S.E. Sem. III [CMPN]
Digital Logic Design and Applications May '09 : Mumbai University − Examination Paper Solution Time : 3hrs] N.B. :
[Marks : 100
(1) Question No. 1 is compulsory. (2) Attempt any four questions out of remaining six questions.
1. (a) Converter (670.17)8 into decimal, binary and hex.
[6]
Soln.: (670.17)8 Octal to Decimal : Step 1 : Get the octal no. Step 2 : Write corresponding weights Step 3 : Multiple columnwise
6 7 1 . 1 7 82 81 80 . 8−1 8−2 384 56 0 . 1/8 7/56 1 7 Step 4 : Add the contents of row 3 = 384 + 56 + 0 + + 8 64 = (440.23)10 Octal to Binary : Step 1 : Get the octal no. 6 7 1 . 1 7 Step 2 : Convert each digits into binary 110 111 000 . 001 111 ∴ (670.17)8 = (110 111 000 . 001 111)2
Octal to Hexadecimal : Step 1 : Convert into binary (110 111 000 . 001 111) Step 2 : Convert binary to hexadecimal (1 1011 1000 . 0011 11)2 Add three zeros on extreme left corner and Add 2 zero on extreme right side. Binary (0001 1011 1000 . 0011 1100) group of 4 bit, Hexa number 1 B 8 . 3 C (670.17)8 = (1B8.3C)16
1. (b) Design 16 : 1 MUX using 4 : 1 MUX.
[6]
Soln.: Refer figure for implementation.
Description : • The select inputs S1 and S0 of the multiplexers 1, 2, 3 and 4 are connected together. • The select inputs S3 and S2 are applied to the select inputs S1 and S0 of MUX-5. • The outputs Y1, Y2, Y3, Y4 are applied to the data inputs D0, D1, D2 and D3 of MUX-5 as shown in figure.
1
(2) S.E. − DLDA (CMPN)
Fig.: 16 : 1 multiplexer using 4 : 1 multiplexers. The operation can be summarized using table.
S3 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1
Select Inputs S2 S1 S0 0 0 0 0 0 1 0 1 0 0 1 1 1 0 0 1 0 1 1 1 0 1 1 1 0 0 0 0 0 1 0 1 0 0 1 1 1 0 0 1 0 1 1 1 0 1 1 1
Mux. Outputs Y1 Y2 Y3 Y4 D0 D4 D8 D12 D1 D3 D9 D13 D2 D6 D10 D14 D3 D7 D11 D15 D0 D4 D8 D12 D1 D3 D9 D13 D2 D6 D10 D14 D3 D7 D11 D15 D0 D4 D8 D12 D1 D3 D9 D13 D2 D6 D10 D14 D3 D7 D11 D15 D0 D4 D8 D12 D1 D3 D9 D13 D2 D6 D10 D14 D3 D7 D11 D15
1. (c) Design a full subtractor using only NAND gates.
Final output Y D0 D1 D2 D3 D4 D5 D6 D7 D8 D9 D10 D11 D12 D13 D14 D15
S3 S2 = 00 ∴ MUX − 5 selects Y1 S3 S2 = 01 ∴ MUX − 5 selects Y2 S3 S2 = 10 ∴ MUX − 5 selects Y3 S3 S2 = 11 ∴ MUX − 5 selects Y4
[4]
Soln.: The full subtractor is a combinational circuit with three inputs A, B and Bin and two outputs D and B. 2
Examination Paper Solution (3)
A is the minuend, B is subtrahend, Bin is the borrow produced by the previous stage, D is the difference output and B0 is the borrow output.
Truth Table : The truth table for full subtractor is shown in table. Table : Truth table for a full subtractor. Input Output A B Bin (A − B − Bin) B0 (Minuend) (Subtrahend) Previous borrow 0 0 0 0 0 0 0 1 1 1 0 1 0 1 1 0 1 1 0 1 1 0 0 1 0 1 0 1 0 0 1 1 0 0 0 1 1 1 1 1 K-maps and simplifications : K-maps for D and B0 outputs are shown in fig.(a) and (b). For difference output For borrow output ∴ D = ABBin + ABBin + ABBin + ABBin ∴ B0 = ABin + AB + BBin
ABBin
BBin A
Group 1 : ABin
ABBin
0
00 0
01 1
11 0
10 1
1
1
0
1
0
A 0
00 1
01 1
11 1
10 1
1
0
0
1
0
ABBin
ABBin
Group 3 : BBin (b) K-map for B0
(a) K-map for D Simplification for difference output : From fig. (a), D = ABBin + ABBin + ABBin + ABBin = Bin (AB + AB) + Bin (AB + AB) EX −OR
EX-NOR
∴ D = Bin (A ⊕ B) + Bin (A ⊕ B) Let (A ⊕ B) = C
Group 2 : AB
BBin
∴ D = Bin C + Bin C = Bin ⊕ C ∴ D = Bin ⊕ A ⊕ B
Simplification for borrow output : From fig.(b), B0 = ABin + AB + BBin No further simplification is possible. Logic diagram for full subtractor : Logic diagram for the full subtractor is shown in figure.
3
(4) S.E. − DLDA (CMPN)
Fig.: Logic diagram for a full subtractor. 1. (d) Simplify the following using Boolean Laws : (i) A + AB + ABC + ABCD (ii) A[B + C (AB + AC)]
[4]
Soln.: (i) A + AB + ABC + ABCD A + B + AB(C + CD) A + B + AB(C + D)
(∵ A + AB = A + B) (∵ A (B + C) = AB + AC)
A + B + ABC + ABD A + ABC + B + BAD A + BC + B + AD A + AD + B + BC A+D+B+C A+B+C+D (ii) A[B + C (AB + AC)] = A [B + C (AB.AC)]
(De-Morgan 2 law = A + B = A B )
= A [B + C (A + B) . (A + C)]
(De-Morgan 1 law = A + B = A + B )
= A [B + C (A.A + A.B + A.C + B.C)] = A [B + C (0 + A.B + A.C + B.C)]
(A.A = 0)
= A [B + C.0 + A.BC + A.CC + B.CC]
(A.0 = 0)
= A [B + 0 + A.BC + 0 + 0] = AB + A.A.B.C = AB + 0 = AB 2. (a) Simplify using K-map, obtain SOP equation and realize using only NAND gates. f (A, B, C, D) = π M (1, 2, 3, 8, 9, 10, 11, 14) + d (7, 15) Soln.:
f (A, B, C, D) = π M (1, 2, 3, 8, 9, 10, 11, 14) + d (7, 15) (1) The given Expression : Y = M1 M2 M3 M8 M9 M10 M11 M14 + d (7, 15)
4
[10]
Examination Paper Solution (5)
(2) In K-map inter, 0's corresponding to these mixtures, inter X's for don't cars and inter 1's in the remaining cells as shown in figure for the further simplification : CD
CD 00
00
1
AB AB
3
0
0
AB
01
1
AB
11 10
1
× 5
×
0
13
2
1 6
4
0 14
15
0 8
2
7
1 12
0 3
1
1
CD 10
0 1
4
AB
CD 11
CD 01
0 8
0 11
10
f (ABCD) = BC + BD + ACD + AB (3) Logic Diagram : Step 1 : A B C D
f (A, B, C, D)
Step 2 : AND – OR – NOT into NAND – NAND logic : Replace every AND by NAND every OR by a bubbled OR every by a NAND invertors to get NAND-NAND logic A B C D
f (A, B, C, D)
5
(6) S.E. − DLDA (CMPN)
Step 3 : Draw circuit using only NAND gate. A B C D
2. (b) Consider a chemical mixing tank for which there are 3 variables of interest : liquid level, pressure [10] and temperature. The alarm will be triggered under the following conditions : (i) Low level with high pressure (ii) High level with low pressure (iii) High level with low temperature and high pressure Design the system, implement using only NOR gates. Soln.:
(i) L 0 0 0 0 1 1 1 1
Input P 0 0 1 1 0 0 1 1
(ii) POS expression PT L L
0
Output
T 0 1 0 1 0 1 0 1
0 0 1 1 1 1 1 0
PT 00
0
0 0
L
1
PT 11
PT 01
1
1
1
1
1 4
PT 10 3
0
2
1
5
7
6
0 = (L + P) (L + P + T) (iii) Logic Diagram NOR gates. Step 1 : Implementing the given expression using AND-OR-NOT. The implementation using AND-OR-NOT gates as shown in logic figure. L P T
O
6
Examination Paper Solution (7)
Step 2 : Replace
L
OR by NOR AND by bubbled AND NOT by NOR inverter with the replacement, the current. P
T
Step 3 : Implementing circuit using only NOR gates L P T
3. (a) Design BCD to 7-segment code converter.
[10]
Soln.: BCD to 7 Segment Display Decoder
In most practical applications, seven segment displays are used to give a visual indication of the output states of digital ICs such as decade counters, latches etc. These outputs are usually in four bit BCD (binary coded decimal) form, and are thus not suitable for directly driving seven segment displays. The special BCD to seven segment decoder / driver ICs are used to convert the BCD signal into a form suitable for driving these displays. In this sections, we are going to study LED and LCD decoders / drivers for seven segment displays. Let us tabulate the segments activated during each digit display. Digit
Segments Activated
0
a, b, c, d, e, f
1
b, c
Display a f b e g c d
b c a
2
e g d
a, b, d, e, g
b
a 3
b g c d
a, b, c, d, g
7
(8) S.E. − DLDA (CMPN)
a 4
f
b, c, f, g
b g c d a
5
f
a, c, d, f, g
6
g c d a f e g c d
a, c, d, e, f, g
a 7
b c
a, b, c
8
a f b e g c d
a, b, c, d, e, f, g
a 9
f
a, b, c, d, f, g
b g c d
From the above table we can determine the truth table for BCD−to−7 segment decoder / driver. This truth table also depends on the construction of 7-segment display. If 7-segment display is common anode, the segment driver output must be active low to glow the segment. In case of common cathode type 7-segment display, the segment driver output must be active high to glow the segment. Following table shows the truth tables for both BCD-to 7 segment decoder / driver with common anode display and with common cathode display. Digit
A
B
C
D
a
b
c
d
e
f
g
0 1 2 3 4 5 6 7 8 9
0 0 0 0 0 0 0 0 1 1
0 0 0 0 1 1 1 1 0 0
0 0 1 1 0 0 1 1 0 0
0 1 0 1 0 1 0 1 0 1
1 0 1 1 0 1 1 1 1 1
1 1 1 1 1 0 0 1 1 1
1 1 0 1 1 1 1 1 1 1
1 0 1 1 0 1 1 0 1 1
1 0 1 0 0 0 1 0 1 0
1 0 0 0 1 1 1 0 1 1
0 0 1 1 1 1 1 0 1 1
Table : Truth table for BCD−to−common−cathode 7-segment decoder/driver
8
Examination Paper Solution (9)
K-map Simplification
Digit
A
B
C
D
a
b
c
d
e
f
g
0 1 2 3 4 5 6 7 8 9
0 0 0 0 0 0 0 0 1 1
0 0 0 0 1 1 1 1 0 0
0 0 1 1 0 0 1 1 0 0
0 1 0 1 0 1 0 1 0 1
0 1 0 0 1 0 0 0 0 0
0 0 0 0 0 1 1 0 0 0
0 0 1 0 0 0 0 0 0 0
0 1 0 0 1 0 0 1 0 0
0 1 0 1 1 1 0 1 0 1
0 1 1 1 0 0 0 1 0 0
1 1 0 0 0 0 0 1 0 0
Table : Truth table for BCD−to−common−anode 7-segment decoder/driver
Let us design the combinational circuit for common cathode 7-segment display / driver.
