 front (4 bolt) 650 Repl. CH14565
FW-4145
Rim, 4 x 16 front (6 bolt) 950, 970, 1050, 1070 Repl. CH11166
FW-4279
Rim, 5 x 16 (6 bolt) 870, 970 Repl. AM877153 950, 1050 Repl. CH13187
FW-4362
Rim, 5 x 14 (6 bolt) 750 Repl. CH14724
FW-8351
Rim, 5 x 14 front (6 bolt) 850 w/4wd Repl. CH19748
23
FH-4151
FRONT AXLE PARTS Hub 650 Repl. CH14554
Two wheel drive models
APB-4145
Bushing, spindle 1250 Repl. CH11134; 1450, 1650 Repl. CH13298 (6)
SB-4464
Bushing, spindle 670, 750, 770, 850, 870, 950, 970, (6) 1050, 1070 Repl. CH13301
SB-4440
Bushing, pivot pin 650, 670, 770, 790, 3005 Repl. CH14531 (9)
APB-4145
Bushing, pivot pin 850, 870, 950, 970, 990, (9) 1050 Repl. CH13928 (old # M805921)
51105
Bearing, spindle 650 Repl. CH14542 (11)
51106
Bearing, spindle 670, 750, 770, 850, 870, 950, 970, (11) 1050, 1070 Repl. CH11827
35x48x10TC
Seal, spindle 650 Repl. CH14541 (12)
38x52x9TC
Seal, spindle 670, 770, 850, 870, 950, 970, 1050, (12) 1070 Repl CH11143
35x52x11TC
Seal hub 650 Repl. CH14557 (15)
AS-4314
Seal, hub 670, 770, 790 Repl. M802819 (15)
40x62x19TC
Seal, hub 750, 850, 870, 950, 970, 990, 1050, 1070 (15) Repl. CH10879
30206
Bearing, outer, front hub, 2 wheel drive 1250, (19) 1450, 1650 Repl. CH17189
30208
Bearing, inner, front hub, 2 wheel drive 1250, (16) 1450, 1650, Repl. CH17194
6206-2RS
Brg. inner, front hub, manual strg. 670, 770 Repl. CH14487 (16)
6205-2RS
Bearing, outer, front hub, manual steering (19) 670, 770, 790 Rep. CH11550
32007
Brg., inner, front hub 750, 850, 870, 950, 970, 1050, 1070 Repl. CH11146 (16)
30205
Brg, outer, front hub 750, 850, 870, 950, 970, 1050, 1070 Repl.CH11145 (19)
6205-2RS
Bearing, inner, front hub 650 Repl. CH11550 (16)
6204-2RS
Bearing, outer, front hub 650 Repl. CH13508 (19)
HC-4151
Cap, hub 650 Repl. CH14555 (24)
HC-4145
Cap, hub 750, 870, 970, 1070 Repl. CH11162 (24)
24
FRONT AXLE PARTS w/mechanical front wheel drive (MFWD) SG-1352
Gear 750 850, 870 Repl. CH14625 (3)
6304-2RS
Bearing, ball 650 Repl. CH13511 (2)
6207-2RS
Bearing, ball 750 Repl JD9344 Old # CH14627
6208-2RS
Bearing, ball 870, 970, 990, 1070 (2) Repl. CH15042
OR-1000
Oring packing 870, 970, 990, 1070 (5) Repl. CH16109
35x41x5VB
Seal 870, 970, 990, 1070 (7) Repl. CH16106
30x42x7TC
Seal 750 Repl. CH14638 (7)
APB-4191
Bushing 650 Repl. CH13075
OR-160
Oring packing 870, 970, 990, 1070 (9) Repl. CH10570
DP-110
Radiator Drain Plug 650,750 Repl. CH15532
DP-114
Drain plug 870, 970, 990, 1070 (10) Repl. CH11414
OR-70
Oring packing 870, 970, 990, 1070 (11) Repl. CH14671
32007
Bearing, tapered roller 870, 970, 990, 1070 (14) Repl. CH11146
45x62x9TC
Seal 870, 970, 990, 1070 Repl. CH13163 (17)
SC-1317
Collar, front pinion seal 950, 1050 Repl. CH13151
6009-2RS
Bearing, ball 750 Repl. CH14581 (23)
PG-4190
Gear 750 Repl. CH14598 (30)
6012-2RS
Bearing, ball 870, 970, 990, 1070 (34) Repl. CH13507
(2)
(8)
(18)
25
FRONT AXLE PARTS w/mechanical front wheel drive (MFWD) RP-820
Roll pin 650 Repl. CH14656 (3)
GF-10
Grease fitting 650 Repl. CH11574 (4)
SB-4321
Bushing 650 Repl. CH13147 (5)
35x41x5VB
Seal 650 Repl. CH16106 (6)
30x47x8TC
Seal 655, 670, 755, 770, 790, (6) 855, 955 Repl. M800448
OR-750
O-ring 650 sn 015680 & up (12) Repl. CH11572
OR-500
O-ring 650 Repl. CH11436 (14)
AC-1364
Seal collar 650 Repl. CH14654 (15)
AS-4306
Seal collar 655, 670, 755, 770, 790, (15) 855, 955 Repl. M800447
44x57x11.5TC Seal 650, 655, 670, 755, 756, 770 (16) 855, 856, 955 Repl. CH14642 DP-114
Drain plug 650 Repl. CH11414 (21)
OR-160
O-ring 650 Repl. CH10570 (23)
26
FRONT AXLE PARTS w/mechanical front wheel drive (MFWD) SB-4321
Bushing 950, 1050 Repl. CH13147 (5)
35x41x5VB
Seal 950, 1050 Repl. CH16106 (7)
CG-4321
Gasket 950, 1050 Repl. CH13167 (13)
SR-450
Snap ring 950, 1050 Repl. CH13496 (17)
NB-3110
Needle bearing 950, 1050 Repl. CH13171 (16)
AS-4465
Seal, front knuckle lower 950 SN 016620 & up, (21) 1050 before SN 011000 Repl. CH17593
FGC-4274
Housing, LH 950, 1050 Repl. CH19231 (24)
FGC-4321
Housing RH 950, 1050 Repl. CH19232 (24)
TRB-1221
Steering arm bracket, RH 950, 1050 (25) Repl. CH13149
TRB-1211
Steering arm bracket, LH 950, 1050 (36) Repl. CH13148
GHC-4321
Lower cover 950, 1050 Repl. CH13169 (37)
CG-1376
Gasket for GHC-4321 Repl. CH13170
AC-4274
Seal collar 950, 1050 Repl. CH19160 (38)
64x80x13TC
Seal 950, 1050 Repl. CH19161 (39)
AS-4465
Seal 950 sn -020000Repl. CH17593 (39) (Old #’s CH13175 & CH13176)
27
FRONT AXLE PARTS w/mechanical front wheel drive (MFWD)
OR-450
Oring packing 950, 1050 Repl. CH13520 (2)
SC-4491
Seal collar 950, 1050 Repl. M802467 (old # CH13183) (3)
SAH-4321
Housing, stub axle bearing 950, 1050 Repl. CH13177 (4)
65x88x5TC
Seal, dust cover 950, 1050 Repl. CH13179 (5)
65x88x12TC
Seal 950, 1050 Repl. CH13178 (6)
6211-2RS
Bearing 950, 1050 Repl. CH11552 (7)
OR-2000
Oring 950, 1050 Repl. CH13524 (8)
FDG-4321
Gear 950, 1050 Repl. CH13925 (9)
NJ-306E
Bearing 950, 1050 Repl. JD9513 (10)
SS-6190
Seal collar 655, 670, 750, 755, 756, 770, 790, (11) 855, 856, 955 Repl. CH14967
30x47x8TC
Seal 655, 670, 755, 756, 770, 790, 855, (12) 856, 955 Repl. M800448
6204-2RS
Bearing 655, 670, 755, 756, 770, 855, 856, (13) 955 Repl. M800451
AS-4306
Seal sleeve 655, 670, 755, 756, 770, 790, 855, (16) 856, 955 Repl. M800447
AS-1363
Collar, seal 655, 670, 755, 756, 770, 790, 855 (17) 856, 955 Repl. M800446
44x57x11.5TC Seal 650, 655, 670, 755, 756, 770, 790, 855 (18) 856, 955 Repl. CH14642 OR-600
O’ring, hsg to knuckle 655, 670, 755, 756, 770, (29) 855, 856, 955 Repl. CH11571
28
FRONT AXLE PARTS w/mechanical front wheel drive (MFWD) SR-28
Snap ring 750, 850, 870 Repl. CH14681 (1)
SW-4311
Washer 750, 850, 870 Repl. CH14680 (2)
6205-2RS
Bearing 750, 850, 870 Repl. CH11550 (3)
SR-100
Snap ring 750, 850, 870 Repl. CH14670 (4)
6013-2RS
Bearing 750, 850, 870 Repl. CH14687 (5)
SG-1394
Gear (upper) 750, 850, 870 CH14683 (6)
115x145x13.5TCS Seal 750, 850, 870 Repl. CH14662 (7) SA-1385
Shaft 750, 850, 870 Repl. CH14677 (8)
25x40x7TC
Seal, top 750, 850, 870 Repl. CH14659 (9)
SH-1371
Housing, front axle top (L or R) 750, 850, (11) 870 Repl. CH14658
SR-720
Snap ring 850, 870 Repl. CH14669 (12)
OR-70
O-ring 750, 850, 870 Repl. CH14671 (13)
SG-4311
Gear (lower) 750, 850, 870 Repl. CH14684 (21)
NB-4311
Needle bearing 750, 850, 870 Repl. CH14678 (22)
SB-4311 Bushing 750, 850, 870 Repl. CH14679 (23) ----------------------------------------------------------------------------------------------50x68x12.5
Seal 750, 850 Repl. CH14665 (19)
SR-680 Snap ring 750, 850 Repl. CH14668 (20) ------------------------------------------------------------------------------------------------NB-3110
Needle bearing 950, 1050 Repl. CH13171 (17)
AS-4279
Seal sleeve 950, 1050 Repl. CH20145 (20)
64x80x13TC
Seal 950, 1050 Repl. CH19161 (24)
NJ-306E
Bearing 950, 1050 Repl. JD9513 (28)
6211-2RS
Bearing 950, 1050 Repl. CH11552 (33)
65x88x12TC
Seal 950, 1050 Repl. CH13178 (34)
65x88x5TC
Seal 950, 1050 Repl. CH13179 (35)
29
FRONT AXLE PARTS w/mechanical front wheel drive (MFWD)
LN-35
Lock nut 750, 850 Repl. CH13515 (1)
LW-4311
Lock washer 750, 850 Repl. CH14698 (2)
SG-4122
Gear, stub axle 750, 850, 870 Repl. M804970 (3)
6211-2RS
Bearing 750, 850, 870, 950, 1050 Repl. CH11552 (4)
SR-242
Snap ring 750, 850, 870 Repl. CH13490 (5)
SC-4161
Collar 750, 850 Repl. CH14699 (7)
SR-680
Snap ring 750, 850 Repl. CH14668 (8)
6008-2RS
Bearing 750, 850 Repl. CH14592 (9)
6210-2RS
Bearing 870 Repl. CH11551 (9)
AS-4328
Seal 870 Repl. M804187 (10)
50x68x12.5
Seal 750, 850 Repl. CH14665 (10)
SC-4311
Collar, seal 750, 850 Repl. CH14700 (11)
OR-400
O-ring 750, 850 Repl. CH14701 (12)
OR-500
O-ring 870 Repl. CH11436 (12)
M14x25
Bolt, lug 750, 850 Repl. 19M7646 (15)
30
FRONT AXLE PARTS w/mechanical front wheel drive (MFWD)
6304-2RS
Bearing 650 Repl. CH13511 (2)
6207-2RS
Bearing 750, 850, 870 Repl. JD9344 (2)
6208-2RS
Bearing 970, 1070 Repl. CH15042 (2)
6209-2RS
Bearing 950, 1050 Repl. JD7692 (old # CH13509) (2)
6210-2RS
Bearing 1250, 1450, 1650 Repl. CH11551 (2)
SG-1352
Gear 750 850, 870 Repl. CH14625 (3)
SG-3110
Gear 950, 1050 Repl. CH18039 (3)
6206-2RS
Bearing 650 Repl. CH14676 (4)
6209-2RS
Bearing 950, 1050 Repl. CH13512 (4)
6211-2RS
Bearing 1250, 1450, 1650 Repl. CH17453 (4)
SA-4321
Spindle shaft 950, 1050 Repl. CH13871 (6) For 1050 must use SG-4321, 6306-2RS and SR-34
SA-950
Spindle shaft (original style) 950, 1050 Repl. AM876190 (6)
SG-1389
Gear, lower spindle 950, 1050 Repl. CH13172 (7)
