FREERADIUS SERVER 1. Install dependencies yang dibutuhkan untuk SSL (pake libssl-dev, libmysqlclient-dev atau libmysqlclient16-dev, libtool) root@:
# root@:
# root@:
# root@:
#
apt-get apt-get apt-get apt-get
install install install install
libssl-dev libmysqlclient-dev libmysqlclient16-dev libtool
2. Ekstrak file freeradius-server-2.2.0.tar.bz2 dengan cara root@:
# tar -jxvf freeradius-server-2.2.0.tar.bz2
3. Buat folder baru di usr root@:
# mkdir /usr/local/radius
4. Masuk ke folder hasil ekstrak freeradius dan install root@:
# ./configure --prefix=/usr/local/radius --with-openssl --with-rlm-sql-mysql root@:
# make && make install
5. Konfigurasi file freeradius (radius.conf, sql.conf, clients.conf) root@:
# cd /use/local/radius/etc/raddb root@:
# nano radius.conf modules { $INCLUDE ${confdir}/modules/ $INCLUDE eap.conf $INCLUDE sql.conf sqlcounter noresetcounter { counter-name = Max-All-Session-Time check-name = Max-All-Session sqlmod-inst = sql key = -Name reset = never query = "SELECT SUM(AcctSessionTime) FROM radacct where Name='%{%k}'" } # $INCLUDE sql/mysql/counter.conf # $INCLUDE sqlippool.conf } instantiate { exec expr noresetcounter # daily expiration time }
root@:
# nano sql.conf database = "mysql" driver = "rlm_sql_${database}" # Connection info: server = "localhost" #port = 3306 = "hotspot" = "hotspot" radius_db = "hotspot" root@:
# nano clients.conf client localhost { ipaddr = 127.0.0.1 # ipv6addr = :: # any. # netmask = 32
# # # # }
::1 == localhost
secret = radiussecret require_message_authenticator = no shortname = localhost nastype = other = !root = somepas virtual_server = home1 coa_server = coa
root@:
# nano /usr/local/radius/etc/raddb/siteavailable/default authorize { # filter_name preprocess # auth_log chap mschap # digest # wimax # I suffix # ntdomain eap { ok = return } # unix files sql noresetcounter
# # # #
etc_smbwd ldap daily checkval expiration time pap
} ing { detail # daily unix radutmp # sradutmp # main_pool sql # if (noop) { # ok # } # sql_log # pgsql-voip exec attr_filter.ing_response } session { radutmp sql } post-auth { # main_pool # reply_log sql # sql_log # ldap exec # wimax # update reply { # Reply-Message += "%{TLS-Cert-Serial}" # Reply-Message += "%{TLS-Cert-Expiration}" # Reply-Message += "%{TLS-Cert-Subject}" # Reply-Message += "%{TLS-Cert-Issuer}" # Reply-Message += "%{TLS-Cert-Common-Name}" # Reply-Message += "%{TLS-Cert-Subject-Alt-Name-Email}" # # Reply-Message += "%{TLS-Client-Cert-Serial}" # Reply-Message += "%{TLS-Client-Cert-Expiration}" # Reply-Message += "%{TLS-Client-Cert-Subject}" # Reply-Message += "%{TLS-Client-Cert-Issuer}" # Reply-Message += "%{TLS-Client-Cert-Common-Name}" # Reply-Message += "%{TLS-Client-Cert-Subject-Alt-Name-Email}"
# } Post-Auth-Type REJECT { # log failed authentications in SQL, too. sql attr_filter.access_reject } } 6. Buat database baru root@:
# mysql –u root –p mysql> CREATE DATABASE hotspot; mysql> GRANT ALL PRIVILEGES ON hotspot.* ‘hotspot’@’localhost’ IDENTIFIED BY ‘hotspot’; (db, , ) mysql> FLUSH PRIVILEGES; mysql> quit; 7. Import schema.sql dan nas.sql untuk database yang telah dibuat (Skip jika memakai
Phpmyprepaid) root@:
# mysql –u radius –p radius < /usr/local/radius/etc/raddb/sql/mysql/schema.sql root@:
# mysql –u radius –p radius < /usr/local/radius/etc/raddb/sql/mysql/nas.sql mysql> INSERT INTO radcheck (Name, Attribute, Value) VALUES ('test','-','test'); 8. Aktifkan service radius dan cek koneksi Terminal 1 root@:
# /usr/local/radius/sbin/radius –X Terminal 2 root@:
# /usr/local/radius/bin/radtest test test localhost 0 radiussecret
CHILLISPOT 1. Install chillispot_1.0-10_i386.deb root@:
# dpkg –i –force-architecture chillispot_1.010_i386.deb
2. konfigurasi chilli.conf root@:
# nano /etc/chilli.conf #fg #debug #interval 3600 #pidfile /var/run/chilli.pid #statedir ./ net 192.168.182.0/24 #dynip 192.168.182.0/24 #statip 192.168.182.0/24 dns1 208.67.222.222 dns2 208.67.220.220 #domain key.chillispot.org #ipup /etc/chilli.ipup #ipdown /etc/chilli.ipdown #radiuslisten 127.0.0.1 radiusserver1 127.0.0.1 radiusserver2 127.0.0.1 #radiusauthport 1812 #radiusacctport 1813 radiussecret radiussecret #radiusnasid nas01 #radiuslocationid isocc=us,cc=1,ac=408,network=ACMEWISP_NewarkAirport #radiuslocationname ACMEWISP,Gate_14_Terminal_C_of_Newark_Airport #proxylisten 127.0.0.1 #proxyport 3128 #proxyclient 192.168.182.0/24 #proxysecret radiussecret dhif wlan0 #dhmac 00:00:5E:00:02:00 #lease 600 uamserver https://192.168.182.1//.php #sesuai path & file uamhomepage http://192.168.182.1:3990/pre uamsecret uamsecret #uamlisten 192.168.182.1 #uamport 3990 uamallowed 192.168.137.2 #uamanydns #macauth #macallowed 00-0A-5E-AC-BE-51,00-30-1B-3C-32-E9 #macwd #macsuffix suffix
APACHE SSL root@:
