THE 8086 AND 8088 MICROPROCESSORS The first IBM PC was based on the i8088 processor. This device is fully software compatible with the i8086, but it has an 8-bit external data bus (16-bit internally) and has a 4 byte instruction prefetch queue. The 8086 and 8088 can really be considered together for our purposes. The 8086/8088 microprocessor consists of two internal units: the execution unit (EU), which executes the instructions, and the bus interface unit, which fetches instructions, reads operands and writes results. This is sketched below (from Floyd’s book). The BIU allows some overlapping between instruction fetching and execution.

Bus Interface Unit(BIU) Fetches Opcodes, Reads Operands, Writes Data

Execution Unit (EU)

8086/8088 MPU

8086/8088 Architecture. E U

B IU A d d r e s s B u s 2 0 b it s

A H

A L

B H

B L

C H

C L

D H

D L

S U M M A T IO N

D a ta B u s

C S D S S P S S B P E S D I IO B I

B us C o n tro l

I n te r n a l C o m m u n i c a t io n s R e g is te r s

8088 B us

T e m p o ra ry R e g is t e r s I n s tr u c t io n Q u e u e A LU E U C o n tr o l

1

2

3

4

F la g s

The following figure shows the internal organisation of the 8086/8088: The Bus Interface Unit (BIU) consists of the following: Instruction Queue: this allows the next instructions or data to be fetched from memory while the processor is executing the current instruction. The memory interface is usually much slower than the processor execution time, so this decouples the memory cycle time from the execution time.

ET4508/ED5532

Ciaran MacNamee / Karl Rinne

L4a-1

Segment s: The Code Segment (CS), Data Segment (DS), Stack Segment (SS) and Extra Segment (ES) s are 16-bit s, used with the 16-bit Base s to generate the 20-bit address required to allow the 8086/8088 to address 1Mb of memory. They are changed under program control to point to different segments as a program executes. The Segmented architecture was used in the 8086 to keep compatibility with earlier processors such as the 8085. It is one of the most significant elements of the Intel Architecture. CS 16 -bit S egnm ent B ase A ddress

00 00

IP 16-bit O ffset A ddress

20-bit P hysical A ddre ss

The Instruction Pointer (IP) and Address Summation: The IP contains the Offset Address of the next instruction, which is the distance in bytes from the base address given by the current Code Segment (CS) . The figure shows how this is done. The contents of the CS are shifted left by four. Bit 15 moves to the Bit 19 position. The lowest four bits are filled with zeros. The resulting value is added to the Instruction Pointer contents to make up a 20-bit physical address. The CS makes up a segment base address and the IP is looked as an offset into this segment. This segmented model also applies to all the other general s and segment s in the 8086 device. For example, the SS and SP are combined in the same way to address the stack area in physical memory. Exercise: 1. The CS contains A820, while the IP contains CE24. What is the resulting physical address? 2. The CS contains B500, while the IP contains 0024. What is the resulting physical address?

THE 8088 MICROPROCESSOR IN CIRCUIT The 8086 and 8088 microprocessors require some additional circuit to operate in a microcomputer system. For example, to fit in a 40-pin package, these processors multiplex the address and data buses on the same pins. So some demultiplexing logic is needed to build up separate address and data buses that can interface with devices like RAMs and ROMs. In fact, in Maximum Mode the 8086 or 8088 needs to be ed by at least the following devices: 8288 Bus Controller, 8284A Clock Generator as well as 74HC373 and 74HC245 devices. The block diagram is as follows:

Note that in Maximum mode, the 8288 uses a set of status signals (S0, S1, S2) to rebuild the normal bus control signals of the microprocessor (MRDC#, MWTC#, IORC#, IOWC# etc). We’ll just look at the function of a few 8086/8288 pins briefly: RESET: The processor reset input pin, clears the flags , segment s etc., sets the effective program address to FFFF0h (CS=FFFFh, IP=0000). BHE# (8086 only): Bus High Enable (BHE#) is used with the A0 signal to help interface the 16-bit data bus of the 8086 to byte-wide memory. The table shows how BHE# and A0 are used together:

ET4508/ED5532

Ciaran MacNamee / Karl Rinne

L4a-2

BHE# 0 0 1 1

A0 0 1 0 1

Selection Whole word (16-bits) High byte to/from odd address Low byte to/from even address No selection

This is how memory is accessed using these signals: Byte-Wide addressing (8088)

ODD Addresses (8086)

EVEN Addresses (8086)

FFFFF

FFFFF

FFFFE

FFFFE FFFFD FFFFC

FFFFD FFFFB FFFF9

FFFFC FFFFA FFFF8

A19..A1

00002 00001 00000

A19..A1

00005 00003 00001

00004 00002 00000

D15:D8

D7:D0

BHE#

A0

This scheme applies even when16-bit memories are used. It allows the 8086 to access byte data. Similar schemes allow 32-bit processors like the 80386 to access byte data.

