AS/400 Guide

Version 1.0 Updated October 13, 2003

This document contains confidential and proprietary information of DMS SYSTEMS CORP and may not be disclosed to persons other than those to whom it was originally distributed. It must not be duplicated, published or used for any other purpose than expressly authorized by DMS SYSTEMS CORP.

Table Of Contents AS/400 Guide ...................................................................................................... 1 AS/400 Guide ................................................................................................... 1 General Concepts ..................................................................................................... 2 Computer Basics .................................................................................................... 2 AS/400 Operating System ....................................................................................... 3 Keyboard Basics .................................................................................................... 4 AS/400 Help.......................................................................................................... 6 Screen Layout ....................................................................................................... 7 Command Language (CL) ........................................................................................ 8 AS/400 Primary Menus ............................................................................................ 12 OS/400 Main Menu............................................................................................... 12 Tasks .......................................................................................................... 13 Office Tasks ........................................................................................................ 14 General System Tasks .......................................................................................... 15 Files, Libraries and Folders .................................................................................... 16 Communications .................................................................................................. 17 Define or Change the System ................................................................................ 18 Problem Handling................................................................................................. 19 Go To Menu ........................................................................................................ 20 Information Assistant Options ................................................................................ 23 Client Access/400 Tasks........................................................................................ 24 Daily Operational Tasks ........................................................................................... 25 New Setup................................................................................................... 25 Maintaining Profiles ....................................................................................... 28 g Onto the System ...................................................................................... 29 System Status..................................................................................................... 30 Messages............................................................................................................ 31

Jobs................................................................................................................... 36 Job Queues ......................................................................................................... 38 Output Queues .................................................................................................... 39 Spooled Files....................................................................................................... 40 Two sessions on a Workstation .............................................................................. 43 g Off.......................................................................................................... 44 Tape Operations ..................................................................................................... 45 Working with Tape Devices.................................................................................... 45 Tape Management ............................................................................................... 46 Saving Libraries to Tape........................................................................................ 49 Restoring Libraries from Tape ................................................................................ 50 Device Management................................................................................................ 52 Working with Devices ........................................................................................... 52 Printers .............................................................................................................. 53 Working with Print Jobs ........................................................................................ 57 Displays ............................................................................................................. 59 DMS Approved AS/400 Emulation Products .............................................................. 62 Communications..................................................................................................... 63 Remote Locations ................................................................................................ 63 Electronic Customer (ECS)......................................................................... 66 System Backup and Cleanup .................................................................................... 67 System Backup.................................................................................................... 67 IBM Monitoring .................................................................................................... 73 System Software Installation.................................................................................... 74 Installing System Software.................................................................................... 74 DMS System Upgrades and Releases ...................................................................... 75 IBM Version Releases ........................................................................................... 76 Scheduled Maintenance ........................................................................................... 77

Powering the System On ....................................................................................... 77 Powering the System Off....................................................................................... 79 System Cleanup................................................................................................... 82 Tape Drive .......................................................................................................... 84 IBM Program Temporary Fixes ............................................................................... 85 How to email documents from your DMS iSeries.......................................................... 89 How to create a Desktop Icon for Qwik-Order ............................................................. 90

AS/400 Guide

AS/400 Guide

AS/400 Guide The AS/400 guide is an overview of the basic operational functions to run an AS/400 computer system. The guide s the IBM documentation shipped with the computer. Where information may conflict with the IBM documentation, this document will defer to the authority of the IBM documentation. s of the guide include individuals responsible for the day-to-day operations of the system.

The document covers the basics of: Screen layouts Starting and stopping the system Daily operational tasks such as working with jobs and spooled files Printer, display and tape management Communications System backups

DMS Systems Corp. October 13, 2003 Version 1.0

1

AS/400 Guide

General Concepts Computer Basics Computers, while different, have three main operations in common:

The order in which these operations take place is controlled by a set of instructions called a program or application. When you request a task to be accomplished by the computer, the set of instructions is given to the computer by the program or application. The most important program which controls the basic functions of the computer System is the Operating System. The AS/400 Operating System is called OS/400. In addition to controlling all devices connected to the computer, the Operating System controls the numerous requests made by all connected s. The Operating System programs allocate time and use of various requests and jobs being performed. The Operating System allows the computer to: Run more than one program at a time Handle printed output Schedule work Communicate with s The fourth operation that a computer System performs is Storage of information.

A computer System is simply a few components (input devices, processor, output devices, and storage devices) being controlled by an Operating System.

2


AS/400 Guide

AS/400 Operating System The OS/400 Operating System provides the tools you will use to run the AS/400 hardware System. It allows you to run multiple jobs regardless of any other programs running at the same time. The major functions of the OS/400 program are: Control Language is the set of commands used to talk with the computer. Data Management allows the to define and use data files. Work Management controls many jobs, including jobs run by a single and jobs run by other s. Programmer Services provide for online program development and testing. System Operator Services provide a menu for easy access to frequently used operator functions. Communication allow AS/400 System to communicate with other types of systems as well as other AS/400 Systems. Security protects the data. PC allows personal computers to be attached to AS/400 as programmable workstations.


3

AS/400 Guide

Keyboard Basics The information provided is for use on standard PC Keyboards using terminal emulator programs such as IBM's Client Access for Windows or MochaSoft for Windows. Key names are typical however the key may not perform as documented if programmed to do other functions. Keyboard

Key Name

AS/400 Function

Ctrl

Used as Enter key (unless re-programmed to another key). See Enter.

Enter

Data entered is accepted or requested action processed

Home

Positions cursor on first enterable field

Tab

Moves cursor to next enterable field

Page Down

Show more information when a plus "+" shown beside field

Page Up

Shown previous information after Page Down is executed

F1

Help

- Exit Help F3 - Return to Main Menu

4

F4

Prompt for additional parameters when a command is entered on the command line

F9

Returns last command entered on command line

F12

Cancel action and return to previous menu

Function Keys (F1 F24)

As defined at bottom of screen


AS/400 Guide

Initial Screen Entry A cursor will be positioned at the beginning of a field for input on the display screen. This is normally the first field where data is entered. Data typed on the keyboard is entered in the field where the cursor is located. Positioning Cursor Use mouse to position cursor and press left mouse button. Pressing arrow keys positions cursor left, right, up or down. Pressing backspace key moves cursor left one space and erases data. Use when cursor is immediately following the data to be corrected. Pressing tab key moves cursor to next enterable field. Pressing shift key then pressing Tab key moves cursor to previous enterable field. Pressing delete key caused the next character to be deleted and all characters to move left one space. Use when cursor is immediately prior to the mistake to be corrected. When keyboard locks up or other mistakes are made, try the ESC (or Attn), F1 (or Help) to clear the error.


5

AS/400 Guide

AS/400 Help Press F1 key or the HELP key (depending on the terminal type) to access Help related to the screen displayed. Once Help System displayed, typical actions include: Press Page up or Page down keys to display additional information. Use mouse to position cursor on highlighted (yellow) words and double-click to display additional help Press F3 key to exit Help. Select function keys listed at the bottom of the screen for additional functions.