# mkdir /etc/apache2/ssl root@:
# make-ssl-cert /usr/share/ssl-cert/ssleay.cnf /etc/apache2/ssl/apache.pem root@:
# nano /etc/apache2/site-available/ssl NameVirtualHost *:443
Server @localhost SSLEngine On SSLCertificateFile /etc/apache2/ssl/apache.pem DocumentRoot /var/www/
AllowOverride None Options ExecCGI -MultiViews +SymLinksIfOwnerMatch Order allow,deny Allow from all
ErrorLog /var/log/apache2/error.log LogLevel warn CustomLog /var/log/apache2/access.log combined ServerSignature On Alias /doc/ "/usr/share/doc/"
Options Indexes MultiViews FollowSymLinks AllowOverride None Order deny,allow Deny from all Allow from 127.0.0.0/255.0.0.0 ::1/128
root@:
# a2enmod ssl root@:
# a2ensite ssl
PHPMYPREPAID 1. Install phpmyprepaid sesuai file config radius 2. Alter database ALTER TABLE `group` ADD `priority` INT( 11 ) NOT NULL DEFAULT ’1′ AFTER `location_id`;
3. Edit sql.conf group_table = "group"
4. Edit /usr/local/radius/etc/raddb/dictionary ATTRIBUTE Max-All-Session 3000 integer
SQUID PROXY acl kejar src 192.168.182.0/24 acl block dstdomain -i "/etc/squid/block.txt" acl dhuhur time SMTWHA 11:30-12:00 acl jumat time F 11:30-12:30 acl ashar time SMTWHFA 15:00-15:30 acl maghrib time SMTWHFA 17:00-18:00 acl url_regex -i ftp .exe .mp3 .vqf .tar.gz .gz .tar .rpm .zip .rar .avi .mpeg .mpe .mpg .qt .ram .rm .iso .raw .wav .mov .msi .mp4
http_access http_access http_access http_access http_access http_access
deny block deny dhuhur deny jumat deny ashar deny maghrib allow kejar
delay_pools 2 delay_class 1 2 delay_parameters 1 -1/-1 -1/-1 delay_class 2 2 delay_parameters 2 -1/2048000 10000/2049000 delay_access delay_access delay_access delay_access
2 2 1 1
allow deny all deny allow all
reply_body_max_size 50000000 allow
NAT FIREWALL #!/bin/sh # # Firewall script for ChilliSpot # A Wireless LAN Access Point Controller # # Uses $EXTIF (eth0) as the external interface (Internet or intranet) and # $INTIF (eth1) as the internal interface (access points). # # # SUMMARY # * All connections originating from chilli are allowed. # * Only ssh is allowed in on external interface. # * Nothing is allowed in on internal interface. # * Forwarding is allowed to and from the external interface, but disallowed # to and from the internal interface. # * NAT is enabled on the external interface. IPTABLES="/sbin/iptables" EXTIF="eth0" INTIF="wlan0" $IPTABLES -P INPUT DROP $IPTABLES -P FORWARD ACCEPT $IPTABLES -P OUTPUT ACCEPT #Allow related and established on all interfaces (input) $IPTABLES -A INPUT -m state --state RELATED,ESTABLISHED -j ACCEPT #Allow releated, established and ssh on $EXTIF. Reject everything else. $IPTABLES -A INPUT -i $EXTIF -p t -m t --dport 22 --syn -j ACCEPT $IPTABLES -A INPUT -i $EXTIF -j REJECT #Allow related and established from $INTIF. Drop everything else. $IPTABLES -A INPUT -i $INTIF -j DROP #Allow http and https on other interfaces (input). #This is only needed if authentication server is on same server as chilli $IPTABLES -A INPUT -p t -m t --dport 80 --syn -j ACCEPT $IPTABLES -A INPUT -p t -m t --dport 443 --syn -j ACCEPT #Allow 3990 on other interfaces (input). $IPTABLES -A INPUT -p t -m t --dport 3990 --syn -j ACCEPT
#Allow everything on loopback interface. $IPTABLES -A INPUT -i lo -j ACCEPT # Drop everything to and from $INTIF (forward) # This means that access points can only be managed from ChilliSpot $IPTABLES -A FORWARD -i $INTIF -j DROP $IPTABLES -A FORWARD -o $INTIF -j DROP #Enable NAT on output device $IPTABLES -t nat -A POSTROUTING -o $EXTIF -j MASQUERADE ##FOR SQUID## ##Allow transparent proxy (wiboon 1/2) $IPTABLES -A INPUT -p t -m t --dport 3128 --syn -j ACCEPT ##Allow transparent proxy (wiboon 2/2) $IPTABLES -t mangle -A PREROUTING -i tun0 -p t -m t --dport 3128 -syn -j DROP $IPTABLES -t nat -A PREROUTING -i tun0 -p t -m t -d 192.168.182.0/24 --dport 80 -j RETURN $IPTABLES -t nat -A PREROUTING -i tun0 -p t -m t --dport 80 -j REDIRECT --to-ports 3128
Simpan dengan nama s40chilli.iptables, dan aktifkan setiap kali restart root@:
# nano /etc/rc.local sh path/s40chilli.iptables
NB : For activated sh path/s40chilli.iptables
