Colorimetry 71472f

Useful Terminology Colorimetry is the use of the human eye to determine the concentration of colored species. Spectrophotometry is the use of instruments to make the same measurements. It extends the range of possible measurements beyond those that can be determined by the eye alone. Note: This experiment will demonstrate both techniques on the same set of dyes.

Colorimetry Visual Observations – Because colorimetry is based on inspection of materials with the human eye, it is necessary to review aspects of visible light. Visible light is the narrow range of electromagnetic waves with the wavelength of 400-700 nm.

ROY G. BIV= the mnemonic used to the colors of the visible spectrum.

Visible light is only a very small portion of the electromagnetic spectrum. Note: Frequency (υ) and Energy (E) are directly proportional whereas Frequency (υ) and Wavelength (λ) are inversely proportional.

Electromagnetic Spectrum Type of Radiation

Frequency Range (Hz)

Wavelength Range

Type of Transition

gamma-rays

1020-1024

<1 pm

nuclear

X-rays

1017-1020

1 nm-1 pm

inner electron

ultraviolet

1015-1017

400 nm-1 nm

outer electron

visible

4-7.5x1014

750 nm-400 nm

outer electron

near-infrared

1x1014-4x1014

2.5 µm-750 nm

outer electron molecular vibrations

infrared

1013-1014

25 µm-2.5 µm

molecular vibrations

microwaves

3x1011-1013

1 mm-25 µm

molecular rotations, electron spin flips*

radio waves

<3x1011

>1 mm

nuclear spin flips*

Electromagnetic radiation is characterized by its wavelength, , Frequency,  and energy, E: E = h= hc / 

c=

Where h = Planck’s constant & c = speed of light in a vacuum.

(a) longer wavelength, lower energy; (b) shorter wavelength, higher energy.

Color Wheel (ROYGBIV)

Complementary colors lie across the diameter on the color wheel and combine to form “white light”, so the color of a compound seen by the eye is the complement of the color of light absorbed by a colored compound; thus it completes the color.

Observed Color of Compound

Color of Light Absorbed

Approximate Wavelength of Light Absorbed

Green

Red

700 nm

Blue-green

Orange-red

600 nm

Violet

Yellow

550 nm

Red-violet

Yellow-green

530 nm

Red

Blue-green

500 nm

Orange

Blue

450 nm

Yellow

Violet

400 nm

Visual Colorimetry Intensity: For light shining through a colored solution,the observed intensity of the color is found to be dependent on both the thickness of the absorbing layer (pathlength) and the concentration of the colored species. ←Side view

←Top view (a.k.a. Bird’s eye view)

For One Color: A series of solutions of a single color demonstrates the effect of either concentration or pathlength, depending on how it is viewed.

Visual Colorimetry ←Ratio used

←Purple produced

For more than one color: the ratio of an unknown mixture can also be determined by matching the shade of the color to those produced from known ratios. In this example, the ratio of a mixture of red and blue can be determined visibly by comparing the mixture to purples produced from known ratios of red and blue.

Dilution Factor (constant pathlength) 3 drops of dye std + 5 drops water 8 drops total volume

C(diluted) = (Vol Dye / Total Vol) x C(std) = (3 drops / 8 drops) x C(std)

Intensity: When the product of the concentration and the pathlength of any two solutions of a colored compound are the same, the same intensity or darkness of color is observed. Duboscq visual colorimeter

Adjustable Path Lengths

Spectrophotometry Spectrophotometer - an instrument that measures the amount of light absorbed, or the intensity of color at a given wavelength. The intensity of color can be given a numerical value by comparing the amount of light prior to ing it through the sample and after ing through the sample. These quantitative measurements of light absorbed are the Transmittance and the Absorbance.

Transmittance is given by the equation: T = I/Io where I is the intensity of the light after it has gone through the sample & Io is the initial light intensity. Absorbance is related to the %T: A = -logT = -log(I/ Io)

Absorbance Beer-Lambert Law (a.k.a. Beer's law) - the linear relationship between absorbance and concentration of an absorbing species.

A = abc A is the absorbance “a” is molar absorptivity in L/[(mole)(cm)] “b” is the path length in cm “c” is the concentration of the analyte (sample) in mol/L

“a” or molar absorptivity (1/M.cm) It is sometimes called “extinction coefficient” A wavelength dependent constant for the species being analyzed “” is also used in some texts for “a”.