6


AS/400 Guide

Screen Layout Screen Layouts: (top to bottom) Screen Name Selection List or tasks groupings that lead to more menus and/or functions that or accomplish the request. Selection or Command line for entering: Selection number from the displayed list Command Language (CL) Function Keys provide additional options and more flexibility in accessing the System. Screen Bottom Left displays messages or warnings, such as "Function Key not allowed".


7

AS/400 Guide

Command Language (CL) CL commands are “short cuts” to either menus or AS/400 functions. They are entered from the Selection or Command line and executed when the ENTER key is pressed.

Example: "WRKSPLF" and Selection number “5” yields the same result.

Control Language Command names consist of Verb and Subject abbreviations.

8


AS/400 Guide

Command

Description

Verb

Subject

DSPMSG

Display message

DSP

MSG

WRKSPLF

Work with spool file

WRK

SPLF

WRKUSRJOB

Work with jobs

WRK

USRJOB

Common CL Verb and Subject Abbreviations

Verb

ADD

Description

Add

CHG

Change

CLR

Clear

Subject

Description

CMD

Command

DEV

Device

DEVD

Device Description

Y

Copy

DKT

Diskette

CRT

Create

DOC

Document

DLT

Delete

F

File

DSP

Display

FLR

Folder

END

End

HDW

Hardware

HLD

Hold

INF

Information

INZ

Initialize

JOB

Job


9

AS/400 Guide

Verb

10

Description

Subject

Description

MOV

Move

JOBD

Job Description

PRT

Print

JOBQ

Job Queue

RLS

Release

L

List

RMV

Remove

LIB

Library

RNM

Rename

MNU

Menu

RST

Restore

MSG

Message

SAV

Save

MSGQ

Message Queue

STR

Start

OBJ

Object

WRK

Work with

OBJD

Object Description

SBS

Subsystem

SBSD

Subsystem Description

SPLF

Spooled File

STS

Status

SYSVAL

System Value

TAP

Tape

USR


AS/400 Guide

Verb

Description

Subject

USRPRF


Description

Profile

11

AS/400 Guide

AS/400 Primary Menus OS/400 Main Menu Purpose:

Primary screen used for selecting a general task.

Audience:

System Operator

Navigation:

Go Main in command line

Comments: Screen Sample:

12


AS/400 Guide

Tasks Purpose:

Displays options for working with tasks, functions or jobs related to signon session.

Audience:

Systems Operator

Navigation:

Option 1 from Main Menu



13

AS/400 Guide

Office Tasks Purpose:

Displays options that facilitate productivity functions, including file transfers, granting permissions to s, queries and working with s' documents and files.

Audience:

Systems Operator

Navigation:

Option 2 from the Main Operations Menu


14


AS/400 Guide

General System Tasks Purpose:

Work with System-wide jobs and related functions such as spooled files, device and job status’s, printers, job and print queues, files, libraries and folders and system communications.

Audience:

Systems Operator

Navigation:




15

AS/400 Guide

Files, Libraries and Folders Purpose:

Work with data stored in files, libraries, and folders

Audience:

s who are responsible for data integrity

Navigation:



16


AS/400 Guide

Communications Purpose:

Select tasks for configuring and controlling communications network, both local and remote configurations and status’s of lines, controllers and devices.

Audience:

Systems Operator

Navigation:

Option 6 from the Main Menu



17

AS/400 Guide

Define or Change the System Purpose:

Plan, configure and install devices, such as tape drives, controllers, printers and displays. Apply IBM Program Temporary Fixes (PTFs) to IBM licensed programs. Change System values that control how the AS/400 operates

Audience:

Systems Operator

Navigation:



18


AS/400 Guide

Problem Handling Purpose:

Initiate problem resolution by displaying messages sent to the System Operator by the AS/400 System. Utilize messages to pinpoint origination of problem and diagnose the cause.

Audience:

System Operator

Navigation:




19

AS/400 Guide

Go To Menu Purpose:

Go to another menu simply by typing in the name of the menu, a portion of the menu name or "*ALL".

Audience:

System Operator

Navigation:


Comments:

"*ALL" displays all menus on the AS/400 for selection from. See list below for Most Common Menus Called from Go To Menu. To go to a menu shown in list, enter "Go Menu Name" in Parameters or Command Line

Screen Sample:

Most Common Menus Called from "Go To Menu" The Menus give access to all the tasks that execute similar functions.

Name

20

Description

CFG

Configuration

CMN

Communications

CMNSTS

Communication status


AS/400 Guide

Name


Description

DATA

Files, Libraries, and Folders

DEFINE

Define or change the System

DEVICE

Device operations

DOCUMENT

Documents

FILE

File

FOLDER

Folder

JOB

Jobs

LIBRARY

Libraries

MAIN

Main

MAJOR

Major command groups

MESSAGE

Messages

OFCTSK

Office tasks

PRINTER

Printer

PROBLEM

Problem handling

QUERY

Query utilities

RESTORE

Restore

21

AS/400 Guide

Name

Description

SAVE

Save

SECURITY

Security

STATUS

Status

SUBJECT

Subject commands

SYSTEM

General System tasks

TAPE

Tape

Tasks

VERB

Verb commands

Back to Top

22


AS/400 Guide

Information Assistant Options Purpose:

Locate information about AS/400 System, how to comment on that information and what is new in this release of AS/400 System. Search for AS/400 online books, start online education if course is installed, work with system problems, etc.

Audience:

System Operator

Navigation:


Screen Sample:


23

AS/400 Guide

Client Access/400 Tasks Purpose:

Provides options to enable connections and interfaces between PCs and AS/400, such as file transfer and use of printers attached to the AS/400.

Audience:

System Operator

Navigation:


Screen Sample:

24


AS/400 Guide

Daily Operational Tasks New Setup Before working on the AS/400 you must be set up as a so the operating system recognizes you when you sign on. The AS/400 utilizes a profile to make certain determinations as to menus, security levels, program applications, etc. that you will have access to once you are signed on. Note: See DMS System Menu 110 Option 13 (Employee) for additional setup considerations. Steps: Type "WRKUSRPRF" on the command line and press the F4 (PROMPT) key or ENTER key OR From Main Menu, select Option 7 From Define or Change the System, select Option 3 From Security, select Option 6 From Work with Profiles, enter "*ALL" on the profile line to display all active profiles

From the Work with Profile screen you can create, copy, delete, display or work with objects by owner. The easiest and quickest way to create a profile is to use an existing that is already set up. To do this, simply find a who is currently performing similar tasks as the new . During initial installation process, DMS setup two (2) profiles as clones: Name = "" with Power rights Name = "Limited" with more restrictive rights You may want to setup additional clones, such as one for each department. For example Finance, Order Entry, etc. Using this method, security profiles can be defined in detail to reduce the customization need for each employee profile. To create a clone or new profile (using copy function): See Alternative Method. Enter "3" in the Option field beside that s name and press ENTER Key. From Create Profile screen, enter: DMS Systems Corp. October 13, 2003 Version 1.0

25

AS/400 Guide New ’s name - "*USRPRF" (default) Text description = new 's identification Other fields = DMS for required entries. Press ENTER. The 's profile is established with sign-on name and equal to the same value. The can change their later.

