then ;

The process of matching the new or existing facts against Production Rules is called Pattern Matching, which is performed by the Inference Engine. There are a number of algorithms used for Pattern Matching by Inference Engines including: Linear Rete Treat Leaps Drools implements and extends the Rete algorithm; Leaps used to be provided but was retired as it became unmaintained. The Drools Rete implementation is called ReteOO, signifying that Drools has an enhanced and optimized implementation of the Rete algorithm for object oriented systems. Other Rete based engines also have marketing for their proprietary enhancements to Rete, like RetePlus and Rete III. The most common enhancements are covered in "Production Matching for Large Learning Systems (Rete/UL)" (1995) by Robert B. Doorenbos. The Rules are stored in the Production Memory and the facts that the Inference Engine matches against are kept in the Working Memory. Facts are asserted into the Working Memory where they may then be modified or retracted. A system with a large number of rules and facts may result in many rules being true for the same fact assertion; these rules are said to be in conflict. The Agenda manages the execution order of these conflicting rules using a Conflict Resolution strategy.

Figure 1.1. High-level View of a Rule Engine

There are two methods of execution for a rule system: Forward Chaining and Backward Chaining; systems that implement both are called Hybrid Chaining Systems. As of Drools 5.2 Drools provides seamless hybrid chaining, both forward and backwards. Understanding these two modes of operation is the key to understanding why a Production Rule System is different and how to get the best from it. Forward chaining is "data-driven" and thus reactionary, with facts being asserted into working memory, which results in one or more rules being concurrently true and scheduled for execution by the Agenda. In short, we start with a fact, it propagates and we end in a conclusion.

Figure 1.2. Forward Chaining

Backward chaining is "goal-driven", meaning that we start with a conclusion which the engine tries to satisfy. If it can't it then searches for conclusions that it can satisfy; these are known as subgoals, that will help satisfy some unknown part of the current goal. It continues this process until either the initial conclusion is proven or there are no more subgoals. Prolog is an example of a Backward Chaining engine. Drools can also do backward chaining, which we refer to as derivation queries.

Figure 1.3. Backward Chaining

1.2. Why use a Rule Engine? Some frequently asked questions: 1. When should you use a rule engine? 2. What advantage does a rule engine have over hand coded "if...then" approaches? 3. Why should you use a rule engine instead of a scripting framework, like BeanShell? We will attempt to address these questions below.

1.2.1. Advantages of a Rule Engine Declarative Programming Rule engines allow you to say "What to do", not "How to do it". The key advantage of this point is that using rules can make it easy to express solutions to difficult problems and consequently have those solutions verified. Rules are much easier to read than code. Rule systems are capable of solving very, very hard problems, providing an explanation of how the solution was arrived at and why each "decision" along the way was made (not so easy with other of AI systems like neural networks or the human brain - I have no idea why I scratched the side of the car). Logic and Data Separation Your data is in your domain objects, the logic is in the rules. This is fundamentally breaking the OO coupling of data and logic, which can be an advantage or a disadvantage depending on your point of view. The upshot is that the logic can be much easier to maintain as there are changes in the future, as the logic is all laid out in rules. This can be especially true if the logic is cross-domain or multi-domain logic. Instead of the logic being spread across many domain objects or controllers, it can all be organized in one or more very distinct rules files.

Speed and Scalability The Rete algorithm,the Leaps algorithm, and their descendants such as Drools' ReteOO, provide very efficient ways of matching rule patterns to your domain object data. These are especially efficient when you have datasets that change in small portions as the rule engine can past matches. These algorithms are battle proven. Centralization of Knowledge By using rules, you create a repository of knowledge (a knowledge base) which is executable. This means it's a single point of truth, for business policy, for instance. Ideally rules are so readable that they can also serve as documentation. Tool Integration Tools such as Eclipse (and in future, Web based interfaces) provide ways to edit and manage rules and get immediate , validation and content assistance. Auditing and debugging tools are also available. Explanation Facility Rule systems effectively provide an "explanation facility" by being able to log the decisions made by the rule engine along with why the decisions were made. Understandable Rules By creating object models and, optionally, Domain Specific Languages that model your problem domain you can set yourself up to write rules that are very close to natural language. They lend themselves to logic that is understandable to, possibly nontechnical, domain experts as they are expressed in their language, with all the program plumbing, the technical know-how being hidden away in the usual code.

1.2.2. When should you use a Rule Engine? The shortest answer to this is "when there is no satisfactory traditional programming approach to solve the problem.". Given that short answer, some more explanation is required. The reason why there is no "traditional" approach is possibly one of the following: The problem is just too fiddle for traditional code. The problem may not be complex, but you can't see a non-fragile way of

building a solution for it. The problem is beyond any obvious algorithmic solution. It is a complex problem to solve, there are no obvious traditional solutions, or basically the problem isn't fully understood. The logic changes often The logic itself may even be simple but the rules change quite often. In many organizations software releases are few and far between and pluggable rules can help provide the "agility" that is needed and expected in a reasonably safe way. Domain experts (or business analysts) are readily available, but are nontechnical. Domain experts often possess a wealth of knowledge about business rules and processes. They typically are nontechnical, but can be very logical. Rules can allow them to express the logic in their own . Of course, they still have to think critically and be capable of logical thinking. Many people in nontechnical positions do not have training in formal logic, so be careful and work with them, as by codifying business knowledge in rules, you will often expose holes in the way the business rules and processes are currently understood. If rules are a new technology for your project teams, the overhead in getting going must be factored in. It is not a trivial technology, but this document tries to make it easier to understand. Typically in a modern OO application you would use a rule engine to contain key parts of your business logic, especially the really messy parts. This is an inversion of the OO concept of encapsulating all the logic inside your objects. This is not to say that you throw out OO practices, on the contrary in any real world application, business logic is just one part of the application. If you ever notice lots of conditional statements such as "if" and "switch", an overabundance of strategy patterns and other messy logic in your code that just doesn't feel right: that would be a place for rules. If there is some such logic and you keep coming back to fix it, either because you got it wrong, or the logic or your understanding changes: think ing rules. If you are faced with tough problems for which there are no algorithms or patterns: consider using rules. Rules could be used embedded in your application or perhaps as a service. Often a rule engine works best as "stateful" component, being an integral part of an application. However, there have been successful cases of creating

reusable rule services which are stateless. For your organization it is important to decide about the process you will use for updating rules in systems that are in production. The options are many, but different organizations have different requirements. Frequently, rules maintenance is out of the control of the application vendors or project developers.

1.2.3. When not to use a Rule Engine To quote a Drools mailing list regular: It seems to me that in the excitement of working with rules engines, that people forget that a rules engine is only one piece of a complex application or solution. Rules engines are not really intended to handle workflow or process executions nor are workflow engines or process management tools designed to do rules. Use the right tool for the job. Sure, a pair of pliers can be used as a hammering tool in a pinch, but that's not what it's designed for. --Dave Hamu As rule engines are dynamic (dynamic in the sense that the rules can be stored and managed and updated as data), they are often looked at as a solution to the problem of deploying software. (Most IT departments seem to exist for the purpose of preventing software being rolled out.) If this is the reason you wish to use a rule engine, be aware that rule engines work best when you are able to write declarative rules. As an alternative, you can consider data-driven designs (lookup tables), or script processing engines where the scripts are managed in a database and are able to be updated on the fly.

1.2.4. Scripting or Process Engines Hopefully the preceding sections have explained when you may want to use a rule engine. Alternatives are script-based engines that provide the drive for "changes on the fly", and there are many such solutions. Alternatively Process Engines (also capable of workflow) such as jBPM allow

you to graphically (or programmatically) describe steps in a process. Those steps can also involve decision points which are in themselves a simple rule. Process engines and rules often can work nicely together, so they are not mutually exclusive. One key point to note with rule engines is that some rule engines are really scripting engines. The downside of scripting engines is that you are tightly coupling your application to the scripts. If they are rules, you are effectively calling rules directly and this may cause more difficulty in future maintenance, as they tend to grow in complexity over time. The upside of scripting engines is that they can be easier to implement initially, producing results quickly, and are conceptually simpler for imperative programmers. Many people have also implemented data-driven systems successfully in the past (where there are control tables that store meta-data that changes your applications behavior) - these can work well when the control can remain very limited. However, they can quickly grow out of control if extended too much (such that only the original creators can change the applications behavior) or they cause the application to stagnate as they are too inflexible.

1.2.5. Strong and Loose Coupling No doubt you have heard like "tight coupling" and "loose coupling" in systems design. Generally people assert that "loose" or "weak" coupling is preferable in design , due to the added flexibility it affords. Similarly, you can have "strongly coupled" and "weakly coupled" rules. Strongly coupled in this sense means that one rule "firing" will clearly result in another rule firing, and so on; in other words, there is a clear (probably obvious) chain of logic. If your rules are all strongly coupled, the chances are that the will turn out to be inflexible, and, more significantly, that a rule engine is an overkill. A clear chain can be hard coded, or implemented using a Decision Tree. This is not to say that strong coupling is inherently bad, but it is a point to keep in mind when considering a rule engine and the way you capture the rules. "Loosely" coupled rules should result in a system that allows rules to be changed, removed and added without requiring changes to other, unrelated rules.

Chapter 2. Quick Start 2.1. The Basics

2.1.1. Stateless Knowledge Session 2.1.2. Stateful Knowledge Session 2.2. A Little Theory 2.2.1. 2.2.2. 2.2.3. 2.2.4. 2.2.5.

Methods versus Rules Cross Products Activations, Agenda and Conflict Sets. Inference Inference and TruthMaintenance

2.3. More on building and deploying 2.3.1. Knowledge Base by Configuration Using Changesets 2.3.2. Knowledge Agent

2.1. The Basics 2.1.1. Stateless Knowledge Session So where do we get started, there are so many use cases and so much functionality in a rule engine such as Drools that it becomes beguiling. Have no fear my intrepid adventurer, the complexity is layered and you can ease yourself into with simple use cases. Stateless session, not utilising inference, forms the simplest use case. A stateless session can be called like a function ing it some data and then receiving some results back. Some common use cases for stateless sessions are, but not limited to: Validation Is this person eligible for a mortgage? Calculation Compute a mortgage . Routing and Filtering Filter incoming messages, such as emails, into folders. Send incoming messages to a destination. So let's start with a very simple example using a driving license application.

public class Applicant { private String name; private int age; private boolean valid; // getter and setter methods here }

Now that we have our data model we can write our first rule. We assume that the application uses rules to refute invalid applications. As this is a simple validation use case we will add a single rule to disqualify any applicant younger than 18. package com.company.license

rule "Is of valid age" when $a : Applicant( age < 18 ) then $a.setValid( false ); end

To make the engine aware of data, so it can be processed against the rules, we have to insert the data, much like with a database. When the Applicant instance is inserted into the engine it is evaluated against the constraints of the rules, in this case just two constraints for one rule. We say two because the type Applicant is the first object type constraint, and age < 18 is the second field constraint. An object type constraint plus its zero or more field constraints is referred to as a pattern. When an inserted instance satisfies both the object type constraint and all the field constraints, it is said to be matched. The $a is a binding variable which permits us to reference the matched object in the consequence. There its properties can be updated. The dollar character ('$') is optional, but it helps to differentiate variable names from field names. The process of matching patterns against the inserted data is, not surprisingly, often referred to as pattern matching. Let's assume that the rules are in the same folder as the classes, so we can use the classpath resource loader to build our first KnowledgeBase. A Knowledge Base is what we call our collection of compiled definitions, such as rules and processes, which are compiled using the KnowledgeBuilder. Both the KnowledgeBuilder and KnowledgeBase can be created from the factories KnowledeBuilderFactory and KnowledgeBaseFactory.

KnowledgeBuilder kbuilder = KnowledgeBuilderFactory.newKnowledgeBuilder( kbuilder.add( ResourceFactory.newClassPathResource( "licenseApplication. ResourceType.DRL ); if ( kbuilder.hasErrors() ) { System.err.println( kbuilder.getErrors().toString() ); } KnowledgeBase kbase = KnowledgeBaseFactory.newKnowledgeBase(); kbase.addKnowledgePackages( kbuilder.getKnowledgePackages() ); 



The above code snippet looks on the classpath for the licenseApplication.drl file, using the method newClassPathResource(). The resource type is DRL, short for "Drools Rule Language". Once the DRL file has been added we can check the Knowledge Builder object for any errors. If there are no errors, we can add the resulting packages to our Knowledge Base. Now we are ready to build our session and execute against some data: StatelessKnowledgeSession ksession = kbase.newStatelessKnowledgeSession( Applicant applicant = new Applicant( "Mr John Smith", 16 ); assertTrue( applicant.isValid() ); ksession.execute( applicant ); assertFalse( applicant.isValid() ); 



The preceding code executes the data against the rules. Since the applicant is under the age of 18, the application is marked as invalid. So far we've only used a single instance, but what if we want to use more than one? We can execute against any object implementing Iterable, such as a collection. Let's add another class called Application, which has the date of the application, and we'll also move the boolean valid field to the Application class.

public class Applicant { private String name; private int age; // getter and setter methods here } public class Application { private Date dateApplied; private boolean valid; // getter and setter methods here }

We can also add another rule to validate that the application was made within a period of time. package com.company.license

rule "Is of valid age" when Applicant( age < 18 ) $a : Application() then $a.setValid( false ); end

rule "Application was made this year" when $a : Application( dateApplied > "01-jan-2009" ) then $a.setValid( false ); end

Unfortunately a Java array does not implement the Iterable interface, so we have to use the JDK converter method Arrays.asList(...). The code shown below executes against an iterable list, where all collection elements are inserted before any matched rules are fired.

StatelessKnowledgeSession ksession = kbase.newStatelessKnowledgeSession( Applicant applicant = new Applicant( "Mr John Smith", 16 ); Application application = new Application(); assertTrue( application() ); ksession.execute( Arrays.asList( new Object[] { application, applicant } assertFalse( application() ); 



The

two

execute

methods

execute(Object

object)

and

execute(Iterable objects) are actually convenience methods for the interface BatchExecutor's method execute(Command command).

A CommandFactory is used to create commands, so that the following is equivalent to execute(Iterable it): ksession.execute( CommandFactory.newInsertIterable( new Object[] { appli 



Batch Executor and Command Factory are particularly useful when working with multiple Commands and with output identifiers for obtaining results. List cmds = new ArrayList (); cmds.add( CommandFactory.newInsert( new Person( "Mr John Smith" ), "mrSm cmds.add( CommandFactory.newInsert( new Person( "Mr John Doe" ), "mrDoe" BatchExecutionResults results = ksession.execute( CommandFactory.newBatc assertEquals( new Person( "Mr John Smith" ), results.getValue( "mrSmith" 



CommandFactory s many other Commands that can be used in the BatchExecutor like StartProcess, Query, and SetGlobal.

2.1.2. Stateful Knowledge Session Stateful Sessions are longer lived and allow iterative changes over time. Some common use cases for Stateful Sessions are, but not limited to: Monitoring Stock market monitoring and analysis for semi-automatic buying. Diagnostics Fault finding, medical diagnostics Logistics

Parcel tracking and delivery provisioning Compliance Validation of legality for market trades. In contrast to a Stateless Session, the dispose() method must be called afterwards to ensure there are no memory leaks, as the Knowledge Base contains references to Stateful Knowledge Sessions when they are created. StatefulKnowledgeSession also s the BatchExecutor interface, like StatelessKnowledgeSession, the only difference being that the FireAllRules

command is not automatically called at the end for a Stateful Session. We illustrate the monitoring use case with an example for raising a fire alarm. Using just four classes, we represent rooms in a house, each of which has one sprinkler. If a fire starts in a room, we represent that with a single Fire instance. public class Room { private String name // getter and setter methods here } public classs Sprinkler { private Room room; private boolean on; // getter and setter methods here } public class Fire { private Room room; // getter and setter methods here } public class Alarm { }

In the previous section on Stateless Sessions the concepts of inserting and matching against data was introduced. That example assumed that only a single instance of each object type was ever inserted and thus only used literal constraints. However, a house has many rooms, so rules must express relationships between objects, such as a sprinkler being in a certain room. This is best done by using a binding variable as a constraint in a pattern. This "" process results in what is called cross products, which are covered in the next section.

When a fire occurs an instance of the Fire class is created, for that room, and inserted into the session. The rule uses a binding on the room field of the Fire object to constrain matching to the sprinkler for that room, which is

currently off. When this rule fires and the consequence is executed the sprinkler is turned on. rule "When there is a fire turn on the sprinkler" when Fire($room : room) $sprinkler : Sprinkler( room == $room, on == false ) then modify( $sprinkler ) { setOn( true ) }; System.out.println( "Turn on the sprinkler for room " + $room.getNam end 



Whereas the Stateless Session uses standard Java syntax to modify a field, in the above rule we use the modify statement, which acts as a sort of "with" statement. It may contain a series of comma separated Java expressions, i.e., calls to setters of the object selected by the modify statement's control expression. This modifies the data, and makes the engine aware of those changes so it can reason over them once more. This process is called inference, and it's essential for the working of a Stateful Session. Stateless Sessions typically do not use inference, so the engine does not need to be aware of changes to data. Inference can also be turned off explicitly by using the sequential mode. So far we have rules that tell us when matching data exists, but what about when it does not exist? How do we determine that a fire has been extinguished, i.e., that there isn't a Fire object any more? Previously the constraints have been sentences according to Propositional Logic, where the engine is constraining against individual intances. Drools also has for First Order Logic that allows you to look at sets of data. A pattern under the keyword not matches when something does not exist. The rule given below turns the sprinkler off as soon as the fire in that room has disappeared.

rule "When the fire is gone turn off the sprinkler" when $room : Room( ) $sprinkler : Sprinkler( room == $room, on == true ) not Fire( room == $room ) then modify( $sprinkler ) { setOn( false ) }; System.out.println( "Turn off the sprinkler for room " + $room.getNa end 



While there is one sprinkler per room, there is just a single alarm for the building. An Alarm object is created when a fire occurs, but only one Alarm is needed for the entire building, no matter how many fires occur. Previously not was introduced to match the absence of a fact; now we use its complement exists which matches for one or more instances of some category. rule "Raise the alarm when we have one or more fires" when exists Fire() then insert( new Alarm() ); System.out.println( "Raise the alarm" ); end

Likewise, when there are no fires we want to remove the alarm, so the not keyword can be used again. rule "Cancel the alarm when all the fires have gone" when not Fire() $alarm : Alarm() then retract( $alarm ); System.out.println( "Cancel the alarm" ); end

Finally there is a general health status message that is printed when the application first starts and after the alarm is removed and all sprinklers have been turned off.

rule "Status output when things are ok" when not Alarm() not Sprinkler( on == true ) then System.out.println( "Everything is ok" ); end

The above rules should be placed in a single DRL file and saved to some directory on the classpath and using the file name fireAlarm.drl, as in the Stateless Session example. We can then build a Knowledge Base, as before, just using the new name fireAlarm.drl. The difference is that this time we create a Stateful Session from the Knowledge Base, whereas before we created a Stateless Session. KnowledgeBuilder kbuilder = KnowledgeBuilderFactory.newKnowledgeBuilder( kbuilder.add( ResourceFactory.newClassPathResource( "fireAlarm.drl", get ResourceType.DRL ); if ( kbuilder.hasErrors() ) { System.err.println( builder.getErrors().toString() ); } kbase.addKnowledgePackages( kbuilder.getKnowledgePackages() ); StatefulKnowledgeSession ksession = kbase.newStatefulKnowledgeSession(); 



With the session created it is now possible to iteratvely work with it over time. Four Room objects are created and inserted, as well as one Sprinkler object for each room. At this point the engine has done all of its matching, but no rules have fired yet. Calling ksession.fireAllRules() allows the matched rules to fire, but without a fire that will just produce the health message.

String[] names = new String[]{"kitchen", "bedroom", "office", "livingroo Map<String,Room> name2room = new HashMap<String,Room>(); for( String name: names ){ Room room = new Room( name ); name2room.put( name, room ); ksession.insert( room ); Sprinkler sprinkler = new Sprinkler( room ); ksession.insert( sprinkler ); } ksession.fireAllRules() 



> Everything is ok

We now create two fires and insert them; this time a reference is kept for the returned FactHandle. A Fact Handle is an internal engine reference to the inserted instance and allows instances to be retracted or modified at a later point in time. With the fires now in the engine, once fireAllRules() is called, the alarm is raised and the respective sprinklers are turned on. Fire kitchenFire = new Fire( name2room.get( "kitchen" ) ); Fire officeFire = new Fire( name2room.get( "office" ) ); FactHandle kitchenFireHandle = ksession.insert( kitchenFire ); FactHandle officeFireHandle = ksession.insert( officeFire ); ksession.fireAllRules();

> Raise the alarm > Turn on the sprinkler for room kitchen > Turn on the sprinkler for room office

After a while the fires will be put out and the Fire instances are retracted. This results in the sprinklers being turned off, the alarm being cancelled, and eventually the health message is printed again. ksession.retract( kitchenFireHandle ); ksession.retract( officeFireHandle ); ksession.fireAllRules();

> Turn on the sprinkler for room office > Turn on the sprinkler for room kitchen > Cancel the alarm > Everything is ok

Everyone still with me? That wasn't so hard and already I'm hoping you can start to see the value and power of a declarative rule system.

