Denon Rcd M39dab Instructions 38131w

Preparations Operations

RCD-M39 CD RECEIVER

DISC

Informations

Owner’s Manual

n SAFETY PRECAUTIONS

CAUTION:

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO -SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The exclamation point within an equilateral triangle is intended to alert the to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

WARNING:

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

13. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. 14. Batteries shall not be exposed to excessive heat such as sunshine, fire or the like.

CAUTION: CLASS 1 ,, LASER PRODUCT

HOT SURFACE. DO NOT TOUCH.

,,

ADVARSEL: VAROITUS! VARNING:

USYNLIG LASERSTRÅLING VED ÅBNING, NÅR SIKKERHEDSAFBRYDERE ER UDE AF FUNKTION. UNDGÅ UDSAETTELSE FOR STRÅLING. LAITTEEN KÄYTTÄMINEN MUULLA KUIN TÄSSÄ KÄYTTÖOHJEESSA MAINITULLA TAVALLA SAATTAA ALTISTAA KÄYTTÄJÄN TURVALLISUUSLUOKAN 1 YLITTÄVÄLLE NÄKYMÄMTTÖMÄLLE LASERSÄTEILYLLE. OM APPARATEN ANVÄNDS PÅ ANNAT SÄTT ÄN I DENNA BRUKSANVISNING SPECIFICERATS, KAN ANVÄNDAREN UTSÄTTAS FÖR OSYNLIG LASERSTRÅLNING SOM ÖVERSKRIDER GRÄNSEN FÖR LASERKLASS 1.

Hot surface mark

The top surface over the internal heat sink may become hot when operating this product continuously. Do not touch hot areas, especially around the “Hot surface mark” and the top .

CAUTION:

USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE. THIS PRODUCT SHOULD NOT BE ADJUSTED OR REPAIRED BY ANYONE EXCEPT PROPERLY QUALIFIED SERVICE PERSONNEL.

ATTENZIONE: QUESTO APPARECCHIO E’ DOTATO DI DISPOSITIVO OTTICO CON RAGGIO LASER. L’USO IMPROPRIO DELL’APPARECCHIO PUO’ CAUSARE PERICOLOSE ESPOSIZIONI A RADIAZIONI!

DISC

I

• DECLARATION OF CONFORMITY We declare under our sole responsibility that this product, to which this declaration relates, is in conformity with the following standards: EN60065, EN55013, EN55020, EN61000-3-2 and EN61000-3-3. Following the provisions of Low Voltage Directive 2006/95/EC and EMC Directive 2004/108/EC, the EC regulation 1275/2008 and its frame work Directive 2009/125/EC for Energy-related Products (ErP). DENON EUROPE Division of D&M GmbH An der Kleinbahn 18, Nettetal, D-41334

A NOTE ABOUT RECYCLING: This product’s packaging materials are recyclable and can be reused. Please dispose of any materials in accordance with the local recycling regulations. When discarding the unit, comply with local rules or regulations. Batteries should never be thrown away or incinerated but disposed of in accordance with the local regulations concerning battery disposal. This product and the supplied accessories, excluding the batteries, constitute the applicable product according to the WEEE directive.

Informations

CLASS 1 LASER PRODUCT LUOKAN 1 LASERLAITE KLASS 1 LASERAPPARAT

Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat s, stoves, or other apparatus (including amplifiers) that produce heat. 9. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. 10. Only use attachments/accessories specified by the manufacturer. 11. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/ apparatus combination to avoid injury from tip-over. 12. Unplug this apparatus during lightning storms or when unused for long periods of time.

To completely disconnect this product from the mains, disconnect the plug from the wall socket outlet. The mains plug is used to completely interrupt the power supply to the unit and must be within easy access by the .

Operations

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

1. 2. 3. 4. 5. 6. 7. 8.

CAUTION:

Preparations

CAUTION

RISK OF ELECTRIC SHOCK DO NOT OPEN

IMPORTANT SAFETY INSTRUCTIONS

n CAUTIONS ON INSTALLATION

n NOTES ON USE

z

z

z Wall

zz For proper heat dispersal, do not install this unit in a confined space, such as a bookcase or similar enclosure. • More than 0.3 m is recommended. • Do not place any other equipment on this unit.

Informations

DISC

z

Operations

• Avoid high temperatures. Allow for sufficient heat dispersion when installed in a rack. • Handle the power cord carefully. Hold the plug when unplugging the cord. • Keep the unit free from moisture, water, and dust. • Unplug the power cord when not using the unit for long periods of time. • Do not obstruct the ventilation holes. • Do not let foreign objects into the unit. • Do not let insecticides, benzene, and thinner come in with the unit. • Never disassemble or modify the unit in any way. • Ventilation should not be impeded by covering the ventilation openings with items, such as newspapers, tablecloths or curtains. • Naked flame sources such as lighted candles should not be placed on the unit. • Observe and follow local regulations regarding battery disposal. • Do not expose the unit to dripping or splashing fluids. • Do not place objects filled with liquids, such as vases, on the unit. • Do not handle the mains cord with wet hands. • When the switch is in the OFF (STANDBY) position, the equipment is not completely switched off from MAINS. • The equipment shall be installed near the power supply so that the power supply is easily accessible. • Do not keep the battery in a place exposed to direct sunlight or in places with extremely high temperatures, such as near a heater.

Preparations

WARNINGS

II

Thank you for purchasing this DENON product. To ensure proper operation, please read this owner’s manual carefully before using the product. After reading them, be sure to keep them for future reference.

Accessories Check that the following parts are supplied with the product.

Contents Getting started···············································································1 Accessories···················································································1 Features·························································································2 Cautions on handling·····································································2

Connections····················································································4 Connecting the speakers·······························································4 Connecting an iPod or USB memory device to the USB port········5 Connecting a TV············································································6 Connecting an antenna··································································6 Connecting the power cord···························································7

Part names and functions···························································29 Front ···················································································29 Display·························································································30 Rear ····················································································30 Remote control unit·····································································31 Other information········································································34 Discs····························································································34 Explanation ········································································35 Troubleshooting···········································································35 Specifications···············································································37

q Getting Started......................................................................... 1 w CD-ROM (Owner’s manual)..................................................... 1 e Safety Instructions................................................................... 1 r Service network list.................................................................. 1 t Remote control unit (RC-1162)................................................. 1 y R03/AAA batteries.................................................................... 2 u q Power cord: for continental model only............................... 1

w Power cord: for RCD-M39DAB only..................................... 1

i FM indoor antenna (for continental model only)....................... 1 o DAB/FM indoor antenna (for RCD-M39DAB only).................... 1 t

u

u

q

w

Basic operation···············································································9 Preparations···················································································9 Setting the current time (24-Hour Display)··································10 Operations possible during playback···········································11 Playing CDs·················································································12 Listening to FM broadcasts·························································14 Listening to DAB/DAB+ (for RCD-M39DAB only)························18 Listening to AUX··········································································19 Advanced operation·····································································20 Preparations·················································································20 Playing of MP3 and WMA files····················································21 Playing an iPod············································································23 Playing a USB memory device·····················································24 Setting the alarm·········································································25 Other functions············································································27

DISC

i

1

o

Informations

Operations·················································································8

Operations

Preparations··············································································3

Informations···········································································28

Preparations

Getting started

Features

Cautions on handling

Equipped with a 30 W + 30 W (6 Ω) high-quality amplifier circuits.

Direct Play for iPod® and iPhone® via USB

Music data from an iPod can be played back if you connect the USB cable supplied with the iPod via the USB port of this unit, and also an iPod can be controlled with the Remote control unit for this unit.

Playback of MP3 and WMA files

s playback of discs and USB memory devices on which MP3 or WMA files are recorded. The unit’s display can display the title of the track and the name of the artist of the current track. Usable characters “Switching the display” (vpage 13, 24)

Low standby power consumption

Designed with the environment in mind, the unit consumes just 0.3 W while in standby mode.

The board and circuit configuration has been redesigned to achieve lower impedance. Since stable current is supplied to the power amp and other sections, it is possible to realize as much as 30 watts of power.

Remote control unit

This unit is shipped with a remote control unit that has large buttons for frequently used functions, allowing you to quickly find the desired function.

“Simple & Straight” circuit design for sound purity and free of coloration

DISC

• About care • Wipe the cabinet and control clean with a soft cloth. • Follow the instructions when using a chemical cleaner. • Benzene, paint thinner or other organic solvents as well as insecticide may cause material changes and discoloration if brought into with the unit, and should therefore not be used.

2

Informations

DENON’s popular M series gives you high sound quality based on the “simple & straight” concept. Circuitry is uncomplicated, signal paths are short, and all adverse influences on sound quality have been minimized. This unit also provides the “Auto standby mode”, where it goes into the standby state when there is no operation for 30 minutes.

