May 1997
Process Industry Practices Machinery
PIP RESM001 Specification for Agitators
PURPOSE AND USE OF PROCESS INDUSTRY PRACTICES In an effort to minimize the cost of process industry facilities, this Practice has been prepared from the technical requirements in the existing standards of major industrial s, contractors, or standards organizations. By harmonizing these technical requirements into a single set of Practices, istrative, application, and engineering costs to both the purchaser and the manufacturer should be reduced. While this Practice is expected to incorporate the majority of requirements of most s, individual applications may involve requirements that will be appended to and take precedence over this Practice. Determinations concerning fitness for purpose and particular matters or application of the Practice to particular project or engineering situations should not be made solely on information contained in these materials. The use of trade names from time to time should not be viewed as an expression of preference but rather recognized as normal usage in the trade. Other brands having the same specifications are equally correct and may be substituted for those named. All practices or guidelines are intended to be consistent with applicable laws and regulations including OSHA requirements. To the extent these practices or guidelines should conflict with OSHA or other applicable laws or regulations, such laws or regulations must be followed. Consult an appropriate professional before applying or acting on any material contained in or suggested by the Practice.
©Process Industry Practices (PIP), Construction Industry Institute, The University of Texas at Austin, 3208 Red River Street, Suite 340, Austin, Texas 78705. PIP member companies may copy this practice for their internal use.
Not printed with state funds
May 1997
Process Industry Practices Machinery
PIP RESM001 Specification for Agitators Table of Contents 1. Introduction ..................................2
5. Inspection ................................... 11
1.1 Purpose ..............................................2 1.2 Scope .................................................2 1.3 Vendor’s Quotation .............................2
6. Testing ........................................ 11
2. References....................................2
6.1 Mechanical Test ............................... 11 6.2 Noise Level Measurement ................ 11 6.3 Optional Tests .................................. 12
2.1 Process Industry Practices ..................2 2.2 Industry Codes and Standards ............3
7. Preparation for Shipment.......... 12
3. Definitions.....................................3 4. Design and Manufacture..............3 4.1 General...............................................3 4.2 Materials .............................................4 4.3 Agitation Assemblies...........................4 4.4 Steady Bearing ...................................6 4.5 Shaft Sealing System..........................6 4.6 Agitator ..................................7 4.7 Shaft Couplings and Guards ...............8 4.8 Gear Reducer .....................................8 4.9 Drive Motor .......................................10 4.10 Auxiliary Piping ...............................11
Process Industry Practices
7.1 Preservation ..................................... 12 7.2 Cleaning and Painting....................... 12 7.3 Packing and Tagging ........................ 12
8. Vendor’s Data............................. 13 8.1 Proposal ........................................... 13 8.2 Approval Drawings............................ 14 8.3 Final Data......................................... 14
Data Sheets Agitator/Mixer Data Sheet
Page 1 of 14
PIP RESM001 Specification for Agitators
1.
May 1997
Introduction 1.1
Purpose The purpose of this Practice is to provide designers and vendors with mechanical requirements for design and manufacture of permanently mounted agitators for use in process facilities.
1.2
Scope This Practice covers the minimum requirements for design and manufacture of permanently mounted, top and bottom-entering agitators, both with and without mechanical seals. This Practice does not cover requirements for tank mixers, portable and clamp-on, light duty agitators, in-line and jet-type mixers, and high speed dispersers. This Practice also does not cover requirements for the installation of agitators. A typical agitation process data sheet, included with this Practice, may be used to communicate purchaser requirements, however, supplemental information may be necessary to fully define process requirements.
1.3
Vendor’s Quotation 1.3.1
Vendor’s quotation shall conform to this Practice and purchaser’s addenda. At the vendor’s option, an alternate quotation may be offered if the following two conditions are met: a. If there is significant process or delivery advantage, a superior, more reliable agitator design may be offered. Vendor shall provide the technical justification. b. Alternate quotation shall indicate deviations from the requirements in this Practice. Complete details of deviations shall be submitted to purchaser for review.
1.3.2
2.
If vendor’s quotation indicates no deviations from the requirements in this Practice, it shall be assumed by the purchaser that the agitator quoted complies fully with this Practice.
References Applicable requirements in the latest edition (or the edition indicated) of the following industry standards shall be considered an integral part of this Practice: 2.1
Process Industry Practices •
Process Industry Practices (PIP)/American Petroleum Institute (API) –
Page 2 of 14
PIP REIE 686/API RP686 - Guidelines for the Pre-Installation Design and the Installation of Machinery
Process Industry Practices
PIP RESM001 Specification for Agitators
May 1997
2.2
Industry Codes and Standards •
•
•
American Gear Manufacturers Association (AGMA) –
AGMA 2000 - Gear Classification and Inspection Handbook
–
AGMA 6010-E - Spur, Helical, Herringbone, and Bevel Enclosed Drives
American Society of Mechanical Engineers (ASME) –
ASME B1.1 - Unified Inch Screw Threads (UN and UNR Thread Form)
–
ASME B16.5 - Pipe Flanges and Flanged Fittings (Steel)
–
ASME B16.47 - Large Diameter Steel Flanges
American Society for Testing and Materials (ASTM) –
•
International Organization for Standardization (ISO) –
3.
ASTM A269 - Specification for Seamless and Welded Austenitic Stainless Steel Tubing for General Service ISO 1940 Balance Quality of Rotating Rigid Bodies
Definitions For the purposes of this Practice the following definitions apply: Auxiliary Piping Systems: Piping supplied with the agitator for services such as: seal flush or buffer fluid, cooling water, gear reducer lubrication oil, and instrument air or nitrogen Bearing Speed Factor (ndm): An approximation of the speed at which the surfaces of a rolling element bearing roll together, and therefore also an indicator of bearing service severity. The bearing speed factor is determined by multiplying the rotational speed in revolutions per minute times the bearing pitch diameter in millimeters. For convenience, the pitch diameter is taken as one half the sum of the bearing bore and outside diameters. Shrink Disc: Clamping assembly used to secure mechanical shaft seals against rotation on shafts. A shrink disc utilizes a bolted wedge assembly to maintain a friction fit to the shaft. Comment: Use of a shrink disc imposes lower stresses on a shaft than key drives, and does not damage the shaft surface like setscrew drives.
4.
Design and Manufacture 4.1
General 4.1.1
Agitators shall be complete, including drive motor, gear reducer, forced lubrication system (if required) for gear reducer, mounting flange, coupling and guard, shaft, agitation elements, and shaft sealing system. Scope of supply shall conform to the data sheet.
4.1.2
When specified, agitator shall be shop assembled before shipment. Disassembly for shipment shall be limited to that required for shipment,
Process Industry Practices
Page 3 of 14
PIP RESM001 Specification for Agitators
May 1997
rigging, storage, or installation. Components disassembled for shipment shall be clearly matchmarked for reassembly. 4.1.3
Agitators shall be designed for rapid and economical maintenance.4.1.4 Agitators shall be designed so that maintenance and disassembly can be performed with standard shop tools. Any special tools or fixtures required shall be listed in the vendor’s proposal.
4.1.5
Oil fill openings, grease points, and mechanical seal reservoir fill port shall be extended for access without disassembly.
4.1.6
Rabbetted fits or dowels shall be used for alignment for all coupling, adapter housing, and gear casing ts.
4.1.7
Internal agitator components shall be designed to fit through the vessel manhole openings. Vendor shall state the minimum manhole opening required for assembly and maintenance of internal components.
4.1.8
Vendor shall review and comment on purchaser-supplied process performance data, including efficiency, performance, and baffle size and placement.
4.1.9
Vendor shall review and comment on the installation details with respect to agitator mounting and maintenance accessibility of the agitator.
4.1.10 Vendor’s proposal shall state expected sound pressure levels in dB for each octave band. Agitator noise level shall not be higher than specified on the purchaser’s noise data sheet. 4.1.11 Vendor shall state in the proposal if external cooling or forced lubrication is required for the gear reducer, shaft seal, or steady bearing. Cooling water requirements shall be stated in the proposal. 4.1.12 Cooling water ages in heat exchangers or cooling jackets shall be designed for 7.0 barg (100 psig) minimum working pressure. 4.2
4.3
Page 4 of 14
Materials 4.2.1
Material of minor parts (e.g. bolting, shaft keys, and other attachment hardware) in with the process shall have a corrosion resistance equal to or better than that of material of major parts in the same environment.
4.2.2
Material of pressure-containing parts in with the process shall have a corrosion resistance equal to that of the vessel.
4.2.3
Unless otherwise specified, components in with the mechanical seal flush or buffer fluid shall be AISI 300 series stainless steel.
Agitation Assemblies 4.3.1
Shaft shall be designed to resist torsional loads and bending moments for all specified operating conditions, including cold startup.
4.3.2
Unless otherwise specified, shaft shall have a removable coupling spacer so the shaft seal can be replaced without removing the drive or the agitator shaft.
Process Industry Practices
PIP RESM001 Specification for Agitators
May 1997
4.3.3
Shaft shall be equipped with a removable collar or sleeve that s the entire shaft assembly when the coupling spacer is removed. Coupling and sleeve design shall be such that when the coupling bolts are loosened, the sleeve s the shaft automatically.
4.3.4
A dynamic analysis of the shaft assembly shall be performed for both dry and wet conditions, and the results included as part of the vendor’s proposal. This analysis shall that any lateral or torsional resonances are separated from the operating speed range by at least 20% of the normal operating speed. Also, these resonances shall not be within 10% of any agitator vane frequencies, (including baffle effects), or electrical excitation frequencies, such as those caused by variable frequency drives.
4.3.5
Shaft assemblies that operate at more than 100 RPM and less than 300 RPM shall be statically balanced to the purchaser’s tolerance.
4.3.6
Shaft assemblies that operate at 300 RPM or higher speed shall be dynamically balanced to G40 tolerance in accordance with ISO 1940.
4.3.7
With the agitator drive input shaft turned by hand, runouts of the assembled shaft and agitation elements shall not exceed the following limits of total indicator runout (TIR): a. 0.05 mm (0.002 in.) at the gear reducer output shaft b. 0.13 mm (0.005 in.) above and below the mechanical seal housing c. 0.25 mm/m (0.003 in./ft.) of shaft length measured from the agitator mounting flange at the first in-vessel coupling, at the agitator hubs, and at the shaft end without the of a steady bearing d. 0.025 mm (0.001 in.) perpendicular runout at the coupling face
4.3.8
When specified, the shaft shall have extended key seats for adjustment of the agitation elements.