SR-850
Snap ring 950, 1050 Repl. CH13495 (8)
6308-2RS
Bearing 1250, 1450, 1650 Repl. CH16417 (9)
6209-2RS
Bearing 950, 1050 Repl. JD7692 (old # CH13509) (9)
SA-950
Vertical Spindle 950, 1050 Repl. AM876190 (8)
31
FRONT AXLE PARTS w/mechanical front wheel drive (MFWD)
6304-2RS
Bearing 655, 670, 755, 756, 770, 855, 856 Repl. CH13511 (4)
6207-2RS
Bearing 655, 670, 755, 756, 770, 855, 856 Repl. JD9344 (old # CH14627) (6)
SR-34
Snap ring 655, 670, 755, 756, 770, 855, 856 Repl. CH13489 (7)
6009-2RS
Bearing 655, 670, 755, 756, 770, 855, 856 Repl. CH14581 (10)
6211-2RS
Bearing 870 Repl. CH11552 (10)
6210-2RS
Bearing 870 Repl. CH11551
AS-4447
Seal 655, 670, 755, 756, 770, 855, 856 Repl. CH14691 (13)
AS-4328
Seal 870 Repl. M804187 (13)
AC-4447
Collar, seal 655, 670, 755, 756, 770, 855, 856 Repl. CH14692 (14)
32
FRONT AXLE PARTS w/mechanical front wheel drive (MFWD)
RGP-4311
Front ring gear & pinion (1) 750, 850 sn 16001 up Repl. CH14575
SC-3662
Collar, spacer 750, 850 sn 16001 & up (4) Repl. CH14619
40x55x8TC
Seal 750, 850 sn 16001 & up Repl. CH14620 (5)
SC-4191
Collar, seal 750, 850 sn 16001 & up Repl. CH14579 (3)
SC-1317
Collar, seal 950, 1050 Repl. CH13151
30x52x8TC
Seal 650 Repl. CH14633
45x62x9TC
Seal 950, 970, 990, 1050, 1070 Repl. CH13163 (5)
32006
Bearing 750, 850 Repl. CH14577 (6)
32007
Bearing 950, 970, 990, 1050, 1070 Repl. CH11146 (6)
6009-2RS
Bearing 750, 850 Repl. CH14581 (10)
6012-2RS
Bearing 950, 1050 Repl. CH13507 (10)
PG-4740
Spider gear 750, 850 sn 16001 & up, 870 Repl. CH14595 (15)
PG-4190
Spider gear 750, 850 sn 16001 & up, 870 Repl. CH14598 (16)
PH-4311
Pinion housing 750, 850 sn 16001 & up Repl. CH14618 (20)
(3)
(5)
33
CB-4191
Boot (rubber) 750 Repl. M801916 (old # CH14617)
(1)
DS-4191
Sleeve 750 Repl. CH14612
SB-4190
Ball 750 Repl. R26552 (old # CH10566)
DC-4191
Coupling 750, 850 sn 16001 & up Repl. CH14613
SS-4191
Splined shaft seal 750, 850 SN 16001 - Repl. CH14614 (5)
DW-4191
Washer 750 Repl. CH14615
(6)
DS-4311
Spring 750 Repl. CH14616
(7)
(2) (3) (4)
34
DROP BOX PARTS
30x52x8TC
Seal, drop box 750, 850 Repl. CH14633 (1)
35x55x11TC Seal, drop box 950, 1050 Repl. CH13066 (1) 42x60x9TC
Seal, drop box 1250, 1450, 1650 Repl. CH10921 (1)
SS-6190
Sleeve or spacer 750, 850 Repl. CH14967 (2)
SS-4274
Sleeve or spacer 950, 1050 Repl. CH13105 (2)
SC-4130
Sleeve or spacer 1250, 1450, 1650 Repl. CH10959 (2)
6304-2RS
Bearing 850, 950, 1050 Repl. CH13511 (3)
6005-2RS
Bearing 650 Repl. CH14828 (4)
6205-2RS
Bearing 750, 850, 950, 1050 Repl. CH11550 (4)
6306-2RS
Bearing 1250, 1450, 1650 Repl. CH15035 (4)
SR-550
Snap ring 950, 1050 Repl. CH13494 (5)
OR-210
O-ring 750 Repl. CH14583 (6)
SR-29
Snap ring 750, 950, 1050 Repl. CH13488 (7)
6005-2RS
Bearing 750 Repl. CH14828 (9)
6006-2RS
Bearing 950, 1050 Repl. CH13505 (9)
6205-2RS
Bearing 850 Repl. CH11550 (9)
6207-2RS
Bearing 1250, 1450, 1650 Repl. CH14627 (9)
Clutch & Linkage CR-740
Turnbuckle 650 Repl. CH11452 (2)
CR-4197
Rod, clutch, RH thread 650 Repl. CH14777 (3)
CR-4440
Rod, clutch, LH thread 650 Repl. CH14776 (4)
35
Clutch & Linkage CR-2246 (1) Clutch rod end – LH thread 750, 850 SN -016,000, 950 SN -020,000 Repl. CH11398 BR-100
(1) Clutch rod end – LH thread (clevis type) 850 SN 016,001-, 950 SN 020,001-, 1050 Repl. CH10989
CR-4420 (2) Clutch rod 750 Repl. CH14779 CR-4145 (2) Clutch rod end – RH thread 850 SN-016,000, 950 SN -020,000 Repl. CH11189
CD-4335
PTO disc for models w/dual clutch 850, 870, 950, 970, 990, 1050, 1070, 4005 (9” x 13 spline) Repl. M804454 (old # CH13090, LVU801087 & M806764)
CD-4115
Clutch disc, 7-7/8” x 7/8 – 20 spline, 650, 750 Repl. LVU801674 (old CH14760 & M805461)
PP-4115
Pressure plate 650, 750 Repl. LVU803018 (Old # CH14762)
TO-4115
Clutch throw-out (release) bearing 650, 670, 750, 770, 790 w/single clutch Repl. CH14769
CD-4276
Clutch disc, 8-1/2” x 1” – 13 spline, 670 & 770 w/ single clutch Repl. M802964 850 & 950 w/ single clutch Repl. CH18375
PP-4276
Pressure plate – 670 & 770 w/ single clutch Repl. M809105 (old # M802965)
PP-4081
Pressure plate 850 & 950 w/ single clutch Repl. LVU803007 (old # CH11720)
TO-4276
Clutch throw-out (release) bearing 850 & 950 w/single clutch Repl. CH11464
36
SB-4065
Shifter boot 650, 750, 850, 950, 1050 Repl. CH10854
RS-4420
Spring, clutch brg return 650, 750 (1) Repl. CH14770
Shift Lever Guide SLG-4150
Shift lever guide 750 Repl. CH14911
Transmission Bearing 5306-2RS
Bearing, countershaft gear 850, 950 Repl. CH11196
SF-13
Shift fork, 1st & 2nd 850 -007761 SN, (1) 950 -010860 SN Repl. CH10923
SB-4190
Ball only 850, 950 Repl. R26552 (2)
SR-4145
Shift rail, 1-3 & 2-4 for 850 -016,000 SN, (6) 950 -020,000 SN Repl. CH11206
RP-625
Pin 850, 950 Repl. CH11501 (9)
Clutch Safety Switch SS-4440
Clutch safety switch 650, 750, 850, 950, 1050, (6) 1450, 1650 Repl. CH20208 (old # CH10155)
37
Transmission and PTO Gaskets TG-2412
Gasket, transmission 750 Repl. LVU801603 (1) (Old # CH14798)
THROTTLE PARTS TRS-3994
Throttle return spring 2000, 2500, 3000 Repl. 193994-10203
BRAKE PARTS BDC-3630
Brake drum cover 750, 770, 790, 3005 (5) Repl. CH15070
BCG-4420
Brake cover gasket 750, 770, 790, 3005 (6) Repl. M803177 (old # CH15071)
BCG-4130
Brake cover gasket 850 Repl. LVU801217 (6) (old # CH10980)
BCG-4320
Brake cover gasket 950, 1050 Repl. M806836 (6) (old # CH11252)
BS-4440
Brake shoe 650, 670 Repl. M805305 (old # CH20140) (9)
BRS-4200
Brake return spring 650, 670 Repl. CH15066 (8)
BS-4420
Brake shoe 750, 770, 790, 3005 Repl. M805735 (old # CH15072) (9)
BRS-4150
Brake return spring 750, 770, 790, 3005 Repl. CH15073
BS-4130
Brake shoe 850 Repl. M805898 (old # M801894) (9)
(8)
38
BRS-4130
Brake return spring 850 Repl. CH10977 (8)
BS-4145
Brake shoe 950 Repl. M805899 (old # CH11247) (9)
BRS-4145
Brake return spring 950, 1050 Repl. CH11248 (8)
BS-4320
Brake shoe 1050 Repl. M805897 (old # CH13123) (9)
BD-3657
Brake drum 750, 770, 790, 3005 Repl. CH15074 (10)
BC-3671
Brake camshaft, LH 750 Repl. CH15075
(11)
BC-3672
Brake camshaft, RH 750 Repl. CH15078
(11)
BPS-4145
Brake pedal return spring 850, 950
Repl. CH11264
Brake parts continued on next page
39
Brake parts continued BR-103 (3)
Brake turnbuckle 650, 750, 850, 950, 1050
Repl CH11416 (10mm X 90mm OAL) BR-4145 (4) Brake rod end – RH thread 850, 950 Repl CH11271
(OAL approx. 13”) BR-102 (4)
Brake rod end – RH thread 650 Repl. CH15086; 870, 970, 1070 Repl. CH11061 (OAL 11-1/2”)
BR-4320 (4) Brake rod end – RH thread 1050 Repl. CH13131 (OAL approx. 8”) BR-4420 (4) Brake rod end – RH thread 750 Repl. CH15093 (OAL approx. 10”) BR-3775 (4) Brake rod end – RH thread 670, 770, 790 Repl. M803758 (OAL approx. 4-1/8”) BR-100 (5)
Brake rod end – LH thread – 650, 750, 850, 950, 1050 Repl. CH10989 (OAL approx. 4-3/8”)
BR-101 (5)
Brake rod end – LH thread 870, 970, 1070 Repl. M804721 (OAL approx. 8”)
-118 (8)
Brake rod clevis pin w/hair pin clip 650, 750, 850, 950, 1050 Repl. CH10857
6305-2RS
Bearing, brake stub axle 670 Repl. CH11554
6206-2RS
Bearing, brake stub axle 770 Repl. CH14887
6307-2RS
Bearing, brake stub axle 850 Repl. CH11556
SC-4305
Collar, seal 650, 670, 770 Repl. CH19719 (1)
SC-4130
Collar, seal 850 Repl. CH10959 (1)
SC-3343
Collar, seal 950 Repl. CH11236 (1)
35x52x11TC Seal 650, 670, 770, 790 Repl. CH19718 42x80x9TC
Seal 850 Repl. CH10960
40
REAR AXLE PARTS
RAC-3271
Housing, rear axle seal 850, 950, 1050 Repl. CH11228 (1)
RAHG-4420 Gasket, rear axle housing 750 Repl. CH15015 (2) AC-4447
Collar, rear axle seal 650, 655, 670, 750, 755, (5) 770, 855 Repl. CH14692
AS-4447
Seal, rear axle 650, 670, 750, 770 Repl. CH14691 (6) 655 -610729 SN, 755 & 855 -827728 SN
SR-40
Snap ring 670, 770 Repl. CH11484 (1)
6208-2RS
Bearing, inner axle 650, 670, 770 Repl. CH15042 (7)
6009-2RS
Bearing, outer axle 650, 670, 770 Repl. CH14581 (8)
6209-2RS
Bearing, inner & outer 750 Repl. JD7692 (7 & 8) (Old # CH13509)
41
AC-4130
Collar, seal 850 can Repl. CH12573 when used with 58x80x12TC seal, 990 Repl. CH12573
(2)
58x80x12TC Seal used with AC-4130 (3) 60x80x12TC Seal 850, 870, 970, 990 Repl. CH11329 (3) SC-4145
Collar, seal 950, 1050, 1070, 4500, 4600, 4700 Repl. CH11243 (2)
AS-4327
Seal, axle 1070, 4500, 4600, 4700 Repl. M804655 (3)
75x100x13TC Seal, axle 950, 1050 Repl. CH11230 (3) 75x100x7TC Seal, axle dust 950, 1050 Repl. CH11231 (3a) 6009-2RS
Bearing, outer axle 655 -610729 SN, 755 & 855 (6) -827728 SN Repl. CH14581
6011-2RS
Bearing, inner axle 1070 Repl. JD9292 (old # M804641) (8)