2.2. A Little Theory 2.2.1. Methods versus Rules People often confuse methods and rules, and new rule s regular ask, "How do I call a rule?" After the last section, you are now feeling like a rule expert and the answer to that is obvious, but let's summarize the differences nonetheless. public void helloWorld(Person person) { if ( person.getName().equals( "Chuck" ) ) { System.out.println( "Hello Chuck" ); } }

Methods are called directly. Specific instances are ed. One call results in a single execution. rule "Hello World" when Person( name == "Chuck" ) then System.out.println( "Hello Chuck" ); end

Rules execute by matching against any data as long it is inserted into the engine. Rules can never be called directly. Specific instances cannot be ed to a rule.

Depending on the matches, a rule may fire once or several times, or not at all.

2.2.2. Cross Products Earlier the term "cross product" was mentioned, which is the result of a . Imagine for a moment that the data from the fire alarm example were used in combination with the following rule where there ar no field constraints: rule when $room : Room() $sprinkler : Sprinkler() then System.out.println( "room:" + $room.getName() + " sprinkler:" + $sprinkler.getRoom().getName() ) end 



In SQL this would be like doing select * from Room, Sprinkler and every row in the Room table would be ed with every row in the Sprinkler table resulting in the following output: room:office sprinker:office room:office sprinkler:kitchen room:office sprinkler:livingroom room:office sprinkler:bedroom room:kitchen sprinkler:office room:kitchen sprinkler:kitchen room:kitchen sprinkler:livingroom room:kitchen sprinkler:bedroom room:livingroom sprinkler:office room:livingroom sprinkler:kitchen room:livingroom sprinkler:livingroom room:livingroom sprinkler:bedroom room:bedroom sprinkler:office room:bedroom sprinkler:kitchen room:bedroom sprinkler:livingroom room:bedroom sprinkler:bedroom

These cross products can obviously become huge, and they may very well

contain spurious data. The size of cross products is often the source of performance problems for new rule authors. From this it can be seen that it's always desirable to constrain the cross products, which is done with the variable constraint. rule when $room : Room() $sprinkler : Sprinkler( room == $room ) then System.out.println( "room:" + $room.getName() + " sprinkler:" + $sprinkler.getRoom().getName() ) end 



This results in just four rows of data, with the correct Sprinkler for each Room. In SQL (actually HQL) the corresponding query would be select * from Room, Sprinkler where Room == Sprinkler.room. room:office sprinkler:office room:kitchen sprinkler:kitchen room:livingroom sprinkler:livingroom room:bedroom sprinkler:bedroom

2.2.3. Activations, Agenda and Conflict Sets. So far the data and the matching process has been simple and small. To mix things up a bit a new example will be explored that handles cashflow calculations over date periods. The state of the engine will be illustratively shown at key stages to help get a better understanding of what is actually going on under the hood. Three classes will be used, as shown below.

public class CashFlow { private Date

date;

private double amount; private int

type;

long

No;

// getter and setter methods here } public class { private long

No;

private double balance; // getter and setter methods here } public Period { private Date start; private Date end; // getter and setter methods here }

By now you already know how to create Knowledge Bases and how to instantiate facts to populate the StatefulKnowledgeSession, so tables will be used to show the state of the inserted data, as it makes things clearer for illustration purposes. The tables below show that a single fact was inserted for the . Also inserted are a series of debits and credits as CashFlow objects for that , extending over two quarters.

Figure 2.1. CashFlows and

Two rules can be used to determine the debit and credit for that quarter and update the balance. The two rules below constrain the cashflows for

an for a given time period. Notice the "&&" which use short cut syntax to avoid repeating the field name twice.

rule "increase balance for credits"

rule "decrease balance f

when

when

ap : Period()

ap : Period()

acc : ( $No : No )

acc : ( $accoun

CashFlow( type == CREDIT,

CashFlow( type == DEBI

No == $No,

No ==

date >= ap.start && <= ap.end,

date >= ap.s

$amount : amount )

$amount : am

then acc.balance end

then += $amount;

acc.balance -= $amount end

If the Period is set to the first quarter we constrain the rule "increase balance for credits" to fire on two rows of data and "decrease balance for debits" to act on one row of data.

Figure 2.2. ingPeriod, CashFlows and

The two cashflow tables above represent the matched data for the two rules. The data is matched during the insertion stage and, as you discovered in the previous chapter, does not fire straight away, but only after fireAllRules() is called. Meanwhile, the rule plus its matched data is placed on the Agenda and referred to as an Activation. The Agenda is a table of Activations that are able to fire and have their consequences executed, as soon as fireAllRules() is called. Activations on the Agenda are executed in turn. Notice that the order of execution so far is considered arbitrary.


After all of the above activations are fired, the has a balance of -25.


If the Period is updated to the second quarter, we have just a single matched row of data, and thus just a single Activation on the Agenda.


The firing of that Activation results in a balance of 25.


What if you don't want the order of Activation execution to be arbitrary? When there is one or more Activations on the Agenda they are said to be in conflict, and a conflict resolver strategy is used to determine the order of execution. At the simplest level the default strategy uses salience to determine rule priority. Each rule has a default value of 0, the higher the value the higher the priority. To illustrate this we add a rule to print the balance, where we want this rule to be executed after all the debits and credits have been applied for all s. We achieve this by asg a negative salience to this rule so that it fires after all rules with the default salience 0.

rule "Print balance for Period" salience -50 when ap : Period() acc : () then System.out.println( acc.No + " : " + acc.balance ); end

The table below depicts the resulting Agenda. The three debit and credit rules are shown to be in arbitrary order, while the print rule is ranked last, to execute afterwards.


Earlier we showed how rules would equate to SQL, which can often help people with an SQL background to understand rules. The two rules above can be represented with two views and a trigger for each view, as below:

select * from acc,

select * from acc,

Cashflow cf,

Cashflow cf,

Period ap

Perio

where acc.No == cf.No and

where acc.No == cf.

cf.type == CREDIT and

cf.type == DEBIT and

cf.date >= ap.start and

cf.date >= ap.start

cf.date <= ap.end

cf.date <= ap.end

trigger : acc.balance += cf.amount

trigger : acc.balance -= c

Drools also features ruleflow-group attributes which allows workflow diagrams to declaratively specify when rules are allowed to fire. The screenshot below is taken from Eclipse using the Drools plugin. It has two ruleflow-group nodes which ensures that the calculation rules are executed before the reporting rules.

The use of the ruleflow-group attribute in a rule is shown below.

rule "increase balance for credits" ruleflow-group "calculation"

rule "Print balance for ruleflow-group "report when

when ap : Period()

ap : Period()

acc : ( $No : No )

acc : ()

CashFlow( type == CREDIT, No == $No,

then System.out.println( ac

date >= ap.start && <= ap.end, $amount : amount )

" end

then acc.balance

+= $amount;

end

2.2.4. Inference Inference has a bad names these days, as something not relevant to business use cases and just too complicated to be useful. It is true that contrived and complicated examples occur with inference, but that should not detract from the fact that simple and useful ones exist too. But more than this, correct use of inference can crate more agile and less error prone businesses with easier to maintain software. So what is inference? Something is inferred when we gain knowledge of something from using previous knowledge. For example given a Person fact with an age field and a rule that provides age policy control, we can infer whether a Person is an adult or a child and act on this. rule "Infer Adult" when $p : Person( age >= 18 ) then insert( new IsAdult( $p ) ) end

So in the above every Person who is 18 or over will have an instance of IsAdult inserted for them. This fact is special in that it is known as a relation. We can use this inferred relation in any rule:

$p : Person() IsAdult( person == $p )

So now we know what inference is, and have a basic example, how does this facilitate good rule design and maintenance? Let's take a government department that are responsible for issuing ID cards when children become adults, hence forth referred to as ID department. They might have a decision table that includes logic like this, which says when an adult living in london is 18 or over, issue the card:

However the ID department does not set the policy on who an adult is. That's done at a central government level. If the central government where to change that age to 21 there is a change management process. Someone has to liaise with the ID department and make sure their systems are updated, in time for the law going live. This change management process and communication between departments is not ideal for an agile environment and change become costly and error prone. Also the card department is managing more information than it needs to be aware of with its "monolothic" approach to rules management which is "leaking" information better placed else where. By this I mean that it doesn't care what explicit "age >= 18" information determines whether someone is an adult, only that they are an adult. Instead what if we were to split (de-couple) the authoring responsibility, so the central government maintains its rules and the ID department maintains its. So its the central governments job to determine who is an adult and if they change the law they just update their central repository with the new rules, which others use:

The IsAdult fact, as discussed previously, is inferred from the policy rules. It encapsulates the seemingly arbitrary piece of logic "age >= 18" and provides semantic abstractions for it's meaning. Now if anyone uses the above rules, they no longer need to be aware of explicit information that determines whether someone is an adult or not. They can just use the inferred fact:

While the example is very minimal and trivial it illustrates some important points. We started with a monolithic and leaky approach to our knowledge engineering. We create a single decision table that had all possible information in it that leaks information from central government that the ID department did not care about and did not want to manage. We first de-coupled the knowledge process so responsible for only what it needed to know. We leaky knowledge using an inferred fact IsAdult. The also gave a semantic abstraction to the previously 18".

each department was then encapsulated this use of the term IsAdult arbitrary logic "age >=

So a general rule or thumb when doing your knowledge engineering is: Bad Monolithic Leaky

Good De-couple knowledge responsibilities Encapsulate knowledge Provide semantic abstractions for those encapsulations

2.2.5. Inference and TruthMaintenance The previous example was issuing ID cards to over 18s, in this example we now issue bus es, either a child or adult . rule "Issue Child Bus " when $p : Person( age < 16 ) then insert(new ChildBus( $p ) ); end

rule "Issue Adult Bus " when $p : Person( age >= 16 ) then insert(new AdultBus( $p ) ); end

As before the above example is considered monolithic, leaky and providing poor separation of concerns. As before we can provide a more robust application with a separation of concerns using inference. Notice this time we don't just insert the inferred object, we use "logicalInsert": rule "Infer Child" when $p : Person( age < 16 ) then logicalInsert( new IsChild( $p ) ) end rule "Infer Adult" when $p : Person( age >= 16 ) then logicalInsert( new IsAdult( $p ) ) end

A "logicalInsert" is part of the Drools Truth Maintenance System (TMS). Here the fact is logically inserted, this fact is dependant on the truth of the "when" clause. It means that when the rule becomes false the fact is automatically retracted. This works particularly well as the two rules are mutually exclusive. So in the above rules if the person is under 16 it inserts an IsChild fact, once the person is 16 or over the IsChild fact is automatically retracted and the IsAdult fact inserted. We can now bring back in the code to issue the es, these two can also be logically inserted, as the TMS s chaining of logical insertions for a cascading set of retracts. rule "Issue Child Bus " when $p : Person( ) IsChild( person == $p ) then logicalInsert(new ChildBus( $p ) ); end

rule "Issue Adult Bus " when $p : Person( age >= 16 ) IsAdult( person =$p ) then logicalInsert(new AdultBus( $p ) ); end

Now when the person changes from being 15 to 16, not only is the IsChild fact automatically retracted, so is the person's ChildBus fact. For bonus points we can combine this with the 'not' conditional element to handle notifications, in this situation a request for the returning of the . So when the TMS automatically retracts the ChildBus object, this rule triggers and sends a request to the person: rule "Return ChildBus Request "when $p : Person( ) not( ChildBus( person == $p ) ) then requestChildBus( $p ); end

2.3. More on building and deploying

2.3.1. Knowledge Changesets

Base

by

Configuration

Using

So far, the programmatic API has been used to build a Knowledge Base. Quite often it's more desirable to do this via configuration. To facilitate this, Drools s the "Changeset" feature. The file changeset.xml contains a list of resources, and it may also point recursively to another changeset XML file. Currently there is no XML schema for the changeset XML, but we hope to add one soon. A few examples will be shown to give you the gist of things. A resource approach is employed that uses a prefix to indicate the protocol. All the protocols provided by java.net.URL, such as "file" and "http", are ed, as well as an additional "classpath". Currently the type attribute must always be specified for a resource, as it is not inferred from the file name extension. Here is a simple example that points to a http location for some rules. 



To use the above XML, the code is almost identical as before, except we change the resource type to CHANGE_SET. KnowledgeBuilder kbuilder = KnowledgeBuilderFactory.newKnowledgeBuilder( kbuilder.add( ResourceFactory.newClasspathResource( "myChangeSet.xml", g ResourceType.CHANGE_SET ); if ( kbuilder.hasErrors() ) { System.err.println( builder.getErrors().toString() ); } 



Changesets can include any number of resources, and they even additional configuration information, which currently is only needed for decision tables. The example below is expanded to load the rules from a http URL location, and an Excel decision table from the classpath.





2.3.2. Knowledge Agent The Knowlege Agent provides automatic loading, caching and re-loading of resources and is configured from a properties files. The Knowledge Agent can update or rebuild this Knowlege Base as the resources it uses are changed. The strategy for this is determined by the configuration given to the factory, but it is typically pull-based using regular polling. We hope to add pushbased updates and rebuilds in future versions. KnowledgeAgent kagent = KnowledgeAgentFactory.newKnowledgeAgent( "MyAgen kagent.applyChangeSet( ResourceFactory.newUrlResource( url ) ); KnowledgeBase kbase = kagent.getKnowledgeBase(); 



A KnowledgeAgent object will continuously scan all the added resources, using a default polling interval of 60 seconds and, when some last modification date is updated, it will applied the changes into the cached Knowledge Base using the new resources. Note that the previous KnowledgeBase reference will still exist and you'll have to call getKnowledgeBase() to access the newly built

KnowledgeBase. If a directory is specified as part of the change set, the entire

contents of that directory will be scanned for changes. The way modifications are applied depends on drools.agent.newInstance property present in the KnowledgeAgentConfiguration object ed to the agent. For polling to occur, the polling and notifier services must be started: ResourceFactory.getResourceChangeNotifierService().start(); ResourceFactory.getResourceChangeScannerService().start();

2.3.2.1. Knowledge Agent and Custom ClassLoaders Because Knowledge Agent could scan and process remote resources, it could ends up failing when compiling or executing rules, queries, functions, etc. that use classes outside the agent's classloader. If this is your case, you could take 2 approach: use a custom classloader for agent's kbuilder or force the agent to use the same classloader that its kbase has.

2.3.2.1.1. Custom ClassLoaders for KnowledgeBuilder Knowledge Agent uses KnowledgeBuilder internally in order to compile managed resources. If you need to custom configuration to these compilers you could a KnowledgeBuilderConfiguration object to KnowledgeAgentFactory.newKnowledgeAgent(). This object will be used in every builder the agent creates. Using a KnowledgeBuilderConfiguration you can specify a custom classloader.

2.3.2.1.2. Reuse KnowledgeBase ClassLoader Most of the times, the classloader you wan't to use in the compilation process of remote resources is the same needed in the agent's kbase, so the rules could be executed. If you want to use this approach, you will need to setup the desired ClassLoader to the agen't kbase and use the "drools.agent.useKBaseClassLoaderForCompiling" property of KnowledgeAgentConfiguration object. This approach lets you modify agent's kbuilder classloader in runtime by modifying the classloader the agent's kbase uses. This will serve also when not using incremental change set processing (see the section below). When the kbase is recreated its configuration is reused, so the classloader is

maintained. KnowledgeBaseConfiguration kbaseConfig = KnowledgeBaseFactory.newKnowledgeBaseConfiguration(null, customClass KnowledgeBase kbase = KnowledgeBaseFactory.newKnowledgeBase(kbaseConfig); //kbase with cus KnowledgeAgentConfiguration aconf = KnowledgeAgentFactory.newKnowledgeAgentConfiguration(); aconf.setProperty("drools.agent.newInstance", "false"); //incremental ch aconf.setProperty("drools.agent.useKBaseClassLoaderForCompiling", "true" KnowledgeAgent kagent = KnowledgeAgentFactory.newKnowledgeAgent( "test agent", kbase, aconf); 



2.3.2.2. Incremental Change Set Processing Knowledge Agent can process change sets in two different ways: recreating the knowledge base every time a new change set is processed or applying the change set in the cached knowledge base without destroying it. This behavior is controlled by the "newInstance" property of the KnowledgeAgentConfiguration object ed to the Agent's constructor. When "newInstace" is set to true (the default value), the agent will destroy the cached Knowledge Base it contains and populate a new one containing the change set modifications. When "newInstance" is set to "false" change sets are applied directly to the cached Knowledge Base. The rule that were not modified in the change sets' resources are not replaced in the Knowledge Base, the modified or deleted rules are modified or deleted from the cached Knowledge Base. Functions, Queries and Definition Types are always replaced in the cached Knowledge Base whether they are modified or not. The following code snippet creates a new Knowledge Agent with its "newInstace" property set to false KnowledgeAgentConfiguration aconf = KnowledgeAgentFactory.newKnowledgeAg aconf.setProperty("drools.agent.newInstance", "false"); KnowledgeAgent kagent = KnowledgeAgentFactory.newKnowledgeAgent("test ag 

2.3.2.3. Remote HTTP resource caching



A note on remote HTTP Url Resources: if your knowledge agent is "pulling" resources from a http(s) URL, then you might rightly be concerned if that resource (remote web server) suddenly disappears. To survive a restart when a resource is no longer available remotely (eg the remote server is being restarted) then you can set a System Property: drools.resource.urlcache to a directory that has write permissions for the application: the Knowledge Agent will cache copies of the remote resources in that local directory. For example, using the java command line: Ddrools.resource.urlcache=/s/someone/KnowledgeCache - will keep local copies of the resources (rules, packages etc) in that directory, for the agent to use should it be restarted (when a remote resource becomes available, and is updated, it will automatically update the local cache copy).

Chapter 3. Advanced Concepts and Theory 3.1. Truth Maintenance with Logical Objects 3.1.1. Example Scenario 3.1.2. Lazy Truth Maintenance 3.1.3. Important note: Equality for Java objects 3.2. Rete Algorithm

3.1. Truth Objects

Maintenance

with

Logical

After regular inserts you have to retract facts explicitly. With logical assertions, the fact that was asserted will be automatically retracted when the conditions that asserted it in the first place are no longer true. Actually, it's even cleverer then that, because it will be retracted only if there isn't any single condition that s the logical assertion. Normal insertions are said to be stated, i.e., just like the intuitive meaning of "stating a fact" implies. Using a HashMap and a counter, we track how many times a particular equality is stated; this means we count how many different instances are equal. When we logically insert an object during a RHS execution we are said to justify it, and it is considered to be justified by the firing rule. For each

logical insertion there can only be one equal object, and each subsequent equal logical insertion increases the justification counter for this logical assertion. A justification is removed by the LHS of the creating rule becoming untrue, and the counter is decreased accordingly. As soon as we have no more justifications the logical object is automatically retracted. If we try to logically insert an object when there is an equal stated object, this will fail and return null. If we state an object that has an existing equal object that is justified we override the Fact; how this override works depends on the configuration setting WM_BEHAVIOR_PRESERVE. When the property is set to discard we use the existing handle and replace the existing instance with the new Object, which is the default behavior; otherwise we override it to stated but we create an new FactHandle. This can be confusing on a first read, so hopefully the flow charts below help. When it says that it returns a new FactHandle, this also indicates the Object was propagated through the network.

Figure 3.1. Stated Insertion

Figure 3.2. Logical Insertion

3.1.1. Example Scenario An example may make things clearer. Imagine a credit card processing application, processing transactions for a given and we have a working memory accumulating knowledge about a single transaction. The rule engine is doing its best to decide whether transactions are possibly fraudulent or not. Imagine that this rule base basically has rules that kick in when there is "reason to be suspicious" and when "everything is normal".