Alternative Method: To create a clone or new profile (not the copy function): 1. 26

Type a "1" in the Option field beside Profile __________. Type the name of the you are establishing. DMS Systems Corp. October 13, 2003 Version 1.0

AS/400 Guide 2.

Press ENTER to display the Create Profile screen. Update fields as needed. DMS for required entries.

Back to Copy Method Back to Top


27

AS/400 Guide

Maintaining Profiles Many istrative processes require changes to Profiles. The most common change requests are as follows:

•

reset when forgets

•

Changes to access rights when changes positions

•

Disable profile when is terminated or voluntarily leaves the company

Steps: 1.

Type "WRKUSRPRF" on the command line and press the F4 (PROMPT) key or ENTER key OR

28

•

From Main Menu, select Option 7

•

From Define or Change the System, select Option 3

•

From Security, select Option 6

2.

From Work with Profiles, enter "xxxx" (xxxx = profile name) on the profile line to display the specific 's profile.

3.

For each of the situations above, enter "2" beside name and press enter key:

•

For resets, enter "*Same" in to reset to same as name

•

For profile disables, enter "*Disable" in Status

•

For other changes such as access rights, make changes as needed

•

To delete a profile, enter "4" beside name. Note: Profiles cannot be deleted if the owns objects, such as files, jobs, etc. These objects must be moved to another before deleting.


AS/400 Guide

g Onto the System The top right corner of the Sign On screen shows the name of the system, the subsystem, and the display station identifier (ID) g onto. Steps: 1.

Type your ID

2.

Use the Tab key to move cursor to field for entry. NOTE: The field is displayed only if security is active.

3.

Press the ENTER key.

4.

Depending on options defined in your profile, one or more of the following may occur:

•

The AS/400 Main Menu is displayed.

•

Another menu is displayed.

•

A program or procedure is run.

•

A current library is inserted into your library list.


29

AS/400 Guide

System Status The AS/400 provides quick access to the most important areas of the AS/400 system. From this display you can move to the areas that you will probably need to check most often in order to check printers, find jobs and look at spooled files, make changes or check the operational status of the system. Steps: 1.


2.

From General System Tasks, select Option 2

The most used options are normally be 1,2,3 & 4.

30


AS/400 Guide

Messages The AS/400 system uses messages extensively to convey information to s. These messages can be generated either from the AS/400 operating system or from s. The messages generated from the AS/400 are of two types: informational and warning. Some messages require a response in order for a further activity to take place. Most messages, however, are informational and do not require a response. Messages are sent to, received, stored and displayed from areas called message queues. There are four types of message queues. The type of message queue is important when displaying messages.

Queue

Queue Description

WRKUSR

Workstation message queue

WRKSTN

Workstation message queue

SYSOPR

System operator’s message queue

USRPRF

profile message queue

Instructions include: •

Send Regular Message

•

Send Break Message

•

Display Messages

•

Remove Messages

Send Regular Message Steps: 1.

Type "SNDMSG" on the command line and press the F4 (PROMPT) key or ENTER key. OR

•


•

From Tasks, select Option 3

2.

Type message in the text and who it is to be sent to.

3.



31

AS/400 Guide

Back to Instructions Back to Top

Send Break Message A break message will interrupt a ’s session and display immediately on the ’s screen. Steps: 1.

Type "SNDBRKMSG" on the command line and press the F4 (PROMPT) key or ENTER key OR

32

•


•


•

From Messages, select Option 2

2.

Type message in the text and who it is to be sent to.

3.



AS/400 Guide


Display Messages Steps: 1.

Type "DSPMSG" on the command line and press the F4 (PROMPT) key or ENTER key OR

2.

•


•


•

From Messages, select Option 2

To display messages enter one of the following options on the message queue line:

•

WRKUSR - display messages sent to the workstation message queue if any exist. After exiting messages sent to the profile message queue are displayed.

•

WRKSTN - display messages sent to the workstation message queue.

•

SYSOPR - display messages sent to the system operator message queue.

•

USRPRF - display messages sent to the profile message queue.


33

AS/400 Guide


Remove Messages From the display message screen you have three options on how to remove messages from a message queue.

34

•

To remove a message, press F11 while the cursor is on the message you want removed.

•

To remove all messages, Press F13.

•

To remove all except unanswered messages, press F16, leaving messages that require a response so a further activity can occur.


AS/400 Guide



35

AS/400 Guide

Jobs Execution of routines (called programs) on the AS/400 are referred to as jobs. There are two types of jobs that run on the AS/400. 1.

Interactive - s enter data at a terminal and receive data back from the AS/400

2.

Batch - a function to be performed or a program to be run is put in line with other programs or functions to be done “in the background”.

s can perform other activities while another request is being executed. The AS/400 has separate areas (subsystems) within the operating system where these activities are performed. For example, interactive and batch jobs are run in the QINTER and QBATCH subsystems, respectively. Other subsystems may exist that are subsystems of either QINTER or QBATCH that handle the processing of jobs. For example, the DMS D/E application has a subsystem named DMSDOC. Jobs can be further classified as:

•

Submitted jobs are submitted and waiting for the AS/400 to allot time to start processing

•

Active jobs are executing routines

There are two ways to check jobs to determine if they are running or waiting to be run:

•

Work with Active Jobs

•

Work with Submitted Jobs

Working with Active jobs Steps: 1.

Type "WRKACTJOB" on the command line and press the F4 (PROMPT) key or ENTER key OR

36

•


•



AS/400 Guide

Back to Options Back to Top

Working with Submitted job Steps: 1.

Type "WRKSBMJOB" on the command line and press the F4 (PROMPT) key or ENTER key OR

•


•

From Tasks, select Option 6

Back to Options Back to Top DMS Systems Corp. October 13, 2003 Version 1.0

37

AS/400 Guide

Job Queues The operating system decides how much time a job requires to run efficiently. This is accomplished using job queues. A job queue is part of or attached to a subsystem. The AS/400 assigns a job to a job queue before the job starts to run. There may be many jobs running in several job queues at the same time but in reality only a small piece of each program is being worked on for a brief period time. Because of the processing speed of the AS/400 it appears to the that the programs are running at the same time. The job queue allocates the jobs under its control until the job has been completed. The AS/400 gives some job queues a higher priority than other job queues. The QINTER job queue that handles interactive jobs has a higher priority than other job queues such as QBATCH that handles batch jobs enabling interactive jobs to completed more quickly. In some instances it may be necessary for the to change the way jobs are being processed. To do this you work with job queues. Warning: Exercise extreme care when making changes to job queues. Changes directly affect system processing and mistakes can lead to disastrous results. Steps: 1.

Type "WRKJOBQ" on the command line and press the F4 (PROMPT) key or ENTER key OR

38

•


•


•

From Jobs, select Option 5


AS/400 Guide

Output Queues When the AS/400 has completed processing a job, the results or output of the job are stored in areas known as output queues. An output queue can be a device such as a printer. All jobs that run on an AS/400 have an output queue assigned. Warning: Exercise extreme care when making changes to output queues. Changes directly impact the availability of processing output and mistakes can lead to disastrous results. Steps: 1.