ET4508/ED5532

Ciaran MacNamee / Karl Rinne

L4a-3

ALE (Address Latch Enable): On both the 8086 and 8088 processors the address and data buses are multiplexed. This means that the same pins are used to carry both address and data information – at different times during the read or write cycle. At the start of the cycle the address/data bus carries the address signals, while at the end of the cycle the pins are used for the data bus. The ALE signal is used to allow external logic to LATCH the addresses while the AD lines carry address data and hold those addresses so that they can be applied to the other devices in the system. The address latches used are 74HC373 or equivalent parts. Unlike a flip flop, the 74HC373 is a transparent latch. When its Latch Enable (LE) signal is high the 74HC373 outputs follow its inputs. When the LE signal goes low, the 74HC373 outputs hold the data that the inputs had prior to when the LE signal went low. The ALE signal is connected directly to the LE input of the 74HC373. The diagram below shows this: C lock

A ddress/ D ata Bus

A ddress Tim e

D ata Tim e

ALE

O utput of 74H C 373

Microcom puter A ddressBus

74HC 373 or equivalent

A ddress/ D ata Bus

In0:In7

A LE

Q0:Q7

S ystem Address B us

LE O E# TriState C ontrol signal, O E#, show n connected to GN D for sim plicity

The 8288 Bus Controller generate the DEN# and DT/R# signals that control the Enable and Direction Control inputs, respectively, of a 74HC245 bi-directional transceiver, which is placed between the processor’s address/data bus and the data bus of the microcomputer. Can you see why multiplexed address/data buses had to be abandoned in high performance Intel processors? 8086/8088 MEMORY AND I/O CYCLES The following figures show an 8086/8088 read, write and I/O cycles. Recall that microprocessors are clocked synchronous state machines, that is, they perform some action when they receive a clock edge. That’s why we show the clock signal in the following diagrams: the processor bus unit takes some action when the clock signal occurs.

ET4508/ED5532

Ciaran MacNamee / Karl Rinne

L4a-4

Bus Read Cycle (Memory or I/O) •

The 4 processor clock cycles are called T states. Four cycles is the shortest time that the processor can use for carrying out a read or an input cycle.

•

At the beginning of T1, the processor outputs S2, S1, S0, A16/S3…A19/S6, AD0..AD15 and BHE#/S7.

•

The 8288 bus controller transitions the ALE signal from low to high, thereby allowing the address to through the transparent latches (74HC373). The address, along with the BHE# signal is latched when ALE goes low, providing the latched address A0..A19.

•

During T2 the processor removes the address and data. S3..S6 status is output on the upper 4 address/status lines of the processor.

•

The AD0..AD15 signals are floated as inputs, waiting for data to be read.

•

Data bus transceivers (74HC245) are enabled towards the microprocessor (the READ direction) by the DT/R# and DEN signals.

•

The MRDC# (ie MEMR#) or IORC# (IOR#) signal is asserted.

•

The signals are maintained during T3. At the end of T3 the microprocessor samples the input data.

•

During T4 the memory and I/O control lines are de-asserted.

Bus Write Cycle (Memory or I/O) •

The 4 processor clock cycles are called T states. Four cycles is the shortest time that the processor can use for carrying out a write or an output cycle.

•

At the beginning of T1, the processor outputs S2, S1, S0, A16/S3…A19/S6, AD0..AD15 and BHE#/S7.

•

The 8288 bus controller transitions the ALE signal from low to high, thereby allowing the address to through the transparent latches (74HC373). The address, along with the BHE# signal is latched when ALE goes low, providing the latched address A0..A19.

•

During T2 the processor removes the address and data. S3..S6 status is output on the upper 4 address/status lines of the processor.

•

Output data is driven out on the AD0..AD15 lines.

•

Data bus transceivers (74HC245) are enabled away from the microprocessor (the WRITE direction) by the DT/R# and DEN signals.

•

The MWRC# (ie MEMW#) or IOWC# (IOW#) signal is asserted at the beginning of T3.

•

The signals are maintained during T3.

•

During T4 the memory and I/O control lines are de-asserted. In simple Intel Architecture systems, the data is usually written to the memory or output device at the rising edge of the MWRC# or IOWC# signal.

ET4508/ED5532

Ciaran MacNamee / Karl Rinne

L4a-5

Wait States Wait States are used to help interface to slow memory or I/O devices. The READY input signal on the 8086 is used to insert wait states into the processor bus cycle, so that the processor stretches out its read or write cycle, to accommodate the slow device. Generating Wait States The normal memory or I/O cycle on an 8086 is 4 clocks long – T1 to T4. Wait states , called Tw can be inserted in the bus cycle as follows: The 8086 READY line is sampled at the rising edge of T3. If READY is low, a WAUT state is inserted. During the WAIT state the READY is sampled again at the next rising edge of the clock, and another WAIT is inserted if READY is still low. A number of further WAIT states can be inserted in this way. The memory or I/O device can initiate WAIT state generation by bringing a RDY signal low. To synchronise the 8086 READY signal and to ensure that the 8086 timing requirements are met the memory device’s RDY signal is normally connected to the 8284’s RDY input. The memory device needs to bring RDY low prior to the rising edge of the 8086’s T2 clock. The 8284 drives the 8086 READY signal low at the falling edge of T2. When the 8086 samples READY at the rising of T3 it finds that it is low, and it inserts a WAIT state for the next clock state. The memory device has to bring RDY high early in T3 so that the 8284 can bring READY high before the rising edge of T3 if another WAIT state is to be avoided. The figure below shows a read or input cycle using WAIT states.