4.3.9
For shafts with multiple agitation elements, the key seats shall be circumferentially staggered around the shaft.
4.3.10 Bolting of agitator blades shall conform to ASME B1.1. 4.3.11 Bolted connections of the agitation elements to the hub shall have a maximum diametral clearance of 0.8 mm (0.03 in.). 4.3.12 Blades shall be fastened to the hub with a minimum of three (3) bolts. Bolt threaded length in hub and blade t shall be minimized. 4.3.13 Bolts shall be secured by lockwire or other positive locking method. 4.3.14 Unless otherwise specified, agitator hub-to-shaft attachments shall be key driven. 4.3.15 Total allowable variation in the radial sweep of the blade tips shall be 13 mm (0.5 in.). Radial sweep shall be measured without use of a steady bearing. 4.3.16 Maximum tolerance for axial location of blades and hubs shall be ±13 mm (0.5 in.).
Process Industry Practices
Page 5 of 14
PIP RESM001 Specification for Agitators
4.4
May 1997
Steady Bearing 4.4.1
Unless specifically approved by the purchaser, steady bearings shall not be used.
4.4.2
If the use of steady bearings is approved, then the steady bearing design shall conform to the following criteria: a. Proposals for agitators that have a steady bearing shall include sufficient detail for evaluation of the steady bearing design. b. Bearing design shall provide sufficient clearance for the differential radial and axial thermal expansion of the shaft and the bearing . c. Bearing shall have provisions for lateral and axial adjustment of the bearing assembly for alignment purposes. d. Agitator shaft shall have a replaceable sleeve at the bearing. Shaft sleeves for abrasive services shall be hard coated. e. Bearing shall have a replaceable liner. Unless otherwise specified, liner shall be made of glass-filled polytetrafluorethylene (PTFE). f.
4.5
Unless otherwise specified, bearing liner and shaft sleeve shall be fieldreplaceable without removing the agitator shaft or the bearing .
Shaft Sealing System 4.5.1
When specified, a sealing system shall be supplied by the vendor.
4.5.2
For toxic fluids, and for flammable fluids with vapor pressure that exceeds atmospheric pressure at operating temperature or maximum ambient temperature, the shaft sealing system shall have pressurized dual mechanical seals.
4.5.3
When specified, the sealing system shall have a positive shut-off device that allows maintenance of the sealing system without clearing the vessel. Comment: Partial depressuring of the vessel is allowed for maintenance, therefore the positive shut-off device may have a lower pressure rating than the actual mechanical seal.
4.5.4
The shaft sealing system shall have the following features: a. Seals shall be hydraulically balanced design and of single cartridge construction. The inner seal of dual seals shall have a reverse balance feature designed and constructed to withstand reverse pressure differentials without opening. b. Seal cartridge shall be field-removable without removing the gear reducer or the shaft. c. Seal cartridge design shall be adequate for stand-alone static bench testing before installation. d. Seal cartridges shall be self-venting through the seal circulation return line. Centerline of the seal flush return port shall be a minimum of 3 mm (0.13 in.) above the seal faces.
Page 6 of 14
Process Industry Practices
PIP RESM001 Specification for Agitators
May 1997
e. Seal cartridges shall have leak detection port(s). Leak detection ports shall have a tapped connection and shall be permanently labeled by stamping. f.
The rotating seal element shall be setscrew driven. When specified, the rotating seal element shall be key or shrink disc driven. Comment: The use of setscrews to drive large or high pressure mechanical seals requires the use of a large number of setscrews, which creates the possibility of distortion or improper installation of the seal due to uneven tightening. Mechanical damage to the shaft and possibly the shaft O-rings can result from the setscrews upsetting the shaft metal when tightened. The use of key or shrink disc driven seal elements eliminates these possible problems.
g. Pressure ts in the seal cartridge housing shall be sealed with O-rings. Use of gaskets is prohibited. h. Unless otherwise specified, the seal cartridge shall not have cooling jackets. i.
Dual seals shall have a seal reservoir with a minimum capacity of 12 liters (3 gallons).
j.
Seal reservoir shall have a level gauge, a fill connection, and vent and drain connections. Level gauge shall be sized to indicate a range of ±50 mm (2 in.) of normal operating level.
k. Systems with dual seals shall have a device that provides positive circulation of buffer fluid from the seal reservoir to the seal. Circulation device can be a pumping ring or a separate circulation pump. Comment: When a dead-ended seal lubrication system is specified, a cooling jacket may be required, and a circulation device is not necessary. 4.5.5
An anti-friction bearing shall be mounted in or near the mechanical seal cartridge to minimize shaft motion at the seal. For continuous service, the bearing shall have a minimum L10 life of 40,000 hours. Calculation of bearing life shall be based on the specified operating conditions.
4.5.6
When specified, a separate lifting device for seal maintenance shall be included in the vendor’s proposal. Comment: A separate lifting device for mechanical seal maintenance (usually a small bolt on trolley and hoist assembly) is recommended if no permanent overhead lifting capacity is available and the weight of any item in the seal system exceeds 20 kg (45 lb.).
4.6
Agitator 4.6.1
Process Industry Practices
Unless otherwise specified on the data sheet, agitators shall be equipped with a through-bolted connection flange with dimensions, drilling, and pressure rating in accordance with ASME B16.5 or ASME B16.47, whichever applies. Connection flange bolt hole orientation shall match vessel flange.
Page 7 of 14
PIP RESM001 Specification for Agitators
4.6.2 4.7
May 1997
Agitators shall be ed on the vessel nozzle.
Shaft Couplings and Guards 4.7.1
The coupling between the motor and gear reducer shall be of non-lubricated flexible design.
4.7.2
Coupling service factor shall be a minimum of 2.0 based on the motor nameplate power.
4.7.3
Couplings for motors 35 kW (50 hp) and larger shall be flexible disk type.
4.7.4
Couplings for gear reducer output shaft and agitator shaft shall be of rigid design.
4.7.5
Unless otherwise specified, agitator shaft coupling hubs shall be keyed or welded in place and the arrangement indicated on the outline dimension drawing. Threaded coupling mounts are prohibited.
4.7.6
When specified, shaft ends for agitator shaft coupling hubs shall be tapered for ease of disassembly. Comment: Tapered coupling hubs are used at coupling ts where the coupling must be easily field removable and also have a moderate interference fit to transmit torque. The coupling located just above the mechanical seal is an example of this.
4.8
4.7.7
When interference fits are specified, cylindrical bore couplings shall be mounted using an interference fit of 0.0005 mm/mm (0.0005 in./in.) of shaft diameter.
4.7.8
A coupling guard shall be supplied for the motor driver coupling area. Coupling guard shall be removable and shall be mounted so that the rotating parts are covered to within 13 mm (0.5 in.) of the stationary housings. Guard shall be rigid enough so that of the guard with moving parts does not occur as a result of bodily with the guard.
Gear Reducer 4.8.1
Page 8 of 14
General 4.8.1.1
Gear reducer shall be specifically designed for agitator service.
4.8.1.2
Output shaft and bearings shall be designed to the weight of the agitator assembly.
4.8.1.3
Gear reducer shall be designed to withstand all torsional, bending, and thrust loads so that significant deflections are not transmitted to the gears and bearings.
4.8.1.4
Gear reducer shall be furnished in accordance with AGMA 6010-E.
4.8.1.5
Gears shall be spiral bevel and/or helical. Use of worm gears, hypoid gears, double helical, or herringbone gears is prohibited.
Process Industry Practices
PIP RESM001 Specification for Agitators
May 1997
4.8.2
4.8.3
Process Industry Practices
4.8.1.6
Minimum gear reducer service factor shall be 1.4. For services in which polymerization or solidification is possible in the vessel, gear reducer service factor shall be 2.0, as a minimum.
4.8.1.7
Gears shall be finished to Quality Level 9, as a minimum, in accordance with AGMA 2000.
4.8.1.8
For continuous duty agitators, gear reducer anti-friction bearings shall be designed for an L10 life of 40,000 hours. Loads on bearings shall be based on nominal driver rating and agitator shaft loads transmitted to the gear reducer.
4.8.1.9
Thermal rating of the gear reducer shall be calculated in accordance with AGMA 6010-E using a factor of 0.75 for the ambient modifier, T4.
Cooling/Lubrication 4.8.2.1
When the driver nominal nameplate power exceeds the thermal rating of the gear reducer, an external cooling system shall be provided.
4.8.2.2
Preferred cooling system shall consist of ducting and a fan mounted on the input shaft. When fan cooling is insufficient, forced-oil circulation through an external cooler shall be provided.
4.8.2.3
Forced-oil circulation system components shall include: •
Replaceable element filter
•
Motor-driven oil pump
•
Cooler (water or air cooled)
•
Pump discharge pressure gauge
•
Low oil pressure alarm switch
•
Sump and cooler exit temperature gauges
•
Stainless steel piping.
4.8.2.4
Gear reducer lubrication system shall be designed to operate automatically without operator intervention.
4.8.2.5
All gears shall be lubricated with oil.
4.8.2.6
Low speed bearings with a speed factor (ndm) less than 150,000 may be grease-lubricated. Sealed-for-life bearings are unacceptable.
Gear Reducer Housing 4.8.3.1
Gear reducer housing shall have lifting lugs sized and located to lift the agitator assembly for installation and maintenance.
4.8.3.2
Housing shall have an oil level sight glass. Normal oil levels for static and operating conditions shall be plainly marked on the housing.
Page 9 of 14
PIP RESM001 Specification for Agitators
May 1997
4.8.3.3
Housing shall have a gear reducer nameplate securely attached on its exterior. Nameplate shall be made of 300 series stainless steel and shall be attached with corrosion resistant fasteners.
4.8.3.4
Nameplate shall have the following information permanently marked on it: a. Size and type or model b. Rated power c. Service factor d. Ratio e. Input and output RPM f. Manufacturer’s name g. Serial number h. Purchaser’s equipment number
4.8.3.5
4.9
Page 10 of 14
Housing shall have rotation arrows cast or attached with corrosion resistant fasteners. Arrows shall indicate direction of rotation of input and output shafts.