9
(10) S.E. − DLDA (CMPN)
Logic Diagram :
3. (b) Draw the 2-input TTL NAND gate and explain. List important characteristics of TTL family.
[10]
Soln.: Two Input TTL-NAND Gate (Totem Pole Output) : A two input TTL-NAND gate is shown in figure 1. A and B are the two inputs while Y is the output terminal of this NAND gate.
Fig.1 : Two input TTL-NAND gate
Fig.2 : Transistor Q1 is replaced by its equivalent.
Operation : In order to understand the operation of this circuit, let us replace transistor Q1 by its equivalent circuit as shown figure 2. 10
Examination Paper Solution (11)
1. A and B are the input terminals. The input voltages A and B can be either LOW (zero volts ideally) or HIGH (+ VCC ideally). 2. A and B both LOW : If A and B both are connected to ground, then both the B-E junctions of transistor Q1 are forward biased. • Hence diodes D1 and D2 in figure will conduct to force the voltage at point C in figure 2 to 0.7 V. • This voltage is insufficient to forward bias base-emitter junction of Q2. Hence Q2 will remain OFF. • Therefore its collector voltage VX rises to VCC. • As transistor Q3 is operating in the emitter follower mode, output Y will be pulled up to high voltage. ∴ Y = 1 (HIGH) … For A = B = 0 (LOW) • The equivalent circuit for this input condition is shown in figure 3(a).
(a) Equivalent circuit for A = B = 0.
(b) Equivalent circuit for A = 1, B = 0.
(c) Equivalent circuit for A = B = 1 Fig.3 3. Either A or B LOW : If any one input (A or B) s connected to ground with the other terminal left open or connected to +VCC, then the corresponding diode (D1 and D2) will conduct. 11
(12) S.E. − DLDA (CMPN)
• • • •
•
This will pull down the voltage at 'C' to 0.7 V. This voltage is insufficient to turn ON Q2. So it remains OFF. So collector voltage VX of Q2 will be equal to VCC. This voltage acts as base voltage for Q3. As Q3 acts as an emitter follower, output Y will be pulled to VCC. ∴ Y =1 if A = 0 and B = 1 if A = 1and B = 0 The equivalent circuit for this mode is shown in figure 3(b).
4. A and B both HIGH : If A and B both are connected to +VCC, then both the diodes D1 and D2 will be reverse biased and do not conduct. • Therefore diode D3 is forward biased and base current is supplied to transistor Q2 via R1 and D3. • As Q3 conducts, the voltage at X will drop down and Q3 will be OFF, whereas voltage at Z (across R3) will increase to turn ON Q4. • As Q4 goes into saturation, the output voltage Y will be pulled down to a low voltage. • The equivalent circuit for this mode of operation is shown in figure 3(c). • This discussion reveals that the circuit operates as a NAND gate. Standard TTL Characteristics : In 1964 Texas Instruments Corporation introduced the standard RRL ICs, 54/74 series. There are several series / subfamilies in the TTL family of logic devices. We first examine the electrical characteristics of the standard 74 series. Later we introduce the other TTL series and compare their characteristics with those of the standard series. Supply voltage and temperature range : Both the 74 series and 54 series operate on supply voltage of 5V. The 74 series works reliably over the range 4.75V to 5.25V, while the 54 series can tolerate a supply variation of 4.5 to 5.5V. he 74 series devices are guaranteed to work reliably over a temperature range of 0 to 70°C where as 54 series devices can handle temperature variations from −55 to +125°C. From the above values we can say that 54 series devices have greater tolerance of voltage and temperature variations. Hence, these devices are used where it is necessary to maintain reliable operation over an extreme range of conditions. For example, in military and space application. The only disadvantage of these devices is that they are expensive. Voltage Levels and Noise Margin : Table shows the input and output logic voltage levels for the standard 74 series. The minimum and maximum values shown in the table are for worst case conditions of power supply, temperature and loading conditions. Voltages Minimum Typical Maximum VOL 0.2 0.4 − VOH 2.4 3.4 − 0.8 VIL − − VIH 2.0 − − Table : Voltage levels
Looking at the table we can say that, in the worst case, there is difference of 0.4V between the driver output voltages and the required load input voltages. For instance, the worst-case low values are VOL(max) = 0.4V driver output VIL(max) = 0.8V load input Similarly, the worst-case high values are VOH(min) = 2.4V driver output VIH(min) = 2V load input In either case, the difference is 0.4V. This difference is called noise margin. For TTL, Low state noise margin, VNL and high state noise margin, VNH both are equal and 0.4V. This is illustrated in 12
Examination Paper Solution (13)
Figure. It provides built-in protection against noise. It ensures reliable operation of the device for induced noise voltages less than 0.4V. 5V
5V Logic 1
VOH(min) 2.4V
VOL(max) 0.4V 0V
Logic 1
Noise margin (VNH)
VIH(min) 2V
VNH = VOH(MIN) – VIH(MIN) = 2.4 − 2 = 0.4V
VIL(max) 0.8V
VNL = VIL(MAX) – VOL(MAX) = 0.8 − 0.4 = 0.4V
Noise margin (VNL)
Logic 0
Logic 0
0V Input voltage ranges
Output voltage ranges
Fig. TTL logic levels and noise margin Power Dissipation and Propagation Delay : A standard TTL gate has an average power dissipation of about 10 mW. It may vary from this value because of signal levels, tolerances, etc. We know that, the propagation delay time is the time it takes for the output of a gate to change after the inputs have changed. The propagation delay time of a TTL gate is approximately 10 nanoseconds. Fan-Out : A standard TTL output can typically drive 10 standard TTL inputs. Therefore, standard TTL has fanout 10. Table summarizes the characteristics of standard TTL Characteristics Values Supply voltage For 74 series − (4.75 to 5.25) units For 54 series − (4.5 to 5.5) units Temperature range For 74 series − (0°C to 70°C) For 54 series − (−55° to 125°C) Voltage levels VOL(max) − 0.4V VOH(max) − 2.4 V VIL(max) − 0.8 V VIH(min) − 2.0 V Noise margin 0.4V Power dissipation 10 mW per gate Propagation delay Typically 10 ns Fanout 10 Table : Standard TTL characteristics 4. (a) Design a BCD adder using 4-bit binary adders and explain.
[10]
Soln.:
• • • • •
A BCD adder adds two BCD digits and produces a BCD digit A-BCD cannot be greater than 9. The two given BCD numbers are to be added using the rules of binary addition. If sum is less than or equal to 9 and carry - 0, then no correction is necessary. The sum is correct and in the true BCD form. But if sum is invalid BCD or carry - 1, then the result is wrong and needs correction. The wrong result can be corrected by adding six (0110) to it. 13
(14) S.E. − DLDA (CMPN)
Block diagram of BCD adder : • From the points stated above, we understand, that the 4-bit BCD adder .should consist of the following blocks. 1. A 4-bit binary adder to add the given numbers A and B. 2. A combinational circuit to check if sum is greater than 9 or carry = 1. 3. One more 4-bit binary adder to add six (0110) to the incorrect sum if sum > 9 or carry = 1. • The block diagram of such a BCD adder is shown in figure1. • So we have to design the combinational circuit that senses if sum is greater than 9 or Carry = 1. Fig.1 : Block diagram of BCD adder. Design of Combination Circuit : • The output of combinational circuit should be 1 if the sum produced by adder 1 is greater than 9 i.e. 1001. The truth table is as follows : Table : Truth table for combinational circuit design.
Sub bits of adder-1
Inputs S2 S1 0 0 0 0 0 1 0 1 1 0 1 0 1 1 1 1 0 0 0 0 0 1 0 1 1 0 1 0 1 1 1 1
S3 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1
S0 0 1 0 1 0 1 0 1 0 1 0 1 0 1 0 1
Output Y 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1
Sum is valid BCD number. ∴ Y=0
Sum is invalid BCD number. ∴ Y=1
Write K-map : The K-map for Y output of the combinational circuit is as shown figure 2. For Y output
S1S2 S3S2 00
00 0
01 0
11 0
10 0
01
0
0
0
0
11
1
1
1
1
10
0
0
1
1
Group 1 : S3S2
Group 2 : S3S1 Fig.2 : K-map for Y output. 14
Examination Paper Solution (15)
•
• • •
The Boolean expression is, Y = S3S2 + S3S1 The BCD adder is shown in figure 3. The output of the combinational circuit should be 1 if Cout of adder-1 is high. Therefore Y is ORed with Cout of adder 1 as shown in figure 3. The output of combinational circuit is connected to B1B2 inputs of adder-2 and B3 = B1 = 0 as they are connected to ground permanently. This make B3 B2 B1 B0 = 0 1 1 0 if Y' = 1. The sum outputs of adder-1 are applied to A3A2A1A0 of adder-2. The output of combinational circuit is to be used as final output carry and the carry output of adder-2 is to be ignored.
Operation : Case 1 : Sum ≤ 9 and carry = 0. The output of combinational circuit Y' = 0. Hence B3 B2 B1 B0 = 0000 for adder-2. • Hence output of adder-2 is same as that of adder-1.
Fig.3 : 4-bit BCD adder. Case II : Sum > 9 and carry = 0. • If S3 S2 S1 S0 of adder-1 is greater than 9, then output Y' of combinational circuit becomes 1. • ∴ B3 B2 B1 B0 = 0110 (of adder-2). • Hence six (011) will be adder to the sum output of adder-1. • We get the corrected BCD result at the output of adder-2. Case III : Sum ≤ 9 but carry = 1. • An carry output of adder-1 is high, Y' = 1. • ∴ B3 B2 B1 B0 = 0 1 1 0 (of adder-2). • ∴ 0 1 1 0 will be added to the sum output of adder-1. • We get the corrected BCD result at the output of adder-2. Thus the four bit BCD addition can be carried out using the binary adder. 15
(16) S.E. − DLDA (CMPN)
4. (b) Design a MOD-6 synchronous up-counter and explain its operation.
[10]
Soln.:
Flip-flops required : 2n ≥ N N=6 n=3 i.e., three flip-flops required. • • • • •
The principle of operation of a 2-bit synchronous counter to a 3-bit counter shown in figure 1. FF-A acts as a toggle FF since JA = KA = 1. QA output of FF-A is applied to JB as well as KB. Hence if QA = 1 at the instant of triggering, then FF-B will toggle but if QA = 0 then FF-B will not change its state. QA and QB are ANDed and the output of AND gate is applied to JC and KC. Hence when QA and QB both are simultaneously high, then JC = KC = 1 and FF-C will toggle. Otherwise there is no change in the state of FF-3.
So in general we can say that each FF should have its J and K inputs connected such that they are high only when the outputs of all lower order FFs are in the high state.
