Simplifying Air-Traffic Control: An Exercise in Software Design Daniel Jackson & John Chapin MIT Lab for Computer Science {dnj, jchapin}@lcs.mit.edu July 15, 1999

Abstract

We redesigned and reimplemented a component of CTAS, an air traffic control system developed by NASA and now deployed in several US airports. Our case study demonstrates how basic software engineering techniques can make a complex system dramatically simpler. We describe lessons learned from reverse engineering the component with a variety of tools and redeg it to be smaller, simpler and more flexible.

1

What this paper is about

Many managers now believe that improved process is the key to better software, and that technology is a second-order effect. We disagree with this view. In this project we achieved dramatic simplifications of a complex software system, using basic software engineering techniques of the sort commonly taught in university courses but still not widely used in industry. The original purpose of the case study was to explore the power of advanced techniques such as object modelling; we were surprised to discover that basic techniques were sufficient. We took a component of a complex system written in about 80,000 lines of C++ code, replaced it by a new version in Java about one-fifth of the size, and demonstrated that the system still performed its primary functions. Although our new version only performs the essential functions of the original component, it could be extended to cover the full functionality without any substantial change in its architecture. In this paper we explain how this was achieved and what lessons we drew from it, in particular for industrial practice and for computer science education. The impatient are encouraged to jump straight to the discussion of the lessons we learned from this project (Section 7). If you want to understand our design and how it relates to the original design, you should start at the beginning, but you can omit the sections on how the case study was organized (3) and how we reverse engineered the code (4).

1

2

Overview of CTAS

The Center/TRACON Automation System (CTAS) is a suite of tools to help controllers manage air traffic flow at large airports. It should not be confused with its anagram TCAS, which is a different system installed on-board aircraft that warns pilots of impending collisions. In the United States, the rate at which aircraft can land at airports is the limiting factor in air traffic flow. The purpose of CTAS is to increase the landing rate through automated planning. CTAS receives as input the location, velocity, and flight plans of all aircraft near an airport, along with weather data, information about available runways and standard landing patterns, and controller commands. CTAS combines this information with models of the descent rates and other characteristics of specific aircraft to make accurate predictions of aircraft trajectories as much as forty minutes in advance. This information is fed into dynamic planning algorithms which suggest a landing sequence that minimizes unused landing slots. An installation of CTAS at Dallas/Fort Worth (DFW) has produced a 10% improvement in the sustained landing rate, which is regarded as a major success. CTAS contains two primary tools. The Final Approach Spacing Tool (FAST) is used by low-altitude controllers who manage the airspace near an airport. The Traffic Management Advisor (TMA) is used by high-altitude controllers who manage aircraft further away. The two tools involve largely the same set of software components. The output of CTAS is a suggested timeline. Figure 1 shows sample output from TMA, a timeline for aircraft crossing the boundary from the high-altitude domain to the low-altitude domain. A marking on the central timeline of 10 indicates 10 minutes from the current time. The appearance of EGF586 on the left at 6.5 minutes from now indicates the time at which Air 586 will arrive at the boundary if it follows its current trajectory. The appearance of “EGF586 3” on the right at about 9.5 is a suggestion to delay the aircraft by 3 minutes. The architecture of CTAS in TMA configuration is shown in Figure 2. The Communications Manager (CM) sits at the center, where it acts as a message switch moving data among the other components and maintains the database of aircraft information (position and velocity, aircraft type, etc.). Input data streams such as radar feeds and flight plans are collated by the Input Source Manager (ISM). The algorithmic processes are the Route Analyzer (RA) and Trajectory Synthesizer (TS) which collectively predict paths and arrival times for aircraft, and the Dynamic Planner (DP) which computes runway assignments and suggested delays. In addition to its primary functions as message switch and database, the CM acts as the “main” process, responsible for initializing most of the other processes and terminating them when they appear to be behaving inappropriately. Neither FAST nor TMA can run without the CM, and if the CM dies, the system dies with it. In contrast, failures of algorithmic or interface processes can be tolerated.

3

Reasons for a case study on CTAS and CM

CTAS is an attractive subject for a case study for several reasons. • It is a prime example of infrastructural software: software that operates vital systems such as transportation, medicine, power, etc. Working on CTAS enables evaluating the viability of software engineering techniques for this important class of software systems. • CTAS is large enough to present the complexities typical of large-scale software development, rather than a small safety-critical device. The code of CTAS is about half a million lines long. • CTAS is not a strawman. Although most of NASA’s efforts have been directed towards algorithmic aspects of CTAS, not its software engineering aspects, it is a well-constructed piece of software.

