The X,Y coordinate system Everything that you draw in AutoCAD is exact. It will be more accurate than you will ever need it to be. We're talking 14 decimal points accurate. All objects drawn on the screen are placed there based on a simple X,Y coordinate system. In AutoCAD this is known as the World Coordinate System (WCS). You must understand this to know how to put things where you want them. (3-D work has an added axis, the Z-axis, but this is not covered in this lesson.) Below is a diagram showing you how this system works (place your mouse on the diagram for more info).

Here is how it works: AutoCAD uses points to determine where an object is located. There is an origin where it begins counting from. This point is (0,0). Every object is located in relation to the origin. If you were to draw a line straight out to the right from the origin, this would be considered the positive X-axis.

If you were to draw a line straight up, this would be the positive Y-axis. The picture above shows a point located at (9,6). This means that the point is 9 units over in the X-axis and 6 units up in the Y-axis. When you are working with points, X always comes first. The other point shown is (10,-4). This means that the point is 10 units in the negative X-axis (left) and 4 units in the negative Y-axis (down). A line has two points, a start point and an end point. AutoCAD works with the points to display the line on the screen. Move your cursor over the picture above and you will see line drawn from the absolute points of (-10,-4) to (9,6). Most of the time you will not have an indication of where the origin is. You may need to draw a line from the endpoint of an existing line. To do this you use relative points. These work the same way, but you have to add the @ symbol (shift+2) to tell AutoCAD that this next point is relative from the last point entered. myCADsite.com

To review: ABSOLUTE POINTS are exact points on the drawing space. RELATIVE POINTS are relative to an OBJECT on the drawing space.

Entering Points in AutoCAD

You can enter points directly on the command line using three different systems. The one you use will depend on which is more applicable for the situation. The first assignment will get you used to this. The three systems are as follows: ABSOLUTE CO-ORDINATES - Using this method, you enter the points as they relate to the origin of the WCS. To enter a point just enter in the exact point as X,Y. RELATIVE CO-ORDINATES - This allows you to enter points in relation to the first point you have entered. After you've entered one point, the next would be entered as @X,Y. This means that AutoCAD will draw a line from the first point to another point X units over and Y units up relative to the previous point.

POLAR CO-ORDINATES - You would use this system if you know that you want to draw a line a certain distance at a particular angle. You would enter this as @D
Command

Keystroke

Icon

Location

Result

Draw a straight line segment from one point to the next

Line

Line / L

Home rel="nofollow"> LIne

Circle

Circle / C

Home> Circle > Center, Radius

Draws a circle based on a center point and radius.

Erase

Erase / E

Modify > Erase

Erases an object.

Arc

Arc / E

Draw > Arc > Center, Start, End

Draws an arc based on a center point and 2 endpoints

Print

Print / Plot CTRL+P

Quick Access Toolbar > Print

Enables the Print/Plot Configuration Dialog Box

Undo

U / CTRL+Z

Quick Access Toolbar> Undo

Undoes the last command.

Assignment

Also print it in scale 1:1,so that the drawn lines and circles can be measured using a ruler. Topics covered in this Lesson: Rectangle | Extend | Offset | Trim | Introduction to Object Snaps

The previous lesson dealt with drawing commands. This lesson will introduce some common modifying commands. In AutoCAD, you may actually use modifying commands more often than drawing commands. Now that you know the basics, here's some more commands to add to your collection. Three commands, Trim, Extend and Offset are used often in 2D AutoCAD work. Command

Rectangle

Keystroke RECTANGLE / REC

Icon

Location

Result

H ome > Draw > Draws a rectangle after you enter one corner and then the Rectangle second.

Trim

TRIM / TR

Home > Modify Trims objects to a selected > cutting edge. Trim

Extend

EXTEND / EX

Home > Modify Extends objects to a selected > Extend boundary edge.

Offset

OFFSET / O

Home > Modify Offsets an object (parallel) by > Offset a set distance.

Object Snaps

CLICK OSNAP / OS / F3

Tools > Object Snap Settings

Brings up the OSNAP dialog box.

Assignment #2 - Modifying Commands

The purpose of this assignment is to use the commands learned in the previous lesson and learn some new ones. Duplicate the drawing called Assign_2. Click HERE to the DWG file. Once again, do not worry about title blocks, text or dimensions, draw only the geometry (in green). Start AutoCAD and begin the the drawing by opening up the template file like you did in Lesson 1-2. Draw a LINE from 1,2 to 3,2 to 3,4 to 1,4 (* to watch the command line as you do this.) For the last line's endpoint , you can either type in 1,2 or C to close the line back to the first point you entered. These are absolute coordinates. Make sure you understand what the points your just entered represent. Draw the next square using the RECTANGLE command. A rectangle is created by specifying 2 points to represent the opposite corners. Enter the first point as 4.5,2 and then make the opposite corner 2 inches over and 2 inches up @2,2 using relative coordinates. This is much faster and also makes the square one object and not 4 separate lines. ERASE the rectangle. You will see that all of it is gone with one pick. Redraw it and continue. For the 3rd square, draw a 1.5 x 1.5 unit square using any of the methods you know. The bottom left corner must be at 8,2. Draw a line from 2,5 to 2,6.5 Draw another line from 1,6 to 3,6 You should now have two perpendicular lines. What you want to do is trim off the top of the vertical line and create a T.

Start the TRIM command. It will first ask for a cutting edge. Select the horizontal line and press <ENTER>. It will now ask for the object to be trimmed. Select the vertical line anywhere above the horizontal (cutting) line and press <ENTER> to finish the command. This is what you saw on the command line: Command: TR <enter> TRIM Current settings: Projection=UCS, Edge=None Select cutting edges ... Select objects: <Select the Horizontal line> 1 found Select objects: <enter> Select object to trim or shift-select to extend or [Fence/Crossing/Project/Edge/eRase/Undo]: <Select the vertical line> Select object to trim or shift-select to extend or [Project/Edge/Undo]: <enter> Once again, it is important to keep your eye on the command line as it will guide you through most commands. Draw a LINE from 4,6.5 to 6,6.5 Draw another line from 5,5 to 5,6 What you want to do now is extend the vertical line up to the meet horizontal line. Start the EXTEND command. AutoCAD asks for a boundary edge; select the horizontal line press <ENTER>. It then asks for an object to extend; select somewhere in the top half of the vertical line. Press <ENTER> to end the command. Your command line history should match what is shown below. Command: EX <enter> EXTEND Current settings: Projection=UCS, Edge=None Select boundary edges ... Select objects: <Select the horizontal line> 1 found Select objects: <enter> Select object to extend or shift-select to trim or [Fence/Crossing/Project/Edge/Undo]: <Select the top half of the vertical line> Select object to extend or shift-select to trim or [Project/Edge/Undo]: <enter> Draw a CIRCLE with a center point of 7.5,5.5 with a radius of .5 Now you will use to offset command to make another circle 1/4" larger. Start the OFFSET command (watch the command line) and enter .125 as the offset distance (1/2 of 1/4"). Now select the circle and pick anywhere outside the circle. Press <ENTER> to end the command.
