D 901
Boiler Temperature Control (BTC 1PA, 2PA, 3PA, and 4PA)
09/02
The BTC products are designed to be mounted on single, two, three or four stage boilers in order to provide accurate water temperature control in a variety of applications. The controls may be used to provide a setpoint temperature, outdoor reset with reset override, or dedicated DHW generation. Up to two additional relay s may be included to operate the boiler pump and provide an alarm signal in case of a sensor failure.
Power: 24 V ±10% 50/60 Hz 75 VA Pump/Stage 1 relays: 120 V (ac) 5 A 1/6 hp pilot duty 240 VA Stage 2 to 4 relays: 120 V (ac) 3 A 1/6 hp Alarm relay: 24 V (ac) 3 A 1/6 hp Demand input: 20 to 260 V (ac) 2 VA
H3001A
Setp Dem
Four Stage BTC 4PA 158033
Item
Signal wiring must be rated at least 300 V
1 of 20
tektra 901-00 Made in Canada
© 2002
D 901 - 09/02
Introduction This brochure is organized into four main sections. They are: 1) Sequence of Operation, 2) Installation, 3) Control Settings, and 4) Troubleshooting. The Sequence of Operation section has 5 sub-sections. We recommend reading Section A: General of the Sequence of Operation, as this contains important information on the overall operation of the control. Then read the sub-sections that apply to your installation. The Control Settings section (starting at DIP Switch Settings) of this brochure describes the various items that are adjusted and displayed by the control. The control functions of each adjustable item are described in the Sequence of Operation.
Table Of Contents Table of Contents............................................Pg 2 Interface..................................................Pg 2 Description of Display Elements ..................Pg 3 Sequence of Operation ..................................Pg 4 Section A: General ................................Pg 4 Section B: Setpoint ...............................Pg 6 Section C: Dedicated DHW...................Pg 7 Section D: Outdoor Reset.....................Pg 7 Section E: External Boiler ....................Pg 8
Installation.......................................................Pg 8 Testing .............................................................Pg 9 Control Settings..............................................Pg 11 DIP Switch Setting.................................Pg 11 View Menu ..............................................Pg 11 Adjust Menu ...........................................Pg 12 Error Messages...............................................Pg 14 Typical Applications.......................................Pg 15 Technical Data ................................................Pg 20
Interface The BTC uses a Liquid Crystal Display (LCD) as a method of supplying information. You use the LCD in order to setup and monitor the operation of your system. The BTC uses three push buttons (Item, ▲, ▼) for selecting and adjusting settings. As you program your control, record your settings in the actual settings column of the Adjust menu. The table is found in the second half of this brochure.
Menu All of the items displayed by the control are organized into two menus. These menus are listed on the upper right hand side of the display (Menu Field). The default menu for the BTC is the View menu. While in the View menu, the VIEW segment is displayed. To select the Adjust menu, press and hold simultaneously all three buttons for 1 second. The display then advances to the Adjust menu and the ADJUST segment is turned on in the display. The display will automatically revert back to the View menu after 20 seconds of keypad inactivity. Once in a menu, there will be a group of items that can be viewed within that menu.
Item The abbreviated name of the selected item will be displayed in the item field of the display. To view the next available item, press and release the Item button. Once you have reached the last available item in a menu, pressing and releasing the Item button will return the display to the first item in the selected menu.
Adjust To make an adjustment to a setting in the control, begin by selecting the Adjust menu by pressing and holding simultaneously all three buttons. Then select the desired item using the Item button. Finally, use the ▲ or ▼ button to make the adjustment.
Item
Item
Item
Additional information can be gained by observing the Status field of the LCD. The status field will indicate which of the control’s outputs are currently active. Most symbols in the status field are only visible when the View menu is selected. © 2002
D 901 - 09/02
2 of 20
Display
Setp Dem
Symbol Description Pump Displays when the boiler pump is in operation.
,
°F, °C Units of measurement.
Burner
Pointer
Displays when the stage 1 and/or 2, 3, 4 relay is turned on.
Displays the operation as indicated by the text.
3 of 20
© 2002
D 901 - 09/02
Sequence of Operation
Section A
Section B
Section C
Section D
Section E
General Operation Page 4 - 5
Setpoint Operation Page 6
Dedicated DHW Page 7
Outdoor Reset Page 7
External Boiler Operation Page 8
Section A: General POWERING UP THE CONTROL When the BTC is powered up, the control turns on all segments in the display for 2 seconds. Next, the software version is displayed for 2 seconds. Finally, the control enters into the normal operating mode.
MODES OF OPERATION (MODE) The BTC series of controls allows for six modes of operation in order to define the control operation and piping arrangement used. The piping arrangement can be categorized into parallel and primary / secondary. The mode of operation is selected using the MODE item in the Adjust menu. The temperature being controlled out to the heating system is measured by the operating sensor. The piping arrangement determines which sensor the BTC uses as the operating sensor. The operating sensor is either the boiler outlet sensor or the boiler supply sensor. (see page 15 and 16 for typical applications) Boiler Outlet Sensor
Parallel In parallel piping applications, the boiler outlet temperature is typically the same temperature that is being delivered out to the system. Therefore, the operating sensor in parallel piping applications is the boiler outlet sensor.
Primary / Secondary In primary / secondary applications, the boiler outlet temperature is typically higher than the primary loop temperature. Therefore, the BTC uses an additional sensor (boiler supply) to measure the temperature delivered out to the system. The operating sensor in primary / secondary piping applications is the boiler supply sensor.
Boiler Inlet Sensor
Boiler Supply Sensor
Boiler Outlet Sensor
Boiler Inlet Sensor
Mode 1 (MODE = 1) Mode 1 is designed for setpoint operation using parallel piping. Once a heat demand signal is present, the control operates the boiler stages to maintain a fixed temperature at the boiler outlet sensor. Refer to section B for a description of setpoint operation.
Mode 2 (MODE = 2) Mode 2 is designed for setpoint operation using primary / secondary piping. Once a heat demand signal is present, the control operates the boiler stages to maintain a fixed temperature at the boiler supply sensor. Refer to section B for a description of setpoint operation. Boiler Outlet Sensor
Mode 3 (MODE = 3) Mode 3 is designed for dedicated DHW operation using parallel piping. The control operates the boiler stages based on the boiler outlet sensor to maintain a tank temperature at the DHW sensor. Refer to section C for a description of dedicated DHW operation.
DHW Sensor Boiler Inlet Sensor
Mode 4 (MODE = 4) Mode 4 is designed for outdoor reset and reset override operation using parallel piping. Once a heat demand is present, the control operates the boiler stages to maintain an outdoor reset temperature at the boiler outlet sensor. Once a setpoint demand (reset override) is present, the control operates the boiler stages to maintain a setpoint temperature at the boiler outlet sensor. If both a heat demand and a setpoint demand are present at the same time, the control targets the higher of the two requirements. Refer to section D for a description of outdoor reset operation.
Mode 5 (MODE = 5) Mode 5 is designed for outdoor reset and reset override operation using primary / secondary piping. Once a heat demand is present, the control operates the boiler stages to maintain an outdoor reset temperature at the boiler supply sensor. Once a setpoint demand (reset override) is present, the control operates the boiler stages to maintain a setpoint temperature at the boiler supply sensor. If both a heat demand and a setpoint demand are present at the same time, the control targets the higher of the two requirements. Refer to section D for a description of outdoor reset operation. © 2002
D 901 - 09/02
4 of 20
Mode 6 (MODE = 6)
Boiler Outlet Sensor
Boiler Outlet Sensor
Mode 6 is designed for external boiler control. This mode of operation allows for an external control to operatemultiple boilers equipped with a BTC. The BTC is used to provide boiler pump control. Once a heat demand is present, the control closes the Stg 1 Stg 1 and operates the boiler pump. Refer to section E for a description of external boiler operation.
il e Bo
160˚F (71˚C)
rO n
165˚F (74˚C)
Differential = 10˚F (5˚C)
rO n
Target temperature 160˚F (71˚C)
Bo il e
An on / off heat source must be operated with a differential in order to prevent short cycling. The boiler differential is divided around the boiler target temperature. The first stage will close when the water temperature at the operating sensor is 1/2 of the differential setting below the boiler target temperature, and will open when the water temperature at the operating sensor is 1/2 of the differential setting above the boiler target temperature. The remaining stages will operate sequentially based on the staging mode selected.
155˚F (68˚C) Time
Supply Water Temperature
BOILER DIFFERENTIAL (DIFF)
STAGING MODE (STGMODE) The BTC controls can operate up to four stages in order to supply the required target temperature. The method of staging used by the control is either P (proportional) or PID (proportional & Integral & Derivative), and is selected using the STGMODE item in the Adjust menu.
Proportional (P) Proportional staging, also known as step staging, is based on manually adjusted settings which determine when the next stage is required to turn on. These manual settings are based on temperature and time. The interstage differential sets the temperature drop at which the next stage turns on. However, in order for a stage to fire, the interstage delay on and minimum off times must first elapse.
Interstage Differential (STG DIFF) The interstage differential is the temperature drop at which the next stage will turn on. Once a stage turns on, the next stage cannot turn on until the temperature drops the interstage differential below the temperature at which the previous stage turned on. The interstage differential is adjustable through the STG DIFF setting in the Adjust menu.
Target temperature 160˚F (71˚C)
Boiler Differential = 10˚F (5˚C)
165˚F (74˚C) Stg 1 OFF
163˚F (73˚C)
Stg 2 OFF
160˚F (71˚C)
Interstage Delay On (ON DLY) The interstage delay on is the amount of time that must elapse before turning on the next stage. Once a stage turns on, the next stage cannot turn on until the interstage delay on time elapses. The interstage delay on is adjustable through the ON DLY setting in the Adjust menu.
155˚F (68˚C) 153˚F (67˚C)
Stg 1 ON Stg 2 ON
Time
Interstage Differential = 2°F
Interstage Delay Off (OFF DLY) The interstage delay off is the amount of time that must elapse before turning off the next stage. Once a stage turns off, the next stage cannot turn off until the interstage delay off time elapses. The interstage delay off is adjustable through the OFF DLY setting in the Adjust menu.
Minimum On Time (MIN ON) The minimum on time is the minimum amount of time that a stage must be on before it is allowed to turn off. Once a stage turns on, it cannot turn off until a minimum on time elapses. The minimum on time is adjustable through the MIN ON setting in the Adjust menu.
Minimum Off Time (MIN OFF) The minimum off time is the minimum amount of time that a stage must be off before it is allowed to turn on. Once a stage turns off, it cannot turn on until a minimum off time elapses. The minimum off time is adjustable through the MIN OFF setting in the Adjust menu.
Proportional & Integral & Derivative (PID) PID staging allows the control to determine when the next stage is required to turn on. The BTC automatically determines the settings that are manually selected in proportional staging mode. After each stage is turned on in the firing sequence, the control waits a minimum amount of time before turning on the next stage. After the minimum time delay between stages has expired, the BTC examines the control error to determine when the next stage is to fire. The control error is determined using PID logic. Proportional compares the actual operating sensor temperature to the boiler target temperature. The colder the temperature, the sooner the next stage is turned on. Integral
compares the actual operating sensor temperature to the boiler target temperature over a period of time.