Of course there are many rules that operate no matter what, performing standard calculations, etc. Now there are possibly many reasons as to what could trigger a "reason to be suspicious": someone notifying the bank, a sequence of large transactions, transactions for geographically disparate locations, or even reports of credit card theft. Rather then smattering all the little conditions in lots of rules, imagine there is a fact class called "Suspicious". Then there can be a series of rules whose job is to look for things that may raise suspicion, and if they fire, they logically insert a new Suspicious() instance. All the other rules just have conditions like "not Suspicious()" or "Suspicious()" depending on their needs. Note that this has the advantage of allowing there to be many rules around raising suspicion, without touching the other rules. After all the facts causing the Suspicious() insertion are removed, the handling reverts to a normal mode of operation where, for instance, a rule with "not Suspicious()" may kick in, which flushes through any blocked transactions. If you have followed this far, you will note that truth maintenance, like logical assertions, allows rules to behave a little like a human would, and can certainly make the rules more manageable.

3.1.2. Lazy Truth Maintenance You no longer need to enable or disable truth maintenance, via the kbase configuration. It is now handled automatically and turned on only when needed. This was done along with the code changes so that all entry points use the same code, previous to this the default entry point and named entry points used different code, to avoid TMS overhead for event processing.

3.1.3. Important note: Equality for Java objects It is important to note that for Truth Maintenance (and logical assertions) to work at all, your Fact objects (which may be JavaBeans) must override equals and hashCode methods (from java.lang.Object) correctly. As the truth maintenance system needs to know when two different physical objects are equal in value, both equals and hashCode must be overridden correctly, as per the Java standard. Two objects are equal if and only if their equals methods return true for each

other and if their hashCode methods return the same values. See the Java API for more details (but do keep in mind you MUST override both equals and hashCode).

3.2. Rete Algorithm The Rete algorithm was invented by Dr. Charles Forgy and documented in his PhD thesis in 1978-79. A simplified version of the paper was published in 1982 (http://citeseer.ist.psu.edu/context/505087/0). The latin word "rete" means "net" or "network". The Rete algorithm can be broken into 2 parts: rule compilation and runtime execution. The compilation algorithm describes how the Rules in the Production Memory are processed to generate an efficient discrimination network. In nontechnical , a discrimination network is used to filter data as it propagates through the network. The nodes at the top of the network would have many matches, and as we go down the network, there would be fewer matches. At the very bottom of the network are the terminal nodes. In Dr. Forgy's 1982 paper, he described 4 basic nodes: root, 1-input, 2-input and terminal.

Figure 3.3. Rete Nodes

The root node is where all objects enter the network. From there, it

immediately goes to the ObjectTypeNode. The purpose of the ObjectTypeNode is to make sure the engine doesn't do more work than it needs to. For example, say we have 2 objects: and Order. If the rule engine tried to evaluate every single node against every object, it would waste a lot of cycles. To make things efficient, the engine should only the object to the nodes that match the object type. The easiest way to do this is to create an ObjectTypeNode and have all 1-input and 2-input nodes descend from it. This way, if an application asserts a new , it won't propagate to the nodes for the Order object. In Drools when an object is asserted it retrieves a list of valid ObjectTypesNodes via a lookup in a HashMap from the object's Class; if this list doesn't exist it scans all the ObjectTypeNodes finding valid matches which it caches in the list. This enables Drools to match against any Class type that matches with an instanceof check.

Figure 3.4. ObjectTypeNodes

ObjectTypeNodes can propagate to AlphaNodes, LeftInputAdapterNodes and BetaNodes. AlphaNodes are used to evaluate literal conditions. Although the 1982 paper only covers equality conditions, many RETE implementations other operations. For example, .name == "Mr Trout" is a literal condition. When a rule has multiple literal conditions for a single object type, they are linked together. This means that if an application asserts an object, it must first satisfy the first literal condition before it can proceed to the next AlphaNode. In Dr. Forgy's paper, he refers to these as IntraElement conditions. The following diagram shows the AlphaNode combinations for Cheese( name == "cheddar", strength == "strong" ):

Figure 3.5. AlphaNodes

Drools extends Rete by optimizing the propagation from ObjectTypeNode to AlphaNode using hashing. Each time an AlphaNode is added to an ObjectTypeNode it adds the literal value as a key to the HashMap with the AlphaNode as the value. When a new instance enters the ObjectType node, rather than propagating to each AlphaNode, it can instead retrieve the correct AlphaNode from the HashMap,thereby avoiding unnecessary literal checks. There are two two-input nodes, Node and NotNode, and both are types of BetaNodes. BetaNodes are used to compare 2 objects, and their fields, to each other. The objects may be the same or different types. By convention we refer to the two inputs as left and right. The left input for a BetaNode is generally a list of objects; in Drools this is a Tuple. The right input is a single object. Two Nodes can be used to implement 'exists' checks. BetaNodes also have memory. The left input is called the Beta Memory and re all incoming tuples. The right input is called the Alpha Memory and re all incoming objects. Drools extends Rete by performing indexing on the BetaNodes. For instance, if we know that a BetaNode is performing a check on a String field, as each object enters we can do a hash lookup on that String value. This means when facts enter from the opposite side, instead of iterating over all the facts to find valid s, we do a lookup returning potentially valid candidates. At any point a valid is found the Tuple is ed with the Object; which is referred to as a partial match; and then propagated to the next node.

Figure 3.6. Node

To enable the first Object, in the above case Cheese, to enter the network we use a LeftInputNodeAdapter - this takes an Object as an input and propagates a single Object Tuple. Terminal nodes are used to indicate a single rule having matched all its conditions; at this point we say the rule has a full match. A rule with an 'or' conditional disjunctive connective results in subrule generation for each possible logically branch; thus one rule can have multiple terminal nodes. Drools also performs node sharing. Many rules repeat the same patterns, and node sharing allows us to collapse those patterns so that they don't have to be re-evaluated for every single instance. The following two rules share the first pattern, but not the last:

rule when Cheese( $chedddar : name == "cheddar" ) $person : Person( favouriteCheese == $cheddar ) then System.out.println( $person.getName() + " likes cheddar" ); end

rule when Cheese( $chedddar : name == "cheddar" ) $person : Person( favouriteCheese != $cheddar ) then System.out.println( $person.getName() + " does not like cheddar" end





As you can see below, the compiled Rete network shows that the alpha node is shared, but the beta nodes are not. Each beta node has its own TerminalNode. Had the second pattern been the same it would have also been shared.

Figure 3.7. Node Sharing

Chapter 4. Guide 4.1. Building 4.1.1. Building using Code 4.1.2. Building using Configuration and the ChangeSet XML 4.2. Deploying 4.2.1. 4.2.2. 4.2.3. 4.2.4. 4.2.5. 4.2.6.

KnowledgePackage and Knowledge Definitions KnowledgeBase In-Process Building and Deployment Building and Deployment in Separate Processes StatefulknowledgeSessions and KnowledgeBase Modifications KnowledgeAgent

4.3. Running 4.3.1. KnowledgeBase 4.3.2. StatefulKnowledgeSession 4.3.3. KnowledgeRuntime 4.3.4. Agenda 4.3.5. Event Model 4.3.6. KnowledgeRuntimeLogger 4.3.7. StatelessKnowledgeSession 4.3.8. Commands and the CommandExecutor 4.3.9. Marshalling 4.3.10. Persistence and Transactions 4.3.11. Drools Clips

4.1. Building

Figure 4.1. org.drools.builder

4.1.1. Building using Code The KnowledgeBuilder is responsible for taking source files, such as a DRL file or an Excel file, and turning them into a Knowledge Package of rule and process definitions which a Knowledge Base can consume. An object of the class ResourceType indicates the type of resource it is being asked to build. The ResourceFactory provides capabilities to load resources from a number of sources, such as Reader, ClassPath, URL, File, or ByteArray. Binaries, such as decision tables (Excel .xls files), should not use a Reader based resource handler, which is only suitable for text based resources.

Figure 4.2. KnowledgeBuilder

The KnowlegeBuilder is created using the KnowledgeBuilderFactory.

Figure 4.3. KnowledgeBuilderFactory

A KnowledgeBuilder can be created using the default configuration.

Example 4.1. Creating a new KnowledgeBuilder KnowledgeBuilder kbuilder = KnowledgeBuilderFactory.newKnowledgeBuilde 



A configuration can be created using the KnowledgeBuilderFactory. This allows the behavior of the Knowledge Builder to be modified. The most common usage is to provide a custom class loader so that the KnowledgeBuilder object can resolve classes that are not in the default classpath. The first parameter is for properties and is optional, i.e., it may be left null, in which case the default options will be used. The options parameter can be used for things like changing the dialect or ing new accumulator functions.

Example 4.2. Creating a new KnowledgeBuilder with a custom ClassLoader KnowledgeBuilderConfiguration kbuilderConf = KnowledgeBuilderFactory.n KnowledgeBuilder kbuilder = KnowledgeBuilderFactory.newKnowledgeBuilde 



Resources of any type can be added iteratively. Below, a DRL file is added. Unlike Drools 4.0 Package Builder, the Knowledge Builder can now handle multiple namespaces, so you can just keep adding resources regardless of namespace.

Example 4.3. Adding DRL Resources kbuilder.add( ResourceFactory.newFileResource( "/project/myrules.drl" ResourceType.DRL); 



It is best practice to always check the hasErrors() method after an addition. You should not add more resources or retrieve the Knowledge Packages if there are errors. getKnowledgePackages() returns an empty list if there are

errors.

Example 4.4. Validating if( kbuilder.hasErrors() ) { System.out.println( kbuilder.getErrors() ); return; }

When all the resources have been added and there are no errors the collection of Knowledge Packages can be retrieved. It is a Collection because there is one Knowledge Package per package namespace. These Knowledge Packages are serializable and often used as a unit of deployment.

Example 4.5. Getting the KnowledgePackages Collection kpkgs = kbuilder.getKnowledgePackages(); 

The final example puts it all together.

Example 4.6. Putting it all together



KnowledgeBuilder kbuilder = KnowledgeBuilderFactory.newKnowledgeBuilde if( kbuilder.hasErrors() ) { System.out.println( kbuilder.getErrors() ); return; } KnowledgeBuilder kbuilder = KnowledgeBuilderFactory.newKnowledgeBuilde kbuilder.add( ResourceFactory.newFileResource( "/project/myrules1.drl" ResourceType.DRL); kbuilder.add( ResourceFactory.newFileResource( "/project/myrules2.drl" ResourceType.DRL); if( kbuilder.hasErrors() ) { System.out.println( kbuilder.getErrors() ); return; } Collection kpkgs = kbuilder.getKnowledgePackages(); 



4.1.2. Building using Configuration and the ChangeSet XML Instead of adding the resources to create definitions programmatically it is also possible to do it by configuration, via the ChangeSet XML. The simple XML file s three elements: add, remove, and modify, each of which has a sequence of subelements defining a configuration entity. The following XML schema is not normative and intended for illustration only.

Example 4.7. XML Schema for ChangeSet XML (not normative) <xs:schema xmlns:xs="http://www.w3.org/2001/XMLSchema" xmlns="http://drools.org/drools-5.0/change-set" targetNamespace="http://drools.org/drools-5.0/change-set"> <xs:element name="change-set" type="ChangeSet"/> <xs:complexType name="ChangeSet"> <xs:choice maxOccurs="unbounded"> <xs:element name="add" type="Operation"/> <xs:element name="remove" type="Operation"/>

yp <xs:element name="modify" type="Operation"/> <xs:complexType name="Operation"> <xs:sequence> <xs:element name="resource" type="Resource" maxOccurs="unbounded"/> <xs:complexType name="Resource"> <xs:sequence>

<xs:element name="decisiontable-conf" type="DecTabConf" minOccurs="0"/>

<xs:attribute name="source" type="xs:string"/> <xs:attribute name="type" type="ResourceType"/> <xs:complexType name="DecTabConf"> <xs:attribute name="input-type" type="DecTabInpType"/> <xs:attribute name="worksheet-name" type="xs:string" use="optional"/>

<xs:simpleType name="ResourceType"> <xs:restriction base="xs:string"> <xs:enumeration value="DRL"/> <xs:enumeration value="XDRL"/> <xs:enumeration value="DSL"/> <xs:enumeration value="DSLR"/> <xs:enumeration value="DRF"/> <xs:enumeration value="DTABLE"/> <xs:enumeration value="PKG"/> <xs:enumeration value="BRL"/> <xs:enumeration value="CHANGE_SET"/>

<xs:simpleType name="DecTabInpType"> <xs:restriction base="xs:string"> <xs:enumeration value="XLS"/> <xs:enumeration value="CSV"/> 



Currently only the add element is ed, but the others will be implemented to iterative changes. The following example loads a single DRL file.

Example 4.8. Simple ChangeSet XML 



Notice the file: prefix, which signifies the protocol for the resource. The Change Set s all the protocols provided by java.net.URL, such as "file" and "http", as well as an additional "classpath". Currently the type attribute must always be specified for a resource, as it is not inferred from the file name extension. Using the ClassPath resource loader in Java allows you to specify the Class Loader to be used to locate the resource but this is not possible from XML. Instead, the Class Loader will default to the one used by the Knowledge Builder unless the ChangeSet XML is itself loaded by the ClassPath resource, in which case it will use the Class Loader specified for that resource. Currently you still need to use the API to load that ChangeSet, but we will add for containers such as Spring in the future, so that the process

of creating a Knowledge Base can be done completely by XML configuration. Loading resources using an XML file couldn't be simpler, as it's just another resource type.

Example 4.9. Loading the ChangeSet XML kbuilder.add( ResourceFactory.newUrlResource( url ), ResourceType.CHAN 



ChangeSets can include any number of resources, and they even additional configuration information, which currently is only needed for decision tables. Below, the example is expanded to load rules from a http URL location, and an Excel decision table from the classpath.

Example 4.10. ChangeSet XML with resource configuration 



4.2. Deploying 4.2.1. KnowledgePackage and Knowledge Definitions A Knowledge Package is a collection of Knowledge Definitions, such as rules and processes. It is created by the Knowledge Builder, as described in the chapter "Building". Knowledge Packages are self-contained and serializable, and they currently form the basic deployment unit.

Figure 4.4. KnowledgePackage

Knowledge Packages are added to the Knowledge Base. However, a Knowledge Package instance cannot be reused once it's added to the Knowledge Base. If you need to add it to another Knowledge Base, try serializing it first and using the "cloned" result. We hope to fix this limitation in future versions of Drools.

4.2.2. KnowledgeBase The Knowlege Base is a repository of all the application's knowledge definitions. It may contain rules, processes, functions, and type models. The Knowledge Base itself does not contain instance data, known as facts; instead, sessions are created from the Knowledge Base into which data can be inserted and where process instances may be started. Creating the Knowlege Base can be heavy, whereas session creation is very light, so it is recommended that Knowledge Bases be cached where possible to allow for repeated session creation.

Figure 4.5. KnowledgeBase

A KnowledgeBase object is also serializable, and some people may prefer to build and then store a KnowledgeBase, treating it also as a unit of deployment,

instead of the Knowledge Packages. The KnowlegeBase is created using the KnowledgeBaseFactory.

Figure 4.6. KnowledgeBaseFactory

A KnowledgeBase can be created using the default configuration.

Example 4.12. Creating a new KnowledgeBase KnowledgeBase kbase = KnowledgeBaseFactory.newKnowledgeBase();

If a custom class loader was used with the KnowledgeBuilder to resolve types not in the default class loader, then that must also be set on the KnowledgeBase. The technique for this is the same as with the KnowledgeBuilder.

Example 4.13. Creating a new KnowledgeBase with a custom ClassLoader KnowledgeBaseConfiguration kbaseConf = KnowledgeBaseFactory.createKnowledgeBaseConfiguration( null, cl ); KnowledgeBase kbase = KnowledgeBaseFactory.newKnowledgeBase( kbaseConf 



4.2.3. In-Process Building and Deployment This is the simplest form of deployment. It compiles the knowledge definitions and adds them to the Knowledge Base in the same JVM. This approach requires drools-core.jar and drools-compiler.jar to be on the classpath.

Example 4.14. Add KnowledgePackages to a KnowledgeBase Collection kpkgs = kbuilder.getKnowledgePackages(); KnowledgeBase kbase = KnowledgeBaseFactory.newKnowledgeBase(); kbase.addKnowledgePackages( kpkgs ); 



Note that the addKnowledgePackages(kpkgs) method can be called iteratively to add additional knowledge.

4.2.4. Building and Deployment in Separate Processes Both the KnowledgeBase and the KnowledgePackage are units of deployment and serializable. This means you can have one machine do any necessary building, requiring drools-compiler.jar, and have another machine deploy and execute everything, needing only drools-core.jar. Although serialization is standard Java, we present an example of how one machine might write out the deployment unit and how another machine might read in and use that deployment unit.

Example 4.15. Writing the KnowledgePackage to an OutputStream ObjectOutputStream out = new ObjectOutputStream( new FileOutputStream( out.writeObject( kpkgs ); out.close(); 



Example 4.16. InputStream

Reading

the

KnowledgePackage

from

an

ObjectInputStream in = new ObjectInputStream( new FileInputStream( fil // The input stream might contain an individual // package or a collection. @SuppressWarnings( "unchecked" ) Collection kpkgs = ()in.readObject( Collection ); in.close(); KnowledgeBase kbase = KnowledgeBaseFactory.newKnowledgeBase(); kbase.addKnowledgePackages( kpkgs ); 



The KnowledgeBase is also serializable and some people may prefer to build

and then store the KnowledgeBase itself, instead of the Knowledge Packages. Drools Guvnor, our server side management system, uses this deployment approach. After Guvnor has compiled and published serialized Knowledge Packages on a URL, Drools can use the URL resource type to load them.

4.2.5. StatefulknowledgeSessions KnowledgeBase Modifications

and

Stateful Knowledge Sessions will be discussed in more detail in section "Running". The KnowledgeBase creates and returns StatefulKnowledgeSession objects, and it may optionally keep references to those. When KnowledgeBase modifications occur those modifications are applied against the data in the sessions. This reference is a weak reference and it is also optional, which is controlled by a boolean flag.

4.2.6. KnowledgeAgent The KnowlegeAgent provides automatic loading, caching and re-loading of resources and is configured from a properties files. The Knowledge Agent can update or rebuild this Knowlege Base as the resources it uses are changed. The strategy for this is determined by the configuration given to the factory, but it is typically pull-based using regular polling. We hope to add pushbased updates and rebuilds in future versions. The Knowledge Agent will continuously scan all the added resources, using a default polling interval of 60 seconds. If their date of the last modification is updated it will rebuild the cached Knowledge Base using the new resources.

Figure 4.7. KnowledgeAgent

The KnowlegeBuilder is created using a KnowledgeBuilderFactory object. The agent must specify a name, which is used in the log files to associate a log entry with the corresponding agent.

Example 4.17. Creating the KnowledgeAgent KnowledgeAgent kagent = KnowledgeAgentFactory.newKnowledgeAgent( "MyAg 



Figure 4.8. KnowledgeAgentFactory

The following example constructs an agent that will build a new KnowledgeBase from the specified ChangeSet. (See section "Building" for more details on the ChangeSet format.) Note that the method can be called

iteratively to add new resources over time. The Knowledge Agent polls the resources added from the ChangeSet every 60 seconds, the default interval, to see if they are updated. Whenever changes are found it will construct a new Knowledge Base or apply the modifications to the existing Knowledge Base according to its configuration. If the change set specifies a resource that is a directory its contents will be scanned for changes, too.

Example 4.18. Writing the KnowledgePackage to an OutputStream KnowledgeAgent kagent = KnowledgeAgentFactory.newKnowledgeAgent( "MyAg kagent.applyChangeSet( ResourceFactory.newUrlResource( url ) ); KnowledgeBase kbase = kagent.getKnowledgeBase(); 



Resource scanning is not on by default, it's a service and must be started, and the same is true for notification. Both can be done via the ResourceFactory.

Example 4.19. Starting the Scanning and Notification Services ResourceFactory.getResourceChangeNotifierService().start(); ResourceFactory.getResourceChangeScannerService().start();

The

default

resource

scanning ResourceChangeScannerService.

period A

may

ResourceChangeScannerConfiguration

object

is

be changed suitably

ed

to

the

via the updated service's

configure() method, which allows for the service to be reconfigured on

demand.

Example 4.20. Changing the Scanning Intervals ResourceChangeScannerConfiguration sconf = ResourceFactory.getResourceChangeScannerService().newResourceChang // Set the disk scanning interval to 30s, default is 60s. sconf.setProperty( "drools.resource.scanner.interval", "30" ); ResourceFactory.getResourceChangeScannerService().configure( sconf ); 



Knowledge Agents can take an empty Knowledge Base or a populated one. If a populated Knowledge Base is provided, the Knowledge Agent will run an iterator from Knowledge Base and subscribe to the resources that it finds. While it is possible for the Knowledge Builder to build all resources found in a directory, that information is lost by the Knowledge Builder so that those directories will not be continuously scanned. Only directories specified as part of the applyChangeSet(Resource) method are monitored. One of the advantages of providing KnowledgeBase as the starting point is that you can provide it with a KnowledgeBaseConfiguration. When resource changes are detected and a new KnowledgeBase object is instantiated, it will use the KnowledgeBaseConfiguration of the previous KnowledgeBase object.