Operations

Weight and Dramatic sound

• Before turning the power switch on Check once again that all connections are correct and that there are no problems with the connection cables. • Power is supplied to some of the circuitry even when the unit is set to the standby mode. When leaving home for long periods of time, be sure to unplug the power cord from the power outlet. • Proper ventilation If the unit is left in a room full of smoke from cigarettes, etc., for long periods of time, the surface of the optical pickup may get dirty, preventing it from receiving signals properly. • About condensation If there is a major difference in temperature between the inside of the unit and its surroundings, condensation may form on parts inside the unit, causing it to fail to operate properly. If this happens, let the unit sit for an hour or two with the power turned off and wait until there is little difference in temperature before using the unit. • Cautions on using mobile phones Using a mobile phone near this unit may result in noise. If that occurs, move the mobile phone away from the unit when it is in use. • Moving the unit Be sure to remove a disc, turn off the power and unplug the power cord from the power outlet. Next, disconnect the cables connected to other system units before moving the unit.

Preparations

High quality amplifier stressing sound quality

Preparations

Here, we explain the connection methods for this unit.

Preparations

Preparations F Connecting the speakers vpage 4 F Connecting a TV vpage 6 F Connecting an antenna vpage 6

Operations

F Connecting an iPod or USB memory device to the USB port vpage 5

F Connecting the power cord vpage 7 Informations

DISC

3

NOTE • Do not plug in the power cord until all connections have been completed. • When making connections, also refer to the owner’s manual of the other components. • Be sure to connect the left and right channels properly (left with left, right with right). • Do not bundle power supply cords together with connection cables. Doing so can result in humming or noise.

Connecting the speakers Connecting the speaker cables

Subwoofer with built-in amplifier

Carefully check the left (L) and right (R) channels and + (red) and – (black) polarities on the speakers being connected to the unit, and be sure to connect the channels and polarities correctly.

Speaker SC-M39

(R)

(L)

IN

w

Subwoofer cable

q

w

q

the speaker terminal 2 Turn counterclockwise to loosen it.

Optical cable L

L

R

R

NOTE • Disconnect this unit’s power plug from the power outlet before connecting the speakers. Also, turn off the subwoofer. • Use speakers with an impedance of 6 to 16 Ω. The protection circuit may be activated if speakers with an impedance other than specified are used. • Connect the speaker cables so they do not stick out of the speaker terminals. The protection circuit may be activated if the wires touch the rear or if the + and – sides touch each other (vpage 35 “Protection circuit”). • Never touch the speaker terminals while the power supply is connected. Doing so could result in electric shock.

DISC

4

Informations

the speaker cable’s core wire to 3 Insert all the way into the speaker terminal. the speaker terminal clockwise 4 Turn to tighten it.

Speaker cable

Audio cable

either twist the core wire tightly or apply solder to it.

Operations

off about 10 mm of sheathing 1 Peel from the tip of the speaker cable, then

Cables used for connections Audio cable (sold separately)

Preparations

Connections

Connecting an iPod or USB memory device to the USB port • You can enjoy music stored on an iPod or USB memory device. • For operating instructions see “Playing an iPod” (vpage  23) or “Playing a USB memory device” (vpage 24).

Preparations

ed iPod models • iPod classic

Cables used for connections To connect an iPod to this unit, use the USB cable supplied with the iPod. iPod USB memory device

Operations

or

• iPod nano

Informations

• iPod touch

DENON does not guarantee that all USB memory devices will operate or receive power. When using a portable USB connection type HDD of the kind to which an AC adapter can be connected to supply power, use the AC adapter.

NOTE • USB memory devices will not work via a USB hub. • It is not possible to use this unit by connecting the unit’s USB port to a PC via a USB cable. • Do not use an extension cable when connecting a USB memory device. This may cause radio interference with other devices. • When connecting an iPhone to this unit, keep the iPhone at least 20 cm away from this unit. If the iPhone is kept closer to this unit and a telephone call is received by the iPhone, noise may be output from this device. • If the iPod is connected using an iPod cable (commercially available) that is longer than 2 m, sound may not be played correctly. In this case, use a genuine iPod cable, or a cable that is shorter than 1 m.

• iPhone

(as of June 2012)

DISC

5

Connecting an antenna

Connecting a TV TV AUDIO AUDIO OUT L R

L

OPTICAL OUT

FM (for continental model only)

DAB/FM (for RCD-M39DAB only)

• Connect the FM antenna included with the unit to enjoy listening to radio broadcasts. • After connecting the antenna and receiving a broadcast signal (vpage  14 “Listening to FM broadcasts”), use tape to fix the antenna in a position where noise is the lowest.

nnConnecting the DAB/FM indoor antenna DAB/FM indoor antenna (Supplied)

FM indoor antenna (Supplied)

R

Operations

or L

DAB station reception (vpage 18.

Preparations

• Select the connector to use and connect the device. • To listen to TV audio through this unit, use the optical digital connection.

R

Informations

NOTE NOTE • Other digital audio signals than 2 channel linear PCM cannot be input through DIGITAL IN (OPTICAL) connector of this unit. • When you try to input digital audio signals other than 2 channel linear PCM to this unit, set the digital audio output setting of the TV to 2 channel PCM. For details, see the operating instructions of the TV.

DISC

• Do not connect two FM antennas simultaneously. • If you are unable to receive a good broadcast signal, we recommend installing an outdoor antenna. Inquire at the retail store where you purchased the unit for details.

6

Connecting the power cord Preparations

For continental model only

Operations

Power cord (Supplied)

To household power outlet (AC 230 V, 50/60 Hz)

Informations

For RCD-M39DAB only

Power cord (Supplied)

To household power outlet (AC 230 V, 50/60 Hz)

NOTE • Only use the supplied power cord. • Be sure the power cord is unplugged from the power outlet before connecting or disconnecting it to the AC IN.

DISC

7

Operations

Here, we explain functions and operations that let you make better use of this unit.

Preparations

Operations F Basic operation vpage 9

Operations

F Advanced operation vpage 20

Informations

DISC

8

nn Turning the power on (vpage 9) nn Before playing a disc (vpage 9) nn Turning the power off (vpage 9) nn Setting the current time (24-Hour Display) (vpage 10)

nn Advanced operation (vpage 20)

Before playing a disc

Press POWER X.

1 Press POWER X. CD to set the input source 2 Press to “DISC”.

• The power turns on. Press again to set the power to standby. • Power indicator Normal standby........................Off Power on..................................Green Alarm standby..........................Orange iPod charge standby.................Red

When the power is in the standby mode, pressing one of the following buttons also turns this unit on. • X, 5 or 1/3z on the main unit • CD, TUNER, iPod/USB, DIGITAL IN, ANA or 1/3z on the remote control unit zzIf a disc has already been inserted, playback starts.

NOTE • Power continues to be supplied to some of the circuitry even when the power is in the standby mode. When leaving home for long periods of time, unplug the power cord from the power outlet. • Be sure to stop playback before turning the power off.

If no disc is loaded “NO DISC” is displayed.

3 Insert a disc (vpage 34). • Press 5 on the main unit to open/close the disc tray. • The disc tray also closes when 1/3 is pressed.

NOTE Do not place any foreign objects in the disc tray. Doing so could damage it.

Turning the power off Press POWER X.

The power indicator turns off, and so does the power.

nnCompletely turning off the power

Unplug the power cord from the wall outlet. • Note that the time setting is cleared when the power cord is unplugged from the outlet. • The settings made for the various functions may be cleared if the power cord is left unplugged from a power outlet for an extended period of time.

DISC

9

NOTE • Be sure to stop playback before turning the power off. • Make sure that the disc tray is completely shut before turning off the power. • Do not push the disc tray in by hand when the power is turned off. Doing so could damage the set.

Informations

nn Playing CDs (vpage 12) nn Listening to FM broadcasts (vpage 14) nn Listening to DAB/DAB+ (for RCD-M39DAB only) (vpage 18)

Turning the power on

Operations

nn Selecting the input source (vpage 11) nn Adjusting the master volume (vpage 11) nn Adjusting the tone (vpage 11) nn Turning off the sound temporarily (vpage 11) nn Switching the display’s brightness (vpage 11)

Preparations

Preparations

Basic operation

Setting the current time (24-Hour Display) Press POWER X to turn the 1 power on. 2 Press SETUP. Various types of setting menus are displayed.

select “CLOCK

press ENTER or p.

Press CLOCK. Press once more and the display returns to its original condition.

nnChecking the current time when the power is set to standby Press CLOCK. The current time is displayed for 10 seconds.

NOTE

SETUP CLOCK SETUP

The time cannot be set when in the standby mode. Turn on the power first.

Operations

Use ui to 3 SETUP”, then

nnChecking the current time when the power is on

Preparations

GExampleH Setting the current time to 10:15 am

4 Use ui to set the “hours”. CLOCK

Informations

SETUP 10:00

5 Press ENTER or p. 6 Use ui to set the “minutes”. The “minutes” display flashes.

CLOCK

SETUP 10:15

7 Press ENTER or p.

The current time is set, and the normal display reappears.

DISC

10

Operations possible during playback Adjusting the tone

Turning off the sound temporarily

Press CD, TUNER, iPod/USB, DIGITAL IN or ANA to select

SDB TONE to select the 1 Press tone parameter to be adjusted.