Derivative
determines how fast or slow the operating sensor temperature is changing. If the temperature is increasing slowly, the next stage is turned on sooner. If the temperature is increasing quickly, the next stage is turned on later, if at all. 5 of 20
© 2002
D 901 - 09/02
Boiler Mass (BOIL MASS) The boiler mass setting allows the installer to adjust the control to the thermal mass of different types of heat sources used. The boiler mass setting automatically determines the interstage differential, interstage delay on, interstage delay off, minimum on time and minimum off time of the stages when PID staging is used. A higher thermal mass setting provides slower staging, while a lower thermal mass provides faster staging.
The BOIL MIN is the lowest water temperature that the control is allowed to use as a boiler target temperature. During mild conditions, if the BTC calculates a boiler target temperature that is below the BOIL MIN setting, the boiler target temperature is adjusted to at least the BOIL MIN setting. During this condition, if the boiler is operating, the MIN segment turns on in the LCD while the boiler target temperature or boiler operating sensor temperature is viewed. If the installed boiler is designed for condensing or low temperature operation, set the BOIL MIN adjustment to OFF.
BOIL MIN
WWSD
BOILER MAXIMUM (BOIL MAX)
Increasing Water Temperature
BOIL MAX
BOILER MINIMUM (BOIL MIN)
Decreasing Outdoor Temperature
The BOIL MAX is the highest water temperature that the control is allowed to use as a boiler target temperature. If the control does target BOIL MAX, and the boiler outlet sensor is near the BOIL MAX temperature, the MAX segment turns on in the LCD while the boiler target, boiler inlet, boiler outlet or boiler supply temperature is viewed.
BOILER TARGET TEMPERATURE (BOIL TARGET) The boiler target temperature is determined from the mode of operation. The control displays the temperature that it is currently trying to maintain at the operating sensor as BOIL TARGET in the View menu. The operating sensor for modes 1, 3 and 4 is the boiler outlet sensor, and the operating sensor for modes 2 and 5 is the boiler supply sensor. If the control does not presently have a requirement for heat, it displays “---” in the LCD. There is no boiler target temperature generated in Mode 6.
BOILER PUMP OPERATION The boiler pump (Pmp Pmp) operates based on the mode of operation selected. During setpoint operation (modes 1 and 2), the boiler pump closes whenever there is a heat demand. During dedicated DHW operation (mode 3), the boiler pump closes whenever there is an internal heat demand. During outdoor reset (modes 4 and 5), the boiler pump closes whenever there is either a heat demand and the BTC is not in Warm Weather Shut Down (WWSD), whenever there is a setpoint demand. During Warm Weather Shut Down, if the boiler pump has not operated at least once every 70 hours, the control turns on the output for 10 seconds. This minimizes the possibility of the pump seizing during a long period of inactivity. During External Boiler Operation (Mode 6), the boiler pump closes whenever there is a heat demand.
Boiler Purge (PUMP DLY) After a demand is satisfied, the BTC continues to operate the boiler pump for a period of time. The length of time that the boiler pump continues to run is based on the pump DLY setting. Once the last stage of the boiler turns off, the control keeps the boiler pump running for the time selected. This setting allows purging of any excess heat out of the boiler after the boiler is shut off. This also helps to prevent the water in the boiler from flashing into steam after the boiler is shut off. When OFF is selected, there is no purging. When ON is selected, pump operation is continuous. Also, during outdoor reset and the pump DLY is set to ON, the pump continues to run even during Warm Weather Shut Down.
Boiler Purge (∆T MIN) After a demand is satisfied, the BTC continues to operate the boiler pump for a period of time. The length of time that the boiler pump continues to run is based on the ∆T MIN setting. The control uses the ∆T (temperature difference) between the boiler inlet and the boiler outlet to determine the amount of purging required. Once the last stage of the boiler turns off, the control keeps the boiler pump running until the ∆T drops below the ∆T minimum setting for a minimum of 20 seconds. This setting allows purging of any excess heat out of the boiler after the boiler is shut off. This also helps to prevent the water in the boiler from flashing into steam after the boiler is shut off. Note: Boiler purge based on ∆T MIN is available in certain models. If the BTC model incorporates the ∆T MIN purging, the PUMP DLY purging will not be available.
Section B: Setpoint Operation When either mode 1 or 2 is selected, the BTC controls the water temperature based on a fixed setpoint. The setpoint temperature is set using the BOIL TARGET item in the Adjust menu.
HEAT DEMAND A heat demand is required whenever heat is required for the setpoint load. A heat demand is generated when a voltage between 24 and 240 V (ac) is applied across the CD (common demand) and the Ht D (heat demand) terminals (1 and 2). Once voltage is applied, the BTC turns on the Dem segment in the display. The BTC closes the Pmp Pmp s, which starts the boiler pump and the control turns on the boiler pump segment in the display. The BTC then operates the boiler stages to maintain the setpoint temperature.
© 2002
D 901 - 09/02
6 of 20
Section C: Dedicated Domestic Hot Water (DHW) Operation When mode 3 is selected, the BTC provides dedicated DHW operation.
INTERNAL DHW DEMAND A sensor is required to be connected on the Com and the Sup/D terminals (4 and 6). An internal demand for DHW is generated when the temperature at the DHW sensor drops 1/2 of the tank differential setting below the desired DHW tank temperature. The TANK TARGET setting is used to set the desired DHW tank temperature. Once an internal demand is generated, the Dem segment turns on in the LCD. The BTC then closes the Pmp Pmp , which starts the boiler pump and the control turns on the boiler pump segment in the display. The BTC then operates the boiler stages to maintain the programmed boiler target temperature at the boiler outlet sensor. The boiler target temperature is set using the BOIL TARGET item in the Adjust menu. Note An external demand is not required in this mode of operation.
TANK DIFFERENTIAL (TANK DIFF) A differential setting that operates 1/2 above and below the TANK TARGET is selectable using the TANK DIFF item in the Adjust menu.
Section D: Outdoor Reset Operation When either mode 4 or 5 is selected, the BTC uses outdoor reset to control the water temperature. Outdoor reset adjusts the target temperature based on the outdoor air temperature and reset ratio. The reset ratio is determined from the Boiler Start, Boiler Design, Outdoor Start and Outdoor Design settings.
HEAT DEMAND A heat demand is required whenever heat is required in the system. A heat demand is generated when a voltage between 24 and 240 V (ac) is applied across the CD (common demand) and the Ht D (heat demand) terminals (1 and 2). Once voltage is applied, the BTC turns on the Dem segment in the display. If the BTC is not in warm weather shut down (WWSD), it closes the Pmp Pmp , which starts the boiler pump and the control turns on the boiler pump segment in the display. The BTC then operates the boiler stages to maintain the boiler target temperature.
BOILER START (BOIL START) The BOIL START temperature is the theoretical boiler supply water temperature that the heating system requires when the outdoor air temperature equals the OUTDR START temperature setting. The BOIL START is typically set to the desired building temperature.
OUTDOOR START (OUTDR START) The OUTDR START temperature is the outdoor air temperature at which the control provides the BOIL START water temperature to the system. The OUTDR START is typically set to the desired building temperature.
OUTDOOR DESIGN (OUTDR DSGN) The OUTDR DSGN is the outdoor air temperature that is the typical coldest temperature of the year where the building is located. This temperature is used when doing heat loss calculations for the building.
OUTDR DSGN BOIL START
OUTDR START Decreasing Outdoor Temperature
Increasing Water Temperature
BOIL DSGN
BOILER DESIGN (BOIL DSGN) The BOIL DSGN temperature is the water temperature required to heat the boiler zones when the outdoor air is as cold as the OUTDR DSGN temperature.
WARM WEATHER SHUT DOWN (WWSD) When the outdoor air temperature rises above the WWSD setting, the BTC turns on the WWSD segment in the display. When the control is in Warm Weather Shut Down, the Dem segment is displayed if there is a heat demand. However, the control does not operate the heating system to satisfy this demand. The control does respond to a setpoint demand and operates as described below.
RESET OVERRIDE (SETPOINT DEMAND) A setpoint demand is required whenever heat is required for the setpoint load. The setpoint demand overrides the reset water temperature. A setpoint demand is generated when a voltage between 24 and 240 V (ac) is applied across the CD (common demand) and the Set D (setpoint demand) terminals (1 and 3). Once voltage is applied, the BTC turns on the Setp Dem pointer in the display. The BTC closes the Pmp Pmp , which starts the boiler pump and the control turns on the boiler pump segment in the display. The BTC then operates the boiler stages to maintain the programmed boiler target temperature. The reset override operation is not affected by WWSD.
7 of 20
© 2002
D 901 - 09/02
Section E: External Boiler Operation When mode 6 is selected, the BTC allows for an external boiler control to operate the boiler stages. In this mode, the BTC operates the boiler pump in order to provide purging and exercising. The staging operation is provided by an external device such as an Energy Management System (EMS) or Boiler Staging control.
HEAT DEMAND A heat demand is generated when a voltage between 24 and 240 V (ac) is applied across the CD (common demand) and the Ht D (heat demand) terminals (1 and 2). Once voltage is applied, the BTC turns on the Dem segment in the display. The BTC closes the Pmp Pmp , which starts the boiler pump and the control turns on the boiler pump segment in the display. The BTC also closes the Stg 1 Stg 1 , which turns on stage 1 of the boiler. The Stg 1 Stg 1 is closed as long as the heat demand is present.
Installation ELECTRICAL CONNECTIONS TO THE CONTROL The installer should test to confirm that no voltage is present at any of the wires during installation. The BTC includes a 24 pin connector for ease of installation.
12 C 11 10 9 Com 8 Boil in 7 Boil O 6 Sup/D 5 Os 4 Com 3 Set D 2 Ht D 1 CD
24 R 23 Alarm 22 Stg 4 21 Stg 4 20 Stg 3 19 Stg 3 18 Stg 2 17 Stg 2 16 Stg 1 15 Stg 1 14 Pmp 13 Pmp
Powered Input Connections 24 V (ac) Power Connect the 24 V (ac) power supply to the C and R terminals (12 and 24). This connection provides power to the microprocessor and display of the control. As well, this connection provides power to the Alarm terminal (25) from the R terminal (24).
Heat Demand To generate a heat demand, a voltage between 24 V (ac) and 240 V (ac) must be applied across the CD (common demand) and the Ht D (heat demand) terminals (1 and 2).
R
C
12
C
24 to 240 V(ac) 2 Ht D 1 CD
Setpoint Demand To generate a setpoint demand, a voltage between 24 V (ac) and 240 V (ac) must be applied across the CD (common demand) and the Set D (setpoint demand) terminals (1 and 3).
24 to 240 V(ac) 3 Set D 2 Ht D 1 CD
Caution: The same power supply must be used for both the heat demand and setpoint demand circuits since they share the CD (common demand) terminal.