2

Indeed, CTAS has been officially adopted by the FAA for nationwide deployment. As part of this effort the FAA has hired Computer Sciences Corporation to extend CTAS with additional features. Even without CSC’s extensions, the “research” version studied here is in daily use at DFW. Within CTAS, this case study focused on the CM. While the algorithmic components are well understood and stable, the CM has grown steadily over the development cycle and has become the repository for various unrelated features, which were placed there only because they have no obvious home elsewhere in the system. As a result, the CM is complicated and its design is less elegant than the design of the rest of CTAS. It is also the only single point of failure in the system so its reliability is particularly critical. Its source code is in about a hundred files and is about 80,000 lines long, of which about a quarter are comments.

4

Organization of the case study

The case study was run as a one-semester graduate seminar entitled “6.894: Workshop in Software Design” [6894]. Twelve students and three faculty participated. We started by reverse engineering the existing system. Based on the resulting list of problems and proposed solutions, we decided to reimplement the CM completely rather than modifying the existing code. After substantial design work, the students spent three weeks in implementation and at the end successfully demonstrated basic system operation with the new CM. The new component was written in Java, had about 50 classes and 10,000 lines of code. Handling of messages depended on a script about 1800 lines long (of which 1450 were taken verbatim from the previous C version of the CM). This script was processed by a compiler, built by one of the teams specially for the project, into about 2000 lines of Java. The compiler itself was 10,000 lines of C++; its cost was not justified within the scope of the project, but might have paid off had we reimplemented the CM in its entirety. A separate paper describes the message scripting language and compiler [KPM99].

5

Reverse engineering efforts

The case study began with an effort to understand the existing design of CTAS in general and the CM in particular. We used our ignorance of the existing design as an opportunity to experiment with several reverse engineering tools. Of the lessons that came out of this experience, the most interesting perhaps was realizing how dramatic is the effect of coding style on the utility of analysis tools. The documentation for CTAS includes motivation and architecture overview [NASA], software structures [CSC], manuals, and research papers on the underlying algorithms [DKB94]. However, there appears to be no document that explains in high-level what the system computes or what assumptions it makes about its environment. Nor is there a design document that describes the relationship between the components of CTAS: how they communicate, what services they offer, etc. We were forced to infer this information from the code, a challenge common to many commercial development efforts. We used three off-the-shelf tools and built two others. We also spent a lot of time simply reading the code, a task much eased by NASA’s consistent naming and code layout standards. Imagix is a commercial visualization tool that constructs a cross-reference database from the source code and uses it to generate sophisticated reports and diagrams [Ima]. We used it to generate a variety of call graphs. Its ability to abstract by showing calls between files rather than individual procedures was essential. It was able to handle the entire Communications Manager, and we generated some useful call graphs from it. We tried to use its impressive array of cross-referencing relations to compute an approximate object model from the header files, but were not successful. Imagix:

3

Lackwit is a research tool that uses type inference to analyze data structures in large C programs [OJ97]. Lackwit was able to generate a database of the entire Communications Manager in about 80MB, and we used it successfully to answer queries about where in the code particular data structures were used. We also used it to construct a call graph showing only those procedures involved in the direct handling of an aircraft record. Lackwit can make semantic distinctions that syntactic tools such as Imagix cannot. For example, one query asked where values held in a particular integer variable might flow. This variable held an identifier for a Route Analyzer process. The variables and data structure fields that were identified by Lackwit could not have been found with grep, since although many of these had a name ending “ra_index”, not all did, and their type was not sufficient to distinguish them. Unfortunately, a bug in Lackwit prevented us from analyzing static procedures (of which several were crucial), and Lackwit’s handling of type casts was not as good as d. CodeSurfer is a program slicer in beta release [Gra]. CodeSurfer offered the most powerful features of the three off-the-shelf tools: it can generate program slices and display them graphically or textually. This would have allowed us to show, for example, the code that might affect the value of a field in the aircraft database. Unfortunately the CM proved too large to be analyzed directly by CodeSurfer. The fact that Lackwit handled the CM while CodeSurfer could not was no surprise, since Lackwit was designed largely to overcome the well-known scalability limitations of current slicing techniques. Although CodeSurfer does not scale to the same size systems as Lackwit does, it provides more detailed semantic information than the type inference algorithms used in Lackwit–-it is flow sensitive, for example. We are continuing to experiment with applying CodeSurfer to fragments of the CM. It should be pointed out that we were using a beta release generously provided to us by Grammatech; we would probably have had more success were it not for some flaws that have now been corrected. One team of students constructed an ad hoc tool that generated a function concordance that could be viewed across the web. When a function name was entered into the HTML form, the tool displayed an entry giving the function’s arguments and results, a list of calling and called functions, and frequently a two line specification. These entries were cross-linked to the code for easy navigation. The tool also generated diagrams showing call graphs of various forms; functions appearing in the graph could be selected by regular expression matches against their names. The concordance generator proved extremely useful as an aid to studying the code.Its success was due, in retrospect, to several factors. First, the web interface is hugely beneficial: it spares the the effort of setting the tool up, learning how to invoke it, and dealing with the query syntax. It also eliminates all problems of platform dependence, since the tool runs on a single machine. Second, by employing AT&T’s dot graphing program [ATT] as a backend, the tool was able to respond to queries with well-formatted, easyto-read diagrams. Third, the tool exploited NASA’s rigorous coding standards: almost every function in the code had a standardized header with a brief specification and list of arguments, much in the style of JavaDoc, and these were brought out in the concordance enabling readers to rapidly learn the meaning of a function. The same group that developed the function concordance also built a post-processor that converted message traces into message sequence charts, in which messages are shown as horizontal lines between vertical lines that represent processes executing through time. This tool made it much easier to understand the protocols between the CM and the other components, which was a vital step in successfully replacing the CM. The archaeological work performed in this phase uncovered some previously unknown problems with the CM implementation, indicating that our reverse engineering got beyond the surface level. A primary reason we were able to do this so quickly is the effective coding and commenting standards that Lackwit:

CodeSurfer:

Concordance generator:

Message sequence chart generator:

Results:

4

NASA followed, which enabled Imagix and the concordance generator to effective and rapid study of how various functions were implemented.

6

The Existing Design

The existing CM design uses a functional decomposition. There is a module that handles addition and deletion of flight plans, for example; a module that interacts with the Input Source Manager; a module that maintains the assignment of aircraft to Route Analyzers, etc. The control flow of this design is implicit. There is a Motif interface: not, it should be noted, for the air-traffic controller, but for system s to configure the CM itself. The main processing loop runs when called periodically by Motif. Here is a partial list of problems identified in the existing design and addressed by the redesign. • Blocking sends: The NASA developers regarded this as the most serious problem. Because the sending of messages uses blocking primitives, it was possible for the CM to become deadlocked. At certain points, the CM would create more messages than the algorithmic processes could handle. It would fill its outgoing buffers and stall, waiting to write more. Meanwhile, an algorithmic process would send a message to the CM and wait for a response before continuing to process further messages. To mitigate this problem, the NASA team modified the CM to batch messages into groups of limited size. This causes considerable complexity in the current design, and also makes the behavior of the system as a whole hard to analyze. • Failures: The system is not fault-tolerant. Although it can withstand the crash of an algorithmic process or a interface, the CM is a single point of failure, and once it crashes, the entire system must be rebooted. The FAA has specified that no system outage is to last longer than 25 seconds, yet it takes more time than that to restart the system and refill the aircraft database with fresh records. • Monitoring: The FAA would like to add various monitoring features to CTAS that would allow its behavior to be continually evaluated, both to measure performance and to detect symptoms of impending failure. Adding this to the existing CM is difficult, because it is not clear what the impact of inserted code would be, nor is it easy to find points in the code that should be instrumented. • Complexity: The NASA developers are dissatisfied in general with the complexity of the Communications Manager. Having never had the opportunity to redesign it, they have watched with concern as it has become more and more complicated. The CM has become unwieldy, showing the properties of all software systems whose structure has degraded: small changes are hard to make, and analyzing even simple properties of the CM as a whole is close to impossible. We decided to focus our redesign effort on reducing the complexity of the CM, with the conviction that many of the other problems would be ameliorated as a byproduct of this effort. Our design addressed the problems of monitoring and blocking sends explicitly. We believe the benefits we achieved by focusing on complexity reduction may be achievable in other commercial systems, especially if they have evolved over a number of years. We did not address the fault tolerance issue as part of our group project, but one student designed an architecture in which the CM is wrapped and replicated, and was able to demonstrate a successful implementation of this scheme by the end of the term. In our redesign, we also separated those parts of the state that cannot be trivially reconstructed on reboot from the rest, with the intention that these might eventually be stored in a persistent object-oriented database.