6209-2RS
Bearing, outer axle 655 SN 610730-, 755 & 855 (6) SN 827729- Repl. JD7692
6207-2RS
Bearing, inner axle 655, 755, 855 Repl. JD9344 (8)
6210-2RS
Bearing, inner axle 850 Repl. CH11551 (8)
6210-2RSNR Bearing w/snap ring, outer axle 850, (6) 870, 970 Repl. CH10965 6212-2RS
Bearing, inner axle 950, 1050 Repl. CH11553 (8)
6312-2RS
Bearing, outer axle 950 Repl. CH11555 (6)
6212-2RS
Bearing, outer axle 1050 Repl. CH13386 (6)
42
PTO Seals, Bearings & Couplers
SC-4130
Collar, PTO seal 850, 870, 950, 970, (10) 1050, 1070, 1250 Repl. CH10959
6005-2RS
PTO bearing 650 –005128 Repl. CH14828 (6)
6205-2RS
PTO bearing 750, 850, 870, 950, 970, (6) 1070, 1050 Repl. CH11550
6205-2RSNR PTO bearing w/snap ring 670, 770 Repl. CH14888 (6) 6006-2RS
PTO bearing 650 Repl. CH13505 (7)
6007-2RS
PTO bearing 670, 770 Repl. CH13506 (7)
6206-2RS
PTO bearing 750 Repl. CH14887 (7)
6207-2RS
PTO bearing 870, 970, 1070 Repl. JD9344 (7)
6307-2RS
PTO bearing 1250 Repl. CH16424 (7)
6308-2RS
PTO bearing 1450, 1650 Repl. CH16417 (7)
38x50x8TC
PTO seal 650 Repl. CH14788
(8)
38x55x8TC
PTO seal 750 Repl. CH14809
(8)
38x62x9TC
PTO seal 1450, 1650 Repl. CH18637 (8)
40x55x8TC
PTO seal 655, 670, 755, 756, 770, 855, 856 (8) Repl. CH14620
AC-4210
Collar, PTO seal 655, 755, 756, 850, 855, 856, 950, 955, 1050 (10) Repl. CH13092
42x60x9TC
PTO seal 850, 870, 950, 970, 1050, 1070, (8) 1250 Repl. CH10921
Continued on next page
43
PTO Bearing, Seals and Couplers 5305-2RS
PTO bearing 850 SN -16000, (5) 950 SN -20000 Repl. CH19229
6204-2RS
PTO bearing 670, 770 Repl. M803810 (5)
6304-2RS
PTO bearing 650 Repl. CH13511; 750 Repl. JD8509 (5)
6308-2RS
PTO bearing 1250, 1450, 1650 Repl. CH16417 (5)
6204-2RS
PTO bearing 750 Repl. CH13508 (3)
6304-2RS
PTO bearing 870, 970, 1070 Repl. CH13511 (3)
SR-40
Snap ring 850, 950, 1050 Repl. CH11484 (9)
SC-2522
Coupler 1250, 1450, 1650 Repl. CH10870 (1)
SC-2618
Coupler 850 SN 16001 & up, 870, 950 SN 20001 & up, (1) 970, 1050, 1070 Repl. CH13718
SC-4300
Coupler 650, 670, 750, 770, 790 Repl. CH14838 (1)
Rock Shaft Seals SS-4130
Splined rock shaft seal 850, 950, 1050 (D) Repl. CH10996
OR-600
Oring 850, 950, 1050 Repl. CH11571 (B)
SS-4150
Splined rock shaft seal 750 (D) Repl. CH15138
OR-500
Oring 750 Repl. CH11436 (B)
44
Hydraulic cover gasket HCG-4197
Hyd cover gasket 650 Repl. LVU801601 (4) (Old # CH15106)
HCG-4312
Hyd cover gasket 750 Repl. LVU801609 (4) (Old # CH15111)
HCG-4145
Hyd cover gasket 850, 950, 1050 (4) Repl. LVU801617 (old # CH17998)
AB-42280
Breather tube 650, 750 Repl. CH11403 (3)
HH-4150
Hyd hose 650, 750 Repl. CH11407 (11)
HP-7C
Hyd pump 650 Repl. CH15095
HP-9C
Hyd pump 750 Repl. CH15096
HV-451
Hydraulic valve 650, 750, 850, 950 Repl. LVA801753 (Old # CH16132)
HVG-4151
Gasket for HV-451 valve Repl. CH11428
OR-112
O-ring, hyd. valve base Repl. CH11570
10x20x7TC
Seal for hyd. valve Repl. CH11426
JB-1500
Banjo bolt fitting 1250, 1450, 1650 (1) Repl. CH16844
PG-3414
Copper washer for JB-1500 Repl. CH11548 (2)
OR-200
Oring 1250, 1450, 1650 Repl. CH11562 (5)
Hydraulic Pumps HP-7C
Hydraulic Pump 650
HP-9C
Hydraulic Pump 750
HP-9A
Hydraulic Pump 850 / 950
HP-3000
Hydraulic Pump 1050 (JD Part – New part available soon.)
45
Pins, Chains, and Side Links
P-3916
Upper arm pin Pin dia. ¾”, 12mm thread, 3-9/16” OAL Can replace CH10998
P-4516
Upper arm pin w/ shoulder, ¾” pin dia., 16mm thread, 4-5/16” OAL
P-771
Top link pin Cat. 1
¾” dia. X 2-3/4” usable length.
P-772
Top link pin Cat. 1
¾” dia. X 3-7/8” usable length.
P-728
Lift arm pin Cat. 1
7/8” X 7/8” X 5-1/2” OA length.
SC-350
Stabilizer chain 3-1/2” long rd. ctr. tube w/counter wt.
SC-425
Stabilizer chain 4-1/4” long sq. ctr. tube w/lock nut 950, 1050
SL-975
Side link, non adjustable w/clevis pin
SL-1150
Side link, non adjustable w/clevis pin
SL-155
Side link, non adjustable w/clevis pin 950, 1050 Repl. CH19069
ASL-750
Adj. Side link – 7-1/2” center tube w/clevis pin
ASL-950
Adj. Side link – 9-1/2” center tube w/clevis pin
P-159
Clevis pin w/hair pin clip for ASL-750, ASL-950, SL-155, SL-975, SL-1150 side links
46
HB-4155
Hood hinge bolt bushing – rubber 650, 750, 850, 950, 1050, 1250, 1450, 1650 Repl. CH15723
HB-100
Hood hinge bolt 650, 750, 850, 950, 1050, 1250 Repl. CH14152
SB-100
Seat bushing 3/8” ID x 5/8” long 650, 750 Repl. CH11437
RC-151
Rubber cushion, seat – approx. 1-1/2” tall (B) 650, 750 Repl. CH15277
SR-205
Seat rod (hinge pin) – 205mm long 650, 750, 850, (C) 950, 1050 Repl. CH11075 (w/ washers & cotter pins)
RD-6327
Rubber damper for seat rod 650, 750, 850, (D) 950, 1050 Repl. CH18084
Seat Mounting Hardware (A)
47
SA-1654B This universal seat comes with an adjustable bracket set that allows the unit to fit most any tractor with a flip type seat
SB-054 Adjustable mounting bracket set for most flip type seats
SB-2000 Seat bracket only (one piece) SA-1654C High back universal seat with one piece bracket
48
SEALS Size 10x20x7TC 115x145x13.5TC 14x25x7TC 20x32x7TC 20x35x7TC 20x35x7TC 22x35x8TC 25x40x7TC 25x42x8TC 26x38x7TC 30x42x7TC 30x45x8TC 30x47x8TC 30x52x8TC 35x41x5VB 35x48x10TC 35x52x11TC 35x55x11TC 35x55x8TC 38x50x8TC 38x50x8TC 38x52x9TC 38x55x8TC 38x62x9TC 40x55x8TC 40x55x8TC 40x62x19TC 40x62x8TC 42x60x9TC 42x60x9TC 42x80x9TCV 44x57x11.5TC 45x62x9TC 45x68x9TC 50x68x12.5 55x78x12TC 60x80x12TC 64x80x13TC 65x88x05TC 65x88x12TC 75x100x13SC 75x100x13TC 75x100x7TC 90x115x13TC AS-4328 AS-4447 17x30x7TC
Repl. JD # CH11426 CH14662 CH15098 CH19260 CH14814 M806768 CH13097 CH14659 R91130 CH14736 CH14638 CH11465 M800448 CH14633 CH16106 CH14541 CH14557 CH13066 CH14996 CH14788 M800723 CH11143 CH14809 CH18637 CH14620 CH14620 CH10879 CH13067 CH10921 CH10921 CH10960 CH14642 CH13163 AL38095 CH14665 CH11227 CH11329 CH19161 CH13179 CH13178 CH18877 CH11230 CH11231 CH18878 M804187 CH14691 M805569
Application 3pt. Valve seal 650, 750, 850, 950 Seal, front knuckle 750, 850 Hyd. pump shaft seal 650, 670, 750 Seal, PS top 1050, 1250, 1450, 1650 Seal, front transmission plate 750 Seal, frt drive shaft 655, 755, 855 Seal, dual clutch main drive shaft 850, 950, 1050 Seal, top cap 850 w/MFWD Seal, frt axle diff 670 770 Steering column bearing seal 650, 750 Seal, MFWD pivot 850
Old # CH17860
Old # MT1160
Seal, front axle 670 770 Seal, drop box 750, 850 Seal, top cap 950 & 1050 w/MFWD Seal, spindle 650 Seal, front wheel hub 650 Seal, drop box 950, 1050 Brake shaft seal 750 PTO seal 650 Seal, horizontal shaft inner 1050 Seal, spindle 850, 950, 1050 PTO seal 750 PTO seal 1450, 1650 PTO seal 655, 670, 755, 756, 770, 855, 856 Seal, front differential housing 750, 850 Seal, front hub, 2wd 870, 970, 990, 1070 Seal, trans main shaft 850, 950, 1050 Seal, drop box 1250, 1450, 1650 PTO seal 850, 870, 950, 970, 1050, 1070, 1250 Seal, brake shaft 850 Seal, front knuckle 650 Seal, front differential housing 950, 1050 Seal, rear axle 900HC Old # M800118 Seal, stub axle 750, 850 Seal, brake shaft 950 Seal, rear axle 850 Seal, lower knuckle 950, 1050 Seal, stub axle dust 950, 1050 Seal, stub axle 950, 1050 Seal, rear axle inner 1650 Seal, rear axle 950, 1050 Seal, rear axle dust 950, 1050 Seal, rear axle outer 1650 Seal, front knuckle 870 Seal, rear axle 650, 670, 750, 770; MFWD stub axle 670 770 Seal 4100, 4110, 4115 Compact Utility Tractors
49
Pricing – Freight – Returns PRICES ARE SUBJECT TO CHANGE WITHOUT NOTICE Payment:
We accept Visa, MasterCard, Discover and American Express. UPS fee for COD shipments is $10.00. This does not include the shipping charges.
Freight policy:
Effective January 1, 2010 Order values of $2,750.00 or more (new parts only for JD & Yanmar) will be freight PREPAID, Eastern & Central time zones. Pacific and Western time zones are PREPAID on order values of $3,750.00 or more. The title of the product, and inherent risk of loss, will transfer to the customer upon shipment from our warehouse. Claims for product damages or lost in transit are the responsibility of the buyer and should be filed with the carrier immediately. All returns must be authorized by Fredricks Importing, Inc. and must be in good condition. Used or installed parts will not be accepted. Parts must be returned within 30 days of purchase and be PREPAID. Returned goods subject to 25% handling charge. Returns including cores must be totally assembled. Disassembled items will not be accepted. Cores must be in condition to be rebuilt. Electrical parts are not returnable.