Output Connections Boiler Pump The Pmp Pmp terminals (13 and 14) are an isolated output in the BTC. There is no power available on these terminals from the control. These terminals are to be used as a switch to either make or break power to the boiler pump. Since this is an isolated , it may switch a voltage between 24 V (ac) and 120 V (ac). © 2002
D 901 - 09/02
8 of 20
N L
14 Pmp 13 Pmp
24 R
Boiler s The Stg 1 Stg 1, Stg 2 Stg 2, Stg 3 Stg 3, and Stg 4 Stg 4 terminals (15 and 16, 17 and 18, 19 and 20, 21 and 22) are isolated outputs in the BTC. There is no power available on these terminals from the control. These terminals are to be used as a switch to either make or break the boiler circuit. When the BTC requires boiler stages to fire, it closes the between the appropriate terminals.
stage 4
22 Stg 4
stage 3
21 Stg 4 20 Stg 3
Alarm The Alarm terminal (23) on the BTC is a powered output. When the relay in the BTC closes, 24 V (ac) from the R terminal (24) is provided to the Alarm terminal (23). To operate the alarm, connect one side of the alarm circuit to the Alarm terminal (23) and the second side of the alarm circuit to the common (C) side of the 24 V (ac) power supply.
Sensor and Unpowered Input Connections
19 Stg 3 18 Stg 2 17 Stg 2 16 Stg 1
stage 2
15 Stg 1
stage 1
Do not apply power to these terminals as this damages the control.
Outdoor Sensor Connect the two wires from the Outdoor Sensor 070 to the Com (common sensor) and Os (outdoor sensor) terminals (4 and 5). The outdoor sensor is used by the BTC to measure the outdoor air temperature.
9 Com
Boiler Outlet Sensor
8 Boil in 7 Boil O
Boiler Outlet Sensor Connect the two wires from the Boiler Outlet Sensor 071 to the Com (common sensor) and Boil O (boiler outlet sensor) terminals (9 and 7). The boiler outlet sensor is used by the BTC to measure the boiler outlet water temperature from the boiler. Note: The boiler outlet sensor is required for every mode of operation.
Boiler Inlet Sensor
9 Com
Connect the two wires from the Boiler Inlet Sensor 071 to the Com (common sensor) and Boil in (boiler inlet sensor) terminals (9 and 8). The boiler inlet sensor is used by the BTC to measure the boiler inlet water temperature to the boiler.
8 Boil in
Boiler Inlet Sensor
Note: The boiler inlet sensor is required for every mode of operation.
Boiler Supply / DHW Sensor Either a Boiler Supply Sensor 071 or DHW Sensor 071 may be connected to the BTC. If a sensor is used, connect the two wires from the sensor to the Com (common sensor) and Sup/D (boiler supply/DHW sensor) terminals (4 and 6).
6 Sup/D
6 Sup/D
5 Os
5 Os
4 Com
Boiler Outlet Sensor
Boiler Outlet Sensor
OR Tank Sensor
Boiler Supply Sensor
4 Com
Boiler Inlet Sensor
Boiler Inlet Sensor
TESTING The wiring harness must be unplugged from the connector on the control before testing. To remove the wiring harness, push down on the tab which fits over the tab on the connector from the control and pull away form the control. The following tests are performed using standard testing practices and procedures and should only be carried out by properly trained and experienced persons. A good quality electrical test meter, capable of reading from at least 0 - 300 V (ac) and at least 0 - 2,000,000 Ohms, is essential to properly test the wiring and sensors.
Test the Sensors In order to test the sensors, the actual temperature at each sensor location must be measured. A good quality digital thermometer with a surface temperature probe is recommended for ease of use and accuracy. First measure the temperature using the thermometer and then measure the resistance of the sensor at the control. Using the chart below, estimate the temperature measured by the sensor. The sensor and the thermometer readings should be close. If the meter reads a very high resistance, there may be a broken wire, a poor wiring connection or a defective sensor. If the resistance is very low, the wiring may be shorted, there may be moisture in the sensor or the sensor may be defective. To test for a defective sensor, measure the resistance directly at the sensor location. 9 of 20
9 Com 8 Boil in
© 2002
D 901 - 09/02
Temperature °F -50 -40 -30 -20 -10 0 10
Resistance
Temperature
Resistance
Temperature
°C
Ω
°F
°C
Ω
°F
°C
-46 -40 -34 -29 -23 -18 -12
490,813 336,606 234,196 165,180 118,018 85,362 62,465
20 30 40 50 60 70 80
-7 -1 4 10 16 21 27
46,218 34,558 26,099 19,900 15,311 11,883 9,299
90 100 110 120 130 140 150
32 38 43 49 54 60 66
Resistance Ω 7,334 5,828 4,665 3,760 3,050 2,490 2,045
Resistance
Temperature °F
°C
Ω
160 170 180 190 200 210 220
71 77 82 88 93 99 104
1,689 1,403 1,172 983 829 703 598
Test the Power Supply Make sure exposed wires and bare terminals are not in with other wires or grounded surfaces. Turn on the power and measure the voltage between the C and R terminals (12 and 24) using an AC voltmeter, the reading should be between 22 and 26 V (ac). 22 to 26 V (ac) 12
C
24 R
Test the Powered Inputs Heat Demand If a heat demand is used, measure the voltage between the CD (common demand) and the Ht D (heat demand) terminals (1 and 2). When the heat demand device calls for heat, you should measure between 20 and 260 V (ac) at the terminals. When the heat demand device is off, you should measure less than 5 V (ac).
Setpoint Demand If a setpoint demand is used, measure the voltage between the CD (common demand) and the Set D (setpoint demand) terminals (1 and 3). When the setpoint demand device calls for heat, you should measure between 20 and 260 V (ac) at the terminals. When the setpoint demand device is off, you should measure less than 5 V (ac).
20 to 260 V (ac) 2 Ht D 1 CD
Connecting the Control Make sure all power to the devices and wiring harness is off. Reconnect the wiring harness to the connector on the control by aligning the tab on the wiring harness to the tab on the connector on the control and then pushing the wiring harness into the connector on the control. The tab on the wiring harness should snap over the tab on the connector of the control Apply power to the control. The operation of the control on power up is described in the Sequence of Operation section of the brochure.
Testing the Control’s Outputs The BTC has a built-in test routine which is used to the main control functions. The test sequence is enabled when the ▲ button is pressed and held while in the View menu. The outputs are tested in the following sequence: Step 1: After 1 second, the pump is turned on. Step 2: After 4 seconds, Stage 1 is turned on. Step 3: After 7 seconds, Stage 2 is turned on. Step 4: After 10 seconds, Stage 3 is turned on. Step 5: After 13 seconds, Stage 4 is turned on. Step 6: After 16 seconds, the Alarm is turned on. Step 7: After the ▲ button is released, the control continues normal operation.
© 2002
D 901 - 09/02
10 of 20
Control Settings DIP SWITCH SETTING Note: DIP switches may be located either on the front or back of the control.
(A) Advanced / Installer The Advanced / Installer DIP switch is used to select which items are available to be viewed and / or adjusted in the interface. The Advanced Access Level includes all the settings available in the control. The Installer Access Level includes the settings and items which are required for system setup.
B A
OFF OFF
Advanced
Installer
(B) DIP switch B is not used In some cases, depending on the boiler the BTC is installed into, DIP switch B may be used for additional features.
View Menu (1 of 1)
Se ct IN ion ST AD V
Item Field
Access Level
Description
Current outdoor air temperature as measured by the outdoor sensor. This is the default display for the control. MODE = 4, 5
A
Target boiler supply is the temperature the control is currently trying to maintain at the boiler supply sensor or the boiler outlet sensor.
Range
-60 to 190°F (-51 to 88°C)
---, 35 to 226°F (2 to 108°C)
MODE = 1, 2, 3, 4, 5
A
Current boiler supply water temperature as measured by the boiler supply sensor. MODE = 2, 5
A
Current boiler outlet water temperature as measured by the boiler outlet sensor. MODE = 1, 3, 4, 6 (Installer Level) MODE = 2, 5 (Advanced Level)
14 to 266°F (-10 to 130°C)
14 to 266°F (-10 to 130°C)
A
Current boiler inlet water temperature as measured by the boiler inlet sensor.
14 to 266°F (-10 to 130°C)
A
Current ∆T (temperature difference) between the boiler outlet sensor and the boiler inlet sensor.
-99 to 252°F (-55 to 140°C)
A
Current DHW tank temperature as measured by the DHW sensor. MODE = 3
The total number of running hours of the boiler since this item was last cleared.
11 of 20
14 to 266°F (-10 to 130°C)
0 to 999
© 2002
D 901 - 09/02
Adjust Menu (1 of 2)
Se ct IN ion S AD T V
Item Field
Access Level
Description
A
Sets the operating mode for the control.
A
Selects the staging operation to be either automatic or manual. MODE = 1, 2, 3, 4, 5
A
Minimum boiler target temperature during reset override, setpoint or DHW operation. MODE = 1, 2, 3, 4, 5
C
Sets the DHW storage tank’s temperature. MODE = 3
C
D
Sets the differential for the DHW storage tank. MODE = 3
The outdoor starting temperature used in the reset ratio for the heating system.
Range
1, 2, 3, 4, 5, 6
PID (automatic staging) P (manual staging)
OFF, 70 to 220°F (OFF, 21 to 104°C)
OFF, 70 to 190°F (OFF, 21 to 88°C)
2 to 10°F (1 to 6°C)
35 to 85°F (2 to 29°C)
MODE = 4, 5
D
The design outdoor air temperature used in the heat loss calculations for the heating system. MODE = 4, 5
D
The starting water temperature used in the reset ratio calculation for the heating system. MODE = 4, 5
D
The design water temperature used in the heat loss calculations for the heating system. MODE = 4, 5
A
A
The maximum boiler target water temperature. MODE = 1, 2, 3, 4, 5
The minimum temperature allowed for the boiler target temperature. MODE = 1, 2, 3, 4, 5
© 2002
D 901 - 09/02
12 of 20
-60 to 32°F (-51 to 0°C)
35 to 150°F (2 to 66°C)
70 to 220°F (21 to 104°C)
120 to 225°F, OFF (49 to 107°C, OFF)
OFF, 80 to 180°F (OFF, 27 to 82°C)
Actual Setting
Adjust Menu (2 of 2)
Se ct IN ion S AD T V
Item Field
Access Level
A
Description
The thermal mass of the boiler used. MODE = 1, 2, 3, 4, 5 and STGMODE = PId
A
The differential that the control is to use when it is operating the boiler. MODE = 1, 2, 3, 4, 5
A
The interstage differential that the control is to use when it is operating the boiler. MODE = 1, 2, 3, 4, 5 and STGMODE = P
A
The interstage delay that the control is to use when an additional stage is required to turn on. MODE = 1, 2, 3, 4, 5 and STGMODE = P
A
The interstage delay that the control is to use when a stage is required to turn off. MODE = 1, 2, 3, 4, 5 and STGMODE = P
A
The minimum on time for each stage when manual staging is selected. MODE = 1, 2, 3, 4, 5 and STGMODE = P
A
The minimum off time for each stage when manual staging is selected. MODE = 1, 2, 3, 4, 5 and STGMODE = P
Range
1 (light mass) 2 (medium mass) 3 (heavy mass)
2 to 42°F (1 to 23°C)
0 to 10°F (0 to 6°C)
0:10 to 8:00 minutes
0:10 to 4:00 minutes
0:10 to 5:00 minutes
0:10 to 5:00 minutes
A
Determines when to stop purging.
OFF, 0:20 to 9:55 min, On
A
Determines how long to purge based on the ∆T (temperature difference). This setting may appear in some models. If this setting is present, the pump DLY setting above will not be available.