5

7

The New Design

In our redesign, we investigated how the CM might look if NASA were able to redesign it from scratch. Our new design, shown in Figure 3, is dramatically simpler than the existing design. What surprised us was not just that we were able to simplify the design so extensively, but that we were able to do it using such standard and well known techniques. • Data abstraction. The existing design is built in a traditional, procedure-oriented style, in which procedures communicate by arguments and global variables that are bound to elaborate record structures defined in header files. Most of the components of the redesign, in contrast, are abstract data types that encapsulate data structures and prevent direct access. • Infinite queues. The redesign uses a standard message queue abstraction. By providing an illusion of an infinite queue with non-blocking reads and writes, it allows client code to be written without any concerns for deadlock. We were thus able to avoid the complexities that arose in the existing design from the need to avoid filling the outgoing buffers. This data abstraction is more intricate than the others. Unlike a traditional “ive” data abstraction, the infinite queue is “active”: it uses its own internal thread to move messages from the application-level virtual buffer to the limited-capacity operating system queue. • Generic message processor. In the existing design, messages are handled in a traditional style. A large case statement branches on the message type, and the message is then deconstructed and copied into a local record by type-specific code. The message handling code is long and complicated, and there is much replication. In our redesign, a generic processor finds a handler appropriate to an incoming message by looking up its type and the type of the component that sent it in a table. Code that is executed for all messages regardless of message type is factored out, so that each handler is simpler than a branch of the case statement in the existing system. Registration of message handlers is dynamic, making it easy to change the association between message types and handlers during execution. This simplifies monitoring: for example, incoming messages of a given type can be tracked by adding a new handler ed for that type. • Uniform external interfaces. The existing CM has two input modes: in operation it receives input messages from the ISM component, while during testing it uses a different software subsystem to read input from a file. In our redesign, all input to the CM is via messages. To run the system from the recorded data, we implemented a process that masquerades as the Input Source Manager (ISM), reading the file of recorded data and generating messages that are indistinguishable to the CM from real ISM messages. This scheme simplifies the CM and makes playback mode a better predictor of real behavior. • Message handler language. Rather than writing the message handlers by hand in Java, we chose to generate the handler code from a domain-specific message handling language. This language was designed to accommodate the existing C header file descriptions of message formats, so that we only had to write small fragments of code to indicate, for example, how fields of messages should be mapped to database records. The design of the language and its compiler is orthogonal to the rest of the design, and is described in detail in a recent paper [KPM99]. The above techniques enabled us to reimplement the primary CM functionality in 15,000 lines of Java, less than 20 percent of the previous amount of C++ code. This result is qualified, however, by two factors. First, we did not implement the istrative interface used to configure CTAS. Second, we reused code from the existing CM in two areas: file parsing and message formats. The CM reads in the configuration of the airport and airspace from a file, from which it populates its internal data structures; we saw no benefit in rewriting this code, so we wrapped it in native Java methods. The recorded data file is

6

parsed in our design in a separate process, which we chose to code in C so that we could use existing parsing code. As mentioned above, our message handler compiler was also able to exploit existing C header files to generate code that extracts fields from messages.

