Lecture-10 Lens Antenna

By-Manthan S. Manavadaria

V. T. Patel Dept. of EC Engineering

Chapter 10: Lens Antenna (Content)  Chapter 10: Lens Antenna

10.1

Dielectric lens, reflector lens antennas, Polyroid

“A microwave

antenna

in

which a dielectric lens is placed in front of the dipole or horn radiator to concentrate the radiated energy into a narrow beam or to focus received energy on the receiving dipole or

horn.”

Reference: http://www.radiogigabit.com/smart-lens-antennas/ Lens Antenna

2

V. T. Patel Dept. of EC Engineering

Dielectric Lens  There are two types of lens antenna  Delay lances (electrical path length increased by lens medium) Ex. Dielectric lances, H plane metal-plate lenses  Fast lances (electrical path length decreased by lens medium) Ex. E plane metal-plate lenses

Lens Antenna

3

V. T. Patel Dept. of EC Engineering

Dielectric Lens  There are two types of dielectric lenses  Non Metallic  Metallic/artificial  Non Metallic Dielectric lens

 This types is similar to optical lens  It may designed by ray analysis geometrical optics.

methods

of

 Metallic or Artificial Dielectric lens  This types is less heavy compare to nonmetallic lens  It consist of discrete metal particles of macroscopic size.

Lens Antenna

4

V. T. Patel Dept. of EC Engineering

Non Metallic Dielectric lens (Fermat’s Principle)

Lens Antenna

5

V. T. Patel Dept. of EC Engineering

Non Metallic Dielectric lens (Fermat’s Principle)

Lens Antenna

6

V. T. Patel Dept. of EC Engineering

Non Metallic Dielectric lens

Reflection Coefficient

Lens Antenna

7

V. T. Patel Dept. of EC Engineering

Metallic/Artificial Dielectric lens

Lens Antenna

8

V. T. Patel Dept. of EC Engineering

Reflector Lens Antenna

Lens Antenna

9

V. T. Patel Dept. of EC Engineering

Polyrod  A dielectric rod or wire can act as a guide for EM waves. This tendency to radiate is turned to advantage in the polyrod antenna. (made of Polystyrene)

Lens Antenna

10

V. T. Patel Dept. of EC Engineering

Lens Antenna