Example 4.21. Using an existing KnowledgeBase KnowledgeBaseConfiguration kbaseConf = KnowledgeBaseFactory.createKnowledgeBaseConfiguration( null, cl ); KnowledgeBase kbase KnowledgeBaseFactory.newKnowledgeBase( kbaseConf ) // Populate kbase with resources here. KnowledgeAgent kagent = KnowledgeAgentFactory.newKnowledgeAgent( "MyAgent", kbase ); KnowledgeBase kbase = kagent.getKnowledgeBase(); 



In the above example getKnowledgeBase() will return the same provided kbase instance until resource changes are detected and a new Knowledge Base is built. When the new Knowledge Base is built, it will be done with the KnowledgeBaseConfiguration that was provided to the previous KnowledgeBase. As mentioned previously, a ChangeSet XML can specify a directory and all of its contents will be added. If this ChangeSet XML is used with the applyChangeSet() method it will also add any directories to the scanning process. When the directory scan detects an additional file, it will be added to the Knowledge Base; any removed file is removed from the Knowledge Base, and modified files will be removed from the Knowledge Base.

Example 4.22. ChangeSet XML which adds a directories contents 



Note that for the resource type PKG the drools-compiler dependency is not needed as the Knowledge Agent is able to handle those with just drools-core. The KnowledgeAgentConfiguration can be used to modify a Knowledge Agent's default behavior. You could use this to load the resources from a directory, while inhibiting the continuous scan for changes of that directory.

Example 4.23. Change the Scanning Behavior KnowledgeBase kbase = KnowledgeBaseFactory.newKnowledgeBase(); KnowledgeAgentConfiguration kaconf = KnowledgeAgentFactory.newKnowledgeAgentConfiguation(); // Do not scan directories, just files. kaconf.setProperty( "drools.agent.scanDirectories", "false" ); KnowledgeAgent kagent = KnowledgeAgentFactory.newKnowledgeAgent( "test agent", kaconf ); 



Previously we mentioned Drools Guvnor and how it can build and publish serialized Knowledge Packages on a URL, and that the ChangeSet XML can handle URLs and Packages. Taken together, this forms an importanty deployment scenario for the Knowledge Agent.

4.3. Running

4.3.1. KnowledgeBase The KnowlegeBase is a repository of all the application's knowledge definitions. It will contain rules, processes, functions, and type models. The Knowledge Base itself does not contain data; instead, sessions are created from the KnowledgeBase into which data can be inserted and from which process instances may be started. Creating the KnowlegeBase can be heavy, whereas session creation is very light, so it is recommended that Knowle Bases be cached where possible to allow for repeated session creation.

Example 4.24. Creating a new KnowledgeBase KnowledgeBase kbase = KnowledgeBaseFactory.newKnowledgeBase();

4.3.2. StatefulKnowledgeSession The StatefulKnowledgeSession stores and executes on the runtime data. It is created from the KnowledgeBase.

Figure 4.9. StatefulKnowledgeSession

Example 4.25. KnowledgeBase

Create

a

StatefulKnowledgeSession

from

a

StatefulKnowledgeSession ksession = kbase.newStatefulKnowledgeSession( 



4.3.3. KnowledgeRuntime

4.3.3.1. WorkingMemoryEntryPoint The

WorkingMemoryEntryPoint

provides

the

methods

around

inserting,

updating and retrieving facts. The term "entry point" is related to the fact that we have multiple partitions in a Working Memory and you can choose which one you are inserting into, although this use case is aimed at event processing and covered in more detail in the Fusion manual. Most rule based applications will work with the default entry point alone. The KnowledgeRuntime interface provides the main interaction with the engine. It is available in rule consequences and process actions. In this manual the focus is on the methods and interfaces related to rules, and the methods pertaining to processes will be ignored for now. But you'll notice that the KnowledgeRuntime inherits methods from both the WorkingMemory and the ProcessRuntime, thereby providing a unified API to work with processes and

rules. When working with rules, three interfaces form the KnowledgeRuntime: WorkingMemoryEntryPoint, WorkingMemory and the KnowledgeRuntime itself.

Figure 4.10. WorkingMemoryEntryPoint

4.3.3.1.1. Insertion Insertion is the act of telling the WorkingMemory about a fact, which you do by ksession.insert(yourObject), for example. When you insert a fact, it is

examined for matches against the rules. This means all of the work for deciding about firing or not firing a rule is done during insertion; no rule, however, is executed until you call fireAllRules(), which you call after you have finished inserting your facts. It is a common misunderstanding for people to think the condition evaluation happens when you call

fireAllRules(). Expert systems typically use the term assert or assertion to

refer to facts made available to the system. However, due to "assert" being a keyword in most languages, we have decided to use the insert keyword; so expect to hear the two used interchangeably. When an Object is inserted it returns a FactHandle. This FactHandle is the token used to represent your inserted object within the WorkingMemory. It is also used for interactions with the WorkingMemory when you wish to retract or modify an object. Cheese stilton = new Cheese("stilton"); FactHandle stiltonHandle = ksession.insert( stilton );

As mentioned in the Knowledge Base section, a Working Memory may operate in two assertion modes, i.e., equality or identity, with identity being the default. Identity means that the Working Memory uses an IdentityHashMap to store all asserted objects. New instance assertions always result in the return of a new FactHandle, but if an instance is asserted again then it returns the original fact handle, i.e., it ignores repeated insertions for the same fact. Equality means that the Working Memory uses a HashMap to store all asserted Objects. New instance assertions will only return a new FactHandle if no equal objects have been asserted.

4.3.3.1.2. Retraction Retraction is the removal of a fact from Working Memory, which means that it will no longer track and match that fact, and any rules that are activated and dependent on that fact will be cancelled. Note that it is possible to have rules that depend on the nonexistence of a fact, in which case retracting a fact may cause a rule to activate. (See the not and exist keywords.) Retraction is done using the FactHandle that was returned by the insert call. Cheese stilton = new Cheese("stilton"); FactHandle stiltonHandle = ksession.insert( stilton ); .... ksession.retract( stiltonHandle );

4.3.3.1.3. Update The Rule Engine must be notified of modified facts, so that they can be reprocessed. Internally, modification is actually a retract followed by an insert; the Rule Engine removes the fact from the WorkingMemory and inserts it again. You must use the update() method to notify the WorkingMemory of changed objects for those objects that are not able to notify the WorkingMemory themselves. Notice that update() always takes the modified object as a second parameter, which allows you to specify new instances for immutable objects. The update() method can only be used with objects that have shadow proxies turned on. The update method is only available within Java code. On the right hand side of a rule, also the modify statement is ed, providing simplified calls to the object's setters. Cheese stilton = new Cheese("stilton"); FactHandle stiltonHandle = workingMemory.insert( stilton ); ... stilton.setPrice( 100 ); workingMemory.update( stiltonHandle, stilton );

4.3.3.2. WorkingMemory The WorkingMemory provides access to the Agenda, permits query executions, and lets you access named Enty Points.

Figure 4.11. WorkingMemory

4.3.3.2.1. Query Queries are used to retrieve fact sets based on patterns, as they are used in rules. Patterns may make use of optional parameters. Queries can be defined in the Knowlege Base, from where they are called up to return the matching results. While iterating over the result collection, any bound identifier in the query can be accessed using the get(String identifier) method and any FactHandle for that identifier can be retrieved using getFactHandle(String identifier).

Figure 4.12. QueryResults

Figure 4.13. QueryResultsRow

Example 4.26. Simple Query Example QueryResults results = ksession.getQueryResults( "my query", new Object[] { "string" } ); for ( QueryResultsRow row : results ) { System.out.println( row.get( "varName" ) ); } 



4.3.3.2.2. Live Querries Drools has always had query , but the result was returned as an iterable set; this makes it hard to monitor changes over time. We have now complimented this with Live Querries, which has a listener attached instead of returning an iterable result set. These live querries stay open creating a view and publish change events for the contents of this view. So now you can execute your query, with parameters and listen to changes in the resulting view.

Example 4.27. Implementing ViewChangedEventListener final List updated = new ArrayList(); final List removed = new ArrayList(); final List added = new ArrayList();

ViewChangedEventListener listener = new ViewChangedEventListener() { public void rowUpdated(Row row) { updated.add( row.get( "$price" ) ); }

public void rowRemoved(Row row) { removed.add( row.get( "$price" ) ); }

public void rowAdded(Row row) { added.add( row.get( "$price" ) ); } };

// Open the LiveQuery LiveQuery query = ksession.openLiveQuery( "cheeses", new Object[] { "cheddar", "s listener ); ... ... query.dispose() // make sure you call dispose when you want the query 



A Drools blog article contains an example of Glazed Lists integration for live queries, http://blog.athico.com/2010/07/glazed-lists-examples-for-drools-live.html

4.3.3.3. KnowledgeRuntime The KnowledgeRuntime provides further methods that are applicable to both

rules and processes, such as setting globals and ing Channels (previously exit points, some references may remain in docs for a while).

Figure 4.14. KnowledgeRuntime

4.3.3.3.1. Globals Globals are named objects that can be ed to the rule engine, without needing to insert them. Most often these are used for static information, or for services that are used in the RHS of a rule, or perhaps as a means to return objects from the rule engine. If you use a global on the LHS of a rule, make sure it is immutable. A global must first be declared in a rules file before it can be set on the session. global java.util.List list

With the Knowledge Base now aware of the global identifier and its type, it is now possible to call ksession.setGlobal() for any session. Failure to declare the global type and identifier first will result in an exception being thrown. To set the global on the session use ksession.setGlobal(identifier, value): List list = new ArrayList(); ksession.setGlobal("list", list);

If a rule evaluates on a global before you set it you will get a NullPointerException.

4.3.3.4. StatefulRuleSession The StatefulRuleSession is inherited by the StatefulKnowledgeSession and provides the rule related methods that are relevant from outside of the engine.

Figure 4.15. StatefulRuleSession

4.3.3.4.1. Agenda Filters

Figure 4.16. AgendaFilters

AgendaFilter objects are optional implementations of the filter interface which

are used to allow or deny the firing of an activation. What you filter on is entirely up to the implementation. Drools 4.0 used to supply some out of the box filters, which have not be exposed in drools 5.0 knowledge-api, but they are simple to implement and the Drools 4.0 code base can be referred to. To use a filter specify it while calling fireAllRules(). The following example permits only rules ending in the string "Test". All others will be filtered out.

ksession.fireAllRules( new RuleNameEndsWithAgendaFilter( "Test" ) );

4.3.4. Agenda The Agenda is a Rete feature. During actions on the WorkingMemory, rules may become fully matched and eligible for execution; a single Working Memory Action can result in multiple eligible rules. When a rule is fully matched an Activation is created, referencing the rule and the matched facts, and placed onto the Agenda. The Agenda controls the execution order of these Activations using a Conflict Resolution strategy. The engine cycles repeatedly through two phases: 1. Working Memory Actions. This either in the Consequence application process. Once the Java application process calls

is where most of the work (the RHS itself) or the Consequence has finished fireAllRules() the engine

takes place, main Java or the main switches to

the Agenda Evaluation phase. 2. Agenda Evaluation. This attempts to select a rule to fire. If no rule is found it exits, otherwise it fires the found rule, switching the phase back to Working Memory Actions.

Figure 4.17. Two Phase Execution

The process repeats until the agenda is clear, in which case control returns to the calling application. When Working Memory Actions are taking place, no rules are being fired.

Figure 4.18. Agenda

4.3.4.1. Conflict Resolution Conflict resolution is required when there are multiple rules on the agenda. (The basics to this are covered in chapter "Quick Start".) As firing a rule may have side effects on the working memory, the rule engine needs to know in what order the rules should fire (for instance, firing ruleA may cause ruleB to be removed from the agenda). The default conflict resolution strategies employed by Drools are: Salience and LIFO (last in, first out). The most visible one is salience (or priority), in which case a can specify that a certain rule has a higher priority (by giving it a higher number) than other rules. In that case, the rule with higher salience will be preferred. LIFO priorities are based on the assigned Working Memory Action counter value, with all rules created during the same action receiving the same value. The execution order of a set of firings with the same priority value is arbitrary. As a general rule, it is a good idea not to count on rules firing in any particular order, and to author the rules without worrying about a "flow".

However when a flow is needed a number of possibilities exist, including but not limited to: agenda groups, rule flow groups, activation groups, control/semaphore facts. These are discussed in later sections. Drools 4.0 ed custom conflict resolution strategies; while this capability still exists in Drools it has not yet been exposed to the end via knowledge-api in Drools 5.0.

4.3.4.2. AgendaGroup

Figure 4.19. AgendaGroup

Agenda groups are a way to partition rules (activations, actually) on the agenda. At any one time, only one group has "focus" which means that activations for rules in that group only will take effect. You can also have rules with "auto focus" which means that the focus is taken for its agenda group when that rule's conditions are true. Agenda groups are known as "modules" in CLIPS terminology. While it best to design rules that do not need control flow, this is not always possible. Agenda groups provide a handy way to create a "flow" between grouped rules. You can switch the group which has focus either from within the rule engine, or via the API. If your rules have a clear need for multiple "phases" or "sequences" of processing, consider using agenda-groups for this purpose. Each time setFocus() is called it pushes that Agenda Group onto a stack. When the focus group is empty it is popped from the stack and the focus

group that is now on top evaluates. An Agenda Group can appear in multiple locations on the stack. The default Agenda Group is "MAIN", with all rules which do not specify an Agenda Group being in this group. It is also always the first group on the stack, given focus initially, by default. ksession.getAgenda().getAgendaGroup( "Group A" ).setFocus();

4.3.4.3. ActivationGroup

Figure 4.20. ActivationGroup

An activation group is a set of rules bound together by the same "activationgroup" rule attribute. In this group only one rule can fire, and after that rule has fired all the other rules are cancelled from the agenda. The clear() method can be called at any time, which cancels all of the activations before one has had a chance to fire. ksession.getAgenda().getActivationGroup( "Group B" ).clear();

4.3.4.4. RuleFlowGroup

Figure 4.21. RuleFlowGroup

A rule flow group is a group of rules associated by the "ruleflow-group" rule attribute. These rules can only fire when the group is activate. The group itself can only become active when the elaboration of the ruleflow diagram reaches the node representing the group. Here too, the clear() method can be called at any time to cancels all activations still remaining on the Agenda. ksession.getAgenda().getRuleFlowGroup( "Group C" ).clear();

4.3.5. Event Model The event package provides means to be notified of rule engine events, including rules firing, objects being asserted, etc. This allows you, for instance, to separate logging and auditing activities from the main part of your application (and the rules). The

KnowlegeRuntimeEventManager

interface

is

implemented

by

the

KnowledgeRuntime which provides two interfaces, WorkingMemoryEventManager

and ProcessEventManager. We will only cover the WorkingMemoryEventManager here.

Figure 4.22. KnowledgeRuntimeEventManager

The WorkingMemoryEventManager allows for listeners to be added and removed, so that events for the working memory and the agenda can be listened to.

Figure 4.23. WorkingMemoryEventManager

The following code snippet shows how a simple agenda listener is declared and attached to a session. It will print activations after they have fired.

Example 4.28. Adding an AgendaEventListener ksession.addEventListener( new DefaultAgendaEventListener() { public void afterActivationFired(AfterActivationFiredEvent event) { super.afterActivationFired( event ); System.out.println( event ); } }); 



Drools

also

provides

DebugWorkingMemoryEventListener

and

DebugAgendaEventListener which implement each method with a debug print

statement. To print all Working Memory events, you add a listener like this:

Example 4.29. Creating a new KnowledgeBuilder ksession.addEventListener( new DebugWorkingMemoryEventListener() ); 



All emitted events implement the KnowlegeRuntimeEvent interface which can be used to retrieve the actual KnowlegeRuntime the event originated from.

Figure 4.24. KnowlegeRuntimeEvent

The events currently ed are: ActivationCreatedEvent ActivationCancelledEvent BeforeActivationFiredEvent AfterActivationFiredEvent AgendaGroupPushedEvent AgendaGroupPoppedEvent ObjectInsertEvent ObjectRetractedEvent ObjectUpdatedEvent ProcessCompletedEvent ProcessNodeLeftEvent ProcessNodeTriggeredEvent ProcessStartEvent

4.3.6. KnowledgeRuntimeLogger The KnowledgeRuntimeLogger uses the comprehensive event system in Drools to create an audit log that can be used to log the execution of an application for later inspection, using tools such as the Eclipse audit viewer.

Figure 4.25. KnowledgeRuntimeLoggerFactory

Example 4.30. FileLogger KnowledgeRuntimeLogger logger = KnowledgeRuntimeLoggerFactory.newFileLogger(ksession, "logdir/mylogf ... logger.close(); 



4.3.7. StatelessKnowledgeSession The StatelessKnowledgeSession wraps the StatefulKnowledgeSession, instead of extending it. Its main focus is on decision service type scenarios. It avoids the need to call dispose(). Stateless sessions do not iterative insertions and the method call fireAllRules() from Java code; the act of calling execute() is a single-shot method that will internally instantiate a StatefulKnowledgeSession, add all the data and execute commands,

call fireAllRules(), and then call dispose(). While the main way to work with this class is via the BatchExecution (a subinterface of Command) as ed by the CommandExecutor interface, two convenience methods are provided for when simple object insertion is all that's required. The CommandExecutor and BatchExecution are talked about in detail in their own section.

Figure 4.26. StatelessKnowledgeSession

Our simple example shows a stateless session executing a given collection of Java objects using the convenience API. It will iterate the collection, inserting each element in turn.

Example 4.31. Simple StatelessKnowledgeSession execution with a Collection KnowledgeBuilder kbuilder = KnowledgeBuilderFactory.newKnowledgeBuilde kbuilder.add( ResourceFactory.newFileSystemResource( fileName ), Resou if (kbuilder.hasErrors() ) { System.out.println( kbuilder.getErrors() ); } else { KnowledgeBase kbase = KnowledgeBaseFactory.newKnowledgeBase(); kbase.addKnowledgePackages( kbuilder.getKnowledgePackages() ); StatelessKnowledgeSession ksession = kbase.newStatelessKnowledgeSe ksession.execute( collection ); } 



If this was done as a single Command it would be as follows:

Example 4.32. Simple StatelessKnowledgeSession execution with InsertElements Command ksession.execute( CommandFactory.newInsertElements( collection ) ); 



If you wanted to insert the collection itself, and the collection's individual elements, then CommandFactory.newInsert(collection) would do the job. Methods of the CommandFactory create the ed commands, all of which can

be

marshalled

using

XStream

and

the

BatchExecutionHelper.

BatchExecutionHelper provides details on the XML format as well as how to

use Drools Pipeline to automate the marshalling of BatchExecution and ExecutionResults.

StatelessKnowledgeSession s globals, scoped in a number of ways. I'll

cover the non-command way first, as commands are scoped to a specific execution call. Globals can be resolved in three ways. The Stateless Knowledge Session method getGlobals() returns a Globals instance which provides access to the session's globals. These are shared for all execution calls. Exercise caution regarding mutable globals because execution calls can be executing simultaneously in different threads. Example 4.33. Session scoped global StatelessKnowledgeSession ksession = kbase.newStatelessKnowledgeSes // Set a global hbnSession, that can be used for DB interactions in ksession.setGlobal( "hbnSession", hibernateSession ); // Execute while being able to resolve the "hbnSession" identifier. ksession.execute( collection ); 



Using a delegate is another way of global resolution. Asg a value to a global (with setGlobal(String, Object)) results in the value being stored in an internal collection mapping identifiers to values. Identifiers in this internal collection will have priority over any supplied delegate. Only if an identifier cannot be found in this internal collection, the delegate global (if any) will be used. The third way of resolving globals is to have execution scoped globals. Here, a Command to set a global is ed to the CommandExecutor. The CommandExecutor interface also offers the ability to export data via "out" parameters. Inserted facts, globals and query results can all be returned.