Fig.1 : A 3-bit synchronous binary counter. Operation : Initially all the FFs are in their rest state. ∴ QC QB QA = 0 0 0 1st clock pulse : • FF-A toggles and QA changes to 1 from 0. But since QA = 0 at the instant o application of 1st falling clock edge, JB = KB = 0 and QB does not change state. ∴ QB remains 0. • Similarly QC also does not change state. ∴ QC = 0 ∴ QC QB QA = 0 0 1 … after 1st clock pulse 2nd clock pulse : • FF-A toggles and QA becomes 0. • But at the instant of application of 2nd falling clock edge QA was equal to 1. Hence JB = KB = 1. Hence FF-B will toggle and QB becomes 1. • Output of AND gate is 0 at the instant of negative clock edge. So JC = KC = 0. Hence QC remains 0. … after the 2nd clock pulse ∴ QC QB QA = 0 1 0 3rd clock pulse : • After the 3rd clock pulse, the outputs are QC QB QA = 0 1 1. 4th clock pulse : • Note that QB = QA = 1. Hence output of AND gate = 1 and JC = KC = 1, at the instant of application of 4th negative edge of the clock. 16
Examination Paper Solution (17)
• • • • •
•
Hence on application of this clock pulse, FF-C will toggle and QC changes from 0 to 1. FF-A toggles as usual and QA becomes 0. Since QA was equal to 1 earlier, FF-B will also toggle to make QB = 0. … after the 4th clock pulse ∴ QC QB QA = 1 0 0 Thus the counting progresses. After the 7th clock pulse the output is 111 and after the 8th clock pulse, all the flip-flops toggle and change their outputs to 0. Hence QC QB QA = 0 0 0 after the 8th pulse and the operation repeats. Table summarizes operation of the three bit synchronous counter.
Table : Summary of operation of a 3-bit synchronous counter.
Clock 0 1st (↓) 2nd (↓) 3rd (↓) 4th (↓) 5th (↓) 6th (↓) 7th (↓)
QC 0 0 0 0 1 1 1 1
QB 0 0 1 1 0 0 1 1
QA 0 1 0 1 0 1 0 1
Fig.2 : Timing diagram for a 3-bit synchronous counter. Timing diagram : • Timing diagram for a 3-bit synchronous counter is shown in figure 2. • Note that the waveforms of synchronous counter are exactly same as those of an asynchronous counter. 5. (a) Simplify using K-map and realize using NOR gates. f (A, B, C, D) = π m (1, 3, 7, 11, 15) + d (0, 2, 5, 8, 14) Soln.:
f (A, B, C, D) = π m (1, 3, 7, 11, 15) + d (0, 2, 5, 8, 14) (1) The given expression Let Y = M1 M3 M7 M11 M15 + d (0, 2, 5, 8, 14) (2) In K-map, enter 0's corresponding to those mixtures enter ×'s for don't corresponds and enter 1's in the remaining cells
17
[10]
(18) S.E. − DLDA (CMPN)
CD
CD 00
00
×
AB AB
0
01
×
1 4
AB
11
1
AB
10
1 7
6
×
0 13
1 8
2
0
1
×
× 3
5
12
CD 10
0 1
0
AB
CD 11
CD 01
15
14
0 9
1 11
10
(3) Logic diagram Step 1 :A B C D
y
Step 2 : AND-OR-NOT into NOR-NOR logic Replace entry AND by bubbled AND entry OR by NOR entry NOT by NOR A B C D
O
Step 3 : Implements circuit using only NOR gates A B C D
y
5. (b) Draw a 4-bit Johnson counter using shift and prove that it is "Divide by 4" logic.
[10]
Soln.:
•
In the ring counter the outputs of FF-3 were connected directly to the inputs of FF-0 i.e., Q3 to J0, Q3 to K0.
•
Instead if the outputs are cross coupled to the inputs i.e., if Q3 is connected to K0 and Q3.5 connected to J0 then the circuit is called as twisted ring counter or Johnson's counter. 18
Examination Paper Solution (19)
•
The Johnson's counter is shown in figure 1.
Fig.1 : Twisted ring counter or Johnson counter.
• •
All the flip-flops are negative edge triggered, and clock pulses are applied to all of them simultaneously. The clear inputs of all the flip-flops are connected together and connected to an external clear signal. Note that all these clear inputs are active low inputs.
Operation : • Initially a short negative going pulse is applied to the clear input of all the flip-flops. This will reset all the flip-flops. Hence initially the outputs are, Q3 Q2 Q1 Q0 = 0 0 0 0 • But Q3 = 1 and since it is coupled to J0 it is also equal to 1. … Initially ∴ J0 = 1 and K0 = 0 On the first falling edge of clock pulse : • As soon as the first negative edge of clock arrives, FF-0 will be set. Hence Q0 will become 1. • But there is no change in the status of any other flip-flop. • Hence after the first negative going edge of the clock the flip-flop outputs are, Q3 Q2 Q1 Q0 = 0 0 0 1 On the second negative going clock edge : Before the second negative going clock edge, Q3 = 0 and Q3 = 1. Hence J0 = 1 and K0 = 1. Also Q0 = 1. Hence J1 = 1. • Hence as soon as the second falling clock edge arrives, FF-0 continues to be in the set mode and FF-1 will now set. Hence Q1 will become 1 and Q1 = 1. • There is no change in the status of any other flip-flop. • Hence after the second clock edge the outputs are, Q3 Q2 Q1 Q0 = 0 0 1 1 • Similarly after the third clock pulse, the outputs are Q3 Q2 Q1 Q0 = 0 1 1 1 • And after the fourth clock pulse, the outputs are Q3 Q2 Q1 Q0 = 1 1 1 1 Note that now Q3 = 0, i.e., J0 = 0 and K0 = 1. • Hence as soon as the fifth negative going clock pulse strikes, FF-0 will reset. But the outputs of the other flip-flops will remain unchanged. So after the fifth clock pulse, the outputs are, … after the 5th clock pulse Q3 Q2 Q1 Q0 = 1 1 1 0 • This operation will continue till we reach the all zero output state. (i.e., Q3 Q2 Q1 Q0 = 0 0 0 0) • The operation of Johnson's counter is summarised in table.
19
(20) S.E. − DLDA (CMPN)
CLEAR
CLK
Q3
Q2
Q1
Q0
State number
1 1 1 1 1 1 1 1
Initially ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓
0 0 0 0 1 1 1 1 0
0 0 0 1 1 1 1 0 0
0 0 1 1 1 1 0 0 0
0 1 1 1 1 0 0 0 0
1 2 3 4 5 6 7 8 1
Decimal equivalent 0 1 3 7 15 14 12 8 0
Note that there are 8 distinct states of output. In general we can say that the number of states of a Johnson's counter is twice the number of flip-flops used. Therefore, for 4 flip-flops, states will be 8, 5 flip-flops states will be 10 and for 8 flip-flops states will 16.
Waveforms for Johnson's counter The waveforms for a 4-bit Johnsons counter are shown in figure.
Fig.2: Waveforms of Johnson counter. 6. (a) Simplify using Quine McClusky method. f (A, B, C, D) = π m (0, 2, 3, 6, 7, 8, 9, 12, 13) Realize the equation using any universal gate. Soln.:
f (A, B, C, D)
= π m (0, 2, 3, 6, 7, 8, 9, 12, 13) = ∑ M (1, 4, 5, 10, 11, 14, 15)
(1) Group the min according to number's of 1's. Binary Representation Group Min A B C D 1 1 0 0 0 1 4 0 1 0 0 2 5 0 1 0 1 10 1 0 1 0 3 11 1 0 1 1 14 1 1 1 0 4 15 1 1 1 1 20
[10]
Examination Paper Solution (21)
(2) Group the min to form Point : Group Min
1−5 4−5 10 − 11 10 − 14 11 − 15 11 − 15
1 2 3
Binary Representation A B C D 0 0 1 − 0 1 0 − 1 0 1 − 1 1 0 − 1 1 1 − 1 1 1 −
ACD A BC
Prime implicant
(3) Group the minterm to form ______ . Group
Min
2
10−11−11−15 10−14−11−15
A 1 1
Binary Representation B C D 1 − − 1 − −
AC is prime implicants
(4) Collect all the prime implicant f (A, B, C, D) = ACD + ABC + AC (5) Prepare the PI table. PI term ACD
Decimal represent 1, 5
1
4
×
4, 5
A C
10, 11, 14, 15
10
11
14
15
×
×
×
×
× ×
ABC
5 ×
In the PI table find the column only 1 cross (×) and encircle these (×) points. Put () in front of the corresponding PI's. These () marked PI in above table on the essential prime implicants. Hence simplified expression for y, y (A, B, C D) = A C D + A BC + A C (6) Logic diagram : Step 1 : A
B C
D
y (A, B, C, D)
Step 2 : AND-OR-NOT into NAND-NAND logic Replace entry AND by NAND entry OR by bubbled OR entry inverts by NAND invert to get NAND-NAND logic. 21
(22) S.E. − DLDA (CMPN)
A
B C
D
y (A, B, C, D)
Step 3 : Draw circuit using only NAND gates : A B C D
y (A, B, C, D)
6. (b) Implement the following expression using 8 : 1 MUX. f (A, B, C, D) = ∑ m (0, 1, 5, 7, 9, 10, 15)
[10]
Soln.: Below figure shows the implementation of given Boolean function with 8 : 1 multiplexer. D0 D1 D2 D3 D4 D5 D6 D7 0 1 2 3 4 5 6 7 A A 8 9 10 11 12 13 14 15 1 A 0 0 0 1 A A A
1 0
D0 D1 D2 D3 8 : 1 D4 MUX D5 D6 D7
y
7. Write short notes on : [20] 7. (a) De Morgan's Theorems The two theorems suggested by De-Morgen and which are extremely useful in Boolean algebra are as follows : Theorem 1 : AB = A + B : NAND = Bubbled OR • This theorem states that the complement of a product is equal to addition of the complements. • This rule is illustrated fig.1. The left hand side (LHS) of this theorem represents a NAND gate with inputs A and B whereas the right hand side (RHS) of the theorem represents an OR gate with inverted inputs. 22
Examination Paper Solution (23)
•
This OR gate is called as "Bubbled OR". Thus we can state De-Morgans first theorem as, NAND = Bubbled OR
Fig.1 : Illustration of De-Morgan's first theorem. This theorem can be verified by writing a truth table as shown in fig.2. A 0 0 1 1
B 0 1 0 1
AB 1 1 1 0
A 1 1 0 0
B 1 0 1 0
A+B 1 1 1 0
LHS
RHS AB + A + B Fig.2 : Verification of the theorem AB = A + B Theorem 2 : A + B = A.B : NOR = Bubbled AND • The LHS of this theorem represents a NOR gate with inputs A and B whereas the RHS represents an AND gate with inverted inputs. • This AND gate is called as "Bubbled AND". Thus we can state De-Morgan's second theorem as : NOR = Bubbled AND
Fig.3 : Illustration of De-Morgan's second theorem. •
This theorem can be verified by writing a truth table for both the sides of the theorem statement. This truth table is shown in fig.4, which shows that LHS = RHS. A 0 0 1 1
B 0 1 0 1
A+B 1 0 0 0
A 1 1 0 0
B 1 0 1 0
A.B 1 0 0 0
LHS
RHS A + B = A.B Fig.4 : Truth table to De-Morgan's theorem
EX-OR using NAND : • The Boolean expression for EX-NOR is Y = A B = AB + AB = X + Z • Taking double inversion of RHS, Y = X + Z = X.Z
… De Morgan's theorem
∴ Y = (A B) . (AB) • This is the required expression for EX-NOR in of only NAND gates. Figure shows the Fig.: EX-NOR using only NAND gates. realization. Refer figure for implementation. 23
(24) S.E. − DLDA (CMPN)
Description : • The select inputs S1 and S0 of the multiplexers 1, 2, 3 and 4 are connected together. • The select inputs S3 and S2 are applied to the select inputs S1 and S0 of MUX-5. • The outputs Y1, Y2, Y3, Y4 are applied to the data inputs D0, D1, D2 and D3 of MUX-5 as shown in figure.