Returned goods:
NOTE: OEM part numbers are used for identification and reference only.
2
PARTS for JOHN DEERE Headlights and Bulbs LB-4155
Head light bulb 850, 950, 1050, 1250, 1450, 1650 Repl. CH11439
LB-4262
Head light bulb 650, 750 Repl. CH15208
HL-4201
Head light assembly 650, 750 Repl. CH18025
HL-4145
Head light assembly 850, 950, 1050 1250, 1450, 1650 Repl. CH11323
Turn Signal Switch TSS-4080
Turn signal switch 670, 770 Repl. M805412
TSS-4080
Turn signal switch 850, 950, 1050 Will repl. M800365 by removing bullet type wire connecters & replace with ring, hook or spade terminals
Fender lights FL-4150
Fender light, two bolt mount, 1-3/4” center, amber lens
FL-4440
Fender light, post mount, amber lens (approx. 2-1/4” dia.)
FL-6012
Fender light, post mount, amber lens (approx. 3-1/4” dia.)
ALTERNATOR AL-1215
Alternator, 12V – 15 Amp, 650, 750
Repl. MIA10312 (old # CH15587) AL-1235
Alternator, 12V – Fits: 850, 950, 1050, 1250, 1450 Repl: TY6647, CH10493
3
Voltage Regulator VR-550
Voltage regulator, 6-plug 850, 950, 1050, 1250, 1450, 1650 Repl. CH12806
VR-522
Voltage regulator, 6-plug 650, 750 Repl. M802471 (old # CH15589)
VR-150
Voltage regulator – 20 amp 670, 770, 870, 970, 1070; F915 Commercial Mower; 322, 330, 332 Garden Tractors Repl. AM101406
Ignition Switch IS-52110
Ignition switch 650, 750, 850, 950, 1050 Repl. CH11696
IK-5216
Ignition (double cut flat steel) KEY only for IS-52110 Repl. CH12206
Indicator Lamp Assembly ILA-4151
Indicator lamp assembly 850, 950, 1050 Repl. CH11893
Hour Meter Cable HMC-4167
Hour meter cable 655, 755 Repl. AM875587 Approx. 48” long
HMC-4275
Hour meter cable 650, 670, 750, 770, 850, 855, 950, 955, 1050 Repl. CH12241 (old # AM875588) Approx. 54-1/2” long
Dash Board DBP-8595
Dash board early 850 & early 950 Repl. AM878226 (old # CH12257)
DBP-1050
Dash board with fuel gauge opening 850, 950, 1050 Repl. CH19206
4
Model
Part # Standard
Replaces Standard
Part # .010
Replaces .25 under
Part # .030 .75 under
CH15398 AM876251 CH15399 AM876252
MB-152A MB-355A MB-555A RB-55A
CH17660 AM876249 CH17661 AM876250
MB-152C MB-355C MB-555C RB-55C
MB-152 MB-255 MB-355 MB-555 RB-55
CH15398 AM876257 AM876251 CH15399 AM876252
MB-152A MB-255A MB-355A MB-555A RB-55A
CH17660 AM876258 AM876249 CH17661 AM876250
MB-152C MB-255C MB-355C MB-555C RB-55C
MB-516 MB-315 MB-215 MB-516 RB-16
CH10338 AM875925 AM875926 CH10338 AM875927
MB-516A MB-315A MB-215A MB-516A RB-16A
CH17665 AM875931 AM875932 CH17665 AM875933
MB-516C MB-315C MB-215C MB-516C RB-16C
MB-525 MB-225 MB-325 MB-425 RB-45
CH20066 AM875929 AM875928 CH20067 AM875930
MB-525A MB-225A MB-325A MB-425A RB-45A
CH17673 AM875936 AM875935 CH17675 AM875937
MB-525C MB-225C MB-325C MB-425C RB-45C
MB-9150A RB-9150A
AM875374 AM875395
MB-9150C RB-9150C
650 Front main MB-152 Center main - flanged MB-355 Rear main MB-555 Rod bearing RB-55 750 Front main 2nd main 3rd main - flanged Rear main Rod bearing 850 Front main 2nd main 3rd main - flanged Rear main Rod bearing 950 / 1050 Front main 2nd main 3rd main - flanged Rear main Rod bearing
770 / 790 / 870 / 955 / 970 / 1070 / 3320 / 3520 / 4300 / 4310 / 4500 / 4600 / 4700 Main bearing MB-9150 AM875371 Rod bearing - JD3203 RB-9150 AM875392
TB-150
Thrust bearing set (2 pieces) 770, 790 w/3TNE84, 870, 955, 970, 1070, 3120, 3203, 3320, 3520, 4300, 4310, 4500, 4600, 4700 Repl. AM875373 & MIA880555 NOTE: Order 2 for one engine
5
PILOT BUSHINGS PB-4450
Pilot bushing 650, 670, 750, 770, 790, 850, 950 Repl. CH10408
Connecting Rod w/ piston pin bushing CR-215
Connecting rod w/ bushing 850 Repl. CH10682
CR-375
Connecting rod w/ bushing 650, 750 Repl. CH15609
CR-384
Connecting rod w/ bushing 950, 1050 Repl. CH10683
CR-9150
Connecting rod w/ bushing 770, 870, 955, 970, 1070, 4500, 4600, 4700 Repl. AM875391
Piston Pin Bushing PPB-4060
Piston pin bushing 650, 750 Repl. M808605 (old # CH15482)
PPB-4160
Piston pin bushing 850 Repl. CH10357
PPB-4450
Piston pin bushing 950, 1050 Repl. M806859
PPB-9100
Piston pin bushing 770, 870, 955, 970, 1070, 4300, 4500, 4600, 4700 Repl. M801256
Crankshaft CS-380
Crankshaft w/keys 850 Repl. CH10659
CS-384
Crankshaft w/keys 950, 1050 Repl. CH20055
6
CS-3154
FRONT CRANKSHAFT SEALS Front crank seal 850, 950, 1050 Repl. CH10390
CS-1450
Front crank seal 650, 750 Repl. CH15390
CS-9795
Front crank seal 770, 790, 855, 870, 955, 970, 990, 1070, 4200, 4300, 4310, 4400, 4410, 4500, 4510, 4600, 4610, 4700, 4710 Repl. M800988
CS-1250
REAR CRANKSHAFT SEALS Rear crank seal 950, 1050 Repl. CH10191
CS-1551
Rear crank seal 650, 750 Repl. CH15402
CS-4085
Rear crank seal 655, 670, 755, JD 2210, 2305, 2320, 4100 Repl. M801941 (old # M87809)
CS-4160
Rear crank seal 850 Repl. CH10340
CS-9120
Rear crank seal 770, 790, 870, 955, 970, 990, 1070, 2520, 3120, 3203, 3320, 3520, 3720, 4200, 4300, 4310, 4400, 4410, 4500, 4510, 4600, 4610, 4700, 4710 Repl. M805278
WS-80
Wet sleeve w/o’rings 850 Repl. CH13597
OR-1300
O’ring for WS-80 Repl. CH10327
WS-90
Wet sleeve w/o’rings 950 Repl. CH13598
OR-1000
O’ring for WS-90 Repl. CH16109
7
EP-1567 RS-520
Piston w/ pin & clips 650, 750 Repl. CH15479 (80mm) Ring set – STD. 650, 750 Repl. CH15608 (80mm)
EP-1567A RS-520A
0.25mm OS piston w/ pin & clips 650, 750 Repl. CH15622 0.25mm OS ring set 650, 750 Repl. CH15621
EP-1567B RS-520B
0.50mm OS piston w/ pin & clips 650, 750 0.50mm OS ring set 650 750
EP-4160 RS-300
Piston w/ pin & clips 850 Repl. CH10355 (80mm) Ring set 850 Repl. CH12046
EP-4763 RS-763
Piston w/ pin & clips 950 Repl. CH11803 (90mm) Ring set 950 Repl. CH12053
RS-350
Ring set, STD 870, 1070 Repl. AM877273 (84mm)
RS-350A
Ring set, 0.25 mm OS 870, 1070 Repl. AM877294
RS-350B
Ring set, 0.50 mm OS 870, 1070 Repl. AM878245
RS-351
Ring set, STD 770, 970 Repl. AM875390 (82mm)
RS-351A
Ring set, 0.25 mm OS 770, 970 Repl. AM875394
RS-351B
Ring set, 0.50 mm OS 770, 970 Repl. AM878243
FOR JD 1050 Must purchase EP-4763 piston and RS-763 ring set together as our ring set does NOT have the keystone type top ring.