2 to 20°F, OFF (1 to 11°C)
D
The system’s warm weather shut down. MODE = 4, 5
The units of measure that all of the temperatures are to be displayed in by the control.
13 of 20
Actual Setting
35 to 100°F, OFF (2 to 38°C, OFF)
°F, °C
© 2002
D 901 - 09/02
Error Displayed
Description of Error The control was unable to read a piece of information from its EEPROM. The control will stop operation until all settings in the Adjust menu have been checked by the or installer.
The control is no longer able to read the boiler outlet sensor due to a short circuit. In this case, if the boiler inlet sensor is present and operational, the control will operate using the boiler inlet sensor. Otherwise, the control will not operate the boiler stages.
The control is no longer able to read the boiler outlet sensor due to an open circuit. In this case, if the boiler inlet sensor is present and operational, the control will operate using the boiler inlet sensor. Otherwise, the control will not operate the boiler stages.
The control is no longer able to read the boiler inlet sensor due to a short circuit. In this case, the control will continue operation.
The control is no longer able to read the boiler inlet sensor due to an open circuit. In this case, the control will continue operation.
The control is no longer able to read the boiler supply sensor due to a short circuit. In this case, if the boiler outlet sensor is present and operational, the control will operate based on the boiler outlet sensor. If the boiler outlet sensor is not available and the boiler inlet sensor is present and operational, the control will operate using the boiler inlet sensor. Otherwise, the control will not operate the boiler stages.
The control is no longer able to read the boiler supply sensor due to an open circuit. In this case, if the boiler outlet sensor is present and operational, the control will operate based on the boiler outlet sensor. If the boiler outlet sensor is not available and the boiler inlet sensor is present and operational, the control will operate using the boiler inlet sensor. Otherwise, the control will not operate the boiler stages.
The control is no longer able to read the outdoor sensor due to a short circuit. In this case the control assumes an outdoor temperature of 32°F and continues operation.
The control is no longer able to read the outdoor sensor due to an open circuit. In this case the control assumes an outdoor temperature of 32°F and continues operation.
The control is no longer able to read the tank sensor due to a short circuit. In this case the control will not operate the boiler stages.
The control is no longer able to read the tank sensor due to an open circuit. In this case the control will not operate the boiler stages.
© 2002
D 901 - 09/02
14 of 20
Applications —Mechanical The following are only mechanical and electrical concept drawings, not engineered drawings. They are not intended to describe a complete system, nor any particular system. It is up to the designer to determine the necessary components for and configuration of the particular system being designed, including additional equipment, isolation relays (for loads greater than the control’s specified output ratings), and any safety devices which in the judgement of the designer are appropriate, in order to properly size, configure and design that system and to ensure compliance with building and safety code requirements.
MODE 2
MODE 1 BTC
BTC
M
M
Boiler Supply Sensor
Boil Out Sensor
Boil Out Sensor
Boil In Sensor Boil In Sensor
MODE 4
MODE 3 BTC
BTC Outdoor Sensor
Thermostat
DHW Sensor
Boil Out Sensor
Boil Out Sensor
Boil In Sensor
Boil In Sensor
15 of 20
© 2002
D 901 - 09/02
Application —Mechanical MODE 5 BTC Outdoor Sensor
Relay
DHW Aquastat Boiler Supply Sensor
Boil Out Sensor
Boil In Sensor
MODE 6
268
BTC
BTC
Outdoor Sensor
Boiler Out Sensor
Boiler Supply Sensor
© 2002
D 901 - 09/02
Boiler In Sensor
16 of 20
Boiler Out Sensor
Boiler In Sensor
Com Boil in Boil O Sup/D Os Com Set D Ht D CD
C
17 of 20
© 2002
120 V (ac) L
N
C
R
24 R 23 Alarm 22 Stg 4 21 Stg 4 20 Stg 3 19 Stg 3 18 Stg 2 17 Stg 2 16 Stg 1 15 Stg 1 14 Pmp 13 Pmp
24 V (ac)
Class II Transformer
12 11 10 9 8 7 6 5 4 3 2 1
Boiler #1
Electrical A1, A2 = Alarms P1 = Primary Pump P2, P3 = Boiler Pumps S1 = Outdoor Sensor 070 S2 = Boiler Supply Sensor 071 S3, S5 = Boiler Outlet Sensor 071 S4, S6 = Boiler Inlet Sensor 071 T1 = Thermostat
stage 1
stage 2
stage 3
stage 4
P3
A1
S4
S3
12 C 11 10 9 Com 8 Boil in 7 Boil O 6 Sup/D 5 Os 4 Com 3 Set D 2 Ht D 1 CD 24 23 22 21 20 19 18 17 16 15 14 13 R Alarm Stg 4 Stg 4 Stg 3 Stg 3 Stg 2 Stg 2 Stg 1 Stg 1 Pmp Pmp
Boiler #2
stage 1
stage 2
stage 3
stage 4
S2 S1
P2
A2
S6
S5
T1
6 7 8 9 10 11 Boil Com Setp Power Prim Dem Dem Dem N L P1
5A
1 2 3 4 5
268 Com Boil Boil Out UnO - Sup Ret + Sw
Do not apply power
5A
5A
5A
5A
5A
5A
5A
5A
5A
P1
C.A./ Alarm
Relay 1 1
Relay 2 2
Relay 3 3
Relay 4 4
Relay 5 5
Relay 6 6
Relay 7 7
Relay 8 8
Relay 9 9
12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
5A
Application —Electrical, Mode 6 example #1 (2x BTC 4PA, 1x tekmar 268)
D 901 - 09/02
18 of 20
© 2002
120 V (ac) L
N
C
R
24R 23Alarm 22 21 20 19 18 Stg 2 17 Stg 2 16 Stg 1 15 Stg 1 14 Pmp 13 Pmp
24 V (ac)
Class II Transformer
12 C 11 10 9 Com 8 Boil in 7 Boil O 6 Sup/D 5 Os 4 Com 3 Set D 2 Ht D 1 CD
Boiler #1
Electrical A1, A2 = Alarms P1 = Primary Pump P2, P3 = Boiler Pumps S1 = Outdoor Sensor 070 S2 = Boiler Supply Sensor 071 S3, S5 = Boiler Outlet Sensor 071 S4, S6 = Boiler Inlet Sensor 071 T1 = Thermostat
stage 1
stage 2
P3
A1
S4
S3
12 C 11 10 9 Com 8 Boil in 7 Boil O 6 Sup/D 5 Os 4 Com 3 Set D 2 Ht D 1 CD 24R 23Alarm 22 21 20 19 18 Stg 2 17 Stg 2 16 Stg 1 15 Stg 1 14 Pmp 13 Pmp
Boiler #2
stage 1
stage 2
S2 S1
P2
A2
S6
S5
T1
6 7 8 9 10 11 Boil Com Setp Power Prim Dem Dem Dem N L P1
5A
1 2 3 4 5
268 Com Boil Boil Out UnO - Sup Ret + Sw
Do not apply power
5A
5A
5A
5A
5A
5A
5A
5A
5A
P1
C.A./ Alarm
Relay 1 1
Relay 2 2
Relay 3 3
Relay 4 4
Relay 6 6
typical for Boiler #3
Relay 5 5
Relay 8 8
typical for Boiler #4
Relay 7 7
Relay 9 9
12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
5A
Application —Electrical, Mode 6 example #2 (2x BTC 2PA, 1x tekmar 268)
D 901 - 09/02
19 of 20
© 2002
120 V (ac) L
24 V (ac)
Class II Transformer
12 C 11 10 9 Com 8 Boil in 7 Boil O 6 Sup/D 5 Os 4 Com 3 Set D 2 Ht D 1 CD
N
C
R
24R 23Alarm 22 21 20 19 18 Stg 2 17 Stg 2 16 Stg 1 15 Stg 1 14 Pmp 13 Pmp
Boiler #1
Electrical A1, A2 = Alarms P1 = Primary Pump P2, P3 = Boiler Pumps S1 = Outdoor Sensor 070 S2 = Boiler Supply Sensor 071 S3, S5 = Boiler Outlet Sensor 071 S4, S6 = Boiler Inlet Sensor 071 T1 = Thermostat
stage 2 stage 1
P3
A1
S4
S3
12 C 11 10 9 Com 8 Boil in 7 Boil O 6 Sup/D 5 Os 4 Com 3 Set D 2 Ht D 1 CD
24R 23Alarm 22 21 20 19 18 Stg 2 17 Stg 2 16 Stg 1 15 Stg 1 14 Pmp 13 Pmp
Boiler #2
stage 1
stage 2
S2
P2
A2
S6
S5
S1
T1
P1
6 7 8 9 10 11 Boil Com Setp Power Prim Dem Dem Dem N L P1
5A
1 2 3 4 5
264 Com Boil Boil Out UnO Sup Ret Sw
Do not apply power
5A
5A
5A
5A
C.A./ Alarm
Relay 1 1
Relay 2 2
Relay 3 3
Relay 4 4
12 13 14 15 16 17 18 19 20 21
5A
Application —Electrical, Mode 6 example #3 (2x BTC 2PA, 1x tekmar 264)
D 901 - 09/02
Technical Data Four Stage BTC 4PA Control Enclosure Dimensions Approvals Ambient conditions
Power supply Pump / Stage1 relay Stage 2 to 4 relays Alarm relay Demands Sensors included
Optional devices
Microprocessor PI control; This is not a safety (limit) control Enclosure D, black Noryl plastic 4-3/4” H x 2-7/8” W x 1-7/8” D (120 x 74 x 48 mm) CSA C US, meets ICES & FCC regulations for EMI/RFI. Indoor use only, -40 to 140°F (-40 to 60°C), < 90% RH noncondensing. 24 V ±10% 50/60 Hz 75 VA 120 V (ac) 5 A 1/6 hp, pilot duty 240 VA 120 V (ac) 3 A 1/6 hp 24 V (ac) 3 A 1/6 hp 20 to 260 V (ac) 2VA NTC thermistor, 10 kΩ @ 77°F (25°C ±0.2°C) ß=3892 2 of Universal Sensor 071 Universal Sensor 071
Power: 24 V ±10% 50/60 Hz 75 VA Pump/Stage 1 relays: 120 V (ac) 5 A 1/6 hp pilot duty 240 VA Stage 2 to 4 relays: 120 V (ac) 3 A 1/6 hp Alarm relay: 24 V (ac) 3 A 1/6 hp Demand input: 20 to 260 V (ac) 2 VA
H3001A
Setp Dem
Four Stage BTC 4PA 158033
Item
Signal wiring must be rated at least 300 V
tektra 901-00 Made in Canada
tekmar Control Systems Ltd., Canada tekmar Control Systems, Inc., U.S.A. Head Office: 5100 Silver Star Road Vernon, B.C. Canada V1B 3K4 (250) 545-7749 Fax. (250) 545-0650 Web Site: www.tekmarcontrols.com Product design, software and literature are Copyright © 2002 by: tekmar Control Systems Ltd. and tekmar Control Systems, Inc.
20 of 20
All specifications are subject to change without notice. Printed in Canada. D 901 - 09/02.