Press MUTE :.

the input source.

SDB

The desired input source can be selected directly.

S. DIRECT

nnUsing the button on the main unit

Press SOURCE. • Every time you press SOURCE, the input source switches in the following order. iPod/USB

DIGITAL IN

• To make other tone adjustments at this time, press SDB TONE. • If no operation is performed for 5 seconds, the adjustment is retained and the normal display reappears. SDB

BASS

The volume level is displayed.

ON

–

OFF

Adjusts the bass sound. GVariable rangeH

–10dB

–

+10dB

GVariable rangeH

–10dB

–

+10dB

BALANCE Adjusts the left/right volume balance.

GVariable rangeH

L06

–

CENTER

–

R06

S.DIRECT Plays back a disc using the SOURCE DIRECT mode. During the SOURCE DIRECT mode, the audio signals by the tone control circuits (SDB/BASS/TREBLE/ BALANCE), the music reproduction is more faithful to the original sound.

GAdjustable rangeH VOLUME 00 – 49, VOLUME MAX

You can also adjust the volume this by turning VULUME on the main unit.

DISC

GDefault settingsH • SDB........................................OFF • BASS...................................... 0dB • TREBLE.................................. 0dB • BALANCE........................CENTER • S.DIRECT...............................OFF

11

Switching the display’s brightness Press DIMMER. 100 %

70 %

Off

40 %

• The display’s brightness switches each time the button is pressed.

TREBLE Adjusts the treble sound.

To cancel, press MUTE : again. (The mute mode is also canceled when VOLUME df is pressed.)

Informations

Use VOLUME df to adjust the volume.

Emphasizes the bass sound when the Super Dynamic Bass (SDB) function is set to ON. GSelectable modesH



Adjusting the master volume

BALANCE

Use o p to adjust the SDB, 2 BASS, TREBLE or BALANCE.

TUNER ANA

TREBLE

Operations

You can also use the following operation to select an input source.

DISC

BASS

“MUTE ON” is displayed.

Preparations

Selecting the input source

Playing CDs Before you start this operation, perform the procedure in “Before playing a disc” (vpage 9).

Playing repeatedly (Repeat playback)

Playing random order (Random playback)

Press REPEAT.

1 In the stop mode, press RANDOM. 2 Press 1/3.

Playback in the respective repeat mode starts.

Press 1/3.

The tracks start playing in random order.

The 1 indicator lights and playback begins.

nnStopping playback

Press 2. • You can also perform this operation by pressing 2 (for continental model only) or BAND/2 (for RCD-M39DAB model only) on the main unit.

All-track repeat

Operations

Single-track repeat

nnPlaying of MP3 and WMA files (vpage 21)

The “RANDOM” indicator lights.

Repeat off (indicator turns off) 1 (Single-track repeat)

Only 1 track plays repeatedly.

ALL (All-track repeat)

All tracks play repeatedly.

Repeat off (indicator turns off) Normal playback resumes.

Informations

nnStopping playback temporarily Press 1/3. 3 is displayed. • To resume playback, press 1/3.

The repeat playback mode is canceled if you open the disc tray or turn off power.

nnFast-forwarding and fast-reversing (searching)

If REPEAT is pressed during random playback, after the current session of random playback is finished, another session in a different order of tracks starts.

During playback, press and hold in 6, 7.

nnMoving to the beginning of tracks (skipping)

During playback, press 8, 9. • The disc skips as many tracks as times the button is pressed. • When you press reverse once, playback returns to the beginning of the current track. • You can also perform this operation by pressing 8/–, +/9 on the main unit.

NOTE Random play cannot be set or canceled during playback.

nnCanceling random playback While stopped, press RANDOM. The “RANDOM” indicator turns off.

nnTo play the desired track

Press 0 – 9, +10 to select the track. GExampleH Track 4 : 4 GExampleH Track 12 : +10, 2 GExampleH Track 20 : +10, +10, 0

DISC

Preparations

Playing CDs

The random playback mode is canceled if you open the disc tray or turn off power.

12

Playing CDs

Up to 25 tracks can be programmed.

the stop mode, press 1 InPROGRAM .

nnChecking the order of the programmed tracks

In the stop mode, press 9. The track numbers are displayed in the programmed order each time the button is pressed.

nnTo clear the last track programmed

“PGM” is displayed.

GExampleH To program tracks 3, 12, 7 to play in that order: Press PROGRAM, 3, +10, 2, 7.

3 Press 1/3.

Playback starts in the programmed order.

nnTo clear one programmed track at a time

In the stop mode, press 9 to select the track to be cleared, then press CLEAR.

Elapsed time of current track

Remaining time of current track

Remaining time for all remaining tracks • The display switches each time the button is pressed.

nnClearing the all programmed track In the stop mode, press PROGRAM.

13

Informations

• If REPEAT is pressed during program playback, the tracks are played repeatedly in the programmed order. • If RANDOM is pressed during program playback, the programmed tracks are played in random order. • The program is cleared when the disc tray is opened or the power is turned off.

DISC

Press INFO.

Operations

2 Use 0 – 9, +10 to select the tracks.

In the stop mode, press CLEAR. The last track programmed is cleared each time the button is pressed.

Switching the display

Preparations

Playing tracks in the desired order (Program playback)

Listening to FM broadcasts Connect the antenna beforehand (vpage 6).

1

Press TUNER to reception band.

select

the

• When “FM AUTO” is selected: “AUTO” is displayed. • When “FM MONO” is selected: “MONO” is displayed. FM AUTO FM MONO zzRCD-M39DAB only

• You can also perform this operation by pressing BAND/2 on the main unit. (For RCD-M39DAB only) • When the reception band mode is set to “FM AUTO”, the “ST” indicator lights when a stereo broadcast is tuned in. When a station is received, the “TUNED” indication will light.

If the signal is weak and stable stereo reception is not possible, select “FM MONO” to receive in monaural.

nnAuto presetting with the remote control unit

Names of up to 8 characters can be input.

in the preset channel you 1 Tune want to name. 2 Press ENTER twice.

The display switches to the station name input display.

Perform this operation when tuned to an FM or DAB broadcast station.

1 Press SETUP. ui to select “TUNER 2 Use SETUP”, then press ENTER or p. Use ui to select “FM AUTO 3 PRESET”, then press ENTER or p.

ENTER while 4 Press ENTER ” is flashing. Broadcast stations automatically.

“PRESET are

preset

3 Input the station name.

Names of up to 8 characters can be input. • u, i button........................... Selects the character. • p button................................ Moves the cursor to the right. • CLEAR button......................... Deletes the currently selected character. • Characters that can be input.

A ~ Z, 0 ~ 9, ^ ’ ( ) z + , - . / = (space)

4 Press ENTER.

The characters you have input are entered.

nnTo tune automatically

• To give names to other stations, repeat steps 1 to 4.

Press and hold in TUNE –, + to tune in stations automatically. • Stations whose signal is weak cannot be tuned in. • In the DAB mode, tuning only moves to receivable stations, so auto tuning is not possible. (For RCD-M39DAB only)

nnCanceling auto presetting Press TUNER or 2.

nnTo stop auto tuning Press TUNE –, +.

Broadcast stations whose antenna signal are weak cannot be preset automatically. If you wish to preset such stations, tune them in manually.

NOTE When FM auto preset is performed, the channel currently ed as the FM preset is deleted, and the newly preset FM broadcast station is ed to the same number as the deleted channel.

DISC

14

Informations

2

Use TUNE –, + to select the reception band.

This unit can be preset with a total of 40 DAB and FM broadcast stations. • A maximum of 30 DAB broadcast stations can be preset. (For RCD-M39DAB only)

nnGiving station names to preset channels

Operations

DABz

Automatically presetting FM/DAB stations (Auto preset)

Preparations

Tuning in broadcast stations

Listening to FM broadcasts

This unit can be preset with a total of 40 FM broadcast stations.

in the station you want to 1 Tune preset. 2 Press ENTER.

The minimum number display “P– –” for the uned preset flashes.

then press ENTER.

The reception frequency and reception mode are preset and the display switches to the station name input display.

Names of up to 8 characters can be input. • u, i button...................... Selects the character. • p button........................... Moves the cursor to the right. • CLEAR button.................... Deletes the currently selected character. • Characters that can be input.

A ~ Z, 0 ~ 9, ^ ’ ( ) z + , - . / = (space) • If you do not want to input a station name, press ENTER without inputting anything else. • If you make a mistake when inputting, perform the procedure again. Whatever was previously input is overwritten.

5 Press ENTER.

The characters you have input are entered.

• To give names to other stations, repeat steps 1 to 5.

NOTE

Listening to preset stations Use 0 – 9, +10 or CHANNEL –, + to select the preset number.

8/–, +/9 on the main unit can be used both for switching the preset channel and for tuning. Before operating them, switch the main unit to the “preset mode” or “tuning mode” using the procedure below.