8
Head Gasket HG-650
Head gasket 650 (2T80UJ eng) Repl. MIU10631 (old # M802217)
HG-655
Head gasket 655 Repl. M800004 (old # M801790)
HG-567
Head gasket 750 Repl. M802218 (old # CH15372)
HG-755
Head gasket 670, 755 Repl. M807297 (old # M87853 & M805694)
HG-156
Head gasket 770 Repl. M805831
HG-150
Head gasket 850 Repl. MIU800109 (old # CH10115)
HG-865
Head gasket 855, 856 Repl. M805845
HG-157
Head gasket 870, 955 Repl. M805837 (old # M804333)
HG-950
Head gasket 950, 1050 thru engine SN 089472 Repl. M808712
HG-970
Head gasket 970 Repl. M805849 (old # M801187)
HG-1070
Head gasket 1070 Repl. M805850 (old # M804334)
Valve Cover Gasket VCG-650
Valve cover gasket 650 Repl. CH15429
VCG-1550
Valve cover gasket 750 Repl. CH15431
VCG-1150
Valve cover gasket 850 Repl. CH10129
VCG-1250
Valve cover gasket 950, 1050 Repl. CH13884
VCG-9150
Valve cover gasket 790, 870, 955, 4300 Repl. M801741
VCG-9550
Valve cover gasket 970, 1070, 4500, 4600, 4700 Repl. M801230
9
Front Cover Gasket FCG-4450
Front cover gasket 850, 950, 1050 Repl. CH12819
FCG-1450
Front cover gasket 650, 750 Repl. CH15386
Main Bearing Housing Gasket MBHG-4160 Main brg housing gasket 850 Repl. CH10339 MBHG-4460 Main brg housing gasket 950, 1050 Repl. CH10445 MBHG-9150 Main brg housing gasket 770, 855, 856, 870, 955, 970, 1070 Repl. M801204 OR-1350
Main brg housing O-ring 650, 750 Repl. CH15404
10
Oil Pan Gaskets OPG-1150
Oil pan gasket 850 Repl. M811637 & CH12820
OPG-1250
Oil pan gasket 950, 1050 Repl. M811638 & CH12821
OPG-1575
Oil pan gasket 750 Repl. M806944 (old # CH15376)
OPG-650
Oil pan gasket 650 Repl. M810522 (old # CH15375)
OPG-1730
Oil pan gasket (UPPER) 955, 970, 1070 (4)
OPG-9550
Oil pan gasket (LOWER) 955, 970, 1070 (5)
Oil Pumps OP-1423
Oil pump 850, 950, 1050 Repl. CH20064
OPG-3202
Oil pump gasket for OP-1423 applications Repl. CH10414
OP-9350
Oil pump 650, 750 Repl. CH15617
OPG-1450
Gasket for OP-9350 oil pump Repl. CH15492
OP-9553
Oil pump: Compact Utility Tractors 3036E, 3038E, 3520, 3720, 4105 Repl. RG60604
OPG-9150
Gasket for OP-9553 Repl. M801005
Oil Pressure Sending Switch OP-39450
Oil pressure sending switch 650, 750 Repl. CH15500
Oil Filter OF-4085
Oil filter, spin-on – 3.75” tall 650, 750, 850, 855, 856, 950, 1050 Repl. M801002
Air Filters AF-2276
Air filter w/fin125 & 170 Skid Steer Loaders Repl. AH19847; 850, 950, 1050 & Excavators 25, 30, 50 Repl. CH12767
AF-6270
Air filter w/fin 650, 655, 750, 756 Repl. CH15451
11
Valve Train Parts IV-1218
Valve, intake 850 Repl. CH10055
EV-1218
Valve, exhaust 850 Repl. CH10056
IV-1422
Intake valve 1050 before SN 11,000 Repl. CH15724
EV-1422
Exhaust valve 1050 Repl. CH15725
IV-4600
Valve, intake 950 Repl. CH10094
EV-4600
Valve, exhaust 950 Repl. CH10095
IV-9100
Valve, intake 770, 870, 955, 970, 1070, 4300, 4500 4600 Repl. M801220
EV-9100
Valve, exhaust 770, 870, 970, 1070, 4300, 4400, 4500, 4600 Repl. M811796 (old # M801221)
IG-1180
Guide, intake 650, 750; Intake & Exhaust 855, 856, 4200, 4300, 4400 Repl. CH16041
EG-1181
Guide, exhaust 650, 750 Repl. CH16042
IG-4160
Guide, intake 850 Repl. CH16043
EG-4160
Guide, exhaust 850 Repl. CH16044
IG-4450
Guide, intake 770, 790, 870, 950, 955, 970, 1050, 1070, 4300, 4500, 4600, 4700 Repl. M801227 (old # CH16045)
EG-4450
Guide, exhaust 950, 1050 Repl. CH19595 (old # CH16046) 770, 790, 870, 955, 970, 1070, 4300, 4500, 4600, 4700 Repl. M801228
VS-4460
Valve stem seal, intake & exhaust 950, 1050; Intake only 770, 790, 870, 955, 970, 1070, 4300, 4500, 4600, 4700 Repl. CH10450
VS-1400
Valve stem seal, exhaust 770, 790, 870, 970, 1070, 4300, 4500, 4600, 4700 Repl. T110650
VS-4160
Valve stem seal, intake & exhaust 650, 670, 750, 755, 756, 850, 855, 856, 2210, 4200, 4300, 4400 Repl. CH10346 (old # CH15432)
VS-4211
Valve spring 850 Repl. CH10086
VS-4060
Valve spring 650, 750 Repl. CH15417
VS-4511
Valve spring 950, 1050 Repl. CH10093
VS-9795
Valve spring 770, 790, 870, 955, 970, 1070, 4300, 4500, 4600, 4700 Repl. M801222
12
Water Pumps WP-2000
Water pump 850, 950, 1050 Repl. CH12859
WPG-2000
Gasket water pump to back plate 850, 950 1050 Repl. CH10490
WPG-4450
Gasket, back plate to head 850, 950, 1050 Repl. CH10420
WP-4201
Water pump 650, 750 Repl. CH15502
WPG-1450
Gasket, water pump to back plate 650, 750 Repl. CH15506
WPG-4441
Gasket, back plate to head 650, 750 Repl. CH15508
WPP-4235
Water pump pulley 850, 950, 1050 Repl. CH10491
WP-9107
Water Pump, 770, 790, 870, 970, 990, 1070 Repl: AM881340, M805843, M876341
Radiator Cooling Fan CF-4474
Fan 650 Repl. CH15515; 655, 670, 750 Repl. CH16048
Thermostat HT-9350
Thermostat 650, 670, 750, 755, 850, 950, 1050 Repl. CH15536
TG-9350
Gasket, thermostat 650, 670, 750, 755, 850, 950, 1050 Repl. M805702 (old # CH16026)
13
Temperature sending switch TS-44901
Temp sending switch for tractors w/warning light 650, 655, 750, 755, 850, 855, 950, 955, 1050 Repl. CH15516
FB-35
Fan belt 650, 750 Repl. CH18206
FB-36
Fan belt 850 before SN 007760 Repl. CH10154
FB-39
Fan belt 850 SN 007761 & up Repl. CH14022
FB-37
Fan belt 950 before SN 010859 Repl. CH10367
FB-40
Fan belt 950 SN 010860 & up, 1050 Repl. CH12865; 870, 970, 1070 Repl. M808685 (old # M802627)
FB-38
Fan belt 855, 856 Repl. M805441
FB-40
Fan belt 770, 870, 970, 1070 Repl. M808685 (old # M802627)
Fan Belts
14
Radiator Hoses RH-4902
Lower radiator hose 650, 750 Repl. CH15529
RH-4903
By hose 650, 750 Repl. CH15530
RH-4761
Upper radiator hose 650, 750 Repl. CH15528
RH-9150
Lower radiator hose 770, 790 Repl. M802634
RH-1150
By hose 850 -007760 Repl. CH10159
RH-4460
Upper radiator hose 850 sn 007761Repl. CH13960 (old # CH14029)
RH-336
Upper radiator hose 850 -007760 Repl. CH11773
RH-4761
Lower radiator hose 850 Repl. CH14030
RH-1254
Lower radiator hose 950 –010859 Repl CH10310
RH-3810
Lower radiator hose 950 SN 010860-020000 Repl. CH14034
RH-1250
By hose 950 –010859 Repl. CH10270
RH-1252
By hose 950 sn 010860 & up, 1050 Repl. CH13628
RH-4460
Upper radiator hose 950 sn 010860 - 020000 Repl. CH13960 (old # CH14033); sn 020001 & up Repl. CH19298
RH-4460
Upper radiator hose1050 Repl. CH13960 (old # CH14029)
RH-1252
By hose1050 Repl. CH13628
OFT-4450
Round over-flow tank w/cap 850, 870, 950, 970, 990 -590000 sn, 1050, 1070 Repl. CH12866; 670, 770 Repl CH15518
RA-4450
Radiator 850 Repl. CH19293 (old # CH14024)
Radiator Drain Cock Assembly RD-1250
Drain cock (3 way) assembly 850, 950, 1050 Repl. CH10272
15
16
Manifolds, Muffler & Gaskets EM-1158
Exhaust Manifold 850 Repl. CH12069
MG-150
Manifold to head gasket, 850 Repl. CH10142 (3 required)
MG-1250
Manifold to head gasket, 950, 1050 Repl. CH10224 (3 required)
EM-1258
Exhaust Manifold 950 Repl. CH12068
MA-250
Muffler with elbow, mounting flange and pipe 650, 750, 850, 950, 1050 Repl. M802472
WC-3
Weather cap for 1-3/4” pipe Fits MA-250
MG-1450
Muffler to manifold gasket 650, 750, 850, 950, 1050 Repl. CH10403 & CH15915 755, 855 SN-009184 Repl. M805706
MG-1550
Gasket, manifold to head 750 Repl. M806016 (old # CH15458)
MG-9150
Gasket, manifold to head 870, 955, 970, 1070, 3320, 3520 Repl. M801746
GLOW PLUG GP-778
Glow plug 670, Compact Utility Models: 2210 Repl. AT110814 THERMOSTART PLUG
TE-4450
Thermostart plug 850, 900HC, 950, 1050 Repl. CH14079; (1) 650, 750 Repl. CH15593
TE-766
Adaptor for TE-4450 Repl. CH10459 (2) THERMOSTART TANK
HT-1750
Thermostart tank assembly 650, 750, 850, 950, 1050 Repl. CH11796
17
Injector pump IP-390
Injection Pump 850 / 950 / 1050 Repl. CH10679
IP-375
Injection Pump 750
IP-200
Injection Pump 650
Injector parts IA-4060
Injector assembly 650, 750 Repl. CH15620 (1)
IA-4160
Injector assembly 850 Repl. CH12411
IA-4770
Injector assembly 950, 1050 Repl. CH10685 (1)
IN-4770
Injector nozzle 650, 750, 850, 950, 1050 Repl. CH10499 (marked YDN-4SK1 6F)
IW-3854
Fuel Injection Valve Insulator 650, 750, 850, (1) 950, 1050 Repl. CH10072
GW-1550
Chamber gasket 650, 750 Repl. CH15436 (2)
GW-3288
Chamber gasket 850 Repl. CH10062
GW-4900
Chamber gasket 950, 1050 Repl. CH10099
IC-1550
Injector chamber, rear 650, 750 Repl. CH15434 (3)
IC-1400
Injector chamber, front 650, 750 Repl. CH15435 (4)
IC-1141
Injector chamber, rear 950, 1050 Repl. CH11763 (3)
IC-4450
Injector chamber, front 950 Repl. CH16008
IC-4400
Inj. chamber, rear 850 Repl. CH10092
(3)
IC-4160
Inj. chamber, front 850 Repl. CH14169
(4)
(1)
(2) (2)
(4)
18
Fuel System Parts TC-5504
Fuel tank cap (Metal) 1050 Repl. AM875877
TC-155
Fuel tank cap (Plastic) 850, 950, 1050 Repl. CH20242 (old # CH17086)
FT-32
Fuel tank 1050 Repl. CH13281
P-4060
Fuel bleeder plug Repl. CH10319
PG-3418
Gasket for P-4060 Repl. CH10558 (10)
FB-1
Fuel bowl 650, 670, 750, 870, 970, 990, (2) 1070 Repl. CH15552
OR-4321
O-ring for FB-1 fuel bowl Repl. CH10060 (3)
FF-3262
Fuel filter, 2.717” tall, 650, 670, 750, 4115 (1) Repl. CH15553
FF-3263
Fuel filter, 3.49” tall, 655, 755, 770, 850, (1) 855, 950, 1050, 4210, 4310, 4400 Repl. M801101
(5)
(Old # CH10479) FF-3507
Fuel filter, 3.50” tall, 1.969” OD 870, 955, (1) 970, 1070 Repl. T111383