Example 4.34. Out identifiers

// Set up a list of commands List cmds = new ArrayList(); cmds.add( CommandFactory.newSetGlobal( "list1", new ArrayList(), true cmds.add( CommandFactory.newInsert( new Person( "jon", 102 ), "person" cmds.add( CommandFactory.newQuery( "Get People" "getPeople" ); // Execute the list ExecutionResults results = ksession.execute( CommandFactory.newBatchExecution( cmds ) ); // Retrieve the ArrayList results.getValue( "list1" ); // Retrieve the inserted Person fact results.getValue( "person" ); // Retrieve the query as a QueryResults instance. results.getValue( "Get People" ); 



4.3.7.1. Sequential Mode With Rete you have a stateful session where objects can be asserted and modified over time, and where rules can also be added and removed. Now what happens if we assume a stateless session, where after the initial data set no more data can be asserted or modified and rules cannot be added or removed? Certainly it won't be necessary to re-evaluate rules, and the engine will be able to operate in a simplified way. 1. Order the Rules by salience and position in the ruleset (by setting a sequence attribute on the rule terminal node). 2. Create an array, one element for each possible rule activation; element position indicates firing order. 3. Turn off all node memories, except the right-input Object memory. 4. Disconnect the Left Input Adapter Node propagation, and let the Object plus the Node be referenced in a Command object, which is added to a list on the Working Memory for later execution. 5. Assert all objects, and, when all assertions are finished and thus rightinput node memories are populated, check the Command list and execute each in turn.

6. All resulting Activations should be placed in the array, based upon the determined sequence number of the Rule. Record the first and last populated elements, to reduce the iteration range. 7. Iterate the array of Activations, executing populated element in turn. 8. If we have a maximum number of allowed rule executions, we can exit our network evaluations early to fire all the rules in the array. The LeftInputAdapterNode no longer creates a Tuple, adding the Object, and then propagate the Tuple – instead a Command object is created and added to a list in the Working Memory. This Command object holds a reference to the LeftInputAdapterNode and the propagated object. This stops any left-input propagations at insertion time, so that we know that a right-input propagation will never need to attempt a with the left-inputs (removing the need for left-input memory). All nodes have their memory turned off, including the left-input Tuple memory but excluding the right-input object memory, which means that the only node ing an insertion propagation is the right-input object memory. Once all the assertions are finished and all right-input memories populated, we can then iterate the list of LeftInputAdatperNode Command objects calling each in turn. They will propagate down the network attempting to with the right-input objects, but they won't be ed in the left input as we know there will be no further object assertions and thus propagations into the right-input memory. There is no longer an Agenda, with a priority queue to schedule the Tuples; instead, there is simply an array for the number of rules. The sequence number of the RuleTerminalNode indicates the element within the array where to place the Activation. Once all Command objects have finished we can iterate our array, checking each element in turn, and firing the Activations if they exist. To improve performance, we the first and the last populated cell in the array. The network is constructed, with each RuleTerminalNode being given a sequence number based on a salience number and its order of being added to the network. Typically the right-input node memories are Hash Maps, for fast object retraction; here, as we know there will be no object retractions, we can use a list when the values of the object are not indexed. For larger numbers of objects indexed Hash Maps provide a performance increase; if we know an object type has only a few instances, indexing is probably not advantageous, and a list can be used. Sequential mode can only be used with a Stateless Session and is off by default. To turn it on, either call RuleBaseConfiguration.setSequential(true),

or set the rulebase configuration property drools.sequential to true. Sequential

mode

can fall back to a dynamic agenda by calling setSequentialAgenda with SequentialAgenda.DYNAMIC. You may also set the "drools.sequential.agenda" property to "sequential" or "dynamic".

4.3.8. Commands and the CommandExecutor Drools has the concept of stateful or stateless sessions. We've already covered stateful sessions, which use the standard working memory that can be worked with iteratively over time. Stateless is a one-off execution of a working memory with a provided data set. It may return some results, with the session being disposed at the end, prohibiting further iterative interactions. You can think of stateless as treating a rule engine like a function call with optional return results. In Drools 4 we ed these two paradigms but the way the interacted with them was different. StatelessSession used an execute(...) method which would insert a collection of objects as facts. StatefulSession didn't have this method, and insert used the more traditional insert(...) method. The other issue was that the StatelessSession did not return any results, so that s themselves had to map globals to get results, and it wasn't possible to do anything besides inserting objects; s could not start processes or execute queries. Drools 5.0 addresses all of these issues and more. The foundation for this is the CommandExecutor interface, which both the stateful and stateless interfaces extend, creating consistency and ExecutionResults:

Figure 4.27. CommandExecutor

Figure 4.28. ExecutionResults

The CommandFactory allows for commands to be executed on those sessions, the only difference being that the Stateless Knowledge Session executes fireAllRules() at the end before disposing the session. The currently ed commands are: FireAllRules GetGlobal SetGlobal InsertObject InsertElements Query StartProcess BatchExecution InsertObject will insert a single object, with an optional "out" identifier. InsertElements will iterate an Iterable, inserting each of the elements. What

this means is that a Stateless Knowledge Session is no longer limited to just inserting objects, it can now start processes or execute queries, and do this in any order.

Example 4.35. Insert Command StatelessKnowledgeSession ksession = kbase.newStatelessKnowledgeSessio ExecutionResults bresults = ksession.execute( CommandFactory.newInsert( new Cheese( "stilton" ), Stilton stilton = bresults.getValue( "stilton_id" ); 



The execute method always returns an ExecutionResults instance, which allows access to any command results if they specify an out identifier such as the "stilton_id" above.

Example 4.36. InsertElements Command StatelessKnowledgeSession ksession = kbase.newStatelessKnowledgeSessio Command cmd = CommandFactory.newInsertElements( Arrays.asList( Object[ new Cheese( "stilton" ), new Cheese( "brie" ), new Cheese( "cheddar" ), }); ExecutionResults bresults = ksession.execute( cmd ); 



The execute method only allows for a single command. That's where BatchExecution comes in, which represents a composite command, created from a list of commands. Now, execute will iterate over the list and execute each command in turn. This means you can insert some objects, start a process, call fireAllRules and execute a query, all in a single execute(...) call, which is quite powerful. As mentioned previosly, the Stateless Knowledge Session will execute fireAllRules() automatically at the end. However the keen-eyed reader probably has already noticed the FireAllRules command and wondered how that works with a StatelessKnowledgeSession. The FireAllRules command is allowed, and using it will disable the automatic execution at the end; think of using it as a sort of manual override function.

Commands out identifiers. Any command that has an out identifier set on it will add its results to the returned ExecutionResults instance. Let's look at a simple example to see how this works.

Example 4.37. BatchExecution Command StatelessKnowledgeSession ksession = kbase.newStatelessKnowledgeSessio List cmds = new ArrayList(); cmds.add( CommandFactory.newInsertObject( new Cheese( "stilton", 1), " cmds.add( CommandFactory.newStartProcess( "process cheeses" ) ); cmds.add( CommandFactory.newQuery( "cheeses" ) ); ExecutionResults bresults = ksession.execute( CommandFactory.newBatchE Cheese stilton = ( Cheese ) bresults.getValue( "stilton" ); QueryResults qresults = ( QueryResults ) bresults.getValue( "cheeses" 



In the above example multiple commands are executed, two of which populate the ExecutionResults. The query command defaults to use the same identifier as the query name, but it can also be mapped to a different identifier. A custom XStream marshaller can be used with the Drools Pipeline to achieve XML scripting, which is perfect for services. Here are two simple XML samples, one for the BatchExecution and one for the ExecutionResults.

Example 4.38. Simple BatchExecution XML stilton <price>25 0

Example 4.39. Simple ExecutionResults XML <execution-results> stilton 25 <price>30

Spring and Camel, covered in the integrations book, facilitate declarative services.

Example 4.40. BatchExecution Marshalled to XML stilton <price>1 0 <string>stilton <string>cheddar

The CommandExecutor returns an ExecutionResults, and this is handled by the pipeline code snippet as well. A similar output for the XML sample above would be:

Example 4.41. ExecutionResults Marshalled to XML

<execution-results> stilton <price>2

cheese cheddar <price>2 0 cheddar <price>1 0

The BatchExecutionHelper provides a configured XStream instance to the marshalling of Batch Executions, where the resulting XML can be used as a message format, as shown above. Configured converters only exist for the commands ed via the Command Factory. The may add other converters for their objects. This is very useful for scripting stateless or stateful knowledge sessions, especially when services are involved. There is currently no XML schema to schema validation. The basic format is outlined here, and the drools-pipeline module has an illustrative unit test in the XStreamBatchExecutionTest unit test. The root element is and it can contain zero or more commands elements.

Example 4.42. Root XML element ...

This contains a list of elements that represent commands, the ed commands is limited to those Commands provided by the Command Factory. The most basic of these is the element, which inserts objects. The contents of the insert element is the object, as dictated by XStream.

Example 4.43. Insert ...

The insert element features an "out-identifier" attribute, demanding that the inserted object will also be returned as part of the result payload.

Example 4.44. Insert with Out Identifier Command ...

It's also possible to insert a collection of objects using the element. This command does not an out-identifier. The org.domain.Class is just an illustrative object that XStream would

serialize.

Example 4.45. Insert Elements command

... ... ...

Next, there is the <set-global> element, which sets a global for the session.

Example 4.46. Insert Elements command <set-global identifier='Var'> ...

<set-global>

also

s

two

other

optional

attributes,

out

and

out-identifier. A true value for the boolean out will add the global to the payload, using the name from the identifier

attribute. out-identifier works like out but additionally allows you to override the identifier used in the payload.

Example 4.47. Set Global Command

<set-global identifier='Var1' out='true'> ... <set-global identifier='Var2' out-identifier='alternativeVa ... 



There is also a element, without contents, with just an out-identifier attribute. (There is no need for an out attribute because

retrieving the value is the sole purpose of a element.

Example 4.48. Get Global Command

<string>stilton <string>cheddar

The <start-process> command accepts optional parameters. Other process related methods will be added later, like interacting with work items.

Example 4.50. Start Process Command <startProcess processId='org.drools.actions'> <parameter identifier='person'> John Doe

Example 4.51. Signal Event Command <signal-event process-instance-id='1' event-type='MyEvent'> <string>MyValue

Example 4.52. Complete Work Item Command

<string>SomeOtherString

Example 4.53. Abort Work Item Command

for more commands will be added over time.

4.3.9. Marshalling The MarshallerFactory is used to marshal and unmarshal Stateful Knowledge Sessions.

Figure 4.29. MarshallerFactory

At the simplest the MarshallerFactory can be used as follows:

Example 4.54. Simple Marshaller Example

// ksession is the StatefulKnowledgeSession // kbase is the KnowledgeBase ByteArrayOutputStream baos = new ByteArrayOutputStream(); Marshaller marshaller = MarshallerFactory.newMarshaller( kbase ); marshaller.marshall( baos, ksession ); baos.close();

However, with marshalling you need more flexibility when dealing with referenced data. To achieve this we have the ObjectMarshallingStrategy interface. Two implementations are provided, but s can implement their own. The two supplied strategies are IdentityMarshallingStrategy and SerializeMarshallingStrategy. SerializeMarshallingStrategy is the default, as

used

in

the

example

above,

and

it

just

calls

the

Serializable

or

Externalizable methods on a instance. IdentityMarshallingStrategy

instead creates an integer id for each object and stores them in a Map, while the id is written to the stream. When unmarshalling it accesses the IdentityMarshallingStrategy map to retrieve the instance. This means that if you use the IdentityMarshallingStrategy, it is stateful for the life of the Marshaller instance and will create ids and keep references to all objects that it attempts to marshal. Below is he code to use an Identity Marshalling Strategy.

Example 4.55. IdentityMarshallingStrategy ByteArrayOutputStream baos = new ByteArrayOutputStream(); ObjectMarshallingStrategy oms = MarshallerFactory.newIdentityMarshalli Marshaller marshaller = MarshallerFactory.newMarshaller( kbase, new ObjectMarshallingStrateg marshaller.marshall( baos, ksession ); baos.close(); 



For added flexability we can't assume that a single strategy is suitable. Therefore we have added the ObjectMarshallingStrategyAcceptor interface that each Object Marshalling Strategy contains. The Marshaller has a chain of strategies, and when it attempts to read or write a object it iterates the

strategies asking if they accept responsability for marshalling the object. One of the provided implementations is ClassFilterAcceptor. This allows strings and wild cards to be used to match class names. The default is "*.*", so in the above example the Identity Marshalling Strategy is used which has a default "*.*" acceptor. Assuming that we want to serialize all classes except for one given package, where we will use identity lookup, we could do the following:

Example 4.56. IdentityMarshallingStrategy with Acceptor ByteArrayOutputStream baos = new ByteArrayOutputStream(); ObjectMarshallingStrategyAcceptor identityAcceptor = MarshallerFactory.newClassFilterAcceptor( new String[] { "org.domain ObjectMarshallingStrategy identityStrategy = MarshallerFactory.newIdentityMarshallingStrategy( identityAcceptor ) ObjectMarshallingStrategy sms = MarshallerFactory.newSerializeMarshall Marshaller marshaller = MarshallerFactory.newMarshaller( kbase, new ObjectMarshallingStrategy[]{ id marshaller.marshall( baos, ksession ); baos.close(); 



Note that the acceptance checking order is in the natural order of the supplied array.

4.3.10. Persistence and Transactions Longterm out of the box persistence with Java Persistence API (JPA) is possible with Drools. You will need to have some implementation of the Java Transaction API (JTA) installed. For development purposes we recommend the Bitronix Transaction Manager, as it's simple to set up and works embedded, but for production use JBoss Transactions is recommended.

Example 4.57. Simple example using transactions

Environment env = KnowledgeBaseFactory.newEnvironment(); env.set( EnvironmentName.ENTITY_MANAGER_FACTORY, Persistence.createEntityManagerFactory( "emf-name" ) ); env.set( EnvironmentName.TRANSACTION_MANAGER, TransactionManagerServices.getTransactionManager() );

// KnowledgeSessionConfiguration may be null, and a default will be us StatefulKnowledgeSession ksession = JPAKnowledgeService.newStatefulKnowledgeSession( kbase, null, env ); int sessionId = ksession.getId();

Transaction ut = (Transaction) new InitialContext().lookup( "java:comp/Transa ut.begin(); ksession.insert( data1 ); ksession.insert( data2 ); ksession.startProcess( "process1" ); ut.commit(); 

To



use

a

JPA,

the Environment must be set with both the EntityManagerFactory and the TransactionManager. If rollback occurs the ksession state is also rolled back, so you can continue to use it after a rollback. To load a previously persisted Stateful Knowledge Session you'll need the id, as shown below:

Example 4.58. Loading a StatefulKnowledgeSession StatefulKnowledgeSession ksession = JPAKnowledgeService.loadStatefulKnowledgeSession( sessionId, kbase, 

To enable persistence several classes persistence.xml, as in the example below:

Example 4.59. Configuring JPA



must

be

added

to

your

<property name="hibernate.hbm2ddl.auto" value="update" /> <property name="hibernate.show_sql" value="true" /> <property name="hibernate.transaction.manager_lookup_class" value="org.hibernate.transaction.BTMTransactionM 



The jdbc JTA data source would have to be configured first. Bitronix provides a number of ways of doing this, and its documentation should be contsulted for details. For a quick start, here is the programmatic approach:

Example 4.60. Configuring JTA DataSource PoolingDataSource ds = new PoolingDataSource(); ds.setUniqueName( "jdbc/BitronixJTADataSource" ); ds.setClassName( "org.h2.jdbcx.JdbcDataSource" ); ds.setMaxPoolSize( 3 ); ds.setAllowLocalTransactions( true ); ds.getDriverProperties().put( "", "sa" ); ds.getDriverProperties().put( "", "sasa" ); ds.getDriverProperties().put( "URL", "jdbc:h2:mem:mydb" ); ds.init();

Bitronix also provides a simple embedded JNDI service, ideal for testing. To use it add a jndi.properties file to your META-INF and add the following line to it:

Example 4.61. JNDI properties java.naming.factory.initial=bitronix.tm.jndi.BitronixInitialContextFac 



4.3.11. Drools Clips Drools Clips is an alpha level research project to provide a Clips like front end ot Drools. As of Drools 5.2 this module as stopped working, we will try and fix for 5.3. Deftemplates are working, the knowledge base handles multiple name spaces and you can attach the knoweldge base to the session for interative building, to provide a more "shell" like environment suitable for Clips. deftemplate defrule deffunction and/or/not/exists/test conditional elements Literal, Variable, Return Value and Predicate field constarints

This project is very early stages and in need of love. If you want to help, open up eclipse import api, core, compiler and clips and you should be good to go. The unit tests should be self explanatory.

Chapter 5. The Rule Language 5.1. Overview 5.1.1. A rule file 5.1.2. What makes a rule 5.2. Keywords

5.3. Comments 5.3.1. Single line comment 5.3.2. Multi-line comment 5.4. Error Messages 5.4.1. Message format 5.4.2. Error Messages Description 5.4.3. Other Messages 5.5. Package 5.5.1. import 5.5.2. global 5.6. Function 5.7. Type Declaration 5.7.1. 5.7.2. 5.7.3. 5.7.4. 5.7.5. 5.7.6. 5.7.7.

Declaring New Types Declaring Metadata Declaring Metadata for Existing Types Parameterized constructors for declared types Non Typesafe Classes Accessing Declared Types from the Application Code Type Declaration 'extends'

5.8. Rule 5.8.1. 5.8.2. 5.8.3. 5.8.4. 5.8.5.

Rule Attributes Timers and Calendars Left Hand Side (when) syntax The Right Hand Side (then) A Note on Auto-boxing and Primitive Types

5.9. Query 5.10. Domain Specific Languages 5.10.1. 5.10.2. 5.10.3. 5.10.4. 5.10.5.

When to Use a DSL DSL Basics Adding Constraints to Facts Developing a DSL DSL and DSLR Reference

5.11. XML Rule Language 5.11.1. When to use XML

5.11.2. The XML format 5.11.3. Legacy Drools 2.x XML rule format 5.11.4. Automatic transforming between formats (XML and DRL)

5.1. Overview Drools has a "native" rule language. This format is very light in of punctuation, and s natural and domain specific languages via "expanders" that allow the language to morph to your problem domain. This chapter is mostly concerted with this native rule format. The diagrams used to present the syntax are known as "railroad" diagrams, and they are basically flow charts for the language . The technically very keen may also refer to DRL.g which is the Antlr3 grammar for the rule language. If you use the Rule Workbench, a lot of the rule structure is done for you with content assistance, for example, type "ru" and press ctrl+space, and it will build the rule structure for you.

5.1.1. A rule file A rule file is typically a file with a .drl extension. In a DRL file you can have multiple rules, queries and functions, as well as some resource declarations like imports, globals and attributes that are assigned and used by your rules and queries. However, you are also able to spread your rules across multiple rule files (in that case, the extension .rule is suggested, but not required) spreading rules across files can help with managing large numbers of rules. A DRL file is simply a text file. The overall structure of a rule file is:

Example 5.1. Rules file

package package-name

imports globals functions queries rules

The order in which the elements are declared is not important, except for the package name that, if declared, must be the first element in the rules file. All elements are optional, so you will use only those you need. We will discuss each of them in the following sections.

5.1.2. What makes a rule For the inpatients, just as an early view, a rule has the following rough structure: rule "name"

attributes when

LHS then

RHS end

It's really that simple. Mostly punctuation is not needed, even the double quotes for "name" are optional, as are newlines. Attributes are simple (always optional) hints to how the rule should behave. LHS is the conditional parts of the rule, which follows a certain syntax which is covered below. RHS is basically a block that allows dialect specific semantic code to be executed. It is important to note that white space is not important, except in the case of domain specific languages, where lines are processed one by one and spaces may be significant to the domain language.

5.2. Keywords Drools 5 introduces the concept of hard and soft keywords. Hard keywords are reserved, you cannot use any hard keyword when naming your domain objects, properties, methods, functions and other elements that are used in the rule text. Here is the list of hard keywords that must be avoided as identifiers when writing rules: true false null

Soft keywords are just recognized in their context, enabling you to use these words in any other place if you wish, although, it is still recommended to avoid them, to avoid confusions, if possible. Here is a list of the soft keywords: lock-on-active date-effective date-expires no-loop auto-focus activation-group agenda-group ruleflow-group entry-point duration package import dialect salience

enabled attributes rule extend

when then template query declare function global eval not in or and exists forall

accumulate collect from action reverse result end

over init

Of course, you can have these (hard and soft) words as part of a method name in camel case, like notSomething() or accumulateSomething() - there are no issues with that scenario.

Although the 3 hard keywords above are unlikely to be used in your existing domain models, if you absolutely need to use them as identifiers instead of keywords, the DRL language provides the ability to escape hard keywords on rule text. To escape a word, simply enclose it in grave accents, like this: Holiday( `true` == "yes" ) // please note that Drools will resolve that 



5.3. Comments Comments are sections of text that are ignored by the rule engine. They are stripped out when they are encountered, except inside semantic code blocks, like the RHS of a rule.