Type "WRKOUTQ" on the command line and press the F4 (PROMPT) key or ENTER key OR

•


•

From General Systems Tasks, select Option 8

•

From Device Operations, select Option 3

•

From Printer, select Option 5

•

From Work with Output Queue, accept default of "*ALL"


39

AS/400 Guide

Spooled Files Spooled files are the internal “output” resulting from programs that run on the AS/400. The system maintains these files and the AS/400 generates the “hard copy” output that you receive on your printer. Spooled files are generated by:

•

Application programs

•

interface activity on the AS/400 i.e. running queries,

•

AS/400 operating system, i.e. job logs that tell what activities have taken place during a ’s session.

The Work With Spooled Files screen provides a list of spooled files on the system. You can find files for another , yourself, or for all s on the system. Steps: 1.

Type "WRKSPLF *ALL" on the command line and press the F4 (Prompt) key or Enter Key. For current , enter "WRKSPLF" or for a specific enter "WRKSPLF" and "'s Sign-on ID". OR

•


•


•

From Jobs, select Option 3

•

Enter "*ALL" in Name field. For current , enter "*CURRENT" and for a specific , enter 's Sign-on ID.

2.

Files are shown for the all s

3.

Type an option number next to one or more of the files and press the F4 (Prompt) key or Enter Key. Note: When the ENTER key is pressed, the function associated with the selected option is performed for the selected file. If you place more than one number in the entry fields, the specified functions are performed on the files in the order in which the files are displayed. If you press the ENTER key from this display without typing any other data, you are returned to the previous menu or display. The options you can select are:

40

Option

Command

Command Description

1

Send

Sends the spooled file to another AS/400

2

Change

Allows you to change the printer and/or the output queue that is currently associated with the spooled file.

3

Hold

Holds the spooled file so no further action can be DMS Systems Corp. October 13, 2003 Version 1.0

AS/400 Guide

4.

Option

Command

Command Description performed with it until it is released.

4

Delete

Deletes the spooled file from the system. When you choose this option the Confirm Delete of Spooled Files prompt is displayed. You can either accept or decline deletion. If you accept the spooled file is deleted permanently from the system.

5

Display

Displays the contents of the data in the spooled file to the screen.

6

Release

Releases the spooled file from hold status.

7

Messages

Displays messages related to the printing of the spooled file.

8

Attributes

Displays the attributes of the spooled file to the screen.

Enter F11 to obtain more information (3 different views of the same file).

The column headers describe the following: Heading

Description

File

The file name that was specified by the program when the file was created, or the device file

The name of the who owns the spooled file.

Device or Queue

If a printer was specified for this spooled file this is the name of the printer. It is also the name of the output queue that contains the file.

Status

Shows the status of the file. There are several statuses such as ready, open, etc. A spooled file can have a status with an * in front which indicates a change to the file as a result of taking an option.

Total Pages

The total number of pages or records in the spooled file.

Current Page

Shows page number currently being printed.


41

AS/400 Guide

42

Heading

Description

Copy

The number of copies of the spooled file printed


AS/400 Guide

Two sessions on a Workstation The AS/400 allows two sessions at the same time from one workstation address. All functions can be performed in both sessions. Use two sessions when 2 or more different operations are performed on the same workstation, such as order entry and receiving. For more than two sessions, see Additional Instructions. Warning: Use this function only when operationally required. It is easy to confuse which session you are in at any given time. Steps: 1.

Establish first session as normal through standard sign on process.

2.

“Toggle” out of that session in order to get to another sign on screen. Note: The specific key combinations used to “toggle” will vary according to workstation type or emulation package used. Key combinations mean pressing two keys at the same time. Some key combinations are ALT & SYSRQ, ALT & ESC, SHIFT & ESC, SHIFT & ATTN. Reference the display manual for specific key combinations.

3.

A dotted line appears at the bottom of the screen below the function keys and the cursor is at the start of the dotted line. Type 1 press ENTER.

4.

At the new sign on screen, repeat sign on process.

5.

To return to the original session "toggle" using the identified key combination.

6.

Sign off a session using the standard sign off process. g off one session, will return control to the other session.

Additional Instructions The workstation can be set up with more than one AS/400 address. Each address can have two sessions. Repeat the process below for as many addresses as workstation is allotted on the AS/400. Steps: 1.

To use the second address press the ALT & JUMP, or ALT & PAGE UP key combination (see note above) to bring up a sign-on screen.

2.

Sign on using standard sign on process.

3.

Follow instructions above to establish two sessions.


43

AS/400 Guide

g Off Steps: To sign off the AS/400:

44

1.

Enter Option 90 on Selection or command line and press ENTER key.

2.

Initial Sign On screen displayed.


AS/400 Guide

Tape Operations Working with Tape Devices Working with tape devices is the only way of making sure that data and operating systems can be recovered in the event of a major system crash. It is through the tape device that you save and restore new programs and updates as well as archived data. To your tape device is connected to the system and is operational you need to check its status. The following process shows the name of the tape device and it operational status. You have the option to vary on or off the device, work with any jobs on the device or display descriptions of the jobs. Steps: 1.

Type "Go TAPE" on the command line and press the F4 (PROMPT) key or ENTER key

OR

2.

•


•

From General Systems Tasks, select Option 8

•


From Work with Tape Device Status, select Option 6


45

AS/400 Guide

Tape Management Before you can save or restore information to or from a tape respective, you must have a tape in the tape drive. Warning: Before beginning any tape operation, you should make sure that the tape is set to the proper setting (either write-protected to prevent overlay or non-write protected to allow writing to) depending on the particular use of the tape. Instructions include:

•

Load Tape

•

Unload Tape

•

Display Tape

•

Initialize Tape

Load Tape Steps: To load a tape, follow these steps: 1.

Remove the tape from its protective cover. This is usually a clear plastic box that protects the tape from dust, light or moisture.

2.

Go to the front of the AS/400 U unit. Depending upon your model you may have one or more tape drives. Locate the proper tape door.

3.

Press the blue tape door release button to pop open the tape door.

4.

Slide the tape vertically into the drive as far as you can by hand until it stops. DO NOT FORCE THE TAPE ALL THE WAY IN.

5.

Close the tape door until it latches which will slide the tape the rest of the way into the drive. The blue tape door release button will pop back out.

6.

You are now ready to begin tape operations

Back to Top

Unload Tape Steps:

46

1.

Go to the front of the AS/400 U unit. Depending upon your model you may have on or more tape drives. Locate the proper tape door.

2.

Press the blue tape door release button to pop open the tape door and eject the tape.

3.

Slide the tape vertically out of the drive.


AS/400 Guide 4.

Close the tape door until it latches and the blue tape door release button pops back out.

5.

Make sure the tape is correctly labeled and return the tape to its protective cover.

Back to Top

Display Tape Before beginning any save or restore operations from tape you must first make sure you have the proper tape in the drive. Steps: 1.

Type "Go TAPE" on the command line and press the F4 (PROMPT) key OR

2.

•


•


•


From Tape, select Option 1 NOTE: Always enter "*print" in output field to view the contents from your spooled file. The "*" option will display the contents to the screen in an interactive job.

Back to Top

Initialize Tape A tape must be initialized before any data can be written to it. Steps: 1.

Type "Go TAPE" on the command line and press the ENTER key OR

•



47

AS/400 Guide

2. 3.