Fig.: 16 : 1 multiplexer using 4 : 1 multiplexers The operation can be summarized using table. S3 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1
Select Inputs S2 S1 0 0 0 0 0 1 0 1 1 0 1 0 1 1 1 1 0 0 0 0 0 1 0 1 1 0 1 0 1 1 1 1
S0 0 1 0 1 0 1 0 1 0 1 0 1 0 1 0 1
Y1 D0 D1 D2 D3 D0 D1 D2 D3 D0 D1 D2 D3 D0 D1 D2 D3
Mux. Outputs Y2 Y3 Y4 D4 D8 D12 D3 D9 D13 D6 D10 D14 D7 D11 D15 D4 D8 D12 D3 D9 D13 D6 D10 D14 D7 D11 D15 D4 D8 D12 D3 D9 D13 D6 D10 D14 D7 D11 D15 D4 D8 D12 D3 D9 D13 D6 D10 D14 D7 D11 D15
Final output Y D0 D1 D2 D3 D4 D5 D6 D7 D8 D9 D10 D11 D12 D13 D14 D15
S3 S2 = 00 ∴ MUX − 5 selects Y1 S3 S2 = 01 ∴ MUX − 5 selects Y2 S3 S2 = 10 ∴ MUX − 5 selects Y3 S3 S2 = 11 ∴ MUX − 5 selects Y4
7. (b) NOR as universal gate Similar to NAND gate, the NOR gate is also a universal gate, since it can be used to generate the NOT, AND, OR and NAND functions. 24
Examination Paper Solution (25)
NOT Function : An inverter can be made from a NOR gate by connecting all of the inputs together and creating, in effect, a single common input, as shown in Fig. 1.
Fig. 1 : NOT function using NOR gate OR Function : An OR function can be generated using only NOR gates. It can be generated by simply inverting output of NOR gate; i.e. A + B = A + B. Fig. 2 shows the two input OR gate using NOR gates.
Fig. 2 : OR function using NOR gates A
B
A+B
0 0 1 1
0 1 0 1
0 1 1 1
A
B
0 0 0 1 ≡ 1 0 1 1 Table : Truth table
A+B 1 0 0 0
A+B 0 1 1 1
AND Function : AND function is generated using only NOR gates as follows : We know that Boolean expression for AND gate is Y = A. B =
A.B
=
A+B
Rule 9 : [ A = A ] DeMorgan’s Theorem 2
The above equation is implemented using only NOR gates as shown in the Fig. 3.
Fig. 3 : AND function using NOR gates
25
(26) S.E. − DLDA (CMPN)
Note : Bubble at the input of NOR gate indicates inverted input. A
B
A+B
A
B
0 0 1 1
0 1 0 1
0 0 0 1
0 0 1 1
0 1 0 1
≡
A+B 1 1 1 0
A+B 0 0 0 1
Table : Truth table NAND Function : NAND function is generated using only NOR gates as follows : We know that Boolean expression for NAND gate is Y = =
A.B A+B
=
A+B
DeMorgan’s Theorem 1 Rule 9 : [ A = A ]
The above equation is implemented using only NOR gates, as shown in the Fig. 8.
Fig. 8 : NAND function using only NOR gates
A
B
A+B
0 0 1 1
0 1 0 1
1 1 1 0
A
B
A+B
0 0 1 0 1 1 ≡ 1 0 1 1 1 0 Table : Truth table
A+B 0 0 0 1
A+B 1 1 1 0
7. (c) ALU Arithmetic Logic Unit (ALU) : • ALU is a very widely used and popular combinational circuit. • It is capable of performing the arithmetic as well as the logic operations. • ALU is the heart of any microprocessor. • Figure 1 shows the block diagram of ALU IC 74181, Table 1 gives the pin description and Figure 2 gives its pin configuration. • 74181 is a 24-pin IC dual in line (DTP) package. • A (A0 − A3) and B (B0 − B3) are the two 4 bit variables. 26
Examination Paper Solution (27)
Table 1: Pin description of 74181 Pin Name Description Operated inputs A0 − A3 Operand inputs B0 − B3 Function select inputs S0 − S3 M Mode control input Carry input (active low) Cn F0 − F3 A=B G P Cn + 4
Function output Comparator output (equality output) Carry generate output Carry propagate otput Carry output (active low)
Fig. 1 : Block diagram of ALU IC 74181 • • • • •
•
•
Fig. 2 : Pin configuration of the ALU IC 74181
It can perform a total of 16 arithmetic operations which includes addition, subtraction, compare and double operations. It provides many logic operations such as AND, OR, NOR, NAND EX-OR, compare etc on the two four bit variables. 74181 is a high speed 4 bit parallel ALU. It is controlled by four function select inputs S0 − S3. These lines can select 16 different operations for one mode (arithmetic) and 16 another operations for the other mode (logic). M is the mode control input. It decides the mode of operation to be either arithmetic or logic. M=0 For arithmetic operations M =1 For logic operations G and P outputs are used when a number of 74181 circuits are to be used in cascade alongwith 74182, the look ahead carry generator circuit to make the arithmetic operations faster. When mode control input is high (M = 1), then the logic operations are performed on the individual bits and all the internal carries are enabled. 27
(28) S.E. − DLDA (CMPN)
• • • •
•
When mode control input is low (M = 0), the arithmetic operations are performed on the two 4-bit words and all the internal carriers are enabled. IC 74181 incorporates full internal carry lookahead. This enhances its speed of operation to a great extent. It provides a ripple carry between the devices using the Cn+4 output. (see cascading of two 74181s). Or for exploiting the option of carry lookahead between the packages, we have to use the P (carry propagate) and G (carry generate) outputs. This option should be used only when the speed requirements are stringent. If low speed of operation is acceptable, the ripple carry operation using Cn+4 and Cn should be exercised.
A = B Output : 1. A = B output indicates the logical equality of the two operands. This output goes HIGH when the unit is in the subtract mode and A = B. 2. This output also goes high when all the four “Function outputs” are HIGH. 3. It is possible to wire AND the A = B outputs when more than one 74181s are being used. The wire ANDing becomes possible because A = B is an open collector output. This enables us to compare words which are longer than 4-bits. Function tables : (If the question is 10 marks, then mention the functional table in details) • Table 2(a) shows the function table for IC 74181. It is valid for the active high operands and active high outputs, and with C n = 1 i.e. no carry. Table 2(a): Function table for IC 74181 with active high data and Cn = 1 (no carry) Function Select Inputs
S3 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1
• •
S2 0 0 0 0 1 1 1 1 0 0 0 0 1 1 1 1
S1 0 0 1 1 0 0 1 1 0 0 1 1 0 0 1 1
S0 0 1 0 1 0 1 0 1 0 1 0 1 0 1 0 1
Active high data and Cn = 1 Logic operations (M = 1) Arithmetic operations (M = 0) F=A F = A (Inversion) F=A+B F = A + B (NOR) F = A.B F=0 F = AB (NAND) F = B (Invert) F = A ⊕ B (EXOR) F= AB F= A+B F = A ⊕ B (EXNOR) F=B F = AB (AND) F = logic 1 F=A+ B F = A + B (OR) F=A
F=A+ B F = minus 1 (2’s comp) F = A plus A B F = (A + B)plus A B F = A minus B minus 1 F = A B minus 1 F = A plus AB F = A plus B F = (A + B ) plus AB F = AB minus 1 F = A plus A* F = (A + B) plus A F = (A + B ) plus A F = A Minus 1
Each bit is shifted to the next more significant position. The arithmetic operations listed in function Table 2(a), correspond to no carry input. They will get modified if the carry input is present as shown in Table 2(b). It is possible to use IC 74181 with either active high inputs or with active low inputs. With active low inputs the device produces active low outputs and with active high inputs it produces active high outputs. 28
Examination Paper Solution (29)
• The function table for active low inputs and outputs has been given in Table 2(b). Table 2(b) : Function table for IC 74181 with active low data and C n = 0 (with carry).
Function Select Inputs S3 0 0 0 0 0
S2 0 0 0 0 0
S1 0 0 1 1 1
S0 0 1 0 1 1
0
1
0
1
Active Low data and Cn = 0 Logic operations M = 0 Arithmetic operations M = 1 F = A minus 1 F = A (inversion) F = AB minus 1 F = AB (NAND) F= A+B F=1 F = A+B
F = A B minus 1 F = minus 1 F = A plus (A + B )
F = B (inversion)
F = AB plus (A + B )
7. (d) TTL vs COMS logic family : High Speed CMOS The high speed CMOS devices have silicon gates instead of metal gates. This improved version of CMOS ICs has higher switching speeds and higher output current capacity. The high speed CMOS devices are pin compatible and functionally equivalent to TTL ICs with the same device numbers.
Comparison of CMOS and TTL Families Parameter
VIH (min) VIL (max) VOH (min) VOL (max) VNH VNL Propagation Delay (ns) Power per gate (mW) Speed power product or figure or merit Input connection Power dissipation Fan out Noise
CMOS
TTL
Silicon gate CMOS 3.5 1.0 4.9 0.1 1.4 0.9
Metal gate CMOS 3.5 1.5 4.95 0.05 1.45 1.45
74
74LS
74AS
74ALS
2.0 0.8 2.4 0.4 0.4 0.4
2.0 0.8 2.7 0.5 0.7 0.3
2.0 0.8 2.7 0.5 0.7 0.3
2.0 0.8 2.7 0.4 0.7 0.4
8
105
10
10
1.5
4
0.17
0.1
10
2
8.5
1
1.4 pJ
10.5 pJ
100 pJ
20 pJ
12.8 pJ
4 pJ
Input cannot be left open. It has to be connected to 0, or to VDD or to the another input. Very less, but increases with increase in switching speed Fan−out is more than TTL typically 50 More susceptible to noise
Input can be left open. It is treated as logic high input. More than CMOS. It is constant, does not depend on switching speed. Fan−out for TTL is 10. Less susceptible to noise.
29
Digital Logic Design and Applications May '09 : Mumbai University − Examination Paper Solution Time : 3hrs] N.B. :
[Marks : 100
(1) Question No. 1 is compulsory. (2) Attempt any four questions out of remaining six questions.