Drive Motor 4.9.1
Drive motor shall have a 1.15 service factor.
4.9.2
Motor nameplate power shall not be less than 115% of maximum agitator power requirements, including drive losses. Motor service factor shall not be used to meet this requirement.
4.9.3
Vertical motors shall have a rain shield.
4.9.4
Motor shall be mounted on a rigid bracket attached to the gear reducer.
4.9.5
Foot mounted motors shall have stainless steel shims with a minimum thickness of 3 mm (0.125 in.) to the motor feet. The shim pack shall consist of no less than three and no more than five shim pieces.
4.9.6
The agitator motor mounting adapter runouts for flange mount motors shall not exceed 0.05 mm (0.002 in.) concentricity (radial runout) and 0.13 mm (0.005 in.) perpendicularity (face runout) as measured from the gear reducer input shaft.
4.9.7
When specified, positioning screws to aid in driver alignment shall be provided for both foot and flange mount motors. For foot mount motors, horizontal positioning screws for both transverse and longitudinal directions shall be provided. For flange mount motors, positioning screws to adjust motor alignment in two directions normal to the shaft axis shall be provided. Any part of the positioning screw assembly above the plane of the mounting surface shall be removable without cutting, burning, or grinding.
4.9.8
The motor shall be provided with a grounding lug on the frame.
Process Industry Practices
PIP RESM001 Specification for Agitators
May 1997
4.10
Auxiliary Piping 4.10.1 Piping connections to purchaser systems 3/4 NPS or larger shall be flanged. 4.10.2 Piping components in with the mechanical seal flush fluid shall be stainless steel. 4.10.3 Seal flush system shall be stainless steel tubing that conforms to ASTM A269. Minimum size of tubing shall be 1/2 in. Use of 3/4 in. tubing is preferred.
5.
6.
Inspection 5.1
Purchaser will specify the minimum requirements for inspection in the purchase order or a separate addendum to the data sheet.
5.2
When specified on the data sheet, inspection shall be conducted by the purchaser before the agitator is shipped.
5.3
Purchaser shall have access to inspect the agitator, or any of its auxiliary systems, at any time during their fabrication or testing.
5.4
Vendor shall notify the purchaser a minimum of five (5) days before any scheduled shop tests and before the equipment is to be ready for final inspection.
Testing 6.1
6.2
Mechanical Test 6.1.1
The purchased motor, gear drive, and mechanical seal assembly shall be given a mechanical run test at the vendor’s facility.
6.1.2
The motor, gear drive, and seal assembly shall be operated at full speed and partial or no load conditions for one hour after bearing temperatures have stabilized, or for a mutually agreed upon time period.
6.1.3
Dual seal systems shall be operated at normal operating pressure during the mechanical performance test.
6.1.4
Bearing temperatures and housing vibration shall be measured and recorded just prior to the end of the mechanical test.
6.1.5
Bearing temperatures shall not exceed 65°C (150°F). Vibration as measured at the top of the gear drive shall not exceed 5 mm/sec (0.2 in/sec) RMS.
6.1.6
Shaft runouts at the input shaft and mechanical seal area shall be measured and recorded on the test data sheets after the mechanical test.
Noise Level Measurement 6.2.1
Process Industry Practices
When specified, the vendor shall measure and record the noise level of the agitator during the mechanical test as stated in Section 6.2.1.1 through 6.2.1.4.
Page 11 of 14
PIP RESM001 Specification for Agitators
6.3
May 1997
6.2.1.1
Noise level shall be measured in the horizontal plane at a distance of 1 m (3 ft.) from the drive motor or gear reducer surface.
6.2.1.2
A survey of the operating agitator shall be made to determine the location with the highest noise level. Noise level at this location shall be recorded.
6.2.1.3
Overall noise level shall be measured and recorded using the “A” weight filter. Frequency analysis of the noise shall be performed using an octave band filter with center frequencies from 31.5 to 8 kHz. Noise levels for each of the octave filter bands shall be recorded.
6.2.1.4
Noise level measurements shall be taken with the sound level meter operating in the slow response mode and a visual average of the meter fluctuation shall be recorded. Meter shall also be observed operating in fast response mode with the “A” weight filter. If the meter deflection on fast response is greater than 5 dB, then maximum and minimum meter values shall be recorded for each measurement.
Optional Tests When specified, optional tests, such as part or full load tests or testing to validate agitation element design, shall be performed.
7.
Preparation for Shipment 7.1
Preservation Interior of the gear reducer shall be treated with corrosion inhibitors in accordance with PIP REIE 686/API RP686.
7.2
7.3
Page 12 of 14
Cleaning and Painting 7.2.1
Exterior surfaces shall be painted with the vendor’s standard paint.
7.2.2
Stainless steel surfaces shall not be painted unless covered by insulation.
7.2.3
Exposed machined surfaces shall be coated with an easily removable rust preventative.
Packing and Tagging 7.3.1
Agitator shall be braced and small piping shall be secured to prevent damage during shipment.
7.3.2
All flanged openings shall be sealed with gaskets and metal covers. Small piping shall be sealed with metal or plastic plugs.
7.3.3
Mounting flanges shall be protected with sheet steel covers. Wooden covers with a minimum thickness of 20 mm (3/4 in.) shall be placed over the steel covers and shall be secured with a minimum of four (4) bolts.
Process Industry Practices
PIP RESM001 Specification for Agitators
May 1997
8.
7.3.4
Special tools and small accessories shall be boxed and shipped with the agitator.
7.3.5
A complete set of installation and operation instructions and a certified outline dimension drawing enclosed in a waterproof envelope shall be attached to the agitator.
7.3.6
Material shipped separately shall be identified with the purchaser’s item number on a metal tag.
7.3.7
Each separate item, crate, bag, etc., shall be identified with purchaser’s order and requisition numbers and all special markings specified by the purchase order.
Vendor’s Data 8.1
Proposal Vendor shall submit as a minimum the following data with the proposal: a. Spare parts list with unit pricing for spare parts. Spare parts list shall include parts required for three years of normal operation and critical startup spare parts. b. Completed agitator data sheet c. Preliminary (or typical) outline drawings showing: •
Principal dimensions
•
Weights of principal components
•
Clearances required for installation and maintenance
•
Mounting flange dimensions
•
Drive motor
•
Agitator blade-to-hub connection details
•
Seal reservoir mounting location
•
Direction of rotation when looking at the top of the agitator
d. Typical cross-sectional drawing of the gear reducer showing details of construction e. Cross-sectional drawing of the shaft seal, with details and specifications of all sealing system components f.
Cross-sectional drawing of the steady bearing (if required)
g. Agitator performance (mixing) calculations and curves h. Typical schematics for seal flush and lubrication systems i.
A detailed procedure for replacement of mechanical seals
j.
Drawings showing the forces and moments applied by the agitator assembly to the vessel mounting flange
Process Industry Practices
Page 13 of 14
PIP RESM001 Specification for Agitators
8.2
May 1997
Approval Drawings After receipt of the order, vendor shall furnish the following certified drawings: a. Outline drawing(s) of the complete assembled agitator. Drawing(s) shall include: •
Principal dimensions
•
Direction of rotation of the agitator
•
Size and location of connections to the agitator
•
Size and location of mounting flanges
•
Total weight and individual weights of principal maintenance items
b. Actual cross-sectional drawings of the gear reducer, shaft sealing system, and steady bearing c. Drawings of auxiliary equipment or piping d. Drawings showing the forces and moments applied by the agitator assembly to the vessel mounting flange e. Bill of materials f. 8.3
Drive motor data sheet
Final Data 8.3.1
After final inspection, the vendor shall furnish the following data: a. As-built data sheets and final drawings b. Operating and maintenance instructions, including lubrication requirements, and a detailed procedure for mechanical seal replacement c. Parts list with factory cross reference number d. Certified data from the shop tests that were performed. Data shall be provided for purchaser’s review and acceptance prior to shipment of the agitator. e. Purchaser specified ducumentation such as material certifications.
8.3.2
Page 14 of 14
The number of copies required will be specified in the purchase order.