1 Press SETUP. ui to select “TUNER 2 Use SETUP”, then press ENTER or p.

Use ui to select “MODE 3 SELECT”, then press ENTER or

p.

Use ui to select “PRESET 4 MODE” or “TUNING MODE”, then press ENTER.

PRESET MODE

TUNING MODE

DISC

15

Press 8/–, +/9 on the main unit to switch preset channels. • This is the same operation as CHANNEL –, + on the remote control unit. Press 8/–, +/9 on the main unit to change the received frequency. • This is the same operation as TUNE–, + on the remote control unit.

Informations

When the ed preset number is selected, “*” is displayed. To overwrite this preset number, press ENTER.

Setting the preset channels and changing the received frequency on the main unit

Operations

0 – 9, +10 or CHANNEL –, + 3 Use to select the number to be preset,

4 Input the station name.

Preparations

Presetting FM stations manually

Listening to FM broadcasts

PTY (Program Type)

RDS (works only on the FM band) is a broadcasting service which allows a station to send additional information along with the regular radio program signal. The following four types of RDS information can be received with this unit:

PTY identifies the type of RDS program. The program types and their displays are as follows:

nnRDS Search

Use this function to automatically tune to FM stations that provide the RDS service.

EASY M

4 Press o p.

Weather Finance Children’s CHILDREN programmes SOCIAL Social Affairs RELIGION Religion PHONE IN Phone In TRAVEL Travel LEISURE Leisure JAZZ Jazz Music COUNTRY Country Music NATION M National Music OLDIES Oldies Music FOLK M Folk Music DOCUMENT Documentary WEATHER FINANCE

• If no RDS station is found, “NO STATION” is displayed.

Viewing information during reception Press INFO while receiving a RDS to display the information currently being broadcast.

*1

*2

PS

RT

PTY CT

*1 Frequency *2 Program service name • If a station name is entered, it is displayed.

DISC

p.

Use ui to call out the desired 4 program type. 5 Press o p.

Automatically begin the PTY search operation.

• If no program of the specified type is found, “NO STATION” is displayed.

Automatically begin the RDS search operation.

Freq.

1 Press TUNER to select “FM”. 2 Press DAB/RDS. ui to select “PTY 3 Use SEARCH”, then press ENTER or

16

Informations

LIGHT M CLASSICS OTHER M

p.

News Current Affairs Information Sports Education Drama Culture Science Varied Pop Music Rock Music Easy Listening Music Light Classical Serious Classical Other Music

Use this function to find RDS stations broadcasting a designated program type (PTY). For a description of each program type, refer to “Program Type (PTY)”.

Operations

1 Press TUNER to select “FM”. 2 Press DAB/RDS. ui to select “RDS 3 Use SEARCH”, then press ENTER or

NEWS AFFAIRS INFO SPORT EDUCATE DRAMA CULTURE SCIENCE VARIED POP M ROCK M

nnPTY search

Preparations

RDS (Radio Data System)

Listening to FM broadcasts

RT (Radio Text)

TP identifies programs that carry traffic announcements. This allows you to easily find out the latest traffic conditions in your area before leaving home.

RT allows RDS stations to send text messages that appear on the display.

nnTP search

• When the RT mode is turned on while an RDS broadcast station not offering an RT service is tuned in, “NO RT” is displayed on the display. • The RT mode cannot be set in the FM stations not offering RDS broadcasts.

Use this function to find RDS stations broadcasting traffic programs (TP stations).

• “NO STATION” is displayed when there is no traffic information broadcast station.

CT (Clock Time) Use this to correct the time of the clock on this unit. q During CT reception, press SETUP. The “AUTO Adj mm:ss” is displayed. w Press ENTER to set. The “RDS mm:ss” is displayed. • The time on the set’s internal clock is updated to the currently displayed “CT” time.

Do not operate any buttons while the time is being updated. If buttons are operated, CT reception is not possible and the time is not updated.

DISC

17

Informations

Automatically begin the TP search operation.

NOTE The operations described below selecting “RDS Search” will not function in areas in which there are no RDS broadcasts.

Operations

1 Press TUNER to select “FM”. 2 Press DAB/RDS. Use ui to select “TP SEARCH”, 3 then press ENTER or p. 4 Press o p.

Preparations

TP (Traffic Program)

Listening to DAB/DAB+ (for RCD-M39DAB only)

nnAbout DAB+

1 Press TUNER to select “DAB”. • When a DAB operation is performed for the first time after purchase, auto scanning is performed automatically.

TUNE +, – to select the 2 Press desired broadcast station. • The broadcast stations are displayed in the order in which they were scanned.

DAB stations can be stored in the preset memory and played in the same way as FM stations. • “Presetting FM stations manually” (vpage 15) • “Listening to preset stations” (vpage 15) • A maximum of 30 DAB broadcast stations can be preset.

Auto scanning broadcast stations Connect the antenna beforehand.

SETUP during DAB 1 Press reception. ui to select “TUNER 2 Use SETUP”, then press ENTER or p. ui to select “DAB AUTO SCAN”, then press 3 Use ENTER or p. 4 Press ENTER. This unit searches for receivable DAB stations.

DISC

18

Switching the reception information for the currently tuned in DAB station steps 1 to 2 under 1 Perform “Tuning in DAB stations” to tune in a DAB station.

2 Press INFO. • The display switches as shown below each time the button is pressed.

$ q Dynamic Label Segment : Text data included in the broadcast is scrolled. $ w Station Name : The service station name is displayed. $ e Program Type : The category of the tuned in station is displayed. $ r Ensemble Name : The ensemble name is displayed. $ t Frequency: The frequency is displayed. $ y Signal Quality : The reception signal sensitivity is displayed (0 to 8). • If the reception signal sensitivity is 7 or greater, the program can be received without noise. $ u Audio Information : The mode of the currently tuned in station and its bit rate are displayed. $ i Date and Time : The current date and time are displayed. • When SETUP is pressed, the set’s internal clock is updated to the currently displayed time.

Informations

• The main difference between DAB and DAB+ is the type of audio codec used. DAB: MPEG2 DAB+: MAEG4 (AAC) • This unit can receive both DAB and DAB+ broadcasts.

Tuning in DAB stations

Operations

• Since the DAB system is broadcasted in digital format, DAB system can supply crystal-clear audio and stable reception even in mobile objects. DAB is a new generation radio which can provide data service and supplementary multi-media services. • DAB broadcasts multiple services under one Ensemble that are called service components. • Each component contains inherent programmes; news, music, sports, and many more. • Each Ensemble and service component has its label, and s can recognize a current broadcasting station and service contents by using the label. • The main service component is broadcast as Primary while the others are broadcast as Secondary. • Also rich character information is serviced through Dynamic Labels; song title, artist composer etc.

Preparations

nnAbout DAB (Digital Audio Broadcasting)

Listening to DAB/DAB+ (For RCD-M39DAB only)

DAB initialize

1 ui to select “item”, then 2 Use press ENTER.

When the “DAB Initialize” procedure is performed, all the preset memory settings for the stations and DABs are reset.

Press DAB/RDS during DAB reception.

1

during

DAB

The service list is created with the auto scan function.

Station Order

MULTIPLEX (In order of frequency) DRC (Dynamic Range Control)

Off



1/2

ALPHANUMERIC (In alphabetical order) 1

DISC

2 Press DIGITAL IN or ANA.

Play the component connected to this unit. ui to select “TUNER SETUP”, then press the 3 2 Use ENTER or p. Use ui to select “DAB INITIALIZE”, then press 3 the ENTER or p. 4 Press ENTER. • Once initialization is completed, auto scanning is performed automatically.

19

Informations

The DAB module’s version is displayed.

Check the connection, then turn on this units.

Operations

• The program can be received without noise when the cursor move to the right of the sensitivity display.

1 Prepare for playback.

• When there is no component connected to the DIGITAL IN connector, “SIGNAL UNLOCK” is not displayed when you press DIGITAL IN.

The reception sensitivity of the currently tuned in frequency is displayed.

Tuning Aid

DAB Version

Press SETUP reception.

Listening to AUX

Preparations

Making the DAB settings

nn Basic operation (vpage 9) nn Before playing a USB or an iPod (vpage 20) nn MP3 or WMA playback order of MP3 or WMA files (vpage 20)

Before playing a USB or an iPod

1 Press POWER X. USB memory device or iPod connection 2 Connect cable (vpage 5).

When the USB memory device or iPod is connected to the USB port on this unit, the source automatically switches to “USB” and file playback begins.

nnTurning the power off (to the standby mode) Press POWER X again.

MP3 or WMA playback order of MP3 or WMA files When there are multiple folders containing MP3 or WMA files, the playback order of folders is automatically set when this unit reads the media. The files in each folder are played back in the order in which the files were recorded on the media, from the oldest date and time.

nnPlayback order of folders CD-R/CD-RW For playback of files on CD-R or CD-RW , files in all folders on the first layer are played first, next on the second layer, then next on the third layer, and so on in this order.

Be sure to stop playback before turning the power off.