•


•


From Tape, select Option 2 To identify tape for future reference, enter a name that is easily recognized (ex. company name initials, such as DMS) into the New Volume Identifier field. Warning: The tape must be set to the proper density. With the cursor in the Tape density field press the F4=Prompt key to display a list of valid tape densities on the AS/400. Refer to the tape you are using to get the correct setting. Type in the correct density.

Back to Top

48


AS/400 Guide

Saving Libraries to Tape Saving libraries to tape is how you archive, distribute and backup data from the AS/400 so you can restore in the event of a system crash. The basic way to save a library and all its respective objects is to use the Save Library command. You can save:

•

Specific libraries by name

•

List of library names or a generic name

•

All non-System libraries by using the command *NONSYS.

Steps: 1.

Type "SAVLIB" on the command line and press the F4 (PROMPT) key or ENTER key OR

•


•


•

From Save, select Option 2

•

Save more than one library at a time by placing a (+) sign on the + for more values line and pressing ENTER. A second screen allows entry of multiple libraries.


49

AS/400 Guide

Restoring Libraries from Tape Restoring libraries from tape is how you archive, distribute and backup data to the AS/400 so you can recover in the event of a system crash. The Restore Library command restores a library and all its respective objects. Options include:

•

Restore specific libraries by name and list library names or a generic name.

•

Restore all non-System libraries using the "*NONSYS” command, if they were saved originally with the *NONSYS option.

Warning: restoring library to complete

Prior to restoring a library from tape, make sure the library you are from tape does currently exist on the AS/400. If it does, perform a delete remove the current version from the system to ensure that you have a backup from tape put on the system.

Steps: 1.

Type "RSTLIB" on the command line and press F4 (PROMPT) key or ENTER key

•

From Tape, select Option 5

OR

2.

•


•


From Restore, select Option 2 NOTE: Use "*all" in Database Member Option and Allow Object Differences fields.

50


AS/400 Guide


51

AS/400 Guide

Device Management Working with Devices s can change and control the interaction of physical hardware with the AS/400. Physical hardware includes displays, printers, tape drives, controllers, and virtual devices. Options are provided to diagnose and correct system problems relating to hardware. Steps: 1.

Type "WRKDEVD” on the command line and press the F4 (PROMPT) key or ENTER key. All devices installed are shown by default. To display a specific group of devices, enter "WRKDEVD xxx" where xxx = device group name, such as *prt for printers. OR

52

•


•

From Define or Change the System, select Option 1

•

From Configuration, select Option 1

•

From Configure Devices and Communications, select Option 1

•

On Configure Local Hardware, select the device type by enter the option on the command line.


AS/400 Guide

Printers Printers are the most frequently configured device type. These instructions include:

•

Setting Up Printers

•

Determine Status of Printer

•

Start A Printer

•

Stop A Printer

Setting Up Printers Recommended procedures for installing printers include:

•

Set the QAUTOCFG option under system values to “1”. The first time you power up a new printer the system automatically recognizes it and attaches it to the list of installed devices.

•

Establish naming convention: (see screen below)

•

Device Description (2nd column): PRTxxxx, where xxxx is an extension to make each unique. "PRT" as the prefix aids in differentiating printers from other output types and groups printers together when all devices are shown.

•

Text-Description Field (4th column): Describe where the printer is located

You can set up the printer by one of the following methods: 1.

Using F6=Create enter all required information such as name, type, controller, port, address and other printer specific information


53

AS/400 Guide 2.

Copy and Change. Using option 3 copy a similar existing printer specification and then using option 2 to change the parameters of the new printer.

3.

Setting up a printer through the display terminal it is attached to. Refer to the terminal manufacturer’s documentation for specific instructions.

Warning: Do not set up a printer at the same address as another existing device. The OS/400 will issue an “address conflict” message. The AS/400 uses controllers (designated as CTL) to determine where to set up specific addresses for devices. To setup a printer, you must know:

•

Controller printer will be connected to

•

Port on the controller the printer will be attached to

•

Address on the port printer connected to

For a visual layout of what is currently set up in the system:

•

Type "PRTDEVADR xxxx", where "xxxx" is the controller name and press ENTER key. A spooled file named QPDCDEVA is generated. It can be view and/or printed.

NOTE: Device controllers have ports that are numbered beginning with 0 (which is considered the first port). Each port has a limitation of 7 addresses. These addresses can be for any combination of devices but no more than 7 individual devices can be set up on any each port. As an example, if you have an 8-port controller the maximum number of devices ed would be 56 (this may be less depending upon how your location establishes the system console). Back to Top

54


AS/400 Guide

Determine Status of Printer Steps: 1.

Type "WRKCFGSTS *dev" on the command line and ENTER Key. All devices are displayed.

2.

From Work with Configuration Status, select the device OR

•

From Work With Device Descriptions, enter Option 8 next to printer and press Enter Key

In the above example, PRT01 is active and the job that is running is QSPLJOB number 013156. From this screen: Back to Top

Start A Printer A printer is varied off by loss of power either to the printer and/or to the display that the printer is attached to. In order for a printer to work it must be in VARIED ON and it must also be STARTED. 1.

From Work with Configuration Status, use option 1 to VARY ON a printer that has been VARIED OFF.

2.

Type "WRKWTR" on the command line and press the ENTER key to display a list of printers and the status of the writers.

3.

Type "STRPRTWTR xxxx" ("xxxx" is the printer name) on the command line and press ENTER key. The printer is restarted.


55

AS/400 Guide

Back to Top

Stop A Printer To make physical changes to the printer or to diagnose problem, the printer must be varied off. it is a good idea to also END the printer. 1.

Type "WRKWTR" on the command line and press the ENTER key to display a list of printers and the status of the writers.

2.

Type "ENDWTR xxxx" ("xxxx" is the printer name) on the command line and press ENTER key. The writer is ended.

3.

From Work with Configuration Status, use option 2 to VARY OFF an active printer. Note: After a printer has been ENDED it has to be STARTED again before it will print output.

Back to Top

56


AS/400 Guide

Working with Print Jobs s can change and control the interaction of print jobs with the AS/400. Display Messages for the System Operator helps determine detailed information about a printing job. Reference section on Working with Messages. Each printer-specific message will be displayed on the System Operator message queue. You are responsible for monitoring messages and taking appropriate action. Example: Invoicing job may require a special form. A message to "Change Forms" will hold up the print job until the responds. You may have to align the forms and/or tell the printer to continue printing from the point it stopped. Steps: 1.

Type "WRKCFGSTS *dev" on the command line and ENTER Key (all devices displayed) OR

•


•


•

From Device Operations select Option 1

•

From Work With Configuration Status, press ENTER Key

2.

From Work with Configuration Status, enter Option 5 beside printer

3.

From Print Writer, Press F6 for detail message information


57

AS/400 Guide

58


AS/400 Guide

Displays These instructions include:

•

Setting Up Display

•

Determine Status of Display

•

Stop A Display

•

Start A Display

Setting Up Devices Recommended procedures for installing displays include:

•

Set the QAUTOCFG option under system values to “1”. The first time you power up a new device the system automatically recognizes it and attaches it to the list of installed devices.

•

Establish naming convention: (see screen below)

•

Device Description (2nd column): DSPxxxx, where xxxx is an extension to make each unique. "DSP" as the prefix aids in differentiating displays from other output types and groups displays together when all devices are shown.