5.3.1. Single line comment

Figure 5.1. Single line comment

To create single line comments, you can use either '#' or '//'. The parser will ignore anything in the line after the comment symbol. Example: rule "Testing Comments" when # this is a single line comment // this is also a single line comment eval( true ) # this is a comment in the same line of a pattern then // this is a comment inside a semantic code block # this is another comment in a semantic code block end

5.3.2. Multi-line comment

Figure 5.2. Multi-line comment

Multi-line comments are used to comment blocks of text, both in and outside semantic code blocks. Example: rule "Test Multi-line Comments" when /* this is a multi-line comment in the left hand side of a rule */ eval( true ) then /* and this is a multi-line comment in the right hand side of a rule */ end

5.4. Error Messages Drools 5 introduces standardized error messages. This standardization aims to help s to find and resolve problems in a easier and faster way. In this section you will learn how to identify and interpret those error messages, and you will also receive some tips on how to solve the problems associated with them.

5.4.1. Message format The standardization includes the error message format and to better explain this format, let's use the following example:

Figure 5.3. Error Message Format

1st Block: This area identifies the error code. 2nd Block: Line and column information. 3rd Block: Some text describing the problem. 4th Block: This is the first context. Usually indicates the rule, function, template or query where the error occurred. This block is not mandatory. 5th Block: Identifies the pattern where the error occurred. This block is not mandatory.

5.4.2. Error Messages Description

5.4.2.1. 101: No viable alternative Indicates the most common errors, where the parser came to a decision point but couldn't identify an alternative. Here are some examples:

Example 5.2. 1: rule one 2:

when

3:

exists Foo()

4:

exits Bar()

5:

then

6: end

The above example generates this message: [ERR 101] Line 4:4 no viable alternative at input 'exits' in rule one At first glance this seems to be valid syntax, but it is not (exits != exists). Let's take a look at next example:

Example 5.3.

1: package org.drools; 2: rule 3:

when

4: 5:

Object() then

6:

System.out.println("A RHS");

7: end

Now the above code generates this message: [ERR 101] Line 3:2 no viable alternative at input 'WHEN' This message means that the parser encountered the token WHEN, actually a hard keyword, but it's in the wrong place since the the rule name is missing. The error "no viable alternative" also occurs when you make a simple lexical mistake. Here is a sample of a lexical problem:

Example 5.4. 1: rule simple_rule 2:

when

3: 4:

Student( name == "Andy ) then

5: end

The above code misses to close the quotes and because of this the parser generates this error message: [ERR 101] Line 0:-1 no viable alternative at input '<eof>' in rule simple_rule in pattern Student

Note Usually the Line and Column information are accurate, but in some cases (like unclosed quotes), the parser generates a 0:-1

position. In this case you should check whether you didn't forget to close quotes, apostrophes or parentheses.

5.4.2.2. 102: Mismatched input This error indicates that the parser was looking for a particular symbol that it didn’t find at the current input position. Here are some samples:

Example 5.5. 1: rule simple_rule 2: 3:

when foo3 : Bar(

The above example generates this message: [ERR 102] Line 0:-1 mismatched input '<eof>' expecting ')' in rule simple_rule in pattern Bar To fix this problem, it is necessary to complete the rule statement.

Note Usually when you get a 0:-1 position, it means that parser reached the end of source.

The following code generates more than one error message:

Example 5.6.

1: package org.drools; 2: 3: rule "Avoid NPE on wrong syntax" 4:

when

5: 6:

not( Cheese( ( type == "stilton", price == 10 ) || ( type == "b then

7:

System.out.println("OK");

8: end 



These are the errors associated with this source: [ERR 102] Line 5:36 mismatched input ',' expecting ')' in rule "Avoid NPE on wrong syntax" in pattern Cheese [ERR 101] Line 5:57 no viable alternative at input 'type' in rule "Avoid NPE on wrong syntax" [ERR 102] Line 5:106 mismatched input ')' expecting 'then' in rule "Avoid NPE on wrong syntax" Note that the second problem is related to the first. To fix it, just replace the commas (',') by AND operator ('&&').

Note In some situations you can get more than one error message. Try to fix one by one, starting at the first one. Some error messages are generated merely as consequences of other errors.

5.4.2.3. 103: Failed predicate A validating semantic predicate evaluated to false. Usually these semantic predicates are used to identify soft keywords. This sample shows exactly this situation:

Example 5.7.

1: package nesting; 2: dialect "mvel" 3: 4: import org.drools.Person 5: import org.drools.Address 6: 7: fdsfdsfds 8: 9: rule "test something" 10:

when

11: 12:

p: Person( name=="Michael" ) then

13:

p.name = "other";

14:

System.out.println(p.name);

15: end

With this sample, we get this error message: [ERR 103] Line 7:0 rule 'rule_key' failed {(validateIdentifierKey(DroolsSoftKeywords.RULE))}? in rule

predicate:

The fdsfdsfds text is invalid and the parser couldn’t identify it as the soft keyword rule.

Note This error is very similar to 102: Mismatched input, but usually involves soft keywords.

5.4.2.4. 104: Trailing semi-colon not allowed This error is associated with the eval clause, where its expression may not be terminated with a semicolon. Check this example:

Example 5.8.

1: rule simple_rule 2:

when

3: 4:

eval(abc();) then

5: end

Due to the trailing semicolon within eval, we get this error message: [ERR 104] Line 3:4 trailing semi-colon not allowed in rule simple_rule This problem is simple to fix: just remove the semi-colon.

5.4.2.5. 105: Early Exit The recognizer came to a subrule in the grammar that must match an alternative at least once, but the subrule did not match anything. Simply put: the parser has entered a branch from where there is no way out. This example illustrates it:

Example 5.9. 1: template test_error 2:

aa s

11;

3: end

This is the message associated to the above sample: [ERR 105] Line 2:2 required (...)+ loop did not match anything at input 'aa' in template test_error To fix this problem it is necessary to remove the numeric value as it is neither a valid data type which might begin a new template slot nor a possible start for any other rule file construct.

5.4.3. Other Messages

Any other message means that something bad has happened, so please the development team.

5.5. Package A package is a collection of rules and other related constructs, such as imports and globals. The package are typically related to each other - perhaps HR rules, for instance. A package represents a namespace, which ideally is kept unique for a given grouping of rules. The package name itself is the namespace, and is not related to files or folders in any way. It is possible to assemble rules from multiple rule sources, and have one top level package configuration that all the rules are kept under (when the rules are assembled). Although, it is not possible to merge into the same package resources declared under different names. A single Rulebase may, however, contain multiple packages built on it. A common structure is to have all the rules for a package in the same file as the package declaration (so that is it entirely self-contained). The following railroad diagram shows all the components that may make up a package. Note that a package must have a namespace and be declared using standard Java conventions for package names; i.e., no spaces, unlike rule names which allow spaces. In of the order of elements, they can appear in any order in the rule file, with the exception of the package statement, which must be at the top of the file. In all cases, the semicolons are optional.

Figure 5.4. package

Notice that any rule atttribute (as described the section Rule Attributes) may also be written at package level, superseding the attribute's default value. The modified default may still be replaced by an attribute setting within a rule.

5.5.1. import

Figure 5.5. import

Import statements work like import statements in Java. You need to specify the fully qualified paths and type names for any objects you want to use in the rules. Drools automatically imports classes from the Java package of the same name, and also from the package java.lang.

5.5.2. global

Figure 5.6. global

With global you define global variables. They are used to make application objects available to the rules. Typically, they are used to provide data or services that the rules use, especially application services used in rule consequences, and to return data from the rules, like logs or values added in rule consequences, or for the rules to interact with the application, doing callbacks. Globals are not inserted into the Working Memory, and therefore a global should never be used to establish conditions in rules except when it has a constant immutable value. The engine cannot be notified about value changes of globals and does not track their changes. Incorrect use of globals in constraints may yield surprising results - surprising in a bad way. If multiple packages declare globals with the same identifier they must be of the same type and all of them will reference the same global value. In order to use globals you must: 1. Declare your global variable in your rules file and use it in rules. Example: global java.util.List myGlobalList;

rule "Using a global" when eval( true ) then myGlobalList.add( "Hello World" ); end

2. Set the global value on your working memory. It is a best practice to set all global values before asserting any fact to the working memory. Example:

List list = new ArrayList(); WorkingMemory wm = rulebase.newStatefulSession(); wm.setGlobal( "myGlobalList", list );

Note that these are just named instances of objects that you in from your application to the working memory. This means you can in any object you want: you could in a service locator, or perhaps a service itself. With the new from element it is now common to a Hibernate session as a global, to allow from to pull data from a named Hibernate query. One example may be an instance of a Email service. In your integration code that is calling the rule engine, you obtain your emailService object, and then set it in the working memory. In the DRL, you declare that you have a global of type EmailService, and give it the name "email". Then in your rule consequences, you can use things like email.sendSMS(number, message). Globals are not designed to share data between rules and they should never be used for that purpose. Rules always reason and react to the working memory state, so if you want to data from rule to rule, assert the data as facts into the working memory. It is strongly discouraged to set or change a global value from inside your rules. We recommend to you always set the value from your application using the working memory interface.

5.6. Function

Figure 5.7. function

Functions are a way to put semantic code in your rule source file, as opposed to in normal Java classes. They can't do anything more than what you can do with helper classes. (In fact, the compiler generates the helper class for you behind the scenes.) The main advantage of using functions in a rule is that you can keep the logic all in one place, and you can change the functions as needed (which can be a good or a bad thing). Functions are most useful for invoking actions on the consequence (then) part of a rule, especially if that particular action is used over and over again, perhaps with only differing parameters for each rule. A typical function declaration looks like: function String hello(String name) { return "Hello "+name+"!"; }

Note that the function keyword is used, even though its not really part of Java. Parameters to the function are defined as for a method, and you don't have to have parameters if they are not needed. The return type is defined just like in a regular method. Alternatively, you could use a static method in a helper class, e.g., Foo.hello(). Drools s the use of function imports, so all you would need to do is: import function my.package.Foo.hello

Irrespective of the way the function is defined or imported, you use a function by calling it by its name, in the consequence or inside a semantic code block. Example: rule "using a static function" when eval( true ) then System.out.println( hello( "Bob" ) ); end

5.7. Type Declaration

Figure 5.8. meta_data

Figure 5.9. type_declaration

Type declarations have two main goals in the rules engine: to allow the declaration of new types, and to allow the declaration of metadata for types. Declaring new types: Drools works out of the box with plain Java objects as facts. Sometimes, however, s may want to define the model directly to the rules engine, without worrying about creating models in a lower level language like Java. At other times, there is a domain model already built, but eventually the wants or needs to complement this model with additional entities that are used mainly during the reasoning process. Declaring metadata: facts may have meta information associated to them. Examples of meta information include any kind of data that is not represented by the fact attributes and is consistent among all instances of that fact type. This meta information may be queried at runtime by the engine and used in the reasoning process.

5.7.1. Declaring New Types To declare a new type, all you need to do is use the keyword declare, followed by the list of fields, and the keyword end.

Example 5.10. Declaring a new fact type: Address declare Address number : int streetName : String city : String end

The previous example declares a new fact type called Address. This fact type will have three attributes: number, streetName and city. Each attribute has a type that can be any valid Java type, including any other class created by the or even other fact types previously declared. For instance, we may want to declare another fact type Person:

Example 5.11. declaring a new fact type: Person

declare Person name : String dateOfBirth : java.util.Date address : Address end

As

we

can

see

on

the

previous

example,

dateOfBirth

is

of

type

java.util.Date, from the Java API, while address is of the previously defined

fact type Address. You may avoid having to write the fully qualified name of a class every time you write it by using the import clause, as previously discussed.

Example 5.12. Avoiding the need to use fully qualified class names by using import import java.util.Date

declare Person name : String dateOfBirth : Date address : Address end

When you declare a new fact type, Drools will, at compile time, generate bytecode that implements a Java class representing the fact type. The generated Java class will be a one-to-one Java Bean mapping of the type definition. So, for the previous example, the generated Java class would be:

Example 5.13. generated Java class for the previous Person fact type declaration

public class Person implements Serializable { private String name; private java.util.Date dateOfBirth; private Address address; // empty constructor public Person() {...} // constructor with all fields public Person( String name, Date dateOfBirth, Address address ) {. // if keys are defined, constructor with keys public Person( ...keys... ) {...} // getters and setters // equals/hashCode // toString } 



Since the generated class is a simple Java class, it can be used transparently in the rules, like any other fact.

Example 5.14. Using the declared types in rules rule "Using a declared Type" when $p : Person( name == "Bob" ) then // Insert Mark, who is Bob's mate. Person mark = new Person(); mark.setName("Mark"); insert( mark ); end

5.7.2. Declaring Metadata Metadata may be assigned to several different constructions in Drools: fact

types, fact attributes and rules. Drools uses the at sign ('@') to introduce metadata, and it always uses the form: @metadata_key( metadata_value )

The parenthesized metadata_value is optional. For instance, if you want to declare a metadata attribute like author, whose value is Bob, you could simply write:

Example 5.15. Declaring a metadata attribute @author( Bob )

Drools allows the declaration of any arbitrary metadata attribute, but some will have special meaning to the engine, while others are simply available for querying at runtime. Drools allows the declaration of metadata both for fact types and for fact attributes. Any metadata that is declared before the attributes of a fact type are assigned to the fact type, while metadata declared after an attribute are assigned to that particular attribute.

Example 5.16. Declaring metadata attributes for fact types and attributes import java.util.Date

declare Person @author( Bob ) @dateOfCreation( 01-Feb-2009 )

name : String @key @maxLength( 30 ) dateOfBirth : Date address : Address end

In the previous example, there are two metadata items declared for the fact

type (@author and @dateOfCreation) and two more defined for the name attribute (@key and @maxLength). Please note that the @key metadata has no required value, and so the parentheses and the value were omitted.: @position can be used to declare the position of a field, overriding the default declared order. This is used for positional constraints in patterns. declare Cheese name : String @position(1) shop : String @position(2) price : int @position(0) end

5.7.3. Declaring Metadata for Existing Types Drools allows the declaration of metadata attributes for existing types in the same way as when declaring metadata attributes for new fact types. The only difference is that there are no fields in that declaration. For instance, if there is a class org.drools.examples.Person, and one wants to declare metadata for it, it's possible to write the following code:

Example 5.17. Declaring metadata for an existing type import org.drools.examples.Person

declare Person @author( Bob ) @dateOfCreation( 01-Feb-2009 ) end

Instead of using the import, it is also possible to reference the class by its fully qualified name, but since the class will also be referenced in the rules, it is usually shorter to add the import and use the short class name everywhere.

Example 5.18. Declaring metadata using the fully qualified class name

declare org.drools.examples.Person @author( Bob ) @dateOfCreation( 01-Feb-2009 ) end

5.7.4. Parameterized constructors for declared types Generate constructors with parameters for declared types. Example: for a declared type like the following: declare Person firstName : String @key lastName : String @key age : int end

The compiler will implicitly generate 3 constructors: one without parameters, one with the @key fields, and one with all fields. Person() // parameterless constructor Person( String firstName, String lastName ) Person( String firstName, String lastName, int age )

5.7.5. Non Typesafe Classes @typesafe( ) has been added to type declarations. By default all type declarations are compiled with type safety enabled; @typesafe( false ) provides a means to override this behaviour by permitting a fall-back, to type unsafe evaluation where all constraints are generated as MVEL constraints and executed dynamically. This can be important when dealing with collections that do not have any generics or mixed type collections.

5.7.6. Accessing Declared Types from the Application Code Declared types are usually used inside rules files, while Java models are used

when sharing sometimes, the declared types, and providing management.

the model between rules and applications. Although, application may need to access and handle facts from the especially when the application is wrapping the rules engine higher level, domain specific interfaces for rules

In such cases, the generated classes can be handled as usual with the Java Reflection API, but, as we know, that usually requires a lot of work for small results. Therefore, Drools provides a simplified API for the most common fact handling the application may want to do. The first important thing to realize is that a declared fact will belong to the package where it was declared. So, for instance, in the example below, Person will belong to the org.drools.examples package, and so the fully qualified name of the generated class will be org.drools.examples.Person.

Example 5.19. Declaring a type in the org.drools.examples package package org.drools.examples

import java.util.Date

declare Person name : String dateOfBirth : Date address : Address end

Declared types, as discussed previously, are generated at knowledge base compilation time, i.e., the application will only have access to them at application run time. Therefore, these classes are not available for direct reference from the application. Drools then provides an interface through which s can handle declared types from the application code: org.drools.definition.type.FactType. Through this interface, the can instantiate, read and write fields in the declared fact types.

Example 5.20. Handling declared fact types through the API

// get a reference to a knowledge base with a declared type: KnowledgeBase kbase = ...

// get the declared FactType FactType personType = kbase.getFactType( "org.drools.examples", "Person" );

// handle the type as necessary: // create instances: Object bob = personType.newInstance();

// set attributes values personType.set( bob, "name", "Bob" ); personType.set( bob, "age", 42 );

// insert fact into a session StatefulKnowledgeSession ksession = ... ksession.insert( bob ); ksession.fireAllRules();

// read attributes String name = personType.get( bob, "name" ); int age = personType.get( bob, "age" );

The API also includes other helpful methods, like setting all the attributes at once, reading values from a Map, or reading all attributes at once, into a Map. Although the API is similar to Java reflection (yet much simpler to use), it does not use reflection underneath, relying on much more performant accessors implemented with generated bytecode.

5.7.7. Type Declaration 'extends'

Type declarations now 'extends' keyword for inheritance In order to extend a type declared in Java by a DRL declared subtype, repeat the supertype in a declare statement without any fields. import org.people.Person

declare Person end

declare Student extends Person school : String end

declare Longtudent extends Student years : int course : String end

5.8. Rule

Figure 5.10. rule

A rule specifies that when a particular set of conditions occur, specified in the Left Hand Side (LHS), then do what queryis specified as a list of actions in the Right Hand Side (RHS). A common question from s is "Why use when instead of if?" "When" was chosen over "if" because "if" is normally part of a procedural execution flow, where, at a specific point in time, a condition is to be checked. In contrast, "when" indicates that the condition evaluation is not tied to a specific evaluation sequence or point in time, but that it happens continually, at any time during the life time of the engine; whenever the condition is met, the actions are executed. A rule must have a name, unique within its rule package. If you define a rule twice in the same DRL it produces an error while loading. If you add a DRL that includes a rule name already in the package, it replaces the previous rule. If a rule name is to have spaces, then it will need to be enclosed in double quotes (it is best to always use double quotes). Attributes - described below - are optional. They are best written one per line. The LHS of the rule follows the when keyword (ideally on a new line), similarly the RHS follows the then keyword (again, ideally on a newline). The rule is terminated by the keyword end. Rules cannot be nested.

Example 5.21. Rule Syntax Overview rule " " * when * then * end

Example 5.22. A simple rule

rule "Approve if not rejected" salience -100 agenda-group "approval" when not Rejection() p : Policy(approved == false, policyState:status) exists Driver(age > 25) Process(status == policyState) then log("APPROVED: due to no objections."); p.setApproved(true); end

5.8.1. Rule Attributes Rule attributes provide a declarative way to influence the behavior of the rule. Some are quite simple, while others are part of complex subsystems such as ruleflow. To get the most from Drools you should make sure you have a proper understanding of each attribute.

Figure 5.11. rule attributes

no-loop

default value: false type: Boolean When a rule's consequence modifies a fact it may cause the rule to activate again, causing an infinite loop. Setting no-loop to true will skip the creation of another Activation for the rule with the current set of facts. ruleflow-group

default value: N/A type: String Ruleflow is a Drools feature that lets you exercise control over the firing of rules. Rules that are assembled by the same ruleflow-group identifier

fire only when their group is active. lock-on-active

default value: false type: Boolean Whenever a ruleflow-group becomes active or an agenda-group receives the focus, any rule within that group that has lock-on-active set to true will not be activated any more; irrespective of the origin of the update, the activation of a matching rule is discarded. This is a stronger version of no-loop, because the change could now be caused not only by the rule itself. It's ideal for calculation rules where you have a number of rules that modify a fact and you don't want any rule re-matching and firing again. Only when the ruleflow-group is no longer active or the agendagroup loses the focus those rules with lock-on-active set to true become eligible again for their activations to be placed onto the agenda. salience

default value: 0 type: integer Each rule has an integer salience attribute which defaults to zero and can be negative or positive. Salience is a form of priority where rules with higher salience values are given higher priority when ordered in the Activation queue. Drools also s dynamic salience where you can use an expression involving bound variables. Example 5.23. Dynamic Salience rule "Fire in rank order 1,2,.." salience( -$rank ) when Element( $rank : rank,... ) then ... end

agenda-group

default value: MAIN type: String Agenda groups allow the to partition the Agenda providing more execution control. Only rules in the agenda group that has acquired the focus are allowed to fire. auto-focus

default value: false type: Boolean When a rule is activated where the auto-focus value is true and the rule's agenda group does not have focus yet, then it is given focus, allowing the rule to potentially fire. activation-group

default value: N/A type: String Rules that belong to the same activation-group, identified by this attribute's string value, will only fire exclusively. In other words, the first rule in an activation-group to fire will cancel the other rules' activations, i.e., stop them from firing. Note: This used to be called Xor group, but technically it's not quite an Xor. You may still hear people mention Xor group; just swap that term in your mind with activation-group. dialect

default value: as specified by the package type: String possible values: "java" or "mvel" The dialect species the language to be used for any code expressions in the LHS or the RHS code block. Currently two dialects are available, Java and MVEL. While the dialect can be specified at the package level, this attribute allows the package definition to be overridden for a rule. date-effective

default value: N/A

type: String, containing a date and time definition A rule can only activate if the current date and time is after dateeffective attribute. date-expires

default value: N/A type: String, containing a date and time definition A rule cannot activate if the current date and time is after the dateexpires attribute. duration

default value: no default value type: long The duration dictates that the rule will fire after a specified duration, if it is still true.