For playback of files recorded on USB, files in the first folder on the first layer are played first, next folders on the second layer in the folder, then next on the third layer, and so on in this order. Then accordingly files on another first layer are played.

• The playback order displayed on a PC may differ from the actual playback order. • The playback order with a CD-R/CD-RW may differ, depending on the writing software.

NOTE The playback order may differ from the order in which the folders or files were recorded if you delete or add a folder or file on USB. This occurs because of data recording specifications and is not a malfunction.

DISC

20

Informations

USB memory device

NOTE

Operations

nn Playing of MP3 and WMA files (vpage 21) nn Playing an iPod (vpage 23) nn Playing a USB memory device (vpage 24) nn Setting the alarm (vpage 25) nn Other functions (vpage 27)

Preparations

Preparations

Advanced operation

Playing of MP3 and WMA files MP3 and WMA formats

MP3 and WMA files playback

CD-R and CD-RW discs created in the format described below can be played.

“Windows Media” and “Windows” are ed trademarks or trademarks in the United States and other countries of Microsoft Corporation of the United States.

nnWriting software format

a CD-R or CD-RW disc 1 Load containing music files in the MP3

ISO9660 Level 1 When written in other formats, it may not be possible to play the disc properly.

nnMaximum number of playable files and folders

MPEG-1 Audio Layer-3 WMA (Windows Media Audio)

nnTag data

ID3-Tag (Ver. 1.x and 2.x ) META-Tag (Compatible with title, artist and album names)

MP3 WMA

Folder Mode Disc Mode

Extension .mp3 .wma

• Be sure to give files the extension “.MP3” or “.WMA”. Files with any other extensions or with no extensions cannot be played. • In accordance with copyright laws, recordings you have made should only be used for your personal enjoyment and may not be used in other ways without permission of the copyright holder.

DISC

21

Disc Mode

All the files in the selected folder are played. After the selected folder and files are played, all the files in all the folders are played.

3 Use ui to select the folder to be played. 4 Use 8, 9 or o p to select the file to be played. 5 Press 1/3.

Informations

File format

Folder Mode

GAbout the displayH • When “Folder Mode” is selected: “FLD” indicator lights. • When “Disc Mode” is selected: “FLD” indicator turns off.

nnFile format

Playable MP3/WMA file Sampling Bit rate frequency 32, 44.1, 48 kHz 32 ~ 320 kbps 32, 44.1, 48 kHz 64 ~ 192 kbps

Press FOLDER MODE and select 2 “Folder Mode” or “Disc Mode”. Operations

Number of files : 255 Number of folders : 255

or WMA format into the disc tray (vpage 34).

Preparations

There are many music distribution sites on the Internet allowing you to music files in MP3 or WMA (Windows Media® Audio) format. The music (files) ed from such sites can be stored on CD-R or CD-RW discs and played on this unit.

Playing of MP3 and WMA files Folder Use ui to select the folder, then press ENTER. File Use o p to select the file, then press ENTER. Also use 8, 9 to select the file, or use 0 – 9, +10 to select the file number. • The folder and file numbers are set automatically when the disc is loaded.

nnTo play repeatedly

Press REPEAT. Playback starts in the respective repeat mode. • The selectable repeat modes differ in the “Folder Mode” and the “Disc Mode”. When “Folder Mode” is selected: Repeat of all the tracks in the folder

Single-track repeat

Single-track repeat

All-track repeat

Repeat off (indicator turns off)

GSelectable itemsH

When “Folder Mode” is selected:

FLD FLD

During playback, press INFO. File name

Title name / Artist name

Title name / Album name • The characters that can be displayed are as follows:

A–Z

a–z

All the files in the selected folder are played repeatedly. Folder mode playback resumes.

When “Disc Mode” is selected: “Playing repeatedly (Repeat playback)” (vpage 12)

nnSetting random playback

“Playing random order (Random playback)” (vpage 12)

0–9

! ” # $ % & : ; < > ? @ l [ ] _ ` | { } ˜ ^ ’ ( ) z + , - . / = (space)

DISC

Programmed playback is not possible with MP3/WMA discs.

22

Informations

1 FLD Only the selected track is played repeatedly.

nnSwitching the display

Operations

Repeat off When “Disc Mode” is selected:

• Copyright-protected files cannot be played. • Depending on the application software used for writing, it may not be possible to write the data properly. • Depending on the disc’s recording conditions, it may not be possible to play some discs properly.

Preparations

nnTo switch the folder or file during playback

Playing an iPod

• Depending on the type of iPod and the software version, some functions may not operate. • Note that DENON will accept no responsibility whatsoever for any problems arising with the data on an iPod when using this unit in conjunction with the iPod.

Remote control iPod buttons buttons

to

The mode switches each time the button is pressed.

GSelectable modeH Display location Playable files Active buttons

Remote mode

Main unit display

iPod display

P

P P

P

P P

ui to select the item, then press ENTER to select 3 Use the music file to be played. 4 Press 1/3. Playback starts.

13

8, 9

8, 9

Play the track / Pause the track. Play the track from the beginning/ Play the next track.

6, 7 8, 9 Fast-reverse the track/FastPress and hold Press and hold forward the track.

Browse mode

Audio file Video file Remote control unit and main unit iPod

1/3

Operation on this unit

u, i ENTER or p REMOTE/ BROWSE REPEAT RANDOM

Click Wheel

o

MENU

2

–

Select – – –

Select an item. Enter the selection or plays the track. Switch between the browse mode and the remote mode. Switch the repeat function Switch the shuffle function Display the menu or return to the previous menu. Stop

nnTo switch the display

During playback, press INFO. The display switches each time the button is pressed. Title name / Artist name

Title name / Album name

Disconnecting the iPod POWER 1 Press standby mode.

X to set the

2 Disconnect the iPod cable from the USB port. By pressing POWER X while the power of this unit is on with iPod being connected, this unit enters the iPod charge standby mode, continuing to charge iPod. In this case, the power indicator lights in red. When iPod is fully charged, the power indicator lights off.

DISC

23

Informations

NOTE

2

Press REMOTE/BROWSE select the display mode.

nnRemote control unit and iPod button relations

Operations

“Made for iPod” and “Made for iPhone” mean that an electronic accessory has been designed to connect specifically to iPod, or iPhone, respectively, and has been certified by the developer to meet Apple performance standards. Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards. iPhone, iPod, iPod classic, iPod nano, iPod shuffle, and iPod touch are trademarks of Apple Inc., ed in the U.S. and other countries. iPhone is a trademark of Apple Inc. • Individual s are permitted to use iPhone, iPod, iPod classic, iPod nano, iPod shuffle, and iPod touch for private copy and playback of non-copyrighted contents and contents whose copy and playback is permitted by law. Copyright infringement is prohibited by law.

1

Playback preparation (vpage 20 “Before playing a USB or an iPod”).

Preparations

With this unit, you can listen to music on an iPod. It is also possible to operate the iPod from the main unit or remote control unit.

Playing a USB memory device Files stored on USB memory devices created in the formats below can be played.

nnUSB-compatible file systems

“FAT16” or “FAT32” • If the USB memory device is divided into multiple partitions, only the top drive can be selected.

Maximum number of files in a folder: 255 Maximum number of folders: 255

nnFile format

• When “Folder Mode” is selected: “FLD” indicator lights. • When “Memory Mode” is selected: “FLD” indicator turns off.

All the files in the selected folder are played.

nnTag data

After the selected folder and files are played, all the files in all the folders are played. Extension .mp3 .wma

Only music files that are not copyright-protected can be played on this set. • Contents ed from pay sites on the Internet are copyright protected. Also, files encoded in WMA format when ripped from a CD, etc., on a computer may be copyright protected, depending on the computer’s settings.

DISC

Press 2.

nnStopping playback temporarily Press 1/3. The 3 is displayed. • To resume playback, press 1/3.

nnFast-forwarding and fast-reversing (searching)

ui to select the folder to be 3 Use played. 4 Use 8, 9 or o p to select the file to be played. 5 Press 1/3.

For details on the order of playback for files stored on a USB memory device, see “MP3 or WMA playback order of MP3 or WMA files” (vpage 20).

24

nnPlaying repeatedly Press REPEAT.

nnPlaying random order

In the stop mode, press RANDOM.

Informations

Playable MP3/WMA file Sampling Bit rate frequency 32, 44.1, 48 kHz 32 ~ 320 kbps 32, 44.1, 48 kHz 64 ~ 192 kbps

nnStopping playback

During playback, press and hold in 6, 7.

Memory Mode

ID3-Tag (Ver.1.x and 2.x) META-Tag (Compatible with title, artist and album names)

MP3 WMA

Mode”.

Folder Mode

MPEG-1 Audio Layer-3 WMA (Windows Media Audio)

File format

Press FOLDER MODE and select 2 “Folder Mode” or “Memory

Folder Use ui to select the folder, then press ENTER. File Use o p to select the file, then press ENTER. Use 8, 9 to select the file, or use 0 – 9, +10 to select the file number. • The folder and file numbers are set automatically when the USB memory device is loaded.