•

Text-Description Field (4th column): Describe where the display is located

You can set up the display by one of the following methods: 1.

Using F6=Create enter all required information such as name, type, controller, port, address and other display specific information

2.

Copy and Change. Using option 3 copy a similar existing display specification and then using option 2 to change the parameters of the new display.


59

AS/400 Guide 3.

Setting up a display through the display terminal it is attached to. Refer to the terminal manufacturer’s documentation for specific instructions.

Warning: Do not set up a display at the same address as another existing device. The OS/400 will issue an “address conflict” message. The AS/400 uses controllers (designated as CTL) to determine where to set up specific addresses for devices. To setup a display, you must know:

•

Controller display will be connected to

•

Port on the controller the display will be attached to

•

Address on the port display connected to

For a visual layout of what is currently set up in the system:

•

Type "PRTDEVADR xxxx", where "xxxx" is the controller name and press ENTER Key. A spooled file named QPDCDEVA is generated. It can be view and/or printed.

NOTE: Device controllers have ports that are numbered beginning with 0 (which is considered the first port). Each port has a limitation of 7 addresses. These addresses can be for any combination of devices but no more than 7 individual devices can be set up on any each port. As an example, if you have an 8-port controller the maximum number of devices ed would be 56 (this may be less depending upon how your location establishes the system console). Back to Top

Determine Status of Display Steps: 1.

60

Type "WRKCFGSTS *dev" on the command line and ENTER Key. All devices are displayed. DMS Systems Corp. October 13, 2003 Version 1.0

AS/400 Guide 2.

From Work with Configuration Status, select the device OR

•

From Work With Device Descriptions, enter "8" next to display and press ENTER Key

In the above example DSP11 is active and the job that is running is RHETT (the s ID) number 013404. Back to Top

Start A Display A display is varied off by loss of power to the display. In order for a display to work, it must be in VARIED ON. 1.

From Work with Configuration Status, enter "1" to VARY ON a display that has been VARIED OFF.

Back to Top

Stop A Display To make physical changes to the display or to diagnose problem, the display must be varied off. 1.

From Work with Configuration Status, enter "2" to VARY OFF an active display.

Back to Top


61

AS/400 Guide

DMS Approved AS/400 Emulation Products There are several terminal emulation products on the market that allow you to use your PC as an AS/400 terminal. The PC commands are translated into commands that the AS/400 recognizes and responds to. You have to install hardware and software to make this work. The DMS Systems Corp. approved AS/400 emulation products are:

•

IBM Client Access

•

MochaSoft

•

BOSaNOVA Plus manufactured by Better On Line Solutions, Ltd.

One of these products is installed on each PC where access to the AS/400 is needed. Instructions are provided in each package. It is not the intent of this section to discuss in depth the installation process. Below is a screen print of a PC that is connected to an AS/400 and emulating an AS/400 terminal.

62


AS/400 Guide

Communications Remote Locations The AS/400 uses lines and controllers to communicate with devices set up on the system both locally and remotely. To monitor these you use the Communications Status display. Instructions include:

•

Lines Status

•

Controllers Status

•

Devices Status

Lines Status Steps: To access the Communications Status screen: 1.

Type "WRKCFGSTS *lin" and press the ENTER key OR

•

From Main Menu, select option 6

•

From Communications, select Option 1

•

From Communication Status, select option 1

From this screen you can work with the lines in a variety of ways:

•

You can vary lines on and off, work with jobs or with line descriptions.

•

Using the function keys you can F14=Work with Lines to change, copy, delete, display or create new lines.

•

Using F23=More Options you can hold devices, end recovery, release devices, resume recovery or display communications status.


63

AS/400 Guide

•

Using F10=Display Associated Devices will list all devices associated with a particular line and also the type of those devices.

Back to Top

Controllers Status Steps: To display status of controllers: 1.

Type "WRKCFGSTS *CTL" on command line and press ENTER key OR

•


From this screen you can work with the controllers in a variety of ways.

•

You can vary on and off, work with jobs or with controller descriptions.

•

Use F14=Work with Controllers to change, copy, delete, display or create new controllers.

•

Use F23=More Options to hold devices, end recovery, release devices, resume recovery or display communications status.

•

Use F10=Display Associated Devices to list all devices and lines associated with a particular controller and also the type of those devices.

Back to Top

Devices Status Steps: To display status of devices: 1.

Type "WRKCFGSTS *DEV" on command line and press ENTER key. OR

64


AS/400 Guide

•


From this screen you can work with the devices in a variety of ways:

•

Vary on and off, work with jobs or with device descriptions.

•

Use F14=Work with Devices to change, copy, delete, display or create new devices.

•

Use F23=More Options you can hold devices, end recovery, release devices, resume recovery or display communications status.

•

Use F10=Display Associated Devices will list all devices and also the type of those devices.

Back to Top


65

AS/400 Guide

Electronic Customer (ECS) The AS/400 provides the capability of electronic customer . This feature enables interaction with systems at IBM and DMS Systems Corp. for software updates and upgrades as well as provide remote when circumstances dictate. DMS Systems Corp. uses a program called Bug Busters to enable personnel to sign onto your system remotely and work as if they were located at your place of business. This program is initially set up at system installation and normally will not be changed unless advised by DMS Systems. IBM uses electronic customer to distribute system upgrades and updates directly to your AS/400 upon request from you.

66


AS/400 Guide

System Backup and Cleanup System Backup Backing up data and system files on the AS/400 is the most important function executed on a regular basis. A backup plan must be established before loading production data. The initial full system backup is created when the AS/400 is installed and DMS systems are loaded. Daily backups are initiated at entry of data through the Menu 110 framework. Backups will not start if there are any active jobs running. s are forced off system before a backup starts without a warning message. While messages should be checked periodically during the day, they must be checked before start of business each day to the backup completed successfully. A common failure messages occurs when a tape drive needs to be cleaned. See instructions for Displaying Messages in Messages section. Insert tape labeled "Clean Cartridge" into tape drive to clean the drive. Restart job when cleaning is complete. Included in this process are:

•

Risks to Consider in Backup Plan

•

Backup Plan

•

Backup Tasks

Risks to Consider in Backup Plan: •

If current data is not recoverable in the event of a major system failure, then the entire operation will be brought to a standstill.

•

Volume of data that is reasonable to re-enter. This factor affects the frequency of backups For example, if you can afford to enter a weeks worth of transactions, backup should be made weekly. Consider the following:

•

Volume of changes, especially files

•

or processing cycles

•

Impact of the loss of data

There is no standard of what or how frequently data is backed up. The more frequent the backup, the more tape sets used and the more data saved the safer you are. Conversely, the less frequent the backups the more at risk you are. Using the Set up Backup option on the AS/400, you can perform backup tasks automatically on a schedule of your choice and back up as much data or as little data as you feel comfortable with. Back to Top


67

AS/400 Guide

Backup Plan Three major areas should be backed up: 1.

IBM System Libraries - ex. QUSRSYS, QGPL, QSYS, QHLPSYS, QDOC and others.

2.

Application/ Libraries - ex. ARLIB, APLIB, GLLIB, etc.