FB-9155
Fuel bowl 870, 955, 970, 1070 (2) Repl. T111383
OR-650
O-ring for FB-9155 fuel bowl Repl. CH17154
TV-4200
Taper valve for fuel shutoff 650, 750, 770, (6) 850, 870, 950, 970, 1050, 1070 Repl. CH12734
H-5534
Fuel shutoff handle 650, 750, 850, 950, (7) 1050, 1250, 1450, 1650 Repl. CH12735
TVS-553
Taper valve spring 850, 870, 950, 970, 1050, 1070 Repl. CH10082
OR-240
O’ring for H-5534 handle Repl. CH10571 (4)
FBH-552
Fuel bowl head 850, 950, 1050 (12)
(3)
(9)
Repl. CH12792 FBR-250
Fuel bowl retainer ring 650, 655, 670, 750, 755, 770, 850, 855, (14) 870, 950, 970, 990, 1050, 1070, 1250, 1450, 1650, 4115 Repl. CH10106
19
FBR-556
Fuel bowl retainer ring for FB-9155 fuel bowl (14) Repl. T111382
20
Steering Parts
SW-150
Steering wheel 650, 750 Repl. M119181
SC-2500
Steering shaft 850, 950 (A) Repl. CH11175 (bearings not included)
SB-4145
Steering shaft bearing 850, 870, 950, (B) 970, 1050 Repl. CH11171
SC-1550
Steering shaft 650, 750 Repl. CH14731 (A) (bearings not included)
WK-519
Strg shaft woodruff key 650, 750 Repl. 26M4226
SB-750
Steering shaft bearing 650, 670, 750, (B) 770, 790 Repl. CH14732
SCB-4740
Steering column bushing 850, 950 Repl. CH11456 (2)
SCG-42
Steering column grommet 650, 750, 850, 950, (5) 1050 Repl. CH13854
SSS-4310
Steering sector shaft 650, 750 Repl. AM119584 (Old # CH14733)
26x38x7TC
Seal, steering sector shaft 650, 670, 750, 770 Repl. CH14736
SCB-1511
Lower housing 650, 750 Repl. CH14730
SC-1515
Strg box side cover 650, 750 Repl. CH14735 (10)
SBS-4080
Seal, steering housing 850 (-16000 sn), (5) 950 (-20000 sn) Repl. CH10813
(8)
21
JB-1500
Fitting, Power steering banjo bolt 1050 Repl. CH16844 (1)
PG-3414
Copper packing for JB-1500 Repl. CH11548 (2)
TIE ROD ENDS
DC-4730
Dust cover, ball t, common to most models Repl. CH11448
TR-1812
Tie rod end LH thread for right side 655, 670, 755, (B) 770, 850, 855, 955 Repl. AM878082
TR-1813
Tie rod end RH thread for left side 655, 670, 755, 770, 850, 855, 955 Repl. AM878081
TR-4150
Tie rod end (long) 650, 750 Repl. AM875955 (C)
TR-8290
Tie rod end (short) 650, 750 Repl. AM878080 (A) (Old # CH14551 & AM875953)
(A)
22
FRONT WHEELS FW-4100
Rim, 3 x 12 front (4 bolt) 650 Repl. CH14565
FW-4145
Rim, 4 x 16 front (6 bolt) 950, 970, 1050, 1070 Repl. CH11166
FW-4279
Rim, 5 x 16 (6 bolt) 870, 970 Repl. AM877153 950, 1050 Repl. CH13187
FW-4362
Rim, 5 x 14 (6 bolt) 750 Repl. CH14724
FW-8351
Rim, 5 x 14 front (6 bolt) 850 w/4wd Repl. CH19748
23
FH-4151
FRONT AXLE PARTS Hub 650 Repl. CH14554
Two wheel drive models
APB-4145
Bushing, spindle 1250 Repl. CH11134; 1450, 1650 Repl. CH13298 (6)
SB-4464
Bushing, spindle 670, 750, 770, 850, 870, 950, 970, (6) 1050, 1070 Repl. CH13301
SB-4440
Bushing, pivot pin 650, 670, 770, 790, 3005 Repl. CH14531 (9)
APB-4145
Bushing, pivot pin 850, 870, 950, 970, 990, (9) 1050 Repl. CH13928 (old # M805921)
51105
Bearing, spindle 650 Repl. CH14542 (11)
51106
Bearing, spindle 670, 750, 770, 850, 870, 950, 970, (11) 1050, 1070 Repl. CH11827
35x48x10TC
Seal, spindle 650 Repl. CH14541 (12)
38x52x9TC
Seal, spindle 670, 770, 850, 870, 950, 970, 1050, (12) 1070 Repl CH11143
35x52x11TC
Seal hub 650 Repl. CH14557 (15)
AS-4314
Seal, hub 670, 770, 790 Repl. M802819 (15)
40x62x19TC
Seal, hub 750, 850, 870, 950, 970, 990, 1050, 1070 (15) Repl. CH10879
30206
Bearing, outer, front hub, 2 wheel drive 1250, (19) 1450, 1650 Repl. CH17189
30208
Bearing, inner, front hub, 2 wheel drive 1250, (16) 1450, 1650, Repl. CH17194
6206-2RS
Brg. inner, front hub, manual strg. 670, 770 Repl. CH14487 (16)
6205-2RS
Bearing, outer, front hub, manual steering (19) 670, 770, 790 Rep. CH11550
32007
Brg., inner, front hub 750, 850, 870, 950, 970, 1050, 1070 Repl. CH11146 (16)
30205
Brg, outer, front hub 750, 850, 870, 950, 970, 1050, 1070 Repl.CH11145 (19)
6205-2RS
Bearing, inner, front hub 650 Repl. CH11550 (16)
6204-2RS
Bearing, outer, front hub 650 Repl. CH13508 (19)
HC-4151
Cap, hub 650 Repl. CH14555 (24)
HC-4145
Cap, hub 750, 870, 970, 1070 Repl. CH11162 (24)
24
FRONT AXLE PARTS w/mechanical front wheel drive (MFWD) SG-1352
Gear 750 850, 870 Repl. CH14625 (3)
6304-2RS
Bearing, ball 650 Repl. CH13511 (2)
6207-2RS
Bearing, ball 750 Repl JD9344 Old # CH14627
6208-2RS
Bearing, ball 870, 970, 990, 1070 (2) Repl. CH15042
OR-1000
Oring packing 870, 970, 990, 1070 (5) Repl. CH16109
35x41x5VB
Seal 870, 970, 990, 1070 (7) Repl. CH16106
30x42x7TC
Seal 750 Repl. CH14638 (7)
APB-4191
Bushing 650 Repl. CH13075
OR-160
Oring packing 870, 970, 990, 1070 (9) Repl. CH10570
DP-110
Radiator Drain Plug 650,750 Repl. CH15532
DP-114
Drain plug 870, 970, 990, 1070 (10) Repl. CH11414
OR-70
Oring packing 870, 970, 990, 1070 (11) Repl. CH14671
32007
Bearing, tapered roller 870, 970, 990, 1070 (14) Repl. CH11146
45x62x9TC
Seal 870, 970, 990, 1070 Repl. CH13163 (17)
SC-1317
Collar, front pinion seal 950, 1050 Repl. CH13151
6009-2RS
Bearing, ball 750 Repl. CH14581 (23)
PG-4190
Gear 750 Repl. CH14598 (30)
6012-2RS
Bearing, ball 870, 970, 990, 1070 (34) Repl. CH13507
(2)
(8)
(18)
25
FRONT AXLE PARTS w/mechanical front wheel drive (MFWD) RP-820
Roll pin 650 Repl. CH14656 (3)
GF-10
Grease fitting 650 Repl. CH11574 (4)
SB-4321
Bushing 650 Repl. CH13147 (5)
35x41x5VB
Seal 650 Repl. CH16106 (6)
30x47x8TC
Seal 655, 670, 755, 770, 790, (6) 855, 955 Repl. M800448
OR-750
O-ring 650 sn 015680 & up (12) Repl. CH11572
OR-500
O-ring 650 Repl. CH11436 (14)
AC-1364
Seal collar 650 Repl. CH14654 (15)
AS-4306
Seal collar 655, 670, 755, 770, 790, (15) 855, 955 Repl. M800447
44x57x11.5TC Seal 650, 655, 670, 755, 756, 770 (16) 855, 856, 955 Repl. CH14642 DP-114
Drain plug 650 Repl. CH11414 (21)
OR-160
O-ring 650 Repl. CH10570 (23)
26
FRONT AXLE PARTS w/mechanical front wheel drive (MFWD) SB-4321
Bushing 950, 1050 Repl. CH13147 (5)
35x41x5VB
Seal 950, 1050 Repl. CH16106 (7)
CG-4321
Gasket 950, 1050 Repl. CH13167 (13)
SR-450
Snap ring 950, 1050 Repl. CH13496 (17)
NB-3110
Needle bearing 950, 1050 Repl. CH13171 (16)
AS-4465
Seal, front knuckle lower 950 SN 016620 & up, (21) 1050 before SN 011000 Repl. CH17593
FGC-4274
Housing, LH 950, 1050 Repl. CH19231 (24)
FGC-4321
Housing RH 950, 1050 Repl. CH19232 (24)
TRB-1221
Steering arm bracket, RH 950, 1050 (25) Repl. CH13149
TRB-1211
Steering arm bracket, LH 950, 1050 (36) Repl. CH13148
GHC-4321
Lower cover 950, 1050 Repl. CH13169 (37)
CG-1376
Gasket for GHC-4321 Repl. CH13170
AC-4274
Seal collar 950, 1050 Repl. CH19160 (38)
64x80x13TC
Seal 950, 1050 Repl. CH19161 (39)
AS-4465
Seal 950 sn -020000Repl. CH17593 (39) (Old #’s CH13175 & CH13176)
27
FRONT AXLE PARTS w/mechanical front wheel drive (MFWD)
OR-450
Oring packing 950, 1050 Repl. CH13520 (2)
SC-4491
Seal collar 950, 1050 Repl. M802467 (old # CH13183) (3)
SAH-4321
Housing, stub axle bearing 950, 1050 Repl. CH13177 (4)
65x88x5TC
Seal, dust cover 950, 1050 Repl. CH13179 (5)
65x88x12TC
Seal 950, 1050 Repl. CH13178 (6)
6211-2RS
Bearing 950, 1050 Repl. CH11552 (7)
OR-2000
Oring 950, 1050 Repl. CH13524 (8)
FDG-4321
Gear 950, 1050 Repl. CH13925 (9)
NJ-306E
Bearing 950, 1050 Repl. JD9513 (10)
SS-6190
Seal collar 655, 670, 750, 755, 756, 770, 790, (11) 855, 856, 955 Repl. CH14967
30x47x8TC
Seal 655, 670, 755, 756, 770, 790, 855, (12) 856, 955 Repl. M800448
6204-2RS
Bearing 655, 670, 755, 756, 770, 855, 856, (13) 955 Repl. M800451
AS-4306
Seal sleeve 655, 670, 755, 756, 770, 790, 855, (16) 856, 955 Repl. M800447
AS-1363
Collar, seal 655, 670, 755, 756, 770, 790, 855 (17) 856, 955 Repl. M800446
44x57x11.5TC Seal 650, 655, 670, 755, 756, 770, 790, 855 (18) 856, 955 Repl. CH14642 OR-600
O’ring, hsg to knuckle 655, 670, 755, 756, 770, (29) 855, 856, 955 Repl. CH11571
28
FRONT AXLE PARTS w/mechanical front wheel drive (MFWD) SR-28
Snap ring 750, 850, 870 Repl. CH14681 (1)
SW-4311
Washer 750, 850, 870 Repl. CH14680 (2)
6205-2RS
Bearing 750, 850, 870 Repl. CH11550 (3)
SR-100
Snap ring 750, 850, 870 Repl. CH14670 (4)
6013-2RS
Bearing 750, 850, 870 Repl. CH14687 (5)
SG-1394
Gear (upper) 750, 850, 870 CH14683 (6)
115x145x13.5TCS Seal 750, 850, 870 Repl. CH14662 (7) SA-1385
Shaft 750, 850, 870 Repl. CH14677 (8)
25x40x7TC
Seal, top 750, 850, 870 Repl. CH14659 (9)
SH-1371
Housing, front axle top (L or R) 750, 850, (11) 870 Repl. CH14658
SR-720
Snap ring 850, 870 Repl. CH14669 (12)
OR-70
O-ring 750, 850, 870 Repl. CH14671 (13)
SG-4311
Gear (lower) 750, 850, 870 Repl. CH14684 (21)
NB-4311
Needle bearing 750, 850, 870 Repl. CH14678 (22)
SB-4311 Bushing 750, 850, 870 Repl. CH14679 (23) ----------------------------------------------------------------------------------------------50x68x12.5
Seal 750, 850 Repl. CH14665 (19)
SR-680 Snap ring 750, 850 Repl. CH14668 (20) ------------------------------------------------------------------------------------------------NB-3110
Needle bearing 950, 1050 Repl. CH13171 (17)
AS-4279
Seal sleeve 950, 1050 Repl. CH20145 (20)
64x80x13TC
Seal 950, 1050 Repl. CH19161 (24)
NJ-306E