D 901
Boiler Temperature Control (BTC 1PA, 2PA, 3PA, and 4PA)
09/02
The BTC products are designed to be mounted on single, two, three or four stage boilers in order to provide accurate water temperature control in a variety of applications. The controls may be used to provide a setpoint temperature, outdoor reset with reset override, or dedicated DHW generation. Up to two additional relay s may be included to operate the boiler pump and provide an alarm signal in case of a sensor failure.
Power: 24 V ±10% 50/60 Hz 75 VA Pump/Stage 1 relays: 120 V (ac) 5 A 1/6 hp pilot duty 240 VA Stage 2 to 4 relays: 120 V (ac) 3 A 1/6 hp Alarm relay: 24 V (ac) 3 A 1/6 hp Demand input: 20 to 260 V (ac) 2 VA
H3001A
Setp Dem
Four Stage BTC 4PA 158033
Item
Signal wiring must be rated at least 300 V
1 of 20
tektra 901-00 Made in Canada
© 2002
D 901 - 09/02
Introduction This brochure is organized into four main sections. They are: 1) Sequence of Operation, 2) Installation, 3) Control Settings, and 4) Troubleshooting. The Sequence of Operation section has 5 sub-sections. We recommend reading Section A: General of the Sequence of Operation, as this contains important information on the overall operation of the control. Then read the sub-sections that apply to your installation. The Control Settings section (starting at DIP Switch Settings) of this brochure describes the various items that are adjusted and displayed by the control. The control functions of each adjustable item are described in the Sequence of Operation.
Table Of Contents Table of Contents............................................Pg 2 Interface..................................................Pg 2 Description of Display Elements ..................Pg 3 Sequence of Operation ..................................Pg 4 Section A: General ................................Pg 4 Section B: Setpoint ...............................Pg 6 Section C: Dedicated DHW...................Pg 7 Section D: Outdoor Reset.....................Pg 7 Section E: External Boiler ....................Pg 8
Installation.......................................................Pg 8 Testing .............................................................Pg 9 Control Settings..............................................Pg 11 DIP Switch Setting.................................Pg 11 View Menu ..............................................Pg 11 Adjust Menu ...........................................Pg 12 Error Messages...............................................Pg 14 Typical Applications.......................................Pg 15 Technical Data ................................................Pg 20
Interface The BTC uses a Liquid Crystal Display (LCD) as a method of supplying information. You use the LCD in order to setup and monitor the operation of your system. The BTC uses three push buttons (Item, ▲, ▼) for selecting and adjusting settings. As you program your control, record your settings in the actual settings column of the Adjust menu. The table is found in the second half of this brochure.
Menu All of the items displayed by the control are organized into two menus. These menus are listed on the upper right hand side of the display (Menu Field). The default menu for the BTC is the View menu. While in the View menu, the VIEW segment is displayed. To select the Adjust menu, press and hold simultaneously all three buttons for 1 second. The display then advances to the Adjust menu and the ADJUST segment is turned on in the display. The display will automatically revert back to the View menu after 20 seconds of keypad inactivity. Once in a menu, there will be a group of items that can be viewed within that menu.
Item The abbreviated name of the selected item will be displayed in the item field of the display. To view the next available item, press and release the Item button. Once you have reached the last available item in a menu, pressing and releasing the Item button will return the display to the first item in the selected menu.
Adjust To make an adjustment to a setting in the control, begin by selecting the Adjust menu by pressing and holding simultaneously all three buttons. Then select the desired item using the Item button. Finally, use the ▲ or ▼ button to make the adjustment.
Item
Item
Item
Additional information can be gained by observing the Status field of the LCD. The status field will indicate which of the control’s outputs are currently active. Most symbols in the status field are only visible when the View menu is selected. © 2002
D 901 - 09/02
2 of 20
Display
Setp Dem
Symbol Description Pump Displays when the boiler pump is in operation.
,
°F, °C Units of measurement.
Burner
Pointer
Displays when the stage 1 and/or 2, 3, 4 relay is turned on.
Displays the operation as indicated by the text.
3 of 20
© 2002
D 901 - 09/02
Sequence of Operation
Section A
Section B
Section C
Section D
Section E
General Operation Page 4 - 5
Setpoint Operation Page 6
Dedicated DHW Page 7
Outdoor Reset Page 7
External Boiler Operation Page 8
Section A: General POWERING UP THE CONTROL When the BTC is powered up, the control turns on all segments in the display for 2 seconds. Next, the software version is displayed for 2 seconds. Finally, the control enters into the normal operating mode.
MODES OF OPERATION (MODE) The BTC series of controls allows for six modes of operation in order to define the control operation and piping arrangement used. The piping arrangement can be categorized into parallel and primary / secondary. The mode of operation is selected using the MODE item in the Adjust menu. The temperature being controlled out to the heating system is measured by the operating sensor. The piping arrangement determines which sensor the BTC uses as the operating sensor. The operating sensor is either the boiler outlet sensor or the boiler supply sensor. (see page 15 and 16 for typical applications) Boiler Outlet Sensor
Parallel In parallel piping applications, the boiler outlet temperature is typically the same temperature that is being delivered out to the system. Therefore, the operating sensor in parallel piping applications is the boiler outlet sensor.
Primary / Secondary In primary / secondary applications, the boiler outlet temperature is typically higher than the primary loop temperature. Therefore, the BTC uses an additional sensor (boiler supply) to measure the temperature delivered out to the system. The operating sensor in primary / secondary piping applications is the boiler supply sensor.
Boiler Inlet Sensor
Boiler Supply Sensor
Boiler Outlet Sensor
Boiler Inlet Sensor
Mode 1 (MODE = 1) Mode 1 is designed for setpoint operation using parallel piping. Once a heat demand signal is present, the control operates the boiler stages to maintain a fixed temperature at the boiler outlet sensor. Refer to section B for a description of setpoint operation.
Mode 2 (MODE = 2) Mode 2 is designed for setpoint operation using primary / secondary piping. Once a heat demand signal is present, the control operates the boiler stages to maintain a fixed temperature at the boiler supply sensor. Refer to section B for a description of setpoint operation. Boiler Outlet Sensor
Mode 3 (MODE = 3) Mode 3 is designed for dedicated DHW operation using parallel piping. The control operates the boiler stages based on the boiler outlet sensor to maintain a tank temperature at the DHW sensor. Refer to section C for a description of dedicated DHW operation.
DHW Sensor Boiler Inlet Sensor
Mode 4 (MODE = 4) Mode 4 is designed for outdoor reset and reset override operation using parallel piping. Once a heat demand is present, the control operates the boiler stages to maintain an outdoor reset temperature at the boiler outlet sensor. Once a setpoint demand (reset override) is present, the control operates the boiler stages to maintain a setpoint temperature at the boiler outlet sensor. If both a heat demand and a setpoint demand are present at the same time, the control targets the higher of the two requirements. Refer to section D for a description of outdoor reset operation.
Mode 5 (MODE = 5) Mode 5 is designed for outdoor reset and reset override operation using primary / secondary piping. Once a heat demand is present, the control operates the boiler stages to maintain an outdoor reset temperature at the boiler supply sensor. Once a setpoint demand (reset override) is present, the control operates the boiler stages to maintain a setpoint temperature at the boiler supply sensor. If both a heat demand and a setpoint demand are present at the same time, the control targets the higher of the two requirements. Refer to section D for a description of outdoor reset operation. © 2002
D 901 - 09/02
4 of 20
Mode 6 (MODE = 6)
Boiler Outlet Sensor
Boiler Outlet Sensor
Mode 6 is designed for external boiler control. This mode of operation allows for an external control to operatemultiple boilers equipped with a BTC. The BTC is used to provide boiler pump control. Once a heat demand is present, the control closes the Stg 1 Stg 1 and operates the boiler pump. Refer to section E for a description of external boiler operation.
il e Bo
160˚F (71˚C)
rO n
165˚F (74˚C)
Differential = 10˚F (5˚C)
rO n
Target temperature 160˚F (71˚C)
Bo il e
An on / off heat source must be operated with a differential in order to prevent short cycling. The boiler differential is divided around the boiler target temperature. The first stage will close when the water temperature at the operating sensor is 1/2 of the differential setting below the boiler target temperature, and will open when the water temperature at the operating sensor is 1/2 of the differential setting above the boiler target temperature. The remaining stages will operate sequentially based on the staging mode selected.
155˚F (68˚C) Time
Supply Water Temperature
BOILER DIFFERENTIAL (DIFF)
STAGING MODE (STGMODE) The BTC controls can operate up to four stages in order to supply the required target temperature. The method of staging used by the control is either P (proportional) or PID (proportional & Integral & Derivative), and is selected using the STGMODE item in the Adjust menu.
Proportional (P) Proportional staging, also known as step staging, is based on manually adjusted settings which determine when the next stage is required to turn on. These manual settings are based on temperature and time. The interstage differential sets the temperature drop at which the next stage turns on. However, in order for a stage to fire, the interstage delay on and minimum off times must first elapse.
Interstage Differential (STG DIFF) The interstage differential is the temperature drop at which the next stage will turn on. Once a stage turns on, the next stage cannot turn on until the temperature drops the interstage differential below the temperature at which the previous stage turned on. The interstage differential is adjustable through the STG DIFF setting in the Adjust menu.
Target temperature 160˚F (71˚C)
Boiler Differential = 10˚F (5˚C)
165˚F (74˚C) Stg 1 OFF
163˚F (73˚C)
Stg 2 OFF
160˚F (71˚C)
Interstage Delay On (ON DLY) The interstage delay on is the amount of time that must elapse before turning on the next stage. Once a stage turns on, the next stage cannot turn on until the interstage delay on time elapses. The interstage delay on is adjustable through the ON DLY setting in the Adjust menu.
155˚F (68˚C) 153˚F (67˚C)
Stg 1 ON Stg 2 ON
Time
Interstage Differential = 2°F
Interstage Delay Off (OFF DLY) The interstage delay off is the amount of time that must elapse before turning off the next stage. Once a stage turns off, the next stage cannot turn off until the interstage delay off time elapses. The interstage delay off is adjustable through the OFF DLY setting in the Adjust menu.
Minimum On Time (MIN ON) The minimum on time is the minimum amount of time that a stage must be on before it is allowed to turn off. Once a stage turns on, it cannot turn off until a minimum on time elapses. The minimum on time is adjustable through the MIN ON setting in the Adjust menu.
Minimum Off Time (MIN OFF) The minimum off time is the minimum amount of time that a stage must be off before it is allowed to turn on. Once a stage turns off, it cannot turn on until a minimum off time elapses. The minimum off time is adjustable through the MIN OFF setting in the Adjust menu.
Proportional & Integral & Derivative (PID) PID staging allows the control to determine when the next stage is required to turn on. The BTC automatically determines the settings that are manually selected in proportional staging mode. After each stage is turned on in the firing sequence, the control waits a minimum amount of time before turning on the next stage. After the minimum time delay between stages has expired, the BTC examines the control error to determine when the next stage is to fire. The control error is determined using PID logic. Proportional compares the actual operating sensor temperature to the boiler target temperature. The colder the temperature, the sooner the next stage is turned on. Integral
compares the actual operating sensor temperature to the boiler target temperature over a period of time.
