For other options, keypads or custom configurations please EAO Switch directly. KEYPADS

Product Profile

Non illuminated keypad

The S.series is a high quality, vandal resistant keypad range especially designed to meet the needs of public environment applications, vending machines, ticket machines, door entry systems, banking/ATM, telephones and industrial machinery. Technical drawings see pages 93-94 • Illuminated or non illuminated options

Non-illuminated keypad, 3x4 keys, pin header connection

Non-illuminated keypad, 4x4 keys, pin header connection

• Anti pull-off keys • High impact resistance • All metal construction (chromed Zamak keys and housing)

Part No.

Output type

Part No.

Output type

S.12150.001

Matrix

S.16350.001

Matrix

S.12100.001

Common point

S.16300.001

Common point

• IP67 front face sealing with gasket supplied • Front or rear mounting • 12 or 16 key versions

Illuminated keypad

Illuminated keypad, 3x4 keys, pin header connection

Illuminated keypad, 4x4 keys, pin header connection

Part No.

Output type

Part No.

Output type

S.12150.241

Matrix

S.16350.241

Matrix

S.12100.241

Common point

S.16300.241

Common point