“b” or path length (cm) The diameter of the cuvette or sample holder which is the distance the light travels through the absorbing sample. Becomes a constant when the same cuvette is used for all samples

“c” or concentration (M or mol/L) Generally the main use of Beer’s Law is to determine the concentration of various solutions

A Working Curve is produced by plotting the Absorbance vs. the Concentration.

From A Working Curve – one can determine the concentration of an unknown sample by knowing the absorption.

Equation Summary: T= (I/Io) = 10-A %T = (I/Io) x 100 A = -logT = log(1/T)

Note the scale for Absorbance: 9/10th of the scale is from 0-1 and 1/10th is from 1-2. For this reason, the spectrometers have been calibrated in % Transmittance and all readings will be taken in %Transmittance.

Spectronic 20 (a.k.a. Spec-20)

Spec-20 - A single-beam visible light spectrophotometer.



Tungsten filament lamp emits visible wavelengths of light.



Blank is inserted to adjust 100%Transmittance at each wavelength.



Simple Spectrophotometer Schematic

The lamp emits all colors of light (i.e., white light). The monochromator selects one wavelength and that wavelength is sent through the sample. The detector detects the wavelength of light that has ed through the sample. The amplifier increases the signal so that it is easier to read against the background noise.

Spectronic 20 Instructions (available next to each instrument) 1. With sample chamber empty, set desired wavelength then adjust to 0%T with left knob on front . 2. Insert blank solution, close lid and adjust 100%T with right knob on front . 3. Insert dye solutions, read and record %T values. 4. Change wavelength, repeat steps 2-4.

NOTE: Some digital instruments have a filter on the lower left of the front that must be changed midway through the wavelength range studied.

Plots of Absorption Data Plots similar to those on p. 8.9 will need to be generated in Excel. 1.4

#1

1.2

♦

1 0.8 Absorbance 0.6 0.4

#2

Plot of Abs. vs nm for Blue Dye

♦ ♦ ♦ ♦ ♦

0.2 ♦ ♦ ♦ ♦ ♦♦ ♦ ♦♦♦ 0 400 450 500 550 600 Wavelength (nm)

♦ ♦

650

700

1.6 ⊗ 1.4 1.2 ♦ ⊗ ⊗ 1 ⊗ 0.8 ♦ Absorbance 0.6 ♦ 0.4 ♦ ⊗ ⊗ 0.2 ♦ ♦ ♦ ⊗⊗ ♦ ♦ 0 ⊗ ⊗ ♦♦ ♦ ♦♦ ⊗⊗ ⊗ ⊗ -0.2 400 450 500 550 600 Wavelength (nm)

♦ ♦

♦ ⊗⊗ ⊗

650

1.6 ⊗ 1.4 1.2 ⊗ ⊗ 1 ⊗ 0.8 Absorbance 0.6 0.4 ⊗ ⊗ 0.2 ⊗ ⊗ 0⊗⊗ ⊗⊗ ⊗ ⊗ ⊗⊗ ⊗ ⊗ -0.2 400 450 500 550 600 650 700 Wavelength (nm)

#3

Overlay Plot of Blue and Red dye Abs. vs nm curves

⊗ ♦

700

Plot of Abs. vs nm for Red Dye

Plot of Abs. vs nm for Purple Red/Blue Dye mix

1 0.9 Θ 0.8 Θ 0.7 Θ Θ Θ 0.6 Absorbance 0.5 Θ Θ 0.4 Θ 0.3 Θ Θ 0.2 Θ Θ Θ Θ 0.1 Θ ΘΘ Θ 0 400 450 500 550 600 650 700 Wavelength (nm)

Checkout Visual Portion 1 - 12 well plate 3 - 12 well strips 5 - toothpicks* 5 - Beral pipets*

Spec-20s 5 - cuvettes 1 - pr forceps

*Don’t have to be returned. There aren’t enough cuvettes for all groups. So 1/2 will start with the Spec-20s and 1/2 will start with the visual portion.

Dyes - Located in Lab Blue std. = _____ ppm Red std. = _____ ppm

Waste Should be placed in labeled containers.

Formal Report This is a formal report. Follow given guidelines. (It will be due April 21-24.)

Next week Atomic Spectra (Green Packet 9.1 – 9.10)