1. (a) Converter (670.17)8 into decimal, binary and hex.
[6]
Soln.: (670.17)8 Octal to Decimal : Step 1 : Get the octal no. Step 2 : Write corresponding weights Step 3 : Multiple columnwise
6 7 1 . 1 7 82 81 80 . 8−1 8−2 384 56 0 . 1/8 7/56 1 7 Step 4 : Add the contents of row 3 = 384 + 56 + 0 + + 8 64 = (440.23)10 Octal to Binary : Step 1 : Get the octal no. 6 7 1 . 1 7 Step 2 : Convert each digits into binary 110 111 000 . 001 111 ∴ (670.17)8 = (110 111 000 . 001 111)2
Octal to Hexadecimal : Step 1 : Convert into binary (110 111 000 . 001 111) Step 2 : Convert binary to hexadecimal (1 1011 1000 . 0011 11)2 Add three zeros on extreme left corner and Add 2 zero on extreme right side. Binary (0001 1011 1000 . 0011 1100) group of 4 bit, Hexa number 1 B 8 . 3 C (670.17)8 = (1B8.3C)16
1. (b) Design 16 : 1 MUX using 4 : 1 MUX.
[6]
Soln.: Refer figure for implementation.
Description : • The select inputs S1 and S0 of the multiplexers 1, 2, 3 and 4 are connected together. • The select inputs S3 and S2 are applied to the select inputs S1 and S0 of MUX-5. • The outputs Y1, Y2, Y3, Y4 are applied to the data inputs D0, D1, D2 and D3 of MUX-5 as shown in figure.
1
(2) S.E. − DLDA (CMPN)
Fig.: 16 : 1 multiplexer using 4 : 1 multiplexers. The operation can be summarized using table.
S3 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1
Select Inputs S2 S1 S0 0 0 0 0 0 1 0 1 0 0 1 1 1 0 0 1 0 1 1 1 0 1 1 1 0 0 0 0 0 1 0 1 0 0 1 1 1 0 0 1 0 1 1 1 0 1 1 1
Mux. Outputs Y1 Y2 Y3 Y4 D0 D4 D8 D12 D1 D3 D9 D13 D2 D6 D10 D14 D3 D7 D11 D15 D0 D4 D8 D12 D1 D3 D9 D13 D2 D6 D10 D14 D3 D7 D11 D15 D0 D4 D8 D12 D1 D3 D9 D13 D2 D6 D10 D14 D3 D7 D11 D15 D0 D4 D8 D12 D1 D3 D9 D13 D2 D6 D10 D14 D3 D7 D11 D15
1. (c) Design a full subtractor using only NAND gates.
Final output Y D0 D1 D2 D3 D4 D5 D6 D7 D8 D9 D10 D11 D12 D13 D14 D15
S3 S2 = 00 ∴ MUX − 5 selects Y1 S3 S2 = 01 ∴ MUX − 5 selects Y2 S3 S2 = 10 ∴ MUX − 5 selects Y3 S3 S2 = 11 ∴ MUX − 5 selects Y4
[4]
Soln.: The full subtractor is a combinational circuit with three inputs A, B and Bin and two outputs D and B. 2
Examination Paper Solution (3)
A is the minuend, B is subtrahend, Bin is the borrow produced by the previous stage, D is the difference output and B0 is the borrow output.
Truth Table : The truth table for full subtractor is shown in table. Table : Truth table for a full subtractor. Input Output A B Bin (A − B − Bin) B0 (Minuend) (Subtrahend) Previous borrow 0 0 0 0 0 0 0 1 1 1 0 1 0 1 1 0 1 1 0 1 1 0 0 1 0 1 0 1 0 0 1 1 0 0 0 1 1 1 1 1 K-maps and simplifications : K-maps for D and B0 outputs are shown in fig.(a) and (b). For difference output For borrow output ∴ D = ABBin + ABBin + ABBin + ABBin ∴ B0 = ABin + AB + BBin
ABBin
BBin A
Group 1 : ABin
ABBin
0
00 0
01 1
11 0
10 1
1
1
0
1
0
A 0
00 1
01 1
11 1
10 1
1
0
0
1
0
ABBin
ABBin
Group 3 : BBin (b) K-map for B0
(a) K-map for D Simplification for difference output : From fig. (a), D = ABBin + ABBin + ABBin + ABBin = Bin (AB + AB) + Bin (AB + AB) EX −OR
EX-NOR
∴ D = Bin (A ⊕ B) + Bin (A ⊕ B) Let (A ⊕ B) = C
Group 2 : AB
BBin
∴ D = Bin C + Bin C = Bin ⊕ C ∴ D = Bin ⊕ A ⊕ B
Simplification for borrow output : From fig.(b), B0 = ABin + AB + BBin No further simplification is possible. Logic diagram for full subtractor : Logic diagram for the full subtractor is shown in figure.
3
(4) S.E. − DLDA (CMPN)
Fig.: Logic diagram for a full subtractor. 1. (d) Simplify the following using Boolean Laws : (i) A + AB + ABC + ABCD (ii) A[B + C (AB + AC)]
[4]
Soln.: (i) A + AB + ABC + ABCD A + B + AB(C + CD) A + B + AB(C + D)
(∵ A + AB = A + B) (∵ A (B + C) = AB + AC)
A + B + ABC + ABD A + ABC + B + BAD A + BC + B + AD A + AD + B + BC A+D+B+C A+B+C+D (ii) A[B + C (AB + AC)] = A [B + C (AB.AC)]
(De-Morgan 2 law = A + B = A B )
= A [B + C (A + B) . (A + C)]
(De-Morgan 1 law = A + B = A + B )
= A [B + C (A.A + A.B + A.C + B.C)] = A [B + C (0 + A.B + A.C + B.C)]
(A.A = 0)
= A [B + C.0 + A.BC + A.CC + B.CC]
(A.0 = 0)
= A [B + 0 + A.BC + 0 + 0] = AB + A.A.B.C = AB + 0 = AB 2. (a) Simplify using K-map, obtain SOP equation and realize using only NAND gates. f (A, B, C, D) = π M (1, 2, 3, 8, 9, 10, 11, 14) + d (7, 15) Soln.:
f (A, B, C, D) = π M (1, 2, 3, 8, 9, 10, 11, 14) + d (7, 15) (1) The given Expression : Y = M1 M2 M3 M8 M9 M10 M11 M14 + d (7, 15)
4
[10]
Examination Paper Solution (5)
(2) In K-map inter, 0's corresponding to these mixtures, inter X's for don't cars and inter 1's in the remaining cells as shown in figure for the further simplification : CD
CD 00
00
1
AB AB
3
0
0
AB
01
1
AB
11 10
1
× 5
×
0
13
2
1 6
4
0 14
15
0 8
2
7
1 12
0 3
1
1
CD 10
0 1
4
AB
CD 11
CD 01
0 8
0 11
10
f (ABCD) = BC + BD + ACD + AB (3) Logic Diagram : Step 1 : A B C D
f (A, B, C, D)
Step 2 : AND – OR – NOT into NAND – NAND logic : Replace every AND by NAND every OR by a bubbled OR every by a NAND invertors to get NAND-NAND logic A B C D
f (A, B, C, D)
5
(6) S.E. − DLDA (CMPN)
Step 3 : Draw circuit using only NAND gate. A B C D
2. (b) Consider a chemical mixing tank for which there are 3 variables of interest : liquid level, pressure [10] and temperature. The alarm will be triggered under the following conditions : (i) Low level with high pressure (ii) High level with low pressure (iii) High level with low temperature and high pressure Design the system, implement using only NOR gates. Soln.:
(i) L 0 0 0 0 1 1 1 1
Input P 0 0 1 1 0 0 1 1
(ii) POS expression PT L L
0
Output
T 0 1 0 1 0 1 0 1
0 0 1 1 1 1 1 0
PT 00
0
0 0
L
1
PT 11
PT 01
1
1
1
1
1 4
PT 10 3
0
2
1
5
7
6
0 = (L + P) (L + P + T) (iii) Logic Diagram NOR gates. Step 1 : Implementing the given expression using AND-OR-NOT. The implementation using AND-OR-NOT gates as shown in logic figure. L P T
O
6
Examination Paper Solution (7)
Step 2 : Replace
L
OR by NOR AND by bubbled AND NOT by NOR inverter with the replacement, the current. P
T
Step 3 : Implementing circuit using only NOR gates L P T
3. (a) Design BCD to 7-segment code converter.
[10]
Soln.: BCD to 7 Segment Display Decoder
In most practical applications, seven segment displays are used to give a visual indication of the output states of digital ICs such as decade counters, latches etc. These outputs are usually in four bit BCD (binary coded decimal) form, and are thus not suitable for directly driving seven segment displays. The special BCD to seven segment decoder / driver ICs are used to convert the BCD signal into a form suitable for driving these displays. In this sections, we are going to study LED and LCD decoders / drivers for seven segment displays. Let us tabulate the segments activated during each digit display. Digit
Segments Activated
0
a, b, c, d, e, f
1
b, c
Display a f b e g c d
b c a
2
e g d
a, b, d, e, g
b
a 3
b g c d
a, b, c, d, g
7
(8) S.E. − DLDA (CMPN)
a 4
f
b, c, f, g
b g c d a
5
f
a, c, d, f, g
6
g c d a f e g c d
a, c, d, e, f, g
a 7
b c
a, b, c
8
a f b e g c d
a, b, c, d, e, f, g
a 9
f
a, b, c, d, f, g
b g c d
From the above table we can determine the truth table for BCD−to−7 segment decoder / driver. This truth table also depends on the construction of 7-segment display. If 7-segment display is common anode, the segment driver output must be active low to glow the segment. In case of common cathode type 7-segment display, the segment driver output must be active high to glow the segment. Following table shows the truth tables for both BCD-to 7 segment decoder / driver with common anode display and with common cathode display. Digit
A
B
C
D
a
b
c
d
e
f
g
0 1 2 3 4 5 6 7 8 9
0 0 0 0 0 0 0 0 1 1
0 0 0 0 1 1 1 1 0 0
0 0 1 1 0 0 1 1 0 0
0 1 0 1 0 1 0 1 0 1
1 0 1 1 0 1 1 1 1 1
1 1 1 1 1 0 0 1 1 1
1 1 0 1 1 1 1 1 1 1
1 0 1 1 0 1 1 0 1 1
1 0 1 0 0 0 1 0 1 0
1 0 0 0 1 1 1 0 1 1
0 0 1 1 1 1 1 0 1 1
Table : Truth table for BCD−to−common−cathode 7-segment decoder/driver
8
Examination Paper Solution (9)
K-map Simplification
Digit
A
B
C
D
a
b
c
d
e
f
g
0 1 2 3 4 5 6 7 8 9
0 0 0 0 0 0 0 0 1 1
0 0 0 0 1 1 1 1 0 0
0 0 1 1 0 0 1 1 0 0
0 1 0 1 0 1 0 1 0 1
0 1 0 0 1 0 0 0 0 0
0 0 0 0 0 1 1 0 0 0
0 0 1 0 0 0 0 0 0 0
0 1 0 0 1 0 0 1 0 0
0 1 0 1 1 1 0 1 0 1
0 1 1 1 0 0 0 1 0 0
1 1 0 0 0 0 0 1 0 0
Table : Truth table for BCD−to−common−anode 7-segment decoder/driver
Let us design the combinational circuit for common cathode 7-segment display / driver.