Bearing 950, 1050 Repl. JD9513 (28)
6211-2RS
Bearing 950, 1050 Repl. CH11552 (33)
65x88x12TC
Seal 950, 1050 Repl. CH13178 (34)
65x88x5TC
Seal 950, 1050 Repl. CH13179 (35)
29
FRONT AXLE PARTS w/mechanical front wheel drive (MFWD)
LN-35
Lock nut 750, 850 Repl. CH13515 (1)
LW-4311
Lock washer 750, 850 Repl. CH14698 (2)
SG-4122
Gear, stub axle 750, 850, 870 Repl. M804970 (3)
6211-2RS
Bearing 750, 850, 870, 950, 1050 Repl. CH11552 (4)
SR-242
Snap ring 750, 850, 870 Repl. CH13490 (5)
SC-4161
Collar 750, 850 Repl. CH14699 (7)
SR-680
Snap ring 750, 850 Repl. CH14668 (8)
6008-2RS
Bearing 750, 850 Repl. CH14592 (9)
6210-2RS
Bearing 870 Repl. CH11551 (9)
AS-4328
Seal 870 Repl. M804187 (10)
50x68x12.5
Seal 750, 850 Repl. CH14665 (10)
SC-4311
Collar, seal 750, 850 Repl. CH14700 (11)
OR-400
O-ring 750, 850 Repl. CH14701 (12)
OR-500
O-ring 870 Repl. CH11436 (12)
M14x25
Bolt, lug 750, 850 Repl. 19M7646 (15)
30
FRONT AXLE PARTS w/mechanical front wheel drive (MFWD)
6304-2RS
Bearing 650 Repl. CH13511 (2)
6207-2RS
Bearing 750, 850, 870 Repl. JD9344 (2)
6208-2RS
Bearing 970, 1070 Repl. CH15042 (2)
6209-2RS
Bearing 950, 1050 Repl. JD7692 (old # CH13509) (2)
6210-2RS
Bearing 1250, 1450, 1650 Repl. CH11551 (2)
SG-1352
Gear 750 850, 870 Repl. CH14625 (3)
SG-3110
Gear 950, 1050 Repl. CH18039 (3)
6206-2RS
Bearing 650 Repl. CH14676 (4)
6209-2RS
Bearing 950, 1050 Repl. CH13512 (4)
6211-2RS
Bearing 1250, 1450, 1650 Repl. CH17453 (4)
SA-4321
Spindle shaft 950, 1050 Repl. CH13871 (6) For 1050 must use SG-4321, 6306-2RS and SR-34
SA-950
Spindle shaft (original style) 950, 1050 Repl. AM876190 (6)
SG-1389
Gear, lower spindle 950, 1050 Repl. CH13172 (7)
SR-850
Snap ring 950, 1050 Repl. CH13495 (8)
6308-2RS
Bearing 1250, 1450, 1650 Repl. CH16417 (9)
6209-2RS
Bearing 950, 1050 Repl. JD7692 (old # CH13509) (9)
SA-950
Vertical Spindle 950, 1050 Repl. AM876190 (8)
31
FRONT AXLE PARTS w/mechanical front wheel drive (MFWD)
6304-2RS
Bearing 655, 670, 755, 756, 770, 855, 856 Repl. CH13511 (4)
6207-2RS
Bearing 655, 670, 755, 756, 770, 855, 856 Repl. JD9344 (old # CH14627) (6)
SR-34
Snap ring 655, 670, 755, 756, 770, 855, 856 Repl. CH13489 (7)
6009-2RS
Bearing 655, 670, 755, 756, 770, 855, 856 Repl. CH14581 (10)
6211-2RS
Bearing 870 Repl. CH11552 (10)
6210-2RS
Bearing 870 Repl. CH11551
AS-4447
Seal 655, 670, 755, 756, 770, 855, 856 Repl. CH14691 (13)
AS-4328
Seal 870 Repl. M804187 (13)
AC-4447
Collar, seal 655, 670, 755, 756, 770, 855, 856 Repl. CH14692 (14)
32
FRONT AXLE PARTS w/mechanical front wheel drive (MFWD)
RGP-4311
Front ring gear & pinion (1) 750, 850 sn 16001 up Repl. CH14575
SC-3662
Collar, spacer 750, 850 sn 16001 & up (4) Repl. CH14619
40x55x8TC
Seal 750, 850 sn 16001 & up Repl. CH14620 (5)
SC-4191
Collar, seal 750, 850 sn 16001 & up Repl. CH14579 (3)
SC-1317
Collar, seal 950, 1050 Repl. CH13151
30x52x8TC
Seal 650 Repl. CH14633
45x62x9TC
Seal 950, 970, 990, 1050, 1070 Repl. CH13163 (5)
32006
Bearing 750, 850 Repl. CH14577 (6)
32007
Bearing 950, 970, 990, 1050, 1070 Repl. CH11146 (6)
6009-2RS
Bearing 750, 850 Repl. CH14581 (10)
6012-2RS
Bearing 950, 1050 Repl. CH13507 (10)
PG-4740
Spider gear 750, 850 sn 16001 & up, 870 Repl. CH14595 (15)
PG-4190
Spider gear 750, 850 sn 16001 & up, 870 Repl. CH14598 (16)
PH-4311
Pinion housing 750, 850 sn 16001 & up Repl. CH14618 (20)
(3)
(5)
33
CB-4191
Boot (rubber) 750 Repl. M801916 (old # CH14617)
(1)
DS-4191
Sleeve 750 Repl. CH14612
SB-4190
Ball 750 Repl. R26552 (old # CH10566)
DC-4191
Coupling 750, 850 sn 16001 & up Repl. CH14613
SS-4191
Splined shaft seal 750, 850 SN 16001 - Repl. CH14614 (5)
DW-4191
Washer 750 Repl. CH14615
(6)
DS-4311
Spring 750 Repl. CH14616
(7)
(2) (3) (4)
34
DROP BOX PARTS
30x52x8TC
Seal, drop box 750, 850 Repl. CH14633 (1)
35x55x11TC Seal, drop box 950, 1050 Repl. CH13066 (1) 42x60x9TC
Seal, drop box 1250, 1450, 1650 Repl. CH10921 (1)
SS-6190
Sleeve or spacer 750, 850 Repl. CH14967 (2)
SS-4274
Sleeve or spacer 950, 1050 Repl. CH13105 (2)
SC-4130
Sleeve or spacer 1250, 1450, 1650 Repl. CH10959 (2)
6304-2RS
Bearing 850, 950, 1050 Repl. CH13511 (3)
6005-2RS
Bearing 650 Repl. CH14828 (4)
6205-2RS
Bearing 750, 850, 950, 1050 Repl. CH11550 (4)
6306-2RS
Bearing 1250, 1450, 1650 Repl. CH15035 (4)
SR-550
Snap ring 950, 1050 Repl. CH13494 (5)
OR-210
O-ring 750 Repl. CH14583 (6)
SR-29
Snap ring 750, 950, 1050 Repl. CH13488 (7)
6005-2RS
Bearing 750 Repl. CH14828 (9)
6006-2RS
Bearing 950, 1050 Repl. CH13505 (9)
6205-2RS
Bearing 850 Repl. CH11550 (9)
6207-2RS
Bearing 1250, 1450, 1650 Repl. CH14627 (9)
Clutch & Linkage CR-740
Turnbuckle 650 Repl. CH11452 (2)
CR-4197
Rod, clutch, RH thread 650 Repl. CH14777 (3)
CR-4440
Rod, clutch, LH thread 650 Repl. CH14776 (4)
35
Clutch & Linkage CR-2246 (1) Clutch rod end – LH thread 750, 850 SN -016,000, 950 SN -020,000 Repl. CH11398 BR-100
(1) Clutch rod end – LH thread (clevis type) 850 SN 016,001-, 950 SN 020,001-, 1050 Repl. CH10989
CR-4420 (2) Clutch rod 750 Repl. CH14779 CR-4145 (2) Clutch rod end – RH thread 850 SN-016,000, 950 SN -020,000 Repl. CH11189
CD-4335
PTO disc for models w/dual clutch 850, 870, 950, 970, 990, 1050, 1070, 4005 (9” x 13 spline) Repl. M804454 (old # CH13090, LVU801087 & M806764)
CD-4115
Clutch disc, 7-7/8” x 7/8 – 20 spline, 650, 750 Repl. LVU801674 (old CH14760 & M805461)
PP-4115
Pressure plate 650, 750 Repl. LVU803018 (Old # CH14762)
TO-4115
Clutch throw-out (release) bearing 650, 670, 750, 770, 790 w/single clutch Repl. CH14769
CD-4276
Clutch disc, 8-1/2” x 1” – 13 spline, 670 & 770 w/ single clutch Repl. M802964 850 & 950 w/ single clutch Repl. CH18375
PP-4276
Pressure plate – 670 & 770 w/ single clutch Repl. M809105 (old # M802965)
PP-4081
Pressure plate 850 & 950 w/ single clutch Repl. LVU803007 (old # CH11720)
TO-4276
Clutch throw-out (release) bearing 850 & 950 w/single clutch Repl. CH11464
36
SB-4065
Shifter boot 650, 750, 850, 950, 1050 Repl. CH10854
RS-4420
Spring, clutch brg return 650, 750 (1) Repl. CH14770
Shift Lever Guide SLG-4150
Shift lever guide 750 Repl. CH14911
Transmission Bearing 5306-2RS
Bearing, countershaft gear 850, 950 Repl. CH11196
SF-13
Shift fork, 1st & 2nd 850 -007761 SN, (1) 950 -010860 SN Repl. CH10923
SB-4190
Ball only 850, 950 Repl. R26552 (2)
SR-4145
Shift rail, 1-3 & 2-4 for 850 -016,000 SN, (6) 950 -020,000 SN Repl. CH11206
RP-625
Pin 850, 950 Repl. CH11501 (9)
Clutch Safety Switch SS-4440
Clutch safety switch 650, 750, 850, 950, 1050, (6) 1450, 1650 Repl. CH20208 (old # CH10155)
37
Transmission and PTO Gaskets TG-2412
Gasket, transmission 750 Repl. LVU801603 (1) (Old # CH14798)
THROTTLE PARTS TRS-3994
Throttle return spring 2000, 2500, 3000 Repl. 193994-10203
BRAKE PARTS BDC-3630
Brake drum cover 750, 770, 790, 3005 (5) Repl. CH15070
BCG-4420
Brake cover gasket 750, 770, 790, 3005 (6) Repl. M803177 (old # CH15071)
BCG-4130
Brake cover gasket 850 Repl. LVU801217 (6) (old # CH10980)
BCG-4320
Brake cover gasket 950, 1050 Repl. M806836 (6) (old # CH11252)
BS-4440
Brake shoe 650, 670 Repl. M805305 (old # CH20140) (9)
BRS-4200
Brake return spring 650, 670 Repl. CH15066 (8)
BS-4420
Brake shoe 750, 770, 790, 3005 Repl. M805735 (old # CH15072) (9)
BRS-4150
Brake return spring 750, 770, 790, 3005 Repl. CH15073
BS-4130
Brake shoe 850 Repl. M805898 (old # M801894) (9)
(8)
38
BRS-4130
Brake return spring 850 Repl. CH10977 (8)
BS-4145
Brake shoe 950 Repl. M805899 (old # CH11247) (9)
BRS-4145
Brake return spring 950, 1050 Repl. CH11248 (8)
BS-4320
Brake shoe 1050 Repl. M805897 (old # CH13123) (9)
BD-3657
Brake drum 750, 770, 790, 3005 Repl. CH15074 (10)
BC-3671
Brake camshaft, LH 750 Repl. CH15075
(11)
BC-3672
Brake camshaft, RH 750 Repl. CH15078
(11)
BPS-4145
Brake pedal return spring 850, 950
Repl. CH11264
Brake parts continued on next page
39
Brake parts continued BR-103 (3)
Brake turnbuckle 650, 750, 850, 950, 1050
Repl CH11416 (10mm X 90mm OAL) BR-4145 (4) Brake rod end – RH thread 850, 950 Repl CH11271
(OAL approx. 13”) BR-102 (4)
Brake rod end – RH thread 650 Repl. CH15086; 870, 970, 1070 Repl. CH11061 (OAL 11-1/2”)
BR-4320 (4) Brake rod end – RH thread 1050 Repl. CH13131 (OAL approx. 8”) BR-4420 (4) Brake rod end – RH thread 750 Repl. CH15093 (OAL approx. 10”) BR-3775 (4) Brake rod end – RH thread 670, 770, 790 Repl. M803758 (OAL approx. 4-1/8”) BR-100 (5)
Brake rod end – LH thread – 650, 750, 850, 950, 1050 Repl. CH10989 (OAL approx. 4-3/8”)
BR-101 (5)
Brake rod end – LH thread 870, 970, 1070 Repl. M804721 (OAL approx. 8”)
-118 (8)
Brake rod clevis pin w/hair pin clip 650, 750, 850, 950, 1050 Repl. CH10857
6305-2RS
Bearing, brake stub axle 670 Repl. CH11554
6206-2RS
Bearing, brake stub axle 770 Repl. CH14887
6307-2RS
Bearing, brake stub axle 850 Repl. CH11556
SC-4305
Collar, seal 650, 670, 770 Repl. CH19719 (1)
SC-4130
Collar, seal 850 Repl. CH10959 (1)
SC-3343
Collar, seal 950 Repl. CH11236 (1)
35x52x11TC Seal 650, 670, 770, 790 Repl. CH19718 42x80x9TC
Seal 850 Repl. CH10960
40