Operations

nnMaximum number of playable files and folders

1

Playback preparation (vpage 20 “Before playing a USB or an iPod”).

nnTo switch the folder or file during playback

Preparations

Playing a USB memory device

Playable USB memory formats

Playing a USB memory device During playback, press INFO.

Title name / Artist name

File name Title name / Album name

• The characters that can be displayed are as follows:

A–Z

a–z

Setting the alarm This device can playback using the alarm playback (everyday alarm, once alarm) and sleep timer.

nnAlarm operation when the time settings for alarms overlap When the sleep timer is set • Automatically stops playback after the time set for the sleep timer has elapsed.

0–9

NOTE

• Automatically starts playback at the earlier alarm start time set for either of the alarms. • Automatically stops playback at the earlier alarm stop time set for either of the alarms.

If the current time is not set, enter alarm setting mode to get time setting mode.

1 Press SETUP. ui to select “ALARM 2 Use SETUP”, then press ENTER or p.

ui to select the alarm 3 Use mode, then press ENTER or p. MODE SELECT ONCE ALARM ONCE ALARM

Informations

• DENON will take no responsibility whatsoever for any loss or damage to data on USB memory devices when using the USB memory device connected to this unit. • USB memory devices will not work via a USB hub. • DENON does not guarantee that all USB memory devices will operate or be suppled power. When using a USB connection type portable hard disk of the type for which power can be supplied by connecting an AC adapter, we recommend using the AC adapter.

When the once alarm and everyday alarm are both set (sleep timer is not set)

• Everyday alarm (“EVERYDAY ALARM”) Playback starts and stops (the power turns off) at the set times each day. • Once alarm (“ONCE ALARM”) Playback starts and stops (the power turns off) once only at the set times.

Operations

! ” # $ % & : ; < > ? @ l [ ] _ ` | { } ˜ ^ ’ ( ) z + , - . / = (space)

Setting the alarm

EVERYDAY ALARM

Use ui to select the source, 4 then press ENTER or p. SOURCE DISC DISC

SELECT

iPod/USB

DIGITAL IN

TUNER ANA

when the “TUNER” function is selected 5 UseOnly ui to select the preset number, then press

ENTER or p.

• When no name has been ed for the selected preset number, the frequency appears after the preset number is displayed.

v See overleaf

DISC

25

Preparations

nnSwitching the display

Setting the alarm

ON

TIME 10:00>

00:00

Use ui to select “minutes” for the alarm start time, 7 then press ENTER or p.

8

TIME 10:30>

OFF TIME 10:30> 11:00

alarm settings are displayed after this. • When set to “OFF”, time operation is disabled, but the alarm settings remain unchanged.

OFF TIME 10:30> 11:30

Use o p to select “ON” or “OFF” for the alarm, 10 then press ENTER.

Use this function to automatically switch the power to the standby mode after a specific amount of time (minutes). The sleep timer can be set to up to 90 minutes, in steps of 10 minutes.

Press SLEEP during playback and select the setting time. SLEEP 90 min

SLEEP 80 min

SLEEP 70 min

SLEEP 60 min

SLEEP 50 min

SLEEP 40 min

SLEEP 30 min

nnTo check the alarm settings

q Press SETUP. w Use ui to select “ALARM ON/OFF” , then press ENTER. e When “ON” is displayed for the alarm setting, press ENTER. The alarm settings are displayed for 3 seconds.

nnTo change the alarm settings

SLEEP 20 min

SLEEP 10 min

SLEEP OFF

• After about 5 seconds, the setting is entered and the display returns to as it was before.

nnCanceling the sleep timer

Either press SLEEP to select “SLEEP OFF” or press POWER X.

Perform the operations at “Setting the alarm” (vpage 25).

nnTo change the setting while setting the alarm

Press o. The setting returns to the previous step. Display the setting you want to change, then make the desired setting.

ONCE ALARM0ON 1 EVERYDAY 0OFF1 ONCE ALARM0ON 1 EVERYDAY 0OFF1

11 Press POWER X to set the power to standby.

Alarm standby mode is set, and the power indicator lights orange.

DISC

Setting the sleep timer

26

nnTo check the time remaining until the sleep timer is activated Press SLEEP.

Informations

ui to select “minutes” for the alarm stop time, 9 Use then press ENTER or p.

• The alarm settings are displayed for 3 seconds.

“EVERYDAY”.

r Use o p to select “ON” or “OFF” for the alarm, then press ENTER. The

00:00

Use ui to select “hours” for the alarm stop time, then press ENTER or p.

• The indicator lights and the alarm setting is entered.

q Press SETUP. w Use ui to select “ALARM ON/OFF”, then press ENTER. e Use ui to select “ONCE” or

Operations

ON

nnSetting the alarm to on or off

Preparations

ui to select “hours” for the alarm start time, 6 Use then press ENTER or p.

Other functions Auto standby

Last function memory

An optimizing filter suited for the properties of the speakers (SC-M39) can be used.

With the Auto standby ON, this unit will automatically enter the standby mode after about 30 continuous minutes of stop mode with no operation. For the input source “ANA” only, when no operation is performed for eight hours, this unit automatically enters the standby mode.

This stores the settings as they were immediately before going into the standby mode. When the power is turned back on, the settings are restored to as they were immediately before going into the standby mode.

1 Press SETUP. ui to select “SPK 2 Use OPTIMISE”, then press the 3 Use ui to select “ON”, then press the ENTER or p. The setting is entered.

ON

he response is optimized for the speakers (SC-M39, sold T separately).

OFF

T he response is flat.

1 ui to select “AUTO 2 Use STANDBY”, then press ENTER

Resetting the microprocessor Perform this procedure if the display is abnormal or if operations cannot be performed. When the microprocessor is reset, all the settings are reset to their default values.

or p.

SOURCE

8/–

Operations

ENTER or p.

Press SETUP.

Preparations

Using an optimizing filter

3 Use ui to select “ON”, then press ENTER or p. The setting is entered.

NOTE

When the power is in standby, the power turns on when any of the buttons below other than POWER X is operated, and the respective operation is performed.

Informations

Auto power on

In the following situations, the Auto standby function does not operate. • When an iPod (Remote mode) is connected to the USB port on the unit. • When the source is “TUNER”. • The default setting for the Auto Standby mode is “ON”.

1 Unplug the power cord. the power cord into a power outlet while 2 Plug simultaneously pressing 8/– and SOURCE on the

• 5 (on the main unit).......... The disc tray opens. • 1/3.................................. Playback of the “CD”, “iPod” or “USB” starts. • CD..................................... The source switches to “DISC”. • TUNER.............................. The source switches to “TUNER” and the band last set is tuned in. • iPod/USB.......................... The source switches to “iPod/USB”. • DIGITAL IN........................ The source switches to “DIGITAL IN”. • ANA....................... The source switches to “ANA”.

main unit.

“INITIALIZE” is displayed.

If “INITIALIZE” does not display in step 2, start over from step 1.

DISC

27

Informations

Here, we list various information related to this unit. Please refer to this information as needed.

F Other information vpage 34

Operations

F Part names and functions vpage 29

Preparations

Informations

F Troubleshooting vpage 35 F Specifications vpage 37

DISC

28

Informations

F Index vpage 37

Preparations

Part names and functions Front For buttons not explained here, see the page indicated in parentheses ( ).

RCD-M39DAB

Q2

Q3

Q1

Q0

q Power operation button (X)················································ (9, 20) w Power indicator·········································································· (9) e USB port······················································································ (5) r Disc tray···················································································· (34) t Headphones jack (PHONES) When the headphones are plugged into this jack, audio will no longer be output from the connected speakers.

o

Operations

Image when viewed from the top of the front

NOTE To prevent hearing loss, do not raise the volume level excessively when using headphones.

RCD-M39DAB

Preset/Tuning buttons (8/–, +/9)················································· (12, 15, 21, 24, 27)

o Stop button (2) (for continental model only)············································ (12, 14, 24)

Band/Stop button (BAND/2) (for RCD-M39DAB model only)······································ (12, 14, 24)

Q0 Play/Pause button (1/3)·································· (9, 12, 21, 23, 24) Q1 Disc tray open/close button (5)················································ (9) Q2 Remote control sensor···························································· (33) Q3 Display q w

e

DISC

r

t y

u

i

29

Informations

y SOURCE button·································································· (11, 27) u VOLUME control knob····························································· (11) i Reverse-skip/Forward-skip buttons

Rear

Display i

u

y

t

r

Preparations

For buttons not explained here, see the page indicated in parentheses ( ).

e RCD-M39DAB

y

q Information display Various information is displayed here.

w Remote control signal reception indicator e Timer operation indicator r Play mode indicator························ (12, 22, 24) t TOTAL indicator

y Tuner reception mode indicators·············· (14) u Tone indicators············································ (11) SDB: Lights when the super dynamic bass function is set to “ON”. TONE: Lights when the tone (bass/treble) is being adjusted.

i Playback mode indicators

Informations

Lights when the total number of tracks and total time of the CD are displayed.