9
(10) S.E. − DLDA (CMPN)
Logic Diagram :
3. (b) Draw the 2-input TTL NAND gate and explain. List important characteristics of TTL family.
[10]
Soln.: Two Input TTL-NAND Gate (Totem Pole Output) : A two input TTL-NAND gate is shown in figure 1. A and B are the two inputs while Y is the output terminal of this NAND gate.
Fig.1 : Two input TTL-NAND gate
Fig.2 : Transistor Q1 is replaced by its equivalent.
Operation : In order to understand the operation of this circuit, let us replace transistor Q1 by its equivalent circuit as shown figure 2. 10
Examination Paper Solution (11)
1. A and B are the input terminals. The input voltages A and B can be either LOW (zero volts ideally) or HIGH (+ VCC ideally). 2. A and B both LOW : If A and B both are connected to ground, then both the B-E junctions of transistor Q1 are forward biased. • Hence diodes D1 and D2 in figure will conduct to force the voltage at point C in figure 2 to 0.7 V. • This voltage is insufficient to forward bias base-emitter junction of Q2. Hence Q2 will remain OFF. • Therefore its collector voltage VX rises to VCC. • As transistor Q3 is operating in the emitter follower mode, output Y will be pulled up to high voltage. ∴ Y = 1 (HIGH) … For A = B = 0 (LOW) • The equivalent circuit for this input condition is shown in figure 3(a).
(a) Equivalent circuit for A = B = 0.
(b) Equivalent circuit for A = 1, B = 0.
(c) Equivalent circuit for A = B = 1 Fig.3 3. Either A or B LOW : If any one input (A or B) s connected to ground with the other terminal left open or connected to +VCC, then the corresponding diode (D1 and D2) will conduct. 11
(12) S.E. − DLDA (CMPN)
• • • •
•
This will pull down the voltage at 'C' to 0.7 V. This voltage is insufficient to turn ON Q2. So it remains OFF. So collector voltage VX of Q2 will be equal to VCC. This voltage acts as base voltage for Q3. As Q3 acts as an emitter follower, output Y will be pulled to VCC. ∴ Y =1 if A = 0 and B = 1 if A = 1and B = 0 The equivalent circuit for this mode is shown in figure 3(b).
4. A and B both HIGH : If A and B both are connected to +VCC, then both the diodes D1 and D2 will be reverse biased and do not conduct. • Therefore diode D3 is forward biased and base current is supplied to transistor Q2 via R1 and D3. • As Q3 conducts, the voltage at X will drop down and Q3 will be OFF, whereas voltage at Z (across R3) will increase to turn ON Q4. • As Q4 goes into saturation, the output voltage Y will be pulled down to a low voltage. • The equivalent circuit for this mode of operation is shown in figure 3(c). • This discussion reveals that the circuit operates as a NAND gate. Standard TTL Characteristics : In 1964 Texas Instruments Corporation introduced the standard RRL ICs, 54/74 series. There are several series / subfamilies in the TTL family of logic devices. We first examine the electrical characteristics of the standard 74 series. Later we introduce the other TTL series and compare their characteristics with those of the standard series. Supply voltage and temperature range : Both the 74 series and 54 series operate on supply voltage of 5V. The 74 series works reliably over the range 4.75V to 5.25V, while the 54 series can tolerate a supply variation of 4.5 to 5.5V. he 74 series devices are guaranteed to work reliably over a temperature range of 0 to 70°C where as 54 series devices can handle temperature variations from −55 to +125°C. From the above values we can say that 54 series devices have greater tolerance of voltage and temperature variations. Hence, these devices are used where it is necessary to maintain reliable operation over an extreme range of conditions. For example, in military and space application. The only disadvantage of these devices is that they are expensive. Voltage Levels and Noise Margin : Table shows the input and output logic voltage levels for the standard 74 series. The minimum and maximum values shown in the table are for worst case conditions of power supply, temperature and loading conditions. Voltages Minimum Typical Maximum VOL 0.2 0.4 − VOH 2.4 3.4 − 0.8 VIL − − VIH 2.0 − − Table : Voltage levels
Looking at the table we can say that, in the worst case, there is difference of 0.4V between the driver output voltages and the required load input voltages. For instance, the worst-case low values are VOL(max) = 0.4V driver output VIL(max) = 0.8V load input Similarly, the worst-case high values are VOH(min) = 2.4V driver output VIH(min) = 2V load input In either case, the difference is 0.4V. This difference is called noise margin. For TTL, Low state noise margin, VNL and high state noise margin, VNH both are equal and 0.4V. This is illustrated in 12
Examination Paper Solution (13)
Figure. It provides built-in protection against noise. It ensures reliable operation of the device for induced noise voltages less than 0.4V. 5V
5V Logic 1
VOH(min) 2.4V
VOL(max) 0.4V 0V
Logic 1
Noise margin (VNH)
VIH(min) 2V
VNH = VOH(MIN) – VIH(MIN) = 2.4 − 2 = 0.4V
VIL(max) 0.8V
VNL = VIL(MAX) – VOL(MAX) = 0.8 − 0.4 = 0.4V
Noise margin (VNL)
Logic 0
Logic 0
0V Input voltage ranges
Output voltage ranges
Fig. TTL logic levels and noise margin Power Dissipation and Propagation Delay : A standard TTL gate has an average power dissipation of about 10 mW. It may vary from this value because of signal levels, tolerances, etc. We know that, the propagation delay time is the time it takes for the output of a gate to change after the inputs have changed. The propagation delay time of a TTL gate is approximately 10 nanoseconds. Fan-Out : A standard TTL output can typically drive 10 standard TTL inputs. Therefore, standard TTL has fanout 10. Table summarizes the characteristics of standard TTL Characteristics Values Supply voltage For 74 series − (4.75 to 5.25) units For 54 series − (4.5 to 5.5) units Temperature range For 74 series − (0°C to 70°C) For 54 series − (−55° to 125°C) Voltage levels VOL(max) − 0.4V VOH(max) − 2.4 V VIL(max) − 0.8 V VIH(min) − 2.0 V Noise margin 0.4V Power dissipation 10 mW per gate Propagation delay Typically 10 ns Fanout 10 Table : Standard TTL characteristics 4. (a) Design a BCD adder using 4-bit binary adders and explain.
[10]
Soln.:
• • • • •
A BCD adder adds two BCD digits and produces a BCD digit A-BCD cannot be greater than 9. The two given BCD numbers are to be added using the rules of binary addition. If sum is less than or equal to 9 and carry - 0, then no correction is necessary. The sum is correct and in the true BCD form. But if sum is invalid BCD or carry - 1, then the result is wrong and needs correction. The wrong result can be corrected by adding six (0110) to it. 13
(14) S.E. − DLDA (CMPN)
Block diagram of BCD adder : • From the points stated above, we understand, that the 4-bit BCD adder .should consist of the following blocks. 1. A 4-bit binary adder to add the given numbers A and B. 2. A combinational circuit to check if sum is greater than 9 or carry = 1. 3. One more 4-bit binary adder to add six (0110) to the incorrect sum if sum > 9 or carry = 1. • The block diagram of such a BCD adder is shown in figure1. • So we have to design the combinational circuit that senses if sum is greater than 9 or Carry = 1. Fig.1 : Block diagram of BCD adder. Design of Combination Circuit : • The output of combinational circuit should be 1 if the sum produced by adder 1 is greater than 9 i.e. 1001. The truth table is as follows : Table : Truth table for combinational circuit design.
Sub bits of adder-1
Inputs S2 S1 0 0 0 0 0 1 0 1 1 0 1 0 1 1 1 1 0 0 0 0 0 1 0 1 1 0 1 0 1 1 1 1
S3 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1
S0 0 1 0 1 0 1 0 1 0 1 0 1 0 1 0 1
Output Y 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1
Sum is valid BCD number. ∴ Y=0
Sum is invalid BCD number. ∴ Y=1
Write K-map : The K-map for Y output of the combinational circuit is as shown figure 2. For Y output
S1S2 S3S2 00
00 0
01 0
11 0
10 0
01
0
0
0
0
11
1
1
1
1
10
0
0
1
1
Group 1 : S3S2
Group 2 : S3S1 Fig.2 : K-map for Y output. 14
Examination Paper Solution (15)
•
• • •
The Boolean expression is, Y = S3S2 + S3S1 The BCD adder is shown in figure 3. The output of the combinational circuit should be 1 if Cout of adder-1 is high. Therefore Y is ORed with Cout of adder 1 as shown in figure 3. The output of combinational circuit is connected to B1B2 inputs of adder-2 and B3 = B1 = 0 as they are connected to ground permanently. This make B3 B2 B1 B0 = 0 1 1 0 if Y' = 1. The sum outputs of adder-1 are applied to A3A2A1A0 of adder-2. The output of combinational circuit is to be used as final output carry and the carry output of adder-2 is to be ignored.
Operation : Case 1 : Sum ≤ 9 and carry = 0. The output of combinational circuit Y' = 0. Hence B3 B2 B1 B0 = 0000 for adder-2. • Hence output of adder-2 is same as that of adder-1.
Fig.3 : 4-bit BCD adder. Case II : Sum > 9 and carry = 0. • If S3 S2 S1 S0 of adder-1 is greater than 9, then output Y' of combinational circuit becomes 1. • ∴ B3 B2 B1 B0 = 0110 (of adder-2). • Hence six (011) will be adder to the sum output of adder-1. • We get the corrected BCD result at the output of adder-2. Case III : Sum ≤ 9 but carry = 1. • An carry output of adder-1 is high, Y' = 1. • ∴ B3 B2 B1 B0 = 0 1 1 0 (of adder-2). • ∴ 0 1 1 0 will be added to the sum output of adder-1. • We get the corrected BCD result at the output of adder-2. Thus the four bit BCD addition can be carried out using the binary adder. 15
(16) S.E. − DLDA (CMPN)
4. (b) Design a MOD-6 synchronous up-counter and explain its operation.
[10]
Soln.:
Flip-flops required : 2n ≥ N N=6 n=3 i.e., three flip-flops required. • • • • •
The principle of operation of a 2-bit synchronous counter to a 3-bit counter shown in figure 1. FF-A acts as a toggle FF since JA = KA = 1. QA output of FF-A is applied to JB as well as KB. Hence if QA = 1 at the instant of triggering, then FF-B will toggle but if QA = 0 then FF-B will not change its state. QA and QB are ANDed and the output of AND gate is applied to JC and KC. Hence when QA and QB both are simultaneously high, then JC = KC = 1 and FF-C will toggle. Otherwise there is no change in the state of FF-3.
So in general we can say that each FF should have its J and K inputs connected such that they are high only when the outputs of all lower order FFs are in the high state.