REAR AXLE PARTS
RAC-3271
Housing, rear axle seal 850, 950, 1050 Repl. CH11228 (1)
RAHG-4420 Gasket, rear axle housing 750 Repl. CH15015 (2) AC-4447
Collar, rear axle seal 650, 655, 670, 750, 755, (5) 770, 855 Repl. CH14692
AS-4447
Seal, rear axle 650, 670, 750, 770 Repl. CH14691 (6) 655 -610729 SN, 755 & 855 -827728 SN
SR-40
Snap ring 670, 770 Repl. CH11484 (1)
6208-2RS
Bearing, inner axle 650, 670, 770 Repl. CH15042 (7)
6009-2RS
Bearing, outer axle 650, 670, 770 Repl. CH14581 (8)
6209-2RS
Bearing, inner & outer 750 Repl. JD7692 (7 & 8) (Old # CH13509)
41
AC-4130
Collar, seal 850 can Repl. CH12573 when used with 58x80x12TC seal, 990 Repl. CH12573
(2)
58x80x12TC Seal used with AC-4130 (3) 60x80x12TC Seal 850, 870, 970, 990 Repl. CH11329 (3) SC-4145
Collar, seal 950, 1050, 1070, 4500, 4600, 4700 Repl. CH11243 (2)
AS-4327
Seal, axle 1070, 4500, 4600, 4700 Repl. M804655 (3)
75x100x13TC Seal, axle 950, 1050 Repl. CH11230 (3) 75x100x7TC Seal, axle dust 950, 1050 Repl. CH11231 (3a) 6009-2RS
Bearing, outer axle 655 -610729 SN, 755 & 855 (6) -827728 SN Repl. CH14581
6011-2RS
Bearing, inner axle 1070 Repl. JD9292 (old # M804641) (8)
6209-2RS
Bearing, outer axle 655 SN 610730-, 755 & 855 (6) SN 827729- Repl. JD7692
6207-2RS
Bearing, inner axle 655, 755, 855 Repl. JD9344 (8)
6210-2RS
Bearing, inner axle 850 Repl. CH11551 (8)
6210-2RSNR Bearing w/snap ring, outer axle 850, (6) 870, 970 Repl. CH10965 6212-2RS
Bearing, inner axle 950, 1050 Repl. CH11553 (8)
6312-2RS
Bearing, outer axle 950 Repl. CH11555 (6)
6212-2RS
Bearing, outer axle 1050 Repl. CH13386 (6)
42
PTO Seals, Bearings & Couplers
SC-4130
Collar, PTO seal 850, 870, 950, 970, (10) 1050, 1070, 1250 Repl. CH10959
6005-2RS
PTO bearing 650 –005128 Repl. CH14828 (6)
6205-2RS
PTO bearing 750, 850, 870, 950, 970, (6) 1070, 1050 Repl. CH11550
6205-2RSNR PTO bearing w/snap ring 670, 770 Repl. CH14888 (6) 6006-2RS
PTO bearing 650 Repl. CH13505 (7)
6007-2RS
PTO bearing 670, 770 Repl. CH13506 (7)
6206-2RS
PTO bearing 750 Repl. CH14887 (7)
6207-2RS
PTO bearing 870, 970, 1070 Repl. JD9344 (7)
6307-2RS
PTO bearing 1250 Repl. CH16424 (7)
6308-2RS
PTO bearing 1450, 1650 Repl. CH16417 (7)
38x50x8TC
PTO seal 650 Repl. CH14788
(8)
38x55x8TC
PTO seal 750 Repl. CH14809
(8)
38x62x9TC
PTO seal 1450, 1650 Repl. CH18637 (8)
40x55x8TC
PTO seal 655, 670, 755, 756, 770, 855, 856 (8) Repl. CH14620
AC-4210
Collar, PTO seal 655, 755, 756, 850, 855, 856, 950, 955, 1050 (10) Repl. CH13092
42x60x9TC
PTO seal 850, 870, 950, 970, 1050, 1070, (8) 1250 Repl. CH10921
Continued on next page
43
PTO Bearing, Seals and Couplers 5305-2RS
PTO bearing 850 SN -16000, (5) 950 SN -20000 Repl. CH19229
6204-2RS
PTO bearing 670, 770 Repl. M803810 (5)
6304-2RS
PTO bearing 650 Repl. CH13511; 750 Repl. JD8509 (5)
6308-2RS
PTO bearing 1250, 1450, 1650 Repl. CH16417 (5)
6204-2RS
PTO bearing 750 Repl. CH13508 (3)
6304-2RS
PTO bearing 870, 970, 1070 Repl. CH13511 (3)
SR-40
Snap ring 850, 950, 1050 Repl. CH11484 (9)
SC-2522
Coupler 1250, 1450, 1650 Repl. CH10870 (1)
SC-2618
Coupler 850 SN 16001 & up, 870, 950 SN 20001 & up, (1) 970, 1050, 1070 Repl. CH13718
SC-4300
Coupler 650, 670, 750, 770, 790 Repl. CH14838 (1)
Rock Shaft Seals SS-4130
Splined rock shaft seal 850, 950, 1050 (D) Repl. CH10996
OR-600
Oring 850, 950, 1050 Repl. CH11571 (B)
SS-4150
Splined rock shaft seal 750 (D) Repl. CH15138
OR-500
Oring 750 Repl. CH11436 (B)
44
Hydraulic cover gasket HCG-4197
Hyd cover gasket 650 Repl. LVU801601 (4) (Old # CH15106)
HCG-4312
Hyd cover gasket 750 Repl. LVU801609 (4) (Old # CH15111)
HCG-4145
Hyd cover gasket 850, 950, 1050 (4) Repl. LVU801617 (old # CH17998)
AB-42280
Breather tube 650, 750 Repl. CH11403 (3)
HH-4150
Hyd hose 650, 750 Repl. CH11407 (11)
HP-7C
Hyd pump 650 Repl. CH15095
HP-9C
Hyd pump 750 Repl. CH15096
HV-451
Hydraulic valve 650, 750, 850, 950 Repl. LVA801753 (Old # CH16132)
HVG-4151
Gasket for HV-451 valve Repl. CH11428
OR-112
O-ring, hyd. valve base Repl. CH11570
10x20x7TC
Seal for hyd. valve Repl. CH11426
JB-1500
Banjo bolt fitting 1250, 1450, 1650 (1) Repl. CH16844
PG-3414
Copper washer for JB-1500 Repl. CH11548 (2)
OR-200
Oring 1250, 1450, 1650 Repl. CH11562 (5)
Hydraulic Pumps HP-7C
Hydraulic Pump 650
HP-9C
Hydraulic Pump 750
HP-9A
Hydraulic Pump 850 / 950
HP-3000
Hydraulic Pump 1050 (JD Part – New part available soon.)
45
Pins, Chains, and Side Links
P-3916
Upper arm pin Pin dia. ¾”, 12mm thread, 3-9/16” OAL Can replace CH10998
P-4516
Upper arm pin w/ shoulder, ¾” pin dia., 16mm thread, 4-5/16” OAL
P-771
Top link pin Cat. 1
¾” dia. X 2-3/4” usable length.
P-772
Top link pin Cat. 1
¾” dia. X 3-7/8” usable length.
P-728
Lift arm pin Cat. 1
7/8” X 7/8” X 5-1/2” OA length.
SC-350
Stabilizer chain 3-1/2” long rd. ctr. tube w/counter wt.
SC-425
Stabilizer chain 4-1/4” long sq. ctr. tube w/lock nut 950, 1050
SL-975
Side link, non adjustable w/clevis pin
SL-1150
Side link, non adjustable w/clevis pin
SL-155
Side link, non adjustable w/clevis pin 950, 1050 Repl. CH19069
ASL-750
Adj. Side link – 7-1/2” center tube w/clevis pin
ASL-950
Adj. Side link – 9-1/2” center tube w/clevis pin
P-159
Clevis pin w/hair pin clip for ASL-750, ASL-950, SL-155, SL-975, SL-1150 side links
46
HB-4155
Hood hinge bolt bushing – rubber 650, 750, 850, 950, 1050, 1250, 1450, 1650 Repl. CH15723
HB-100
Hood hinge bolt 650, 750, 850, 950, 1050, 1250 Repl. CH14152
SB-100
Seat bushing 3/8” ID x 5/8” long 650, 750 Repl. CH11437
RC-151
Rubber cushion, seat – approx. 1-1/2” tall (B) 650, 750 Repl. CH15277
SR-205
Seat rod (hinge pin) – 205mm long 650, 750, 850, (C) 950, 1050 Repl. CH11075 (w/ washers & cotter pins)
RD-6327
Rubber damper for seat rod 650, 750, 850, (D) 950, 1050 Repl. CH18084
Seat Mounting Hardware (A)
47
SA-1654B This universal seat comes with an adjustable bracket set that allows the unit to fit most any tractor with a flip type seat
SB-054 Adjustable mounting bracket set for most flip type seats
SB-2000 Seat bracket only (one piece) SA-1654C High back universal seat with one piece bracket
48
SEALS Size 10x20x7TC 115x145x13.5TC 14x25x7TC 20x32x7TC 20x35x7TC 20x35x7TC 22x35x8TC 25x40x7TC 25x42x8TC 26x38x7TC 30x42x7TC 30x45x8TC 30x47x8TC 30x52x8TC 35x41x5VB 35x48x10TC 35x52x11TC 35x55x11TC 35x55x8TC 38x50x8TC 38x50x8TC 38x52x9TC 38x55x8TC 38x62x9TC 40x55x8TC 40x55x8TC 40x62x19TC 40x62x8TC 42x60x9TC 42x60x9TC 42x80x9TCV 44x57x11.5TC 45x62x9TC 45x68x9TC 50x68x12.5 55x78x12TC 60x80x12TC 64x80x13TC 65x88x05TC 65x88x12TC 75x100x13SC 75x100x13TC 75x100x7TC 90x115x13TC AS-4328 AS-4447 17x30x7TC
Repl. JD # CH11426 CH14662 CH15098 CH19260 CH14814 M806768 CH13097 CH14659 R91130 CH14736 CH14638 CH11465 M800448 CH14633 CH16106 CH14541 CH14557 CH13066 CH14996 CH14788 M800723 CH11143 CH14809 CH18637 CH14620 CH14620 CH10879 CH13067 CH10921 CH10921 CH10960 CH14642 CH13163 AL38095 CH14665 CH11227 CH11329 CH19161 CH13179 CH13178 CH18877 CH11230 CH11231 CH18878 M804187 CH14691 M805569
Application 3pt. Valve seal 650, 750, 850, 950 Seal, front knuckle 750, 850 Hyd. pump shaft seal 650, 670, 750 Seal, PS top 1050, 1250, 1450, 1650 Seal, front transmission plate 750 Seal, frt drive shaft 655, 755, 855 Seal, dual clutch main drive shaft 850, 950, 1050 Seal, top cap 850 w/MFWD Seal, frt axle diff 670 770 Steering column bearing seal 650, 750 Seal, MFWD pivot 850
Old # CH17860
Old # MT1160
Seal, front axle 670 770 Seal, drop box 750, 850 Seal, top cap 950 & 1050 w/MFWD Seal, spindle 650 Seal, front wheel hub 650 Seal, drop box 950, 1050 Brake shaft seal 750 PTO seal 650 Seal, horizontal shaft inner 1050 Seal, spindle 850, 950, 1050 PTO seal 750 PTO seal 1450, 1650 PTO seal 655, 670, 755, 756, 770, 855, 856 Seal, front differential housing 750, 850 Seal, front hub, 2wd 870, 970, 990, 1070 Seal, trans main shaft 850, 950, 1050 Seal, drop box 1250, 1450, 1650 PTO seal 850, 870, 950, 970, 1050, 1070, 1250 Seal, brake shaft 850 Seal, front knuckle 650 Seal, front differential housing 950, 1050 Seal, rear axle 900HC Old # M800118 Seal, stub axle 750, 850 Seal, brake shaft 950 Seal, rear axle 850 Seal, lower knuckle 950, 1050 Seal, stub axle dust 950, 1050 Seal, stub axle 950, 1050 Seal, rear axle inner 1650 Seal, rear axle 950, 1050 Seal, rear axle dust 950, 1050 Seal, rear axle outer 1650 Seal, front knuckle 870 Seal, rear axle 650, 670, 750, 770; MFWD stub axle 670 770 Seal 4100, 4110, 4115 Compact Utility Tractors
49
Related Documents 2w1qw
John Deere Catalog 6r6a56
October 2021 0
John Deere Parts Catalog 54342n
June 2021 0
John Deere 5j735
April 2023 0
John Deere 5j735
November 2022 0
John Deere - Parts Catalog - Frame 5b 5j3iv
June 2021 0
John Deere - Parts Catalog - Frame 9 1n3e4o
November 2019 61More Documents from "Shannon Horn" 3j1s4c
John Deere Catalog 6r6a56
October 2021 0
310257690.pdf 6w671q
November 2019 45
April 2022 0
Como Desbloquear Pdf Para Copiar Texto 5k4j52
November 2019 67
F 111 Aardvark Color Walk Around Pdf 1u1i4e
December 2019 77