8

Lessons Learnt

The following are the opinions of the authors, and not necessarily the consensus of the class as a whole. • Simple designs are possible. The most obvious lesson is that a complex and successful software system can be dramatically simplified. The new design is not only simpler, but is more flexible, easier to analyze and easier to tune. • Standard software engineering techniques work. The purpose of our project was not to demonstrate that standard techniques, such as data abstraction [Par72, LG86], would solve the problem. In fact, we had hoped to experiment with more advanced techniques, in particular object modelling. But we were able to bring about such major improvements using standard techniques alone that we never progressed to more ambitious ones. In the last few years, the focus of debate about software development has moved from technology to process. More companies appear to be concerned with the maturity level of their organization than the technical education of their engineers. Our experience suggests that before considering refinements of process, it may be worth evaluating the potential of well-understood software engineering notions that have yet to be applied to the system at hand. From an educational point of view, our experience suggests that undergraduate computer science courses should emphasize basic notions of modularity, specification and data abstraction, and should not let these be displaced by more advanced topics, such as design patterns, object-oriented methods, concurrency, functional languages, and so on. In the author’s experience, professional developers usually show much more sophistication in their use of algorithms than in their understanding of abstraction, which is usually more critical to the success of a development. Perhaps this indicates that undergraduate teaching in algorithms is simply more effective than in software engineering. On the other hand, it may suggest that our curricula are biased towards issues of programming-in-the-small, to the detriment of the needs of industry. • Coding standards are vital. Our reverse engineering efforts were immeasurably helped by NASA’s rigorous coding standards. Before embarking on a major development, it may be worth considering what kinds of tools might later be used to analyze the code, and how lexical and syntactic conventions might make their task easier and more productive. Griswold has coined the term “information transparency” to describe code that has been written with analysis in mind, and makes a compelling argument for paying attention to this aspect of design [Gri98]. • Reverse engineering tools work. Although we spent a lot of time reading code, tools made a big difference. Their contribution was not so much in generating representations that could replace the code in reasoning about it, but rather in rapidly directing us to the relevant parts of the code pertinent to the question at hand. • High level models are vital. Most of our reverse engineering efforts were focused on answering very basic questions about the behavior of the system as a whole, and the assumptions it makes about the behaviour of aircraft and the structure of airspace. The documentation of CTAS, although several hundred pages long, does not include any system-level models that address these issues. This is typical of industrial development environments. Such models are time-consuming and difficult to construct, and they can seem unnecessary to expert developers who have already formed them inside their heads. But the price paid for their omission is high. New developers who a team

7

acquire expertise in a slow and error-prone fashion, often from the code. Expert developers may have inconsistent models of the system, but, since these are not articulated, do not discover the inconsistencies until integration. Most worryingly, one can miss the forest for the trees: the most basic and fundamental issues are often given only scant attention because of pressure to meet deadlines and resolve low-level implementation problems. For example, the CTAS documentation does not seriously address the fundamental issue of how aircraft are related to identifiers. It does mention that, because records for the arrival of an aircraft and its scheduled departure from the same airport may both be ed by the FAA computer to CTAS, an aircraft cannot be identified by its call sign alone. This problem was detected during a test at DFW, and was fixed by appending the departure airport to the call sign. It is not obvious that even this is good enough, since if the FAA computer can send flight plans even before the flight has taken off, it might include flight plans for the same flight on two different days. In fact, the FAA’s computer system holds at most one day’s worth of flight plans, but this assumption is not documented anywhere. An the FAA system that allows it to store more flight plan information might thus cause a serious failure, and it is not hard to imagine the impact of such a change being overlooked. Careful construction of an object model [Jac99] would resolve issues of this sort early on in development, and would result in simpler, safer and more economical software. An object model is simply one way to describe the abstract state of a system or its environment; what matters is not how the state is described but whether it is described at all. A report on the development of CDIS, an en route air traffic control system, corroborates this: it attributes only 8% of the total project effort to the task of constructing a specification of abstract states and operations, and claims that eliminating this phase would have increased the cost of the project overall [Hal96]. The value of component specifications is now widely accepted. High level models are perhaps even more important, since they are harder to extract from the code, and have a more major impact on the system as a whole. In addition, they are considerably cheaper to construct than precise component specifications.

9

Conclusions

The FAA is under pressure from airlines and air traffic controllers to field the current version of CTAS more widely as soon as possible. The delay that a redesign of CTAS would introduce cannot currently be justified, whatever the benefits. Whether the FAA is open to redesign in the long term is a different question. The FAA has reportedly set aside some tens of millions of dollars for the CSC effort to make CTAS more robust and add monitoring and control features. Our work demonstrates that a redesign of at least the CM is possible and would result in a smaller and simpler system, which could consequently be expected to be more robust. More generally, our work s an unpublished hypothesis articulated some years ago by Prof. Satyanarayanan of CMU. He suggested that the common experience of deployed software systems both growing in size and degrading structurally as new features are added is an artifact of insufficient resource investment. A system to which sufficient attention is paid should actually shrink over time as the developers improve their understanding of the problem and take advantage of more powerful tools. We observed this effect quite strongly in this case study. Our redesign benefited significantly from Java, a standard tool not available when CTAS development began, the message handling script compiler, an application-specific tool developed after studying the CM’s implementation, and a simple infinite queue data abstraction, which solved a problem whose importance was not recognized until the system had been implemented and its dynamic behavior became evident.