Fig.1 : A 3-bit synchronous binary counter. Operation : Initially all the FFs are in their rest state. ∴ QC QB QA = 0 0 0 1st clock pulse : • FF-A toggles and QA changes to 1 from 0. But since QA = 0 at the instant o application of 1st falling clock edge, JB = KB = 0 and QB does not change state. ∴ QB remains 0. • Similarly QC also does not change state. ∴ QC = 0 ∴ QC QB QA = 0 0 1 … after 1st clock pulse 2nd clock pulse : • FF-A toggles and QA becomes 0. • But at the instant of application of 2nd falling clock edge QA was equal to 1. Hence JB = KB = 1. Hence FF-B will toggle and QB becomes 1. • Output of AND gate is 0 at the instant of negative clock edge. So JC = KC = 0. Hence QC remains 0. … after the 2nd clock pulse ∴ QC QB QA = 0 1 0 3rd clock pulse : • After the 3rd clock pulse, the outputs are QC QB QA = 0 1 1. 4th clock pulse : • Note that QB = QA = 1. Hence output of AND gate = 1 and JC = KC = 1, at the instant of application of 4th negative edge of the clock. 16
Examination Paper Solution (17)
• • • • •
•
Hence on application of this clock pulse, FF-C will toggle and QC changes from 0 to 1. FF-A toggles as usual and QA becomes 0. Since QA was equal to 1 earlier, FF-B will also toggle to make QB = 0. … after the 4th clock pulse ∴ QC QB QA = 1 0 0 Thus the counting progresses. After the 7th clock pulse the output is 111 and after the 8th clock pulse, all the flip-flops toggle and change their outputs to 0. Hence QC QB QA = 0 0 0 after the 8th pulse and the operation repeats. Table summarizes operation of the three bit synchronous counter.
Table : Summary of operation of a 3-bit synchronous counter.
Clock 0 1st (↓) 2nd (↓) 3rd (↓) 4th (↓) 5th (↓) 6th (↓) 7th (↓)
QC 0 0 0 0 1 1 1 1
QB 0 0 1 1 0 0 1 1
QA 0 1 0 1 0 1 0 1
Fig.2 : Timing diagram for a 3-bit synchronous counter. Timing diagram : • Timing diagram for a 3-bit synchronous counter is shown in figure 2. • Note that the waveforms of synchronous counter are exactly same as those of an asynchronous counter. 5. (a) Simplify using K-map and realize using NOR gates. f (A, B, C, D) = π m (1, 3, 7, 11, 15) + d (0, 2, 5, 8, 14) Soln.:
f (A, B, C, D) = π m (1, 3, 7, 11, 15) + d (0, 2, 5, 8, 14) (1) The given expression Let Y = M1 M3 M7 M11 M15 + d (0, 2, 5, 8, 14) (2) In K-map, enter 0's corresponding to those mixtures enter ×'s for don't corresponds and enter 1's in the remaining cells
17
[10]
(18) S.E. − DLDA (CMPN)
CD
CD 00
00
×
AB AB
0
01
×
1 4
AB
11
1
AB
10
1 7
6
×
0 13
1 8
2
0
1
×
× 3
5
12
CD 10
0 1
0
AB
CD 11
CD 01
15
14
0 9
1 11
10
(3) Logic diagram Step 1 :A B C D
y
Step 2 : AND-OR-NOT into NOR-NOR logic Replace entry AND by bubbled AND entry OR by NOR entry NOT by NOR A B C D
O
Step 3 : Implements circuit using only NOR gates A B C D
y
5. (b) Draw a 4-bit Johnson counter using shift and prove that it is "Divide by 4" logic.
[10]
Soln.:
•
In the ring counter the outputs of FF-3 were connected directly to the inputs of FF-0 i.e., Q3 to J0, Q3 to K0.
•
Instead if the outputs are cross coupled to the inputs i.e., if Q3 is connected to K0 and Q3.5 connected to J0 then the circuit is called as twisted ring counter or Johnson's counter. 18
Examination Paper Solution (19)
•
The Johnson's counter is shown in figure 1.
Fig.1 : Twisted ring counter or Johnson counter.
• •
All the flip-flops are negative edge triggered, and clock pulses are applied to all of them simultaneously. The clear inputs of all the flip-flops are connected together and connected to an external clear signal. Note that all these clear inputs are active low inputs.
Operation : • Initially a short negative going pulse is applied to the clear input of all the flip-flops. This will reset all the flip-flops. Hence initially the outputs are, Q3 Q2 Q1 Q0 = 0 0 0 0 • But Q3 = 1 and since it is coupled to J0 it is also equal to 1. … Initially ∴ J0 = 1 and K0 = 0 On the first falling edge of clock pulse : • As soon as the first negative edge of clock arrives, FF-0 will be set. Hence Q0 will become 1. • But there is no change in the status of any other flip-flop. • Hence after the first negative going edge of the clock the flip-flop outputs are, Q3 Q2 Q1 Q0 = 0 0 0 1 On the second negative going clock edge : Before the second negative going clock edge, Q3 = 0 and Q3 = 1. Hence J0 = 1 and K0 = 1. Also Q0 = 1. Hence J1 = 1. • Hence as soon as the second falling clock edge arrives, FF-0 continues to be in the set mode and FF-1 will now set. Hence Q1 will become 1 and Q1 = 1. • There is no change in the status of any other flip-flop. • Hence after the second clock edge the outputs are, Q3 Q2 Q1 Q0 = 0 0 1 1 • Similarly after the third clock pulse, the outputs are Q3 Q2 Q1 Q0 = 0 1 1 1 • And after the fourth clock pulse, the outputs are Q3 Q2 Q1 Q0 = 1 1 1 1 Note that now Q3 = 0, i.e., J0 = 0 and K0 = 1. • Hence as soon as the fifth negative going clock pulse strikes, FF-0 will reset. But the outputs of the other flip-flops will remain unchanged. So after the fifth clock pulse, the outputs are, … after the 5th clock pulse Q3 Q2 Q1 Q0 = 1 1 1 0 • This operation will continue till we reach the all zero output state. (i.e., Q3 Q2 Q1 Q0 = 0 0 0 0) • The operation of Johnson's counter is summarised in table.
19
(20) S.E. − DLDA (CMPN)
CLEAR
CLK
Q3
Q2
Q1
Q0
State number
1 1 1 1 1 1 1 1
Initially ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓
0 0 0 0 1 1 1 1 0
0 0 0 1 1 1 1 0 0
0 0 1 1 1 1 0 0 0
0 1 1 1 1 0 0 0 0
1 2 3 4 5 6 7 8 1
Decimal equivalent 0 1 3 7 15 14 12 8 0
Note that there are 8 distinct states of output. In general we can say that the number of states of a Johnson's counter is twice the number of flip-flops used. Therefore, for 4 flip-flops, states will be 8, 5 flip-flops states will be 10 and for 8 flip-flops states will 16.
Waveforms for Johnson's counter The waveforms for a 4-bit Johnsons counter are shown in figure.
Fig.2: Waveforms of Johnson counter. 6. (a) Simplify using Quine McClusky method. f (A, B, C, D) = π m (0, 2, 3, 6, 7, 8, 9, 12, 13) Realize the equation using any universal gate. Soln.:
f (A, B, C, D)
= π m (0, 2, 3, 6, 7, 8, 9, 12, 13) = ∑ M (1, 4, 5, 10, 11, 14, 15)
(1) Group the min according to number's of 1's. Binary Representation Group Min A B C D 1 1 0 0 0 1 4 0 1 0 0 2 5 0 1 0 1 10 1 0 1 0 3 11 1 0 1 1 14 1 1 1 0 4 15 1 1 1 1 20
[10]
Examination Paper Solution (21)
(2) Group the min to form Point : Group Min
1−5 4−5 10 − 11 10 − 14 11 − 15 11 − 15
1 2 3
Binary Representation A B C D 0 0 1 − 0 1 0 − 1 0 1 − 1 1 0 − 1 1 1 − 1 1 1 −
ACD A BC
Prime implicant
(3) Group the minterm to form ______ . Group
Min
2
10−11−11−15 10−14−11−15
A 1 1
Binary Representation B C D 1 − − 1 − −
AC is prime implicants
(4) Collect all the prime implicant f (A, B, C, D) = ACD + ABC + AC (5) Prepare the PI table. PI term ACD
Decimal represent 1, 5
1
4
×
4, 5
A C
10, 11, 14, 15
10
11
14
15
×
×
×
×
× ×
ABC
5 ×
In the PI table find the column only 1 cross (×) and encircle these (×) points. Put () in front of the corresponding PI's. These () marked PI in above table on the essential prime implicants. Hence simplified expression for y, y (A, B, C D) = A C D + A BC + A C (6) Logic diagram : Step 1 : A
B C
D
y (A, B, C, D)
Step 2 : AND-OR-NOT into NAND-NAND logic Replace entry AND by NAND entry OR by bubbled OR entry inverts by NAND invert to get NAND-NAND logic. 21
(22) S.E. − DLDA (CMPN)
A
B C
D
y (A, B, C, D)
Step 3 : Draw circuit using only NAND gates : A B C D
y (A, B, C, D)
6. (b) Implement the following expression using 8 : 1 MUX. f (A, B, C, D) = ∑ m (0, 1, 5, 7, 9, 10, 15)
[10]
Soln.: Below figure shows the implementation of given Boolean function with 8 : 1 multiplexer. D0 D1 D2 D3 D4 D5 D6 D7 0 1 2 3 4 5 6 7 A A 8 9 10 11 12 13 14 15 1 A 0 0 0 1 A A A
1 0
D0 D1 D2 D3 8 : 1 D4 MUX D5 D6 D7
y
7. Write short notes on : [20] 7. (a) De Morgan's Theorems The two theorems suggested by De-Morgen and which are extremely useful in Boolean algebra are as follows : Theorem 1 : AB = A + B : NAND = Bubbled OR • This theorem states that the complement of a product is equal to addition of the complements. • This rule is illustrated fig.1. The left hand side (LHS) of this theorem represents a NAND gate with inputs A and B whereas the right hand side (RHS) of the theorem represents an OR gate with inverted inputs. 22
Examination Paper Solution (23)
•
This OR gate is called as "Bubbled OR". Thus we can state De-Morgans first theorem as, NAND = Bubbled OR
Fig.1 : Illustration of De-Morgan's first theorem. This theorem can be verified by writing a truth table as shown in fig.2. A 0 0 1 1
B 0 1 0 1
AB 1 1 1 0
A 1 1 0 0
B 1 0 1 0
A+B 1 1 1 0
LHS
RHS AB + A + B Fig.2 : Verification of the theorem AB = A + B Theorem 2 : A + B = A.B : NOR = Bubbled AND • The LHS of this theorem represents a NOR gate with inputs A and B whereas the RHS represents an AND gate with inverted inputs. • This AND gate is called as "Bubbled AND". Thus we can state De-Morgan's second theorem as : NOR = Bubbled AND
Fig.3 : Illustration of De-Morgan's second theorem. •
This theorem can be verified by writing a truth table for both the sides of the theorem statement. This truth table is shown in fig.4, which shows that LHS = RHS. A 0 0 1 1
B 0 1 0 1
A+B 1 0 0 0
A 1 1 0 0
B 1 0 1 0
A.B 1 0 0 0
LHS
RHS A + B = A.B Fig.4 : Truth table to De-Morgan's theorem
EX-OR using NAND : • The Boolean expression for EX-NOR is Y = A B = AB + AB = X + Z • Taking double inversion of RHS, Y = X + Z = X.Z
… De Morgan's theorem
∴ Y = (A B) . (AB) • This is the required expression for EX-NOR in of only NAND gates. Figure shows the Fig.: EX-NOR using only NAND gates. realization. Refer figure for implementation. 23
(24) S.E. − DLDA (CMPN)
Description : • The select inputs S1 and S0 of the multiplexers 1, 2, 3 and 4 are connected together. • The select inputs S3 and S2 are applied to the select inputs S1 and S0 of MUX-5. • The outputs Y1, Y2, Y3, Y4 are applied to the data inputs D0, D1, D2 and D3 of MUX-5 as shown in figure.