Derivative
determines how fast or slow the operating sensor temperature is changing. If the temperature is increasing slowly, the next stage is turned on sooner. If the temperature is increasing quickly, the next stage is turned on later, if at all. 5 of 20
© 2002
D 901 - 09/02
Boiler Mass (BOIL MASS) The boiler mass setting allows the installer to adjust the control to the thermal mass of different types of heat sources used. The boiler mass setting automatically determines the interstage differential, interstage delay on, interstage delay off, minimum on time and minimum off time of the stages when PID staging is used. A higher thermal mass setting provides slower staging, while a lower thermal mass provides faster staging.
The BOIL MIN is the lowest water temperature that the control is allowed to use as a boiler target temperature. During mild conditions, if the BTC calculates a boiler target temperature that is below the BOIL MIN setting, the boiler target temperature is adjusted to at least the BOIL MIN setting. During this condition, if the boiler is operating, the MIN segment turns on in the LCD while the boiler target temperature or boiler operating sensor temperature is viewed. If the installed boiler is designed for condensing or low temperature operation, set the BOIL MIN adjustment to OFF.
BOIL MIN
WWSD
BOILER MAXIMUM (BOIL MAX)
Increasing Water Temperature
BOIL MAX
BOILER MINIMUM (BOIL MIN)
Decreasing Outdoor Temperature
The BOIL MAX is the highest water temperature that the control is allowed to use as a boiler target temperature. If the control does target BOIL MAX, and the boiler outlet sensor is near the BOIL MAX temperature, the MAX segment turns on in the LCD while the boiler target, boiler inlet, boiler outlet or boiler supply temperature is viewed.
BOILER TARGET TEMPERATURE (BOIL TARGET) The boiler target temperature is determined from the mode of operation. The control displays the temperature that it is currently trying to maintain at the operating sensor as BOIL TARGET in the View menu. The operating sensor for modes 1, 3 and 4 is the boiler outlet sensor, and the operating sensor for modes 2 and 5 is the boiler supply sensor. If the control does not presently have a requirement for heat, it displays “---” in the LCD. There is no boiler target temperature generated in Mode 6.
BOILER PUMP OPERATION The boiler pump (Pmp Pmp) operates based on the mode of operation selected. During setpoint operation (modes 1 and 2), the boiler pump closes whenever there is a heat demand. During dedicated DHW operation (mode 3), the boiler pump closes whenever there is an internal heat demand. During outdoor reset (modes 4 and 5), the boiler pump closes whenever there is either a heat demand and the BTC is not in Warm Weather Shut Down (WWSD), whenever there is a setpoint demand. During Warm Weather Shut Down, if the boiler pump has not operated at least once every 70 hours, the control turns on the output for 10 seconds. This minimizes the possibility of the pump seizing during a long period of inactivity. During External Boiler Operation (Mode 6), the boiler pump closes whenever there is a heat demand.
Boiler Purge (PUMP DLY) After a demand is satisfied, the BTC continues to operate the boiler pump for a period of time. The length of time that the boiler pump continues to run is based on the pump DLY setting. Once the last stage of the boiler turns off, the control keeps the boiler pump running for the time selected. This setting allows purging of any excess heat out of the boiler after the boiler is shut off. This also helps to prevent the water in the boiler from flashing into steam after the boiler is shut off. When OFF is selected, there is no purging. When ON is selected, pump operation is continuous. Also, during outdoor reset and the pump DLY is set to ON, the pump continues to run even during Warm Weather Shut Down.
Boiler Purge (∆T MIN) After a demand is satisfied, the BTC continues to operate the boiler pump for a period of time. The length of time that the boiler pump continues to run is based on the ∆T MIN setting. The control uses the ∆T (temperature difference) between the boiler inlet and the boiler outlet to determine the amount of purging required. Once the last stage of the boiler turns off, the control keeps the boiler pump running until the ∆T drops below the ∆T minimum setting for a minimum of 20 seconds. This setting allows purging of any excess heat out of the boiler after the boiler is shut off. This also helps to prevent the water in the boiler from flashing into steam after the boiler is shut off. Note: Boiler purge based on ∆T MIN is available in certain models. If the BTC model incorporates the ∆T MIN purging, the PUMP DLY purging will not be available.
Section B: Setpoint Operation When either mode 1 or 2 is selected, the BTC controls the water temperature based on a fixed setpoint. The setpoint temperature is set using the BOIL TARGET item in the Adjust menu.
HEAT DEMAND A heat demand is required whenever heat is required for the setpoint load. A heat demand is generated when a voltage between 24 and 240 V (ac) is applied across the CD (common demand) and the Ht D (heat demand) terminals (1 and 2). Once voltage is applied, the BTC turns on the Dem segment in the display. The BTC closes the Pmp Pmp s, which starts the boiler pump and the control turns on the boiler pump segment in the display. The BTC then operates the boiler stages to maintain the setpoint temperature.
© 2002
D 901 - 09/02
6 of 20
Section C: Dedicated Domestic Hot Water (DHW) Operation When mode 3 is selected, the BTC provides dedicated DHW operation.
INTERNAL DHW DEMAND A sensor is required to be connected on the Com and the Sup/D terminals (4 and 6). An internal demand for DHW is generated when the temperature at the DHW sensor drops 1/2 of the tank differential setting below the desired DHW tank temperature. The TANK TARGET setting is used to set the desired DHW tank temperature. Once an internal demand is generated, the Dem segment turns on in the LCD. The BTC then closes the Pmp Pmp , which starts the boiler pump and the control turns on the boiler pump segment in the display. The BTC then operates the boiler stages to maintain the programmed boiler target temperature at the boiler outlet sensor. The boiler target temperature is set using the BOIL TARGET item in the Adjust menu. Note An external demand is not required in this mode of operation.
TANK DIFFERENTIAL (TANK DIFF) A differential setting that operates 1/2 above and below the TANK TARGET is selectable using the TANK DIFF item in the Adjust menu.
Section D: Outdoor Reset Operation When either mode 4 or 5 is selected, the BTC uses outdoor reset to control the water temperature. Outdoor reset adjusts the target temperature based on the outdoor air temperature and reset ratio. The reset ratio is determined from the Boiler Start, Boiler Design, Outdoor Start and Outdoor Design settings.
HEAT DEMAND A heat demand is required whenever heat is required in the system. A heat demand is generated when a voltage between 24 and 240 V (ac) is applied across the CD (common demand) and the Ht D (heat demand) terminals (1 and 2). Once voltage is applied, the BTC turns on the Dem segment in the display. If the BTC is not in warm weather shut down (WWSD), it closes the Pmp Pmp , which starts the boiler pump and the control turns on the boiler pump segment in the display. The BTC then operates the boiler stages to maintain the boiler target temperature.
BOILER START (BOIL START) The BOIL START temperature is the theoretical boiler supply water temperature that the heating system requires when the outdoor air temperature equals the OUTDR START temperature setting. The BOIL START is typically set to the desired building temperature.
OUTDOOR START (OUTDR START) The OUTDR START temperature is the outdoor air temperature at which the control provides the BOIL START water temperature to the system. The OUTDR START is typically set to the desired building temperature.
OUTDOOR DESIGN (OUTDR DSGN) The OUTDR DSGN is the outdoor air temperature that is the typical coldest temperature of the year where the building is located. This temperature is used when doing heat loss calculations for the building.
OUTDR DSGN BOIL START
OUTDR START Decreasing Outdoor Temperature
Increasing Water Temperature
BOIL DSGN
BOILER DESIGN (BOIL DSGN) The BOIL DSGN temperature is the water temperature required to heat the boiler zones when the outdoor air is as cold as the OUTDR DSGN temperature.
WARM WEATHER SHUT DOWN (WWSD) When the outdoor air temperature rises above the WWSD setting, the BTC turns on the WWSD segment in the display. When the control is in Warm Weather Shut Down, the Dem segment is displayed if there is a heat demand. However, the control does not operate the heating system to satisfy this demand. The control does respond to a setpoint demand and operates as described below.
RESET OVERRIDE (SETPOINT DEMAND) A setpoint demand is required whenever heat is required for the setpoint load. The setpoint demand overrides the reset water temperature. A setpoint demand is generated when a voltage between 24 and 240 V (ac) is applied across the CD (common demand) and the Set D (setpoint demand) terminals (1 and 3). Once voltage is applied, the BTC turns on the Setp Dem pointer in the display. The BTC closes the Pmp Pmp , which starts the boiler pump and the control turns on the boiler pump segment in the display. The BTC then operates the boiler stages to maintain the programmed boiler target temperature. The reset override operation is not affected by WWSD.
7 of 20
© 2002
D 901 - 09/02
Section E: External Boiler Operation When mode 6 is selected, the BTC allows for an external boiler control to operate the boiler stages. In this mode, the BTC operates the boiler pump in order to provide purging and exercising. The staging operation is provided by an external device such as an Energy Management System (EMS) or Boiler Staging control.
HEAT DEMAND A heat demand is generated when a voltage between 24 and 240 V (ac) is applied across the CD (common demand) and the Ht D (heat demand) terminals (1 and 2). Once voltage is applied, the BTC turns on the Dem segment in the display. The BTC closes the Pmp Pmp , which starts the boiler pump and the control turns on the boiler pump segment in the display. The BTC also closes the Stg 1 Stg 1 , which turns on stage 1 of the boiler. The Stg 1 Stg 1 is closed as long as the heat demand is present.
Installation ELECTRICAL CONNECTIONS TO THE CONTROL The installer should test to confirm that no voltage is present at any of the wires during installation. The BTC includes a 24 pin connector for ease of installation.
12 C 11 10 9 Com 8 Boil in 7 Boil O 6 Sup/D 5 Os 4 Com 3 Set D 2 Ht D 1 CD
24 R 23 Alarm 22 Stg 4 21 Stg 4 20 Stg 3 19 Stg 3 18 Stg 2 17 Stg 2 16 Stg 1 15 Stg 1 14 Pmp 13 Pmp
Powered Input Connections 24 V (ac) Power Connect the 24 V (ac) power supply to the C and R terminals (12 and 24). This connection provides power to the microprocessor and display of the control. As well, this connection provides power to the Alarm terminal (25) from the R terminal (24).
Heat Demand To generate a heat demand, a voltage between 24 V (ac) and 240 V (ac) must be applied across the CD (common demand) and the Ht D (heat demand) terminals (1 and 2).
R
C
12
C
24 to 240 V(ac) 2 Ht D 1 CD
Setpoint Demand To generate a setpoint demand, a voltage between 24 V (ac) and 240 V (ac) must be applied across the CD (common demand) and the Set D (setpoint demand) terminals (1 and 3).
24 to 240 V(ac) 3 Set D 2 Ht D 1 CD
Caution: The same power supply must be used for both the heat demand and setpoint demand circuits since they share the CD (common demand) terminal.