Process Industry Practices
RESM001
Specification for Agitators
PAGE 1 OF 3
AGITATOR DATA SHEET JOB __________________________________________________________
NUMBER
ITEM NO _____________________________________________________________ SERVICE _____________________________________________________________
CLIENT____________________________________________________________
REQUISITION NUMBER _________________________________________________
PROJECT LOCATION ________________________________________________
_____________________________________________________________________
UNIT ______________________________________________________________ DESIGN, MANUFACTURE, INSPECTION, AND TESTING SHALL CONFORM TO SPECIFICATION NOTES: PURCHASER
¡ INDICATES INFORMATION COMPLETED BY PURCHASER
GENERAL o MODEL NUMBER ¡ DRIVER TYPE OPERATING CONDITIONS
MIXER MANUFACTURER DRIVER ITEM NUMBER
¡ PRESSURE ¡ MIXED VOLUME
¡ QUANTITY
¡ UP ¡ RADIAL PERFORMANCE RPM o MAX SHAFT POWER o NORMAL SHAFT POWER o o IMPELLER DIAMETER CONSTRUCTION FEATURES
¡ DOWN
GAL
o MANUFACTURER CODE x FLAT x PROPELLER
o QUANTITY x PITCHED x MULTIPLE o PITCH
¡ VESSEL MFR
IN
x AGITATOR HUBS x BLADES x MECHANICAL SEAL PARTS ¡ NOT REQUIRED o RATED TEMP
x MANUFACTURER
¡ AGITATOR MFR
x MANUFACTURER CODE
o BRG SPAN (IN)
¡ POSITIVE SEAL SHUTOFF FOR MANTENANCE
o CRITICAL SPEED (RPM)
¡ KEY-DRIVEN ROTATING ELEMENT
GEARBOX
¡ SHRINKING-DISC DRIVEN ROTATING ELEMENT
o MANUFACTURER
o MODEL NUMBER
x PARALLEL SHAFT
TYPE
o RATED POWER
HP
o AGMA S.F. BEARINGS
o EFFICIENCY LOW SPEED
o TYPE o LUBRICATION TYPE o AFBMA L-10 LIFE
MOTOR
o MANUFACTURER o TYPE o HORSEPOWER
x SEAL RESERVOIR SIZE %
x COOLING WATER
¡ FLUID x FORCED CIRCULATION o PSIG o SOURCE
PAINTING
¡ INTERFERENCE FIT
¡ MANUFACTURER STANDARD ¡ SPEC NUMBER ¡ ASSEMBLE COMPLETE BEFORE SHIPMENT ¡ INSPECTION REQUIREMENTS ¡ MECHANICAL TEST ¡ OPTIONAL TEST ¡ FINAL BEFORE SHIPMENT ¡ OTHER ¡OPTIONAL TESTING ¡ PART LOAD ¡ FULL LOAD ¡ NOISE LEVEL ¡ AGITATOR PERFORMANCE ¡ OTHER o MODEL o RPM o FRAME o FOOT MOUNT o FLANGE MOUNT REVISIONS
NUMBER
REVIEWED
DATE
APPROVED
ORIGINATOR
o FLOW
o COOLING JACKET SEAL FLUSH
x DEAD ENDED x PRESSURIZED
HS COUPLING
¡ INTERFERENCE FIT x MANUFACTURER x MODEL LS COUPLING ¡ TAPERED HUBS
¡ MAINTENANCE LIFTING DEVICE
x RIGHT ANGLE o AGMA QUALITY
HIGH SPEED
°F
MANUFACTURER/TYPE
x MECHANICAL SEAL TYPE
x BOTTOM STEADY BEARING
BRG ED BY:
HP
x IMPELLER x SHAFT x MOUNTING FLANGE x GASKET SHAFT SEALS ¡ REQUIRED o RATED PRESSURE PSIG x PACKING x SIZE/NO RINGS
¡ EXTENDED KEY SEATS
o SHAFT DIA (IN)
HP
MATERIALS OF CONSTRUCTION
o NO BLADES o RECOMMENDED CLEARANCE FROM OBSTRUCTION IN o PROJECTED BLADE AREA (IN2) o THICKNESS (IN) ATTACHMENT o WELDED o BOLTED ¡ POSITIVE LOCK HUB o FABRICATED o CAST o KEY-DRIVEN o SHAFT o HOLLOW o SOLID o STEPPED o FLANGED x STABILIZERS
o SERIAL NUMBER ¡ DRIVER PROVIDED BY
GAL
o OPERATING SPEED o CALCULATED PRIMARY PUMPING CAPACITY 3 o ROTATION o CW
TYPE
x BY MANUFACTURER OR
DIRECTION OF FLUID MOVEMENT
PSIG MIN MAX
IMPELLER
o BY MANUFACTURER
o GPM
RESM001
Specification for Agitators
PAGE 2a OF 3
AGITATOR DATA SHEET JOB NUMBER __________________________________________________________
ITEM NO _______________________________________________________________
VESSEL DETAILS ¡ VESSEL ITEM NUMBER
VESSEL DETAILS
¡ SIZE:
D/L
¡ API 620
H
(W)
¡ ASME SECT VIII
TOP HEAD TYPE
FT
¡ OTHER
¡ INTERNALS
¡ FLAT
¡ ASME DISHED
¡ CONE
¡ OTHER
BOTTOM HEAD TYPE
¡ CAPACITY
GAL/BBL
x MOUNTING FLANGE SIZE
FACING
x SIZE OPENING FOR IMPELLER INSTALLATION
RATING IN
¡ FLAT
¡ ASME DISHED
¡ CONE
¡ OTHER
FT-LB
DESCRIPTION
A
NORMAL LIQUID LEVEL
B
MAXIMUM LIQUID LEVEL
C
IMPELLER DIAMETER
D
IMPELLER DEPTH
E
VESSEL REFERENCE DEPTH
F
VESSEL I.D.
INCHES
¡ 2:1 ELLIPTICAL
LOADS TORQUE
ID
¡ 2:1 ELLIPTICAL
STATIC MOMENT
FT-LB
REMARKS
DYNAMIC MOMENT
FT-LB
WEIGHT
LB
RESM001
Specification for Agitators
PAGE 2b OF 3
AGITATOR DATA SHEET JOB NUMBER __________________________________________________________
ITEM NO _______________________________________________________________
TANK DETAILS ¡ VESSEL ITEM NUMBER
VESSEL DETAILS
¡ SIZE:
D/L
¡ API 620
H
(W)
¡ ASME SECT VIII
TOP HEAD TYPE
FT
¡ OTHER
¡ INTERNALS
¡ FLAT
¡ ASME DISHED
¡ CONE
¡ OTHER
BOTTOM HEAD TYPE
¡ CAPACITY
GAL/BBL
x MOUNTING FLANGE SIZE
FACING
RATING
x SIZE OPENING FOR IMPELLER INSTALLATION
IN
¡ FLAT
¡ ASME DISHED
¡ CONE
¡ OTHER
FT-LB
DESCRIPTION
A
NORMAL LIQUID LEVEL
B
MAXIMUM LIQUID LEVEL
C
IMPELLER DIAMETER
D
IMPELLER DEPTH
E
VESSEL REFERENCE DEPTH
F
VESSEL I.D.
INCHES
¡ 2:1 ELLIPTICAL
LOADS TORQUE
ID
¡ 2:1 ELLIPTICAL
STATIC MOMENT
FT-LB
REMARKS
DYNAMIC MOMENT
FT-LB
WEIGHT
LB
Specification for Agitators
RESM001 PAGE 3 OF 3
AGITATOR DATA SHEET JOB NUMBER __________________________________________________________
ITEM NO _______________________________________________________________
AGITATOR PROCESS DEFINITION FLUID PROPERTIES, COMPOSITION AND CONDITIONS FEED
COMPONENT
RATE(GPM)
TEMP (°°F)
3
DENSITY (LB/FT )
VISCOSITY ()
REMARKS
1 2 PRODUCT OPERATING TEMPERATURE (°°F)
FOAMING TENDENCY
VISCOUS PROPERTY
MAX. VISCOSITY ()
¡ NORMAL
¡ NONE
¡ DILUENT
¡ STARTUP
¡ MINIMUM
¡ MODERATE
¡ NEWTONIAN
¡ INTERMDEDIATE BLEND
¡ MAXIMUM
¡ EXCESSIVE
¡ PSEUDOPLASTIC
¡ FINAL BLEND
¡ OTHER
¡ UPSET
¡ TOXICITY
¡ VAPOR PRESSURE AT OPERATING TEMP OPERATION (CONTINUOUS RETENTION TIME) MIXING DURING
¡ FILLING
¡ DRAWOFF
¡ EMPTYING
¡ REQUIRED
¡ (MIN.) ¡ BATCH
PRIMARY BULK FLUID VELOCITY (FT/SEC)
o QUOTED
¡ BLEND TIME (MIN) ¡ TURNOVERS PER HOUR
AVERAGE SHEAR RATE (1/SEC)
¡ REQUIRED
o QUOTED
o MAX
¡ RECIPE (VOLUME/SEQUENCE MIX TIME)
¡ SIZE (GAL)
NORMAL
¡ MINIMUM
MAXIMUM
PROCESS REQUIREMENTS (COMPLETE ALL THAT APPLY) ¡ BLENDING OF MISCIBLE LIQUIDS
¡DISSOLVING
¡ SOLIDS SUSPENSION
¡ SOLUBILITY
¡ PARTICLE SIZE
¡ EASY
¡ MODERATE
¡ DIFFICULT
¡ DISSOLVING SOLIDS MAY AGGLOMERATE
MICRON
¡ WEIGHT % SOLIDS
¡ HEAT TRANSFER
¡ DISTRIBUTION
¡ SERVICE
¡ HEAT
¡ COOL ¡ MAINTAIN TEMPERATURE
¡ HEAT TRANSFER FLUID
NATURE OF SOLIDS
¡ SOLUBLE
¡ INSOLUBLE
¡ ABRASIVE
¡ SPECIFIC HEAT
BTU/LB
¡ STICKY
¡ CRYSTALLINE
¡ FLUFFY
¡ CONDUCTIVITY
°F
¡ SETTLING VELOCITY (fpm)
¡ DUTY
BTU/HR
¡ RESUSPEND AFTER SETTLING REQUIRED
¡ EXTERNAL JACKETS
¡ SOLIDS FLOAT
¡ OTHER
¡ UNIFORM SUSPENSION
¡ COMPLETE SUSPENSION
¡ SUPERFICIAL GAS VELOCITY
¡ ALL SOLIDS IN MOTION
¡ REQUIRED RESULTS ¡ EASILY WETTED
¡ FINE BUBBLES o UNGASSED POWER INPUT (HP)
¡ REDUCE AGGLOMERATES TO
MICRONS MAX
¡ CRYSTALLIZATION
¡ TWO SPEED MOTOR ¡ GAS SOURCE
¡ IMPELLER TO SCRAPE SURFACE(S)
¡ SOLIDS FORMATION
¡ COARSE RADIAL DISPERSION
¡ SMOOTH
REQUIRED RESULTS
¡ POLYMERIZING
FT/SEC
¡ GASSED/UNGASSED VOLUME RATIO
¡ DISPERSION (NON-MISCIBLE)
CRYSTALS
¡ TUBE BAFFLES
¡ GAS DISPERSION
REQUIRE RESULTS
¡ RESISTS WETTING
¡ INTERNAL COIL
¡ INTERLOCK DRIVER TO GAS FLOW ¡ SPARGER RING
¡ INJECTION TUBE
¡ FROM EVOLUTION
¡ FRIABLE
¡ FORM SLURRY
¡ SETTLE OUT
¡ DEPOSIT ON SURFACE
¡ CHEMICAL REACTION REACTION RATE
¡ EXTRACTION
¡ RAPID
¡ MODERATE
¡ SLOW
¡ LIQUID-LIQUID
¡ LEACHING
¡ WASHING
¡ PARTIPATIVE EXTRACTION
Process Industry Practices Machinery
PIP RESM001 Specification for Agitators
PURPOSE AND USE OF PROCESS INDUSTRY PRACTICES In an effort to minimize the cost of process industry facilities, this Practice has been prepared from the technical requirements in the existing standards of major industrial s, contractors, or standards organizations. By harmonizing these technical requirements into a single set of Practices, istrative, application, and engineering costs to both the purchaser and the manufacturer should be reduced. While this Practice is expected to incorporate the majority of requirements of most s, individual applications may involve requirements that will be appended to and take precedence over this Practice. Determinations concerning fitness for purpose and particular matters or application of the Practice to particular project or engineering situations should not be made solely on information contained in these materials. The use of trade names from time to time should not be viewed as an expression of preference but rather recognized as normal usage in the trade. Other brands having the same specifications are equally correct and may be substituted for those named. All practices or guidelines are intended to be consistent with applicable laws and regulations including OSHA requirements. To the extent these practices or guidelines should conflict with OSHA or other applicable laws or regulations, such laws or regulations must be followed. Consult an appropriate professional before applying or acting on any material contained in or suggested by the Practice.
