DIN 2501 PN10 PLATE FLANGE SLIP ON PLATE 1. Standard: DIN2501 2. Type: Slip on plate flange 3. Pressure: PN10 4. Size: DN15 – DN500, larger Sizes available on request 5. Raw Material: P245GH, P250GH, P265GH, C22.8, S235JR 6. Process: Forged



7. Basic requirements for Material and Flange

 STANDARD FLANGE DIN 2501 FOR SOLDERING OR WELDING PN 10 Nominal Pipe Size

Diameter

Flange Flange

Thk of

Dia of Bolt

Dia

I.D

Flanges

Cirlce

No. of

Weight

Dia of Bolt Holes

PLATE

BLIND

DN

Pipe

D

D5

B

K

holes

D2

KG

KG

15

21.30

95

22.00

14

65

4

14

0.67

0.71

20

26.90

105

27.60

16

75

4

14

0.93

1.01

25

33.70

115

34.40

16

85

4

14

1.11

1.23

32

42.40

140

43.10

16

100

4

18

1.62

1.81

40

48.30

150

49.00

16

110

4

18

1.85

2.09

50

60.30

165

61.10

18

125

4

18

2.46

2.88

65

76.10

185

77.10

18

145

4

18

2.99

3.65

80

88.90

200

90.30

20

160

8

18

3.61

4.61

100

114.30

220

115.90

20

180

8

18

3.99

5.65

125

139.70

250

141.60

22

210

8

18

5.41

8.13

150

168.30

285

170.50

22

240

8

22

6.55

10.44

175

193.70

315

196.10

24

270

8

22

8.42

200

219.10

340

221.80

24

295

12

22

8.97

16.48

250

273.00

405

276.20

26

355

12

26

12.76

23.99

300

323.90

460

327.60

28

410

12

26

16.60

30.73

350

355.60

520

359.70

30

470

16

26

24.08

42.56

400

406.40

580

411.00

32

525

16

30

30.20

60.68

450

457.00

640

462.30

38

585

20

30

41.67

71.74

500

508.00

715

513.60

38

650

20

33

52.87

96.4

600

610.00

840

616.50

42

770

20

36

77.58

145.6

700

711.00

910

716.00

44

840

24

36

77.13

800

813.00

1025

818.00

50

950

24

39

106.35 Email: [email protected] Web: www.glenflange.com

900

914.00

1125

920.00

54

1050

28

39

125.39

1000

1016.00

1255

1022.00

60

1170

28

42

177.99