Example 5.24. Some attribute examples rule "my rule" salience 42 agenda-group "number 1" when ...

5.8.2. Timers and Calendars Rules now both interval and cron based timers, which replace the now deprecated duration attribute.

Example 5.25. Sample timer attribute uses

timer ( int: ? ) timer ( int: 30s ) timer ( int: 30s 5m ) timer ( cron: ) timer ( cron:* 0/15 * * * ? )

Interval (indicated by "int:") timers follow the semantics of java.util.Timer objects, with an initial delay and an optional repeat interval. Cron (indicated by "cron:") timers follow standard Unix cron expressions:

Example 5.26. A Cron Example rule "Send SMS every 15 minutes" timer (cron:* 0/15 * * * ?) when $a : Alarm( on == true ) then channels[ "sms" ].insert( new Sms( $a.mobileNumber, "The alarm is end 



Calendars are used to control when rules can fire. The Calendar API is modelled on Quartz:

Example 5.27. Adapting a Quartz Calendar Calendar weekDayCal = QuartzHelper.quartzCalendarAdapter(org.quartz.Ca 



Calendars are ed with the StatefulKnowledgeSession:

Example 5.28. ing a Calendar ksession.getCalendars().set( "weekday", weekDayCal );

They can be used in conjunction with normal rules and rules including timers. The rule attribute "calendars" may contain one or more comma-separated calendar names written as string literals.

Example 5.29. Using Calendars and Timers together rule "weekdays are high priority" calendars "weekday" timer (int:0 1h) when Alarm() then send( "priority high - we have an alarm ); end rule "weekend are low priority" calendars "weekend" timer (int:0 4h) when Alarm() then send( "priority low - we have an alarm ); end

5.8.3. Left Hand Side (when) syntax

5.8.3.1. What is the Left Hand Side? The Left Hand Side (LHS) is a common name for the conditional part of the rule. It consists of zero or more Conditional Elements. If the LHS is empty, it will be considered as a condition element that is always true and it will be activated once, when a new WorkingMemory session is created.

Figure 5.12. Left Hand Side

Example 5.30. Rule without a Conditional Element rule "no CEs" when // empty then ... // actions (executed once) end

# The above rule is internally rewritten as:

rule "eval(true)" when eval( true ) then ... // actions (executed once) end

Conditional elements work on one or more patterns (which are described below). The most common conditional element is "and". Therefore it is implicit when you have multiple patterns in the LHS of a rule that are not connected in any way:

Example 5.31. Implicit and

rule "2 unconnected patterns" when Pattern1() Pattern2() then ... // actions end

# The above rule is internally rewritten as:

rule "2 and connected patterns" when Pattern1() and Pattern2() then ... // actions end

Note An "and" cannot have a leading declaration binding (unlike for example or). This is obvious, since a declaration can only reference a single fact at a time, and when the "and" is satisfied it matches both facts - so which fact would the declaration bind to? // Compile error $person : (Person( name == "Romeo" ) and Person( name == "Juliet")) 



5.8.3.2. Pattern (conditional element)

5.8.3.2.1. What is a pattern? A pattern element is the most important Conditional Element. It can

potentially match on each fact that is inserted in the working memory. A pattern contains of zero or more constraints and has an optional pattern binding. The railroad diagram below shows the syntax for this.

Figure 5.13. Pattern

In its simplest form, with no constraints, a pattern matches against a fact of the given type. In the following case the type is Cheese, which means that the pattern will match against all Person objects in the Working Memory: Person()

The type need not be the actual class of some fact object. Patterns may refer to superclasses or even interfaces, thereby potentially matching facts from many different classes. Object() // matches all objects in the working memory

Inside of the pattern parenthesis is where all the action happens: it defines the constraints for that pattern. For example, with a age related constraint: Person( age == 100 )

Note For backwards compatibility reasons it's allowed to suffix patterns with the ; character. But it is not recommended to do that.

5.8.3.2.2. Pattern binding For referring to the matched object, use a pattern binding variable such as $p.

Example 5.32. Pattern with a binding variable rule ... when $p : Person() then System.out.println( "Person " + $p ); end

The prefixed dollar symbol ($) is just a convention; it can be useful in complex rules where it helps to easily differentiate between variables and fields, but it is not mandatory.

5.8.3.3. Constraint (part of a pattern)

5.8.3.3.1. What is a constraint? A constraint is an expression that returns true or false. This example has a constraint that states 5 is smaller than 6: Person( 5 < 6 )

// just an example, as constraints like this would be u





In essence, it's a Java expression with some enhancements (such as property access) and a few differences (such as equals() semantics for ==). Let's take a deeper look.

5.8.3.3.2. Property access on Java Beans (POJO's) Any bean property can be used directly. A bean property is exposed using a standard Java bean getter: a method getMyProperty() (or isMyProperty() for a primitive boolean) which takes no arguments and return something. For example: the age property is written as age in DRL instead of the getter getAge():

Person( age == 50 )

// this is the same as: Person( getAge() == 50 )

Drools uses the standard JDK Introspector class to do this mapping, so it follows the standard Java bean specification.

Note We recommend using property access (age) over using getters explicitly (getAge()) because of performance enhancements through field indexing.

Warning Property accessors must not change the state of the object in a way that may effect the rules. that the rule engine effectively caches the results of its matching in between invocations to make it faster. public int getAge() { age++; // Do NOT do this return age; }

public int getAge() { Date now = DateUtil.now(); // Do NOT do this return DateUtil.differenceInYears(now, birthday); }

To solve this latter case, insert a fact that wraps the current date into working memory and update that fact between fireAllRules as needed.

Note The following fallback applies: if the getter of a property cannot

be found, the compiler will resort to using the property name as a method name and without arguments: Person( age == 50 )

// If Person.getAge() does not exists, this falls back to: Person( age() == 50 )

Nested property access is also ed: Person( address.houseNumber == 50 )

// this is the same as: Person( getAddress().getHouseNumber() == 50 )

Nested properties are also indexed.

Warning In a stateful session, care should be taken when using nested accessors as the Working Memory is not aware of any of the nested values, and does not know when they change. Either consider them immutable while any of their parent references are inserted into the Working Memory. Or, instead, if you wish to modify a nested value you should mark all of the outer facts as updated. In the above example, when the houseNumber changes, any Person with that Address must be marked as updated.

5.8.3.3.3. Java expression You can use any Java expression that returns a boolean as a constraint inside the parentheses of a pattern. Java expressions can be mixed with other expression enhancements, such as property access: Person( age == 50 )

It is possible to change the evaluation priority by using parentheses, as in any logic or mathematical expression: Person( age > 100 && ( age % 10 == 0 ) )

It is possible to reuse Java methods: Person( Math.round( weight / ( height * height ) ) < 25.0 )

Warning As for property accessors, methods must not change the state of the object in a way that may affect the rules. Any method executed on a fact in the LHS should be a read only method. Person( incrementAndGetAge() == 10 ) // Do NOT do this

Warning The state of a fact should not change between rule invocations (unless those facts are marked as updated to the working memory on every change): Person( System.currentTimeMillis() % 1000 == 0 ) // Do NOT do this 



Normal Java operator precedence applies, see the operator precedence list below.

Important All operators have normal Java semantics except for == and !=. The == operator has null-safe equals() semantics:

// Similar to: java.util.Objects.equals(person.getFirstName(), "John // so (because "John" is not null) similar to: // "John".equals(person.getFirstName()) Person( firstName == "John" ) 



The != operator has null-safe !equals() semantics: // Similar to: !java.util.Objects.equals(person.getFirstName(), "Joh Person( firstName != "John" ) 



Type coercion is always attempted if the field and the value are of different types; exceptions will be thrown if a bad coercion is attempted. For instance, if "ten" is provided as a string in a numeric evaluator, an exception is thrown, whereas "10" would coerce to a numeric 10. Coercion is always in favor of the field type and not the value type: Person( age == "10" ) // "10" is coerced to 10

5.8.3.3.4. Comma separated AND The comma character (',') is used to separate constraint groups. It has implicit AND connective semantics. // Person is at least 50 and weighs at least 80 kg Person( age > 50, weight > 80 )

// Person is at least 50, weighs at least 80 kg and is taller than 2 met Person( age > 50, weight > 80, height > 2 ) 



Note Although the && and , operators have the same semantics, they are resolved with different priorities: The && operator precedes the || operator. Both the && and || operator precede the , operator. See the operator precedence list below. The comma operator should be preferred at the top level

constraint, as it makes constraints easier to read and the engine will often be able to optimize them better.

The comma (,) operator cannot be embedded in a composite constraint expression, such as parentheses: Person( ( age > 50, weight > 80 ) || height > 2 ) // Do NOT do this: com

// Use this instead Person( ( age > 50 && weight > 80 ) || height > 2 ) 



5.8.3.3.5. Binding variables A property can be bound to a variable: // 2 persons of the same age Person( $firstAge : age ) // binding Person( age == $firstAge ) // constraint expression

The prefixed dollar symbol ($) is just a convention; it can be useful in complex rules where it helps to easily differentiate between variables and fields.

Note For backwards compatibility reasons, It's allowed (but not recommended) to mix a constraint binding and constraint expressions as such: // Not recommended Person( $age : age * 2 < 100 )

// Recommended (seperates bindings and constraint expressions) Person( age * 2 < 100, $age : age )

Bound variable restrictions using the operator == provide for very fast execution as it use hash indexing to improve performance.

5.8.3.3.6. Unification Drools does not allow bindings to the same declaration. However this is an important aspect to derivation query unification. While positional arguments are always processed with unification a special unification symbol, ':=', was introduced for named arguments named arguments. The following "unifies" the age argument across two people. Person( $age := age ) Person( $age := age)

In essence unification will declare a binding for the first occurance, and constrain to the same value of the bound field for sequence occurances.

5.8.3.3.7. Special literal Besides normal Java literals (including Java 5 enums), this literal is also ed:

5.8.3.3.7.1. Date literal The date format dd-mmm-yyyy is ed by default. You can customize this by providing an alternative date format mask as the System property named drools.dateformat. If more control is required, use a restriction.

Example 5.33. Date Literal Restriction Cheese( bestBefore < "27-Oct-2009" )

5.8.3.3.8. List and Map access It's possible to directly access a List value by index:

// Same as childList(0).getAge() == 18 Person( childList[0].age == 18 )

It's also possible to directly access a Map value by key: // Same as credentialMap.get("jsmith").isValid() Person( credentialMap["jsmith"].valid )

5.8.3.3.9. Abbreviated combined relation condition This allows you to place more than one restriction on a field using the restriction connectives && or ||. Grouping via parentheses is permitted, resulting in a recursive syntax pattern.

Figure 5.14. Abbreviated combined relation condition

Figure 5.15. parentheses

Abbreviated

combined

relation

condition

with

// Simple abbreviated combined relation condition using a single && Person( age > 30 && < 40 )

// Complex abbreviated combined relation using groupings Person( age ( (> 30 && < 40) || (> 20 && < 25) ) )

// Mixing abbreviated combined relation with constraint connectives Person( age > 30 && < 40 || location == "london" )

5.8.3.3.10. Special DRL operators

Figure 5.16. Operators

Coercion to the correct value for the evaluator and the field will be attempted.

5.8.3.3.10.1. The operators < <= > >=

These operators can be used on properties with natural ordering. For example, for Date fields, < means before, for String fields, it means alphabetically lower. Person( firstName < $otherFirstName )

Person( birthDate < $otherBirthDate )

Only applies on Comperable properties.

5.8.3.3.10.2. The operator matches

Matches a field against any valid Java Regular Expression. Typically that regexp is a string literal, but variables that resolve to a valid regexp are also allowed.

Example 5.34. Regular Expression Constraint Cheese( type matches "(Buffalo)?\\S*Mozarella" )

Note Like in Java, regular expressions written as string literals need to escape '\'. Up to Drools 5.1 there was a configuration to nonescaped regexps from Drools 4.0 for backwards compatilibity. From Drools 5.2 this is no longer ed.

Only applies on String properties.

5.8.3.3.10.3. The operator not matches

The operator returns true if the String does not match the regular expression. The same rules apply as for the matches operator. Example:

Example 5.35. Regular Expression Constraint Cheese( type not matches "(Buffulo)?\\S*Mozarella" )

Only applies on String properties.

5.8.3.3.10.4. The operator contains

The operator contains is used to check whether a field that is a Collection or array contains the specified value.

Example 5.36. Contains with Collections CheeseCounter( cheeses contains "stilton" ) // contains with a String CheeseCounter( cheeses contains $var ) // contains with a variable 



Only applies on Collection properties.

5.8.3.3.10.5. The operator not contains

The operator not contains is used to check whether a field that is a Collection or array does not contain the specified value.

Example 5.37. Literal Constraint with Collections CheeseCounter( cheeses not contains "cheddar" ) // not contains with a CheeseCounter( cheeses not contains $var ) // not contains with a vari 



Only applies on Collection properties.

Note For backward compatibility, the excludes operator is ed as a synonym for not contains.

5.8.3.3.10.6. The operator memberOf

The operator memberOf is used to check whether a field is a member of a collection or array.

Example 5.38. Literal Constraint with Collections CheeseCounter( cheese memberOf $matureCheeses )

Person( father memberOf parents )

5.8.3.3.10.7. The operator not memberOf

The operator not memberOf is used to check whether a field is not a member of a collection or array.

Example 5.39. Literal Constraint with Collections CheeseCounter( cheese not memberOf $matureCheeses )

Person( father not memberOf childern )

5.8.3.3.10.8. The operator soundslike

This operator is similar to matches, but it checks whether a word has almost the same sound (using English pronunciation) as the given value. This is based on the Soundex algorithm (see http://en.wikipedia.org/wiki/Soundex).

Example 5.40. Test with soundslike // match cheese "fubar" or "foobar" Cheese( name soundslike 'foobar' )

5.8.3.3.10.9. The operator str

This operator str is used to check whether a field that is a String starts with or ends with a certain value. It can also be used to check the length of the String.

Message( routingValue str[startsWith] "R1" )

Message( routingValue str[endsWith] "R2" )

Message( routingValue str[length] 17 )

5.8.3.3.10.10. The operators in and not in (compound value restriction) The compound value restriction is used where there is more than one possible value to match. Currently only the in and not in evaluators this. The second operand of this operator must be a comma-separated list of values, enclosed in parentheses. Values may be given as variables, literals, return values or qualified identifiers. Both evaluators are actually syntactic sugar, internally rewritten as a list of multiple restrictions using the operators != and ==.

Figure 5.17. compoundValueRestriction

Example 5.41. Compound Restriction using "in" Person( $cheese : favouriteCheese ) Cheese( type in ( "stilton", "cheddar", $cheese ) )

5.8.3.3.11. Inline eval operator (deprecated)

Figure 5.18. Inline Eval Expression

An inline eval constraint can use any valid dialect expression as long as it results to a primitive boolean. The expression must be constant over time. Any previously bound variable, from the current or previous pattern, can be used. This example will find all male-female pairs where the male is 2 years older than the female; the variable age is auto-created in the second pattern by the autovivification process.

Example 5.42. Return Value operator Person( girlAge : age, sex = "F" ) Person( eval( age == girlAge + 2 ), sex = 'M' ) // eval() is actually 



Note Inline eval's are effectively obsolete as their inner syntax is now directly ed. It's recommended not to use them. Simply write the expression without wrapping eval() around it.

5.8.3.3.12. Operator precedence The operators are evaluated in this precedence: Table 5.1. Operator precedence

Operator type

Operators Notes

(nested) property access

.

Not normal Java semantics

List/Map access

[ ]


constraint binding

:


multiplicative

*/ %

additive

+-

shift

<< >> >>>

relational

< > <= >= instanceof

equality

== !=

non-short circuiting AND

&

non-short circuiting exclusive OR

^

non-short circuiting inclusive OR

|

logical AND

&&

logical OR

||

ternary

? :

Comma separated AND

,

Does not use normal Java (not) same semantics: uses (not) equals semantics instead.


5.8.3.4. Positional Arguments Patterns now positional arguments on type declarations. Positional arguments are ones where you don't need to specify the field name, as the position maps to a known named field. i.e. Person( name == "mark" ) can be rewritten as Person( "mark"; ). The semicolon ';' is important so that the engine knows that everything before it is a positional argument. Otherwise we might assume it was a boolean expression, which is

how it could be interpretted after the semicolon. You can mix positional and named arguments on a pattern by using the semicolon ';' to separate them. Any variables used in a positional that have not yet been bound will be bound to the field that maps to that position. declare Cheese name : String shop : String price : int end

Example patterns, with two constraints and a binding. semicolon ';' is used to differentiate the positional section from the named argument section. Variables and literals and expressions using just literals are ed in posional arguments, but not variables. Positional arguments are always resolved using unification. Cheese( "stilton", "Cheese Shop", p; ) Cheese( "stilton", "Cheese Shop"; p : price ) Cheese( "stilton"; shop == "Cheese Shop", p : price ) Cheese( name == "stilton"; shop == "Cheese Shop", p : price )

Positional arguments that are given a previously consrain against that using unification; these are arguments. If the binding does not yet exist, it will binding it to the field represented by the position referred to as output arguments.

declared binding will referred to as input create the declaration argument; these are

5.8.3.5. Basic conditional elements

5.8.3.5.1. Conditional Element and The Conditional Element "and" is used to group other Conditional Elements into a logical conjunction. Drools s both prefix and and infix and.

Figure 5.19. infixAnd

Traditional infix and is ed: //infixAnd Cheese( cheeseType : type ) and Person( favouriteCheese == cheeseType ) 



Explicit grouping with parentheses is also ed: //infixAnd with grouping ( Cheese( cheeseType : type ) and ( Person( favouriteCheese == cheeseType ) or Person( favouriteCheese == cheeseType ) )

Note The symbol && (as an alternative to and) is deprecated. But it is still ed in the syntax for backwards compatibility.

Figure 5.20. prefixAnd

Prefix and is also ed: (and Cheese( cheeseType : type ) Person( favouriteCheese == cheeseType ) )

The root element of the LHS is an implicit prefix and and doesn't need to be specified:

Example 5.43. implicit root prefixAnd

when Cheese( cheeseType : type ) Person( favouriteCheese == cheeseType ) then ...

5.8.3.5.2. Conditional Element or The Conditional Element or is used to group other Conditional Elements into a logical disjunction. Drools s both prefix or and infix or.

Figure 5.21. infixOr

Traditional infix or is ed: //infixOr Cheese( cheeseType : type ) or Person( favouriteCheese == cheeseType ) 



Explicit grouping with parentheses is also ed: //infixOr with grouping ( Cheese( cheeseType : type ) or ( Person( favouriteCheese == cheeseType ) and Person( favouriteCheese == cheeseType ) )

Note The symbol || (as an alternative to or) is deprecated. But it is still ed in the syntax for backwards compatibility.

Figure 5.22. prefixOr

Prefix or is also ed: (or Person( sex == "f", age > 60 ) Person( sex == "m", age > 65 )

Note The behavior of the Conditional Element or is different from the connective || for constraints and restrictions in field constraints. The engine actually has no understanding of the Conditional Element or. Instead, via a number of different logic transformations, a rule with or is rewritten as a number of subrules. This process ultimately results in a rule that has a single or as the root node and one subrule for each of its CEs. Each subrule can activate and fire like any normal rule; there is no special behavior or interaction between these subrules. This can be most confusing to new rule authors.