3.

Folders - ex. Mary Smith, John Doe, etc.

Plans vary according to business needs. Generally plans include:

•

Daily backups (all workdays) of libraries and folders that changed frequently.

•

Weekly or monthly backups of application/ libraries and folders.

•

Quarterly system backups

•

As needed following major system changes system backups. Major system changes include updating with releases or PTF’s, etc. A system save will save:

•

All AS/400 system libraries and objects, including profiles, system security, device configuration, and operating system objects.

•

All libraries including all licensed internal code and libraries, all documents and folders, all distribution and mail objects.

A system save will not:

•

Save the contents of any active job queues, output queues, or data queues.

Backup Tasks From this menu you can display backup status to determine what has been previously backed up and you set up automated backups. Steps: To access the Backup Tasks menu: 1.

Type "GO BACKUP" on the command line and pressing the ENTER key.

Back to Top

68


AS/400 Guide

From this menu you can change set up automated backups. 1.

From Backup Tasks, select option 10

The daily, weekly and monthly backup options screens all perform the same way.


69

AS/400 Guide

70


AS/400 Guide

From this screen you can change your backup library list. At a minimum the following libraries be backed up daily: File

Description

A99XXX

Client specific customized files for the A/P application

A99FILES

A/P application files

DMF010

DMS application files

DMSXXX

Client specific customized files for the D/E application

DMUXXX

Client specific customized files for the D/E application

DMSPGMTNEW


DMSUSRQRY


G99FILES

G/L application files

G99XXX

Client specific customized files for the G/L application

P99FILES

Payroll application files

P99XXX

Client specific customized files for the Payroll application

From this screen you can change your backup times. You need to be aware of processing that occurs on your system before setting up backups.


71

AS/400 Guide

Back to Top

72


AS/400 Guide

IBM Monitoring IBM provides a monitoring service to check the AS/400 hard drive(s) on regular intervals for potential failure. This requires the following:

•

Dedicated phone line to AS/400

•

Regular review of messages for IBM notification

•

Schedule IBM representative to assess hard drive and take necessary action


73

AS/400 Guide

System Software Installation Installing System Software Your AS/400 has come loaded with the latest versions of the DMS Distribution Express software and IBM’s OS/400 operating system, program products and licensed internal code.

74


AS/400 Guide

DMS System Upgrades and Releases DMS Systems Corp. issues updates, fixes and new releases of its software as needed. The new software updates and fixes are transmitted electronically and applied directly to your AS/400 system. New application releases are distributed to you on tape. You are responsible for restoring new programs or enhancements from tape to your system. You will be advised in advance enabling time for planning the implementation of new functionality into your organization.


75

AS/400 Guide

IBM Version Releases IBM issues new releases of its OS/400 operating system, program products and licensed internal code. New releases are called versions and will be handled through DMS Corp. DMS orders the new version releases for you. There is generally no charge except for media (tape or CD-ROM) for these version releases. You are responsible for loading these onto your system. Once they are ed to the AS/400 they must be installed. You can view licensed programs and operating system versions running on your machine. The Install Licensed Programs screen is helpful in determining if the latest releases are installed. Steps:

76

1.


2.

From Define or change the system, select Option 2

3.

From Work with Licensed Programs, select Option 11

4.

From Install Licensed Programs, press F11=Display Release command key.

5.

Where the Installed Release column is blank, the release is not installed on your system.

6.

From this screen, type 1 in the Option column and press enter to install the versions not installed. These are the version releases that are sent to you on either tape or CDROM media and have been ed.


AS/400 Guide

Scheduled Maintenance Powering the System On When you start the AS/400 (turn the power on), an IPL (Initial Program Load) is executed for the system to reset and recognize changes to certain system characteristics. There are four situations that typically require an IPL:

•

Starting normal operations

•

Starting a remote system

•

Changing configuration options

•

Recovering after a power failure

The IPL system default from IBM is unattended (normal). It is executed automatically after the power is turned on and the Sign On display is shown on all available display stations. This documentation addresses only the unattended IPL. Warning: Due to the problems that can occur if an IPL is not completed successfully, s must call DMS prior to re-starting the AS/400.

Before Powering on the System: 1.

Turn on the power of display stations, printers, tape devices, disk devices and controllers used.

2.

Make sure the mode is set to Normal.

•

Press the right or left select push buttons (up and down arrows located above) until 02 is displayed in the Function/Data display box.

•

Press the blue ENTER push button located to the right of the select buttons to accept the 02.

•

Press the right or left select push buttons until 02 BN is displayed in the Function/Data display box.

•

Press the blue ENTER push button to accept the 02 BN.

•

Press the right or left select push buttons until 01 BN is displayed in the Function/Data display box.

•

Press the blue ENTER push button to accept the 01 BN.

To Power on the System: 1.

Press the Power On/Off button (the large square white button on the AS/400 U unit) to start the system. In normal start up mode a series of numbers will be displayed and will change frequently in the Function/Data display box. If these numbers do not display or fail to change or the system attention light comes on and remains lit an error condition has been encountered.


77

AS/400 Guide NOTE: It may take more than 1 hour for the system to completely power up under normal circumstances depending on such factors as your system model and configuration. This is normal. If the system has to be restarted after a hard shut down, for example, a power failure, it may take much longer. You are allowed to sign on to the system before an IPL has finished, but some functions may not be available until the IPL has completed.

78


AS/400 Guide

Powering the System Off WARNING: You can stop the system using the Power On/Off button (the large square white button on the AS/400 U unit) if you are in the MANUAL MODE, however, this is NOT RECOMMENDED because of the errors that may occur with your data files. A schedule that automatically powers your system on and off can be setup. You can determine the time of day you want the system powered on and off and specify special circumstances that change that normal daily schedule, such as a holiday or special closing. This requires setting certain system values.

Before you stop the system Make sure all s are signed off the system and all batch jobs are finished: 1.

2.

3.

Send a message that interrupts all s signed on the system telling them to sign off.

•

Enter "SNDBRKMSG" on command line and press ENTER key

•

Type in message telling s to sign off the system for a power down.

•

Type *ALLACT in the Send to field to send the message to all active s.

Check to make sure all s have signed off the system.

•

Type WRKACTJOB on the command line, press ENTER key.

•

When everyone is signed off the system, the display will show only your job with status = run. To sign someone off the system, place a 4 in front of the and press the ENTER key.

•

Press the F5 (Refresh) to redisplay to make sure your job is the only active job.

Check the status of any batch jobs that might be affected if the system is powered down.

•

Type WRKACTJOB on the command line, press ENTER key. NOTE: If the Work with Jobs display is shown, you need to switch to basic assistance level (1) using F21 (Select assistance level).

•

Press F14 (Select other jobs) on the Work with Jobs display.

•

Type "*ALL" in the field.

•

In the vertically displayed options type an "N" in every field except the Message waiting, Running, and Running job held fields. The Work with Jobs display is shown again with the batch jobs listed.

•

If any job queues have jobs waiting to run, press F22 (Work with Job queues) to see the Work with Job Queues display.


79

AS/400 Guide

•

Hold any job queues that have jobs waiting to run on the Work with Job queues display. NOTE: You must release these job queues when the system is restarted.

4.