©Process Industry Practices (PIP), Construction Industry Institute, The University of Texas at Austin, 3208 Red River Street, Suite 340, Austin, Texas 78705. PIP member companies may copy this practice for their internal use.
Not printed with state funds
May 1997
Process Industry Practices Machinery
PIP RESM001 Specification for Agitators Table of Contents 1. Introduction ..................................2
5. Inspection ................................... 11
1.1 Purpose ..............................................2 1.2 Scope .................................................2 1.3 Vendor’s Quotation .............................2
6. Testing ........................................ 11
2. References....................................2
6.1 Mechanical Test ............................... 11 6.2 Noise Level Measurement ................ 11 6.3 Optional Tests .................................. 12
2.1 Process Industry Practices ..................2 2.2 Industry Codes and Standards ............3
7. Preparation for Shipment.......... 12
3. Definitions.....................................3 4. Design and Manufacture..............3 4.1 General...............................................3 4.2 Materials .............................................4 4.3 Agitation Assemblies...........................4 4.4 Steady Bearing ...................................6 4.5 Shaft Sealing System..........................6 4.6 Agitator ..................................7 4.7 Shaft Couplings and Guards ...............8 4.8 Gear Reducer .....................................8 4.9 Drive Motor .......................................10 4.10 Auxiliary Piping ...............................11
Process Industry Practices
7.1 Preservation ..................................... 12 7.2 Cleaning and Painting....................... 12 7.3 Packing and Tagging ........................ 12
8. Vendor’s Data............................. 13 8.1 Proposal ........................................... 13 8.2 Approval Drawings............................ 14 8.3 Final Data......................................... 14
Data Sheets Agitator/Mixer Data Sheet
Page 1 of 14
PIP RESM001 Specification for Agitators
1.
May 1997
Introduction 1.1
Purpose The purpose of this Practice is to provide designers and vendors with mechanical requirements for design and manufacture of permanently mounted agitators for use in process facilities.
1.2
Scope This Practice covers the minimum requirements for design and manufacture of permanently mounted, top and bottom-entering agitators, both with and without mechanical seals. This Practice does not cover requirements for tank mixers, portable and clamp-on, light duty agitators, in-line and jet-type mixers, and high speed dispersers. This Practice also does not cover requirements for the installation of agitators. A typical agitation process data sheet, included with this Practice, may be used to communicate purchaser requirements, however, supplemental information may be necessary to fully define process requirements.
1.3
Vendor’s Quotation 1.3.1
Vendor’s quotation shall conform to this Practice and purchaser’s addenda. At the vendor’s option, an alternate quotation may be offered if the following two conditions are met: a. If there is significant process or delivery advantage, a superior, more reliable agitator design may be offered. Vendor shall provide the technical justification. b. Alternate quotation shall indicate deviations from the requirements in this Practice. Complete details of deviations shall be submitted to purchaser for review.
1.3.2
2.
If vendor’s quotation indicates no deviations from the requirements in this Practice, it shall be assumed by the purchaser that the agitator quoted complies fully with this Practice.
References Applicable requirements in the latest edition (or the edition indicated) of the following industry standards shall be considered an integral part of this Practice: 2.1
Process Industry Practices •
Process Industry Practices (PIP)/American Petroleum Institute (API) –
Page 2 of 14
PIP REIE 686/API RP686 - Guidelines for the Pre-Installation Design and the Installation of Machinery
Process Industry Practices
PIP RESM001 Specification for Agitators
May 1997
2.2
Industry Codes and Standards •
•
•
American Gear Manufacturers Association (AGMA) –
AGMA 2000 - Gear Classification and Inspection Handbook
–
AGMA 6010-E - Spur, Helical, Herringbone, and Bevel Enclosed Drives
American Society of Mechanical Engineers (ASME) –
ASME B1.1 - Unified Inch Screw Threads (UN and UNR Thread Form)
–
ASME B16.5 - Pipe Flanges and Flanged Fittings (Steel)
–
ASME B16.47 - Large Diameter Steel Flanges
American Society for Testing and Materials (ASTM) –
•
International Organization for Standardization (ISO) –
3.
ASTM A269 - Specification for Seamless and Welded Austenitic Stainless Steel Tubing for General Service ISO 1940 Balance Quality of Rotating Rigid Bodies
Definitions For the purposes of this Practice the following definitions apply: Auxiliary Piping Systems: Piping supplied with the agitator for services such as: seal flush or buffer fluid, cooling water, gear reducer lubrication oil, and instrument air or nitrogen Bearing Speed Factor (ndm): An approximation of the speed at which the surfaces of a rolling element bearing roll together, and therefore also an indicator of bearing service severity. The bearing speed factor is determined by multiplying the rotational speed in revolutions per minute times the bearing pitch diameter in millimeters. For convenience, the pitch diameter is taken as one half the sum of the bearing bore and outside diameters. Shrink Disc: Clamping assembly used to secure mechanical shaft seals against rotation on shafts. A shrink disc utilizes a bolted wedge assembly to maintain a friction fit to the shaft. Comment: Use of a shrink disc imposes lower stresses on a shaft than key drives, and does not damage the shaft surface like setscrew drives.
4.
Design and Manufacture 4.1
General 4.1.1
Agitators shall be complete, including drive motor, gear reducer, forced lubrication system (if required) for gear reducer, mounting flange, coupling and guard, shaft, agitation elements, and shaft sealing system. Scope of supply shall conform to the data sheet.
4.1.2
When specified, agitator shall be shop assembled before shipment. Disassembly for shipment shall be limited to that required for shipment,
Process Industry Practices
Page 3 of 14
PIP RESM001 Specification for Agitators
May 1997
rigging, storage, or installation. Components disassembled for shipment shall be clearly matchmarked for reassembly. 4.1.3
Agitators shall be designed for rapid and economical maintenance.4.1.4 Agitators shall be designed so that maintenance and disassembly can be performed with standard shop tools. Any special tools or fixtures required shall be listed in the vendor’s proposal.
4.1.5
Oil fill openings, grease points, and mechanical seal reservoir fill port shall be extended for access without disassembly.
4.1.6
Rabbetted fits or dowels shall be used for alignment for all coupling, adapter housing, and gear casing ts.
4.1.7
Internal agitator components shall be designed to fit through the vessel manhole openings. Vendor shall state the minimum manhole opening required for assembly and maintenance of internal components.
4.1.8
Vendor shall review and comment on purchaser-supplied process performance data, including efficiency, performance, and baffle size and placement.
4.1.9
Vendor shall review and comment on the installation details with respect to agitator mounting and maintenance accessibility of the agitator.
4.1.10 Vendor’s proposal shall state expected sound pressure levels in dB for each octave band. Agitator noise level shall not be higher than specified on the purchaser’s noise data sheet. 4.1.11 Vendor shall state in the proposal if external cooling or forced lubrication is required for the gear reducer, shaft seal, or steady bearing. Cooling water requirements shall be stated in the proposal. 4.1.12 Cooling water ages in heat exchangers or cooling jackets shall be designed for 7.0 barg (100 psig) minimum working pressure. 4.2
4.3
Page 4 of 14
Materials 4.2.1
Material of minor parts (e.g. bolting, shaft keys, and other attachment hardware) in with the process shall have a corrosion resistance equal to or better than that of material of major parts in the same environment.
4.2.2
Material of pressure-containing parts in with the process shall have a corrosion resistance equal to that of the vessel.
4.2.3
Unless otherwise specified, components in with the mechanical seal flush or buffer fluid shall be AISI 300 series stainless steel.
Agitation Assemblies 4.3.1
Shaft shall be designed to resist torsional loads and bending moments for all specified operating conditions, including cold startup.
4.3.2
Unless otherwise specified, shaft shall have a removable coupling spacer so the shaft seal can be replaced without removing the drive or the agitator shaft.
Process Industry Practices
PIP RESM001 Specification for Agitators
May 1997
4.3.3
Shaft shall be equipped with a removable collar or sleeve that s the entire shaft assembly when the coupling spacer is removed. Coupling and sleeve design shall be such that when the coupling bolts are loosened, the sleeve s the shaft automatically.
4.3.4
A dynamic analysis of the shaft assembly shall be performed for both dry and wet conditions, and the results included as part of the vendor’s proposal. This analysis shall that any lateral or torsional resonances are separated from the operating speed range by at least 20% of the normal operating speed. Also, these resonances shall not be within 10% of any agitator vane frequencies, (including baffle effects), or electrical excitation frequencies, such as those caused by variable frequency drives.
4.3.5
Shaft assemblies that operate at more than 100 RPM and less than 300 RPM shall be statically balanced to the purchaser’s tolerance.
4.3.6
Shaft assemblies that operate at 300 RPM or higher speed shall be dynamically balanced to G40 tolerance in accordance with ISO 1940.
4.3.7
With the agitator drive input shaft turned by hand, runouts of the assembled shaft and agitation elements shall not exceed the following limits of total indicator runout (TIR): a. 0.05 mm (0.002 in.) at the gear reducer output shaft b. 0.13 mm (0.005 in.) above and below the mechanical seal housing c. 0.25 mm/m (0.003 in./ft.) of shaft length measured from the agitator mounting flange at the first in-vessel coupling, at the agitator hubs, and at the shaft end without the of a steady bearing d. 0.025 mm (0.001 in.) perpendicular runout at the coupling face
4.3.8
When specified, the shaft shall have extended key seats for adjustment of the agitation elements.