The Conditional Element or also allows for optional pattern binding. This means that each resulting subrule will bind its pattern to the pattern binding. Each pattern must be bound separately, using eponymous variables: pensioner : ( Person( sex == "f", age > 60 ) or Person( sex == "m", age 



(or pensioner : Person( sex == "f", age > 60 ) pensioner : Person( sex == "m", age > 65 ) )

Since the conditional element or results in multiple subrule generation, one for each possible logically outcome, the example above would result in the internal generation of two rules. These two rules work independently within the Working Memory, which means both can match, activate and fire - there is no shortcutting.

The best way to think of the conditional element or is as a shortcut for generating two or more similar rules. When you think of it that way, it's clear that for a single rule there could be multiple activations if two or more of the disjunction are true.

5.8.3.5.3. Conditional Element not

Figure 5.23. not

The CE not is first order logic's non-existential quantifier and checks for the non-existence of something in the Working Memory. Think of "not" as meaning "there must be none of...". The keyword not may be followed by parentheses around the CEs that it applies to. In the simplest case of a single pattern (like below) you may optionally omit the parentheses.

Example 5.44. No Busses not Bus()

Example 5.45. No red Busses // Brackets are optional: not Bus(color == "red") // Brackets are optional: not ( Bus(color == "red", number == 42) ) // "not" with nested infix and - two patterns, // brackets are requires: not ( Bus(color == "red") and Bus(color == "blue") )

5.8.3.5.4. Conditional Element exists

Figure 5.24. exists

The CE exists is first order logic's existential quantifier and checks for the existence of something in the Working Memory. Think of "exists" as meaning "there is at least one..". It is different from just having the pattern on its own, which is more like saying "for each one of...". If you use exists with a pattern, the rule will only activate at most once, regardless of how much data there is in working memory that matches the condition inside of the exists pattern. Since only the existence matters, no bindings will be established. The keyword exists must be followed by parentheses around the CEs that it applies to. In the simplest case of a single pattern (like below) you may omit the parentheses.

Example 5.46. At least one Bus exists Bus()

Example 5.47. At least one red Bus exists Bus(color == "red") // brackets are optional: exists ( Bus(color == "red", number == 42) ) // "exists" with nested infix and, // brackets are required: exists ( Bus(color == "red") and Bus(color == "blue") )

5.8.3.6. Advanced conditional elements

5.8.3.6.1. Conditional Element forall

Figure 5.25. forall

The Conditional Element forall completes the First Order Logic in Drools. The Conditional Element forall evaluates to true when all facts that match the first pattern match all the remaining patterns. Example: rule "All English buses are red" when forall( $bus : Bus( type == 'english') Bus( this == $bus, color = 'red' ) ) then # all english buses are red end

In the above rule, we "select" all Bus objects whose type is "english". Then, for each fact that matches this pattern we evaluate the following patterns and if they match, the forall CE will evaluate to true. To state that all facts of a given type in the working memory must match a set of constraints, forall can be written with a single pattern for simplicity. Example:

Example 5.48. Single Pattern Forall

rule "All Buses are Red" when forall( Bus( color == 'red' ) ) then # all asserted Bus facts are red end

Another example shows multiple patterns inside the forall:

Example 5.49. Multi-Pattern Forall rule "all employees have health and dental care programs" when forall( $emp : Employee() HealthCare( employee == $emp ) DentalCare( employee == $emp ) ) then # all employees have health and dental care end

Forall can be nested inside other CEs. For instance, forall can be used inside a not CE. Note that only single patterns have optional parentheses, so that with a nested forall parentheses must be used:

Example 5.50. Combining Forall with Not CE

rule "not all employees have health and dental care" when not ( forall( $emp : Employee() HealthCare( employee == $emp ) DentalCare( employee == $emp ) ) ) then # not all employees have health and dental care end

As a side note, forall( p1 p2 p3...) is equivalent to writing: not(p1 and not(and p2 p3...))

Also, it is important to note that forall is a scope delimiter. Therefore, it can use any previously bound variable, but no variable bound inside it will be available for use outside of it.

5.8.3.6.2. Conditional Element from

Figure 5.26. from

The Conditional Element from enables s to specify an arbitrary source for data to be matched by LHS patterns. This allows the engine to reason over data not in the Working Memory. The data source could be a sub-field on a bound variable or the results of a method call. It is a powerful construction that allows out of the box integration with other application components and frameworks. One common example is the integration with data retrieved ondemand from databases using hibernate named queries. The expression used to define the object source is any expression that follows regular MVEL syntax. Therefore, it allows you to easily use object property navigation, execute method calls and access maps and collections elements.

Here is a simple example of reasoning and binding on another pattern subfield: rule "validate zipcode" when Person( $personAddress : address ) Address( zipcode == "23920W") from $personAddress then # zip code is ok end

With all the flexibility from the new expressiveness in the Drools engine you can slice and dice this problem many ways. This is the same but shows how you can use a graph notation with the 'from': rule "validate zipcode" when $p : Person( ) $a : Address( zipcode == "23920W") from $p.address then # zip code is ok end

Previous examples were evaluations using a single pattern. The CE from also object sources that return a collection of objects. In that case, from will iterate over all objects in the collection and try to match each of them individually. For instance, if we want a rule that applies 10% discount to each item in an order, we could do: rule "apply 10% discount to all items over US$ 100,00 in an order" when $order : Order() $item

: OrderItem( value > 100 ) from $order.items

then # apply discount to $item end

The above example will cause the rule to fire once for each item whose value is greater than 100 for each given order. You must take caution, however, when using from, especially in conjunction with the lock-on-active rule attribute as it may produce unexpected results.

Consider the example provided earlier, but now slightly modified as follows: rule "Assign people in North Carolina (NC) to sales region 1" ruleflow-group "test" lock-on-active true when $p : Person( ) $a : Address( state == "NC") from $p.address then modify ($p) {} #Assign person to sales region 1 in a modify block end

rule "Apply a discount to people in the city of Raleigh" ruleflow-group "test" lock-on-active true when $p : Person( ) $a : Address( city == "Raleigh") from $p.address then modify ($p) {} #Apply discount to person in a modify block end 



In the above example, persons in Raleigh, NC should be assigned to sales region 1 and receive a discount; i.e., you would expect both rules to activate and fire. Instead you will find that only the second rule fires. If you were to turn on the audit log, you would also see that when the second rule fires, it deactivates the first rule. Since the rule attribute lock-on-active prevents a rule from creating new activations when a set of facts change, the first rule fails to reactivate. Though the set of facts have not changed, the use of from returns a new fact for all intents and purposes each time it is evaluated. First, it's important to review why you would use the above pattern. You may have many rules across different rule-flow groups. When rules modify working memory and other rules downstream of your RuleFlow (in different rule-flow groups) need to be reevaluated, the use of modify is critical. You don't, however, want other rules in the same rule-flow group to place activations on one another recursively. In this case, the no-loop attribute is ineffective, as it would only prevent a rule from activating itself recursively. Hence, you resort to lock-on-active.

There are several ways to address this issue: Avoid the use of from when you can assert all facts into working memory or use nested object references in your constraint expressions (shown below). Place the variable assigned used in the modify block as the last sentence in your condition (LHS). Avoid the use of lock-on-active when you can explicitly manage how rules within the same rule-flow group place activations on one another (explained below). The preferred solution is to minimize use of from when you can assert all your facts into working memory directly. In the example above, both the Person and Address instance can be asserted into working memory. In this case, because the graph is fairly simple, an even easier solution is to modify your rules as follows: rule "Assign people in North Carolina (NC) to sales region 1" ruleflow-group "test" lock-on-active true when $p : Person(address.state == "NC" ) then modify ($p) {} #Assign person to sales region 1 in a modify block end

rule "Apply a discount to people in the city of Raleigh" ruleflow-group "test" lock-on-active true when $p : Person(address.city == "Raleigh" ) then modify ($p) {} #Apply discount to person in a modify block end 



Now, you will find that both rules fire as expected. However, it is not always possible to access nested facts as above. Consider an example where a Person holds one or more Addresses and you wish to use an existential quantifier to match people with at least one address that meets certain conditions. In this case, you would have to resort to the use of from to reason over the collection.

There are several ways to use from to achieve this and not all of them exhibit an issue with the use of lock-on-active. For example, the following use of from causes both rules to fire as expected: rule "Assign people in North Carolina (NC) to sales region 1" ruleflow-group "test" lock-on-active true when $p : Person($addresses : addresses) exists (Address(state == "NC") from $addresses) then modify ($p) {} #Assign person to sales region 1 in a modify block end

rule "Apply a discount to people in the city of Raleigh" ruleflow-group "test" lock-on-active true when $p : Person($addresses : addresses) exists (Address(city == "Raleigh") from $addresses) then modify ($p) {} #Apply discount to person in a modify block end 

However, the following slightly different approach does exhibit the problem:



rule "Assign people in North Carolina (NC) to sales region 1" ruleflow-group "test" lock-on-active true when $assessment : Assessment() $p : Person() $addresses : List() from $p.addresses exists (Address( state == "NC") from $addresses) then modify ($assessment) {} #Modify assessment in a modify block end

rule "Apply a discount to people in the city of Raleigh" ruleflow-group "test" lock-on-active true when $assessment : Assessment() $p : Person() $addresses : List() from $p.addresses exists (Address( city == "Raleigh") from $addresses) then modify ($assessment) {} #Modify assessment in a modify block end

In the above example, the $addresses variable is returned from the use of from. The example also introduces a new object, assessment, to highlight one possible solution in this case. If the $assessment variable assigned in the condition (LHS) is moved to the last condition in each rule, both rules fire as expected. Though the above examples demonstrate how to combine the use of from with lock-on-active where no loss of rule activations occurs, they carry the drawback of placing a dependency on the order of conditions on the LHS. In addition, the solutions present greater complexity for the rule author in of keeping track of which conditions may create issues. A better alternative is to assert more facts into working memory. In this case, a person's addresses may be asserted into working memory and the use of from would not be necessary. There are cases, however, where asserting all data into working memory is not practical and we need to find other solutions. Another option is to

reevaluate the need for lock-on-active. An alternative to lock-on-active is to directly manage how rules within the same rule-flow group activate one another by including conditions in each rule that prevent rules from activating each other recursively when working memory is modified. For example, in the case above where a discount is applied to citizens of Raleigh, a condition may be added to the rule that checks whether the discount has already been applied. If so, the rule does not activate.

5.8.3.6.3. Conditional Element collect

Figure 5.27. collect

The Conditional Element collect allows rules to reason over a collection of objects obtained from the given source or from the working memory. In First Oder Logic this is the cardinality quantifier. A simple example: import java.util.ArrayList

rule "Raise priority if system has more than 3 pending alarms" when $system : System() $alarms : ArrayList( size >= 3 ) from collect( Alarm( system == $system, status == 'pending then # Raise priority, because system $system has # 3 or more alarms pending. The pending alarms # are $alarms. end 



In the above example, the rule will look for all pending alarms in the working memory for each given system and group them in ArrayLists. If 3 or more

alarms are found for a given system, the rule will fire. The result pattern of collect can be any concrete class that implements the java.util.Collection

interface

and

provides

a

default

no-arg

public

constructor. This means that you can use Java collections like ArrayList, LinkedList, HashSet, etc., or your own class, as long as it implements the java.util.Collection interface and provide a default no-arg public constructor. Both source and result patterns can be constrained as any other pattern. Variables bound before the collect CE are in the scope of both source and result patterns and therefore you can use them to constrain both your source and result patterns. But note that collect is a scope delimiter for bindings, so that any binding made inside of it is not available for use outside of it. Collect accepts nested from CEs. The following example is a valid use of "collect": import java.util.LinkedList;

rule "Send a message to all mothers" when $town : Town( name == 'Paris' ) $mothers : LinkedList() from collect( Person( gender == 'F', children > 0 ) from $town.getPeople() ) then # send a message to all mothers end

5.8.3.6.4. Conditional Element accumulate

Figure 5.28. accumulate

The Conditional Element accumulate is a more flexible and powerful form of collect, in the sense that it can be used to do what collect does and also

achieve results that the CE collect is not capable of doing. Basically, what it does is that it allows a rule to iterate over a collection of objects, executing custom actions for each of the elements, and at the end it returns a result object. Accumulate s both the use of pre-defined accumulate functions, or the use of inline custom code. Inline custom code should be avoided though, as it is extremely hard to maintain, and frequently leads to code duplication. Accumulate functions are easier to test and reuse.

5.8.3.6.4.1. Accumulate Functions The accumulate CE is a very powerful CE, but it gets real declarative and easy to use when using predefined functions that are known as Accumulate Functions. They work exactly like accumulate, but instead of explicitly writing custom code in every accumulate CE, the can use predefined code for common operations. For instance, a rule to apply a 10% discount on orders over $100 could be

written in the following way, using Accumulate Functions: rule "Apply 10% discount to orders over US$ 100,00" when $order : Order() $total : Number( doubleValue > 100 ) from accumulate( OrderItem( order == $order, $value : value sum( $value ) ) then # apply discount to $order end 



In the above example, sum is an Accumulate Function and will sum the $value of all OrderItems and return the result. Drools ships with the following built-in accumulate functions: average min max count sum collectList collectSet These common functions accept any expression as input. For instance, if someone wants to calculate the average profit on all items of an order, a rule could be written using the average function: rule "Average profit" when $order : Order() $profit : Number() from accumulate( OrderItem( order == $order, $cost : cost, average( 1 - $cost / $price ) ) then # average profit for $order is $profit end 



Accumulate Functions are all pluggable. That means that if needed, custom,

domain specific functions can easily be added to the engine and rules can start to use them without any restrictions. To implement a new Accumulate Functions all one needs to do is to create a Java class that implements the org.drools.runtime.rule.TypedAccumulateFunction interface and add a line to the configuration file or set a system property to let the engine know about the new function. As an example of an Accumulate Function implementation, the following is the implementation of the average function: /** * An implementation of an accumulator capable of calculating average va */ public class AverageAccumulateFunction implements AccumulateFunction { public void readExternal(ObjectInput in) throws IOException, ClassNo } public void writeExternal(ObjectOutput out) throws IOException { } public static class AverageData implements Externalizable { public int

count = 0;

public double total = 0;

public AverageData() {} public void readExternal(ObjectInput in) throws IOException, Cla count

= in.readInt();

total

= in.readDouble();

} public void writeExternal(ObjectOutput out) throws IOException { out.writeInt(count); out.writeDouble(total); } } /* (non-Javadoc) * @see org.drools.base.accumulators.AccumulateFunction#createContex */ public Serializable createContext() { return new AverageData(); }

} /* (non-Javadoc) * @see org.drools.base.accumulators.AccumulateFunction#init(java.la */ public void init(Serializable context) throws Exception { AverageData data = (AverageData) context; data.count = 0; data.total = 0; } /* (non-Javadoc) * @see org.drools.base.accumulators.AccumulateFunction#accumulate(j */ public void accumulate(Serializable context, Object value) { AverageData data = (AverageData) context; data.count++; data.total += ((Number) value).doubleValue(); } /* (non-Javadoc) * @see org.drools.base.accumulators.AccumulateFunction#reverse(java */ public void reverse(Serializable context, Object value) throws Exception { AverageData data = (AverageData) context; data.count--; data.total -= ((Number) value).doubleValue(); } /* (non-Javadoc) * @see org.drools.base.accumulators.AccumulateFunction#getResult(ja */ public Object getResult(Serializable context) throws Exception { AverageData data = (AverageData) context; return new Double( data.count == 0 ? 0 : data.total / data.count } /* (non-Javadoc) * @see org.drools.base.accumulators.AccumulateFunction#sReve */

public boolean sReverse() { return true; } /** * {@inheritDoc} */ public Class< ? > getResultType() { return Number.class; } } 



The code for the function is very simple, as we could expect, as all the "dirty" integration work is done by the engine. Finally, to plug the function into the engine, we added it to the configuration file: drools.accumulate.function.average = org.drools.base.accumulators.AverageAccumulateFunction

Here, "drools.accumulate.function." is a prefix that must always be used, "average" is how the function will be used in the rule file, and "org.drools.base.accumulators.AverageAccumulateFunction" is the fully qualified name of the class that implements the function behavior.

5.8.3.6.4.2. Accumulate with inline custom code

Warning The use of accumulate with inline custom code is not a good practice for several reasons, including dificulties on maintaining and testing rules that use them, as well as the inability of reusing that code. Implementing your own accumulate functions is very simple and straightforward, they are easy to unit test and to use. This form of accumulate is ed for backward compatibility only.

The general syntax of the accumulate CE with inline custom code is:

from accumulate( <source pattern>, init( ), action( ), reverse( ), result( ) ) 



The meaning of each of the elements is the following: <source pattern>: the source pattern is a regular pattern that the engine will try to match against each of the source objects. : this is a semantic block of code in the selected dialect that will be executed once for each tuple, before iterating over the source objects. : this is a semantic block of code in the selected dialect that will be executed for each of the source objects. : this is an optional semantic block of code in the selected dialect that if present will be executed for each source object that no longer matches the source pattern. The objective of this code block is to undo any calculation done in the block, so that the engine can do decremental calculation when a source object is modified or retracted, hugely improving performance of these operations. : this is a semantic expression in the selected dialect that is executed after all source objects are iterated. : this is a regular pattern that the engine tries to match against the object returned from the . If it matches, the accumulate conditional element evaluates to true and the engine proceeds with the evaluation of the next CE in the rule. If it does not matches, the accumulate CE evaluates to false and the engine stops evaluating CEs for that rule. It is easier to understand if we look at an example:

rule "Apply 10% discount to orders over US$ 100,00" when $order : Order() $total : Number( doubleValue > 100 ) from accumulate( OrderItem( order == $order, $value : value init( double total = 0; ), action( total += $value; ), reverse( total -= $value; ), result( total ) ) then # apply discount to $order end 



In the above example, for each Order in the Working Memory, the engine will execute the init code initializing the total variable to zero. Then it will iterate over all OrderItem objects for that order, executing the action for each one (in the example, it will sum the value of all items into the total variable). After iterating over all OrderItem objects, it will return the value corresponding to the result expression (in the above example, the value of variable total). Finally, the engine will try to match the result with the Number pattern, and if the double value is greater than 100, the rule will fire. The example used Java as the semantic dialect, and as such, note that the usage of the semicolon as statement delimiter is mandatory in the init, action and reverse code blocks. The result is an expression and, as such, it does not it ';'. If the uses any other dialect, he must comply to that dialect's specific syntax. As mentioned before, the reverse code is optional, but it is strongly recommended that the writes it in order to benefit from the improved performance on update and retract. The accumulate CE can be used to execute any action on source objects. The following example instantiates and populates a custom object:

rule "Accumulate using custom objects" when $person

: Person( $likes : likes )

$cheesery : Cheesery( totalAmount > 100 ) from accumulate( $cheese : Cheese( type == $likes ), init( Cheesery cheesery = new Cheesery( action( cheesery.addCheese( $cheese ); reverse( cheesery.removeCheese( $cheese result( cheesery ) ); then // do something end 



5.8.3.6.4.3. Multi-function Accumulates The accumulate CE now s multiple functions. For instance, if one needs to find the minimum, maximum and average value for the same set of data, instead of having to repeat the accumulate statement 3 times, a single accumulate can be used. rule "Max, min and average" when accumulate( Cheese( $price : price ), $max : max( $price ), $min : min( $price ), $avg : average( $price ) ) then // do something end

5.8.3.7. Conditional Element eval

Figure 5.29. eval

The conditional element eval is essentially a catch-all which allows any semantic code (that returns a primitive boolean) to be executed. This code can refer to variables that were bound in the LHS of the rule, and functions in the rule package. Overuse of eval reduces the declarativeness of your rules and can result in a poorly performing engine. While eval can be used anywhere in the patterns, the best practice is to add it as the last conditional element in the LHS of a rule. Evals cannot be indexed and thus are not as efficient as Field Constraints. However this makes them ideal for being used when functions return values that change over time, which is not allowed within Field Constraints. For folks who are familiar with Drools 2.x lineage, the old Drools parameter and condition tags are equivalent to binding a variable to an appropriate type, and then using it in an eval node. p1 : Parameter() p2 : Parameter() eval( p1.getList().containsKey( p2.getItem() ) )

p1 : Parameter() p2 : Parameter() // call function isValid in the LHS eval( isValid( p1, p2 ) )

5.8.3.8. Railroad diagrams AccumulateAction Statement action

(

, )

Drools Expert Guide 6m3132

Overview 1s532p

More details 6h715l

Related Documents 2w1qw

Drools Expert Guide 6m3132

Jess, Drools 1c84l

Drools Documentation 661u1b

Expert 24 Manual n6g2v

Pdf Expert Guide 4m2z37

Expert Fat Loss Guide 4f2u22