Operations

w

q

1 : During Playback 3 : During pause

q

w

e

r

q Analog audio connectors (ANA)·················································· (6)

w Digital audio connector (DIGITAL IN)··················································· (6)

e Subwoofer connector (SUBWOOFER OUT)······································ (4)

DISC

30

t r Speaker terminals (SPEAKERS)··················· (4) t AC inlet (AC IN)·············································· (7) y FM antenna terminal (ANTENNA) (for continental model only)····························· (6)

DAB/FM antenna terminal (ANTENNA) (for RCD-M39DAB only)·································· (6)

Remote control unit Buttons that work with all sources (CD, TUNER, iPod and USB)

Buttons that work with CDs The buttons listed at “Buttons that work with all sources” can also be used.

q w

e

r q Play/Pause button (1/3)······················· (9, 12) w Reverse-skip/Forward-skip buttons (8, 9)············································· (12, 21)

e Fast-reverse/Fast-forward buttons (6, 7) ···················································· (12)

Q4

q

········································ (10, 14, 15, 18, 25, 27)

y

w

w

e Q3

e

i Q2 r t

o

y

u Q1 Q0

DISC

31

i o

Informations

u

r Cursor buttons (uio p)···························· (21) t ENTER button·············································· (22) y Number buttons (0 – 9, +10 )················ (12, 22) u CLEAR button·············································· (13) i Information button (INFO)···················· (13, 22) o PROGRAM button······································· (13) Q0 REPEAT button······································ (12, 22) Q1 RANDOM button········································· (12) Q2 FOLDER MODE button································ (21) Q3 Stop button (2)··········································· (12) Q4 SOURCE button (CD)···································· (9)

Operations

t

q SLEEP button··············································· (26) w CLOCK button·············································· (10) e DIMMER button··········································· (11) r POWER button (X)·································· (9, 20) t SOURCE buttons··································· (11, 27) y MUTE button (:)······································ (11) u VOLUME buttons (d f)······························ (11) i SDB TONE button······································· (11) o SETUP button

Preparations

This section explains the buttons used to playback each source.

Remote control unit

nnButtons that work with iPods or USBs

The buttons listed at “Buttons that work with all sources” can also be used.

q

w

The buttons listed at “Buttons that work with all sources” can also be used.

q SOURCE button (TUNER)··························· (14) w Tuning buttons (TUNE +, –)·················· (14, 18) e Cursor buttons (uio p)······················ (14, 18) r ENTER button········································ (14, 18) t SETUP button········································ (14, 18) y Number buttons (0 – 9, +10 )······················ (15) u CLEAR button·············································· (14) i Information button (INFO)···················· (16, 18) o DAB/RDS button··································· (16, 19) Q0 CHANNEL buttons (+, –)····························· (15) Q1 Stop button (2)··········································· (14)

q

q SOURCE button (iPod/USB)······················· (11) w Play/Pause button (1/3)····················· (23, 24) e Reverse-skip/Forward-skip buttons (8, 9)············································· (23, 24)

r Fast-reverse/Fast-forward buttons (6, 7)··············································· (23, 24)

w e

r Q3

r

Q2

t

Q0

v See overleaf

e r o

y u

t

y

i

u i

DISC

Q1 Q0

32

o

Informations

e

t REMOTE/BROWSE button························· (23) y Cursor buttons (uio p)······················ (23, 24) u ENTER button········································ (23, 24) i Number buttons (0 – 9, +10 )······················ (22) o Information button (INFO)·························· (23) Q0 REPEAT button······································ (23, 24) Q1 RANDOM button··································· (23, 24) Q2 FOLDER MODE button································ (24) Q3 Stop button (2)··········································· (24)

Operations

w Q1

Preparations

nnButtons that work with the tuner

Remote control unit

q Remove the rear lid in the direction of the arrow and remove it.

Operating range of the remote control unit

w Load the two batteries properly as indicated by the marks in the battery compartment.

Preparations

Inserting the batteries

Approx. 7 m 30°

30°

Operations

NOTE

e Put the rear cover back on.

NOTE

DISC

33

Informations

• Insert the specified batteries in the remote control unit. • Replace the batteries with new ones if the set does not operate even when the remote control unit is operated close to the unit. (The supplied batteries are only for ing operation. Replace them with new batteries at an early date.) • When inserting the batteries, be sure to do so in the proper direction, following the q and w marks in the battery compartment. • To prevent damage or leakage of battery fluid: • Do not use a new battery together with an old one. • Do not use two different types of batteries. • Do not attempt to charge dry batteries. • Do not short-circuit, disassemble, heat or dispose of batteries in flames. • Do not keep the battery in a place exposed to direct sunlight or in places with extremely high temperatures, such as near a heater. • If the battery fluid should leak, carefully wipe the fluid off the inside of the battery compartment and insert new batteries. • Remove the batteries from the remote control unit if it will not be in use for long periods. • Used batteries should be disposed of in accordance with the local regulations regarding battery disposal. • The remote control unit may function improperly if rechargeable batteries are used.

• The set may function improperly or the remote control unit may not operate if the remote control sensor is exposed to direct sunlight, strong artificial light from an inverter type fluorescent lamp or infrared light. • When using 3D video devices that transmit radio communication signals (such as infrared signals etc) between the various units (such as the monitor, 3D glasses, 3D transmitter unit etc), the remote control unit may not operate due to interference from those radio communication signals. If this occurs, adjust the direction and distance of the 3D communication for each unit, and check that the remote control unit operation is not affected by these signals.

Discs Discs playable on this unit q Music CDs Discs marked with the logo below can be played in this unit.

NOTE

Holding discs

• Place the disc in the tray, label side up. • Make sure the disc tray is fully open when inserting the disc. • Place the discs flat, 12 cm discs in the outer tray guide (Figure 1), 8 cm discs in the inner tray guide (Figure 2).

• Be sure to remove discs after using them. • Be sure to store discs in their cases to protect them from dust, scratches, warping, etc. • Do not store discs in the following places: 1. Places exposed to direct sunlight for long periods of time 2. Dusty or humid places 3. Places exposed to heat from heaters, etc.

Figure 1

Figure 2

Outer tray guide

Inner tray guide 8 cm disc

12 cm disc

Cleaning discs • If there are fingerprints or dirt on a disc, wipe them off before using the disc. Fingerprints and dirt can impair sound quality and cause interruptions in playback. • Use a commercially available disc cleaning set or a soft cloth to clean discs.

Informations

• Discs in special shapes (heart-shaped discs, octagonal discs, etc.) cannot be played. Do not attempt to play them, as doing so can damage the unit. • Some discs and some recording formats cannot be played. • Non-finalized discs cannot be played. • What is finalization? Finalization is the process that makes recorded CD-R/CD-RW discs playable on compatible players.

Cautions on storing discs

• Place 8 cm discs in the inner tray guide without using an adapter.

• “00 Tr 00 : 00” is displayed if a disc that cannot be played is loaded. • “NO DISC” is displayed if the disc is loaded upside-down or if no disc is loaded. Do not touch the signal surface.

NOTE Do not push the disc tray in by hand when the power is turned off. Doing so could damage the set.

Cautions on loading discs

Cautions on handling

• Only load one disc at a time. Loading two or more discs can damage the unit or scratch the discs. • Do not use cracked or warped discs or discs that have been repaired with adhesive, etc. • Do not use discs on which the sticky part of cellophane tape or labels is exposed or on which there are traces of where labels have been removed. Such discs can get caught inside the player and damage it.

• Do not get fingerprints, oil or dirt on discs. • Take special care not to scratch discs when removing them from their cases. • Do not bend or heat discs. • Do not enlarge the hole in the center . • Do not write on the labeled (printed) surface with ball-point pens, pencils, etc., or stick new labels on discs. • Water droplets may form on discs if they are moved suddenly from a cold place (outdoors for example) to a warm place, but do not try to dry them off using a hairdryer, etc.

DISC

Operations

w CD-R/CD-RW

Loading discs

Preparations

Other information

34

Gently wipe the disc from the inside towards the outside.

Do not wipe in a circular motion.

NOTE Do not use record spray, antistatic agents, benzene, thinner or other solvents.

Explanation

B Bit rate This expresses the read amount per 1 second of video/audio data recorded in a disc.

M MP3 (MPEG Audio Layer-3) This is an internationally standardized audio data compression scheme, using the “MPEG-1” video compression standard. It compresses the data volume to about one eleventh its original size while maintaining sound quality equivalent to a music CD. MPEG (Moving Picture Experts Group), MPEG-2, MPEG-4 These are the names for digital compression format standards used for the encoding of video and audio. Video standards include “MPEG-1 Video”, “MPEG2 Video”, “MPEG-4 Visual”, “MPEG-4 AVC”. Audio standards include “MPEG-1 Audio”, “MPEG-2 Audio”, “MPEG-4 AAC”.