4.3.9
For shafts with multiple agitation elements, the key seats shall be circumferentially staggered around the shaft.
4.3.10 Bolting of agitator blades shall conform to ASME B1.1. 4.3.11 Bolted connections of the agitation elements to the hub shall have a maximum diametral clearance of 0.8 mm (0.03 in.). 4.3.12 Blades shall be fastened to the hub with a minimum of three (3) bolts. Bolt threaded length in hub and blade t shall be minimized. 4.3.13 Bolts shall be secured by lockwire or other positive locking method. 4.3.14 Unless otherwise specified, agitator hub-to-shaft attachments shall be key driven. 4.3.15 Total allowable variation in the radial sweep of the blade tips shall be 13 mm (0.5 in.). Radial sweep shall be measured without use of a steady bearing. 4.3.16 Maximum tolerance for axial location of blades and hubs shall be ±13 mm (0.5 in.).
Process Industry Practices
Page 5 of 14
PIP RESM001 Specification for Agitators
4.4
May 1997
Steady Bearing 4.4.1
Unless specifically approved by the purchaser, steady bearings shall not be used.
4.4.2
If the use of steady bearings is approved, then the steady bearing design shall conform to the following criteria: a. Proposals for agitators that have a steady bearing shall include sufficient detail for evaluation of the steady bearing design. b. Bearing design shall provide sufficient clearance for the differential radial and axial thermal expansion of the shaft and the bearing . c. Bearing shall have provisions for lateral and axial adjustment of the bearing assembly for alignment purposes. d. Agitator shaft shall have a replaceable sleeve at the bearing. Shaft sleeves for abrasive services shall be hard coated. e. Bearing shall have a replaceable liner. Unless otherwise specified, liner shall be made of glass-filled polytetrafluorethylene (PTFE). f.
4.5
Unless otherwise specified, bearing liner and shaft sleeve shall be fieldreplaceable without removing the agitator shaft or the bearing .
Shaft Sealing System 4.5.1
When specified, a sealing system shall be supplied by the vendor.
4.5.2
For toxic fluids, and for flammable fluids with vapor pressure that exceeds atmospheric pressure at operating temperature or maximum ambient temperature, the shaft sealing system shall have pressurized dual mechanical seals.
4.5.3
When specified, the sealing system shall have a positive shut-off device that allows maintenance of the sealing system without clearing the vessel. Comment: Partial depressuring of the vessel is allowed for maintenance, therefore the positive shut-off device may have a lower pressure rating than the actual mechanical seal.
4.5.4
The shaft sealing system shall have the following features: a. Seals shall be hydraulically balanced design and of single cartridge construction. The inner seal of dual seals shall have a reverse balance feature designed and constructed to withstand reverse pressure differentials without opening. b. Seal cartridge shall be field-removable without removing the gear reducer or the shaft. c. Seal cartridge design shall be adequate for stand-alone static bench testing before installation. d. Seal cartridges shall be self-venting through the seal circulation return line. Centerline of the seal flush return port shall be a minimum of 3 mm (0.13 in.) above the seal faces.
Page 6 of 14
Process Industry Practices
PIP RESM001 Specification for Agitators
May 1997
e. Seal cartridges shall have leak detection port(s). Leak detection ports shall have a tapped connection and shall be permanently labeled by stamping. f.
The rotating seal element shall be setscrew driven. When specified, the rotating seal element shall be key or shrink disc driven. Comment: The use of setscrews to drive large or high pressure mechanical seals requires the use of a large number of setscrews, which creates the possibility of distortion or improper installation of the seal due to uneven tightening. Mechanical damage to the shaft and possibly the shaft O-rings can result from the setscrews upsetting the shaft metal when tightened. The use of key or shrink disc driven seal elements eliminates these possible problems.
g. Pressure ts in the seal cartridge housing shall be sealed with O-rings. Use of gaskets is prohibited. h. Unless otherwise specified, the seal cartridge shall not have cooling jackets. i.
Dual seals shall have a seal reservoir with a minimum capacity of 12 liters (3 gallons).
j.
Seal reservoir shall have a level gauge, a fill connection, and vent and drain connections. Level gauge shall be sized to indicate a range of ±50 mm (2 in.) of normal operating level.
k. Systems with dual seals shall have a device that provides positive circulation of buffer fluid from the seal reservoir to the seal. Circulation device can be a pumping ring or a separate circulation pump. Comment: When a dead-ended seal lubrication system is specified, a cooling jacket may be required, and a circulation device is not necessary. 4.5.5
An anti-friction bearing shall be mounted in or near the mechanical seal cartridge to minimize shaft motion at the seal. For continuous service, the bearing shall have a minimum L10 life of 40,000 hours. Calculation of bearing life shall be based on the specified operating conditions.
4.5.6
When specified, a separate lifting device for seal maintenance shall be included in the vendor’s proposal. Comment: A separate lifting device for mechanical seal maintenance (usually a small bolt on trolley and hoist assembly) is recommended if no permanent overhead lifting capacity is available and the weight of any item in the seal system exceeds 20 kg (45 lb.).
4.6
Agitator 4.6.1
Process Industry Practices
Unless otherwise specified on the data sheet, agitators shall be equipped with a through-bolted connection flange with dimensions, drilling, and pressure rating in accordance with ASME B16.5 or ASME B16.47, whichever applies. Connection flange bolt hole orientation shall match vessel flange.
Page 7 of 14
PIP RESM001 Specification for Agitators
4.6.2 4.7
May 1997
Agitators shall be ed on the vessel nozzle.
Shaft Couplings and Guards 4.7.1
The coupling between the motor and gear reducer shall be of non-lubricated flexible design.
4.7.2
Coupling service factor shall be a minimum of 2.0 based on the motor nameplate power.
4.7.3
Couplings for motors 35 kW (50 hp) and larger shall be flexible disk type.
4.7.4
Couplings for gear reducer output shaft and agitator shaft shall be of rigid design.
4.7.5
Unless otherwise specified, agitator shaft coupling hubs shall be keyed or welded in place and the arrangement indicated on the outline dimension drawing. Threaded coupling mounts are prohibited.
4.7.6
When specified, shaft ends for agitator shaft coupling hubs shall be tapered for ease of disassembly. Comment: Tapered coupling hubs are used at coupling ts where the coupling must be easily field removable and also have a moderate interference fit to transmit torque. The coupling located just above the mechanical seal is an example of this.
4.8
4.7.7
When interference fits are specified, cylindrical bore couplings shall be mounted using an interference fit of 0.0005 mm/mm (0.0005 in./in.) of shaft diameter.
4.7.8
A coupling guard shall be supplied for the motor driver coupling area. Coupling guard shall be removable and shall be mounted so that the rotating parts are covered to within 13 mm (0.5 in.) of the stationary housings. Guard shall be rigid enough so that of the guard with moving parts does not occur as a result of bodily with the guard.
Gear Reducer 4.8.1
Page 8 of 14
General 4.8.1.1
Gear reducer shall be specifically designed for agitator service.
4.8.1.2
Output shaft and bearings shall be designed to the weight of the agitator assembly.
4.8.1.3
Gear reducer shall be designed to withstand all torsional, bending, and thrust loads so that significant deflections are not transmitted to the gears and bearings.
4.8.1.4
Gear reducer shall be furnished in accordance with AGMA 6010-E.
4.8.1.5
Gears shall be spiral bevel and/or helical. Use of worm gears, hypoid gears, double helical, or herringbone gears is prohibited.
Process Industry Practices
PIP RESM001 Specification for Agitators
May 1997
4.8.2
4.8.3
Process Industry Practices
4.8.1.6
Minimum gear reducer service factor shall be 1.4. For services in which polymerization or solidification is possible in the vessel, gear reducer service factor shall be 2.0, as a minimum.
4.8.1.7
Gears shall be finished to Quality Level 9, as a minimum, in accordance with AGMA 2000.
4.8.1.8
For continuous duty agitators, gear reducer anti-friction bearings shall be designed for an L10 life of 40,000 hours. Loads on bearings shall be based on nominal driver rating and agitator shaft loads transmitted to the gear reducer.
4.8.1.9
Thermal rating of the gear reducer shall be calculated in accordance with AGMA 6010-E using a factor of 0.75 for the ambient modifier, T4.
Cooling/Lubrication 4.8.2.1
When the driver nominal nameplate power exceeds the thermal rating of the gear reducer, an external cooling system shall be provided.
4.8.2.2
Preferred cooling system shall consist of ducting and a fan mounted on the input shaft. When fan cooling is insufficient, forced-oil circulation through an external cooler shall be provided.
4.8.2.3
Forced-oil circulation system components shall include: •
Replaceable element filter
•
Motor-driven oil pump
•
Cooler (water or air cooled)
•
Pump discharge pressure gauge
•
Low oil pressure alarm switch
•
Sump and cooler exit temperature gauges
•
Stainless steel piping.
4.8.2.4
Gear reducer lubrication system shall be designed to operate automatically without operator intervention.
4.8.2.5
All gears shall be lubricated with oil.
4.8.2.6
Low speed bearings with a speed factor (ndm) less than 150,000 may be grease-lubricated. Sealed-for-life bearings are unacceptable.
Gear Reducer Housing 4.8.3.1
Gear reducer housing shall have lifting lugs sized and located to lift the agitator assembly for installation and maintenance.
4.8.3.2
Housing shall have an oil level sight glass. Normal oil levels for static and operating conditions shall be plainly marked on the housing.
Page 9 of 14
PIP RESM001 Specification for Agitators
May 1997
4.8.3.3
Housing shall have a gear reducer nameplate securely attached on its exterior. Nameplate shall be made of 300 series stainless steel and shall be attached with corrosion resistant fasteners.
4.8.3.4
Nameplate shall have the following information permanently marked on it: a. Size and type or model b. Rated power c. Service factor d. Ratio e. Input and output RPM f. Manufacturer’s name g. Serial number h. Purchaser’s equipment number
4.8.3.5
4.9
Page 10 of 14
Housing shall have rotation arrows cast or attached with corrosion resistant fasteners. Arrows shall indicate direction of rotation of input and output shafts.
Drive Motor 4.9.1
Drive motor shall have a 1.15 service factor.
4.9.2
Motor nameplate power shall not be less than 115% of maximum agitator power requirements, including drive losses. Motor service factor shall not be used to meet this requirement.
