PC-BASED DIGITAL VIDEO RECORDER QUICK CONNECTION GUIDE

www.aventuratechnologies.com

Network

DVR Audio Out

Connect to router for optional remote viewing

B

D

A

C

BNC Cables

Optional Matrix Output

Audio Out Video Out Video Out

Power

Connect each BNC Output to a CCTV Monitor and Speaker

BNC Pigtail Cable BNC Pigtail Cable

Connect to UPS or power strip

VID1

Mouse

Keyboard

Speakers

Microphone

AID1

BNC A/V Input

A. Channels 1 to 4 B. Channels 5 to 8 C. Channels 9 to12 D. Channels 13 to 16 Connect and secure each pigtail cable to the DVR card. Each pigtail cable has 8 BNC inputs, 4 for video and 4 for audio. Connect each BNC Input to its respective video and audio source using a BNC cable or video balun. VID1 is Video for channel 1 AID1 is Audio for channel 1. VID2 is Video for channel 2 AID2 is audio for channel 2, etc.

Audio Source

VGA Monitor

BNC Cables Use optional speakers to hear live audio

Use optional microphone to talk to client DVRs

Please refer to the Aventura CD for additional information and a complete manual.

Camera
