Fire Protection to FM Global Standards FG-Sprinklerkonferansen 2016 Steve Plummer, Group Manager Field Engineering Nordic Region PUBLIC

FM Global

Overview  FM Global  Fire protection – Today’s challenges – Project handling – Nonstorage and storage applications

 New protection options

PUBLIC

FM Global

 Speciality focus  Mutuality  Engineering

PUBLIC

 Business risk consulting  Global delivery  FM Approvals

FM Global

Today's Challenges  Business is global  Supply chain risks are growing  Business is changing – – – –

Building design, larger and higher New storage solutions Increasing amounts of plastics Integration of operations

 Understanding the client’s operations and innovation in insurance coverage and engineering solutions are critical PUBLIC

FM Global

PUBLIC

FM Global

PUBLIC

FM Global

The Full Impact of Fires – Iceberg  Property & Business Interruption  Supply Chain

   

Community  Customers Environment  Market Share Life Safety Macro Economic  Reputation

PUBLIC

FM Global

Project Handling  What design and installation standard does the client (or other stakeholders) want to work to?  Nonstorage or Storage application? – Storage >20m2 or >1.5m high plastics or >3m ordinary combustibles, protect according to Data Sheet 8-9

 Occupancy specific data sheets; hydraulic or cutting oil, paper mills, woodworking, chemical plants, ignitable liquids etc PUBLIC

FM Global

Nonstorage Protection  FM Global Data Sheet 3-26 & 2-0  K80 sprinklers or water-mist is acceptable for HC-1 occupancy  Minimum K115 sprinklers in manufacturing areas (HC-2) – HC-3 occuancy, minimum K160 sprinklers – Ceiling heights >18 m, use K360 sprinklers

 Extended coverage (EC) heads allow sprinkler spacings up to 36 m2, but beware: – Ceiling slopes >10°and PUBLIC – Obstructed ceiling construction

FM Global

PUBLIC

FM Global

Obstructions - Nonstorage  Obstructions to sprinkler discharge  “Individual obstructions” ≥1.2m wide  Obstructions can only be considered an “individual obstruction” if less than 3 diameters apart  Spacing of sprinklers under non-flat obstructions should be 1.2m or install a flat barrier PUBLIC

FM Global

Storage Protection  Ceiling only or ceiling and in-rack sprinklers?  Ceiling Only – FM Global Data Sheets 8-9 & 2-0 – Storage sprinklers (“ESFR” or “large-drop”), large orifice quick response storage heads – Flexible and economic – FM Global standards require minimum K160 sprinklers for storage applications PUBLIC

FM Global

PUBLIC

FM Global

Storage Protection  Constraints of ceiling only protection – – – – –

Limited to 12 – 13.5m buildings Obstructions Lack of flue spaces Solid shelves Open top containers

 Must not stop water getting to seat of fire PUBLIC

FM Global

Storage Protection  Ceiling and in-rack automatic sprinklers (IRAS) – Can be used for any storage height – Very effective protection – suppression usually achieved – New options can keep water supply to the same size as for ceiling only

PUBLIC

FM Global

Storage Protection  In-rack sprinkler protection – Minimum K115 orifice heads, quick-response – Constraints • Heads need to be located in the correct position in the racks • Face sprinklers needed for some solutions • Need to be removed and reinstalled if racks are moved PUBLIC

FM Global

PUBLIC

FM Global

PUBLIC

FM Global

New storage protection options  Factory Mutual began testing sprinklers in 1884  In the past 30 years, the focus has been on developing ceiling sprinkler protection – FM Global began research into “large drop” sprinklers in the 1970s and “ESFR” sprinklers in the 1980s

PUBLIC

FM Global

New storage protection options  Most testing of in-rack sprinkler designs was done in the 1960s and 1970s using K80 and K115 heads  Research into “ESFR” in-racks began in the late 2000s  New protection options published in FM Global Data Sheet 8-9 in May 2015  Alternative in-rack sprinkler designs can be used for all commodities covered by Data Sheet 8-9 but must be open frame racks with adequate flue spaces (no solid shelves and no open top containers) PUBLIC

FM Global

K200 to K320 pendent sprinklers in the flue and face in every transverse flue (at uprights only for face sprinklers if no more than 2.6m apart)

PUBLIC

FM Global

New storage protection options  Vertical intervals of 9 m or 12 m  5 to 10 heads (5 in two adjacent rack) at 250 to 455 LPM/head  Treat top level of in-racks as the “floor” for the purposes of deg the ceiling system  Do not need to balance in-rack sprinklers with ceiling, nor for them flowing simultaneously  150 mm clearance needed from top of storage to sprinkler deflector PUBLIC

FM Global

Typical Layout for Uncartoned Plastics and Cartoned Expanded Plastics

PUBLIC

FM Global

Typical Layout for Cartoned Unexpanded Plastics and Lower Hazard Commodities

PUBLIC

FM Global

PUBLIC

FM Global

New storage protection options  Protection for unlimited building heights  Lower cost with far fewer levels of in-rack sprinklers (every 9m or 12m)  Reduced vulnerability to damage  Efficient fire control  Lower water demands  Reduced water usage and environmental impact PUBLIC

FM Global

Summary  FM Global  Fire protection – Today’s challenges – Project handling – Nonstorage and storage applications

 New protection options

PUBLIC

FM Global

Resources  www.fmglobaldatasheets.com  www.approvalguide.com  www.fmglobal.com

PUBLIC

FM Global

PUBLIC

FM Global

FM Global Seminar  Teknologisk Institutt Haugesund  1st – 2nd June – Ensuring Effective Sprinkler Installations: Deg and Installing Automatic Sprinkler Systems to FM Global Standards

PUBLIC

FM Global

Questions?