4.9.3
Vertical motors shall have a rain shield.
4.9.4
Motor shall be mounted on a rigid bracket attached to the gear reducer.
4.9.5
Foot mounted motors shall have stainless steel shims with a minimum thickness of 3 mm (0.125 in.) to the motor feet. The shim pack shall consist of no less than three and no more than five shim pieces.
4.9.6
The agitator motor mounting adapter runouts for flange mount motors shall not exceed 0.05 mm (0.002 in.) concentricity (radial runout) and 0.13 mm (0.005 in.) perpendicularity (face runout) as measured from the gear reducer input shaft.
4.9.7
When specified, positioning screws to aid in driver alignment shall be provided for both foot and flange mount motors. For foot mount motors, horizontal positioning screws for both transverse and longitudinal directions shall be provided. For flange mount motors, positioning screws to adjust motor alignment in two directions normal to the shaft axis shall be provided. Any part of the positioning screw assembly above the plane of the mounting surface shall be removable without cutting, burning, or grinding.
4.9.8
The motor shall be provided with a grounding lug on the frame.
Process Industry Practices
PIP RESM001 Specification for Agitators
May 1997
4.10
Auxiliary Piping 4.10.1 Piping connections to purchaser systems 3/4 NPS or larger shall be flanged. 4.10.2 Piping components in with the mechanical seal flush fluid shall be stainless steel. 4.10.3 Seal flush system shall be stainless steel tubing that conforms to ASTM A269. Minimum size of tubing shall be 1/2 in. Use of 3/4 in. tubing is preferred.
5.
6.
Inspection 5.1
Purchaser will specify the minimum requirements for inspection in the purchase order or a separate addendum to the data sheet.
5.2
When specified on the data sheet, inspection shall be conducted by the purchaser before the agitator is shipped.
5.3
Purchaser shall have access to inspect the agitator, or any of its auxiliary systems, at any time during their fabrication or testing.
5.4
Vendor shall notify the purchaser a minimum of five (5) days before any scheduled shop tests and before the equipment is to be ready for final inspection.
Testing 6.1
6.2
Mechanical Test 6.1.1
The purchased motor, gear drive, and mechanical seal assembly shall be given a mechanical run test at the vendor’s facility.
6.1.2
The motor, gear drive, and seal assembly shall be operated at full speed and partial or no load conditions for one hour after bearing temperatures have stabilized, or for a mutually agreed upon time period.
6.1.3
Dual seal systems shall be operated at normal operating pressure during the mechanical performance test.
6.1.4
Bearing temperatures and housing vibration shall be measured and recorded just prior to the end of the mechanical test.
6.1.5
Bearing temperatures shall not exceed 65°C (150°F). Vibration as measured at the top of the gear drive shall not exceed 5 mm/sec (0.2 in/sec) RMS.
6.1.6
Shaft runouts at the input shaft and mechanical seal area shall be measured and recorded on the test data sheets after the mechanical test.
Noise Level Measurement 6.2.1
Process Industry Practices
When specified, the vendor shall measure and record the noise level of the agitator during the mechanical test as stated in Section 6.2.1.1 through 6.2.1.4.
Page 11 of 14
PIP RESM001 Specification for Agitators
6.3
May 1997
6.2.1.1
Noise level shall be measured in the horizontal plane at a distance of 1 m (3 ft.) from the drive motor or gear reducer surface.
6.2.1.2
A survey of the operating agitator shall be made to determine the location with the highest noise level. Noise level at this location shall be recorded.
6.2.1.3
Overall noise level shall be measured and recorded using the “A” weight filter. Frequency analysis of the noise shall be performed using an octave band filter with center frequencies from 31.5 to 8 kHz. Noise levels for each of the octave filter bands shall be recorded.
6.2.1.4
Noise level measurements shall be taken with the sound level meter operating in the slow response mode and a visual average of the meter fluctuation shall be recorded. Meter shall also be observed operating in fast response mode with the “A” weight filter. If the meter deflection on fast response is greater than 5 dB, then maximum and minimum meter values shall be recorded for each measurement.
Optional Tests When specified, optional tests, such as part or full load tests or testing to validate agitation element design, shall be performed.
7.
Preparation for Shipment 7.1
Preservation Interior of the gear reducer shall be treated with corrosion inhibitors in accordance with PIP REIE 686/API RP686.
7.2
7.3
Page 12 of 14
Cleaning and Painting 7.2.1
Exterior surfaces shall be painted with the vendor’s standard paint.
7.2.2
Stainless steel surfaces shall not be painted unless covered by insulation.
7.2.3
Exposed machined surfaces shall be coated with an easily removable rust preventative.
Packing and Tagging 7.3.1
Agitator shall be braced and small piping shall be secured to prevent damage during shipment.
7.3.2
All flanged openings shall be sealed with gaskets and metal covers. Small piping shall be sealed with metal or plastic plugs.
7.3.3
Mounting flanges shall be protected with sheet steel covers. Wooden covers with a minimum thickness of 20 mm (3/4 in.) shall be placed over the steel covers and shall be secured with a minimum of four (4) bolts.
Process Industry Practices
PIP RESM001 Specification for Agitators
May 1997
8.
7.3.4
Special tools and small accessories shall be boxed and shipped with the agitator.
7.3.5
A complete set of installation and operation instructions and a certified outline dimension drawing enclosed in a waterproof envelope shall be attached to the agitator.
7.3.6
Material shipped separately shall be identified with the purchaser’s item number on a metal tag.
7.3.7
Each separate item, crate, bag, etc., shall be identified with purchaser’s order and requisition numbers and all special markings specified by the purchase order.
Vendor’s Data 8.1
Proposal Vendor shall submit as a minimum the following data with the proposal: a. Spare parts list with unit pricing for spare parts. Spare parts list shall include parts required for three years of normal operation and critical startup spare parts. b. Completed agitator data sheet c. Preliminary (or typical) outline drawings showing: •
Principal dimensions
•
Weights of principal components
•
Clearances required for installation and maintenance
•
Mounting flange dimensions
•
Drive motor
•
Agitator blade-to-hub connection details
•
Seal reservoir mounting location
•
Direction of rotation when looking at the top of the agitator
d. Typical cross-sectional drawing of the gear reducer showing details of construction e. Cross-sectional drawing of the shaft seal, with details and specifications of all sealing system components f.
Cross-sectional drawing of the steady bearing (if required)
g. Agitator performance (mixing) calculations and curves h. Typical schematics for seal flush and lubrication systems i.
A detailed procedure for replacement of mechanical seals
j.
Drawings showing the forces and moments applied by the agitator assembly to the vessel mounting flange
Process Industry Practices
Page 13 of 14
PIP RESM001 Specification for Agitators
8.2
May 1997
Approval Drawings After receipt of the order, vendor shall furnish the following certified drawings: a. Outline drawing(s) of the complete assembled agitator. Drawing(s) shall include: •
Principal dimensions
•
Direction of rotation of the agitator
•
Size and location of connections to the agitator
•
Size and location of mounting flanges
•
Total weight and individual weights of principal maintenance items
b. Actual cross-sectional drawings of the gear reducer, shaft sealing system, and steady bearing c. Drawings of auxiliary equipment or piping d. Drawings showing the forces and moments applied by the agitator assembly to the vessel mounting flange e. Bill of materials f. 8.3
Drive motor data sheet
Final Data 8.3.1
After final inspection, the vendor shall furnish the following data: a. As-built data sheets and final drawings b. Operating and maintenance instructions, including lubrication requirements, and a detailed procedure for mechanical seal replacement c. Parts list with factory cross reference number d. Certified data from the shop tests that were performed. Data shall be provided for purchaser’s review and acceptance prior to shipment of the agitator. e. Purchaser specified ducumentation such as material certifications.
8.3.2
Page 14 of 14
The number of copies required will be specified in the purchase order.