Output Connections Boiler Pump The Pmp Pmp terminals (13 and 14) are an isolated output in the BTC. There is no power available on these terminals from the control. These terminals are to be used as a switch to either make or break power to the boiler pump. Since this is an isolated , it may switch a voltage between 24 V (ac) and 120 V (ac). © 2002
D 901 - 09/02
8 of 20
N L
14 Pmp 13 Pmp
24 R
Boiler s The Stg 1 Stg 1, Stg 2 Stg 2, Stg 3 Stg 3, and Stg 4 Stg 4 terminals (15 and 16, 17 and 18, 19 and 20, 21 and 22) are isolated outputs in the BTC. There is no power available on these terminals from the control. These terminals are to be used as a switch to either make or break the boiler circuit. When the BTC requires boiler stages to fire, it closes the between the appropriate terminals.
stage 4
22 Stg 4
stage 3
21 Stg 4 20 Stg 3
Alarm The Alarm terminal (23) on the BTC is a powered output. When the relay in the BTC closes, 24 V (ac) from the R terminal (24) is provided to the Alarm terminal (23). To operate the alarm, connect one side of the alarm circuit to the Alarm terminal (23) and the second side of the alarm circuit to the common (C) side of the 24 V (ac) power supply.
Sensor and Unpowered Input Connections
19 Stg 3 18 Stg 2 17 Stg 2 16 Stg 1
stage 2
15 Stg 1
stage 1
Do not apply power to these terminals as this damages the control.
Outdoor Sensor Connect the two wires from the Outdoor Sensor 070 to the Com (common sensor) and Os (outdoor sensor) terminals (4 and 5). The outdoor sensor is used by the BTC to measure the outdoor air temperature.
9 Com
Boiler Outlet Sensor
8 Boil in 7 Boil O
Boiler Outlet Sensor Connect the two wires from the Boiler Outlet Sensor 071 to the Com (common sensor) and Boil O (boiler outlet sensor) terminals (9 and 7). The boiler outlet sensor is used by the BTC to measure the boiler outlet water temperature from the boiler. Note: The boiler outlet sensor is required for every mode of operation.
Boiler Inlet Sensor
9 Com
Connect the two wires from the Boiler Inlet Sensor 071 to the Com (common sensor) and Boil in (boiler inlet sensor) terminals (9 and 8). The boiler inlet sensor is used by the BTC to measure the boiler inlet water temperature to the boiler.
8 Boil in
Boiler Inlet Sensor
Note: The boiler inlet sensor is required for every mode of operation.
Boiler Supply / DHW Sensor Either a Boiler Supply Sensor 071 or DHW Sensor 071 may be connected to the BTC. If a sensor is used, connect the two wires from the sensor to the Com (common sensor) and Sup/D (boiler supply/DHW sensor) terminals (4 and 6).
6 Sup/D
6 Sup/D
5 Os
5 Os
4 Com
Boiler Outlet Sensor
Boiler Outlet Sensor
OR Tank Sensor
Boiler Supply Sensor
4 Com
Boiler Inlet Sensor
Boiler Inlet Sensor
TESTING The wiring harness must be unplugged from the connector on the control before testing. To remove the wiring harness, push down on the tab which fits over the tab on the connector from the control and pull away form the control. The following tests are performed using standard testing practices and procedures and should only be carried out by properly trained and experienced persons. A good quality electrical test meter, capable of reading from at least 0 - 300 V (ac) and at least 0 - 2,000,000 Ohms, is essential to properly test the wiring and sensors.
Test the Sensors In order to test the sensors, the actual temperature at each sensor location must be measured. A good quality digital thermometer with a surface temperature probe is recommended for ease of use and accuracy. First measure the temperature using the thermometer and then measure the resistance of the sensor at the control. Using the chart below, estimate the temperature measured by the sensor. The sensor and the thermometer readings should be close. If the meter reads a very high resistance, there may be a broken wire, a poor wiring connection or a defective sensor. If the resistance is very low, the wiring may be shorted, there may be moisture in the sensor or the sensor may be defective. To test for a defective sensor, measure the resistance directly at the sensor location. 9 of 20
9 Com 8 Boil in
© 2002
D 901 - 09/02
Temperature °F -50 -40 -30 -20 -10 0 10
Resistance
Temperature
Resistance
Temperature
°C
Ω
°F
°C
Ω
°F
°C
-46 -40 -34 -29 -23 -18 -12
490,813 336,606 234,196 165,180 118,018 85,362 62,465
20 30 40 50 60 70 80
-7 -1 4 10 16 21 27
46,218 34,558 26,099 19,900 15,311 11,883 9,299
90 100 110 120 130 140 150
32 38 43 49 54 60 66
Resistance Ω 7,334 5,828 4,665 3,760 3,050 2,490 2,045
Resistance
Temperature °F
°C
Ω
160 170 180 190 200 210 220
71 77 82 88 93 99 104
1,689 1,403 1,172 983 829 703 598
Test the Power Supply Make sure exposed wires and bare terminals are not in with other wires or grounded surfaces. Turn on the power and measure the voltage between the C and R terminals (12 and 24) using an AC voltmeter, the reading should be between 22 and 26 V (ac). 22 to 26 V (ac) 12
C
24 R
Test the Powered Inputs Heat Demand If a heat demand is used, measure the voltage between the CD (common demand) and the Ht D (heat demand) terminals (1 and 2). When the heat demand device calls for heat, you should measure between 20 and 260 V (ac) at the terminals. When the heat demand device is off, you should measure less than 5 V (ac).
Setpoint Demand If a setpoint demand is used, measure the voltage between the CD (common demand) and the Set D (setpoint demand) terminals (1 and 3). When the setpoint demand device calls for heat, you should measure between 20 and 260 V (ac) at the terminals. When the setpoint demand device is off, you should measure less than 5 V (ac).
20 to 260 V (ac) 2 Ht D 1 CD
Connecting the Control Make sure all power to the devices and wiring harness is off. Reconnect the wiring harness to the connector on the control by aligning the tab on the wiring harness to the tab on the connector on the control and then pushing the wiring harness into the connector on the control. The tab on the wiring harness should snap over the tab on the connector of the control Apply power to the control. The operation of the control on power up is described in the Sequence of Operation section of the brochure.
Testing the Control’s Outputs The BTC has a built-in test routine which is used to the main control functions. The test sequence is enabled when the ▲ button is pressed and held while in the View menu. The outputs are tested in the following sequence: Step 1: After 1 second, the pump is turned on. Step 2: After 4 seconds, Stage 1 is turned on. Step 3: After 7 seconds, Stage 2 is turned on. Step 4: After 10 seconds, Stage 3 is turned on. Step 5: After 13 seconds, Stage 4 is turned on. Step 6: After 16 seconds, the Alarm is turned on. Step 7: After the ▲ button is released, the control continues normal operation.
© 2002
D 901 - 09/02
10 of 20
Control Settings DIP SWITCH SETTING Note: DIP switches may be located either on the front or back of the control.
(A) Advanced / Installer The Advanced / Installer DIP switch is used to select which items are available to be viewed and / or adjusted in the interface. The Advanced Access Level includes all the settings available in the control. The Installer Access Level includes the settings and items which are required for system setup.
B A
OFF OFF
Advanced
Installer
(B) DIP switch B is not used In some cases, depending on the boiler the BTC is installed into, DIP switch B may be used for additional features.
View Menu (1 of 1)
Se ct IN ion ST AD V
Item Field
Access Level
Description
Current outdoor air temperature as measured by the outdoor sensor. This is the default display for the control. MODE = 4, 5
A
Target boiler supply is the temperature the control is currently trying to maintain at the boiler supply sensor or the boiler outlet sensor.
Range
-60 to 190°F (-51 to 88°C)
---, 35 to 226°F (2 to 108°C)
MODE = 1, 2, 3, 4, 5
A
Current boiler supply water temperature as measured by the boiler supply sensor. MODE = 2, 5
A
Current boiler outlet water temperature as measured by the boiler outlet sensor. MODE = 1, 3, 4, 6 (Installer Level) MODE = 2, 5 (Advanced Level)
14 to 266°F (-10 to 130°C)
14 to 266°F (-10 to 130°C)
A
Current boiler inlet water temperature as measured by the boiler inlet sensor.
14 to 266°F (-10 to 130°C)
A
Current ∆T (temperature difference) between the boiler outlet sensor and the boiler inlet sensor.
-99 to 252°F (-55 to 140°C)
A
Current DHW tank temperature as measured by the DHW sensor. MODE = 3
The total number of running hours of the boiler since this item was last cleared.
11 of 20
14 to 266°F (-10 to 130°C)
0 to 999
© 2002
D 901 - 09/02
Adjust Menu (1 of 2)
Se ct IN ion S AD T V
Item Field
Access Level
Description
A
Sets the operating mode for the control.
A
Selects the staging operation to be either automatic or manual. MODE = 1, 2, 3, 4, 5
A
Minimum boiler target temperature during reset override, setpoint or DHW operation. MODE = 1, 2, 3, 4, 5
C
Sets the DHW storage tank’s temperature. MODE = 3
C
D
Sets the differential for the DHW storage tank. MODE = 3
The outdoor starting temperature used in the reset ratio for the heating system.
Range
1, 2, 3, 4, 5, 6
PID (automatic staging) P (manual staging)
OFF, 70 to 220°F (OFF, 21 to 104°C)
OFF, 70 to 190°F (OFF, 21 to 88°C)
2 to 10°F (1 to 6°C)
35 to 85°F (2 to 29°C)
MODE = 4, 5
D
The design outdoor air temperature used in the heat loss calculations for the heating system. MODE = 4, 5
D
The starting water temperature used in the reset ratio calculation for the heating system. MODE = 4, 5
D
The design water temperature used in the heat loss calculations for the heating system. MODE = 4, 5
A
A
The maximum boiler target water temperature. MODE = 1, 2, 3, 4, 5
The minimum temperature allowed for the boiler target temperature. MODE = 1, 2, 3, 4, 5
© 2002
D 901 - 09/02
12 of 20
-60 to 32°F (-51 to 0°C)
35 to 150°F (2 to 66°C)
70 to 220°F (21 to 104°C)
120 to 225°F, OFF (49 to 107°C, OFF)
OFF, 80 to 180°F (OFF, 27 to 82°C)
Actual Setting
Adjust Menu (2 of 2)
Se ct IN ion S AD T V
Item Field
Access Level
A
Description
The thermal mass of the boiler used. MODE = 1, 2, 3, 4, 5 and STGMODE = PId
A
The differential that the control is to use when it is operating the boiler. MODE = 1, 2, 3, 4, 5
A
The interstage differential that the control is to use when it is operating the boiler. MODE = 1, 2, 3, 4, 5 and STGMODE = P
A
The interstage delay that the control is to use when an additional stage is required to turn on. MODE = 1, 2, 3, 4, 5 and STGMODE = P
A
The interstage delay that the control is to use when a stage is required to turn off. MODE = 1, 2, 3, 4, 5 and STGMODE = P
A
The minimum on time for each stage when manual staging is selected. MODE = 1, 2, 3, 4, 5 and STGMODE = P
A
The minimum off time for each stage when manual staging is selected. MODE = 1, 2, 3, 4, 5 and STGMODE = P
Range
1 (light mass) 2 (medium mass) 3 (heavy mass)
2 to 42°F (1 to 23°C)
0 to 10°F (0 to 6°C)
0:10 to 8:00 minutes
0:10 to 4:00 minutes
0:10 to 5:00 minutes
0:10 to 5:00 minutes
A
Determines when to stop purging.
OFF, 0:20 to 9:55 min, On
A
Determines how long to purge based on the ∆T (temperature difference). This setting may appear in some models. If this setting is present, the pump DLY setting above will not be available.
2 to 20°F, OFF (1 to 11°C)
D
The system’s warm weather shut down. MODE = 4, 5
The units of measure that all of the temperatures are to be displayed in by the control.