S Sampling frequency Sampling involves taking a reading of a sound wave (analog signal) at regular intervals and expressing the height of the wave at each reading in digitized format (producing a digital signal). The number of readings taken in one second is called the “sampling frequency”. The larger the value, the closer the reproduced sound is to the original. Speaker impedance This is an AC resistance value, indicated in Ω (ohms). Greater power can be obtained with this value smaller.

GGeneralH Symptom Set does not operate properly. Display not lit and sound not produced when power switched to on. Display lit but sound not produced. Display is off.

W WMA (Windows Media Audio) This is audio compression technology developed by Microsoft Corporation. WMA data can be encoded using Windows Media® Player Ver.7, 7.1, Windows Media®Player for Windows® XP and Windows Media® Player 9 Series. To encode WMA files, only use applications authorized by Microsoft Corporation. If you use an unauthorized application, the file may not work properly.

Power turns off suddenly and power indicator flashes red. (Flashes at 0.5 second intervals)

Power turns off suddenly and power indicator flashes red. (Flashes at 0.25 second intervals)

Cause • External noise or interference is causing the set to malfunction. • Power cord not plugged in securely.

Countermeasure • Reset the microprocessor.

Page 27

• Check the connections on the set's rear and the connection of the power plug to the power outlet.

7

• Select the appropriate input source. • Volume control set to minimum. • Turn volume up to suitable level. • MUTING is on. • Switch off MUTING. • The Dimmer setting is set to • Set to something other than “OFF”. “OFF”. • Protection circuit activated due • Turn off the power, wait for the to a rise in internal temperature. set to fully cool down, then turn the power back on. • Place the set in a well-ventilated location. • Core wires of two speakers • First unplug the power cord, are touching each other or a then twist the core wires tightly core wire is sticking out of or terminate the speaker cables, the terminal and touching the then reconnect. set’s rear , activating the protection circuit. • Set is damaged. • Turn off the power and a DENON service center .

11

• Wrong input source selected.

11 11 11 35

II 4

–

v See overleaf

DISC

35

Informations

F Finalize This is processing that enables playing back of disc of CD, which was recorded using a recorder, by other players.

If a problem occurs first check the following: 1. Are the connections correct? 2. Is the set being operated as described in the owner’s manual? 3. Are the other components operating properly? If this unit does not operate properly, check the items listed in the table below. If the problem persists, there may be a malfunction. In this case, disconnect the power immediately and your retail outlet.

Operations

D Dynamic range The difference between the maximum undistorted sound level and the minimum sound level that is discernible above the noise emitted by the device.

P Protection circuit This is a function to prevent damage to components within the power supply when an abnormality such as an overload, excess voltage occurs or temperature for any reason. In this unit, the power indicator blinks and the unit enters standby mode when an abnormality occurs.

Preparations

Troubleshooting

A AAC (Advanced Audio Coding) This is an internationally standardized audio data compression scheme. It has a compression ratio 1.4 times higher than the “MP3” audio compression scheme adopted for “MPEG-1”.

GRemote control unitH

GUSBH Countermeasure • Replace with new batteries. • Operate within the specified range. • Remove the obstacle.

Cause • The disc is not properly loaded.

Countermeasure • Reload the disc.

• Insert the batteries in the proper direction, following the polarity marks in the battery compartment. • Move the set to a place in which the remote control sensor will not be exposed to strong light.

Page 33 33

Symptom When a USB memory device is connected, “USB” is not displayed.

– 33

33

GCDH Symptom “00 Tr 00 : 00” is shown on the display even though a CD is loaded. Disc does not play when 1/3 button is pressed. A specific part of a disc is not played. A CD-R or CD-RW disc cannot be played. MP3 and WMA files cannot be played.

• The disc is dirty or scratched.

Page 34

• Wipe the disc clean or replace the disc.

34

• Wipe the disc clean or replace the disc.

34

• The disc has not been finalized. • Finalize the disc then play it. • The recording conditions are bad • Use a properly recorded disc. or the quality of the disc itself it poor. • The file formats, extensions or • Create discs with file formats, settings made when the disc extensions or settings was created are not compatible compatible with this unit. with this unit.

34 –

• The disc is dirty or scratched.

21

GTunerH Symptom Continuous noise is heard when receiving FM programs.

Cause • Antenna cable is not properly connected.

DISC

Countermeasure • Connect the antenna cable properly. • Connect an outdoor antenna.

Page 6 –

36

Page 5 –

–

– 23 5 –

–

24 24

Informations

Cause Countermeasure • The set cannot recognize a USB • Check the connection. memory device. • A USB memory device not • Connect a USB memory device conforming to mass storage class conforming to mass storage or MTP standards is connected. class or MTP standards. • A USB memory device that • This is not a malfunction. the set cannot recognize is DENON does not guarantee that connected. all USB memory devices will operate or receive power. • USB memory device is • Connect the USB memory connected via USB hub. device directly to the USB port. iPod cannot be • Input source other than “USB” is • Switch the SOURCE to “USB”. played. selected. • Cable is not properly connected. • Reconnect. Files on a USB • USB memory device is in a • Set the format to FAT16 or memory device format other than FAT16 or FAT32. For details, refer to the cannot be played. FAT32. USB memory device’s operating instructions. • USB memory device is divided • When divided into multiple into multiple partitions. partitions, only files stored in the top partition can be played. • Files are stored in a non• Record the files in a compatible compatible format. format. • You are attempting to play a file • Files that are copyright that is copyright protected. protected cannot be played on this set.

Operations

Cause • Batteries are worn. • You are operating outside of the specified range. • Obstacle between main unit and Remote control unit. • The batteries are not inserted in the proper direction, as indicated by the polarity marks in the battery compartment. • The set’s Remote control sensor is exposed to strong light (direct sunlight, fluorescent light, etc.).

Preparations

Symptom Set does not work properly when Remote control unit operated.

Index vvA

nn Audio section • Power amplifier Rated output:

nn Tuner section Receiving range:

Usable sensitivity: FM stereo separation:

Playback frequency response: Wow & flutter: Sampling frequency:

nn Clock/Timer section Clock method: Timer:

Power supply: Power consumption:

vvB BASS··································································· 11 Bit rate····················································· 21, 24, 35 Browse mode······················································ 23

FM: 87.50 MHz – 108.00 MHz DAB: BAND3 170 MHz – 240 MHz FM: 1.2 μV/75 Ω DAB: –93 dBm/50 Ω 35 dB (1 kHz)

vvC Cable Audio cable························································· 4 Optical cable······················································· 4 Speaker cable····················································· 4 Subwoofer cable················································· 4 Characters········································· 14, 15, 22, 25 Condensation························································ 2 Connection Antenna······························································ 6 iPod····································································· 5 Power cord························································· 7 Speaker······························································· 4 TV······································································· 6 USB memory device··········································· 5 CT (Clock Time)··················································· 17 Current time························································ 10

2 Hz – 20 kHz Below measurable limits (± 0.001%) 44.1 kHz

Crystal oscillator (Within 1 – 2 minutes per month) Everyday/Once timer: One each Sleep timer: 90 minutes, maximum

AC 230 V, 50/60 Hz 70 W Approx. 0.3 W (standby)

• For purposes of improvement, specifications and design are subject to change without notice.

vvD DAB (Digital Audio Broadcasting)························ 18 DAB/FM indoor antenna········································ 6 Display································································· 30 Display’s brightness············································ 11 Dynamic range···················································· 35

vvF Finalize·························································· 34, 35 FM indoor antenna················································ 6 Front ·························································· 29

vvH Headphones························································ 29

vvI Input source························································ 11

DISC

37

vvP Playback AUX·································································· 19 CD····································································· 12 DAB·································································· 18 FM···································································· 14 iPod··································································· 23 MP3·································································· 21 USB memory device········································· 24 WMA································································ 21 Protection circuit············································· 4, 35 PTY······································································ 16

vvR RDS····································································· 16 Rear ··························································· 30 Remote control unit············································ 31 Inserting the batteries······································ 33 Remote mode····················································· 23 Resetting the microprocessor····························· 27 RT········································································ 17

vvS Sampling frequency································ 21, 24, 35 SDB····································································· 11 Speaker impedance············································· 35 Subwoofer····························································· 4

vvT Tone···································································· 11 TP········································································ 17 TREBLE······························································· 11 Turning the power on············································ 9

vvV Volume································································ 11

vvW WMA······················································· 20, 21, 35

Informations

nn General

30 W + 30 W (6 Ω, 1 kHz T.H.D 10 %)

MP3························································· 20, 21, 35 Mute···································································· 11

Operations

nn CD section

Accessories··························································· 1 Alarm··································································· 25

vvM

Preparations

Specifications

Dimensions Preparations

199.0 45.0

308.0

Operations

272.0

28.0

25.0

Unit : mm

129.1

11.0

Informations

130.0

30.0 29.0

152.0

115.0

8.5

106.5

210.0

29.0

Weight : 4.0 kg

DISC

38

V00

www.denon.com

D&M Holdings Inc. 3520 10158 00AD