Process Industry Practices
RESM001
Specification for Agitators
PAGE 1 OF 3
AGITATOR DATA SHEET JOB __________________________________________________________
NUMBER
ITEM NO _____________________________________________________________ SERVICE _____________________________________________________________
CLIENT____________________________________________________________
REQUISITION NUMBER _________________________________________________
PROJECT LOCATION ________________________________________________
_____________________________________________________________________
UNIT ______________________________________________________________ DESIGN, MANUFACTURE, INSPECTION, AND TESTING SHALL CONFORM TO SPECIFICATION NOTES: PURCHASER
¡ INDICATES INFORMATION COMPLETED BY PURCHASER
GENERAL o MODEL NUMBER ¡ DRIVER TYPE OPERATING CONDITIONS
MIXER MANUFACTURER DRIVER ITEM NUMBER
¡ PRESSURE ¡ MIXED VOLUME
¡ QUANTITY
¡ UP ¡ RADIAL PERFORMANCE RPM o MAX SHAFT POWER o NORMAL SHAFT POWER o o IMPELLER DIAMETER CONSTRUCTION FEATURES
¡ DOWN
GAL
o MANUFACTURER CODE x FLAT x PROPELLER
o QUANTITY x PITCHED x MULTIPLE o PITCH
¡ VESSEL MFR
IN
x AGITATOR HUBS x BLADES x MECHANICAL SEAL PARTS ¡ NOT REQUIRED o RATED TEMP
x MANUFACTURER
¡ AGITATOR MFR
x MANUFACTURER CODE
o BRG SPAN (IN)
¡ POSITIVE SEAL SHUTOFF FOR MANTENANCE
o CRITICAL SPEED (RPM)
¡ KEY-DRIVEN ROTATING ELEMENT
GEARBOX
¡ SHRINKING-DISC DRIVEN ROTATING ELEMENT
o MANUFACTURER
o MODEL NUMBER
x PARALLEL SHAFT
TYPE
o RATED POWER
HP
o AGMA S.F. BEARINGS
o EFFICIENCY LOW SPEED
o TYPE o LUBRICATION TYPE o AFBMA L-10 LIFE
MOTOR
o MANUFACTURER o TYPE o HORSEPOWER
x SEAL RESERVOIR SIZE %
x COOLING WATER
¡ FLUID x FORCED CIRCULATION o PSIG o SOURCE
PAINTING
¡ INTERFERENCE FIT
¡ MANUFACTURER STANDARD ¡ SPEC NUMBER ¡ ASSEMBLE COMPLETE BEFORE SHIPMENT ¡ INSPECTION REQUIREMENTS ¡ MECHANICAL TEST ¡ OPTIONAL TEST ¡ FINAL BEFORE SHIPMENT ¡ OTHER ¡OPTIONAL TESTING ¡ PART LOAD ¡ FULL LOAD ¡ NOISE LEVEL ¡ AGITATOR PERFORMANCE ¡ OTHER o MODEL o RPM o FRAME o FOOT MOUNT o FLANGE MOUNT REVISIONS
NUMBER
REVIEWED
DATE
APPROVED
ORIGINATOR
o FLOW
o COOLING JACKET SEAL FLUSH
x DEAD ENDED x PRESSURIZED
HS COUPLING
¡ INTERFERENCE FIT x MANUFACTURER x MODEL LS COUPLING ¡ TAPERED HUBS
¡ MAINTENANCE LIFTING DEVICE
x RIGHT ANGLE o AGMA QUALITY
HIGH SPEED
°F
MANUFACTURER/TYPE
x MECHANICAL SEAL TYPE
x BOTTOM STEADY BEARING
BRG ED BY:
HP
x IMPELLER x SHAFT x MOUNTING FLANGE x GASKET SHAFT SEALS ¡ REQUIRED o RATED PRESSURE PSIG x PACKING x SIZE/NO RINGS
¡ EXTENDED KEY SEATS
o SHAFT DIA (IN)
HP
MATERIALS OF CONSTRUCTION
o NO BLADES o RECOMMENDED CLEARANCE FROM OBSTRUCTION IN o PROJECTED BLADE AREA (IN2) o THICKNESS (IN) ATTACHMENT o WELDED o BOLTED ¡ POSITIVE LOCK HUB o FABRICATED o CAST o KEY-DRIVEN o SHAFT o HOLLOW o SOLID o STEPPED o FLANGED x STABILIZERS
o SERIAL NUMBER ¡ DRIVER PROVIDED BY
GAL
o OPERATING SPEED o CALCULATED PRIMARY PUMPING CAPACITY 3 o ROTATION o CW
TYPE
x BY MANUFACTURER OR
DIRECTION OF FLUID MOVEMENT
PSIG MIN MAX
IMPELLER
o BY MANUFACTURER
o GPM
RESM001
Specification for Agitators
PAGE 2a OF 3
AGITATOR DATA SHEET JOB NUMBER __________________________________________________________
ITEM NO _______________________________________________________________
VESSEL DETAILS ¡ VESSEL ITEM NUMBER
VESSEL DETAILS
¡ SIZE:
D/L
¡ API 620
H
(W)
¡ ASME SECT VIII
TOP HEAD TYPE
FT
¡ OTHER
¡ INTERNALS
¡ FLAT
¡ ASME DISHED
¡ CONE
¡ OTHER
BOTTOM HEAD TYPE
¡ CAPACITY
GAL/BBL
x MOUNTING FLANGE SIZE
FACING
x SIZE OPENING FOR IMPELLER INSTALLATION
RATING IN
¡ FLAT
¡ ASME DISHED
¡ CONE
¡ OTHER
FT-LB
DESCRIPTION
A
NORMAL LIQUID LEVEL
B
MAXIMUM LIQUID LEVEL
C
IMPELLER DIAMETER
D
IMPELLER DEPTH
E
VESSEL REFERENCE DEPTH
F
VESSEL I.D.
INCHES
¡ 2:1 ELLIPTICAL
LOADS TORQUE
ID
¡ 2:1 ELLIPTICAL
STATIC MOMENT
FT-LB
REMARKS
DYNAMIC MOMENT
FT-LB
WEIGHT
LB
RESM001
Specification for Agitators
PAGE 2b OF 3
AGITATOR DATA SHEET JOB NUMBER __________________________________________________________
ITEM NO _______________________________________________________________
TANK DETAILS ¡ VESSEL ITEM NUMBER
VESSEL DETAILS
¡ SIZE:
D/L
¡ API 620
H
(W)
¡ ASME SECT VIII
TOP HEAD TYPE
FT
¡ OTHER
¡ INTERNALS
¡ FLAT
¡ ASME DISHED
¡ CONE
¡ OTHER
BOTTOM HEAD TYPE
¡ CAPACITY
GAL/BBL
x MOUNTING FLANGE SIZE
FACING
RATING
x SIZE OPENING FOR IMPELLER INSTALLATION
IN
¡ FLAT
¡ ASME DISHED
¡ CONE
¡ OTHER
FT-LB
DESCRIPTION
A
NORMAL LIQUID LEVEL
B
MAXIMUM LIQUID LEVEL
C
IMPELLER DIAMETER
D
IMPELLER DEPTH
E
VESSEL REFERENCE DEPTH
F
VESSEL I.D.
INCHES
¡ 2:1 ELLIPTICAL
LOADS TORQUE
ID
¡ 2:1 ELLIPTICAL
STATIC MOMENT
FT-LB
REMARKS
DYNAMIC MOMENT
FT-LB
WEIGHT
LB
Specification for Agitators
RESM001 PAGE 3 OF 3
AGITATOR DATA SHEET JOB NUMBER __________________________________________________________
ITEM NO _______________________________________________________________
AGITATOR PROCESS DEFINITION FLUID PROPERTIES, COMPOSITION AND CONDITIONS FEED
COMPONENT
RATE(GPM)
TEMP (°°F)
3
DENSITY (LB/FT )
VISCOSITY ()
REMARKS
1 2 PRODUCT OPERATING TEMPERATURE (°°F)
FOAMING TENDENCY
VISCOUS PROPERTY
MAX. VISCOSITY ()
¡ NORMAL
¡ NONE
¡ DILUENT
¡ STARTUP
¡ MINIMUM
¡ MODERATE
¡ NEWTONIAN
¡ INTERMDEDIATE BLEND
¡ MAXIMUM
¡ EXCESSIVE
¡ PSEUDOPLASTIC
¡ FINAL BLEND
¡ OTHER
¡ UPSET
¡ TOXICITY
¡ VAPOR PRESSURE AT OPERATING TEMP OPERATION (CONTINUOUS RETENTION TIME) MIXING DURING
¡ FILLING
¡ DRAWOFF
¡ EMPTYING
¡ REQUIRED
¡ (MIN.) ¡ BATCH
PRIMARY BULK FLUID VELOCITY (FT/SEC)
o QUOTED
¡ BLEND TIME (MIN) ¡ TURNOVERS PER HOUR
AVERAGE SHEAR RATE (1/SEC)
¡ REQUIRED
o QUOTED
o MAX
¡ RECIPE (VOLUME/SEQUENCE MIX TIME)
¡ SIZE (GAL)
NORMAL
¡ MINIMUM
MAXIMUM
PROCESS REQUIREMENTS (COMPLETE ALL THAT APPLY) ¡ BLENDING OF MISCIBLE LIQUIDS
¡DISSOLVING
¡ SOLIDS SUSPENSION
¡ SOLUBILITY
¡ PARTICLE SIZE
¡ EASY
¡ MODERATE
¡ DIFFICULT
¡ DISSOLVING SOLIDS MAY AGGLOMERATE
MICRON
¡ WEIGHT % SOLIDS
¡ HEAT TRANSFER
¡ DISTRIBUTION
¡ SERVICE
¡ HEAT
¡ COOL ¡ MAINTAIN TEMPERATURE
¡ HEAT TRANSFER FLUID
NATURE OF SOLIDS
¡ SOLUBLE
¡ INSOLUBLE
¡ ABRASIVE
¡ SPECIFIC HEAT
BTU/LB
¡ STICKY
¡ CRYSTALLINE
¡ FLUFFY
¡ CONDUCTIVITY
°F
¡ SETTLING VELOCITY (fpm)
¡ DUTY
BTU/HR
¡ RESUSPEND AFTER SETTLING REQUIRED
¡ EXTERNAL JACKETS
¡ SOLIDS FLOAT
¡ OTHER
¡ UNIFORM SUSPENSION
¡ COMPLETE SUSPENSION
¡ SUPERFICIAL GAS VELOCITY
¡ ALL SOLIDS IN MOTION
¡ REQUIRED RESULTS ¡ EASILY WETTED
¡ FINE BUBBLES o UNGASSED POWER INPUT (HP)
¡ REDUCE AGGLOMERATES TO
MICRONS MAX
¡ CRYSTALLIZATION
¡ TWO SPEED MOTOR ¡ GAS SOURCE
¡ IMPELLER TO SCRAPE SURFACE(S)
¡ SOLIDS FORMATION
¡ COARSE RADIAL DISPERSION
¡ SMOOTH
REQUIRED RESULTS
¡ POLYMERIZING
FT/SEC
¡ GASSED/UNGASSED VOLUME RATIO
¡ DISPERSION (NON-MISCIBLE)
CRYSTALS
¡ TUBE BAFFLES
¡ GAS DISPERSION
REQUIRE RESULTS
¡ RESISTS WETTING
¡ INTERNAL COIL
¡ INTERLOCK DRIVER TO GAS FLOW ¡ SPARGER RING
¡ INJECTION TUBE
¡ FROM EVOLUTION
¡ FRIABLE
¡ FORM SLURRY
¡ SETTLE OUT
¡ DEPOSIT ON SURFACE
¡ CHEMICAL REACTION REACTION RATE
¡ EXTRACTION
¡ RAPID
¡ MODERATE
¡ SLOW
¡ LIQUID-LIQUID
¡ LEACHING
¡ WASHING
¡ PARTIPATIVE EXTRACTION
Related Documents 2w1qw
Agitator Selection 615ek
October 2021 0
Agitator 576y5p
April 2020 18
Agitator 576y5p
April 2020 29
Brant Agitator 2r572m
December 2019 82
Agitator Design 5s3r40
August 2020 0
Agitator Handbook 5c356u
November 2019 82More Documents from "Ramakrishna Koushik" 4k44m
Agitator Selection 615ek
October 2021 0
Pinch Analysis Intro 4n1ow
July 2021 0
Generator Protection Relay Settings 462v60
November 2019 91
Sap Fico Theory-new 6y4s6i
October 2019 100
Plc Soft Master Ml200 1361r
February 2022 0