•

Press F12 (Cancel) to return to Work with Jobs display.

•

Press F5 (Refresh) every few minutes to view the active jobs until all active jobs have completed processing.

Make sure there are no tapes in any of the tape drives and no disks in any of the disk drives.

Powering off the system Power off the system immediately 1.

Type "Go Power" in command line and press the ENTER key.

2.

Select option 3 (Power off the system immediately) if you want to keep the power off until the next time the system is scheduled to power on or it is done manually.

3.

Use the Confirm Power Off of System display to either confirm or cancel of the power off option. When you press F16 (Confirm), an immediate power down occurs that causes the subsystems to end all active jobs.

Power off the system and restart immediately

80

1.

Type "Go Power" in command line and press the ENTER key.

2.

Select option 4 (Power off the system immediately and then power on) if you want to power off the system and then immediately restart the system.

3.

Use the Confirm Power Off of System display to either confirm or cancel of the power off option. When you press F16 (Confirm), the system stops running and then starts again automatically.


AS/400 Guide


81

AS/400 Guide

System Cleanup In order to keep the AS/400 functioning as efficiently as possible it is necessary to periodically clean up the system to remove any unnecessary or unneeded messages and other types of logs. You can request that s delete their own logs on a periodic basis but it is easier to set up the AS/400 to perform this task automatically. Included in this procedure are:

•

Cleanup Tasks

•

Change Cleanup Options

Cleanup Tasks Steps: To access the Cleanup Tasks display: 1.

Type "GO CLEANUP" on the command line and press F4 (PROMPT) key or ENTER key

Back to Top

Change Cleanup Options From this screen you can change any of the fields. The system defaults are listed below. The AS/400 time is military time so 22:00:00 is 11:00 p.m. each day. Steps: To change the cleanup options: 82


AS/400 Guide 1.

From Cleanup Tasks, select option 1

It is recommended that the automatic cleanup option be set to Yes all the time.

Back to Top


83

AS/400 Guide

Tape Drive Tape drives must be cleaned on regular intervals to ensure backups and the nightly job schedule complete successfully. A drive that needs to be cleaned will stop the job schedule from completion and limit business as usual the next day until the drive is cleaned and jobs finished. Steps: If cleaning tape drive as part of regular maintenance: 1.

84

Insert tape labeled "Clean Cartridge" into tape drive to clean the drive.


AS/400 Guide

IBM Program Temporary Fixes IBM issues PTFs (Program Temporary Fixes) to update its OS/400 operating system, program products and licensed internal code until new release versions are issued. Warning: You are not notified by either IBM or DMS Corp. when PTFs are available. It is your responsibility to order these PTFs directly from IBM. It is recommended that you order PTFs every 6 months to ensure your operating system has the latest changes. Steps: To access the Program Temporary Fix screen: 1.

Type "GO PTF" on the command line and press F4 (PROMPT) key or ENTER key OR

•


•

From Define or change the system, select Option 6

The PTF process is basically 3 steps: 1.

Ordering

2.

Loading

3.

Applying

Back to Top


85

AS/400 Guide

Ordering PTFs Before ordering, IBM to obtain the CUMULATIVE PTF PACKAGE number for your OS/400 version. A cumulative package includes all PTFs issued from the version release date through the date of order. It ensures all the current fixes are delivered for applying to the OS/400 operating system. Each PTF is assigned a generic ID number. The format is SF99VRM where V=OS/400 version, R=OS/400 release number and M=modification number ex. SF99V3R1M0. Steps: To order a PTF: 1.

From Program Temporary Fix, select Option 6

2.

Enter a PTF identifier (required to proceed).

3.

At the end of the ordering screens, you will be prompted to your company information such as address, phone number, name etc. When all the request information has been entered press the ENTER key.

4.

The order request is sent to IBM through ECS (Electronic Customer ).

5.

Upon receipt IBM sends the requested PTFs back either through ECS or on media (tape or CD-ROM) (for large changes in of data)

Back to PTF Process Back to Top

86


AS/400 Guide

Loading PTFs Once you have been notified either through a message to the system operator that the fixes have been received or a delivery from IBM you must load the PTFs onto your system. Steps: 1.

From Program Temporary Fix, select Option 1.



87

AS/400 Guide

Applying PTFs Once you have loaded the fixes that have been received you must then apply the PTFs onto your system. Steps: 1.

From Program Temporary Fix, select Option 2.

2.

Once the PTFs are applied, you must IPL (Initial Program Loaded) the system, enabling the changes to take affect and become “permanent” until the next release version is applied to the system.


88


AS/400 Guide

How to email documents from your DMS iSeries. Requirements:

PC with Microsoft Outlook, IBM Client Access, and an Internet connection

Exporting AS/400 printer output to your PC: You can easily export an AS/400 printer output file to your PC file system where you can work with it using various PC Office tools – Excel, Word, Outlook Example - you can attach an AS/400 printer output file for an invoice, Purchase Order, Report, Query, etc. to an e-mail.

(Printer output files are converted to ASCII text files when they are exported.)

To export an iSeries printer output file to your PC, follow these easy steps: •

Double click the iSeries Operations Navigator icon located on your Desktop.

•

Expand System under My Connections (left ) by clicking the "+" sign or double-click My Connections and then select your connection option. (If you have not already established a connection from your PC to the iSeries (AS/400), you will be presented with a “Sign-on to iSeries” window where you will be expected to enter your iSeries ID and .)

•

You may get a Windows sign-on screen that will need your ID and .

•

Expand Basic Operations by clicking the "+" sign.

•

Click your desired Printer output option.

•

(A list of printer output files will appear in the right of your screen.) Using the drag-and-drop feature, drag the desired printer output file to your desktop. (You can also right-click your desired printer output file and select Copy and Paste the file to the location of your choice.)

Once the file is located on the PC desktop, follow the normal operations for attaching a file to your email, printing the file or etc.


89

AS/400 Guide

How to create a Desktop Icon for Qwik-Order The best way to create a Qwik-Order desktop for your customer’s to easily access your QwikOrder Website Portal is as follows:

1.

Send them an email with a link to your Qwik-Order website. (For Example: http://66.179.164.71:?? DMS for the complete link number)

2.

Clink on the link above and the Qwik-Order website comes up in their Internet Explorer browser.

3.

Clink on ‘File’ on the menu bar at the top left of the screen.

4.

Click on ‘Send’ and then select ‘Shortcut to Desktop’

This will place a Qwik-Order icon shortcut on their desktop. After clicking on it to start Qwik-Order, the icon will change to your customer’s Qwik-Order icon designed for you so that it will stand out on their desktop and be easy to find.

90


As 400 Guide 5t3x38

Overview 1s532p

More details 6h715l

Related Documents 2w1qw

As 400 Guide 5t3x38

As 400 Guide 6i382b

As 400 e182z

Dr 400 Manual 6j2112

As 400 Tutorial 162w58

Conexion Libre As 400 1lr22

More Documents from "Vijay Das" 3e3a3e

As 400 Guide 5t3x38

Fault Current Limitar 1i1j2a

Marketing Research Project d335d

Introduction To Sentaurus Tcad 123h5

Mensuration Formulas For Ssc And Banking In Pdf Part 2 2w3m3k