Fig.: 16 : 1 multiplexer using 4 : 1 multiplexers The operation can be summarized using table. S3 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1
Select Inputs S2 S1 0 0 0 0 0 1 0 1 1 0 1 0 1 1 1 1 0 0 0 0 0 1 0 1 1 0 1 0 1 1 1 1
S0 0 1 0 1 0 1 0 1 0 1 0 1 0 1 0 1
Y1 D0 D1 D2 D3 D0 D1 D2 D3 D0 D1 D2 D3 D0 D1 D2 D3
Mux. Outputs Y2 Y3 Y4 D4 D8 D12 D3 D9 D13 D6 D10 D14 D7 D11 D15 D4 D8 D12 D3 D9 D13 D6 D10 D14 D7 D11 D15 D4 D8 D12 D3 D9 D13 D6 D10 D14 D7 D11 D15 D4 D8 D12 D3 D9 D13 D6 D10 D14 D7 D11 D15
Final output Y D0 D1 D2 D3 D4 D5 D6 D7 D8 D9 D10 D11 D12 D13 D14 D15
S3 S2 = 00 ∴ MUX − 5 selects Y1 S3 S2 = 01 ∴ MUX − 5 selects Y2 S3 S2 = 10 ∴ MUX − 5 selects Y3 S3 S2 = 11 ∴ MUX − 5 selects Y4
7. (b) NOR as universal gate Similar to NAND gate, the NOR gate is also a universal gate, since it can be used to generate the NOT, AND, OR and NAND functions. 24
Examination Paper Solution (25)
NOT Function : An inverter can be made from a NOR gate by connecting all of the inputs together and creating, in effect, a single common input, as shown in Fig. 1.
Fig. 1 : NOT function using NOR gate OR Function : An OR function can be generated using only NOR gates. It can be generated by simply inverting output of NOR gate; i.e. A + B = A + B. Fig. 2 shows the two input OR gate using NOR gates.
Fig. 2 : OR function using NOR gates A
B
A+B
0 0 1 1
0 1 0 1
0 1 1 1
A
B
0 0 0 1 ≡ 1 0 1 1 Table : Truth table
A+B 1 0 0 0
A+B 0 1 1 1
AND Function : AND function is generated using only NOR gates as follows : We know that Boolean expression for AND gate is Y = A. B =
A.B
=
A+B
Rule 9 : [ A = A ] DeMorgan’s Theorem 2
The above equation is implemented using only NOR gates as shown in the Fig. 3.
Fig. 3 : AND function using NOR gates
25
(26) S.E. − DLDA (CMPN)
Note : Bubble at the input of NOR gate indicates inverted input. A
B
A+B
A
B
0 0 1 1
0 1 0 1
0 0 0 1
0 0 1 1
0 1 0 1
≡
A+B 1 1 1 0
A+B 0 0 0 1
Table : Truth table NAND Function : NAND function is generated using only NOR gates as follows : We know that Boolean expression for NAND gate is Y = =
A.B A+B
=
A+B
DeMorgan’s Theorem 1 Rule 9 : [ A = A ]
The above equation is implemented using only NOR gates, as shown in the Fig. 8.
Fig. 8 : NAND function using only NOR gates
A
B
A+B
0 0 1 1
0 1 0 1
1 1 1 0
A
B
A+B
0 0 1 0 1 1 ≡ 1 0 1 1 1 0 Table : Truth table
A+B 0 0 0 1
A+B 1 1 1 0
7. (c) ALU Arithmetic Logic Unit (ALU) : • ALU is a very widely used and popular combinational circuit. • It is capable of performing the arithmetic as well as the logic operations. • ALU is the heart of any microprocessor. • Figure 1 shows the block diagram of ALU IC 74181, Table 1 gives the pin description and Figure 2 gives its pin configuration. • 74181 is a 24-pin IC dual in line (DTP) package. • A (A0 − A3) and B (B0 − B3) are the two 4 bit variables. 26
Examination Paper Solution (27)
Table 1: Pin description of 74181 Pin Name Description Operated inputs A0 − A3 Operand inputs B0 − B3 Function select inputs S0 − S3 M Mode control input Carry input (active low) Cn F0 − F3 A=B G P Cn + 4
Function output Comparator output (equality output) Carry generate output Carry propagate otput Carry output (active low)
Fig. 1 : Block diagram of ALU IC 74181 • • • • •
•
•
Fig. 2 : Pin configuration of the ALU IC 74181
It can perform a total of 16 arithmetic operations which includes addition, subtraction, compare and double operations. It provides many logic operations such as AND, OR, NOR, NAND EX-OR, compare etc on the two four bit variables. 74181 is a high speed 4 bit parallel ALU. It is controlled by four function select inputs S0 − S3. These lines can select 16 different operations for one mode (arithmetic) and 16 another operations for the other mode (logic). M is the mode control input. It decides the mode of operation to be either arithmetic or logic. M=0 For arithmetic operations M =1 For logic operations G and P outputs are used when a number of 74181 circuits are to be used in cascade alongwith 74182, the look ahead carry generator circuit to make the arithmetic operations faster. When mode control input is high (M = 1), then the logic operations are performed on the individual bits and all the internal carries are enabled. 27
(28) S.E. − DLDA (CMPN)
• • • •
•
When mode control input is low (M = 0), the arithmetic operations are performed on the two 4-bit words and all the internal carriers are enabled. IC 74181 incorporates full internal carry lookahead. This enhances its speed of operation to a great extent. It provides a ripple carry between the devices using the Cn+4 output. (see cascading of two 74181s). Or for exploiting the option of carry lookahead between the packages, we have to use the P (carry propagate) and G (carry generate) outputs. This option should be used only when the speed requirements are stringent. If low speed of operation is acceptable, the ripple carry operation using Cn+4 and Cn should be exercised.
A = B Output : 1. A = B output indicates the logical equality of the two operands. This output goes HIGH when the unit is in the subtract mode and A = B. 2. This output also goes high when all the four “Function outputs” are HIGH. 3. It is possible to wire AND the A = B outputs when more than one 74181s are being used. The wire ANDing becomes possible because A = B is an open collector output. This enables us to compare words which are longer than 4-bits. Function tables : (If the question is 10 marks, then mention the functional table in details) • Table 2(a) shows the function table for IC 74181. It is valid for the active high operands and active high outputs, and with C n = 1 i.e. no carry. Table 2(a): Function table for IC 74181 with active high data and Cn = 1 (no carry) Function Select Inputs
S3 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1
• •
S2 0 0 0 0 1 1 1 1 0 0 0 0 1 1 1 1
S1 0 0 1 1 0 0 1 1 0 0 1 1 0 0 1 1
S0 0 1 0 1 0 1 0 1 0 1 0 1 0 1 0 1
Active high data and Cn = 1 Logic operations (M = 1) Arithmetic operations (M = 0) F=A F = A (Inversion) F=A+B F = A + B (NOR) F = A.B F=0 F = AB (NAND) F = B (Invert) F = A ⊕ B (EXOR) F= AB F= A+B F = A ⊕ B (EXNOR) F=B F = AB (AND) F = logic 1 F=A+ B F = A + B (OR) F=A
F=A+ B F = minus 1 (2’s comp) F = A plus A B F = (A + B)plus A B F = A minus B minus 1 F = A B minus 1 F = A plus AB F = A plus B F = (A + B ) plus AB F = AB minus 1 F = A plus A* F = (A + B) plus A F = (A + B ) plus A F = A Minus 1
Each bit is shifted to the next more significant position. The arithmetic operations listed in function Table 2(a), correspond to no carry input. They will get modified if the carry input is present as shown in Table 2(b). It is possible to use IC 74181 with either active high inputs or with active low inputs. With active low inputs the device produces active low outputs and with active high inputs it produces active high outputs. 28
Examination Paper Solution (29)
• The function table for active low inputs and outputs has been given in Table 2(b). Table 2(b) : Function table for IC 74181 with active low data and C n = 0 (with carry).
Function Select Inputs S3 0 0 0 0 0
S2 0 0 0 0 0
S1 0 0 1 1 1
S0 0 1 0 1 1
0
1
0
1
Active Low data and Cn = 0 Logic operations M = 0 Arithmetic operations M = 1 F = A minus 1 F = A (inversion) F = AB minus 1 F = AB (NAND) F= A+B F=1 F = A+B
F = A B minus 1 F = minus 1 F = A plus (A + B )
F = B (inversion)
F = AB plus (A + B )
7. (d) TTL vs COMS logic family : High Speed CMOS The high speed CMOS devices have silicon gates instead of metal gates. This improved version of CMOS ICs has higher switching speeds and higher output current capacity. The high speed CMOS devices are pin compatible and functionally equivalent to TTL ICs with the same device numbers.
Comparison of CMOS and TTL Families Parameter
VIH (min) VIL (max) VOH (min) VOL (max) VNH VNL Propagation Delay (ns) Power per gate (mW) Speed power product or figure or merit Input connection Power dissipation Fan out Noise
CMOS
TTL
Silicon gate CMOS 3.5 1.0 4.9 0.1 1.4 0.9
Metal gate CMOS 3.5 1.5 4.95 0.05 1.45 1.45
74
74LS
74AS
74ALS
2.0 0.8 2.4 0.4 0.4 0.4
2.0 0.8 2.7 0.5 0.7 0.3
2.0 0.8 2.7 0.5 0.7 0.3
2.0 0.8 2.7 0.4 0.7 0.4
8
105
10
10
1.5
4
0.17
0.1
10
2
8.5
1
1.4 pJ
10.5 pJ
100 pJ
20 pJ
12.8 pJ
4 pJ
Input cannot be left open. It has to be connected to 0, or to VDD or to the another input. Very less, but increases with increase in switching speed Fan−out is more than TTL typically 50 More susceptible to noise
Input can be left open. It is treated as logic high input. More than CMOS. It is constant, does not depend on switching speed. Fan−out for TTL is 10. Less susceptible to noise.
29
Related Documents 2w1qw
Dlda - M_09 w6l55
December 2019 94
Fisica M09 Aluno 4r2l3o
August 2022 0More Documents from "babu" 6c6z71
Dlda - M_09 w6l55
December 2019 94
Presentation On u 6o4g46
November 2019 85
Dnv Standard 6b561q
April 2020 30
As,nc,nfkasjdghjldghhxfghsdgfkdgsfj 3l5v6f
June 2021 0
Asics Gel Kayano 23 3li1z
December 2019 69