8

Finally, our work underlines the power of software engineering fundamentals such as data abstraction, consistent coding style, and a design focus on simplicity. Both educators and industrial developers would do well to renew their focus on these well-understood techniques rather than letting them slide in favor of currently fashionable advanced approaches.

Acknowledgments

Most of the reverse engineering and implementation work was done by 11 students: Michelle Antonelli, Eric Bothwell, Chandrasekhar Boyapati, Tim Chien, Eddie Kohler, Charles Lee, SeungYong (Albert) Lee, David Montgomery, Massimiliano Poletto, Phil Sarin, Ilya Shlyakhter and Tony Wen. Nadine Alameh and Mark Schaefer contributed in the reverse engineering phase. In addition to the authors, one other faculty member, James Corbett (visiting from the University of Hawaii), contributed to the reverse engineering and to the design. We are very grateful to our colleagues at NASA Ames for their help and encouragement: to Heinz Erzberger, CTAS’s Chief Scientist at NASA, for his early enthusiasm that got the project going; to Michelle Eshow, the manager of the CTAS development, to Karen Tung Cate, her assistant lead, and to John Robinson, aerospace engineer, for their time in explaining CTAS to us, and for visiting us at MIT and reviewing our design work. Thanks also to Rick Lloyd and Ted Roe of Lincoln Laboratories for giving us their insights into CTAS, and to John Hansman of the MIT Department of Aeronautics and Astronautics for teaching us some basic notions of air traffic control. We would like to thank Imagix Corporation for generously providing a free license to the class for use of the Imagix reverse engineering tool, and to John Blattner of Imagix for his helpful advice; to Robert O’Callahan for help with his Lackwit tool; and to Jean Foster and Alex Prengel in the faculty liason office of Athena at MIT for setting up the class infrastructure.

References

[DKB94] [Gri98]

[Hal96] [Jac99] [KPM99]

[LG86] [OJ97] [Par72]

Davis, T. J., Krzeczowski, K. J., and Bergh, C. The Final Approach Spacing Tool. 13th IFAC Symposium on Automatic Control in Aerospace, Palo Alto, California, September 1994. William G. Griswold. Coping With Software Change Using Information Transparency. Technical Report CS98-585, Department of Computer Science and Engineering, University of California, San Diego, April 1998 (revised August 1998). Anthony Hall. Using Formal Methods to Develop an ATC Information System. IEEE Software, 13(2), pp. 66-76, March 1996. Daniel Jackson. Alloy: A new object modelling language. Submitted for publication. March 1999. Eddie Kohler, Massimiliano Poletto, and David Montgomery. Evolving Software with an Application-Specific Language. Submitted to the ACM SIGPLAN 1999 Workshop on Compiler for System Software (WCSSS ’99) Barbara Liskov and John Guttag. Abstraction and Specification in Software Development. MIT Press, 1986. Robert O’Callahan and Daniel Jackson. Lackwit: A Program Understanding Tool Based on Type Inference. Proc. International Conference on Software Engineering, Boston, MA, May 1997. David Parnas. On the criteria to be used in decomposing systems into modules. Communications of the ACM, Vol. 15, No. 12, December 1972.

9

URLs

[6894] [ATT] [NASA] [CSC] [Gra] [Ima]

Daniel Jackson. Workshop in Software Design. MIT Course 6.894, Fall 1998. http://sdg.lcs.mit.edu/~dnj/6894/ AT&T. Graphviz (a package that includes the dot graph layout tool). http://www.research.att.com/sw/tools/graphviz/ NASA. Center/TRACON Automation System. http://ctas.arc.nasa.gov/ Computer Sciences Corporation. Center/TRACON Automation System. http://www.ctas-techxfer.com/ Grammatech Corporation. CodeSurfer tool. http://www.grammatech.com/products/codesurfer/codesurfer.html Imagix Corporation. Imagix tool http://www.imagix.com/.

10

Figure 1: CTAS output, in timeline form

11

Figure 2: Architecture of CTAS in TMA mode Diagram taken from [CSC]

12

Figure 3: Informal architectural sketch of our new design of the CM

13