13 of 20
Actual Setting
35 to 100°F, OFF (2 to 38°C, OFF)
°F, °C
© 2002
D 901 - 09/02
Error Displayed
Description of Error The control was unable to read a piece of information from its EEPROM. The control will stop operation until all settings in the Adjust menu have been checked by the or installer.
The control is no longer able to read the boiler outlet sensor due to a short circuit. In this case, if the boiler inlet sensor is present and operational, the control will operate using the boiler inlet sensor. Otherwise, the control will not operate the boiler stages.
The control is no longer able to read the boiler outlet sensor due to an open circuit. In this case, if the boiler inlet sensor is present and operational, the control will operate using the boiler inlet sensor. Otherwise, the control will not operate the boiler stages.
The control is no longer able to read the boiler inlet sensor due to a short circuit. In this case, the control will continue operation.
The control is no longer able to read the boiler inlet sensor due to an open circuit. In this case, the control will continue operation.
The control is no longer able to read the boiler supply sensor due to a short circuit. In this case, if the boiler outlet sensor is present and operational, the control will operate based on the boiler outlet sensor. If the boiler outlet sensor is not available and the boiler inlet sensor is present and operational, the control will operate using the boiler inlet sensor. Otherwise, the control will not operate the boiler stages.
The control is no longer able to read the boiler supply sensor due to an open circuit. In this case, if the boiler outlet sensor is present and operational, the control will operate based on the boiler outlet sensor. If the boiler outlet sensor is not available and the boiler inlet sensor is present and operational, the control will operate using the boiler inlet sensor. Otherwise, the control will not operate the boiler stages.
The control is no longer able to read the outdoor sensor due to a short circuit. In this case the control assumes an outdoor temperature of 32°F and continues operation.
The control is no longer able to read the outdoor sensor due to an open circuit. In this case the control assumes an outdoor temperature of 32°F and continues operation.
The control is no longer able to read the tank sensor due to a short circuit. In this case the control will not operate the boiler stages.
The control is no longer able to read the tank sensor due to an open circuit. In this case the control will not operate the boiler stages.
© 2002
D 901 - 09/02
14 of 20
Applications —Mechanical The following are only mechanical and electrical concept drawings, not engineered drawings. They are not intended to describe a complete system, nor any particular system. It is up to the designer to determine the necessary components for and configuration of the particular system being designed, including additional equipment, isolation relays (for loads greater than the control’s specified output ratings), and any safety devices which in the judgement of the designer are appropriate, in order to properly size, configure and design that system and to ensure compliance with building and safety code requirements.
MODE 2
MODE 1 BTC
BTC
M
M
Boiler Supply Sensor
Boil Out Sensor
Boil Out Sensor
Boil In Sensor Boil In Sensor
MODE 4
MODE 3 BTC
BTC Outdoor Sensor
Thermostat
DHW Sensor
Boil Out Sensor
Boil Out Sensor
Boil In Sensor
Boil In Sensor
15 of 20
© 2002
D 901 - 09/02
Application —Mechanical MODE 5 BTC Outdoor Sensor
Relay
DHW Aquastat Boiler Supply Sensor
Boil Out Sensor
Boil In Sensor
MODE 6
268
BTC
BTC
Outdoor Sensor
Boiler Out Sensor
Boiler Supply Sensor
© 2002
D 901 - 09/02
Boiler In Sensor
16 of 20
Boiler Out Sensor
Boiler In Sensor
Com Boil in Boil O Sup/D Os Com Set D Ht D CD
C
17 of 20
© 2002
120 V (ac) L
N
C
R
24 R 23 Alarm 22 Stg 4 21 Stg 4 20 Stg 3 19 Stg 3 18 Stg 2 17 Stg 2 16 Stg 1 15 Stg 1 14 Pmp 13 Pmp
24 V (ac)
Class II Transformer
12 11 10 9 8 7 6 5 4 3 2 1
Boiler #1
Electrical A1, A2 = Alarms P1 = Primary Pump P2, P3 = Boiler Pumps S1 = Outdoor Sensor 070 S2 = Boiler Supply Sensor 071 S3, S5 = Boiler Outlet Sensor 071 S4, S6 = Boiler Inlet Sensor 071 T1 = Thermostat
stage 1
stage 2
stage 3
stage 4
P3
A1
S4
S3
12 C 11 10 9 Com 8 Boil in 7 Boil O 6 Sup/D 5 Os 4 Com 3 Set D 2 Ht D 1 CD 24 23 22 21 20 19 18 17 16 15 14 13 R Alarm Stg 4 Stg 4 Stg 3 Stg 3 Stg 2 Stg 2 Stg 1 Stg 1 Pmp Pmp
Boiler #2
stage 1
stage 2
stage 3
stage 4
S2 S1
P2
A2
S6
S5
T1
6 7 8 9 10 11 Boil Com Setp Power Prim Dem Dem Dem N L P1
5A
1 2 3 4 5
268 Com Boil Boil Out UnO - Sup Ret + Sw
Do not apply power
5A
5A
5A
5A
5A
5A
5A
5A
5A
P1
C.A./ Alarm
Relay 1 1
Relay 2 2
Relay 3 3
Relay 4 4
Relay 5 5
Relay 6 6
Relay 7 7
Relay 8 8
Relay 9 9
12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
5A
Application —Electrical, Mode 6 example #1 (2x BTC 4PA, 1x tekmar 268)
D 901 - 09/02
18 of 20
© 2002
120 V (ac) L
N
C
R
24R 23Alarm 22 21 20 19 18 Stg 2 17 Stg 2 16 Stg 1 15 Stg 1 14 Pmp 13 Pmp
24 V (ac)
Class II Transformer
12 C 11 10 9 Com 8 Boil in 7 Boil O 6 Sup/D 5 Os 4 Com 3 Set D 2 Ht D 1 CD
Boiler #1
Electrical A1, A2 = Alarms P1 = Primary Pump P2, P3 = Boiler Pumps S1 = Outdoor Sensor 070 S2 = Boiler Supply Sensor 071 S3, S5 = Boiler Outlet Sensor 071 S4, S6 = Boiler Inlet Sensor 071 T1 = Thermostat
stage 1
stage 2
P3
A1
S4
S3
12 C 11 10 9 Com 8 Boil in 7 Boil O 6 Sup/D 5 Os 4 Com 3 Set D 2 Ht D 1 CD 24R 23Alarm 22 21 20 19 18 Stg 2 17 Stg 2 16 Stg 1 15 Stg 1 14 Pmp 13 Pmp
Boiler #2
stage 1
stage 2
S2 S1
P2
A2
S6
S5
T1
6 7 8 9 10 11 Boil Com Setp Power Prim Dem Dem Dem N L P1
5A
1 2 3 4 5
268 Com Boil Boil Out UnO - Sup Ret + Sw
Do not apply power
5A
5A
5A
5A
5A
5A
5A
5A
5A
P1
C.A./ Alarm
Relay 1 1
Relay 2 2
Relay 3 3
Relay 4 4
Relay 6 6
typical for Boiler #3
Relay 5 5
Relay 8 8
typical for Boiler #4
Relay 7 7
Relay 9 9
12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
5A
Application —Electrical, Mode 6 example #2 (2x BTC 2PA, 1x tekmar 268)
D 901 - 09/02
19 of 20
© 2002
120 V (ac) L
24 V (ac)
Class II Transformer
12 C 11 10 9 Com 8 Boil in 7 Boil O 6 Sup/D 5 Os 4 Com 3 Set D 2 Ht D 1 CD
N
C
R
24R 23Alarm 22 21 20 19 18 Stg 2 17 Stg 2 16 Stg 1 15 Stg 1 14 Pmp 13 Pmp
Boiler #1
Electrical A1, A2 = Alarms P1 = Primary Pump P2, P3 = Boiler Pumps S1 = Outdoor Sensor 070 S2 = Boiler Supply Sensor 071 S3, S5 = Boiler Outlet Sensor 071 S4, S6 = Boiler Inlet Sensor 071 T1 = Thermostat
stage 2 stage 1
P3
A1
S4
S3
12 C 11 10 9 Com 8 Boil in 7 Boil O 6 Sup/D 5 Os 4 Com 3 Set D 2 Ht D 1 CD
24R 23Alarm 22 21 20 19 18 Stg 2 17 Stg 2 16 Stg 1 15 Stg 1 14 Pmp 13 Pmp
Boiler #2
stage 1
stage 2
S2
P2
A2
S6
S5
S1
T1
P1
6 7 8 9 10 11 Boil Com Setp Power Prim Dem Dem Dem N L P1
5A
1 2 3 4 5
264 Com Boil Boil Out UnO Sup Ret Sw
Do not apply power
5A
5A
5A
5A
C.A./ Alarm
Relay 1 1
Relay 2 2
Relay 3 3
Relay 4 4
12 13 14 15 16 17 18 19 20 21
5A
Application —Electrical, Mode 6 example #3 (2x BTC 2PA, 1x tekmar 264)
D 901 - 09/02
Technical Data Four Stage BTC 4PA Control Enclosure Dimensions Approvals Ambient conditions
Power supply Pump / Stage1 relay Stage 2 to 4 relays Alarm relay Demands Sensors included
Optional devices
Microprocessor PI control; This is not a safety (limit) control Enclosure D, black Noryl plastic 4-3/4” H x 2-7/8” W x 1-7/8” D (120 x 74 x 48 mm) CSA C US, meets ICES & FCC regulations for EMI/RFI. Indoor use only, -40 to 140°F (-40 to 60°C), < 90% RH noncondensing. 24 V ±10% 50/60 Hz 75 VA 120 V (ac) 5 A 1/6 hp, pilot duty 240 VA 120 V (ac) 3 A 1/6 hp 24 V (ac) 3 A 1/6 hp 20 to 260 V (ac) 2VA NTC thermistor, 10 kΩ @ 77°F (25°C ±0.2°C) ß=3892 2 of Universal Sensor 071 Universal Sensor 071
Power: 24 V ±10% 50/60 Hz 75 VA Pump/Stage 1 relays: 120 V (ac) 5 A 1/6 hp pilot duty 240 VA Stage 2 to 4 relays: 120 V (ac) 3 A 1/6 hp Alarm relay: 24 V (ac) 3 A 1/6 hp Demand input: 20 to 260 V (ac) 2 VA
H3001A
Setp Dem
Four Stage BTC 4PA 158033
Item
Signal wiring must be rated at least 300 V
tektra 901-00 Made in Canada
tekmar Control Systems Ltd., Canada tekmar Control Systems, Inc., U.S.A. Head Office: 5100 Silver Star Road Vernon, B.C. Canada V1B 3K4 (250) 545-7749 Fax. (250) 545-0650 Web Site: www.tekmarcontrols.com Product design, software and literature are Copyright © 2002 by: tekmar Control Systems Ltd. and tekmar Control Systems, Inc.
20 of 20
All specifications are subject to change without notice. Printed in Canada. D 901 - 09/02.
Related Documents 2w1qw
Btc Iom 2o4q
November 2022 0
Btc f3n11
May 2023 0
Free Btc 302z3p
April 2020 135
Presentacion Btc 2rt5b
May 2022 0
Fm2a58+ Btc 86k13
November 2019 89
