1067

SideControl Positioner, electropneumatic positioner for pneumatic actuators • • • •

Type 1067 can be combined with...

Integral process controller (PID characteristic) Digital electronics Optional position Attachment to linear or rotary actuators to NAMUR (DIN IEC 534-6, VDI/VDE 3845) • Compact design • Choice of internal or external position sensor

Type 2702

Type 8805

Type 8323

Globe control valve

Angle seat valve

Rotary actuator

Pressure transmitter

acc. to NAMUR/IEC

The SideControl Positioner Type 1067 serves to position pneumatically actuated positioner valves. SideControl finds applications in many areas by attachment to Burkert process valves or to linear and rotary actuators to IEC 534 or VDI/VDE 3845, or coupled to a separate position sensor or pneumatic positioning system. The compact design of the aluminium

Technical data Materials Body Fluidic manifold Operating temperature Control medium Dust content Particle density Pressure dew point Oil concentration Pressure range Air flow capacity small large Control air consumption in equilibrium Port connection Flow: QNn-value for air (l/min) Operating voltage Electrical power consumption Signal input Setpoint for positioner and process controller Process value for PID controller binary input

Aluminium painted Aluminium anodized 0 to +60 °C Quality classes acc. to DIN ISO 8573-1 Class 4 (≤15 μm) Class 5 (≤10 mg/m3) Class 4 (≤+3°C ) Class 5 (≤25 mg/m3) -1 to 6 bar 35 l/min 70 l/min 0 l/min G 1/8 Measured at +20 °C, 6 bar pressure at valve inlet and 1 bar pressure difference 24 V DC < 10 W

body and the availability of versions for low air flow capacities enable attachment to positioning valves of small nominal diameter and size. The integral PID process controller may be activated to set up decentralized control loops.

Technical data Position sensor system Intern/Extern Electrical connection Type of protection Option Statement of pressure (bar) Positioner Rotation Ext. position sensor sys. Stroke PID controller Proportional action factor (amplification) Reset time Rate time Working point of controller

Rotary potentiometer with coupling shaft Screw terminals 1.5 mm2 2 PG9 bushings IP 65 Position binary/analog (4-20mA) Excess pressure to atmospheric Positioning range 0 to 180° 0 to 25 mm 0 to 50 mm Parameter range 0.0 to 999.9 0.5 to 999.9 0.0 to 999.9 0 to 100%

0 (4) to 20 mA oder 0 to 10 V 4 to 20 mA make or break

back

next

Process Valves, 5 Caulside Drive, Antrim, Northern Ireland, BT41 2DU www.process-valves.com, [email protected], Tel +44 (0) 28 9448 1809

1067 Functional diagram Process setpoint (external or internal)

External position setpoint

Position sensor system Actual position

Setpoint position

Process controller

Positioner

Input air

Positioning valve

Solenoid valves

Exhaust air

Sensor

Process value (e.g. pressure, flow rate, level, temperature)

Supplementary functions • Selection of a transfer characteristic (linear, equiprocentile or freely programmable) for correction of the flow or operating characteristic of the valve • Determination of a dead band for the setpoint • Tight closure function to assure tight closure of the valve • Determination of safety position to be assumed under certain circumstances • Determination of the direction of action of the setpoint or actual value • Splitting of the entire setpoint range over several positioners • Stroke limitation • Limitation of positioning speed • PID controller

Process Valves, 5 Caulside Drive, Antrim, Northern Ireland, BT41 2DU www.process-valves.com, [email protected], Tel +44 (0) 28 9448 1809

1067

Control function A (spring closing), single acting

external

Bürkert piston actuators (Type 2700, 2712) Globe control valves

Control function A (spring closing), single acting

external

Linear diaphragm actuators with mechanical interface acc. to DIN IEC 534-6

single acting

internal

double acting

internal

single acting

internal

double acting

internal

single acting

internal

double acting

internal

Linear diaphragm actuators with mechanical interface and “Analog position ” board

Ø 80 Ø 100 Ø 125 Ø 175 and Ø 225 Ø 80 Ø 100 Ø 125 Ø 175 and Ø 225 small, 14 l/min large, 35 l/min double, 70 l/min small, 14 l/min large, 35 l/min small, 14 l/min large, 35 l/min double, 70 l/m small, 14 l/min large, 35 l/min large, 35 l/min double, 70 l/m large, 35 l/min

449105 449105 550690 550690 449105 449105 550690 550690 447787 416947 420093 444210 416948 447787 416947 420093 444210 416948 428629 428630 428532

651713 653020 653020 655534 651713 653020 653020 655534 – – – – – – – – – – – – –

Item no. for associated attachment parts

Item no. for external position sensor system

Item no. for positioner

Actuator size [mm] Actuator version „„

Position sensor system

Bürkert piston actuators (Type 2730, 2731) Control diaphragm valves

Rotary actuators with bracket „ and mech. interface VDI/VDE 3845

„

Circuit function

Actuator type

Ordering table for positioner for attachment to a pneumatic actuator (other versions on request)

642769 642769 642768 550622 642769 642768 642768 550622 420153 420153 420153 420153 420153 420152 420152 420152 420152 420152 420153 420153 420153

The bracket (also known as bridge) usually belongs to the scope of delivery of the actuator manufacturer or should be obtained from there.

The air flow capacity of the positioner must be selected according to the actuator volume and version. This choice affects the dynamics and control performance of the entire control valve system. „„

Ordering chart for accessories Version

Item no.

Console VA VDI/VDE3845-ISO5211 FO5 for mounting the pneumatic actuator of ball valve Type 8805

672243

Ordering note On attachment to a Burkert positioning valve, the positioner SideControl 1067 is supplied only as a part of a complete control valve (positioner, position sensor system, associated attachment parts and positioning valve). For selection of a suitable positioning valve, please use the data sheets for the types 27XX. For ordering a complete control valve please write your specifications on the form supplied at the back of the separate datasheet. For ordering a complete control valve, please state • • • •

the item no. of the positioner SideControl Type 1067, the item no. of the position sensor system, the item no. of the selected control valve and the item no. of the associated attachment parts with the remark SideControl Type 1067 - control valve.

Burkert supplies a completely assembled and tested control valve.

Process Valves, 5 Caulside Drive, Antrim, Northern Ireland, BT41 2DU www.process-valves.com, [email protected], Tel +44 (0) 28 9448 1809

642292

1067 Dimensions

Lever

Body dimensions WxHxD= 125 x 80 x 80 mm3

M6

80

60.0d

36.0 Ø 50.0

G 1/8 32.5

125

NAMUR connection plate (rear side) of the positioner with internal position sensor system. The lever serves (with diaphragm actuators only) to convert the stroke into a rotation (0 to 60°). With rotary actuators, the rotation (0 to 90°) is taken from the actuator shaft by means of an adapter.
